├── AudioLogic.h ├── AudioPatterns.h ├── Commands.h ├── Drawing.h ├── Effects.h ├── Fire2012WithPalette.h ├── GradientPalettes.h ├── LICENSE ├── Noise.h ├── Pulse.h ├── README.md ├── Torch.h ├── Wave.h └── torch.ino /AudioLogic.h: -------------------------------------------------------------------------------- 1 | /* 2 | * Torch: https://github.com/evilgeniuslabs/torch 3 | * Copyright (C) 2015 Jason Coon 4 | * 5 | * This program is free software: you can redistribute it and/or modify 6 | * it under the terms of the GNU General Public License as published by 7 | * the Free Software Foundation, either version 3 of the License, or 8 | * (at your option) any later version. 9 | * 10 | * This program is distributed in the hope that it will be useful, 11 | * but WITHOUT ANY WARRANTY; without even the implied warranty of 12 | * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 13 | * GNU General Public License for more details. 14 | * 15 | * You should have received a copy of the GNU General Public License 16 | * along with this program. If not, see . 17 | */ 18 | 19 | #define MSGEQ7_STROBE_PIN 2 20 | #define MSGEQ7_RESET_PIN 3 21 | #define MSGEQ7_LEFT_PIN A0 22 | #define MSGEQ7_RIGHT_PIN A1 23 | 24 | const uint8_t bandCount = 7; 25 | 26 | int levelsLeft[bandCount]; 27 | int peaksLeft[bandCount]; 28 | 29 | int levelsRight[bandCount]; 30 | int peaksRight[bandCount]; 31 | 32 | static const uint8_t peakDecay = (1024 / MATRIX_HEIGHT) / 4; 33 | bool drawPeaks = true; 34 | 35 | int noiseCorrection[bandCount] = { 36 | // -55, -50, -45, -55, -40, -55, -50, 37 | 0, 0, 0, 0, 0, 0, 0 38 | }; 39 | 40 | uint8_t bandOffset = 3; 41 | 42 | uint8_t horizontalPixelsPerBand = MATRIX_WIDTH / (bandCount * 2); 43 | 44 | uint8_t levelsPerVerticalPixel = 63; // 1024 / MATRIX_HEIGHT; 45 | 46 | uint8_t levelsPerHue = 1024 / 256; 47 | 48 | void initializeAudio() { 49 | pinMode(MSGEQ7_LEFT_PIN, INPUT); 50 | pinMode(MSGEQ7_RIGHT_PIN, INPUT); 51 | pinMode(MSGEQ7_RESET_PIN, OUTPUT); 52 | pinMode(MSGEQ7_STROBE_PIN, OUTPUT); 53 | digitalWrite(MSGEQ7_RESET_PIN, LOW); 54 | digitalWrite(MSGEQ7_STROBE_PIN, HIGH); 55 | } 56 | 57 | void readAudio() { 58 | digitalWrite(MSGEQ7_RESET_PIN, HIGH); 59 | digitalWrite(MSGEQ7_RESET_PIN, LOW); 60 | 61 | int levelLeft; 62 | int levelRight; 63 | 64 | for (uint8_t band = 0; band < bandCount; band++) { 65 | digitalWrite(MSGEQ7_STROBE_PIN, LOW); 66 | delayMicroseconds(30); 67 | 68 | levelLeft = analogRead(MSGEQ7_LEFT_PIN); 69 | levelRight = analogRead(MSGEQ7_RIGHT_PIN); 70 | digitalWrite(MSGEQ7_STROBE_PIN, HIGH); 71 | 72 | levelLeft += noiseCorrection[band]; 73 | levelRight += noiseCorrection[band]; 74 | 75 | // if (levelLeft < 0) levelLeft = 0; 76 | // if (levelLeft > 1023) levelLeft = 1023; 77 | // 78 | // if (levelRight < 0) levelRight = 0; 79 | // if (levelRight > 1023) levelRight = 1023; 80 | 81 | levelsLeft[band] = levelLeft; 82 | levelsRight[band] = levelRight; 83 | 84 | // if (levelLeft >= peaksLeft[band]) { 85 | peaksLeft[band] = levelLeft; 86 | // } 87 | // else if (peaksLeft[band] > 0) { 88 | // peaksLeft[band] = peaksLeft[band] - peakDecay; 89 | // if(peaksLeft[band] < 0) peaksLeft[band] = 0; 90 | // } 91 | // 92 | // if (levelRight >= peaksRight[band]) { 93 | peaksRight[band] = levelRight; 94 | // } 95 | // else if (peaksRight[band] > 0) { 96 | // peaksRight[band] = peaksRight[band] - peakDecay; 97 | // if(peaksRight[band] < 0) peaksRight[band] = 0; 98 | // } 99 | } 100 | } 101 | -------------------------------------------------------------------------------- /AudioPatterns.h: -------------------------------------------------------------------------------- 1 | /* 2 | * Torch: https://github.com/evilgeniuslabs/torch 3 | * Copyright (C) 2015 Jason Coon 4 | * 5 | * This program is free software: you can redistribute it and/or modify 6 | * it under the terms of the GNU General Public License as published by 7 | * the Free Software Foundation, either version 3 of the License, or 8 | * (at your option) any later version. 9 | * 10 | * This program is distributed in the hope that it will be useful, 11 | * but WITHOUT ANY WARRANTY; without even the implied warranty of 12 | * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 13 | * GNU General Public License for more details. 14 | * 15 | * You should have received a copy of the GNU General Public License 16 | * along with this program. If not, see . 17 | */ 18 | 19 | uint16_t analyzerColumns() { 20 | fill_solid(leds, NUM_LEDS, CRGB::Black); 21 | 22 | for (uint8_t bandIndex = 0; bandIndex < bandCount; bandIndex++) { 23 | int levelLeft = levelsLeft[bandIndex]; 24 | int levelRight = levelsRight[bandIndex]; 25 | 26 | if (drawPeaks) { 27 | levelLeft = peaksLeft[bandIndex]; 28 | levelRight = peaksRight[bandIndex]; 29 | } 30 | 31 | CRGB colorLeft = ColorFromPalette(palette, levelLeft / levelsPerHue); // CRGB colorLeft = ColorFromPalette(palette, bandIndex * (256 / bandCount)); 32 | CRGB colorRight = ColorFromPalette(palette, levelRight / levelsPerHue); 33 | 34 | uint8_t x = bandIndex + bandOffset; 35 | if (x >= MATRIX_WIDTH) 36 | x -= MATRIX_WIDTH; 37 | 38 | drawFastVLine(x, (MATRIX_HEIGHT - 1) - levelLeft / levelsPerVerticalPixel, MATRIX_HEIGHT - 1, colorLeft); 39 | drawFastVLine(x + bandCount, (MATRIX_HEIGHT - 1) - levelRight / levelsPerVerticalPixel, MATRIX_HEIGHT - 1, colorRight); 40 | } 41 | 42 | return 1; 43 | } 44 | 45 | uint16_t analyzerColumnsSolid() { 46 | fill_solid(leds, NUM_LEDS, CRGB::Black); 47 | 48 | for (uint8_t bandIndex = 0; bandIndex < bandCount; bandIndex++) { 49 | int levelLeft = levelsLeft[bandIndex]; 50 | int levelRight = levelsRight[bandIndex]; 51 | 52 | if (drawPeaks) { 53 | levelLeft = peaksLeft[bandIndex]; 54 | levelRight = peaksRight[bandIndex]; 55 | } 56 | 57 | CRGB colorLeft = ColorFromPalette(palette, gHue); 58 | CRGB colorRight = ColorFromPalette(palette, gHue); 59 | 60 | uint8_t x = bandIndex + bandOffset; 61 | if (x >= MATRIX_WIDTH) 62 | x -= MATRIX_WIDTH; 63 | 64 | drawFastVLine(x, (MATRIX_HEIGHT - 1) - levelLeft / levelsPerVerticalPixel, MATRIX_HEIGHT - 1, colorLeft); 65 | drawFastVLine(x + bandCount, (MATRIX_HEIGHT - 1) - levelRight / levelsPerVerticalPixel, MATRIX_HEIGHT - 1, colorRight); 66 | } 67 | 68 | return 1; 69 | } 70 | 71 | uint16_t analyzerPixels() { 72 | fill_solid(leds, NUM_LEDS, CRGB::Black); 73 | 74 | for (uint8_t bandIndex = 0; bandIndex < bandCount; bandIndex++) { 75 | int levelLeft = levelsLeft[bandIndex]; 76 | int levelRight = levelsRight[bandIndex]; 77 | 78 | if (drawPeaks) { 79 | levelLeft = peaksLeft[bandIndex]; 80 | levelRight = peaksRight[bandIndex]; 81 | } 82 | 83 | CRGB colorLeft = ColorFromPalette(palette, levelLeft / levelsPerHue); 84 | CRGB colorRight = ColorFromPalette(palette, levelRight / levelsPerHue); 85 | 86 | uint8_t x = bandIndex + bandOffset; 87 | if (x >= MATRIX_WIDTH) 88 | x -= MATRIX_WIDTH; 89 | 90 | leds[XY(x, (MATRIX_HEIGHT - 1) - levelLeft / levelsPerVerticalPixel)] = colorLeft; 91 | leds[XY(x + bandCount, (MATRIX_HEIGHT - 1) - levelLeft / levelsPerVerticalPixel)] = colorRight; 92 | } 93 | 94 | return 0; 95 | } 96 | 97 | uint16_t fallingSpectrogram() { 98 | moveDown(); 99 | 100 | for (uint8_t bandIndex = 0; bandIndex < bandCount; bandIndex++) { 101 | int levelLeft = levelsLeft[bandIndex]; 102 | int levelRight = levelsRight[bandIndex]; 103 | 104 | if (drawPeaks) { 105 | levelLeft = peaksLeft[bandIndex]; 106 | levelRight = peaksRight[bandIndex]; 107 | } 108 | 109 | if (levelLeft <= 8) levelLeft = 0; 110 | if (levelRight <= 8) levelRight = 0; 111 | 112 | CRGB colorLeft; 113 | CRGB colorRight; 114 | 115 | if (currentPaletteIndex < 2) { // invert the first two palettes 116 | colorLeft = ColorFromPalette(palette, 205 - (levelLeft / levelsPerHue - 205)); 117 | colorRight = ColorFromPalette(palette, 205 - (levelLeft / levelsPerHue - 205)); 118 | } 119 | else { 120 | colorLeft = ColorFromPalette(palette, levelLeft / levelsPerHue); 121 | colorRight = ColorFromPalette(palette, levelRight / levelsPerHue); 122 | } 123 | 124 | uint8_t x = bandIndex + bandOffset; 125 | if (x >= MATRIX_WIDTH) 126 | x -= MATRIX_WIDTH; 127 | 128 | leds[XY(x, 0)] = colorLeft; 129 | leds[XY(x + bandCount, 0)] = colorRight; 130 | } 131 | 132 | return 0; 133 | } 134 | 135 | uint16_t audioFire() { 136 | moveUp(); 137 | 138 | for (uint8_t bandIndex = 0; bandIndex < bandCount; bandIndex++) { 139 | int levelLeft = levelsLeft[bandIndex]; 140 | int levelRight = levelsRight[bandIndex]; 141 | 142 | if (drawPeaks) { 143 | levelLeft = peaksLeft[bandIndex]; 144 | levelRight = peaksRight[bandIndex]; 145 | } 146 | 147 | if (levelLeft <= 8) levelLeft = 0; 148 | if (levelRight <= 8) levelRight = 0; 149 | 150 | CRGB colorLeft = ColorFromPalette(HeatColors_p, levelLeft / 5); 151 | CRGB colorRight = ColorFromPalette(HeatColors_p, levelRight / 5); 152 | 153 | uint8_t x = bandIndex + bandOffset; 154 | if (x >= MATRIX_WIDTH) 155 | x -= MATRIX_WIDTH; 156 | 157 | leds[XY(x, MATRIX_HEIGHT - 1)] = colorLeft; 158 | leds[XY(x + bandCount, MATRIX_HEIGHT - 1)] = colorRight; 159 | } 160 | 161 | return 0; 162 | } 163 | 164 | uint16_t rainbowAudioNoise() { 165 | static int lastPeak0 = 0; 166 | 167 | noisespeedx = 0; 168 | 169 | if (peaksLeft[0] >= lastPeak0) { 170 | noisespeedx = peaksLeft[0] / 57; 171 | } 172 | 173 | lastPeak0 = peaksLeft[0]; 174 | 175 | noisespeedy = 0; 176 | noisespeedz = 0; 177 | noisescale = 30; 178 | colorLoop = 0; 179 | return drawNoise(RainbowColors_p); 180 | } 181 | 182 | uint16_t rainbowStripeAudioNoise() { 183 | static int lastPeak0 = 0; 184 | 185 | noisespeedy = 0; 186 | 187 | if (peaksLeft[0] >= lastPeak0) { 188 | noisespeedy = peaksLeft[0] / 57; 189 | } 190 | 191 | lastPeak0 = peaksLeft[0]; 192 | 193 | noisespeedx = 0; 194 | noisespeedz = 0; 195 | noisescale = 20; 196 | colorLoop = 0; 197 | return drawNoise(RainbowStripeColors_p); 198 | } 199 | 200 | uint16_t partyAudioNoise() { 201 | static int lastPeak0 = 0; 202 | 203 | noisespeedx = 0; 204 | 205 | if (peaksLeft[0] >= lastPeak0) { 206 | noisespeedx = peaksLeft[0] / 57; 207 | } 208 | 209 | lastPeak0 = peaksLeft[0]; 210 | 211 | noisespeedy = 0; 212 | noisespeedz = 0; 213 | noisescale = 30; 214 | colorLoop = 0; 215 | return drawNoise(PartyColors_p); 216 | } 217 | 218 | uint16_t forestAudioNoise() { 219 | static int lastPeak0 = 0; 220 | 221 | noisespeedx = 0; 222 | 223 | if (peaksLeft[0] >= lastPeak0) { 224 | noisespeedx = peaksLeft[0] / 57; 225 | } 226 | 227 | lastPeak0 = peaksLeft[0]; 228 | 229 | noisespeedy = 0; 230 | noisespeedz = 0; 231 | noisescale = 120; 232 | colorLoop = 0; 233 | return drawNoise(ForestColors_p); 234 | } 235 | 236 | uint16_t cloudAudioNoise() { 237 | static int lastPeak0 = 0; 238 | 239 | noisespeedx = 0; 240 | 241 | if (peaksLeft[0] >= lastPeak0) { 242 | noisespeedx = peaksLeft[0] / 57; 243 | } 244 | 245 | lastPeak0 = peaksLeft[0]; 246 | 247 | noisespeedy = 0; 248 | noisespeedz = 0; 249 | noisescale = 30; 250 | colorLoop = 0; 251 | return drawNoise(CloudColors_p); 252 | } 253 | 254 | uint16_t fireAudioNoise() { 255 | static int lastPeak0 = 0; 256 | static int lastPeak6 = 0; 257 | 258 | noisespeedx = 0; 259 | noisespeedz = 0; 260 | 261 | if (peaksLeft[0] >= lastPeak0) { 262 | noisespeedx = peaksLeft[0] / 32; 263 | } 264 | 265 | if (peaksLeft[6] >= lastPeak6) { 266 | noisespeedz = peaksLeft[6] / 128; 267 | } 268 | 269 | lastPeak0 = peaksLeft[0]; 270 | lastPeak6 = peaksLeft[6]; 271 | 272 | noisespeedy = 0; 273 | noisescale = 50; 274 | colorLoop = 0; 275 | 276 | return drawNoise(HeatColors_p, 60); 277 | } 278 | 279 | uint16_t lavaAudioNoise() { 280 | static int lastPeak0 = 0; 281 | static int lastPeak6 = 0; 282 | 283 | noisespeedy = 0; 284 | noisespeedz = 0; 285 | 286 | if (peaksLeft[0] >= lastPeak0) { 287 | noisespeedy = peaksLeft[0] / 32; 288 | } 289 | 290 | if (peaksLeft[6] >= lastPeak6) { 291 | noisespeedz = peaksLeft[6] / 128; 292 | } 293 | 294 | lastPeak0 = peaksLeft[0]; 295 | lastPeak6 = peaksLeft[6]; 296 | 297 | noisespeedx = 0; 298 | noisescale = 50; 299 | colorLoop = 0; 300 | return drawNoise(LavaColors_p); 301 | } 302 | 303 | uint16_t oceanAudioNoise() { 304 | static int lastPeak0 = 0; 305 | 306 | noisespeedy = 0; 307 | 308 | if (peaksLeft[0] >= lastPeak0) { 309 | noisespeedy = peaksLeft[0] / 57; 310 | } 311 | 312 | lastPeak0 = peaksLeft[0]; 313 | 314 | noisespeedx = 0; 315 | noisespeedz = 0; 316 | noisescale = 90; 317 | colorLoop = 0; 318 | return drawNoise(OceanColors_p); 319 | } 320 | 321 | uint16_t blackAndWhiteAudioNoise() { 322 | SetupBlackAndWhiteStripedPalette(); 323 | static int lastPeak0 = 0; 324 | 325 | noisespeedy = 0; 326 | 327 | if (peaksLeft[0] >= lastPeak0) { 328 | noisespeedy = peaksLeft[0] / 128; 329 | } 330 | 331 | lastPeak0 = peaksLeft[0]; 332 | 333 | noisespeedx = 0; 334 | noisespeedz = 0; 335 | noisescale = 15; 336 | colorLoop = 0; 337 | return drawNoise(blackAndWhiteStripedPalette); 338 | } 339 | 340 | uint16_t blackAndBlueAudioNoise() { 341 | SetupBlackAndBlueStripedPalette(); 342 | static int lastPeak0 = 0; 343 | 344 | noisespeedx = 0; 345 | 346 | if (peaksLeft[0] >= lastPeak0) { 347 | noisespeedx = peaksLeft[0] / 57; 348 | } 349 | 350 | lastPeak0 = peaksLeft[0]; 351 | 352 | noisespeedy = 0; 353 | noisespeedz = 0; 354 | noisescale = 45; 355 | colorLoop = 0; 356 | return drawNoise(blackAndBlueStripedPalette); 357 | } 358 | -------------------------------------------------------------------------------- /Commands.h: -------------------------------------------------------------------------------- 1 | /* 2 | * Torch: https://github.com/evilgeniuslabs/torch 3 | * Copyright (C) 2015 Jason Coon 4 | * 5 | * This program is free software: you can redistribute it and/or modify 6 | * it under the terms of the GNU General Public License as published by 7 | * the Free Software Foundation, either version 3 of the License, or 8 | * (at your option) any later version. 9 | * 10 | * This program is distributed in the hope that it will be useful, 11 | * but WITHOUT ANY WARRANTY; without even the implied warranty of 12 | * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 13 | * GNU General Public License for more details. 14 | * 15 | * You should have received a copy of the GNU General Public License 16 | * along with this program. If not, see . 17 | */ 18 | 19 | #ifndef IrCodes_H 20 | #define IrCodes_H 21 | 22 | enum class InputCommand { 23 | None, 24 | Up, 25 | Down, 26 | Left, 27 | Right, 28 | Select, 29 | Brightness, 30 | PlayMode, 31 | Power, 32 | BrightnessUp, 33 | BrightnessDown, 34 | CyclePalette, 35 | NextPalette, 36 | PreviousPalette, 37 | 38 | Pattern1, 39 | Pattern2, 40 | Pattern3, 41 | Pattern4, 42 | Pattern5, 43 | Pattern6, 44 | Pattern7, 45 | Pattern8, 46 | Pattern9, 47 | Pattern10, 48 | Pattern11, 49 | Pattern12, 50 | 51 | RedUp, 52 | RedDown, 53 | GreenUp, 54 | GreenDown, 55 | BlueUp, 56 | BlueDown, 57 | 58 | Red, 59 | RedOrange, 60 | Orange, 61 | YellowOrange, 62 | Yellow, 63 | 64 | Green, 65 | Lime, 66 | Aqua, 67 | Teal, 68 | Navy, 69 | 70 | Blue, 71 | RoyalBlue, 72 | Purple, 73 | Indigo, 74 | Magenta, 75 | 76 | White, 77 | Pink, 78 | LightPink, 79 | BabyBlue, 80 | LightBlue, 81 | }; 82 | 83 | // IR Raw Key Codes for SparkFun remote 84 | #define IRCODE_SPARKFUN_POWER 0x10EFD827 // 284153895 85 | #define IRCODE_SPARKFUN_A 0x10EFF807 // 86 | #define IRCODE_SPARKFUN_B 0x10EF7887 87 | #define IRCODE_SPARKFUN_C 0x10EF58A7 88 | #define IRCODE_SPARKFUN_UP 0x10EFA05F // 284139615 89 | #define IRCODE_SPARKFUN_LEFT 0x10EF10EF 90 | #define IRCODE_SPARKFUN_SELECT 0x10EF20DF 91 | #define IRCODE_SPARKFUN_RIGHT 0x10EF807F 92 | #define IRCODE_SPARKFUN_DOWN 0x10EF00FF 93 | #define IRCODE_SPARKFUN_HELD 0xFFFFFFFF 94 | 95 | // IR Raw Key Codes for Adafruit remote 96 | #define IRCODE_ADAFRUIT_HELD 0x7FFFFFFF // 4294967295 97 | #define IRCODE_ADAFRUIT_VOLUME_UP 0x00FD40BF // 16597183 98 | #define IRCODE_ADAFRUIT_PLAY_PAUSE 0x00FD807F // 16613503 99 | #define IRCODE_ADAFRUIT_VOLUME_DOWN 0x00FD00FF // 16580863 100 | #define IRCODE_ADAFRUIT_SETUP 0x00FD20DF // 16589023 101 | #define IRCODE_ADAFRUIT_UP 0x00FDA05F // 16621663 102 | #define IRCODE_ADAFRUIT_STOP_MODE 0x00FD609F // 16605343 103 | #define IRCODE_ADAFRUIT_LEFT 0x00FD10EF // 16584943 104 | #define IRCODE_ADAFRUIT_ENTER_SAVE 0x00FD906F // 16617583 105 | #define IRCODE_ADAFRUIT_RIGHT 0x00FD50AF // 16601263 106 | #define IRCODE_ADAFRUIT_0_10_PLUS 0x00FD30CF // 16593103 107 | #define IRCODE_ADAFRUIT_DOWN 0x00FDB04F // 16625743 108 | #define IRCODE_ADAFRUIT_BACK 0x00FD708F // 16609423 109 | #define IRCODE_ADAFRUIT_1 0x00FD08F7 // 16582903 110 | #define IRCODE_ADAFRUIT_2 0x00FD8877 // 16615543 111 | #define IRCODE_ADAFRUIT_3 0x00FD48B7 // 16599223 112 | #define IRCODE_ADAFRUIT_4 0x00FD28D7 // 16591063 113 | #define IRCODE_ADAFRUIT_5 0x00FDA857 // 16623703 114 | #define IRCODE_ADAFRUIT_6 0x00FD6897 // 16607383 115 | #define IRCODE_ADAFRUIT_7 0x00FD18E7 // 16586983 116 | #define IRCODE_ADAFRUIT_8 0x00FD9867 // 16619623 117 | #define IRCODE_ADAFRUIT_9 0x00FD58A7 // 16603303 118 | 119 | // IR Raw Key Codes for eTopxizu 44Key IR Remote Controller for 5050 3528 RGB LED Light Strip 120 | #define IRCODE_ETOPXIZU_HELD 0x7FFFFFFF // 4294967295 121 | #define IRCODE_ETOPXIZU_POWER 16712445 122 | #define IRCODE_ETOPXIZU_PLAY_PAUSE 16745085 123 | #define IRCODE_ETOPXIZU_BRIGHTNESS_UP 16726725 124 | #define IRCODE_ETOPXIZU_BRIGHTNESS_DOWN 16759365 125 | 126 | #define IRCODE_ETOPXIZU_DIY1 16724175 127 | #define IRCODE_ETOPXIZU_DIY2 16756815 128 | #define IRCODE_ETOPXIZU_DIY3 16740495 129 | #define IRCODE_ETOPXIZU_DIY4 16716015 130 | #define IRCODE_ETOPXIZU_DIY5 16748655 131 | #define IRCODE_ETOPXIZU_DIY6 16732335 132 | 133 | #define IRCODE_ETOPXIZU_JUMP3 16720095 134 | #define IRCODE_ETOPXIZU_JUMP7 16752735 135 | #define IRCODE_ETOPXIZU_FADE3 16736415 136 | #define IRCODE_ETOPXIZU_FADE7 16769055 137 | #define IRCODE_ETOPXIZU_FLASH 16764975 138 | #define IRCODE_ETOPXIZU_AUTO 16773135 139 | 140 | #define IRCODE_ETOPXIZU_QUICK 16771095 141 | #define IRCODE_ETOPXIZU_SLOW 16762935 142 | 143 | #define IRCODE_ETOPXIZU_RED_UP 16722135 144 | #define IRCODE_ETOPXIZU_RED_DOWN 16713975 145 | 146 | #define IRCODE_ETOPXIZU_GREEN_UP 16754775 147 | #define IRCODE_ETOPXIZU_GREEN_DOWN 16746615 148 | 149 | #define IRCODE_ETOPXIZU_BLUE_UP 16738455 150 | #define IRCODE_ETOPXIZU_BLUE_DOWN 16730295 151 | 152 | #define IRCODE_ETOPXIZU_RED 16718565 153 | #define IRCODE_ETOPXIZU_RED_ORANGE 16722645 154 | #define IRCODE_ETOPXIZU_ORANGE 16714485 155 | #define IRCODE_ETOPXIZU_YELLOW_ORANGE 16726215 156 | #define IRCODE_ETOPXIZU_YELLOW 16718055 157 | 158 | #define IRCODE_ETOPXIZU_GREEN 16751205 159 | #define IRCODE_ETOPXIZU_LIME 16755285 160 | #define IRCODE_ETOPXIZU_AQUA 16747125 161 | #define IRCODE_ETOPXIZU_TEAL 16758855 162 | #define IRCODE_ETOPXIZU_NAVY 16750695 163 | 164 | #define IRCODE_ETOPXIZU_BLUE 16753245 165 | #define IRCODE_ETOPXIZU_ROYAL_BLUE 16749165 166 | #define IRCODE_ETOPXIZU_PURPLE 16757325 167 | #define IRCODE_ETOPXIZU_INDIGO 16742535 168 | #define IRCODE_ETOPXIZU_MAGENTA 16734375 169 | 170 | #define IRCODE_ETOPXIZU_WHITE 16720605 171 | #define IRCODE_ETOPXIZU_PINK 16716525 172 | #define IRCODE_ETOPXIZU_LIGHT_PINK 16724685 173 | #define IRCODE_ETOPXIZU_BABY_BLUE 16775175 174 | #define IRCODE_ETOPXIZU_LIGHT_BLUE 16767015 175 | 176 | bool sparkfunRemoteEnabled = false; 177 | bool adafruitRemoteEnabled = true; 178 | bool etopxizuRemoteEnabled = true; 179 | 180 | // Low level IR code reading function 181 | // Function will return 0 if no IR code available 182 | unsigned long decodeIRCode() { 183 | 184 | decode_results results; 185 | 186 | results.value = 0; 187 | 188 | // Attempt to read an IR code ? 189 | if (irReceiver.decode(&results)) { 190 | delay(20); 191 | 192 | if (results.value != 0) 193 | // Serial.println(results.value); 194 | 195 | // Prepare to receive the next IR code 196 | irReceiver.resume(); 197 | } 198 | 199 | return results.value; 200 | } 201 | 202 | // Read an IR code 203 | // Function will return 0 if no IR code available 204 | unsigned long readIRCode() { 205 | 206 | // Is there an IR code to read ? 207 | unsigned long code = decodeIRCode(); 208 | if (code == 0) { 209 | // No code so return 0 210 | return 0; 211 | } 212 | 213 | // Keep reading until code changes 214 | while (decodeIRCode() == code) { 215 | ; 216 | } 217 | // Serial.println(code); 218 | return code; 219 | } 220 | 221 | unsigned long lastIrCode = 0; 222 | 223 | unsigned int holdStartTime = 0; 224 | unsigned int defaultHoldDelay = 500; 225 | bool isHolding = false; 226 | 227 | unsigned int zeroStartTime = 0; 228 | unsigned int zeroDelay = 120; 229 | 230 | unsigned long readIRCode(unsigned int holdDelay) { 231 | // read the raw code from the sensor 232 | unsigned long irCode = readIRCode(); 233 | 234 | //Serial.print(millis()); 235 | //Serial.print("\t"); 236 | //Serial.println(irCode); 237 | 238 | // don't return a short click until we know it's not a long hold 239 | // we'll have to wait for holdDelay ms to pass before returning a non-zero IR code 240 | // then, after that delay, as long as the button is held, we can keep returning the code 241 | // every time until it's released 242 | 243 | // the ir remote only sends codes every 107 ms or so (avg 106.875, max 111, min 102), 244 | // so the ir sensor will return 0 even if a button is held 245 | // so we have to wait longer than that before returning a non-zero code 246 | // in order to detect that a button has been released and is no longer held 247 | 248 | // only reset after we've gotten 0 back for more than the ir remote send interval 249 | unsigned int zeroTime = 0; 250 | 251 | if (irCode == 0) { 252 | zeroTime = millis() - zeroStartTime; 253 | if (zeroTime >= zeroDelay && lastIrCode != 0) { 254 | //Serial.println(F("zero delay has elapsed, returning last ir code")); 255 | // the button has been released for longer than the zero delay 256 | // start over delays over and return the last code 257 | irCode = lastIrCode; 258 | lastIrCode = 0; 259 | return irCode; 260 | } 261 | 262 | return 0; 263 | } 264 | 265 | // reset the zero timer every time a non-zero code is read 266 | zeroStartTime = millis(); 267 | 268 | unsigned int heldTime = 0; 269 | 270 | if (irCode == IRCODE_SPARKFUN_HELD || irCode == IRCODE_ADAFRUIT_HELD) { 271 | // has the hold delay passed? 272 | heldTime = millis() - holdStartTime; 273 | if (heldTime >= holdDelay) { 274 | isHolding = true; 275 | //Serial.println(F("hold delay has elapsed, returning last ir code")); 276 | return lastIrCode; 277 | } 278 | else if (holdStartTime == 0) { 279 | isHolding = false; 280 | holdStartTime = millis(); 281 | } 282 | } 283 | else { 284 | // not zero, not IRCODE_SPARKFUN_HELD 285 | // store it for use later, until the hold and zero delays have elapsed 286 | holdStartTime = millis(); 287 | isHolding = false; 288 | lastIrCode = irCode; 289 | return 0; 290 | } 291 | 292 | return 0; 293 | } 294 | 295 | void heldButtonHasBeenHandled() { 296 | lastIrCode = 0; 297 | isHolding = false; 298 | holdStartTime = 0; 299 | } 300 | 301 | unsigned long waitForIRCode() { 302 | 303 | unsigned long irCode = readIRCode(); 304 | while ((irCode == 0) || (irCode == 0xFFFFFFFF)) { 305 | delay(200); 306 | irCode = readIRCode(); 307 | } 308 | return irCode; 309 | } 310 | 311 | InputCommand getCommand(unsigned long input) { 312 | if (adafruitRemoteEnabled) { 313 | switch (input) { 314 | case IRCODE_ADAFRUIT_UP: 315 | return InputCommand::Up; 316 | 317 | case IRCODE_ADAFRUIT_DOWN: 318 | return InputCommand::Down; 319 | 320 | case IRCODE_ADAFRUIT_LEFT: 321 | return InputCommand::Left; 322 | 323 | case IRCODE_ADAFRUIT_RIGHT: 324 | return InputCommand::Right; 325 | 326 | case IRCODE_ADAFRUIT_ENTER_SAVE: 327 | return InputCommand::Select; 328 | 329 | case IRCODE_ADAFRUIT_STOP_MODE: 330 | case IRCODE_ADAFRUIT_1: 331 | return InputCommand::PlayMode; 332 | 333 | case IRCODE_ADAFRUIT_2: 334 | return InputCommand::CyclePalette; 335 | 336 | case IRCODE_ADAFRUIT_PLAY_PAUSE: 337 | return InputCommand::Power; 338 | 339 | case IRCODE_ADAFRUIT_VOLUME_UP: 340 | return InputCommand::BrightnessUp; 341 | 342 | case IRCODE_ADAFRUIT_VOLUME_DOWN: 343 | return InputCommand::BrightnessDown; 344 | } 345 | } 346 | 347 | if (sparkfunRemoteEnabled) { 348 | switch (input) { 349 | case IRCODE_SPARKFUN_UP: 350 | return InputCommand::Up; 351 | 352 | case IRCODE_SPARKFUN_DOWN: 353 | return InputCommand::Down; 354 | 355 | case IRCODE_SPARKFUN_LEFT: 356 | return InputCommand::Left; 357 | 358 | case IRCODE_SPARKFUN_RIGHT: 359 | return InputCommand::Right; 360 | 361 | case IRCODE_SPARKFUN_SELECT: 362 | return InputCommand::Select; 363 | 364 | case IRCODE_SPARKFUN_POWER: 365 | return InputCommand::Brightness; 366 | 367 | case IRCODE_SPARKFUN_A: 368 | return InputCommand::PlayMode; 369 | 370 | case IRCODE_SPARKFUN_B: 371 | return InputCommand::CyclePalette; 372 | } 373 | } 374 | 375 | if (etopxizuRemoteEnabled) { 376 | switch (input) { 377 | case IRCODE_ETOPXIZU_QUICK: 378 | return InputCommand::Up; 379 | 380 | case IRCODE_ETOPXIZU_SLOW: 381 | return InputCommand::Down; 382 | 383 | case IRCODE_ETOPXIZU_PLAY_PAUSE: 384 | return InputCommand::PlayMode; 385 | 386 | case IRCODE_ETOPXIZU_POWER: 387 | return InputCommand::Power; 388 | 389 | case IRCODE_ETOPXIZU_BRIGHTNESS_UP: 390 | return InputCommand::BrightnessUp; 391 | case IRCODE_ETOPXIZU_BRIGHTNESS_DOWN: 392 | return InputCommand::BrightnessDown; 393 | 394 | case IRCODE_ETOPXIZU_DIY1: 395 | return InputCommand::Pattern1; 396 | case IRCODE_ETOPXIZU_DIY2: 397 | return InputCommand::Pattern2; 398 | case IRCODE_ETOPXIZU_DIY3: 399 | return InputCommand::Pattern3; 400 | case IRCODE_ETOPXIZU_DIY4: 401 | return InputCommand::Pattern4; 402 | case IRCODE_ETOPXIZU_DIY5: 403 | return InputCommand::Pattern5; 404 | case IRCODE_ETOPXIZU_DIY6: 405 | return InputCommand::Pattern6; 406 | case IRCODE_ETOPXIZU_JUMP3: 407 | return InputCommand::Pattern7; 408 | case IRCODE_ETOPXIZU_JUMP7: 409 | return InputCommand::Pattern8; 410 | case IRCODE_ETOPXIZU_FADE3: 411 | return InputCommand::Pattern9; 412 | case IRCODE_ETOPXIZU_FADE7: 413 | return InputCommand::Pattern10; 414 | 415 | case IRCODE_ETOPXIZU_FLASH: 416 | return InputCommand::PreviousPalette; 417 | // return InputCommand::Pattern11; 418 | 419 | case IRCODE_ETOPXIZU_AUTO: 420 | return InputCommand::NextPalette; 421 | // return InputCommand::Pattern12; 422 | 423 | case IRCODE_ETOPXIZU_RED_UP: 424 | return InputCommand::RedUp; 425 | case IRCODE_ETOPXIZU_RED_DOWN: 426 | return InputCommand::RedDown; 427 | 428 | case IRCODE_ETOPXIZU_GREEN_UP: 429 | return InputCommand::GreenUp; 430 | case IRCODE_ETOPXIZU_GREEN_DOWN: 431 | return InputCommand::GreenDown; 432 | 433 | case IRCODE_ETOPXIZU_BLUE_UP: 434 | return InputCommand::BlueUp; 435 | case IRCODE_ETOPXIZU_BLUE_DOWN: 436 | return InputCommand::BlueDown; 437 | 438 | case IRCODE_ETOPXIZU_RED: 439 | return InputCommand::Red; 440 | case IRCODE_ETOPXIZU_RED_ORANGE: 441 | return InputCommand::RedOrange; 442 | case IRCODE_ETOPXIZU_ORANGE: 443 | return InputCommand::Orange; 444 | case IRCODE_ETOPXIZU_YELLOW_ORANGE: 445 | return InputCommand::YellowOrange; 446 | case IRCODE_ETOPXIZU_YELLOW: 447 | return InputCommand::Yellow; 448 | 449 | case IRCODE_ETOPXIZU_GREEN: 450 | return InputCommand::Green; 451 | case IRCODE_ETOPXIZU_LIME: 452 | return InputCommand::Lime; 453 | case IRCODE_ETOPXIZU_AQUA: 454 | return InputCommand::Aqua; 455 | case IRCODE_ETOPXIZU_TEAL: 456 | return InputCommand::Teal; 457 | case IRCODE_ETOPXIZU_NAVY: 458 | return InputCommand::Navy; 459 | 460 | case IRCODE_ETOPXIZU_BLUE: 461 | return InputCommand::Blue; 462 | case IRCODE_ETOPXIZU_ROYAL_BLUE: 463 | return InputCommand::RoyalBlue; 464 | case IRCODE_ETOPXIZU_PURPLE: 465 | return InputCommand::Purple; 466 | case IRCODE_ETOPXIZU_INDIGO: 467 | return InputCommand::Indigo; 468 | case IRCODE_ETOPXIZU_MAGENTA: 469 | return InputCommand::Magenta; 470 | 471 | case IRCODE_ETOPXIZU_WHITE: 472 | return InputCommand::White; 473 | case IRCODE_ETOPXIZU_PINK: 474 | return InputCommand::Pink; 475 | case IRCODE_ETOPXIZU_LIGHT_PINK: 476 | return InputCommand::LightPink; 477 | case IRCODE_ETOPXIZU_BABY_BLUE: 478 | return InputCommand::BabyBlue; 479 | case IRCODE_ETOPXIZU_LIGHT_BLUE: 480 | return InputCommand::LightBlue; 481 | } 482 | } 483 | 484 | return InputCommand::None; 485 | } 486 | 487 | InputCommand readCommand() { 488 | return getCommand(readIRCode()); 489 | } 490 | 491 | InputCommand readCommand(unsigned int holdDelay) { 492 | return getCommand(readIRCode(holdDelay)); 493 | } 494 | 495 | #endif 496 | -------------------------------------------------------------------------------- /Drawing.h: -------------------------------------------------------------------------------- 1 | /* 2 | * Torch: https://github.com/evilgeniuslabs/torch 3 | * Copyright (C) 2015 Jason Coon 4 | * 5 | * This program is free software: you can redistribute it and/or modify 6 | * it under the terms of the GNU General Public License as published by 7 | * the Free Software Foundation, either version 3 of the License, or 8 | * (at your option) any later version. 9 | * 10 | * This program is distributed in the hope that it will be useful, 11 | * but WITHOUT ANY WARRANTY; without even the implied warranty of 12 | * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 13 | * GNU General Public License for more details. 14 | * 15 | * You should have received a copy of the GNU General Public License 16 | * along with this program. If not, see . 17 | */ 18 | 19 | void drawCircle(int16_t x0, int16_t y0, uint16_t radius, const CRGB& color) 20 | { 21 | int a = radius, b = 0; 22 | int radiusError = 1 - a; 23 | 24 | if (radius == 0) { 25 | leds[XY(x0, y0)] = color; 26 | return; 27 | } 28 | 29 | while (a >= b) 30 | { 31 | leds[XY(a + x0, b + y0)] = color; 32 | leds[XY(b + x0, a + y0)] = color; 33 | leds[XY(-a + x0, b + y0)] = color; 34 | leds[XY(-b + x0, a + y0)] = color; 35 | leds[XY(-a + x0, -b + y0)] = color; 36 | leds[XY(-b + x0, -a + y0)] = color; 37 | leds[XY(a + x0, -b + y0)] = color; 38 | leds[XY(b + x0, -a + y0)] = color; 39 | 40 | b++; 41 | if (radiusError < 0) 42 | radiusError += 2 * b + 1; 43 | else 44 | { 45 | a--; 46 | radiusError += 2 * (b - a + 1); 47 | } 48 | } 49 | } 50 | 51 | void drawFastVLine(uint16_t x, uint16_t y0, uint16_t y1, const CRGB& color) { 52 | uint16_t i; 53 | 54 | for (i = y0; i <= y1; i++) { 55 | leds[XY(x, i)] = color; 56 | } 57 | } 58 | -------------------------------------------------------------------------------- /Effects.h: -------------------------------------------------------------------------------- 1 | /* 2 | * Torch: https://github.com/evilgeniuslabs/torch 3 | * Copyright (C) 2015 Jason Coon 4 | * 5 | * This program is free software: you can redistribute it and/or modify 6 | * it under the terms of the GNU General Public License as published by 7 | * the Free Software Foundation, either version 3 of the License, or 8 | * (at your option) any later version. 9 | * 10 | * This program is distributed in the hope that it will be useful, 11 | * but WITHOUT ANY WARRANTY; without even the implied warranty of 12 | * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 13 | * GNU General Public License for more details. 14 | * 15 | * You should have received a copy of the GNU General Public License 16 | * along with this program. If not, see . 17 | */ 18 | 19 | // give it a linear tail to the right 20 | void streamRight(byte scale, int fromX = 0, int toX = MATRIX_WIDTH, int fromY = 0, int toY = MATRIX_HEIGHT) 21 | { 22 | for (int x = fromX + 1; x < toX; x++) { 23 | for (int y = fromY; y < toY; y++) { 24 | leds[XY(x, y)] += leds[XY(x - 1, y)]; 25 | leds[XY(x, y)].nscale8(scale); 26 | } 27 | } 28 | for (int y = fromY; y < toY; y++) 29 | leds[XY(0, y)].nscale8(scale); 30 | } 31 | 32 | // give it a linear tail to the left 33 | void streamLeft(byte scale, int fromX = MATRIX_WIDTH, int toX = 0, int fromY = 0, int toY = MATRIX_HEIGHT) 34 | { 35 | for (int x = toX; x < fromX; x++) { 36 | for (int y = fromY; y < toY; y++) { 37 | leds[XY(x, y)] += leds[XY(x + 1, y)]; 38 | leds[XY(x, y)].nscale8(scale); 39 | } 40 | } 41 | for (int y = fromY; y < toY; y++) 42 | leds[XY(0, y)].nscale8(scale); 43 | } 44 | 45 | // give it a linear tail downwards 46 | void streamDown(byte scale) 47 | { 48 | for (int x = 0; x < MATRIX_WIDTH; x++) { 49 | for (int y = 1; y < MATRIX_HEIGHT; y++) { 50 | leds[XY(x, y)] += leds[XY(x, y - 1)]; 51 | leds[XY(x, y)].nscale8(scale); 52 | } 53 | } 54 | for (int x = 0; x < MATRIX_WIDTH; x++) 55 | leds[XY(x, 0)].nscale8(scale); 56 | } 57 | 58 | // give it a linear tail upwards 59 | void streamUp(byte scale) 60 | { 61 | for (int x = 0; x < MATRIX_WIDTH; x++) { 62 | for (int y = MATRIX_HEIGHT - 2; y >= 0; y--) { 63 | leds[XY(x, y)] += leds[XY(x, y + 1)]; 64 | leds[XY(x, y)].nscale8(scale); 65 | } 66 | } 67 | for (int x = 0; x < MATRIX_WIDTH; x++) 68 | leds[XY(x, MATRIX_HEIGHT - 1)].nscale8(scale); 69 | } 70 | 71 | // give it a linear tail up and to the left 72 | void streamUpAndLeft(byte scale) 73 | { 74 | for (int x = 0; x < MATRIX_WIDTH - 1; x++) { 75 | for (int y = MATRIX_HEIGHT - 2; y >= 0; y--) { 76 | leds[XY(x, y)] += leds[XY(x + 1, y + 1)]; 77 | leds[XY(x, y)].nscale8(scale); 78 | } 79 | } 80 | for (int x = 0; x < MATRIX_WIDTH; x++) 81 | leds[XY(x, MATRIX_HEIGHT - 1)].nscale8(scale); 82 | for (int y = 0; y < MATRIX_HEIGHT; y++) 83 | leds[XY(MATRIX_WIDTH - 1, y)].nscale8(scale); 84 | } 85 | 86 | // give it a linear tail up and to the right 87 | void streamUpAndRight(byte scale) 88 | { 89 | for (int x = 0; x < MATRIX_WIDTH - 1; x++) { 90 | for (int y = MATRIX_HEIGHT - 2; y >= 0; y--) { 91 | leds[XY(x + 1, y)] += leds[XY(x, y + 1)]; 92 | leds[XY(x, y)].nscale8(scale); 93 | } 94 | } 95 | // fade the bottom row 96 | for (int x = 0; x < MATRIX_WIDTH; x++) 97 | leds[XY(x, MATRIX_HEIGHT - 1)].nscale8(scale); 98 | 99 | // fade the right column 100 | for (int y = 0; y < MATRIX_HEIGHT; y++) 101 | leds[XY(MATRIX_WIDTH - 1, y)].nscale8(scale); 102 | } 103 | 104 | void moveUp() 105 | { 106 | for (int y = 0; y < MATRIX_HEIGHT - 1; y++) { 107 | for (int x = 0; x < MATRIX_WIDTH; x++) { 108 | leds[XY(x, y)] = leds[XY(x, y + 1)]; 109 | } 110 | } 111 | } 112 | 113 | void moveDown() { 114 | for (int y = MATRIX_HEIGHT - 1; y > 0; y--) { 115 | for (int x = 0; x < MATRIX_WIDTH; x++) { 116 | leds[XY(x, y)] = leds[XY(x, y - 1)]; 117 | } 118 | } 119 | } 120 | -------------------------------------------------------------------------------- /Fire2012WithPalette.h: -------------------------------------------------------------------------------- 1 | // Fire2012 with programmable Color Palette 2 | // by Mark Kriegsman: https://github.com/FastLED/FastLED/blob/master/examples/Fire2012WithPalette/Fire2012WithPalette.ino 3 | // 4 | // This code is the same fire simulation as the original "Fire2012", 5 | // but each heat cell's temperature is translated to color through a FastLED 6 | // programmable color palette, instead of through the "HeatColor(...)" function. 7 | // 8 | // Four different static color palettes are provided here, plus one dynamic one. 9 | // 10 | // The three static ones are: 11 | // 1. the FastLED built-in HeatColors_p -- this is the default, and it looks 12 | // pretty much exactly like the original Fire2012. 13 | // 14 | // To use any of the other palettes below, just "uncomment" the corresponding code. 15 | // 16 | // 2. a gradient from black to red to yellow to white, which is 17 | // visually similar to the HeatColors_p, and helps to illustrate 18 | // what the 'heat colors' palette is actually doing, 19 | // 3. a similar gradient, but in blue colors rather than red ones, 20 | // i.e. from black to blue to aqua to white, which results in 21 | // an "icy blue" fire effect, 22 | // 4. a simplified three-step gradient, from black to red to white, just to show 23 | // that these gradients need not have four components; two or 24 | // three are possible, too, even if they don't look quite as nice for fire. 25 | // 26 | // The dynamic palette shows how you can change the basic 'hue' of the 27 | // color palette every time through the loop, producing "rainbow fire". 28 | 29 | // Fire2012 by Mark Kriegsman, July 2012 30 | // as part of "Five Elements" shown here: http://youtu.be/knWiGsmgycY 31 | //// 32 | // This basic one-dimensional 'fire' simulation works roughly as follows: 33 | // There's a underlying array of 'heat' cells, that model the temperature 34 | // at each point along the line. Every cycle through the simulation, 35 | // four steps are performed: 36 | // 1) All cells cool down a little bit, losing heat to the air 37 | // 2) The heat from each cell drifts 'up' and diffuses a little 38 | // 3) Sometimes randomly new 'sparks' of heat are added at the bottom 39 | // 4) The heat from each cell is rendered as a color into the leds array 40 | // The heat-to-color mapping uses a black-body radiation approximation. 41 | // 42 | // Temperature is in arbitrary units from 0 (cold black) to 255 (white hot). 43 | // 44 | // This simulation scales it self a bit depending on MATRIX_HEIGHT; it should look 45 | // "OK" on anywhere from 20 to 100 LEDs without too much tweaking. 46 | // 47 | // I recommend running this simulation at anywhere from 30-100 frames per second, 48 | // meaning an interframe delay of about 10-35 milliseconds. 49 | // 50 | // Looks best on a high-density LED setup (60+ pixels/meter). 51 | // 52 | // 53 | // There are two main parameters you can play with to control the look and 54 | // feel of your fire: COOLING (used in step 1 above), and SPARKING (used 55 | // in step 3 above). 56 | // 57 | // COOLING: How much does the air cool as it rises? 58 | // Less cooling = taller flames. More cooling = shorter flames. 59 | // Default 55, suggested range 20-100 60 | #define COOLING 55 // 100 // 55 // 86 61 | 62 | // SPARKING: What chance (out of 255) is there that a new spark will be lit? 63 | // Higher chance = more roaring fire. Lower chance = more flickery fire. 64 | // Default 120, suggested range 50-200. 65 | #define SPARKING 50 // 30 // 120 // 90 // 60 66 | 67 | uint16_t fire2012WithPalette() 68 | { 69 | // Array of temperature readings at each simulation cell 70 | static byte heat[MATRIX_WIDTH][MATRIX_HEIGHT]; 71 | 72 | for(uint8_t x = 0; x < MATRIX_WIDTH; x++) { 73 | // Step 1. Cool down every cell a little 74 | for (int i = 0; i < MATRIX_HEIGHT; i++) { 75 | heat[x][i] = qsub8(heat[x][i], random8(0, ((COOLING * 10) / MATRIX_HEIGHT) + 2)); 76 | } 77 | 78 | // Step 2. Heat from each cell drifts 'up' and diffuses a little 79 | for (int k = MATRIX_HEIGHT - 1; k >= 2; k--) { 80 | heat[x][k] = (heat[x][k - 1] + heat[x][k - 2] + heat[x][k - 2]) / 3; 81 | } 82 | 83 | // Step 3. Randomly ignite new 'sparks' of heat near the bottom 84 | if (random8() < SPARKING) { 85 | int y = random8(2); 86 | heat[x][y] = qadd8(heat[x][y], random8(160, 255)); 87 | } 88 | 89 | // Step 4. Map from heat cells to LED colors 90 | for (int j = 0; j < MATRIX_HEIGHT; j++) { 91 | // Scale the heat value from 0-255 down to 0-240 92 | // for best results with color palettes. 93 | byte colorindex = scale8(heat[x][j], 240); 94 | leds[XY(x, (MATRIX_HEIGHT - 1) - j)] = ColorFromPalette(HeatColors_p, colorindex); 95 | } 96 | } 97 | 98 | return 15; 99 | } 100 | -------------------------------------------------------------------------------- /GradientPalettes.h: -------------------------------------------------------------------------------- 1 | // ColorWavesWithPalettes 2 | // Animated shifting color waves, with several cross-fading color palettes. 3 | // by Mark Kriegsman, August 2015 4 | // 5 | // Color palettes courtesy of cpt-city and its contributors: 6 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/ 7 | // 8 | // Color palettes converted for FastLED using "PaletteKnife" v1: 9 | // http://fastled.io/tools/paletteknife/ 10 | // 11 | 12 | // Gradient Color Palette definitions for 33 different cpt-city color palettes. 13 | // 956 bytes of PROGMEM for all of the palettes together, 14 | // +618 bytes of PROGMEM for gradient palette code (AVR). 15 | // 1,494 bytes total for all 34 color palettes and associated code. 16 | 17 | // Gradient palette "ib_jul01_gp", originally from 18 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/ing/xmas/tn/ib_jul01.png.index.html 19 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 20 | // Size: 16 bytes of program space. 21 | 22 | DEFINE_GRADIENT_PALETTE( ib_jul01_gp ) { 23 | 0, 194, 1, 1, 24 | 94, 1, 29, 18, 25 | 132, 57,131, 28, 26 | 255, 113, 1, 1}; 27 | 28 | // Gradient palette "es_vintage_57_gp", originally from 29 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/vintage/tn/es_vintage_57.png.index.html 30 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 31 | // Size: 20 bytes of program space. 32 | 33 | DEFINE_GRADIENT_PALETTE( es_vintage_57_gp ) { 34 | 0, 2, 1, 1, 35 | 53, 18, 1, 0, 36 | 104, 69, 29, 1, 37 | 153, 167,135, 10, 38 | 255, 46, 56, 4}; 39 | 40 | // Gradient palette "es_vintage_01_gp", originally from 41 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/vintage/tn/es_vintage_01.png.index.html 42 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 43 | // Size: 32 bytes of program space. 44 | 45 | DEFINE_GRADIENT_PALETTE( es_vintage_01_gp ) { 46 | 0, 4, 1, 1, 47 | 51, 16, 0, 1, 48 | 76, 97,104, 3, 49 | 101, 255,131, 19, 50 | 127, 67, 9, 4, 51 | 153, 16, 0, 1, 52 | 229, 4, 1, 1, 53 | 255, 4, 1, 1}; 54 | 55 | // Gradient palette "es_rivendell_15_gp", originally from 56 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/rivendell/tn/es_rivendell_15.png.index.html 57 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 58 | // Size: 20 bytes of program space. 59 | 60 | DEFINE_GRADIENT_PALETTE( es_rivendell_15_gp ) { 61 | 0, 1, 14, 5, 62 | 101, 16, 36, 14, 63 | 165, 56, 68, 30, 64 | 242, 150,156, 99, 65 | 255, 150,156, 99}; 66 | 67 | // Gradient palette "rgi_15_gp", originally from 68 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/ds/rgi/tn/rgi_15.png.index.html 69 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 70 | // Size: 36 bytes of program space. 71 | 72 | DEFINE_GRADIENT_PALETTE( rgi_15_gp ) { 73 | 0, 4, 1, 31, 74 | 31, 55, 1, 16, 75 | 63, 197, 3, 7, 76 | 95, 59, 2, 17, 77 | 127, 6, 2, 34, 78 | 159, 39, 6, 33, 79 | 191, 112, 13, 32, 80 | 223, 56, 9, 35, 81 | 255, 22, 6, 38}; 82 | 83 | // Gradient palette "retro2_16_gp", originally from 84 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/ma/retro2/tn/retro2_16.png.index.html 85 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 86 | // Size: 8 bytes of program space. 87 | 88 | DEFINE_GRADIENT_PALETTE( retro2_16_gp ) { 89 | 0, 188,135, 1, 90 | 255, 46, 7, 1}; 91 | 92 | // Gradient palette "Analogous_1_gp", originally from 93 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/red/tn/Analogous_1.png.index.html 94 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 95 | // Size: 20 bytes of program space. 96 | 97 | DEFINE_GRADIENT_PALETTE( Analogous_1_gp ) { 98 | 0, 3, 0,255, 99 | 63, 23, 0,255, 100 | 127, 67, 0,255, 101 | 191, 142, 0, 45, 102 | 255, 255, 0, 0}; 103 | 104 | // Gradient palette "es_pinksplash_08_gp", originally from 105 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/pink_splash/tn/es_pinksplash_08.png.index.html 106 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 107 | // Size: 20 bytes of program space. 108 | 109 | DEFINE_GRADIENT_PALETTE( es_pinksplash_08_gp ) { 110 | 0, 126, 11,255, 111 | 127, 197, 1, 22, 112 | 175, 210,157,172, 113 | 221, 157, 3,112, 114 | 255, 157, 3,112}; 115 | 116 | // Gradient palette "es_pinksplash_07_gp", originally from 117 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/pink_splash/tn/es_pinksplash_07.png.index.html 118 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 119 | // Size: 28 bytes of program space. 120 | 121 | DEFINE_GRADIENT_PALETTE( es_pinksplash_07_gp ) { 122 | 0, 229, 1, 1, 123 | 61, 242, 4, 63, 124 | 101, 255, 12,255, 125 | 127, 249, 81,252, 126 | 153, 255, 11,235, 127 | 193, 244, 5, 68, 128 | 255, 232, 1, 5}; 129 | 130 | // Gradient palette "Coral_reef_gp", originally from 131 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/other/tn/Coral_reef.png.index.html 132 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 133 | // Size: 24 bytes of program space. 134 | 135 | DEFINE_GRADIENT_PALETTE( Coral_reef_gp ) { 136 | 0, 40,199,197, 137 | 50, 10,152,155, 138 | 96, 1,111,120, 139 | 96, 43,127,162, 140 | 139, 10, 73,111, 141 | 255, 1, 34, 71}; 142 | 143 | // Gradient palette "es_ocean_breeze_068_gp", originally from 144 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/ocean_breeze/tn/es_ocean_breeze_068.png.index.html 145 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 146 | // Size: 24 bytes of program space. 147 | 148 | DEFINE_GRADIENT_PALETTE( es_ocean_breeze_068_gp ) { 149 | 0, 100,156,153, 150 | 51, 1, 99,137, 151 | 101, 1, 68, 84, 152 | 104, 35,142,168, 153 | 178, 0, 63,117, 154 | 255, 1, 10, 10}; 155 | 156 | // Gradient palette "es_ocean_breeze_036_gp", originally from 157 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/ocean_breeze/tn/es_ocean_breeze_036.png.index.html 158 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 159 | // Size: 16 bytes of program space. 160 | 161 | DEFINE_GRADIENT_PALETTE( es_ocean_breeze_036_gp ) { 162 | 0, 1, 6, 7, 163 | 89, 1, 99,111, 164 | 153, 144,209,255, 165 | 255, 0, 73, 82}; 166 | 167 | // Gradient palette "departure_gp", originally from 168 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/mjf/tn/departure.png.index.html 169 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 170 | // Size: 88 bytes of program space. 171 | 172 | DEFINE_GRADIENT_PALETTE( departure_gp ) { 173 | 0, 8, 3, 0, 174 | 42, 23, 7, 0, 175 | 63, 75, 38, 6, 176 | 84, 169, 99, 38, 177 | 106, 213,169,119, 178 | 116, 255,255,255, 179 | 138, 135,255,138, 180 | 148, 22,255, 24, 181 | 170, 0,255, 0, 182 | 191, 0,136, 0, 183 | 212, 0, 55, 0, 184 | 255, 0, 55, 0}; 185 | 186 | // Gradient palette "es_landscape_64_gp", originally from 187 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/landscape/tn/es_landscape_64.png.index.html 188 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 189 | // Size: 36 bytes of program space. 190 | 191 | DEFINE_GRADIENT_PALETTE( es_landscape_64_gp ) { 192 | 0, 0, 0, 0, 193 | 37, 2, 25, 1, 194 | 76, 15,115, 5, 195 | 127, 79,213, 1, 196 | 128, 126,211, 47, 197 | 130, 188,209,247, 198 | 153, 144,182,205, 199 | 204, 59,117,250, 200 | 255, 1, 37,192}; 201 | 202 | // Gradient palette "es_landscape_33_gp", originally from 203 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/landscape/tn/es_landscape_33.png.index.html 204 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 205 | // Size: 24 bytes of program space. 206 | 207 | DEFINE_GRADIENT_PALETTE( es_landscape_33_gp ) { 208 | 0, 1, 5, 0, 209 | 19, 32, 23, 1, 210 | 38, 161, 55, 1, 211 | 63, 229,144, 1, 212 | 66, 39,142, 74, 213 | 255, 1, 4, 1}; 214 | 215 | // Gradient palette "rainbowsherbet_gp", originally from 216 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/ma/icecream/tn/rainbowsherbet.png.index.html 217 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 218 | // Size: 28 bytes of program space. 219 | 220 | DEFINE_GRADIENT_PALETTE( rainbowsherbet_gp ) { 221 | 0, 255, 33, 4, 222 | 43, 255, 68, 25, 223 | 86, 255, 7, 25, 224 | 127, 255, 82,103, 225 | 170, 255,255,242, 226 | 209, 42,255, 22, 227 | 255, 87,255, 65}; 228 | 229 | // Gradient palette "gr65_hult_gp", originally from 230 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/hult/tn/gr65_hult.png.index.html 231 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 232 | // Size: 24 bytes of program space. 233 | 234 | DEFINE_GRADIENT_PALETTE( gr65_hult_gp ) { 235 | 0, 247,176,247, 236 | 48, 255,136,255, 237 | 89, 220, 29,226, 238 | 160, 7, 82,178, 239 | 216, 1,124,109, 240 | 255, 1,124,109}; 241 | 242 | // Gradient palette "gr64_hult_gp", originally from 243 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/hult/tn/gr64_hult.png.index.html 244 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 245 | // Size: 32 bytes of program space. 246 | 247 | DEFINE_GRADIENT_PALETTE( gr64_hult_gp ) { 248 | 0, 1,124,109, 249 | 66, 1, 93, 79, 250 | 104, 52, 65, 1, 251 | 130, 115,127, 1, 252 | 150, 52, 65, 1, 253 | 201, 1, 86, 72, 254 | 239, 0, 55, 45, 255 | 255, 0, 55, 45}; 256 | 257 | // Gradient palette "GMT_drywet_gp", originally from 258 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/gmt/tn/GMT_drywet.png.index.html 259 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 260 | // Size: 28 bytes of program space. 261 | 262 | DEFINE_GRADIENT_PALETTE( GMT_drywet_gp ) { 263 | 0, 47, 30, 2, 264 | 42, 213,147, 24, 265 | 84, 103,219, 52, 266 | 127, 3,219,207, 267 | 170, 1, 48,214, 268 | 212, 1, 1,111, 269 | 255, 1, 7, 33}; 270 | 271 | // Gradient palette "ib15_gp", originally from 272 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/ing/general/tn/ib15.png.index.html 273 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 274 | // Size: 24 bytes of program space. 275 | 276 | DEFINE_GRADIENT_PALETTE( ib15_gp ) { 277 | 0, 113, 91,147, 278 | 72, 157, 88, 78, 279 | 89, 208, 85, 33, 280 | 107, 255, 29, 11, 281 | 141, 137, 31, 39, 282 | 255, 59, 33, 89}; 283 | 284 | // Gradient palette "Fuschia_7_gp", originally from 285 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/ds/fuschia/tn/Fuschia-7.png.index.html 286 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 287 | // Size: 20 bytes of program space. 288 | 289 | DEFINE_GRADIENT_PALETTE( Fuschia_7_gp ) { 290 | 0, 43, 3,153, 291 | 63, 100, 4,103, 292 | 127, 188, 5, 66, 293 | 191, 161, 11,115, 294 | 255, 135, 20,182}; 295 | 296 | // Gradient palette "es_emerald_dragon_08_gp", originally from 297 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/emerald_dragon/tn/es_emerald_dragon_08.png.index.html 298 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 299 | // Size: 16 bytes of program space. 300 | 301 | DEFINE_GRADIENT_PALETTE( es_emerald_dragon_08_gp ) { 302 | 0, 97,255, 1, 303 | 101, 47,133, 1, 304 | 178, 13, 43, 1, 305 | 255, 2, 10, 1}; 306 | 307 | // Gradient palette "lava_gp", originally from 308 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/neota/elem/tn/lava.png.index.html 309 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 310 | // Size: 52 bytes of program space. 311 | 312 | DEFINE_GRADIENT_PALETTE( lava_gp ) { 313 | 0, 0, 0, 0, 314 | 46, 18, 0, 0, 315 | 96, 113, 0, 0, 316 | 108, 142, 3, 1, 317 | 119, 175, 17, 1, 318 | 146, 213, 44, 2, 319 | 174, 255, 82, 4, 320 | 188, 255,115, 4, 321 | 202, 255,156, 4, 322 | 218, 255,203, 4, 323 | 234, 255,255, 4, 324 | 244, 255,255, 71, 325 | 255, 255,255,255}; 326 | 327 | // Gradient palette "fire_gp", originally from 328 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/neota/elem/tn/fire.png.index.html 329 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 330 | // Size: 28 bytes of program space. 331 | 332 | DEFINE_GRADIENT_PALETTE( fire_gp ) { 333 | 0, 1, 1, 0, 334 | 76, 32, 5, 0, 335 | 146, 192, 24, 0, 336 | 197, 220,105, 5, 337 | 240, 252,255, 31, 338 | 250, 252,255,111, 339 | 255, 255,255,255}; 340 | 341 | // Gradient palette "Colorfull_gp", originally from 342 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/atmospheric/tn/Colorfull.png.index.html 343 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 344 | // Size: 44 bytes of program space. 345 | 346 | DEFINE_GRADIENT_PALETTE( Colorfull_gp ) { 347 | 0, 10, 85, 5, 348 | 25, 29,109, 18, 349 | 60, 59,138, 42, 350 | 93, 83, 99, 52, 351 | 106, 110, 66, 64, 352 | 109, 123, 49, 65, 353 | 113, 139, 35, 66, 354 | 116, 192,117, 98, 355 | 124, 255,255,137, 356 | 168, 100,180,155, 357 | 255, 22,121,174}; 358 | 359 | // Gradient palette "Magenta_Evening_gp", originally from 360 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/atmospheric/tn/Magenta_Evening.png.index.html 361 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 362 | // Size: 28 bytes of program space. 363 | 364 | DEFINE_GRADIENT_PALETTE( Magenta_Evening_gp ) { 365 | 0, 71, 27, 39, 366 | 31, 130, 11, 51, 367 | 63, 213, 2, 64, 368 | 70, 232, 1, 66, 369 | 76, 252, 1, 69, 370 | 108, 123, 2, 51, 371 | 255, 46, 9, 35}; 372 | 373 | // Gradient palette "Pink_Purple_gp", originally from 374 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/atmospheric/tn/Pink_Purple.png.index.html 375 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 376 | // Size: 44 bytes of program space. 377 | 378 | DEFINE_GRADIENT_PALETTE( Pink_Purple_gp ) { 379 | 0, 19, 2, 39, 380 | 25, 26, 4, 45, 381 | 51, 33, 6, 52, 382 | 76, 68, 62,125, 383 | 102, 118,187,240, 384 | 109, 163,215,247, 385 | 114, 217,244,255, 386 | 122, 159,149,221, 387 | 149, 113, 78,188, 388 | 183, 128, 57,155, 389 | 255, 146, 40,123}; 390 | 391 | // Gradient palette "Sunset_Real_gp", originally from 392 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/atmospheric/tn/Sunset_Real.png.index.html 393 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 394 | // Size: 28 bytes of program space. 395 | 396 | DEFINE_GRADIENT_PALETTE( Sunset_Real_gp ) { 397 | 0, 120, 0, 0, 398 | 22, 179, 22, 0, 399 | 51, 255,104, 0, 400 | 85, 167, 22, 18, 401 | 135, 100, 0,103, 402 | 198, 16, 0,130, 403 | 255, 0, 0,160}; 404 | 405 | // Gradient palette "es_autumn_19_gp", originally from 406 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/es/autumn/tn/es_autumn_19.png.index.html 407 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 408 | // Size: 52 bytes of program space. 409 | 410 | DEFINE_GRADIENT_PALETTE( es_autumn_19_gp ) { 411 | 0, 26, 1, 1, 412 | 51, 67, 4, 1, 413 | 84, 118, 14, 1, 414 | 104, 137,152, 52, 415 | 112, 113, 65, 1, 416 | 122, 133,149, 59, 417 | 124, 137,152, 52, 418 | 135, 113, 65, 1, 419 | 142, 139,154, 46, 420 | 163, 113, 13, 1, 421 | 204, 55, 3, 1, 422 | 249, 17, 1, 1, 423 | 255, 17, 1, 1}; 424 | 425 | // Gradient palette "BlacK_Blue_Magenta_White_gp", originally from 426 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/basic/tn/BlacK_Blue_Magenta_White.png.index.html 427 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 428 | // Size: 28 bytes of program space. 429 | 430 | DEFINE_GRADIENT_PALETTE( BlacK_Blue_Magenta_White_gp ) { 431 | 0, 0, 0, 0, 432 | 42, 0, 0, 45, 433 | 84, 0, 0,255, 434 | 127, 42, 0,255, 435 | 170, 255, 0,255, 436 | 212, 255, 55,255, 437 | 255, 255,255,255}; 438 | 439 | // Gradient palette "BlacK_Magenta_Red_gp", originally from 440 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/basic/tn/BlacK_Magenta_Red.png.index.html 441 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 442 | // Size: 20 bytes of program space. 443 | 444 | DEFINE_GRADIENT_PALETTE( BlacK_Magenta_Red_gp ) { 445 | 0, 0, 0, 0, 446 | 63, 42, 0, 45, 447 | 127, 255, 0,255, 448 | 191, 255, 0, 45, 449 | 255, 255, 0, 0}; 450 | 451 | // Gradient palette "BlacK_Red_Magenta_Yellow_gp", originally from 452 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/basic/tn/BlacK_Red_Magenta_Yellow.png.index.html 453 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 454 | // Size: 28 bytes of program space. 455 | 456 | DEFINE_GRADIENT_PALETTE( BlacK_Red_Magenta_Yellow_gp ) { 457 | 0, 0, 0, 0, 458 | 42, 42, 0, 0, 459 | 84, 255, 0, 0, 460 | 127, 255, 0, 45, 461 | 170, 255, 0,255, 462 | 212, 255, 55, 45, 463 | 255, 255,255, 0}; 464 | 465 | // Gradient palette "Blue_Cyan_Yellow_gp", originally from 466 | // http://soliton.vm.bytemark.co.uk/pub/cpt-city/nd/basic/tn/Blue_Cyan_Yellow.png.index.html 467 | // converted for FastLED with gammas (2.6, 2.2, 2.5) 468 | // Size: 20 bytes of program space. 469 | 470 | DEFINE_GRADIENT_PALETTE( Blue_Cyan_Yellow_gp ) { 471 | 0, 0, 0,255, 472 | 63, 0, 55,255, 473 | 127, 0,255,255, 474 | 191, 42,255, 45, 475 | 255, 255,255, 0}; 476 | 477 | 478 | // Single array of defined cpt-city color palettes. 479 | // This will let us programmatically choose one based on 480 | // a number, rather than having to activate each explicitly 481 | // by name every time. 482 | // Since it is const, this array could also be moved 483 | // into PROGMEM to save SRAM, but for simplicity of illustration 484 | // we'll keep it in a regular SRAM array. 485 | // 486 | // This list of color palettes acts as a "playlist"; you can 487 | // add or delete, or re-arrange as you wish. 488 | const TProgmemRGBGradientPalettePtr gGradientPalettes[] = { 489 | Sunset_Real_gp, 490 | es_rivendell_15_gp, 491 | es_ocean_breeze_036_gp, 492 | rgi_15_gp, 493 | retro2_16_gp, 494 | Analogous_1_gp, 495 | es_pinksplash_08_gp, 496 | Coral_reef_gp, 497 | es_ocean_breeze_068_gp, 498 | es_pinksplash_07_gp, 499 | es_vintage_01_gp, 500 | departure_gp, 501 | es_landscape_64_gp, 502 | es_landscape_33_gp, 503 | rainbowsherbet_gp, 504 | gr65_hult_gp, 505 | gr64_hult_gp, 506 | GMT_drywet_gp, 507 | ib_jul01_gp, 508 | es_vintage_57_gp, 509 | ib15_gp, 510 | Fuschia_7_gp, 511 | es_emerald_dragon_08_gp, 512 | lava_gp, 513 | fire_gp, 514 | Colorfull_gp, 515 | Magenta_Evening_gp, 516 | Pink_Purple_gp, 517 | es_autumn_19_gp, 518 | BlacK_Blue_Magenta_White_gp, 519 | BlacK_Magenta_Red_gp, 520 | BlacK_Red_Magenta_Yellow_gp, 521 | Blue_Cyan_Yellow_gp }; 522 | 523 | 524 | // Count of how many cpt-city gradients are defined: 525 | const uint8_t gGradientPaletteCount = 526 | sizeof( gGradientPalettes) / sizeof( TProgmemRGBGradientPalettePtr ); 527 | -------------------------------------------------------------------------------- /LICENSE: -------------------------------------------------------------------------------- 1 | GNU GENERAL PUBLIC LICENSE 2 | Version 3, 29 June 2007 3 | 4 | Copyright (C) 2007 Free Software Foundation, Inc. 5 | Everyone is permitted to copy and distribute verbatim copies 6 | of this license document, but changing it is not allowed. 7 | 8 | Preamble 9 | 10 | The GNU General Public License is a free, copyleft license for 11 | software and other kinds of works. 12 | 13 | The licenses for most software and other practical works are designed 14 | to take away your freedom to share and change the works. By contrast, 15 | the GNU General Public License is intended to guarantee your freedom to 16 | share and change all versions of a program--to make sure it remains free 17 | software for all its users. We, the Free Software Foundation, use the 18 | GNU General Public License for most of our software; it applies also to 19 | any other work released this way by its authors. You can apply it to 20 | your programs, too. 21 | 22 | When we speak of free software, we are referring to freedom, not 23 | price. Our General Public Licenses are designed to make sure that you 24 | have the freedom to distribute copies of free software (and charge for 25 | them if you wish), that you receive source code or can get it if you 26 | want it, that you can change the software or use pieces of it in new 27 | free programs, and that you know you can do these things. 28 | 29 | To protect your rights, we need to prevent others from denying you 30 | these rights or asking you to surrender the rights. Therefore, you have 31 | certain responsibilities if you distribute copies of the software, or if 32 | you modify it: responsibilities to respect the freedom of others. 33 | 34 | For example, if you distribute copies of such a program, whether 35 | gratis or for a fee, you must pass on to the recipients the same 36 | freedoms that you received. You must make sure that they, too, receive 37 | or can get the source code. And you must show them these terms so they 38 | know their rights. 39 | 40 | Developers that use the GNU GPL protect your rights with two steps: 41 | (1) assert copyright on the software, and (2) offer you this License 42 | giving you legal permission to copy, distribute and/or modify it. 43 | 44 | For the developers' and authors' protection, the GPL clearly explains 45 | that there is no warranty for this free software. For both users' and 46 | authors' sake, the GPL requires that modified versions be marked as 47 | changed, so that their problems will not be attributed erroneously to 48 | authors of previous versions. 49 | 50 | Some devices are designed to deny users access to install or run 51 | modified versions of the software inside them, although the manufacturer 52 | can do so. This is fundamentally incompatible with the aim of 53 | protecting users' freedom to change the software. The systematic 54 | pattern of such abuse occurs in the area of products for individuals to 55 | use, which is precisely where it is most unacceptable. Therefore, we 56 | have designed this version of the GPL to prohibit the practice for those 57 | products. If such problems arise substantially in other domains, we 58 | stand ready to extend this provision to those domains in future versions 59 | of the GPL, as needed to protect the freedom of users. 60 | 61 | Finally, every program is threatened constantly by software patents. 62 | States should not allow patents to restrict development and use of 63 | software on general-purpose computers, but in those that do, we wish to 64 | avoid the special danger that patents applied to a free program could 65 | make it effectively proprietary. To prevent this, the GPL assures that 66 | patents cannot be used to render the program non-free. 67 | 68 | The precise terms and conditions for copying, distribution and 69 | modification follow. 70 | 71 | TERMS AND CONDITIONS 72 | 73 | 0. Definitions. 74 | 75 | "This License" refers to version 3 of the GNU General Public License. 76 | 77 | "Copyright" also means copyright-like laws that apply to other kinds of 78 | works, such as semiconductor masks. 79 | 80 | "The Program" refers to any copyrightable work licensed under this 81 | License. Each licensee is addressed as "you". "Licensees" and 82 | "recipients" may be individuals or organizations. 83 | 84 | To "modify" a work means to copy from or adapt all or part of the work 85 | in a fashion requiring copyright permission, other than the making of an 86 | exact copy. The resulting work is called a "modified version" of the 87 | earlier work or a work "based on" the earlier work. 88 | 89 | A "covered work" means either the unmodified Program or a work based 90 | on the Program. 91 | 92 | To "propagate" a work means to do anything with it that, without 93 | permission, would make you directly or secondarily liable for 94 | infringement under applicable copyright law, except executing it on a 95 | computer or modifying a private copy. Propagation includes copying, 96 | distribution (with or without modification), making available to the 97 | public, and in some countries other activities as well. 98 | 99 | To "convey" a work means any kind of propagation that enables other 100 | parties to make or receive copies. Mere interaction with a user through 101 | a computer network, with no transfer of a copy, is not conveying. 102 | 103 | An interactive user interface displays "Appropriate Legal Notices" 104 | to the extent that it includes a convenient and prominently visible 105 | feature that (1) displays an appropriate copyright notice, and (2) 106 | tells the user that there is no warranty for the work (except to the 107 | extent that warranties are provided), that licensees may convey the 108 | work under this License, and how to view a copy of this License. If 109 | the interface presents a list of user commands or options, such as a 110 | menu, a prominent item in the list meets this criterion. 111 | 112 | 1. Source Code. 113 | 114 | The "source code" for a work means the preferred form of the work 115 | for making modifications to it. "Object code" means any non-source 116 | form of a work. 117 | 118 | A "Standard Interface" means an interface that either is an official 119 | standard defined by a recognized standards body, or, in the case of 120 | interfaces specified for a particular programming language, one that 121 | is widely used among developers working in that language. 122 | 123 | The "System Libraries" of an executable work include anything, other 124 | than the work as a whole, that (a) is included in the normal form of 125 | packaging a Major Component, but which is not part of that Major 126 | Component, and (b) serves only to enable use of the work with that 127 | Major Component, or to implement a Standard Interface for which an 128 | implementation is available to the public in source code form. A 129 | "Major Component", in this context, means a major essential component 130 | (kernel, window system, and so on) of the specific operating system 131 | (if any) on which the executable work runs, or a compiler used to 132 | produce the work, or an object code interpreter used to run it. 133 | 134 | The "Corresponding Source" for a work in object code form means all 135 | the source code needed to generate, install, and (for an executable 136 | work) run the object code and to modify the work, including scripts to 137 | control those activities. However, it does not include the work's 138 | System Libraries, or general-purpose tools or generally available free 139 | programs which are used unmodified in performing those activities but 140 | which are not part of the work. For example, Corresponding Source 141 | includes interface definition files associated with source files for 142 | the work, and the source code for shared libraries and dynamically 143 | linked subprograms that the work is specifically designed to require, 144 | such as by intimate data communication or control flow between those 145 | subprograms and other parts of the work. 146 | 147 | The Corresponding Source need not include anything that users 148 | can regenerate automatically from other parts of the Corresponding 149 | Source. 150 | 151 | The Corresponding Source for a work in source code form is that 152 | same work. 153 | 154 | 2. Basic Permissions. 155 | 156 | All rights granted under this License are granted for the term of 157 | copyright on the Program, and are irrevocable provided the stated 158 | conditions are met. This License explicitly affirms your unlimited 159 | permission to run the unmodified Program. The output from running a 160 | covered work is covered by this License only if the output, given its 161 | content, constitutes a covered work. This License acknowledges your 162 | rights of fair use or other equivalent, as provided by copyright law. 163 | 164 | You may make, run and propagate covered works that you do not 165 | convey, without conditions so long as your license otherwise remains 166 | in force. You may convey covered works to others for the sole purpose 167 | of having them make modifications exclusively for you, or provide you 168 | with facilities for running those works, provided that you comply with 169 | the terms of this License in conveying all material for which you do 170 | not control copyright. Those thus making or running the covered works 171 | for you must do so exclusively on your behalf, under your direction 172 | and control, on terms that prohibit them from making any copies of 173 | your copyrighted material outside their relationship with you. 174 | 175 | Conveying under any other circumstances is permitted solely under 176 | the conditions stated below. Sublicensing is not allowed; section 10 177 | makes it unnecessary. 178 | 179 | 3. Protecting Users' Legal Rights From Anti-Circumvention Law. 180 | 181 | No covered work shall be deemed part of an effective technological 182 | measure under any applicable law fulfilling obligations under article 183 | 11 of the WIPO copyright treaty adopted on 20 December 1996, or 184 | similar laws prohibiting or restricting circumvention of such 185 | measures. 186 | 187 | When you convey a covered work, you waive any legal power to forbid 188 | circumvention of technological measures to the extent such circumvention 189 | is effected by exercising rights under this License with respect to 190 | the covered work, and you disclaim any intention to limit operation or 191 | modification of the work as a means of enforcing, against the work's 192 | users, your or third parties' legal rights to forbid circumvention of 193 | technological measures. 194 | 195 | 4. Conveying Verbatim Copies. 196 | 197 | You may convey verbatim copies of the Program's source code as you 198 | receive it, in any medium, provided that you conspicuously and 199 | appropriately publish on each copy an appropriate copyright notice; 200 | keep intact all notices stating that this License and any 201 | non-permissive terms added in accord with section 7 apply to the code; 202 | keep intact all notices of the absence of any warranty; and give all 203 | recipients a copy of this License along with the Program. 204 | 205 | You may charge any price or no price for each copy that you convey, 206 | and you may offer support or warranty protection for a fee. 207 | 208 | 5. Conveying Modified Source Versions. 209 | 210 | You may convey a work based on the Program, or the modifications to 211 | produce it from the Program, in the form of source code under the 212 | terms of section 4, provided that you also meet all of these conditions: 213 | 214 | a) The work must carry prominent notices stating that you modified 215 | it, and giving a relevant date. 216 | 217 | b) The work must carry prominent notices stating that it is 218 | released under this License and any conditions added under section 219 | 7. This requirement modifies the requirement in section 4 to 220 | "keep intact all notices". 221 | 222 | c) You must license the entire work, as a whole, under this 223 | License to anyone who comes into possession of a copy. This 224 | License will therefore apply, along with any applicable section 7 225 | additional terms, to the whole of the work, and all its parts, 226 | regardless of how they are packaged. This License gives no 227 | permission to license the work in any other way, but it does not 228 | invalidate such permission if you have separately received it. 229 | 230 | d) If the work has interactive user interfaces, each must display 231 | Appropriate Legal Notices; however, if the Program has interactive 232 | interfaces that do not display Appropriate Legal Notices, your 233 | work need not make them do so. 234 | 235 | A compilation of a covered work with other separate and independent 236 | works, which are not by their nature extensions of the covered work, 237 | and which are not combined with it such as to form a larger program, 238 | in or on a volume of a storage or distribution medium, is called an 239 | "aggregate" if the compilation and its resulting copyright are not 240 | used to limit the access or legal rights of the compilation's users 241 | beyond what the individual works permit. Inclusion of a covered work 242 | in an aggregate does not cause this License to apply to the other 243 | parts of the aggregate. 244 | 245 | 6. Conveying Non-Source Forms. 246 | 247 | You may convey a covered work in object code form under the terms 248 | of sections 4 and 5, provided that you also convey the 249 | machine-readable Corresponding Source under the terms of this License, 250 | in one of these ways: 251 | 252 | a) Convey the object code in, or embodied in, a physical product 253 | (including a physical distribution medium), accompanied by the 254 | Corresponding Source fixed on a durable physical medium 255 | customarily used for software interchange. 256 | 257 | b) Convey the object code in, or embodied in, a physical product 258 | (including a physical distribution medium), accompanied by a 259 | written offer, valid for at least three years and valid for as 260 | long as you offer spare parts or customer support for that product 261 | model, to give anyone who possesses the object code either (1) a 262 | copy of the Corresponding Source for all the software in the 263 | product that is covered by this License, on a durable physical 264 | medium customarily used for software interchange, for a price no 265 | more than your reasonable cost of physically performing this 266 | conveying of source, or (2) access to copy the 267 | Corresponding Source from a network server at no charge. 268 | 269 | c) Convey individual copies of the object code with a copy of the 270 | written offer to provide the Corresponding Source. This 271 | alternative is allowed only occasionally and noncommercially, and 272 | only if you received the object code with such an offer, in accord 273 | with subsection 6b. 274 | 275 | d) Convey the object code by offering access from a designated 276 | place (gratis or for a charge), and offer equivalent access to the 277 | Corresponding Source in the same way through the same place at no 278 | further charge. You need not require recipients to copy the 279 | Corresponding Source along with the object code. If the place to 280 | copy the object code is a network server, the Corresponding Source 281 | may be on a different server (operated by you or a third party) 282 | that supports equivalent copying facilities, provided you maintain 283 | clear directions next to the object code saying where to find the 284 | Corresponding Source. Regardless of what server hosts the 285 | Corresponding Source, you remain obligated to ensure that it is 286 | available for as long as needed to satisfy these requirements. 287 | 288 | e) Convey the object code using peer-to-peer transmission, provided 289 | you inform other peers where the object code and Corresponding 290 | Source of the work are being offered to the general public at no 291 | charge under subsection 6d. 292 | 293 | A separable portion of the object code, whose source code is excluded 294 | from the Corresponding Source as a System Library, need not be 295 | included in conveying the object code work. 296 | 297 | A "User Product" is either (1) a "consumer product", which means any 298 | tangible personal property which is normally used for personal, family, 299 | or household purposes, or (2) anything designed or sold for incorporation 300 | into a dwelling. In determining whether a product is a consumer product, 301 | doubtful cases shall be resolved in favor of coverage. For a particular 302 | product received by a particular user, "normally used" refers to a 303 | typical or common use of that class of product, regardless of the status 304 | of the particular user or of the way in which the particular user 305 | actually uses, or expects or is expected to use, the product. A product 306 | is a consumer product regardless of whether the product has substantial 307 | commercial, industrial or non-consumer uses, unless such uses represent 308 | the only significant mode of use of the product. 309 | 310 | "Installation Information" for a User Product means any methods, 311 | procedures, authorization keys, or other information required to install 312 | and execute modified versions of a covered work in that User Product from 313 | a modified version of its Corresponding Source. The information must 314 | suffice to ensure that the continued functioning of the modified object 315 | code is in no case prevented or interfered with solely because 316 | modification has been made. 317 | 318 | If you convey an object code work under this section in, or with, or 319 | specifically for use in, a User Product, and the conveying occurs as 320 | part of a transaction in which the right of possession and use of the 321 | User Product is transferred to the recipient in perpetuity or for a 322 | fixed term (regardless of how the transaction is characterized), the 323 | Corresponding Source conveyed under this section must be accompanied 324 | by the Installation Information. But this requirement does not apply 325 | if neither you nor any third party retains the ability to install 326 | modified object code on the User Product (for example, the work has 327 | been installed in ROM). 328 | 329 | The requirement to provide Installation Information does not include a 330 | requirement to continue to provide support service, warranty, or updates 331 | for a work that has been modified or installed by the recipient, or for 332 | the User Product in which it has been modified or installed. Access to a 333 | network may be denied when the modification itself materially and 334 | adversely affects the operation of the network or violates the rules and 335 | protocols for communication across the network. 336 | 337 | Corresponding Source conveyed, and Installation Information provided, 338 | in accord with this section must be in a format that is publicly 339 | documented (and with an implementation available to the public in 340 | source code form), and must require no special password or key for 341 | unpacking, reading or copying. 342 | 343 | 7. Additional Terms. 344 | 345 | "Additional permissions" are terms that supplement the terms of this 346 | License by making exceptions from one or more of its conditions. 347 | Additional permissions that are applicable to the entire Program shall 348 | be treated as though they were included in this License, to the extent 349 | that they are valid under applicable law. If additional permissions 350 | apply only to part of the Program, that part may be used separately 351 | under those permissions, but the entire Program remains governed by 352 | this License without regard to the additional permissions. 353 | 354 | When you convey a copy of a covered work, you may at your option 355 | remove any additional permissions from that copy, or from any part of 356 | it. (Additional permissions may be written to require their own 357 | removal in certain cases when you modify the work.) You may place 358 | additional permissions on material, added by you to a covered work, 359 | for which you have or can give appropriate copyright permission. 360 | 361 | Notwithstanding any other provision of this License, for material you 362 | add to a covered work, you may (if authorized by the copyright holders of 363 | that material) supplement the terms of this License with terms: 364 | 365 | a) Disclaiming warranty or limiting liability differently from the 366 | terms of sections 15 and 16 of this License; or 367 | 368 | b) Requiring preservation of specified reasonable legal notices or 369 | author attributions in that material or in the Appropriate Legal 370 | Notices displayed by works containing it; or 371 | 372 | c) Prohibiting misrepresentation of the origin of that material, or 373 | requiring that modified versions of such material be marked in 374 | reasonable ways as different from the original version; or 375 | 376 | d) Limiting the use for publicity purposes of names of licensors or 377 | authors of the material; or 378 | 379 | e) Declining to grant rights under trademark law for use of some 380 | trade names, trademarks, or service marks; or 381 | 382 | f) Requiring indemnification of licensors and authors of that 383 | material by anyone who conveys the material (or modified versions of 384 | it) with contractual assumptions of liability to the recipient, for 385 | any liability that these contractual assumptions directly impose on 386 | those licensors and authors. 387 | 388 | All other non-permissive additional terms are considered "further 389 | restrictions" within the meaning of section 10. If the Program as you 390 | received it, or any part of it, contains a notice stating that it is 391 | governed by this License along with a term that is a further 392 | restriction, you may remove that term. If a license document contains 393 | a further restriction but permits relicensing or conveying under this 394 | License, you may add to a covered work material governed by the terms 395 | of that license document, provided that the further restriction does 396 | not survive such relicensing or conveying. 397 | 398 | If you add terms to a covered work in accord with this section, you 399 | must place, in the relevant source files, a statement of the 400 | additional terms that apply to those files, or a notice indicating 401 | where to find the applicable terms. 402 | 403 | Additional terms, permissive or non-permissive, may be stated in the 404 | form of a separately written license, or stated as exceptions; 405 | the above requirements apply either way. 406 | 407 | 8. Termination. 408 | 409 | You may not propagate or modify a covered work except as expressly 410 | provided under this License. Any attempt otherwise to propagate or 411 | modify it is void, and will automatically terminate your rights under 412 | this License (including any patent licenses granted under the third 413 | paragraph of section 11). 414 | 415 | However, if you cease all violation of this License, then your 416 | license from a particular copyright holder is reinstated (a) 417 | provisionally, unless and until the copyright holder explicitly and 418 | finally terminates your license, and (b) permanently, if the copyright 419 | holder fails to notify you of the violation by some reasonable means 420 | prior to 60 days after the cessation. 421 | 422 | Moreover, your license from a particular copyright holder is 423 | reinstated permanently if the copyright holder notifies you of the 424 | violation by some reasonable means, this is the first time you have 425 | received notice of violation of this License (for any work) from that 426 | copyright holder, and you cure the violation prior to 30 days after 427 | your receipt of the notice. 428 | 429 | Termination of your rights under this section does not terminate the 430 | licenses of parties who have received copies or rights from you under 431 | this License. If your rights have been terminated and not permanently 432 | reinstated, you do not qualify to receive new licenses for the same 433 | material under section 10. 434 | 435 | 9. Acceptance Not Required for Having Copies. 436 | 437 | You are not required to accept this License in order to receive or 438 | run a copy of the Program. Ancillary propagation of a covered work 439 | occurring solely as a consequence of using peer-to-peer transmission 440 | to receive a copy likewise does not require acceptance. However, 441 | nothing other than this License grants you permission to propagate or 442 | modify any covered work. These actions infringe copyright if you do 443 | not accept this License. Therefore, by modifying or propagating a 444 | covered work, you indicate your acceptance of this License to do so. 445 | 446 | 10. Automatic Licensing of Downstream Recipients. 447 | 448 | Each time you convey a covered work, the recipient automatically 449 | receives a license from the original licensors, to run, modify and 450 | propagate that work, subject to this License. You are not responsible 451 | for enforcing compliance by third parties with this License. 452 | 453 | An "entity transaction" is a transaction transferring control of an 454 | organization, or substantially all assets of one, or subdividing an 455 | organization, or merging organizations. If propagation of a covered 456 | work results from an entity transaction, each party to that 457 | transaction who receives a copy of the work also receives whatever 458 | licenses to the work the party's predecessor in interest had or could 459 | give under the previous paragraph, plus a right to possession of the 460 | Corresponding Source of the work from the predecessor in interest, if 461 | the predecessor has it or can get it with reasonable efforts. 462 | 463 | You may not impose any further restrictions on the exercise of the 464 | rights granted or affirmed under this License. For example, you may 465 | not impose a license fee, royalty, or other charge for exercise of 466 | rights granted under this License, and you may not initiate litigation 467 | (including a cross-claim or counterclaim in a lawsuit) alleging that 468 | any patent claim is infringed by making, using, selling, offering for 469 | sale, or importing the Program or any portion of it. 470 | 471 | 11. Patents. 472 | 473 | A "contributor" is a copyright holder who authorizes use under this 474 | License of the Program or a work on which the Program is based. The 475 | work thus licensed is called the contributor's "contributor version". 476 | 477 | A contributor's "essential patent claims" are all patent claims 478 | owned or controlled by the contributor, whether already acquired or 479 | hereafter acquired, that would be infringed by some manner, permitted 480 | by this License, of making, using, or selling its contributor version, 481 | but do not include claims that would be infringed only as a 482 | consequence of further modification of the contributor version. For 483 | purposes of this definition, "control" includes the right to grant 484 | patent sublicenses in a manner consistent with the requirements of 485 | this License. 486 | 487 | Each contributor grants you a non-exclusive, worldwide, royalty-free 488 | patent license under the contributor's essential patent claims, to 489 | make, use, sell, offer for sale, import and otherwise run, modify and 490 | propagate the contents of its contributor version. 491 | 492 | In the following three paragraphs, a "patent license" is any express 493 | agreement or commitment, however denominated, not to enforce a patent 494 | (such as an express permission to practice a patent or covenant not to 495 | sue for patent infringement). To "grant" such a patent license to a 496 | party means to make such an agreement or commitment not to enforce a 497 | patent against the party. 498 | 499 | If you convey a covered work, knowingly relying on a patent license, 500 | and the Corresponding Source of the work is not available for anyone 501 | to copy, free of charge and under the terms of this License, through a 502 | publicly available network server or other readily accessible means, 503 | then you must either (1) cause the Corresponding Source to be so 504 | available, or (2) arrange to deprive yourself of the benefit of the 505 | patent license for this particular work, or (3) arrange, in a manner 506 | consistent with the requirements of this License, to extend the patent 507 | license to downstream recipients. "Knowingly relying" means you have 508 | actual knowledge that, but for the patent license, your conveying the 509 | covered work in a country, or your recipient's use of the covered work 510 | in a country, would infringe one or more identifiable patents in that 511 | country that you have reason to believe are valid. 512 | 513 | If, pursuant to or in connection with a single transaction or 514 | arrangement, you convey, or propagate by procuring conveyance of, a 515 | covered work, and grant a patent license to some of the parties 516 | receiving the covered work authorizing them to use, propagate, modify 517 | or convey a specific copy of the covered work, then the patent license 518 | you grant is automatically extended to all recipients of the covered 519 | work and works based on it. 520 | 521 | A patent license is "discriminatory" if it does not include within 522 | the scope of its coverage, prohibits the exercise of, or is 523 | conditioned on the non-exercise of one or more of the rights that are 524 | specifically granted under this License. You may not convey a covered 525 | work if you are a party to an arrangement with a third party that is 526 | in the business of distributing software, under which you make payment 527 | to the third party based on the extent of your activity of conveying 528 | the work, and under which the third party grants, to any of the 529 | parties who would receive the covered work from you, a discriminatory 530 | patent license (a) in connection with copies of the covered work 531 | conveyed by you (or copies made from those copies), or (b) primarily 532 | for and in connection with specific products or compilations that 533 | contain the covered work, unless you entered into that arrangement, 534 | or that patent license was granted, prior to 28 March 2007. 535 | 536 | Nothing in this License shall be construed as excluding or limiting 537 | any implied license or other defenses to infringement that may 538 | otherwise be available to you under applicable patent law. 539 | 540 | 12. No Surrender of Others' Freedom. 541 | 542 | If conditions are imposed on you (whether by court order, agreement or 543 | otherwise) that contradict the conditions of this License, they do not 544 | excuse you from the conditions of this License. If you cannot convey a 545 | covered work so as to satisfy simultaneously your obligations under this 546 | License and any other pertinent obligations, then as a consequence you may 547 | not convey it at all. For example, if you agree to terms that obligate you 548 | to collect a royalty for further conveying from those to whom you convey 549 | the Program, the only way you could satisfy both those terms and this 550 | License would be to refrain entirely from conveying the Program. 551 | 552 | 13. Use with the GNU Affero General Public License. 553 | 554 | Notwithstanding any other provision of this License, you have 555 | permission to link or combine any covered work with a work licensed 556 | under version 3 of the GNU Affero General Public License into a single 557 | combined work, and to convey the resulting work. The terms of this 558 | License will continue to apply to the part which is the covered work, 559 | but the special requirements of the GNU Affero General Public License, 560 | section 13, concerning interaction through a network will apply to the 561 | combination as such. 562 | 563 | 14. Revised Versions of this License. 564 | 565 | The Free Software Foundation may publish revised and/or new versions of 566 | the GNU General Public License from time to time. Such new versions will 567 | be similar in spirit to the present version, but may differ in detail to 568 | address new problems or concerns. 569 | 570 | Each version is given a distinguishing version number. If the 571 | Program specifies that a certain numbered version of the GNU General 572 | Public License "or any later version" applies to it, you have the 573 | option of following the terms and conditions either of that numbered 574 | version or of any later version published by the Free Software 575 | Foundation. If the Program does not specify a version number of the 576 | GNU General Public License, you may choose any version ever published 577 | by the Free Software Foundation. 578 | 579 | If the Program specifies that a proxy can decide which future 580 | versions of the GNU General Public License can be used, that proxy's 581 | public statement of acceptance of a version permanently authorizes you 582 | to choose that version for the Program. 583 | 584 | Later license versions may give you additional or different 585 | permissions. However, no additional obligations are imposed on any 586 | author or copyright holder as a result of your choosing to follow a 587 | later version. 588 | 589 | 15. Disclaimer of Warranty. 590 | 591 | THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY 592 | APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT 593 | HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY 594 | OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, 595 | THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR 596 | PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM 597 | IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF 598 | ALL NECESSARY SERVICING, REPAIR OR CORRECTION. 599 | 600 | 16. Limitation of Liability. 601 | 602 | IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING 603 | WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MODIFIES AND/OR CONVEYS 604 | THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY 605 | GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE 606 | USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF 607 | DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD 608 | PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), 609 | EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF 610 | SUCH DAMAGES. 611 | 612 | 17. Interpretation of Sections 15 and 16. 613 | 614 | If the disclaimer of warranty and limitation of liability provided 615 | above cannot be given local legal effect according to their terms, 616 | reviewing courts shall apply local law that most closely approximates 617 | an absolute waiver of all civil liability in connection with the 618 | Program, unless a warranty or assumption of liability accompanies a 619 | copy of the Program in return for a fee. 620 | 621 | END OF TERMS AND CONDITIONS 622 | 623 | How to Apply These Terms to Your New Programs 624 | 625 | If you develop a new program, and you want it to be of the greatest 626 | possible use to the public, the best way to achieve this is to make it 627 | free software which everyone can redistribute and change under these terms. 628 | 629 | To do so, attach the following notices to the program. It is safest 630 | to attach them to the start of each source file to most effectively 631 | state the exclusion of warranty; and each file should have at least 632 | the "copyright" line and a pointer to where the full notice is found. 633 | 634 | {one line to give the program's name and a brief idea of what it does.} 635 | Copyright (C) {year} {name of author} 636 | 637 | This program is free software: you can redistribute it and/or modify 638 | it under the terms of the GNU General Public License as published by 639 | the Free Software Foundation, either version 3 of the License, or 640 | (at your option) any later version. 641 | 642 | This program is distributed in the hope that it will be useful, 643 | but WITHOUT ANY WARRANTY; without even the implied warranty of 644 | MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 645 | GNU General Public License for more details. 646 | 647 | You should have received a copy of the GNU General Public License 648 | along with this program. If not, see . 649 | 650 | Also add information on how to contact you by electronic and paper mail. 651 | 652 | If the program does terminal interaction, make it output a short 653 | notice like this when it starts in an interactive mode: 654 | 655 | {project} Copyright (C) {year} {fullname} 656 | This program comes with ABSOLUTELY NO WARRANTY; for details type `show w'. 657 | This is free software, and you are welcome to redistribute it 658 | under certain conditions; type `show c' for details. 659 | 660 | The hypothetical commands `show w' and `show c' should show the appropriate 661 | parts of the General Public License. Of course, your program's commands 662 | might be different; for a GUI interface, you would use an "about box". 663 | 664 | You should also get your employer (if you work as a programmer) or school, 665 | if any, to sign a "copyright disclaimer" for the program, if necessary. 666 | For more information on this, and how to apply and follow the GNU GPL, see 667 | . 668 | 669 | The GNU General Public License does not permit incorporating your program 670 | into proprietary programs. If your program is a subroutine library, you 671 | may consider it more useful to permit linking proprietary applications with 672 | the library. If this is what you want to do, use the GNU Lesser General 673 | Public License instead of this License. But first, please read 674 | . 675 | -------------------------------------------------------------------------------- /Noise.h: -------------------------------------------------------------------------------- 1 | /* 2 | * Torch: https://github.com/evilgeniuslabs/torch 3 | * Copyright (C) 2015 Jason Coon 4 | * 5 | * This program is free software: you can redistribute it and/or modify 6 | * it under the terms of the GNU General Public License as published by 7 | * the Free Software Foundation, either version 3 of the License, or 8 | * (at your option) any later version. 9 | * 10 | * This program is distributed in the hope that it will be useful, 11 | * but WITHOUT ANY WARRANTY; without even the implied warranty of 12 | * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 13 | * GNU General Public License for more details. 14 | * 15 | * You should have received a copy of the GNU General Public License 16 | * along with this program. If not, see . 17 | */ 18 | 19 | #define MAX_DIMENSION ((MATRIX_WIDTH > MATRIX_HEIGHT) ? MATRIX_WIDTH : MATRIX_HEIGHT) 20 | 21 | // The 16 bit version of our coordinates 22 | static uint16_t noisex; 23 | static uint16_t noisey; 24 | static uint16_t noisez; 25 | 26 | // We're using the x/y dimensions to map to the x/y pixels on the matrix. We'll 27 | // use the z-axis for "time". speed determines how fast time moves forward. Try 28 | // 1 for a very slow moving effect, or 60 for something that ends up looking like 29 | // water. 30 | uint32_t noisespeedx = 1; 31 | uint32_t noisespeedy = 1; 32 | uint32_t noisespeedz = 1; 33 | 34 | // Scale determines how far apart the pixels in our noise matrix are. Try 35 | // changing these values around to see how it affects the motion of the display. The 36 | // higher the value of scale, the more "zoomed out" the noise will be. A value 37 | // of 1 will be so zoomed in, you'll mostly see solid colors. 38 | uint16_t noisescale = 30; // scale is set dynamically once we've started up 39 | 40 | // This is the array that we keep our computed noise values in 41 | uint8_t noise[MAX_DIMENSION][MAX_DIMENSION]; 42 | 43 | uint8_t colorLoop = 0; 44 | 45 | CRGBPalette16 blackAndWhiteStripedPalette; 46 | 47 | // This function sets up a palette of black and white stripes, 48 | // using code. Since the palette is effectively an array of 49 | // sixteen CRGB colors, the various fill_* functions can be used 50 | // to set them up. 51 | void SetupBlackAndWhiteStripedPalette() 52 | { 53 | // 'black out' all 16 palette entries... 54 | fill_solid( blackAndWhiteStripedPalette, 16, CRGB::Black); 55 | // and set every fourth one to white. 56 | blackAndWhiteStripedPalette[0] = CRGB::White; 57 | blackAndWhiteStripedPalette[4] = CRGB::White; 58 | blackAndWhiteStripedPalette[8] = CRGB::White; 59 | blackAndWhiteStripedPalette[12] = CRGB::White; 60 | 61 | } 62 | 63 | CRGBPalette16 blackAndBlueStripedPalette; 64 | 65 | // This function sets up a palette of black and blue stripes, 66 | // using code. Since the palette is effectively an array of 67 | // sixteen CRGB colors, the various fill_* functions can be used 68 | // to set them up. 69 | void SetupBlackAndBlueStripedPalette() 70 | { 71 | // 'black out' all 16 palette entries... 72 | fill_solid( blackAndBlueStripedPalette, 16, CRGB::Black); 73 | 74 | for(uint8_t i = 0; i < 6; i++) { 75 | blackAndBlueStripedPalette[i] = CRGB::Blue; 76 | } 77 | } 78 | 79 | // There are several different palettes of colors demonstrated here. 80 | // 81 | // FastLED provides several 'preset' palettes: RainbowColors_p, RainbowStripeColors_p, 82 | // OceanColors_p, CloudColors_p, LavaColors_p, ForestColors_p, and PartyColors_p. 83 | // 84 | // Additionally, you can manually define your own color palettes, or you can write 85 | // code that creates color palettes on the fly. 86 | 87 | boolean initialized = false; 88 | 89 | // Fill the x/y array of 8-bit noise values using the inoise8 function. 90 | void fillnoise8() { 91 | 92 | if(!initialized) { 93 | initialized = true; 94 | // Initialize our coordinates to some random values 95 | noisex = random16(); 96 | noisey = random16(); 97 | noisez = random16(); 98 | } 99 | 100 | // If we're runing at a low "speed", some 8-bit artifacts become visible 101 | // from frame-to-frame. In order to reduce this, we can do some fast data-smoothing. 102 | // The amount of data smoothing we're doing depends on "speed". 103 | uint8_t dataSmoothing = 0; 104 | uint16_t lowestNoise = noisespeedx < noisespeedy ? noisespeedx : noisespeedy; 105 | lowestNoise = lowestNoise < noisespeedz ? lowestNoise : noisespeedz; 106 | if( lowestNoise < 8) { 107 | dataSmoothing = 200 - (lowestNoise * 4); 108 | } 109 | 110 | for(int i = 0; i < MAX_DIMENSION; i++) { 111 | int ioffset = noisescale * i; 112 | for(int j = 0; j < MAX_DIMENSION; j++) { 113 | int joffset = noisescale * j; 114 | 115 | uint8_t data = inoise8(noisex + ioffset, noisey + joffset, noisez); 116 | 117 | // The range of the inoise8 function is roughly 16-238. 118 | // These two operations expand those values out to roughly 0..255 119 | // You can comment them out if you want the raw noise data. 120 | data = qsub8(data,16); 121 | data = qadd8(data,scale8(data,39)); 122 | 123 | if( dataSmoothing ) { 124 | uint8_t olddata = noise[i][j]; 125 | uint8_t newdata = scale8( olddata, dataSmoothing) + scale8( data, 256 - dataSmoothing); 126 | data = newdata; 127 | } 128 | 129 | noise[i][j] = data; 130 | } 131 | } 132 | 133 | noisex += noisespeedx; 134 | noisey += noisespeedy; 135 | noisez += noisespeedz; 136 | } 137 | 138 | void mapNoiseToLEDsUsingPalette(CRGBPalette16 palette, uint8_t hueReduce = 0) 139 | { 140 | static uint8_t ihue=0; 141 | 142 | for(int i = 0; i < MATRIX_WIDTH; i++) { 143 | for(int j = 0; j < MATRIX_HEIGHT; j++) { 144 | // We use the value at the (i,j) coordinate in the noise 145 | // array for our brightness, and the flipped value from (j,i) 146 | // for our pixel's index into the color palette. 147 | 148 | uint8_t index = noise[j][i]; 149 | uint8_t bri = noise[i][j]; 150 | 151 | // if this palette is a 'loop', add a slowly-changing base value 152 | if( colorLoop) { 153 | index += ihue; 154 | } 155 | 156 | // brighten up, as the color palette itself often contains the 157 | // light/dark dynamic range desired 158 | if( bri > 127 ) { 159 | bri = 255; 160 | } else { 161 | bri = dim8_raw( bri * 2); 162 | } 163 | 164 | if(hueReduce > 0) { 165 | if(index < hueReduce) index = 0; 166 | else index -= hueReduce; 167 | } 168 | 169 | CRGB color = ColorFromPalette( palette, index, bri); 170 | uint16_t n = XY(i, j); 171 | 172 | leds[n] = color; 173 | } 174 | } 175 | 176 | ihue+=1; 177 | } 178 | 179 | uint16_t drawNoise(CRGBPalette16 palette,uint8_t hueReduce = 0) { 180 | // generate noise data 181 | fillnoise8(); 182 | 183 | // convert the noise data to colors in the LED array 184 | // using the current palette 185 | mapNoiseToLEDsUsingPalette(palette, hueReduce); 186 | 187 | return 10; 188 | } 189 | 190 | uint16_t rainbowNoise() { 191 | noisespeedx = 9; 192 | noisespeedy = 0; 193 | noisespeedz = 0; 194 | noisescale = 30; 195 | colorLoop = 0; 196 | return drawNoise(RainbowColors_p); 197 | } 198 | 199 | uint16_t rainbowStripeNoise() { 200 | noisespeedx = 9; 201 | noisespeedy = 0; 202 | noisespeedz = 0; 203 | noisescale = 20; 204 | colorLoop = 0; 205 | return drawNoise(RainbowStripeColors_p); 206 | } 207 | 208 | uint16_t partyNoise() { 209 | noisespeedx = 9; 210 | noisespeedy = 0; 211 | noisespeedz = 0; 212 | noisescale = 30; 213 | colorLoop = 0; 214 | return drawNoise(PartyColors_p); 215 | } 216 | 217 | uint16_t forestNoise() { 218 | noisespeedx = 9; 219 | noisespeedy = 0; 220 | noisespeedz = 0; 221 | noisescale = 120; 222 | colorLoop = 0; 223 | return drawNoise(ForestColors_p); 224 | } 225 | 226 | uint16_t cloudNoise() { 227 | noisespeedx = 9; 228 | noisespeedy = 0; 229 | noisespeedz = 0; 230 | noisescale = 30; 231 | colorLoop = 0; 232 | return drawNoise(CloudColors_p); 233 | } 234 | 235 | uint16_t fireNoise() { 236 | noisespeedx = 8; // 24; 237 | noisespeedy = 0; 238 | noisespeedz = 8; 239 | noisescale = 50; 240 | colorLoop = 0; 241 | return drawNoise(HeatColors_p, 60); 242 | } 243 | 244 | uint16_t lavaNoise() { 245 | noisespeedx = 32; 246 | noisespeedy = 0; 247 | noisespeedz = 16; 248 | noisescale = 50; 249 | colorLoop = 0; 250 | return drawNoise(LavaColors_p); 251 | } 252 | 253 | uint16_t oceanNoise() { 254 | noisespeedx = 9; 255 | noisespeedy = 0; 256 | noisespeedz = 0; 257 | noisescale = 90; 258 | colorLoop = 0; 259 | return drawNoise(OceanColors_p); 260 | } 261 | 262 | uint16_t blackAndWhiteNoise() { 263 | SetupBlackAndWhiteStripedPalette(); 264 | noisespeedx = 9; 265 | noisespeedy = 0; 266 | noisespeedz = 0; 267 | noisescale = 30; 268 | colorLoop = 0; 269 | return drawNoise(blackAndWhiteStripedPalette); 270 | } 271 | 272 | uint16_t blackAndBlueNoise() { 273 | SetupBlackAndBlueStripedPalette(); 274 | noisespeedx = 9; 275 | noisespeedy = 0; 276 | noisespeedz = 0; 277 | noisescale = 30; 278 | colorLoop = 0; 279 | return drawNoise(blackAndBlueStripedPalette); 280 | } 281 | -------------------------------------------------------------------------------- /Pulse.h: -------------------------------------------------------------------------------- 1 | /* 2 | * Torch: https://github.com/evilgeniuslabs/torch 3 | * Copyright (C) 2015 Jason Coon 4 | * 5 | * This program is free software: you can redistribute it and/or modify 6 | * it under the terms of the GNU General Public License as published by 7 | * the Free Software Foundation, either version 3 of the License, or 8 | * (at your option) any later version. 9 | * 10 | * This program is distributed in the hope that it will be useful, 11 | * but WITHOUT ANY WARRANTY; without even the implied warranty of 12 | * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 13 | * GNU General Public License for more details. 14 | * 15 | * You should have received a copy of the GNU General Public License 16 | * along with this program. If not, see . 17 | */ 18 | 19 | uint16_t pulse() { 20 | // palette = RainbowColors_p; 21 | 22 | static uint8_t hue = 0; 23 | static uint8_t centerX = 0; 24 | static uint8_t centerY = 0; 25 | static uint8_t step = 0; 26 | 27 | static const uint8_t maxSteps = 16; 28 | static const float fadeRate = 0.8; 29 | 30 | dimAll(235); 31 | 32 | if (step == 0) { 33 | centerX = random(32); 34 | centerY = random(32); 35 | hue = random(256); // 170; 36 | 37 | drawCircle(centerX, centerY, step, ColorFromPalette(palette, hue)); 38 | step++; 39 | } 40 | else { 41 | if (step < maxSteps) { 42 | // initial pulse 43 | drawCircle(centerX, centerY, step, ColorFromPalette(palette, hue, pow(fadeRate, step - 2) * 255)); 44 | 45 | // secondary pulse 46 | if (step > 3) { 47 | drawCircle(centerX, centerY, step - 3, ColorFromPalette(palette, hue, pow(fadeRate, step - 2) * 255)); 48 | } 49 | step++; 50 | } 51 | else { 52 | step = 0; 53 | } 54 | } 55 | 56 | return 30; 57 | } 58 | -------------------------------------------------------------------------------- /README.md: -------------------------------------------------------------------------------- 1 | # Torch 2 | Cylindrical light art display. 3 | 4 | [v2 Demo Video](https://youtu.be/FigdmlocAUE?list=PLUYGVM-2vDxK88TIxaxSD_qWTSBVVwPWg): 5 | 6 | [![v2 Demo Video](http://img.youtube.com/vi/FigdmlocAUE/0.jpg)](https://youtu.be/FigdmlocAUE?list=PLUYGVM-2vDxK88TIxaxSD_qWTSBVVwPWg) 7 | 8 | [v1 Demo Video](https://www.youtube.com/watch?v=MlNcL1obSB0): 9 | 10 | [![v1 Demo Video](http://img.youtube.com/vi/MlNcL1obSB0/0.jpg)](https://www.youtube.com/watch?v=MlNcL1obSB0) 11 | 12 | Available from Evil Genius Labs: http://www.evilgeniuslabs.org 13 | 14 | Cylindrical, music-reactive light art display, built with 240 WS2812B RGB LEDs, controlled with a Particle Photon or Teensy, using the FastLED library. 15 | 16 | Controlled via an app or webpage over Wi-Fi, and/or a wireless infrared remote control. 17 | 18 | Comes with over 20 patterns built-in. 19 | 20 | Programmable over Wi-Fi or micro USB cable. 21 | 22 | Firmware and all patterns are fully open-source. 23 | -------------------------------------------------------------------------------- /Torch.h: -------------------------------------------------------------------------------- 1 | // Slightly modified version of the fire pattern from MessageTorch by Lukas Zeller: 2 | // https://github.com/plan44/messagetorch 3 | 4 | // The MIT License (MIT) 5 | 6 | // Copyright (c) 2014 Lukas Zeller 7 | 8 | // Permission is hereby granted, free of charge, to any person obtaining a copy of 9 | // this software and associated documentation files (the "Software"), to deal in 10 | // the Software without restriction, including without limitation the rights to 11 | // use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of 12 | // the Software, and to permit persons to whom the Software is furnished to do so, 13 | // subject to the following conditions: 14 | 15 | // The above copyright notice and this permission notice shall be included in all 16 | // copies or substantial portions of the Software. 17 | 18 | // THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR 19 | // IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS 20 | // FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR 21 | // COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER 22 | // IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN 23 | // CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE. 24 | 25 | // torch parameters 26 | 27 | uint16_t cycle_wait = 1; // 0..255 28 | 29 | byte flame_min = 100; // 0..255 30 | byte flame_max = 220; // 0..255 31 | 32 | byte random_spark_probability = 2; // 0..100 33 | byte spark_min = 200; // 0..255 34 | byte spark_max = 255; // 0..255 35 | 36 | byte spark_tfr = 40; // 0..256 how much energy is transferred up for a spark per cycle 37 | uint16_t spark_cap = 200; // 0..255: spark cells: how much energy is retained from previous cycle 38 | 39 | uint16_t up_rad = 40; // up radiation 40 | uint16_t side_rad = 35; // sidewards radiation 41 | uint16_t heat_cap = 0; // 0..255: passive cells: how much energy is retained from previous cycle 42 | 43 | byte red_bg = 0; 44 | byte green_bg = 0; 45 | byte blue_bg = 0; 46 | byte red_bias = 10; 47 | byte green_bias = 0; 48 | byte blue_bias = 0; 49 | int red_energy = 180; 50 | int green_energy = 20; // 145; 51 | int blue_energy = 0; 52 | 53 | byte upside_down = 0; // if set, flame (or rather: drop) animation is upside down. Text remains as-is 54 | 55 | // torch mode 56 | // ========== 57 | 58 | #define numLeds NUM_LEDS 59 | #define ledsPerLevel MATRIX_WIDTH 60 | #define levels MATRIX_HEIGHT 61 | 62 | byte currentEnergy[numLeds]; // current energy level 63 | byte nextEnergy[numLeds]; // next energy level 64 | byte energyMode[numLeds]; // mode how energy is calculated for this point 65 | 66 | enum { 67 | torch_passive = 0, // just environment, glow from nearby radiation 68 | torch_nop = 1, // no processing 69 | torch_spark = 2, // slowly looses energy, moves up 70 | torch_spark_temp = 3, // a spark still getting energy from the level below 71 | }; 72 | 73 | inline void reduce(byte &aByte, byte aAmount, byte aMin = 0) 74 | { 75 | int r = aByte-aAmount; 76 | if (raMax) 87 | aByte = aMax; 88 | else 89 | aByte = (byte)r; 90 | } 91 | 92 | uint16_t random2(uint16_t aMinOrMax, uint16_t aMax = 0) 93 | { 94 | if (aMax==0) { 95 | aMax = aMinOrMax; 96 | aMinOrMax = 0; 97 | } 98 | uint32_t r = aMinOrMax; 99 | aMax = aMax - aMinOrMax + 1; 100 | r += rand() % aMax; 101 | return r; 102 | } 103 | 104 | void resetEnergy() 105 | { 106 | for (int i=0; i>8; 140 | // this cell becomes active spark 141 | energyMode[i] = torch_spark; 142 | } 143 | else { 144 | increase(e, spark_tfr); 145 | } 146 | break; 147 | } 148 | case torch_passive: { 149 | e = ((int)e*heat_cap)>>8; 150 | increase(e, ((((int)currentEnergy[i-1]+(int)currentEnergy[i+1])*side_rad)>>9) + (((int)currentEnergy[i-ledsPerLevel]*up_rad)>>8)); 151 | } 152 | default: 153 | break; 154 | } 155 | nextEnergy[i++] = e; 156 | } 157 | } 158 | } 159 | 160 | const uint8_t energymap[32] = {0, 64, 96, 112, 128, 144, 152, 160, 168, 176, 184, 184, 192, 200, 200, 208, 208, 216, 216, 224, 224, 224, 232, 232, 232, 240, 240, 240, 240, 248, 248, 248}; 161 | 162 | void calcNextColors() 163 | { 164 | for (int i=0; i250) 173 | leds[i] = CRGB(170, 170, e); // blueish extra-bright spark 174 | else { 175 | if (e>0) { 176 | // energy to brightness is non-linear 177 | byte eb = energymap[e>>3]; 178 | byte r = red_bias; 179 | byte g = green_bias; 180 | byte b = blue_bias; 181 | increase(r, (eb*red_energy)>>8); 182 | increase(g, (eb*green_energy)>>8); 183 | increase(b, (eb*blue_energy)>>8); 184 | leds[i] = CRGB(r, g, b); 185 | } 186 | else { 187 | // background, no energy 188 | leds[i] = CRGB(red_bg, green_bg, blue_bg); 189 | } 190 | } 191 | } 192 | } 193 | 194 | void injectRandom() 195 | { 196 | // random flame energy at bottom row 197 | for (int i=0; i. 17 | */ 18 | 19 | uint16_t wave() { 20 | static byte rotation = 3; 21 | 22 | static const uint8_t scaleWidth = 256 / MATRIX_WIDTH; 23 | static const uint8_t scaleHeight = 256 / MATRIX_HEIGHT; 24 | 25 | static const uint8_t maxX = MATRIX_WIDTH - 1; 26 | static const uint8_t maxY = MATRIX_HEIGHT - 1; 27 | 28 | static uint8_t waveCount = 1; 29 | static uint8_t hue = 1; 30 | static uint8_t theta = 0; 31 | 32 | // EVERY_N_SECONDS(10) { 33 | // rotation = random(0, 1); 34 | // waveCount = random(1, 3); 35 | // } 36 | 37 | int n = 0; 38 | 39 | switch (rotation) { 40 | case 0: 41 | for (int x = 0; x < MATRIX_WIDTH; x++) { 42 | n = quadwave8(x * 2 + theta) / scaleHeight; 43 | leds[XY(x, n)] = ColorFromPalette(palette, x + hue); 44 | if (waveCount == 2) 45 | leds[XY(x, maxY - n)] = ColorFromPalette(palette, x + hue); 46 | } 47 | break; 48 | 49 | case 1: 50 | for (int y = 0; y < MATRIX_HEIGHT; y++) { 51 | n = quadwave8(y * 2 + theta) / scaleWidth; 52 | leds[XY(n, y)] = ColorFromPalette(palette, y + hue); 53 | if (waveCount == 2) 54 | leds[XY(maxX - n, y)] = ColorFromPalette(palette, y + hue); 55 | } 56 | break; 57 | 58 | case 2: 59 | for (int x = 0; x < MATRIX_WIDTH; x++) { 60 | n = quadwave8(x * 2 - theta) / scaleHeight; 61 | leds[XY(x, n)] = ColorFromPalette(palette, x + hue); 62 | if (waveCount == 2) 63 | leds[XY(x, maxY - n)] = ColorFromPalette(palette, x + hue); 64 | } 65 | break; 66 | 67 | case 3: 68 | for (int y = 0; y < MATRIX_HEIGHT; y++) { 69 | n = quadwave8(y * 2 - theta) / scaleWidth; 70 | leds[XY(n, y)] = ColorFromPalette(palette, y + hue); 71 | if (waveCount == 2) 72 | leds[XY(maxX - n, y)] = ColorFromPalette(palette, y + hue); 73 | } 74 | break; 75 | } 76 | 77 | dimAll(254); 78 | 79 | EVERY_N_MILLISECONDS(10) { 80 | theta++; 81 | hue++; 82 | } 83 | 84 | return 0; 85 | } 86 | -------------------------------------------------------------------------------- /torch.ino: -------------------------------------------------------------------------------- 1 | /* 2 | * Torch: https://github.com/evilgeniuslabs/torch 3 | * Copyright (C) 2015 Jason Coon 4 | * 5 | * This program is free software: you can redistribute it and/or modify 6 | * it under the terms of the GNU General Public License as published by 7 | * the Free Software Foundation, either version 3 of the License, or 8 | * (at your option) any later version. 9 | * 10 | * This program is distributed in the hope that it will be useful, 11 | * but WITHOUT ANY WARRANTY; without even the implied warranty of 12 | * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 13 | * GNU General Public License for more details. 14 | * 15 | * You should have received a copy of the GNU General Public License 16 | * along with this program. If not, see . 17 | */ 18 | 19 | #include 20 | #include 21 | #include 22 | #include 23 | 24 | #if FASTLED_VERSION < 3001000 25 | #error "Requires FastLED 3.1 or later; check github for latest code." 26 | #endif 27 | 28 | #define LED_PIN 11 29 | #define IR_RECV_PIN 12 30 | #define COLOR_ORDER GRB 31 | #define CHIPSET WS2812B 32 | #define NUM_LEDS 240 33 | 34 | const uint8_t MATRIX_WIDTH = 14; 35 | const uint8_t MATRIX_HEIGHT = 17; 36 | 37 | const int MATRIX_CENTER_X = MATRIX_WIDTH / 2; 38 | const int MATRIX_CENTER_Y = MATRIX_HEIGHT / 2; 39 | 40 | const byte MATRIX_CENTRE_X = MATRIX_CENTER_X - 1; 41 | const byte MATRIX_CENTRE_Y = MATRIX_CENTER_Y - 1; 42 | 43 | const uint8_t brightnessCount = 5; 44 | uint8_t brightnessMap[brightnessCount] = { 16, 32, 64, 128, 255 }; 45 | uint8_t brightness = brightnessMap[0]; 46 | 47 | CRGB leds[NUM_LEDS + 1]; 48 | IRrecv irReceiver(IR_RECV_PIN); 49 | 50 | #define BUTTON_1_PIN 16 51 | #define BUTTON_2_PIN 17 52 | 53 | Bounce button1 = Bounce(); 54 | Bounce button2 = Bounce(); 55 | 56 | #include "Commands.h" 57 | #include "GradientPalettes.h" 58 | 59 | CRGB solidColor = CRGB::White; 60 | 61 | typedef uint16_t(*PatternFunctionPointer)(); 62 | typedef PatternFunctionPointer PatternList []; 63 | #define ARRAY_SIZE(A) (sizeof(A) / sizeof((A)[0])) 64 | 65 | int autoPlayDurationSeconds = 10; 66 | unsigned int autoPlayTimout = 0; 67 | bool autoplayEnabled = false; 68 | 69 | InputCommand command; 70 | 71 | int currentPatternIndex = 0; 72 | PatternFunctionPointer currentPattern; 73 | 74 | CRGB w(85, 85, 85), W(CRGB::White); 75 | CRGBPalette16 snowColors = CRGBPalette16( W, W, W, W, w, w, w, w, w, w, w, w, w, w, w, w ); 76 | 77 | CRGB l(0xE1A024); 78 | CRGBPalette16 incandescentColors = CRGBPalette16( l, l, l, l, l, l, l, l, l, l, l, l, l, l, l, l ); 79 | 80 | const CRGBPalette16 palettes[] = { 81 | RainbowColors_p, 82 | RainbowStripeColors_p, 83 | OceanColors_p, 84 | CloudColors_p, 85 | ForestColors_p, 86 | PartyColors_p, 87 | HeatColors_p, 88 | LavaColors_p, 89 | snowColors, 90 | }; 91 | 92 | const int paletteCount = ARRAY_SIZE(palettes); 93 | 94 | int currentPaletteIndex = 0; 95 | CRGBPalette16 palette = palettes[0]; 96 | 97 | uint8_t gHue = 0; // rotating "base color" used by many of the patterns 98 | 99 | #include "Drawing.h" 100 | #include "Effects.h" 101 | 102 | #include "Noise.h" 103 | #include "Pulse.h" 104 | #include "Wave.h" 105 | #include "Fire2012WithPalette.h" 106 | #include "Torch.h" 107 | #include "AudioLogic.h" 108 | #include "AudioPatterns.h" 109 | 110 | const PatternList patterns = { 111 | analyzerColumns, 112 | analyzerColumnsSolid, 113 | analyzerPixels, 114 | fallingSpectrogram, 115 | audioFire, 116 | rainbowAudioNoise, 117 | rainbowStripeAudioNoise, 118 | partyAudioNoise, 119 | forestAudioNoise, 120 | cloudAudioNoise, 121 | fireAudioNoise, 122 | lavaAudioNoise, 123 | oceanAudioNoise, 124 | blackAndWhiteAudioNoise, 125 | blackAndBlueAudioNoise, 126 | fireNoise, 127 | lavaNoise, 128 | torch, 129 | fire2012WithPalette, 130 | rainbowNoise, 131 | rainbowStripeNoise, 132 | partyNoise, 133 | forestNoise, 134 | cloudNoise, 135 | oceanNoise, 136 | blackAndWhiteNoise, 137 | blackAndBlueNoise, 138 | pulse, 139 | wave, 140 | pride, 141 | colorWaves, 142 | rainbow, 143 | rainbowWithGlitter, 144 | confetti, 145 | bpm, 146 | juggle, 147 | sinelon, 148 | hueCycle, 149 | rainbowTwinkles, 150 | snowTwinkles, 151 | cloudTwinkles, 152 | incandescentTwinkles, 153 | fireflies, 154 | showSolidColor 155 | }; 156 | 157 | const int patternCount = ARRAY_SIZE(patterns); 158 | 159 | void setup() { 160 | delay(500); // sanity delay 161 | // Serial.begin(9600); 162 | // Serial.println("setup start"); 163 | 164 | loadSettings(); 165 | 166 | FastLED.addLeds(leds, NUM_LEDS); 167 | FastLED.setCorrection(TypicalLEDStrip); 168 | FastLED.setBrightness(brightness); 169 | // FastLED.setDither(false); 170 | FastLED.setDither(brightness < 255); 171 | 172 | // Initialize the IR receiver 173 | irReceiver.enableIRIn(); 174 | irReceiver.blink13(true); 175 | 176 | pinMode(BUTTON_1_PIN, INPUT_PULLUP); 177 | pinMode(BUTTON_2_PIN, INPUT_PULLUP); 178 | button1.attach(BUTTON_1_PIN); 179 | button2.attach(BUTTON_2_PIN); 180 | button1.interval(5); 181 | button2.interval(5); 182 | 183 | currentPattern = patterns[currentPatternIndex]; 184 | 185 | autoPlayTimout = millis() + (autoPlayDurationSeconds * 1000); 186 | 187 | initializeAudio(); 188 | 189 | // Serial.println("setup end"); 190 | } 191 | 192 | void loop() { 193 | // Add entropy to random number generator; we use a lot of it. 194 | random16_add_entropy(random()); 195 | 196 | EVERY_N_MILLISECONDS(30) { 197 | readAudio(); 198 | } 199 | 200 | uint16_t requestedDelay = currentPattern(); 201 | 202 | FastLED.show(); // display this frame 203 | 204 | handleInput(requestedDelay); 205 | 206 | if (autoplayEnabled && millis() > autoPlayTimout) { 207 | move(1); 208 | autoPlayTimout = millis() + (autoPlayDurationSeconds * 1000); 209 | } 210 | 211 | // do some periodic updates 212 | EVERY_N_MILLISECONDS(20) { 213 | gHue++; // slowly cycle the "base color" through the rainbow 214 | } 215 | } 216 | 217 | void loadSettings() { 218 | // load settings from EEPROM 219 | 220 | // brightness 221 | brightness = EEPROM.read(0); 222 | if (brightness < 1) 223 | brightness = 1; 224 | else if (brightness > 255) 225 | brightness = 255; 226 | 227 | // currentPatternIndex 228 | currentPatternIndex = EEPROM.read(1); 229 | if (currentPatternIndex < 0) 230 | currentPatternIndex = 0; 231 | else if (currentPatternIndex >= patternCount) 232 | currentPatternIndex = patternCount - 1; 233 | 234 | // solidColor 235 | solidColor.r = EEPROM.read(2); 236 | solidColor.g = EEPROM.read(3); 237 | solidColor.b = EEPROM.read(4); 238 | 239 | if (solidColor.r == 0 && solidColor.g == 0 && solidColor.b == 0) 240 | solidColor = CRGB::White; 241 | } 242 | 243 | void setSolidColor(CRGB color) { 244 | solidColor = color; 245 | 246 | EEPROM.write(2, solidColor.r); 247 | EEPROM.write(3, solidColor.g); 248 | EEPROM.write(4, solidColor.b); 249 | 250 | moveTo(patternCount - 1); 251 | } 252 | 253 | void powerOff() 254 | { 255 | // clear the display 256 | const uint8_t stepSize = 4; 257 | 258 | for (uint8_t i = 0; i < NUM_LEDS / 2 - stepSize; i += stepSize) { 259 | for (uint8_t j = 0; j < stepSize; j++) { 260 | leds[i + j] = CRGB::Black; 261 | leds[(NUM_LEDS - 1) - (i + j)] = CRGB::Black; 262 | } 263 | FastLED.show(); // display this frame 264 | } 265 | 266 | fill_solid(leds, NUM_LEDS, CRGB::Black); 267 | 268 | FastLED.show(); // display this frame 269 | 270 | while (true) { 271 | // check for physical button input 272 | button1.update(); 273 | button2.update(); 274 | 275 | if (button1.rose() || button2.rose()) { 276 | Serial.println("Button released"); 277 | return; 278 | } 279 | 280 | // check for ir remote input 281 | InputCommand command = readCommand(); 282 | if (command != InputCommand::None) 283 | return; 284 | } 285 | } 286 | 287 | void move(int delta) { 288 | moveTo(currentPatternIndex + delta); 289 | } 290 | 291 | void moveTo(int index) { 292 | currentPatternIndex = index; 293 | 294 | if (currentPatternIndex >= patternCount) 295 | currentPatternIndex = 0; 296 | else if (currentPatternIndex < 0) 297 | currentPatternIndex = patternCount - 1; 298 | 299 | currentPattern = patterns[currentPatternIndex]; 300 | 301 | fill_solid(leds, NUM_LEDS, CRGB::Black); 302 | 303 | EEPROM.write(1, currentPatternIndex); 304 | } 305 | 306 | int getBrightnessLevel() { 307 | int level = 0; 308 | for (int i = 0; i < brightnessCount; i++) { 309 | if (brightnessMap[i] >= brightness) { 310 | level = i; 311 | break; 312 | } 313 | } 314 | return level; 315 | } 316 | 317 | uint8_t cycleBrightness() { 318 | adjustBrightness(1); 319 | 320 | if (brightness == brightnessMap[0]) 321 | return 0; 322 | 323 | return brightness; 324 | } 325 | 326 | void adjustBrightness(int delta) { 327 | int level = getBrightnessLevel(); 328 | 329 | level += delta; 330 | 331 | // don't wrap 332 | if (level < 0) 333 | level = 0; 334 | if (level >= brightnessCount) 335 | level = brightnessCount - 1; 336 | 337 | brightness = brightnessMap[level]; 338 | FastLED.setBrightness(brightness); 339 | FastLED.setDither(brightness < 255); 340 | 341 | EEPROM.write(0, brightness); 342 | } 343 | 344 | void cyclePalette(int delta = 1) { 345 | if (currentPaletteIndex == 0 && delta < 0) 346 | currentPaletteIndex = paletteCount - 1; 347 | else if (currentPaletteIndex >= paletteCount - 1 && delta > 0) 348 | currentPaletteIndex = 0; 349 | else 350 | currentPaletteIndex += delta; 351 | 352 | if (currentPaletteIndex >= paletteCount) 353 | currentPaletteIndex = 0; 354 | 355 | palette = palettes[currentPaletteIndex]; 356 | } 357 | 358 | unsigned long button1PressTimeStamp; 359 | unsigned long button2PressTimeStamp; 360 | 361 | void handleInput(unsigned int requestedDelay) { 362 | unsigned int requestedDelayTimeout = millis() + requestedDelay; 363 | 364 | while (true) { 365 | // check for physical button input 366 | button1.update(); 367 | button2.update(); 368 | 369 | if (button1.fell()) { 370 | Serial.println("Button 1 depressed"); 371 | button1PressTimeStamp = millis(); 372 | } 373 | 374 | if (button2.fell()) { 375 | Serial.println("Button 2 depressed"); 376 | button2PressTimeStamp = millis(); 377 | } 378 | 379 | if (button1.rose()) { 380 | Serial.println("Button 1 released"); 381 | move(1); 382 | } 383 | 384 | if (button2.rose()) { 385 | Serial.println("Button 2 released"); 386 | powerOff(); 387 | break; 388 | } 389 | 390 | command = readCommand(defaultHoldDelay); 391 | 392 | if (command != InputCommand::None) { 393 | // Serial.print("command: "); 394 | // Serial.println((int) command); 395 | } 396 | 397 | if (command == InputCommand::Up) { 398 | move(1); 399 | break; 400 | } 401 | else if (command == InputCommand::Down) { 402 | move(-1); 403 | break; 404 | } 405 | else if (command == InputCommand::Brightness) { 406 | if (isHolding || cycleBrightness() == 0) { 407 | heldButtonHasBeenHandled(); 408 | powerOff(); 409 | break; 410 | } 411 | } 412 | else if (command == InputCommand::Power) { 413 | powerOff(); 414 | break; 415 | } 416 | else if (command == InputCommand::BrightnessUp) { 417 | adjustBrightness(1); 418 | } 419 | else if (command == InputCommand::BrightnessDown) { 420 | adjustBrightness(-1); 421 | } 422 | else if (command == InputCommand::PlayMode) { // toggle pause/play 423 | autoplayEnabled = !autoplayEnabled; 424 | } 425 | else if (command == InputCommand::NextPalette) { // cycle color palette 426 | cyclePalette(1); 427 | } 428 | else if (command == InputCommand::PreviousPalette) { // cycle color palette 429 | cyclePalette(-1); 430 | } 431 | 432 | // pattern buttons 433 | 434 | else if (command == InputCommand::Pattern1) { 435 | moveTo(0); 436 | break; 437 | } 438 | else if (command == InputCommand::Pattern2) { 439 | moveTo(1); 440 | break; 441 | } 442 | else if (command == InputCommand::Pattern3) { 443 | moveTo(2); 444 | break; 445 | } 446 | else if (command == InputCommand::Pattern4) { 447 | moveTo(3); 448 | break; 449 | } 450 | else if (command == InputCommand::Pattern5) { 451 | moveTo(4); 452 | break; 453 | } 454 | else if (command == InputCommand::Pattern6) { 455 | moveTo(5); 456 | break; 457 | } 458 | else if (command == InputCommand::Pattern7) { 459 | moveTo(6); 460 | break; 461 | } 462 | else if (command == InputCommand::Pattern8) { 463 | moveTo(7); 464 | break; 465 | } 466 | else if (command == InputCommand::Pattern9) { 467 | moveTo(8); 468 | break; 469 | } 470 | else if (command == InputCommand::Pattern10) { 471 | moveTo(9); 472 | break; 473 | } 474 | else if (command == InputCommand::Pattern11) { 475 | moveTo(10); 476 | break; 477 | } 478 | else if (command == InputCommand::Pattern12) { 479 | moveTo(11); 480 | break; 481 | } 482 | 483 | // custom color adjustment buttons 484 | 485 | else if (command == InputCommand::RedUp) { 486 | solidColor.red += 1; 487 | setSolidColor(solidColor); 488 | break; 489 | } 490 | else if (command == InputCommand::RedDown) { 491 | solidColor.red -= 1; 492 | setSolidColor(solidColor); 493 | break; 494 | } 495 | else if (command == InputCommand::GreenUp) { 496 | solidColor.green += 1; 497 | setSolidColor(solidColor); \ 498 | break; 499 | } 500 | else if (command == InputCommand::GreenDown) { 501 | solidColor.green -= 1; 502 | setSolidColor(solidColor); 503 | break; 504 | } 505 | else if (command == InputCommand::BlueUp) { 506 | solidColor.blue += 1; 507 | setSolidColor(solidColor); 508 | break; 509 | } 510 | else if (command == InputCommand::BlueDown) { 511 | solidColor.blue -= 1; 512 | setSolidColor(solidColor); 513 | break; 514 | } 515 | 516 | // color buttons 517 | 518 | else if (command == InputCommand::Red && currentPatternIndex != patternCount - 2 && currentPatternIndex != patternCount - 3) { // Red, Green, and Blue buttons can be used by ColorInvaders game, which is the next to last pattern 519 | setSolidColor(CRGB::Red); 520 | break; 521 | } 522 | else if (command == InputCommand::RedOrange) { 523 | setSolidColor(CRGB::OrangeRed); 524 | break; 525 | } 526 | else if (command == InputCommand::Orange) { 527 | setSolidColor(CRGB::Orange); 528 | break; 529 | } 530 | else if (command == InputCommand::YellowOrange) { 531 | setSolidColor(CRGB::Goldenrod); 532 | break; 533 | } 534 | else if (command == InputCommand::Yellow) { 535 | setSolidColor(CRGB::Yellow); 536 | break; 537 | } 538 | 539 | else if (command == InputCommand::Green && currentPatternIndex != patternCount - 2 && currentPatternIndex != patternCount - 3) { // Red, Green, and Blue buttons can be used by ColorInvaders game, which is the next to last pattern 540 | setSolidColor(CRGB::Green); 541 | break; 542 | } 543 | else if (command == InputCommand::Lime) { 544 | setSolidColor(CRGB::Lime); 545 | break; 546 | } 547 | else if (command == InputCommand::Aqua) { 548 | setSolidColor(CRGB::Aqua); 549 | break; 550 | } 551 | else if (command == InputCommand::Teal) { 552 | setSolidColor(CRGB::Teal); 553 | break; 554 | } 555 | else if (command == InputCommand::Navy) { 556 | setSolidColor(CRGB::Navy); 557 | break; 558 | } 559 | 560 | else if (command == InputCommand::Blue && currentPatternIndex != patternCount - 2 && currentPatternIndex != patternCount - 3) { // Red, Green, and Blue buttons can be used by ColorInvaders game, which is the next to last pattern 561 | setSolidColor(CRGB::Blue); 562 | break; 563 | } 564 | else if (command == InputCommand::RoyalBlue) { 565 | setSolidColor(CRGB::RoyalBlue); 566 | break; 567 | } 568 | else if (command == InputCommand::Purple) { 569 | setSolidColor(CRGB::Purple); 570 | break; 571 | } 572 | else if (command == InputCommand::Indigo) { 573 | setSolidColor(CRGB::Indigo); 574 | break; 575 | } 576 | else if (command == InputCommand::Magenta) { 577 | setSolidColor(CRGB::Magenta); 578 | break; 579 | } 580 | 581 | else if (command == InputCommand::White && currentPatternIndex != patternCount - 2 && currentPatternIndex != patternCount - 3) { 582 | setSolidColor(CRGB::White); 583 | break; 584 | } 585 | else if (command == InputCommand::Pink) { 586 | setSolidColor(CRGB::Pink); 587 | break; 588 | } 589 | else if (command == InputCommand::LightPink) { 590 | setSolidColor(CRGB::LightPink); 591 | break; 592 | } 593 | else if (command == InputCommand::BabyBlue) { 594 | setSolidColor(CRGB::CornflowerBlue); 595 | break; 596 | } 597 | else if (command == InputCommand::LightBlue) { 598 | setSolidColor(CRGB::LightBlue); 599 | break; 600 | } 601 | 602 | if (millis() >= requestedDelayTimeout) 603 | break; 604 | } 605 | } 606 | 607 | uint16_t XY( uint8_t x, uint8_t y) // maps the matrix to the strip 608 | { 609 | uint16_t i; 610 | i = (y * MATRIX_WIDTH) + (MATRIX_WIDTH - x); 611 | 612 | i = (NUM_LEDS - 1) - i; 613 | 614 | if (i > NUM_LEDS) 615 | i = NUM_LEDS; 616 | 617 | return i; 618 | } 619 | 620 | // scale the brightness of the screenbuffer down 621 | void dimAll(byte value) 622 | { 623 | for (int i = 0; i < NUM_LEDS; i++) { 624 | leds[i].nscale8(value); 625 | } 626 | } 627 | 628 | uint16_t showSolidColor() { 629 | fill_solid(leds, NUM_LEDS, solidColor); 630 | 631 | return 60; 632 | } 633 | 634 | uint16_t rainbow() 635 | { 636 | // FastLED's built-in rainbow generator 637 | fill_rainbow(leds, NUM_LEDS, gHue, 1); 638 | 639 | return 8; 640 | } 641 | 642 | uint16_t rainbowWithGlitter() 643 | { 644 | // built-in FastLED rainbow, plus some random sparkly glitter 645 | rainbow(); 646 | addGlitter(80); 647 | return 8; 648 | } 649 | 650 | void addGlitter(fract8 chanceOfGlitter) 651 | { 652 | if (random8() < chanceOfGlitter) { 653 | leds[random16(NUM_LEDS)] += CRGB::White; 654 | } 655 | } 656 | 657 | uint16_t confetti() 658 | { 659 | // random colored speckles that blink in and fade smoothly 660 | fadeToBlackBy(leds, NUM_LEDS, 10); 661 | int pos = random16(NUM_LEDS); 662 | leds[pos] += ColorFromPalette(palette, gHue + random8(64), 255); // CHSV(gHue + random8(64), 200, 255); 663 | return 8; 664 | } 665 | 666 | uint16_t bpm() 667 | { 668 | // colored stripes pulsing at a defined Beats-Per-Minute (BPM) 669 | uint8_t BeatsPerMinute = 62; 670 | uint8_t beat = beatsin8(BeatsPerMinute, 64, 255); 671 | for (int i = 0; i < NUM_LEDS; i++) { //9948 672 | leds[i] = ColorFromPalette(palette, gHue + (i * 2), beat - gHue + (i * 10)); 673 | } 674 | return 8; 675 | } 676 | 677 | uint16_t juggle() { 678 | // N colored dots, weaving in and out of sync with each other 679 | fadeToBlackBy(leds, NUM_LEDS, 20); 680 | byte dothue = 0; 681 | byte dotCount = 3; 682 | for (int i = 0; i < dotCount; i++) { 683 | leds[beatsin16(i + dotCount - 1, 0, NUM_LEDS)] |= CHSV(dothue, 200, 255); 684 | dothue += 256 / dotCount; 685 | } 686 | return 0; 687 | } 688 | 689 | // An animation to play while the crowd goes wild after the big performance 690 | uint16_t applause() 691 | { 692 | static uint16_t lastPixel = 0; 693 | fadeToBlackBy(leds, NUM_LEDS, 32); 694 | leds[lastPixel] = CHSV(random8(HUE_BLUE, HUE_PURPLE), 255, 255); 695 | lastPixel = random16(NUM_LEDS); 696 | leds[lastPixel] = CRGB::White; 697 | return 8; 698 | } 699 | 700 | // An "animation" to just fade to black. Useful as the last track 701 | // in a non-looping performance-oriented playlist. 702 | uint16_t fadeToBlack() 703 | { 704 | fadeToBlackBy(leds, NUM_LEDS, 10); 705 | return 8; 706 | } 707 | 708 | uint16_t sinelon() 709 | { 710 | // a colored dot sweeping back and forth, with fading trails 711 | fadeToBlackBy( leds, NUM_LEDS, 20); 712 | uint16_t pos = beatsin16(13, 0, NUM_LEDS); 713 | static uint16_t prevpos = 0; 714 | if ( pos < prevpos ) { 715 | fill_solid( leds + pos, (prevpos - pos) + 1, CHSV(gHue, 220, 255)); 716 | } else { 717 | fill_solid( leds + prevpos, (pos - prevpos) + 1, CHSV( gHue, 220, 255)); 718 | } 719 | prevpos = pos; 720 | 721 | return 8; 722 | } 723 | 724 | uint16_t hueCycle() { 725 | fill_solid(leds, NUM_LEDS, CHSV(gHue, 255, 255)); 726 | return 60; 727 | } 728 | 729 | // Pride2015 by Mark Kriegsman 730 | // https://gist.github.com/kriegsman/964de772d64c502760e5 731 | 732 | // This function draws rainbows with an ever-changing, 733 | // widely-varying set of parameters. 734 | uint16_t pride() 735 | { 736 | static uint16_t sPseudotime = 0; 737 | static uint16_t sLastMillis = 0; 738 | static uint16_t sHue16 = 0; 739 | 740 | uint8_t sat8 = beatsin88(87, 220, 250); 741 | uint8_t brightdepth = beatsin88(341, 96, 224); 742 | uint16_t brightnessthetainc16 = beatsin88(203, (25 * 256), (40 * 256)); 743 | uint8_t msmultiplier = beatsin88(147, 23, 60); 744 | 745 | uint16_t hue16 = sHue16;//gHue * 256; 746 | uint16_t hueinc16 = beatsin88(113, 1, 3000); 747 | 748 | uint16_t ms = millis(); 749 | uint16_t deltams = ms - sLastMillis; 750 | sLastMillis = ms; 751 | sPseudotime += deltams * msmultiplier; 752 | sHue16 += deltams * beatsin88(400, 5, 9); 753 | uint16_t brightnesstheta16 = sPseudotime; 754 | 755 | for (int i = 0; i < NUM_LEDS; i++) { 756 | hue16 += hueinc16; 757 | uint8_t hue8 = hue16 / 256; 758 | 759 | brightnesstheta16 += brightnessthetainc16; 760 | uint16_t b16 = sin16(brightnesstheta16) + 32768; 761 | 762 | uint16_t bri16 = (uint32_t) ((uint32_t) b16 * (uint32_t) b16) / 65536; 763 | uint8_t bri8 = (uint32_t) (((uint32_t) bri16) * brightdepth) / 65536; 764 | bri8 += (255 - brightdepth); 765 | 766 | CRGB newcolor = CHSV(hue8, sat8, bri8); 767 | 768 | uint8_t pixelnumber = i; 769 | pixelnumber = (NUM_LEDS - 1) - pixelnumber; 770 | 771 | nblend(leds[pixelnumber], newcolor, 64); 772 | } 773 | 774 | return 0; 775 | } 776 | 777 | /////////////////////////////////////////////////////////////////////// 778 | 779 | // Forward declarations of an array of cpt-city gradient palettes, and 780 | // a count of how many there are. The actual color palette definitions 781 | // are at the bottom of this file. 782 | extern const TProgmemRGBGradientPalettePtr gGradientPalettes[]; 783 | extern const uint8_t gGradientPaletteCount; 784 | 785 | // Current palette number from the 'playlist' of color palettes 786 | uint8_t gCurrentPaletteNumber = 0; 787 | 788 | CRGBPalette16 gCurrentPalette( CRGB::Black); 789 | CRGBPalette16 gTargetPalette( gGradientPalettes[0] ); 790 | 791 | // ten seconds per color palette makes a good demo 792 | // 20-120 is better for deployment 793 | #define SECONDS_PER_PALETTE 10 794 | 795 | uint16_t colorWaves() 796 | { 797 | EVERY_N_SECONDS( SECONDS_PER_PALETTE ) { 798 | gCurrentPaletteNumber = addmod8( gCurrentPaletteNumber, 1, gGradientPaletteCount); 799 | gTargetPalette = gGradientPalettes[ gCurrentPaletteNumber ]; 800 | } 801 | 802 | EVERY_N_MILLISECONDS(40) { 803 | nblendPaletteTowardPalette( gCurrentPalette, gTargetPalette, 16); 804 | } 805 | 806 | colorwaves( leds, NUM_LEDS, gCurrentPalette); 807 | 808 | return 20; 809 | } 810 | 811 | 812 | // This function draws color waves with an ever-changing, 813 | // widely-varying set of parameters, using a color palette. 814 | void colorwaves( CRGB* ledarray, uint16_t numleds, CRGBPalette16& palette) 815 | { 816 | static uint16_t sPseudotime = 0; 817 | static uint16_t sLastMillis = 0; 818 | static uint16_t sHue16 = 0; 819 | 820 | // uint8_t sat8 = beatsin88( 87, 220, 250); 821 | uint8_t brightdepth = beatsin88( 341, 96, 224); 822 | uint16_t brightnessthetainc16 = beatsin88( 203, (25 * 256), (40 * 256)); 823 | uint8_t msmultiplier = beatsin88(147, 23, 60); 824 | 825 | uint16_t hue16 = sHue16;//gHue * 256; 826 | uint16_t hueinc16 = beatsin88(113, 300, 1500); 827 | 828 | uint16_t ms = millis(); 829 | uint16_t deltams = ms - sLastMillis ; 830 | sLastMillis = ms; 831 | sPseudotime += deltams * msmultiplier; 832 | sHue16 += deltams * beatsin88( 400, 5, 9); 833 | uint16_t brightnesstheta16 = sPseudotime; 834 | 835 | for ( uint16_t i = 0 ; i < numleds; i++) { 836 | hue16 += hueinc16; 837 | uint8_t hue8 = hue16 / 256; 838 | uint16_t h16_128 = hue16 >> 7; 839 | if ( h16_128 & 0x100) { 840 | hue8 = 255 - (h16_128 >> 1); 841 | } else { 842 | hue8 = h16_128 >> 1; 843 | } 844 | 845 | brightnesstheta16 += brightnessthetainc16; 846 | uint16_t b16 = sin16( brightnesstheta16 ) + 32768; 847 | 848 | uint16_t bri16 = (uint32_t)((uint32_t)b16 * (uint32_t)b16) / 65536; 849 | uint8_t bri8 = (uint32_t)(((uint32_t)bri16) * brightdepth) / 65536; 850 | bri8 += (255 - brightdepth); 851 | 852 | uint8_t index = hue8; 853 | //index = triwave8( index); 854 | index = scale8( index, 240); 855 | 856 | CRGB newcolor = ColorFromPalette( palette, index, bri8); 857 | 858 | uint16_t pixelnumber = i; 859 | pixelnumber = (numleds - 1) - pixelnumber; 860 | 861 | nblend( ledarray[pixelnumber], newcolor, 128); 862 | } 863 | } 864 | 865 | // Alternate rendering function just scrolls the current palette 866 | // across the defined LED strip. 867 | void palettetest( CRGB* ledarray, uint16_t numleds, const CRGBPalette16& gCurrentPalette) 868 | { 869 | static uint8_t startindex = 0; 870 | startindex--; 871 | fill_palette( ledarray, numleds, startindex, (256 / NUM_LEDS) + 1, gCurrentPalette, 255, LINEARBLEND); 872 | } 873 | 874 | #define STARTING_BRIGHTNESS 64 875 | #define FADE_IN_SPEED 32 876 | #define FADE_OUT_SPEED 20 877 | uint8_t DENSITY = 255; 878 | 879 | uint16_t cloudTwinkles() 880 | { 881 | DENSITY = 255; 882 | colortwinkles(CloudColors_p); 883 | return 20; 884 | } 885 | 886 | uint16_t rainbowTwinkles() 887 | { 888 | DENSITY = 255; 889 | colortwinkles(RainbowColors_p); 890 | return 20; 891 | } 892 | 893 | uint16_t snowTwinkles() 894 | { 895 | DENSITY = 255; 896 | colortwinkles(snowColors); 897 | return 20; 898 | } 899 | 900 | uint16_t incandescentTwinkles() 901 | { 902 | DENSITY = 255; 903 | colortwinkles(incandescentColors); 904 | return 20; 905 | } 906 | 907 | uint16_t fireflies() 908 | { 909 | DENSITY = 16; 910 | colortwinkles(incandescentColors); 911 | return 20; 912 | } 913 | 914 | enum { GETTING_DARKER = 0, GETTING_BRIGHTER = 1 }; 915 | 916 | void colortwinkles(CRGBPalette16 palette) 917 | { 918 | // Make each pixel brighter or darker, depending on 919 | // its 'direction' flag. 920 | brightenOrDarkenEachPixel( FADE_IN_SPEED, FADE_OUT_SPEED); 921 | 922 | // Now consider adding a new random twinkle 923 | if ( random8() < DENSITY ) { 924 | int pos = random16(NUM_LEDS); 925 | if ( !leds[pos]) { 926 | leds[pos] = ColorFromPalette( palette, random8(), STARTING_BRIGHTNESS, NOBLEND); 927 | setPixelDirection(pos, GETTING_BRIGHTER); 928 | } 929 | } 930 | } 931 | 932 | void brightenOrDarkenEachPixel( fract8 fadeUpAmount, fract8 fadeDownAmount) 933 | { 934 | for ( uint16_t i = 0; i < NUM_LEDS; i++) { 935 | if ( getPixelDirection(i) == GETTING_DARKER) { 936 | // This pixel is getting darker 937 | leds[i] = makeDarker( leds[i], fadeDownAmount); 938 | } else { 939 | // This pixel is getting brighter 940 | leds[i] = makeBrighter( leds[i], fadeUpAmount); 941 | // now check to see if we've maxxed out the brightness 942 | if ( leds[i].r == 255 || leds[i].g == 255 || leds[i].b == 255) { 943 | // if so, turn around and start getting darker 944 | setPixelDirection(i, GETTING_DARKER); 945 | } 946 | } 947 | } 948 | } 949 | 950 | CRGB makeBrighter( const CRGB& color, fract8 howMuchBrighter) 951 | { 952 | CRGB incrementalColor = color; 953 | incrementalColor.nscale8( howMuchBrighter); 954 | return color + incrementalColor; 955 | } 956 | 957 | CRGB makeDarker( const CRGB& color, fract8 howMuchDarker) 958 | { 959 | CRGB newcolor = color; 960 | newcolor.nscale8( 255 - howMuchDarker); 961 | return newcolor; 962 | } 963 | 964 | // Compact implementation of 965 | // the directionFlags array, using just one BIT of RAM 966 | // per pixel. This requires a bunch of bit wrangling, 967 | // but conserves precious RAM. The cost is a few 968 | // cycles and about 100 bytes of flash program memory. 969 | uint8_t directionFlags[ (NUM_LEDS + 7) / 8]; 970 | 971 | bool getPixelDirection( uint16_t i) { 972 | uint16_t index = i / 8; 973 | uint8_t bitNum = i & 0x07; 974 | 975 | uint8_t andMask = 1 << bitNum; 976 | return (directionFlags[index] & andMask) != 0; 977 | } 978 | 979 | void setPixelDirection( uint16_t i, bool dir) { 980 | uint16_t index = i / 8; 981 | uint8_t bitNum = i & 0x07; 982 | 983 | uint8_t orMask = 1 << bitNum; 984 | uint8_t andMask = 255 - orMask; 985 | uint8_t value = directionFlags[index] & andMask; 986 | if ( dir ) { 987 | value += orMask; 988 | } 989 | directionFlags[index] = value; 990 | } 991 | --------------------------------------------------------------------------------
