9 | 10 | ## Level set topology optimization in Firedrake 🚧 🚧 (in progress) 11 | 12 | LeToP implements the level set method in topology optimization. 13 | It combines the automated calculation of shape derivatives in [Firedrake](https://gitlab.com/florian.feppon/null-space-optimizer) and [pyadjoint](https://github.com/dolfin-adjoint/pyadjoint) with the [Null space optimizer](https://gitlab.com/florian.feppon/null-space-optimizer) to find the optimal design. The level set in advected with a Hamilton-Jacobi equation and properly reinitialized to maintain the signed distance property. 14 | 15 | The user interface is very close to pyadjoint to allow for easy compatibility. 16 | 17 | # Installation 18 | 19 | Install with 20 | 21 | ```python 22 | pip3 install . 23 | ``` 24 | at the project's root directory and with the Firedrake's virtual environment activated. 25 | LeTop depends on the [10.5281/zenodo.7017917](https://zenodo.org/record/7017917#.Y4YXbLLMKK0), which can be simply installed by passing the flag `--doi 10.5281/zenodo.7017917` to `firedrake-install`. 26 | 27 | ## Installation issues 28 | ``` 29 | src/C/umfpack.c:23:10: fatal error: 'umfpack.h' file not found 30 | ``` 31 | The package `cvxopt` cannot find the suitesparse library, which should be within PETSc (check the option `--download-suitesparse` was passed). Create the following environment variables before installing `letop`: 32 | ``` 33 | export CVXOPT_SUITESPARSE_LIB_DIR=$PETSC_DIR/$PETSC_ARCH/lib 34 | export CVXOPT_SUITESPARSE_INC_DIR=$PETSC_DIR/$PETSC_ARCH/include 35 | ``` 36 | 37 | # Examples 38 | ## Cantilever 39 | 40 | ![cantilever](https://media.giphy.com/media/eWze54pzWhoBiiJDmK/giphy.gif) 41 | 42 | ## Heat exchanger 43 | 44 | ![heat_exchanger_3D](https://user-images.githubusercontent.com/7770764/139540221-8195f162-3850-4939-b116-e466fdb9d8b5.gif) 45 | 46 | ## Bridge 47 | 48 | ![bridge](https://user-images.githubusercontent.com/7770764/139540289-b7daff65-5c98-4828-8a07-445aab79b7bb.gif) 49 | 50 | 51 | 52 | LLNL Release Number: LLNL-CODE-817098 53 | 54 | ## Considerations when using LeToP 55 | 56 | Make use of the pyadjoint context manager `stop_annotating()` and the decorator `no_annotations` for: 57 | 58 | - When using `interpolate()` or `project` from Firedrake as they might annotate unnecessary operations and result in wrong the shape derivatives. 59 | - Similarly, when extending LeToP routines, make sure you are not annotating additional operations as Firedrake annotates everything by default when importing `firedrake_adjoint`. 60 | - The shape velocities should be zeroed on the Dirichlet and Neumann boundaries. Use the `RegularizationSolver` boundary conditions to this effect. 61 | - Add fd.parameters["form_compiler"]["quadrature_degree"] = 4 to ensure quadrature does not go too high due to the heaviside function (used to mark the subdomains) 62 | - The isocontours of the level set must have enough mesh resolution, otherwise the reinitialization solver might fail. 63 | -------------------------------------------------------------------------------- /docker/Dockerfile: -------------------------------------------------------------------------------- 1 | FROM firedrakeproject/firedrake-env:latest 2 | 3 | # This DockerFile is looked after by 4 | MAINTAINER Miguel Salazar 5 | USER root 6 | 7 | RUN apt-get update && apt-get install -y wget libglu1 libxcursor-dev libxinerama1 8 | RUN pip3 install meshio[all] pygmsh 9 | USER firedrake 10 | WORKDIR /home/firedrake 11 | 12 | # Now install Firedrake. 13 | RUN curl -O https://raw.githubusercontent.com/firedrakeproject/firedrake/master/scripts/firedrake-install 14 | RUN bash -c "python3 firedrake-install --no-package-manager --disable-ssh --remove-build-files --pip-install scipy --doi 10.5281/zenodo.5526481" 15 | -------------------------------------------------------------------------------- /letop/__about__.py: -------------------------------------------------------------------------------- 1 | # -*- coding: utf-8 -*- 2 | # 3 | 4 | __author__ = u"Miguel Salazar de Troya" 5 | __email__ = "salazardetro1@llnl.gov" 6 | __copyright__ = u"Copyright (c) 2019 {} <{}>".format(__author__, __email__) 7 | __license__ = "License :: OSI Approved :: MIT License" 8 | __version__ = "0.0.1" 9 | __status__ = "Development Status :: 4 - Beta" 10 | -------------------------------------------------------------------------------- /letop/__init__.py: -------------------------------------------------------------------------------- 1 | # -*- coding: utf-8 -*- 2 | # 3 | from .__about__ import ( 4 | __author__, 5 | __email__, 6 | __license__, 7 | __status__, 8 | __version__, 9 | ) 10 | 11 | __all__ = [ 12 | "__author__", 13 | "__email__", 14 | "__license__", 15 | "__version__", 16 | "__status__", 17 | ] 18 | -------------------------------------------------------------------------------- /letop/levelset/__init__.py: -------------------------------------------------------------------------------- 1 | from .level_set_functional import LevelSetFunctional 2 | from .regularization_solver import RegularizationSolver 3 | -------------------------------------------------------------------------------- /letop/levelset/level_set_functional.py: -------------------------------------------------------------------------------- 1 | from pyadjoint.drivers import compute_gradient, compute_hessian 2 | from pyadjoint.enlisting import Enlist 3 | from pyadjoint.tape import get_working_tape, stop_annotating, no_annotations 4 | from pyadjoint import Control, AdjFloat 5 | 6 | 7 | class LevelSetFunctional(object): 8 | """Class representing a Lagrangian that depends on a level set 9 | 10 | This class is based of pyadjoint.ReducedFunctional and shares many functionalities. 11 | The motivation is to calculate shape derivatives when we evolve a level set. 12 | 13 | Args: 14 | functional (:obj:`OverloadedType`): An instance of an OverloadedType, 15 | usually :class:`AdjFloat`. This should be the return value of the 16 | functional you want to reduce. 17 | controls (list[Control]): A list of Control instances, which you want 18 | to map to the functional. It is also possible to supply a single Control 19 | instance instead of a list. 20 | """ 21 | 22 | def __init__( 23 | self, 24 | functional, 25 | controls, 26 | level_set, 27 | scale=1.0, 28 | tape=None, 29 | eval_cb_pre=lambda *args: None, 30 | eval_cb_post=lambda *args: None, 31 | derivative_cb_pre=lambda *args: None, 32 | derivative_cb_post=lambda *args: None, 33 | hessian_cb_pre=lambda *args: None, 34 | hessian_cb_post=lambda *args: None, 35 | ): 36 | self.functional = functional 37 | self.cost_function = self.functional 38 | self.tape = get_working_tape() if tape is None else tape 39 | self.controls = Enlist(controls) 40 | self.level_set = Enlist(level_set) 41 | self.scale = scale 42 | self.eval_cb_pre = eval_cb_pre 43 | self.eval_cb_post = eval_cb_post 44 | self.derivative_cb_pre = derivative_cb_pre 45 | self.derivative_cb_post = derivative_cb_post 46 | self.hessian_cb_pre = hessian_cb_pre 47 | self.hessian_cb_post = hessian_cb_post 48 | 49 | # TODO Check that the level set is in the tape. 50 | # Actually, not even pyadjoint checks if the given Control is in the 51 | # tape. 52 | 53 | def derivative(self, options={}): 54 | """Returns the derivative of the functional w.r.t. the control. 55 | 56 | Using the adjoint method, the derivative of the functional with 57 | respect to the control, around the last supplied value of the control, 58 | is computed and returned. 59 | 60 | Args: 61 | options (dict): A dictionary of options. To find a list of available options 62 | have a look at the specific control type. 63 | 64 | Returns: 65 | OverloadedType: The derivative with respect to the control. 66 | Should be an instance of the same type as the control. 67 | 68 | """ 69 | # Call callback 70 | self.derivative_cb_pre(self.level_set) 71 | 72 | derivatives = compute_gradient( 73 | self.functional, 74 | self.controls, 75 | options=options, 76 | tape=self.tape, 77 | adj_value=self.scale, 78 | ) 79 | 80 | # Call callback 81 | self.derivative_cb_post( 82 | self.functional.block_variable.checkpoint, 83 | self.level_set.delist(derivatives), 84 | self.level_set, 85 | ) 86 | 87 | return self.level_set.delist(derivatives) 88 | 89 | @no_annotations 90 | def hessian(self, m_dot, options={}): 91 | """Returns the action of the Hessian of the functional w.r.t. the control on a vector m_dot. 92 | 93 | Using the second-order adjoint method, the action of the Hessian of the 94 | functional with respect to the control, around the last supplied value 95 | of the control, is computed and returned. 96 | 97 | Args: 98 | m_dot ([OverloadedType]): The direction in which to compute the 99 | action of the Hessian. 100 | options (dict): A dictionary of options. To find a list of 101 | available options have a look at the specific control type. 102 | 103 | Returns: 104 | OverloadedType: The action of the Hessian in the direction m_dot. 105 | Should be an instance of the same type as the control. 106 | """ 107 | # Call callback 108 | self.hessian_cb_pre(self.level_set) 109 | 110 | r = compute_hessian( 111 | self.functional, 112 | self.controls, 113 | m_dot, 114 | options=options, 115 | tape=self.tape, 116 | ) 117 | 118 | # Call callback 119 | self.hessian_cb_post( 120 | self.functional.block_variable.checkpoint, 121 | self.level_set.delist(r), 122 | self.level_set, 123 | ) 124 | 125 | return self.level_set.delist(r) 126 | 127 | @no_annotations 128 | def __call__(self, values): 129 | """Computes the reduced functional with supplied control value. 130 | 131 | Args: 132 | values ([OverloadedType]): If you have multiple controls this should be a list of 133 | new values for each control in the order you listed the controls to the constructor. 134 | If you have a single control it can either be a list or a single object. 135 | Each new value should have the same type as the corresponding control. 136 | 137 | If values has a len(ufl_shape) > 0, we are in a Taylor test and we are updating 138 | self.controls 139 | If values has ufl_shape = (), it is a level set. 140 | 141 | Returns: 142 | :obj:`OverloadedType`: The computed value. Typically of instance 143 | of :class:`AdjFloat`. 144 | 145 | """ 146 | values = Enlist(values) 147 | if len(values) != len(self.level_set): 148 | raise ValueError( 149 | "values should be a list of same length as level sets." 150 | ) 151 | 152 | # Call callback. 153 | self.eval_cb_pre(self.level_set.delist(values)) 154 | 155 | # TODO Is there a better way to do this? 156 | if len(values[0].ufl_shape) > 0: 157 | for i, value in enumerate(values): 158 | self.controls[i].update(value) 159 | else: 160 | for i, value in enumerate(values): 161 | self.level_set[i].block_variable.checkpoint = value 162 | 163 | self.tape.reset_blocks() 164 | blocks = self.tape.get_blocks() 165 | with self.marked_controls(): 166 | with stop_annotating(): 167 | for i in range(len(blocks)): 168 | blocks[i].recompute() 169 | 170 | func_value = self.scale * self.functional.block_variable.checkpoint 171 | 172 | # Call callback 173 | self.eval_cb_post(func_value, self.level_set.delist(values)) 174 | 175 | return func_value 176 | 177 | # TODO fix this to avoid deleting the level set 178 | def optimize_tape(self): 179 | self.tape.optimize( 180 | controls=self.controls + self.level_set, 181 | functionals=[self.functional], 182 | ) 183 | 184 | def marked_controls(self): 185 | return marked_controls(self) 186 | 187 | 188 | class marked_controls(object): 189 | def __init__(self, rf): 190 | self.rf = rf 191 | 192 | def __enter__(self): 193 | for control in self.rf.controls: 194 | control.mark_as_control() 195 | 196 | def __exit__(self, *args): 197 | for control in self.rf.controls: 198 | control.unmark_as_control() 199 | -------------------------------------------------------------------------------- /letop/levelset/regularization_solver.py: -------------------------------------------------------------------------------- 1 | from firedrake import ( 2 | LinearVariationalSolver, 3 | LinearVariationalProblem, 4 | FacetNormal, 5 | VectorElement, 6 | FunctionSpace, 7 | Function, 8 | Constant, 9 | TrialFunction, 10 | TestFunction, 11 | assemble, 12 | solve, 13 | par_loop, 14 | DirichletBC, 15 | WRITE, 16 | READ, 17 | RW, 18 | File, 19 | warning, 20 | ) 21 | from pyadjoint.enlisting import Enlist 22 | from pyadjoint import no_annotations 23 | from firedrake.mesh import ExtrudedMeshTopology 24 | from letop.physics import min_mesh_size 25 | 26 | from ufl import grad, inner, dot, dx, ds 27 | from ufl import ds_b, ds_t, ds_tb, ds_v 28 | 29 | 30 | direct_parameters = { 31 | "mat_type": "aij", 32 | "ksp_type": "preonly", 33 | "pc_type": "lu", 34 | "pc_factor_mat_solver_type": "mumps", 35 | } 36 | 37 | iterative_parameters = { 38 | "mat_type": "aij", 39 | "ksp_type": "cg", 40 | "pc_type": "hypre", 41 | "pc_hypre_type": "boomeramg", 42 | "pc_hypre_boomeramg_max_iter": 200, 43 | "pc_hypre_boomeramg_coarsen_type": "HMIS", 44 | "pc_hypre_boomeramg_agg_nl": 1, 45 | "pc_hypre_boomeramg_strong_threshold": 0.7, 46 | "pc_hypre_boomeramg_interp_type": "ext+i", 47 | "pc_hypre_boomeramg_P_max": 4, 48 | "pc_hypre_boomeramg_relax_type_all": "sequential-Gauss-Seidel", 49 | "pc_hypre_boomeramg_grid_sweeps_all": 1, 50 | "pc_hypre_boomeramg_max_levels": 15, 51 | "ksp_monitor_true_residual": None, 52 | } 53 | 54 | 55 | class RegularizationSolver(object): 56 | @no_annotations 57 | def __init__( 58 | self, 59 | S, 60 | mesh, 61 | beta=1, 62 | gamma=1.0e4, 63 | bcs=None, 64 | dx=dx, 65 | design_domain=None, 66 | solver_parameters=direct_parameters, 67 | output_dir="./", 68 | ): 69 | """ 70 | Solver class to regularize the shape derivatives as explained in 71 | Frédéric de Gournay 72 | Velocity Extension for the Level-set Method and Multiple Eigenvalues in Shape Optimization 73 | SIAM J. Control Optim., 45(1), 343–367. (25 pages) 74 | Args: 75 | S ([type]): Function space of the mesh coordinates 76 | mesh ([type]): Mesh 77 | beta ([type], optional): Regularization parameter. 78 | It should be finite multiple of the mesh size. 79 | Defaults to 1. 80 | gamma ([type], optional): Penalty parameter for the penalization of the normal components 81 | of the regularized shape derivatives on the boundary. Defaults to 1.0e4. 82 | bcs ([type], optional): Dirichlet Boundary conditions. 83 | They should be setting the regularized shape derivatives to zero 84 | wherever there are boundary conditions on the original PDE. 85 | Defaults to None. 86 | dx ([type], optional): [description]. Defaults to dx. 87 | design_domain ([type], optional): If we're interested in setting the shape derivatives to 88 | zero outside of the design_domain, 89 | we pass design_domain marker. 90 | This is convenient when we want to fix certain regions in the domain. 91 | Defaults to None. 92 | solver_parameters ([type], optional): Solver options. Defaults to direct_parameters. 93 | output_dir (str, optional): Plot the output somewhere. Defaults to "./". 94 | """ 95 | n = FacetNormal(mesh) 96 | theta, xi = [TrialFunction(S), TestFunction(S)] 97 | self.xi = xi 98 | 99 | hmin = min_mesh_size(mesh) 100 | if beta > 20.0 * hmin: 101 | warning( 102 | f"Length scale parameter beta ({beta}) is much larger than the mesh size {hmin}" 103 | ) 104 | 105 | self.beta_param = Constant(beta) 106 | 107 | self.a = ( 108 | self.beta_param * inner(grad(theta), grad(xi)) + inner(theta, xi) 109 | ) * (dx) 110 | if isinstance(mesh.topology, ExtrudedMeshTopology): 111 | ds_reg = ds_b + ds_v + ds_tb + ds_t 112 | else: 113 | ds_reg = ds 114 | self.a += Constant(gamma) * (inner(dot(theta, n), dot(xi, n))) * ds_reg 115 | 116 | # Dirichlet boundary conditions equal to zero for regions where we want 117 | # the domain to be static, i.e. zero velocities 118 | 119 | if bcs is None: 120 | self.bcs = [] 121 | else: 122 | self.bcs = Enlist(bcs) 123 | if design_domain is not None: 124 | # Heaviside step function in domain of interest 125 | V_DG0_B = FunctionSpace(mesh, "DG", 0) 126 | I_B = Function(V_DG0_B) 127 | I_B.assign(1.0) 128 | # Set to zero all the cells within sim_domain 129 | par_loop( 130 | ("{[i] : 0 <= i < f.dofs}", "f[i, 0] = 0.0"), 131 | dx(design_domain), 132 | {"f": (I_B, WRITE)}, 133 | is_loopy_kernel=True, 134 | ) 135 | 136 | I_cg_B = Function(S) 137 | dim = S.mesh().geometric_dimension() 138 | # Assume that `A` is a :class:`.Function` in CG1 and `B` is a 139 | # `.Function` in DG0. Then the following code sets each DoF in 140 | # `A` to the maximum value that `B` attains in the cells adjacent to 141 | # that DoF:: 142 | par_loop( 143 | ( 144 | "{{[i, j] : 0 <= i < A.dofs and 0 <= j < {0} }}".format( 145 | dim 146 | ), 147 | "A[i, j] = fmax(A[i, j], B[0, 0])", 148 | ), 149 | dx, 150 | {"A": (I_cg_B, RW), "B": (I_B, READ)}, 151 | is_loopy_kernel=True, 152 | ) 153 | 154 | import numpy as np 155 | 156 | class MyBC(DirichletBC): 157 | def __init__(self, V, value, markers): 158 | # Call superclass init 159 | # We provide a dummy subdomain id. 160 | super(MyBC, self).__init__(V, value, 0) 161 | # Override the "nodes" property which says where the boundary 162 | # condition is to be applied. 163 | self.nodes = np.unique( 164 | np.where(markers.dat.data_ro_with_halos > 0)[0] 165 | ) 166 | 167 | self.bcs.append(MyBC(S, 0, I_cg_B)) 168 | 169 | self.Av = assemble(self.a, bcs=self.bcs) 170 | 171 | self.solver_parameters = solver_parameters 172 | 173 | @no_annotations 174 | def solve(self, velocity, dJ): 175 | """Solve the problem 176 | 177 | Args: 178 | velocity ([type]): Solution. velocity means regularized shape derivatives 179 | dJ ([type]): Shape derivatives to be regularized 180 | """ 181 | for bc in self.bcs: 182 | bc.apply(dJ) 183 | 184 | solve( 185 | self.Av, 186 | velocity.vector(), 187 | dJ, 188 | options_prefix="reg_solver", 189 | solver_parameters=self.solver_parameters, 190 | ) 191 | -------------------------------------------------------------------------------- /letop/optimization/__init__.py: -------------------------------------------------------------------------------- 1 | from .cg_hj_solver import HamiltonJacobiCGSolver 2 | from .cg_reinit_solver import ReinitSolverCG 3 | from .interface import InfDimProblem, Constraint 4 | from .nullspace_shape import nlspace_solve 5 | from .utils import read_checkpoint, is_checkpoint 6 | -------------------------------------------------------------------------------- /letop/optimization/cg_hj_solver.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | import firedrake_ts as fdts 3 | from letop.physics import AdvectionDiffusionGLS 4 | from typing import Union, List, Callable 5 | 6 | 7 | def HamiltonJacobiCGSolver( 8 | V: fd.FunctionSpace, 9 | theta: fd.Function, 10 | phi: fd.Function, 11 | t_end: float = 5000.0, 12 | bcs: Union[fd.DirichletBC, List[fd.DirichletBC]] = None, 13 | monitor_callback: Callable = None, 14 | solver_parameters=None, 15 | pre_jacobian_callback=None, 16 | post_jacobian_callback=None, 17 | pre_function_callback=None, 18 | post_function_callback=None, 19 | ) -> fdts.DAESolver: 20 | """Builds the solver for the advection-diffusion equation (Hamilton-Jacobi in the context of 21 | topology optimization) which is used to advect the level set) 22 | 23 | Args: 24 | V (fd.FunctionSpace): Function space of the level set 25 | theta (fd.Function): Velocity function 26 | phi (fd.Function): Level set 27 | t_end (float, optional): Max time of simulation. Defaults to 5000.0. 28 | bcs (Union[fd.DirichletBC, List[fd.DirichletBC]], optional): BC for the equation. Defaults to None. 29 | monitor_callback (Callable, optional): Monitor function called each time step. Defaults to None. 30 | solver_parameters ([type], optional): Solver options. Defaults to None. 31 | :kwarg pre_jacobian_callback: A user-defined function that will 32 | be called immediately before Jacobian assembly. This can 33 | be used, for example, to update a coefficient function 34 | that has a complicated dependence on the unknown solution. 35 | :kwarg pre_function_callback: As above, but called immediately 36 | before residual assembly. 37 | :kwarg post_jacobian_callback: As above, but called after the 38 | Jacobian has been assembled. 39 | :kwarg post_function_callback: As above, but called immediately 40 | after residual assembly. 41 | 42 | 43 | Returns: 44 | fdts.DAESolver: DAESolver configured to solve the advection-diffusion equation 45 | """ 46 | 47 | default_peclet_inv = 1e-4 48 | if solver_parameters: 49 | PeInv = solver_parameters.get("peclet_number", default_peclet_inv) 50 | else: 51 | PeInv = default_peclet_inv 52 | 53 | phi_t = fd.Function(V) 54 | # Galerkin residual 55 | F = AdvectionDiffusionGLS(V, theta, phi, PeInv=PeInv, phi_t=phi_t) 56 | 57 | problem = fdts.DAEProblem(F, phi, phi_t, (0.0, t_end), bcs=bcs) 58 | parameters = { 59 | "ts_type": "rosw", 60 | "ts_rows_type": "2m", 61 | "ts_adapt_type": "dsp", 62 | "ts_exact_final_time": "matchstep", 63 | "ts_atol": 1e-7, 64 | "ts_rtol": 1e-7, 65 | "ksp_type": "preonly", 66 | "pc_type": "lu", 67 | "pc_factor_mat_solver_type": "mumps", 68 | } 69 | if solver_parameters: 70 | parameters.update(solver_parameters) 71 | 72 | return fdts.DAESolver( 73 | problem, 74 | solver_parameters=parameters, 75 | monitor_callback=monitor_callback, 76 | pre_function_callback=pre_function_callback, 77 | post_function_callback=post_function_callback, 78 | pre_jacobian_callback=pre_jacobian_callback, 79 | post_jacobian_callback=post_jacobian_callback, 80 | ) 81 | -------------------------------------------------------------------------------- /letop/optimization/cg_reinit_solver.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from firedrake import inner, sqrt, grad, dx, conditional, le 3 | from pyop2 import READ, RW 4 | import numpy as np 5 | from pyadjoint import no_annotations 6 | 7 | 8 | class BCOut(fd.DirichletBC): 9 | def __init__(self, V, value, markers): 10 | super(BCOut, self).__init__(V, value, 0) 11 | self.nodes = np.unique( 12 | np.where(markers.dat.data_ro_with_halos == 0)[0] 13 | ) 14 | 15 | 16 | class BCInt(fd.DirichletBC): 17 | def __init__(self, V, value, markers): 18 | super(BCInt, self).__init__(V, value, 0) 19 | self.nodes = np.unique( 20 | np.where(markers.dat.data_ro_with_halos != 0)[0] 21 | ) 22 | 23 | 24 | class ReinitSolverCG: 25 | def __init__(self, phi: fd.Function, solver_parameters=None) -> None: 26 | """Reinitialization solver. Returns the level set 27 | to a signed distance function 28 | 29 | Args: 30 | V (fd.FunctionSpace): Function space of the level set 31 | """ 32 | V = phi.function_space() 33 | self.V = V 34 | self.phi = phi 35 | self.mesh = V.ufl_domain() 36 | self.DG0 = fd.FunctionSpace(self.mesh, "DG", 0) 37 | 38 | rho, sigma = fd.TrialFunction(V), fd.TestFunction(V) 39 | a = rho * sigma * dx 40 | self.phi_int = fd.Function(V) 41 | self.A_proj = fd.assemble(a) 42 | 43 | self.solver_parameters = { 44 | "ksp_type": "preonly", 45 | "pc_type": "lu", 46 | "pc_factor_mat_solver_type": "mumps", 47 | } 48 | if solver_parameters: 49 | self.solver_parameters.update(solver_parameters) 50 | 51 | @no_annotations 52 | def solve(self, phi: fd.Function, iters: int = 5) -> fd.Function: 53 | 54 | marking = fd.Function(self.DG0) 55 | marking_bc_nodes = fd.Function(self.V) 56 | # Mark cells cut by phi(x) = 0 57 | domain = "{[i, j]: 0 <= i < b.dofs}" 58 | instructions = """ 59 | min_value = 1e20 60 | max_value = -1e20 61 | for i 62 | min_value = fmin(min_value, b[i, 0]) 63 | max_value = fmax(max_value, b[i, 0]) 64 | end 65 | a[0, 0] = 1.0 if (min_value < 0 and max_value > 0) else 0.0 66 | """ 67 | fd.par_loop( 68 | (domain, instructions), 69 | dx, 70 | {"a": (marking, RW), "b": (phi, READ)}, 71 | is_loopy_kernel=True, 72 | ) 73 | # Mark the nodes in the marked cells 74 | fd.par_loop( 75 | ("{[i] : 0 <= i < A.dofs}", "A[i, 0] = fmax(A[i, 0], B[0, 0])"), 76 | dx, 77 | {"A": (marking_bc_nodes, RW), "B": (marking, READ)}, 78 | is_loopy_kernel=True, 79 | ) 80 | # Mark the nodes in the marked cells 81 | # Project the gradient of phi on the cut cells 82 | self.phi.assign(phi) 83 | V = self.V 84 | rho, sigma = fd.TrialFunction(V), fd.TestFunction(V) 85 | a = rho * sigma * marking * dx 86 | L_proj = ( 87 | self.phi 88 | / sqrt(inner(grad(self.phi), grad(self.phi))) 89 | * marking 90 | * sigma 91 | * dx 92 | ) 93 | bc_proj = BCOut(V, fd.Constant(0.0), marking_bc_nodes) 94 | self.A_proj = fd.assemble(a, tensor=self.A_proj, bcs=bc_proj) 95 | b_proj = fd.assemble(L_proj, bcs=bc_proj) 96 | solver_proj = fd.LinearSolver( 97 | self.A_proj, solver_parameters=self.solver_parameters 98 | ) 99 | solver_proj.solve(self.phi_int, b_proj) 100 | 101 | def nabla_phi_bar(phi): 102 | return sqrt(inner(grad(phi), grad(phi))) 103 | 104 | def d1(s): 105 | return fd.Constant(1.0) - fd.Constant(1.0) / s 106 | 107 | def d2(s): 108 | return conditional( 109 | le(s, fd.Constant(1.0)), s - fd.Constant(1.0), d1(s) 110 | ) 111 | 112 | def residual_phi(phi): 113 | return fd.norm( 114 | fd.assemble( 115 | d2(nabla_phi_bar(phi)) * inner(grad(phi), grad(sigma)) * dx 116 | ) 117 | ) 118 | 119 | a = inner(grad(rho), grad(sigma)) * dx 120 | L = ( 121 | inner( 122 | (-d2(nabla_phi_bar(self.phi)) + fd.Constant(1.0)) 123 | * grad(self.phi), 124 | grad(sigma), 125 | ) 126 | * dx 127 | ) 128 | bc = BCInt(V, self.phi_int, marking_bc_nodes) 129 | phi_sol = fd.Function(V) 130 | A = fd.assemble(a, bcs=bc) 131 | b = fd.assemble(L, bcs=bc) 132 | solver = fd.LinearSolver(A, solver_parameters=self.solver_parameters) 133 | 134 | # Solve the Signed distance equation with Picard iteration 135 | bc.apply(phi_sol) 136 | init_res = residual_phi(phi_sol) 137 | res = 1e10 138 | it = 0 139 | while res > init_res or it < iters: 140 | solver.solve(phi_sol, b) 141 | self.phi.assign(phi_sol) 142 | b = fd.assemble(L, bcs=bc, tensor=b) 143 | it += 1 144 | res = residual_phi(phi_sol) 145 | if res > init_res: 146 | fd.warning( 147 | f"Residual in signed distance function increased: {res}, before: {init_res}" 148 | ) 149 | return self.phi 150 | -------------------------------------------------------------------------------- /letop/optimization/hj_context.py: -------------------------------------------------------------------------------- 1 | from firedrake import ( 2 | assemble, 3 | dmhooks, 4 | function, 5 | ) 6 | from firedrake.exceptions import ConvergenceError 7 | from firedrake.petsc import PETSc 8 | from firedrake.utils import cached_property 9 | 10 | 11 | def _make_reasons(reasons): 12 | return dict( 13 | [ 14 | (getattr(reasons, r), r) 15 | for r in dir(reasons) 16 | if not r.startswith("_") 17 | ] 18 | ) 19 | 20 | 21 | TSReasons = _make_reasons(PETSc.TS.ConvergedReason()) 22 | 23 | 24 | def check_ts_convergence(ts): 25 | r = ts.getConvergedReason() 26 | # TODO: submit PR to petsc4py to add the following reasons 27 | # TSFORWARD_DIVERGED_LINEAR_SOLVE = -3, 28 | # TSADJOINT_DIVERGED_LINEAR_SOLVE = -4 29 | if r == -3: 30 | raise ConvergenceError( 31 | "TS solve failed to converge. Reason: TSFORWARD_DIVERGED_LINEAR_SOLVE" 32 | ) 33 | if r == -4: 34 | raise ConvergenceError( 35 | "TS solve failed to converge. Reason: TSADJOINT_DIVERGED_LINEAR_SOLVE" 36 | ) 37 | reason = TSReasons[r] 38 | if r < 0: 39 | raise ConvergenceError( 40 | f"TS solve failed to converge after {ts.getStepNumber()} iterations. Reason: {reason}" 41 | ) 42 | 43 | 44 | class _HJContext(object): 45 | r""" 46 | Context holding information for TS callbacks. 47 | 48 | :arg problem: a :class:`HamiltonJacobiProlbem`. 49 | :arg appctx: Any extra information used in the assembler. For the 50 | matrix-free case this will contain the Newton state in 51 | ``"state"``. 52 | :arg options_prefix: The options prefix of the TS. 53 | """ 54 | 55 | def __init__( 56 | self, 57 | problem, 58 | appctx=None, 59 | options_prefix=None, 60 | ): 61 | from firedrake.bcs import DirichletBC 62 | 63 | self.options_prefix = options_prefix 64 | 65 | self._problem = problem 66 | 67 | self.fcp = problem.form_compiler_parameters 68 | 69 | if appctx is None: 70 | appctx = {} 71 | appctx.setdefault("state", self._problem.phi_n) 72 | appctx.setdefault("form_compiler_parameters", self.fcp) 73 | 74 | self.appctx = appctx 75 | 76 | self.bcs_F = [ 77 | bc if isinstance(bc, DirichletBC) else bc._F for bc in problem.bcs 78 | ] 79 | 80 | def set_rhsfunction(self, ts): 81 | r"""Set the function to compute F(t,U,U_t) where F() = 0 is the DAE to be solved.""" 82 | with self._F.dat.vec_wo as v: 83 | ts.setRHSFunction(self.form_function, f=v) 84 | 85 | @staticmethod 86 | def form_function(ts, t, X, F): 87 | r"""Form the residual for this problem 88 | 89 | :arg ts: a PETSc TS object 90 | :arg t: the time at step/stage being solved 91 | :arg X: state vector 92 | :arg F: function vector 93 | """ 94 | dm = ts.getDM() 95 | ctx = dmhooks.get_appctx(dm) 96 | # X may not be the same vector as the vec behind self._problem.phi_n, so 97 | # copy guess in from X. 98 | with ctx._problem.phi_n.dat.vec_wo as v: 99 | X.copy(v) 100 | 101 | b1 = assemble(ctx._problem.L1) 102 | ctx._problem.solver1.solve(ctx._problem.p1, b1) 103 | 104 | b2 = assemble(ctx._problem.L2) 105 | ctx._problem.solver2.solve(ctx._problem.p2, b2) 106 | 107 | b3 = assemble(ctx._problem.Lb) 108 | ctx._problem.solver_b.solve(ctx._F, b3) 109 | 110 | # F may not be the same vector as self._F, so copy 111 | # residual out to F. 112 | with ctx._F.dat.vec_ro as v: 113 | v.copy(F) 114 | 115 | @cached_property 116 | def _F(self): 117 | return function.Function(self._problem.phi_n.function_space()) 118 | -------------------------------------------------------------------------------- /letop/optimization/interface.py: -------------------------------------------------------------------------------- 1 | from letop.physics.utils import max_mesh_dimension 2 | import firedrake as fd 3 | from firedrake import inner, dx 4 | from pyadjoint import Control, no_annotations 5 | from pyadjoint.enlisting import Enlist 6 | from letop.levelset import ( 7 | LevelSetFunctional, 8 | RegularizationSolver, 9 | ) 10 | from letop.optimization import ( 11 | HamiltonJacobiCGSolver, 12 | ReinitSolverCG, 13 | ) 14 | from letop.physics import calculate_max_vel, InteriorBC 15 | from pyop2.profiling import timed_function 16 | from ufl.algebra import Abs 17 | from petsc4py.PETSc import TS 18 | 19 | 20 | 21 | class Constraint(object): 22 | @no_annotations 23 | def __init__(self, rfnl, constraint_value, scalar_control): 24 | """Docstring for __init__. 25 | 26 | :rfnl: LevelSetFunctional 27 | :constraint_value: Scalar 28 | :scalar_control: Control 29 | 30 | """ 31 | if not isinstance(rfnl, LevelSetFunctional): 32 | raise TypeError( 33 | f"Provided '{type(rfnl).__name__}', not a LevelSetFunctional" 34 | ) 35 | if not isinstance(scalar_control, Control): 36 | raise TypeError( 37 | f"Provided '{type(scalar_control).__name__}', not a Control" 38 | ) 39 | if not isinstance(constraint_value, float): 40 | raise TypeError( 41 | f"Provided '{type(constraint_value).__name__}', not a float" 42 | ) 43 | 44 | self.rfnl = rfnl 45 | self.constraint_value = constraint_value 46 | self.scalar_control = scalar_control 47 | 48 | def evaluate(self, x): 49 | # TODO: Any way to check that the value saved in self.scalar_control corresponds to `x`? 50 | """Evaluate the constraint as G(x) - Gval <= 0 51 | 52 | Args: 53 | x ([type]): [description] 54 | 55 | Returns: 56 | [float]: [Constraint value. Violation if it is > 0] 57 | """ 58 | 59 | return self.scalar_control.tape_value() - self.constraint_value 60 | 61 | def derivative(self): 62 | return self.rfnl.derivative() 63 | 64 | 65 | class InfDimProblem(object): 66 | def __init__( 67 | self, 68 | cost_function, 69 | reg_solver, 70 | eqconstraints=None, 71 | ineqconstraints=None, 72 | reinit_distance=0.05, 73 | solver_parameters=None, 74 | output_dir=None, 75 | ): 76 | """Problem interface for the null-space solver 77 | 78 | Args: 79 | cost_function ([type]): [description] 80 | reg_solver ([type]): [description] 81 | eqconstraints ([type], optional): [description]. Defaults to None. 82 | ineqconstraints ([type], optional): [description]. Defaults to None. 83 | reinit_distance (int, optional): The reinitialization solver is activated 84 | after the level set is shifted reinit_distance * D, 85 | where D is the max dimensions of a mesh 86 | Defaults to 0.1 87 | solver_parameters ([type], optional): [description]. Defaults to None. 88 | 89 | Raises: 90 | TypeError: [description] 91 | TypeError: [description] 92 | TypeError: [description] 93 | 94 | Returns: 95 | [type]: [description] 96 | """ 97 | if not isinstance(reg_solver, RegularizationSolver): 98 | raise TypeError( 99 | f"Provided regularization solver '{type(reg_solver).__name__}',\ 100 | is not a RegularizationSolver" 101 | ) 102 | self.reg_solver = reg_solver 103 | assert len(cost_function.controls) < 2, "Only one control for now" 104 | self.phi = cost_function.level_set[0] 105 | # Copy for the HamiltonJacobiCGSolver 106 | self.phi_hj = fd.Function(cost_function.level_set[0], name="hamilton-jacobi") 107 | # Copy for the Line search 108 | self.phi_ls = fd.Function(cost_function.level_set[0], name="line-search") 109 | # Copy for the Regularization solver 110 | self.phi_rs = fd.Function(cost_function.level_set[0], name='reinit') 111 | self.V = self.phi.function_space() 112 | self.Vvec = cost_function.controls[0].control.function_space() 113 | self.delta_x = fd.Function(self.Vvec) 114 | self.max_distance = reinit_distance * max_mesh_dimension( 115 | self.V.ufl_domain() 116 | ) 117 | self.current_max_distance = self.max_distance 118 | self.current_max_distance_at_t0 = self.current_max_distance 119 | self.accum_distance = 0.0 120 | self.last_distance = 0.0 121 | self.output_dir = output_dir 122 | self.accept_iteration = False 123 | self.termination_event = None 124 | 125 | V_elem = self.V.ufl_element() 126 | if V_elem.family() in ["TensorProductElement", "Lagrange"]: 127 | if V_elem.family() == "TensorProductElement": 128 | assert ( 129 | V_elem.sub_elements()[0].family() == "Q" 130 | and V_elem.sub_elements()[1].family() == "Lagrange" 131 | ), "Only Lagrange basis" 132 | self.build_cg_solvers( 133 | solver_parameters, 134 | ) 135 | else: 136 | raise RuntimeError( 137 | f"Level set function element {self.V.ufl_element()} not supported." 138 | ) 139 | 140 | def event(ts, t, X, fvalue): 141 | max_vel = calculate_max_vel(self.delta_x) 142 | fvalue[0] = ( 143 | self.accum_distance + max_vel * t 144 | ) - self.current_max_distance 145 | 146 | def postevent(ts, events, t, X, forward): 147 | with self.phi_hj.dat.vec_wo as v: 148 | X.copy(v) 149 | self.phi_hj.assign(self.reinit_solver.solve(self.phi_hj)) 150 | with self.phi_hj.dat.vec_wo as v: 151 | v.copy(X) 152 | self.current_max_distance += self.max_distance 153 | 154 | direction = [1] 155 | terminate = [False] 156 | 157 | self.hj_solver.ts.setEventHandler( 158 | direction, terminate, event, postevent 159 | ) 160 | self.hj_solver.ts.setEventTolerances(1e-4, vtol=[1e-4]) 161 | 162 | if eqconstraints: 163 | self.eqconstraints = Enlist(eqconstraints) 164 | for constr in self.eqconstraints: 165 | if not isinstance(constr, Constraint): 166 | raise TypeError( 167 | f"Provided equality constraint '{type(constr).__name__}', not a Constraint" 168 | ) 169 | else: 170 | self.eqconstraints = [] 171 | 172 | if ineqconstraints: 173 | self.ineqconstraints = Enlist(ineqconstraints) 174 | for ineqconstr in self.ineqconstraints: 175 | if not isinstance(ineqconstr, Constraint): 176 | raise TypeError( 177 | f"Provided inequality constraint '{type(ineqconstr).__name__}',\ 178 | not a Constraint" 179 | ) 180 | else: 181 | self.ineqconstraints = [] 182 | 183 | self.n_eqconstraints = len(self.eqconstraints) 184 | self.n_ineqconstraints = len(self.ineqconstraints) 185 | 186 | self.gradJ = fd.Function(self.Vvec) 187 | 188 | self.gradH = [fd.Function(self.Vvec) for _ in self.ineqconstraints] 189 | self.gradG = [fd.Function(self.Vvec) for _ in self.eqconstraints] 190 | 191 | self.cost_function = cost_function 192 | 193 | self.i = 0 # iteration count 194 | 195 | self.beta_param = reg_solver.beta_param.values()[0] 196 | 197 | 198 | def set_termination_event( 199 | self, termination_event, termination_tolerance=1e-2 200 | ): 201 | 202 | if termination_event and not isinstance(termination_event(), float): 203 | raise TypeError(f"termination_event must return a float") 204 | 205 | self.termination_event = termination_event 206 | self.termination_tolerance = termination_tolerance 207 | 208 | def build_cg_solvers(self, solver_parameters=None): 209 | hj_solver_parameters = None 210 | reinit_solver_parameters = None 211 | if solver_parameters: 212 | if solver_parameters.get("hj_solver"): 213 | hj_solver_parameters = solver_parameters["hj_solver"] 214 | if solver_parameters.get("reinit_solver"): 215 | reinit_solver_parameters = solver_parameters["reinit_solver"] 216 | 217 | self.hj_solver = HamiltonJacobiCGSolver( 218 | self.V, 219 | self.delta_x, 220 | self.phi_hj, 221 | solver_parameters=hj_solver_parameters, 222 | ) 223 | self.reinit_solver = ReinitSolverCG( 224 | self.phi_rs, solver_parameters=reinit_solver_parameters 225 | ) 226 | 227 | def fespace(self): 228 | return self.Vvec 229 | 230 | def eval(self, x): 231 | """Returns the triplet (J(x),G(x),H(x))""" 232 | return (self.J(x), self.G(x), self.H(x)) 233 | 234 | @timed_function("Cost function") 235 | def J(self, x): 236 | return self.cost_function(x) 237 | 238 | @timed_function("Cost function gradient") 239 | def dJ(self, x): 240 | return self.cost_function.derivative() 241 | 242 | @timed_function("Equality constraint function") 243 | def G(self, x): 244 | return [eqconstr.evaluate(x) for eqconstr in self.eqconstraints] 245 | 246 | @timed_function("Equality constraint function gradient") 247 | def dG(self, x): 248 | return [eqconstr.derivative() for eqconstr in self.eqconstraints] 249 | 250 | @timed_function("Inequality constraint function") 251 | def H(self, x): 252 | return [ineqconstr.evaluate(x) for ineqconstr in self.ineqconstraints] 253 | 254 | @timed_function("Inequality constraint function gradient") 255 | def dH(self, x): 256 | return [ineqconstr.derivative() for ineqconstr in self.ineqconstraints] 257 | 258 | @no_annotations 259 | def reinit(self, x): 260 | pass 261 | 262 | @no_annotations 263 | def eval_gradients(self, x): 264 | """Returns the triplet (gradJ(x), gradG(x), gradH(x))""" 265 | self.accum_distance += self.last_distance 266 | self.i += 1 267 | self.phi.assign(x) 268 | 269 | if self.termination_event: 270 | event_value = self.termination_event() 271 | if event_value < self.termination_tolerance: 272 | self.accept_iteration = True 273 | 274 | dJ = self.dJ(x) 275 | dG = self.dG(x) 276 | dH = self.dH(x) 277 | 278 | # Regularize all gradients 279 | self.reg_solver.solve(self.gradJ, dJ) 280 | 281 | for gradHi, dHi in zip(self.gradH, dH): 282 | self.reg_solver.solve(gradHi, dHi) 283 | for gradGi, dGi in zip(self.gradG, dG): 284 | self.reg_solver.solve(gradGi, dGi) 285 | 286 | return (self.gradJ, self.gradG, self.gradH) 287 | 288 | def reset_distance(self): 289 | """Necessary in cases where we have performed a reinitialization 290 | but the new level set was scraped by the line search 291 | """ 292 | self.current_max_distance = self.current_max_distance_at_t0 293 | 294 | def velocity_scale(self, delta_x): 295 | return calculate_max_vel(delta_x) 296 | 297 | @no_annotations 298 | def retract(self, input_phi, delta_x, scaling=1): 299 | """input_phi is not modified, 300 | output_phi refers to problem.phi 301 | Args: 302 | input_phi ([type]): [description] 303 | delta_x ([type]): [description] 304 | scaling (int, optional): [description]. Defaults to 1. 305 | 306 | Returns: 307 | [type]: [description] 308 | """ 309 | self.current_max_distance_at_t0 = self.current_max_distance 310 | self.hj_solver.ts.setMaxTime(scaling) 311 | self.hj_solver.ts.setTimeStep(1e-4) 312 | self.hj_solver.ts.setTime(0.0) 313 | self.hj_solver.ts.setStepNumber(0) 314 | try: 315 | self.phi_hj.assign(input_phi) 316 | self.hj_solver.solve() 317 | except: 318 | reason = self.hj_solver.ts.getConvergedReason() 319 | print(f"Time stepping of Hamilton Jacobi failed. Reason: {reason}") 320 | if self.output_dir: 321 | print(f"Printing last solution to {self.output_dir}") 322 | fd.File(f"{self.output_dir}/failed_hj.pvd").write(input_phi) 323 | 324 | max_vel = calculate_max_vel(delta_x) 325 | self.last_distance = max_vel * scaling 326 | 327 | conv = self.hj_solver.ts.getConvergedReason() 328 | rtol, atol = ( 329 | self.hj_solver.parameters["ts_rtol"], 330 | self.hj_solver.parameters["ts_atol"], 331 | ) 332 | max_steps = self.hj_solver.parameters.get("ts_max_steps", 800) 333 | current_time = self.hj_solver.ts.getTime() 334 | total_time = self.hj_solver.ts.getMaxTime() 335 | if conv == TS.ConvergedReason.CONVERGED_ITS: 336 | warning = ( 337 | f"Maximum number of time steps {self.hj_solver.ts.getStepNumber()} reached." 338 | f"Current time is only: {current_time} for total time: {total_time}." 339 | "Consider making the optimization time step dt shorter." 340 | "Restarting this step with more time steps and tighter tolerances if applicable." 341 | ) 342 | fd.warning(warning) 343 | 344 | # Tighten tolerances if we are really far 345 | if current_time / total_time < 0.2: 346 | current_rtol, current_atol = self.hj_solver.ts.getTolerances() 347 | new_rtol, new_atol = max(rtol / 200, current_rtol / 10), max( 348 | atol / 200, current_atol / 10 349 | ) 350 | self.hj_solver.ts.setTolerances(rtol=new_rtol, atol=new_atol) 351 | 352 | # Relax max time steps 353 | current_max_steps = self.hj_solver.ts.getMaxSteps() 354 | new_max_steps = min(current_max_steps * 1.5, max_steps * 3) 355 | self.hj_solver.ts.setMaxSteps(new_max_steps) 356 | 357 | elif conv == TS.ConvergedReason.CONVERGED_TIME: 358 | self.hj_solver.ts.setTolerances(rtol=rtol, atol=atol) 359 | 360 | def restore(self): 361 | pass 362 | 363 | @no_annotations 364 | def inner_product(self, x, y): 365 | return fd.assemble(inner(x, y) * dx) 366 | 367 | def accept(self): 368 | return self.accept_iteration 369 | -------------------------------------------------------------------------------- /letop/optimization/nullspace_shape.py: -------------------------------------------------------------------------------- 1 | import numpy as np 2 | import cvxopt as cvx 3 | import time 4 | from mpi4py import MPI 5 | 6 | import firedrake as fd 7 | from firedrake import inner, Function, dx, Constant, File 8 | from numpy.core.numeric import indices 9 | from sympy import solve 10 | from letop.optimization import InfDimProblem 11 | from pyadjoint import no_annotations 12 | from firedrake.petsc import PETSc 13 | from functools import partial 14 | 15 | 16 | def print(x): 17 | return PETSc.Sys.Print(x) 18 | 19 | 20 | class MPITimer: 21 | def __init__(self, comm) -> None: 22 | self.comm = comm 23 | 24 | def __enter__(self): 25 | self.start = time.process_time() 26 | return self 27 | 28 | def __exit__(self, *args): 29 | self.end = time.process_time() 30 | total_time = self.end - self.start 31 | self.min_time = self.comm.allreduce(total_time, op=MPI.MIN) 32 | self.max_time = self.comm.allreduce(total_time, op=MPI.MAX) 33 | 34 | 35 | def set_parameters(params): 36 | 37 | params_default = { 38 | "alphaJ": 1, 39 | "alphaC": 1, 40 | "maxit": 4000, 41 | "maxtrials": 3, 42 | "debug": 0, 43 | "normalisation_norm": np.inf, 44 | "tol_merit": 0, 45 | "K": 0.1, 46 | "tol_qp": 1e-20, 47 | "show_progress_qp": False, 48 | "monitor_time": False, 49 | "dt": 1.0, 50 | "tol": 1e-5, 51 | "itnormalisation": 10, 52 | } 53 | if params is not None: 54 | for key in params.keys(): 55 | if key not in params_default.keys(): 56 | raise ValueError( 57 | "Don't know how to deal with parameter %s (a %s)" 58 | % (key, params[key].__class__) 59 | ) 60 | 61 | for (prop, default) in params_default.items(): 62 | params[prop] = params.get(prop, default) 63 | else: 64 | params = params_default 65 | 66 | return params 67 | 68 | 69 | def display(message, debug, level=0, color=None): 70 | if color: 71 | try: 72 | import colored as col 73 | 74 | message = col.stylize(message, col.fg(color)) 75 | except Exception: 76 | pass 77 | if debug >= level: 78 | print(message) 79 | 80 | 81 | def inner_product(x, y): 82 | return fd.assemble(inner(x, y) * dx, annotate=False) 83 | 84 | 85 | def compute_norm(f, norm_type=np.inf): 86 | if norm_type == np.inf: 87 | with f.dat.vec_ro as vu: 88 | return vu.norm(PETSc.NormType.NORM_INFINITY) 89 | elif norm_type == 2: 90 | return fd.norm(f) 91 | 92 | 93 | def getTilde(C, p, eps=0): 94 | """ 95 | Obtain the set of violated inequality constraints 96 | """ 97 | tildeEps = C[p:] >= -eps 98 | tildeEps = np.asarray(np.concatenate(([True] * p, tildeEps)), dtype=bool) 99 | return tildeEps 100 | 101 | 102 | def getEps(dC, p, dt, K, norm_type=np.inf): 103 | if len(dC) == 0: 104 | return np.array([]) 105 | if norm_type == np.inf: 106 | eps = [] 107 | for dCi in dC[p:]: 108 | with dCi.dat.vec_ro as dCv: 109 | norm_inf = dCv.norm(PETSc.NormType.NORM_INFINITY) 110 | eps.append(norm_inf) 111 | eps = np.array(eps) * dt * K 112 | elif norm_type == 2: 113 | eps = np.array([fd.norm(dCi) * dt * K for dCi in dC[p:]]) 114 | return eps 115 | 116 | 117 | def p_matrix_eval(dC, tildeEps): 118 | p_matrix = np.zeros((sum(tildeEps), sum(tildeEps))) 119 | ii = 0 120 | for i, tildei in enumerate(tildeEps): 121 | jj = 0 122 | for j, tildej in enumerate(tildeEps): 123 | if tildej and tildei: 124 | p_matrix[ii, jj] = inner_product(dC[i], dC[j]) 125 | jj += 1 126 | if tildei: 127 | ii += 1 128 | return p_matrix 129 | 130 | 131 | def q_vector_eval(dJ, dC, tildeEps): 132 | q_vector = np.zeros((sum(tildeEps), 1)) 133 | ii = 0 134 | for i, tildei in enumerate(tildeEps): 135 | if tildei: 136 | q_vector[ii] = inner_product(dJ, dC[i]) 137 | ii += 1 138 | return q_vector 139 | 140 | 141 | def invert_dCdCT(dCdCT, debug): 142 | try: 143 | dCtdCtTinv = np.linalg.inv(dCdCT) 144 | except Exception: 145 | display( 146 | "Warning, constraints are not qualified. " 147 | + "Using pseudo-inverse.", 148 | debug, 149 | 1, 150 | color="orange_4a", 151 | ) 152 | dCtdCtTinv = np.linalg.pinv(dCdCT) 153 | 154 | return dCtdCtTinv 155 | 156 | 157 | def line_search( 158 | problem, 159 | merit_eval_new, 160 | merit, 161 | AJ, 162 | AC, 163 | dt=1.0, 164 | maxtrials=10, 165 | tol_merit=1e-3, 166 | debug=1.0, 167 | ): 168 | 169 | vel_scale = problem.velocity_scale(problem.delta_x) 170 | problem.delta_x /= vel_scale 171 | success = 0 172 | for k in range(maxtrials): 173 | problem.retract(problem.phi, problem.delta_x, scaling=(dt * 0.5 ** k)) 174 | problem.phi_ls.assign(problem.phi_hj) 175 | (newJ, newG, newH) = problem.eval(problem.phi_ls) 176 | newC = np.concatenate((newG, newH)) 177 | new_merit = merit_eval_new( 178 | AJ, 179 | newJ, 180 | AC, 181 | newC, 182 | ) 183 | print(f"newJ={newJ}, newC={newC}") 184 | print(f"merit={merit}, new_merit={new_merit}") 185 | if new_merit < (1 + np.sign(merit) * tol_merit) * merit: 186 | success = 1 187 | break 188 | else: 189 | display( 190 | "Warning, merit function did not decrease " 191 | + f"(merit={merit}, new_merit={new_merit})" 192 | + f"-> Trial {k+1}", 193 | debug, 194 | 0, 195 | "red", 196 | ) 197 | # Last attempt is accepted, forgo reset the distance. 198 | if k == maxtrials - 1: 199 | break 200 | problem.reset_distance() 201 | if not success: 202 | display( 203 | "All trials have failed, passing to the next iteration.", 204 | debug, 205 | color="red", 206 | ) 207 | 208 | return newJ, newG, newH 209 | 210 | 211 | def solve_dual_problem( 212 | p_matrix, q_vector, tildeEps, p, show_progress_qp=None, tol_qp=None 213 | ): 214 | # Solve the dual problem to obtain the new set of active constraints 215 | # Solve it using a quadratic solver: 216 | # minimize (1/2)*x'*P*x + q'*x 217 | # subject to G*x <= h 218 | # A*x = b. 219 | # A and b are optionals and not given here. 220 | # sum(tildeEps) = p + qtildeEps 221 | 222 | qtildeEps = sum(tildeEps) - p 223 | 224 | Pcvx = cvx.matrix(p_matrix) 225 | qcvx = cvx.matrix(q_vector) 226 | Gcvx = cvx.matrix( 227 | np.concatenate((np.zeros((qtildeEps, p)), -np.eye(qtildeEps)), axis=1) 228 | ) 229 | hcvx = cvx.matrix(np.zeros((qtildeEps, 1))) 230 | if p + qtildeEps > 0: 231 | return cvx.solvers.qp( 232 | Pcvx, 233 | qcvx, 234 | Gcvx, 235 | hcvx, 236 | options={ 237 | "show_progress": show_progress_qp, 238 | "reltol": 1e-20, 239 | "abstol": 1e-20, 240 | "feastol": tol_qp, 241 | }, 242 | ) 243 | else: 244 | return None 245 | 246 | 247 | def dCdCT_eval(dC, hat): 248 | dCdCT = np.zeros((sum(hat), sum(hat))) 249 | ii = 0 250 | for i, tildei in enumerate(hat): 251 | jj = 0 252 | for j, tildej in enumerate(hat): 253 | if tildej and tildei: 254 | dCdCT[ii, jj] = inner_product(dC[i], dC[j]) 255 | jj += 1 256 | if tildei: 257 | ii += 1 258 | return dCdCT 259 | 260 | 261 | def dCdCT_eval_tilde(dC, indicesEps): 262 | dCdCT = np.zeros((sum(indicesEps), sum(indicesEps))) 263 | ii = 0 264 | for i, indi in enumerate(indicesEps): 265 | jj = 0 266 | for j, indj in enumerate(indicesEps): 267 | if indi and indj: 268 | dCdCT[ii, jj] = inner_product(dC[i], dC[j]) 269 | jj += 1 270 | if indi: 271 | ii += 1 272 | return dCdCT 273 | 274 | 275 | def dCdJ_eval(dJ, dC, hat): 276 | dCdJ = hat.copy() 277 | ii = 0 278 | for i, hati in enumerate(hat): 279 | if hati: 280 | dCdJ[ii] = inner_product(dC[i], dJ) 281 | ii += 1 282 | return dCdJ 283 | 284 | 285 | def xiJ_eval(dJ, dC, muls, hat): 286 | xiJ = Function(dJ.function_space()) 287 | if hat.any(): 288 | list_func = [] 289 | for i, hati in enumerate(hat): 290 | if hati: 291 | list_func.append(Constant(muls[i]) * dC[i]) 292 | else: 293 | # Still add a function to be able to call Function.assign with 294 | # objects of same shape. 295 | list_func.append(Constant(0.0) * dC[i]) 296 | xiJ.assign(dJ + sum(list_func)) 297 | else: 298 | xiJ.assign(dJ) 299 | 300 | return xiJ 301 | 302 | 303 | def xiC_eval(C, dC, dCtdCtTinv, alphas, indicesEps): 304 | if len(C) == 0: 305 | return None 306 | # Sum of functions over indicesEps 307 | xiC = Function(dC[0].function_space()) 308 | if indicesEps.any(): 309 | list_func = [] 310 | dCdTinvCalpha = dCtdCtTinv.dot(C[indicesEps] * alphas[indicesEps]) 311 | ii = 0 312 | for i, indi in enumerate(indicesEps): 313 | if indi: 314 | list_func.append(Constant(dCdTinvCalpha[ii]) * dC[i]) 315 | ii += 1 316 | xiC.assign(sum(list_func)) 317 | return xiC 318 | 319 | 320 | def merit_eval(muls, indicesEps, dCtdCtTinv, AJ, J, AC, C): 321 | return AJ * (J + muls.dot(C)) + 0.5 * AC * C[indicesEps].dot( 322 | dCtdCtTinv.dot(C[indicesEps]) 323 | ) 324 | 325 | 326 | @no_annotations 327 | def nlspace_solve( 328 | problem: InfDimProblem, params=None, results=None, descent_output_dir=None 329 | ): 330 | """ 331 | Solve the optimization problem 332 | min J(phi) 333 | phi in V 334 | under the constraints 335 | g_i(phi)=0 for all i=0..p-1 336 | h_i(phi)<=0 for all i=0..q-1 337 | 338 | Usage 339 | ----- 340 | results=nlspace_solve(problem: InfDimProblem, params: dict, results:dict) 341 | 342 | Inputs 343 | ------ 344 | problem : an `~InfDimProblem` object corresponding to the optimization 345 | problem above. 346 | 347 | params : (optional) a dictionary containing algorithm parameters 348 | (see below). 349 | 350 | results : (optional) a previous output of the nlspace_solve` function. 351 | The optimization will keep going from the last input of 352 | the dictionary `results['phi'][-1]`. 353 | Useful to restart an optimization after an interruption. 354 | descent_output_dir : Plot the descent direction in the given directory 355 | 356 | Output 357 | ------ 358 | results : dictionary containing 359 | results['J'] : values of the objective function along the path 360 | (J(phi_0),...,J(phi_n)) 361 | results['G'] : equality constraint values 362 | (G(phi_0),...,G(phi_n)) 363 | results['H'] : inequality constraints values 364 | (H(phi_0),...,H(phi_n)) 365 | results['muls'] : lagrange multiplier values 366 | (mu(phi_0),...,mu(phi_n)) 367 | 368 | 369 | Optional algorithm parameters 370 | ----------------------------- 371 | 372 | params['alphaJ'] : (default 1) scaling coefficient for the null space 373 | step xiJ decreasing the objective function 374 | 375 | params['alphaC'] : (default 1) scaling coefficient for the Gauss Newton 376 | step xiC decreasing the violation of the constraints 377 | 378 | params['alphas'] : (optional) vector of dimension 379 | problem.nconstraints + problem.nineqconstraints containing 380 | proportionality coefficients scaling the Gauss Newton direction xiC for 381 | each of the constraints 382 | 383 | params['debug'] : Tune the verbosity of the output (default 0) 384 | Set param['debug']=-1 to display only the final result 385 | Set param['debug']=-2 to remove any output 386 | 387 | params['dt'] : (default : `1.0`). Pseudo time-step expressed in a time unit. 388 | Used to modulate the optimization convergence/oscillatory behavior. 389 | 390 | params['hmin'] : (default : `1.0`). Mesh minimum length. TODO Replace this for dt 391 | in the calculation of the tolerances `eps` 392 | 393 | params['K']: tunes the distance at which inactive inequality constraints 394 | are felt. Constraints are felt from a distance K*params['dt'] 395 | 396 | params['maxit'] : Maximal number of iterations (default : 4000) 397 | 398 | params['maxtrials']: (default 3) number of trials in between time steps 399 | until the merit function decreases 400 | 401 | params['tol'] : (default 1e-7) Algorithm stops when 402 | ||phi_{n+1}-phi_n|| params["tol"] and len(results["J"]) < params["maxit"]: 444 | with MPITimer(problem.phi.comm) as timings: 445 | 446 | results["J"].append(J) 447 | results["G"].append(G) 448 | results["H"].append(H) 449 | 450 | if problem.accept(): 451 | break 452 | 453 | it = len(results["J"]) - 1 454 | display("\n", params["debug"], 1) 455 | display( 456 | f"{it}. J=" 457 | + format(J, ".4g") 458 | + " " 459 | + "G=[" 460 | + ",".join(format(constraint, ".4g") for constraint in G[:10]) 461 | + "] " 462 | + "H=[" 463 | + ",".join(format(constraint, ".4g") for constraint in H[:10]) 464 | + "] " 465 | + " ||dx||_V=" 466 | + format(normdx, ".4g"), 467 | params["debug"], 468 | 0, 469 | ) 470 | 471 | # Returns the gradients (in the primal space). They are 472 | # firedrake.Function's 473 | (dJ, dG, dH) = problem.eval_gradients(problem.phi) 474 | dC = dG + dH 475 | 476 | H = np.asarray(H) 477 | G = np.asarray(G) 478 | C = np.concatenate((G, H)) 479 | 480 | # Obtain the tolerances for the inequality constraints and the indices 481 | # for the violated constraints 482 | eps = getEps( 483 | dC, 484 | problem.n_eqconstraints, 485 | params["dt"], 486 | params["K"], 487 | norm_type=params["normalisation_norm"], 488 | ) 489 | tildeEps = getTilde(C, problem.n_eqconstraints, eps=eps) 490 | print(f"eps: {eps}") 491 | # Obtain the violated contraints 492 | tilde = getTilde(C, problem.n_eqconstraints) 493 | 494 | p_matrix = p_matrix_eval(dC, tildeEps) 495 | q_vector = q_vector_eval(dJ, dC, tildeEps) 496 | qp_results = solve_dual_problem( 497 | p_matrix, 498 | q_vector, 499 | tildeEps, 500 | problem.n_eqconstraints, 501 | show_progress_qp=params["show_progress_qp"], 502 | tol_qp=params["tol_qp"], 503 | ) 504 | muls = np.zeros(len(C)) 505 | oldmuls = np.zeros(len(C)) 506 | hat = np.asarray([False] * len(C)) 507 | 508 | if qp_results: 509 | muls[tildeEps] = np.asarray(qp_results["x"]).flatten() 510 | oldmuls = muls.copy() 511 | hat = np.asarray([True] * len(C)) 512 | hat[problem.n_eqconstraints :] = ( 513 | muls[problem.n_eqconstraints :] > 30 * params["tol_qp"] 514 | ) 515 | if params.get("disable_dual", False): 516 | hat = tildeEps 517 | 518 | dCdCT = dCdCT_eval(dC, hat) 519 | dCdCTinv = invert_dCdCT(dCdCT, params["debug"]) 520 | muls = np.zeros(len(C)) 521 | 522 | dCdJ = dCdJ_eval(dJ, dC, hat) 523 | muls[hat] = -dCdCTinv.dot(dCdJ[hat]) 524 | 525 | if not np.all(muls[problem.n_eqconstraints :] >= 0): 526 | display( 527 | "Warning, the active set has not been predicted " 528 | + "correctly Using old lagrange multipliers", 529 | params["debug"], 530 | level=1, 531 | color="orange_4a", 532 | ) 533 | hat = np.asarray([True] * len(C)) 534 | muls = oldmuls.copy() 535 | 536 | results["muls"].append(muls) 537 | display( 538 | f"Lagrange multipliers: {muls[:10]}", params["debug"], level=5 539 | ) 540 | xiJ = xiJ_eval(dJ, dC, muls, hat) 541 | 542 | # Set of constraints union of active and new violated constraints. 543 | indicesEps = np.logical_or(tilde, hat) 544 | dCdCT = dCdCT_eval(dC, indicesEps) 545 | dCtdCtTinv = invert_dCdCT(dCdCT, params["debug"]) 546 | 547 | xiC = xiC_eval(C, dC, dCtdCtTinv, alphas, indicesEps) 548 | 549 | # TODO Consider this? AC = min(0.9, alphaC * dt / max(compute_norm(xiC), 1e-9)) 550 | AJ = params["alphaJ"] 551 | AC = params["alphaC"] 552 | 553 | # Make updates with merit function 554 | if xiC: 555 | problem.delta_x.assign( 556 | Constant(-AJ) * xiJ - Constant(AC) * xiC 557 | ) 558 | else: 559 | problem.delta_x.assign(Constant(-AJ) * xiJ) 560 | normdx = fd.norm(problem.delta_x) 561 | 562 | merit_eval_new = partial(merit_eval, muls, indicesEps, dCtdCtTinv) 563 | merit = merit_eval_new(AJ, J, AC, C) 564 | results["merit"].append(merit) 565 | if len(results["merit"]) > 3: 566 | print( 567 | f"Merit oscillation: {(results['merit'][-1] - results['merit'][-2]) * (results['merit'][-2] - results['merit'][-3])}" 568 | ) 569 | 570 | if descent_output_dir: 571 | descent_pvd.write(problem.delta_x) 572 | 573 | newJ, newG, newH = line_search( 574 | problem, 575 | merit_eval_new, 576 | merit, 577 | AJ, 578 | AC, 579 | dt=params["dt"], 580 | maxtrials=params["maxtrials"], 581 | tol_merit=params["tol_merit"], 582 | debug=params["debug"], 583 | ) 584 | problem.phi.assign(problem.phi_ls) 585 | (J, G, H) = (newJ, newG, newH) 586 | 587 | if params["monitor_time"]: 588 | print( 589 | f"Max time per iteration: {timings.max_time}, min time per iteration: {timings.min_time}" 590 | ) 591 | 592 | results["J"].append(J) 593 | results["G"].append(G) 594 | results["H"].append(H) 595 | 596 | display("\n", params["debug"], -1) 597 | display("Optimization completed.", params["debug"], -1) 598 | return results 599 | -------------------------------------------------------------------------------- /letop/optimization/utils.py: -------------------------------------------------------------------------------- 1 | import firedrake_adjoint as fda 2 | from pyadjoint import no_annotations 3 | import re 4 | import glob 5 | import firedrake as fd 6 | 7 | 8 | @no_annotations 9 | def is_checkpoint(output_dir): 10 | checkpoints = glob.glob(f"{output_dir}/checkpoint*") 11 | checkpoints_sorted = sorted( 12 | checkpoints, 13 | key=lambda L: list(map(int, re.findall(r"iter_(\d+)\.h5", L)))[0], 14 | ) 15 | return checkpoints_sorted 16 | 17 | 18 | @no_annotations 19 | def read_checkpoint(checkpoints, phi): 20 | last_file = checkpoints[-1] 21 | current_iter = int(re.findall(r"iter_(\d+)\.h5", last_file)[0]) 22 | with fd.HDF5File(last_file, "r") as checkpoint: 23 | checkpoint.read(phi, "/checkpoint") 24 | print(f"Restarting simulation at {current_iter}") 25 | return current_iter 26 | -------------------------------------------------------------------------------- /letop/physics/__init__.py: -------------------------------------------------------------------------------- 1 | from .navier_stokes_brinkman import ( 2 | NavierStokesBrinkmannForm, 3 | NavierStokesBrinkmannSolver, 4 | mark_no_flow_regions, 5 | InteriorBC, 6 | ) 7 | from .advection_diffusion import AdvectionDiffusionGLS 8 | from .utils import hs, min_mesh_size, calculate_max_vel, max_mesh_dimension 9 | -------------------------------------------------------------------------------- /letop/physics/advection_diffusion.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from firedrake import inner, dot, grad, div, dx 3 | 4 | def AdvectionDiffusionGLS( 5 | V: fd.FunctionSpace, 6 | theta: fd.Function, 7 | phi: fd.Function, 8 | PeInv: float = 1e-4, 9 | phi_t: fd.Function = None, 10 | ): 11 | PeInv_ct = fd.Constant(PeInv) 12 | rho = fd.TestFunction(V) 13 | F = ( 14 | inner(theta, grad(phi)) * rho + PeInv_ct * inner(grad(phi), grad(rho)) 15 | ) * dx 16 | 17 | if phi_t: 18 | F += phi_t * rho * dx 19 | 20 | h = fd.CellDiameter(V.ufl_domain()) 21 | R_U = dot(theta, grad(phi)) - PeInv_ct * div(grad(phi)) 22 | 23 | if phi_t: 24 | R_U += phi_t 25 | 26 | beta_gls = 0.9 27 | tau_gls = beta_gls * ( 28 | (4.0 * dot(theta, theta) / h ** 2) 29 | + 9.0 * (4.0 * PeInv_ct / h ** 2) ** 2 30 | ) ** (-0.5) 31 | 32 | theta_U = dot(theta, grad(rho)) - PeInv_ct * div(grad(rho)) 33 | F += tau_gls * inner(R_U, theta_U) * dx() 34 | 35 | return F 36 | -------------------------------------------------------------------------------- /letop/physics/navier_stokes_brinkman.py: -------------------------------------------------------------------------------- 1 | from cmath import tau 2 | import firedrake as fd 3 | from firedrake import ( 4 | inner, 5 | dot, 6 | grad, 7 | div, 8 | dx, 9 | ) 10 | from pyadjoint.enlisting import Enlist 11 | import ufl 12 | from .utils import hs 13 | from typing import Callable, Union 14 | from ufl.algebra import Product 15 | from functools import partial 16 | from firedrake.cython.dmcommon import FACE_SETS_LABEL, CELL_SETS_LABEL 17 | from pyop2.utils import as_tuple 18 | from firedrake.utils import cached_property 19 | from pyop2.datatypes import IntType 20 | import numpy as np 21 | from typing import List 22 | 23 | 24 | def mark_no_flow_regions(mesh: fd.Mesh, regions: List, regions_marker: List): 25 | dm = mesh.topology_dm 26 | dm.createLabel(FACE_SETS_LABEL) 27 | dm.markBoundaryFaces("boundary_faces") 28 | for region, marker in zip(regions, regions_marker): 29 | cells = dm.getStratumIS(CELL_SETS_LABEL, region) 30 | for cell in cells.array: 31 | faces = dm.getCone(cell) 32 | for face in faces: 33 | if dm.getLabelValue("boundary_faces", face) == 1: 34 | continue 35 | dm.setLabelValue(FACE_SETS_LABEL, face, marker) 36 | dm.removeLabel("boundary_faces") 37 | return mesh 38 | 39 | 40 | class InteriorBC(fd.DirichletBC): 41 | @cached_property 42 | def nodes(self): 43 | dm = self.function_space().mesh().topology_dm 44 | section = self.function_space().dm.getDefaultSection() 45 | nodes = [] 46 | for sd in as_tuple(self.sub_domain): 47 | nfaces = dm.getStratumSize(FACE_SETS_LABEL, sd) 48 | faces = dm.getStratumIS(FACE_SETS_LABEL, sd) 49 | if nfaces == 0: 50 | continue 51 | for face in faces.indices: 52 | # if dm.getLabelValue("interior_facets", face) < 0: 53 | # continue 54 | closure, _ = dm.getTransitiveClosure(face) 55 | for p in closure: 56 | dof = section.getDof(p) 57 | offset = section.getOffset(p) 58 | nodes.extend((offset + d) for d in range(dof)) 59 | return np.unique(np.asarray(nodes, dtype=IntType)) 60 | 61 | 62 | def NavierStokesBrinkmannForm( 63 | W: fd.FunctionSpace, 64 | w: fd.Function, 65 | nu, 66 | phi: Union[fd.Function, Product] = None, 67 | brinkmann_penalty: fd.Constant = None, 68 | brinkmann_min=0.0, 69 | design_domain=None, 70 | hs: Callable = hs, 71 | beta_gls=0.9, 72 | ) -> ufl.form: 73 | """Returns the Galerkin Least Squares formulation for the Navier-Stokes problem with a Brinkmann term 74 | 75 | Args: 76 | W (fd.FunctionSpace): [description] 77 | w (fd.Function): [description] 78 | phi (fd.Function): [description] 79 | nu ([type]): [description] 80 | brinkmann_penalty ([type], optional): [description]. Defaults to None. 81 | design_domain ([type], optional): Region where the level set is defined. Defaults to None. 82 | 83 | Returns: 84 | ufl.form: Nonlinear form 85 | """ 86 | mesh = w.ufl_domain() 87 | 88 | W_elem = W.ufl_element() 89 | assert isinstance(W_elem, fd.MixedElement) 90 | if brinkmann_penalty: 91 | assert isinstance(brinkmann_penalty, fd.Constant) 92 | assert W_elem.num_sub_elements() == 2 93 | 94 | for W_sub_elem in W_elem.sub_elements(): 95 | assert W_sub_elem.family() == "Lagrange" 96 | assert W_sub_elem.degree() == 1 97 | assert isinstance(W_elem.sub_elements()[0], fd.VectorElement) 98 | 99 | v, q = fd.TestFunctions(W) 100 | u, p = fd.split(w) 101 | 102 | # Main NS form 103 | F = ( 104 | nu * inner(grad(u), grad(v)) * dx 105 | + inner(dot(grad(u), u), v) * dx 106 | - p * div(v) * dx 107 | + div(u) * q * dx 108 | ) 109 | 110 | # Brinkmann terms for design 111 | def add_measures(list_dd, **kwargs): 112 | return sum((dx(dd, kwargs) for dd in list_dd[1::]), dx(list_dd[0])) 113 | 114 | def alpha(phi): 115 | return brinkmann_penalty * hs(phi) + fd.Constant(brinkmann_min) 116 | 117 | if brinkmann_penalty and phi is not None: 118 | if design_domain is not None: 119 | dx_brinkmann = partial(add_measures, Enlist(design_domain)) 120 | else: 121 | dx_brinkmann = dx 122 | 123 | F = F + alpha(phi) * inner(u, v) * dx_brinkmann() 124 | 125 | # GLS stabilization 126 | R_U = dot(u, grad(u)) - nu * div(grad(u)) + grad(p) 127 | if isinstance(beta_gls, (float, int)): 128 | beta_gls = fd.Constant(beta_gls) 129 | h = fd.CellSize(mesh) 130 | tau_gls = beta_gls * ( 131 | (4.0 * dot(u, u) / h ** 2) + 9.0 * (4.0 * nu / h ** 2) ** 2 132 | ) ** (-0.5) 133 | 134 | theta_U = dot(u, grad(v)) - nu * div(grad(v)) + grad(q) 135 | F = F + tau_gls * inner(R_U, theta_U) * dx() 136 | 137 | if brinkmann_penalty and phi is not None: 138 | tau_gls_alpha = beta_gls * ( 139 | (4.0 * dot(u, u) / h ** 2) 140 | + 9.0 * (4.0 * nu / h ** 2) ** 2 141 | + (alpha(phi) / 1.0) ** 2 142 | ) ** (-0.5) 143 | R_U_alpha = R_U + alpha(phi) * u 144 | theta_alpha = theta_U + alpha(phi) * v 145 | 146 | F = F + tau_gls_alpha * inner(R_U_alpha, theta_alpha) * dx_brinkmann() 147 | if ( 148 | design_domain is not None 149 | ): # Substract this domain from the original integral 150 | F = F - tau_gls * inner(R_U, theta_U) * dx_brinkmann() 151 | 152 | return F 153 | 154 | 155 | class NavierStokesBrinkmannSolver(object): 156 | def __init__( 157 | self, problem: fd.NonlinearVariationalProblem, **kwargs 158 | ) -> None: 159 | """Same than NonlinearVariationalSolver, but with just the SIMPLE preconditioner by default 160 | Args: 161 | problem ([type]): [description] 162 | nullspace ([type], optional): [description]. Defaults to None. 163 | solver_parameters ([type], optional): [description]. Defaults to None. 164 | """ 165 | solver_parameters_default = { 166 | # "snes_type": "ksponly", 167 | # "snes_no_convergence_test" : None, 168 | # "snes_max_it": 1, 169 | "snes_type": "newtonls", 170 | "snes_linesearch_type": "l2", 171 | "snes_linesearch_maxstep": 1.0, 172 | # "snes_monitor": None, 173 | # "snes_linesearch_monitor": None, 174 | "snes_rtol": 1.0e-4, 175 | "snes_atol": 1.0e-4, 176 | "snes_stol": 0.0, 177 | "snes_max_linear_solve_fail": 10, 178 | "snes_converged_reason": None, 179 | "ksp_type": "fgmres", 180 | "mat_type": "aij", 181 | # "default_sub_matrix_type": "aij", 182 | "ksp_rtol": 1.0e-4, 183 | "ksp_atol": 1.0e-4, 184 | "ksp_max_it": 2000, 185 | # "ksp_monitor": None, 186 | "ksp_converged_reason": None, 187 | "pc_type": "fieldsplit", 188 | "pc_fieldsplit_type": "schur", 189 | "pc_fieldsplit_schur_factorization_type": "full", 190 | "pc_fieldsplit_schur_precondition": "selfp", 191 | "fieldsplit_0": { 192 | "ksp_type": "richardson", 193 | "ksp_richardson_self_scale": False, 194 | "ksp_max_it": 1, 195 | "pc_type": "ml", 196 | "ksp_atol": 1e-2, 197 | "pc_mg_cycle_type": "v", 198 | "pc_mg_type": "full", 199 | # "ksp_converged_reason": None, 200 | # "ksp_monitor": None, 201 | }, 202 | "fieldsplit_1": { 203 | "ksp_type": "preonly", 204 | "pc_type": "ml", 205 | # "ksp_monitor": None, 206 | # "ksp_converged_reason": None, 207 | }, 208 | "fieldsplit_1_upper_ksp_type": "preonly", 209 | "fieldsplit_1_upper_pc_type": "jacobi", 210 | } 211 | solver_parameters = kwargs.pop("solver_parameters", None) 212 | if solver_parameters: 213 | solver_parameters_default.update(solver_parameters) 214 | 215 | self.solver = fd.NonlinearVariationalSolver( 216 | problem, solver_parameters=solver_parameters_default, **kwargs 217 | ) 218 | 219 | def solve(self, **kwargs): 220 | self.solver.solve(**kwargs) 221 | -------------------------------------------------------------------------------- /letop/physics/utils.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from functools import lru_cache 3 | import numpy as np 4 | import ufl 5 | import math 6 | from mpi4py import MPI 7 | 8 | 9 | @lru_cache(1) 10 | def min_mesh_size(mesh): 11 | """Calculate minimum cell diameter in mesh 12 | 13 | Args: 14 | mesh ([type]): [description] 15 | 16 | Returns: 17 | float: [description] 18 | """ 19 | DG0 = fd.FunctionSpace(mesh, "DG", 0) 20 | h_sizes = fd.assemble( 21 | fd.CellDiameter(mesh) 22 | / fd.CellVolume(mesh) 23 | * fd.TestFunction(DG0) 24 | * fd.dx 25 | ).dat.data_ro 26 | local_min_size = np.max(h_sizes) 27 | min_size = mesh.comm.allreduce(local_min_size, op=MPI.MAX) 28 | return min_size 29 | 30 | 31 | def hs( 32 | phi: fd.Function, 33 | epsilon: fd.Constant = fd.Constant(10000.0), 34 | width_h: float = None, 35 | shift: float = 0.0, 36 | min_value: fd.Function = fd.Constant(0.0), 37 | ): 38 | """Heaviside approximation 39 | 40 | Args: 41 | phi (fd.Function): Level set 42 | epsilon ([type], optional): Parameter to approximate the Heaviside. 43 | Defaults to Constant(10000.0). 44 | width_h (float): Width of the Heaviside approximation transition in 45 | terms of multiple of the mesh element size 46 | shift: (float): Shift the level set value to define the interface. 47 | 48 | Returns: 49 | [type]: [description] 50 | """ 51 | if width_h: 52 | if epsilon: 53 | fd.warning( 54 | "Epsilon and width_h are both defined, pick one or the other. \ 55 | Overriding epsilon choice" 56 | ) 57 | mesh = phi.ufl_domain() 58 | hmin = min_mesh_size(mesh) 59 | epsilon = fd.Constant( 60 | math.log(0.99 ** 2 / 0.01 ** 2) / (width_h * hmin) 61 | ) 62 | 63 | return ( 64 | fd.Constant(1.0) 65 | / (fd.Constant(1.0) + ufl.exp(-epsilon * (phi - fd.Constant(shift)))) 66 | + min_value 67 | ) 68 | 69 | 70 | def dirac_delta(phi: fd.Function, epsilon=fd.Constant(10000.0), width_h=None): 71 | """Dirac delta approximation 72 | 73 | Args: 74 | phi (fd.Function): Level set 75 | epsilon ([type], optional): Parameter to approximate the Heaviside. 76 | Defaults to Constant(10000.0). 77 | width_h (float): Width of the Heaviside approximation transition in 78 | terms of multiple of the mesh element size 79 | 80 | Returns: 81 | [type]: [description] 82 | """ 83 | if width_h: 84 | if epsilon: 85 | fd.warning( 86 | "Epsilon and width_h are both defined, pick one or the other. \ 87 | Overriding epsilon choice" 88 | ) 89 | mesh = phi.ufl_domain() 90 | hmin = min_mesh_size(mesh) 91 | epsilon = fd.Constant( 92 | math.log(0.95 ** 2 / 0.05 ** 2) / (width_h * hmin) 93 | ) 94 | 95 | return ( 96 | fd.Constant(epsilon) 97 | * ufl.exp(-epsilon * phi) 98 | / (fd.Constant(1.0) + ufl.exp(-epsilon * phi)) ** 2 99 | ) 100 | 101 | 102 | def calculate_max_vel(velocity: fd.Function): 103 | mesh = velocity.ufl_domain() 104 | MAXSP = fd.FunctionSpace(mesh, "R", 0) 105 | maxv = fd.Function(MAXSP) 106 | domain = "{[i, j] : 0 <= i < u.dofs}" 107 | instruction = """ 108 | maxv[0] = abs(u[i, 0]) + abs(u[i, 1]) 109 | """ 110 | fd.par_loop( 111 | (domain, instruction), 112 | fd.dx, 113 | {"u": (velocity, fd.READ), "maxv": (maxv, fd.MAX)}, 114 | is_loopy_kernel=True, 115 | ) 116 | maxval = maxv.dat.data[0] 117 | return maxval 118 | 119 | 120 | @lru_cache(1) 121 | def max_mesh_dimension(mesh: fd.Mesh): 122 | coords = mesh.coordinates 123 | MAXSP = fd.FunctionSpace(mesh, "R", 0) 124 | max_y = fd.Function(MAXSP) 125 | min_y = fd.Function(MAXSP) 126 | max_x = fd.Function(MAXSP) 127 | min_x = fd.Function(MAXSP) 128 | domain = "{[i, j] : 0 <= i < u.dofs}" 129 | 130 | def extract_comp(mode, comp, result): 131 | instruction = f""" 132 | component[0] = abs(u[i, {comp}]) 133 | """ 134 | fd.par_loop( 135 | (domain, instruction), 136 | fd.dx, 137 | {"u": (coords, fd.READ), "component": (result, mode)}, 138 | is_loopy_kernel=True, 139 | ) 140 | return result 141 | 142 | max_y_comp = extract_comp(fd.MAX, 1, max_y).dat.data[0] 143 | min_y_comp = extract_comp(fd.MIN, 1, min_y).dat.data[0] 144 | max_x_comp = extract_comp(fd.MAX, 0, max_x).dat.data[0] 145 | min_x_comp = extract_comp(fd.MIN, 0, min_x).dat.data[0] 146 | max_dim_x = abs(max_x_comp - min_x_comp) 147 | max_dim_y = abs(max_y_comp - min_y_comp) 148 | 149 | max_dim = max(max_dim_x, max_dim_y) 150 | if mesh.geometric_dimension() == 3: 151 | max_z = fd.Function(MAXSP) 152 | min_z = fd.Function(MAXSP) 153 | max_z_comp = extract_comp(fd.MAX, 2, max_z).dat.data[0] 154 | min_z_comp = extract_comp(fd.MIN, 2, min_z).dat.data[0] 155 | max_dim_z = abs(max_z_comp - min_z_comp) 156 | max_dim = max(max_dim, max_dim_z) 157 | 158 | return max_dim 159 | -------------------------------------------------------------------------------- /letop_examples/__init__.py: -------------------------------------------------------------------------------- 1 | from .heat_exchanger import heat_exchanger_optimization 2 | from .cantilever import compliance_optimization 3 | -------------------------------------------------------------------------------- /letop_examples/bridge/bridge.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from firedrake import ( 3 | cos, 4 | pi, 5 | inner, 6 | grad, 7 | dx, 8 | ds, 9 | sym, 10 | nabla_grad, 11 | tr, 12 | Identity, 13 | ds_t, 14 | ) 15 | import firedrake_adjoint as fda 16 | import numpy as np 17 | 18 | from letop.levelset import LevelSetFunctional, RegularizationSolver 19 | from letop.optimization import InfDimProblem, Constraint 20 | from letop.physics import hs 21 | from letop.optimization import nlspace_solve 22 | import itertools 23 | from firedrake import PETSc 24 | from solver_parameters import ( 25 | gamg_parameters, 26 | hj_solver_parameters, 27 | reinit_solver_parameters, 28 | ) 29 | 30 | 31 | import argparse 32 | 33 | fd.parameters["pyop2_options"]["block_sparsity"] = False 34 | 35 | 36 | def print(x): 37 | PETSc.Sys.Print(x) 38 | 39 | 40 | class MyBC(fd.DirichletBC): 41 | def __init__(self, V, value, markers): 42 | # Call superclass init 43 | # We provide a dummy subdomain id. 44 | super(MyBC, self).__init__(V, value, 0) 45 | # Override the "nodes" property which says where the boundary 46 | # condition is to be applied. 47 | self.nodes = np.unique(np.where(markers.dat.data_ro_with_halos > 0)[0]) 48 | 49 | 50 | def create_function_marker(PHI, W, xlimits, ylimits): 51 | x, y, z = fd.SpatialCoordinate(PHI.ufl_domain()) 52 | x_func, y_func, z_func = ( 53 | fd.Function(PHI), 54 | fd.Function(PHI), 55 | fd.Function(PHI), 56 | ) 57 | with fda.stop_annotating(): 58 | x_func.interpolate(x) 59 | y_func.interpolate(y) 60 | z_func.interpolate(z) 61 | 62 | domain = "{[i, j]: 0 <= i < f.dofs and 0<= j <= 3}" 63 | instruction = f""" 64 | f[i, j] = 1.0 if (x[i, 0] < {xlimits[1]} and x[i, 0] > {xlimits[0]}) and (y[i, 0] < {ylimits[0]} or y[i, 0] > {ylimits[1]}) and z[i, 0] < 1e-7 else 0.0 65 | """ 66 | I_BC = fd.Function(W) 67 | fd.par_loop( 68 | (domain, instruction), 69 | dx, 70 | { 71 | "f": (I_BC, fd.RW), 72 | "x": (x_func, fd.READ), 73 | "y": (y_func, fd.READ), 74 | "z": (z_func, fd.READ), 75 | }, 76 | is_loopy_kernel=True, 77 | ) 78 | 79 | return I_BC 80 | 81 | 82 | def compliance_bridge(): 83 | 84 | parser = argparse.ArgumentParser(description="Heat exchanger") 85 | parser.add_argument( 86 | "--n_iters", 87 | dest="n_iters", 88 | type=int, 89 | action="store", 90 | default=1000, 91 | help="Number of optimization iterations", 92 | ) 93 | parser.add_argument( 94 | "--output_dir", 95 | dest="output_dir", 96 | type=str, 97 | action="store", 98 | default="./", 99 | help="Output directory", 100 | ) 101 | opts = parser.parse_args() 102 | output_dir = opts.output_dir 103 | # Elasticity parameters 104 | E, nu = 1.0, 0.3 105 | rho_min = fd.Constant(1e-4) # Min Vol fraction 106 | eps = fd.Constant(100.0) # Heaviside parameter 107 | mu, lmbda = fd.Constant(E / (2 * (1 + nu))), fd.Constant( 108 | E * nu / ((1 + nu) * (1 - 2 * nu)) 109 | ) 110 | 111 | mesh = fd.RectangleMesh(20, 40, 0.5, 1, quadrilateral=True) 112 | mh = fd.MeshHierarchy(mesh, 1) 113 | m = fd.ExtrudedMeshHierarchy(mh, height=1, base_layer=40) 114 | mesh = m[-1] 115 | 116 | S = fd.VectorFunctionSpace(mesh, "CG", 1) 117 | s = fd.Function(S, name="deform") 118 | mesh.coordinates.assign(mesh.coordinates + s) 119 | 120 | x, y, z = fd.SpatialCoordinate(mesh) 121 | PHI = fd.FunctionSpace(mesh, "CG", 1) 122 | lx = 1.0 123 | ly = 2.0 124 | lz = ly 125 | phi_expr = ( 126 | -cos(4.0 / lx * pi * x) 127 | * cos(4.0 * pi / ly * y) 128 | * cos(4.0 / lz * pi * z) 129 | - 0.6 130 | ) 131 | with fda.stop_annotating(): 132 | phi = fd.interpolate(-phi_expr, PHI) 133 | phi.rename("LevelSet") 134 | 135 | H1 = fd.VectorElement("CG", mesh.ufl_cell(), 1) 136 | W = fd.FunctionSpace(mesh, H1) 137 | print(f"DOFS: {W.dim()}") 138 | 139 | modes = [fd.Function(W) for _ in range(6)] 140 | modes[0].interpolate(fd.Constant([1, 0, 0])) 141 | modes[1].interpolate(fd.Constant([0, 1, 0])) 142 | modes[2].interpolate(fd.Constant([0, 0, 1])) 143 | modes[3].interpolate(fd.as_vector([0, z, -y])) 144 | modes[4].interpolate(fd.as_vector([-z, 0, x])) 145 | modes[5].interpolate(fd.as_vector([y, -x, 0])) 146 | nullmodes = fd.VectorSpaceBasis(modes) 147 | # Make sure they're orthonormal. 148 | nullmodes.orthonormalize() 149 | 150 | u = fd.TrialFunction(W) 151 | v = fd.TestFunction(W) 152 | 153 | def epsilon(u): 154 | return sym(nabla_grad(u)) 155 | 156 | def sigma(v): 157 | return 2.0 * mu * epsilon(v) + lmbda * tr(epsilon(v)) * Identity(3) 158 | 159 | # Variational forms 160 | a = inner(hs(phi, eps, min_value=rho_min) * sigma(u), nabla_grad(v)) * dx( 161 | degree=2 162 | ) 163 | t = fd.Constant((0.0, 0.0, -1.0e-1)) 164 | L = inner(t, v) * ds_t 165 | 166 | # Dirichlet BCs 167 | ylimits = (0.2, 1.8) 168 | xlimits = (0.4, 0.6) 169 | I_BC = create_function_marker(PHI, W, xlimits, ylimits) 170 | bc1 = MyBC(W, 0, I_BC) 171 | bc2 = fd.DirichletBC(W.sub(0), fd.Constant(0.0), 2) 172 | bc3 = fd.DirichletBC(W.sub(1), fd.Constant(0.0), 4) 173 | 174 | u_sol = fd.Function(W) 175 | fd.solve( 176 | a == L, 177 | u_sol, 178 | bcs=[bc1, bc2, bc3], 179 | solver_parameters=gamg_parameters, 180 | near_nullspace=nullmodes, 181 | ) 182 | 183 | # Cost function 184 | Jform = fd.assemble( 185 | inner(hs(phi, eps, min_value=rho_min) * sigma(u_sol), epsilon(u_sol)) 186 | * dx(degree=2) 187 | ) 188 | # Constraint 189 | VolPen = fd.assemble(hs(phi, eps, min_value=rho_min) * dx(degree=2)) 190 | total_vol = fd.assemble(fd.Constant(1.0) * dx(domain=mesh), annotate=False) 191 | VolControl = fda.Control(VolPen) 192 | Vval = 0.15 * total_vol 193 | 194 | # Plotting 195 | global_counter1 = itertools.count() 196 | phi_pvd = fd.File(f"{output_dir}/level_set_evolution.pvd") 197 | 198 | def deriv_cb(phi): 199 | iter = next(global_counter1) 200 | if iter % 10 == 0: 201 | phi_pvd.write(phi[0]) 202 | 203 | c = fda.Control(s) 204 | Jhat = LevelSetFunctional(Jform, c, phi, derivative_cb_pre=deriv_cb) 205 | Vhat = LevelSetFunctional(VolPen, c, phi) 206 | 207 | # Regularization solver. Zero on the BCs boundaries 208 | beta_param = 0.005 209 | bcs_vel_1 = MyBC(S, 0, I_BC) 210 | bcs_vel_2 = fd.DirichletBC(S, fd.Constant((0.0, 0.0, 0.0)), "top") 211 | bcs_vel = [bcs_vel_1, bcs_vel_2] 212 | reg_solver = RegularizationSolver( 213 | S, 214 | mesh, 215 | beta=beta_param, 216 | gamma=1.0e4, 217 | dx=dx, 218 | bcs=bcs_vel, 219 | output_dir=None, 220 | solver_parameters=gamg_parameters, 221 | ) 222 | dt = 0.05 223 | tol = 1e-5 224 | 225 | params = { 226 | "alphaC": 1.0, 227 | "K": 0.0001, 228 | "debug": 5, 229 | "maxit": opts.n_iters, 230 | "alphaJ": 2.0, 231 | "dt": dt, 232 | "maxtrials": 500, 233 | "tol_merit": 5e-2, # new merit can be within 0.5% of the previous merit 234 | "itnormalisation": 50, 235 | "tol": tol, 236 | } 237 | hj_solver_parameters["ts_dt"] = dt / 50.0 238 | solver_parameters = { 239 | "hj_solver": hj_solver_parameters, 240 | "reinit_solver": reinit_solver_parameters, 241 | } 242 | 243 | vol_constraint = Constraint(Vhat, Vval, VolControl) 244 | problem = InfDimProblem( 245 | Jhat, 246 | reg_solver, 247 | ineqconstraints=vol_constraint, 248 | solver_parameters=solver_parameters, 249 | ) 250 | _ = nlspace_solve(problem, params) 251 | 252 | 253 | if __name__ == "__main__": 254 | compliance_bridge() 255 | -------------------------------------------------------------------------------- /letop_examples/bridge/solver_parameters.py: -------------------------------------------------------------------------------- 1 | gamg_parameters = { 2 | "ksp_type": "cg", 3 | "ksp_max_it": 200, 4 | "pc_type": "gamg", 5 | "mat_type": "aij", 6 | "ksp_converged_reason": None, 7 | "mg_levels_esteig_ksp_type": "cg", 8 | "mg_levels_ksp_chebyshev_esteig_steps": 50, 9 | "mg_levels_ksp_type": "chebyshev", 10 | "mg_levels_pc_type": "sor", 11 | "pc_gamg_type": "agg", 12 | "pc_gamg_agg_nsmooths": 1, 13 | "pc_gamg_threshold": 0.01, 14 | } 15 | 16 | hj_solver_parameters = { 17 | "peclet_number": 1e-3, 18 | "ksp_type": "gmres", 19 | "ksp_converged_maxits": None, 20 | "snes_type": "ksponly", 21 | "snes_no_convergence_test": None, 22 | "snes_atol": 1e-5, 23 | "ksp_atol": 1e-5, 24 | "ksp_rtol": 1e-5, 25 | "ts_type": "beuler", 26 | "pc_type": "bjacobi", 27 | "sub_pc_type": "ilu", 28 | "sub_pc_factor_levels": 1, 29 | "ksp_max_it": 5000, 30 | "ksp_gmres_restart": 200, 31 | "ts_atol": 1e-5, 32 | "ts_rtol": 1e-5, 33 | "ts_max_steps": 400, 34 | } 35 | 36 | reinit_solver_parameters = { 37 | "ksp_type": "cg", 38 | "ksp_rtol": 1e-6, 39 | "pc_type": "hypre", 40 | "pc_hypre_type": "boomeramg", 41 | "pc_hypre_boomeramg_max_iter": 5, 42 | "pc_hypre_boomeramg_coarsen_type": "PMIS", 43 | "pc_hypre_boomeramg_agg_nl": 2, 44 | "pc_hypre_boomeramg_strong_threshold": 0.95, 45 | "pc_hypre_boomeramg_interp_type": "ext+i", 46 | "pc_hypre_boomeramg_P_max": 2, 47 | "pc_hypre_boomeramg_relax_type_all": "sequential-Gauss-Seidel", 48 | "pc_hypre_boomeramg_grid_sweeps_all": 1, 49 | "pc_hypre_boomeramg_truncfactor": 0.3, 50 | "pc_hypre_boomeramg_max_levels": 6, 51 | "ksp_max_it": 200, 52 | "ksp_converged_maxits": None, 53 | } 54 | -------------------------------------------------------------------------------- /letop_examples/cantilever/__init__.py: -------------------------------------------------------------------------------- 1 | from .cantilever import compliance_optimization 2 | -------------------------------------------------------------------------------- /letop_examples/cantilever/cantilever.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | import firedrake_adjoint as fda 3 | from firedrake import ( 4 | inner, 5 | dx, 6 | ds, 7 | cos, 8 | pi, 9 | exp, 10 | max_value, 11 | sym, 12 | nabla_grad, 13 | tr, 14 | Identity, 15 | ) 16 | 17 | from letop.levelset import LevelSetFunctional, RegularizationSolver 18 | from letop.optimization import InfDimProblem, Constraint 19 | from letop.optimization import nlspace_solve 20 | 21 | import os 22 | 23 | 24 | def compliance_optimization(n_iters=200): 25 | 26 | output_dir = "cantilever/" 27 | 28 | path = os.path.abspath(__file__) 29 | dir_path = os.path.dirname(path) 30 | m = fd.Mesh(f"{dir_path}/mesh_cantilever.msh") 31 | mesh = fd.MeshHierarchy(m, 0)[-1] 32 | 33 | # Perturb the mesh coordinates. Necessary to calculate shape derivatives 34 | S = fd.VectorFunctionSpace(mesh, "CG", 1) 35 | s = fd.Function(S, name="deform") 36 | mesh.coordinates.assign(mesh.coordinates + s) 37 | 38 | # Initial level set function 39 | x, y = fd.SpatialCoordinate(mesh) 40 | PHI = fd.FunctionSpace(mesh, "CG", 1) 41 | lx = 2.0 42 | ly = 1.0 43 | phi_expr = ( 44 | -cos(6.0 / lx * pi * x) * cos(4.0 * pi * y) 45 | - 0.6 46 | + max_value(200.0 * (0.01 - x ** 2 - (y - ly / 2) ** 2), 0.0) 47 | + max_value(100.0 * (x + y - lx - ly + 0.1), 0.0) 48 | + max_value(100.0 * (x - y - lx + 0.1), 0.0) 49 | ) 50 | # Avoid recording the operation interpolate into the tape. 51 | # Otherwise, the shape derivatives will not be correct 52 | with fda.stop_annotating(): 53 | phi = fd.interpolate(phi_expr, PHI) 54 | phi.rename("LevelSet") 55 | fd.File(output_dir + "phi_initial.pvd").write(phi) 56 | 57 | # Physics. Elasticity 58 | rho_min = 1e-5 59 | beta = fd.Constant(200.0) 60 | 61 | def hs(phi, beta): 62 | return fd.Constant(1.0) / ( 63 | fd.Constant(1.0) + exp(-beta * phi) 64 | ) + fd.Constant(rho_min) 65 | 66 | H1_elem = fd.VectorElement("CG", mesh.ufl_cell(), 1) 67 | W = fd.FunctionSpace(mesh, H1_elem) 68 | 69 | u = fd.TrialFunction(W) 70 | v = fd.TestFunction(W) 71 | 72 | # Elasticity parameters 73 | E, nu = 1.0, 0.3 74 | mu, lmbda = fd.Constant(E / (2 * (1 + nu))), fd.Constant( 75 | E * nu / ((1 + nu) * (1 - 2 * nu)) 76 | ) 77 | 78 | def epsilon(u): 79 | return sym(nabla_grad(u)) 80 | 81 | def sigma(v): 82 | return 2.0 * mu * epsilon(v) + lmbda * tr(epsilon(v)) * Identity(2) 83 | 84 | a = inner(hs(-phi, beta) * sigma(u), nabla_grad(v)) * dx 85 | t = fd.Constant((0.0, -75.0)) 86 | L = inner(t, v) * ds(2) 87 | 88 | bc = fd.DirichletBC(W, fd.Constant((0.0, 0.0)), 1) 89 | parameters = { 90 | "ksp_type": "preonly", 91 | "pc_type": "lu", 92 | "mat_type": "aij", 93 | "ksp_converged_reason": None, 94 | "pc_factor_mat_solver_type": "mumps", 95 | } 96 | u_sol = fd.Function(W) 97 | F = fd.action(a, u_sol) - L 98 | problem = fd.NonlinearVariationalProblem(F, u_sol, bcs=bc) 99 | solver = fd.NonlinearVariationalSolver( 100 | problem, solver_parameters=parameters 101 | ) 102 | solver.solve() 103 | # fd.solve( 104 | # a == L, u_sol, bcs=[bc], solver_parameters=parameters 105 | # ) # , nullspace=nullspace) 106 | with fda.stop_annotating(): 107 | fd.File("u_sol.pvd").write(u_sol) 108 | 109 | # Cost function: Compliance 110 | J = fd.assemble( 111 | fd.Constant(1e-2) 112 | * inner(hs(-phi, beta) * sigma(u_sol), epsilon(u_sol)) 113 | * dx 114 | ) 115 | 116 | # Constraint: Volume 117 | with fda.stop_annotating(): 118 | total_volume = fd.assemble(fd.Constant(1.0) * dx(domain=mesh)) 119 | VolPen = fd.assemble(hs(-phi, beta) * dx) 120 | # Needed to track the value of the volume 121 | VolControl = fda.Control(VolPen) 122 | Vval = total_volume / 2.0 123 | 124 | phi_pvd = fd.File("phi_evolution.pvd", target_continuity=fd.H1) 125 | 126 | def deriv_cb(phi): 127 | with fda.stop_annotating(): 128 | phi_pvd.write(phi[0]) 129 | 130 | c = fda.Control(s) 131 | Jhat = LevelSetFunctional(J, c, phi, derivative_cb_pre=deriv_cb) 132 | Vhat = LevelSetFunctional(VolPen, c, phi) 133 | beta_param = 0.1 134 | # Boundary conditions for the shape derivatives. 135 | # They must be zero at the boundary conditions. 136 | bcs_vel = fd.DirichletBC(S, fd.Constant((0.0, 0.0)), (1, 2)) 137 | # Regularize the shape derivatives 138 | reg_solver = RegularizationSolver( 139 | S, 140 | mesh, 141 | beta=beta_param, 142 | gamma=1.0e5, 143 | dx=dx, 144 | bcs=bcs_vel, 145 | output_dir=None, 146 | ) 147 | # Hamilton-Jacobi equation to advect the level set 148 | dt = 0.05 149 | tol = 1e-5 150 | 151 | # Optimization problem 152 | vol_constraint = Constraint(Vhat, Vval, VolControl) 153 | problem = InfDimProblem(Jhat, reg_solver, ineqconstraints=vol_constraint) 154 | 155 | parameters = { 156 | "ksp_type": "preonly", 157 | "pc_type": "lu", 158 | "mat_type": "aij", 159 | "ksp_converged_reason": None, 160 | "pc_factor_mat_solver_type": "mumps", 161 | } 162 | 163 | params = { 164 | "alphaC": 3.0, 165 | "K": 0.1, 166 | "debug": 5, 167 | "alphaJ": 1.0, 168 | "dt": dt, 169 | "maxtrials": 10, 170 | "maxit": n_iters, 171 | "itnormalisation": 50, 172 | "tol": tol, 173 | } 174 | results = nlspace_solve(problem, params) 175 | 176 | return results 177 | 178 | 179 | if __name__ == "__main__": 180 | compliance_optimization() 181 | -------------------------------------------------------------------------------- /letop_examples/cantilever/mesh_cantilever.geo: -------------------------------------------------------------------------------- 1 | size = 0.02; 2 | width = 2.0; 3 | height = 1.0; 4 | p0 = newp; 5 | Point(p0) = {0.0, 0.0, 0.0, size}; 6 | p1 = newp; 7 | Point(p1) = {width, 0.0, 0.0, size}; 8 | p2 = newp; 9 | Point(p2) = {width, 15.0/32.0 * height, 0.0, size}; 10 | p3 = newp; 11 | Point(p3) = {width, 17.0/32.0 * height, 0.0, size}; 12 | p4 = newp; 13 | Point(p4) = {width, height, 0.0, size}; 14 | p5 = newp; 15 | Point(p5) = {0.0, height, 0.0, size}; 16 | 17 | l0 = newl; 18 | Line(l0) = {p0, p1}; 19 | l1 = newl; 20 | Line(l1) = {p1, p2}; 21 | l2 = newl; 22 | Line(l2) = {p2, p3}; 23 | l3 = newl; 24 | Line(l3) = {p3, p4}; 25 | l4 = newl; 26 | Line(l4) = {p4, p5}; 27 | l5 = newl; 28 | Line(l5) = {p5, p0}; 29 | 30 | ll0 = newll; 31 | Line Loop(ll0) = {l0, l1, l2, l3, l4, l5}; 32 | s0 = news; 33 | Plane Surface(s0) = {ll0}; 34 | Physical Line(1) = {l5}; 35 | Physical Line(2) = {l2}; 36 | Physical Surface(0) = {s0}; 37 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger/2D_mesh.geo: -------------------------------------------------------------------------------- 1 | // This code was created by pygmsh vunknown. 2 | SetFactory("OpenCASCADE"); 3 | Mesh.CharacteristicLengthMin = 0.02; 4 | Mesh.CharacteristicLengthMax = 0.02; 5 | s0 = news; 6 | Rectangle(s0) = {0.0, 0.0, 0.0, 1.2, 1.5}; 7 | s1 = news; 8 | Rectangle(s1) = {-0.2, -2.7755575615628914e-17, 0.0, 0.2, 0.2}; 9 | s2 = news; 10 | Rectangle(s2) = {-0.2, 0.26, 0.0, 0.2, 0.2}; 11 | s3 = news; 12 | Rectangle(s3) = {1.2, -2.7755575615628914e-17, 0.0, 0.2, 0.2}; 13 | s4 = news; 14 | Rectangle(s4) = {1.2, 0.26, 0.0, 0.2, 0.2}; 15 | Physical Surface(2) = {s1}; 16 | Physical Surface(3) = {s2}; 17 | Physical Surface(4) = {s3}; 18 | Physical Surface(5) = {s4}; 19 | Physical Surface(0) = {s0}; 20 | bo1[] = BooleanFragments{ Surface{s0}; Delete; } { Surface{s1};Surface{s2};Surface{s3};Surface{s4}; Delete;}; 21 | vb1[] = Boundary{Surface{ s1 };}; 22 | vb2[] = Boundary{Surface{ s2 };}; 23 | vb3[] = Boundary{Surface{ s3 };}; 24 | vb4[] = Boundary{Surface{ s4 };}; 25 | vb0[] = Boundary{Surface{ s0 };}; 26 | Physical Curve(5) = {vb0[], 27 | vb1[0], vb1[2], 28 | vb2[0], vb2[2], 29 | vb3[0], vb3[2], 30 | vb4[0], vb4[2]}; 31 | Physical Curve(5) -= {-vb1[1], -vb2[1], -vb3[3], -vb4[3]}; 32 | Physical Curve(1) = {vb1[3]}; 33 | Physical Curve(2) = {vb3[1]}; 34 | Physical Curve(3) = {vb2[3]}; 35 | Physical Curve(4) = {vb4[1]}; 36 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger/2D_mesh.py: -------------------------------------------------------------------------------- 1 | import pygmsh as pg 2 | from heat_exchanger_nls import ( 3 | height, 4 | width, 5 | dist_center, 6 | inlet_width, 7 | inlet_depth, 8 | line_sep, 9 | ymin1, 10 | ymin2, 11 | ) 12 | from heat_exchanger_nls import ( 13 | INMOUTH1, 14 | INMOUTH2, 15 | OUTMOUTH1, 16 | OUTMOUTH2, 17 | INLET1, 18 | INLET2, 19 | OUTLET1, 20 | OUTLET2, 21 | WALLS, 22 | DOMAIN, 23 | ) 24 | 25 | 26 | def main(): 27 | size = 0.02 28 | geom = pg.opencascade.Geometry( 29 | characteristic_length_min=size, characteristic_length_max=size 30 | ) 31 | 32 | main_rect = geom.add_rectangle([0.0, 0.0, 0.0], width, height) 33 | mouth_inlet1 = geom.add_rectangle( 34 | [-inlet_depth, ymin1, 0.0], inlet_depth, inlet_width 35 | ) 36 | mouth_inlet2 = geom.add_rectangle( 37 | [-inlet_depth, ymin2, 0.0], inlet_depth, inlet_width 38 | ) 39 | 40 | mouth_outlet1 = geom.add_rectangle( 41 | [width, ymin1, 0.0], inlet_depth, inlet_width 42 | ) 43 | mouth_outlet2 = geom.add_rectangle( 44 | [width, ymin2, 0.0], inlet_depth, inlet_width 45 | ) 46 | 47 | print("ymin1 :{}".format(ymin1)) 48 | print("ymin2 :{}".format(ymin2)) 49 | 50 | geom.add_physical(mouth_inlet1, INMOUTH1) 51 | geom.add_physical(mouth_inlet2, INMOUTH2) 52 | geom.add_physical(mouth_outlet1, OUTMOUTH1) 53 | geom.add_physical(mouth_outlet2, OUTMOUTH2) 54 | geom.add_physical([main_rect], DOMAIN) 55 | 56 | _ = geom.boolean_fragments( 57 | [main_rect], [mouth_inlet1, mouth_inlet2, mouth_outlet1, mouth_outlet2] 58 | ) 59 | 60 | geom.add_raw_code( 61 | """vb1[] = Boundary{{Surface{{ {0} }};}}; 62 | vb2[] = Boundary{{Surface{{ {1} }};}}; 63 | vb3[] = Boundary{{Surface{{ {2} }};}}; 64 | vb4[] = Boundary{{Surface{{ {3} }};}}; 65 | vb0[] = Boundary{{Surface{{ {4} }};}};""".format( 66 | mouth_inlet1.id, 67 | mouth_inlet2.id, 68 | mouth_outlet1.id, 69 | mouth_outlet2.id, 70 | main_rect.id, 71 | ) 72 | ) 73 | geom.add_raw_code( 74 | """Physical Curve({0}) = {{vb0[], 75 | vb1[0], vb1[2], 76 | vb2[0], vb2[2], 77 | vb3[0], vb3[2], 78 | vb4[0], vb4[2]}};""".format( 79 | WALLS 80 | ) 81 | ) 82 | 83 | geom.add_raw_code( 84 | "Physical Curve({0}) -= {{-vb1[1], -vb2[1], -vb3[3], -vb4[3]}};\n \ 85 | Physical Curve({1}) = {{vb1[3]}};\n \ 86 | Physical Curve({2}) = {{vb3[1]}};\n \ 87 | Physical Curve({3}) = {{vb2[3]}};\n \ 88 | Physical Curve({4}) = {{vb4[1]}};".format( 89 | WALLS, INLET1, OUTLET1, INLET2, OUTLET2 90 | ) 91 | ) 92 | 93 | mesh = pg.generate_mesh(geom, geo_filename="2D_mesh.geo") 94 | import meshio 95 | 96 | meshio.write("2D_mesh_heat_exchanger.vtk", mesh) 97 | 98 | 99 | if __name__ == "__main__": 100 | main() 101 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger/README.md: -------------------------------------------------------------------------------- 1 | Example code used in the paper "Two dimensional topology optimization of heat exchangers with the density and level-set methods", Miguel Salazar et al. 2 | Run with 3 | ```python 4 | python3 heat_exchanger_nls.py --mu 0.02 5 | ``` 6 | for a simulation with dynamic viscosity equal to 0.02. 7 | 8 | ![heat_exchanger](https://media.giphy.com/media/YhgqJt24PCXJgUdmLu/giphy.gif) 9 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger/__init__.py: -------------------------------------------------------------------------------- 1 | from .heat_exchanger_nls import heat_exchanger_optimization 2 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger/heat_exchanger_nls.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | import firedrake_adjoint as fda 3 | from firedrake import ( 4 | inner, 5 | derivative, 6 | grad, 7 | div, 8 | dx, 9 | ds, 10 | dot, 11 | dS, 12 | jump, 13 | avg, 14 | sin, 15 | cos, 16 | pi, 17 | exp, 18 | ) 19 | 20 | from letop.levelset import LevelSetFunctional, RegularizationSolver 21 | from letop.optimization import InfDimProblem, Constraint 22 | from letop.optimization import nlspace_solve 23 | 24 | from pyadjoint import stop_annotating 25 | import os 26 | 27 | # Parameters 28 | height = 1.5 29 | shift_center = 0.52 30 | dist_center = 0.03 31 | inlet_width = 0.2 32 | inlet_depth = 0.2 33 | width = 1.2 34 | line_sep = height / 2.0 - shift_center 35 | # Line separating both inlets 36 | DOMAIN = 0 37 | INMOUTH1 = 2 38 | INMOUTH2 = 3 39 | OUTMOUTH1 = 4 40 | OUTMOUTH2 = 5 41 | INLET1, OUTLET1, INLET2, OUTLET2, WALLS, DESIGNBC = 1, 2, 3, 4, 5, 6 42 | ymin1 = line_sep - (dist_center + inlet_width) 43 | ymin2 = line_sep + dist_center 44 | 45 | 46 | def heat_exchanger_optimization(mu=0.03, n_iters=1000): 47 | 48 | output_dir = "2D/" 49 | 50 | path = os.path.abspath(__file__) 51 | dir_path = os.path.dirname(path) 52 | mesh = fd.Mesh(f"{dir_path}/2D_mesh.msh") 53 | # Perturb the mesh coordinates. Necessary to calculate shape derivatives 54 | S = fd.VectorFunctionSpace(mesh, "CG", 1) 55 | s = fd.Function(S, name="deform") 56 | mesh.coordinates.assign(mesh.coordinates + s) 57 | 58 | # Initial level set function 59 | x, y = fd.SpatialCoordinate(mesh) 60 | PHI = fd.FunctionSpace(mesh, "CG", 1) 61 | phi_expr = sin(y * pi / 0.2) * cos(x * pi / 0.2) - fd.Constant(0.8) 62 | # Avoid recording the operation interpolate into the tape. 63 | # Otherwise, the shape derivatives will not be correct 64 | with fda.stop_annotating(): 65 | phi = fd.interpolate(phi_expr, PHI) 66 | phi.rename("LevelSet") 67 | fd.File(output_dir + "phi_initial.pvd").write(phi) 68 | 69 | # Physics 70 | mu = fd.Constant(mu) # viscosity 71 | alphamin = 1e-12 72 | alphamax = 2.5 / (2e-4) 73 | parameters = { 74 | "mat_type": "aij", 75 | "ksp_type": "preonly", 76 | "ksp_converged_reason": None, 77 | "pc_type": "lu", 78 | "pc_factor_mat_solver_type": "mumps", 79 | } 80 | stokes_parameters = parameters 81 | temperature_parameters = parameters 82 | u_inflow = 2e-3 83 | tin1 = fd.Constant(10.0) 84 | tin2 = fd.Constant(100.0) 85 | 86 | P2 = fd.VectorElement("CG", mesh.ufl_cell(), 2) 87 | P1 = fd.FiniteElement("CG", mesh.ufl_cell(), 1) 88 | TH = P2 * P1 89 | W = fd.FunctionSpace(mesh, TH) 90 | 91 | U = fd.TrialFunction(W) 92 | u, p = fd.split(U) 93 | V = fd.TestFunction(W) 94 | v, q = fd.split(V) 95 | 96 | epsilon = fd.Constant(10000.0) 97 | 98 | def hs(phi, epsilon): 99 | return fd.Constant(alphamax) * fd.Constant(1.0) / ( 100 | fd.Constant(1.0) + exp(-epsilon * phi) 101 | ) + fd.Constant(alphamin) 102 | 103 | def stokes(phi, BLOCK_INLET_MOUTH, BLOCK_OUTLET_MOUTH): 104 | a_fluid = mu * inner(grad(u), grad(v)) - div(v) * p - q * div(u) 105 | darcy_term = inner(u, v) 106 | return ( 107 | a_fluid * dx 108 | + hs(phi, epsilon) * darcy_term * dx(0) 109 | + alphamax 110 | * darcy_term 111 | * (dx(BLOCK_INLET_MOUTH) + dx(BLOCK_OUTLET_MOUTH)) 112 | ) 113 | 114 | # Dirichlet boundary conditions 115 | inflow1 = fd.as_vector( 116 | [ 117 | u_inflow 118 | * sin( 119 | ((y - (line_sep - (dist_center + inlet_width))) * pi) 120 | / inlet_width 121 | ), 122 | 0.0, 123 | ] 124 | ) 125 | inflow2 = fd.as_vector( 126 | [ 127 | u_inflow 128 | * sin(((y - (line_sep + dist_center)) * pi) / inlet_width), 129 | 0.0, 130 | ] 131 | ) 132 | 133 | noslip = fd.Constant((0.0, 0.0)) 134 | 135 | # Stokes 1 136 | bcs1_1 = fd.DirichletBC(W.sub(0), noslip, WALLS) 137 | bcs1_2 = fd.DirichletBC(W.sub(0), inflow1, INLET1) 138 | bcs1_3 = fd.DirichletBC(W.sub(1), fd.Constant(0.0), OUTLET1) 139 | bcs1_4 = fd.DirichletBC(W.sub(0), noslip, INLET2) 140 | bcs1_5 = fd.DirichletBC(W.sub(0), noslip, OUTLET2) 141 | bcs1 = [bcs1_1, bcs1_2, bcs1_3, bcs1_4, bcs1_5] 142 | 143 | # Stokes 2 144 | bcs2_1 = fd.DirichletBC(W.sub(0), noslip, WALLS) 145 | bcs2_2 = fd.DirichletBC(W.sub(0), inflow2, INLET2) 146 | bcs2_3 = fd.DirichletBC(W.sub(1), fd.Constant(0.0), OUTLET2) 147 | bcs2_4 = fd.DirichletBC(W.sub(0), noslip, INLET1) 148 | bcs2_5 = fd.DirichletBC(W.sub(0), noslip, OUTLET1) 149 | bcs2 = [bcs2_1, bcs2_2, bcs2_3, bcs2_4, bcs2_5] 150 | 151 | # Forward problems 152 | U1, U2 = fd.Function(W), fd.Function(W) 153 | L = inner(fd.Constant((0.0, 0.0, 0.0)), V) * dx 154 | problem = fd.LinearVariationalProblem( 155 | stokes(-phi, INMOUTH2, OUTMOUTH2), L, U1, bcs=bcs1 156 | ) 157 | solver_stokes1 = fd.LinearVariationalSolver( 158 | problem, solver_parameters=stokes_parameters, options_prefix="stokes_1" 159 | ) 160 | solver_stokes1.solve() 161 | problem = fd.LinearVariationalProblem( 162 | stokes(phi, INMOUTH1, OUTMOUTH1), L, U2, bcs=bcs2 163 | ) 164 | solver_stokes2 = fd.LinearVariationalSolver( 165 | problem, solver_parameters=stokes_parameters, options_prefix="stokes_2" 166 | ) 167 | solver_stokes2.solve() 168 | 169 | # Convection difussion equation 170 | ks = fd.Constant(1e0) 171 | cp_value = 5.0e5 172 | cp = fd.Constant(cp_value) 173 | T = fd.FunctionSpace(mesh, "DG", 1) 174 | t = fd.Function(T, name="Temperature") 175 | w = fd.TestFunction(T) 176 | 177 | # Mesh-related functions 178 | n = fd.FacetNormal(mesh) 179 | h = fd.CellDiameter(mesh) 180 | u1, p1 = fd.split(U1) 181 | u2, p2 = fd.split(U2) 182 | 183 | def upwind(u): 184 | return (dot(u, n) + abs(dot(u, n))) / 2.0 185 | 186 | u1n = upwind(u1) 187 | u2n = upwind(u2) 188 | 189 | # Penalty term 190 | alpha = fd.Constant(500.0) 191 | # Bilinear form 192 | a_int = dot(grad(w), ks * grad(t) - cp * (u1 + u2) * t) * dx 193 | 194 | a_fac = ( 195 | fd.Constant(-1.0) * ks * dot(avg(grad(w)), jump(t, n)) * dS 196 | + fd.Constant(-1.0) * ks * dot(jump(w, n), avg(grad(t))) * dS 197 | + ks("+") * (alpha("+") / avg(h)) * dot(jump(w, n), jump(t, n)) * dS 198 | ) 199 | 200 | a_vel = ( 201 | dot( 202 | jump(w), 203 | cp * (u1n("+") + u2n("+")) * t("+") 204 | - cp * (u1n("-") + u2n("-")) * t("-"), 205 | ) 206 | * dS 207 | + dot(w, cp * (u1n + u2n) * t) * ds 208 | ) 209 | 210 | a_bnd = ( 211 | dot(w, cp * dot(u1 + u2, n) * t) * (ds(INLET1) + ds(INLET2)) 212 | + w * t * (ds(INLET1) + ds(INLET2)) 213 | - w * tin1 * ds(INLET1) 214 | - w * tin2 * ds(INLET2) 215 | + alpha / h * ks * w * t * (ds(INLET1) + ds(INLET2)) 216 | - ks * dot(grad(w), t * n) * (ds(INLET1) + ds(INLET2)) 217 | - ks * dot(grad(t), w * n) * (ds(INLET1) + ds(INLET2)) 218 | ) 219 | 220 | aT = a_int + a_fac + a_vel + a_bnd 221 | 222 | LT_bnd = ( 223 | alpha / h * ks * tin1 * w * ds(INLET1) 224 | + alpha / h * ks * tin2 * w * ds(INLET2) 225 | - tin1 * ks * dot(grad(w), n) * ds(INLET1) 226 | - tin2 * ks * dot(grad(w), n) * ds(INLET2) 227 | ) 228 | 229 | problem = fd.LinearVariationalProblem(derivative(aT, t), LT_bnd, t) 230 | solver_temp = fd.LinearVariationalSolver( 231 | problem, 232 | solver_parameters=temperature_parameters, 233 | options_prefix="temperature", 234 | ) 235 | solver_temp.solve() 236 | # fd.solve(eT == 0, t, solver_parameters=temperature_parameters) 237 | 238 | # Cost function: Flux at the cold outlet 239 | scale_factor = 4e-4 240 | Jform = fd.assemble( 241 | fd.Constant(-scale_factor * cp_value) * inner(t * u1, n) * ds(OUTLET1) 242 | ) 243 | # Constraints: Pressure drop on each fluid 244 | power_drop = 1e-2 245 | Power1 = fd.assemble(p1 / power_drop * ds(INLET1)) 246 | Power2 = fd.assemble(p2 / power_drop * ds(INLET2)) 247 | 248 | phi_pvd = fd.File("phi_evolution.pvd") 249 | 250 | def deriv_cb(phi): 251 | with stop_annotating(): 252 | phi_pvd.write(phi[0]) 253 | 254 | c = fda.Control(s) 255 | 256 | # Reduced Functionals 257 | Jhat = LevelSetFunctional(Jform, c, phi, derivative_cb_pre=deriv_cb) 258 | P1hat = LevelSetFunctional(Power1, c, phi) 259 | P1control = fda.Control(Power1) 260 | 261 | P2hat = LevelSetFunctional(Power2, c, phi) 262 | P2control = fda.Control(Power2) 263 | 264 | Jhat_v = Jhat(phi) 265 | print("Initial cost function value {:.5f}".format(Jhat_v), flush=True) 266 | print("Power drop 1 {:.5f}".format(Power1), flush=True) 267 | print("Power drop 2 {:.5f}".format(Power2), flush=True) 268 | 269 | beta_param = 0.08 270 | # Regularize the shape derivatives only in the domain marked with 0 271 | reg_solver = RegularizationSolver( 272 | S, mesh, beta=beta_param, gamma=1e5, dx=dx, design_domain=0 273 | ) 274 | 275 | tol = 1e-5 276 | dt = 0.05 277 | params = { 278 | "alphaC": 1.0, 279 | "debug": 5, 280 | "alphaJ": 1.0, 281 | "dt": dt, 282 | "K": 1e-3, 283 | "maxit": n_iters, 284 | "maxtrials": 5, 285 | "itnormalisation": 10, 286 | "tol_merit": 5e-3, # new merit can be within 0.5% of the previous merit 287 | # "normalize_tol" : -1, 288 | "tol": tol, 289 | } 290 | 291 | solver_parameters = { 292 | "reinit_solver": { 293 | "h_factor": 2.0, 294 | } 295 | } 296 | # Optimization problem 297 | problem = InfDimProblem( 298 | Jhat, 299 | reg_solver, 300 | ineqconstraints=[ 301 | Constraint(P1hat, 1.0, P1control), 302 | Constraint(P2hat, 1.0, P2control), 303 | ], 304 | solver_parameters=solver_parameters, 305 | ) 306 | results = nlspace_solve(problem, params) 307 | 308 | return results 309 | 310 | 311 | if __name__ == "__main__": 312 | heat_exchanger_optimization() 313 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger/parameters.py: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/LLNL/letop/71d532b2f7f0caf0d50ba90a01419906570260dd/letop_examples/heat_exchanger/parameters.py -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_3D/box_heat_exch.geo: -------------------------------------------------------------------------------- 1 | //+ 2 | SetFactory("OpenCASCADE"); 3 | //+ 4 | Box(1) = {0, 0, 0, 10, 10, 3}; 5 | //+ 6 | Cylinder(2) = {0, 2, 1.5, -2, 0, 0, 1.0, 2*Pi}; 7 | //+ 8 | Cylinder(3) = {0, 8, 1.5, -2, 0, 0, 1.0, 2*Pi}; 9 | //+ 10 | Cylinder(4) = {10, 8, 1.5, 2, 0, 0, 1.0, 2*Pi}; 11 | //+ 12 | Cylinder(5) = {10, 2, 1.5, 2, 0, 0, 1.0, 2*Pi}; 13 | //+ 14 | BooleanFragments{ Volume{1}; Delete; }{ Volume{4}; Volume{5}; Volume{2}; Volume{3}; Delete; } 15 | Dilate {{0, 0, 0}, {0.1, 0.1, 0.1}} { 16 | Volume{3}; Volume{1}; Volume{2}; Volume{4}; Volume{5}; 17 | } 18 | //+ 19 | Physical Surface(1) = {26}; 20 | //+ 21 | Physical Surface(2) = {40}; 22 | //+ 23 | Physical Surface(3) = {38}; 24 | //+ 25 | Physical Surface(4) = {42}; 26 | //+ 27 | Physical Surface(5) = {34, 35, 36, 28, 33, 30, 39, 41, 37, 25}; 28 | //+ 29 | Physical Volume(0) = {1}; 30 | mesh_size = 0.02; 31 | MeshSize{ PointsOf{ Volume{1, 2, 3, 4, 5}; } } = mesh_size; 32 | //+ 33 | Physical Volume(6) = {3}; 34 | //+ 35 | Physical Volume(7) = {2}; 36 | //+ 37 | Physical Volume(8) = {4}; 38 | //+ 39 | Physical Volume(9) = {5}; 40 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_3D/box_heat_exch.geo.opt: -------------------------------------------------------------------------------- 1 | General.AxesFormatX = "%.3g"; 2 | General.AxesFormatY = "%.3g"; 3 | General.AxesFormatZ = "%.3g"; 4 | General.AxesLabelX = ""; 5 | General.AxesLabelY = ""; 6 | General.AxesLabelZ = ""; 7 | General.BackgroundImageFileName = ""; 8 | General.BuildInfo = "Version: 4.7.1; License: GNU General Public License; Build OS: MacOSX; Build date: 20201116; Build host: gmsh.info; Build options: 64Bit ALGLIB ANN Bamg Blas[petsc] Blossom Cgns DIntegration Dlopen DomHex Eigen Fltk Gmm Hxt Jpeg[fltk] Kbipack Lapack[petsc] MathEx Med Mesh Metis Mmg Mpeg Netgen ONELAB ONELABMetamodel OpenCASCADE OpenCASCADE-CAF OpenGL OptHom PETSc Parser Plugins Png[fltk] Post QuadTri Solver TetGen/BR Voro++ Zlib[fltk]; FLTK version: 1.4.0; PETSc version: 3.9.3 (real arithmtic); OCC version: 7.4.0; MED version: 4.1.0; Packaged by: geuzaine; Web site: https://gmsh.info; Issue tracker: https://gitlab.onelab.info/gmsh/gmsh/issues"; 9 | General.BuildOptions = "64Bit ALGLIB ANN Bamg Blas[petsc] Blossom Cgns DIntegration Dlopen DomHex Eigen Fltk Gmm Hxt Jpeg[fltk] Kbipack Lapack[petsc] MathEx Med Mesh Metis Mmg Mpeg Netgen ONELAB ONELABMetamodel OpenCASCADE OpenCASCADE-CAF OpenGL OptHom PETSc Parser Plugins Png[fltk] Post QuadTri Solver TetGen/BR Voro++ Zlib[fltk]"; 10 | General.DefaultFileName = "untitled.geo"; 11 | General.Display = ""; 12 | General.ErrorFileName = ".gmsh-errors"; 13 | General.ExecutableFileName = "/Applications/Gmsh.app/Contents/MacOS/gmsh"; 14 | General.FileName = "box_heat_exch.geo"; 15 | General.FltkTheme = ""; 16 | General.GraphicsFont = "Helvetica"; 17 | General.GraphicsFontEngine = "Native"; 18 | General.GraphicsFontTitle = "Helvetica"; 19 | General.OptionsFileName = ".gmsh-options"; 20 | General.RecentFile0 = "box_heat_exch.geo"; 21 | General.TextEditor = "open -t '%s'"; 22 | General.TmpFileName = ".gmsh-tmp"; 23 | General.Version = "4.7.1"; 24 | General.WatchFilePattern = ""; 25 | General.AbortOnError = 0; 26 | General.AlphaBlending = 1; 27 | General.Antialiasing = 0; 28 | General.ArrowHeadRadius = 0.12; 29 | General.ArrowStemLength = 0.5600000000000001; 30 | General.ArrowStemRadius = 0.02; 31 | General.Axes = 0; 32 | General.AxesMikado = 0; 33 | General.AxesAutoPosition = 1; 34 | General.AxesForceValue = 0; 35 | General.AxesMaxX = 1; 36 | General.AxesMaxY = 1; 37 | General.AxesMaxZ = 1; 38 | General.AxesMinX = 0; 39 | General.AxesMinY = 0; 40 | General.AxesMinZ = 0; 41 | General.AxesTicsX = 5; 42 | General.AxesTicsY = 5; 43 | General.AxesTicsZ = 5; 44 | General.AxesValueMaxX = 1; 45 | General.AxesValueMaxY = 1; 46 | General.AxesValueMaxZ = 1; 47 | General.AxesValueMinX = 0; 48 | General.AxesValueMinY = 0; 49 | General.AxesValueMinZ = 0; 50 | General.BackgroundGradient = 1; 51 | General.BackgroundImage3D = 0; 52 | General.BackgroundImagePage = 0; 53 | General.BackgroundImagePositionX = 0; 54 | General.BackgroundImagePositionY = 0; 55 | General.BackgroundImageWidth = -1; 56 | General.BackgroundImageHeight = -1; 57 | General.BoundingBoxSize = 1.766352490303145; 58 | General.Camera = 0; 59 | General.CameraAperture = 40; 60 | General.CameraEyeSeparationRatio = 1.5; 61 | General.CameraFocalLengthRatio = 1; 62 | General.Clip0A = 1; 63 | General.Clip0B = 0; 64 | General.Clip0C = 0; 65 | General.Clip0D = 0; 66 | General.Clip1A = 0; 67 | General.Clip1B = 1; 68 | General.Clip1C = 0; 69 | General.Clip1D = 0; 70 | General.Clip2A = 0; 71 | General.Clip2B = 0; 72 | General.Clip2C = 1; 73 | General.Clip2D = 0; 74 | General.Clip3A = -1; 75 | General.Clip3B = 0; 76 | General.Clip3C = 0; 77 | General.Clip3D = 1; 78 | General.Clip4A = 0; 79 | General.Clip4B = -1; 80 | General.Clip4C = 0; 81 | General.Clip4D = 1; 82 | General.Clip5A = 0; 83 | General.Clip5B = 0; 84 | General.Clip5C = -1; 85 | General.Clip5D = 1; 86 | General.ClipFactor = 5; 87 | General.ClipOnlyDrawIntersectingVolume = 0; 88 | General.ClipOnlyVolume = 0; 89 | General.ClipPositionX = 2064; 90 | General.ClipPositionY = 207; 91 | General.ClipWholeElements = 0; 92 | General.ColorScheme = 1; 93 | General.ConfirmOverwrite = 1; 94 | General.ContextPositionX = 2084; 95 | General.ContextPositionY = 204; 96 | General.DetachedMenu = 0; 97 | General.DisplayBorderFactor = 0.2; 98 | General.DoubleBuffer = 1; 99 | General.DrawBoundingBoxes = 0; 100 | General.ExpertMode = 0; 101 | General.ExtraPositionX = 650; 102 | General.ExtraPositionY = 350; 103 | General.ExtraHeight = 100; 104 | General.ExtraWidth = 100; 105 | General.FastRedraw = 0; 106 | General.FieldPositionX = 1469; 107 | General.FieldPositionY = 511; 108 | General.FieldHeight = 488; 109 | General.FieldWidth = 651; 110 | General.FileChooserPositionX = 200; 111 | General.FileChooserPositionY = 200; 112 | General.FltkColorScheme = 0; 113 | General.FltkRefreshRate = 5; 114 | General.FontSize = -1; 115 | General.GraphicsFontSize = 15; 116 | General.GraphicsFontSizeTitle = 18; 117 | General.GraphicsHeight = 1310; 118 | General.GraphicsPositionX = 0; 119 | General.GraphicsPositionY = 45; 120 | General.GraphicsWidth = 2560; 121 | General.HighOrderToolsPositionX = 650; 122 | General.HighOrderToolsPositionY = 150; 123 | General.HighResolutionGraphics = 1; 124 | General.HighResolutionPointSizeFactor = 2; 125 | General.InitialModule = 0; 126 | General.InputScrolling = 1; 127 | General.Light0 = 1; 128 | General.Light0X = 0.65; 129 | General.Light0Y = 0.65; 130 | General.Light0Z = 1; 131 | General.Light0W = 0; 132 | General.Light1 = 0; 133 | General.Light1X = 0.5; 134 | General.Light1Y = 0.3; 135 | General.Light1Z = 1; 136 | General.Light1W = 0; 137 | General.Light2 = 0; 138 | General.Light2X = 0.5; 139 | General.Light2Y = 0.3; 140 | General.Light2Z = 1; 141 | General.Light2W = 0; 142 | General.Light3 = 0; 143 | General.Light3X = 0.5; 144 | General.Light3Y = 0.3; 145 | General.Light3Z = 1; 146 | General.Light3W = 0; 147 | General.Light4 = 0; 148 | General.Light4X = 0.5; 149 | General.Light4Y = 0.3; 150 | General.Light4Z = 1; 151 | General.Light4W = 0; 152 | General.Light5 = 0; 153 | General.Light5X = 0.5; 154 | General.Light5Y = 0.3; 155 | General.Light5Z = 1; 156 | General.Light5W = 0; 157 | General.LineWidth = 1; 158 | General.ManipulatorPositionX = 650; 159 | General.ManipulatorPositionY = 150; 160 | General.MaxX = 1.2000001; 161 | General.MaxY = 1.0000001; 162 | General.MaxZ = 0.3500001; 163 | General.MenuWidth = 219; 164 | General.MenuHeight = 200; 165 | General.MenuPositionX = 400; 166 | General.MenuPositionY = 400; 167 | General.MessageFontSize = -1; 168 | General.MessageHeight = 300; 169 | General.MinX = -0.2000001; 170 | General.MinY = -1e-07; 171 | General.MinZ = -0.05000009999999996; 172 | General.MouseHoverMeshes = 0; 173 | General.MouseSelection = 1; 174 | General.MouseInvertZoom = 0; 175 | General.NativeFileChooser = 1; 176 | General.NonModalWindows = 1; 177 | General.NoPopup = 0; 178 | General.NumThreads = 1; 179 | General.OptionsPositionX = 1591; 180 | General.OptionsPositionY = 212; 181 | General.Orthographic = 1; 182 | General.PluginPositionX = 649; 183 | General.PluginPositionY = 549; 184 | General.PluginHeight = 488; 185 | General.PluginWidth = 708; 186 | General.PointSize = 3; 187 | General.PolygonOffsetAlwaysOn = 0; 188 | General.PolygonOffsetFactor = 0.5; 189 | General.PolygonOffsetUnits = 1; 190 | General.ProgressMeterStep = 10; 191 | General.QuadricSubdivisions = 6; 192 | General.RotationX = -0; 193 | General.RotationY = 0; 194 | General.RotationZ = -0; 195 | General.RotationCenterGravity = 1; 196 | General.RotationCenterX = 0; 197 | General.RotationCenterY = 0; 198 | General.RotationCenterZ = 0; 199 | General.SaveOptions = 0; 200 | General.SaveSession = 1; 201 | General.ScaleX = 1; 202 | General.ScaleY = 1; 203 | General.ScaleZ = 1; 204 | General.Shininess = 0.4; 205 | General.ShininessExponent = 40; 206 | General.ShowModuleMenu = 1; 207 | General.ShowOptionsOnStartup = 0; 208 | General.ShowMessagesOnStartup = 0; 209 | General.SmallAxes = 1; 210 | General.SmallAxesPositionX = -60; 211 | General.SmallAxesPositionY = -40; 212 | General.SmallAxesSize = 30; 213 | General.StatisticsPositionX = 650; 214 | General.StatisticsPositionY = 150; 215 | General.Stereo = 0; 216 | General.SystemMenuBar = 1; 217 | General.Terminal = 0; 218 | General.Tooltips = 1; 219 | General.Trackball = 1; 220 | General.TrackballHyperbolicSheet = 1; 221 | General.TrackballQuaternion0 = 0; 222 | General.TrackballQuaternion1 = 0; 223 | General.TrackballQuaternion2 = 0; 224 | General.TrackballQuaternion3 = 1; 225 | General.TranslationX = 0; 226 | General.TranslationY = 0; 227 | General.TranslationZ = 0; 228 | General.VectorType = 4; 229 | General.Verbosity = 5; 230 | General.VisibilityPositionX = 1854; 231 | General.VisibilityPositionY = 406; 232 | General.ZoomFactor = 4; 233 | General.Color.Background = {255,255,255}; 234 | General.Color.BackgroundGradient = {208,215,255}; 235 | General.Color.Foreground = {85,85,85}; 236 | General.Color.Text = {0,0,0}; 237 | General.Color.Axes = {0,0,0}; 238 | General.Color.SmallAxes = {0,0,0}; 239 | General.Color.AmbientLight = {25,25,25}; 240 | General.Color.DiffuseLight = {255,255,255}; 241 | General.Color.SpecularLight = {255,255,255}; 242 | Geometry.DoubleClickedPointCommand = ""; 243 | Geometry.DoubleClickedCurveCommand = ""; 244 | Geometry.DoubleClickedSurfaceCommand = ""; 245 | Geometry.DoubleClickedVolumeCommand = ""; 246 | Geometry.OCCTargetUnit = ""; 247 | Geometry.AutoCoherence = 1; 248 | Geometry.Clip = 0; 249 | Geometry.CopyMeshingMethod = 0; 250 | Geometry.Curves = 1; 251 | Geometry.CurveNumbers = 0; 252 | Geometry.CurveSelectWidth = 3; 253 | Geometry.CurveType = 0; 254 | Geometry.CurveWidth = 2; 255 | Geometry.DoubleClickedEntityTag = 0; 256 | Geometry.ExactExtrusion = 1; 257 | Geometry.ExtrudeReturnLateralEntities = 1; 258 | Geometry.ExtrudeSplinePoints = 5; 259 | Geometry.HighlightOrphans = 0; 260 | Geometry.LabelType = 0; 261 | Geometry.Light = 1; 262 | Geometry.LightTwoSide = 1; 263 | Geometry.MatchGeomAndMesh = 0; 264 | Geometry.MatchMeshScaleFactor = 1; 265 | Geometry.MatchMeshTolerance = 1e-06; 266 | Geometry.Normals = 0; 267 | Geometry.NumSubEdges = 40; 268 | Geometry.OCCAutoFix = 1; 269 | Geometry.OCCBooleanPreserveNumbering = 1; 270 | Geometry.OCCBoundsUseStl = 0; 271 | Geometry.OCCDisableStl = 0; 272 | Geometry.OCCFixDegenerated = 0; 273 | Geometry.OCCFixSmallEdges = 0; 274 | Geometry.OCCFixSmallFaces = 0; 275 | Geometry.OCCImportLabels = 1; 276 | Geometry.OCCMakeSolids = 0; 277 | Geometry.OCCParallel = 0; 278 | Geometry.OCCScaling = 1; 279 | Geometry.OCCSewFaces = 0; 280 | Geometry.OCCThruSectionsDegree = -1; 281 | Geometry.OCCUnionUnify = 1; 282 | Geometry.OffsetX = 0; 283 | Geometry.OffsetY = 0; 284 | Geometry.OffsetZ = 0; 285 | Geometry.OldCircle = 0; 286 | Geometry.OldRuledSurface = 0; 287 | Geometry.OldNewReg = 1; 288 | Geometry.Points = 1; 289 | Geometry.PointNumbers = 0; 290 | Geometry.PointSelectSize = 6; 291 | Geometry.PointSize = 4; 292 | Geometry.PointType = 0; 293 | Geometry.ReparamOnFaceRobust = 0; 294 | Geometry.ScalingFactor = 1; 295 | Geometry.OrientedPhysicals = 1; 296 | Geometry.SnapX = 0.1; 297 | Geometry.SnapY = 0.1; 298 | Geometry.SnapZ = 0.1; 299 | Geometry.Surfaces = 0; 300 | Geometry.SurfaceNumbers = 0; 301 | Geometry.SurfaceType = 0; 302 | Geometry.Tangents = 0; 303 | Geometry.Tolerance = 1e-08; 304 | Geometry.ToleranceBoolean = 0; 305 | Geometry.Transform = 0; 306 | Geometry.TransformXX = 1; 307 | Geometry.TransformXY = 0; 308 | Geometry.TransformXZ = 0; 309 | Geometry.TransformYX = 0; 310 | Geometry.TransformYY = 1; 311 | Geometry.TransformYZ = 0; 312 | Geometry.TransformZX = 0; 313 | Geometry.TransformZY = 0; 314 | Geometry.TransformZZ = 1; 315 | Geometry.Volumes = 0; 316 | Geometry.VolumeNumbers = 0; 317 | Geometry.Color.Points = {90,90,90}; 318 | Geometry.Color.Curves = {0,0,255}; 319 | Geometry.Color.Surfaces = {128,128,128}; 320 | Geometry.Color.Volumes = {255,255,0}; 321 | Geometry.Color.Selection = {255,0,0}; 322 | Geometry.Color.HighlightZero = {255,0,0}; 323 | Geometry.Color.HighlightOne = {255,150,0}; 324 | Geometry.Color.HighlightTwo = {255,255,0}; 325 | Geometry.Color.Tangents = {255,255,0}; 326 | Geometry.Color.Normals = {255,0,0}; 327 | Geometry.Color.Projection = {0,255,0}; 328 | Mesh.Algorithm = 2; 329 | Mesh.Algorithm3D = 1; 330 | Mesh.AlgorithmSwitchOnFailure = 1; 331 | Mesh.AngleSmoothNormals = 30; 332 | Mesh.AngleToleranceFacetOverlap = 0.1; 333 | Mesh.AnisoMax = 9.999999999999999e+32; 334 | Mesh.AllowSwapAngle = 10; 335 | Mesh.BdfFieldFormat = 1; 336 | Mesh.Binary = 0; 337 | Mesh.BoundaryLayerFanPoints = 5; 338 | Mesh.CgnsImportOrder = 1; 339 | Mesh.CgnsImportIgnoreBC = 0; 340 | Mesh.CgnsImportIgnoreSolution = 0; 341 | Mesh.CgnsConstructTopology = 0; 342 | Mesh.CgnsExportCPEX0045 = 0; 343 | Mesh.CgnsExportStructured = 0; 344 | Mesh.Clip = 0; 345 | Mesh.ColorCarousel = 1; 346 | Mesh.CompoundClassify = 1; 347 | Mesh.CompoundMeshSizeFactor = 0.5; 348 | Mesh.CpuTime = 0; 349 | Mesh.DrawSkinOnly = 0; 350 | Mesh.Dual = 0; 351 | Mesh.ElementOrder = 1; 352 | Mesh.Explode = 1; 353 | Mesh.FirstElementTag = 1; 354 | Mesh.FirstNodeTag = 1; 355 | Mesh.FlexibleTransfinite = 0; 356 | Mesh.Format = 10; 357 | Mesh.Hexahedra = 1; 358 | Mesh.HighOrderDistCAD = 0; 359 | Mesh.HighOrderIterMax = 100; 360 | Mesh.HighOrderNumLayers = 6; 361 | Mesh.HighOrderOptimize = 0; 362 | Mesh.HighOrderPassMax = 25; 363 | Mesh.HighOrderPeriodic = 0; 364 | Mesh.HighOrderPoissonRatio = 0.33; 365 | Mesh.HighOrderSavePeriodic = 0; 366 | Mesh.HighOrderPrimSurfMesh = 0; 367 | Mesh.HighOrderThresholdMin = 0.1; 368 | Mesh.HighOrderThresholdMax = 2; 369 | Mesh.LabelSampling = 1; 370 | Mesh.LabelType = 0; 371 | Mesh.LcIntegrationPrecision = 1e-09; 372 | Mesh.Light = 1; 373 | Mesh.LightLines = 2; 374 | Mesh.LightTwoSide = 1; 375 | Mesh.Lines = 0; 376 | Mesh.LineNumbers = 0; 377 | Mesh.LineWidth = 1; 378 | Mesh.MaxIterDelaunay3D = 0; 379 | Mesh.MaxNumThreads1D = 0; 380 | Mesh.MaxNumThreads2D = 0; 381 | Mesh.MaxNumThreads3D = 0; 382 | Mesh.MaxRetries = 10; 383 | Mesh.MeshOnlyVisible = 0; 384 | Mesh.MeshOnlyEmpty = 0; 385 | Mesh.MeshSizeExtendFromBoundary = 1; 386 | Mesh.MeshSizeFactor = 1; 387 | Mesh.MeshSizeMin = 0; 388 | Mesh.MeshSizeMax = 1e+22; 389 | Mesh.MeshSizeFromCurvature = 0; 390 | Mesh.MeshSizeFromPoints = 1; 391 | Mesh.MeshSizeFromParametricPoints = 0; 392 | Mesh.MetisAlgorithm = 1; 393 | Mesh.MetisEdgeMatching = 2; 394 | Mesh.MetisMaxLoadImbalance = -1; 395 | Mesh.MetisObjective = 1; 396 | Mesh.MetisMinConn = -1; 397 | Mesh.MetisRefinementAlgorithm = 2; 398 | Mesh.MinimumCirclePoints = 7; 399 | Mesh.MinimumCurvePoints = 3; 400 | Mesh.MinimumElementsPerTwoPi = 6; 401 | Mesh.MshFileVersion = 4.1; 402 | Mesh.MedFileMinorVersion = -1; 403 | Mesh.MedImportGroupsOfNodes = 0; 404 | Mesh.MedSingleModel = 0; 405 | Mesh.PartitionHexWeight = -1; 406 | Mesh.PartitionLineWeight = -1; 407 | Mesh.PartitionPrismWeight = -1; 408 | Mesh.PartitionPyramidWeight = -1; 409 | Mesh.PartitionQuadWeight = -1; 410 | Mesh.PartitionTrihedronWeight = 0; 411 | Mesh.PartitionTetWeight = -1; 412 | Mesh.PartitionTriWeight = -1; 413 | Mesh.PartitionCreateTopology = 1; 414 | Mesh.PartitionCreatePhysicals = 1; 415 | Mesh.PartitionCreateGhostCells = 0; 416 | Mesh.PartitionSplitMeshFiles = 0; 417 | Mesh.PartitionTopologyFile = 0; 418 | Mesh.PartitionOldStyleMsh2 = 1; 419 | Mesh.ReparamMaxTriangles = 250000; 420 | Mesh.NbHexahedra = 0; 421 | Mesh.NbNodes = 0; 422 | Mesh.NbPartitions = 0; 423 | Mesh.NbPrisms = 0; 424 | Mesh.NbPyramids = 0; 425 | Mesh.NbTrihedra = 0; 426 | Mesh.NbQuadrangles = 0; 427 | Mesh.NbTetrahedra = 0; 428 | Mesh.NbTriangles = 0; 429 | Mesh.NewtonConvergenceTestXYZ = 0; 430 | Mesh.Normals = 0; 431 | Mesh.NumSubEdges = 2; 432 | Mesh.Optimize = 1; 433 | Mesh.OptimizeThreshold = 0.3; 434 | Mesh.OptimizeNetgen = 0; 435 | Mesh.Points = 0; 436 | Mesh.PointNumbers = 0; 437 | Mesh.PointSize = 4; 438 | Mesh.PointType = 0; 439 | Mesh.Prisms = 1; 440 | Mesh.Pyramids = 1; 441 | Mesh.Trihedra = 1; 442 | Mesh.Quadrangles = 1; 443 | Mesh.QualityInf = 0; 444 | Mesh.QualitySup = 0; 445 | Mesh.QualityType = 2; 446 | Mesh.RadiusInf = 0; 447 | Mesh.RadiusSup = 0; 448 | Mesh.RandomFactor = 1e-09; 449 | Mesh.RandomFactor3D = 1e-12; 450 | Mesh.RandomSeed = 1; 451 | Mesh.PreserveNumberingMsh2 = 0; 452 | Mesh.IgnoreParametrization = 0; 453 | Mesh.IgnorePeriodicity = 1; 454 | Mesh.RecombinationAlgorithm = 0; 455 | Mesh.RecombineAll = 0; 456 | Mesh.RecombineOptimizeTopology = 5; 457 | Mesh.Recombine3DAll = 0; 458 | Mesh.Recombine3DLevel = 0; 459 | Mesh.Recombine3DConformity = 0; 460 | Mesh.RefineSteps = 10; 461 | Mesh.Renumber = 1; 462 | Mesh.SaveAll = 0; 463 | Mesh.SaveElementTagType = 1; 464 | Mesh.SaveTopology = 0; 465 | Mesh.SaveParametric = 0; 466 | Mesh.SaveGroupsOfElements = 1; 467 | Mesh.SaveGroupsOfNodes = 0; 468 | Mesh.ScalingFactor = 1; 469 | Mesh.SecondOrderIncomplete = 0; 470 | Mesh.SecondOrderLinear = 0; 471 | Mesh.Smoothing = 1; 472 | Mesh.SmoothCrossField = 0; 473 | Mesh.CrossFieldClosestPoint = 1; 474 | Mesh.SmoothNormals = 0; 475 | Mesh.SmoothRatio = 1.8; 476 | Mesh.StlAngularDeflection = 0.35; 477 | Mesh.StlLinearDeflection = 0.01; 478 | Mesh.StlOneSolidPerSurface = 0; 479 | Mesh.StlRemoveDuplicateTriangles = 0; 480 | Mesh.SubdivisionAlgorithm = 0; 481 | Mesh.SurfaceEdges = 1; 482 | Mesh.SurfaceFaces = 0; 483 | Mesh.SurfaceNumbers = 0; 484 | Mesh.SwitchElementTags = 0; 485 | Mesh.Tangents = 0; 486 | Mesh.Tetrahedra = 1; 487 | Mesh.ToleranceEdgeLength = 0; 488 | Mesh.ToleranceInitialDelaunay = 1e-08; 489 | Mesh.Triangles = 1; 490 | Mesh.UnvStrictFormat = 1; 491 | Mesh.VolumeEdges = 1; 492 | Mesh.VolumeFaces = 0; 493 | Mesh.VolumeNumbers = 0; 494 | Mesh.Voronoi = 0; 495 | Mesh.ZoneDefinition = 0; 496 | Mesh.Color.Points = {0,0,255}; 497 | Mesh.Color.PointsSup = {255,0,255}; 498 | Mesh.Color.Lines = {0,0,0}; 499 | Mesh.Color.Triangles = {160,150,255}; 500 | Mesh.Color.Quadrangles = {130,120,225}; 501 | Mesh.Color.Tetrahedra = {160,150,255}; 502 | Mesh.Color.Hexahedra = {130,120,225}; 503 | Mesh.Color.Prisms = {232,210,23}; 504 | Mesh.Color.Pyramids = {217,113,38}; 505 | Mesh.Color.Trihedra = {20,255,0}; 506 | Mesh.Color.Tangents = {255,255,0}; 507 | Mesh.Color.Normals = {255,0,0}; 508 | Mesh.Color.Zero = {255,120,0}; 509 | Mesh.Color.One = {0,255,132}; 510 | Mesh.Color.Two = {255,160,0}; 511 | Mesh.Color.Three = {0,255,192}; 512 | Mesh.Color.Four = {255,200,0}; 513 | Mesh.Color.Five = {0,216,255}; 514 | Mesh.Color.Six = {255,240,0}; 515 | Mesh.Color.Seven = {0,176,255}; 516 | Mesh.Color.Eight = {228,255,0}; 517 | Mesh.Color.Nine = {0,116,255}; 518 | Mesh.Color.Ten = {188,255,0}; 519 | Mesh.Color.Eleven = {0,76,255}; 520 | Mesh.Color.Twelve = {148,255,0}; 521 | Mesh.Color.Thirteen = {24,0,255}; 522 | Mesh.Color.Fourteen = {108,255,0}; 523 | Mesh.Color.Fifteen = {84,0,255}; 524 | Mesh.Color.Sixteen = {68,255,0}; 525 | Mesh.Color.Seventeen = {104,0,255}; 526 | Mesh.Color.Eighteen = {0,255,52}; 527 | Mesh.Color.Nineteen = {184,0,255}; 528 | Solver.Executable0 = ""; 529 | Solver.Executable1 = ""; 530 | Solver.Executable2 = ""; 531 | Solver.Executable3 = ""; 532 | Solver.Executable4 = ""; 533 | Solver.Executable5 = ""; 534 | Solver.Executable6 = ""; 535 | Solver.Executable7 = ""; 536 | Solver.Executable8 = ""; 537 | Solver.Executable9 = ""; 538 | Solver.Name0 = "GetDP"; 539 | Solver.Name1 = ""; 540 | Solver.Name2 = ""; 541 | Solver.Name3 = ""; 542 | Solver.Name4 = ""; 543 | Solver.Name5 = ""; 544 | Solver.Name6 = ""; 545 | Solver.Name7 = ""; 546 | Solver.Name8 = ""; 547 | Solver.Name9 = ""; 548 | Solver.Extension0 = ".pro"; 549 | Solver.Extension1 = ""; 550 | Solver.Extension2 = ""; 551 | Solver.Extension3 = ""; 552 | Solver.Extension4 = ""; 553 | Solver.Extension5 = ""; 554 | Solver.Extension6 = ""; 555 | Solver.Extension7 = ""; 556 | Solver.Extension8 = ""; 557 | Solver.Extension9 = ""; 558 | Solver.OctaveInterpreter = "octave"; 559 | Solver.PythonInterpreter = "python"; 560 | Solver.RemoteLogin0 = ""; 561 | Solver.RemoteLogin1 = ""; 562 | Solver.RemoteLogin2 = ""; 563 | Solver.RemoteLogin3 = ""; 564 | Solver.RemoteLogin4 = ""; 565 | Solver.RemoteLogin5 = ""; 566 | Solver.RemoteLogin6 = ""; 567 | Solver.RemoteLogin7 = ""; 568 | Solver.RemoteLogin8 = ""; 569 | Solver.RemoteLogin9 = ""; 570 | Solver.SocketName = ".gmshsock"; 571 | Solver.AlwaysListen = 0; 572 | Solver.AutoArchiveOutputFiles = 0; 573 | Solver.AutoCheck = 1; 574 | Solver.AutoLoadDatabase = 0; 575 | Solver.AutoSaveDatabase = 1; 576 | Solver.AutoMesh = 2; 577 | Solver.AutoMergeFile = 1; 578 | Solver.AutoShowViews = 2; 579 | Solver.AutoShowLastStep = 1; 580 | Solver.Plugins = 0; 581 | Solver.ShowInvisibleParameters = 0; 582 | Solver.Timeout = 5; 583 | PostProcessing.DoubleClickedGraphPointCommand = ""; 584 | PostProcessing.GraphPointCommand = ""; 585 | PostProcessing.AnimationDelay = 0.1; 586 | PostProcessing.AnimationCycle = 0; 587 | PostProcessing.AnimationStep = 1; 588 | PostProcessing.CombineRemoveOriginal = 1; 589 | PostProcessing.CombineCopyOptions = 1; 590 | PostProcessing.DoubleClickedGraphPointX = 0; 591 | PostProcessing.DoubleClickedGraphPointY = 0; 592 | PostProcessing.DoubleClickedView = 0; 593 | PostProcessing.ForceElementData = 0; 594 | PostProcessing.ForceNodeData = 0; 595 | PostProcessing.Format = 10; 596 | PostProcessing.GraphPointX = 0; 597 | PostProcessing.GraphPointY = 0; 598 | PostProcessing.HorizontalScales = 1; 599 | PostProcessing.Link = 0; 600 | PostProcessing.NbViews = 0; 601 | PostProcessing.Plugins = 1; 602 | PostProcessing.SaveInterpolationMatrices = 1; 603 | PostProcessing.SaveMesh = 1; 604 | PostProcessing.Smoothing = 0; 605 | Print.ParameterCommand = "Mesh.Clip=1; View.Clip=1; General.ClipWholeElements=1; General.Clip0D=Print.Parameter; SetChanged;"; 606 | Print.Parameter = 0; 607 | Print.ParameterFirst = -1; 608 | Print.ParameterLast = 1; 609 | Print.ParameterSteps = 10; 610 | Print.Background = 0; 611 | Print.CompositeWindows = 0; 612 | Print.DeleteTemporaryFiles = 1; 613 | Print.EpsBestRoot = 1; 614 | Print.EpsCompress = 0; 615 | Print.EpsLineWidthFactor = 1; 616 | Print.EpsOcclusionCulling = 1; 617 | Print.EpsPointSizeFactor = 1; 618 | Print.EpsPS3Shading = 0; 619 | Print.EpsQuality = 1; 620 | Print.Format = 10; 621 | Print.GeoLabels = 1; 622 | Print.GeoOnlyPhysicals = 0; 623 | Print.GifDither = 0; 624 | Print.GifInterlace = 0; 625 | Print.GifSort = 1; 626 | Print.GifTransparent = 0; 627 | Print.Height = -1; 628 | Print.JpegQuality = 100; 629 | Print.JpegSmoothing = 0; 630 | Print.PgfTwoDim = 1; 631 | Print.PgfExportAxis = 0; 632 | Print.PgfHorizontalBar = 0; 633 | Print.PostElementary = 1; 634 | Print.PostElement = 0; 635 | Print.PostGamma = 0; 636 | Print.PostEta = 0; 637 | Print.PostSICN = 0; 638 | Print.PostSIGE = 0; 639 | Print.PostDisto = 0; 640 | Print.TexAsEquation = 0; 641 | Print.TexForceFontSize = 0; 642 | Print.TexWidthInMm = 150; 643 | Print.Text = 1; 644 | Print.X3dCompatibility = 0; 645 | Print.X3dPrecision = 1e-09; 646 | Print.X3dRemoveInnerBorders = 0; 647 | Print.X3dTransparency = 0; 648 | Print.X3dSurfaces = 1; 649 | Print.X3dEdges = 0; 650 | Print.X3dVertices = 0; 651 | Print.Width = -1; 652 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_3D/heat_exchanger.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from firedrake import inner, dot, grad, div, dx, ds, sin, pi, as_vector, cos 3 | import firedrake_adjoint as fda 4 | 5 | from letop.levelset import LevelSetFunctional, RegularizationSolver 6 | from letop.optimization import ( 7 | InfDimProblem, 8 | Constraint, 9 | nlspace_solve, 10 | read_checkpoint, 11 | is_checkpoint, 12 | ) 13 | from letop.physics import ( 14 | mark_no_flow_regions, 15 | ) 16 | from physics_solvers import ( 17 | temperature_solver, 18 | flow_solver, 19 | bc_velocity_profile, 20 | ) 21 | import signal 22 | from qois import pressure_drop, heat_flux 23 | from itertools import count 24 | import petsc4py 25 | from pyadjoint import stop_annotating 26 | import argparse 27 | from copy import copy 28 | from solver_parameters import ( 29 | reinit_solver_parameters, 30 | hj_solver_parameters, 31 | regularization_solver_parameters, 32 | temperature_solver_parameters, 33 | ns_solver_parameters, 34 | ) 35 | from parameters_box import WALLS, DESIGN_DOMAIN 36 | 37 | petsc4py.PETSc.Sys.popErrorHandler() 38 | 39 | 40 | def print(x): 41 | return fd.PETSc.Sys.Print(x) 42 | 43 | 44 | def forward( 45 | W, 46 | T, 47 | phi, 48 | opts, 49 | brinkmann_penalty, 50 | *, 51 | no_flow_domain_1, 52 | no_flow_domain_2, 53 | markers, 54 | ): 55 | # Parameters 56 | nu = fd.Constant(opts.nu) # viscosity 57 | beta_gls = 0.9 58 | PeInv_val = 2e-4 59 | PeInv = fd.Constant(PeInv_val) 60 | t1 = fd.Constant(10.0) 61 | t2 = fd.Constant(1.0) 62 | 63 | x, y, z = fd.SpatialCoordinate(W.ufl_domain()) 64 | 65 | inflow1, inflow2 = bc_velocity_profile(opts.type_he, (x, y, z)) 66 | 67 | # Navier-Stokes 1 68 | w_sol1 = fd.Function(W) 69 | 70 | solver1 = flow_solver( 71 | W, 72 | w_sol1, 73 | no_flow=no_flow_domain_1, 74 | phi=phi, 75 | beta_gls=beta_gls, 76 | solver_parameters=ns_solver_parameters, 77 | brinkmann_penalty=brinkmann_penalty, 78 | design_domain=DESIGN_DOMAIN, 79 | inflow=inflow1, 80 | inlet=markers["INLET1"], 81 | walls=(markers["WALLS"], markers["INLET2"], markers["OUTLET2"]), 82 | nu=nu, 83 | ) 84 | solver1.solve() 85 | u_sol1, _ = fd.split(w_sol1) 86 | 87 | # Navier-Stokes 2 88 | w_sol2 = fd.Function(W) 89 | solver2 = flow_solver( 90 | W, 91 | w_sol2, 92 | no_flow=no_flow_domain_2, 93 | phi=-phi, 94 | beta_gls=beta_gls, 95 | solver_parameters=ns_solver_parameters, 96 | brinkmann_penalty=brinkmann_penalty, 97 | design_domain=DESIGN_DOMAIN, 98 | inflow=inflow2, 99 | inlet=markers["INLET2"], 100 | walls=(markers["WALLS"], markers["INLET1"], markers["OUTLET1"]), 101 | nu=nu, 102 | ) 103 | solver2.solve() 104 | u_sol2, _ = fd.split(w_sol2) 105 | 106 | beta = u_sol1 + u_sol2 107 | t = fd.Function(T, name="Temperature") 108 | solver_T = temperature_solver( 109 | T, 110 | t, 111 | beta, 112 | PeInv, 113 | solver_parameters=temperature_solver_parameters, 114 | t1=t1, 115 | INLET1=markers["INLET1"], 116 | t2=t2, 117 | INLET2=markers["INLET2"], 118 | ) 119 | solver_T.solve() 120 | 121 | return w_sol1, w_sol2, t 122 | 123 | 124 | def heat_exchanger_3D(): 125 | parser = argparse.ArgumentParser(description="Level set method parameters") 126 | parser.add_argument( 127 | "--nu", 128 | action="store", 129 | dest="nu", 130 | type=float, 131 | help="Kinematic Viscosity", 132 | default=1.0, 133 | ) 134 | parser.add_argument( 135 | "--brinkmann_penalty", 136 | action="store", 137 | dest="brinkmann_penalty", 138 | type=float, 139 | help="Brinkmann term", 140 | default=1e5, 141 | ) 142 | parser.add_argument( 143 | "--refinement", 144 | action="store", 145 | dest="refinement", 146 | type=int, 147 | help="Level of refinement", 148 | default=0, 149 | ) 150 | parser.add_argument( 151 | "--pressure_drop_constraint", 152 | action="store", 153 | dest="pressure_drop_constraint", 154 | type=float, 155 | help="Pressure drop constraint", 156 | default=10.0, 157 | ) 158 | parser.add_argument( 159 | "--n_iters", 160 | dest="n_iters", 161 | type=int, 162 | action="store", 163 | default=1000, 164 | help="Number of optimization iterations", 165 | ) 166 | parser.add_argument( 167 | "--output_dir", 168 | dest="output_dir", 169 | type=str, 170 | action="store", 171 | default="./", 172 | help="Output folder", 173 | ) 174 | parser.add_argument( 175 | "--type", 176 | dest="type_he", 177 | type=str, 178 | action="store", 179 | default="parallel", 180 | help="Type of heat exchanger: parallel or counter", 181 | ) 182 | opts = parser.parse_args() 183 | print(f"Parameters used: {opts}") 184 | 185 | beta_param = 0.4 186 | mesh = fd.Mesh("./box_heat_exch.msh") 187 | 188 | from parameters_box import ( 189 | INLET2, 190 | INLET1, 191 | OUTLET1, 192 | OUTLET2, 193 | INMOUTH1, 194 | INMOUTH2, 195 | OUTMOUTH1, 196 | OUTMOUTH2, 197 | ) 198 | 199 | if opts.type_he == "counter": 200 | INLET1, OUTLET1 = OUTLET1, INLET1 201 | elif opts.type_he == "u_flow": 202 | INLET2, OUTLET1 = OUTLET1, INLET2 203 | OUTMOUTH1, INMOUTH2 = INMOUTH2, OUTMOUTH1 204 | 205 | markers = { 206 | "WALLS": WALLS, 207 | "INLET1": INLET1, 208 | "INLET2": INLET2, 209 | "OUTLET1": OUTLET1, 210 | "OUTLET2": OUTLET2, 211 | } 212 | 213 | no_flow_domain_1 = [INMOUTH2, OUTMOUTH2] 214 | no_flow_domain_2 = [INMOUTH1, OUTMOUTH1] 215 | no_flow = no_flow_domain_1.copy() 216 | no_flow.extend(no_flow_domain_2) 217 | mesh = mark_no_flow_regions(mesh, no_flow, no_flow) 218 | 219 | mh = fd.MeshHierarchy(mesh, opts.refinement) 220 | mesh = mh[-1] 221 | 222 | pressure_drop_constraint = opts.pressure_drop_constraint 223 | pressure_drop_1 = pressure_drop_constraint 224 | pressure_drop_2 = pressure_drop_constraint 225 | 226 | S = fd.VectorFunctionSpace(mesh, "CG", 1) 227 | 228 | PHI = fd.FunctionSpace(mesh, "CG", 1) 229 | phi = fd.Function(PHI, name="LevelSet") 230 | x, y, z = fd.SpatialCoordinate(mesh) 231 | 232 | ω = 0.25 233 | phi_expr = sin(y * pi / ω) * cos(x * pi / ω) * sin( 234 | z * pi / ω 235 | ) - fd.Constant(0.2) 236 | 237 | checkpoints = is_checkpoint(opts.output_dir) 238 | if checkpoints: 239 | current_iter = read_checkpoint(checkpoints, phi) 240 | with open( 241 | f"{opts.output_dir}/brinkmann_penalty.txt", "r" 242 | ) as txt_brinkmann: 243 | brinkmann_penalty_initial = fd.Constant(txt_brinkmann.read()) 244 | print( 245 | f"Current brinkmann term: {brinkmann_penalty_initial.values()[0]}" 246 | ) 247 | else: 248 | with stop_annotating(): 249 | phi.interpolate(phi_expr) 250 | current_iter = 0 251 | brinkmann_penalty_initial = fd.Constant(opts.brinkmann_penalty) 252 | 253 | P2 = fd.VectorElement("CG", mesh.ufl_cell(), 1) 254 | P1 = fd.FiniteElement("CG", mesh.ufl_cell(), 1) 255 | TH = P2 * P1 256 | W = fd.FunctionSpace(mesh, TH) 257 | print(f"DOFS: {W.dim()}") 258 | 259 | T = fd.FunctionSpace(mesh, "CG", 1) 260 | 261 | global_counter = count(current_iter) 262 | 263 | def receive_signal(signum, stack): 264 | iter_current = next(copy(global_counter)) 265 | print(f"Received: {signum}, iter: {iter_current}") 266 | with fd.HDF5File( 267 | f"{opts.output_dir}/checkpoint_iter_{iter_current}.h5", "w" 268 | ) as checkpoint: 269 | checkpoint.write(phi, "/checkpoint") 270 | with open( 271 | f"{opts.output_dir}/brinkmann_penalty.txt", "w" 272 | ) as txt_brinkmann: 273 | txt_brinkmann.write(str(brinkmann_penalty.values()[0])) 274 | 275 | signal.signal(signal.SIGHUP, receive_signal) 276 | 277 | phi_pvd = fd.File( 278 | f"{opts.output_dir}/phi_evolution.pvd", 279 | target_degree=1, 280 | target_continuity=fd.H1, 281 | mode="a", 282 | ) 283 | ns1 = fd.File(f"{opts.output_dir}/navier_stokes_1.pvd", mode="a") 284 | ns2 = fd.File(f"{opts.output_dir}/navier_stokes_2.pvd", mode="a") 285 | temperature = fd.File(f"{opts.output_dir}/temperature.pvd", mode="a") 286 | temperature_pvd = fd.Function(T) 287 | 288 | def termination_event_1(): 289 | p1_constraint = P1control.tape_value() - 1 290 | p2_constraint = P2control.tape_value() - 1 291 | event_value = max(p1_constraint, p2_constraint) 292 | print(f"Value event: {event_value}") 293 | return event_value 294 | 295 | def termination_event_2(): 296 | iter_current = next(copy(global_counter)) 297 | print(f"Value event iter count: {iter_current}") 298 | return float(iter_current % 500) 299 | 300 | brinkmann_penalty_initial_value = brinkmann_penalty_initial.values()[0] 301 | if brinkmann_penalty_initial_value > opts.brinkmann_penalty: 302 | termination_events = [termination_event_2, termination_event_2] 303 | brinkmann_pen_terms = [ 304 | brinkmann_penalty_initial, 305 | fd.Constant(brinkmann_penalty_initial_value * 10), 306 | ] 307 | else: 308 | termination_events = [termination_event_1, None] 309 | brinkmann_pen_terms = [ 310 | brinkmann_penalty_initial, 311 | fd.Constant(brinkmann_penalty_initial_value * 5), 312 | ] 313 | 314 | for termination_event, brinkmann_penalty in zip( 315 | termination_events, brinkmann_pen_terms 316 | ): 317 | 318 | s = fd.Function(S, name="deform") 319 | mesh.coordinates.assign(mesh.coordinates + s) 320 | # w_sol1, w_sol2, t = forward(brinkmann_penalty) 321 | 322 | w_sol1, w_sol2, t = forward( 323 | W, 324 | T, 325 | phi, 326 | opts, 327 | brinkmann_penalty, 328 | no_flow_domain_1=no_flow_domain_1, 329 | no_flow_domain_2=no_flow_domain_2, 330 | markers=markers, 331 | ) 332 | 333 | w_sol1_control = fda.Control(w_sol1) 334 | w_sol2_control = fda.Control(w_sol2) 335 | t_control = fda.Control(t) 336 | 337 | J = heat_flux(w_sol2, t, OUTLET2) 338 | J_hot = heat_flux(w_sol1, t, OUTLET1) 339 | Pdrop1 = pressure_drop(w_sol1, INLET1, OUTLET1, pressure_drop_1) 340 | Pdrop2 = pressure_drop(w_sol2, INLET2, OUTLET2, pressure_drop_2) 341 | print(f"Cold flux: {J}, hot flux: {J_hot}") 342 | 343 | c = fda.Control(s) 344 | J_hot_control = fda.Control(J_hot) 345 | 346 | def deriv_cb(phi): 347 | with stop_annotating(): 348 | iter = next(global_counter) 349 | print(f"Hot flux: {J_hot_control.tape_value()}") 350 | if iter % 15 == 0: 351 | u_sol1, p_sol1 = w_sol1_control.tape_value().split() 352 | u_sol2, p_sol2 = w_sol2_control.tape_value().split() 353 | 354 | u_sol1.rename("Velocity1") 355 | p_sol1.rename("Pressure1") 356 | 357 | u_sol2.rename("Velocity2") 358 | p_sol2.rename("Pressure2") 359 | 360 | ns1.write(u_sol1, p_sol1, time=iter) 361 | ns2.write(u_sol2, p_sol2, time=iter) 362 | phi_pvd.write(phi[0], time=iter) 363 | 364 | temperature_pvd.assign(t_control.tape_value()) 365 | temperature_pvd.rename("temperature") 366 | temperature.write(temperature_pvd, time=iter) 367 | 368 | # Reduced Functionals 369 | Jhat = LevelSetFunctional(J, c, phi, derivative_cb_pre=deriv_cb) 370 | P1hat = LevelSetFunctional(Pdrop1, c, phi) 371 | P1control = fda.Control(Pdrop1) 372 | 373 | P2hat = LevelSetFunctional(Pdrop2, c, phi) 374 | P2control = fda.Control(Pdrop2) 375 | print("Pressure drop 1 {:.5f}".format(Pdrop1)) 376 | print("Pressure drop 2 {:.5f}".format(Pdrop2)) 377 | 378 | reg_solver = RegularizationSolver( 379 | S, 380 | mesh, 381 | beta=beta_param, 382 | gamma=1e6, 383 | dx=dx, 384 | design_domain=DESIGN_DOMAIN, 385 | solver_parameters=regularization_solver_parameters, 386 | ) 387 | 388 | tol = 1e-7 389 | dt = 0.02 390 | params = { 391 | "alphaC": 0.1, 392 | "debug": 5, 393 | "alphaJ": 0.1, 394 | "dt": dt, 395 | "K": 1e-3, 396 | "maxit": opts.n_iters, 397 | "maxtrials": 10, 398 | "itnormalisation": 10, 399 | "tol_merit": 1e-2, # new merit can be within 1% of the previous merit 400 | # "normalize_tol" : -1, 401 | "tol": tol, 402 | } 403 | 404 | hj_solver_parameters["ts_dt"] = dt / 50.0 405 | solver_parameters = { 406 | "hj_solver": hj_solver_parameters, 407 | "reinit_solver": reinit_solver_parameters, 408 | } 409 | 410 | problem = InfDimProblem( 411 | Jhat, 412 | reg_solver, 413 | ineqconstraints=[ 414 | Constraint(P1hat, 1.0, P1control), 415 | Constraint(P2hat, 1.0, P2control), 416 | ], 417 | reinit_distance=0.08, 418 | solver_parameters=solver_parameters, 419 | ) 420 | problem.set_termination_event( 421 | termination_event, termination_tolerance=1e-1 422 | ) 423 | 424 | _ = nlspace_solve(problem, params) 425 | fda.get_working_tape().clear_tape() 426 | 427 | 428 | if __name__ == "__main__": 429 | fd.parameters["form_compiler"]["quadrature_degree"] = 4 430 | heat_exchanger_3D() 431 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_3D/parameters_box.py: -------------------------------------------------------------------------------- 1 | WALLS = 5 2 | INLET1 = 1 3 | INLET2 = 3 4 | OUTLET1 = 2 5 | OUTLET2 = 4 6 | DESIGN_DOMAIN = 0 7 | INMOUTH1 = 6 8 | INMOUTH2 = 7 9 | OUTMOUTH1 = 8 10 | OUTMOUTH2 = 9 11 | 12 | inlet_1_coords = (-0.2, 0.8, 0.15) 13 | inlet_2_coords = (-0.2, 0.2, 0.15) 14 | outlet_1_coords = (1.2, 0.8, 0.15) 15 | outlet_2_coords = (1.2, 0.2, 0.15) 16 | 17 | # Inlet radius 18 | R1 = 0.1 19 | R2 = 0.1 20 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_3D/physics_solvers.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from letop.physics import ( 3 | AdvectionDiffusionGLS, 4 | NavierStokesBrinkmannForm, 5 | NavierStokesBrinkmannSolver, 6 | InteriorBC, 7 | ) 8 | 9 | 10 | def temperature_solver( 11 | T, t, beta, PeInv, solver_parameters, *, t1, INLET1, t2, INLET2 12 | ): 13 | F_T = AdvectionDiffusionGLS(T, beta, t, PeInv=PeInv) 14 | 15 | bc1 = fd.DirichletBC(T, t1, INLET1) 16 | bc2 = fd.DirichletBC(T, t2, INLET2) 17 | bcs = [bc1, bc2] 18 | problem_T = fd.NonlinearVariationalProblem(F_T, t, bcs=bcs) 19 | return fd.NonlinearVariationalSolver( 20 | problem_T, solver_parameters=solver_parameters 21 | ) 22 | 23 | 24 | def flow_solver( 25 | W, 26 | w_sol, 27 | no_flow=None, 28 | phi=None, 29 | beta_gls=0.9, 30 | design_domain=None, 31 | solver_parameters=None, 32 | brinkmann_penalty=0.0, 33 | *, 34 | inflow, 35 | inlet, 36 | walls, 37 | nu, 38 | ): 39 | F = NavierStokesBrinkmannForm( 40 | W, 41 | w_sol, 42 | nu, 43 | phi=phi, 44 | brinkmann_penalty=brinkmann_penalty, 45 | design_domain=design_domain, 46 | beta_gls=beta_gls, 47 | ) 48 | 49 | noslip = fd.Constant((0.0, 0.0, 0.0)) 50 | bcs_1 = fd.DirichletBC(W.sub(0), noslip, walls) 51 | bcs_2 = fd.DirichletBC(W.sub(0), inflow, inlet) 52 | bcs = [bcs_1, bcs_2] 53 | if no_flow: 54 | bcs_no_flow = InteriorBC(W.sub(0), noslip, no_flow) 55 | bcs.append(bcs_no_flow) 56 | 57 | problem = fd.NonlinearVariationalProblem(F, w_sol, bcs=bcs) 58 | 59 | return NavierStokesBrinkmannSolver( 60 | problem, solver_parameters=solver_parameters 61 | ) 62 | 63 | 64 | def bc_velocity_profile(type_he, X): 65 | u_inflow = 1.0 66 | from parameters_box import ( 67 | inlet_1_coords, 68 | inlet_2_coords, 69 | outlet_1_coords, 70 | R1, 71 | R2, 72 | ) 73 | 74 | if type_he == "parallel": 75 | sign_inlet_1 = 1 76 | sign_inlet_2 = 1 77 | elif type_he == "counter": 78 | inlet_1_coords, outlet_1_coords = outlet_1_coords, inlet_1_coords 79 | sign_inlet_1 = -1 80 | sign_inlet_2 = 1 81 | elif type_he == "u_flow": 82 | inlet_2_coords, outlet_1_coords = outlet_1_coords, inlet_2_coords 83 | R1, R2 = R2, R1 84 | sign_inlet_1 = 1 85 | sign_inlet_2 = -1 86 | else: 87 | raise RuntimeError( 88 | f"type of heat exchanger {type_he} is invalid. \ 89 | Choose parallel, counter or u_flow" 90 | ) 91 | 92 | x1, y1, z1 = inlet_1_coords 93 | x, y, z = X 94 | r1_2 = (x - x1) ** 2 + (y - y1) ** 2 + (z - z1) ** 2 95 | inflow1 = fd.as_vector( 96 | [sign_inlet_1 * u_inflow / R1 ** 2 * (R1 ** 2 - r1_2), 0.0, 0.0] 97 | ) 98 | x2, y2, z2 = inlet_2_coords 99 | r2_2 = (x - x2) ** 2 + (y - y2) ** 2 + (z - z2) ** 2 100 | inflow2 = fd.as_vector( 101 | [sign_inlet_2 * u_inflow / R2 ** 2 * (R2 ** 2 - r2_2), 0.0, 0.0] 102 | ) 103 | 104 | return ( 105 | inflow1, 106 | inflow2, 107 | ) 108 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_3D/qois.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from firedrake import ds, inner 3 | 4 | 5 | def pressure_drop(w_sol, INLET, OUTLET, pdrop_constr): 6 | _, p_sol = fd.split(w_sol) 7 | 8 | return fd.assemble(p_sol * ds(INLET) - p_sol * ds(OUTLET)) / pdrop_constr 9 | 10 | 11 | def heat_flux(w_sol, t, OUTLET): 12 | u_sol, _ = fd.split(w_sol) 13 | scale_factor = 5.0 14 | n = fd.FacetNormal(w_sol.ufl_domain()) 15 | return fd.assemble( 16 | fd.Constant(-scale_factor) * inner(t * u_sol, n) * ds(OUTLET) 17 | ) 18 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_3D/solver_parameters.py: -------------------------------------------------------------------------------- 1 | reinit_solver_parameters = { 2 | "ksp_type": "cg", 3 | "ksp_rtol": 1e-6, 4 | "pc_type": "hypre", 5 | "pc_hypre_type": "boomeramg", 6 | "pc_hypre_boomeramg_max_iter": 5, 7 | "pc_hypre_boomeramg_coarsen_type": "PMIS", 8 | "pc_hypre_boomeramg_agg_nl": 2, 9 | "pc_hypre_boomeramg_strong_threshold": 0.95, 10 | "pc_hypre_boomeramg_interp_type": "ext+i", 11 | "pc_hypre_boomeramg_P_max": 2, 12 | "pc_hypre_boomeramg_relax_type_all": "sequential-Gauss-Seidel", 13 | "pc_hypre_boomeramg_grid_sweeps_all": 1, 14 | "pc_hypre_boomeramg_truncfactor": 0.3, 15 | "pc_hypre_boomeramg_max_levels": 6, 16 | "ksp_max_it": 200, 17 | "ksp_converged_maxits": None, 18 | } 19 | 20 | hj_solver_parameters = { 21 | "peclet_number": 1e-3, 22 | "ksp_type": "gmres", 23 | "ksp_converged_maxits": None, 24 | "snes_type": "ksponly", 25 | "snes_no_convergence_test": None, 26 | "snes_atol": 1e-5, 27 | "ksp_atol": 1e-5, 28 | "ksp_rtol": 1e-5, 29 | "ts_type": "beuler", 30 | "pc_type": "bjacobi", 31 | "sub_pc_type": "ilu", 32 | "sub_pc_factor_levels": 1, 33 | "ksp_max_it": 5000, 34 | "ksp_gmres_restart": 200, 35 | "ts_atol": 1e-5, 36 | "ts_rtol": 1e-5, 37 | "ts_max_steps": 400, 38 | # "ksp_monitor": None 39 | # "snes_monitor": None, 40 | # "ts_monitor": None, 41 | # "ksp_converged_reason": None, 42 | } 43 | regularization_solver_parameters = { 44 | "mat_type": "aij", 45 | "ksp_type": "cg", 46 | "pc_type": "hypre", 47 | "pc_hypre_type": "boomeramg", 48 | "pc_hypre_boomeramg_max_iter": 200, 49 | "pc_hypre_boomeramg_coarsen_type": "HMIS", 50 | "pc_hypre_boomeramg_agg_nl": 1, 51 | "pc_hypre_boomeramg_strong_threshold": 0.7, 52 | "pc_hypre_boomeramg_interp_type": "ext+i", 53 | "pc_hypre_boomeramg_P_max": 4, 54 | "pc_hypre_boomeramg_relax_type_all": "sequential-Gauss-Seidel", 55 | "pc_hypre_boomeramg_grid_sweeps_all": 1, 56 | "pc_hypre_boomeramg_max_levels": 15, 57 | "ksp_converged_reason": None, 58 | } 59 | temperature_solver_parameters = { 60 | "ksp_type": "fgmres", 61 | "snes_atol": 1e-6, 62 | "pc_type": "python", 63 | "pc_python_type": "firedrake.AssembledPC", 64 | "assembled_mat_type": "aij", 65 | "assembled_pc_type": "hypre", 66 | "assembled_pc_hypre_boomeramg_P_max": 4, 67 | "assembled_pc_hypre_boomeramg_agg_nl": 1, 68 | "assembled_pc_hypre_boomeramg_agg_num_paths": 2, 69 | "assembled_pc_hypre_boomeramg_coarsen_type": "HMIS", 70 | "assembled_pc_hypre_boomeramg_interp_type": "ext+i", 71 | "assembled_pc_hypre_boomeramg_no_CF": True, 72 | "ksp_max_it": 300, 73 | } 74 | 75 | ns_solver_tolerances = 1e-4 76 | ns_solver_parameters = { 77 | "ksp_converged_maxits": None, 78 | "ksp_max_it": 1000, 79 | "ksp_atol": ns_solver_tolerances, 80 | "ksp_rtol": ns_solver_tolerances, 81 | # "ksp_monitor": None, 82 | "snes_atol": 1e-4, 83 | "snes_rtol": 1e-4, 84 | "snes_max_it": 10, 85 | "snes_no_convergence_test": None, 86 | "ksp_converged_reason": None, 87 | } 88 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_ns/2D_mesh.geo: -------------------------------------------------------------------------------- 1 | // This code was created by pygmsh vunknown. 2 | SetFactory("OpenCASCADE"); 3 | Mesh.CharacteristicLengthMin = 0.02; 4 | Mesh.CharacteristicLengthMax = 0.02; 5 | s0 = news; 6 | Rectangle(s0) = {0.0, 0.0, 0.0, 1.2, 1.5}; 7 | s1 = news; 8 | Rectangle(s1) = {-0.2, -2.7755575615628914e-17, 0.0, 0.2, 0.2}; 9 | s2 = news; 10 | Rectangle(s2) = {-0.2, 0.26, 0.0, 0.2, 0.2}; 11 | s3 = news; 12 | Rectangle(s3) = {1.2, -2.7755575615628914e-17, 0.0, 0.2, 0.2}; 13 | s4 = news; 14 | Rectangle(s4) = {1.2, 0.26, 0.0, 0.2, 0.2}; 15 | Physical Surface(2) = {s1}; 16 | Physical Surface(3) = {s2}; 17 | Physical Surface(4) = {s3}; 18 | Physical Surface(5) = {s4}; 19 | Physical Surface(0) = {s0}; 20 | bo1[] = BooleanFragments{ Surface{s0}; Delete; } { Surface{s1};Surface{s2};Surface{s3};Surface{s4}; Delete;}; 21 | vb1[] = Boundary{Surface{ s1 };}; 22 | vb2[] = Boundary{Surface{ s2 };}; 23 | vb3[] = Boundary{Surface{ s3 };}; 24 | vb4[] = Boundary{Surface{ s4 };}; 25 | vb0[] = Boundary{Surface{ s0 };}; 26 | Physical Curve(5) = {vb0[], 27 | vb1[0], vb1[2], 28 | vb2[0], vb2[2], 29 | vb3[0], vb3[2], 30 | vb4[0], vb4[2]}; 31 | Physical Curve(5) -= {-vb1[1], -vb2[1], -vb3[3], -vb4[3]}; 32 | Physical Curve(1) = {vb1[3]}; 33 | Physical Curve(2) = {vb3[1]}; 34 | Physical Curve(3) = {vb2[3]}; 35 | Physical Curve(4) = {vb4[1]}; 36 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_ns/2D_mesh.py: -------------------------------------------------------------------------------- 1 | import pygmsh as pg 2 | from parameters import ( 3 | height, 4 | width, 5 | dist_center, 6 | inlet_width, 7 | inlet_depth, 8 | line_sep, 9 | ymin1, 10 | ymin2, 11 | ) 12 | from parameters import ( 13 | INMOUTH1, 14 | INMOUTH2, 15 | OUTMOUTH1, 16 | OUTMOUTH2, 17 | INLET1, 18 | INLET2, 19 | OUTLET1, 20 | OUTLET2, 21 | WALLS, 22 | DOMAIN, 23 | ) 24 | 25 | 26 | def main(): 27 | # geom = pg.built_in.Geometry() 28 | size = 0.02 29 | geom = pg.opencascade.Geometry( 30 | characteristic_length_min=size, characteristic_length_max=size 31 | ) 32 | 33 | main_rect = geom.add_rectangle([0.0, 0.0, 0.0], width, height) 34 | mouth_inlet1 = geom.add_rectangle( 35 | [-inlet_depth, ymin1, 0.0], inlet_depth, inlet_width 36 | ) 37 | mouth_inlet2 = geom.add_rectangle( 38 | [-inlet_depth, ymin2, 0.0], inlet_depth, inlet_width 39 | ) 40 | 41 | mouth_outlet1 = geom.add_rectangle( 42 | [width, ymin1, 0.0], inlet_depth, inlet_width 43 | ) 44 | mouth_outlet2 = geom.add_rectangle( 45 | [width, ymin2, 0.0], inlet_depth, inlet_width 46 | ) 47 | 48 | print("ymin1 :{}".format(ymin1)) 49 | print("ymin2 :{}".format(ymin2)) 50 | 51 | geom.add_physical(mouth_inlet1, INMOUTH1) 52 | geom.add_physical(mouth_inlet2, INMOUTH2) 53 | geom.add_physical(mouth_outlet1, OUTMOUTH1) 54 | geom.add_physical(mouth_outlet2, OUTMOUTH2) 55 | geom.add_physical([main_rect], DOMAIN) 56 | 57 | _ = geom.boolean_fragments( 58 | [main_rect], [mouth_inlet1, mouth_inlet2, mouth_outlet1, mouth_outlet2] 59 | ) 60 | 61 | geom.add_raw_code( 62 | """vb1[] = Boundary{{Surface{{ {0} }};}}; 63 | vb2[] = Boundary{{Surface{{ {1} }};}}; 64 | vb3[] = Boundary{{Surface{{ {2} }};}}; 65 | vb4[] = Boundary{{Surface{{ {3} }};}}; 66 | vb0[] = Boundary{{Surface{{ {4} }};}};""".format( 67 | mouth_inlet1.id, 68 | mouth_inlet2.id, 69 | mouth_outlet1.id, 70 | mouth_outlet2.id, 71 | main_rect.id, 72 | ) 73 | ) 74 | geom.add_raw_code( 75 | """Physical Curve({0}) = {{vb0[], 76 | vb1[0], vb1[2], 77 | vb2[0], vb2[2], 78 | vb3[0], vb3[2], 79 | vb4[0], vb4[2]}};""".format( 80 | WALLS 81 | ) 82 | ) 83 | 84 | geom.add_raw_code( 85 | "Physical Curve({0}) -= {{-vb1[1], -vb2[1], -vb3[3], -vb4[3]}};\n \ 86 | Physical Curve({1}) = {{vb1[3]}};\n \ 87 | Physical Curve({2}) = {{vb3[1]}};\n \ 88 | Physical Curve({3}) = {{vb2[3]}};\n \ 89 | Physical Curve({4}) = {{vb4[1]}};".format( 90 | WALLS, INLET1, OUTLET1, INLET2, OUTLET2 91 | ) 92 | ) 93 | 94 | mesh = pg.generate_mesh(geom, geo_filename="2D_mesh.geo") 95 | import meshio 96 | 97 | meshio.write("2D_mesh_heat_exchanger.vtk", mesh) 98 | 99 | 100 | if __name__ == "__main__": 101 | main() 102 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_ns/heat_exchanger.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | import firedrake_adjoint as fda 3 | from firedrake import inner, grad, ds, dx, sin, cos, pi, dot, div 4 | 5 | from letop.levelset import LevelSetFunctional, RegularizationSolver 6 | from letop.optimization import Constraint, InfDimProblem, nullspace_shape 7 | from letop.physics import ( 8 | NavierStokesBrinkmannForm, 9 | mark_no_flow_regions, 10 | InteriorBC, 11 | hs, 12 | ) 13 | from pyadjoint import get_working_tape 14 | 15 | from params import ( 16 | line_sep, 17 | dist_center, 18 | inlet_width, 19 | WALLS, 20 | INLET1, 21 | INLET2, 22 | OUTLET1, 23 | OUTLET2, 24 | INMOUTH1, 25 | INMOUTH2, 26 | OUTMOUTH1, 27 | OUTMOUTH2, 28 | DOMAIN, 29 | ) 30 | 31 | from pyadjoint import stop_annotating 32 | import argparse 33 | 34 | 35 | def heat_exchanger_navier_stokes(): 36 | 37 | parser = argparse.ArgumentParser(description="Level set method parameters") 38 | parser.add_argument( 39 | "--nu", 40 | action="store", 41 | dest="nu", 42 | type=float, 43 | help="Viscosity", 44 | default=0.5, 45 | ) 46 | opts, unknown = parser.parse_known_args() 47 | 48 | output_dir = "2D/" 49 | 50 | mesh = fd.Mesh("./2D_mesh.msh") 51 | no_flow_domain_1 = [3, 5] 52 | no_flow_domain_1_markers = [7, 8] 53 | no_flow_domain_2 = [2, 4] 54 | no_flow_domain_2_markers = [9, 10] 55 | no_flow = no_flow_domain_1.copy() 56 | no_flow.extend(no_flow_domain_2) 57 | no_flow_markers = no_flow_domain_1_markers.copy() 58 | no_flow_markers.extend(no_flow_domain_2_markers) 59 | mesh = mark_no_flow_regions(mesh, no_flow, no_flow_markers) 60 | 61 | S = fd.VectorFunctionSpace(mesh, "CG", 1) 62 | 63 | x, y = fd.SpatialCoordinate(mesh) 64 | PHI = fd.FunctionSpace(mesh, "CG", 1) 65 | phi_expr = sin(y * pi / 0.2) * cos(x * pi / 0.2) - fd.Constant(0.8) 66 | with stop_annotating(): 67 | phi = fd.interpolate(phi_expr, PHI) 68 | phi.rename("LevelSet") 69 | fd.File(output_dir + "phi_initial.pvd").write(phi) 70 | 71 | # Parameters 72 | solver_parameters = { 73 | "mat_type": "aij", 74 | "ksp_type": "preonly", 75 | "ksp_converged_reason": None, 76 | "pc_type": "lu", 77 | "pc_factor_mat_solver_type": "mumps", 78 | # "snes_monitor" : None, 79 | # "snes_type" : "ksponly", 80 | # "snes_no_convergence_test" : None, 81 | # "snes_max_it": 1, 82 | } 83 | u_inflow = 1.0 84 | nu = fd.Constant(opts.nu) 85 | brinkmann_penalty = fd.Constant(1e5) 86 | 87 | P2 = fd.VectorElement("CG", mesh.ufl_cell(), 1) 88 | P1 = fd.FiniteElement("CG", mesh.ufl_cell(), 1) 89 | TH = P2 * P1 90 | W = fd.FunctionSpace(mesh, TH) 91 | n = fd.FacetNormal(mesh) 92 | 93 | def forward(brinkmann_penalty): 94 | 95 | # Stokes 1 96 | w_sol1 = fd.Function(W) 97 | F1 = NavierStokesBrinkmannForm( 98 | W, 99 | w_sol1, 100 | nu, 101 | phi=-phi, 102 | brinkmann_penalty=brinkmann_penalty, 103 | design_domain=DOMAIN, 104 | ) 105 | 106 | # Dirichelt boundary conditions 107 | inflow1 = fd.as_vector( 108 | [ 109 | u_inflow 110 | * sin( 111 | ((y - (line_sep - (dist_center + inlet_width))) * pi) 112 | / inlet_width 113 | ), 114 | 0.0, 115 | ] 116 | ) 117 | 118 | noslip = fd.Constant((0.0, 0.0)) 119 | 120 | bcs1_1 = fd.DirichletBC(W.sub(0), noslip, WALLS) 121 | bcs1_2 = fd.DirichletBC(W.sub(0), inflow1, INLET1) 122 | bcs1_3 = fd.DirichletBC(W.sub(1), fd.Constant(0.0), OUTLET1) 123 | bcs1_4 = fd.DirichletBC(W.sub(0), noslip, INLET2) 124 | bcs1_5 = fd.DirichletBC(W.sub(0), noslip, OUTLET2) 125 | bc_no_flow_1 = InteriorBC(W.sub(0), noslip, no_flow_domain_1_markers) 126 | bcs1 = [bcs1_1, bcs1_2, bcs1_3, bcs1_4, bcs1_5, bc_no_flow_1] 127 | # bcs1 = [bcs1_1, bcs1_2, bcs1_3, bcs1_4, bcs1_5] 128 | 129 | # Stokes 2 130 | w_sol2 = fd.Function(W) 131 | F2 = NavierStokesBrinkmannForm( 132 | W, 133 | w_sol2, 134 | nu, 135 | phi=phi, 136 | brinkmann_penalty=brinkmann_penalty, 137 | design_domain=DOMAIN, 138 | ) 139 | inflow2 = fd.as_vector( 140 | [ 141 | u_inflow 142 | * sin(((y - (line_sep + dist_center)) * pi) / inlet_width), 143 | 0.0, 144 | ] 145 | ) 146 | bcs2_1 = fd.DirichletBC(W.sub(0), noslip, WALLS) 147 | bcs2_2 = fd.DirichletBC(W.sub(0), inflow2, INLET2) 148 | bcs2_3 = fd.DirichletBC(W.sub(1), fd.Constant(0.0), OUTLET2) 149 | bcs2_4 = fd.DirichletBC(W.sub(0), noslip, INLET1) 150 | bcs2_5 = fd.DirichletBC(W.sub(0), noslip, OUTLET1) 151 | bc_no_flow_2 = InteriorBC(W.sub(0), noslip, no_flow_domain_2_markers) 152 | bcs2 = [bcs2_1, bcs2_2, bcs2_3, bcs2_4, bcs2_5, bc_no_flow_2] 153 | 154 | # Forward problems 155 | problem1 = fd.NonlinearVariationalProblem(F1, w_sol1, bcs=bcs1) 156 | problem2 = fd.NonlinearVariationalProblem(F2, w_sol2, bcs=bcs2) 157 | solver1 = fd.NonlinearVariationalSolver( 158 | problem1, 159 | solver_parameters=solver_parameters, 160 | options_prefix="ns_stokes1", 161 | ) 162 | solver1.solve() 163 | solver2 = fd.NonlinearVariationalSolver( 164 | problem2, 165 | solver_parameters=solver_parameters, 166 | options_prefix="ns_stokes2", 167 | ) 168 | solver2.solve() 169 | u1, p1 = fd.split(w_sol1) 170 | u2, p2 = fd.split(w_sol2) 171 | 172 | # Convection difussion equation 173 | k = fd.Constant(1e-3) 174 | t1 = fd.Constant(1.0) 175 | t2 = fd.Constant(10.0) 176 | 177 | h = fd.CellDiameter(mesh) 178 | T = fd.FunctionSpace(mesh, "CG", 1) 179 | t, rho = fd.Function(T), fd.TestFunction(T) 180 | n = fd.FacetNormal(mesh) 181 | beta = u1 + u2 182 | F = ( 183 | inner(beta, grad(t)) * rho + k * inner(grad(t), grad(rho)) 184 | ) * dx - inner(k * grad(t), n) * rho * (ds(OUTLET1) + ds(OUTLET2)) 185 | 186 | R_U = dot(beta, grad(t)) - k * div(grad(t)) 187 | beta_gls = 0.9 188 | h = fd.CellSize(mesh) 189 | tau_gls = beta_gls * ( 190 | (4.0 * dot(beta, beta) / h ** 2) + 9.0 * (4.0 * k / h ** 2) ** 2 191 | ) ** (-0.5) 192 | degree = 4 193 | 194 | theta_U = dot(beta, grad(rho)) - k * div(grad(rho)) 195 | F_T = F + tau_gls * inner(R_U, theta_U) * dx(degree=degree) 196 | 197 | bc1 = fd.DirichletBC(T, t1, INLET1) 198 | bc2 = fd.DirichletBC(T, t2, INLET2) 199 | bcs = [bc1, bc2] 200 | problem_T = fd.NonlinearVariationalProblem(F_T, t, bcs=bcs) 201 | solver_T = fd.NonlinearVariationalSolver( 202 | problem_T, 203 | solver_parameters=solver_parameters, 204 | options_prefix="temperature", 205 | ) 206 | solver_T.solve() 207 | t.rename("Temperature") 208 | 209 | fd.File("temperature.pvd").write(t) 210 | 211 | return w_sol1, w_sol2, t 212 | 213 | def opti_problem(w_sol1, w_sol2, t): 214 | u1, p1 = fd.split(w_sol1) 215 | u2, p2 = fd.split(w_sol2) 216 | 217 | power_drop = 20 218 | Power1 = fd.assemble(p1 / power_drop * ds(INLET1)) 219 | Power2 = fd.assemble(p2 / power_drop * ds(INLET2)) 220 | scale_factor = 1.0 221 | Jform = fd.assemble( 222 | fd.Constant(-scale_factor) * inner(t * u1, n) * ds(OUTLET1) 223 | ) 224 | return Jform, Power1, Power2 225 | 226 | # Plotting files and functions 227 | phi_pvd = fd.File("phi_evolution.pvd") 228 | flow_pvd = fd.File("flow_opti.pvd") 229 | 230 | w_pvd_1 = fd.Function(W) 231 | w_pvd_2 = fd.Function(W) 232 | 233 | def termination_event_1(): 234 | p1_constraint = P1control.tape_value() - 1 235 | p2_constraint = P2control.tape_value() - 1 236 | event_value = max(p1_constraint, p2_constraint) - 1 237 | print(f"Value event: {event_value}") 238 | return event_value 239 | 240 | for termination_event, brinkmann_penalty in zip( 241 | [termination_event_1, None], [fd.Constant(1e4), fd.Constant(1e5)] 242 | ): 243 | s = fd.Function(S, name="deform") 244 | mesh.coordinates.assign(mesh.coordinates + s) 245 | w_sol1, w_sol2, t = forward(brinkmann_penalty) 246 | w_sol1_control = fda.Control(w_sol1) 247 | w_sol2_control = fda.Control(w_sol2) 248 | 249 | Jform, Power1, Power2 = opti_problem(w_sol1, w_sol2, t) 250 | 251 | def deriv_cb(phi): 252 | with stop_annotating(): 253 | phi_pvd.write(phi[0]) 254 | w_pvd_1.assign(w_sol1_control.tape_value()) 255 | u1, p1 = w_pvd_1.split() 256 | u1.rename("vel1") 257 | w_pvd_2.assign(w_sol2_control.tape_value()) 258 | u2, p2 = w_pvd_2.split() 259 | u2.rename("vel2") 260 | flow_pvd.write(u1, u2) 261 | 262 | c = fda.Control(s) 263 | 264 | # Reduced Functionals 265 | Jhat = LevelSetFunctional(Jform, c, phi, derivative_cb_pre=deriv_cb) 266 | P1hat = LevelSetFunctional(Power1, c, phi) 267 | P1control = fda.Control(Power1) 268 | 269 | P2hat = LevelSetFunctional(Power2, c, phi) 270 | P2control = fda.Control(Power2) 271 | 272 | print("Power drop 1 {:.5f}".format(Power1), flush=True) 273 | print("Power drop 2 {:.5f}".format(Power2), flush=True) 274 | 275 | beta_param = 0.08 276 | reg_solver = RegularizationSolver( 277 | S, mesh, beta=beta_param, gamma=1e5, dx=dx, design_domain=DOMAIN 278 | ) 279 | 280 | tol = 1e-5 281 | dt = 0.05 282 | params = { 283 | "alphaC": 1.0, 284 | "debug": 5, 285 | "alphaJ": 1.0, 286 | "dt": dt, 287 | "K": 1e-3, 288 | "maxit": 200, 289 | # "maxit": 2, 290 | "maxtrials": 5, 291 | "itnormalisation": 10, 292 | "tol_merit": 5e-3, # new merit can be within 0.5% of the previous merit 293 | # "normalize_tol" : -1, 294 | "tol": tol, 295 | "monitor_time": True, 296 | } 297 | 298 | problem = InfDimProblem( 299 | Jhat, 300 | reg_solver, 301 | ineqconstraints=[ 302 | Constraint(P1hat, 1.0, P1control), 303 | Constraint(P2hat, 1.0, P2control), 304 | ], 305 | reinit_distance=0.1, 306 | termination_event=termination_event, 307 | ) 308 | _ = nullspace_shape(problem, params) 309 | get_working_tape().clear_tape() 310 | 311 | 312 | if __name__ == "__main__": 313 | heat_exchanger_navier_stokes() 314 | -------------------------------------------------------------------------------- /letop_examples/heat_exchanger_ns/params.py: -------------------------------------------------------------------------------- 1 | height = 1.5 2 | shift_center = 0.52 3 | dist_center = 0.03 4 | inlet_width = 0.2 5 | inlet_depth = 0.2 6 | width = 1.2 7 | line_sep = height / 2.0 - shift_center 8 | # Line separating both inlets 9 | DOMAIN = 0 10 | INMOUTH1 = 2 11 | INMOUTH2 = 3 12 | OUTMOUTH1 = 4 13 | OUTMOUTH2 = 5 14 | INLET1, OUTLET1, INLET2, OUTLET2, WALLS, DESIGNBC = 1, 2, 3, 4, 5, 6 15 | ymin1 = line_sep - (dist_center + inlet_width) 16 | ymin2 = line_sep + dist_center 17 | -------------------------------------------------------------------------------- /letop_examples/navier_stokes/mesh_stokes.geo: -------------------------------------------------------------------------------- 1 | // This code was created by pygmsh vunknown. 2 | p0 = newp; 3 | Point(p0) = {0.0, 0.0, 0.0, 0.02}; 4 | p1 = newp; 5 | Point(p1) = {0.0, 0.2, 0.0, 0.02}; 6 | p2 = newp; 7 | Point(p2) = {0.0, 0.4, 0.0, 0.02}; 8 | p3 = newp; 9 | Point(p3) = {0.0, 0.6000000000000001, 0.0, 0.02}; 10 | p4 = newp; 11 | Point(p4) = {0.0, 0.8, 0.0, 0.02}; 12 | p5 = newp; 13 | Point(p5) = {0.0, 1.0, 0.0, 0.02}; 14 | p6 = newp; 15 | Point(p6) = {1.0, 1.0, 0.0, 0.02}; 16 | p7 = newp; 17 | Point(p7) = {1.0, 0.8, 0.0, 0.02}; 18 | p8 = newp; 19 | Point(p8) = {1.0, 0.6000000000000001, 0.0, 0.02}; 20 | p9 = newp; 21 | Point(p9) = {1.0, 0.4, 0.0, 0.02}; 22 | p10 = newp; 23 | Point(p10) = {1.0, 0.2, 0.0, 0.02}; 24 | p11 = newp; 25 | Point(p11) = {1.0, 0.0, 0.0, 0.02}; 26 | l0 = newl; 27 | Line(l0) = {p0, p1}; 28 | l1 = newl; 29 | Line(l1) = {p1, p2}; 30 | l2 = newl; 31 | Line(l2) = {p2, p3}; 32 | l3 = newl; 33 | Line(l3) = {p3, p4}; 34 | l4 = newl; 35 | Line(l4) = {p4, p5}; 36 | l5 = newl; 37 | Line(l5) = {p5, p6}; 38 | l6 = newl; 39 | Line(l6) = {p6, p7}; 40 | l7 = newl; 41 | Line(l7) = {p7, p8}; 42 | l8 = newl; 43 | Line(l8) = {p8, p9}; 44 | l9 = newl; 45 | Line(l9) = {p9, p10}; 46 | l10 = newl; 47 | Line(l10) = {p10, p11}; 48 | l11 = newl; 49 | Line(l11) = {p11, p0}; 50 | ll0 = newll; 51 | Line Loop(ll0) = {l0, l1, l2, l3, l4, l5, l6, l7, l8, l9, l10, l11}; 52 | s0 = news; 53 | Plane Surface(s0) = {ll0}; 54 | Physical Line(1) = {l1}; 55 | Physical Line(2) = {l3}; 56 | Physical Line(3) = {l9}; 57 | Physical Line(4) = {l7}; 58 | Physical Line(5) = {l0, l2, l4, l5, l6, l8, l10, l11}; 59 | Physical Surface(0) = {s0}; 60 | -------------------------------------------------------------------------------- /letop_examples/navier_stokes/navier_stokes.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from firedrake import cos, pi, dx, inner, grad 3 | import firedrake_adjoint as fda 4 | from pyadjoint import stop_annotating 5 | from letop.physics import ( 6 | NavierStokesBrinkmannForm, 7 | NavierStokesBrinkmannSolver, 8 | hs, 9 | ) 10 | from letop.levelset import LevelSetFunctional 11 | from letop.levelset import RegularizationSolver 12 | from letop.optimization import InfDimProblem, Constraint, nullspace_shape 13 | 14 | 15 | def main(): 16 | mesh = fd.Mesh("./mesh_stokes.msh") 17 | mh = fd.MeshHierarchy(mesh, 1) 18 | mesh = mh[-1] 19 | # mesh = fd.Mesh("./mesh_stokes_inlets.msh") 20 | S = fd.VectorFunctionSpace(mesh, "CG", 1) 21 | s = fd.Function(S, name="deform") 22 | mesh.coordinates.assign(mesh.coordinates + s) 23 | 24 | x, y = fd.SpatialCoordinate(mesh) 25 | PHI = fd.FunctionSpace(mesh, "DG", 1) 26 | lx = 1.0 27 | # phi_expr = -0.5 * cos(3.0 / lx * pi * x + 1.0) * cos(3.0 * pi * y) - 0.3 28 | lx = 2.0 29 | phi_expr = -cos(6.0 / lx * pi * x + 1.0) * cos(4.0 * pi * y) - 0.6 30 | 31 | with stop_annotating(): 32 | phi = fd.interpolate(phi_expr, PHI) 33 | phi.rename("LevelSet") 34 | 35 | nu = fd.Constant(1.0) 36 | V = fd.VectorFunctionSpace(mesh, "CG", 1) 37 | P = fd.FunctionSpace(mesh, "CG", 1) 38 | W = V * P 39 | w_sol = fd.Function(W) 40 | brinkmann_penalty = 1e6 41 | F = NavierStokesBrinkmannForm( 42 | W, w_sol, phi, nu, brinkmann_penalty=brinkmann_penalty 43 | ) 44 | 45 | x, y = fd.SpatialCoordinate(mesh) 46 | u_inflow = 1.0 47 | y_inlet_1_1 = 0.2 48 | y_inlet_1_2 = 0.4 49 | inflow1 = fd.as_vector( 50 | [ 51 | u_inflow * 100 * (y - y_inlet_1_1) * (y - y_inlet_1_2), 52 | 0.0, 53 | ] 54 | ) 55 | y_inlet_2_1 = 0.6 56 | y_inlet_2_2 = 0.8 57 | inflow2 = fd.as_vector( 58 | [ 59 | u_inflow * 100 * (y - y_inlet_2_1) * (y - y_inlet_2_2), 60 | 0.0, 61 | ] 62 | ) 63 | 64 | noslip = fd.Constant((0.0, 0.0)) 65 | bc1 = fd.DirichletBC(W.sub(0), noslip, 5) 66 | bc2 = fd.DirichletBC(W.sub(0), inflow1, (1)) 67 | bc3 = fd.DirichletBC(W.sub(0), inflow2, (2)) 68 | bcs = [bc1, bc2, bc3] 69 | 70 | problem = fd.NonlinearVariationalProblem(F, w_sol, bcs=bcs) 71 | solver_parameters = { 72 | "ksp_type": "preonly", 73 | "pc_type": "lu", 74 | "mat_type": "aij", 75 | "ksp_converged_reason": None, 76 | "pc_factor_mat_solver_type": "mumps", 77 | } 78 | # solver_parameters = { 79 | # "ksp_type": "fgmres", 80 | # "pc_type": "hypre", 81 | # "pc_hypre_type": "euclid", 82 | # "pc_hypre_euclid_level": 5, 83 | # "mat_type": "aij", 84 | # "ksp_converged_reason": None, 85 | # "ksp_atol": 1e-3, 86 | # "ksp_rtol": 1e-3, 87 | # "snes_atol": 1e-3, 88 | # "snes_rtol": 1e-3, 89 | # } 90 | solver = NavierStokesBrinkmannSolver( 91 | problem, solver_parameters=solver_parameters 92 | ) 93 | solver.solve() 94 | pvd_file = fd.File("ns_solution.pvd") 95 | u, p = w_sol.split() 96 | pvd_file.write(u, p) 97 | 98 | u, p = fd.split(w_sol) 99 | 100 | Vol = fd.assemble(hs(-phi) * fd.Constant(1.0) * dx(0, domain=mesh)) 101 | VControl = fda.Control(Vol) 102 | Vval = fd.assemble(fd.Constant(0.5) * dx(domain=mesh), annotate=False) 103 | with stop_annotating(): 104 | print("Initial constraint function value {}".format(Vol)) 105 | 106 | J = fd.assemble( 107 | fd.Constant(brinkmann_penalty) * hs(phi) * inner(u, u) * dx(0) 108 | + nu / fd.Constant(2.0) * inner(grad(u), grad(u)) * dx 109 | ) 110 | 111 | c = fda.Control(s) 112 | 113 | phi_pvd = fd.File("phi_evolution_euclid.pvd", target_continuity=fd.H1) 114 | 115 | def deriv_cb(phi): 116 | with stop_annotating(): 117 | phi_pvd.write(phi[0]) 118 | 119 | Jhat = LevelSetFunctional(J, c, phi, derivative_cb_pre=deriv_cb) 120 | Vhat = LevelSetFunctional(Vol, c, phi) 121 | 122 | bcs_vel_1 = fd.DirichletBC(S, noslip, (1, 2, 3, 4)) 123 | bcs_vel = [bcs_vel_1] 124 | reg_solver = RegularizationSolver( 125 | S, mesh, beta=0.5, gamma=1e5, dx=dx, bcs=bcs_vel, design_domain=0 126 | ) 127 | 128 | tol = 1e-5 129 | dt = 0.0002 130 | params = { 131 | "alphaC": 1.0, 132 | "debug": 5, 133 | "alphaJ": 1.0, 134 | "dt": dt, 135 | "K": 0.1, 136 | "maxit": 2000, 137 | "maxtrials": 5, 138 | "itnormalisation": 10, 139 | "tol_merit": 1e-4, # new merit can be within 5% of the previous merit 140 | # "normalize_tol" : -1, 141 | "tol": tol, 142 | } 143 | 144 | problem = InfDimProblem( 145 | Jhat, 146 | reg_solver, 147 | ineqconstraints=[Constraint(Vhat, Vval, VControl)], 148 | ) 149 | _ = nullspace_shape(problem, params) 150 | 151 | 152 | if __name__ == "__main__": 153 | main() 154 | -------------------------------------------------------------------------------- /pyproject.toml: -------------------------------------------------------------------------------- 1 | [tool.black] 2 | line-length = 79 3 | include = '\.pyi?$' 4 | exclude = ''' 5 | /( 6 | \.git 7 | | \.hg 8 | | \.mypy_cache 9 | | \.tox 10 | | \.venv 11 | | _build 12 | | buck-out 13 | | build 14 | | dist 15 | )/ 16 | ''' 17 | -------------------------------------------------------------------------------- /setup.py: -------------------------------------------------------------------------------- 1 | # -*- coding: utf-8 -*- 2 | # 3 | import codecs 4 | import os 5 | 6 | from setuptools import find_packages, setup 7 | 8 | # https://packaging.python.org/single_source_version/ 9 | base_dir = os.path.abspath(os.path.dirname(__file__)) 10 | about = {} 11 | with open(os.path.join(base_dir, "letop", "__about__.py"), "rb") as f: 12 | exec(f.read(), about) 13 | 14 | 15 | def read(fname): 16 | return codecs.open(os.path.join(base_dir, fname), encoding="utf-8").read() 17 | 18 | 19 | setup( 20 | name="letop", 21 | version=about["__version__"], 22 | packages=find_packages(), 23 | author=about["__author__"], 24 | author_email=about["__email__"], 25 | install_requires=[ 26 | "numpy>=1.12.1", 27 | "scipy>=0.19.1", 28 | "cvxopt>=1.2.1", 29 | "gmsh>=4.8.4", 30 | "pygmsh>=6.1.0", 31 | "pre-commit>=2.12.1", 32 | "firedrake-ts @ git+https://github.com/IvanYashchuk/firedrake-ts.git", 33 | ], 34 | description="A little bit of foobar in your life", 35 | long_description=read("README.md"), 36 | long_description_content_type="text/markdown", 37 | license=about["__license__"], 38 | classifiers=[ 39 | about["__license__"], 40 | about["__status__"], 41 | # See for all classifiers. 42 | "Operating System :: OS Independent", 43 | "Programming Language :: Python", 44 | "Programming Language :: Python :: 3", 45 | "Topic :: Scientific/Engineering", 46 | "Topic :: Scientific/Engineering :: Mathematics", 47 | ], 48 | python_requires=">=3", 49 | entry_points={"console_scripts": ["letop-show = letop.cli:show"]}, 50 | ) 51 | -------------------------------------------------------------------------------- /test/2D_mesh.geo: -------------------------------------------------------------------------------- 1 | // This code was created by pygmsh v6.0.2. 2 | SetFactory("OpenCASCADE"); 3 | Mesh.CharacteristicLengthMin = 0.01; 4 | Mesh.CharacteristicLengthMax = 0.01; 5 | s0 = news; 6 | Rectangle(s0) = {0.0, 0.0, 0.0, 1.0, 1.0}; 7 | s1 = news; 8 | Rectangle(s1) = {-0.2, -2.7755575615628914e-17, 0.0, 0.2, 0.2}; 9 | s2 = news; 10 | Physical Surface(2) = {s1}; 11 | Physical Surface(0) = {s0}; 12 | bo1[] = BooleanFragments{ Surface{s0}; Delete; } { Surface{s1};}; 13 | -------------------------------------------------------------------------------- /test/3D_mesh.geo: -------------------------------------------------------------------------------- 1 | // This code was created by pygmsh v6.0.2. 2 | SetFactory("OpenCASCADE"); 3 | Mesh.CharacteristicLengthMin = 0.02; 4 | Mesh.CharacteristicLengthMax = 0.02; 5 | s0 = news; 6 | Box(s0) = {0.0, 0.0, 0.0, 1.0, 1.0, 1.0}; 7 | s1 = news; 8 | Box(s1) = {-0.2, -2.7755575615628914e-17, 0.0, 0.2, 0.2, 0.2}; 9 | s2 = news; 10 | bo1[] = BooleanFragments{ Volume{s0}; Delete; } { Volume{s1}; Delete;}; 11 | Physical Volume(2) = {s1}; 12 | Physical Volume(0) = {s0}; 13 | -------------------------------------------------------------------------------- /test/build_example_meshes.sh: -------------------------------------------------------------------------------- 1 | #!/usr/bin/env bash 2 | 3 | 4 | source $1/bin/activate 5 | cd ../ 6 | letop=$(pwd) 7 | 8 | 9 | for d in $letop/letop_examples/*/; do 10 | if [ "$letop/letop_examples/heat_exchanger/" = "$d" ]; then 11 | echo "Running ${d}" 12 | cd $d 13 | python3 2D_mesh.py 14 | gmsh -2 -option 2D_mesh.geo.opt 2D_mesh.geo 15 | fi 16 | if [ "$letop/letop_examples/cantilever/" = "$d" ]; then 17 | echo "Running ${d}" 18 | cd $d 19 | gmsh -2 -option mesh_cantilever.geo.opt mesh_cantilever.geo 20 | fi 21 | done 22 | -------------------------------------------------------------------------------- /test/conftest.py: -------------------------------------------------------------------------------- 1 | #!/usr/bin/env python 2 | # -*- coding: utf-8 -*- 3 | import pytest 4 | import numpy.random 5 | from pyadjoint import set_working_tape, Tape 6 | 7 | 8 | def pytest_runtest_setup(item): 9 | """ Hook function which is called before every test """ 10 | set_working_tape(Tape()) 11 | 12 | # Fix the seed to avoid random test failures due to slight tolerance variations 13 | numpy.random.seed(21) 14 | 15 | 16 | -------------------------------------------------------------------------------- /test/nullspace/test_line_search.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | import firedrake_adjoint as fda 3 | import numpy as np 4 | from firedrake import dx 5 | from letop.optimization.nullspace_shape import line_search 6 | from letop.optimization import InfDimProblem 7 | from letop.levelset import LevelSetFunctional, RegularizationSolver 8 | from letop.physics import hs 9 | from numpy.testing import assert_allclose 10 | 11 | 12 | def merit_eval_new(AJ, J, AC, C): 13 | return J 14 | 15 | 16 | def test_line_search(): 17 | mesh = fd.UnitSquareMesh(50, 50) 18 | 19 | # Shape derivative 20 | S = fd.VectorFunctionSpace(mesh, "CG", 1) 21 | s = fd.Function(S, name="deform") 22 | mesh.coordinates.assign(mesh.coordinates + s) 23 | 24 | # Level set 25 | PHI = fd.FunctionSpace(mesh, "CG", 1) 26 | x, y = fd.SpatialCoordinate(mesh) 27 | 28 | with fda.stop_annotating(): 29 | phi = fd.interpolate(-(x - 0.5), PHI) 30 | 31 | solver_parameters = { 32 | "ts_atol": 1e-4, 33 | "ts_rtol": 1e-4, 34 | "ts_dt": 1e-2, 35 | "ts_exact_final_time": "matchstep", 36 | "ts_monitor": None, 37 | } 38 | 39 | ## Search direction 40 | with fda.stop_annotating(): 41 | delta_x = fd.interpolate(fd.as_vector([-100 * x, 0.0]), S) 42 | delta_x.rename("velocity") 43 | 44 | # Cost function 45 | J = fd.assemble(hs(-phi) * dx) 46 | 47 | # Reduced Functional 48 | c = fda.Control(s) 49 | Jhat = LevelSetFunctional(J, c, phi) 50 | 51 | # InfDim Problem 52 | beta_param = 0.08 53 | reg_solver = RegularizationSolver( 54 | S, mesh, beta=beta_param, gamma=1e5, dx=dx 55 | ) 56 | solver_parameters = {"hj_solver": solver_parameters} 57 | problem = InfDimProblem( 58 | Jhat, reg_solver, solver_parameters=solver_parameters 59 | ) 60 | 61 | with fda.stop_annotating(): 62 | problem.delta_x.assign(delta_x) 63 | 64 | AJ, AC = 1.0, 1.0 65 | C = np.array([]) 66 | merit = merit_eval_new(AJ, J, AC, C) 67 | 68 | rtol = 1e-4 69 | newJ, newG, newH = line_search( 70 | problem, 71 | merit_eval_new, 72 | merit, 73 | AJ, 74 | AC, 75 | dt=1.0, 76 | tol_merit=rtol, 77 | maxtrials=20, 78 | ) 79 | 80 | assert_allclose(newJ, J, rtol=rtol) 81 | 82 | 83 | if __name__ == "__main__": 84 | test_line_search() 85 | -------------------------------------------------------------------------------- /test/physics/test_navier_stokes.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from firedrake import sqrt, inner, dx 3 | from firedrake import sin, grad, pi, sym, div 4 | from letop.physics import ( 5 | NavierStokesBrinkmannForm, 6 | NavierStokesBrinkmannSolver, 7 | mark_no_flow_regions, 8 | InteriorBC, 9 | ) 10 | import pytest 11 | 12 | 13 | def test_solver_no_flow_region(): 14 | mesh = fd.Mesh("./2D_mesh.msh") 15 | no_flow = [2] 16 | no_flow_markers = [1] 17 | mesh = mark_no_flow_regions(mesh, no_flow, no_flow_markers) 18 | P2 = fd.VectorElement("CG", mesh.ufl_cell(), 1) 19 | P1 = fd.FiniteElement("CG", mesh.ufl_cell(), 1) 20 | TH = P2 * P1 21 | W = fd.FunctionSpace(mesh, TH) 22 | (v, q) = fd.TestFunctions(W) 23 | 24 | # Stokes 1 25 | w_sol1 = fd.Function(W) 26 | nu = fd.Constant(0.05) 27 | F = NavierStokesBrinkmannForm(W, w_sol1, nu, beta_gls=2.0) 28 | 29 | x, y = fd.SpatialCoordinate(mesh) 30 | u_mms = fd.as_vector( 31 | [sin(2.0 * pi * x) * sin(pi * y), sin(pi * x) * sin(2.0 * pi * y)] 32 | ) 33 | p_mms = -0.5 * (u_mms[0] ** 2 + u_mms[1] ** 2) 34 | f_mms_u = ( 35 | grad(u_mms) * u_mms + grad(p_mms) - 2.0 * nu * div(sym(grad(u_mms))) 36 | ) 37 | f_mms_p = div(u_mms) 38 | F += -inner(f_mms_u, v) * dx - f_mms_p * q * dx 39 | bc1 = fd.DirichletBC(W.sub(0), u_mms, "on_boundary") 40 | bc2 = fd.DirichletBC(W.sub(1), p_mms, "on_boundary") 41 | bc_no_flow = InteriorBC(W.sub(0), fd.Constant((0.0, 0.0)), no_flow_markers) 42 | 43 | solver_parameters = {"ksp_max_it": 500, "ksp_monitor": None} 44 | 45 | problem1 = fd.NonlinearVariationalProblem( 46 | F, w_sol1, bcs=[bc1, bc2, bc_no_flow] 47 | ) 48 | solver1 = NavierStokesBrinkmannSolver( 49 | problem1, 50 | options_prefix="navier_stokes", 51 | solver_parameters=solver_parameters, 52 | ) 53 | solver1.solve() 54 | u_sol, _ = w_sol1.split() 55 | u_mms_func = fd.interpolate(u_mms, W.sub(0)) 56 | error = fd.errornorm(u_sol, u_mms_func) 57 | assert error < 0.07 58 | 59 | 60 | def run_solver(r): 61 | mesh = fd.UnitSquareMesh(2 ** r, 2 ** r) 62 | P2 = fd.VectorElement("CG", mesh.ufl_cell(), 1) 63 | P1 = fd.FiniteElement("CG", mesh.ufl_cell(), 1) 64 | TH = P2 * P1 65 | W = fd.FunctionSpace(mesh, TH) 66 | (v, q) = fd.TestFunctions(W) 67 | 68 | # Stokes 1 69 | w_sol1 = fd.Function(W) 70 | nu = fd.Constant(0.05) 71 | F = NavierStokesBrinkmannForm(W, w_sol1, nu, beta_gls=2.0) 72 | 73 | from firedrake import sin, grad, pi, sym, div, inner 74 | 75 | x, y = fd.SpatialCoordinate(mesh) 76 | u_mms = fd.as_vector( 77 | [sin(2.0 * pi * x) * sin(pi * y), sin(pi * x) * sin(2.0 * pi * y)] 78 | ) 79 | p_mms = -0.5 * (u_mms[0] ** 2 + u_mms[1] ** 2) 80 | f_mms_u = ( 81 | grad(u_mms) * u_mms + grad(p_mms) - 2.0 * nu * div(sym(grad(u_mms))) 82 | ) 83 | f_mms_p = div(u_mms) 84 | F += -inner(f_mms_u, v) * dx - f_mms_p * q * dx 85 | bc1 = fd.DirichletBC(W.sub(0), u_mms, "on_boundary") 86 | bc2 = fd.DirichletBC(W.sub(1), p_mms, "on_boundary") 87 | 88 | solver_parameters = {"ksp_max_it": 200} 89 | 90 | problem1 = fd.NonlinearVariationalProblem(F, w_sol1, bcs=[bc1, bc2]) 91 | solver1 = NavierStokesBrinkmannSolver( 92 | problem1, 93 | options_prefix="navier_stokes", 94 | solver_parameters=solver_parameters, 95 | ) 96 | solver1.solve() 97 | u_sol, _ = w_sol1.split() 98 | fd.File("test_u_sol.pvd").write(u_sol) 99 | u_mms_func = fd.interpolate(u_mms, W.sub(0)) 100 | error = fd.errornorm(u_sol, u_mms_func) 101 | print(f"Error: {error}") 102 | return error 103 | 104 | 105 | def run_convergence_test(): 106 | import numpy as np 107 | 108 | diff = np.array([run_solver(i) for i in range(4, 7)]) 109 | return np.log2(diff[:-1] / diff[1:]) 110 | 111 | 112 | def test_l2_conv(): 113 | assert (run_convergence_test() > 0.8).all() 114 | -------------------------------------------------------------------------------- /test/test_examples.py: -------------------------------------------------------------------------------- 1 | from letop_examples import ( 2 | compliance_optimization, 3 | heat_exchanger_optimization, 4 | ) 5 | from numpy.testing import assert_allclose 6 | 7 | 8 | def test_heat_exchanger(): 9 | results = heat_exchanger_optimization(n_iters=10) 10 | cost_func = results["J"][-1] 11 | assert_allclose( 12 | cost_func, 13 | -1.316, 14 | rtol=1e-2, 15 | ) 16 | 17 | 18 | def test_compliance(): 19 | results = compliance_optimization(n_iters=10) 20 | cost_func = results["J"][-1] 21 | assert_allclose( 22 | cost_func, 23 | 11.86, 24 | rtol=1e-2, 25 | ) 26 | 27 | if __name__ == "__main__": 28 | test_heat_exchanger() 29 | -------------------------------------------------------------------------------- /test/test_hj_solver.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from firedrake.bcs import DirichletBC 3 | from firedrake.interpolation import interpolate 4 | from firedrake import inner 5 | from ufl.algebra import Abs 6 | 7 | 8 | import pytest 9 | 10 | from letop.optimization import ( 11 | HamiltonJacobiCGSolver, 12 | ) 13 | 14 | mesh = fd.UnitSquareMesh(50, 50, quadrilateral=True) 15 | x, y = fd.SpatialCoordinate(mesh) 16 | final_t = 0.2 17 | 18 | # First case 19 | phi_init_1 = -(x - 1.0) * y 20 | phi_exact_1 = (-(x + final_t - 1.0) * (y - final_t)) * (x < 1.0 - final_t) * ( 21 | y > final_t 22 | ) 23 | # Second case 24 | phi_init_2 = x * y 25 | phi_exact_2 = ((x - final_t) * y) * (x > final_t) 26 | 27 | # Third case 28 | phi_init_3 = -(x - 1.0) * y 29 | phi_exact_3 = (-(x + final_t - 1.0) * y) * (x < 1.0 - final_t) 30 | 31 | # Fourth case 32 | phi_init_4 = -(x) * (y - 1) 33 | phi_exact_4 = (-(x - final_t) * (y + final_t - 1.0)) * (x > final_t) * ( 34 | y < 1.0 - final_t 35 | ) 36 | 37 | 38 | @pytest.mark.parametrize( 39 | "phi_init, phi_exact, bc_tuple, velocity", 40 | [ 41 | ( 42 | phi_init_1, 43 | phi_exact_1, 44 | (fd.Constant(0.0), (2, 3)), 45 | fd.Constant((-1.0, 1.0)), 46 | ), 47 | ( 48 | phi_init_2, 49 | phi_exact_2, 50 | (fd.Constant(0.0), (1)), 51 | fd.Constant((1.0, 0.0)), 52 | ), 53 | ( 54 | phi_init_3, 55 | phi_exact_3, 56 | (fd.Constant(0.0), (2)), 57 | fd.Constant((-1.0, 0.0)), 58 | ), 59 | ( 60 | phi_init_4, 61 | phi_exact_4, 62 | (fd.Constant(0.0), (1, 4)), 63 | fd.Constant((1.0, -1.0)), 64 | ), 65 | ], 66 | ) 67 | def test_cg_hj_solver(phi_init, phi_exact, bc_tuple, velocity): 68 | V = fd.FunctionSpace(mesh, "CG", 1) 69 | fd.File('init.pvd').write(fd.interpolate(phi_init, V)) 70 | bc = fd.DirichletBC(V, *bc_tuple) 71 | 72 | phi0 = interpolate(phi_init, V) 73 | solver_parameters = { 74 | "ts_atol": 1e-6, 75 | "ts_rtol": 1e-6, 76 | "ts_dt": 1e-4, 77 | "ts_exact_final_time": "matchstep", 78 | "ts_monitor": None, 79 | "ts_type": "rosw", 80 | "ts_rows_type": "2m", 81 | "ts_adapt_type": "dsp", 82 | "ts_exact_final_time": "matchstep", 83 | "ksp_type": "preonly", 84 | "pc_type": "lu", 85 | "pc_factor_mat_solver_type": "mumps", 86 | } 87 | 88 | solver = HamiltonJacobiCGSolver( 89 | V, 90 | velocity, 91 | phi0, 92 | t_end=final_t, 93 | bcs=bc, 94 | solver_parameters=solver_parameters, 95 | ) 96 | 97 | solver.solve() 98 | error = fd.errornorm(interpolate(phi_exact, V), phi0) 99 | assert error < 1e-3 100 | print(f"Error: {error}") 101 | -------------------------------------------------------------------------------- /test/test_regularization_solver.py: -------------------------------------------------------------------------------- 1 | from firedrake import ( 2 | UnitSquareMesh, 3 | SpatialCoordinate, 4 | VectorFunctionSpace, 5 | Function, 6 | TestFunction, 7 | assemble, 8 | norm, 9 | project, 10 | inner, 11 | as_vector, 12 | cos, 13 | pi, 14 | sin, 15 | dx, 16 | File, 17 | Mesh, 18 | conditional, 19 | ) 20 | import numpy as np 21 | from letop.levelset import RegularizationSolver 22 | 23 | 24 | def regularization_form(r): 25 | mesh = UnitSquareMesh(2 ** r, 2 ** r) 26 | x = SpatialCoordinate(mesh) 27 | 28 | S = VectorFunctionSpace(mesh, "CG", 1) 29 | beta = 4.0 30 | reg_solver = RegularizationSolver(S, mesh, beta=beta, gamma=0.0, dx=dx) 31 | 32 | # Exact solution with free Neumann boundary conditions for this domain 33 | u_exact = Function(S) 34 | u_exact_component = cos(x[0] * pi * 2) * cos(x[1] * pi * 2) 35 | u_exact.interpolate(as_vector((u_exact_component, u_exact_component))) 36 | f = Function(S) 37 | theta = TestFunction(S) 38 | f_component = (1 + beta * 8 * pi * pi) * u_exact_component 39 | f.interpolate(as_vector((f_component, f_component))) 40 | rhs_form = inner(f, theta) * dx 41 | 42 | velocity = Function(S) 43 | rhs = assemble(rhs_form) 44 | reg_solver.solve(velocity, rhs) 45 | File("solution_vel_unitsquare.pvd").write(velocity) 46 | return norm(project(u_exact - velocity, S)) 47 | 48 | 49 | def test_regularization_convergence(): 50 | diff = np.array([regularization_form(i) for i in range(3, 6)]) 51 | conv = np.log2(diff[:-1] / diff[1:]) 52 | assert (np.array(conv) > 1.8).all() 53 | 54 | 55 | def domainify(vector, x): 56 | dim = len(x) 57 | return conditional( 58 | x[0] > 0.0, vector, as_vector(tuple(0.0 for _ in range(dim))) 59 | ) 60 | 61 | 62 | def test_2D_dirichlet_regions(): 63 | # Can't do mesh refinement because MeshHierarchy ruins the domain tags 64 | mesh = Mesh("./2D_mesh.msh") 65 | dim = mesh.geometric_dimension() 66 | x = SpatialCoordinate(mesh) 67 | 68 | S = VectorFunctionSpace(mesh, "CG", 1) 69 | beta = 1.0 70 | reg_solver = RegularizationSolver( 71 | S, mesh, beta=beta, gamma=0.0, dx=dx, design_domain=0 72 | ) 73 | 74 | # Exact solution with free Neumann boundary conditions for this domain 75 | u_exact = Function(S) 76 | u_exact_component = (-cos(x[0] * pi * 2) + 1) * (-cos(x[1] * pi * 2) + 1) 77 | 78 | u_exact.interpolate( 79 | as_vector(tuple(u_exact_component for _ in range(dim))) 80 | ) 81 | f = Function(S) 82 | f_component = ( 83 | -beta 84 | * ( 85 | 4.0 * pi * pi * cos(2 * pi * x[0]) * (-cos(2 * pi * x[1]) + 1) 86 | + 4.0 * pi * pi * cos(2 * pi * x[1]) * (-cos(2 * pi * x[0]) + 1) 87 | ) 88 | + u_exact_component 89 | ) 90 | f.interpolate(as_vector(tuple(f_component for _ in range(dim)))) 91 | 92 | theta = TestFunction(S) 93 | rhs_form = inner(f, theta) * dx 94 | 95 | velocity = Function(S) 96 | rhs = assemble(rhs_form) 97 | reg_solver.solve(velocity, rhs) 98 | assert norm(project(domainify(u_exact, x) - velocity, S)) < 1e-3 99 | 100 | 101 | def test_3D_dirichlet_regions(): 102 | # Can't do mesh refinement because MeshHierarchy ruins the domain tags 103 | mesh = Mesh("./3D_mesh.msh") 104 | dim = mesh.geometric_dimension() 105 | x = SpatialCoordinate(mesh) 106 | solver_parameters_amg = { 107 | "ksp_type": "cg", 108 | "ksp_converged_reason": None, 109 | "ksp_rtol": 1e-7, 110 | "pc_type": "hypre", 111 | "pc_hypre_type": "boomeramg", 112 | "pc_hypre_boomeramg_max_iter": 5, 113 | "pc_hypre_boomeramg_coarsen_type": "PMIS", 114 | "pc_hypre_boomeramg_agg_nl": 2, 115 | "pc_hypre_boomeramg_strong_threshold": 0.95, 116 | "pc_hypre_boomeramg_interp_type": "ext+i", 117 | "pc_hypre_boomeramg_P_max": 2, 118 | "pc_hypre_boomeramg_relax_type_all": "sequential-Gauss-Seidel", 119 | "pc_hypre_boomeramg_grid_sweeps_all": 1, 120 | "pc_hypre_boomeramg_truncfactor": 0.3, 121 | "pc_hypre_boomeramg_max_levels": 6, 122 | } 123 | 124 | S = VectorFunctionSpace(mesh, "CG", 1) 125 | beta = 1.0 126 | reg_solver = RegularizationSolver( 127 | S, 128 | mesh, 129 | beta=beta, 130 | gamma=0.0, 131 | dx=dx, 132 | design_domain=0, 133 | solver_parameters=solver_parameters_amg, 134 | ) 135 | 136 | # Exact solution with free Neumann boundary conditions for this domain 137 | u_exact = Function(S) 138 | u_exact_component = ( 139 | (-cos(x[0] * pi * 2) + 1) 140 | * (-cos(x[1] * pi * 2) + 1) 141 | * (-cos(x[2] * pi * 2) + 1) 142 | ) 143 | 144 | u_exact.interpolate( 145 | as_vector(tuple(u_exact_component for _ in range(dim))) 146 | ) 147 | f = Function(S) 148 | f_component = ( 149 | -beta 150 | * ( 151 | 4.0 152 | * pi 153 | * pi 154 | * cos(2 * pi * x[0]) 155 | * (-cos(2 * pi * x[1]) + 1) 156 | * (-cos(2 * pi * x[2]) + 1) 157 | + 4.0 158 | * pi 159 | * pi 160 | * cos(2 * pi * x[1]) 161 | * (-cos(2 * pi * x[0]) + 1) 162 | * (-cos(2 * pi * x[2]) + 1) 163 | + 4.0 164 | * pi 165 | * pi 166 | * cos(2 * pi * x[2]) 167 | * (-cos(2 * pi * x[1]) + 1) 168 | * (-cos(2 * pi * x[0]) + 1) 169 | ) 170 | + u_exact_component 171 | ) 172 | f.interpolate(as_vector(tuple(f_component for _ in range(dim)))) 173 | 174 | theta = TestFunction(S) 175 | rhs_form = inner(f, theta) * dx 176 | 177 | velocity = Function(S) 178 | rhs = assemble(rhs_form) 179 | reg_solver.solve(velocity, rhs) 180 | error = norm( 181 | project( 182 | domainify(u_exact, x) - velocity, 183 | S, 184 | solver_parameters=solver_parameters_amg, 185 | ) 186 | ) 187 | assert error < 5e-2 188 | 189 | 190 | if __name__ == "__main__": 191 | test_regularization_convergence() 192 | test_2D_dirichlet_regions() 193 | test_3D_dirichlet_regions() 194 | -------------------------------------------------------------------------------- /test/test_reinit_solver.py: -------------------------------------------------------------------------------- 1 | import firedrake as fd 2 | from firedrake import sqrt 3 | from letop.optimization import ReinitSolverCG 4 | from letop.physics import max_mesh_dimension 5 | import pytest 6 | 7 | 8 | def test_max_dim(): 9 | mesh = fd.UnitSquareMesh(100, 100) 10 | 11 | assert pytest.approx(max_mesh_dimension(mesh), 1.0) 12 | 13 | mesh = fd.RectangleMesh(10, 20, 5.0, 3.0) 14 | 15 | assert pytest.approx(max_mesh_dimension(mesh), 5.0) 16 | 17 | mesh = fd.CubeMesh(10, 10, 10, 8.0) 18 | 19 | assert pytest.approx(max_mesh_dimension(mesh), 8.0) 20 | 21 | 22 | def test_cone_cg_2D(): 23 | mesh = fd.UnitSquareMesh(100, 100) 24 | V = fd.FunctionSpace(mesh, "CG", 1) 25 | 26 | radius = 0.2 27 | x, y = fd.SpatialCoordinate(mesh) 28 | x_shift = 0.5 29 | phi_init = ( 30 | (x - x_shift) * (x - x_shift) + (y - 0.5) * (y - 0.5) - radius ** 2 31 | ) 32 | phi0 = fd.Function(V).interpolate(phi_init) 33 | 34 | phi_pvd = fd.File("phi_reinit.pvd") 35 | 36 | phi = fd.Function(V) 37 | reinit_solver = ReinitSolverCG(phi) 38 | phin = reinit_solver.solve(phi0, iters=10) 39 | phi_pvd.write(phin) 40 | 41 | phi_solution = fd.interpolate( 42 | sqrt((x - x_shift) * (x - x_shift) + (y - 0.5) * (y - 0.5)) - radius, 43 | V, 44 | ) 45 | error_numeri = fd.errornorm(phin, phi_solution) 46 | print(f"error: {error_numeri}") 47 | assert error_numeri < 1e-4 48 | -------------------------------------------------------------------------------- /test/unstructured_rectangle.geo: -------------------------------------------------------------------------------- 1 | //+ 2 | SetFactory("OpenCASCADE"); 3 | //+ 4 | Rectangle(1) = {0, 0, 0, 1, 1.0, 0}; 5 | MeshSize{ PointsOf{ Surface{1}; } } = 0.02; 6 | --------------------------------------------------------------------------------
