├── quantization ├── __init__.py ├── ptq │ ├── channel_wise_correction.py │ ├── onnx2trt_step04_ppq_training.py │ ├── onnx2trt_step01_merge_mean_scale.py │ ├── onnx2trt_step05_pdq_optimize.py │ ├── onnx2trt_step03_weight_equalization.py │ ├── onnx2trt_step02_remove_output_sigmoid.py │ ├── onnx2trt_step06_extra_pdq_init.py │ ├── onnx2trt_step07_extra_pdq_training.py │ ├── remove_inititalizers_from_inputs.py │ ├── filter_cache.py │ ├── trt_utils.py │ ├── remove_edge_logits_QDQ.py │ ├── data_loader.py │ ├── create_json_inputs.py │ ├── quantization_filter.py │ ├── P01_MT_onnx2tensorRT_int8.py │ └── ppq_optimize.py ├── README.md ├── ppq_optimize.py ├── calib_cache2json.py ├── calib_json2calib.py ├── onnx_optimize.py ├── fiter_scales.py ├── onnx_change_resize_mode.py ├── calib_merge_json2calib.py ├── calib_filter_Sigmoid.py ├── find_nodes_onnx.py ├── onnx_remove_split_qdq.py ├── json_filter.py ├── trt_calibrator.py ├── onnx_export_v2.py ├── onnx_export.py ├── onnx_move_qdq_relu_forward.py ├── onnx_remove_dup_qdqs.py ├── compare_trt_trt.py ├── onnx2trt_lsq.py ├── C03_compare_trt_fp32_int8.py ├── C02_compare_trt_fp32_int8.py ├── P02_MT_onnx2tensorRT_int8.py ├── onnx2tensorRT_adaround.py ├── P01_MT_onnx2tensorRT_int8.py ├── P01_MT_onnx2tensorRT_int8_sample.py ├── compare_onnx_trt_v3.py ├── onnx_calibrator.py ├── compare_onnx_onnx_v2.py ├── onnx2trt.py ├── P03_MT_onnx2tensorRT_int8.py ├── compare_onnx_onnx_v3.py ├── compare_onnx_trt_v1.py └── qat │ └── ppq_optimize.py ├── onnx_optimize ├── README.md ├── __init__.py ├── step05_fuse_repconvs.py ├── step04_extract_sub_graph.py ├── step01_export_torch_to_onnx.py ├── step02_onnx_simplify.py └── step03_fuse_normalize_to_conv.py ├── .vscode └── settings.json ├── prune ├── README_dev.md └── README.md ├── 01.install.md ├── README.md ├── trt_calibrator.py ├── onnx2trt.py └── onnx_calibrator.py /quantization/__init__.py: -------------------------------------------------------------------------------- 1 | -------------------------------------------------------------------------------- /quantization/ptq/channel_wise_correction.py: -------------------------------------------------------------------------------- 1 | # 调整 -------------------------------------------------------------------------------- /quantization/README.md: -------------------------------------------------------------------------------- 1 | 2 | 3 | # 量化流程 4 | 5 | 6 | 7 | 1. 简单量化 -------------------------------------------------------------------------------- /quantization/ppq_optimize.py: -------------------------------------------------------------------------------- 1 | 2 | 3 | # Step 01- 如果当前节点有多个后续节点，那么将QDQ移动到前面 -------------------------------------------------------------------------------- /quantization/ptq/onnx2trt_step04_ppq_training.py: -------------------------------------------------------------------------------- 1 | # 进行PPQ训练，获取好的结果 2 | 3 | -------------------------------------------------------------------------------- /quantization/ptq/onnx2trt_step01_merge_mean_scale.py: -------------------------------------------------------------------------------- 1 | # 将Step01的结果合入第一层Conv/或者强制添加一层1x1卷积 -------------------------------------------------------------------------------- /quantization/ptq/onnx2trt_step05_pdq_optimize.py: -------------------------------------------------------------------------------- 1 | # 对PPQ训练的模型，进行QDQ节点位置的调整优化 2 | 3 | -------------------------------------------------------------------------------- /quantization/ptq/onnx2trt_step03_weight_equalization.py: -------------------------------------------------------------------------------- 1 | # 连续的两个卷积层，进行输出部分的channel平衡(需要有输入数据) -------------------------------------------------------------------------------- /quantization/ptq/onnx2trt_step02_remove_output_sigmoid.py: -------------------------------------------------------------------------------- 1 | # 移除输出部分的sigmoid, reshape, transpose等结构 -------------------------------------------------------------------------------- /quantization/ptq/onnx2trt_step06_extra_pdq_init.py: -------------------------------------------------------------------------------- 1 | # 对PPQ训练的模型，添加部分QDQ节点，进一步优化QDQ模型的效果 2 | 3 | -------------------------------------------------------------------------------- /quantization/ptq/onnx2trt_step07_extra_pdq_training.py: -------------------------------------------------------------------------------- 1 | # 对PPQ训练的模型，添加部分QDQ节点，进一步优化QDQ模型的效果 2 | 3 | -------------------------------------------------------------------------------- /onnx_optimize/README.md: -------------------------------------------------------------------------------- 1 | ## onnx模型结构优化 2 | 3 | 4 | # 1 通用优化 5 | 6 | 7 | 8 | 9 | # 2. conv-bn merge 10 | 11 | 12 | 13 | 14 | # 3. normalize-conv merge -------------------------------------------------------------------------------- /.vscode/settings.json: -------------------------------------------------------------------------------- 1 | { 2 | "workbench.colorCustomizations": { 3 | "editor.lineHighlightBackground": "#1073cf2d", 4 | "editor.lineHighlightBorder": "#9fced11f", 5 | "activityBar.background": "#58024F", 6 | "titleBar.activeBackground": "#7B036E", 7 | "titleBar.activeForeground": "#FFF8FE" 8 | }, 9 | "python.formatting.provider": "black" 10 | } -------------------------------------------------------------------------------- /onnx_optimize/__init__.py: -------------------------------------------------------------------------------- 1 | from step01_export_torch_to_onnx import export_torch_to_onnx 2 | from step02_onnx_simplify import optimize_onnx_model 3 | from step03_fuse_normalize_to_conv import fuse_normalize_to_conv 4 | from step04_extract_sub_graph import extract_sub_graph 5 | 6 | __all__ = ["export_torch_to_onnx", 7 | "optimize_onnx_model", 8 | "fuse_normalize_to_conv", 9 | "extract_sub_graph", 10 | ] 11 | -------------------------------------------------------------------------------- /onnx_optimize/step05_fuse_repconvs.py: -------------------------------------------------------------------------------- 1 | import onnx 2 | 3 | 4 | def find_common_input(onnx_model, node): 5 | pass 6 | 7 | def fuse_repconvs(onnx_model): 8 | # Step 01: find rep convs 9 | for node in onnx_model.graph.node: 10 | if node.op_type == "Add": 11 | find_common_input(onnx_model, node) 12 | 13 | 14 | # step 02: merge rep conv weights 15 | 16 | 17 | # step 03: remove extra conv and bn nodes -------------------------------------------------------------------------------- /onnx_optimize/step04_extract_sub_graph.py: -------------------------------------------------------------------------------- 1 | import onnx 2 | 3 | 4 | def extract_sub_graph(input_path, output_path, input_names=None, output_names=None): 5 | onnx.utils.extract_model(input_path, output_path, input_names, output_names) 6 | 7 | 8 | if __name__ == "__main__": 9 | import sys 10 | 11 | input_path = sys.argv[1] 12 | output_path = sys.argv[2] 13 | input_names = ["input.1"] 14 | output_names = ["1080"] 15 | extract_sub_graph(input_path, output_path, input_names, output_names) 16 | -------------------------------------------------------------------------------- /quantization/calib_cache2json.py: -------------------------------------------------------------------------------- 1 | import sys 2 | import struct 3 | import json 4 | 5 | 6 | scale_map = {} 7 | with open(sys.argv[1]) as fr: 8 | for line in fr.readlines()[1:]: 9 | name, value = line.strip().split(":") 10 | if value.strip() == "0": 11 | val = 0.0 12 | else: 13 | val = struct.unpack("!f", bytes.fromhex(value.strip()))[0] 14 | 15 | scale_map[name] = val 16 | 17 | scale_map = {k: scale_map[k] for k in sorted(scale_map)} 18 | 19 | with open(".".join(sys.argv[1].split(".")[:-1]) + ".json", "w") as fw: 20 | json.dump(scale_map, fw, indent=4) 21 | -------------------------------------------------------------------------------- /quantization/calib_json2calib.py: -------------------------------------------------------------------------------- 1 | import sys 2 | import struct 3 | import json 4 | 5 | 6 | with open(sys.argv[1]) as fr: 7 | scale_map = json.load(fr) 8 | 9 | scale_map = {k: scale_map[k] for k in sorted(scale_map)} 10 | with open(".".join(sys.argv[1].split(".")[:-1]) + ".cache", "w") as file: 11 | file.write("TRT-8400-EntropyCalibration2\n") 12 | for key in sorted(scale_map.keys()): 13 | value = scale_map[key] 14 | scale = float(value) 15 | scale_hex = hex(struct.unpack(" 0.5: 18 | print(name, val) 19 | else: 20 | lines.append(line) 21 | 22 | with open(calib_cache + "_filter_scale05.calib_cache", "w") as fw: 23 | fw.writelines(lines) -------------------------------------------------------------------------------- /quantization/onnx_change_resize_mode.py: -------------------------------------------------------------------------------- 1 | import onnx 2 | import sys 3 | import onnxoptimizer 4 | from onnx import helper, shape_inference 5 | from onnxsim import simplify 6 | from onnx import numpy_helper 7 | import numpy as np 8 | 9 | onnx_model = onnx.load(sys.argv[1]) 10 | 11 | for node in onnx_model.graph.node: 12 | if node.op_type == "Resize": 13 | for attr in node.attribute: 14 | if (attr.name == "coordinate_transformation_mode"): 15 | attr.s = "half_pixel".encode("UTF-8") 16 | elif attr.name == "mode": 17 | attr.s = "linear".encode("UTF-8") 18 | elif attr.name == "nearest_mode": 19 | attr.s = "round_prefer_floor".encode("UTF-8") 20 | 21 | model_opt = onnxoptimizer.optimize(onnx_model) 22 | # model_simp, check = simplify(model_opt) 23 | model_simp = shape_inference.infer_shapes(model_opt) 24 | onnx.save(model_simp, sys.argv[2]) 25 | -------------------------------------------------------------------------------- /prune/README_dev.md: -------------------------------------------------------------------------------- 1 | 1. 剪枝概述 2 | 3 | 4 | 5 | 6 | 2. 常用工具 7 | 8 | - nni: 基于torch.fx，在某些复杂网络如nanodet上失效； 9 | - pytorch原生工具: 难以获取网络的拓扑结构，对于包含Concat等结构的网络剪枝困难； 10 | - torch.fx工具虽然提供了相关的功能，但是对于其中的shape计算、特殊算子等支持并不友好(其实是我太懒，不想新学一种表示) 11 | - 更简单的办法是，通过onnx作为中间层，使用onnx simpliier工具优化后，读取模型的拓扑结构； 12 | - 根据onnx模型中的拓扑结构，来进行结构化的剪枝；保存模型权重，输出模型结构； 13 | - 最后进行模型的finetune，输出最终的模型； 14 | - 问题: onnx会修改权重的名称，无法根据名称找到对应关系； 15 | - 解决方案: 16 | - 通过计算相似度等方式找到权重对应关系 ----> 设置training为True后，权重名称也得以与state_dict中一致 17 | - 通过设置export的training=True来避免Conv-BN融合 18 | - 问题: 对于Add、Concat、Channel Shuffle结构，需要进行针对性的识别和处理 ----> 复杂度较高 19 | - 解决方案: 20 | - 使用torch的hook机制，对特定类型的节点进行hook，从而获得每个op的mask 21 | - 然后根据mask的结果，对权重进行prune(整个流程可能跟nni中的torch.fx是一致的) 22 | - Add、Concat模块没办法直接进行Hook，需要使用自定义的module实现后才能完成hook功能 23 | - 为了便于后续的研究，将采用复杂的方案来进行剪枝；而不是每个模块设置一个prune函数 24 | 25 | 3. 剪枝工具开发 26 | - shufflenet剪枝: channel shuffle 27 | - FPN剪枝: Add层的处理 28 | 29 | 30 | 4. 实验记录 31 | 32 | - 方案一: 直接根据BN层的scale参数的l1-norm大小来剪枝 33 | - 方案二: 根据当前层的输出的l1-norm大小来剪枝 34 | - -------------------------------------------------------------------------------- /quantization/ptq/remove_inititalizers_from_inputs.py: -------------------------------------------------------------------------------- 1 | import argparse 2 | 3 | import onnx 4 | 5 | 6 | def get_args(): 7 | parser = argparse.ArgumentParser() 8 | parser.add_argument("--input", required=True, help="input model") 9 | parser.add_argument("--output", required=True, help="output model") 10 | args = parser.parse_args() 11 | return args 12 | 13 | 14 | def remove_initializer_from_input(): 15 | args = get_args() 16 | 17 | model = onnx.load(args.input) 18 | if model.ir_version < 4: 19 | print("Model with ir_version below 4 requires to include initilizer in graph input") 20 | return 21 | 22 | inputs = model.graph.input 23 | name_to_input = {} 24 | for input in inputs: 25 | name_to_input[input.name] = input 26 | 27 | for initializer in model.graph.initializer: 28 | if initializer.name in name_to_input: 29 | inputs.remove(name_to_input[initializer.name]) 30 | 31 | onnx.save(model, args.output) 32 | 33 | 34 | if __name__ == "__main__": 35 | remove_initializer_from_input() -------------------------------------------------------------------------------- /quantization/ptq/filter_cache.py: -------------------------------------------------------------------------------- 1 | from trt_utils import read_calib_cache 2 | from trt_utils import write_cache_to_json 3 | import onnx 4 | 5 | 6 | # 过滤掉不输入onnx节点的量化值，以及数字过大的量化值 7 | onnx_model = onnx.load("/mapai/howellyang/code/onnx2trt/RMTNet_release20220609_mm2conv.optimized.rm_inits.onnx") 8 | onnx_output_names = [] 9 | for node in onnx_model.graph.node: 10 | for o in node.output: 11 | onnx_output_names.append(o) 12 | 13 | scale_map = read_calib_cache("/mapai/howellyang/code/onnx2trt/RMTNet_release20220609_mm2conv.optimized.trt_int8_with_531pics_calib_percentile595.calib_cache") 14 | calib_cache = "/mapai/howellyang/code/onnx2trt/RMTNet_release20220609_mm2conv.optimized.trt_int8_with_531pics_calib_percentile595.filtered.calib_cache" 15 | 16 | scale_map = {k: scale_map[k] for k in sorted(scale_map)} 17 | with open(calib_cache, "w") as file: 18 | file.write("TRT-8400-EntropyCalibration2\n") 19 | for key in sorted(scale_map.keys()): 20 | value = scale_map[key] 21 | scale = float(value) 22 | scale_hex = hex(struct.unpack(" 转换容易失败 23 | same_name_map = {} 24 | for value, names in same_value_map.items(): 25 | if len(names) > 1: 26 | print(names) 27 | 28 | exit(0) 29 | 30 | scale_map_etp.update(scale_map_etp) 31 | 32 | 33 | with open(sys.argv[3], "w") as file: 34 | file.write("TRT-8400-EntropyCalibration2\n") 35 | for key in sorted(scale_map_etp.keys()): 36 | scale = scale_map_etp[key] 37 | # if scale > 0.5: 38 | # print("scale过大, 建议不量化:", key, scale, 128.0 * scale) 39 | # continue 40 | if len(key) > 5: 41 | print(key, scale) 42 | continue 43 | scale_hex = hex(struct.unpack("
6 | 7 | ### 1. 问题描述 8 | 9 | 常见的剪枝工具没有处理特殊结构的能力: 10 | - depthwise convolution: 普通卷积的权重的shape是[Co, Ci, Kw, Kh], 深度分离卷积的权重shape是[Co, 1, Kw, Kh]; 进行channel-wise剪枝时，需要根据前置节点的channel，决定当前节点的channel选择，并且决定了后置节点的输入channel的选择； 11 | 12 | - channel shuffle: 通道shuffle后的卷积的输入权重，剪枝通道要与通道shuffle前的通道对应上；需要识别不同卷积层之间的通道对应关系； 13 | 14 | - Add结构: 输入的多个卷积层，其剪枝的channel需要保持一致，否则将会出现Add的channel之间的不对应的问题； 15 | 16 | - Slice结构: slice前整个feature map的有效channel数是原模型的1/2，但是slice之后的两个feature map中有效channel数不是原来的1/2了；导致模型结构不符合预期； 17 | 18 |

19 | ### 2. 解决方案 20 | 21 | 放弃的解决方案： 22 | - 使用已有的nni等工具: 23 | - 基于torch.fx来识别不同模块之间的关联关系；然后开发对应的剪枝功能； 24 | - torch.fx会转换所有的表达式，粒度很细；学习成本有点高； 25 | - 使用onnx来获取拓扑结构： 26 | - onnx能够很简单的识别模块间的关联关系 27 | - onnx对于channel间的转换的识别能力不够(onnx无法单独设置每一层的输入) 28 | 29 | 30 | 最终选择的解决方案： 31 | - 使用torch的hook机制，自行构建mask和剪枝流程: 32 | - 首先，使用hook获取模块的id，用于后续构架关联关系 33 | - 其次，识别需要联合剪枝的模块(在这里主要是指Add) 34 | - 然后，构建剪枝用到的mask 35 | - 最后，对权重进行修改 36 | 37 | 38 | 特殊要素的处理: 39 | - depthwise convolution: 根据输入来决定输出channel的选择； 40 | - channel shuffle: 通过输出置零来实现需要剪枝的channel之间的传递； 41 | - add: 记录add相关的模块id，计算权重的均值来剪枝 42 | - slice: 针对shufflenet的结构，将channel划分为4组，分别进行channel选择； 43 | 44 |

45 | 46 | ### 3. 实际效果 47 | 48 | 剪枝工具开发 49 | - shufflenet剪枝: channel shuffle 50 | - FPN剪枝: Add层的处理 -------------------------------------------------------------------------------- /quantization/calib_filter_Sigmoid.py: -------------------------------------------------------------------------------- 1 | # 过滤掉calib_cache中的sigmoid层 2 | import sys 3 | import onnx 4 | 5 | onnx_model = onnx.load(sys.argv[1]) 6 | 7 | 8 | # Sigmoid\HardSigmoid 9 | sigmoid_inputs = [] 10 | sigmoid_outputs = [] 11 | 12 | add_inputs = [] 13 | add_outputs = [] 14 | 15 | for node in onnx_model.graph.node: 16 | if node.op_type in ["HardSigmoid", "Sigmoid"]: 17 | input_name = node.input[0] 18 | sigmoid_inputs.append(input_name) 19 | output_name = node.output[0] 20 | sigmoid_outputs.append(output_name) 21 | elif node.op_type in ["Mul", "Add", "Concat"]: 22 | input_name = node.input[0] 23 | add_inputs.append(input_name) 24 | input_name = node.input[1] 25 | add_inputs.append(input_name) 26 | 27 | output_name = node.output[0] 28 | add_outputs.append(output_name) 29 | 30 | # print(sigmoid_outputs) 31 | 32 | # 过滤Sigmoid的输出 33 | lines = [] 34 | total_sigmoids = 0 35 | total_nodes = 0 36 | with open(sys.argv[2]) as fr: 37 | for i, line in enumerate(fr.readlines()): 38 | if i == 0: 39 | lines.append(line) 40 | else: 41 | total_nodes += 1 42 | 43 | name, value = line.strip().split(":") 44 | name = name.strip(" ") 45 | if name in sigmoid_outputs or name in add_outputs or name in sigmoid_inputs or name in add_inputs: 46 | total_sigmoids += 1 47 | continue 48 | else: 49 | lines.append(line) 50 | 51 | 52 | print("total nodes", total_nodes) 53 | print("sigmoids ", total_sigmoids) 54 | print("final nodes", len(lines) - 1) 55 | 56 | with open(sys.argv[3], "w") as fw: 57 | fw.writelines(lines) -------------------------------------------------------------------------------- /01.install.md: -------------------------------------------------------------------------------- 1 | # onnx2trt 2 | 3 | 4 | 【DEPRECATED】 开发过程中，发现了一个整体思路与我这个repo类似，但功能更完善，且实现了一些高级算法的repo，建议使用这个repo来进行模型量化和部署； https://github.com/openppl-public/ppq 5 | 6 | 7 | 8 | onnx2trt是用于进行tensorRT的int8模型量化的工具; 在进行int8模型量化时，某些int8 tensorRT模型的精度会出现一定程度的下降。而当前tensorRT默认使用的校准算法是Entropy, 为此特意开发onnx2trt工具来优化量化模型的精度。 9 | 10 | 11 | 12 | ## 安装 13 | python36 (py37会遇到pycuda安装的问题) 14 | 15 | pip install nvidia-pyindex 16 | pip install nvidia-tensorrt 17 | pip install pycuda 18 | pip install sympy 19 | 20 | 21 | 22 | ## tensorRT量化存在的问题 23 | 24 | 1. 大模型的量化误差累积 25 | 在进行模型的量化校准时，通常的做法是先用fp32模型进行一遍infer，然后统计每个节点的动态范围。这样的做法简单快捷，做一遍infer即可得到整个模型所有节点的动态范围。 26 | 但是，当层数较多时，量化的误差会不断累积；距离模型输入越远，这种量化误差越大。 27 | 28 | 29 | 2. 量化后阈值偏移 30 | 当某个节点的输出数量比较小时，节点输出的cosine相似度已经很高，但是却出现了阈值偏移； 31 | 例如：fp32_out = [-6.223839, 3.5978181, -2.4270086], int8_out = [-2.37992859, 1.80094731, -1.93005347] 32 | 如果这个输出后接的是softmax结构的话，这种阈值偏移对最终精度的影响会比较小； 33 | 但是如果这里输出的是分数score的话，就会带来一些不利于实际部署的结果：例如recall降低，precision升高的变化；这时需要重新调整阈值来维持precision或者recall不变，以保证模型部署的效果。 34 | bias correction相关: https://zhuanlan.zhihu.com/p/450227567 35 | 36 | 37 | TODO: 38 | - [ ] QDQ量化工具: 使用QDQ方式进行tensorRT的模型量化. 39 | - image 40 | - 需要直到tensorRT做了哪些网络节点的优化，才能方便地插入QDQ节点； 41 | - [ ] 量化精度损失分析工具: 42 | - tensorRT自带量化分析工具polygraph: https://zhuanlan.zhihu.com/p/535021438 43 | - 分析流程示例：https://blog.csdn.net/TracelessLe/article/details/120656484 44 | - 给定每个节点的量化scale值，计算每一层的量化前后的cosine值. 45 | - 给定每个节点的量化scale值，计算这一层量化对最终输出的莲花cosine值. 46 | - [ ] 自定义scale计算工具/自定义calibrator: 47 | - 用于trt exec生成trt engine(隐式设置精度). 48 | - 用于QDQ生成trt engine(显式设置精度). 49 | 50 | -------------------------------------------------------------------------------- /quantization/find_nodes_onnx.py: -------------------------------------------------------------------------------- 1 | # 找出所有A-->B之间的节点 2 | from numpy import linspace 3 | import onnx 4 | 5 | # A = "8305" 6 | # B = "8527" 7 | # E = ["8302", "8305", "8530"] 8 | 9 | # A = "8835" 10 | # B = "8897" 11 | 12 | A = "8772" 13 | B = "8834" 14 | 15 | Final_Nodes = [A, B] 16 | 17 | input_path = "/apdcephfs/private_howellyang/onnx2trt/model.onnx" 18 | output_path = "/apdcephfs/private_howellyang/onnx2trt/model_{}_to_{}.onnx".format(A, B) 19 | calib_cache = "/apdcephfs/private_howellyang/onnx2trt/model.trt_int8_with_1578pics_calib_entropy.calib_cache" 20 | input_names = [A] 21 | output_names = [B] 22 | 23 | onnx.utils.extract_model(input_path, output_path, input_names, output_names) 24 | 25 | onnx_model = onnx.load(output_path) 26 | 27 | for node in onnx_model.graph.node: 28 | Final_Nodes.extend(node.output) 29 | # if node.op_type in ["QuantizeLinear"]: 30 | # act_name = node.input[0] 31 | # scale_name = node.input[1] 32 | # scale_value = scales_map[scale_name] 33 | # if act_name in weights_map: # 权重量化 34 | # if act_name not in weights_scale_map: 35 | # weights_scale_map[act_name] = [] 36 | 37 | # weights_scale_map[act_name].append(scale_value) 38 | # else: # act 量化 39 | # if act_name not in acts_scale_map: 40 | # acts_scale_map[act_name] = [] 41 | 42 | # acts_scale_map[act_name].append(scale_value) 43 | print(Final_Nodes) 44 | 45 | lines = [] 46 | with open(calib_cache) as fr: 47 | for i, line in enumerate(fr.readlines()): 48 | if i == 0: 49 | lines.append(line) 50 | else: 51 | node_name, hex_value = line.strip().split(":") 52 | if node_name in Final_Nodes: 53 | continue 54 | else: 55 | lines.append(line) 56 | 57 | with open(calib_cache + "_remove_{}_to_{}.calib_cache".format(A, B), "w") as fw: 58 | fw.writelines(lines) 59 | -------------------------------------------------------------------------------- /quantization/ptq/trt_utils.py: -------------------------------------------------------------------------------- 1 | 2 | 3 | import struct 4 | from matplotlib import scale 5 | import numpy as np 6 | 7 | def read_calib_cache(calib_cache): 8 | scale_map = {} 9 | with open(calib_cache) as fr: 10 | for line in fr.readlines()[1:]: 11 | name, value = line.strip().split(": ") 12 | name = name.strip(":") 13 | value = value.strip(":") 14 | if value.strip() == "0": 15 | val = 0.0 16 | else: 17 | val = struct.unpack("!f", bytes.fromhex(value.strip()))[0] 18 | 19 | scale_map[name] = val 20 | 21 | scale_map = {k: scale_map[k] for k in sorted(scale_map)} 22 | return scale_map 23 | 24 | 25 | def write_cache_to_json(scale_map, calib_cache): 26 | scale_map = {k: scale_map[k] for k in sorted(scale_map)} 27 | with open(calib_cache, "w") as file: 28 | file.write("TRT-8400-EntropyCalibration2\n") 29 | for key in sorted(scale_map.keys()): 30 | value = scale_map[key] 31 | scale = float(value) 32 | scale_hex = hex(struct.unpack(" np.ndarray: 47 | if x is None and not accepet_none: 48 | raise ValueError("Trying to convert an empty value.") 49 | if isinstance(x, np.ndarray): 50 | return x 51 | elif isinstance(x, int) or isinstance(x, float): 52 | return np.array( 53 | [ 54 | x, 55 | ] 56 | ) 57 | elif isinstance(x, torch.Tensor): 58 | if x.numel() == 0 and accepet_none: 59 | return None 60 | if x.numel() == 0 and not accepet_none: 61 | raise ValueError("Trying to convert an empty value.") 62 | if x.numel() == 1: 63 | return DataLoader.convert_any_to_numpy(x.detach().cpu().item()) 64 | if x.numel() > 1: 65 | return x.detach().cpu().numpy() 66 | elif isinstance(x, list) or isinstance(x, tuple): 67 | return np.array(x) 68 | else: 69 | raise TypeError( 70 | f"input value {x}({type(x)}) can not be converted as numpy type." 71 | ) 72 | 73 | 74 | def read_image(path): 75 | # 多任务模型 76 | _img_transforms = transforms.Compose( 77 | [ 78 | transforms.Resize((384, 768)), 79 | transforms.ToTensor(), 80 | transforms.Normalize((0.485, 0.456, 0.406), (0.229, 0.224, 0.225)), 81 | ] 82 | ) 83 | img = Image.open(path).convert("RGB") 84 | img_w, img_h = img.size[0], img.size[1] 85 | img = _img_transforms(img) 86 | img = img.unsqueeze(0) 87 | return img 88 | -------------------------------------------------------------------------------- /quantization/json_filter.py: -------------------------------------------------------------------------------- 1 | 2 | failed_tasks = { 3 | "code": 0, 4 | "msg": "", 5 | "detail": [ 6 | { 7 | "pkg_task_id": "999180333210000000161202285_null_210000000161202285", 8 | "status": -1, 9 | "status_landmark": 2, 10 | "status_land_line": 2, 11 | "status_scene": 2, 12 | "status_camera": 2, 13 | "status_traffic_light": -1, 14 | "status_img": -1 15 | }, 16 | { 17 | "pkg_task_id": "999180100210000000177231923_null_210000000177231923", 18 | "status": -1, 19 | "status_landmark": 2, 20 | "status_land_line": 2, 21 | "status_scene": 2, 22 | "status_camera": 2, 23 | "status_traffic_light": -1, 24 | "status_img": -1 25 | }, 26 | { 27 | "pkg_task_id": "999180203210000000161217375_null_210000000161217375", 28 | "status": -1, 29 | "status_landmark": 2, 30 | "status_land_line": 2, 31 | "status_scene": 2, 32 | "status_camera": 2, 33 | "status_traffic_light": -1, 34 | "status_img": -1 35 | }, 36 | { 37 | "pkg_task_id": "999180148210000000161242266_null_210000000161242266", 38 | "status": -1, 39 | "status_landmark": 2, 40 | "status_land_line": 2, 41 | "status_scene": 2, 42 | "status_camera": 2, 43 | "status_traffic_light": -1, 44 | "status_img": -1 45 | }, 46 | { 47 | "pkg_task_id": "999204618210000000161212957_null_210000000161212957", 48 | "status": -1, 49 | "status_landmark": 2, 50 | "status_land_line": 2, 51 | "status_scene": 2, 52 | "status_camera": 2, 53 | "status_traffic_light": -1, 54 | "status_img": -1 55 | }, 56 | { 57 | "pkg_task_id": "999195621210000000177226766_null_210000000177226766", 58 | "status": -1, 59 | "status_landmark": 2, 60 | "status_land_line": 2, 61 | "status_scene": 2, 62 | "status_camera": 2, 63 | "status_traffic_light": -1, 64 | "status_img": -1 65 | }, 66 | { 67 | "pkg_task_id": "999202427210000000161237174_null_210000000161237174", 68 | "status": -1, 69 | "status_landmark": 2, 70 | "status_land_line": 2, 71 | "status_scene": 2, 72 | "status_camera": 2, 73 | "status_traffic_light": -1, 74 | "status_img": -1 75 | }, 76 | { 77 | "pkg_task_id": "999202404210000000177220569_null_210000000177220569", 78 | "status": -1, 79 | "status_landmark": 2, 80 | "status_land_line": 2, 81 | "status_scene": 2, 82 | "status_camera": 2, 83 | "status_traffic_light": -1, 84 | "status_img": -1 85 | }, 86 | { 87 | "pkg_task_id": "999192126210000000177226943_null_210000000177226943", 88 | "status": -1, 89 | "status_landmark": 2, 90 | "status_land_line": 2, 91 | "status_scene": 2, 92 | "status_camera": 2, 93 | "status_traffic_light": -1, 94 | "status_img": -1 95 | }, 96 | { 97 | "pkg_task_id": "999194214210000000177357511_null_210000000177357511", 98 | "status": -1, 99 | "status_landmark": 2, 100 | "status_land_line": 2, 101 | "status_scene": 2, 102 | "status_camera": 2, 103 | "status_traffic_light": -1, 104 | "status_img": -1 105 | }, 106 | { 107 | "pkg_task_id": "999194403210000000177230387_null_210000000177230387", 108 | "status": -1, 109 | "status_landmark": 2, 110 | "status_land_line": 2, 111 | "status_scene": 2, 112 | "status_camera": 2, 113 | "status_traffic_light": -1, 114 | "status_img": -1 115 | } 116 | ], 117 | "detail_explain": "pkg_task_id,status,status_landmark,status_land_line,status_scene,status_camera,status_traffic_light,status_img" 118 | } 119 | 120 | for info in failed_tasks["detail"]: 121 | print('"{}"'.format(info["pkg_task_id"]), end = ",") 122 | 123 | print("\n"*4) -------------------------------------------------------------------------------- /onnx_optimize/step03_fuse_normalize_to_conv.py: -------------------------------------------------------------------------------- 1 | import onnx 2 | import numpy as np 3 | from onnx import numpy_helper 4 | from step02_onnx_simplify import get_post_nodes 5 | 6 | 7 | def fuse_normalize_to_conv(onnx_model, means, scales, input_tensor_name=None): 8 | # Y = (x - means)/scales 9 | initializer_names = [ 10 | initializer.name for initializer in onnx_model.graph.initializer 11 | ] 12 | inputs = [inp for inp in onnx_model.graph.input if inp not in initializer_names] 13 | if input_tensor_name is None: 14 | assert ( 15 | len(inputs) == 1 16 | ), "if multiple input exists, please specify input_tensor_name" 17 | input_tensor_name = inputs[0] 18 | 19 | weight_name2tensor = {} 20 | for weight in onnx_model.graph.initializer: 21 | weight_name2tensor[weight.name] = weight 22 | 23 | # find post nodes 24 | post_nodes = get_post_nodes(onnx_model, input_tensor_name) 25 | for post_node in post_nodes: 26 | if post_node.op_type != "Conv": 27 | raise NameError( 28 | "the input tensor is used by non-Conv node, normalize process can't be fused" 29 | ) 30 | 31 | paddings = [0] 32 | for attr in post_node.attribute: 33 | if attr.name == "pads": 34 | paddings = attr.ints 35 | break 36 | 37 | for pad in paddings: 38 | if pad != 0: 39 | raise NameError( 40 | "the conv after input has padding, normalize process can't be fused" 41 | ) 42 | 43 | group_num = 1 44 | for attr in post_node.attribute: 45 | if attr.name == "group": 46 | group_num = attr.i 47 | if group_num > 1: 48 | raise NameError( 49 | "the conv after input has group > 1, normalize process can't be fused" 50 | ) 51 | 52 | # fuse normalize-conv 53 | assert ( 54 | len(post_node.input) == 3 55 | ), " conv node must has bias for normalize fusion" 56 | weight_name = post_node.input[1] 57 | weight_tensor = weight_name2tensor[weight_name] 58 | weight_value = numpy_helper.to_array(weight_tensor) # out_ch, in_ch, ker, ker 59 | 60 | bias_name = post_node.input[2] 61 | bias_tensor = weight_name2tensor[bias_name] 62 | bias_value = numpy_helper.to_array(bias_tensor) # out_ch, in_ch, ker, ker 63 | 64 | assert ( 65 | len(means) == len(scales) == np.shape(weight_value)[1] 66 | ), "mean and scale value mismatch the input channel num" 67 | 68 | means = np.reshape(np.array(means), (1, -1, 1, 1)) 69 | scales = np.reshape(np.array(means), (1, -1, 1, 1)) 70 | 71 | new_weight_value = np.array(weight_value / scales).astype(np.float32) 72 | raw_shape = tuple([i for i in weight_tensor.dims]) 73 | new_shape = np.shape(new_weight_value) 74 | assert new_shape == raw_shape 75 | weight_tensor.ClearField("float_data") 76 | weight_tensor.ClearField("int32_data") 77 | weight_tensor.ClearField("int64_data") 78 | weight_tensor.raw_data = new_weight_value.tobytes() 79 | 80 | new_bias_value = np.array( 81 | bias_value - np.sum(weight_value * means / scales) 82 | ).astype(np.float32) 83 | raw_shape = tuple([i for i in bias_tensor.dims]) 84 | new_shape = np.shape(new_bias_value) 85 | assert new_shape == raw_shape 86 | bias_tensor.ClearField("float_data") 87 | bias_tensor.ClearField("int32_data") 88 | bias_tensor.ClearField("int64_data") 89 | bias_tensor.raw_data = new_bias_value.tobytes() 90 | 91 | return onnx_model 92 | 93 | 94 | if __name__ == "__main__": 95 | import sys 96 | 97 | onnx_model = onnx.load(sys.argv[1]) 98 | means = eval(sys.argv[2]) 99 | scales = eval(sys.argv[3]) 100 | onnx_model = fuse_normalize_to_conv(onnx_model, means, scales) 101 | -------------------------------------------------------------------------------- /quantization/ptq/create_json_inputs.py: -------------------------------------------------------------------------------- 1 | #!/usr/bin/python3 #指定解释器 2 | # encoding:utf-8 3 | 4 | import sys 5 | from polygraphy.json import save_json 6 | 7 | print(sys.getdefaultencoding()) 8 | s = "中文乱码问题解决" 9 | print(s) 10 | 11 | # --------------------------------------------------------------- 12 | # 这个脚本向你展示了如何使用 tensorRT 对 PPQ 导出的模型进行推理 13 | 14 | # This script shows you how to export ppq internal graph to tensorRT 15 | # --------------------------------------------------------------- 16 | 17 | # For this inference test, all test data is randomly picked. 18 | # If you want to use real data, just rewrite the defination of SAMPLES 19 | print("开始import") 20 | import onnxruntime 21 | import torch 22 | from tqdm import tqdm 23 | import glob 24 | import cv2 25 | import numpy as np 26 | from torchvision import transforms 27 | from PIL import Image 28 | import os 29 | from sklearn.metrics.pairwise import cosine_similarity 30 | import onnx 31 | from copy import deepcopy 32 | 33 | def convert_any_to_numpy(x, accepet_none: bool = True) -> np.ndarray: 34 | if x is None and not accepet_none: 35 | raise ValueError("Trying to convert an empty value.") 36 | if isinstance(x, np.ndarray): 37 | return x 38 | elif isinstance(x, int) or isinstance(x, float): 39 | return np.array( 40 | [ 41 | x, 42 | ] 43 | ) 44 | elif isinstance(x, torch.Tensor): 45 | if x.numel() == 0 and accepet_none: 46 | return None 47 | if x.numel() == 0 and not accepet_none: 48 | raise ValueError("Trying to convert an empty value.") 49 | if x.numel() == 1: 50 | return convert_any_to_numpy(x.detach().cpu().item()) 51 | if x.numel() > 1: 52 | return x.detach().cpu().numpy() 53 | elif isinstance(x, list) or isinstance(x, tuple): 54 | return np.array(x) 55 | else: 56 | raise TypeError( 57 | f"input value {x}({type(x)}) can not be converted as numpy type." 58 | ) 59 | 60 | def read_image(path): 61 | # 多任务模型 62 | _img_transforms = transforms.Compose( 63 | [ 64 | transforms.Resize((384, 768)), 65 | transforms.ToTensor(), 66 | transforms.Normalize((0.485, 0.456, 0.406), (0.229, 0.224, 0.225)), 67 | ] 68 | ) 69 | img = Image.open(path).convert("RGB") 70 | img_w, img_h = img.size[0], img.size[1] 71 | img = _img_transforms(img) 72 | img = img.unsqueeze(0) 73 | return img 74 | 75 | 76 | def read_image_v2(path): 77 | mean = [123.675, 116.28, 103.53] 78 | std = [58.395, 57.12, 57.375] 79 | input_w = 960 80 | input_h = 480 81 | mean = np.array(mean) 82 | std = np.array(std) 83 | img = cv2.imread(path) 84 | img = cv2.resize(img, (input_w, input_h)) 85 | img = img.astype(np.float32) 86 | img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB) 87 | 88 | # Norm 89 | for i in range(3): 90 | img[..., i] = (img[..., i] - mean[i]) / std[i] 91 | 92 | # hwc -> nchw ----> 这里输入方式不对 93 | # h, w, c = img.shape 94 | # img = img.reshape((1, c, h ,w)) 95 | img = np.transpose(img, (2, 0, 1)).astype(np.float32) 96 | img = np.expand_dims(img, axis=0) 97 | return np.ascontiguousarray(img, dtype=np.float32) 98 | 99 | calibration_files = glob.glob( 100 | os.path.join("/mapai/howellyang/code/road-service/road_service/calib_images/", "*.jpg") 101 | )[:1] 102 | 103 | 104 | SAMPLES = [ 105 | read_image_v2(path) for path in calibration_files 106 | ] # rewirte this to use real data. 107 | 108 | # List[Dict[str, numpy.ndarray]] 109 | import json 110 | from json import JSONEncoder 111 | import numpy 112 | class NumpyArrayEncoder(JSONEncoder): 113 | def default(self, obj): 114 | if isinstance(obj, numpy.ndarray): 115 | return obj.tolist() 116 | return JSONEncoder.default(self, obj) 117 | 118 | feed_dict_list = [{"input.1": np.array(read_image_v2(path))} for path in calibration_files] 119 | 120 | 121 | save_json(feed_dict_list, "calibration_data_1k5.json") 122 | 123 | # with open( ,"w") as fw: 124 | # json.dump(feed_dict_list, fw, cls=NumpyArrayEncoder, indent=4) 125 | # # encodedNumpyData = json.dumps(feed_dict_list, cls=NumpyArrayEncoder) -------------------------------------------------------------------------------- /README.md: -------------------------------------------------------------------------------- 1 | # ONNX2TRT: 端上模型部署[整理中] 2 | 3 | 4 | ## 1. 概述 5 | 6 | 模型的压缩(蒸馏、剪枝、量化)和部署，是模型在自动驾驶和物联网产业落地中的重要步骤。端上的设备 7 | 8 | 在实际工作过程中，我们遇到了很多的困难: 文档缺失、依赖库冲突、算子不支持、精度差、速度慢等。 9 | 10 | 因此，我将我在实际工作过程中的一些经验，整理成文档记录在这里，供其它开发者参考。同时，我会将过程中用到的一些脚本，整理成一些独立的工具脚本，方便大家使用。 11 | 12 |
13 | 14 | ## 2. 模型部署流程 15 | 16 | 模型部署的一般步骤为: 17 | - 模型导出onnx 18 | - onnx模型结构优化 19 | - 模型量化，构建tensorRT的engine 20 | - tensorRT模型部署 21 | - 精度和速度测试 22 | - 问题排查与分析 23 | 24 | 接下来，我将给出相关的工具，并对其中的关键步骤进行详细说明； 25 | 26 |
27 | 28 | ### 2.1 模型导出 29 | onnx是一种模型表示方式，能够将不同框架下的模型，统一表示为同一种形式；因此，尝尝被用来作为模型转换的中间节点；目前，tensorRT已经支持了直接用torch转成tensorRT的engine；但是其它的SDK框架，如MNN、TNN、Paddle-Lite、OpenVino等仍然只支持onnx格式的模型转换；并且，onnx本身也是一种很好用的模型框架，可以很方便地在上面做开发； 30 | 31 | ``` 32 | import torch 33 | # 加载你的模型 34 | model = build_model(config.model) 35 | checkpoint = torch.load(model_path, map_location=lambda storage, loc: storage) 36 | load_model_weight(model, checkpoint) 37 | 38 | # 设置输入的大小 39 | input_shape = (320, 192) # W H 40 | dummy_input = torch.autograd.Variable(torch.randn(1, 3, input_shape[1],input_shape[0])) # N, C, H, W 41 | 42 | # 设置输出节点名称，便于后续部署 43 | output_names = ["s8_cls", "s8_reg", "s16_cls", "s16_reg"] 44 | model.eval() 45 | torch.onnx.export( 46 | model, 47 | dummy_input, 48 | output_path, 49 | verbose=True, 50 | keep_initializers_as_inputs=False, 51 | do_constant_folding=True, 52 | training=False, 53 | opset_version=11, 54 | output_names=output_names, 55 | ) 56 | 57 | ``` 58 | 59 | 其它常用框架基本都有导出为onnx模型的代码，可以通过搜索引擎很容易得到相关结果，在此不作介绍。 60 | 61 | 导出模型为onnx以后，如果不需要做模型量化，可以直接将onnx模型转换为所需的格式后进行模型部署；如果想快速完成部署，可以使用在线模型转换的工具来完成模型转换 https://convertmodel.com/； 62 | 63 |
64 | 65 | ### 2.2 onnx模型结构优化 ### 66 | 67 | onnx模型结构优化，一方面是为后续的模型量化做准备；另一方面是减少了输入和输出部分的计算，这部分计算对云端的算力而言可能是无关紧要的，但是对端上的微弱算力而言，这部分计算能省则省。 68 | 69 |
