** 12 | **For People Fall Detection demo application, you may proceed the following steps :
** 13 | 14 | # Please download the following file from DROPBOX link 15 | [https://www.dropbox.com/s/41nivrxk9px14gy/main.exe?dl=0](https://www.dropbox.com/scl/fi/z18ain7xgiauer827iwep/main.exe?rlkey=16fclfrau57qao4ehe27g9rby&dl=0) 16 | ## Download FDS 'main' file: Please download by Dropbox linking as following, (150 MB) 17 | 18 | ## Running procedures in brief: 19 | 20 | ## (Step 1) Run main program (process_1) on your working directory 21 | 22 | (your_working_directory) $ ./main 23 | 24 | ## (Step 2) Edit json file for Radar installation parameters before running next program (process_2) 25 | 26 | edit mmWave_pc3OVH_fds.json 27 | 28 | ## (Step 3) Run process_2 on IDE environment 29 | 30 | run jb_FDS_Client_WINDOWS_v01.py 31 | 32 | ## (Step 4) got process_1 output data 33 | 34 | the process_1 output data is function of point cloud v6 based on our dedicated Algorithm 35 | 36 | objData = f(v6) 37 | 38 | ## (Step 5) write your stateMachine() function 39 | 40 | Please write your own stateMachine() which is the function of above objData 41 | 42 | for judging falling State, 43 | 44 | State = stateMachine(objData) 45 | 46 | ## Appendix I: 47 | 48 | for example: 49 | 50 | the following Algo_y and State waveform are shown as following, 51 | 52 | Algo_y := Green Line 53 | 54 | State := Yellow Line 55 | 56 | State is function of Algo_y 57 | 58 | State = f(Algo_y) 59 | 60 | 61 | ![image](https://user-images.githubusercontent.com/2010446/206073881-f9f894de-808b-4d16-83e6-1d94aa9e99e2.png) 62 | 63 | 64 | for example(v4958): 65 | 66 | picture left: process_1 output 67 | 68 | picture right: process_2 output 69 | 70 | ![image](https://user-images.githubusercontent.com/2010446/206364163-55b85838-2433-429c-8666-9bfdc404839d.png) 71 | 72 | 73 | 74 | ## Object data Struct: 75 | class objSM: 76 | def __init__(self,name = None,fdsData = None, state = None,live = None,sm_cnt = None): 77 | self.name = name #string, object Name 78 | self.data = fdsData #dictionary, fds data 79 | self.state = state #string , stateS = ['','idle','wait','wait_s','active','rising','squat','notify'] 80 | self.live = live #int 81 | self.max_inVal_keep = -10.0 #float, for check squat/falling 82 | self.min_inVal_keep = 0.0 #float 83 | self.sm_cnt = sm_cnt #int, start count when state entry to [Active] state 84 | self.sm_ykeep = 0.0 #float, keep yMean data for judget state when object signal lose 85 | self.center = (0,0) #float, object location, unit: m 86 | 87 | 88 | ## fdsData Struct: (Data type: dictionary) 89 | 90 | fdsDic: {'chk' : chk, 'aveA': aveA, 'dopA': dopA,'algoY': algoY,'curveA': d_A ,'cells': v_cells} 91 | chk : check data aviliable 92 | aveA: y average array of object height 93 | dopA: average array of object doppler 94 | algoY: algorithm of algoY data 95 | curveA: a series of algoY data 96 | cells: The position occupied by the cell group represents the object 97 | 98 | 99 | example: 100 | 101 | for obj in objA: #(where the objA is objSM type) 102 | print(f'JB>fn={fn} objName: {obj.name} state: {obj.state} obj.center= {np.round(obj.center,2)}m cells: {obj.data["cells"]}' ) 103 | print(f'JB>fn={fn} objData:\n {obj.data} ' ) 104 | 105 | 106 | print(f'JB>fn={fn} objData: {obj.data}') 107 | JB>fn=19757 objData: 108 | {'chk':True,'aveA':[2.332,1.906, 1.86, 2.1464, 2.720, 2.206, 1.775, 1.880, 1.138,1.371,2.008,1.658,1.137,0.803,0.8154], 109 | 'dopA': [0.0173, 0.286, 0.1772, -0.0884, 0.032, 0.120, -0.049, -0.594, -0.2099, 0.040, 0.162, 0.132, 0.0203, 0.0255, 0.2394], 110 | 'algoY': -4.0327, 'curveA': [0.0,0.0,0.007,0.0014,0.0021,0.00043,0.0012,0.0009,-0.004,-0.051,-0.003,-0.032,-0.556,-1.769,-1.625], 111 | 'cells': [(11, 11), (11, 12), (9, 10), (9, 12), (12, 11), (10, 12), (10, 11), (9, 11), (10, 13)]} 112 | 113 | ## State Machine state: [0:'',1:'idle',2:'wait',3:'wait_s',4:'active',5:'rising',6:'squat',7:'notify'] 114 | 115 | ## falling: 116 | 117 | falling 118 | 119 | ## leave detection area: 120 | 121 | leave 122 | 123 | 124 | ## squat: 125 | 126 | squart 127 | 128 | ## Parameter for Statemachine: 129 | 130 | ![FDS-GREENLINE](https://user-images.githubusercontent.com/2010446/209904267-6d906254-8735-42fc-b70e-e1089ee1ae7f.jpg) 131 | 132 | ## FDS falling Green 133 | ![fds_green](https://github.com/bigheadG/PCT_FDS/assets/2010446/6e19c655-b960-41f6-a69c-404c1ff8c366) 134 | 135 | ## FDS falling Red 136 | ![fds_red](https://github.com/bigheadG/PCT_FDS/assets/2010446/b37ed25f-fdb5-4d2e-be5d-a37f63245af5) 137 | 138 | ## Reference 139 | 140 | 141 | 1. LabGuide: [People counting Overhead reference guide](https://dev.ti.com/tirex/explore/node?node=AGn5r.xojDrrAKHxSfvzFg__VLyFKFf__LATEST) 142 | 143 | 2. TuningGuide_01: 144 | [3D_people_counting_tracker_layer_tuning_guide.pdf](https://github.com/bigheadG/mmWave_elink/files/7465690/3D_people_counting_tracker_layer_tuning_guide.pdf) 145 | 146 | 3. TuningGuide_02: 147 | [3D_people_counting_detection_layer_tuning_guide.pdf](https://github.com/bigheadG/mmWave_elink/files/7502420/3D_people_counting_detection_layer_tuning_guide.pdf) 148 | --------------------------------------------------------------------------------
