3 | There are two main ways of setting them up. 4 | 5 | ## Standalone emitter 6 | A standalone emitter is any renderer assigned to a layer dedicated for velocity emitters.
7 | This layer is excluded when rendering the scene making all standalone emitters invisible. 8 | 9 | 1. Create a dedicated layer for velocity emitters (For example - "Velocity") 10 | 11 | 1. Setup the layer mask to contain the created layer
12 | ![Layer Mask property](Images/layer_mask.png) 13 | 14 | 1. If you are using a render feature, exclude the layer in the filtering settings
15 | ![Filtering > Transparent Layer Mask property](Images/culling_mask.png)
16 | (When using a velocity camera, the layer will be excluded autmatically) 17 | 18 | 1. Create an emitter
19 | ![2D Object > Sprites > Velocity Emitter](Images/velocity_emitter_object.png)
20 | See the _Configuration_ section below for more info on how to configure an emitter. 21 | 22 | ## Integrated emitter 23 | _(Render feature only)_
24 | Sometimes we want to use an existing renderer as an emitter while still having it appear on the screen.
25 | In cases like this, we can utilize rendering layers to use the same renderer for both rendering and emitting velocity. 26 | 27 | 1. Choose a rendering layer to use for velocity emitters (For example - "Layer2")
28 | ![Rendering Layer Mask property](Images/rendering_layer_mask.png) 29 | 30 | 1. Find a renderer that you want to use as an emitter and add to it the __Velocity Emitter__ component
31 | ![Add Component > PixelGraphics > Velocity Emitter](Images/velocity_emitter_component.png)
32 | See the _Configuration_ section below for more info on how to configure an emitter. 33 | 34 | 1. Make sure that the rendering layer you have picked is checked in the Rendering Layer Mask of the renderer.
35 | ![Rendering Layer Mask property](Images/renderer_rendering_layer_mask.png) 36 | 37 | ## Configuration 38 | 39 | ### `Mode` 40 | The emitter mode decides what should be the source of velocity for this emitter.
41 | There are four modes available: 42 | 43 | Mode | Description 44 | --- | --- 45 | Translation | Velocity is calculated based on the change of position between frames 46 | Rigidbody | Velocity is read from a Rigidbody component 47 | Rigidbody2D | Velocity is read from a Rigidbody2D component 48 | Custom | Velocity is read from a public `customVelocity` field 49 | 50 | ### `Max Speed` 51 | The maximum speed for this emitter.
52 | The actuall speed of an emitter is remapped so that, upon reaching the maximum speed, the resulting speed will be equal to 1. 53 | Anything above that will also result in 1 as well. 54 | 55 | ### `Remapping` 56 | A curve that allows you to fine-tune how the speed is remapped.
57 | X-axis is the real speed (0 = 0, 1 = maxSpeed).
58 | Y-axis is the speed passed to the velocity texture. 59 | 60 | Pseudocode describing how the final speed is calculated: 61 | ``` 62 | speed = remapping(clamp01(length(velocity) / maxSpeed)) 63 | ``` 64 | 65 | ## Custom emitters 66 | Velocity emitters are not the only way to interact with the buffer. 67 | In fact, any sprite assigned to our velocity layer can do that. 68 | 69 | You can use [the default emitter shader](../Runtime/Shaders/Velocity/Emitter.shader) as a template 70 | and create your own shaders that will interact with the buffer differently. 71 | 72 | --- 73 | 74 | Once you have set up a few emitters, you can use [the available shaders](./shaders.md) to see them in action. -------------------------------------------------------------------------------- /Documentation~/index.md: -------------------------------------------------------------------------------- 1 | # PixelGraphics overview 2 | 3 | PixelGraphics is a collection of interactive foliage shaders for Unity
4 | _Tested on Unity 2020.2 - PC & WebGL_ 5 | 6 | ### Installation 7 | Pixel Graphics can be [installed as a unity package](https://docs.unity3d.com/Manual/upm-ui-giturl.html) 8 | using this url: 9 | ``` 10 | https://github.com/aarthificial/pixelgraphics.git 11 | ``` 12 | 13 | ### Usage 14 | 1. [Set up a velocity texture](./velocity.md) 15 | 1. [Place some emitters in your scene](./emitters.md) 16 | 1. [Create materials using the available shaders](./shaders.md) 17 | 1. [Or create your own shaders](./properties.md) 18 | -------------------------------------------------------------------------------- /Documentation~/properties.md: -------------------------------------------------------------------------------- 1 | # Shader properties 2 | Once you have set up the velocity texture, you will gain access to a few shader properties. 3 | You can utilize them to create your own shaders.
4 | These properties can be accessed as follows, from within a shader graph:
5 | ![Accesing a shader property](Images/shader_properties.png)
6 | (Make sure that `Exposed` is not checked) 7 | 8 | ### Velocity Texture 9 | Reference: `_PG_VelocityTexture`
10 | Type: `Texture2D` 11 | 12 | The velocity texture itself.
13 | You can sample it using the coordinates returned from a `Screen Position` node.
14 | The retrieved value represents the velocity data for a given fragment/vertex. 15 | 16 | Channel | Data 17 | --- | --- 18 | R | Displacement along the X-axis 19 | G | Displacement along the Y-axis 20 | B | Velocity along the X-axis 21 | A | Velocity along the Y-axis 22 | 23 | ### Pixel Screen Params 24 | Reference: `_PG_PixelScreenParams`
25 | Type: `Vector4` 26 | 27 | Component | Data 28 | --- | --- 29 | X | Width of the camera measured in "pixel art" pixels 30 | Y | Height of the camera measured in "pixel art" pixels 31 | Z | Pixels per unit 32 | W | 1 / Pixels per unit 33 | 34 | ### Velocity Simulation Params 35 | Reference: `_PG_VelocitySimulationParams`
36 | Type: `Vector4` 37 | 38 | Component | Data 39 | --- | --- 40 | X | Stiffness 41 | Y | Damping 42 | Z | Blur strength 43 | W | Max delta time 44 | -------------------------------------------------------------------------------- /Documentation~/shaders.md: -------------------------------------------------------------------------------- 1 | # Available Shaders 2 | 3 | ### `foliage_shader` and `foliage_pixelart_shader` 4 | Simple wind simulation and velocity reaction.
5 | Sways in any direction.
6 | Best for bushes/trees and other foliage suspended in the air. 7 | 8 | ### `grass_shader` and `grass_pixelart_shader` 9 | Simple wind simulation and velocity reaction.
10 | Sways back and forth along its right axis.
11 | Best for grass/flowers and other small foliage that grows out of the ground. 12 | 13 | ## Variants 14 | Each shader is available in two variants - normal and pixelart. 15 | 16 | | Default sprite | grass_shader | grass_pixelart_shader | 17 | | --- | --- | --- | 18 | |![Default texture](Images/shader_variant_default.png)|![Normal variant](Images/shader_variant_normal.png)|![Pixelart variant](Images/shader_variant_pixelart.png) 19 | 20 | ### Pixelart shaders 21 | Pros: 22 | - Pixel-perfect distortion at higher resolutions 23 | 24 | Cons: 25 | - Computationally heavy 26 | - Can be used only with normal sprite renderers. 27 | 28 | ### Normal shaders 29 | Pros: 30 | - Lightweight 31 | - Can be used with any renderer 32 | - Can be used for *non* pixel art assets 33 | 34 | Cons: 35 | - Pixel-perfect effect requires upscaling 36 | 37 | ## Preparing mesh 38 | Depending on what shader variant you are using, you will need to prepare your sprites differently. 39 | 40 | Normal shaders displace the vertices of a mesh. 41 | To improve the effect, a mesh needs to be additionally subdivided. 42 | This can be done using the Custom Outline mode of the Sprite Editor (see the table below). 43 | 44 | Pixelart shaders displace only the uv coordinates, the mesh itself stays the same. 45 | To make it work, the mesh needs to be bigger than the actual sprite to account for any possible displacement. 46 | This can be done using the Sprite Editor (see the table below) or the import settings. 47 | 48 | | | Normal shader | Pixelart shader | 49 | | --- | --- | --- | 50 | | Outline | ![Outline for normal shaders](Images/outline_normal.png) | ![Outline for pixelart shaders](Images/outline_pixelart.png) | 51 | | Mesh | ![Mesh for normal shaders](Images/outline_mesh_normal.png) | ![Mesh for pixelart shaders](Images/outline_mesh_pixelart.png) | 52 | 53 | ## Configuration 54 | 55 | ### `Velocity Strength` 56 | How much the material is distorted by the velocity texture. 57 | 58 | ### `Wind Velocity` 59 | 2D Vector defining direction and speed of the wind. 60 | 61 | ### `Wind Strength` 62 | How much the material is distorted by the wind. 63 | 64 | ### `Wind Scale` 65 | Scale of the noise used to generate the wind. 66 | 67 | ## Displacement Mask 68 | The distortion can be further controlled by using a secondary texture called `_DisplacementMask` 69 | 70 | | Channel | Function | 71 | | --- | --- | 72 | | R | Controls how much a given fragment/vertex get displaced by the velocity texture | 73 | | G | Controls how much a given fragment/vertex get displaced by the wind | 74 | 75 | Secondary textures are assigned from within the sprite editor: 76 | 77 | ![Assigning a secondary texture](Images/secondary_texture.png) 78 | 79 | You can use a displacement mask to, for example, keep the branches of a bush in place: 80 | 81 | | Texture | Displacement mask | 82 | | --- | --- | 83 | |![Texture](Images/displacement_texture.png)|![Displacement mask](Images/displacement_mask.png)| 84 | 85 | --- 86 | 87 | These shaders are just an example of what is possible. You can use [the exposed properties](./emitters.md) to create your own interactive shaders. 88 | -------------------------------------------------------------------------------- /Documentation~/velocity.md: -------------------------------------------------------------------------------- 1 | # Velocity Texture 2 | The velocity texture is a screen space buffer that stores current velocity of specific objects (emitters) and performs 3 | a simple, spring based simulation for every pixel on the screen.
4 | It can be used to cheaply fake displacement effects caused by moving objects. 5 | For example, grass swaying when the player passes by. 6 | 7 | The velocity texture consists of four channels: 8 | 9 | Channel | Data 10 | --- | --- 11 | R | Displacement along the X-axis 12 | G | Displacement along the Y-axis 13 | B | Velocity along the X-axis 14 | A | Velocity along the Y-axis 15 | 16 | ## Setup 17 | The velocity texture can be set up using two different methods.
18 | The preferred one is to add a `Velocity Render Feature` to your renderer. 19 | 20 | Unfortuantely, as of writing this, only the Forward Renderer supports render features.
21 | If you are using a different renderer (the 2D Renderer, for example) 22 | add a `Velocity Camera` component to your main camera instead. 23 | 24 | (In the future (2021.2) the 2D Renderer will also support render features) 25 | 26 | Adding a render feature | Adding a camera component 27 | --- | --- 28 | ![Add Render Feature > Velocity Render Feature](Images/render_feature.png) | ![Add Component > PixelGraphics > Velocity Camera](Images/velocity_camera.png) 29 | 30 | ## Configuration 31 | Both the render feature and the camera component use the same configuration.
32 | The only difference being that the component does not support the rendering layer mask. 33 | 34 | Render feature | Camera component 35 | --- | --- 36 | ![Add Render Feature](Images/render_feature_ui.png) | ![Velocity Camera](Images/velocity_camera_ui.png) 37 | 38 | ### `Pixels Per Unit` 39 | The amount of pixels that make up one unit of the scene.
40 | Set this value to match the PPU value of sprites in the scene. 41 | 42 | ### `Rendering Layer Mask` 43 | _(Render feature only)_
44 | Rendering layers used for [integrated emitters](./emitters.md#integrated-emitter) 45 | 46 | ### `Layer Mask` 47 | Normal layers used for [standalone emitters](./emitters.md#standalone-emitter) 48 | 49 | ### `Texture Scale` 50 | The resolution of the velocity texture relative to the screen resolution.
51 | 1.0 means full screen size. 52 | 53 | ### `Preview` 54 | _(Render feature only)_
55 | Displays the velocity texture on the screen. For debugging only. 56 | 57 | ![No blur](Images/velocity_texture_preview.png) 58 | 59 | ### `Stiffness` 60 | The spring constant.
61 | The higher the value the stiffer the spring. 62 | 63 | ### `Damping` 64 | The linear damping coefficient. Causes the spring to slow down and eventually reach equilibrium.
65 | Setting it to 0 will cause the spring to oscillate (almost) indefinitely. 66 | 67 | ### `Blur Strength` 68 | The strength of the blur.
69 | Other factors, like the `Texture Scale`, can also affect blurring. 70 | 71 | Blur = 0 | Blur = 1 72 | --- | --- 73 | ![No blur](Images/velocity_texture_no_blur.png) | ![Blur](Images/velocity_texture_blur.png) 74 | 75 | ### `Max Delta Time` 76 | The maximum delta time in seconds. Used to keep the simulation stable in case of FPS drops.
77 | Should be higher than the average delta time of your targeted frame rate. The default value is 1/30 (30 FPS) 78 | 79 | --- 80 | 81 | Once you have set up a render texture, you can start [placing emitters in your scene](./emitters.md) -------------------------------------------------------------------------------- /Editor.meta: -------------------------------------------------------------------------------- 1 | fileFormatVersion: 2 2 | guid: d030f88a2e679364989b30f32eff1f5e 3 | folderAsset: yes 4 | DefaultImporter: 5 | externalObjects: {} 6 | userData: 7 | assetBundleName: 8 | assetBundleVariant: 9 | -------------------------------------------------------------------------------- /Editor/Common.meta: -------------------------------------------------------------------------------- 1 | fileFormatVersion: 2 2 | guid: ad8d5c1da4883bc448276a016ad52c89 3 | folderAsset: yes 4 | DefaultImporter: 5 | externalObjects: {} 6 | userData: 7 | assetBundleName: 8 | assetBundleVariant: 9 | -------------------------------------------------------------------------------- /Editor/Common/RenderingLayerMaskPropertyDrawer.cs: -------------------------------------------------------------------------------- 1 | using Aarthificial.PixelGraphics.Common; 2 | using UnityEditor; 3 | using UnityEngine; 4 | 5 | namespace Aarthificial.PixelGraphics.Editor.Common 6 | { 7 | [CustomPropertyDrawer(typeof(RenderingLayerMask))] 8 | public class RenderingLayerMaskPropertyDrawer : PropertyDrawer 9 | { 10 | private readonly string[] _options = new string[32]; 11 | private bool _optionsCreated; 12 | 13 | public override void OnGUI( 14 | Rect position, 15 | SerializedProperty property, 16 | GUIContent label 17 | ) 18 | { 19 | CreateOptions(); 20 | var maskProperty = property.FindPropertyRelative("mask"); 21 | 22 | EditorGUI.BeginProperty(position, label, property); 23 | maskProperty.intValue = EditorGUI.MaskField( 24 | position, 25 | label, 26 | maskProperty.intValue, 27 | _options 28 | ); 29 | 30 | EditorGUI.EndProperty(); 31 | } 32 | 33 | private void CreateOptions() 34 | { 35 | if (_optionsCreated) return; 36 | 37 | for (var i = 0; i < _options.Length; i++) 38 | { 39 | _options[i] = $"Layer{i + 1}"; 40 | } 41 | 42 | _optionsCreated = true; 43 | } 44 | } 45 | } -------------------------------------------------------------------------------- /Editor/Common/RenderingLayerMaskPropertyDrawer.cs.meta: -------------------------------------------------------------------------------- 1 | fileFormatVersion: 2 2 | guid: a36483216636c084cbca067635aab9d2 3 | MonoImporter: 4 | externalObjects: {} 5 | serializedVersion: 2 6 | defaultReferences: [] 7 | executionOrder: 0 8 | icon: {instanceID: 0} 9 | userData: 10 | assetBundleName: 11 | assetBundleVariant: 12 | -------------------------------------------------------------------------------- /Editor/Common/VelocityEmitterEditor.cs: -------------------------------------------------------------------------------- 1 | using System.Reflection; 2 | using Aarthificial.PixelGraphics.Common; 3 | using Aarthificial.PixelGraphics.Forward; 4 | using Aarthificial.PixelGraphics.Universal; 5 | using UnityEditor; 6 | using UnityEngine; 7 | using UnityEngine.Rendering; 8 | using UnityEngine.Rendering.Universal; 9 | 10 | namespace Aarthificial.PixelGraphics.Editor.Common 11 | { 12 | [CustomEditor(typeof(VelocityEmitter))] 13 | public class VelocityEmitterEditor : UnityEditor.Editor 14 | { 15 | private static readonly GUIContent RigidbodyLabel = EditorGUIUtility.TrTextContent( 16 | "Rigidbody", 17 | "The rigidbody component used as the source of velocity." 18 | ); 19 | 20 | private SerializedProperty _mode; 21 | private SerializedProperty _rigidbody; 22 | private SerializedProperty _rigidbody2D; 23 | private SerializedProperty _maxSpeed; 24 | private SerializedProperty _remapping; 25 | private SerializedProperty _customVelocity; 26 | 27 | private void OnEnable() 28 | { 29 | _mode = serializedObject.FindProperty("mode"); 30 | _rigidbody = serializedObject.FindProperty("rb"); 31 | _rigidbody2D = serializedObject.FindProperty("rb2D"); 32 | _maxSpeed = serializedObject.FindProperty("maxSpeed"); 33 | _remapping = serializedObject.FindProperty("remapping"); 34 | _customVelocity = serializedObject.FindProperty(nameof(VelocityEmitter.customVelocity)); 35 | } 36 | 37 | public override void OnInspectorGUI() 38 | { 39 | serializedObject.Update(); 40 | 41 | EditorGUILayout.PropertyField(_mode); 42 | switch ((VelocityEmitter.EmitterMode) _mode.intValue) 43 | { 44 | case VelocityEmitter.EmitterMode.Rigidbody: 45 | EditorGUILayout.PropertyField(_rigidbody, RigidbodyLabel); 46 | break; 47 | case VelocityEmitter.EmitterMode.Rigidbody2D: 48 | EditorGUILayout.PropertyField(_rigidbody2D, RigidbodyLabel); 49 | break; 50 | case VelocityEmitter.EmitterMode.Custom: 51 | EditorGUILayout.PropertyField(_customVelocity); 52 | break; 53 | } 54 | 55 | EditorGUILayout.PropertyField(_maxSpeed); 56 | EditorGUILayout.PropertyField(_remapping); 57 | 58 | serializedObject.ApplyModifiedProperties(); 59 | } 60 | 61 | [MenuItem("GameObject/2D Object/Sprites/Velocity Emitter")] 62 | private static void CreateCustomEmitter(MenuCommand menuCommand) 63 | { 64 | var prefab = AssetDatabase.LoadAssetAtPath( 65 | "Packages/com.aarthificial.pixelgraphics/Runtime/Prefabs/Velocity Emitter.prefab" 66 | ); 67 | var instance = PrefabUtility.InstantiatePrefab(prefab) as GameObject; 68 | if (instance == null) return; 69 | 70 | PrefabUtility.UnpackPrefabInstance(instance, PrefabUnpackMode.Completely, InteractionMode.AutomatedAction); 71 | GameObjectUtility.SetParentAndAlign(instance, menuCommand.context as GameObject); 72 | 73 | if (TryGetRendererData(out var data)) 74 | { 75 | foreach (var feature in data.rendererFeatures) 76 | { 77 | if (feature is VelocityRenderFeature velocityRenderFeature) 78 | { 79 | instance.layer = GetFirstLayerFromMask(velocityRenderFeature.settings.layerMask); 80 | break; 81 | } 82 | } 83 | } 84 | 85 | var camera = FindObjectOfType(); 86 | if (camera != null) 87 | { 88 | instance.layer = GetFirstLayerFromMask(camera.settings.layerMask); 89 | } 90 | 91 | Undo.RegisterCreatedObjectUndo(instance, "Create " + instance.name); 92 | Selection.activeObject = instance; 93 | } 94 | 95 | private static int GetFirstLayerFromMask(int mask) 96 | { 97 | var layer = 0; 98 | while (layer < 32) 99 | { 100 | if ((mask & (1 << layer)) != 0) 101 | break; 102 | layer++; 103 | } 104 | 105 | return layer; 106 | } 107 | 108 | private static bool TryGetRendererData(out ForwardRendererData data) 109 | { 110 | if (!(GraphicsSettings.currentRenderPipeline is UniversalRenderPipelineAsset pipeline)) 111 | { 112 | data = null; 113 | return false; 114 | } 115 | 116 | data = typeof(UniversalRenderPipelineAsset).GetProperty( 117 | "scriptableRendererData", 118 | BindingFlags.Instance | BindingFlags.NonPublic 119 | ) 120 | ?.GetValue(pipeline) as ForwardRendererData; 121 | 122 | return data != null; 123 | } 124 | } 125 | } -------------------------------------------------------------------------------- /Editor/Common/VelocityEmitterEditor.cs.meta: -------------------------------------------------------------------------------- 1 | fileFormatVersion: 2 2 | guid: 37f3f7a5bc8c485aa3f3ece389901c33 3 | timeCreated: 1623710397 -------------------------------------------------------------------------------- /Editor/Unity.PixelGraphics.Editor.asmdef: -------------------------------------------------------------------------------- 1 | { 2 | "name": "Unity.PixelGraphics.Editor", 3 | "rootNamespace": "Aarthificial.PixelGraphics.Editor", 4 | "references": [ 5 | "Unity.PixelGraphics", 6 | "Unity.RenderPipelines.Universal.Core", 7 | "Unity.RenderPipelines.Universal.Runtime" 8 | ], 9 | "includePlatforms": [ 10 | "Editor" 11 | ], 12 | "excludePlatforms": [], 13 | "allowUnsafeCode": false, 14 | "overrideReferences": false, 15 | "precompiledReferences": [], 16 | "autoReferenced": true, 17 | "defineConstraints": [], 18 | "versionDefines": [], 19 | "noEngineReferences": false 20 | } -------------------------------------------------------------------------------- /Editor/Unity.PixelGraphics.Editor.asmdef.meta: -------------------------------------------------------------------------------- 1 | fileFormatVersion: 2 2 | guid: c5f19ed5799fc7a4a8431c64769e0fc5 3 | AssemblyDefinitionImporter: 4 | externalObjects: {} 5 | userData: 6 | assetBundleName: 7 | assetBundleVariant: 8 | -------------------------------------------------------------------------------- /Editor/Universal.meta: -------------------------------------------------------------------------------- 1 | fileFormatVersion: 2 2 | guid: f2c3272ffe974935a6a21e78b9a899b9 3 | timeCreated: 1623700274 -------------------------------------------------------------------------------- /Editor/Universal/VelocityCameraEditor.cs: -------------------------------------------------------------------------------- 1 | using Aarthificial.PixelGraphics.Common; 2 | using Aarthificial.PixelGraphics.Universal; 3 | using UnityEditor; 4 | 5 | namespace Aarthificial.PixelGraphics.Editor.Universal 6 | { 7 | [CustomEditor(typeof(VelocityCamera))] 8 | public class VelocityCameraEditor : UnityEditor.Editor 9 | { 10 | private SerializedProperty _passSettings; 11 | private SerializedProperty _ppu; 12 | private SerializedProperty _layerMask; 13 | private SerializedProperty _textureScale; 14 | private SerializedProperty _simulationSettings; 15 | 16 | private void OnEnable() 17 | { 18 | _simulationSettings = serializedObject.FindProperty("simulation"); 19 | _passSettings = serializedObject.FindProperty("settings"); 20 | _ppu = _passSettings.FindPropertyRelative(nameof(VelocityPassSettings.pixelsPerUnit)); 21 | _layerMask = _passSettings.FindPropertyRelative(nameof(VelocityPassSettings.layerMask)); 22 | _textureScale = _passSettings.FindPropertyRelative(nameof(VelocityPassSettings.textureScale)); 23 | } 24 | 25 | public override void OnInspectorGUI() 26 | { 27 | serializedObject.Update(); 28 | 29 | EditorGUILayout.PropertyField(_ppu); 30 | EditorGUILayout.PropertyField(_layerMask); 31 | EditorGUILayout.PropertyField(_textureScale); 32 | EditorGUILayout.PropertyField(_simulationSettings); 33 | 34 | serializedObject.ApplyModifiedProperties(); 35 | } 36 | } 37 | } -------------------------------------------------------------------------------- /Editor/Universal/VelocityCameraEditor.cs.meta: -------------------------------------------------------------------------------- 1 | fileFormatVersion: 2 2 | guid: 3c20774b0d454b5eb94d3ab4cbfaf8f7 3 | timeCreated: 1623700340 -------------------------------------------------------------------------------- /LICENSE.md: -------------------------------------------------------------------------------- 1 | MIT License 2 | 3 | Copyright (c) 2021 Jacob 4 | 5 | Permission is hereby granted, free of charge, to any person obtaining a copy 6 | of this software and associated documentation files (the "Software"), to deal 7 | in the Software without restriction, including without limitation the rights 8 | to use, copy, modify, merge, publish, distribute, sublicense, and/or sell 9 | copies of the Software, and to permit persons to whom the Software is 10 | furnished to do so, subject to the following conditions: 11 | 12 | The above copyright notice and this permission notice shall be included in all 13 | copies or substantial portions of the Software. 14 | 15 | THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR 16 | IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, 17 | FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE 18 | AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER 19 | LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, 20 | OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE 21 | SOFTWARE. -------------------------------------------------------------------------------- /LICENSE.md.meta: -------------------------------------------------------------------------------- 1 | fileFormatVersion: 2 2 | guid: f21e13358323cbb4bbc65722da270d56 3 | TextScriptImporter: 4 | externalObjects: {} 5 | userData: 6 | assetBundleName: 7 | assetBundleVariant: 8 | -------------------------------------------------------------------------------- /README.md: -------------------------------------------------------------------------------- 1 | # PixelGraphics 2 | 3 | [![Made with Unity](https://img.shields.io/badge/Made%20with-Unity-57b9d3.svg?style=flat&logo=unity)](https://unity3d.com) 4 | [![semantic-release](https://img.shields.io/badge/%20%20%F0%9F%93%A6%F0%9F%9A%80-semantic--release-e10079.svg)](https://github.com/semantic-release/semantic-release) 5 | 6 | [![Patreon](https://img.shields.io/endpoint.svg?url=https%3A%2F%2Fshieldsio-patreon.vercel.app%2Fapi%3Fusername%3Daarthificial%26type%3Dpatrons&style=for-the-badge)](https://www.patreon.com/aarthificial) 7 | 8 | PixelGraphics is a collection of interactive foliage shaders for Unity
