├── 3-Splitting-CI-CD
    ├── CD
    │   ├── README.md
    │   ├── app
    │   │   ├── service.yaml
    │   │   └── deployment.yaml
    │   ├── artifact_version_update
    │   ├── Application.yaml
    │   └── Jenkinsfile
    └── CI
    │   ├── devops.html
    │   ├── artifact_version_update
    │   ├── k8s
    │       ├── manifests
    │       │   ├── service.yaml
    │       │   └── deployment.yaml
    │       └── Application.yaml
    │   ├── src
    │       └── main
    │       │   ├── java
    │       │       └── HelloWorld.java
    │       │   └── webapp
    │       │       └── WEB-INF
    │       │           └── web.xml
    │   ├── Dockerfile
    │   ├── install-tomcat-playbook.yml
    │   ├── deploy-playbook.yml
    │   ├── README.md
    │   ├── bluegreen-deployment.yaml
    │   ├── tomcat-users.xml
    │   ├── pom.xml
    │   ├── blue-green-playbook.yml
    │   └── Jenkinsfile
├── 1-apache-loadbalancer
    ├── apache_1
    │   ├── index1.html
    │   └── Dockerfile
    ├── apache_2
    │   ├── index2.html
    │   └── Dockerfile
    ├── haproxy
    │   ├── Dockerfile
    │   └── haproxy.cfg
    ├── docker-compose.yaml
    └── README.MD
├── 2-nginx-reverseproxy
    ├── app1
    │   ├── index.html
    │   ├── Dockerfile
    │   └── README.md
    ├── app2
    │   ├── index.html
    │   ├── Dockerfile
    │   └── README.md
    ├── reverse-proxy
    │   ├── index.html
    │   ├── Dockerfile
    │   └── default.conf
    ├── README.md
    └── docker-compose.yaml
└── README.md


/3-Splitting-CI-CD/CD/README.md:
--------------------------------------------------------------------------------
1 | #
2 | #Argo-CD
3 |


--------------------------------------------------------------------------------
/1-apache-loadbalancer/apache_1/index1.html:
--------------------------------------------------------------------------------
1 | Serving from Apache Server 1
2 |


--------------------------------------------------------------------------------
/1-apache-loadbalancer/apache_2/index2.html:
--------------------------------------------------------------------------------
1 | Serving from Apache Server 2
2 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/devops.html:
--------------------------------------------------------------------------------
1 | This is the Load Balanced health check file
2 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/app1/index.html:
--------------------------------------------------------------------------------
1 | <h1>Hello World!</h1>
2 |
3 | <p> App1 </p>
4 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/app2/index.html:
--------------------------------------------------------------------------------
1 | <h1>Hello World!</h1>
2 |
3 | <p> App2 </p>
4 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/app1/Dockerfile:
--------------------------------------------------------------------------------
1 | FROM nginx
2 | COPY ./index.html /usr/share/nginx/html/index.html
3 | EXPOSE 80
4 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/app2/Dockerfile:
--------------------------------------------------------------------------------
1 | FROM nginx
2 | COPY ./index.html /usr/share/nginx/html/index.html
3 | EXPOSE 80
4 |


--------------------------------------------------------------------------------
/1-apache-loadbalancer/apache_1/Dockerfile:
--------------------------------------------------------------------------------
1 | FROM httpd:2.4
2 |
3 | COPY index1.html /usr/local/apache2/htdocs/index.html
4 |


--------------------------------------------------------------------------------
/1-apache-loadbalancer/apache_2/Dockerfile:
--------------------------------------------------------------------------------
1 | FROM httpd:2.4
2 |
3 | COPY index2.html /usr/local/apache2/htdocs/index.html
4 |


--------------------------------------------------------------------------------
/1-apache-loadbalancer/haproxy/Dockerfile:
--------------------------------------------------------------------------------
1 | FROM haproxy:1.7
2 |
3 | COPY ./haproxy.cfg /usr/local/etc/haproxy/haproxy.cfg
4 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/artifact_version_update:
--------------------------------------------------------------------------------
1 | #!/bin/bash
2 | set -x
3 |
4 | COMMIT=`git rev-parse HEAD | cut -c -7`
5 | echo $COMMIT
6 | sed -E -i'' "s/(.*nightwolf:).*/\1${COMMIT}/" $1
7 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/reverse-proxy/index.html:
--------------------------------------------------------------------------------
1 | <html>
2 | <head>
3 | <title>DevOPs Area Project</title>
4 | </head>
5 | <body>
6 | <h1>Hello! This is the first reverse-proxy .</h1>
7 | </body>
8 | </html>
9 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CD/app/service.yaml:
--------------------------------------------------------------------------------
 1 | apiVersion: v1
 2 | kind: Service
 3 | metadata:
 4 |   name: nginx-service-1
 5 |   labels:
 6 |     app: tomcat
 7 | spec:
 8 |   type: LoadBalancer
 9 |   ports:
10 |   - port: 8080
11 |   selector:
12 |     app: tomcat
13 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/k8s/manifests/service.yaml:
--------------------------------------------------------------------------------
 1 | apiVersion: v1
 2 | kind: Service
 3 | metadata:
 4 |   name: nginx-service-1
 5 |   labels:
 6 |     app: tomcat
 7 | spec:
 8 |   type: LoadBalancer
 9 |   ports:
10 |   - port: 8080
11 |   selector:
12 |     app: tomcat
13 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CD/artifact_version_update:
--------------------------------------------------------------------------------
1 | #!/bin/bash
2 | set -x
3 |
4 | ##COMMIT=`git rev-parse HEAD | cut -c -7`
5 | ##echo $COMMIT
6 | echo $GIT_COMMIT_REV
7 | #sed -E -i'' "s/(.*nightwolf:).*/\1${COMMIT}/" $1
8 | sed -E -i'' "s/(.*nightwolf:).*/\1${GIT_COMMIT_REV}/" $1
9 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/README.md:
--------------------------------------------------------------------------------
 1 | # nginx-container-reverse-proxy
 2 | if you want to create a reserve proxy for docker containers
 3 |
 4 |
 5 | the goal of this project is to do reverse proxy:
 6 |
 7 | *  /app1 --> goes to the 1st microservice
 8 |
 9 | * /app2 --> goes to the 2nd microservice
10 |
11 | * / will go to the default index.html file
12 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/reverse-proxy/Dockerfile:
--------------------------------------------------------------------------------
 1 | #GET the base default nginx image from docker hub
 2 | FROM nginx
 3 |
 4 | #Delete the Existing default.conf
 5 | RUN rm /etc/nginx/conf.d/default.conf
 6 |
 7 | #Copy the custom default.conf to the nginx configuration
 8 | COPY default.conf /etc/nginx/conf.d
 9 | COPY ./index.html /usr/share/nginx/html/index.html
10 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/src/main/java/HelloWorld.java:
--------------------------------------------------------------------------------
 1 | import spark.servlet.SparkApplication;
 2 |
 3 | import static spark.Spark.get;
 4 |
 5 | public class HelloWorld implements SparkApplication {
 6 | 	public static void main(String[] args) {
 7 | 		new HelloWorld().init();
 8 | 	}
 9 |
10 | 	@Override
11 | 	public void init() {
12 | 		get("/", (req, res) -> "Final Project 26.12.2023!!!");
13 | 	}
14 | }
15 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/app1/README.md:
--------------------------------------------------------------------------------
 1 | # docker-nginx-sandbox
 2 | This is a sandbox to play with Nginx under docker container
 3 | and if you changed he message in index.html file you could see the changes after building the docker image and container form the Docker file like
 4 |
 5 | Today is 9th Augest
 6 |
 7 | #docker build -t testnginx .
 8 |
 9 | #docker run -d -p 80:80 testnginx
10 |
11 |
12 |
13 |
14 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/app2/README.md:
--------------------------------------------------------------------------------
 1 | # docker-nginx-sandbox
 2 | This is a sandbox to play with Nginx under docker container
 3 | and if you changed he message in index.html file you could see the changes after building the docker image and container form the Docker file like
 4 |
 5 | Today is 9th Augest
 6 |
 7 | #docker build -t testnginx .
 8 |
 9 | #docker run -d -p 80:80 testnginx
10 |
11 |
12 |
13 |
14 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/Dockerfile:
--------------------------------------------------------------------------------
 1 | FROM maven:3.5.2-jdk-8-alpine AS MAVEN
 2 | COPY pom.xml /tmp/
 3 | COPY src /tmp/src/
 4 | WORKDIR /tmp/
 5 | RUN mvn package
 6 |
 7 | FROM tomcat:9.0-jre8-alpine
 8 | WORKDIR $CATALINA_HOME/webapps/
 9 | COPY --from=MAVEN /tmp/target/*.war .
10 | RUN rm -rf ROOT && mv *.war ROOT.war
11 | ##HEALTHCHECK --interval=1m --timeout=3s CMD wget --quiet --tries=1 --spider http://localhost:8080/wizard/ || exit 1
12 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CD/app/deployment.yaml:
--------------------------------------------------------------------------------
 1 | apiVersion: apps/v1
 2 | kind: Deployment
 3 | metadata:
 4 |   name: tomcat-deployment
 5 | spec:
 6 |   selector:
 7 |     matchLabels:
 8 |       app: tomcat
 9 |   replicas: 2
10 |   template:
11 |     metadata:
12 |       labels:
13 |         app: tomcat
14 |     spec:
15 |       containers:
16 |       - name: tomcat
17 |         image: mzain/nightwolf:0494775
18 |         ports:
19 |         - containerPort: 8080
20 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/k8s/manifests/deployment.yaml:
--------------------------------------------------------------------------------
 1 | apiVersion: apps/v1
 2 | kind: Deployment
 3 | metadata:
 4 |   name: tomcat-deployment
 5 | spec:
 6 |   selector:
 7 |     matchLabels:
 8 |       app: tomcat
 9 |   replicas: 2
10 |   template:
11 |     metadata:
12 |       labels:
13 |         app: tomcat
14 |     spec:
15 |       containers:
16 |       - name: tomcat
17 |         image: mzain/nightwolf:0c8ed12
18 |         ports:
19 |         - containerPort: 8080
20 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/reverse-proxy/default.conf:
--------------------------------------------------------------------------------
 1 | server {
 2 |     listen       80;
 3 |     server_name  nginxserver;
 4 |
 5 |     location / {
 6 |          root   /usr/share/nginx/html;
 7 |          index  index.html index.htm;
 8 |     }
 9 |
10 |     location /app1 {
11 |          proxy_pass http://app1:80/;
12 |     }
13 |
14 |     location /app2 {
15 |          proxy_pass http://app2:80/;
16 |     }
17 |
18 |     location /devops {
19 |          proxy_pass http://devopsarea.com/;
20 |     }
21 |
22 |
23 |     error_page   500 502 503 504  /50x.html;
24 |     location = /50x.html {
25 |         root   /usr/share/nginx/html;
26 |     }
27 |
28 | }
29 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/k8s/Application.yaml:
--------------------------------------------------------------------------------
 1 | apiVersion: argoproj.io/v1alpha1
 2 | kind: Application
 3 | metadata:
 4 |   name: zein-app
 5 |   # You'll usually want to add your resources to the argocd namespace.
 6 |   namespace: argocd
 7 | spec:
 8 |   # The project the application belongs to.
 9 |   project: default
10 |
11 |   # Source of the application manifests
12 |   source:
13 |     repoURL: https://github.com/DevOps-Area/Projects.git
14 |     targetRevision: HEAD
15 |     path: k8s/
16 |   destination:
17 |     server: https://kubernetes.default.svc
18 |     namespace: prod
19 |
20 |   syncPolicy:
21 |     automated:
22 |       selfHeal: true
23 |       prune: true
24 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CD/Application.yaml:
--------------------------------------------------------------------------------
 1 | apiVersion: argoproj.io/v1alpha1
 2 | kind: Application
 3 | metadata:
 4 |   name: devopsarea-app
 5 |   # You'll usually want to add your resources to the argocd namespace.
 6 |   namespace: argocd
 7 | spec:
 8 |   # The project the application belongs to.
 9 |   project: default
10 |
11 |   # Source of the application manifests
12 |   source:
13 |     repoURL: https://github.com/zeineldin/Java-testapp-CD.git
14 |     targetRevision: HEAD
15 |     path: app/
16 |   destination:
17 |     server: https://kubernetes.default.svc
18 |     namespace: prod
19 |
20 |   syncPolicy:
21 |     automated:
22 |       selfHeal: true
23 |       prune: true
24 |


--------------------------------------------------------------------------------
/1-apache-loadbalancer/docker-compose.yaml:
--------------------------------------------------------------------------------
 1 | version: '3'
 2 |
 3 | services:
 4 |     apache_1:
 5 |         container_name: apache_1
 6 |         build: ./apache_1
 7 |         ports:
 8 |           - 6060:80
 9 |     apache_2:
10 |         container_name: apache_2
11 |         build: ./apache_2
12 |         ports:
13 |           - 7070:80
14 |         deploy:
15 |           resources:
16 |             limits:
17 |               cpus: 1
18 |               memory: 512M
19 |             reservations:
20 |               cpus: 0.5
21 |               memory: 256M
22 |
23 |     haproxy_img:
24 |         container_name: haproxy
25 |         build: ./haproxy
26 |         ports:
27 |           - 80:80
28 |


--------------------------------------------------------------------------------
/1-apache-loadbalancer/README.MD:
--------------------------------------------------------------------------------
 1 | ## Creating a single HAProxy and two Apache containers with Docker compose
 2 |
 3 | - In this porject  we will create  two identical Apache servers and one HAProxy container.
 4 |
 5 | - When we want to access our website, we will be calling HAProxy, not the Apache servers. HAProxy will divert traffic to Apache servers in "round-robin" fashion.
 6 |
 7 | 1. HTTP Request goes to HAProxy container.
 8 |
 9 | 2. HAProxy container goes  either Apache container 1 or 2.
10 |
11 | 3. Response is served by Apache container 1 or 2.
12 |
13 | - To test this use command
14 |
15 |  $ for in in {1..10} ; do echo "the working server is `curl -s http://127.0.0.1:90/`"; done
16 |
17 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/src/main/webapp/WEB-INF/web.xml:
--------------------------------------------------------------------------------
 1 | <web-app xmlns="http://java.sun.com/xml/ns/javaee"
 2 |          xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 3 |          xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd"
 4 |          version="3.0">
 5 |
 6 | 	<filter>
 7 | 		<filter-name>SparkFilter</filter-name>
 8 | 		<filter-class>spark.servlet.SparkFilter</filter-class>
 9 | 		<init-param>
10 | 			<param-name>applicationClass</param-name>
11 | 			<param-value>HelloWorld</param-value>
12 | 		</init-param>
13 | 	</filter>
14 |
15 | 	<filter-mapping>
16 | 		<filter-name>SparkFilter</filter-name>
17 | 		<url-pattern>/</url-pattern>
18 | 	</filter-mapping>
19 | </web-app>
20 |


--------------------------------------------------------------------------------
/1-apache-loadbalancer/haproxy/haproxy.cfg:
--------------------------------------------------------------------------------
 1 | global
 2 |     log /dev/log local0
 3 |     log localhost local1 notice
 4 |     maxconn 2000
 5 |     daemon
 6 |
 7 | defaults
 8 |     log global
 9 |     mode http
10 |     option httplog
11 |     option dontlognull
12 |     retries 3
13 |     timeout connect 5000
14 |     timeout client 50000
15 |     timeout server 50000
16 |
17 | frontend http-in
18 |     bind *:80
19 |     default_backend webservers
20 |
21 | backend webservers
22 |     stats enable
23 |     stats auth admin:admin
24 |     stats uri /haproxy?stats
25 |     balance roundrobin
26 |     option httpchk
27 |     option forwardfor
28 |     option http-server-close
29 |     server apache1 apache_1:80 check
30 |     server apache2 apache_2:80 check
31 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/install-tomcat-playbook.yml:
--------------------------------------------------------------------------------
 1 | ---
 2 | - hosts: web
 3 |   serial: 1
 4 |   become: yes
 5 |   become_method: sudo
 6 |
 7 |   tasks:
 8 |
 9 |    - name: Install Java
10 |      apt: name=default-jdk state=present
11 |
12 |    - name: Install Tomcat
13 |      apt: name=tomcat8 state=present
14 |
15 |    - name: Install Tomcat admin
16 |      apt: name=tomcat8-admin state=present
17 |
18 |    - name: Configure Tomcat users
19 |      copy:
20 |        src: tomcat-users.xml
21 |        dest: /etc/tomcat8/
22 |        owner: root
23 |        group: tomcat8
24 |        mode: 0640
25 |
26 |    - name: Start Tomcat
27 |      service:
28 |        name: tomcat8
29 |        state: started
30 |
31 |    - name: wait for tomcat to start
32 |      wait_for: port=8080
33 |
34 |


--------------------------------------------------------------------------------
/2-nginx-reverseproxy/docker-compose.yaml:
--------------------------------------------------------------------------------
 1 | version: '3'
 2 |
 3 | services:
 4 |   reverseproxy:
 5 |     build: ./reverse-proxy
 6 |     ports:
 7 |       - 80:80
 8 |     depends_on:
 9 |       - app1
10 |       - app2
11 |     container_name: reverse
12 |
13 |   app1:
14 |     build: ./app1
15 |     ports:
16 |       - 8080:80
17 |     container_name: app1
18 |     deploy:
19 |       resources:
20 |         limits:
21 |           cpus: '1'
22 |           memory: 512M
23 |         reservations:
24 |           cpus: '0.5'
25 |           memory: 256M
26 |
27 |   app2:
28 |     build: ./app2
29 |     ports:
30 |       - 9090:80
31 |     container_name: app2
32 |     deploy:
33 |       resources:
34 |         limits:
35 |           cpus: '1'
36 |           memory: 512M
37 |         reservations:
38 |           cpus: '0.5'
39 |           memory: 256M
40 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CD/Jenkinsfile:
--------------------------------------------------------------------------------
 1 | node {
 2 |     def app
 3 |
 4 |     stage('Clone repository') {
 5 |
 6 |
 7 |         checkout scm
 8 |     }
 9 |
10 |     stage('Update GIT') {
11 |             script {
12 |                 catchError(buildResult: 'SUCCESS', stageResult: 'FAILURE') {
13 |                     withCredentials([usernamePassword(credentialsId: 'github', passwordVariable: 'GIT_PASSWORD', usernameVariable: 'GIT_USERNAME')]) {
14 |                         //def encodedPassword = URLEncoder.encode("$GIT_PASSWORD",'UTF-8')
15 |                         sh "git config user.email eng.mohamed.zeineldin@gmail.com"
16 |                         sh "git config user.name zeineldin"
17 |                         //sh "git switch master"
18 |                         sh "cat app/deployment.yaml"
19 |                         sh "sh artifact_version_update app/deployment.yaml"
20 |                         sh "echo $GIT_COMMIT_REV"
21 |                         //sh "sed -E -i'' "s/(.*nightwolf:).*/\1${GIT_COMMIT_REV}/" app/deployment.yaml"
22 |                         sh "cat app/deployment.yaml"
23 |                         sh "git add ."
24 |                         sh "git commit -m 'Done by Jenkins Job changemanifest: ${env.BUILD_NUMBER}'"
25 |                         sh "git push https://${GIT_USERNAME}:${GIT_PASSWORD}@github.com/${GIT_USERNAME}/Java-testapp-CD/ HEAD:main"
26 |       }
27 |     }
28 |   }
29 | }
30 | }
31 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/deploy-playbook.yml:
--------------------------------------------------------------------------------
 1 | ---
 2 | - hosts: web
 3 |   serial: 1
 4 |   become: yes
 5 |   become_method: sudo
 6 |   #  vars:
 7 |   #  package_name: devopsarea-1.0.war
 8 |
 9 |   tasks:
10 |    - name: Install Java
11 |      apt: name=default-jdk state=present
12 |
13 |    - name: Install Tomcat
14 |      apt: name=tomcat8 state=present
15 |
16 |    - name: Install Tomcat admin
17 |      apt: name=tomcat8-admin state=present
18 |
19 |    - name: Configure Tomcat users
20 |      copy:
21 |        src: tomcat-users.xml
22 |        dest: /etc/tomcat8/
23 |        owner: root
24 |        group: tomcat8
25 |        mode: 640
26 |
27 |    - name: Stop the firewall
28 |      service:
29 |        name: ufw
30 |        state: stopped
31 |
32 | #   - name: restart tomcat
33 | #     service:
34 | #       name: tomcat8
35 | #       state: restarted
36 |
37 |
38 | #   - name: wait for tomcat to start
39 | #     wait_for: port=8080
40 | #   - name: Adding the healthcheck file
41 | #     copy:
42 | #       src: v1-devopsarea-1.0.war
43 | #       dest: /var/lib/tomcat8/webapps/ROOT/
44 |
45 |    - name: deploy the generated package to tomcat
46 |      copy:
47 |        src: ./target/v1-devopsarea-1.0.war
48 |        dest: /var/lib/tomcat8/webapps/
49 |        mode: 0777
50 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/README.md:
--------------------------------------------------------------------------------
 1 |
 2 |
 3 |
 4 | # DevOpsArea Sample Java App -example
 5 |
 6 | Build war with maven and DevOpsArea framework
 7 |
 8 | Steps are the following:
 9 |
10 | 1. Clone the repository to your local machine
11 | 2. The Dockerfile will do:
12 |
13 |         A. Create maven container <br />
14 |
15 |      * copy pom.xml to /tmp <br />
16 |      * copy folder "src" to /tmp/src <br />
17 |      * Go to /tmp folder then run "mvn package"<br />
18 |
19 |       The previos command will generate devopsarea-01.war<br />
20 |
21 |         B. Create tomcat container<br />
22 |
23 |      * Will move the file devopsarea-01.war from maven container to /webapp in tomcat contaner<br />
24 |      * Do health check to make sure that the artifact is deployed
25 |
26 | 3. Run 'docker build -t devopsarea .' <br />
27 |
28 |      * Will create a Docker image called devopsarea <br />
29 |
30 | 4. Run 'docker run -d -p 8080:8080 --name devopsarea-sample-java-app devopsarea' <br />
31 |      * Will create a container called devopsarea-sample-java-app and will forward the container internal port 8080 to locathost 8080 in the hosted machine
32 |
33 | 5. Open [http://localhost:8080/
34 | (http://localhost:8080/ in your browser and see the result.
35 |
36 | Note : if you will use ansible you could do the following command (Run command as user Ansible )
37 | # sudo runuser -l  ansible  -c 'ansible-playbook deploy-playbook.yml'
38 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/bluegreen-deployment.yaml:
--------------------------------------------------------------------------------
 1 | ---
 2 | - hosts: web
 3 |   serial: 1
 4 |   become: yes
 5 |   become_method: sudo
 6 |
 7 |   tasks:
 8 | #   - name: Stop Tomcat
 9 | #     service:
10 | #       name: tomcat8
11 | #       state: stopped
12 |
13 | #   - name: Waits for port 8080 of any IP to close active connections, don't start checking for 1 seconds
14 | #     wait_for:
15 | #       host: 0.0.0.0
16 | #       port: 8080
17 | #       delay: 1
18 | #       state: drained
19 |
20 | #  Remove the file to get out of the LoadBalancer
21 |    - file:
22 |        path: /var/lib/tomcat8/webapps/ROOT/devops.html
23 |        state: absent
24 |
25 | #   - name: Install Tomcat admin
26 | #     apt: name=tomcat8-admin state=present
27 |
28 | #   - name: Configure Tomcat users
29 | #     copy:
30 | #       src: tomcat-users.xml
31 | #       dest: /etc/tomcat8/
32 | #       owner: root
33 | #       group: tomcat8
34 | #       mode: 0640
35 |
36 |    - name: Start Tomcat
37 |      service:
38 |        name: tomcat8
39 |        state: started
40 |
41 |
42 |    - name: wait for tomcat to start
43 |      wait_for: port=8080
44 |
45 |    - name: deploy the generated package to tomcat
46 |      copy:
47 |        src: ./target/v1-devopsarea-1.0.war
48 |        #src: /var/lib/jenkins/workspace/Ansible/target/v1-devopsarea-1.0.war
49 |        dest: /var/lib/tomcat8/webapps/
50 |        mode: 0777
51 |
52 |    - pause:
53 |        seconds: 60
54 |
55 |    - name: Check that you can connect (GET) to a page and it returns a status 200
56 |      uri:
57 |        url: http://localhost:8080/v1-devopsarea-1.0
58 |
59 | #    Create the file to join LoadBalancer
60 |    - name: Adding the healthcheck file
61 |      copy:
62 |        src: devops.html
63 |        dest: /var/lib/tomcat8/webapps/ROOT/
64 |
65 |    - pause:
66 |        seconds: 10
67 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/tomcat-users.xml:
--------------------------------------------------------------------------------
 1 | <?xml version='1.0' encoding='utf-8'?>
 2 |
 3 | <!-- {{ ansible_managed }} -->
 4 |
 5 | <!--
 6 |   Licensed to the Apache Software Foundation (ASF) under one or more
 7 |   contributor license agreements.  See the NOTICE file distributed with
 8 |   this work for additional information regarding copyright ownership.
 9 |   The ASF licenses this file to You under the Apache License, Version 2.0
10 |   (the "License"); you may not use this file except in compliance with
11 |   the License.  You may obtain a copy of the License at
12 |       http://www.apache.org/licenses/LICENSE-2.0
13 |   Unless required by applicable law or agreed to in writing, software
14 |   distributed under the License is distributed on an "AS IS" BASIS,
15 |   WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
16 |   See the License for the specific language governing permissions and
17 |   limitations under the License..
18 | -->
19 | <tomcat-users>
20 | <!--
21 |   NOTE:  By default, no user is included in the "manager-gui" role required
22 |   to operate the "/manager/html" web application.  If you wish to use this app,
23 |   you must define such a user - the username and password are arbitrary.
24 | -->
25 | <!--
26 |   NOTE:  The sample user and role entries below are wrapped in a comment
27 |   and thus are ignored when reading this file. Do not forget to remove
28 |   <!.. ..> that surrounds them.
29 | -->
30 |
31 |   <user username="admin" password="DevOps" roles="manager-gui" />
32 |
33 | <!--
34 |   <role rolename="tomcat"/>
35 |   <role rolename="role1"/>
36 |   <user username="tomcat" password="tomcat" roles="tomcat"/>
37 |   <user username="both" password="tomcat" roles="tomcat,role1"/>
38 |   <user username="role1" password="tomcat" roles="role1"/>
39 | -->
40 |
41 | </tomcat-users>
42 |


--------------------------------------------------------------------------------
/README.md:
--------------------------------------------------------------------------------
 1 | #### <ins>Project 1 : Balancing the load using HAProxy and transferring traffic to two microservices</ins>.
 2 |
 3 | - In this project, we will learn how to balance the traffic load to more than microservices based on a simple Round-Robin.
 4 |
 5 | Example:
 6 |
 7 |   * Hit 1  → Forward to the 1st microservice.
 8 |
 9 |   * Hit 2 →  Forward to the 2nd microservice.
10 |
11 |
12 | #### <ins>You can see this Project in the Below Video</ins>.
13 | [![IMAGE ALT TEXT](http://img.youtube.com/vi/tPjTk6381G8/0.jpg)](http://www.youtube.com/watch?v=tPjTk6381G8 " Project:1  DevOps Project using HA Proxy Load-Balancer")
14 |
15 | ---
16 |
17 | #### <ins>Project 2: Reverse Proxy using (Two Dockerized Microservices and one Nginx container )</ins>.
18 |
19 |  - In this project, we will learn how to reverse proxy to two microservices
20 |
21 |  - Example:
22 |
23 |    /app1  → forward to the 1st microservice
24 |    /app2 → forward to the 2nd microservice
25 |
26 | #### <ins>You can see this Project in the Below Video</ins>.
27 | [![IMAGE ALT TEXT](http://img.youtube.com/vi/1gSKz7-ZaL8/0.jpg)](http://www.youtube.com/watch?v=1gSKz7-ZaL8 "Project:2 Reverse Proxy using Two Dockerized Microservices and one Nginx container ")
28 |
29 | ---
30 |
31 | #### <ins>Project 3: Separation between CI and CD is significant</ins>.
32 |
33 | -> Independent Changes (change the k8s replica number doesn't need a change in the code )
34 |
35 | * Same CI flow using Jenkins and GitHub Actions.
36 | * CI Repository: https://github.com/zeineldin/Java-tes...
37 | * CD Repository: https://github.com/zeineldin/Java-tes...
38 |
39 |  #### <ins>You can see this Project in the Below Video</ins>.
40 |
41 | [![IMAGE ALT TEXT](http://img.youtube.com/vi/0VHriqMjdlk/0.jpg)](http://www.youtube.com/watch?v=0VHriqMjdlk "Project:3 Separation between CI and CD is significant using Github-Jenkins-Docker-ArgoCD-K8s ")
42 |
43 |
44 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/pom.xml:
--------------------------------------------------------------------------------
 1 | <?xml version="1.0" encoding="UTF-8"?>
 2 | <project xmlns="http://maven.apache.org/POM/4.0.0"
 3 |          xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 4 |          xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
 5 | 	<modelVersion>4.0.0</modelVersion>
 6 |
 7 | 	<groupId>devops</groupId>
 8 | 	<artifactId>v1</artifactId>
 9 | 	<version>devopsarea-1.0</version>
10 | 	<packaging>war</packaging>
11 |         <dependencies>
12 | 		<dependency>
13 | 			<groupId>com.sparkjava</groupId>
14 | 			<artifactId>spark-core</artifactId>
15 | 			<version>2.7.2</version>
16 | 		</dependency>
17 | 	</dependencies>
18 |
19 | 	<build>
20 | 		<plugins>
21 | 			<plugin>
22 | 				<groupId>org.apache.maven.plugins</groupId>
23 | 				<artifactId>maven-compiler-plugin</artifactId>
24 | 				<version>3.1</version>
25 | 				<configuration>
26 | 					<source>1.8</source>
27 | 					<target>1.8</target>
28 | 					<optimize>true</optimize>
29 | 					<debug>true</debug>
30 | 				</configuration>
31 | 			</plugin>
32 |
33 |  <plugin>
34 |         <groupId>org.apache.maven.plugins</groupId>
35 |         <artifactId>maven-release-plugin</artifactId>
36 |         <version>3.0.0-M1</version>
37 |         <configuration>
38 |           <tagNameFormat>v@{project.version}</tagNameFormat>
39 |         </configuration>
40 |       </plugin>
41 |
42 |
43 | 			<plugin>
44 | 				<groupId>org.apache.maven.plugins</groupId>
45 | 				<artifactId>maven-enforcer-plugin</artifactId>
46 | 				<version>1.3.1</version>
47 | 				<executions>
48 | 					<execution>
49 | 						<id>enforce-java</id>
50 | 						<goals>
51 | 							<goal>enforce</goal>
52 | 						</goals>
53 | 						<configuration>
54 | 							<rules>
55 | 								<requireJavaVersion>
56 | 									<version>1.8</version>
57 | 								</requireJavaVersion>
58 | 							</rules>
59 | 						</configuration>
60 | 					</execution>
61 | 				</executions>
62 | 			</plugin>
63 | 		</plugins>
64 | 	</build>
65 | </project>
66 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/blue-green-playbook.yml:
--------------------------------------------------------------------------------
 1 | ---
 2 | - hosts: tomcat
 3 |   serial: 1
 4 |   become: yes
 5 |   become_method: sudo
 6 |
 7 |   tasks:
 8 |    - name: Stop Tomcat
 9 |      service:
10 |        name: tomcat8
11 |        state: stopped
12 |
13 |    - name: Waits for port 8080 of any IP to close active connections, don't start checking for 1 seconds
14 |      wait_for:
15 |        host: 0.0.0.0
16 |        port: 8080
17 |        delay: 1
18 |        state: drained
19 |
20 | #  Remove the file to get out of the LoadBalancer
21 |    - file:
22 |        path: /var/lib/tomcat8/webapps/ROOT/devops.html
23 |        state: absent
24 |
25 | #  - shell: rm /var/lib/tomcat8/webapps/ROOT/devops.html
26 |
27 | #   - name: Install Java
28 | #     apt: name=default-jdk state=present
29 |
30 | #   - name: Install Tomcat
31 | #     apt: name=tomcat8 state=present
32 |
33 |    - name: Install Tomcat admin
34 |      apt: name=tomcat8-admin state=present
35 |
36 |    - name: Configure Tomcat users
37 |      copy:
38 |        src: tomcat-users.xml
39 |        dest: /etc/tomcat8/
40 |        owner: root
41 |        group: tomcat8
42 |        mode: 0640
43 |
44 |
45 |
46 |    - name: Start Tomcat
47 |      service:
48 |        name: tomcat8
49 |        state: started
50 |
51 | #   - name: Stop the firewall
52 | #     service:
53 | #       name: ufw
54 | #       state: stopped
55 |
56 | #   - name: restart tomcat
57 | #     service:
58 | #       name: tomcat8
59 | #       state: restarted
60 |
61 |    - name: wait for tomcat to start
62 |      wait_for: port=8080
63 |
64 |    - name: deploy the generated package to tomcat
65 |      copy:
66 |        src: ./target/devopsarea-1.0.war
67 |        dest: /var/lib/tomcat8/webapps/
68 |        mode: 0777
69 |
70 |    - name: Check that you can connect (GET) to a page and it returns a status 200
71 |      uri:
72 |        url: http://localhost:8080/devopsarea-1.0
73 |
74 | #   - pause:
75 | #       seconds: 50
76 |
77 | #    Create the file to join LoadBalancer
78 |    - name: Adding the healthcheck file
79 |      copy:
80 |        src: devops.html
81 |        dest: /var/lib/tomcat8/webapps/ROOT/
82 |
83 | #   - shell: touch /var/lib/tomcat8/webapps/ROOT/devops.html
84 |


--------------------------------------------------------------------------------
/3-Splitting-CI-CD/CI/Jenkinsfile:
--------------------------------------------------------------------------------
 1 | pipeline {
 2 |     agent any
 3 |     environment {
 4 |         DOCKER_IMAGE_NAME = "mzain/nightwolf"
 5 |     }
 6 |
 7 |     stages {
 8 |       stage('Clone repository') {
 9 |         steps {
10 |         checkout scm
11 |     }
12 |       }
13 |
14 |
15 |      stage('Test and Build Docker Image') {
16 |          steps {
17 |          script {
18 |                     env.GIT_COMMIT_REV = sh (script: 'git log -n 1 --pretty=format:"%h"', returnStdout: true)
19 |                     customImage = docker.build("${DOCKER_IMAGE_NAME}:${GIT_COMMIT_REV}")
20 |                     }
21 |                     }
22 |      }
23 |      stage('Push Docker Image') {
24 |       steps {
25 |
26 |                 script {
27 |                     docker.withRegistry('https://registry.hub.docker.com', 'docker') {
28 |                         customImage.push("${GIT_COMMIT_REV}")
29 |                     //    customImage.push("latest")
30 |
31 |                     }
32 |                 }
33 |             }
34 |    }
35 |
36 |   //    stage('Update GIT') {
37 |    //    steps {
38 |     //   script {
39 |     //            catchError(buildResult: 'SUCCESS', stageResult: 'FAILURE') {
40 |      //               withCredentials([usernamePassword(credentialsId: 'github', passwordVariable: 'GIT_PASSWORD', usernameVariable: 'GIT_USERNAME')]) {
41 |                         //def encodedPassword = URLEncoder.encode("$GIT_PASSWORD",'UTF-8')
42 |      //                   sh "git config user.email eng.mohamed.zeineldin@gmail.com"
43 |       //                  sh "git config user.name zeineldin"
44 |                         //sh "git switch master"
45 |                         //sh "cd .."
46 |      //                   sh "rm -rf Java-testapp-CD"
47 |       //                  sh "git clone https://github.com/zeineldin/Java-testapp-CD.git"
48 |       //                  sh "cd Java-testapp-CD/"
49 |       //                  sh "pwd"
50 |             //            sh "cat app/deployment.yaml"
51 |            //             sh "sh artifact_version_update app/deployment.yaml"
52 |           //              sh "cat app/deployment.yaml"
53 |          //               sh "pwd"
54 |         //                sh "git add ."
55 |        //                 sh "git commit -m 'Done by Jenkins Job changemanifest: ${env.BUILD_NUMBER}'"
56 |        //                 sh "git push  https://${GIT_USERNAME}:${GIT_PASSWORD}@github.com/${GIT_USERNAME}/Java-testapp-CD.git HEAD:main"
57 |       //}
58 |       //}
59 |     //}
60 |
61 |         stage('Trigger CD job ') {
62 |                 steps {
63 |                 echo "triggering CD"
64 |                 build job: 'CD', parameters: [string(name: 'GIT_COMMIT_REV', value: env.GIT_COMMIT_REV)]
65 |         }
66 |         }
67 |
68 |   }
69 |  }
70 |
71 |


--------------------------------------------------------------------------------
