├── LICENSE
├── README.md
├── algos
    ├── bst
    │   ├── index.html
    │   ├── script.js
    │   └── styles.css
    ├── path_finding
    │   ├── index.html
    │   ├── script.js
    │   └── styles.css
    ├── sorting
    │   ├── index.html
    │   ├── script.js
    │   └── styles.css
    └── trie
    │   ├── index.html
    │   ├── script.js
    │   └── styles.css
├── assets
    ├── banner.webp
    ├── bst.jpg
    ├── grid.png
    ├── home-page.jpeg
    ├── path-preview.jpg
    ├── path.jpg
    ├── preview2.jpg
    ├── sorting-preview.jpg
    ├── sorting.jpg
    ├── trie-preview.jpg
    └── trie.jpg
├── css
    └── styles.css
└── index.html


/LICENSE:
--------------------------------------------------------------------------------
 1 | MIT License
 2 |
 3 | Copyright (c) 2023 Sayan Maity
 4 |
 5 | Permission is hereby granted, free of charge, to any person obtaining a copy
 6 | of this software and associated documentation files (the "Software"), to deal
 7 | in the Software without restriction, including without limitation the rights
 8 | to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
 9 | copies of the Software, and to permit persons to whom the Software is
10 | furnished to do so, subject to the following conditions:
11 |
12 | The above copyright notice and this permission notice shall be included in all
13 | copies or substantial portions of the Software.
14 |
15 | THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
16 | IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
17 | FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
18 | AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
19 | LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
20 | OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
21 | SOFTWARE.
22 |


--------------------------------------------------------------------------------
/README.md:
--------------------------------------------------------------------------------
 1 | # <img src="https://media2.giphy.com/media/kkCsb4kKRQOzPPDBGL/giphy.gif?cid=ecf05e4731jqkbjr0mvdngqz6hi78xd0pkrlqhbhqq3webnf&rid=giphy.gif&ct=s" height="40px"> Algorithm Visualizer
 2 |
 3 | [![License: MIT](https://img.shields.io/badge/License-MIT-yellow.svg)](https://opensource.org/licenses/MIT)
 4 | [![PRs Welcome](https://img.shields.io/badge/PRs-welcome-brightgreen.svg)](http://makeapullrequest.com)
 5 | [![Netlify Status](https://api.netlify.com/api/v1/badges/6adb0f19-ac48-45e2-a896-9f6ac6d2f620/deploy-status)](https://app.netlify.com/sites/sayancr777-algorithm-visualizer/deploys)
 6 |
 7 | >```Algorithm Visualizer``` is an interactive way and platform that visualize the algorithms in four main domain i.e. Trie data structure, Binary Search Tree, Path Finding and Sort Visual algorithm. The project focuses on visualizng 📊 the algorithm and try to make easier to understand and learn the algorithm.
 8 |
 9 | Author : [Sayan Maity](sayancr777@gmail.com)
10 |
11 | <img src="https://media2.giphy.com/media/6wa5vuYvetU1Jibm13/giphy.gif?cid=ecf05e47ot9ej3657scll8evgmu0okov4ehohagfunabol8j&rid=giphy.gif&ct=g" height="350px" width="100%" >
12 |
13 | ## 🛠️ Built with :
14 | <img src="https://img.shields.io/badge/html5%20-%23E34F26.svg?&style=for-the-badge&logo=html5&logoColor=white"/>  <img src="https://img.shields.io/badge/css3%20-%231572B6.svg?&style=for-the-badge&logo=css3&logoColor=white"/> <img src="https://img.shields.io/badge/javascript%20-%23323330.svg?&style=for-the-badge&logo=javascript&logoColor=%23F7DF1E"/> <img src="https://img.shields.io/badge/netlify%20-%2300C7B7.svg?&style=for-the-badge&logo=netlify&logoColor=white"/>
15 | - **Frontend**: HTML, CSS, Javascript
16 | - **Version Control**: Git
17 | - **Hosting**: Netlify, Github Pages
18 |
19 | ## ✨ Features :
20 | - Step-by-step animation of the algorithm
21 | - Ability to pause animation
22 | - a short information on each algorithms and data structures
23 |
24 | ## 👨‍💻 How to Use :
25 | - Select the algorithm you want to visualize from the dropdown menu.
26 | - Enter the input for the algorithm in the text field (for trie and binary search tree, you can use a list of words)
27 | - Press the "Visualize" button to see the animation of the algorithm in action.
28 | - Press the "Pause" button to pause the animation
29 | - Now go and play with it
30 |
31 | ## 📒 Description :
32 | Will be added sonner ...
33 |
34 |
35 | ## 📸 Screenshots :
36 | <table>
37 |     <tr>
38 |         <td colspan="2">
39 |             <img src="https://github.com/Sayan-Maity/Algorithm-Visualizer/blob/main/assets/home-page.jpeg"></img>
40 |             <br />
41 |             <h3 align="center">Home Page</h3>
42 |         </td>
43 |     </tr>
44 |     <tr>
45 |         <td width="50%">
46 |             <img src="https://github.com/Sayan-Maity/Algorithm-Visualizer/blob/main/assets/trie-preview.jpg"></img>
47 |             <br />
48 |             <p align="center">Trie </p>
49 |         </td>
50 |         <td width="50%">
51 |             <img src="https://github.com/Sayan-Maity/Algorithm-Visualizer/blob/main/assets/preview2.jpg"></img>
52 |             <br />
53 |             <p align="center">Binary Search Tree</p>
54 |         </td>
55 |     </tr>
56 |     <tr>
57 |         <td width="50%">
58 |             <img src="https://github.com/Sayan-Maity/Algorithm-Visualizer/blob/main/assets/path-preview.jpg"></img>
59 |             <br />
60 |             <p align="center">Path Finding</p></td>
61 |         <td width="50%">
62 |             <img src="https://github.com/Sayan-Maity/Algorithm-Visualizer/blob/main/assets/sorting-preview.jpg"></img>
63 |             <br />
64 |             <p align="center">Sorting</p>
65 |         </td>
66 |     </tr>
67 | </table>
68 |
69 |
70 | ## ⏳ Future Improvements :
71 |
72 | - [ ] Add more and more algorithms and data structures
73 | - [ ] Bring a lot of animations to help users visualize things more perfectly
74 | - [ ] Adding the time complexity chart and some small info on each topics
75 |
76 | ## Contributing
77 |
78 | We welcome contributions! If you have an idea for a new feature or have found a bug, please open an issue on Github.
79 |
80 | ## 📝 Endnote
81 | So if you have liked this project then do consider giving it a star which will encourage me to build more of this kind of projects in future and also if you want youcan follow me on [Github](https://github.com/Sayan-Maity/) 😊
82 | Keep Coding !
83 |
84 | <p align="right">~ Sayan Maity</p>
85 |


--------------------------------------------------------------------------------
/algos/bst/index.html:
--------------------------------------------------------------------------------
 1 | <!DOCTYPE html>
 2 | <html lang="en">
 3 |   <head>
 4 |     <title>Algorithm Visualizer | Binary Search Tree</title>
 5 |     <link rel="stylesheet" href="./styles.css" />
 6 |   </head>
 7 |   <body>
 8 |     <div class="container">
 9 |       <div id="header">
10 |         <div id="OperationContainer">
11 |           <input type="text" id="InsertNodeField" placeholder="Enter the number"/>
12 |           <button type="button" id="InsertButton" class="button">Insert</button>
13 |           <input type="text" id="DeleteNodeField" placeholder="Enter the number"/>
14 |           <button type="button" id="DeleteButton" class="button">Delete</button>
15 |         </div>
16 |         <a href="/index.html"><div id="title">Algorithm Visualizer</div></a>
17 |       </div>
18 |       <div class="indicator_container">
19 |         <div class="indicator">
20 |           <div class="indicator_block" id="edge"></div>
21 |           <div class=""><p>Edge</p></div>
22 |         </div>
23 |         <div class="indicator">
24 |           <div class="indicator_block" id="node"></div>
25 |           <div class=""><p>Node</p></div>
26 |         </div>
27 |
28 |       </div>
29 |       <div class="Canvas">
30 |       </div>
31 |     </div>
32 |
33 |     <!-- D3.JS -->
34 |     <script
35 |       src="https://cdnjs.cloudflare.com/ajax/libs/d3/6.5.0/d3.min.js"
36 |       integrity="sha512-0XfwGD1nxplHpehcSVI7lY+m/5L37PNHDt+DOc7aLFckwPXjnjeA1oeNbru7YeI4VLs9i+ADnnHEhP69C9CqTA=="
37 |       crossorigin="anonymous"
38 |     ></script>
39 |     <script src="./script.js"></script>
40 |   </body>
41 | </html>
42 |


--------------------------------------------------------------------------------
/algos/bst/script.js:
--------------------------------------------------------------------------------
  1 | // prerequisite: javascript, d3.js
  2 |
  3 | // structure of node
  4 | // {
  5 | //     nodeId: number <--- unique id for each node. it will be also used as id for html element of node.
  6 | //     value: character <-- this will store value of current node.
  7 | //     children: [] <--- this array will store left and right of node
  8 | // }
  9 |
 10 | // Tree will be stored as object.
 11 | let data = { value: null, children: [] };
 12 | // Current available id for the node. We will give each node a unique id and put this as their html element "id".
 13 | let curId = 1;
 14 |
 15 | const width = Math.max(100, window.innerWidth - 50);
 16 | const height = Math.max(100, window.innerHeight - 100);
 17 | const nodeRadius = 20;
 18 | const LinkStroke = 4;
 19 | const animationDuration = 750;
 20 | const padding = 22;
 21 |
 22 | d3.select('.Canvas').append('svg').append('g');
 23 |
 24 | // During insertion or deletion visualization process disbale the buttons
 25 | const freezeButtons = () => {
 26 |   document.getElementById('InsertButton').disabled = true;
 27 |   document.getElementById('DeleteButton').disabled = true;
 28 | };
 29 | const unfreezeButtons = () => {
 30 |   document.getElementById('InsertButton').disabled = false;
 31 |   document.getElementById('DeleteButton').disabled = false;
 32 | };
 33 |
 34 | // To put delay between visualization.
 35 | const sleep = (ms) => {
 36 |   return new Promise((resolve) => setTimeout(resolve, ms));
 37 | };
 38 |
 39 | const update = (oldData, newData, parentValue, childValue) => {
 40 |   // childValue is node we want to insert/delete and parentValue is parent of node we want to insert/delete.
 41 |
 42 |   /*
 43 |     Small description of "update" function.
 44 |      -> Find the co-ordinates of old tree.
 45 |      -> Find the co-ordinates of new updated tree.
 46 |      -> Put tree on old co-ordinates.
 47 |      -> Animate nodes and links to the new co-ordinates.
 48 |   */
 49 |
 50 |   // Create the old and new updated tree.
 51 |   const treemap = d3.tree().size([width, height]);
 52 |   const oldTree = treemap(d3.hierarchy(data, (d) => d.children));
 53 |   const newTree = treemap(d3.hierarchy(newData, (d) => d.children));
 54 |
 55 |   // Convert both tres from objects to array.
 56 |   const oldTreeArray = oldTree.descendants();
 57 |   const newTreeArray = newTree.descendants();
 58 |   // Putting old and new co-ordinates of nodes in the same array.
 59 |   for (let i = 0; i < newTreeArray.length; i++) {
 60 |     let oldPosition = {};
 61 |     // Traverse the old tree and find the old co-ordinates.
 62 |     for (let j = 0; j < oldTreeArray.length; j++) {
 63 |       if (newTreeArray[i].data.value == childValue) {
 64 |         // Node which we are going to insert, there is no old co-oridnates available
 65 |         // So we are going to use the co-ordinates of parent node.
 66 |         if (oldTreeArray[j].data.value == parentValue) {
 67 |           oldPosition = oldTreeArray[j];
 68 |         }
 69 |       } else {
 70 |         if (oldTreeArray[j].data.value == newTreeArray[i].data.value) {
 71 |           oldPosition = oldTreeArray[j];
 72 |         }
 73 |       }
 74 |     }
 75 |     newTreeArray[i].oldX = oldPosition.x || 0;
 76 |     newTreeArray[i].oldY = (oldPosition.y || 0) + padding;
 77 |     newTreeArray[i].y += padding;
 78 |   }
 79 |
 80 |   // Remove the old tree from canvas. we will draw new one.
 81 |   d3.select('.Canvas > svg g').remove();
 82 |   d3.select('.Canvas > svg').append('g');
 83 |
 84 |   // Create all the edges and put them in new array.
 85 |   let allLinks = [];
 86 |   for (let i = 0; i < newTreeArray.length; i++) {
 87 |     for (let j = 0; j < 2; j++) {
 88 |       if (newTreeArray[i].data.value != null && newTreeArray[i].children[j].data.value != null) {
 89 |         allLinks.push({
 90 |           parent: newTreeArray[i],
 91 |           child: newTreeArray[i].children[j],
 92 |         });
 93 |       }
 94 |     }
 95 |   }
 96 |
 97 |   // We will draw edge(links) 2 times. why?
 98 |   // When we traverse the BST, it will be easy to show animation of searching. we will paint top edge with some color while searching node.
 99 |   for (let i = 0; i < 2; i++) {
100 |     const lineId = i == 0 ? 'Under' : '';
101 |
102 |     // Drawing edges on canvas with some styles and co-ordinates.
103 |     const links = d3
104 |       .select('.Canvas > svg g')
105 |       .selectAll('g.link')
106 |       .data(allLinks)
107 |       .enter()
108 |       .append('g')
109 |       .append('line')
110 |       .attr('id', (d) => `${lineId}link_Source_${d.parent.data.nodeId}_Dest_${d.child.data.nodeId}`)
111 |       .attr('stroke-width', LinkStroke)
112 |       .attr('stroke', 'black')
113 |       .attr('x1', (d) => d.parent.oldX)
114 |       .attr('y1', (d) => d.parent.oldY)
115 |       .attr('x2', (d) => d.child.oldX)
116 |       .attr('y2', (d) => d.child.oldY);
117 |     // Transition from old tree to new tree. move old edges to new edges using co-ordinates.
118 |     links
119 |       .transition()
120 |       .duration(animationDuration)
121 |       .attr('x1', (d) => d.parent.x)
122 |       .attr('y1', (d) => d.parent.y)
123 |       .attr('x2', (d) => d.child.x)
124 |       .attr('y2', (d) => d.child.y);
125 |   }
126 |
127 |   // Draw nodes and their value on screen using old tree co-ordinates.
128 |   const nodes = d3
129 |     .select('.Canvas > svg g')
130 |     .selectAll('g.node')
131 |     .data(newTree)
132 |     .enter()
133 |     .append('g')
134 |     .attr('id', (d) => `node${d.data.nodeId}`)
135 |     .attr('class', (d) => (d.data.value != null ? 'node' : 'null-node'));
136 |   nodes
137 |     .append('circle')
138 |     .attr('id', (d) => `circle${d.data.nodeId}`)
139 |     .attr('r', nodeRadius)
140 |     .attr('cx', (d) => d.oldX)
141 |     .attr('cy', (d) => d.oldY)
142 |     .attr('value', (d) => d.data.value);
143 |   nodes
144 |     .append('text')
145 |     .attr('dx', (d) => d.oldX)
146 |     .attr('dy', (d) => d.oldY)
147 |     .attr('text-anchor', 'middle')
148 |     .attr('alignment-baseline', 'middle')
149 |     .attr('font-size', '20px')
150 |     .attr('font-weight', 'bold')
151 |     .text((d) => d.data.value);
152 |
153 |   // Move nodes from old co-ordinate to new co-ordinates.
154 |   nodes
155 |     .transition()
156 |     .duration(animationDuration)
157 |     .attr('transform', (d) => {
158 |       if (d.data.value != null) return `translate(${parseInt(d.x - d.oldX)}, ${parseInt(d.y - d.oldY)})`;
159 |       else return 'translate(0,0)';
160 |     });
161 |
162 |   data = newData;
163 | };
164 |
165 | const addNode = async () => {
166 |   // Get the node value from input field and verify it's value/type.
167 |   let val = document.getElementById('InsertNodeField').value;
168 |   if (val == '') {
169 |     return;
170 |   }
171 |   if (isNaN(val)) {
172 |     alert('Only integers values are allowed');
173 |     return;
174 |   }
175 |   val = parseInt(val);
176 |   document.getElementById('InsertNodeField').value = '';
177 |
178 |   // Freeze(disable) insert and delete buttons.
179 |   freezeButtons();
180 |
181 |   // Copying object without reference in a dirty way. Might make proper function to copy object later.
182 |   let oldData = JSON.parse(JSON.stringify(data));
183 |   let newData = JSON.parse(JSON.stringify(data));
184 |   let node = newData;
185 |   let parent = null;
186 |
187 |   while (true) {
188 |     if (node.value == null) {
189 |       // If node value is null then that means we already reached leaf node. Insert new node here.
190 |       await sleep(400);
191 |
192 |       // Create a node with given valule.
193 |       const newChild = {
194 |         nodeId: curId,
195 |         value: val,
196 |         children: [{ value: null }, { value: null }],
197 |       };
198 |
199 |       if (parent) {
200 |         // If tree is not empty then "parent" will not be null. Now link newly created node with it parent node.
201 |         if (parent.value < val) parent.children[1] = newChild;
202 |         else parent.children[0] = newChild;
203 |       } else {
204 |         // If tree is empty then this newly created node will act as tree.
205 |         newData = newChild;
206 |       }
207 |
208 |       update(oldData, newData, (parent ? parent.value : -1), (parent ? val : -1));
209 |       curId++;
210 |       await sleep(300);
211 |       break;
212 |     }
213 |
214 |     const nodeElement = document.getElementById(`node${node.nodeId}`);
215 |     if (nodeElement) nodeElement.className.baseVal = 'highlightedNode';
216 |
217 |     if (node.value == val) {
218 |       // If value user is trying to insert already exist then show message
219 |       alert('Value already exists in tree');
220 |       update(oldData, oldData, -1, -1);
221 |       break;
222 |     }
223 |
224 |     parent = node;
225 |     // Go to left or right subtree depending on node values.
226 |     if (node.value > val) {
227 |       node = node.children[0];
228 |     } else {
229 |       node = node.children[1];
230 |     }
231 |
232 |     // Show the edge traversing animation.
233 |     const linkElement = document.getElementById(`link_Source_${parent.nodeId}_Dest_${node.nodeId}`);
234 |     if (linkElement) {
235 |       linkElement.className.baseVal = 'LinkAnimation';
236 |       await sleep(750);
237 |     }
238 |   }
239 |   unfreezeButtons();
240 | };
241 |
242 | // Delete the given node and return updated tree.
243 | const deleteNodeRecur = (newData, val) => {
244 |   if (newData.value == null) {
245 |     return newData;
246 |   }
247 |
248 |   if (val < newData.value) {
249 |     // Find the node in left subtree and return updated subtree.
250 |     newData.children[0] = deleteNodeRecur(newData.children[0], val);
251 |   } else if (val > newData.value) {
252 |     // Find the node in right subtree and return updated subtree.
253 |     newData.children[1] = deleteNodeRecur(newData.children[1], val);
254 |   } else {
255 |     // Found the node which we want to delete.
256 |     if (newData.children[0].value == null) {
257 |       // There is no left children
258 |       return newData.children[1];
259 |     } else if (newData.children[1].value == null) {
260 |       // There is no right children
261 |       return newData.children[0];
262 |     }
263 |
264 |     // Both children Exists
265 |     // In this case we will find inorder successor of node and replace it with current node.
266 |     let successorParent = newData;
267 |     let successor = newData.children[1];
268 |     while (successor.children[0].value != null) {
269 |       successorParent = successor;
270 |       successor = successor.children[0];
271 |     }
272 |     if (successorParent.value != newData.value) successorParent.children[0] = successor.children[1];
273 |     else successorParent.children[1] = successor.children[1];
274 |     newData.value = successor.value;
275 |     return newData;
276 |   }
277 |   return newData;
278 | };
279 |
280 | const deleteNode = async () => {
281 |   // Get the node value from input field and verify it's type.
282 |   let val = document.getElementById('DeleteNodeField').value;
283 |   if (val == '') return;
284 |   if (isNaN(val)) {
285 |     alert('Only integer values are allowed');
286 |     return;
287 |   }
288 |   val = parseInt(val);
289 |   document.getElementById('DeleteNodeField').value = '';
290 |   freezeButtons();
291 |
292 |   // Copying object without reference in a dirty way. Might make proper function to copy object later.
293 |   let oldData = JSON.parse(JSON.stringify(data));
294 |   let newData = JSON.parse(JSON.stringify(data));
295 |   let node = newData;
296 |   let parent = null;
297 |
298 |   while (true) {
299 |     if (node.value == null) {
300 |       alert('Value is not present in tree');
301 |       update(oldData, newData, -1, -1);
302 |       break;
303 |     }
304 |
305 |     const nodeEle = document.getElementById(`node${node.nodeId}`);
306 |     if (nodeEle) nodeEle.className.baseVal = 'highlightedNode';
307 |
308 |     parent = node;
309 |
310 |     if (node.value == val) {
311 |       // Found the node which we want to delete. We just create updated tree with some other function and display it.
312 |       // More better way will be, if there are 2 childs to this node then show animation to find inorder successor.
313 |       await sleep(500);
314 |       newData = deleteNodeRecur(newData, val);
315 |       update(oldData, newData, -1, -1);
316 |       break;
317 |     } else {
318 |       // Go to left or right subtree depending on the value we want to delete.
319 |       if (node.value > val) {
320 |         node = node.children[0];
321 |       } else {
322 |         node = node.children[1];
323 |       }
324 |       // Show the edge aniamtion.
325 |       const linkElement = document.getElementById(`link_Source_${parent.nodeId}_Dest_${node.nodeId}`);
326 |       if (linkElement) linkElement.className.baseVal = 'LinkAnimation';
327 |     }
328 |     await sleep(750);
329 |   }
330 |   unfreezeButtons();
331 | };
332 |
333 | document.getElementById('InsertButton').addEventListener('click', addNode);
334 | document.getElementById('DeleteButton').addEventListener('click', deleteNode);
335 |
336 | // If during writing in insertion or deletion input field, user presses enter key then click on insertion/deletion button.
337 | document.getElementById('InsertNodeField').addEventListener('keyup', function (event) {
338 |   if (event.key === 'Enter') {
339 |     document.getElementById('InsertButton').click();
340 |   }
341 | });
342 | document.getElementById('DeleteNodeField').addEventListener('keyup', function (event) {
343 |   if (event.key === 'Enter') {
344 |     document.getElementById('DeleteButton').click();
345 |   }
346 | });
347 |
348 |
349 | const init = async () => {
350 |   const list = [15, 7, 25, 4, 10, 20, 30, 2, 6, 8, 13, 18, 22, 28, 35];
351 |   for (let i = 0; i < list.length; i++) {
352 |     document.getElementById('InsertNodeField').value = list[i];
353 |     await addNode();
354 |   }
355 | };
356 | // init();
357 |


--------------------------------------------------------------------------------
/algos/bst/styles.css:
--------------------------------------------------------------------------------
  1 | @import url('https://fonts.googleapis.com/css2?family=Poppins:wght@400;500;600;700&display=swap');
  2 |
  3 |
  4 | * {
  5 |   padding: 0;
  6 |   margin: 0;
  7 |   box-sizing: border-box;
  8 | }
  9 |
 10 | body {
 11 |   background: #212833 ;
 12 |   box-shadow: inset 0 70px 80px rgb(0 0 0 / 21%);
 13 |   font-family: 'Poppins', sans-serif;
 14 |
 15 | }
 16 |
 17 | /* =============  Scrollbar  ============= */
 18 | ::-webkit-scrollbar {
 19 |   width: 4px;
 20 | }
 21 | ::-webkit-scrollbar-track {
 22 |   background: #000;
 23 | }
 24 | ::-webkit-scrollbar-thumb {
 25 |   background: white;
 26 | }
 27 |
 28 |
 29 |
 30 | .container {
 31 |   display: flex;
 32 |   flex-direction: column;
 33 |   justify-content: center;
 34 |   align-items: center;
 35 |   display: flex;
 36 |
 37 | }
 38 | #header {
 39 |   width: 1400px;
 40 |   margin-top: 1rem;
 41 |
 42 |   box-shadow: 10px 10px 30px rgba(0, 0, 0, 0.363);
 43 |   border-radius: 10px;
 44 |   background-color: rgba(255, 255, 255, 0.1);
 45 |   overflow: hidden;
 46 |   display: flex;
 47 |   flex-direction: row;
 48 |   justify-content: center;
 49 |   border-top: 1px solid rgba(255, 255, 255, 0.4);
 50 |   border-left: 1px solid rgba(255, 255, 255, 0.4);
 51 |   font-family: 'Poppins', sans-serif;
 52 |   backdrop-filter: blur(8px);
 53 | }
 54 | #header a {
 55 |   text-decoration: none;
 56 |
 57 | }
 58 | #title {
 59 |   text-align: center;
 60 |   font-size: 2rem;
 61 |   /* color: rgb(90, 0, 90) ; */
 62 |   color: rgb(244, 244, 244);
 63 |   padding: 1rem 0;
 64 |   font-weight: bold;
 65 | }
 66 |
 67 |
 68 | #OperationContainer {
 69 |   position: absolute;
 70 |   top: 25px;
 71 |   left: 20px;
 72 | }
 73 |
 74 | #OperationContainer button {
 75 |   background: #161824;
 76 |   margin-left: 0.5rem;
 77 |   outline: none;
 78 |   border: none;
 79 |   padding: 0.4rem 1rem;
 80 |   color: #fff;
 81 |   border-radius: 2px;
 82 | }
 83 | #OperationContainer button:hover {
 84 |   cursor: pointer;
 85 | }
 86 | #OperationContainer input {
 87 |   padding-left: 0.4rem !important;
 88 |   padding: 0.3rem 0;
 89 |   border-radius: 2px;
 90 |   outline: none;
 91 |   border: 1px solid transparent;
 92 | }
 93 | #OperationContainer input:focus {
 94 |   border: 1px solid rgb(183, 0, 255);
 95 | }
 96 |
 97 |
 98 | #InsertNodeField,
 99 | #DeleteNodeField {
100 |   width: 120px;
101 | }
102 | #DeleteNodeField {
103 |   margin-left: 10px;
104 | }
105 |
106 | .Canvas {
107 |   width: 100%;
108 |   height: 100vh;
109 |   display: flex;
110 |   overflow: hidden;
111 |   margin-left: auto;
112 |   margin-right: auto;
113 |   position: relative;
114 | }
115 |
116 |
117 | .indicator_container {
118 |   display: flex;
119 |   align-items: center;
120 |   justify-content: center;
121 |   background-color: cornflowerblue;
122 |   padding: 0.5rem 1rem ;
123 |   font-size: 0.9rem;
124 |   gap: 2rem;
125 |   width: 800px;
126 | }
127 |
128 | .indicator  {
129 |   display: flex;
130 |   align-items: center;
131 | }
132 | .indicator_block {
133 |   margin-right: 0.3rem;
134 | }
135 | .indicator  #edge{
136 |   height: 0.2rem;
137 |   width: 2.5rem;
138 |   background-color: #099691;
139 |   box-shadow: 0 0 1px #333;
140 | }
141 |
142 | .indicator  #node {
143 |   height: 1.5rem;
144 |   width: 1.5rem;
145 |   border-radius: 50%;
146 |   background-color: #25d003;
147 |   box-shadow: 0 0 1px #333;
148 | }
149 |
150 |
151 |
152 |
153 |
154 |
155 |
156 | .indicator text {
157 |   font-size: 20px !important;
158 | }
159 |
160 | svg {
161 |   margin-top: 5px;
162 |   width: 100%;
163 |   /* max-width: 1200px; */
164 |   height: 100%;
165 |   overflow: scroll;
166 | }
167 |
168 | .node circle {
169 |   fill: #29e703;
170 |   /* fill-opacity: 0.6; */
171 |   stroke: #168700;
172 |   stroke-width: 1px;
173 | }
174 | .node text {
175 |   font-size: 22px;
176 |   fill: #ffffff;
177 | }
178 |
179 | .highlightedNode circle {
180 |   fill: red;
181 |   stroke: red;
182 |   stroke-width: 1px;
183 | }
184 |
185 | .null-node,
186 | .null-link {
187 |   visibility: hidden;
188 | }
189 |
190 | line {
191 |   stroke: #099b96;
192 | }
193 |
194 | .LinkAnimation {
195 |   stroke: red;
196 |   stroke-dasharray: 500;
197 |   animation: filling 1s linear forwards;
198 | }
199 |
200 | @keyframes filling {
201 |   from {
202 |     stroke-dashoffset: 500;
203 |   }
204 |   to {
205 |     stroke-dashoffset: 0;
206 |   }
207 | }
208 |


--------------------------------------------------------------------------------
/algos/path_finding/index.html:
--------------------------------------------------------------------------------
 1 |
 2 | <!DOCTYPE html>
 3 | <html lang="en">
 4 | <head>
 5 |   <meta charset="UTF-8">
 6 |   <meta http-equiv="X-UA-Compatible" content="IE=edge">
 7 |   <meta name="viewport" content="width=device-width, initial-scale=1.0">
 8 |   <link rel="stylesheet" href="./styles.css" />
 9 |
10 |   <title>Algorithm Visualizer | Path Finder</title>
11 |   </head>
12 |   <body>
13 |     <div id="header">
14 |       <a href="/index.html"><div id="title">Algorithm Visualizer</div></a>
15 |       <div id="header-right">
16 |         <div>
17 |           <select id="algorithm_type" name="sort_type">
18 |             <option value="dijkstra" selected>Dijkstra's Algorithm</option>
19 |             <option value="Astar">A* Search algorithm</option>
20 |             <option value="bfs">BFS(Breadth first search)</option>
21 |             <option value="dfs">DFS(Depth first search)</option>
22 |           </select>
23 |         </div>
24 |       </div>
25 |     </div>
26 |
27 |     <div id="indicator-container">
28 |       <div class="indicator">
29 |         <div class="indicator-block" id="start-indicator"></div>
30 |         <div><p>Starting Position</p></div>
31 |       </div>
32 |       <div class="indicator">
33 |         <div class="indicator-block" id="end-indicator"></div>
34 |         <div><p>Ending Position</p></div>
35 |       </div>
36 |       <div class="indicator">
37 |         <div class="indicator-block" id="visited-indicator"></div>
38 |         <div><p>Visited Node</p></div>
39 |       </div>
40 |       <div class="indicator">
41 |         <div class="indicator-block" id="wall-indicator"></div>
42 |         <div><p>Wall</p></div>
43 |       </div>
44 |       <div class="indicator">
45 |         <div class="indicator-block" id="path-indicator"></div>
46 |         <div><p>Path</p></div>
47 |       </div>
48 |     </div>
49 |     <div id="container"></div>
50 |     <div id="buttonsdiv">
51 |       <button id="visualizeButton" class="button"><p>Visualize</p></button>
52 |       <button id="clearButton" class="button"><p>Clear Grid</p></button>
53 |     </div>
54 |     <script src="./script.js"></script>
55 |   </body>
56 | </html>
57 |


--------------------------------------------------------------------------------
/algos/path_finding/script.js:
--------------------------------------------------------------------------------
  1 | const rows = 19;
  2 | const cols = 44;
  3 |
  4 | let startingPointX = 9;
  5 | let startingPointY = 15;
  6 | let endingPointX = 9;
  7 | let endingPointY = 27;
  8 |
  9 | let speed = 10;
 10 |
 11 | // it will show whether visualization is currently in process or not.
 12 | let currentlyRunning = false;
 13 | let foundPath = false;
 14 | let mouseIsDown = false;
 15 |
 16 | // for the grid "isBlocked" will show whether there is wall or not on given cell.
 17 | let isBlocked = new Array(rows);
 18 | let gridElements = new Array(rows);
 19 | for (let i = 0; i < rows; i++) {
 20 |   isBlocked[i] = new Array(cols).fill(0);
 21 |   gridElements[i] = new Array(cols);
 22 | }
 23 |
 24 | class PriorityQueue {
 25 |   constructor(defaultNode, comparator) {
 26 |     this.values = [];
 27 |     this.comparator = comparator;
 28 |     this.defaultNode = defaultNode;
 29 |   }
 30 |   // implemention of heap. based on "comparator" function heap will behave like min-heap or max-heap;
 31 |   add(element) {
 32 |     this.values.push(element);
 33 |     let index = this.values.length - 1;
 34 |     while (index >= 1 && this.comparator(this.values[index], this.values[Math.floor(index / 2)])) {
 35 |       [this.values[index], this.values[Math.floor(index / 2)]] = [
 36 |         this.values[Math.floor(index / 2)],
 37 |         this.values[index],
 38 |       ];
 39 |       index = Math.floor(index / 2);
 40 |     }
 41 |   }
 42 |   getTop() {
 43 |     if (this.isEmpty()) return 'No elements in priority queue';
 44 |     return this.values[0];
 45 |   }
 46 |   pop() {
 47 |     if (this.isEmpty()) return 'Underflow';
 48 |     [this.values[0], this.values[this.values.length - 1]] = [this.values[this.values.length - 1], this.values[0]];
 49 |     this.values.pop();
 50 |
 51 |     let element = this.values[0];
 52 |     let index = 0;
 53 |     while (index * 2 + 1 < this.values.length) {
 54 |       let leftNode = this.defaultNode;
 55 |       let rightNode = this.defaultNode;
 56 |       if (index * 2 + 1 < this.values.length) leftNode = this.values[index * 2 + 1];
 57 |       if (index * 2 + 2 < this.values.length) rightNode = this.values[index * 2 + 2];
 58 |
 59 |       if (this.comparator(element, rightNode) && this.comparator(element, leftNode)) break;
 60 |       if (index * 2 + 2 === this.values.length || this.comparator(leftNode, rightNode)) {
 61 |         [this.values[index], this.values[index * 2 + 1]] = [this.values[index * 2 + 1], this.values[index]];
 62 |         index = index * 2 + 1;
 63 |       } else {
 64 |         [this.values[index], this.values[index * 2 + 2]] = [this.values[index * 2 + 2], this.values[index]];
 65 |         index = index * 2 + 2;
 66 |       }
 67 |     }
 68 |   }
 69 |   isEmpty() {
 70 |     return this.values.length === 0;
 71 |   }
 72 | }
 73 |
 74 | class Deque {
 75 |   constructor() {
 76 |     this.values = [];
 77 |   }
 78 |   push_back(element) {
 79 |     this.values.push(element);
 80 |   }
 81 |   pop_back() {
 82 |     if (this.isEmpty()) return;
 83 |     return this.values.pop();
 84 |   }
 85 |   push_front(element) {
 86 |     this.values.unshift(element);
 87 |   }
 88 |   pop_front() {
 89 |     if (this.isEmpty()) return;
 90 |     return this.values.shift();
 91 |   }
 92 |   isEmpty() {
 93 |     return this.values.length == 0;
 94 |   }
 95 | }
 96 |
 97 | // create grid like struccture using table.
 98 | const init = () => {
 99 |   const allowDrop = (e) => {
100 |     e.preventDefault();
101 |   };
102 |
103 |   const drag = (e) => {
104 |     mouseIsDown = false;
105 |     e.dataTransfer.setData('sourceId', e.target.id);
106 |   };
107 |
108 |   const drop = (e) => {
109 |     e.preventDefault();
110 |     let sourceId = e.dataTransfer.getData('sourceId');
111 |     let targetId = e.target.id;
112 |
113 |     var src = document.getElementById(sourceId);
114 |     var tar = document.getElementById(targetId);
115 |     let tarX = Number.parseInt(tar.id.substr(1, 2));
116 |     let tarY = Number.parseInt(tar.id.substr(4, 2));
117 |     if (!src || !tar) return;
118 |     if (
119 |       (src.className === 'startPoint' && tar.className === 'endPoint') ||
120 |       (src.className === 'endPoint' && tar.className === 'startPoint')
121 |     ) {
122 |       [startingPointX, endingPointX] = [endingPointX, startingPointX];
123 |       [startingPointY, endingPointY] = [endingPointY, startingPointY];
124 |     } else {
125 |       if (src.className === 'startPoint') {
126 |         startingPointX = tarX;
127 |         startingPointY = tarY;
128 |       } else {
129 |         endingPointX = tarX;
130 |         endingPointY = tarY;
131 |       }
132 |       src.draggable = false;
133 |       src.ondragstart = null;
134 |       tar.draggable = true;
135 |       tar.ondragstart = (e) => drag(e);
136 |     }
137 |
138 |     [src.className, tar.className] = [tar.className, src.className];
139 |     [src.id, tar.id] = [tar.id, src.id];
140 |   };
141 |   const createGrid = (rows, cols, callback) => {
142 |     let grid = document.createElement('table');
143 |     grid.className = 'grid';
144 |
145 |     for (let i = 0; i < rows; i++) {
146 |       let tr = grid.appendChild(document.createElement('tr'));
147 |       tr.ondrop = (e) => drop(e);
148 |       tr.ondragover = (e) => allowDrop(e);
149 |
150 |       for (let j = 0; j < cols; j++) {
151 |         let cell = tr.appendChild(document.createElement('td'));
152 |         // Unique ID for each cell. if row or cell number is single digit then put 0 infront of it.
153 |         cell.id = 'r' + ('0' + i).slice(-2) + 'c' + ('0' + j).slice(-2);
154 |
155 |         if (i == startingPointX && j == startingPointY) {
156 |           cell.className = 'startPoint';
157 |           cell.draggable = true;
158 |           cell.ondragstart = (e) => drag(e);
159 |         } else if (i == endingPointX && j == endingPointY) {
160 |           cell.className = 'endPoint';
161 |           cell.draggable = true;
162 |           cell.ondragstart = (e) => drag(e);
163 |         }
164 |
165 |         gridElements[i][j] = cell;
166 |
167 |         cell.addEventListener(
168 |           'mouseover',
169 |           () => {
170 |             if (mouseIsDown) callback(cell, i, j);
171 |           },
172 |           false
173 |         );
174 |
175 |         cell.addEventListener(
176 |           'mousedown',
177 |           () => {
178 |             callback(cell, i, j);
179 |           },
180 |           false
181 |         );
182 |       }
183 |     }
184 |
185 |     return grid;
186 |   };
187 |   const grid = createGrid(rows, cols, function (el, row, col) {
188 |     if (row == startingPointX && col == startingPointY) {
189 |     } else if (row == endingPointX && col == endingPointY) {
190 |     } else if (el.className == 'clicked') {
191 |       el.className = '';
192 |       isBlocked[row][col] = 0;
193 |     } else {
194 |       el.className = 'clicked';
195 |       isBlocked[row][col] = 1;
196 |     }
197 |   });
198 |   document.getElementById('container').appendChild(grid);
199 |   document.querySelector('body').addEventListener('mousedown', () => {
200 |     mouseIsDown = 1;
201 |   });
202 |   document.querySelector('body').addEventListener('mouseup', () => {
203 |     mouseIsDown = 0;
204 |   });
205 | };
206 | init();
207 |
208 | const isValid = (x, y) => {
209 |   return x >= 0 && y >= 0 && x < rows && y < cols;
210 | };
211 | // to put delay between visualization.
212 | function sleep(ms) {
213 |   return new Promise((resolve) => setTimeout(resolve, ms));
214 | }
215 | const animate = async (nodesToAnimate, speed) => {
216 |   for (let i = 0; i < nodesToAnimate.length; i++) {
217 |     gridElements[nodesToAnimate[i].x][nodesToAnimate[i].y].className = 'visited';
218 |     await sleep(speed);
219 |     if (currentlyRunning == false) {
220 |       clearGrid();
221 |       return;
222 |     }
223 |   }
224 | };
225 | const generatePath = (path) => {
226 |   let pathFromSrcToDest = [];
227 |   let curi = endingPointX;
228 |   let curj = endingPointY;
229 |
230 |   while (!(curi == startingPointX && curj == startingPointY)) {
231 |     if (path[curi][curj] == 'D') {
232 |       curi++;
233 |     } else if (path[curi][curj] == 'U') {
234 |       curi--;
235 |     } else if (path[curi][curj] == 'L') {
236 |       curj--;
237 |     } else if (path[curi][curj] == 'R') {
238 |       curj++;
239 |     }
240 |     if (!(curi == startingPointX && curj == startingPointY)) {
241 |       pathFromSrcToDest.push({ x: curi, y: curj });
242 |     }
243 |   }
244 |   pathFromSrcToDest.reverse();
245 |   return pathFromSrcToDest;
246 | };
247 | const animatePath = async (path) => {
248 |   if (currentlyRunning == false) return;
249 |   let pathFromSrcToDest = generatePath(path);
250 |
251 |   for (let i = 0; i < pathFromSrcToDest.length; i++) {
252 |     let { x, y } = pathFromSrcToDest[i];
253 |     gridElements[x][y].className = 'path';
254 |     await sleep(speed * 2.5);
255 |
256 |     if (currentlyRunning === false) {
257 |       clearGrid();
258 |       return;
259 |     }
260 |   }
261 |   currentlyRunning = false;
262 | };
263 |
264 | const Dijkstra = async () => {
265 |   // initiazing variables.
266 |   const INF = 1000000000;
267 |   let vis = new Array(rows);
268 |   let path = new Array(rows);
269 |   let dis = new Array(rows);
270 |   for (let i = 0; i < rows; i++) {
271 |     vis[i] = new Array(cols).fill(0);
272 |     path[i] = new Array(cols).fill('0');
273 |     dis[i] = new Array(cols).fill(INF);
274 |   }
275 |   let nodesToAnimate = [];
276 |   // this will default node for min-heap.
277 |   const defaultNode = {
278 |     dis: INF,
279 |     x: -1,
280 |     y: -1,
281 |   };
282 |   // heap will be created based on given comparator function.
283 |   const DijkstraComparator = (a, b) => {
284 |     if (a.dis != b.dis) return a.dis < b.dis;
285 |     return Math.abs(a.y - endingPointY) < Math.abs(b.y - endingPointY);
286 |   };
287 |   const pq = new PriorityQueue(defaultNode, DijkstraComparator);
288 |
289 |   pq.add({ dis: 0, x: startingPointX, y: startingPointY });
290 |   dis[startingPointX][startingPointY] = 0;
291 |   vis[startingPointX][startingPointY] = 1;
292 |   path[startingPointX][startingPointY] = '1';
293 |
294 |   const dx = [1, 0, -1, 0];
295 |   const dy = [0, 1, 0, -1];
296 |   const direction = ['U', 'L', 'D', 'R'];
297 |
298 |   while (!pq.isEmpty()) {
299 |     let p = pq.getTop();
300 |     pq.pop();
301 |     let x = p.x;
302 |     let y = p.y;
303 |
304 |     if (x == endingPointX && y == endingPointY) {
305 |       break;
306 |     }
307 |     if (!(x == startingPointX && y == startingPointY)) {
308 |       nodesToAnimate.push({ x: x, y: y });
309 |     }
310 |     for (let i = 0; i < 4; i++) {
311 |       let newX = x + dx[i];
312 |       let newY = y + dy[i];
313 |       if (isValid(newX, newY) && isBlocked[newX][newY] === 0 && dis[x][y] + 1 < dis[newX][newY]) {
314 |         pq.add({
315 |           dis: dis[x][y] + 1,
316 |           x: newX,
317 |           y: newY,
318 |         });
319 |         vis[newX][newY] = 1;
320 |         dis[newX][newY] = dis[x][y] + 1;
321 |         path[newX][newY] = direction[i];
322 |       }
323 |     }
324 |
325 |     if (currentlyRunning === false) {
326 |       clearGrid();
327 |       return;
328 |     }
329 |   }
330 |
331 |   await animate(nodesToAnimate, speed);
332 |   if (vis[endingPointX][endingPointY]) {
333 |     foundPath = true;
334 |     await animatePath(path);
335 |   } else {
336 |     alert('There is no path between starting and ending point');
337 |   }
338 |   currentlyRunning = false;
339 | };
340 |
341 | const DFS_BFS = async (type) => {
342 |   let vis = new Array(rows);
343 |   let path = new Array(rows);
344 |   for (let i = 0; i < rows; i++) {
345 |     vis[i] = new Array(cols).fill(false);
346 |     path[i] = new Array(cols).fill('0');
347 |   }
348 |   let nodesToAnimate = [];
349 |
350 |   const dq = new Deque();
351 |   dq.push_back([startingPointX, startingPointY]);
352 |   vis[startingPointX][startingPointY] = true;
353 |   path[startingPointX][startingPointY] = '1';
354 |
355 |   const dx = [1, 0, -1, 0];
356 |   const dy = [0, 1, 0, -1];
357 |   const direction = ['U', 'L', 'D', 'R'];
358 |
359 |   while (!dq.isEmpty()) {
360 |     let x, y;
361 |     if (type == 'dfs') {
362 |       [x, y] = dq.pop_back();
363 |     } else {
364 |       [x, y] = dq.pop_front();
365 |     }
366 |
367 |     if (x == endingPointX && y == endingPointY) {
368 |       break;
369 |     }
370 |     if (!(x == startingPointX && y == startingPointY)) {
371 |       nodesToAnimate.push({ x: x, y: y });
372 |     }
373 |     for (let i = 0; i < 4; i++) {
374 |       let newX = x + dx[i];
375 |       let newY = y + dy[i];
376 |       if (isValid(newX, newY) && isBlocked[newX][newY] == 0 && vis[newX][newY] == false) {
377 |         dq.push_back([newX, newY]);
378 |         vis[newX][newY] = true;
379 |         path[newX][newY] = direction[i];
380 |       }
381 |     }
382 |     if (currentlyRunning == false) {
383 |       clearGrid();
384 |       return;
385 |     }
386 |   }
387 |
388 |   await animate(nodesToAnimate, speed + 4);
389 |   if (vis[endingPointX][endingPointY]) {
390 |     foundPath = true;
391 |     await animatePath(path);
392 |   } else {
393 |     alert('There is no path between starting and ending point');
394 |   }
395 |   currentlyRunning = false;
396 | };
397 |
398 | const AStar = async () => {
399 |   const findManhattanDistance = (sx, sy, fx, fy) => {
400 |     return Math.abs(fx - sx) + Math.abs(fy - sy);
401 |   };
402 |   const AStarComparator = (x, y) => {
403 |     return x.f < y.f;
404 |   };
405 |
406 |   const INF = 1000000000;
407 |   let vis = new Array(rows);
408 |   let path = new Array(rows);
409 |   for (let i = 0; i < rows; i++) {
410 |     vis[i] = new Array(cols).fill(0);
411 |     path[i] = new Array(cols).fill('0');
412 |   }
413 |   let nodesToAnimate = [];
414 |
415 |   const defaultNode = {
416 |     f: INF,
417 |     x: -1,
418 |     y: -1,
419 |   };
420 |   const pq = new PriorityQueue(defaultNode, AStarComparator);
421 |   pq.add({
422 |     f: findManhattanDistance(startingPointX, startingPointY, endingPointX, endingPointY),
423 |     x: startingPointX,
424 |     y: startingPointY,
425 |   });
426 |   vis[startingPointX][startingPointY] = 1;
427 |   path[startingPointX][startingPointY] = '1';
428 |
429 |   const dx = [1, 0, -1, 0];
430 |   const dy = [0, 1, 0, -1];
431 |   const direction = ['U', 'L', 'D', 'R'];
432 |
433 |   while (!pq.isEmpty()) {
434 |     let p = pq.getTop();
435 |     pq.pop();
436 |     let x = p.x;
437 |     let y = p.y;
438 |
439 |     if (x == endingPointX && y == endingPointY) {
440 |       break;
441 |     }
442 |     if (!(x == startingPointX && y == startingPointY)) {
443 |       nodesToAnimate.push({ x: x, y: y });
444 |     }
445 |     for (let i = 0; i < 4; i++) {
446 |       let newX = x + dx[i];
447 |       let newY = y + dy[i];
448 |       if (isValid(newX, newY) && isBlocked[newX][newY] === 0 && vis[newX][newY] === 0) {
449 |         let newNode = {};
450 |         pq.add({
451 |           f: findManhattanDistance(newX, newY, endingPointX, endingPointY),
452 |           x: newX,
453 |           y: newY,
454 |         });
455 |         vis[newX][newY] = 1;
456 |         path[newX][newY] = direction[i];
457 |       }
458 |     }
459 |
460 |     if (currentlyRunning === false) {
461 |       clearGrid();
462 |       return;
463 |     }
464 |   }
465 |   await animate(nodesToAnimate, speed + 10);
466 |   if (vis[endingPointX][endingPointY]) {
467 |     foundPath = true;
468 |     await animatePath(path);
469 |   } else {
470 |     alert('There is no path between starting and ending point');
471 |   }
472 |   currentlyRunning = false;
473 | };
474 |
475 | const removeVisitedCell = () => {
476 |   // remove "visited" and "path"
477 |   for (let i = 0; i < rows; i++) {
478 |     for (let j = 0; j < cols; j++) {
479 |       if (gridElements[i][j].className == 'visited' || gridElements[i][j].className == 'path') {
480 |         gridElements[i][j].className = '';
481 |       }
482 |     }
483 |   }
484 | };
485 |
486 | const clearGrid = () => {
487 |   //  remove "visited", "path" and "block(wall)" cells
488 |   currentlyRunning = false;
489 |   for (let i = 0; i < rows; i++) {
490 |     for (let j = 0; j < cols; j++) {
491 |       if ((i == startingPointX && j == startingPointY) || (i == endingPointX && j == endingPointY));
492 |       else {
493 |         gridElements[i][j].className = '';
494 |       }
495 |       isBlocked[i][j] = 0;
496 |     }
497 |   }
498 | };
499 |
500 | const algorithmCaller = () => {
501 |   if (currentlyRunning == true) {
502 |     return;
503 |   }
504 |   type = document.getElementById('algorithm_type').value;
505 |   currentlyRunning = true;
506 |   foundPath = false;
507 |   removeVisitedCell();
508 |   if (type == 'dijkstra') {
509 |     Dijkstra();
510 |   } else if (type == 'Astar') {
511 |     AStar();
512 |   } else if (type == 'bfs' || type == 'dfs') {
513 |     DFS_BFS(type);
514 |   }
515 | };
516 |
517 | document.getElementById('visualizeButton').addEventListener('click', algorithmCaller);
518 | document.getElementById('clearButton').addEventListener('click', clearGrid);
519 |


--------------------------------------------------------------------------------
/algos/path_finding/styles.css:
--------------------------------------------------------------------------------
  1 | @import url('https://fonts.googleapis.com/css2?family=Poppins:wght@400;500;600;700&display=swap');
  2 |
  3 |
  4 | * {
  5 |   padding: 0;
  6 |   margin: 0;
  7 |   box-sizing: border-box;
  8 | }
  9 |
 10 | body {
 11 |   background: #212833 ;
 12 |   display: flex;
 13 |   flex-direction: column;
 14 |   align-items: center;
 15 |   font-family: 'Poppins', sans-serif;
 16 |   box-shadow: inset 0 70px 80px rgb(0 0 0 / 21%);
 17 | }
 18 |
 19 | /* =============  Scrollbar  ============= */
 20 | ::-webkit-scrollbar {
 21 |   width: 4px;
 22 | }
 23 | ::-webkit-scrollbar-track {
 24 |   background: #000;
 25 | }
 26 | ::-webkit-scrollbar-thumb {
 27 |   background: white;
 28 | }
 29 |
 30 |
 31 |
 32 | #header {
 33 |   width: 1400px;
 34 |   margin-top: 1rem;
 35 |   align-items: center;
 36 |
 37 |   box-shadow: 10px 10px 30px rgba(0, 0, 0, 0.363);
 38 |   border-radius: 10px;
 39 |   background-color: rgba(255, 255, 255, 0.1);
 40 |   overflow: hidden;
 41 |   display: flex;
 42 |   flex-direction: row;
 43 |   justify-content: center;
 44 |   border-top: 1px solid rgba(255, 255, 255, 0.4);
 45 |   border-left: 1px solid rgba(255, 255, 255, 0.4);
 46 |   font-family: 'Poppins', sans-serif;
 47 |   backdrop-filter: blur(8px);
 48 | }
 49 | #header a {
 50 |   text-decoration: none;
 51 |
 52 | }
 53 | #title {
 54 |   text-align: center;
 55 |   font-size: 2rem;
 56 |   color: rgb(244, 244, 244);
 57 |   padding: 1rem 0;
 58 |   font-weight: bold;
 59 | }
 60 |
 61 |
 62 |
 63 | #algorithm_type {
 64 |   position: absolute;
 65 |   right: 0 !important;
 66 |   top: 1.5rem ;
 67 |   margin-right: 2rem;
 68 |   padding: 0.5rem 1rem;
 69 |   border-radius: 5px;
 70 |   background: #161824;
 71 |   color: white;
 72 |   outline: none;
 73 |   border: none;
 74 | }
 75 | #algorithm_type:hover {
 76 |   cursor: pointer;
 77 | }
 78 |
 79 | #indicator-container {
 80 |   display: flex;
 81 |   justify-content: center;
 82 |   align-items: center;
 83 |   width: 800px;
 84 |   background-color: cornflowerblue;
 85 | }
 86 | #indicator-container p {
 87 |   font-family: 'Poppins', sans-serif;
 88 |   font-size: 0.9rem;
 89 |   font-weight: normal;
 90 |
 91 | }
 92 |
 93 | .indicator {
 94 |   display: flex;
 95 |   font-weight: bold;
 96 |   margin: 10px 20px;
 97 | }
 98 | .indicator-block {
 99 |   width: 20px;
100 |   height: 20px;
101 |   margin-right: 5px;
102 | }
103 | #start-indicator {
104 |   background-color: rgb(90, 255, 7);
105 | }
106 | #end-indicator {
107 |   background-color: red;
108 | }
109 | #visited-indicator {
110 |   background-color: orange;
111 | }
112 | #wall-indicator {
113 |   background-color: rgb(47, 40, 40);
114 | }
115 | #path-indicator {
116 |   background-color: rgb(128, 0, 167);
117 | }
118 | .button {
119 |   padding: 0.8rem 1.4rem;
120 |   font-size: 1rem !important;
121 |   color: white;
122 |   border-radius: 5px;
123 |   background: #161824;
124 |   letter-spacing: 1.2px;
125 |   border: none;
126 |   outline: none;
127 |   transition: all 0.25s ease-in-out;
128 | }
129 | .button:hover {
130 |   cursor: pointer;
131 |   transform: scale(1.1) perspective(1px);
132 | }
133 |
134 | #visualizeButton {
135 |   margin-right: 10px;
136 | }
137 | #clearButton {
138 |   margin-left: 10px;
139 | }
140 |
141 | .grid {
142 |   margin: 1em auto;
143 |   border-collapse: collapse;
144 | }
145 | .grid td {
146 |   cursor: pointer;
147 |   width: 28px;
148 |   height: 28px;
149 |   border: 1px solid rgb(114, 161, 236);
150 |   text-align: center;
151 |   background-color: white;
152 | }
153 | .grid td.clicked {
154 |   background-color: rgb(47, 40, 40);
155 |   animation: clicked_animation 1.5s 1;
156 | }
157 |
158 | .grid td.startPoint {
159 |   background-color: rgb(90, 255, 7);
160 | }
161 |
162 | .grid td.endPoint {
163 |   background-color: red;
164 | }
165 |
166 | .grid td.visited {
167 |   background-color: orange;
168 |   animation: visited_animation 2s 1;
169 | }
170 |
171 | @keyframes clicked_animation {
172 |   from {
173 |     background-color: rgb(0, 200, 255);
174 |   }
175 |   to {
176 |     /* background-color: yellow; */
177 |   }
178 | }
179 |
180 | @keyframes visited_animation {
181 |   from {
182 |     border-radius: 5px;
183 |     background-color: purple;
184 |   }
185 |   to {
186 |     border-radius: 0px;
187 |     background-color: orange;
188 |   }
189 | }
190 |
191 | .grid td.path {
192 |   background-color: rgb(128, 0, 167);
193 |   animation: change_color 1.5s 1;
194 | }
195 | @keyframes change_color {
196 |   from {
197 |     background-color: rgb(0, 255, 229);
198 |   }
199 |   to {
200 |     background-color: rgb(128, 0, 167);
201 |   }
202 | }
203 |


--------------------------------------------------------------------------------
/algos/sorting/index.html:
--------------------------------------------------------------------------------
 1 | <!DOCTYPE html>
 2 | <html lang="en">
 3 | <head>
 4 |   <meta charset="UTF-8">
 5 |   <meta http-equiv="X-UA-Compatible" content="IE=edge">
 6 |   <meta name="viewport" content="width=device-width, initial-scale=1.0">
 7 |   <link rel="stylesheet" href="./styles.css" />
 8 |
 9 |   <title>Algorithm Visualizer | Sorting</title>
10 | </head>
11 |
12 |   <body>
13 |     <div id="header">
14 |       <div id="headerLeft">
15 |           <div class="headerLeftContent">
16 |             <div class="slidecontainer">
17 |               <input type="range" min="25" max="300" value="150" class="slider" id="speedSlider" />
18 |               <div class="speedValue">Speed</div>
19 |             </div>
20 |             <div class="slidecontainer">
21 |               <input type="range" min="10" max="100" value="50" class="slider" id="barSlider" />
22 |               <div class="sliderValue">Bars: 50</div>
23 |             </div>
24 |             <button class="button" id="generateButton">Generate</button>
25 |           </div>
26 |         <a href="/index.html"><div id="title">Algorithm Visualizer</div></a>
27 |       </div>
28 |       <div id="headerRight">
29 |         <select id="sort_type" name="sort_type">
30 |           <option value="insertion" selected>Insertion Sort</option>
31 |           <option value="bubble">Bubble Sort</option>
32 |           <option value="merge">Merge Sort</option>
33 |           <option value="selection">Selection Sort</option>
34 |           <option value="quick">Quick Sort</option>
35 |         </select>
36 |       </div>
37 |     </div>
38 |     <div id="container"></div>
39 |
40 |     <div id="buttonsdiv">
41 |       <button type="button" id="sortButton" class="button">Sort</button>
42 |       <button type="button" id="pauseButton" class="button">Pause</button>
43 |       <button type="button" id="stopButton" class="button">Stop</button>
44 |     </div>
45 |
46 |     <script src="./script.js"></script>
47 |   </body>
48 | </html>
49 |


--------------------------------------------------------------------------------
/algos/sorting/script.js:
--------------------------------------------------------------------------------
  1 | let heights = [];
  2 | let bars = [];
  3 | let barValues = [];
  4 |
  5 | let barSlider = document.getElementById('barSlider');
  6 | let n = barSlider.value;
  7 | let speedSlider = document.getElementById('speedSlider');
  8 | let delay = 375 - speedSlider.value;
  9 |
 10 | let container = document.getElementById('container');
 11 | let width = container.offsetWidth;
 12 | let height = container.offsetHeight;
 13 | let lineWidth = width / n - 1;
 14 |
 15 | let isStopped = true;
 16 | let isPaused = false;
 17 | let isGenerated = true;
 18 | let isSorted = false;
 19 |
 20 | // stack implementation.
 21 | class Stack {
 22 |   constructor() {
 23 |     this.arr = [];
 24 |     this.top = -1;
 25 |   }
 26 |   push(element) {
 27 |     this.top++;
 28 |     this.arr.push(element);
 29 |   }
 30 |   isEmpty() {
 31 |     return this.top == -1;
 32 |   }
 33 |   pop() {
 34 |     if (this.isEmpty() === false) {
 35 |       this.top = this.top - 1;
 36 |       return this.arr.pop();
 37 |     }
 38 |   }
 39 | }
 40 |
 41 | // get random value between min and max;
 42 | function getRandomValue(min, max) {
 43 |   return Math.random() * (max - min) + min;
 44 | }
 45 | // Generate random heights of the bar and create div element of the bar.
 46 | function generateRandomArray() {
 47 |   isGenerated = true;
 48 |   isSorted = false;
 49 |   isStopped = true;
 50 |   isPaused = false;
 51 |   n = barSlider.value;
 52 |   lineWidth = width / n - 1;
 53 |   container.innerHTML = '';
 54 |   for (let i = 0; i < n; i++) {
 55 |     heights[i] = parseInt(getRandomValue(1, height));
 56 |     bars.push(document.createElement('div'));
 57 |     bars[i].style.width = `${lineWidth}px`;
 58 |     bars[i].style.height = `${heights[i]}px`;
 59 |     bars[i].style.transform = `translate(${i * lineWidth + i}px)`;
 60 |     bars[i].style.backgroundColor = 'white';
 61 |     bars[i].className = 'bar';
 62 |     container.appendChild(bars[i]);
 63 |
 64 |     // if there are more numer of bars then it is not feasible to show bar values because they gets mixed up.
 65 |     if (n <= 60) {
 66 |       barValues.push(document.createElement('div'));
 67 |       barValues[i].innerHTML = heights[i];
 68 |       barValues[i].style.marginBottom = `${heights[i] + 5}px`;
 69 |       barValues[i].style.transform = `translate(${i * lineWidth + i}px)`;
 70 |       barValues[i].className = 'barValue';
 71 |       container.appendChild(barValues[i]);
 72 |     }
 73 |   }
 74 | }
 75 | generateRandomArray();
 76 |
 77 | // swap 2 bars and also swap trnasform property for the animation.
 78 | function swap(i, minindex) {
 79 |   [heights[i], heights[minindex]] = [heights[minindex], heights[i]];
 80 |
 81 |   [bars[i], bars[minindex]] = [bars[minindex], bars[i]];
 82 |   [bars[i].style.transform, bars[minindex].style.transform] = [bars[minindex].style.transform, bars[i].style.transform];
 83 |
 84 |   [barValues[i], barValues[minindex]] = [barValues[minindex], barValues[i]];
 85 |   [barValues[i].style.transform, barValues[minindex].style.transform] = [
 86 |     barValues[minindex].style.transform,
 87 |     barValues[i].style.transform,
 88 |   ];
 89 | }
 90 | // Draw bars with their new Updated heights.
 91 | function draw(coloredBars, colors) {
 92 |   // coloredBars contains indices of the bars which will be in different color than default color
 93 |   // colors array stores color for different bars.
 94 |   for (let i = 0; i < n; i++) {
 95 |     bars[i].style.backgroundColor = 'white';
 96 |     for (let j = 0; j < coloredBars.length; j++) {
 97 |       if (i == coloredBars[j]) {
 98 |         bars[i].style.backgroundColor = colors[j];
 99 |         break;
100 |       }
101 |     }
102 |   }
103 | }
104 |
105 | // to put delay between visualization.
106 | function sleep(ms) {
107 |   return new Promise((resolve) => setTimeout(resolve, ms));
108 | }
109 | // Play animation after sorting process is finished
110 | async function SortedAnimation() {
111 |   // first we will go from left to right and color them in some color.
112 |   // then we will again go from left to right and color them white.
113 |   for (let i = 0; i < n; i++) {
114 |     bars[i].style.backgroundColor = 'lime';
115 |     await sleep(10);
116 |   }
117 |   await sleep(300);
118 |   for (let i = 0; i < n; i++) {
119 |     bars[i].style.backgroundColor = 'white';
120 |     await sleep(10);
121 |   }
122 | }
123 |
124 | // Sorting algos implementation starts...
125 | async function bubbleSort() {
126 |   for (let i = 0; i < n - 1; i++) {
127 |     for (let j = 0; j < n - i - 1; j++) {
128 |       if (isStopped) {
129 |         draw([], []);
130 |         return;
131 |       }
132 |       if (!isPaused) {
133 |         if (heights[j] > heights[j + 1]) {
134 |           swap(j, j + 1);
135 |         }
136 |         draw([j, j + 1], ['green', 'yellow']);
137 |       } else {
138 |         j--;
139 |       }
140 |       await sleep(delay);
141 |     }
142 |   }
143 |   console.log('Bubble sort completed.');
144 |   draw([], []);
145 |   isSorted = true;
146 |   isStopped = true;
147 |   isPaused = false;
148 |   SortedAnimation();
149 | }
150 |
151 | async function selectionSort() {
152 |   for (let i = 0; i < n - 1; i++) {
153 |     let minIndex = i;
154 |     for (let j = i + 1; j < n; j++) {
155 |       if (isStopped) {
156 |         draw([], []);
157 |         return;
158 |       }
159 |       if (!isPaused) {
160 |         if (heights[j] < heights[minIndex]) {
161 |           minIndex = j;
162 |         }
163 |         draw([i, j, minIndex], ['blue', 'red', 'green']);
164 |       } else {
165 |         j--;
166 |       }
167 |       await sleep(delay);
168 |     }
169 |     swap(i, minIndex);
170 |   }
171 |   console.log('Selection sort completed.');
172 |   draw([], []);
173 |   isSorted = true;
174 |   isStopped = true;
175 |   isPaused = false;
176 |   SortedAnimation();
177 | }
178 |
179 | async function insertionSort() {
180 |   for (let i = 0; i < n; i++) {
181 |     let key = heights[i];
182 |     for (let j = i - 1; j >= 0 && heights[j] > key; j--) {
183 |       if (isStopped) {
184 |         draw([], []);
185 |         return;
186 |       }
187 |       if (!isPaused) {
188 |         swap(j, j + 1);
189 |         draw([j, i + 1], ['green', 'red']);
190 |       } else {
191 |         j++;
192 |       }
193 |       await sleep(delay);
194 |     }
195 |   }
196 |   console.log('Insertion sort completed.');
197 |   draw([], []);
198 |   isSorted = true;
199 |   isStopped = true;
200 |   isPaused = false;
201 |   SortedAnimation();
202 | }
203 |
204 | async function mergeSort() {
205 |   for (let curSize = 1; curSize < n; curSize *= 2) {
206 |     for (let start = 0; start < n - 1; start += 2 * curSize) {
207 |       let mid = Math.min(start + curSize - 1, n - 1);
208 |       let end = Math.min(start + 2 * curSize - 1, n - 1);
209 |       let n1 = mid - start + 1;
210 |       let n2 = end - mid;
211 |       let L = [],
212 |         R = [];
213 |       for (let i = 0; i < n1; i++) L.push(heights[start + i]);
214 |       for (let j = 0; j < n2; j++) R.push(heights[mid + 1 + j]);
215 |       let i = 0,
216 |         j = 0,
217 |         k = start;
218 |
219 |       let barsIndices = [];
220 |       let barsColors = [];
221 |       for (let i1 = start; i1 <= end; i1++) {
222 |         barsIndices.push(i1);
223 |         barsColors.push('yellow');
224 |       }
225 |
226 |       while (i < n1 || j < n2) {
227 |         if (isStopped) {
228 |           draw([], []);
229 |           return;
230 |         }
231 |         if (!isPaused) {
232 |           if (j == n2 || (i < n1 && L[i] <= R[j])) {
233 |             draw([k, ...barsIndices], ['green', ...barsColors]);
234 |             i++;
235 |           } else {
236 |             for (let i1 = mid + 1 + j; i1 > k; i1--) {
237 |               swap(i1, i1 - 1);
238 |             }
239 |             draw([k, ...barsIndices], ['green', ...barsColors]);
240 |             j++;
241 |           }
242 |           k++;
243 |         }
244 |         await sleep(delay);
245 |       }
246 |     }
247 |   }
248 |   console.log('Merge sort completed.');
249 |   draw([], []);
250 |   isSorted = true;
251 |   isStopped = true;
252 |   isPaused = false;
253 |   SortedAnimation();
254 | }
255 |
256 | async function quickSort() {
257 |   let s = new Stack();
258 |   s.push(0);
259 |   s.push(n - 1);
260 |   while (!s.isEmpty()) {
261 |     let h = s.pop();
262 |     let l = s.pop();
263 |
264 |     let i = l - 1;
265 |
266 |     let barsIndices = [];
267 |     let barsColors = [];
268 |     for (let i1 = l; i1 <= h; i1++) {
269 |       barsIndices.push(i1);
270 |       barsColors.push('yellow');
271 |     }
272 |
273 |     for (let j = l; j <= h - 1; j++) {
274 |       if (isStopped) {
275 |         draw([], []);
276 |         return;
277 |       }
278 |       if (!isPaused) {
279 |         draw([i, j, ...barsIndices], ['green', 'red', ...barsColors]);
280 |         if (heights[j] <= heights[h]) {
281 |           i++;
282 |           swap(i, j);
283 |         }
284 |       } else {
285 |         j--;
286 |       }
287 |       await sleep(delay);
288 |     }
289 |     swap(i + 1, h);
290 |     let partition = i + 1;
291 |     if (l < partition - 1) {
292 |       s.push(l);
293 |       s.push(partition - 1);
294 |     }
295 |     if (partition + 1 < h) {
296 |       s.push(partition + 1);
297 |       s.push(h);
298 |     }
299 |   }
300 |   console.log('Quick sort completed.');
301 |   draw([], []);
302 |   isSorted = true;
303 |   isStopped = true;
304 |   isPaused = false;
305 |   SortedAnimation();
306 | }
307 |
308 | // when slider value is changed generate new bars and update the value of bar count on the navbar.
309 | barSlider.oninput = () => {
310 |   document.querySelector('.sliderValue').innerHTML = `Bars: ${barSlider.value}`;
311 |   generateRandomArray();
312 | };
313 | speedSlider.oninput = () => {
314 |   delay = 375 - speedSlider.value;
315 | };
316 |
317 | document.getElementById('generateButton').addEventListener('click', generateRandomArray);
318 | document.getElementById('sortButton').addEventListener('click', () => {
319 |   // get the name of selected sorting algorithm.
320 |   type = document.getElementById('sort_type').value;
321 |
322 |   // if there is another sorting visualization going on then return from the function.
323 |   if (!isStopped) return;
324 |   // if recently we used visualization and bars are sorted then generate new unsorted array.
325 |   if (isSorted || !isGenerated) generateRandomArray();
326 |
327 |   isGenerated = false;
328 |   isPaused = false;
329 |   isStopped = false;
330 |
331 |   if (type == 'bubble') bubbleSort();
332 |   else if (type == 'selection') selectionSort();
333 |   else if (type == 'insertion') insertionSort();
334 |   else if (type == 'merge') mergeSort();
335 |   else if (type == 'quick') quickSort();
336 | });
337 | document.getElementById('stopButton').addEventListener('click', () => {
338 |   isStopped = true;
339 |   isPaused = false;
340 |   document.getElementById('pauseButton').innerHTML = 'Pause';
341 |   // if user presses stop button and random bars is not generated then generate rnadom bars.
342 |   if (!isGenerated && !isSorted) generateRandomArray();
343 | });
344 |
345 | document.getElementById('pauseButton').addEventListener('click', () => {
346 |   // if currently sorting is in progress then isStopped will be false.
347 |   if (!isStopped) {
348 |     // toggle button between pause and resume
349 |     if (isPaused) {
350 |       document.getElementById('pauseButton').innerHTML = 'Pause';
351 |       isPaused = false;
352 |     } else {
353 |       document.getElementById('pauseButton').innerHTML = 'Resume';
354 |       isPaused = true;
355 |     }
356 |   }
357 | });
358 |


--------------------------------------------------------------------------------
/algos/sorting/styles.css:
--------------------------------------------------------------------------------
  1 | @import url('https://fonts.googleapis.com/css2?family=Poppins:wght@400;500;600;700&display=swap');
  2 |
  3 |
  4 | * {
  5 |   padding: 0;
  6 |   margin: 0;
  7 |   box-sizing: border-box;
  8 | }
  9 |
 10 | body {
 11 |   background:  #212833 ;
 12 |   box-shadow: inset 0 70px 80px rgb(0 0 0 / 21%);
 13 |   display: flex;
 14 |   flex-direction: column;
 15 |   align-items: center;
 16 |   justify-content: center;
 17 |   margin: auto;
 18 |   font-family: 'Poppins', sans-serif;
 19 |
 20 | }
 21 |
 22 | /* =============  Scrollbar  ============= */
 23 | ::-webkit-scrollbar {
 24 |   width: 4px;
 25 | }
 26 | ::-webkit-scrollbar-track {
 27 |   background: #000;
 28 | }
 29 | ::-webkit-scrollbar-thumb {
 30 |   background: white;
 31 | }
 32 |
 33 |
 34 |
 35 | #header {
 36 |   width: 1400px;
 37 |   margin-top: 1rem;
 38 |
 39 |   box-shadow: 10px 10px 30px rgba(0, 0, 0, 0.363);
 40 |   border-radius: 10px;
 41 |   background-color: rgba(255, 255, 255, 0.1);
 42 |   overflow: hidden;
 43 |   display: flex;
 44 |   align-items: center;
 45 |   justify-content: space-between;
 46 |   border-top: 1px solid rgba(255, 255, 255, 0.4);
 47 |   border-left: 1px solid rgba(255, 255, 255, 0.4);
 48 |   font-family: 'Poppins', sans-serif;
 49 |   backdrop-filter: blur(8px);
 50 | }
 51 | #header a {
 52 |   text-decoration: none;
 53 |
 54 | }
 55 | #title {
 56 |   text-align: center;
 57 |   font-size: 2rem;
 58 |   /* color: rgb(90, 0, 90) ; */
 59 |   color: rgb(244, 244, 244);
 60 |   padding: 1rem 0;
 61 |   font-weight: bold;
 62 | }
 63 |
 64 |
 65 |
 66 | #header > div {
 67 |   flex-grow: 1;
 68 | }
 69 |
 70 | #headerLeft {
 71 |   display: flex;
 72 |   align-items: center;
 73 |   padding-left: 40px;
 74 |   justify-content: space-between;
 75 |   width: 65%;
 76 | }
 77 | .headerLeftContent {
 78 |   display: flex;
 79 | }
 80 | .slidecontainer {
 81 |   position: relative;
 82 |   margin-right: 20px;
 83 | }
 84 | .slider {
 85 |   outline: none;
 86 |   opacity: 0.7;
 87 |   -webkit-transition: 0.2s;
 88 |   transition: opacity 0.2s;
 89 | }
 90 | .slider:hover {
 91 |   opacity: 1;
 92 | }
 93 | .slider::-webkit-slider-thumb {
 94 |   cursor: pointer;
 95 | }
 96 | .sliderValue {
 97 |   position: absolute;
 98 |   top: 20px;
 99 |   left: 40px;
100 | }
101 | .speedValue {
102 |   position: absolute;
103 |   top: 20px;
104 |   left: 40px;
105 | }
106 |
107 | a {
108 |   text-decoration: none;
109 | }
110 |
111 | #headerRight {
112 |   text-align: right;
113 |   padding-right: 55px;
114 |   width: 35%;
115 | }
116 | #sort_type {
117 |   position: absolute;
118 |   right: 0 !important;
119 |   top: 1.5rem ;
120 |   margin-right: 2rem;
121 |   padding: 0.5rem 1rem;
122 |   border-radius: 5px;
123 |   background: #161824;
124 |   color: white;
125 |   outline: none;
126 |   border: none;
127 | }
128 |
129 | #container {
130 |   display: flex;
131 |   width: 99%;
132 |   min-width: 99%;
133 |   height: 570px;
134 |   margin-left: auto;
135 |   margin-right: auto;
136 |   position: relative;
137 |   margin-top: 25px;
138 | }
139 |
140 | .bar {
141 |   margin-right: 1px;
142 |   align-self: flex-end;
143 |   transition: 0.2s transform ease;
144 |   position: absolute;
145 | }
146 | .barValue {
147 |   margin-right: 1px;
148 |   align-self: flex-end;
149 |   transition: 0.2s transform ease;
150 |   position: absolute;
151 |   color: red;
152 |   font-weight: bold;
153 | }
154 |
155 | .button {
156 |   padding: 0.8rem 1.4rem;
157 |   font-size: 1rem;
158 |   color: white;
159 |   border-radius: 5px;
160 |   background: #161824;
161 |   letter-spacing: 1.2px;
162 |   border: none;
163 |   outline: none;
164 |   margin-top: 1rem;
165 |   transition: all 0.25s ease-in-out;
166 | }
167 | .button:hover {
168 |   cursor: pointer;
169 |   transform: scale(1.1) perspective(1px);
170 | }
171 | #buttonsdiv {
172 |   text-align: center;
173 |   margin-bottom: 30px;
174 | }
175 | #sortButton {
176 |   margin-right: 10px;
177 | }
178 | #stopButton {
179 |   margin-left: 10px;
180 | }
181 |
182 | #generateButton {
183 |   padding: 0.4rem 0.8rem;
184 |   font-size: 16px;
185 |   border-radius: 5px;
186 |   margin-top: 0px;
187 |   font-size: 0.9rem;
188 | }
189 | #generateButton:hover {
190 |   transform: scale(1.08) perspective(1px);
191 | }
192 |
193 | @media (max-width: 900px) {
194 |   #title {
195 |     font-size: 0px;
196 |   }
197 |   .slidecontainer,
198 |   #sort_type {
199 |     margin-top: 0px;
200 |   }
201 | }
202 |


--------------------------------------------------------------------------------
/algos/trie/index.html:
--------------------------------------------------------------------------------
 1 | <!DOCTYPE html>
 2 | <html lang="en">
 3 | <head>
 4 |   <meta charset="UTF-8">
 5 |   <meta http-equiv="X-UA-Compatible" content="IE=edge">
 6 |   <meta name="viewport" content="width=device-width, initial-scale=1.0">
 7 |   <link rel="stylesheet" href="./styles.css" />
 8 |
 9 |
10 |   <title>Algorithm Visualizer | Trie</title>
11 |   </head>
12 |   <body>
13 |     <div class="container">
14 |       <div id="header">
15 |         <div id="OperationContainer">
16 |           <input type="text" id="InsertNodeField" placeholder="Enter the word" />
17 |           <button type="button" id="InsertButton" class="button" >Insert</button>
18 |           <input type="text" id="DeleteNodeField" placeholder="Enter the word" />
19 |           <button type="button" id="DeleteButton" class="button">Delete</button>
20 |         </div>
21 |         <a href="/index.html"><div id="title">Algorithm Visualizer</div></a>
22 |       </div>
23 |       <div class="indicator_container">
24 |         <div class="indicator">
25 |           <div class="indicator_block" id="edge"></div>
26 |           <div class=""><p>Edge</p></div>
27 |         </div>
28 |         <div class="indicator">
29 |           <div class="indicator_block" id="node"></div>
30 |           <div class=""><p>Node</p></div>
31 |         </div>
32 |         <div class="indicator">
33 |           <div class="indicator_block" id="end_node"></div>
34 |           <div class=""><p>End of Word Node</p></div>
35 |         </div>
36 |
37 |       </div>
38 |       <div class="Canvas"> </div>
39 |     </div>
40 |
41 |     <script
42 |       src="https://cdnjs.cloudflare.com/ajax/libs/d3/6.5.0/d3.min.js"
43 |       integrity="sha512-0XfwGD1nxplHpehcSVI7lY+m/5L37PNHDt+DOc7aLFckwPXjnjeA1oeNbru7YeI4VLs9i+ADnnHEhP69C9CqTA=="
44 |       crossorigin="anonymous"
45 |     ></script>
46 |     <script src="./script.js"></script>
47 |   </body>
48 | </html>
49 |


--------------------------------------------------------------------------------
/algos/trie/script.js:
--------------------------------------------------------------------------------
  1 | // prerequisite: javascript, d3.js
  2 |
  3 | // structure of node
  4 | // {
  5 | //     nodeId: number <--- unique id for each node. it will be also used as id for html element of node.
  6 | //     value: character <-- this will store character stored in current node
  7 | //     endOfWord: boolean <-- show node as the end of word.
  8 | //     children: [] <--- this array will store all the children nodes and its values
  9 | //     childrenCharacter : {} <-- this will store all children character.
 10 | // }
 11 |
 12 | // Tree will be stored as object.
 13 | let data = { nodeId: 0, value: 'root', endOfWord: false, children: [], childrenCharacter: {} };
 14 | // Current available id for the node. We will give each node a unique id and put this as their html element "id".
 15 | let curId = 1;
 16 |
 17 | const width = Math.max(100, window.innerWidth - 50);
 18 | const height = Math.max(100, window.innerHeight - 200);
 19 | const nodeRadius = 20;
 20 | const LinkStroke = 4;
 21 | const animationDuration = 500;
 22 | const padding = 40;
 23 |
 24 | d3.select('.Canvas').append('svg').append('g');
 25 |
 26 | // During insertion or deletion visualization process disbale the buttons
 27 | const freezeButtons = () => {
 28 |   document.getElementById('InsertButton').disabled = true;
 29 |   document.getElementById('DeleteButton').disabled = true;
 30 | };
 31 | const unfreezeButtons = () => {
 32 |   document.getElementById('InsertButton').disabled = false;
 33 |   document.getElementById('DeleteButton').disabled = false;
 34 | };
 35 |
 36 | // To put delay between visualization.
 37 | const sleep = (ms) => {
 38 |   return new Promise((resolve) => setTimeout(resolve, ms));
 39 | };
 40 |
 41 | // Create the root node.
 42 | const init = () => {
 43 |   const treemap = d3.tree().size([width, height]);
 44 |   const newTree = treemap(d3.hierarchy(data, (d) => d.children));
 45 |
 46 |   newTree.y += padding;
 47 |
 48 |   const nodes = d3
 49 |     .select('.Canvas > svg g')
 50 |     .selectAll('g.node')
 51 |     .data(newTree)
 52 |     .enter()
 53 |     .append('g')
 54 |     .attr('class', () => 'node');
 55 |   nodes
 56 |     .append('circle')
 57 |     .attr('id', (d) => `circle${d.data.nodeId}`)
 58 |     .attr('r', nodeRadius)
 59 |     .attr('cx', (d) => d.x)
 60 |     .attr('cy', (d) => d.y)
 61 |     .attr('value', (d) => d.data.value);
 62 |   nodes
 63 |     .append('text')
 64 |     .attr('dx', (d) => d.x)
 65 |     .attr('dy', (d) => d.y)
 66 |     .attr('text-anchor', 'middle')
 67 |     .attr('alignment-baseline', 'middle')
 68 |     .attr('font-size', '20px')
 69 |     .attr('font-weight', 'bold')
 70 |     .text((d) => d.data.value);
 71 | };
 72 | init();
 73 |
 74 | // To animate from old tree to new tree.
 75 | const update = (oldData, newData, parentId, childId) => {
 76 |   // childId is node we want to insert/delete and parentId is parent of node we want to insert/delete.
 77 |
 78 |   /*
 79 |     Small description of "update" function.
 80 |      -> Find the co-ordinates of old tree.
 81 |      -> Find the co-ordinates of new updated tree.
 82 |      -> Put tree on old co-ordinates.
 83 |      -> Animate nodes and links to the new co-ordinates.
 84 |   */
 85 |
 86 |   // Create the old and new updated tree.
 87 |   const treemap = d3.tree().size([width, height]);
 88 |   const oldTree = treemap(d3.hierarchy(oldData, (d) => d.children));
 89 |   const newTree = treemap(d3.hierarchy(newData, (d) => d.children));
 90 |   // Convert both trees from javascript objects to array.
 91 |   let oldTreeArray = oldTree.descendants();
 92 |   let newTreeArray = newTree.descendants();
 93 |
 94 |   // Putting old and new co-ordinates of nodes in the same array.
 95 |   for (let i = 0; i < newTreeArray.length; i++) {
 96 |     let oldPosition = {};
 97 |     // Traverse the old tree and find the old co-ordinates.
 98 |     for (let j = 0; j < oldTreeArray.length; j++) {
 99 |       if (newTreeArray[i].data.nodeId == childId) {
100 |         // Node which we are going to insert, there is no old co-oridnates available
101 |         // So we are going to use the co-ordinates of parent node.
102 |         if (oldTreeArray[j].data.nodeId == parentId) {
103 |           oldPosition = oldTreeArray[j];
104 |         }
105 |       } else {
106 |         if (oldTreeArray[j].data.nodeId == newTreeArray[i].data.nodeId) {
107 |           oldPosition = oldTreeArray[j];
108 |         }
109 |       }
110 |     }
111 |     newTreeArray[i].oldX = oldPosition.x || 0;
112 |     newTreeArray[i].oldY = (oldPosition.y || 0) + padding;
113 |     newTreeArray[i].y += padding;
114 |   }
115 |
116 |   // Remove the old tree from canvas. we will draw new one.
117 |   d3.select('.Canvas > svg g').remove();
118 |   d3.select('.Canvas > svg').append('g');
119 |
120 |   // Create all the edges and put them in new array.
121 |   let allLinks = [];
122 |   for (let i = 0; i < newTreeArray.length; i++) {
123 |     if (!newTreeArray[i].children) continue;
124 |     for (let j = 0; j < newTreeArray[i].children.length; j++) {
125 |       allLinks.push({
126 |         parent: newTreeArray[i],
127 |         child: newTreeArray[i].children[j],
128 |       });
129 |     }
130 |   }
131 |
132 |   // Drawing edges on canvas with some styles and co-ordinates.
133 |   const links = d3
134 |     .select('.Canvas > svg g')
135 |     .selectAll('g.link')
136 |     .data(allLinks)
137 |     .enter()
138 |     .append('g')
139 |     .append('line')
140 |     .attr('id', (d) => `link${d.parent.data.nodeId}D${d.child.nodeId}`)
141 |     .attr('stroke-width', LinkStroke)
142 |     .attr('stroke', 'black')
143 |     .attr('x1', (d) => d.parent.oldX)
144 |     .attr('y1', (d) => d.parent.oldY)
145 |     .attr('x2', (d) => d.child.oldX)
146 |     .attr('y2', (d) => d.child.oldY);
147 |   // Transition from old tree to new tree. move old edges to new edges using co-ordinates.
148 |   links
149 |     .transition()
150 |     .duration(animationDuration)
151 |     .attr('x1', (d) => d.parent.x)
152 |     .attr('y1', (d) => d.parent.y)
153 |     .attr('x2', (d) => d.child.x)
154 |     .attr('y2', (d) => d.child.y);
155 |
156 |   // Draw nodes and their value on screen using old tree co-ordinates.
157 |   const nodes = d3
158 |     .select('.Canvas > svg g')
159 |     .selectAll('g.node')
160 |     .data(newTree)
161 |     .enter()
162 |     .append('g')
163 |     .attr('id', (d) => `node${d.data.nodeId}`)
164 |     .attr('class', (d) => (d.data.endOfWord ? 'endOfWordNode' : 'node'));
165 |   nodes
166 |     .append('circle')
167 |     .attr('id', (d) => `circle${d.data.nodeId}`)
168 |     .attr('r', nodeRadius)
169 |     .attr('cx', (d) => d.oldX)
170 |     .attr('cy', (d) => d.oldY)
171 |     .attr('value', (d) => d.data.value);
172 |   nodes
173 |     .append('text')
174 |     .attr('dx', (d) => d.oldX)
175 |     .attr('dy', (d) => d.oldY)
176 |     .attr('text-anchor', 'middle')
177 |     .attr('alignment-baseline', 'middle')
178 |     .attr('fill', 'white')
179 |     .attr('font-size', '20px')
180 |     .attr('font-weight', 'bold')
181 |     .text((d) => d.data.value);
182 |
183 |   // Move nodes from old co-ordinate to new co-ordinates.
184 |   nodes
185 |     .transition()
186 |     .duration(animationDuration)
187 |     .attr('transform', function (d) {
188 |       if (d.data.value != null) return `translate(${parseInt(d.x - d.oldX)}, ${parseInt(d.y - d.oldY)})`;
189 |       else return 'translate(0,0)';
190 |     });
191 |
192 |   data = newData;
193 | };
194 |
195 | const addNode = async () => {
196 |   // Get the node value from input field and verify it's value/type.
197 |   let str = document.getElementById('InsertNodeField').value;
198 |   if (str == '') {
199 |     return;
200 |   }
201 |   if (str.length > 12) {
202 |     alert('Word Length should be less than 12.');
203 |     return;
204 |   }
205 |   str = str.toLowerCase();
206 |   document.getElementById('InsertNodeField').value = '';
207 |
208 |   // Freeze(disable) insert and delete buttons.
209 |   freezeButtons();
210 |
211 |   // Copying object without reference in a dirty way. Might make proper function to copy object later.
212 |   let oldData = JSON.parse(JSON.stringify(data));
213 |   let newData = JSON.parse(JSON.stringify(data));
214 |   let node = newData;
215 |
216 |   // Logic of trie insertion with some animation.
217 |   for (let i = 0; i < str.length; i++) {
218 |     if (str[i] in node.childrenCharacter && node.childrenCharacter[str[i]] == true) {
219 |       // Character Node already exits. Just find it and go there.
220 |       for (let j = 0; j < node.children.length; j++) {
221 |         if (node.children[j].value == str[i]) {
222 |           node = node.children[j];
223 |           break;
224 |         }
225 |       }
226 |       if (i == str.length - 1) {
227 |         node.endOfWord = true;
228 |         update(newData, newData, -1, -1);
229 |       }
230 |     } else {
231 |       // Create a node for character. Show node creation animation.
232 |       node.childrenCharacter[str[i]] = true;
233 |       node.children.push({
234 |         nodeId: curId,
235 |         value: str[i],
236 |         endOfWord: i == str.length - 1,
237 |         children: [],
238 |         childrenCharacter: {},
239 |       });
240 |       curId++;
241 |       update(oldData, newData, node.nodeId, node.children[node.children.length - 1].nodeId);
242 |       oldData = JSON.parse(JSON.stringify(newData));
243 |       node = node.children[node.children.length - 1];
244 |     }
245 |     // Show current node in different color(here red).
246 |     const nodeEle = document.getElementById(`node${node.nodeId}`);
247 |     let originalClass = '';
248 |     if (nodeEle) {
249 |       originalClass = nodeEle.className.baseVal;
250 |       nodeEle.className.baseVal = 'highlightedNode';
251 |     }
252 |     await sleep(700);
253 |     // Revert back node to it's original status.
254 |     if (nodeEle) {
255 |       nodeEle.className.baseVal = originalClass;
256 |     }
257 |   }
258 |   unfreezeButtons();
259 | };
260 |
261 | const deleteNodeUtil = async () => {
262 |   // If data object has no children then return.
263 |   if (data.children.length == 0) {
264 |     alert('Trie is empty');
265 |     return;
266 |   }
267 |   // Get the word we want to delete from input field.
268 |   let str = document.getElementById('DeleteNodeField').value;
269 |   if (str == '') {
270 |     return;
271 |   }
272 |   str = str.toLowerCase();
273 |   document.getElementById('DeleteNodeField').value = '';
274 |
275 |   // Freeze(disable) insert and delete buttons.
276 |   freezeButtons();
277 |
278 |   // Copying object without reference in a dirty way. Might make proper function to copy object later.
279 |   const newData = JSON.parse(JSON.stringify(data));
280 |
281 |   // Creating another function for deletion because we are going to write recursive logic to delete word.
282 |   const deleteNode = async (parent, node, str, depth) => {
283 |     // Highlight the node which we are currently processing.
284 |     const nodeEle = document.getElementById(`node${node.nodeId}`);
285 |     let originalClass = '';
286 |     if (nodeEle) {
287 |       originalClass = nodeEle.className.baseVal;
288 |       nodeEle.className.baseVal = 'highlightedNode';
289 |     }
290 |     await sleep(700);
291 |     if (nodeEle) {
292 |       nodeEle.className.baseVal = originalClass;
293 |     }
294 |
295 |     if (depth == str.length) {
296 |       // If last character of word is being processed
297 |       if (node.endOfWord == false) {
298 |         alert('Word not found in trie');
299 |         return false;
300 |       }
301 |       // This node is no more end of word after removal of given word.
302 |       node.endOfWord = false;
303 |
304 |       // If there are still some children to current node
305 |       // Then it means there some words which are ending below.
306 |       // So we cant delete it.
307 |       // Check if current node has some children or not.
308 |       if (node.children.length == 0) {
309 |         // Copying object without reference in a dirty way. Might make proper function to copy object later.
310 |         const oldData = JSON.parse(JSON.stringify(newData));
311 |         // Delete the current node from parent node's "children" and "childrenCharacter" property.
312 |         delete parent.childrenCharacter[str[depth - 1]];
313 |         let charIndex = 0;
314 |         for (let i = 0; i < parent.children.length; i++) {
315 |           if (parent.children[i].value == str[depth - 1]) {
316 |             charIndex = i;
317 |           }
318 |         }
319 |         parent.children.splice(charIndex, 1);
320 |         update(oldData, newData, -1, -1);
321 |       } else {
322 |         update(newData, newData, -1, -1);
323 |       }
324 |       return true;
325 |     }
326 |
327 |     // If not last character, call recursively for the next character.
328 |     // obtained using ASCII value
329 |     if (str[depth] in node.childrenCharacter) {
330 |       let charIndex = 0;
331 |       for (let i = 0; i < node.children.length; i++) {
332 |         if (node.children[i].value == str[depth]) {
333 |           charIndex = i;
334 |         }
335 |       }
336 |
337 |       const isWordFound = await deleteNode(node, node.children[charIndex], str, depth + 1);
338 |       if (isWordFound == false) {
339 |         return false;
340 |       }
341 |
342 |       // Currently we are returning from recursive calls and going back.
343 |
344 |       // If current node does not have any child (ts only child got
345 |       // deleted), and it is not end of another word.
346 |       if (parent && node.children.length == 0 && node.endOfWord == false) {
347 |         const nodeEle = document.getElementById(`node${node.nodeId}`);
348 |         if (nodeEle) {
349 |           nodeEle.className.baseVal = 'highlightedNode';
350 |         }
351 |         await sleep(700);
352 |
353 |         const oldData = JSON.parse(JSON.stringify(newData));
354 |         // Delete the current node from parent node's "children" and "childrenCharacter" property.
355 |         parent.childrenCharacter[str[depth - 1]] = false;
356 |         charIndex = 0;
357 |         for (let i = 0; i < parent.children.length; i++) {
358 |           if (parent.children[i].value == str[depth - 1]) {
359 |             charIndex = i;
360 |           }
361 |         }
362 |         parent.children.splice(charIndex, 1);
363 |         update(oldData, newData, -1, -1);
364 |       }
365 |       return true;
366 |     } else {
367 |       alert('Word not found in trie');
368 |       return false;
369 |     }
370 |   };
371 |
372 |   let node = newData;
373 |   let parent = null;
374 |   await deleteNode(parent, node, str, 0);
375 |
376 |   unfreezeButtons();
377 | };
378 |
379 | document.getElementById('InsertButton').addEventListener('click', addNode);
380 | document.getElementById('DeleteButton').addEventListener('click', deleteNodeUtil);
381 |
382 | // If during writing in insertion or deletion input field, user presses enter key then click on insertion/deletion button.
383 | document.getElementById('InsertNodeField').addEventListener('keyup', function (event) {
384 |   if (event.key === 'Enter') {
385 |     document.getElementById('InsertButton').click();
386 |   }
387 | });
388 | document.getElementById('DeleteNodeField').addEventListener('keyup', function (event) {
389 |   if (event.key === 'Enter') {
390 |     document.getElementById('DeleteButton').click();
391 |   }
392 | });
393 |


--------------------------------------------------------------------------------
/algos/trie/styles.css:
--------------------------------------------------------------------------------
  1 | @import url('https://fonts.googleapis.com/css2?family=Poppins:wght@400;500;600;700&display=swap');
  2 |
  3 |
  4 | * {
  5 |   padding: 0;
  6 |   margin: 0;
  7 |   box-sizing: border-box;
  8 | }
  9 |
 10 | body {
 11 |   background: #212833 ;
 12 |   box-shadow: inset 0 70px 80px rgb(0 0 0 / 21%);
 13 |   font-family: 'Poppins', sans-serif;
 14 | }
 15 |
 16 | /* =============  Scrollbar  ============= */
 17 | ::-webkit-scrollbar {
 18 |   width: 4px;
 19 | }
 20 | ::-webkit-scrollbar-track {
 21 |   background: #000;
 22 | }
 23 | ::-webkit-scrollbar-thumb {
 24 |   background: white;
 25 | }
 26 |
 27 |
 28 | .container {
 29 |   display: flex;
 30 |   flex-direction: column;
 31 |   justify-content: center;
 32 |   align-items: center;
 33 |   display: flex;
 34 |
 35 | }
 36 | #header {
 37 |   width: 1400px;
 38 |   margin-top: 1rem;
 39 |
 40 |   box-shadow: 10px 10px 30px rgba(0, 0, 0, 0.363);
 41 |   border-radius: 10px;
 42 |   background-color: rgba(255, 255, 255, 0.1);
 43 |   overflow: hidden;
 44 |   display: flex;
 45 |   flex-direction: row;
 46 |   justify-content: center;
 47 |   border-top: 1px solid rgba(255, 255, 255, 0.4);
 48 |   border-left: 1px solid rgba(255, 255, 255, 0.4);
 49 |   font-family: 'Poppins', sans-serif;
 50 |   backdrop-filter: blur(8px);
 51 | }
 52 | #header a {
 53 |   text-decoration: none;
 54 |
 55 | }
 56 | #title {
 57 |   text-align: center;
 58 |   font-size: 2rem;
 59 |   /* color: rgb(90, 0, 90) ; */
 60 |   color: rgb(244, 244, 244);
 61 |   padding: 1rem 0;
 62 |   font-weight: bold;
 63 | }
 64 |
 65 | .container {
 66 |   display: flex;
 67 |   flex-flow: column;
 68 |   height: 100%;
 69 | }
 70 | #OperationContainer {
 71 |   position: absolute;
 72 |   top: 25px;
 73 |   left: 20px;
 74 |   display: flex;
 75 |   align-items: center;
 76 | }
 77 | #OperationContainer button {
 78 |   background: #161824;
 79 |   margin-left: 0.5rem;
 80 |   outline: none;
 81 |   border: none;
 82 |   padding: 0.4rem 1rem;
 83 |   color: #fff;
 84 |   border-radius: 2px;
 85 | }
 86 | #OperationContainer button:hover {
 87 |   cursor: pointer;
 88 | }
 89 | #OperationContainer input {
 90 |   padding-left: 0.4rem !important;
 91 |   padding: 0.3rem 0;
 92 |   border-radius: 2px;
 93 |   outline: none;
 94 |   border: 1px solid transparent;
 95 | }
 96 | #OperationContainer input:focus {
 97 |   border: 1px solid rgb(183, 0, 255);
 98 | }
 99 |
100 |
101 | #InsertNodeField,
102 | #DeleteNodeField {
103 |   width: 110px;
104 | }
105 | #DeleteNodeField {
106 |   margin-left: 10px;
107 | }
108 |
109 | .Canvas {
110 |   width: 100%;
111 |   height: 100vh;
112 |   flex: 1 1 auto;
113 |   /* background-color: #212833; */
114 |   overflow: hidden;
115 |   margin-left: auto;
116 |   margin-right: auto;
117 |   position: relative;
118 | }
119 |
120 |
121 |
122 |
123 |
124 | .indicator_container {
125 |   display: flex;
126 |   align-items: center;
127 |   justify-content: center;
128 |   background-color: cornflowerblue;
129 |   padding: 0.5rem 1rem ;
130 |   font-size: 0.9rem;
131 |   gap: 2rem;
132 |   width: 800px;
133 | }
134 |
135 | .indicator  {
136 |   display: flex;
137 |   align-items: center;
138 | }
139 | .indicator_block {
140 |   margin-right: 0.3rem;
141 | }
142 | .indicator  #edge{
143 |   height: 0.2rem;
144 |   width: 2.5rem;
145 |   background-color: #099691;
146 |   box-shadow: 0 0 1px #333;
147 | }
148 |
149 | .indicator  #node, .indicator #end_node{
150 |   height: 1.5rem;
151 |   width: 1.5rem;
152 |   border-radius: 50%;
153 |   border: 1px solid red;
154 | }
155 | .indicator  #node {
156 |   background-color: #fff;
157 |
158 | }
159 | .indicator #end_node {
160 |   background-color: #00911d;
161 |
162 | }
163 |
164 |
165 |
166 |
167 |
168 |
169 |
170 |
171 |
172 | .indicator text {
173 |   font-size: 20px !important;
174 | }
175 |
176 | svg {
177 |   margin-top: 5px;
178 |   width: 100%;
179 |   /* max-width: 1200px; */
180 |   height: 100%;
181 |   overflow: scroll;
182 | }
183 |
184 | .node circle {
185 |   fill: #ffffff;
186 |   stroke: #ff7d12;
187 |   stroke-width: 1px;
188 | }
189 | .node text {
190 |   font-size: 22px;
191 |   fill: rgb(250, 7, 7);
192 | }
193 |
194 | .endOfWordNode circle {
195 |   fill: #00911d;
196 |   stroke: #ffffff;
197 |   stroke-width: 1px;
198 | }
199 | .endOfWordNode text {
200 |   font-size: 23px;
201 |   fill: #ffffff;
202 | }
203 |
204 | .highlightedNode circle {
205 |   fill: red;
206 |   stroke: red;
207 |   stroke-width: 2px;
208 | }
209 | .highlightedNode text {
210 |   font-size: 23px;
211 |   fill: white;
212 | }
213 |
214 | line {
215 |   stroke: #099b96;
216 | }
217 |
218 | .null-node,
219 | .null-link {
220 |   visibility: hidden;
221 | }
222 | text {
223 |   fill: #ffffff;
224 | }
225 |


--------------------------------------------------------------------------------
/assets/banner.webp:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/banner.webp


--------------------------------------------------------------------------------
/assets/bst.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/bst.jpg


--------------------------------------------------------------------------------
/assets/grid.png:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/grid.png


--------------------------------------------------------------------------------
/assets/home-page.jpeg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/home-page.jpeg


--------------------------------------------------------------------------------
/assets/path-preview.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/path-preview.jpg


--------------------------------------------------------------------------------
/assets/path.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/path.jpg


--------------------------------------------------------------------------------
/assets/preview2.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/preview2.jpg


--------------------------------------------------------------------------------
/assets/sorting-preview.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/sorting-preview.jpg


--------------------------------------------------------------------------------
/assets/sorting.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/sorting.jpg


--------------------------------------------------------------------------------
/assets/trie-preview.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/trie-preview.jpg


--------------------------------------------------------------------------------
/assets/trie.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/Sayan-Maity/Algorithm-Visualizer/7cf61e878afc42c273579d2b8f2a0a192c480b5f/assets/trie.jpg


--------------------------------------------------------------------------------
/css/styles.css:
--------------------------------------------------------------------------------
  1 | @import url('https://fonts.googleapis.com/css2?family=Poppins:wght@400;500;600;700&display=swap');
  2 |
  3 |
  4 | * {
  5 |   padding: 0;
  6 |   margin: 0;
  7 |   box-sizing: border-box;
  8 | }
  9 |
 10 | body {
 11 |   background: url("../assets/grid.png") #2b3443 ;
 12 |   background-position: center;
 13 |   background-repeat: no-repeat;
 14 |   box-shadow: inset 0 70px 80px rgb(0 0 0 / 21%);
 15 | }
 16 |
 17 | /* =============  Scrollbar  ============= */
 18 | ::-webkit-scrollbar {
 19 |   width: 4px;
 20 | }
 21 | ::-webkit-scrollbar-track {
 22 |   background: #000;
 23 | }
 24 | ::-webkit-scrollbar-thumb {
 25 |   background: white;
 26 | }
 27 |
 28 |
 29 |
 30 | #main {
 31 |   display: flex;
 32 |   flex-direction: column;
 33 |   justify-content: center;
 34 |   align-items: center;
 35 |   display: flex;
 36 | }
 37 |
 38 | #header {
 39 |   width: 1400px;
 40 |   margin-top: 1rem;
 41 |
 42 |   box-shadow: 10px 10px 30px rgba(0, 0, 0, 0.363);
 43 |   border-radius: 10px;
 44 |   background-color: rgba(255, 255, 255, 0.1);
 45 |   overflow: hidden;
 46 |   display: flex;
 47 |   justify-content: center;
 48 |   border-top: 1px solid rgba(255, 255, 255, 0.4);
 49 |   border-left: 1px solid rgba(255, 255, 255, 0.4);
 50 |   font-family: 'Poppins', sans-serif;
 51 |   backdrop-filter: blur(8px);
 52 | }
 53 | #header a {
 54 |   text-decoration: none;
 55 |
 56 | }
 57 | #title {
 58 |   text-align: center;
 59 |   font-size: 2rem;
 60 |   /* color: rgb(90, 0, 90) ; */
 61 |   color: rgb(244, 244, 244);
 62 |   padding: 1rem 0;
 63 |   font-weight: bold;
 64 | }
 65 |
 66 | #container {
 67 |   display: flex;
 68 |   width: 1000px;
 69 |   display: flex;
 70 |   flex-wrap: wrap;
 71 |   justify-content: center;
 72 |   text-align: center;
 73 | }
 74 |
 75 | .algo-container {
 76 |   width: 25rem;
 77 |   padding: 1rem;
 78 |   margin: 1rem;
 79 |   box-shadow: 10px 10px 30px rgba(0, 0, 0, 0.363);
 80 |   border-radius: 10px;
 81 |   background-color: rgba(255, 255, 255, 0.1);
 82 |   overflow: hidden;
 83 |   display: flex;
 84 |   justify-content: center;
 85 |   border-top: 1px solid rgba(255, 255, 255, 0.5);
 86 |   border-left: 1px solid rgba(255, 255, 255, 0.5);
 87 |   font-family: 'Poppins', sans-serif;
 88 |   backdrop-filter: blur(5px);
 89 | }
 90 |
 91 | /* .imageContainer:hover img{
 92 |   scale: calc(105%);
 93 |   transition: all 0.3s ease-in-out;
 94 | } */
 95 |
 96 | .image {
 97 |   width: 100%;
 98 |   height: 13rem !important;
 99 |   border-radius: 5px;
100 | }
101 |
102 |
103 | .algo-container a {
104 |   text-decoration: none;
105 |   color: #dcebff;
106 |   font-size: 20px;
107 |   margin: 0;
108 | }
109 | .algo-container a .description {
110 |   box-shadow: 20px 20px 20px rgba(0, 0, 0, 0.065);
111 |   border-radius: 5px;
112 |   background-color: rgba(255, 255, 255, 0.062);
113 |   border-top: 1px solid rgba(255, 255, 255, 0.3);
114 |   border-left: 1px solid rgba(255, 255, 255, 0.3);
115 |   font-family: 'Poppins', sans-serif;
116 |   backdrop-filter: blur(5px);
117 |
118 |   padding: 1rem;
119 | }
120 | .algo-container a .description p:nth-child(1) {
121 |   margin-bottom: 0.2rem;
122 |   font-size: 1.1rem;
123 | }
124 | .algo-container a .description p:nth-child(2) {
125 |   font-size: 0.8rem;
126 | }
127 |
128 | @media (max-width: 1050px) {
129 |   #container {
130 |     width: 100%;
131 |   }
132 | }
133 | @media (max-width: 1400px) {
134 |   #header {
135 |     width: 95%;
136 |   }
137 |
138 | }
139 |
140 |
141 |


--------------------------------------------------------------------------------
/index.html:
--------------------------------------------------------------------------------
 1 | <!DOCTYPE html>
 2 | <html lang="en">
 3 | <head>
 4 |   <meta charset="UTF-8">
 5 |   <meta http-equiv="X-UA-Compatible" content="IE=edge">
 6 |   <meta name="viewport" content="width=device-width, initial-scale=1.0">
 7 |   <link rel="stylesheet" href="css/styles.css" />
 8 |
 9 |   <title>Algorithm Visualizer</title>
10 | </head>
11 | <body>
12 |   <div id="main">
13 |     <div id="header">
14 |       <a href="/index.html"><div id="title">Algorithm Visualizer</div></a>
15 |     </div>
16 |     <div id="container">
17 |       <div class="algo-container">
18 |         <a href="algos/trie/index.html" class="category_link" target="_blank">
19 |           <div class="imageContainer">
20 |             <img src="assets/trie.jpg" class="image" />
21 |           </div>
22 |           <div class="description">
23 |             <p>Trie</p>
24 |             <p>Trie is a type of k-ary search tree used for storing and searching a specific key from a set. Using Trie, search complexities can be brought to optimal limit (key length). </p>
25 |           </div>
26 |         </a>
27 |       </div>
28 |       <div class="algo-container">
29 |         <a href="algos/bst/index.html" class="category_link" target="_blank">
30 |           <div class="imageContainer">
31 |             <img src="assets/bst.jpg" class="image" />
32 |           </div>
33 |           <div class="description">
34 |             <p>Binary Search Tree</p>
35 |             <p>A binary search tree follows some order to arrange the elements like the value of left node must be smaller than the parent node, and the value of right node must be greater than the parent node.
36 |           </div>
37 |         </a>
38 |       </div>
39 |       <div class="algo-container">
40 |         <a href="algos/path_finding/index.html" class="category_link" target="_blank">
41 |           <div class="imageContainer">
42 |             <img src="assets/path.jpg" class="image" />
43 |           </div>
44 |           <div class="description">
45 |             <p>Path Finding Algorithms</p>
46 |             <p>Pathfinding algorithms are usually an attempt to solve the shortest and efficient path problems in graph theory. They try to find the best path given a starting point and ending point based on some predefined criteria.
47 |               </p>
48 |           </div>
49 |         </a>
50 |       </div>
51 |       <div class="algo-container">
52 |         <a href="algos/sorting/index.html" class="category_link" target="_blank">
53 |           <div class="imageContainer">
54 |             <img src="assets/sorting.jpg" class="image" />
55 |           </div>
56 |           <div class="description">
57 |             <p>Sorting Algorithms</p>
58 |             <p>Sorting is a process of ordering or placing a list of elements from a collection in some kind of order. It is nothing but storage of data in sorted order. It arranges the data in ascending and descending order which makes searching easier.</p>
59 |           </div>
60 |         </a>
61 |       </div>
62 |     </div>
63 |   </div>
64 | </body>
65 | </html>
66 |
67 |
68 |
69 |
70 |


--------------------------------------------------------------------------------
