├── images
    ├── grafana.jpeg
    ├── influxdb.jpeg
    ├── web_log_anlyzst.jpg
    ├── structure_of_the_data.png
    └── nginx_log_processing_monitoring.png
├── .github
    └── ISSUE_TEMPLATE
    │   ├── custom.md
    │   ├── feature_request.md
    │   └── bug_report.md
├── .editorconfig
├── LICENSE
├── script
    ├── log_distribution.py
    ├── analyzer_threading.py
    └── analyzer_multiprocessing.py
├── .gitignore
└── README.md


/images/grafana.jpeg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/EscapeLife/web-log-analyst/HEAD/images/grafana.jpeg


--------------------------------------------------------------------------------
/images/influxdb.jpeg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/EscapeLife/web-log-analyst/HEAD/images/influxdb.jpeg


--------------------------------------------------------------------------------
/images/web_log_anlyzst.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/EscapeLife/web-log-analyst/HEAD/images/web_log_anlyzst.jpg


--------------------------------------------------------------------------------
/images/structure_of_the_data.png:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/EscapeLife/web-log-analyst/HEAD/images/structure_of_the_data.png


--------------------------------------------------------------------------------
/images/nginx_log_processing_monitoring.png:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/EscapeLife/web-log-analyst/HEAD/images/nginx_log_processing_monitoring.png


--------------------------------------------------------------------------------
/.github/ISSUE_TEMPLATE/custom.md:
--------------------------------------------------------------------------------
1 | ---
2 | name: Custom issue template
3 | about: Describe this issue template's purpose here.
4 |
5 | ---
6 |
7 |
8 |


--------------------------------------------------------------------------------
/.github/ISSUE_TEMPLATE/feature_request.md:
--------------------------------------------------------------------------------
 1 | ---
 2 | name: Feature request
 3 | about: Suggest an idea for this project
 4 |
 5 | ---
 6 |
 7 | **Is your feature request related to a problem? Please describe.**
 8 | A clear and concise description of what the problem is. Ex. I'm always frustrated when [...]
 9 |
10 | **Describe the solution you'd like**
11 | A clear and concise description of what you want to happen.
12 |
13 | **Describe alternatives you've considered**
14 | A clear and concise description of any alternative solutions or features you've considered.
15 |
16 | **Additional context**
17 | Add any other context or screenshots about the feature request here.
18 |


--------------------------------------------------------------------------------
/.editorconfig:
--------------------------------------------------------------------------------
 1 | # top-most EditorConfig file
 2 | root = true
 3 |
 4 | # setting for all files
 5 | [*]
 6 | # character set
 7 | charset = utf-8
 8 | # indented style
 9 | end_of_line = lf
10 | # whether to insert a blank line at the end of a file
11 | insert_final_newline = true
12 | # whether to delete the space at the end of a line
13 | trim_trailing_whitespace = false
14 |
15 | # python
16 | [*.py]
17 | indent_style = space
18 | indent_size = 4
19 |
20 | # shell
21 | [*.sh]
22 | indent_style = space
23 | indent_size = 4
24 |
25 | # javascript
26 | [*.js]
27 | indent_style = space
28 | indent_size = 2
29 |
30 | # makefile
31 | [*.md]
32 | indent_style = tab
33 |
34 | # json or .travis.yml
35 | [*.json]
36 | indent_style = space
37 | indent_size = 2
38 |
39 | # yml
40 | [*.yml}]
41 | indent_style = space
42 | indent_size = 2
43 |


--------------------------------------------------------------------------------
/.github/ISSUE_TEMPLATE/bug_report.md:
--------------------------------------------------------------------------------
 1 | ---
 2 | name: Bug report
 3 | about: Create a report to help us improve
 4 |
 5 | ---
 6 |
 7 | **Describe the bug**
 8 | A clear and concise description of what the bug is.
 9 |
10 | **To Reproduce**
11 | Steps to reproduce the behavior:
12 | 1. Go to '...'
13 | 2. Click on '....'
14 | 3. Scroll down to '....'
15 | 4. See error
16 |
17 | **Expected behavior**
18 | A clear and concise description of what you expected to happen.
19 |
20 | **Screenshots**
21 | If applicable, add screenshots to help explain your problem.
22 |
23 | **Desktop (please complete the following information):**
24 |  - OS: [e.g. iOS]
25 |  - Browser [e.g. chrome, safari]
26 |  - Version [e.g. 22]
27 |
28 | **Smartphone (please complete the following information):**
29 |  - Device: [e.g. iPhone6]
30 |  - OS: [e.g. iOS8.1]
31 |  - Browser [e.g. stock browser, safari]
32 |  - Version [e.g. 22]
33 |
34 | **Additional context**
35 | Add any other context about the problem here.
36 |


--------------------------------------------------------------------------------
/LICENSE:
--------------------------------------------------------------------------------
 1 | MIT License
 2 |
 3 | Copyright (c) 2017 Escape
 4 |
 5 | Permission is hereby granted, free of charge, to any person obtaining a copy
 6 | of this software and associated documentation files (the "Software"), to deal
 7 | in the Software without restriction, including without limitation the rights
 8 | to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
 9 | copies of the Software, and to permit persons to whom the Software is
10 | furnished to do so, subject to the following conditions:
11 |
12 | The above copyright notice and this permission notice shall be included in all
13 | copies or substantial portions of the Software.
14 |
15 | THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
16 | IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
17 | FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
18 | AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
19 | LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
20 | OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
21 | SOFTWARE.
22 |


--------------------------------------------------------------------------------
/script/log_distribution.py:
--------------------------------------------------------------------------------
 1 | import re
 2 | import random
 3 | import datetime
 4 | import threading
 5 |
 6 |
 7 | def read_log(path):
 8 |     with open(path) as f:
 9 |         for line in f:
10 |             yield line
11 |
12 |
13 | def parse(path):
14 |     o = re.compile(r'(?P<ip>\d{1,3}\.\d{1,3}\.\d{1,3}\.\d{1,3}) .* .* \[(?P<time>.*)\] "(?P<method>\w+) (?P<url>[^\s]*) (?P<version>[\w|/\.\d]*)" (?P<status>\d{3}) (?P<length>\d+) "(?P<referer>[^\s]*)" "(?P<ua>.*)"')
15 |     for line in read_log(path):
16 |         m = o.search(line.rstrip("\n"))
17 |         if m:
18 |             data = m.groupdict()
19 |             now = datetime.datetime.now()
20 |             data['time'] = now.strftime('%d/%b/%Y:%H:%M:%S %z')
21 |             yield data
22 |
23 |
24 | def data_source(event, src, *dst):
25 |     files = []
26 |     while not event.is_set():
27 |         for path in dst:
28 |             files.append(open(path, "a"))
29 |         for item in parse(src):
30 |             line = '{ip} - - [{time}] "{method} {url} {version}" {status} {length} "{referer}" "{ua}"\n'.format(**item)
31 |             f = random.choice(files)
32 |             f.write(line)
33 |             f.flush()
34 |             event.wait(0.001)
35 |     for f in files:
36 |         f.close()
37 |
38 |
39 | if __name__ == "__main__":
40 |     import sys
41 |
42 |     e = threading.Event()
43 |     try:
44 |         data_source(e, sys.argv[1], *sys.argv[2:])
45 |     except KeyboardInterrupt:
46 |         e.set()
47 |


--------------------------------------------------------------------------------
/script/analyzer_threading.py:
--------------------------------------------------------------------------------
 1 | import os
 2 | import re
 3 | import sys
 4 | import queue
 5 | import datetime
 6 | import threading
 7 | import requests
 8 |
 9 | compile = re.compile(r'(?P<ip>\d{1,3}\.\d{1,3}\.\d{1,3}\.\d{1,3}) .* .* \[(?P<time>.*)\] "(?P<method>\w+) (?P<url>[^\s]*) (?P<version>[\w|/\.\d]*)" (?P<status>\d{3}) (?P<length>\d+) "(?P<referer>[^\s]*)" "(?P<ua>.*)"')
10 | event = threading.Event()
11 |
12 |
13 | def read_log(q, path):
14 |     offset = 0
15 |     while not event.is_set():
16 |         with open(path) as f:
17 |             if offset > os.stat(path).st_size:
18 |                 offset = 0
19 |             f.seek(offset)
20 |             for line in f:
21 |                 q.put(line)
22 |             offset = f.tell()
23 |         event.wait(0.1)
24 |
25 |
26 | def read_worker(q, path):
27 |     t = threading.Thread(target=read_log, name='read-{}'.format(path), args=(q, path), daemon=True)
28 |     t.start()
29 |
30 |
31 | def parse(q):
32 |     while not event.is_set():
33 |         line = q.get()
34 |         search = compile.search(line.rstrip('\n'))
35 |         if search:
36 |             data = search.groupdict()
37 |             yield data
38 |
39 |
40 | def agg(q, interval=10):
41 |     count = 0
42 |     traffic = 0
43 |     error = 0
44 |     start = datetime.datetime.now()
45 |     for item in parse(q):
46 |         print(item)
47 |         count += 1
48 |         traffic += int(item['length'])
49 |         if int(item['status']) >= 300:
50 |             error += 1
51 |         current = datetime.datetime.now()
52 |         if (current - start).total_seconds() >= interval:
53 |             error_rate = error / count
54 |             send(count, traffic, error_rate)
55 |             start = current
56 |             count = 0
57 |             traffic = 0
58 |             error = 0
59 |
60 |
61 | def send(count, traffic, error_rate):
62 |     line = 'access_log count={},traffic={},error_rate={}'.format(count, traffic, error_rate)
63 |     res = requests.post('http://127.0.0.1:8086/write', data=line, params={'db': 'magedu'})
64 |     if res.status_code >= 300:
65 |         print(res.content)
66 |
67 |
68 | def manager(*paths):
69 |     q = queue.Queue()
70 |     for path in paths:
71 |         read_worker(q, path)
72 |     agg(q, 10)
73 |
74 | if __name__ == '__main__':
75 |     manager(*sys.argv[1:])
76 |


--------------------------------------------------------------------------------
