├── Images ├── Step0.png ├── Step1.png ├── Step2.png ├── Step3.png ├── Step4.png ├── Step5.png ├── Step6.png └── Step7.png ├── .gitignore ├── Sources └── Parallel Driver │ └── Multiplexing │ ├── Examples │ └── 4Digit_CC_Delay │ │ ├── Simulation.pdsprj │ │ ├── src │ │ ├── main.c │ │ └── Seg7.c │ │ ├── .vscode │ │ └── extensions.json │ │ ├── test │ │ └── README │ │ ├── platformio.ini │ │ ├── lib │ │ └── README │ │ └── include │ │ ├── README │ │ ├── aKaReZa.h │ │ └── Seg7.h │ ├── Seg7.h │ └── Seg7.c ├── Multiplexing4Digit.md ├── Basics.md ├── API_Reference.md ├── README.md └── LICENSE /Images/Step0.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/aKaReZa75/AVR_7Segments_GPIO/HEAD/Images/Step0.png -------------------------------------------------------------------------------- /Images/Step1.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/aKaReZa75/AVR_7Segments_GPIO/HEAD/Images/Step1.png -------------------------------------------------------------------------------- /Images/Step2.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/aKaReZa75/AVR_7Segments_GPIO/HEAD/Images/Step2.png -------------------------------------------------------------------------------- /Images/Step3.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/aKaReZa75/AVR_7Segments_GPIO/HEAD/Images/Step3.png -------------------------------------------------------------------------------- /Images/Step4.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/aKaReZa75/AVR_7Segments_GPIO/HEAD/Images/Step4.png -------------------------------------------------------------------------------- /Images/Step5.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/aKaReZa75/AVR_7Segments_GPIO/HEAD/Images/Step5.png -------------------------------------------------------------------------------- /Images/Step6.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/aKaReZa75/AVR_7Segments_GPIO/HEAD/Images/Step6.png -------------------------------------------------------------------------------- /Images/Step7.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/aKaReZa75/AVR_7Segments_GPIO/HEAD/Images/Step7.png -------------------------------------------------------------------------------- /.gitignore: -------------------------------------------------------------------------------- 1 | **/.pio 2 | **/.vscode/.browse.c_cpp.db* 3 | **/.vscode/c_cpp_properties.json 4 | **/.vscode/launch.json 5 | **/.vscode/ipch 6 | **/*.workspace 7 | **/Project Backups -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/Simulation.pdsprj: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/aKaReZa75/AVR_7Segments_GPIO/HEAD/Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/Simulation.pdsprj -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/src/main.c: -------------------------------------------------------------------------------- 1 | #include "aKaReZa.h" 2 | 3 | uint32_t Counter = 0; 4 | 5 | int main(void) 6 | { 7 | Seg7_init(); 8 | while(1) 9 | { 10 | //Counter++; 11 | //Seg7_Puti((uint16_t) (Counter/1000)); 12 | Seg7_Puti(1234); 13 | delay_ms(1); 14 | }; 15 | }; -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/.vscode/extensions.json: -------------------------------------------------------------------------------- 1 | { 2 | // See http://go.microsoft.com/fwlink/?LinkId=827846 3 | // for the documentation about the extensions.json format 4 | "recommendations": [ 5 | "platformio.platformio-ide" 6 | ], 7 | "unwantedRecommendations": [ 8 | "ms-vscode.cpptools-extension-pack" 9 | ] 10 | } 11 | -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/test/README: -------------------------------------------------------------------------------- 1 | 2 | This directory is intended for PlatformIO Test Runner and project tests. 3 | 4 | Unit Testing is a software testing method by which individual units of 5 | source code, sets of one or more MCU program modules together with associated 6 | control data, usage procedures, and operating procedures, are tested to 7 | determine whether they are fit for use. Unit testing finds problems early 8 | in the development cycle. 9 | 10 | More information about PlatformIO Unit Testing: 11 | - https://docs.platformio.org/en/latest/advanced/unit-testing/index.html 12 | -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/platformio.ini: -------------------------------------------------------------------------------- 1 | ; PlatformIO Project Configuration File 2 | ; 3 | ; Build options: build flags, source filter 4 | ; Upload options: custom upload port, speed and extra flags 5 | ; Library options: dependencies, extra library storages 6 | ; Advanced options: extra scripting 7 | ; 8 | ; Please visit documentation for the other options and examples 9 | ; https://docs.platformio.org/page/projectconf.html 10 | 11 | [env:ATmega328P] 12 | platform = atmelavr 13 | board = ATmega328P 14 | framework = arduino 15 | board_build.f_cpu = 16000000UL 16 | upload_port = COM4 17 | monitor_speed = 115200 18 | build_flags = -Wl,-u,vfprintf -lprintf_flt -lm -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/lib/README: -------------------------------------------------------------------------------- 1 | 2 | This directory is intended for project specific (private) libraries. 3 | PlatformIO will compile them to static libraries and link into executable file. 4 | 5 | The source code of each library should be placed in an own separate directory 6 | ("lib/your_library_name/[here are source files]"). 7 | 8 | For example, see a structure of the following two libraries `Foo` and `Bar`: 9 | 10 | |--lib 11 | | | 12 | | |--Bar 13 | | | |--docs 14 | | | |--examples 15 | | | |--src 16 | | | |- Bar.c 17 | | | |- Bar.h 18 | | | |- library.json (optional, custom build options, etc) https://docs.platformio.org/page/librarymanager/config.html 19 | | | 20 | | |--Foo 21 | | | |- Foo.c 22 | | | |- Foo.h 23 | | | 24 | | |- README --> THIS FILE 25 | | 26 | |- platformio.ini 27 | |--src 28 | |- main.c 29 | 30 | and a contents of `src/main.c`: 31 | ``` 32 | #include 33 | #include 34 | 35 | int main (void) 36 | { 37 | ... 38 | } 39 | 40 | ``` 41 | 42 | PlatformIO Library Dependency Finder will find automatically dependent 43 | libraries scanning project source files. 44 | 45 | More information about PlatformIO Library Dependency Finder 46 | - https://docs.platformio.org/page/librarymanager/ldf.html 47 | -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/include/README: -------------------------------------------------------------------------------- 1 | 2 | This directory is intended for project header files. 3 | 4 | A header file is a file containing C declarations and macro definitions 5 | to be shared between several project source files. You request the use of a 6 | header file in your project source file (C, C++, etc) located in `src` folder 7 | by including it, with the C preprocessing directive `#include'. 8 | 9 | ```src/main.c 10 | 11 | #include "header.h" 12 | 13 | int main (void) 14 | { 15 | ... 16 | } 17 | ``` 18 | 19 | Including a header file produces the same results as copying the header file 20 | into each source file that needs it. Such copying would be time-consuming 21 | and error-prone. With a header file, the related declarations appear 22 | in only one place. If they need to be changed, they can be changed in one 23 | place, and programs that include the header file will automatically use the 24 | new version when next recompiled. The header file eliminates the labor of 25 | finding and changing all the copies as well as the risk that a failure to 26 | find one copy will result in inconsistencies within a program. 27 | 28 | In C, the usual convention is to give header files names that end with `.h'. 29 | It is most portable to use only letters, digits, dashes, and underscores in 30 | header file names, and at most one dot. 31 | 32 | Read more about using header files in official GCC documentation: 33 | 34 | * Include Syntax 35 | * Include Operation 36 | * Once-Only Headers 37 | * Computed Includes 38 | 39 | https://gcc.gnu.org/onlinedocs/cpp/Header-Files.html 40 | -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/include/aKaReZa.h: -------------------------------------------------------------------------------- 1 | /** 2 | * @file aKaReZa.h 3 | * @brief Header file for AVR microcontrollers. 4 | * @note This file is designed for use with AVR microcontrollers. 5 | * 6 | * @author Hossein Bagheri 7 | * @github https://github.com/aKaReZa75 8 | * 9 | * @note For a complete list of all macros in this header file, 10 | * along with detailed explanations and examples of usage, visit: 11 | * https://github.com/aKaReZa75/AVR/blob/main/Macros.md 12 | */ 13 | 14 | #ifndef _aKaReZa_H_ 15 | #define _aKaReZa_H_ 16 | 17 | #include 18 | #include 19 | #include 20 | #include 21 | #include 22 | #include 23 | #include "Seg7.h" 24 | 25 | #define bitSet(_Reg, _Bit) (_Reg |= (1<<_Bit)) 26 | #define bitClear(_Reg, _Bit) (_Reg &= ~(1<<_Bit)) 27 | #define bitToggle(_Reg, _Bit) (_Reg ^= 1<<_Bit) 28 | #define bitChange(_Reg, _Bit, Value) (Value == 1 ? bitSet(_Reg, _Bit) : bitClear(_Reg, _Bit)) 29 | #define bitCheck(_Reg, _Bit) ((_Reg>>_Bit) & 0x01) 30 | #define bitCheckHigh(_Reg, _Bit) (bitCheck(_Reg, _Bit)) 31 | #define bitCheckLow(_Reg, _Bit) (!bitCheck(_Reg, _Bit)) 32 | #define bitWaitHigh(_Reg, _Bit) while(bitCheckLow(_Reg, _Bit)) 33 | #define bitWaitLow(_Reg, _Bit) while(bitCheckHigh(_Reg, _Bit)) 34 | #define bitShiftLeft(_Reg, _Pos) (_Reg = _Reg << _Pos) 35 | #define bitShiftRight(_Reg, _Pos) (_Reg = _Reg >> _Pos) 36 | #define Conv_16to8_MSB(_Value) (uint8_t) (_Value >> 8) 37 | #define Conv_16to8_LSB(_Value) (uint8_t) (_Value & 0xFF) 38 | #define Combine_8to16(_valueHigh, _valueLow) (uint16_t) (_valueLow + (_valueHigh<<8)) 39 | 40 | #define GPIO_Config_OUTPUT(_Reg, _Bit) bitSet(_Reg, _Bit) 41 | #define GPIO_Config_INPUT(_Reg, _Bit) bitClear(_Reg, _Bit) 42 | #define delay_ms(_delay_msValue) _delay_ms(_delay_msValue) 43 | #define globalInt_Enable bitSet (SREG, SREG_I) 44 | #define globalInt_Disable bitClear(SREG, SREG_I) 45 | #define intFlag_clear(Reg, Bit) bitSet(Reg, Bit) 46 | #define Initialize true 47 | #define deInitialize false 48 | 49 | #define Math_Const_PI 3.14159265358979 50 | #define MATH_Const_EXP 2.71828182845904 51 | 52 | #endif 53 | -------------------------------------------------------------------------------- /Multiplexing4Digit.md: -------------------------------------------------------------------------------- 1 | ## Multiplexing with 4-Digit 7-Segment Display 2 | 3 | When working with multiple 7-segment displays (e.g., a 4-digit display), the microcontroller typically uses a technique called **multiplexing** to manage the display of each digit. Multiplexing allows you to control several digits with fewer pins by switching between the digits rapidly in a way that makes it appear as though all digits are displayed simultaneously. 4 | 5 | ``` 6 | 4 3 2 1 7 | ----- ----- ----- ----- 8 | | | | | | | | | 9 | ----- ----- ----- ----- 10 | | | | | | | | | 11 | ----- ----- ----- ----- 12 | ``` 13 | 14 | ### How Multiplexing Works: 15 | In multiplexing, the microcontroller switches between digits one by one, activating only one digit at a time while keeping the others turned off. Each digit is displayed for a short period, and the cycle repeats for the next digit. The human eye perceives this rapid switching as continuous display of all digits. 16 | 17 | - **Each digit** of the 7-segment display has its own common pin (e.g., the common cathode or common anode), and these common pins are controlled to switch between digits. 18 | - **For example**, for a 4-digit display, you have four common pins, each connected to one of the 7-segment displays. The segments of the display are connected to GPIO pins of the microcontroller, and only one digit is activated at a time. 19 | 20 | #### How Digits are Displayed: 21 | 1. The microcontroller lights up the first digit (e.g., the first 7-segment display). 22 | 2. The corresponding segments are activated to show the number. 23 | 3. The microcontroller turns off the first digit and turns on the second digit. 24 | 4. The same process repeats for the third and fourth digits. 25 | 5. The cycle continues at a fast enough rate that it seems like all digits are being displayed at once. 26 | 27 | This process is done so quickly (at a high refresh rate) that the human eye perceives a smooth, continuous display of all four digits. 28 | 29 | ### Refresh Rate for Multiplexing: 30 | To avoid flickering or noticeable gaps in the display, the microcontroller needs to switch between digits at a rate that is fast enough for the human eye to not notice the switching. The general rule of thumb is to refresh the display **at least 50 Hz**, which means the display should be updated 50 times per second. 31 | 32 | - For **4 digits**, this means that each digit should be displayed for approximately 1/4th of the total refresh cycle. 33 | - The **total refresh rate** for all four digits is typically set at **50 Hz** or higher. This implies that each digit should be refreshed approximately every **5 ms** (milliseconds). 34 | 35 | Thus, for a 50 Hz refresh rate: 36 | - Each digit should be displayed for around **5 ms** before switching to the next digit. 37 | 38 | If you want to achieve a smoother display with no visible flickering, it's ideal to aim for a refresh rate of **100 Hz or higher**. This means each digit would be refreshed every **2.5 ms**. 39 | 40 | #### Example Calculation: 41 | - If you're targeting a **refresh rate of 100 Hz**, the total time to refresh all four digits would be 10 ms (since 1 / 100 Hz = 10 ms). 42 | - For each digit to be displayed in this 10 ms cycle, each digit should be refreshed for approximately **2.5 ms** (since 10 ms ÷ 4 digits = 2.5 ms per digit). 43 | 44 | # 🌟 Support Me 45 | If you found this repository useful: 46 | - Subscribe to my [YouTube Channel](https://www.youtube.com/@aKaReZa75). 47 | - Share this repository with others. 48 | - Give this repository and my other repositories a star. 49 | - Follow my [GitHub account](https://github.com/aKaReZa75). 50 | 51 | # ✉️ Contact Me 52 | Feel free to reach out to me through any of the following platforms: 53 | - 📧 [Email: aKaReZa75@gmail.com](mailto:aKaReZa75@gmail.com) 54 | - 🎥 [YouTube: @aKaReZa75](https://www.youtube.com/@aKaReZa75) 55 | - 💼 [LinkedIn: @akareza75](https://www.linkedin.com/in/akareza75) 56 | -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Seg7.h: -------------------------------------------------------------------------------- 1 | /** 2 | * @file Seg7.c 3 | * @brief 7-segment display control library for AVR microcontrollers 4 | * @note This file provides functionality to control a 4-digit 7-segment display 5 | * using multiplexing for AVR microcontrollers. 6 | * 7 | * @author Your Name 8 | * @github Your GitHub Link 9 | * 10 | * @note For detailed explanations of this library, along with additional notes and examples of usage, 11 | * please visit the following repository: 12 | * https://github.com/aKaReZa75/AVR_7Segments 13 | */ 14 | #ifndef _Seg7_H_ 15 | #define _Seg7_H_ 16 | 17 | #include "aKaReZa.h" 18 | 19 | /** 20 | * @brief Control and configuration macros for 7-segment display segments (A to G). 21 | * 22 | * These macros define the control ports, configuration ports, and pins for each segment of the 7-segment display. 23 | */ 24 | 25 | /* Define control and configuration for segment A */ 26 | #define __7Seg_A_Control PORTC /**< Control port for segment A */ 27 | #define __7Seg_A_Config DDRC /**< Data direction register for segment A */ 28 | #define __7Seg_A_Pin 0 /**< Pin number for segment A */ 29 | 30 | /* Define control and configuration for segment B */ 31 | #define __7Seg_B_Control PORTC /**< Control port for segment B */ 32 | #define __7Seg_B_Config DDRC /**< Data direction register for segment B */ 33 | #define __7Seg_B_Pin 1 /**< Pin number for segment B */ 34 | 35 | /* Define control and configuration for segment C */ 36 | #define __7Seg_C_Control PORTC /**< Control port for segment C */ 37 | #define __7Seg_C_Config DDRC /**< Data direction register for segment C */ 38 | #define __7Seg_C_Pin 2 /**< Pin number for segment C */ 39 | 40 | /* Define control and configuration for segment D */ 41 | #define __7Seg_D_Control PORTC /**< Control port for segment D */ 42 | #define __7Seg_D_Config DDRC /**< Data direction register for segment D */ 43 | #define __7Seg_D_Pin 3 /**< Pin number for segment D */ 44 | 45 | /* Define control and configuration for segment E */ 46 | #define __7Seg_E_Control PORTD /**< Control port for segment E */ 47 | #define __7Seg_E_Config DDRD /**< Data direction register for segment E */ 48 | #define __7Seg_E_Pin 0 /**< Pin number for segment E */ 49 | 50 | /* Define control and configuration for segment F */ 51 | #define __7Seg_F_Control PORTD /**< Control port for segment F */ 52 | #define __7Seg_F_Config DDRD /**< Data direction register for segment F */ 53 | #define __7Seg_F_Pin 1 /**< Pin number for segment F */ 54 | 55 | /* Define control and configuration for segment G */ 56 | #define __7Seg_G_Control PORTD /**< Control port for segment G */ 57 | #define __7Seg_G_Config DDRD /**< Data direction register for segment G */ 58 | #define __7Seg_G_Pin 4 /**< Pin number for segment G */ 59 | 60 | /* Define control and configuration for decimal point (DP) */ 61 | #define __7Seg_DP_Control PORTD /**< Control port for the decimal point (DP) */ 62 | #define __7Seg_DP_Config DDRD /**< Data direction register for DP */ 63 | #define __7Seg_DP_Pin 7 /**< Pin number for the decimal point (DP) */ 64 | 65 | /* Define control and configuration for each digit */ 66 | #define __7Seg_Digit1_Control PORTB /**< Control port for Digit 1 */ 67 | #define __7Seg_Digit1_Config DDRB /**< Data direction register for Digit 1 */ 68 | #define __7Seg_Digit1_Pin 0 /**< Pin number for Digit 1 */ 69 | 70 | #define __7Seg_Digit2_Control PORTB /**< Control port for Digit 2 */ 71 | #define __7Seg_Digit2_Config DDRB /**< Data direction register for Digit 2 */ 72 | #define __7Seg_Digit2_Pin 1 /**< Pin number for Digit 2 */ 73 | 74 | #define __7Seg_Digit3_Control PORTB /**< Control port for Digit 3 */ 75 | #define __7Seg_Digit3_Config DDRB /**< Data direction register for Digit 3 */ 76 | #define __7Seg_Digit3_Pin 2 /**< Pin number for Digit 3 */ 77 | 78 | #define __7Seg_Digit4_Control PORTB /**< Control port for Digit 4 */ 79 | #define __7Seg_Digit4_Config DDRB /**< Data direction register for Digit 4 */ 80 | #define __7Seg_Digit4_Pin 4 /**< Pin number for Digit 4 */ 81 | 82 | /** 83 | * @brief Initializes the 7-segment display. 84 | * 85 | * This function configures the appropriate ports and pins for controlling the 7-segment display. 86 | * It sets the direction for each pin (input/output) and initializes the display for use. 87 | */ 88 | void Seg7_init(void); 89 | 90 | /** 91 | * @brief Displays a number on the 7-segment display. 92 | * 93 | * This function takes a 4-digit value (0-9999) and displays it on the 7-segment display using multiplexing. 94 | * It will handle sequentially displaying each digit with appropriate timing. 95 | * 96 | * @param _7SegValue The 4-digit number to be displayed on the 7-segment display. 97 | */ 98 | void Seg7_Puti(uint16_t _7SegValue); 99 | 100 | #endif 101 | -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/include/Seg7.h: -------------------------------------------------------------------------------- 1 | /** 2 | * @file Seg7.c 3 | * @brief 7-segment display control library for AVR microcontrollers 4 | * @note This file provides functionality to control a 4-digit 7-segment display 5 | * using multiplexing for AVR microcontrollers. 6 | * 7 | * @author Your Name 8 | * @github Your GitHub Link 9 | * 10 | * @note For detailed explanations of this library, along with additional notes and examples of usage, 11 | * please visit the following repository: 12 | * https://github.com/aKaReZa75/AVR_7Segments 13 | */ 14 | #ifndef _Seg7_H_ 15 | #define _Seg7_H_ 16 | 17 | #include "aKaReZa.h" 18 | 19 | /** 20 | * @brief Control and configuration macros for 7-segment display segments (A to G). 21 | * 22 | * These macros define the control ports, configuration ports, and pins for each segment of the 7-segment display. 23 | */ 24 | 25 | /* Define control and configuration for segment A */ 26 | #define __7Seg_A_Control PORTC /**< Control port for segment A */ 27 | #define __7Seg_A_Config DDRC /**< Data direction register for segment A */ 28 | #define __7Seg_A_Pin 0 /**< Pin number for segment A */ 29 | 30 | /* Define control and configuration for segment B */ 31 | #define __7Seg_B_Control PORTC /**< Control port for segment B */ 32 | #define __7Seg_B_Config DDRC /**< Data direction register for segment B */ 33 | #define __7Seg_B_Pin 1 /**< Pin number for segment B */ 34 | 35 | /* Define control and configuration for segment C */ 36 | #define __7Seg_C_Control PORTC /**< Control port for segment C */ 37 | #define __7Seg_C_Config DDRC /**< Data direction register for segment C */ 38 | #define __7Seg_C_Pin 2 /**< Pin number for segment C */ 39 | 40 | /* Define control and configuration for segment D */ 41 | #define __7Seg_D_Control PORTC /**< Control port for segment D */ 42 | #define __7Seg_D_Config DDRC /**< Data direction register for segment D */ 43 | #define __7Seg_D_Pin 3 /**< Pin number for segment D */ 44 | 45 | /* Define control and configuration for segment E */ 46 | #define __7Seg_E_Control PORTD /**< Control port for segment E */ 47 | #define __7Seg_E_Config DDRD /**< Data direction register for segment E */ 48 | #define __7Seg_E_Pin 0 /**< Pin number for segment E */ 49 | 50 | /* Define control and configuration for segment F */ 51 | #define __7Seg_F_Control PORTD /**< Control port for segment F */ 52 | #define __7Seg_F_Config DDRD /**< Data direction register for segment F */ 53 | #define __7Seg_F_Pin 1 /**< Pin number for segment F */ 54 | 55 | /* Define control and configuration for segment G */ 56 | #define __7Seg_G_Control PORTD /**< Control port for segment G */ 57 | #define __7Seg_G_Config DDRD /**< Data direction register for segment G */ 58 | #define __7Seg_G_Pin 4 /**< Pin number for segment G */ 59 | 60 | /* Define control and configuration for decimal point (DP) */ 61 | #define __7Seg_DP_Control PORTD /**< Control port for the decimal point (DP) */ 62 | #define __7Seg_DP_Config DDRD /**< Data direction register for DP */ 63 | #define __7Seg_DP_Pin 7 /**< Pin number for the decimal point (DP) */ 64 | 65 | /* Define control and configuration for each digit */ 66 | #define __7Seg_Digit1_Control PORTB /**< Control port for Digit 1 */ 67 | #define __7Seg_Digit1_Config DDRB /**< Data direction register for Digit 1 */ 68 | #define __7Seg_Digit1_Pin 0 /**< Pin number for Digit 1 */ 69 | 70 | #define __7Seg_Digit2_Control PORTB /**< Control port for Digit 2 */ 71 | #define __7Seg_Digit2_Config DDRB /**< Data direction register for Digit 2 */ 72 | #define __7Seg_Digit2_Pin 1 /**< Pin number for Digit 2 */ 73 | 74 | #define __7Seg_Digit3_Control PORTB /**< Control port for Digit 3 */ 75 | #define __7Seg_Digit3_Config DDRB /**< Data direction register for Digit 3 */ 76 | #define __7Seg_Digit3_Pin 2 /**< Pin number for Digit 3 */ 77 | 78 | #define __7Seg_Digit4_Control PORTB /**< Control port for Digit 4 */ 79 | #define __7Seg_Digit4_Config DDRB /**< Data direction register for Digit 4 */ 80 | #define __7Seg_Digit4_Pin 4 /**< Pin number for Digit 4 */ 81 | 82 | /** 83 | * @brief Initializes the 7-segment display. 84 | * 85 | * This function configures the appropriate ports and pins for controlling the 7-segment display. 86 | * It sets the direction for each pin (input/output) and initializes the display for use. 87 | */ 88 | void Seg7_init(void); 89 | 90 | /** 91 | * @brief Displays a number on the 7-segment display. 92 | * 93 | * This function takes a 4-digit value (0-9999) and displays it on the 7-segment display using multiplexing. 94 | * It will handle sequentially displaying each digit with appropriate timing. 95 | * 96 | * @param _7SegValue The 4-digit number to be displayed on the 7-segment display. 97 | */ 98 | void Seg7_Puti(uint16_t _7SegValue); 99 | 100 | #endif 101 | -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Seg7.c: -------------------------------------------------------------------------------- 1 | /** 2 | * @file Seg7.c 3 | * @brief 7-segment display control library for AVR microcontrollers 4 | * @note This file provides functionality to control a 4-digit 7-segment display 5 | * using multiplexing for AVR microcontrollers. 6 | * 7 | * @author Your Name 8 | * @github Your GitHub Link 9 | * 10 | * @note For detailed explanations of this library, along with additional notes and examples of usage, 11 | * please visit the following repository: 12 | * https://github.com/aKaReZa75/AVR_7Segments 13 | */ 14 | 15 | #include "Seg7.h" 16 | 17 | /** 18 | * @brief Segment-to-segment mapping for 0-9 using Common Cathode configuration. 19 | * 20 | * This array holds the segment bit pattern for each digit (0-9) for a 7-segment display. 21 | */ 22 | const uint8_t Segments_Data[16] = 23 | { 24 | 0x3F, /**< 0 */ 25 | 0x06, /**< 1 */ 26 | 0x5B, /**< 2 */ 27 | 0x4F, /**< 3 */ 28 | 0x66, /**< 4 */ 29 | 0x6D, /**< 5 */ 30 | 0x7D, /**< 6 */ 31 | 0x07, /**< 7 */ 32 | 0x7F, /**< 8 */ 33 | 0x6F, /**< 9 */ 34 | 0x77, /**< A */ 35 | 0x7C, /**< b */ 36 | 0x39, /**< C */ 37 | 0x5E, /**< d */ 38 | 0x79, /**< E */ 39 | 0x71 /**< F */ 40 | }; 41 | 42 | /** 43 | * @brief Array to store the individual digits for the 4-digit display. 44 | * 45 | * This array holds the values of the individual digits (thousands, hundreds, tens, ones). 46 | */ 47 | uint8_t Segment[4] = {0, 0, 0, 0}; 48 | 49 | 50 | /** 51 | * @brief Initializes the 7-segment display. 52 | * 53 | * This function configures the control and data direction registers for all segments (A-G) 54 | * and digits (1-4) of the 7-segment display. 55 | * It sets each pin as an output to allow control of the display. 56 | */ 57 | void Seg7_init(void) 58 | { 59 | /* Configure all the control and segment pins as outputs */ 60 | GPIO_Config_OUTPUT(__7Seg_A_Config, __7Seg_A_Pin); 61 | GPIO_Config_OUTPUT(__7Seg_B_Config, __7Seg_B_Pin); 62 | GPIO_Config_OUTPUT(__7Seg_C_Config, __7Seg_C_Pin); 63 | GPIO_Config_OUTPUT(__7Seg_D_Config, __7Seg_D_Pin); 64 | GPIO_Config_OUTPUT(__7Seg_E_Config, __7Seg_E_Pin); 65 | GPIO_Config_OUTPUT(__7Seg_F_Config, __7Seg_F_Pin); 66 | GPIO_Config_OUTPUT(__7Seg_G_Config, __7Seg_G_Pin); 67 | GPIO_Config_OUTPUT(__7Seg_DP_Config, __7Seg_DP_Pin); 68 | GPIO_Config_OUTPUT(__7Seg_Digit1_Config, __7Seg_Digit1_Pin); 69 | GPIO_Config_OUTPUT(__7Seg_Digit2_Config, __7Seg_Digit2_Pin); 70 | GPIO_Config_OUTPUT(__7Seg_Digit3_Config, __7Seg_Digit3_Pin); 71 | GPIO_Config_OUTPUT(__7Seg_Digit4_Config, __7Seg_Digit4_Pin); 72 | 73 | /* Set control pins for digits as outputs */ 74 | GPIO_Config_OUTPUT(__7Seg_Digit1_Control, __7Seg_Digit1_Pin); 75 | GPIO_Config_OUTPUT(__7Seg_Digit2_Control, __7Seg_Digit2_Pin); 76 | GPIO_Config_OUTPUT(__7Seg_Digit3_Control, __7Seg_Digit3_Pin); 77 | GPIO_Config_OUTPUT(__7Seg_Digit4_Control, __7Seg_Digit4_Pin); 78 | } 79 | 80 | /** 81 | * @brief Displays a 4-digit number on the 7-segment display using multiplexing. 82 | * 83 | * This function displays a number on the 7-segment display by sequentially activating 84 | * each digit and lighting up the corresponding segments. The function uses multiplexing 85 | * to display all 4 digits in quick succession, creating the illusion that they are 86 | * all being shown at once. 87 | * 88 | * @param _7SegValue The 4-digit value (0-9999) to display on the 7-segment display. 89 | */ 90 | void Seg7_Puti(uint16_t _7SegValue) 91 | { 92 | static uint8_t _Digit = 0; /**< Variable to determine which digit to activate */ 93 | 94 | /* Extract digits (thousands to ones) from the 7-segment value */ 95 | Segment[3] = (_7SegValue % 10); /**< thousands (Digit4) */ 96 | _7SegValue /= 10; 97 | Segment[2] = (_7SegValue % 10); /**< hundreds (Digit3) */ 98 | _7SegValue /= 10; 99 | Segment[1] = (_7SegValue % 10); /**< tens (Digit2) */ 100 | _7SegValue /= 10; 101 | Segment[0] = (_7SegValue % 10); /**< ones (Digit1) */ 102 | 103 | /* Update the segments based on the current digit to display */ 104 | bitChange(__7Seg_A_Control, __7Seg_A_Pin, bitCheck(Segments_Data[Segment[_Digit]], 0)); 105 | bitChange(__7Seg_B_Control, __7Seg_B_Pin, bitCheck(Segments_Data[Segment[_Digit]], 1)); 106 | bitChange(__7Seg_C_Control, __7Seg_C_Pin, bitCheck(Segments_Data[Segment[_Digit]], 2)); 107 | bitChange(__7Seg_D_Control, __7Seg_D_Pin, bitCheck(Segments_Data[Segment[_Digit]], 3)); 108 | bitChange(__7Seg_E_Control, __7Seg_E_Pin, bitCheck(Segments_Data[Segment[_Digit]], 4)); 109 | bitChange(__7Seg_F_Control, __7Seg_F_Pin, bitCheck(Segments_Data[Segment[_Digit]], 5)); 110 | bitChange(__7Seg_G_Control, __7Seg_G_Pin, bitCheck(Segments_Data[Segment[_Digit]], 6)); 111 | 112 | /* Activate the corresponding digit */ 113 | bitChange(__7Seg_Digit1_Control, __7Seg_Digit1_Pin, bitCheck((1<<_Digit), 0)); 114 | bitChange(__7Seg_Digit2_Control, __7Seg_Digit2_Pin, bitCheck((1<<_Digit), 1)); 115 | bitChange(__7Seg_Digit3_Control, __7Seg_Digit3_Pin, bitCheck((1<<_Digit), 2)); 116 | bitChange(__7Seg_Digit4_Control, __7Seg_Digit4_Pin, bitCheck((1<<_Digit), 3)); 117 | 118 | /* Increment the _Digit and reset if necessary */ 119 | _Digit++; 120 | if (_Digit == 4) 121 | { 122 | _Digit = 0; 123 | }; 124 | }; 125 | -------------------------------------------------------------------------------- /Sources/Parallel Driver/Multiplexing/Examples/4Digit_CC_Delay/src/Seg7.c: -------------------------------------------------------------------------------- 1 | /** 2 | * @file Seg7.c 3 | * @brief 7-segment display control library for AVR microcontrollers 4 | * @note This file provides functionality to control a 4-digit 7-segment display 5 | * using multiplexing for AVR microcontrollers. 6 | * 7 | * @author Your Name 8 | * @github Your GitHub Link 9 | * 10 | * @note For detailed explanations of this library, along with additional notes and examples of usage, 11 | * please visit the following repository: 12 | * https://github.com/aKaReZa75/AVR_7Segments 13 | */ 14 | 15 | #include "Seg7.h" 16 | 17 | /** 18 | * @brief Segment-to-segment mapping for 0-9 using Common Cathode configuration. 19 | * 20 | * This array holds the segment bit pattern for each digit (0-9) for a 7-segment display. 21 | */ 22 | const uint8_t Segments_Data[16] = 23 | { 24 | 0x3F, /**< 0 */ 25 | 0x06, /**< 1 */ 26 | 0x5B, /**< 2 */ 27 | 0x4F, /**< 3 */ 28 | 0x66, /**< 4 */ 29 | 0x6D, /**< 5 */ 30 | 0x7D, /**< 6 */ 31 | 0x07, /**< 7 */ 32 | 0x7F, /**< 8 */ 33 | 0x6F, /**< 9 */ 34 | 0x77, /**< A */ 35 | 0x7C, /**< b */ 36 | 0x39, /**< C */ 37 | 0x5E, /**< d */ 38 | 0x79, /**< E */ 39 | 0x71 /**< F */ 40 | }; 41 | 42 | /** 43 | * @brief Array to store the individual digits for the 4-digit display. 44 | * 45 | * This array holds the values of the individual digits (thousands, hundreds, tens, ones). 46 | */ 47 | uint8_t Segment[4] = {0, 0, 0, 0}; 48 | 49 | 50 | /** 51 | * @brief Initializes the 7-segment display. 52 | * 53 | * This function configures the control and data direction registers for all segments (A-G) 54 | * and digits (1-4) of the 7-segment display. 55 | * It sets each pin as an output to allow control of the display. 56 | */ 57 | void Seg7_init(void) 58 | { 59 | /* Configure all the control and segment pins as outputs */ 60 | GPIO_Config_OUTPUT(__7Seg_A_Config, __7Seg_A_Pin); 61 | GPIO_Config_OUTPUT(__7Seg_B_Config, __7Seg_B_Pin); 62 | GPIO_Config_OUTPUT(__7Seg_C_Config, __7Seg_C_Pin); 63 | GPIO_Config_OUTPUT(__7Seg_D_Config, __7Seg_D_Pin); 64 | GPIO_Config_OUTPUT(__7Seg_E_Config, __7Seg_E_Pin); 65 | GPIO_Config_OUTPUT(__7Seg_F_Config, __7Seg_F_Pin); 66 | GPIO_Config_OUTPUT(__7Seg_G_Config, __7Seg_G_Pin); 67 | GPIO_Config_OUTPUT(__7Seg_DP_Config, __7Seg_DP_Pin); 68 | GPIO_Config_OUTPUT(__7Seg_Digit1_Config, __7Seg_Digit1_Pin); 69 | GPIO_Config_OUTPUT(__7Seg_Digit2_Config, __7Seg_Digit2_Pin); 70 | GPIO_Config_OUTPUT(__7Seg_Digit3_Config, __7Seg_Digit3_Pin); 71 | GPIO_Config_OUTPUT(__7Seg_Digit4_Config, __7Seg_Digit4_Pin); 72 | 73 | /* Set control pins for digits as outputs */ 74 | GPIO_Config_OUTPUT(__7Seg_Digit1_Control, __7Seg_Digit1_Pin); 75 | GPIO_Config_OUTPUT(__7Seg_Digit2_Control, __7Seg_Digit2_Pin); 76 | GPIO_Config_OUTPUT(__7Seg_Digit3_Control, __7Seg_Digit3_Pin); 77 | GPIO_Config_OUTPUT(__7Seg_Digit4_Control, __7Seg_Digit4_Pin); 78 | } 79 | 80 | /** 81 | * @brief Displays a 4-digit number on the 7-segment display using multiplexing. 82 | * 83 | * This function displays a number on the 7-segment display by sequentially activating 84 | * each digit and lighting up the corresponding segments. The function uses multiplexing 85 | * to display all 4 digits in quick succession, creating the illusion that they are 86 | * all being shown at once. 87 | * 88 | * @param _7SegValue The 4-digit value (0-9999) to display on the 7-segment display. 89 | */ 90 | void Seg7_Puti(uint16_t _7SegValue) 91 | { 92 | static uint8_t _Digit = 0; /**< Variable to determine which digit to activate */ 93 | 94 | /* Extract digits (thousands to ones) from the 7-segment value */ 95 | Segment[3] = (_7SegValue % 10); /**< thousands (Digit4) */ 96 | _7SegValue /= 10; 97 | Segment[2] = (_7SegValue % 10); /**< hundreds (Digit3) */ 98 | _7SegValue /= 10; 99 | Segment[1] = (_7SegValue % 10); /**< tens (Digit2) */ 100 | _7SegValue /= 10; 101 | Segment[0] = (_7SegValue % 10); /**< ones (Digit1) */ 102 | 103 | /* Update the segments based on the current digit to display */ 104 | bitChange(__7Seg_A_Control, __7Seg_A_Pin, bitCheck(Segments_Data[Segment[_Digit]], 0)); 105 | bitChange(__7Seg_B_Control, __7Seg_B_Pin, bitCheck(Segments_Data[Segment[_Digit]], 1)); 106 | bitChange(__7Seg_C_Control, __7Seg_C_Pin, bitCheck(Segments_Data[Segment[_Digit]], 2)); 107 | bitChange(__7Seg_D_Control, __7Seg_D_Pin, bitCheck(Segments_Data[Segment[_Digit]], 3)); 108 | bitChange(__7Seg_E_Control, __7Seg_E_Pin, bitCheck(Segments_Data[Segment[_Digit]], 4)); 109 | bitChange(__7Seg_F_Control, __7Seg_F_Pin, bitCheck(Segments_Data[Segment[_Digit]], 5)); 110 | bitChange(__7Seg_G_Control, __7Seg_G_Pin, bitCheck(Segments_Data[Segment[_Digit]], 6)); 111 | 112 | /* Activate the corresponding digit */ 113 | bitChange(__7Seg_Digit1_Control, __7Seg_Digit1_Pin, bitCheck((1<<_Digit), 0)); 114 | bitChange(__7Seg_Digit2_Control, __7Seg_Digit2_Pin, bitCheck((1<<_Digit), 1)); 115 | bitChange(__7Seg_Digit3_Control, __7Seg_Digit3_Pin, bitCheck((1<<_Digit), 2)); 116 | bitChange(__7Seg_Digit4_Control, __7Seg_Digit4_Pin, bitCheck((1<<_Digit), 3)); 117 | 118 | /* Increment the _Digit and reset if necessary */ 119 | _Digit++; 120 | if (_Digit == 4) 121 | { 122 | _Digit = 0; 123 | }; 124 | }; 125 | -------------------------------------------------------------------------------- /Basics.md: -------------------------------------------------------------------------------- 1 | ## How a 7-Segment Display Works 2 | A 7-segment display has 7 individual LEDs arranged in the form of a figure-eight. The following is a representation of the segments: 3 | 4 | ``` 5 | A 6 | ----- 7 | F| |B 8 | --G-- 9 | E| |C 10 | ----- 11 | D 12 | ``` 13 | 14 | Each segment can be turned on or off, and by doing so in different combinations, you can display numbers or letters. For example, to display the number '1', you would turn on segments B and C, and leave the rest off. To display the number '8', all segments (A-G) would be turned on. 15 | 16 | ### Common Cathode vs. Common Anode 17 | 18 | There are two types of 7-segment displays: **common cathode** and **common anode**. 19 | 20 | - **Common Cathode**: In a common cathode display, all the cathodes (negative side) of the individual segments are connected together and are typically connected to ground (GND). Each segment is controlled by applying a HIGH signal to the corresponding anode (positive side). The segments light up when a HIGH signal is applied. 21 | 22 | - **Common Anode**: In a common anode display, all the anodes (positive side) of the individual segments are connected together and are typically connected to the VCC (positive voltage). Each segment is controlled by applying a LOW signal to the corresponding cathode (negative side). The segments light up when a LOW signal is applied. 23 | 24 | In both cases, each individual segment is represented by a pin, and by controlling these pins, you can display numbers. The only difference between common anode and common cathode displays is the polarity of the voltage applied to the segments. 25 | 26 | #### Example of Segment Control for Common Cathode: 27 | To display the number '3', the required segments are A, B, C, D, and G. In a common cathode configuration: 28 | - Apply a HIGH signal to segments A, B, C, D, and G. 29 | - The other segments (E, F) remain off. 30 | 31 | #### Example of Segment Control for Common Anode: 32 | To display the number '3', the required segments are A, B, C, D, and G. In a common anode configuration: 33 | - Apply a LOW signal to segments A, B, C, D, and G. 34 | - The other segments (E, F) remain off. 35 | 36 | ### 7-Segment Display Segment Control (Hexadecimal Format) 37 | 38 | | Digit | A | B | C | D | E | F | G | Common Cathode (Active HIGH) | Common Anode (Active LOW) | 39 | |-------|-----|-----|-----|-----|-----|-----|-----|------------------------------|---------------------------| 40 | | **0** | ON | ON | ON | ON | ON | ON | OFF | 0b00111111 → **0x3F** | 0b11000000 → **0xC0** | 41 | | **1** | OFF | ON | ON | OFF | OFF | OFF | OFF | 0b00000110 → **0x06** | 0b11111001 → **0xF9** | 42 | | **2** | ON | ON | OFF | ON | ON | OFF | ON | 0b01011011 → **0x5B** | 0b10100100 → **0xA4** | 43 | | **3** | ON | ON | ON | ON | OFF | OFF | ON | 0b01001111 → **0x4F** | 0b10110000 → **0xB0** | 44 | | **4** | OFF | ON | ON | OFF | OFF | ON | ON | 0b01100110 → **0x66** | 0b10011001 → **0x99** | 45 | | **5** | ON | OFF | ON | ON | OFF | ON | ON | 0b01101101 → **0x6D** | 0b10010010 → **0x92** | 46 | | **6** | ON | OFF | ON | ON | ON | ON | ON | 0b01111101 → **0x7D** | 0b10000010 → **0x82** | 47 | | **7** | ON | ON | ON | OFF | OFF | OFF | OFF | 0b00000111 → **0x07** | 0b11111000 → **0xF8** | 48 | | **8** | ON | ON | ON | ON | ON | ON | ON | 0b01111111 → **0x7F** | 0b10000000 → **0x80** | 49 | | **9** | ON | ON | ON | ON | OFF | ON | ON | 0b01101111 → **0x6F** | 0b10010000 → **0x90** | 50 | | **A** | ON | ON | ON | OFF | ON | ON | ON | 0b01110111 → **0x77** | 0b10001000 → **0x88** | 51 | | **B** | OFF | OFF | ON | ON | ON | ON | ON | 0b01111100 → **0x7C** | 0b10000011 → **0x83** | 52 | | **C** | ON | OFF | OFF | ON | ON | ON | OFF | 0b00111001 → **0x39** | 0b11000110 → **0xC6** | 53 | | **D** | OFF | ON | ON | ON | ON | OFF | ON | 0b01011110 → **0x5E** | 0b10100001 → **0xA1** | 54 | | **E** | ON | OFF | OFF | ON | ON | ON | ON | 0b01111001 → **0x79** | 0b10000110 → **0x86** | 55 | | **F** | ON | OFF | OFF | OFF | ON | ON | ON | 0b01110001 → **0x71** | 0b10001110 → **0x8E** | 56 | 57 | 58 | #### Explanation: 59 | - **A, B, C, D, E, F, G** represent the segments of the 7-segment display. 60 | 61 | - **Common Cathode**: 62 | - In a **common cathode** configuration, a **HIGH** signal turns on the segment. 63 | - The hexadecimal values are based on this configuration, where the bits represent which segments are on (1) or off (0). 64 | 65 | - **Common Anode**: 66 | - In a **common anode** configuration, a **LOW** signal turns on the segment. 67 | - The hexadecimal values for this configuration are inverted compared to the common cathode because the logic is reversed. 68 | 69 | 70 | ```c 71 | /* Common Cathode (Active HIGH - segments light when bit = 1) */ 72 | const uint8_t Seg7_cc[16] = 73 | { 74 | 0x3F, /**< 0: ABCDEF (0b00111111) */ 75 | 0x06, /**< 1: BC (0b00000110) */ 76 | 0x5B, /**< 2: ABDEG (0b01011011) */ 77 | 0x4F, /**< 3: ABCDG (0b01001111) */ 78 | 0x66, /**< 4: BCFG (0b01100110) */ 79 | 0x6D, /**< 5: ACDFG (0b01101101) */ 80 | 0x7D, /**< 6: ACDEFG (0b01111101) */ 81 | 0x07, /**< 7: ABC (0b00000111) */ 82 | 0x7F, /**< 8: ABCDEFG (0b01111111) */ 83 | 0x6F, /**< 9: ABCDFG (0b01101111) */ 84 | 0x77, /**< A: ABCEFG (0b01110111) */ 85 | 0x7C, /**< B: CDEFG (0b01111100) */ 86 | 0x39, /**< C: ADEF (0b00111001) */ 87 | 0x5E, /**< D: BCDEG (0b01011110) */ 88 | 0x79, /**< E: ADEFG (0b01111001) */ 89 | 0x71 /**< F: AEFG (0b01110001) */ 90 | }; 91 | 92 | /* Common Anode (Active LOW - segments light when bit = 0) */ 93 | const uint8_t Seg7_ca[16] = 94 | { 95 | 0xC0, /**< 0: ABCDEF (0b11000000) */ 96 | 0xF9, /**< 1: BC (0b11111001) */ 97 | 0xA4, /**< 2: ABDEG (0b10100100) */ 98 | 0xB0, /**< 3: ABCDG (0b10110000) */ 99 | 0x99, /**< 4: BCFG (0b10011001) */ 100 | 0x92, /**< 5: ACDFG (0b10010010) */ 101 | 0x82, /**< 6: ACDEFG (0b10000010) */ 102 | 0xF8, /**< 7: ABC (0b11111000) */ 103 | 0x80, /**< 8: ABCDEFG (0b10000000) */ 104 | 0x90, /**< 9: ABCDFG (0b10010000) */ 105 | 0x88, /**< A: ABCEFG (0b10001000) */ 106 | 0x83, /**< B: CDEFG (0b10000011) */ 107 | 0xC6, /**< C: ADEF (0b11000110) */ 108 | 0xA1, /**< D: BCDEG (0b10100001) */ 109 | 0x86, /**< E: ADEFG (0b10000110) */ 110 | 0x8E /**< F: AEFG (0b10001110) */ 111 | }; 112 | ``` 113 | 114 | ```c 115 | /* Common Cathode (Hex values for digits 0–15) */ 116 | const uint8_t Seg7_cc[16] = {0x3F, 0x06, 0x5B, 0x4F, 0x66, 0x6D, 0x7D, 0x07, 0x7F, 0x6F, 0x77, 0x7C, 0x39, 0x5E, 0x79, 0x71}; 117 | 118 | /* Common Anode (Hex values for digits 0–15) */ 119 | const uint8_t Seg7_ca[16] = {0xC0, 0xF9, 0xA4, 0xB0, 0x99, 0x92, 0x82, 0xF8, 0x80, 0x90, 0x88, 0x83, 0xC6, 0xA1, 0x86, 0x8E}; 120 | 121 | ``` 122 | 123 | # 🌟 Support Me 124 | If you found this repository useful: 125 | - Subscribe to my [YouTube Channel](https://www.youtube.com/@aKaReZa75). 126 | - Share this repository with others. 127 | - Give this repository and my other repositories a star. 128 | - Follow my [GitHub account](https://github.com/aKaReZa75). 129 | 130 | # ✉️ Contact Me 131 | Feel free to reach out to me through any of the following platforms: 132 | - 📧 [Email: aKaReZa75@gmail.com](mailto:aKaReZa75@gmail.com) 133 | - 🎥 [YouTube: @aKaReZa75](https://www.youtube.com/@aKaReZa75) 134 | - 💼 [LinkedIn: @akareza75](https://www.linkedin.com/in/akareza75) 135 | -------------------------------------------------------------------------------- /API_Reference.md: -------------------------------------------------------------------------------- 1 | ## API Reference 2 | 3 | The following API functions are designed to help with controlling 7-segment displays on the ATMEGA328 microcontroller. 4 | 5 | > [!NOTE] 6 | > The library and all of its APIs provided below have been developed by myself. 7 | This library utilizes various macros defined in the `aKaReZa.h` header file, which are designed to simplify bitwise operations and register manipulations. 8 | Detailed descriptions of these macros can be found at the following link: 9 | > [https://github.com/aKaReZa75/AVR/blob/main/Macros.md](https://github.com/aKaReZa75/AVR/blob/main/Macros.md) 10 | 11 | 12 | ### Flexible Pin Assignment 13 | This library allows you to easily control 7-segment displays, and it is designed with flexibility in mind. Each segment of the 7-segment display (A through G) can be connected to any available pin of the ATMEGA328 microcontroller. This flexibility is crucial because it allows you to customize the pin connections based on your design needs, without being restricted by predefined hardware mappings. 14 | 15 | To make pin configuration easier and more manageable, the `Seg7.h` header file defines a set of macros that allow the user to specify which microcontroller pins should be used for each segment and digit control. This means that each segment (A, B, C, D, E, F, G, and the DP) can be assigned to any GPIO pin of the ATMEGA328. 16 | 17 | ### Example Pin Configuration 18 | In the `Seg7.h` header file, you'll find a set of macros that define the pin assignments for the 7-segment display. These macros are set to specific pins by default, but you can easily change them to any other pin on the microcontroller. For instance, the default configuration may look like this: 19 | 20 | > [!NOTE] 21 | These default pin assignments are based on the pin configuration for the 7-segment shield, as found in the [7Segment Shield](https://github.com/aKaReZa75/eBoard_7Segments) repository. 22 | 23 | ```c 24 | #define _7Seg_A_Control PORTC 25 | #define _7Seg_A_Config DDRC 26 | #define _7Seg_A_Pin 0 27 | 28 | #define _7Seg_B_Control PORTC 29 | #define _7Seg_B_Config DDRC 30 | #define _7Seg_B_Pin 1 31 | 32 | #define _7Seg_C_Control PORTC 33 | #define _7Seg_C_Config DDRC 34 | #define _7Seg_C_Pin 2 35 | 36 | #define _7Seg_D_Control PORTC 37 | #define _7Seg_D_Config DDRC 38 | #define _7Seg_D_Pin 3 39 | 40 | #define _7Seg_E_Control PORTD 41 | #define _7Seg_E_Config DDRD 42 | #define _7Seg_E_Pin 0 43 | 44 | #define _7Seg_F_Control PORTD 45 | #define _7Seg_F_Config DDRD 46 | #define _7Seg_F_Pin 1 47 | 48 | #define _7Seg_G_Control PORTD 49 | #define _7Seg_G_Config DDRD 50 | #define _7Seg_G_Pin 4 51 | 52 | #define _7Seg_DP_Control PORTD 53 | #define _7Seg_DP_Config DDRD 54 | #define _7Seg_DP_Pin 7 55 | 56 | #define _7Seg_Digit1_Control PORTB 57 | #define _7Seg_Digit1_Config DDRB 58 | #define _7Seg_Digit1_Pin 0 59 | 60 | #define _7Seg_Digit2_Control PORTB 61 | #define _7Seg_Digit2_Config DDRB 62 | #define _7Seg_Digit2_Pin 1 63 | 64 | #define _7Seg_Digit3_Control PORTB 65 | #define _7Seg_Digit3_Config DDRB 66 | #define _7Seg_Digit3_Pin 2 67 | 68 | #define _7Seg_Digit4_Control PORTB 69 | #define _7Seg_Digit4_Config DDRB 70 | #define _7Seg_Digit4_Pin 4 71 | ``` 72 | 73 | #### How It Works 74 | - The macros defined in the `Seg7.h` file specify which microcontroller pins are used for each segment and each digit of the 7-segment display. 75 | - For example: 76 | - `_7Seg_A_Control` and `_7Seg_A_Pin` correspond to the control port (PORTC) and pin (pin 0) for segment A. 77 | - Similarly, `_7Seg_B_Control` and `_7Seg_B_Pin` define the port and pin for segment B, and so on for the remaining segments and digits. 78 | 79 | - By using these macros, you can configure each segment and each digit of the display to any port and pin you choose, just by modifying the macro definitions. This flexibility allows you to adapt the code to your specific hardware setup, making it ideal for a wide range of projects. 80 | 81 | For example, if you want to change the pin for segment A to pin 5 of PORTB, you can modify the macro like this: 82 | 83 | ```c 84 | #define _7Seg_A_Control PORTB 85 | #define _7Seg_A_Config DDRB 86 | #define _7Seg_A_Pin 5 87 | ``` 88 | 89 | This allows you to control which pins are connected to each segment, ensuring that you have full control over your display setup. 90 | 91 | ### **Initialization** 92 | ```c 93 | void Seg7_init(void); 94 | ``` 95 | * Initializes the 7-segment display configuration. 96 | * This function sets the appropriate pin directions for controlling the segments and digits of the 7-segment display. 97 | * It configures all the necessary pins as output. 98 | 99 | **Default Configuration** 100 | 101 | | **Segment/Digit** | **Control Port & Pin** | 102 | |---------------------------|--------------------------| 103 | | **Type of 7-Segment** | Common Cathode | 104 | | **Number of Digits** | 4 | 105 | | **Segment A** | PORTC, Pin 0 | 106 | | **Segment B** | PORTC, Pin 1 | 107 | | **Segment C** | PORTC, Pin 2 | 108 | | **Segment D** | PORTC, Pin 3 | 109 | | **Segment E** | PORTD, Pin 0 | 110 | | **Segment F** | PORTD, Pin 1 | 111 | | **Segment G** | PORTD, Pin 4 | 112 | | **Decimal Point (DP)** | PORTD, Pin 7 | 113 | | **Digit 1 (Thousands)** | PORTB, Pin 0 | 114 | | **Digit 2 (Hundreds)** | PORTB, Pin 1 | 115 | | **Digit 3 (Tens)** | PORTB, Pin 2 | 116 | | **Digit 4 (Ones)** | PORTB, Pin 4 | 117 | 118 | **Example:** 119 | ```c 120 | #include "aKaReZa.h" 121 | #include "Seg7.h" 122 | 123 | int main(void) 124 | { 125 | Seg7_init(); /**< Initialize the 7-segment display */ 126 | while(1) 127 | { 128 | /* Your code here to display values */ 129 | } 130 | } 131 | ``` 132 | 133 | ### **Display Number** 134 | ```c 135 | void Seg7_Puti(uint16_t _7SegValue); 136 | ``` 137 | * Displays a 4-digit number on the multiplexed 7-segment display. 138 | * This function uses multiplexing to display the digits sequentially with a short delay between each to simulate continuous display of the 4-digit value. 139 | * It will handle turning on the correct segments for each digit. 140 | 141 | > [!IMPORTANT] 142 | Currently, only **positive integers** between **0 and 9999** can be displayed. 143 | Additionally, only a **4-digit 7-segment display** is supported at the moment. 144 | 145 | 146 | **Example:** 147 | ```c 148 | #include "aKaReZa.h" 149 | #include "Seg7.h" 150 | 151 | int main(void) 152 | { 153 | Seg7_init(); /**< Initialize the 7-segment display */ 154 | while(1) 155 | { 156 | Seg7_Puti(1234); /**< Display the number 1234 */ 157 | } 158 | } 159 | ``` 160 | 161 | > [!CAUTION] 162 | For continuous display, the `Seg7_Puti` function needs to be executed continuously. 163 | It is recommended to use a **timer** to trigger the execution of the function at a fixed interval. 164 | This will prevent delays in the main program loop and ensure smoother performance by automating the multiplexing refresh. 165 | 166 | ## Summary 167 | 168 | Here’s a quick summary of the available functions: 169 | 170 | | Function Name | Description | 171 | |----------------------|--------------------------------------------------| 172 | | `Seg7_init()` | Initializes the 7-segment display configuration. | 173 | | `Seg7_Puti(uint16_t)` | Displays a 4-digit value on the multiplexed 7-segment display. | 174 | 175 | ## Complete Example 176 | 177 | The following example demonstrates how to initialize the 7-segment display, display a 4-digit number using multiplexing, and use a timer interrupt to update the display continuously. 178 | 179 | ```c 180 | #include "aKaReZa.h" 181 | #include "Seg7.h" 182 | 183 | /* Timer0 Overflow Interrupt Service Routine (ISR) */ 184 | ISR(TIMER0_OVF_vect) 185 | { 186 | Seg7_Puti(1234); /* Update the 7-segment display */ 187 | }; 188 | 189 | int main(void) 190 | { 191 | Seg7_init(); /**< Initialize the 7-segment display */ 192 | 193 | Timer0_Init(Initialize); /**< Initialize Timer0 for periodic updates */ 194 | 195 | globalInt_Enable(); /**< Enable global interrupts */ 196 | 197 | while(1) 198 | { 199 | /* Main loop can be used for other tasks, the display will update automatically via Timer0 interrupt */ 200 | }; 201 | }; 202 | ``` 203 | 204 | ### Explanation: 205 | 206 | In this example, the 7-Segments will be updated continuously at the specified interval (1ms in this case) due to the timer interrupt. 207 | 208 | ## Important Notes 209 | 210 | - **Multiplexing**: The 7-segment display operates using multiplexing, meaning each digit is displayed sequentially for a short period. This creates the illusion that all digits are visible at once. Ensure that the refresh rate is set appropriately to avoid flickering. 211 | - **Power Consumption**: Be cautious about power consumption when driving multiple 7-segment displays, as this can draw significant current. 212 | - **Pin Configuration**: Make sure the correct pins are defined in the header file. If you modify the microcontroller's pin configuration or use different segments, update the pin assignments accordingly. 213 | - **Delay Timing**: If the delay between digit switching is too short, the display may become unreadable. If it’s too long, the display might appear sluggish. 214 | - **Initialization**: Don’t forget to initialize the 7-segment display by calling `Seg7_init()`. 215 | - **Wiring Issues**: Ensure that the segments and common cathodes/anodes are wired correctly. 216 | - **Low Refresh Rate**: A refresh rate below 50 Hz may cause visible flickering, making the display hard to read. 217 | 218 | # 🌟 Support Me 219 | If you found this repository useful: 220 | - Subscribe to my [YouTube Channel](https://www.youtube.com/@aKaReZa75). 221 | - Share this repository with others. 222 | - Give this repository and my other repositories a star. 223 | - Follow my [GitHub account](https://github.com/aKaReZa75). 224 | 225 | # ✉️ Contact Me 226 | Feel free to reach out to me through any of the following platforms: 227 | - 📧 [Email: aKaReZa75@gmail.com](mailto:aKaReZa75@gmail.com) 228 | - 🎥 [YouTube: @aKaReZa75](https://www.youtube.com/@aKaReZa75) 229 | - 💼 [LinkedIn: @akareza75](https://www.linkedin.com/in/akareza75) 230 | -------------------------------------------------------------------------------- /README.md: -------------------------------------------------------------------------------- 1 | # 7-Segment Display with AVR Microcontrollers 2 | 3 | A 7-segment display is an electronic display device used to represent numbers, letters, and sometimes other characters. It consists of seven LEDs arranged in a specific way that can be turned on or off to form different digits or characters. The display has 7 segments (labeled A to G) and an optional decimal point (DP). By turning different combinations of these segments on or off, it is possible to represent all the digits from 0 to 9, and in some cases, letters like A, b, C, etc. 4 | 5 | 6 | 7 | 16 | 23 | 24 | 25 | 26 | 27 | 36 | 43 | 44 | 45 | 46 | 47 | 53 | 54 |
8 | 9 | > [!TIP] 10 | > If you're looking to better understand how to navigate and use my GitHub repositories — including exploring their structure, downloading or cloning projects, submitting issues, and asking questions, 11 | > everything you need is clearly explained in this video: 12 | > [aKaReZa 95 - Programming, Git - PART B](https://youtu.be/zYiUItVFRqQ) 13 | > Make sure to check it out! 14 | 15 | 17 | 18 | aKaReZa 95 - Programming, Git - PART B Thumbnail 21 | 22 |
28 | 29 | > [!IMPORTANT] 30 | > Begin your embedded systems journey with clarity and purpose. This episode outlines a structured roadmap for mastering microcontrollers, communication protocols, hardware design, and project development. 31 | > Learn how to choose your specialization, follow curated playlists, and engage effectively with the community—ideal for learners seeking a scalable, goal-driven path into embedded engineering. 32 | > [aKaReZa 124 – Embedded Systems Roadmap](https://youtu.be/3QYfv7A7aMc) 33 | > Watch it now to kickstart your journey! 34 | 35 | 37 | 38 | aKaReZa 124 – Embedded Systems Roadmap Thumbnail 41 | 42 |
48 | 49 | > [!CAUTION] 50 | > It is absolutely critical that you carefully read every single word of this document, line by line, to ensure you don't miss any details. Nothing can be overlooked. 51 | 52 |
55 | 56 | # 🔗 Resources 57 | Here you'll find a collection of useful links and videos related to the topic of AVR microcontrollers. 58 | 59 | 60 | ``` 61 | 7-Segment Display Overview 62 | ├── Basics 63 | │ ├─ Segment arrangement (A–G) 64 | │ ├─ Digit/letter segment combinations 65 | │ ├─ Common Cathode — wiring & logic 66 | │ ├─ Common Anode — wiring & logic 67 | │ └─ Hex code tables (0–F) + examples 68 | │ 69 | ├── Multiplexing 70 | │ ├─ Multiplexing concept 71 | │ ├─ Wiring for digit commons 72 | │ ├─ Refresh rate requirements 73 | │ ├─ Timing calculations 74 | │ └─ Example — 4-digit switching sequence 75 | │ 76 | └── API Reference 77 | ├─ CC_Hex_Array — 0–F hex values 78 | ├─ CA_Hex_Array — 0–F hex values 79 | └─ Multiplex_Example — sample C code 80 | ``` 81 | 82 | > [!TIP] 83 | > The resources are detailed in the sections below. 84 | > To access any of them, simply click on the corresponding blue link. 85 | 86 | - [Basics](./Basics.md) 87 | --- 88 | Covers segment arrangement (A–G), digit/letter combinations, common cathode vs. common anode wiring and logic, and hexadecimal segment code tables for digits 0–F. 89 | 90 | - [Multiplexing](./Multiplexing4Digit.md) 91 | --- 92 | Explains multiplexing operation for 4-digit displays, wiring of digit commons, refresh rate requirements, timing calculations, and example digit-switching sequence. 93 | 94 | - [API Reference](./API_Reference.md) 95 | --- 96 | Provides C arrays for common cathode and common anode hexadecimal values (0–F) and a sample C implementation for multiplexed 7-segment display control. 97 | 98 | ```plaintext 99 | AVR, 7Segment 100 | ├── [aKaReZa 44 - AVR, 7Segment - Part A] 101 | │ ├─ Display Setup — Driving common anode + 4-digit multiplexing. 102 | │ └─ Code Quality — Readability and structure tips. 103 | │ 104 | ├── [aKaReZa 47 - AVR, 7Segment - Part B] 105 | │ ├─ Buttons — Counter increment and input handling. 106 | │ ├─ Digit Split — Displaying digits individually. 107 | │ └─ Optimization — New macros for cleaner code. 108 | │ 109 | └── [aKaReZa 53 - AVR, 7Segment - Part C] 110 | ├─ Modularization — Functions and headers. 111 | ├─ Refresh Issue — Software-based fix. 112 | └─ Timer — Implementing 1-second Timer. 113 | ``` 114 | 115 | 116 | 117 | 125 | 132 | 133 | 134 | 135 | 143 | 150 | 151 | 152 | 153 | 161 | 168 | 169 |
118 |

119 | aKaReZa 44 – AVR, 7Segment - Part A 120 |

121 |

122 | Learn how to set up a common anode 7-segment display with an AVR microcontroller on a breadboard, and then multiplex a four-digit 7-segment display using a custom shield to improve code readability. 123 |

124 | 		126 | 127 | aKaReZa 44 – AVR, 7Segment - Part A Thumbnail 130 | 131 |
136 |

137 | aKaReZa 47 – AVR, 7Segment - Part B 138 |

139 |

140 | Continuation of setting up 7-segment displays, building a counter, adding button functionality, displaying digits, optimizing code, and adding macros. 141 |

142 | 		144 | 145 | aKaReZa 47 – AVR, 7Segment - Part B Thumbnail 148 | 149 |
154 |

155 | aKaReZa 53 – AVR, 7Segment - Part C 156 |

157 |

158 | Continuation of setting up 7-segment displays, addressing three software issues: modular code writing, display refresh during button press, and one-second counting. 159 |

160 | 		162 | 163 | aKaReZa 53 – AVR, 7Segment - Part C Thumbnail 166 | 167 |
