record = new ProducerRecord<>("yinew_applog", log);
39 | kafkaProducer.send(record);
40 | kafkaProducer.flush();
41 | }
42 | }
43 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/datagen/UserProfileDataGen.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.datagen;
2 |
3 | import org.apache.commons.lang3.RandomUtils;
4 | import org.apache.commons.lang3.StringUtils;
5 | import org.apache.hadoop.conf.Configuration;
6 | import org.apache.hadoop.hbase.TableName;
7 | import org.apache.hadoop.hbase.client.Connection;
8 | import org.apache.hadoop.hbase.client.ConnectionFactory;
9 | import org.apache.hadoop.hbase.client.Put;
10 | import org.apache.hadoop.hbase.client.Table;
11 | import org.apache.hadoop.hbase.util.Bytes;
12 |
13 | import java.io.IOException;
14 | import java.util.ArrayList;
15 |
16 | /**
17 | * @author 涛哥
18 | * @nick_name "deep as the sea"
19 | * @contact qq:657270652 wx:doit_edu
20 | * @site www.doitedu.cn
21 | * @date 2021-03-27
22 | * @desc 用户画像数据模拟器
23 | *
24 | * deviceid,k1=v1
25 | *
26 | * hbase中需要先创建好画像标签表
27 | * [root@hdp01 ~]# hbase shell
28 | * hbase> create 'yinew_profile','f'
29 | */
30 | public class UserProfileDataGen {
31 | public static void main(String[] args) throws IOException {
32 |
33 | Configuration conf = new Configuration();
34 | conf.set("hbase.zookeeper.quorum", "hdp01:2181,hdp02:2181,hdp03:2181");
35 |
36 | Connection conn = ConnectionFactory.createConnection(conf);
37 | Table table = conn.getTable(TableName.valueOf("yinew_profile"));
38 |
39 | ArrayList puts = new ArrayList<>();
40 | for (int i = 0; i < 100000; i++) {
41 |
42 | // 生成一个用户的画像标签数据
43 | String deviceId = StringUtils.leftPad(i + "", 6, "0");
44 | Put put = new Put(Bytes.toBytes(deviceId));
45 | for (int k = 1; k <= 100; k++) {
46 | String key = "tag" + k;
47 | String value = "v" + RandomUtils.nextInt(1, 3);
48 | put.addColumn(Bytes.toBytes("f"), Bytes.toBytes(key), Bytes.toBytes(value));
49 | }
50 |
51 | // 将这一条画像数据，添加到list中
52 | puts.add(put);
53 |
54 | // 攒满100条一批
55 | if(puts.size()==100) {
56 | table.put(puts);
57 | puts.clear();
58 | }
59 |
60 | }
61 |
62 | // 提交最后一批
63 | if(puts.size()>0) table.put(puts);
64 |
65 | conn.close();
66 | }
67 | }
68 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/Action.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import lombok.Data;
4 |
5 | @Data
6 | public class Action {
7 | private String msg;
8 | public Action(String msg) {
9 | this.msg = msg;
10 | }
11 | public void doSomeThing() {
12 | System.out.println(msg);
13 | }
14 | }
15 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/Applicant.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import lombok.Data;
4 |
5 | /**
6 | * 申请人，用作fact
7 | */
8 | @Data
9 | public class Applicant {
10 | private String name;
11 | private int age;
12 | private boolean valid;
13 | public Applicant(String name, int age) {
14 | this.name = name;
15 | this.age = age;
16 | this.valid = true;
17 | }
18 | }
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/CanalRecordBean.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import lombok.Data;
4 |
5 | import java.util.List;
6 |
7 | @Data
8 | public class CanalRecordBean {
9 |
10 | private List data;
11 | private String type;
12 |
13 | }
14 |
15 |
16 | @Data
17 | class RuleTableRecord{
18 |
19 | private String ruleName;
20 | private String ruleCode;
21 |
22 |
23 | }
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/DroolsDemo.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 |
4 | import org.kie.api.KieServices;
5 | import org.kie.api.runtime.KieContainer;
6 | import org.kie.api.runtime.KieSession;
7 |
8 | public class DroolsDemo {
9 |
10 | public static void main(String[] args) {
11 |
12 | KieServices kieServices = KieServices.Factory.get();
13 | //默认自动加载 META-INF/kmodule.xml
14 | KieContainer kieContainer = kieServices.getKieClasspathContainer();
15 | //kmodule.xml 中定义的 ksession name
16 | KieSession kieSession = kieContainer.newKieSession("all-rules");
17 |
18 |
19 | Applicant applicant = new Applicant("康康", 17);
20 |
21 | // 向引擎插入一个fact数据
22 | kieSession.insert(applicant);
23 | // 启动规则计算
24 | kieSession.fireAllRules();
25 |
26 | // 销毁kie会话
27 | kieSession.dispose();
28 |
29 | }
30 |
31 | }
32 |
33 |
34 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/DroolsDemo2.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import org.apache.commons.io.FileUtils;
4 | import org.kie.api.io.ResourceType;
5 | import org.kie.api.runtime.KieSession;
6 | import org.kie.internal.utils.KieHelper;
7 |
8 | import java.io.File;
9 | import java.io.IOException;
10 |
11 | public class DroolsDemo2 {
12 |
13 | public static void main(String[] args) throws IOException {
14 |
15 | KieHelper kieHelper = new KieHelper();
16 |
17 |
18 | String drlFilePath = "E:\\yinew_marketing\\dynamic_rule_engine\\src\\main\\resources\\rules\\test.drl";
19 | String s = FileUtils.readFileToString(new File(drlFilePath), "utf-8");
20 |
21 | kieHelper.addContent(s, ResourceType.DRL);
22 | KieSession kieSession = kieHelper.build().newKieSession();
23 |
24 |
25 | Applicant 康康 = new Applicant("康康", 16);
26 | kieSession.insert(康康);
27 | kieSession.fireAllRules();
28 |
29 |
30 | }
31 | }
32 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/FlinkDroolsCanalDemo.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import com.alibaba.fastjson.JSON;
4 | import com.alibaba.fastjson.JSONArray;
5 | import com.alibaba.fastjson.JSONObject;
6 | import lombok.extern.slf4j.Slf4j;
7 | import org.apache.flink.api.common.functions.MapFunction;
8 | import org.apache.flink.api.common.serialization.SimpleStringSchema;
9 | import org.apache.flink.api.common.state.BroadcastState;
10 | import org.apache.flink.api.common.state.MapStateDescriptor;
11 | import org.apache.flink.api.java.functions.KeySelector;
12 | import org.apache.flink.configuration.Configuration;
13 | import org.apache.flink.streaming.api.datastream.*;
14 | import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
15 | import org.apache.flink.streaming.api.functions.co.KeyedBroadcastProcessFunction;
16 | import org.apache.flink.streaming.connectors.kafka.FlinkKafkaConsumer;
17 | import org.apache.flink.util.Collector;
18 | import org.kie.api.io.ResourceType;
19 | import org.kie.api.runtime.KieSession;
20 | import org.kie.internal.utils.KieHelper;
21 |
22 | import java.util.Iterator;
23 | import java.util.Map;
24 | import java.util.Properties;
25 |
26 | /**
27 | * @author 涛哥
28 | * @nick_name "deep as the sea"
29 | * @contact qq:657270652 wx:doit_edu
30 | * @site www.doitedu.cn
31 | * @date 2021-04-06
32 | * @desc 测试准备：
33 | * kafka中创建applicant topic
34 | * [root@hdp03 kafka_2.11-2.0.0]# bin/kafka-topics.sh --create --topic applicant --replication-factor 1 --partitions 1 --zookeeper hdp01:2181
35 | * [root@hdp03 kafka_2.11-2.0.0]# bin/kafka-topics.sh --create --topic test_drools --replication-factor 1 --partitions 1 --zookeeper hdp01:2181
36 | *
37 | *
38 | *
39 | */
40 | @Slf4j
41 | public class FlinkDroolsCanalDemo {
42 |
43 | public static void main(String[] args) throws Exception {
44 |
45 | StreamExecutionEnvironment env = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(new Configuration());
46 |
47 | // 读申请信息流
48 | Properties props = new Properties();
49 | props.setProperty("bootstrap.servers", "hdp01:9092,hdp02:9092,hdp03:9092");
50 | props.setProperty("auto.offset.reset", "latest");
51 | FlinkKafkaConsumer applicantConsumer = new FlinkKafkaConsumer<>("applicant", new SimpleStringSchema(), props);
52 |
53 | // joke,18
54 | DataStreamSource applicantStrStream = env.addSource(applicantConsumer);
55 |
56 | // 将string流转成Applicant对象流
57 | SingleOutputStreamOperator applicantStream = applicantStrStream.map(new MapFunction() {
58 | @Override
59 | public Applicant map(String value) throws Exception {
60 | String[] split = value.split(",");
61 | return new Applicant(split[0],Integer.parseInt(split[1]));
62 | }
63 | });
64 |
65 | // 按照name来keyby
66 | KeyedStream keyedStream = applicantStream.keyBy(new KeySelector() {
67 | @Override
68 | public String getKey(Applicant value) throws Exception {
69 | return value.getName();
70 | }
71 | });
72 |
73 |
74 | // 读规则流，并广播
75 | FlinkKafkaConsumer ruleConsumer = new FlinkKafkaConsumer<>("test_drools", new SimpleStringSchema(), props);
76 | DataStreamSource ruleStream = env.addSource(ruleConsumer);
77 |
78 | MapStateDescriptor stateDescriptor = new MapStateDescriptor<>("ruleState", String.class, KieSession.class);
79 | BroadcastStream broadcastStream = ruleStream.broadcast(stateDescriptor);
80 |
81 | // connect两个流
82 | BroadcastConnectedStream connectedStream = keyedStream.connect(broadcastStream);
83 |
84 |
85 | // 处理
86 | SingleOutputStreamOperator result = connectedStream.process(new KeyedBroadcastProcessFunction() {
87 |
88 | BroadcastState broadcastState;
89 |
90 | /**
91 | * 处理数据流
92 | * @param applicant
93 | * @param ctx
94 | * @param out
95 | * @throws Exception
96 | */
97 | @Override
98 | public void processElement(Applicant applicant, ReadOnlyContext ctx, Collector out) throws Exception {
99 |
100 | Iterator> rulesIterator = broadcastState.iterator();
101 | while(rulesIterator.hasNext()){
102 | Map.Entry entry = rulesIterator.next();
103 | KieSession kieSession = entry.getValue();
104 |
105 | applicant.setValid(true);
106 | kieSession.insert(applicant);
107 | kieSession.fireAllRules();
108 |
109 | if(applicant.isValid()){
110 | out.collect(applicant.getName()+",合法");
111 | }else{
112 | out.collect(applicant.getName()+",不合法");
113 | }
114 |
115 | }
116 | }
117 |
118 | /**
119 | * 处理广播流中的数据
120 | * @param value
121 | * @param ctx
122 | * @param out
123 | * @throws Exception
124 | */
125 | @Override
126 | public void processBroadcastElement(String value, Context ctx, Collector out) throws Exception {
127 | broadcastState = ctx.getBroadcastState(stateDescriptor);
128 |
129 | // 进来的规则信息，是canal从mysql中监听到一个json串
130 | CanalRecordBean canalRecordBean = JSON.parseObject(value, CanalRecordBean.class);
131 |
132 | // 取出规则表数据
133 | RuleTableRecord tableRec = canalRecordBean.getData().get(0);
134 |
135 | String ruleName = tableRec.getRuleName();
136 | String ruleCode = tableRec.getRuleCode();
137 |
138 | KieSession kieSession = new KieHelper().addContent(ruleCode, ResourceType.DRL).build().newKieSession();
139 |
140 | broadcastState.put(ruleName,kieSession);
141 |
142 | }
143 | });
144 |
145 | // 打印
146 | result.print();
147 |
148 | env.execute();
149 |
150 |
151 | }
152 | }
153 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/FlinkDroolsDemo.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import lombok.extern.slf4j.Slf4j;
4 | import org.apache.flink.api.common.functions.MapFunction;
5 | import org.apache.flink.api.common.serialization.SimpleStringSchema;
6 | import org.apache.flink.api.common.state.BroadcastState;
7 | import org.apache.flink.api.common.state.MapStateDescriptor;
8 | import org.apache.flink.api.java.functions.KeySelector;
9 | import org.apache.flink.configuration.Configuration;
10 | import org.apache.flink.streaming.api.datastream.*;
11 | import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
12 | import org.apache.flink.streaming.api.functions.co.KeyedBroadcastProcessFunction;
13 | import org.apache.flink.streaming.connectors.kafka.FlinkKafkaConsumer;
14 | import org.apache.flink.util.Collector;
15 | import org.kie.api.io.ResourceType;
16 | import org.kie.api.runtime.KieSession;
17 | import org.kie.internal.utils.KieHelper;
18 |
19 | import java.util.Iterator;
20 | import java.util.Map;
21 | import java.util.Properties;
22 |
23 | /**
24 | * @author 涛哥
25 | * @nick_name "deep as the sea"
26 | * @contact qq:657270652 wx:doit_edu
27 | * @site www.doitedu.cn
28 | * @date 2021-04-06
29 | * @desc 测试准备：
30 | * kafka中创建applicant topic
31 | * [root@hdp03 kafka_2.11-2.0.0]# bin/kafka-topics.sh --create --topic applicant --replication-factor 1 --partitions 1 --zookeeper hdp01:2181
32 | * [root@hdp03 kafka_2.11-2.0.0]# bin/kafka-topics.sh --create --topic test_drools --replication-factor 1 --partitions 1 --zookeeper hdp01:2181
33 | *
34 | *
35 | *
36 | */
37 | @Slf4j
38 | public class FlinkDroolsDemo {
39 |
40 | public static void main(String[] args) throws Exception {
41 |
42 | StreamExecutionEnvironment env = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(new Configuration());
43 |
44 | // 读申请信息流
45 | Properties props = new Properties();
46 | props.setProperty("bootstrap.servers", "hdp01:9092,hdp02:9092,hdp03:9092");
47 | props.setProperty("auto.offset.reset", "latest");
48 | FlinkKafkaConsumer applicantConsumer = new FlinkKafkaConsumer<>("applicant", new SimpleStringSchema(), props);
49 |
50 | // joke,18
51 | DataStreamSource applicantStrStream = env.addSource(applicantConsumer);
52 |
53 | // 将string流转成Applicant对象流
54 | SingleOutputStreamOperator applicantStream = applicantStrStream.map(new MapFunction() {
55 | @Override
56 | public Applicant map(String value) throws Exception {
57 | String[] split = value.split(",");
58 | return new Applicant(split[0],Integer.parseInt(split[1]));
59 | }
60 | });
61 |
62 | // 按照name来keyby
63 | KeyedStream keyedStream = applicantStream.keyBy(new KeySelector() {
64 | @Override
65 | public String getKey(Applicant value) throws Exception {
66 | return value.getName();
67 | }
68 | });
69 |
70 |
71 | // 读规则流，并广播
72 | FlinkKafkaConsumer ruleConsumer = new FlinkKafkaConsumer<>("test_drools", new SimpleStringSchema(), props);
73 | DataStreamSource ruleStream = env.addSource(ruleConsumer);
74 |
75 | MapStateDescriptor stateDescriptor = new MapStateDescriptor<>("ruleState", String.class, KieSession.class);
76 | BroadcastStream broadcastStream = ruleStream.broadcast(stateDescriptor);
77 |
78 | // connect两个流
79 | BroadcastConnectedStream connectedStream = keyedStream.connect(broadcastStream);
80 |
81 |
82 | // 处理
83 | SingleOutputStreamOperator result = connectedStream.process(new KeyedBroadcastProcessFunction() {
84 |
85 | BroadcastState broadcastState;
86 |
87 | /**
88 | * 处理数据流
89 | * @param applicant
90 | * @param ctx
91 | * @param out
92 | * @throws Exception
93 | */
94 | @Override
95 | public void processElement(Applicant applicant, ReadOnlyContext ctx, Collector out) throws Exception {
96 |
97 | Iterator> rulesIterator = broadcastState.iterator();
98 | while(rulesIterator.hasNext()){
99 | Map.Entry entry = rulesIterator.next();
100 | KieSession kieSession = entry.getValue();
101 |
102 | applicant.setValid(true);
103 | kieSession.insert(applicant);
104 | kieSession.fireAllRules();
105 |
106 | if(applicant.isValid()){
107 | out.collect(applicant.getName()+",合法");
108 | }else{
109 | out.collect(applicant.getName()+",不合法");
110 | }
111 |
112 | }
113 | }
114 |
115 | /**
116 | * 处理广播流中的数据
117 | * @param value
118 | * @param ctx
119 | * @param out
120 | * @throws Exception
121 | */
122 | @Override
123 | public void processBroadcastElement(String value, Context ctx, Collector out) throws Exception {
124 | broadcastState = ctx.getBroadcastState(stateDescriptor);
125 |
126 | // value: rule-name,rule-code
127 | String[] split = value.split(",");
128 |
129 | KieHelper kieHelper = new KieHelper();
130 | KieSession kieSession = kieHelper.addContent(split[1], ResourceType.DRL).build().newKieSession();
131 |
132 |
133 | log.warn("收到一条新的规则，并插入了state");
134 | broadcastState.put(split[0],kieSession);
135 |
136 | }
137 | });
138 |
139 | // 打印
140 | result.print();
141 |
142 | env.execute();
143 |
144 |
145 | }
146 | }
147 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/ReadDrlToKafka.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import org.apache.commons.io.FileUtils;
4 | import org.apache.kafka.clients.producer.KafkaProducer;
5 | import org.apache.kafka.clients.producer.ProducerRecord;
6 |
7 | import java.io.File;
8 | import java.io.IOException;
9 | import java.util.Properties;
10 |
11 | public class ReadDrlToKafka {
12 | public static void main(String[] args) throws IOException {
13 |
14 | Properties props = new Properties();
15 | props.setProperty("bootstrap.servers", "hdp01:9092,hdp02:9092,hdp03:9092");
16 | props.put("key.serializer", "org.apache.kafka.common.serialization.StringSerializer");
17 | props.put("value.serializer", "org.apache.kafka.common.serialization.StringSerializer");
18 | KafkaProducer kafkaProducer = new KafkaProducer<>(props);
19 |
20 | String s = FileUtils.readFileToString(new File("dynamic_rule_engine/src/main/resources/rules/flink.drl"), "utf-8");
21 |
22 | ProducerRecord record = new ProducerRecord<>("test_drools", "rule1,"+s);
23 | kafkaProducer.send(record);
24 | kafkaProducer.flush();
25 |
26 | }
27 | }
28 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/ReadDrlToMySql.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import org.apache.commons.io.FileUtils;
4 | import org.apache.kafka.clients.producer.KafkaProducer;
5 | import org.apache.kafka.clients.producer.ProducerRecord;
6 |
7 | import java.io.File;
8 | import java.io.IOException;
9 | import java.sql.*;
10 | import java.util.Properties;
11 |
12 | /**
13 | * @author 涛哥
14 | * @nick_name "deep as the sea"
15 | * @contact qq:657270652 wx:doit_edu
16 | * @site www.doitedu.cn
17 | * @date 2021-04-07
18 | * @desc
19 | *
20 | * `id` int(11) NOT NULL AUTO_INCREMENT,
21 | * `rule_name` varchar(255) DEFAULT NULL,
22 | * `rule_code` varchar(4096) DEFAULT NULL,
23 | * `rule_status` int(11) DEFAULT NULL,
24 | * `rule_type` varchar(255) DEFAULT NULL,
25 | * `rule_version` varchar(255) DEFAULT NULL,
26 | * `cnt_sqls` varchar(4096) DEFAULT NULL,
27 | * `seq_sqls` varchar(4096) DEFAULT NULL,
28 | * `rule_creator` varchar(255) DEFAULT NULL,
29 | * `rule_auditor` varchar(255) DEFAULT NULL,
30 | * `create_time` datetime DEFAULT NULL,
31 | * `update_time` datetime DEFAULT NULL,
32 | *
33 | */
34 | public class ReadDrlToMySql {
35 | public static void main(String[] args) throws IOException, SQLException {
36 | String ruleName = "rule2";
37 | String ruleCode = FileUtils.readFileToString(new File("dynamic_rule_engine/rules_drl/rule2.drl"), "utf-8");
38 | int ruleStatus = 1;
39 | String ruleType = "1";
40 | String ruleVersion = "1";
41 | String cntSqls = FileUtils.readFileToString(new File("dynamic_rule_engine/rules_drl/rule2_cnt.sql"), "utf-8");
42 | String seqSqls = FileUtils.readFileToString(new File("dynamic_rule_engine/rules_drl/rule2_seq.sql"), "utf-8");
43 | String ruleCreator = "doitedu";
44 | String ruleAuditor = "hunter.d";
45 | Date createTime = new Date(System.currentTimeMillis());
46 | Date updateTime = createTime;
47 | Connection conn = DriverManager.getConnection("jdbc:mysql://hdp01:3306/realtimedw", "root", "ABC123abc.123");
48 | PreparedStatement pst = conn.prepareStatement("insert into yinew_drl_rule (rule_name,rule_code,rule_status,rule_type,rule_version,cnt_sqls,seq_sqls,rule_creator,rule_auditor,create_time,update_time) " +
49 | "values (?,?,?,?,?,?,?,?,?,?,?)");
50 | pst.setString(1,ruleName);
51 | pst.setString(2,ruleCode);
52 | pst.setInt(3,ruleStatus);
53 | pst.setString(4,ruleType);
54 | pst.setString(5,ruleVersion);
55 | pst.setString(6,cntSqls);
56 | pst.setString(7,seqSqls);
57 | pst.setString(8,ruleCreator);
58 | pst.setString(9,ruleAuditor);
59 | pst.setDate(10,createTime);
60 | pst.setDate(11,updateTime);
61 |
62 | boolean execute = pst.execute();
63 |
64 | pst.close();
65 | conn.close();
66 |
67 |
68 | }
69 | }
70 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/RedisDemo.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import com.alibaba.fastjson.JSON;
4 | import redis.clients.jedis.Jedis;
5 |
6 | public class RedisDemo {
7 |
8 | public static void main(String[] args) {
9 |
10 | Jedis jedis = new Jedis("hdp02", 6379);
11 |
12 | String res = jedis.ping();
13 | System.out.println(res);
14 |
15 | // 插入一条扁平数据
16 | jedis.set("key01","value01");
17 |
18 | String res2 = jedis.get("key01");
19 | System.out.println(res2);
20 |
21 |
22 | // 插入一个json
23 | jedis.set("key02","{'a':1,'b':2,c:[4,5,6]}");
24 | String res3 = jedis.get("key02");
25 | System.out.println(res3);
26 |
27 |
28 | // 插入一个person对象
29 | Person p = new Person("宴梅", 30);
30 | String pjson = JSON.toJSONString(p);
31 | jedis.set("yanmei",pjson);
32 | String res4 = jedis.get("yanmei");
33 | System.out.println(res4);
34 |
35 | }
36 | }
37 |
38 | class Person{
39 | String name;
40 | int age;
41 |
42 | public Person(String name, int age) {
43 | this.name = name;
44 | this.age = age;
45 | }
46 |
47 | public String getName() {
48 | return name;
49 | }
50 |
51 | public void setName(String name) {
52 | this.name = name;
53 | }
54 |
55 | public int getAge() {
56 | return age;
57 | }
58 |
59 | public void setAge(int age) {
60 | this.age = age;
61 | }
62 | }
63 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/demos/Slf4jLog4jDemo.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.demos;
2 |
3 | import lombok.extern.slf4j.Slf4j;
4 | import org.slf4j.Logger;
5 | import org.slf4j.LoggerFactory;
6 |
7 |
8 | @Slf4j
9 | public class Slf4jLog4jDemo {
10 |
11 | public static void main(String[] args) throws InterruptedException {
12 |
13 | while(true) {
14 | log.debug("哈哈哈哈哈");
15 | log.info("哈哈哈哈哈");
16 | log.warn("哈哈哈哈哈");
17 | log.error("哈哈哈哈哈");
18 |
19 | Thread.sleep(1000);
20 | }
21 |
22 | }
23 | }
24 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/engine/RuleEngineV1.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.engine;
2 |
3 | import cn.doitedu.dynamic_rule.functions.DeviceKeySelector;
4 | import cn.doitedu.dynamic_rule.functions.Json2BeanMapFunction;
5 | import cn.doitedu.dynamic_rule.functions.RuleProcessFunction;
6 | import cn.doitedu.dynamic_rule.functions.SourceFunctions;
7 | import cn.doitedu.dynamic_rule.pojo.LogBean;
8 | import cn.doitedu.dynamic_rule.pojo.ResultBean;
9 | import org.apache.avro.data.Json;
10 | import org.apache.flink.configuration.Configuration;
11 | import org.apache.flink.streaming.api.datastream.DataStreamSource;
12 | import org.apache.flink.streaming.api.datastream.KeyedStream;
13 | import org.apache.flink.streaming.api.datastream.SingleOutputStreamOperator;
14 | import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
15 |
16 | /**
17 | * @author 涛哥
18 | * @nick_name "deep as the sea"
19 | * @contact qq:657270652 wx:doit_edu
20 | * @site www.doitedu.cn
21 | * @date 2021-03-28
22 | * @desc 静态规则引擎版本1主程序
23 | */
24 | public class RuleEngineV1 {
25 |
26 | public static void main(String[] args) throws Exception {
27 |
28 | StreamExecutionEnvironment env = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(new Configuration());
29 |
30 | // 添加一个消费kafka中用户实时行为事件数据的source
31 | DataStreamSource logStream = env.addSource(SourceFunctions.getKafkaEventSource());
32 |
33 | // 将json格式的数据，转成 logbean格式的数据
34 | SingleOutputStreamOperator beanStream = logStream.map(new Json2BeanMapFunction());
35 |
36 | // 对数据按用户deviceid分key
37 | KeyedStream keyed = beanStream.keyBy(new DeviceKeySelector());
38 |
39 | // 开始核心计算处理
40 | SingleOutputStreamOperator resultStream = keyed.process(new RuleProcessFunction());
41 |
42 | // 打印
43 | resultStream.print();
44 |
45 | env.execute();
46 | }
47 | }
48 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/engine/RuleEngineV2.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.engine;
2 |
3 | import cn.doitedu.dynamic_rule.functions.*;
4 | import cn.doitedu.dynamic_rule.pojo.LogBean;
5 | import cn.doitedu.dynamic_rule.pojo.ResultBean;
6 | import org.apache.flink.configuration.Configuration;
7 | import org.apache.flink.streaming.api.datastream.DataStreamSource;
8 | import org.apache.flink.streaming.api.datastream.KeyedStream;
9 | import org.apache.flink.streaming.api.datastream.SingleOutputStreamOperator;
10 | import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
11 |
12 | /**
13 | * @author 涛哥
14 | * @nick_name "deep as the sea"
15 | * @contact qq:657270652 wx:doit_edu
16 | * @site www.doitedu.cn
17 | * @date 2021-03-28
18 | * @desc 静态规则引擎版本2主程序
19 | * 相对于v1.0来说，只有一处改变： keyed.process（这里用了 RuleProcessFunctionV2）
20 | */
21 | public class RuleEngineV2 {
22 |
23 | public static void main(String[] args) throws Exception {
24 |
25 | StreamExecutionEnvironment env = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(new Configuration());
26 |
27 | // 添加一个消费kafka中用户实时行为事件数据的source
28 | DataStreamSource logStream = env.addSource(SourceFunctions.getKafkaEventSource());
29 |
30 | // 将json格式的数据，转成 logBean格式的数据
31 | SingleOutputStreamOperator beanStream = logStream.map(new Json2BeanMapFunction());
32 |
33 | // 对数据按用户deviceid分key
34 | KeyedStream keyed = beanStream.keyBy(new DeviceKeySelector());
35 |
36 | // 开始核心计算处理
37 | SingleOutputStreamOperator resultStream = keyed.process(new RuleProcessFunctionV2());
38 |
39 | // 打印
40 | resultStream.print();
41 |
42 | env.execute();
43 | }
44 | }
45 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/engine/RuleEngineV3.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.engine;
2 |
3 | import cn.doitedu.dynamic_rule.functions.*;
4 | import cn.doitedu.dynamic_rule.pojo.LogBean;
5 | import cn.doitedu.dynamic_rule.pojo.ResultBean;
6 | import org.apache.flink.configuration.Configuration;
7 | import org.apache.flink.streaming.api.datastream.DataStreamSource;
8 | import org.apache.flink.streaming.api.datastream.KeyedStream;
9 | import org.apache.flink.streaming.api.datastream.SingleOutputStreamOperator;
10 | import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
11 |
12 | /**
13 | * @author 涛哥
14 | * @nick_name "deep as the sea"
15 | * @contact qq:657270652 wx:doit_edu
16 | * @site www.doitedu.cn
17 | * @date 2021-03-28
18 | * @desc 静态规则引擎版本2主程序
19 | * 相对于v1.0来说，只有一处改变： keyed.process（这里用了 RuleProcessFunctionV2）
20 | */
21 | public class RuleEngineV3 {
22 |
23 | public static void main(String[] args) throws Exception {
24 |
25 | StreamExecutionEnvironment env = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(new Configuration());
26 |
27 | // 添加一个消费kafka中用户实时行为事件数据的source
28 | DataStreamSource logStream = env.addSource(SourceFunctions.getKafkaEventSource());
29 |
30 | // 将json格式的数据，转成 logBean格式的数据
31 | SingleOutputStreamOperator beanStream = logStream.map(new Json2BeanMapFunction());
32 |
33 | // 对数据按用户deviceid分key
34 | KeyedStream keyed = beanStream.keyBy(new DeviceKeySelector());
35 |
36 | // 开始核心计算处理
37 | SingleOutputStreamOperator resultStream = keyed.process(new RuleProcessFunctionV3());
38 |
39 | // 打印
40 | resultStream.print();
41 |
42 | env.execute();
43 | }
44 | }
45 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/engine/RuleEngineV4.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.engine;
2 |
3 | import cn.doitedu.dynamic_rule.functions.*;
4 | import cn.doitedu.dynamic_rule.pojo.LogBean;
5 | import cn.doitedu.dynamic_rule.pojo.ResultBean;
6 | import org.apache.flink.configuration.Configuration;
7 | import org.apache.flink.streaming.api.datastream.DataStreamSource;
8 | import org.apache.flink.streaming.api.datastream.KeyedStream;
9 | import org.apache.flink.streaming.api.datastream.SingleOutputStreamOperator;
10 | import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
11 |
12 | /**
13 | * @author 涛哥
14 | * @nick_name "deep as the sea"
15 | * @contact qq:657270652 wx:doit_edu
16 | * @site www.doitedu.cn
17 | * @date 2021-03-28
18 | * @desc 静态规则引擎版本2主程序
19 | * 相对于v1.0来说，只有一处改变： keyed.process（这里用了 RuleProcessFunctionV2）
20 | */
21 | public class RuleEngineV4 {
22 |
23 | public static void main(String[] args) throws Exception {
24 |
25 | StreamExecutionEnvironment env = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(new Configuration());
26 |
27 | // 添加一个消费kafka中用户实时行为事件数据的source
28 | DataStreamSource logStream = env.addSource(SourceFunctions.getKafkaEventSource());
29 |
30 | // 将json格式的数据，转成 logBean格式的数据
31 | SingleOutputStreamOperator beanStream = logStream.map(new Json2BeanMapFunction());
32 |
33 | // 对数据按用户deviceid分key
34 | // TODO 后续可以升级改造成 动态keyBy
35 | KeyedStream keyed = beanStream.keyBy(new DeviceKeySelector());
36 |
37 | // 开始核心计算处理
38 | SingleOutputStreamOperator resultStream = keyed.process(new RuleProcessFunctionV4());
39 |
40 | // 打印
41 | resultStream.print();
42 |
43 | env.execute();
44 | }
45 | }
46 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/engine/RuleEngineV5.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.engine;
2 |
3 | import cn.doitedu.dynamic_rule.functions.*;
4 | import cn.doitedu.dynamic_rule.pojo.LogBean;
5 | import cn.doitedu.dynamic_rule.pojo.ResultBean;
6 | import cn.doitedu.dynamic_rule.utils.StateDescUtil;
7 | import org.apache.flink.configuration.Configuration;
8 | import org.apache.flink.streaming.api.datastream.*;
9 | import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
10 |
11 | /**
12 | * @author 涛哥
13 | * @nick_name "deep as the sea"
14 | * @contact qq:657270652 wx:doit_edu
15 | * @site www.doitedu.cn
16 | * @date 2021-03-28
17 | * @desc 静态规则引擎版本2主程序
18 | * 相对于v4.0来说，只有一处改变： 新增了规则流的读取
19 | */
20 | public class RuleEngineV5 {
21 |
22 | public static void main(String[] args) throws Exception {
23 |
24 | StreamExecutionEnvironment env = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(new Configuration());
25 |
26 | // 添加一个消费kafka中用户实时行为事件数据的source
27 | DataStreamSource logStream = env.addSource(SourceFunctions.getKafkaEventSource());
28 |
29 | // 将json格式的数据，转成 logBean格式的数据
30 | SingleOutputStreamOperator beanStream = logStream.map(new Json2BeanMapFunction());
31 |
32 | // 对数据按用户deviceid分key
33 | // TODO 后续可以升级改造成 动态keyBy
34 | KeyedStream keyed = beanStream.keyBy(new DeviceKeySelector());
35 |
36 | // 读取规则信息流
37 | DataStreamSource ruleStream = env.addSource(SourceFunctions.getKafkaRuleSource());
38 | // 广播
39 | BroadcastStream broadcastStream = ruleStream.broadcast(StateDescUtil.ruleKieStateDesc);
40 |
41 | // 连接 事件流 & 规则广播流
42 | BroadcastConnectedStream connected = keyed.connect(broadcastStream);
43 |
44 | // 开始核心计算处理
45 | SingleOutputStreamOperator resultStream = connected.process(new RuleProcessFunctionV5());
46 |
47 | // 打印
48 | resultStream.print();
49 |
50 | env.execute();
51 | }
52 | }
53 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/functions/DeviceKeySelector.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.functions;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import org.apache.flink.api.java.functions.KeySelector;
5 |
6 | public class DeviceKeySelector implements KeySelector {
7 | @Override
8 | public String getKey(LogBean value) throws Exception {
9 |
10 | return value.getDeviceId();
11 | }
12 | }
13 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/functions/Json2BeanMapFunction.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.functions;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import com.alibaba.fastjson.JSON;
5 | import org.apache.flink.api.common.functions.MapFunction;
6 |
7 | public class Json2BeanMapFunction implements MapFunction {
8 | @Override
9 | public LogBean map(String value) throws Exception {
10 | return JSON.parseObject(value,LogBean.class);
11 | }
12 | }
13 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/functions/RuleProcessFunction.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.functions;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.ResultBean;
5 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
6 | import cn.doitedu.dynamic_rule.service.*;
7 | import cn.doitedu.dynamic_rule.utils.RuleSimulator;
8 | import org.apache.flink.api.common.state.ListState;
9 | import org.apache.flink.api.common.state.ListStateDescriptor;
10 | import org.apache.flink.configuration.Configuration;
11 | import org.apache.flink.streaming.api.functions.KeyedProcessFunction;
12 | import org.apache.flink.util.Collector;
13 |
14 | /**
15 | * @author 涛哥
16 | * @nick_name "deep as the sea"
17 | * @contact qq:657270652 wx:doit_edu
18 | * @site www.doitedu.cn
19 | * @date 2021-03-28
20 | * @desc 规则核心处理函数
21 | */
22 | public class RuleProcessFunction extends KeyedProcessFunction {
23 |
24 | private UserProfileQueryService userProfileQueryService;
25 | private UserActionCountQueryService userActionCountQueryService;
26 | private UserActionSequenceQueryService userActionSequenceQueryService;
27 |
28 | ListState eventState;
29 |
30 | RuleParam ruleParam;
31 |
32 | @Override
33 | public void open(Configuration parameters) throws Exception {
34 |
35 | /**
36 | * 准备一个存储明细事件的state
37 | */
38 | ListStateDescriptor desc = new ListStateDescriptor<>("eventState", LogBean.class);
39 | eventState = getRuntimeContext().getListState(desc);
40 | /**
41 | * 构造底层的核心查询服务
42 | */
43 | userProfileQueryService = new UserProfileQueryServiceHbaseImpl();
44 | userActionCountQueryService = new UserActionCountQueryServiceStateImpl(eventState);
45 | userActionSequenceQueryService = new UserActionSequenceQueryServiceStateImpl(eventState);
46 |
47 | /**
48 | * 获取规则参数
49 | */
50 | ruleParam = RuleSimulator.getRuleParam();
51 |
52 |
53 |
54 | }
55 |
56 | @Override
57 | public void processElement(LogBean logBean, Context ctx, Collector out) throws Exception {
58 | // 将收到的事件放入历史明细state存储中
59 | eventState.add(logBean);
60 |
61 |
62 | // 判断是否满足触发条件
63 | if (ruleParam.getTriggerParam().getEventId().equals(logBean.getEventId())) {
64 | System.out.println("规则计算被触发：" + logBean.getDeviceId() + ","+logBean.getEventId());
65 |
66 | // 查询画像条件
67 | boolean profileMatch = userProfileQueryService.judgeProfileCondition(logBean.getDeviceId(), ruleParam);
68 | if(!profileMatch) return;
69 |
70 | // 查询行为次数条件
71 | boolean countMatch = userActionCountQueryService.queryActionCounts("", ruleParam);
72 | if(!countMatch) return;
73 |
74 | // 查询行为序列条件
75 | boolean sequenceMatch = userActionSequenceQueryService.queryActionSequence(null, ruleParam);
76 | if(!sequenceMatch) return;
77 |
78 |
79 | // 输出一个规则匹配成功的结果
80 | ResultBean resultBean = new ResultBean();
81 | resultBean.setTimeStamp(logBean.getTimeStamp());
82 | resultBean.setRuleId(ruleParam.getRuleName());
83 | resultBean.setDeviceId(logBean.getDeviceId());
84 |
85 | out.collect(resultBean);
86 | }
87 | }
88 | }
89 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/functions/RuleProcessFunctionV3.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.functions;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.ResultBean;
5 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
6 | import cn.doitedu.dynamic_rule.service.*;
7 | import cn.doitedu.dynamic_rule.utils.RuleSimulator;
8 | import org.apache.flink.api.common.state.ListState;
9 | import org.apache.flink.api.common.state.ListStateDescriptor;
10 | import org.apache.flink.api.common.state.StateTtlConfig;
11 | import org.apache.flink.api.common.time.Time;
12 | import org.apache.flink.configuration.Configuration;
13 | import org.apache.flink.streaming.api.functions.KeyedProcessFunction;
14 | import org.apache.flink.util.Collector;
15 |
16 | /**
17 | * @author 涛哥
18 | * @nick_name "deep as the sea"
19 | * @contact qq:657270652 wx:doit_edu
20 | * @site www.doitedu.cn
21 | * @date 2021-03-28
22 | * @desc 规则核心处理函数版本3.0
23 | */
24 | public class RuleProcessFunctionV3 extends KeyedProcessFunction {
25 |
26 | QueryRouterV3 queryRouterV3;
27 |
28 | ListState eventState;
29 |
30 | RuleParam ruleParam;
31 |
32 | @Override
33 | public void open(Configuration parameters) throws Exception {
34 |
35 |
36 | // 构造一个查询路由控制器
37 | queryRouterV3 = new QueryRouterV3();
38 |
39 |
40 | /**
41 | * 获取规则参数
42 | * TODO 规则的获取，现在是通过模拟器生成
43 | * TODO 后期需要改造成从外部获取
44 | */
45 | ruleParam = RuleSimulator.getRuleParam();
46 |
47 | /**
48 | * 准备一个存储明细事件的state
49 | * 控制state的ttl周期为最近2小时
50 | */
51 | ListStateDescriptor desc = new ListStateDescriptor<>("eventState", LogBean.class);
52 | StateTtlConfig ttlConfig = StateTtlConfig.newBuilder(Time.hours(2)).updateTtlOnCreateAndWrite().build();
53 | desc.enableTimeToLive(ttlConfig);
54 | eventState = getRuntimeContext().getListState(desc);
55 |
56 | }
57 |
58 |
59 | /**
60 | * 规则计算核心方法
61 | * @param logBean
62 | * @param ctx
63 | * @param out
64 | * @throws Exception
65 | */
66 | @Override
67 | public void processElement(LogBean logBean, Context ctx, Collector out) throws Exception {
68 |
69 | // 将收到的事件放入历史明细state存储中
70 | // 超过2小时的logBean会被自动清除（前面设置了ttl存活时长）
71 | eventState.add(logBean);
72 |
73 |
74 |
75 | /**
76 | * 主逻辑，进行规则触发和计算
77 | */
78 | if (ruleParam.getTriggerParam().getEventId().equals(logBean.getEventId())) {
79 | System.out.println("规则计算被触发：" + logBean.getDeviceId() + ","+logBean.getEventId());
80 |
81 | boolean b1 = queryRouterV3.profileQuery(logBean, ruleParam);
82 | if(!b1) return;
83 |
84 | boolean b2 = queryRouterV3.sequenceConditionQuery(logBean, ruleParam, eventState);
85 | if(!b2) return;
86 |
87 | boolean b3 = queryRouterV3.countConditionQuery(logBean, ruleParam, eventState);
88 | if(!b3) return;
89 |
90 |
91 | // 输出一个规则匹配成功的结果
92 | ResultBean resultBean = new ResultBean();
93 | resultBean.setTimeStamp(logBean.getTimeStamp());
94 | resultBean.setRuleId(ruleParam.getRuleName());
95 | resultBean.setDeviceId(logBean.getDeviceId());
96 |
97 | out.collect(resultBean);
98 | }
99 | }
100 | }
101 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/functions/RuleProcessFunctionV4.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.functions;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.ResultBean;
5 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
6 | import cn.doitedu.dynamic_rule.service.QueryRouterV4;
7 | import cn.doitedu.dynamic_rule.utils.RuleSimulator;
8 | import lombok.extern.slf4j.Slf4j;
9 | import org.apache.flink.api.common.state.ListState;
10 | import org.apache.flink.api.common.state.ListStateDescriptor;
11 | import org.apache.flink.api.common.state.StateTtlConfig;
12 | import org.apache.flink.api.common.time.Time;
13 | import org.apache.flink.configuration.Configuration;
14 | import org.apache.flink.streaming.api.functions.KeyedProcessFunction;
15 | import org.apache.flink.util.Collector;
16 |
17 | /**
18 | * @author 涛哥
19 | * @nick_name "deep as the sea"
20 | * @contact qq:657270652 wx:doit_edu
21 | * @site www.doitedu.cn
22 | * @date 2021-03-28
23 | * @desc 规则核心处理函数版本4.0
24 | */
25 | @Slf4j
26 | public class RuleProcessFunctionV4 extends KeyedProcessFunction {
27 |
28 | QueryRouterV4 queryRouterV4;
29 |
30 | ListState eventState;
31 |
32 | // RuleParam ruleParam;
33 |
34 | @Override
35 | public void open(Configuration parameters) throws Exception {
36 |
37 | /*
38 | * 获取规则参数
39 | * TODO 规则的获取，现在是通过模拟器生成
40 | * TODO 后期需要改造成从外部获取
41 | */
42 | // ruleParam = RuleSimulator.getRuleParam();
43 |
44 | /*
45 | * 准备一个存储明细事件的state
46 | * 控制state的ttl周期为最近2小时
47 | */
48 | ListStateDescriptor desc = new ListStateDescriptor<>("eventState", LogBean.class);
49 | StateTtlConfig ttlConfig = StateTtlConfig.newBuilder(Time.hours(2)).updateTtlOnCreateAndWrite().build();
50 | desc.enableTimeToLive(ttlConfig);
51 | eventState = getRuntimeContext().getListState(desc);
52 |
53 | // 构造一个查询路由控制器
54 | queryRouterV4 = new QueryRouterV4(eventState);
55 |
56 | }
57 |
58 |
59 | /**
60 | * 规则计算核心方法
61 | * @param logBean 事件bean
62 | * @param ctx 上下文
63 | * @param out 输出
64 | * @throws Exception 异常
65 | */
66 | @Override
67 | public void processElement(LogBean logBean, Context ctx, Collector out) throws Exception {
68 |
69 | // 将收到的事件放入历史明细state存储中
70 | // 超过2小时的logBean会被自动清除（前面设置了ttl存活时长）
71 | eventState.add(logBean);
72 |
73 | // TODO 重大bug，下面的处理过程会不断修改ruleParam中条件的时间字段，如果不在这里重新获取规则，则下一次触发计算时，条件已经不是原来的条件了
74 | RuleParam ruleParam = RuleSimulator.getRuleParam();
75 |
76 |
77 | /*
78 | * 主逻辑，进行规则触发和计算
79 | */
80 | if (ruleParam.getTriggerParam().getEventId().equals(logBean.getEventId())) {
81 | log.debug("规则:{},用户:{},触发事件:{},触发时间:{}", ruleParam.getRuleName(),logBean.getDeviceId(),logBean.getEventId(),logBean.getTimeStamp());
82 |
83 | boolean b1 = queryRouterV4.profileQuery(logBean, ruleParam);
84 | if(!b1) return;
85 |
86 | boolean b2 = queryRouterV4.sequenceConditionQuery(logBean, ruleParam);
87 | if(!b2) return;
88 |
89 | boolean b3 = queryRouterV4.countConditionQuery(logBean, ruleParam);
90 | if(!b3) return;
91 |
92 |
93 | // 输出一个规则匹配成功的结果
94 | ResultBean resultBean = new ResultBean();
95 | resultBean.setTimeStamp(logBean.getTimeStamp());
96 | resultBean.setRuleId(ruleParam.getRuleName());
97 | resultBean.setDeviceId(logBean.getDeviceId());
98 | log.info("{}规则,触发人:{},计算匹配成功", ruleParam.getRuleName(),logBean.getDeviceId());
99 |
100 | out.collect(resultBean);
101 | }
102 | }
103 | }
104 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/functions/RuleProcessFunctionV5.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.functions;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.*;
4 | import cn.doitedu.dynamic_rule.service.QueryRouterV4;
5 | import cn.doitedu.dynamic_rule.utils.RuleOperationHandler;
6 | import cn.doitedu.dynamic_rule.utils.RuleSimulator;
7 | import cn.doitedu.dynamic_rule.utils.StateDescUtil;
8 | import com.alibaba.fastjson.JSON;
9 | import lombok.extern.slf4j.Slf4j;
10 | import org.apache.flink.api.common.state.*;
11 | import org.apache.flink.api.common.time.Time;
12 | import org.apache.flink.configuration.Configuration;
13 | import org.apache.flink.streaming.api.functions.KeyedProcessFunction;
14 | import org.apache.flink.streaming.api.functions.co.KeyedBroadcastProcessFunction;
15 | import org.apache.flink.util.Collector;
16 | import org.kie.api.runtime.KieSession;
17 |
18 | import java.util.ArrayList;
19 | import java.util.Map;
20 |
21 | /**
22 | * @author 涛哥
23 | * @nick_name "deep as the sea"
24 | * @contact qq:657270652 wx:doit_edu
25 | * @site www.doitedu.cn
26 | * @date 2021-03-28
27 | * @desc 规则核心处理函数版本4.0
28 | */
29 | @Slf4j
30 | public class RuleProcessFunctionV5 extends KeyedBroadcastProcessFunction {
31 |
32 | QueryRouterV4 queryRouterV4;
33 |
34 | ListState eventState;
35 |
36 | // RuleParam ruleParam;
37 |
38 | @Override
39 | public void open(Configuration parameters) throws Exception {
40 |
41 | /*
42 | * 准备一个存储明细事件的state
43 | * 控制state的ttl周期为最近2小时
44 | */
45 |
46 | ListStateDescriptor eventStateDesc = StateDescUtil.eventStateDesc;
47 | StateTtlConfig ttlConfig = StateTtlConfig.newBuilder(Time.hours(2)).updateTtlOnCreateAndWrite().build();
48 | eventStateDesc.enableTimeToLive(ttlConfig);
49 | eventState = getRuntimeContext().getListState(eventStateDesc);
50 |
51 | // 构造一个查询路由控制器
52 | queryRouterV4 = new QueryRouterV4(eventState);
53 |
54 | }
55 |
56 |
57 | /**
58 | * 规则计算核心方法
59 | * @param logBean 事件bean
60 | * @param ctx 上下文
61 | * @param out 输出
62 | * @throws Exception 异常
63 | */
64 | @Override
65 | public void processElement(LogBean logBean, ReadOnlyContext ctx, Collector out) throws Exception {
66 |
67 |
68 | ReadOnlyBroadcastState ruleState = ctx.getBroadcastState(StateDescUtil.ruleKieStateDesc);
69 |
70 | // 将收到的事件放入历史明细state存储中
71 | // 超过2小时的logBean会被自动清除（前面设置了ttl存活时长）
72 | eventState.add(logBean);
73 |
74 | Iterable> entries = ruleState.immutableEntries();
75 | for (Map.Entry entry : entries) {
76 |
77 | String ruleName = entry.getKey();
78 | RuleStateBean stateBean = entry.getValue();
79 |
80 | // 从rulestate中取sql
81 | String cntSqls = stateBean.getCntSqls();
82 | String seqSqls = stateBean.getSeqSqls();
83 |
84 | // 从rulestate中取出kiesession
85 | KieSession kieSession = stateBean.getKieSession();
86 |
87 | // 构造ruleparam对象
88 | RuleParam ruleParam = new RuleParam();
89 | ruleParam.setRuleName(ruleName);
90 |
91 |
92 | // 放入cntsql
93 | String[] cntSqlArr = cntSqls.split(";");
94 | ArrayList countParams = new ArrayList<>();
95 | for (String cntSql : cntSqlArr) {
96 | RuleAtomicParam ruleAtomicParam = new RuleAtomicParam();
97 | ruleAtomicParam.setCountQuerySql(cntSql);
98 | countParams.add(ruleAtomicParam);
99 | }
100 | // 将封装好sql的count类条件，放入规则总参数ruleParam
101 | ruleParam.setUserActionCountParams(countParams);
102 |
103 | // 放入seqsql
104 | ruleParam.setActionSequenceQuerySql(seqSqls);
105 |
106 |
107 | // 构建一个queryRouter
108 | QueryRouterV4 queryRouterV4 = new QueryRouterV4(eventState);
109 |
110 |
111 | // 构造DroolFact对象
112 | // TODO 这里还可以完善： 判断规则的类型（规则组），给它注入对应的queryRouter
113 | /**
114 | * String className = stateBean.getRouterClass();
115 | * String classJavaCode = stateBean.getClassCode()
116 | * // 即时编译api调用
117 | * Class cls = jitCompile(classJavaCode)
118 | * QueryRouter router = (QueryRouter)cls.newInstance()
119 | */
120 | DroolFact droolFact = new DroolFact(logBean, ruleParam, queryRouterV4, false);
121 |
122 | // 将droolfact插入kiesssion
123 | kieSession.insert(droolFact);
124 |
125 | // 发射 fire
126 | kieSession.fireAllRules();
127 |
128 | // 判断计算后的结果是否匹配
129 | if(droolFact.isMatch()) {
130 | // 如果匹配，输出一条匹配结果
131 | out.collect(new ResultBean(ruleName,logBean.getDeviceId(),logBean.getTimeStamp()));
132 | }
133 |
134 | }
135 | }
136 |
137 |
138 | /**
139 | * 处理输入的规则操作信息，是canal从mysql中监听到并写入kafka的json数据
140 | * @param canalJson
141 | * @param ctx
142 | * @param out
143 | * @throws Exception
144 | */
145 | @Override
146 | public void processBroadcastElement(String canalJson, Context ctx, Collector out) throws Exception {
147 |
148 | BroadcastState mapState = ctx.getBroadcastState(StateDescUtil.ruleKieStateDesc);
149 |
150 | // 解析json成对象
151 | RuleCanalBean ruleCanalBean = JSON.parseObject(canalJson, RuleCanalBean.class);
152 | log.info("收到一个规则库的操作,信息为: {}",ruleCanalBean);
153 |
154 | // 分情况处理获取的规则操作信息（新增，更新，删除，停用，启用）
155 | RuleOperationHandler.handleRuleOper(ruleCanalBean,mapState);
156 |
157 | }
158 | }
159 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/functions/SourceFunctions.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.functions;
2 |
3 | import org.apache.flink.api.common.serialization.SimpleStringSchema;
4 | import org.apache.flink.streaming.connectors.kafka.FlinkKafkaConsumer;
5 |
6 | import java.util.Properties;
7 |
8 | public class SourceFunctions {
9 |
10 | public static FlinkKafkaConsumer getKafkaEventSource(){
11 |
12 | Properties props = new Properties();
13 | props.setProperty("bootstrap.servers", "hdp01:9092,hdp02:9092,hdp03:9092");
14 | props.setProperty("auto.offset.reset", "latest");
15 | FlinkKafkaConsumer source = new FlinkKafkaConsumer<>("yinew_applog", new SimpleStringSchema(), props);
16 |
17 |
18 | return source;
19 | }
20 |
21 |
22 | public static FlinkKafkaConsumer getKafkaRuleSource() {
23 |
24 |
25 | Properties props = new Properties();
26 | props.setProperty("bootstrap.servers", "hdp01:9092,hdp02:9092,hdp03:9092");
27 | props.setProperty("auto.offset.reset", "latest");
28 | FlinkKafkaConsumer source = new FlinkKafkaConsumer<>("yinew_drl_rule", new SimpleStringSchema(), props);
29 |
30 |
31 | return source;
32 | }
33 | }
34 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/moduletest/ActionCountsQueryClickhouseTest.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.moduletest;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
4 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
5 | import cn.doitedu.dynamic_rule.service.UserActionCountQueryServiceClickhouseImpl;
6 |
7 | import java.util.ArrayList;
8 | import java.util.HashMap;
9 | import java.util.List;
10 |
11 | public class ActionCountsQueryClickhouseTest {
12 |
13 | public static void main(String[] args) throws Exception {
14 |
15 | UserActionCountQueryServiceClickhouseImpl impl = new UserActionCountQueryServiceClickhouseImpl();
16 |
17 |
18 | // 构造2个规则原子条件
19 | RuleAtomicParam param1 = new RuleAtomicParam();
20 | param1.setEventId("B");
21 | HashMap paramProps1 = new HashMap<>();
22 | paramProps1.put("p1","v7");
23 | param1.setRangeStart(0);
24 | param1.setRangeEnd(Long.MAX_VALUE);
25 | param1.setProperties(paramProps1);
26 | param1.setCnt(2);
27 |
28 | RuleAtomicParam param2 = new RuleAtomicParam();
29 | param2.setEventId("W");
30 | HashMap paramProps2 = new HashMap<>();
31 | paramProps2.put("p2","v3");
32 | param2.setProperties(paramProps2);
33 | param2.setRangeStart(0);
34 | param2.setRangeEnd(Long.MAX_VALUE);
35 | param2.setCnt(2);
36 |
37 | ArrayList ruleParams = new ArrayList<>();
38 | ruleParams.add(param1);
39 | ruleParams.add(param2);
40 |
41 | RuleParam ruleParam = new RuleParam();
42 | ruleParam.setUserActionCountParams(ruleParams);
43 |
44 |
45 | boolean b = impl.queryActionCounts("000001", ruleParam);
46 | List params = ruleParam.getUserActionCountParams();
47 | for (RuleAtomicParam param : params) {
48 | System.out.println(param.getCnt() + ", " + param.getRealCnt());
49 | }
50 |
51 |
52 | System.out.println(b);
53 |
54 |
55 |
56 | }
57 | }
58 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/moduletest/ActionCountsQueryTest.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.moduletest;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
5 | import cn.doitedu.dynamic_rule.service.UserActionCountQueryServiceStateImpl;
6 |
7 | import java.util.ArrayList;
8 | import java.util.HashMap;
9 |
10 | /**
11 | * @author 涛哥
12 | * @nick_name "deep as the sea"
13 | * @contact qq:657270652 wx:doit_edu
14 | * @site www.doitedu.cn
15 | * @date 2021-03-28
16 | * @desc 行为次数查询服务功能测试
17 | */
18 | public class ActionCountsQueryTest {
19 | public static void main(String[] args) {
20 |
21 |
22 | UserActionCountQueryServiceStateImpl service = new UserActionCountQueryServiceStateImpl(null);
23 |
24 | // 构造几个明细事件
25 | LogBean logBean1 = new LogBean();
26 | logBean1.setEventId("000010");
27 | HashMap props1 = new HashMap<>();
28 | props1.put("p1","v1");
29 | logBean1.setProperties(props1);
30 |
31 |
32 | LogBean logBean2 = new LogBean();
33 | logBean2.setEventId("000010");
34 | HashMap props2 = new HashMap<>();
35 | props2.put("p1","v2");
36 | logBean2.setProperties(props2);
37 |
38 |
39 | LogBean logBean3 = new LogBean();
40 | logBean3.setEventId("000020");
41 | HashMap props3 = new HashMap<>();
42 | props3.put("p2","v3");
43 | logBean3.setProperties(props3);
44 |
45 |
46 | LogBean logBean4 = new LogBean();
47 | logBean4.setEventId("000020");
48 | HashMap props4 = new HashMap<>();
49 | props4.put("p2","v3");
50 | props4.put("p3","v4");
51 | logBean4.setProperties(props4);
52 |
53 |
54 | ArrayList eventList = new ArrayList<>();
55 | eventList.add(logBean1);
56 | eventList.add(logBean2);
57 | eventList.add(logBean3);
58 | eventList.add(logBean4);
59 |
60 |
61 | // 构造2个规则原子条件
62 | RuleAtomicParam param1 = new RuleAtomicParam();
63 | param1.setEventId("000010");
64 | HashMap paramProps1 = new HashMap<>();
65 | paramProps1.put("p1","v1");
66 | param1.setProperties(paramProps1);
67 | param1.setCnt(2);
68 |
69 | RuleAtomicParam param2 = new RuleAtomicParam();
70 | param2.setEventId("000020");
71 | HashMap paramProps2 = new HashMap<>();
72 | paramProps2.put("p2","v3");
73 | param2.setProperties(paramProps2);
74 | param2.setCnt(2);
75 |
76 | ArrayList ruleParams = new ArrayList<>();
77 | ruleParams.add(param1);
78 | ruleParams.add(param2);
79 |
80 | service.queryActionCountsHelper(eventList,ruleParams);
81 |
82 | for (RuleAtomicParam ruleParam : ruleParams) {
83 | System.out.println(ruleParam.getEventId()+","+ruleParam.getCnt() + "," + ruleParam.getRealCnt());
84 | }
85 |
86 |
87 | }
88 | }
89 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/moduletest/ActionSequenceQueryClickhouseTest.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.moduletest;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
4 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
5 | import cn.doitedu.dynamic_rule.service.UserActionSequenceQueryServiceClickhouseImpl;
6 |
7 | import java.util.ArrayList;
8 | import java.util.HashMap;
9 |
10 | /**
11 | * @author 涛哥
12 | * @nick_name "deep as the sea"
13 | * @contact qq:657270652 wx:doit_edu
14 | * @site www.doitedu.cn
15 | * @date 2021-03-30
16 | * @desc 用户行为路径类匹配查询测试
17 | */
18 | public class ActionSequenceQueryClickhouseTest {
19 | public static void main(String[] args) throws Exception {
20 |
21 | String sql = "SELECT\n" +
22 | " deviceId,\n" +
23 | " sequenceMatch('.*(?1).*(?2).*(?3)')(\n" +
24 | " toDateTime(`timeStamp`),\n" +
25 | " eventId = 'Y' and properties['p1']='vy',\n" +
26 | " eventId = 'B' and properties['p6']='v4',\n" +
27 | " eventId = 'O' and properties['p1']='v9'\n" +
28 | " ) as isMatch3,\n" +
29 | " \n" +
30 | " sequenceMatch('.*(?1).*(?2).*')(\n" +
31 | " toDateTime(`timeStamp`),\n" +
32 | " eventId = 'Y' and properties['p1']='vy',\n" +
33 | " eventId = 'B' and properties['p6']='v4',\n" +
34 | " eventId = 'O' and properties['p1']='v9'\n" +
35 | " ) as isMatch2,\n" +
36 | " \n" +
37 | " sequenceMatch('.*(?1).*')(\n" +
38 | " toDateTime(`timeStamp`),\n" +
39 | " eventId = 'Y' and properties['p1']='vy',\n" +
40 | " eventId = 'B' and properties['p6']='v4',\n" +
41 | " eventId = 'O' and properties['p1']='v9'\n" +
42 | " ) as isMatch1\n" +
43 | "\n" +
44 | "from yinew_detail\n" +
45 | "where \n" +
46 | " deviceId = '000001' \n" +
47 | " and \n" +
48 | " timeStamp >= 0\n" +
49 | " and \n" +
50 | " timeStamp <= 5235295739479\n" +
51 | " and \n" +
52 | " (\n" +
53 | " (eventId='Y' and properties['p1']='vy')\n" +
54 | " or (eventId = 'B' and properties['p6']='v4')\n" +
55 | " or (eventId = 'O' and properties['p1']='v9')\n" +
56 | " )\n" +
57 | "group by deviceId;";
58 |
59 |
60 | // 构造一个序列条件
61 | RuleAtomicParam param1 = new RuleAtomicParam();
62 | param1.setEventId("Y");
63 | HashMap paramProps1 = new HashMap<>();
64 | paramProps1.put("p1","v1");
65 | param1.setProperties(paramProps1);
66 | param1.setRangeStart(0);
67 | param1.setRangeEnd(Long.MAX_VALUE);
68 |
69 | RuleAtomicParam param2 = new RuleAtomicParam();
70 | param2.setEventId("B");
71 | HashMap paramProps2 = new HashMap<>();
72 | paramProps2.put("p6","v4");
73 | param2.setProperties(paramProps2);
74 | param2.setRangeStart(0);
75 | param2.setRangeEnd(Long.MAX_VALUE);
76 |
77 |
78 |
79 | RuleAtomicParam param3 = new RuleAtomicParam();
80 | param3.setEventId("O");
81 | HashMap paramProps3 = new HashMap<>();
82 | paramProps3.put("p1","v9");
83 | param3.setProperties(paramProps3);
84 | param3.setRangeStart(0);
85 | param3.setRangeEnd(Long.MAX_VALUE);
86 |
87 | ArrayList ruleParams = new ArrayList<>();
88 | ruleParams.add(param1);
89 | ruleParams.add(param2);
90 | ruleParams.add(param3);
91 |
92 |
93 | RuleParam ruleParam = new RuleParam();
94 | ruleParam.setUserActionSequenceParams(ruleParams);
95 | ruleParam.setActionSequenceQuerySql(sql);
96 |
97 |
98 | UserActionSequenceQueryServiceClickhouseImpl impl = new UserActionSequenceQueryServiceClickhouseImpl();
99 |
100 | boolean b = impl.queryActionSequence("000001", ruleParam);
101 | System.out.println(ruleParam.getUserActionSequenceQueriedMaxStep());
102 | System.out.println(b);
103 |
104 | }
105 |
106 | }
107 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/moduletest/ActionSequenceQueryTest.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.moduletest;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
5 | import cn.doitedu.dynamic_rule.service.UserActionSequenceQueryServiceStateImpl;
6 |
7 | import java.util.ArrayList;
8 | import java.util.HashMap;
9 |
10 | public class ActionSequenceQueryTest {
11 | public static void main(String[] args) {
12 |
13 | // 构造一些事件
14 | LogBean logBean1 = new LogBean();
15 | logBean1.setEventId("000010");
16 | HashMap props1 = new HashMap<>();
17 | props1.put("p1","v1");
18 | logBean1.setProperties(props1);
19 |
20 | LogBean logBean5 = new LogBean();
21 | logBean5.setEventId("000020");
22 | HashMap props5 = new HashMap<>();
23 | props5.put("p2","v3");
24 | logBean5.setProperties(props5);
25 |
26 |
27 | LogBean logBean2 = new LogBean();
28 | logBean2.setEventId("000310");
29 | HashMap props2 = new HashMap<>();
30 | props2.put("p1","v2");
31 | logBean2.setProperties(props2);
32 |
33 |
34 | LogBean logBean3 = new LogBean();
35 | logBean3.setEventId("000020");
36 | HashMap props3 = new HashMap<>();
37 | props3.put("p2","v3");
38 | props3.put("p4","v5");
39 | logBean3.setProperties(props3);
40 |
41 |
42 | LogBean logBean4 = new LogBean();
43 | logBean4.setEventId("000022");
44 | HashMap props4 = new HashMap<>();
45 | props4.put("p2","v3");
46 | props4.put("p3","v4");
47 | logBean4.setProperties(props4);
48 |
49 |
50 | ArrayList eventList = new ArrayList<>();
51 | eventList.add(logBean1);
52 | eventList.add(logBean5);
53 | eventList.add(logBean2);
54 | eventList.add(logBean3);
55 | eventList.add(logBean4);
56 |
57 | // 构造一个序列条件
58 | RuleAtomicParam param1 = new RuleAtomicParam();
59 | param1.setEventId("000010");
60 | HashMap paramProps1 = new HashMap<>();
61 | paramProps1.put("p1","v1");
62 | param1.setProperties(paramProps1);
63 |
64 | RuleAtomicParam param2 = new RuleAtomicParam();
65 | param2.setEventId("000020");
66 | HashMap paramProps2 = new HashMap<>();
67 | paramProps2.put("p2","v3");
68 | param2.setProperties(paramProps2);
69 |
70 | RuleAtomicParam param3 = new RuleAtomicParam();
71 | param3.setEventId("000020");
72 | HashMap paramProps3 = new HashMap<>();
73 | paramProps3.put("p4","v6");
74 | param3.setProperties(paramProps3);
75 |
76 | ArrayList ruleParams = new ArrayList<>();
77 | ruleParams.add(param1);
78 | ruleParams.add(param2);
79 | ruleParams.add(param3);
80 |
81 |
82 | // 调用sevice计算
83 | UserActionSequenceQueryServiceStateImpl service = new UserActionSequenceQueryServiceStateImpl(null);
84 | int maxStep = service.queryActionSequenceHelper2(eventList, ruleParams);
85 | System.out.println(maxStep);
86 |
87 |
88 | }
89 | }
90 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/moduletest/ProfileQueryTest.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.moduletest;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
4 | import cn.doitedu.dynamic_rule.service.UserProfileQueryServiceHbaseImpl;
5 | import org.junit.Test;
6 |
7 | import java.io.IOException;
8 | import java.util.HashMap;
9 |
10 | /**
11 | * @author 涛哥
12 | * @nick_name "deep as the sea"
13 | * @contact qq:657270652 wx:doit_edu
14 | * @site www.doitedu.cn
15 | * @date 2021-03-28
16 | * @desc 画像条件查询服务模块测试类
17 | */
18 | public class ProfileQueryTest {
19 |
20 | @Test
21 | public void testQueryProfile() throws IOException {
22 | // 构造参数
23 | HashMap userProfileParams = new HashMap<>();
24 | userProfileParams.put("tag12","v92");
25 | userProfileParams.put("tag22","v3");
26 |
27 | RuleParam ruleParam = new RuleParam();
28 | ruleParam.setUserProfileParams(userProfileParams);
29 |
30 |
31 | // 构造一个查询服务
32 | UserProfileQueryServiceHbaseImpl impl = new UserProfileQueryServiceHbaseImpl();
33 | boolean b = impl.judgeProfileCondition("000645", ruleParam);
34 | System.out.println(b);
35 |
36 | }
37 |
38 | }
39 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/BufferAvailableLevel.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 | public enum BufferAvailableLevel {
4 | // 缓存结果部分有效
5 | PARTIAL_AVL,
6 | // 缓存结果完全有效
7 | WHOLE_AVL,
8 | // 缓存结果无效
9 | UN_AVL
10 |
11 | }
12 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/BufferResult.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 | import lombok.ToString;
7 |
8 | /**
9 | * @author 涛哥
10 | * @nick_name "deep as the sea"
11 | * @contact qq:657270652 wx:doit_edu
12 | * @site www.doitedu.cn
13 | * @date 2021-03-31
14 | * @desc 封装从缓存中查询到的结果的实体
15 | */
16 | @Data
17 | @NoArgsConstructor
18 | @AllArgsConstructor
19 | @ToString
20 | public class BufferResult {
21 |
22 | // 缓存结果所对应的key
23 | private String bufferKey;
24 |
25 | // 缓存结果中的value
26 | private Integer bufferValue;
27 |
28 | // 缓存数据的时间窗口起始
29 | private Long bufferRangeStart;
30 |
31 | // 缓存数据的时间窗口结束
32 | private Long bufferRangeEnd;
33 |
34 | // 缓存结果的有效性等级
35 | private BufferAvailableLevel bufferAvailableLevel;
36 |
37 |
38 | // 调整后的后续查询窗口起始点
39 | private Long outSideQueryStart;
40 |
41 |
42 | }
43 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/DroolFact.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 |
4 | import cn.doitedu.dynamic_rule.service.QueryRouterV4;
5 | import lombok.AllArgsConstructor;
6 | import lombok.Data;
7 | import lombok.NoArgsConstructor;
8 |
9 | /**
10 | * @author 涛哥
11 | * @nick_name "deep as the sea"
12 | * @contact qq:657270652 wx:doit_edu
13 | * @site www.doitedu.cn
14 | * @date 2021-04-07
15 | * @desc 封装要insert到drools kiesession中数据的fact实体
16 | */
17 |
18 | @Data
19 | @NoArgsConstructor
20 | @AllArgsConstructor
21 | public class DroolFact {
22 |
23 | private LogBean logBean;
24 |
25 | private RuleParam ruleParam;
26 |
27 | private QueryRouterV4 queryRouterV4;
28 |
29 | private boolean match;
30 |
31 |
32 | }
33 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/LogBean.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 | import lombok.ToString;
7 |
8 | import java.util.Map;
9 |
10 | @Data
11 | @NoArgsConstructor
12 | @AllArgsConstructor
13 | @ToString
14 | public class LogBean {
15 |
16 | private String account ;
17 | private String appId ;
18 | private String appVersion ;
19 | private String carrier ;
20 | private String deviceId ;
21 | private String deviceType ;
22 | private String ip ;
23 | private double latitude ;
24 | private double longitude ;
25 | private String netType ;
26 | private String osName ;
27 | private String osVersion ;
28 | private String releaseChannel ;
29 | private String resolution ;
30 | private String sessionId ;
31 | private long timeStamp ;
32 | private String eventId ;
33 | private Map properties;
34 |
35 | }
36 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/ResultBean.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 |
7 | @Data
8 | @NoArgsConstructor
9 | @AllArgsConstructor
10 | public class ResultBean {
11 |
12 | private String ruleId;
13 | private String deviceId;
14 | private long timeStamp;
15 | }
16 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/RuleAtomicParam.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 |
7 | import java.io.Serializable;
8 | import java.util.HashMap;
9 |
10 | /**
11 | * @author 涛哥
12 | * @nick_name "deep as the sea"
13 | * @contact qq:657270652 wx:doit_edu
14 | * @site www.doitedu.cn
15 | * @date 2021-03-28
16 | * @desc 规则参数中的原子条件封装实体
17 | */
18 | @Data
19 | @NoArgsConstructor
20 | @AllArgsConstructor
21 | public class RuleAtomicParam implements Serializable {
22 |
23 | // 事件的类型要求
24 | private String eventId;
25 |
26 | // 事件的属性要求
27 | private HashMap properties;
28 |
29 | // 规则要求的阈值
30 | private int cnt;
31 |
32 | // 要求的事件发生时间段起始
33 | private long rangeStart;
34 |
35 | // 要求的事件发生时间段结束
36 | private long rangeEnd;
37 |
38 | // 条件对应的clickhouse查询sql
39 | private String countQuerySql;
40 |
41 | // 用于记录查询服务所返回的查询值
42 | private int realCnt;
43 |
44 | // 用于记录初始 range
45 | private long originStart;
46 | public void setOriginStart(long originStart){
47 | this.originStart = originStart;
48 | this.rangeStart = originStart;
49 | }
50 | private long originEnd;
51 | public void setOriginEnd(long originEnd){
52 | this.originEnd = originEnd;
53 | this.rangeEnd = originEnd;
54 | }
55 |
56 |
57 | }
58 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/RuleCanalBean.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 |
7 | import java.util.List;
8 |
9 | @Data
10 | @AllArgsConstructor
11 | @NoArgsConstructor
12 | public class RuleCanalBean {
13 |
14 | private List data;
15 | private String type;
16 |
17 | }
18 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/RuleParam.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 |
7 | import java.io.Serializable;
8 | import java.util.HashMap;
9 | import java.util.List;
10 |
11 | /**
12 | * @author 涛哥
13 | * @nick_name "deep as the sea"
14 | * @contact qq:657270652 wx:doit_edu
15 | * @site www.doitedu.cn
16 | * @date 2021-03-28
17 | * @desc 规则整体条件封装实体
18 | *
19 | * 需求中要实现的判断规则：
20 | * 触发条件：E事件
21 | * 画像属性条件： k3=v3 , k100=v80 , k230=v360
22 | * 行为属性条件： U(p1=v3,p2=v2) >= 3次 且 G(p6=v8,p4=v5,p1=v2)>=1
23 | * 行为次序条件： 依次做过： W(p1=v4) -> R(p2=v3) -> F
24 | *
25 | */
26 | @Data
27 | @NoArgsConstructor
28 | @AllArgsConstructor
29 | public class RuleParam implements Serializable {
30 | private String ruleName;
31 |
32 | // 规则中的触发条件
33 | private RuleAtomicParam triggerParam;
34 |
35 | // 规则中的用户画像条件
36 | private HashMap userProfileParams;
37 |
38 | // 规则中的行为次数类条件
39 | private List userActionCountParams;
40 |
41 | // 规则中的行为序列类条件
42 | private List userActionSequenceParams;
43 |
44 | // 序列模式匹配查询sql
45 | private String actionSequenceQuerySql;
46 |
47 | // 用于记录查询服务所返回的序列中匹配的最大步骤号
48 | private int userActionSequenceQueriedMaxStep;
49 |
50 |
51 |
52 | }
53 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/RuleStateBean.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 |
4 | import lombok.AllArgsConstructor;
5 | import lombok.Data;
6 | import lombok.NoArgsConstructor;
7 | import org.kie.api.runtime.KieSession;
8 |
9 | /**
10 | * @author 涛哥
11 | * @nick_name "deep as the sea"
12 | * @contact qq:657270652 wx:doit_edu
13 | * @site www.doitedu.cn
14 | * @date 2021-04-07
15 | * @desc 用于封装放入state中的规则相关信息
16 | */
17 | @Data
18 | @NoArgsConstructor
19 | @AllArgsConstructor
20 | public class RuleStateBean {
21 |
22 | private String ruleName;
23 | private KieSession kieSession;
24 | private RuleParam ruleParam;
25 | private String ruleType;
26 | // cn.doitedu.dynamic_rule.service.XqueryRouter
27 | private String routerClass;
28 | private String cntSqls;
29 | private String seqSqls;
30 |
31 | }
32 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/pojo/RuleTableRecord.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 |
7 | @Data
8 | @AllArgsConstructor
9 | @NoArgsConstructor
10 | public class RuleTableRecord {
11 |
12 | private int id;
13 | private String rule_name;
14 | private String rule_code;
15 | private int rule_status;
16 | private String rule_type;
17 | private String rule_versioin;
18 | private String cnt_sqls;
19 | private String seq_sqls;
20 |
21 | }
22 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/service/BufferManager.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.service;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.BufferAvailableLevel;
4 | import cn.doitedu.dynamic_rule.pojo.BufferResult;
5 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
6 | import lombok.extern.slf4j.Slf4j;
7 | import redis.clients.jedis.Jedis;
8 |
9 | /**
10 | * @author 涛哥
11 | * @nick_name "deep as the sea"
12 | * @contact qq:657270652 wx:doit_edu
13 | * @site www.doitedu.cn
14 | * @date 2021-03-31
15 | * @desc 缓存管理器
16 | */
17 | @Slf4j
18 | public class BufferManager {
19 | Jedis jedis;
20 |
21 | public BufferManager(){
22 | jedis = new Jedis("hdp02", 6379);
23 | }
24 |
25 |
26 | /**
27 | * 获取缓存数据并返回
28 | * @param bufferKey 缓存key
29 | * @param atomicParam 规则原子条件对象
30 | * @return 缓存数据
31 | */
32 | public BufferResult getBufferData(String bufferKey,RuleAtomicParam atomicParam){
33 | BufferResult bufferResult = getBufferData(bufferKey, atomicParam.getRangeStart(), atomicParam.getRangeEnd(), atomicParam.getCnt());
34 | return bufferResult;
35 | }
36 |
37 | /**
38 | * 获取缓存数据并返回
39 | * @param bufferKey 缓存key
40 | * @param paramRangeStart 缓存数据时间start
41 | * @param paramRangeEnd 缓存数据时间end
42 | * @param threshold 缓存数据对应查询条件的阈值
43 | * @return 缓存数据结果
44 | */
45 | public BufferResult getBufferData(String bufferKey,long paramRangeStart,long paramRangeEnd,int threshold){
46 | // 准备缓存返回结果实体对象
47 | BufferResult bufferResult = new BufferResult();
48 | bufferResult.setBufferAvailableLevel(BufferAvailableLevel.UN_AVL);
49 |
50 | /*
51 | * 解析缓存数据
52 | * 格式: 2|t1,t8
53 | */
54 | String data = jedis.get(bufferKey);
55 | // data可能为null，这里直接切，会产生空指针异常
56 | if(data ==null || data.split("\\|").length<2) return bufferResult;
57 |
58 | String[] split = data.split("\\|");
59 | String[] timeRange = split[1].split(",");
60 |
61 | bufferResult.setBufferKey(bufferKey);
62 | bufferResult.setBufferValue(Integer.parseInt(split[0]));
63 | bufferResult.setBufferRangeStart(Long.parseLong(timeRange[0]));
64 | bufferResult.setBufferRangeEnd(Long.parseLong(timeRange[1]));
65 |
66 | /*
67 | * 判断缓存有效性： 完全有效
68 | */
69 | if(paramRangeStart<= bufferResult.getBufferRangeStart()
70 | && paramRangeEnd>=bufferResult.getBufferRangeEnd()
71 | && bufferResult.getBufferValue()>=threshold){
72 | bufferResult.setBufferAvailableLevel(BufferAvailableLevel.WHOLE_AVL);
73 | log.warn("{} 缓存完全匹配,value为: {}",bufferKey,bufferResult.getBufferValue());
74 | }
75 |
76 | /*
77 | * 判断缓存有效性： 部分有效
78 | * TODO 重大bug修改，少了个else，逻辑就完全错误了
79 | */
80 | else if(paramRangeStart == bufferResult.getBufferRangeStart() && paramRangeEnd>=bufferResult.getBufferRangeEnd()){
81 | bufferResult.setBufferAvailableLevel(BufferAvailableLevel.PARTIAL_AVL);
82 | // 更新外部后续查询的条件窗口起始点
83 | //bufferResult.setOutSideQueryStart(bufferResult.getBufferRangeEnd());
84 | log.warn("count缓存部分匹配");
85 | }
86 |
87 | return bufferResult;
88 | }
89 |
90 | // 插入数据到缓存
91 | public void putBufferData(String bufferKey,int value,long bufferRangeStart,long bufferRangeEnd){
92 | jedis.setex(bufferKey,4*60*60*1000,value+"|"+bufferRangeStart+","+bufferRangeEnd);
93 | }
94 |
95 |
96 | // 更新已存在的缓存数据
97 |
98 |
99 | // 删除已存在的缓存数据
100 |
101 | }
102 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/service/UserActionCountQueryService.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.service;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
5 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
6 | import org.apache.flink.api.common.state.ListState;
7 |
8 | /**
9 | * @author 涛哥
10 | * @nick_name "deep as the sea"
11 | * @contact qq:657270652 wx:doit_edu
12 | * @site www.doitedu.cn
13 | * @date 2021-03-28
14 | * @desc 用户行为次数类条件查询服务接口
15 | */
16 | public interface UserActionCountQueryService {
17 |
18 | public boolean queryActionCounts(String deviceId, RuleParam ruleParam) throws Exception;
19 |
20 | public boolean queryActionCounts(String deviceId, RuleAtomicParam atomicParam,String ruleId) throws Exception;
21 |
22 | }
23 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/service/UserActionCountQueryServiceClickhouseImpl.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.service;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
4 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
5 | import cn.doitedu.dynamic_rule.utils.ConnectionUtils;
6 | import lombok.extern.slf4j.Slf4j;
7 |
8 | import java.sql.Connection;
9 | import java.sql.PreparedStatement;
10 | import java.sql.ResultSet;
11 | import java.util.List;
12 |
13 | @Slf4j
14 | public class UserActionCountQueryServiceClickhouseImpl implements UserActionCountQueryService {
15 |
16 | private static Connection conn;
17 |
18 | static {
19 | // 获取clickhouse的jdbc连接对象
20 | try {
21 | conn = ConnectionUtils.getClickhouseConnection();
22 | } catch (Exception e) {
23 | e.printStackTrace();
24 | }
25 | }
26 |
27 |
28 | /**
29 | *
30 | * 根据给定的deviceId，查询这个人是否满足ruleParam中的所有“次数类"规则条件
31 | * @param deviceId 要查询的用户
32 | * @param ruleParam 规则参数对象
33 | * @return 条件查询的结果是否成立
34 | * @throws Exception
35 | */
36 | @Override
37 | public boolean queryActionCounts(String deviceId, RuleParam ruleParam) throws Exception {
38 |
39 | List userActionCountParams = ruleParam.getUserActionCountParams();
40 |
41 | // 遍历每一个原子条件进行查询判断
42 | for (RuleAtomicParam atomicParam : userActionCountParams) {
43 | queryActionCounts(deviceId,atomicParam,ruleParam.getRuleName());
44 | }
45 | // 如果走到这一句代码，说明上面的每一个原子条件查询后都满足规则，那么返回最终结果true
46 | return true;
47 | }
48 |
49 | /**
50 | *
51 | * 查询单个行为count条件是否成立
52 | * @param deviceId 设备id
53 | * @param atomicParam 原子条件
54 | * @return 是否成立
55 | * @throws Exception 异常
56 | */
57 | @Override
58 | public boolean queryActionCounts(String deviceId, RuleAtomicParam atomicParam,String ruleId) throws Exception {
59 | // 对当前的原子条件拼接查询sql
60 | String sql = atomicParam.getCountQuerySql();
61 | // 获取一个clickhouse 的jdbc连接
62 | PreparedStatement ps = conn.prepareStatement(sql);
63 | // 需要将sql中的deviceId占位符替换成真实deviceId
64 | ps.setString(1,deviceId);
65 | ps.setLong(2,atomicParam.getRangeStart());
66 | ps.setLong(3,atomicParam.getRangeEnd());
67 |
68 | ResultSet resultSet = ps.executeQuery();
69 |
70 | /*sql = sql.replaceAll("\\$\\{did\\}",deviceId);
71 | Statement statement = conn.createStatement();
72 | ResultSet resultSet = statement.executeQuery(sql);*/
73 |
74 | /* *
75 | * deviceId,cnt
76 | * 000001 ,6
77 | **/
78 | // resultSet只有一行，所以while只循环一次
79 | while (resultSet.next()) {
80 | // 从结果中取出cnt字段
81 | int realCnt = (int) resultSet.getLong(2);
82 | // 将查询结果赛回规则参数对象
83 | log.info("规则:{},用户:{},查询clickhouse次数条件,查询前cnt:{},本次cnt:{},累加后cnt:{}",ruleId,deviceId,atomicParam.getRealCnt(),realCnt,atomicParam.getRealCnt()+realCnt);
84 | atomicParam.setRealCnt(atomicParam.getRealCnt() + realCnt);
85 | }
86 |
87 | // 只要有一个原子条件查询结果不满足，则直接返回最终结果false
88 | if (atomicParam.getRealCnt() < atomicParam.getCnt()) {
89 | return false;
90 | } else {
91 | return true;
92 | }
93 | }
94 | }
95 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/service/UserActionCountQueryServiceStateImpl.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.service;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
5 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
6 | import cn.doitedu.dynamic_rule.utils.RuleCalcUtil;
7 | import lombok.extern.slf4j.Slf4j;
8 | import org.apache.flink.api.common.state.ListState;
9 |
10 | import java.util.List;
11 |
12 | /**
13 | * @author 涛哥
14 | * @nick_name "deep as the sea"
15 | * @contact qq:657270652 wx:doit_edu
16 | * @site www.doitedu.cn
17 | * @date 2021-03-28
18 | * @desc 用户行为次数类条件查询服务实现：在flink的state中统计行为次数
19 | */
20 | @Slf4j
21 | public class UserActionCountQueryServiceStateImpl implements UserActionCountQueryService {
22 |
23 | ListState eventState;
24 | public UserActionCountQueryServiceStateImpl(ListState eventState){
25 |
26 | this.eventState = eventState;
27 | }
28 |
29 | /**
30 | * 查询规则参数对象中，要求的用户行为次数类条件是否满足
31 | * 同时，将查询到的真实次数，set回 规则参数对象中
32 | *
33 | * @param ruleParam 规则整体参数对象
34 | * @return 条件是否满足
35 | */
36 | @Override
37 | public boolean queryActionCounts(String deviceId,RuleParam ruleParam) throws Exception {
38 |
39 | // 取出各个用户行为次数原子条件
40 | List userActionCountParams = ruleParam.getUserActionCountParams();
41 |
42 | // 取出历史明细数据
43 | Iterable logBeansIterable = eventState.get();
44 |
45 | // 统计每一个原子条件所发生的真实次数，就在原子条件参数对象中：realCnts
46 | queryActionCountsHelper(logBeansIterable, userActionCountParams);
47 |
48 | // 经过上面的方法执行后，每一个原子条件中，都拥有了一个真实发生次数，我们在此判断是否每个原子条件都满足
49 | for (RuleAtomicParam userActionCountParam : userActionCountParams) {
50 | if (userActionCountParam.getRealCnt() < userActionCountParam.getCnt()) {
51 | return false;
52 | }
53 | }
54 |
55 | // 如果到达这一句话，说明上面的判断中，每个原子条件都满足，则返回整体结果true
56 | return true;
57 | }
58 |
59 |
60 | /**
61 | * 根据传入的历史明细，和规则条件
62 | * 挨个统计每一个规则原子条件的真实发生次数，并将结果set回规则条件参数中
63 | *
64 | * @param logBeansIterable
65 | * @param userActionCountParams
66 | */
67 | public void queryActionCountsHelper(Iterable logBeansIterable, List userActionCountParams) {
68 | for (LogBean logBean : logBeansIterable) {
69 |
70 | for (RuleAtomicParam userActionCountParam : userActionCountParams) {
71 |
72 | // 判断当前logbean 和当前 规则原子条件userActionCountParam 是否一致
73 | boolean isMatch = RuleCalcUtil.eventBeanMatchEventParam(logBean, userActionCountParam,true);
74 | log.debug("用户:{},查询了近期count条件,{},查询到的结果:{}",logBean.getDeviceId(),userActionCountParam.getEventId(),userActionCountParam.getRealCnt());
75 |
76 | // 如果一致，则查询次数结果+1
77 | if (isMatch) {
78 | userActionCountParam.setRealCnt(userActionCountParam.getRealCnt() + 1);
79 | }
80 | }
81 |
82 | }
83 |
84 | }
85 |
86 |
87 | /**
88 | * 接收一个原子count类条件
89 | * 进行查询，并返回是否匹配
90 | * 并且，将查询到的realcount塞回参数对象
91 | * @param deviceId
92 | * @param atomicParam
93 | * @return
94 | * @throws Exception
95 | */
96 | @Override
97 | public boolean queryActionCounts(String deviceId, RuleAtomicParam atomicParam,String ruleId) throws Exception {
98 |
99 | Iterable logBeans = eventState.get();
100 | for (LogBean logBean : logBeans) {
101 | boolean b = RuleCalcUtil.eventBeanMatchEventParam(logBean, atomicParam, true);
102 | // 如果事件和条件匹配，则真实次数+1
103 | if(b) atomicParam.setRealCnt(atomicParam.getRealCnt()+1);
104 | }
105 |
106 | return atomicParam.getRealCnt() >= atomicParam.getCnt();
107 | }
108 |
109 |
110 | }
111 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/service/UserActionSequenceQueryService.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.service;
2 |
3 |
4 | import cn.doitedu.dynamic_rule.pojo.LogBean;
5 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
6 | import org.apache.flink.api.common.state.ListState;
7 |
8 | /**
9 | * @author 涛哥
10 | * @nick_name "deep as the sea"
11 | * @contact qq:657270652 wx:doit_edu
12 | * @site www.doitedu.cn
13 | * @date 2021-03-28
14 | * @desc 用户行为次序列条件查询服务接口
15 | */
16 | public interface UserActionSequenceQueryService {
17 |
18 | public boolean queryActionSequence(String deviceId, RuleParam ruleParam) throws Exception;
19 | }
20 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/service/UserActionSequenceQueryServiceClickhouseImpl.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.service;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
5 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
6 | import cn.doitedu.dynamic_rule.utils.ConnectionUtils;
7 | import lombok.extern.slf4j.Slf4j;
8 | import org.apache.flink.api.common.state.ListState;
9 |
10 | import java.sql.Connection;
11 | import java.sql.PreparedStatement;
12 | import java.sql.ResultSet;
13 | import java.sql.Statement;
14 |
15 | /**
16 | * @author 涛哥
17 | * @nick_name "deep as the sea"
18 | * @contact qq:657270652 wx:doit_edu
19 | * @site www.doitedu.cn
20 | * @date 2021-03-30
21 | * @desc 行为序列类路径匹配查询service，clickhouse实现
22 | */
23 | @Slf4j
24 | public class UserActionSequenceQueryServiceClickhouseImpl implements UserActionSequenceQueryService{
25 |
26 | private static Connection conn;
27 |
28 |
29 | static {
30 | try {
31 | conn = ConnectionUtils.getClickhouseConnection();
32 | } catch (Exception e) {
33 | e.printStackTrace();
34 | }
35 | }
36 |
37 | /**
38 | * 从clickhouse中查询行为序列条件是否满足
39 | *
40 | * @param deviceId
41 | * @param ruleParam
42 | * @return
43 | * @throws Exception
44 | */
45 | @Override
46 | public boolean queryActionSequence(String deviceId, RuleParam ruleParam) throws Exception {
47 | // 获取规则中，路径模式的总步骤数
48 | int totalStep = ruleParam.getUserActionSequenceParams().size();
49 | RuleAtomicParam ruleAtomicParam = ruleParam.getUserActionSequenceParams().get(0);
50 |
51 | // 取出查询sql
52 | String sql = ruleParam.getActionSequenceQuerySql();
53 | PreparedStatement ps = conn.prepareStatement(sql);
54 | // 需要将sql中的deviceId占位符替换成真实deviceId
55 | ps.setString(1,deviceId);
56 | ps.setLong(2,ruleAtomicParam.getRangeStart());
57 | ps.setLong(3,ruleAtomicParam.getRangeEnd());
58 | ResultSet resultSet = ps.executeQuery();
59 |
60 | /*
61 | sql = sql.replaceAll("\\$\\{did\\}",deviceId);
62 | Statement statement = conn.createStatement();
63 | ResultSet resultSet = statement.executeQuery(sql);
64 | */
65 |
66 | // 执行查询
67 | long s = System.currentTimeMillis();
68 |
69 |
70 |
71 | /* 从返回结果中进行条件判断
72 | * ┌─deviceId─┬─isMatch3─┬─isMatch2─┬─isMatch1─┐
73 | * │ 000001 │ 0 │ 0 │ 1 │
74 | * └──────────┴──────────┴──────────┴──────────┘
75 | * 重要逻辑： 查询结果中有几个1，就意味着最大完成步骤是几！！！
76 | */
77 | int maxStep = 0;
78 | while(resultSet.next()){ // 返回结果最多就1行，这个while就走一次!!!
79 | // 对一行结果中的1进行累加，累加结果即完成的最大步骤数
80 | for(int i =2;i eventState;
28 |
29 | public UserActionSequenceQueryServiceStateImpl(ListState eventState){
30 | this.eventState = eventState;
31 | }
32 |
33 |
34 |
35 | /**
36 | * 行为序列： A(p1=v2,p3=v8) B(p6=v9,p7=v7) C()
37 | * 意味着用户要依顺序做过上面的事件
38 | *
39 | * 查询规则条件中的行为序列条件是否满足
40 | * 会将查询到的最大匹配步骤，set回 ruleParam对象中
41 | * @param ruleParam 规则参数对象
42 | * @return 条件成立与否
43 | */
44 | @Override
45 | public boolean queryActionSequence(String deviceId,RuleParam ruleParam) throws Exception {
46 |
47 |
48 | Iterable logBeans = eventState.get();
49 | List userActionSequenceParams = ruleParam.getUserActionSequenceParams();
50 |
51 | // 调用helper统计实际匹配的最大步骤号
52 | int maxStep = queryActionSequenceHelper2(logBeans, userActionSequenceParams);
53 |
54 | // 将这个maxStep丢回规则参数对象，以便本服务的调用者可以根据需要获取到这个最大匹配步骤号
55 | ruleParam.setUserActionSequenceQueriedMaxStep(ruleParam.getUserActionSequenceQueriedMaxStep()+maxStep);
56 |
57 | // 然后判断整个序列条件是否满足：真实最大匹配步骤是否等于条件的步骤数
58 | log.debug("序列匹配:state,规则:{},用户:{},结果maxStep：{},条件步数:{}, ",ruleParam.getRuleName(),deviceId,maxStep,userActionSequenceParams.size());
59 | return maxStep == userActionSequenceParams.size();
60 | }
61 |
62 |
63 | /**
64 | * 统计明细事件中，与序列条件匹配到的最大步骤
65 | *
66 | * @param events 事件明细
67 | * @param userActionSequenceParams 行为序列规则条件
68 | * @return 行为次数
69 | */
70 | public int queryActionSequenceHelper(Iterable events, List userActionSequenceParams) {
71 |
72 | ArrayList eventList = new ArrayList<>();
73 | CollectionUtils.addAll(eventList, events.iterator());
74 |
75 | // 外循环，遍历每一个条件
76 | int maxStep = 0;
77 | int index = 0;
78 | for (RuleAtomicParam userActionSequenceParam : userActionSequenceParams) {
79 |
80 | // 内循环，遍历每一个历史明细事件，看看能否找到与当前条件匹配的事件
81 | boolean isFind = false;
82 | for (int i = index; i < eventList.size(); i++) {
83 | LogBean logBean = eventList.get(i);
84 | // 判断当前的这个事件 logBean，是否满足当前规则条件 userActionSequenceParam
85 | boolean match = RuleCalcUtil.eventBeanMatchEventParam(logBean, userActionSequenceParam, true);
86 | // 如果匹配，则最大步骤号+1，且更新下一次内循环的起始位置,并跳出本轮内循环
87 | if (match) {
88 | maxStep++;
89 | index = i + 1;
90 | isFind = true;
91 | break;
92 | }
93 | }
94 |
95 | if (!isFind) break;
96 |
97 | }
98 |
99 | log.debug("在state中步骤匹配计算完成： 查询到的最大步骤号为： " + maxStep + ",条件中的步骤数为：" + userActionSequenceParams.size());
100 | return maxStep;
101 | }
102 |
103 | /**
104 | * 序列匹配，性能改进版
105 | * @param events 事件明细
106 | * @param userActionSequenceParams 行为序列规则条件
107 | * @return 次数
108 | */
109 | public int queryActionSequenceHelper2(Iterable events, List userActionSequenceParams) {
110 |
111 | int maxStep = 0;
112 | for (LogBean event : events) {
113 | if (RuleCalcUtil.eventBeanMatchEventParam(event, userActionSequenceParams.get(maxStep))) {
114 | maxStep++;
115 | }
116 | if (maxStep == userActionSequenceParams.size()) break;
117 | }
118 | return maxStep;
119 | }
120 |
121 | }
122 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/service/UserProfileQueryService.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.service;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
4 |
5 | import java.io.IOException;
6 |
7 | /**
8 | * @author 涛哥
9 | * @nick_name "deep as the sea"
10 | * @contact qq:657270652 wx:doit_edu
11 | * @site www.doitedu.cn
12 | * @date 2021-03-28
13 | * @desc 用户画像数据查询服务接口
14 | */
15 | public interface UserProfileQueryService {
16 |
17 | public boolean judgeProfileCondition(String deviceId, RuleParam ruleParam);
18 |
19 | }
20 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/service/UserProfileQueryServiceHbaseImpl.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.service;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
4 | import lombok.extern.slf4j.Slf4j;
5 | import org.apache.hadoop.conf.Configuration;
6 | import org.apache.hadoop.hbase.TableName;
7 | import org.apache.hadoop.hbase.client.*;
8 |
9 | import java.io.IOException;
10 | import java.util.HashMap;
11 | import java.util.Set;
12 |
13 | /**
14 | * @author 涛哥
15 | * @nick_name "deep as the sea"
16 | * @contact qq:657270652 wx:doit_edu
17 | * @site www.doitedu.cn
18 | * @date 2021-03-28
19 | * @desc 用户画像查询服务，hbase查询实现类
20 | */
21 | @Slf4j
22 | public class UserProfileQueryServiceHbaseImpl implements UserProfileQueryService {
23 |
24 | static Connection conn;
25 | static Table table;
26 |
27 | static {
28 | Configuration conf = new Configuration();
29 | conf.set("hbase.zookeeper.quorum", "hdp01:2181,hdp02:2181,hdp03:2181");
30 |
31 | log.debug("hbase连接准备创建");
32 | try {
33 | conn = ConnectionFactory.createConnection(conf);
34 | table = conn.getTable(TableName.valueOf("yinew_profile"));
35 | log.debug("hbase连接创建完毕");
36 | }catch (Exception e){
37 | e.printStackTrace();
38 | }
39 | }
40 |
41 | /**
42 | * 构造函数
43 | */
44 | public UserProfileQueryServiceHbaseImpl() throws IOException {
45 | /*Configuration conf = new Configuration();
46 | conf.set("hbase.zookeeper.quorum", "hdp01:2181,hdp02:2181,hdp03:2181");
47 |
48 | log.debug("hbase连接准备创建");
49 | conn = ConnectionFactory.createConnection(conf);
50 | table = conn.getTable(TableName.valueOf("yinew_profile"));
51 | log.debug("hbase连接创建完毕");*/
52 | }
53 |
54 | /**
55 | * 传入一个用户号，以及要查询的条件
56 | * 返回这些条件是否满足
57 | * TODO 本查询只返回了成立与否，而查询到的画像数据值并没有返回 可能为将来的缓存模块带来不便，有待改造
58 | * @param deviceId 设备id
59 | * @param ruleParam 规则参数对象
60 | * @return 是否成立
61 | */
62 | @Override
63 | public boolean judgeProfileCondition(String deviceId, RuleParam ruleParam){
64 |
65 | // 从规则参数中取出画像标签属性条件
66 | HashMap userProfileParams = ruleParam.getUserProfileParams();
67 |
68 | // 取出条件中所要求的所有待查询标签名
69 | Set tagNames = userProfileParams.keySet();
70 |
71 | // 构造一个hbase的查询参数对象
72 | Get get = new Get(deviceId.getBytes());
73 | // 把要查询的标签（hbase表中的列）逐一添加到get参数中
74 | for (String tagName : tagNames) {
75 | get.addColumn("f".getBytes(),tagName.getBytes());
76 | }
77 |
78 |
79 |
80 | // 调用hbase的api执行查询
81 | String valueStr = "";
82 | long ts =0;
83 | long te =0;
84 | try {
85 | ts = System.currentTimeMillis();
86 | Result result = table.get(get);
87 | // 判断结果和条件中的要求是否一致
88 | for (String tagName : tagNames) {
89 | // 从查询结果中取出该标签的值
90 | byte[] valueBytes = result.getValue("f".getBytes(), tagName.getBytes());
91 | // 判断查询到的value和条件中要求的value是否一致，如果不一致，方法直接返回：false
92 | te = System.currentTimeMillis();
93 | if(valueBytes == null){
94 | log.info("规则:{},用户:{},查询Hbase,要求的条件是:{},{},查询结果为:{},匹配失败,耗费时长:{}",ruleParam.getRuleName(),
95 | deviceId,tagName,userProfileParams.get(tagName),"null",te-ts);
96 | return false;
97 | }
98 | valueStr = new String(valueBytes);
99 | if(!valueStr.equals(userProfileParams.get(tagName))){
100 | log.debug("规则:{},用户:{},查询Hbase,要求的条件是:{},{},查询结果为:{},匹配失败,耗费时长:{}",ruleParam.getRuleName(),
101 | deviceId,tagName,userProfileParams.get(tagName),new String(valueBytes),te-ts);
102 | return false;
103 | }
104 | }
105 |
106 | log.info("规则:{},用户:{},查询Hbase,要求的条件是:{},查询结果为:{},匹配成功,耗费时长:{}",ruleParam.getRuleName(),
107 | deviceId,userProfileParams,valueStr,te-ts);
108 | // 如果上面的for循环走完了，那说明每个标签的查询值都等于条件中要求的值，则可以返回true
109 | return true;
110 | } catch (IOException e) {
111 | e.printStackTrace();
112 | }
113 |
114 | // 如果到了这，说明前面的查询出异常了，返回false即可
115 | return false;
116 | }
117 | }
118 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/utils/ClickhouseCountQuerySqlUtil.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.utils;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
4 |
5 | import java.util.HashMap;
6 | import java.util.List;
7 | import java.util.Map;
8 | import java.util.Set;
9 |
10 | /**
11 | * @author 涛哥
12 | * @nick_name "deep as the sea"
13 | * @contact qq:657270652 wx:doit_edu
14 | * @site www.doitedu.cn
15 | * @date 2021-03-30
16 | * @desc 行为次数类条件查询sql拼接工具
17 | */
18 | public class ClickhouseCountQuerySqlUtil {
19 |
20 | public static String getSql(String deviceId,RuleAtomicParam atomicParam){
21 |
22 | String templet1 =
23 | " select " +
24 | "\n deviceId,count() as cnt " +
25 | "\n from yinew_detail " +
26 | "\n where deviceId= '" +deviceId+"'" +
27 | "\n and " +
28 | "\n eventId = '" + atomicParam.getEventId()+"' " +
29 | "\n and " +
30 | "\n timeStamp >= "+atomicParam.getRangeStart()+" and timeStamp <=" + atomicParam.getRangeEnd();
31 |
32 |
33 | String templet3 = "\n group by deviceId";
34 |
35 |
36 | HashMap properties = atomicParam.getProperties();
37 | Set> entries = properties.entrySet();
38 |
39 |
40 | StringBuffer sb = new StringBuffer();
41 | for (Map.Entry entry : entries) {
42 | // "and properties['pageId'] = 'page006'"
43 | sb.append("\n and properties['"+entry.getKey()+"'] = '"+entry.getValue()+"'");
44 |
45 | }
46 |
47 | return templet1+sb.toString()+ templet3;
48 | }
49 |
50 | public static void main(String[] args) {
51 |
52 | RuleAtomicParam ruleAtomicParam = new RuleAtomicParam();
53 | ruleAtomicParam.setEventId("R");
54 | HashMap props = new HashMap<>();
55 | props.put("p1","v2");
56 | props.put("p3","v4");
57 | props.put("p7","v5");
58 | ruleAtomicParam.setProperties(props);
59 | ruleAtomicParam.setRangeStart(1616925000815L);
60 | ruleAtomicParam.setRangeEnd(1616925004815L);
61 |
62 | String sql = getSql("000001", ruleAtomicParam);
63 | System.out.println(sql);
64 |
65 |
66 | }
67 |
68 | }
69 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/utils/ConnectionUtils.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.utils;
2 |
3 | import lombok.extern.slf4j.Slf4j;
4 |
5 | import java.sql.Connection;
6 | import java.sql.DriverManager;
7 |
8 | /**
9 | * @author 涛哥
10 | * @nick_name "deep as the sea"
11 | * @contact qq:657270652 wx:doit_edu
12 | * @site www.doitedu.cn
13 | * @date 2021-03-30
14 | * @desc 各类外部链接创建工具类
15 | */
16 | @Slf4j
17 | public class ConnectionUtils {
18 |
19 |
20 | public static Connection getClickhouseConnection() throws Exception {
21 | //String ckDriver = "com.github.housepower.jdbc.ClickHouseDriver";
22 | String ckDriver = "ru.yandex.clickhouse.ClickHouseDriver";
23 | String ckUrl = "jdbc:clickhouse://192.168.77.63:8123/default";
24 | String table = "yinew_detail";
25 |
26 | Class.forName(ckDriver);
27 | Connection conn = DriverManager.getConnection(ckUrl);
28 | log.debug("clickhouse jdbc 连接创建完成");
29 | return conn;
30 | }
31 |
32 |
33 | }
34 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/utils/RuleCalcUtil.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.utils;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
5 | import org.apache.commons.lang3.time.DateUtils;
6 |
7 | import java.util.*;
8 |
9 | /**
10 | * @author 涛哥
11 | * @nick_name "deep as the sea"
12 | * @contact qq:657270652 wx:doit_edu
13 | * @site www.doitedu.cn
14 | * @date 2021-03-28
15 | * @desc 规则计算中可能用到的各类工具方法
16 | */
17 | public class RuleCalcUtil {
18 | /**
19 | * 工具方法，用于判断一个待判断事件和一个规则中的原子条件是否一致
20 | * @param eventBean
21 | * @param eventParam
22 | * @return
23 | */
24 | public static boolean eventBeanMatchEventParam(LogBean eventBean, RuleAtomicParam eventParam){
25 | // 如果传入的一个事件的事件id与参数中的事件id相同，才开始进行属性判断
26 | if(eventBean.getEventId().equals(eventParam.getEventId())){
27 |
28 | // 取出待判断事件中的属性
29 | Map eventProperties = eventBean.getProperties();
30 |
31 | // 取出条件中的事件属性
32 | HashMap paramProperties = eventParam.getProperties();
33 | Set> entries = paramProperties.entrySet();
34 | // 遍历条件中的每个属性及值
35 | for (Map.Entry entry : entries) {
36 | if(!entry.getValue().equals(eventProperties.get(entry.getKey()))){
37 | return false;
38 | }
39 | }
40 |
41 | return true;
42 | }
43 |
44 | return false;
45 | }
46 |
47 | public static boolean eventBeanMatchEventParam(LogBean eventBean, RuleAtomicParam eventParam,boolean neeTimeCompare){
48 | boolean b = eventBeanMatchEventParam(eventBean, eventParam);
49 |
50 | // 要考虑一点，外部传入的条件中，时间范围条件，如果起始、结束没有约束，应该传入一个 -1
51 | long start = eventParam.getRangeStart();
52 | long end = eventParam.getRangeEnd();
53 |
54 | return b && eventBean.getTimeStamp()>= (start==-1?0:start) && eventBean.getTimeStamp()<= (end==-1?Long.MAX_VALUE:end);
55 |
56 | }
57 |
58 |
59 | public static String getBufferKey(String deviceId,RuleAtomicParam atomicParam){
60 | // deviceId-EVENT-p1-v1-p2-v2
61 | StringBuffer sb = new StringBuffer();
62 | sb.append(deviceId).append("-").append(atomicParam.getEventId());
63 |
64 | HashMap properties = atomicParam.getProperties();
65 | Set> entries = properties.entrySet();
66 | for (Map.Entry entry : entries) {
67 | sb.append("-").append(entry.getKey()).append("-").append(entry.getValue());
68 | }
69 |
70 | return sb.toString();
71 | }
72 |
73 | public static String getBufferKey(String deviceId, List paramList){
74 | // deviceId-EVENT1-p1-v1-p2-v2-EVENT2-p1-v1-p2-v2
75 | StringBuffer sb = new StringBuffer();
76 | sb.append(deviceId);
77 |
78 | for (RuleAtomicParam ruleAtomicParam : paramList) {
79 | sb.append("-").append(ruleAtomicParam.getEventId());
80 | HashMap properties = ruleAtomicParam.getProperties();
81 | Set> entries = properties.entrySet();
82 | for (Map.Entry entry : entries) {
83 | sb.append("-").append(entry.getKey()).append("-").append(entry.getValue());
84 | }
85 | }
86 |
87 | return sb.toString();
88 | }
89 |
90 |
91 | public static long getQuerySplit(){
92 | return DateUtils.addHours(DateUtils.ceiling(new Date(), Calendar.HOUR), -2).getTime();
93 | }
94 |
95 |
96 | }
97 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/utils/RuleOperationHandler.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.utils;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.RuleCanalBean;
4 | import cn.doitedu.dynamic_rule.pojo.RuleStateBean;
5 | import cn.doitedu.dynamic_rule.pojo.RuleTableRecord;
6 | import lombok.extern.slf4j.Slf4j;
7 | import org.apache.flink.api.common.state.BroadcastState;
8 | import org.apache.flink.api.common.state.MapState;
9 | import org.kie.api.io.ResourceType;
10 | import org.kie.api.runtime.KieSession;
11 | import org.kie.internal.utils.KieHelper;
12 |
13 | import java.util.List;
14 |
15 | @Slf4j
16 | public class RuleOperationHandler {
17 |
18 |
19 | /**
20 | * 规则操作处理入口方法
21 | *
22 | * @param ruleCanalBean
23 | * @param mapState
24 | */
25 | public static boolean handleRuleOper(RuleCanalBean ruleCanalBean, BroadcastState mapState) {
26 |
27 | try {
28 | // 从canal信息中，取到规则表的行数据List（id,规则名,规则代码,cntsql,seqsql)
29 | List dataList = ruleCanalBean.getData();
30 | if (dataList == null || dataList.size() < 1) return true;
31 |
32 | // 从行数据List中取到第一行（其实就只有一行）（id,规则名,规则代码,cntsql,seqsql)
33 | RuleTableRecord ruleTableRecord = dataList.get(0);
34 | String ruleName = ruleTableRecord.getRule_name();
35 |
36 | // 如果status=1，则做新增规则的操作
37 | if (ruleTableRecord.getRule_status() == 1) {
38 |
39 | // status =1 表示，有一条规则要使用，则往state中插入该规则信息
40 | RuleStateBean ruleStateBean = new RuleStateBean();
41 | ruleStateBean.setRuleName(ruleName);
42 |
43 | // 往statebean中cntsql
44 | ruleStateBean.setCntSqls(ruleTableRecord.getCnt_sqls());
45 |
46 | // 往statebean中seqsql
47 | ruleStateBean.setSeqSqls(ruleTableRecord.getSeq_sqls());
48 |
49 | // 往statebean中放kiesession
50 | KieHelper kieHelper = new KieHelper();
51 | kieHelper.addContent(ruleTableRecord.getRule_code(), ResourceType.DRL);
52 | KieSession kieSession = kieHelper.build().newKieSession();
53 |
54 | ruleStateBean.setKieSession(kieSession);
55 |
56 |
57 | // 把statebean放入state
58 | mapState.put(ruleName, ruleStateBean);
59 |
60 | }
61 | // 否则，只有删除这种情况，则做删除操作
62 | else {
63 | mapState.remove(ruleName);
64 | }
65 | return true;
66 | } catch (Exception e) {
67 |
68 | log.error("规则处理出现异常,异常信息: \n {}",e.getMessage());
69 |
70 | return false;
71 | }
72 | }
73 |
74 | }
75 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/utils/RuleSimulator.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.utils;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam;
4 | import cn.doitedu.dynamic_rule.pojo.RuleParam;
5 |
6 | import java.util.ArrayList;
7 | import java.util.HashMap;
8 |
9 | /**
10 | * @author 涛哥
11 | * @nick_name "deep as the sea"
12 | * @contact qq:657270652 wx:doit_edu
13 | * @site www.doitedu.cn
14 | * @date 2021-03-28
15 | * @desc 规则模拟器
16 | */
17 | public class RuleSimulator {
18 |
19 | public static RuleParam getRuleParam(){
20 |
21 | RuleParam ruleParam = new RuleParam();
22 | ruleParam.setRuleName("test_rule_1");
23 |
24 | // 构造触发条件
25 | RuleAtomicParam trigger = new RuleAtomicParam();
26 | trigger.setEventId("E");
27 | ruleParam.setTriggerParam(trigger);
28 |
29 |
30 | // 构造画像条件
31 | HashMap userProfileParams = new HashMap<>();
32 | userProfileParams.put("tag5","v1");
33 | //userProfileParams.put("tag6","v2");
34 | ruleParam.setUserProfileParams(userProfileParams);
35 |
36 |
37 | // 行为次数条件
38 | RuleAtomicParam count1 = new RuleAtomicParam();
39 | count1.setEventId("B");
40 | HashMap paramProps1 = new HashMap<>();
41 | paramProps1.put("p1","v1");
42 | count1.setProperties(paramProps1);
43 | count1.setOriginStart(0);
44 | count1.setOriginEnd(Long.MAX_VALUE);
45 | count1.setCnt(10);
46 | String sql1 = "select\n" +
47 | " deviceId,\n" +
48 | " count(1) as cnt\n" +
49 | "from yinew_detail\n" +
50 | "where deviceId= '${did}' and eventId='B' and properties['p1']='v1'\n" +
51 | " and timeStamp between 0 and 6615900580000\n" +
52 | "group by deviceId\n" +
53 | ";";
54 | count1.setCountQuerySql(sql1);
55 |
56 | RuleAtomicParam count2 = new RuleAtomicParam();
57 | count2.setEventId("D");
58 | HashMap paramProps2 = new HashMap<>();
59 | paramProps2.put("p2","v2");
60 | count2.setProperties(paramProps2);
61 | count2.setOriginStart(1617094800000L);
62 | count2.setOriginEnd(Long.MAX_VALUE);
63 | count2.setCnt(22);
64 | String sql2 = "select\n" +
65 | " deviceId,\n" +
66 | " count(1) as cnt\n" +
67 | "from yinew_detail\n" +
68 | "where deviceId= '${did}' and eventId='D' and properties['p2']='v2'\n" +
69 | " and timeStamp between 1617094800000 and 6615900580000\n" +
70 | "group by deviceId \n" +
71 | ";";
72 | count2.setCountQuerySql(sql2);
73 |
74 |
75 | ArrayList countParams = new ArrayList<>();
76 | countParams.add(count1);
77 | countParams.add(count2);
78 | ruleParam.setUserActionCountParams(countParams);
79 |
80 |
81 | // 行为序列（行为路径）条件(2个事件的序列）
82 | RuleAtomicParam param1 = new RuleAtomicParam();
83 | param1.setEventId("A");
84 | HashMap seqProps1 = new HashMap<>();
85 | seqProps1.put("p1","v1");
86 | param1.setProperties(seqProps1);
87 | param1.setOriginStart(0);
88 | param1.setOriginEnd(Long.MAX_VALUE);
89 |
90 | RuleAtomicParam param2 = new RuleAtomicParam();
91 | param2.setEventId("C");
92 | HashMap seqProps2 = new HashMap<>();
93 | seqProps2.put("p2","v2");
94 | param2.setProperties(seqProps2);
95 | param2.setOriginStart(0);
96 | param2.setOriginEnd(Long.MAX_VALUE);
97 |
98 |
99 | ArrayList ruleParams = new ArrayList<>();
100 | ruleParams.add(param1);
101 | ruleParams.add(param2);
102 |
103 | ruleParam.setUserActionSequenceParams(ruleParams);
104 | String sql = "SELECT\n" +
105 | " deviceId,\n" +
106 | " sequenceMatch('.*(?1).*(?2).*')(\n" +
107 | " toDateTime(`timeStamp`),\n" +
108 | " eventId = 'A' and properties['p1']='v1',\n" +
109 | " eventId = 'C' and properties['p2']='v2'\n" +
110 | " ) as isMatch2,\n" +
111 | "\n" +
112 | " sequenceMatch('.*(?1).*')(\n" +
113 | " toDateTime(`timeStamp`),\n" +
114 | " eventId = 'A' and properties['p1']='v1',\n" +
115 | " eventId = 'C' and properties['p2']='v2'\n" +
116 | " ) as isMatch1\n" +
117 | "\n" +
118 | "from yinew_detail\n" +
119 | "where\n" +
120 | " deviceId = '${did}' \n" +
121 | " and\n" +
122 | " timeStamp >= 0\n" +
123 | " and\n" +
124 | " timeStamp <= 6235295739479\n" +
125 | " and\n" +
126 | " (\n" +
127 | " (eventId='A' and properties['p1']='v1')\n" +
128 | " or (eventId = 'C' and properties['p2']='v2')\n" +
129 | " )\n" +
130 | "group by deviceId;";
131 | ruleParam.setActionSequenceQuerySql(sql);
132 |
133 | return ruleParam;
134 | }
135 | }
136 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/java/cn/doitedu/dynamic_rule/utils/StateDescUtil.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rule.utils;
2 |
3 | import cn.doitedu.dynamic_rule.pojo.LogBean;
4 | import cn.doitedu.dynamic_rule.pojo.RuleStateBean;
5 | import org.apache.flink.api.common.state.ListStateDescriptor;
6 | import org.apache.flink.api.common.state.MapStateDescriptor;
7 | import org.kie.api.runtime.KieSession;
8 |
9 | public class StateDescUtil {
10 |
11 | /**
12 | * 存放drools规则容器session的state定义器
13 | */
14 | public static final MapStateDescriptor ruleKieStateDesc = new MapStateDescriptor("ruleKieState",String.class,RuleStateBean.class);
15 |
16 | public static final ListStateDescriptor eventStateDesc = new ListStateDescriptor<>("eventState", LogBean.class);
17 |
18 |
19 | }
20 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/resources/META-INF/kmodule.xml:
--------------------------------------------------------------------------------
1 |
2 |
3 |
4 |
5 |
6 |
7 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/resources/bak/log4j.properties:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/coderblack/yinew_marketing/45ef4c47dec6f42c5e963a915ddaa88ad2a5fcaf/dynamic_rule_engine/src/main/resources/bak/log4j.properties
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/resources/bak/log4j2.properties:
--------------------------------------------------------------------------------
1 | ################################################################################
2 | # Licensed to the Apache Software Foundation (ASF) under one
3 | # or more contributor license agreements. See the NOTICE file
4 | # distributed with this work for additional information
5 | # regarding copyright ownership. The ASF licenses this file
6 | # to you under the Apache License, Version 2.0 (the
7 | # "License"); you may not use this file except in compliance
8 | # with the License. You may obtain a copy of the License at
9 | #
10 | # http://www.apache.org/licenses/LICENSE-2.0
11 | #
12 | # Unless required by applicable law or agreed to in writing, software
13 | # distributed under the License is distributed on an "AS IS" BASIS,
14 | # WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
15 | # See the License for the specific language governing permissions and
16 | # limitations under the License.
17 | ################################################################################
18 |
19 | # Allows this configuration to be modified at runtime. The file will be checked every 30 seconds.
20 | monitorInterval=30
21 |
22 | # This affects logging for both user code and Flink
23 | rootLogger.level = INFO
24 | # rootLogger.appenderRef.file.ref = MainAppender
25 | rootLogger.appenderRef.console.ref = Console_OUT
26 |
27 | # Uncomment this if you want to _only_ change Flink's logging
28 | logger.flink.name = org.apache.flink
29 | logger.flink.level = ERROR
30 |
31 | appender.console.type = Console
32 | appender.console.name = Console_OUT
33 | appender.console.layout.type = PatternLayout
34 | appender.console.layout.pattern = %d{yyyy-MM-dd HH:mm:ss} [%p] %c: %msg%n
35 | appender.console.filter.threshold.type = ThresholdFilter
36 | appender.console.filter.threshold.level = INFO
37 |
38 |
39 | # The following lines keep the log level of common libraries/connectors on
40 | # log level INFO. The root logger does not override this. You have to manually
41 | # change the log levels here.
42 | logger.akka.name = akka
43 | logger.akka.level = ERROR
44 | logger.kafka.name= org.apache.kafka
45 | logger.kafka.level = ERROR
46 | logger.hadoop.name = org.apache.hadoop
47 | logger.hadoop.level = ERROR
48 | logger.zookeeper.name = org.apache.zookeeper
49 | logger.zookeeper.level = ERROR
50 |
51 | logger.doit.name = cn.doitedu.dynamic_rule
52 | logger.doit.level = INFO
53 | #logger.doit.appenderRef.console.ref = Console_OUT
54 | logger.doit.appenderRef.file.ref = MainAppender
55 | logger.doit.additivity = false
56 |
57 | logger.clickhouse.name = ru.yandex.clickhouse
58 | logger.clickhouse.level = WARN
59 |
60 | # Log all infos in the given file
61 | appender.main.name = MainAppender
62 | appender.main.type = RollingFile
63 | appender.main.append = true
64 | #appender.main.fileName = ${sys:log.file}
65 | #appender.main.filePattern = ${sys:log.file}.%i
66 | appender.main.fileName = d:/yinew.log
67 | appender.main.filePattern = d:/yinew.log.%i
68 | appender.main.layout.type = PatternLayout
69 | appender.main.layout.pattern = %d{yyyy-MM-dd HH:mm:ss,SSS} %-5p %-60c %x - %m%n
70 | appender.main.policies.type = Policies
71 | appender.main.policies.size.type = SizeBasedTriggeringPolicy
72 | appender.main.policies.size.size = 100MB
73 | appender.main.policies.startup.type = OnStartupTriggeringPolicy
74 | appender.main.strategy.type = DefaultRolloverStrategy
75 | #appender.main.strategy.max = ${env:MAX_LOG_FILE_NUMBER:-10}
76 | appender.main.strategy.max = 10
77 |
78 | # Suppress the irrelevant (wrong) warnings from the Netty channel handler
79 | logger.netty.name = org.apache.flink.shaded.akka.org.jboss.netty.channel.DefaultChannelPipeline
80 | logger.netty.level = OFF
81 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/resources/log4j.properties:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/coderblack/yinew_marketing/45ef4c47dec6f42c5e963a915ddaa88ad2a5fcaf/dynamic_rule_engine/src/main/resources/log4j.properties
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/resources/log4j2.properties:
--------------------------------------------------------------------------------
1 | ################################################################################
2 | # Licensed to the Apache Software Foundation (ASF) under one
3 | # or more contributor license agreements. See the NOTICE file
4 | # distributed with this work for additional information
5 | # regarding copyright ownership. The ASF licenses this file
6 | # to you under the Apache License, Version 2.0 (the
7 | # "License"); you may not use this file except in compliance
8 | # with the License. You may obtain a copy of the License at
9 | #
10 | # http://www.apache.org/licenses/LICENSE-2.0
11 | #
12 | # Unless required by applicable law or agreed to in writing, software
13 | # distributed under the License is distributed on an "AS IS" BASIS,
14 | # WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
15 | # See the License for the specific language governing permissions and
16 | # limitations under the License.
17 | ################################################################################
18 |
19 | # Allows this configuration to be modified at runtime. The file will be checked every 30 seconds.
20 | monitorInterval=30
21 |
22 | # This affects logging for both user code and Flink
23 | rootLogger.level = INFO
24 | # rootLogger.appenderRef.file.ref = MainAppender
25 | rootLogger.appenderRef.console.ref = Console_OUT
26 |
27 |
28 | # Uncomment this if you want to _only_ change Flink's logging
29 | logger.flink.name = org.apache.flink
30 | logger.flink.level = ERROR
31 |
32 | appender.console.type = Console
33 | appender.console.name = Console_OUT
34 | appender.console.layout.type = PatternLayout
35 | appender.console.layout.pattern = %d{yyyy-MM-dd HH:mm:ss} [%p] %c: %msg%n
36 | appender.console.filter.threshold.type = ThresholdFilter
37 | appender.console.filter.threshold.level = DEBUG
38 |
39 |
40 | # The following lines keep the log level of common libraries/connectors on
41 | # log level INFO. The root logger does not override this. You have to manually
42 | # change the log levels here.
43 | logger.akka.name = akka
44 | logger.akka.level = ERROR
45 | logger.kafka.name= org.apache.kafka
46 | logger.kafka.level = ERROR
47 | logger.hadoop.name = org.apache.hadoop
48 | logger.hadoop.level = ERROR
49 | logger.zookeeper.name = org.apache.zookeeper
50 | logger.zookeeper.level = ERROR
51 |
52 | logger.doit.name = cn.doitedu.dynamic_rule
53 | logger.doit.level = INFO
54 | logger.doit.appenderRef.console.ref = Console_OUT
55 | #logger.doit.appenderRef.file.ref = MainAppender
56 | logger.doit.additivity = false
57 |
58 | logger.clickhouse.name = ru.yandex.clickhouse
59 | logger.clickhouse.level = WARN
60 |
61 | logger.kie.name = org.kie
62 | logger.kie.level = ERROR
63 |
64 | logger.drools.name = org.drools
65 | logger.drools.level = ERROR
66 |
67 | # Log all infos in the given file
68 | appender.main.name = MainAppender
69 | appender.main.type = RollingFile
70 | appender.main.append = true
71 | #appender.main.fileName = ${sys:log.file}
72 | #appender.main.filePattern = ${sys:log.file}.%i
73 | appender.main.fileName = d:/yinew.log
74 | appender.main.filePattern = d:/yinew.log.%i
75 | appender.main.layout.type = PatternLayout
76 | appender.main.layout.pattern = %d{yyyy-MM-dd HH:mm:ss,SSS} %-5p %-60c %x - %m%n
77 | appender.main.policies.type = Policies
78 | appender.main.policies.size.type = SizeBasedTriggeringPolicy
79 | appender.main.policies.size.size = 100MB
80 | appender.main.policies.startup.type = OnStartupTriggeringPolicy
81 | appender.main.strategy.type = DefaultRolloverStrategy
82 | #appender.main.strategy.max = ${env:MAX_LOG_FILE_NUMBER:-10}
83 | appender.main.strategy.max = 10
84 |
85 | # Suppress the irrelevant (wrong) warnings from the Netty channel handler
86 | logger.netty.name = org.apache.flink.shaded.akka.org.jboss.netty.channel.DefaultChannelPipeline
87 | logger.netty.level = OFF
88 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/resources/rules/flink.drl:
--------------------------------------------------------------------------------
1 | package cn.doitedu.demo.droolsdemo.rules
2 | import cn.doitedu.dynamic_rule.demos.Action
3 |
4 | import cn.doitedu.dynamic_rule.demos.Applicant
5 | import cn.doitedu.dynamic_rule.demos.Action
6 |
7 | rule "age if valid"
8 | when
9 | $a: Applicant()
10 | then
11 | if($a.getAge() >=18){
12 | $a.setValid(true);
13 | }else{
14 | $a.setValid(false);
15 | }
16 | end
17 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/main/resources/rules/test.drl:
--------------------------------------------------------------------------------
1 | package cn.doitedu.demo.droolsdemo.rules
2 | import cn.doitedu.dynamic_rule.demos.Action
3 |
4 | // 导包
5 | import cn.doitedu.dynamic_rule.demos.Applicant
6 | import cn.doitedu.dynamic_rule.demos.Action
7 |
8 | // rule1 名称
9 | rule "age if valid"
10 | when // 触发判断条件
11 | $a: Applicant(age < 18)
12 | then // 满足条件后要执行的逻辑
13 | $a.setValid(false);// 可以执行任何java代码（对输入的对象调用方法）
14 | new Action("执行动作").doSomeThing(); //可以执行任何java代码（创建对象调方法）
15 | insert(new Action("不合法")); //可以继续给容器插入对象，以触发其他规则
16 | end
17 |
18 | // rule2 名称
19 | rule "send_act"
20 | when
21 | $a: Action()
22 | then
23 | $a.doSomeThing();
24 | end
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/test/java/ListRemoveDemo.java:
--------------------------------------------------------------------------------
1 | import java.util.ArrayList;
2 |
3 | public class ListRemoveDemo {
4 | public static void main(String[] args) {
5 |
6 | ArrayList lst = new ArrayList<>();
7 | lst.add("a");
8 | /* lst.add("b");
9 | lst.add("c");
10 | lst.add("d");
11 | lst.add("e");*/
12 |
13 | /*for (String s : lst) {
14 | if(s.equals("c")) lst.remove("c");
15 | }*/
16 |
17 |
18 | for (int i = 0; i < lst.size(); i++) {
19 |
20 | String s = lst.get(i);
21 | if (s.equals("a") || s.equals("d")) {
22 | lst.remove(i);
23 | i--;
24 | }
25 |
26 | }
27 |
28 | System.out.println(lst);
29 | }
30 | }
31 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/test/java/RuleTest.java:
--------------------------------------------------------------------------------
1 | import cn.doitedu.dynamic_rule.pojo.DroolFact;
2 | import cn.doitedu.dynamic_rule.pojo.LogBean;
3 | import org.apache.commons.io.FileUtils;
4 | import org.kie.api.io.ResourceType;
5 | import org.kie.api.runtime.KieSession;
6 | import org.kie.internal.utils.KieHelper;
7 |
8 | import java.io.File;
9 | import java.io.IOException;
10 |
11 | public class RuleTest {
12 |
13 | public static void main(String[] args) throws IOException {
14 |
15 |
16 | String s = FileUtils.readFileToString(new File("dynamic_rule_engine/rules_drl/rule1.drl"), "utf-8");
17 |
18 | KieHelper kieHelper = new KieHelper();
19 | KieSession kieSession = kieHelper.addContent(s, ResourceType.DRL).build().newKieSession();
20 |
21 |
22 | DroolFact droolFact = new DroolFact();
23 |
24 | LogBean logBean = new LogBean();
25 | logBean.setEventId("D");
26 |
27 | droolFact.setLogBean(logBean);
28 |
29 |
30 | kieSession.insert(droolFact);
31 | kieSession.fireAllRules();
32 |
33 |
34 | kieSession.dispose();
35 |
36 | }
37 | }
38 |
--------------------------------------------------------------------------------
/dynamic_rule_engine/src/test/java/Test.java:
--------------------------------------------------------------------------------
1 | import org.apache.commons.lang3.RandomStringUtils;
2 | import org.apache.commons.lang3.time.DateUtils;
3 |
4 | import java.util.Calendar;
5 | import java.util.Date;
6 |
7 | public class Test {
8 | public static void main(String[] args) {
9 |
10 | /*for(int i=0;i<100;i++){
11 | System.out.println(RandomStringUtils.randomAlphabetic(1));
12 | }*/
13 |
14 | long x = System.currentTimeMillis() - 2*60*60*1000;
15 | System.out.println(x);
16 |
17 |
18 | Date date = DateUtils.addHours(DateUtils.ceiling(new Date(), Calendar.HOUR), -2);
19 | System.out.println(date);
20 |
21 |
22 |
23 |
24 |
25 |
26 | }
27 | }
28 |
--------------------------------------------------------------------------------
/log4jdemo/pom.xml:
--------------------------------------------------------------------------------
1 |
2 |
5 |
6 | yinew_marketing
7 | cn.doitedu
8 | 1.0
9 |
10 | 4.0.0
11 |
12 | log4jdemo
13 |
14 |
15 |
16 | log4j
17 | log4j
18 | 1.2.17
19 |
20 |
21 |
22 |
23 |
24 |
25 |
26 |
--------------------------------------------------------------------------------
/log4jdemo/src/main/java/cn/doitedu/log4j/Demo.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.log4j;
2 |
3 | import org.apache.log4j.Logger;
4 |
5 | public class Demo {
6 |
7 | public static void main(String[] args) {
8 |
9 | // 根logger
10 | Logger rootLogger = Logger.getRootLogger();
11 |
12 | // 每一个logger对象都有自己的命名
13 | Logger logger1 = Logger.getLogger("cn");
14 |
15 | // cn.doitedu这个logger是 cn这个logger的 子logger
16 | // 子logger会继承父logger的配置
17 | Logger logger2 = Logger.getLogger("cn.doitedu");
18 |
19 |
20 | Logger demoLogger = Logger.getLogger(Demo.class);
21 |
22 |
23 | // debug的级别最低
24 | logger1.debug("这是一条debug级别的日志");
25 |
26 | // info级别大于debug
27 | logger1.info("这是一条info级别的日志");
28 |
29 | // warn级别大于info
30 | logger1.warn("这是一条warn级别的日志");
31 |
32 | // error级别大于warn
33 | logger1.error("这是一条error级别的日志");
34 |
35 |
36 | logger2.debug("这是cn.doitedu 这个 logger的debug日志");
37 | logger2.info("这是cn.doitedu 这个 logger的info日志");
38 | logger2.warn("这是cn.doitedu 这个 logger的warn日志");
39 | logger2.error("这是cn.doitedu 这个 logger的error日志");
40 |
41 |
42 | }
43 | }
44 |
--------------------------------------------------------------------------------
/log4jdemo/src/main/resources/log4j.properties:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/coderblack/yinew_marketing/45ef4c47dec6f42c5e963a915ddaa88ad2a5fcaf/log4jdemo/src/main/resources/log4j.properties
--------------------------------------------------------------------------------
/manageplatform/HELP.md:
--------------------------------------------------------------------------------
1 | # Getting Started
2 |
3 | ### Reference Documentation
4 | For further reference, please consider the following sections:
5 |
6 | * [Official Apache Maven documentation](https://maven.apache.org/guides/index.html)
7 | * [Spring Boot Maven Plugin Reference Guide](https://docs.spring.io/spring-boot/docs/2.4.4/maven-plugin/reference/html/)
8 | * [Create an OCI image](https://docs.spring.io/spring-boot/docs/2.4.4/maven-plugin/reference/html/#build-image)
9 | * [Spring Configuration Processor](https://docs.spring.io/spring-boot/docs/2.4.4/reference/htmlsingle/#configuration-metadata-annotation-processor)
10 | * [Spring Web](https://docs.spring.io/spring-boot/docs/2.4.4/reference/htmlsingle/#boot-features-developing-web-applications)
11 | * [Spring Boot DevTools](https://docs.spring.io/spring-boot/docs/2.4.4/reference/htmlsingle/#using-boot-devtools)
12 |
13 | ### Guides
14 | The following guides illustrate how to use some features concretely:
15 |
16 | * [Building a RESTful Web Service](https://spring.io/guides/gs/rest-service/)
17 | * [Serving Web Content with Spring MVC](https://spring.io/guides/gs/serving-web-content/)
18 | * [Building REST services with Spring](https://spring.io/guides/tutorials/bookmarks/)
19 |
20 |
--------------------------------------------------------------------------------
/manageplatform/mvnw.cmd:
--------------------------------------------------------------------------------
1 | @REM ----------------------------------------------------------------------------
2 | @REM Licensed to the Apache Software Foundation (ASF) under one
3 | @REM or more contributor license agreements. See the NOTICE file
4 | @REM distributed with this work for additional information
5 | @REM regarding copyright ownership. The ASF licenses this file
6 | @REM to you under the Apache License, Version 2.0 (the
7 | @REM "License"); you may not use this file except in compliance
8 | @REM with the License. You may obtain a copy of the License at
9 | @REM
10 | @REM https://www.apache.org/licenses/LICENSE-2.0
11 | @REM
12 | @REM Unless required by applicable law or agreed to in writing,
13 | @REM software distributed under the License is distributed on an
14 | @REM "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY
15 | @REM KIND, either express or implied. See the License for the
16 | @REM specific language governing permissions and limitations
17 | @REM under the License.
18 | @REM ----------------------------------------------------------------------------
19 |
20 | @REM ----------------------------------------------------------------------------
21 | @REM Maven Start Up Batch script
22 | @REM
23 | @REM Required ENV vars:
24 | @REM JAVA_HOME - location of a JDK home dir
25 | @REM
26 | @REM Optional ENV vars
27 | @REM M2_HOME - location of maven2's installed home dir
28 | @REM MAVEN_BATCH_ECHO - set to 'on' to enable the echoing of the batch commands
29 | @REM MAVEN_BATCH_PAUSE - set to 'on' to wait for a keystroke before ending
30 | @REM MAVEN_OPTS - parameters passed to the Java VM when running Maven
31 | @REM e.g. to debug Maven itself, use
32 | @REM set MAVEN_OPTS=-Xdebug -Xrunjdwp:transport=dt_socket,server=y,suspend=y,address=8000
33 | @REM MAVEN_SKIP_RC - flag to disable loading of mavenrc files
34 | @REM ----------------------------------------------------------------------------
35 |
36 | @REM Begin all REM lines with '@' in case MAVEN_BATCH_ECHO is 'on'
37 | @echo off
38 | @REM set title of command window
39 | title %0
40 | @REM enable echoing by setting MAVEN_BATCH_ECHO to 'on'
41 | @if "%MAVEN_BATCH_ECHO%" == "on" echo %MAVEN_BATCH_ECHO%
42 |
43 | @REM set %HOME% to equivalent of $HOME
44 | if "%HOME%" == "" (set "HOME=%HOMEDRIVE%%HOMEPATH%")
45 |
46 | @REM Execute a user defined script before this one
47 | if not "%MAVEN_SKIP_RC%" == "" goto skipRcPre
48 | @REM check for pre script, once with legacy .bat ending and once with .cmd ending
49 | if exist "%HOME%\mavenrc_pre.bat" call "%HOME%\mavenrc_pre.bat"
50 | if exist "%HOME%\mavenrc_pre.cmd" call "%HOME%\mavenrc_pre.cmd"
51 | :skipRcPre
52 |
53 | @setlocal
54 |
55 | set ERROR_CODE=0
56 |
57 | @REM To isolate internal variables from possible post scripts, we use another setlocal
58 | @setlocal
59 |
60 | @REM ==== START VALIDATION ====
61 | if not "%JAVA_HOME%" == "" goto OkJHome
62 |
63 | echo.
64 | echo Error: JAVA_HOME not found in your environment. >&2
65 | echo Please set the JAVA_HOME variable in your environment to match the >&2
66 | echo location of your Java installation. >&2
67 | echo.
68 | goto error
69 |
70 | :OkJHome
71 | if exist "%JAVA_HOME%\bin\java.exe" goto init
72 |
73 | echo.
74 | echo Error: JAVA_HOME is set to an invalid directory. >&2
75 | echo JAVA_HOME = "%JAVA_HOME%" >&2
76 | echo Please set the JAVA_HOME variable in your environment to match the >&2
77 | echo location of your Java installation. >&2
78 | echo.
79 | goto error
80 |
81 | @REM ==== END VALIDATION ====
82 |
83 | :init
84 |
85 | @REM Find the project base dir, i.e. the directory that contains the folder ".mvn".
86 | @REM Fallback to current working directory if not found.
87 |
88 | set MAVEN_PROJECTBASEDIR=%MAVEN_BASEDIR%
89 | IF NOT "%MAVEN_PROJECTBASEDIR%"=="" goto endDetectBaseDir
90 |
91 | set EXEC_DIR=%CD%
92 | set WDIR=%EXEC_DIR%
93 | :findBaseDir
94 | IF EXIST "%WDIR%"\.mvn goto baseDirFound
95 | cd ..
96 | IF "%WDIR%"=="%CD%" goto baseDirNotFound
97 | set WDIR=%CD%
98 | goto findBaseDir
99 |
100 | :baseDirFound
101 | set MAVEN_PROJECTBASEDIR=%WDIR%
102 | cd "%EXEC_DIR%"
103 | goto endDetectBaseDir
104 |
105 | :baseDirNotFound
106 | set MAVEN_PROJECTBASEDIR=%EXEC_DIR%
107 | cd "%EXEC_DIR%"
108 |
109 | :endDetectBaseDir
110 |
111 | IF NOT EXIST "%MAVEN_PROJECTBASEDIR%\.mvn\jvm.config" goto endReadAdditionalConfig
112 |
113 | @setlocal EnableExtensions EnableDelayedExpansion
114 | for /F "usebackq delims=" %%a in ("%MAVEN_PROJECTBASEDIR%\.mvn\jvm.config") do set JVM_CONFIG_MAVEN_PROPS=!JVM_CONFIG_MAVEN_PROPS! %%a
115 | @endlocal & set JVM_CONFIG_MAVEN_PROPS=%JVM_CONFIG_MAVEN_PROPS%
116 |
117 | :endReadAdditionalConfig
118 |
119 | SET MAVEN_JAVA_EXE="%JAVA_HOME%\bin\java.exe"
120 | set WRAPPER_JAR="%MAVEN_PROJECTBASEDIR%\.mvn\wrapper\maven-wrapper.jar"
121 | set WRAPPER_LAUNCHER=org.apache.maven.wrapper.MavenWrapperMain
122 |
123 | set DOWNLOAD_URL="https://repo.maven.apache.org/maven2/io/takari/maven-wrapper/0.5.6/maven-wrapper-0.5.6.jar"
124 |
125 | FOR /F "tokens=1,2 delims==" %%A IN ("%MAVEN_PROJECTBASEDIR%\.mvn\wrapper\maven-wrapper.properties") DO (
126 | IF "%%A"=="wrapperUrl" SET DOWNLOAD_URL=%%B
127 | )
128 |
129 | @REM Extension to allow automatically downloading the maven-wrapper.jar from Maven-central
130 | @REM This allows using the maven wrapper in projects that prohibit checking in binary data.
131 | if exist %WRAPPER_JAR% (
132 | if "%MVNW_VERBOSE%" == "true" (
133 | echo Found %WRAPPER_JAR%
134 | )
135 | ) else (
136 | if not "%MVNW_REPOURL%" == "" (
137 | SET DOWNLOAD_URL="%MVNW_REPOURL%/io/takari/maven-wrapper/0.5.6/maven-wrapper-0.5.6.jar"
138 | )
139 | if "%MVNW_VERBOSE%" == "true" (
140 | echo Couldn't find %WRAPPER_JAR%, downloading it ...
141 | echo Downloading from: %DOWNLOAD_URL%
142 | )
143 |
144 | powershell -Command "&{"^
145 | "$webclient = new-object System.Net.WebClient;"^
146 | "if (-not ([string]::IsNullOrEmpty('%MVNW_USERNAME%') -and [string]::IsNullOrEmpty('%MVNW_PASSWORD%'))) {"^
147 | "$webclient.Credentials = new-object System.Net.NetworkCredential('%MVNW_USERNAME%', '%MVNW_PASSWORD%');"^
148 | "}"^
149 | "[Net.ServicePointManager]::SecurityProtocol = [Net.SecurityProtocolType]::Tls12; $webclient.DownloadFile('%DOWNLOAD_URL%', '%WRAPPER_JAR%')"^
150 | "}"
151 | if "%MVNW_VERBOSE%" == "true" (
152 | echo Finished downloading %WRAPPER_JAR%
153 | )
154 | )
155 | @REM End of extension
156 |
157 | @REM Provide a "standardized" way to retrieve the CLI args that will
158 | @REM work with both Windows and non-Windows executions.
159 | set MAVEN_CMD_LINE_ARGS=%*
160 |
161 | %MAVEN_JAVA_EXE% %JVM_CONFIG_MAVEN_PROPS% %MAVEN_OPTS% %MAVEN_DEBUG_OPTS% -classpath %WRAPPER_JAR% "-Dmaven.multiModuleProjectDirectory=%MAVEN_PROJECTBASEDIR%" %WRAPPER_LAUNCHER% %MAVEN_CONFIG% %*
162 | if ERRORLEVEL 1 goto error
163 | goto end
164 |
165 | :error
166 | set ERROR_CODE=1
167 |
168 | :end
169 | @endlocal & set ERROR_CODE=%ERROR_CODE%
170 |
171 | if not "%MAVEN_SKIP_RC%" == "" goto skipRcPost
172 | @REM check for post script, once with legacy .bat ending and once with .cmd ending
173 | if exist "%HOME%\mavenrc_post.bat" call "%HOME%\mavenrc_post.bat"
174 | if exist "%HOME%\mavenrc_post.cmd" call "%HOME%\mavenrc_post.cmd"
175 | :skipRcPost
176 |
177 | @REM pause the script if MAVEN_BATCH_PAUSE is set to 'on'
178 | if "%MAVEN_BATCH_PAUSE%" == "on" pause
179 |
180 | if "%MAVEN_TERMINATE_CMD%" == "on" exit %ERROR_CODE%
181 |
182 | exit /B %ERROR_CODE%
183 |
--------------------------------------------------------------------------------
/manageplatform/pom.xml:
--------------------------------------------------------------------------------
1 |
2 |
4 | 4.0.0
5 |
6 | org.springframework.boot
7 | spring-boot-starter-parent
8 | 2.4.4
9 |
10 |
11 | cn.doitedu.yinew
12 | manageplatform
13 | 0.0.1-SNAPSHOT
14 | manageplatform
15 | Demo project for Spring Boot
16 |
17 | 1.8
18 |
19 |
20 |
21 | org.springframework.boot
22 | spring-boot-starter-web
23 |
24 |
25 |
26 | org.springframework.boot
27 | spring-boot-starter-freemarker
28 |
29 |
30 |
31 | org.springframework.boot
32 | spring-boot-devtools
33 | runtime
34 | true
35 |
36 |
37 | org.springframework.boot
38 | spring-boot-configuration-processor
39 | true
40 |
41 |
42 | org.projectlombok
43 | lombok
44 | true
45 |
46 |
47 | org.springframework.boot
48 | spring-boot-starter-test
49 | test
50 |
51 |
52 |
53 | redis.clients
54 | jedis
55 | 2.9.0
56 |
57 |
58 |
59 | com.alibaba
60 | fastjson
61 | 1.2.75
62 |
63 |
64 | commons-io
65 | commons-io
66 | 2.7
67 | compile
68 |
69 |
70 |
71 | mysql
72 | mysql-connector-java
73 | 8.0.23
74 |
75 |
76 |
77 |
78 |
79 |
80 | org.springframework.boot
81 | spring-boot-maven-plugin
82 |
83 |
84 |
85 | org.projectlombok
86 | lombok
87 |
88 |
89 |
90 |
91 |
92 |
93 |
94 |
95 |
--------------------------------------------------------------------------------
/manageplatform/src/main/java/cn/doitedu/yinew/manageplatform/ManageplatformApplication.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.yinew.manageplatform;
2 |
3 | import org.springframework.boot.SpringApplication;
4 | import org.springframework.boot.autoconfigure.SpringBootApplication;
5 |
6 | @SpringBootApplication
7 | public class ManageplatformApplication {
8 |
9 | public static void main(String[] args) {
10 | SpringApplication.run(ManageplatformApplication.class, args);
11 | }
12 |
13 | }
14 |
--------------------------------------------------------------------------------
/manageplatform/src/main/java/cn/doitedu/yinew/manageplatform/controller/FreeMarkerDemoController.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.yinew.manageplatform.controller;
2 |
3 | import cn.doitedu.yinew.manageplatform.pojo.Animal;
4 | import cn.doitedu.yinew.manageplatform.pojo.RuleAtomicParam;
5 | import freemarker.template.Configuration;
6 | import freemarker.template.Template;
7 | import freemarker.template.TemplateExceptionHandler;
8 | import org.springframework.web.bind.annotation.RequestMapping;
9 | import org.springframework.web.bind.annotation.RestController;
10 |
11 | import java.io.File;
12 | import java.io.OutputStreamWriter;
13 | import java.io.Writer;
14 | import java.util.ArrayList;
15 | import java.util.HashMap;
16 |
17 | @RestController
18 | public class FreeMarkerDemoController {
19 |
20 | @RequestMapping("/demo")
21 | public String demo(String name, String animalStr) throws Exception {
22 |
23 | String[] split = animalStr.split("-");
24 | ArrayList animals = new ArrayList<>();
25 | for (String s : split) {
26 | String[] s1 = s.split("_");
27 | Animal animal = new Animal(s1[0], Integer.parseInt(s1[1]));
28 | animals.add(animal);
29 | }
30 |
31 | // 数据封装
32 | HashMap data = new HashMap<>();
33 | data.put("user", name);
34 | data.put("animals", animals);
35 |
36 | // 构造模板引擎
37 | Configuration cfg = new Configuration(Configuration.VERSION_2_3_22);
38 | cfg.setDirectoryForTemplateLoading(new File("manageplatform/src/main/resources/templates"));
39 | cfg.setDefaultEncoding("UTF-8");
40 | cfg.setTemplateExceptionHandler(TemplateExceptionHandler.RETHROW_HANDLER);
41 | Template temp = cfg.getTemplate("demo.ftl");
42 | Writer out = new OutputStreamWriter(System.out);
43 |
44 | // 调用模板引擎渲染
45 | temp.process(data, out);
46 |
47 | return "ok";
48 | }
49 |
50 |
51 | @RequestMapping("/cntsql")
52 | public String getRuleCountSql() throws Exception {
53 | ArrayList params = new ArrayList<>();
54 |
55 | RuleAtomicParam param1 = new RuleAtomicParam();
56 | param1.setEventId("H");
57 | HashMap prop1 = new HashMap<>();
58 | prop1.put("p1","v1");
59 | prop1.put("p2","v3");
60 | prop1.put("p4","v5");
61 | param1.setProperties(prop1);
62 |
63 |
64 | RuleAtomicParam param2 = new RuleAtomicParam();
65 | param2.setEventId("C");
66 | HashMap prop2 = new HashMap<>();
67 | prop2.put("p5","v6");
68 | param2.setProperties(prop2);
69 |
70 |
71 | params.add(param1);
72 | params.add(param2);
73 |
74 |
75 | // 数据封装
76 | HashMap data = new HashMap<>();
77 | data.put("events",params);
78 |
79 | Configuration cfg = new Configuration(Configuration.VERSION_2_3_22);
80 | cfg.setDirectoryForTemplateLoading(new File("manageplatform/src/main/resources/templates"));
81 | cfg.setDefaultEncoding("UTF-8");
82 | cfg.setTemplateExceptionHandler(TemplateExceptionHandler.RETHROW_HANDLER);
83 | Template temp = cfg.getTemplate("eventCountModel.ftl");
84 | Writer out = new OutputStreamWriter(System.out);
85 |
86 | // 调用模板引擎渲染
87 | temp.process(data, out);
88 |
89 | return "ok";
90 |
91 | }
92 |
93 | }
94 |
--------------------------------------------------------------------------------
/manageplatform/src/main/java/cn/doitedu/yinew/manageplatform/controller/RuleDashboardController.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.yinew.manageplatform.controller;
2 |
3 |
4 | import cn.doitedu.yinew.manageplatform.pojo.RuleStatus;
5 | import com.alibaba.fastjson.JSON;
6 | import org.springframework.web.bind.annotation.*;
7 | import redis.clients.jedis.Jedis;
8 |
9 | import java.util.ArrayList;
10 | import java.util.List;
11 | import java.util.Map;
12 | import java.util.Set;
13 |
14 | @RestController
15 | public class RuleDashboardController {
16 | Jedis jedis = null;
17 | public RuleDashboardController(){
18 | jedis = new Jedis("hdp02", 6379);
19 | }
20 |
21 | /**
22 | * 获取所有规则的状态信息
23 | *
24 | * {
25 | * ruleName: '运营公众号拉新',
26 | * ruleType: '触发型',
27 | * publishTime: '2021-04-01 12:30:45',
28 | * lastTrigTime: '2021-06-08 13:30:30',
29 | * trigCount: 80,
30 | * hitCount: 20,
31 | * hitRatio: '30%',
32 | * compareGroupRatio: '20%',
33 | * ruleGroupRation: '40%',
34 | * runStatus:"1"
35 | * }
36 | *
37 | * @return
38 | */
39 | @RequestMapping(method = RequestMethod.POST,value = "/api/getrulestatus")
40 | @CrossOrigin(origins = "http://localhost:8000")
41 | public List getRuleStatus(@RequestBody String a){
42 |
43 | Set ruleKeys = jedis.keys("rule_status_*");
44 | ArrayList lst = new ArrayList<>();
45 | for (String ruleKey : ruleKeys) {
46 | Map stringStringMap = jedis.hgetAll(ruleKey);
47 | String json = JSON.toJSONString(stringStringMap);
48 | RuleStatus ruleStatus = JSON.parseObject(json, RuleStatus.class);
49 | lst.add(ruleStatus);
50 | }
51 |
52 |
53 | /*
54 | ArrayList lst = new ArrayList();
55 | RuleStatus r1 = new RuleStatus("运营公众号拉新", "001", "2021-06-10 12:30:30", "2021-06-10 12:30:30", "触发型", "800", "40%", "200", "20%", "35%", "1");
56 | RuleStatus r2 = new RuleStatus("3H爆款激活用户", "002", "2021-06-10 12:30:30", "2021-06-10 12:30:30", "触发型", "800", "40%", "200", "20%", "35%", "1");
57 | RuleStatus r3 = new RuleStatus("拉新促销", "003", "2021-06-10 12:30:30", "2021-06-10 12:30:30", "触发型", "800", "40%", "200", "20%", "35%", "0");
58 | RuleStatus r4 = new RuleStatus("优惠关键词", "004", "2021-06-10 12:30:30", "2021-06-10 12:30:30", "触发型", "800", "40%", "200", "20%", "35%", "1");
59 | RuleStatus r5 = new RuleStatus("高流失风险客户挽留", "005", "2021-06-10 12:30:30", "2021-06-10 12:30:30", "触发型", "800", "40%", "200", "20%", "35%", "1");
60 | RuleStatus r6 = new RuleStatus("新客激活优惠券发送", "006", "2021-06-10 12:30:30", "2021-06-10 12:30:30", "触发型", "800", "40%", "200", "20%", "35%", "0");
61 | RuleStatus r7 = new RuleStatus("双11爆款硬推", "007", "2021-06-10 12:30:30", "2021-06-10 12:30:30", "触发型", "800", "40%", "200", "20%", "35%", "1");
62 | RuleStatus r8 = new RuleStatus("夏日饮品新上架普推", "008", "2021-06-10 12:30:30", "2021-06-10 12:30:30", "触发型", "800", "40%", "200", "20%", "35%", "1");
63 | lst.add(r1);
64 | lst.add(r2);
65 | lst.add(r3);
66 | lst.add(r4);
67 | lst.add(r5);
68 | lst.add(r6);
69 | lst.add(r7);
70 | lst.add(r8);*/
71 |
72 | return lst;
73 | }
74 |
75 |
76 |
77 |
78 | }
79 |
--------------------------------------------------------------------------------
/manageplatform/src/main/java/cn/doitedu/yinew/manageplatform/controller/RuleHandleController.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.yinew.manageplatform.controller;
2 |
3 | import cn.doitedu.yinew.manageplatform.pojo.RuleDefine;
4 | import cn.doitedu.yinew.manageplatform.pojo.RuleStatus;
5 | import com.alibaba.fastjson.JSON;
6 | import org.apache.commons.io.FileUtils;
7 | import org.springframework.web.bind.annotation.*;
8 | import redis.clients.jedis.Jedis;
9 |
10 | import java.io.File;
11 | import java.io.IOException;
12 | import java.sql.Connection;
13 | import java.sql.DriverManager;
14 | import java.sql.PreparedStatement;
15 | import java.text.SimpleDateFormat;
16 | import java.util.*;
17 |
18 | /***
19 | * @author hunter.d
20 | * @qq 657270652
21 | * @wx haitao-duan
22 | * @date 2021/5/9
23 | *
24 | * 仅为演示代码
25 | * 后端管理平台，开发工作量很大，会javaweb开发的同学看到演示代码即可知真实开发思路
26 | **/
27 | @RestController
28 | public class RuleHandleController {
29 |
30 | Jedis jedis = null;
31 | public RuleHandleController(){
32 | jedis = new Jedis("hdp02", 6379);
33 | }
34 |
35 |
36 | @RequestMapping(method = RequestMethod.POST, value = "/api/publishrule")
37 | @CrossOrigin(origins = "http://localhost:8000")
38 | public String publishRule(@RequestBody RuleDefine ruleDefine) throws Exception {
39 |
40 | // 接收到规则定义信息后
41 | // 利用freemarker或者velocity，生成规则所需的sql模板，和drools模板文件
42 | // 将规则定义信息及生成好的sql、drools代码，插入mysql数据库，以供canal监听并通过kafka传递给flink规则引擎
43 | insertRule2Mysql(ruleDefine.getRuleName());
44 |
45 | // 直接将规则信息写入“监控平台”所要读取的redis库
46 | HashMap ruleStatus = new HashMap<>();
47 | Long ruleId = jedis.incr("rule_num");
48 |
49 | SimpleDateFormat sdf = new SimpleDateFormat("yyyy-MM-dd HH:mm:ss");
50 | String publishTime = sdf.format(new Date());
51 | String ruleType = new Random().nextInt(10)%3 ==0 ?"触发型":"单次型";
52 |
53 | ruleStatus.put("ruleName", ruleDefine.getRuleName());
54 | RuleStatus r1 = new RuleStatus(ruleDefine.getRuleName(), ruleId + "", "", publishTime, ruleType, "0", "0%", "0", "0%", "0%", "1");
55 | String s = JSON.toJSONString(r1);
56 | HashMap map = (HashMap) JSON.parseObject(s, Map.class);
57 | System.out.println(map);
58 | Set> entries = map.entrySet();
59 | for (Map.Entry entry : entries) {
60 | jedis.hset("rule_status_" + ruleId, entry.getKey(),entry.getValue());
61 | }
62 | return "ok";
63 | }
64 |
65 |
66 | private void insertRule2Mysql(String ruleName) throws Exception {
67 | String ruleCode = FileUtils.readFileToString(new File("dynamic_rule_engine/rules_drl/rule2.drl"), "utf-8");
68 | int ruleStatus = 1;
69 | String ruleType = "1";
70 | String ruleVersion = "1";
71 | String cntSqls = FileUtils.readFileToString(new File("dynamic_rule_engine/rules_drl/rule2_cnt.sql"), "utf-8");
72 | String seqSqls = FileUtils.readFileToString(new File("dynamic_rule_engine/rules_drl/rule2_seq.sql"), "utf-8");
73 | String ruleCreator = "doitedu";
74 | String ruleAuditor = "hunter.d";
75 | java.sql.Date createTime = new java.sql.Date(System.currentTimeMillis());
76 | java.sql.Date updateTime = createTime;
77 | Connection conn = DriverManager.getConnection("jdbc:mysql://hdp01:3306/realtimedw?useUnicode=true&characterEncoding=utf8", "root", "ABC123abc.123");
78 | PreparedStatement pst = conn.prepareStatement("insert into yinew_drl_rule (rule_name,rule_code,rule_status,rule_type,rule_version,cnt_sqls,seq_sqls,rule_creator,rule_auditor,create_time,update_time) " +
79 | "values (?,?,?,?,?,?,?,?,?,?,?)");
80 | pst.setString(1,ruleName);
81 | pst.setString(2,ruleCode);
82 | pst.setInt(3,ruleStatus);
83 | pst.setString(4,ruleType);
84 | pst.setString(5,ruleVersion);
85 | pst.setString(6,cntSqls);
86 | pst.setString(7,seqSqls);
87 | pst.setString(8,ruleCreator);
88 | pst.setString(9,ruleAuditor);
89 | pst.setDate(10,createTime);
90 | pst.setDate(11,updateTime);
91 |
92 | boolean execute = pst.execute();
93 |
94 | pst.close();
95 | conn.close();
96 |
97 |
98 | }
99 | }
100 |
--------------------------------------------------------------------------------
/manageplatform/src/main/java/cn/doitedu/yinew/manageplatform/pojo/Animal.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.yinew.manageplatform.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 |
7 | @Data
8 | @NoArgsConstructor
9 | @AllArgsConstructor
10 | public class Animal {
11 |
12 | private String name;
13 | private int price;
14 | }
15 |
--------------------------------------------------------------------------------
/manageplatform/src/main/java/cn/doitedu/yinew/manageplatform/pojo/RuleAtomicParam.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.yinew.manageplatform.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 |
7 | import java.io.Serializable;
8 | import java.util.HashMap;
9 |
10 | /**
11 | * @author 涛哥
12 | * @nick_name "deep as the sea"
13 | * @contact qq:657270652 wx:doit_edu
14 | * @site www.doitedu.cn
15 | * @date 2021-03-28
16 | * @desc 规则参数中的原子条件封装实体
17 | */
18 | @Data
19 | @NoArgsConstructor
20 | @AllArgsConstructor
21 | public class RuleAtomicParam implements Serializable {
22 |
23 | // 事件的类型要求
24 | private String eventId;
25 |
26 | // 事件的属性要求
27 | private HashMap properties;
28 |
29 | // 规则要求的阈值
30 | private int cnt;
31 |
32 | // 要求的事件发生时间段起始
33 | private long rangeStart;
34 |
35 | // 要求的事件发生时间段结束
36 | private long rangeEnd;
37 |
38 | // 条件对应的clickhouse查询sql
39 | private String countQuerySql;
40 |
41 | // 用于记录查询服务所返回的查询值
42 | private int realCnt;
43 |
44 | // 用于记录初始 range
45 | private long originStart;
46 | public void setOriginStart(long originStart){
47 | this.originStart = originStart;
48 | this.rangeStart = originStart;
49 | }
50 | private long originEnd;
51 | public void setOriginEnd(long originEnd){
52 | this.originEnd = originEnd;
53 | this.rangeEnd = originEnd;
54 | }
55 |
56 |
57 | }
58 |
--------------------------------------------------------------------------------
/manageplatform/src/main/java/cn/doitedu/yinew/manageplatform/pojo/RuleDefine.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.yinew.manageplatform.pojo;
2 |
3 | import lombok.AllArgsConstructor;
4 | import lombok.Data;
5 | import lombok.NoArgsConstructor;
6 | import org.springframework.web.context.annotation.ApplicationScope;
7 |
8 | import java.io.Serializable;
9 | import java.util.List;
10 |
11 | /***
12 | * @author hunter.d
13 | * @qq 657270652
14 | * @wx haitao-duan
15 | * @date 2021/5/9
16 | **/
17 | @Data
18 | @NoArgsConstructor
19 | @AllArgsConstructor
20 | public class RuleDefine implements Serializable {
21 | private String ruleName;
22 | }
23 |
--------------------------------------------------------------------------------
/manageplatform/src/main/java/cn/doitedu/yinew/manageplatform/pojo/RuleStatus.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.yinew.manageplatform.pojo;
2 |
3 |
4 | import lombok.AllArgsConstructor;
5 | import lombok.Data;
6 | import lombok.NoArgsConstructor;
7 |
8 | import java.io.Serializable;
9 |
10 | @Data
11 | @NoArgsConstructor
12 | @AllArgsConstructor
13 | public class RuleStatus implements Serializable {
14 | /**
15 | * {
16 | * ruleName: '运营公众号拉新',
17 | * ruleType: '触发型',
18 | * publishTime: '2021-04-01 12:30:45',
19 | * lastTrigTime: '2021-06-08 13:30:30',
20 | * trigCount: 80,
21 | * hitCount: 20,
22 | * hitRatio: '30%',
23 | * compareGroupRatio: '20%',
24 | * ruleGroupRatio: '40%',
25 | * runStatus:true
26 | * }
27 | */
28 |
29 | private String ruleName;
30 | private String ruleId;
31 | private String lastTrigTime;
32 | private String publishTime;
33 | private String ruleType;
34 | private String trigCount;
35 | private String hitRatio;
36 | private String hitCount;
37 | private String compareGroupRatio;
38 | private String ruleGroupRatio;
39 | private String runStatus;
40 |
41 | }
42 |
--------------------------------------------------------------------------------
/manageplatform/src/main/resources/application.properties:
--------------------------------------------------------------------------------
1 |
2 |
--------------------------------------------------------------------------------
/manageplatform/src/main/resources/templates/demo.ftl:
--------------------------------------------------------------------------------
1 | [BR]
2 | [BR]
3 | Welcome![BR]
4 | [BR]
5 | [BR]
6 | <#-- Greet the user with his/her name -->[BR]
7 | Welcome ${user}!
[BR]
8 | We have these animals:[BR]
9 |
[BR]
10 | <#list animals as animal>[BR]
11 | - ${animal.name} for ${animal.price} Euros[BR]
12 | [BR]
13 |
[BR]
14 | [BR]
15 |
--------------------------------------------------------------------------------
/manageplatform/src/main/resources/templates/eventCountModel.ftl:
--------------------------------------------------------------------------------
1 | <#list events as eparam >
2 | select
3 | deviceId,
4 | count(1) as cnt
5 | from yinew_detail
6 | where
7 | deviceId = ?
8 | and eventId='${eparam.eventId}'
9 | <#list eparam.properties?keys as key>
10 | and properties['${key}']='${eparam.properties[key]}'
11 |
12 | and timeStamp>= ?
13 | and timeStamp <= ?
14 | group by deviceId;
15 |
--------------------------------------------------------------------------------
/manageplatform/src/test/java/cn/doitedu/yinew/manageplatform/ManageplatformApplicationTests.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.yinew.manageplatform;
2 |
3 | import org.junit.jupiter.api.Test;
4 | import org.springframework.boot.test.context.SpringBootTest;
5 |
6 | @SpringBootTest
7 | class ManageplatformApplicationTests {
8 |
9 | @Test
10 | void contextLoads() {
11 | }
12 |
13 | }
14 |
--------------------------------------------------------------------------------
/manageplatform/template/rule2.drl:
--------------------------------------------------------------------------------
1 | package cn.doitedu.dynamic_rules.rules
2 | import cn.doitedu.dynamic_rule.pojo.DroolFact
3 | import cn.doitedu.dynamic_rule.pojo.LogBean
4 | import cn.doitedu.dynamic_rule.pojo.RuleParam
5 | import cn.doitedu.dynamic_rule.service.QueryRouterV4
6 | import java.util.HashMap
7 | import cn.doitedu.dynamic_rule.pojo.RuleAtomicParam
8 | import java.util.List
9 | import java.util.ArrayList
10 |
11 | rule "rule2"
12 |
13 | when
14 | $d:DroolFact()
15 | $b:LogBean(eventId == "F") from $d.logBean
16 | then
17 | RuleParam ruleParam = $d.getRuleParam();
18 | ruleParam.setRuleId("rule2");
19 | QueryRouterV4 queryRouter = $d.getQueryRouterV4();
20 |
21 | // 填充本规则的画像条件
22 | HashMap profileParams = new HashMap<>();
23 | profileParams.put("tag7","v2");
24 | profileParams.put("tag3","v1");
25 | ruleParam.setUserProfileParams(profileParams);
26 |
27 | // 填充本规则的count类条件(直接从ruleparam中取出cnt条件list，里面已经拥有sql了)
28 | List countParams = ruleParam.getUserActionCountParams();
29 |
30 | RuleAtomicParam param0 = countParams.get(0);
31 | param0.setEventId("H");
32 | HashMap props0 = new HashMap<>();
33 | props0.put("p1","v1");
34 | props0.put("p2","v3");
35 | param0.setProperties(props0);
36 | param0.setCnt(8);
37 | param0.setOriginStart(0);
38 | param0.setOriginEnd(Long.MAX_VALUE);
39 |
40 |
41 | // 填充本规则的次序列条件
42 | ArrayList seqParams = new ArrayList<>();
43 |
44 | RuleAtomicParam seq0 = new RuleAtomicParam();
45 | seq0.setEventId("A");
46 | HashMap seq0prop = new HashMap<>();
47 | seq0prop.put("p1","v1");
48 | seq0.setProperties(seq0prop);
49 | seq0.setOriginStart(0);
50 | seq0.setOriginEnd(Long.MAX_VALUE);
51 |
52 |
53 | RuleAtomicParam seq1 = new RuleAtomicParam();
54 | seq1.setEventId("C");
55 | HashMap seq1prop = new HashMap<>();
56 | seq1prop.put("p2","v2");
57 | seq1.setProperties(seq1prop);
58 | seq1.setOriginStart(0);
59 | seq1.setOriginEnd(Long.MAX_VALUE);
60 |
61 | seqParams.add(seq0);
62 | seqParams.add(seq1);
63 |
64 | ruleParam.setUserActionSequenceParams(seqParams);
65 |
66 | // 执行匹配查询计算
67 | if(
68 | queryRouter.profileQuery($b, ruleParam)
69 | &&
70 | queryRouter.sequenceConditionQuery($b, ruleParam)
71 | &&
72 | queryRouter.countConditionQuery($b, ruleParam)
73 | ){
74 | // 设置结果
75 | $d.setMatch(true);
76 | }
77 |
78 | end
--------------------------------------------------------------------------------
/manageplatform/template/rule2_cnt.sql:
--------------------------------------------------------------------------------
1 | select
2 | deviceId,
3 | count(1) as cnt
4 | from yinew_detail
5 | where deviceId = ? and eventId = 'H' and properties['p1']='v1'
6 | and timeStamp between ? and ?
7 | group by deviceId
--------------------------------------------------------------------------------
/manageplatform/template/rule2_seq.sql:
--------------------------------------------------------------------------------
1 | SELECT
2 | deviceId,
3 | sequenceMatch('.*(?1).*(?2).*')(
4 | toDateTime(`timeStamp`),
5 | eventId = 'A' and properties['p1']='v1',
6 | eventId = 'C' and properties['p2']='v2'
7 | ) as isMatch2,
8 | sequenceMatch('.*(?1).*')(
9 | toDateTime(`timeStamp`),
10 | eventId = 'A' and properties['p1']='v1',
11 | eventId = 'C' and properties['p2']='v2'
12 | ) as isMatch1
13 | from yinew_detail
14 | where
15 | deviceId = ?
16 | and
17 | timeStamp BETWEEN ? AND ?
18 | and
19 | (
20 | (eventId='A' and properties['p1']='v1')
21 | or (eventId = 'C' and properties['p2']='v2')
22 | )
23 | group by deviceId;
--------------------------------------------------------------------------------
/pom.xml:
--------------------------------------------------------------------------------
1 |
2 |
5 | 4.0.0
6 |
7 | cn.doitedu
8 | yinew_marketing
9 | pom
10 | 1.0
11 |
12 | dynamic_rule_engine
13 | user_profile
14 | data_analysis
15 | log4jdemo
16 |
17 |
18 |
19 |
20 |
21 | nexus-aliyun
22 | Nexus aliyun
23 | default
24 | http://maven.aliyun.com/nexus/content/groups/public
25 |
26 | false
27 | never
28 |
29 |
30 | true
31 | never
32 |
33 |
34 |
35 |
36 |
37 |
38 |
39 | ali-plugin
40 | http://maven.aliyun.com/nexus/content/groups/public/
41 |
42 | false
43 | never
44 |
45 |
46 | true
47 | never
48 |
49 |
50 |
51 |
52 |
53 |
54 |
55 | org.projectlombok
56 | lombok
57 | 1.18.18
58 |
59 |
60 |
61 | com.alibaba
62 | fastjson
63 | 1.2.75
64 |
65 |
66 |
67 |
68 |
69 |
70 |
71 |
72 | org.apache.maven.plugins
73 | maven-compiler-plugin
74 | 3.5.1
75 |
76 | 1.8
77 | 1.8
78 |
79 |
80 |
81 |
82 |
83 |
84 |
--------------------------------------------------------------------------------
/user_profile/pom.xml:
--------------------------------------------------------------------------------
1 |
2 |
5 |
6 | yinew_marketing
7 | cn.doitedu
8 | 1.0
9 |
10 | 4.0.0
11 |
12 | user_profile
13 |
14 |
15 |
--------------------------------------------------------------------------------
/user_profile/src/main/java/cn/doitedu/userprofile/demo/Demo.java:
--------------------------------------------------------------------------------
1 | package cn.doitedu.userprofile.demo;
2 |
3 | public class Demo {
4 | }
5 |
--------------------------------------------------------------------------------
/项目介绍.MD:
--------------------------------------------------------------------------------
1 | # 背景介绍
2 | - 本项目是一个将大数据技术综合运用于核心业系统的经典案例
3 | - 项目的目标功能：提供可动态制定规则的实时营销消息推送
4 | - 项目的可扩展适配场景：实时推荐，实时风控，实时精准广告推送等
5 |
6 |
7 | # 需求示例
8 | 通过如下示例，可以对项目所适配的需求进行直观理解
9 |
10 | ## 运营消息推送（市场营销）
11 | 试想场景（1）：公司想对沉默用户进行送券激活
12 |
13 | > - 2021-02月至2021-05月之间
14 | > - 消费总额<500
15 | > - 且月平均访问次数<4
16 | > - 且性别为男
17 | > - 年龄阶段在20-40之间的会员
18 |
19 | 只要发现他登录app，则立马给他在app上弹出一个“购物满100减60”的消息，并赠送该优惠券
20 |
21 | ----
22 |
23 |
24 | 试想场景（2）：公司想对某品类下的购买犹豫潜客进行促单
25 |
26 | > 最近一周内，该用户依次做过如下行为
27 | > - 浏览过移动硬盘品类的商品
28 | > - 收藏过移动硬盘品类的商品
29 | > - 点击过移动硬盘品类的运营位广告
30 | > - 添加过移动硬盘品类商品到购物车
31 |
32 | 只要发现他再次浏览移动硬盘品类的商品，则立马给它推送一个“限时折扣购买希捷移动硬盘”的短信
33 |
34 | ----
35 |
36 | 其他类似场景示意
37 |
38 |
39 |
40 |
41 |
42 |
43 |
44 |
45 |
46 |
47 |
48 |
49 |
50 | ## 实时规则风控（风控系统）
51 |
52 | - 用户名与身份证姓名不一致；
53 |
54 | - 某IP最近1小时注册账号数超过10个；
55 |
56 | - 某账号最近3分钟登陆次数大于5次；
57 |
58 | - 某账号群体最近1小时购买优惠商品超过100件；
59 |
60 | - 某账号最近3分钟领券超过3张；
61 |
62 |
63 |
64 | ## 实时规则推荐（推荐系统）
65 |
66 |
67 |
68 | ## 实时广告智能投放（广告推送）
69 |
70 |
71 |
72 |
73 |
74 | > 总结：一切皆规则；一切皆动态规则
75 |
76 |
77 |
78 |
79 |
80 | # 项目整体结构
81 |
82 |
83 |
84 |
85 |
86 |
--------------------------------------------------------------------------------
