├── .DS_Store ├── .gitattributes ├── LICENSE ├── MedMNIST_tutorial ├── .DS_Store ├── mednist_CE.ipynb ├── mednist_CM.ipynb ├── mednist_HC.ipynb └── pretty_confusion_matrix_local.py ├── NIFTI ├── affine.m ├── bipolar.m ├── bresenham_line3d.m ├── clip_nii.m ├── collapse_nii_scan.m ├── examples.txt ├── expand_nii_scan.m ├── extra_nii_hdr.m ├── flip_lr.m ├── get_nii_frame.m ├── license.txt ├── load_nii.m ├── load_nii_ext.m ├── load_nii_hdr.m ├── load_nii_img.m ├── load_untouch0_nii_hdr.m ├── load_untouch_header_only.m ├── load_untouch_nii.m ├── load_untouch_nii_hdr.m ├── load_untouch_nii_img.m ├── make_ana.m ├── make_nii.m ├── mat_into_hdr.m ├── reslice_nii.m ├── rri_file_menu.m ├── rri_orient.m ├── rri_orient_ui.m ├── rri_select_file.m ├── rri_xhair.m ├── rri_zoom_menu.m ├── save_nii.m ├── save_nii_ext.m ├── save_nii_hdr.m ├── save_untouch0_nii_hdr.m ├── save_untouch_nii.m ├── save_untouch_nii_hdr.m ├── save_untouch_slice.m ├── unxform_nii.m ├── verify_nii_ext.m ├── view_nii.m ├── view_nii_menu.m └── xform_nii.m ├── README.md ├── UNETR_matrixpenalty_v5_2d.csv ├── build_container_v08.sh ├── combine_masks.m ├── doc ├── DOMINO_MICCAI22_PPT.pdf ├── ReadMeDoc.md └── poster1693.pdf ├── make_datalist_json.m ├── test.sh ├── test_domino.py ├── tissue_cond_11.xlsx ├── train.sh └── train_domino.py /.DS_Store: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/lab-smile/DOMINO/3d261da4dec8ba338818babfa471c47c51d0866d/.DS_Store -------------------------------------------------------------------------------- /.gitattributes: -------------------------------------------------------------------------------- 1 | .pth filter=lfs diff=lfs merge=lfs -text 2 | *.pth filter=lfs diff=lfs merge=lfs -text 3 | -------------------------------------------------------------------------------- /MedMNIST_tutorial/.DS_Store: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/lab-smile/DOMINO/3d261da4dec8ba338818babfa471c47c51d0866d/MedMNIST_tutorial/.DS_Store -------------------------------------------------------------------------------- /MedMNIST_tutorial/pretty_confusion_matrix_local.py: -------------------------------------------------------------------------------- 1 | # -*- coding: utf-8 -*- 2 | """ 3 | plot a pretty confusion matrix with seaborn 4 | Created on Mon Jun 25 14:17:37 2018 5 | @author: Wagner Cipriano - wagnerbhbr - gmail - CEFETMG / MMC 6 | REFerences: 7 | https://www.mathworks.com/help/nnet/ref/plotconfusion.html 8 | https://stackoverflow.com/questions/28200786/how-to-plot-scikit-learn-classification-report 9 | https://stackoverflow.com/questions/5821125/how-to-plot-confusion-matrix-with-string-axis-rather-than-integer-in-python 10 | https://www.programcreek.com/python/example/96197/seaborn.heatmap 11 | https://stackoverflow.com/questions/19233771/sklearn-plot-confusion-matrix-with-labels/31720054 12 | http://scikit-learn.org/stable/auto_examples/model_selection/plot_confusion_matrix.html#sphx-glr-auto-examples-model-selection-plot-confusion-matrix-py 13 | """ 14 | 15 | import matplotlib.font_manager as fm 16 | import matplotlib.pyplot as plt 17 | import numpy as np 18 | import seaborn as sn 19 | from matplotlib.collections import QuadMesh 20 | 21 | 22 | def get_new_fig(fn, figsize=[9, 9]): 23 | """Init graphics""" 24 | fig1 = plt.figure(fn, figsize) 25 | ax1 = fig1.gca() # Get Current Axis 26 | ax1.cla() # clear existing plot 27 | return fig1, ax1 28 | 29 | 30 | def configcell_text_and_colors( 31 | array_df, lin, col, oText, facecolors, posi, fz, fmt, show_null_values=0 32 | ): 33 | """ 34 | config cell text and colors 35 | and return text elements to add and to dell 36 | @TODO: use fmt 37 | """ 38 | text_add = [] 39 | text_del = [] 40 | cell_val = array_df[lin][col] 41 | tot_all = array_df[-1][-1] 42 | per = float(cell_val) / array_df[lin][-1] * 100#(float(cell_val) / tot_all) * 100 43 | curr_column = array_df[:, col] 44 | ccl = len(curr_column) 45 | 46 | # last line and/or last column 47 | if (col == (ccl - 1)) or (lin == (ccl - 1)): 48 | # tots and percents 49 | if cell_val != 0: 50 | if (col == ccl - 1) and (lin == ccl - 1): 51 | tot_rig = 0 52 | for i in range(array_df.shape[0] - 1): 53 | tot_rig += array_df[i][i] 54 | per_ok = (float(tot_rig) / cell_val) * 100 55 | elif col == ccl - 1: 56 | tot_rig = array_df[lin][lin] 57 | per_ok = (float(tot_rig) / cell_val) * 100 58 | elif lin == ccl - 1: 59 | tot_rig = array_df[col][col] 60 | per_ok = (float(tot_rig) / cell_val) * 100 61 | per_err = 100 - per_ok 62 | else: 63 | per_ok = per_err = 0 64 | 65 | per_ok_s = ["%.2f%%" % (per_ok), "100%"][per_ok == 100] 66 | 67 | # text to DEL 68 | text_del.append(oText) 69 | 70 | # text to ADD 71 | font_prop = fm.FontProperties(weight="bold", size=fz) 72 | text_kwargs = dict( 73 | color="w", 74 | ha="center", 75 | va="center", 76 | gid="sum", 77 | fontproperties=font_prop, 78 | ) 79 | lis_txt = ["%d" % (cell_val), per_ok_s, "%.2f%%" % (per_err)] 80 | lis_kwa = [text_kwargs] 81 | dic = text_kwargs.copy() 82 | dic["color"] = "g" 83 | lis_kwa.append(dic) 84 | dic = text_kwargs.copy() 85 | dic["color"] = "r" 86 | lis_kwa.append(dic) 87 | lis_pos = [ 88 | (oText._x, oText._y - 0.3), 89 | (oText._x, oText._y), 90 | (oText._x, oText._y + 0.3), 91 | ] 92 | for i in range(len(lis_txt)): 93 | newText = dict( 94 | x=lis_pos[i][0], 95 | y=lis_pos[i][1], 96 | text=lis_txt[i], 97 | kw=lis_kwa[i], 98 | ) 99 | text_add.append(newText) 100 | 101 | # set background color for sum cells (last line and last column) 102 | carr = [0.27, 0.30, 0.27, 1.0] 103 | if (col == ccl - 1) and (lin == ccl - 1): 104 | carr = [0.17, 0.20, 0.17, 1.0] 105 | facecolors[posi] = carr 106 | 107 | else: 108 | if per > 0: 109 | txt = "%s\n%.2f%%" % (cell_val, per) 110 | else: 111 | if show_null_values == 0: 112 | txt = "" 113 | elif show_null_values == 1: 114 | txt = "0\n0.00%" 115 | else: 116 | txt = "0\n0.00%" 117 | oText.set_text(txt) 118 | 119 | # main diagonal 120 | if col == lin: 121 | # set color of the textin the diagonal to white 122 | oText.set_color("k") 123 | # set background color in the diagonal to blue 124 | facecolors[posi] = [0.35, 0.8, 0.55, 1.0] 125 | else: 126 | oText.set_color("r") 127 | 128 | return text_add, text_del 129 | 130 | 131 | def insert_totals(df_cm): 132 | """insert total column and line (the last ones)""" 133 | sum_col = [] 134 | for c in df_cm.columns: 135 | sum_col.append(df_cm[c].sum()) 136 | sum_lin = [] 137 | for item_line in df_cm.iterrows(): 138 | sum_lin.append(item_line[1].sum()) 139 | df_cm["sum_lin"] = sum_lin 140 | sum_col.append(np.sum(sum_lin)) 141 | df_cm.loc["sum_col"] = sum_col 142 | 143 | 144 | def pp_matrix( 145 | df_cm, 146 | annot=True, 147 | cmap="Oranges", 148 | fmt=".2f", 149 | fz=11, 150 | lw=0.5, 151 | cbar=False, 152 | figsize=[8, 8], 153 | show_null_values=0, 154 | pred_val_axis="y", 155 | ): 156 | """ 157 | print conf matrix with default layout (like matlab) 158 | params: 159 | df_cm dataframe (pandas) without totals 160 | annot print text in each cell 161 | cmap Oranges,Oranges_r,YlGnBu,Blues,RdBu, ... see: 162 | fz fontsize 163 | lw linewidth 164 | pred_val_axis where to show the prediction values (x or y axis) 165 | 'col' or 'x': show predicted values in columns (x axis) instead lines 166 | 'lin' or 'y': show predicted values in lines (y axis) 167 | """ 168 | if pred_val_axis in ("col", "x"): 169 | xlbl = "Predicted" 170 | ylbl = "Actual" 171 | else: 172 | xlbl = "Actual" 173 | ylbl = "Predicted" 174 | df_cm = df_cm.T 175 | 176 | # create "Total" column 177 | insert_totals(df_cm) 178 | 179 | # this is for print allways in the same window 180 | fig, ax1 = get_new_fig("Conf matrix default", figsize) 181 | 182 | ax = sn.heatmap( 183 | df_cm, 184 | annot=annot, 185 | annot_kws={"size": fz}, 186 | linewidths=lw, 187 | ax=ax1, 188 | cbar=cbar, 189 | cmap=cmap, 190 | linecolor="w", 191 | fmt=fmt, 192 | ) 193 | 194 | # set ticklabels rotation 195 | ax.set_xticklabels(ax.get_xticklabels(), rotation=45, fontsize=16) 196 | ax.set_yticklabels(ax.get_yticklabels(), rotation=25, fontsize=16) 197 | 198 | # Turn off all the ticks 199 | for t in ax.xaxis.get_major_ticks(): 200 | t.tick1On = False 201 | t.tick2On = False 202 | for t in ax.yaxis.get_major_ticks(): 203 | t.tick1On = False 204 | t.tick2On = False 205 | 206 | # face colors list 207 | quadmesh = ax.findobj(QuadMesh)[0] 208 | facecolors = quadmesh.get_facecolors() 209 | 210 | # iter in text elements 211 | array_df = np.array(df_cm.to_records(index=False).tolist()) 212 | text_add = [] 213 | text_del = [] 214 | posi = -1 # from left to right, bottom to top. 215 | for t in ax.collections[0].axes.texts: # ax.texts: 216 | pos = np.array(t.get_position()) - [0.5, 0.5] 217 | lin = int(pos[1]) 218 | col = int(pos[0]) 219 | posi += 1 220 | 221 | # set text 222 | txt_res = configcell_text_and_colors( 223 | array_df, lin, col, t, facecolors, posi, fz, fmt, show_null_values 224 | ) 225 | 226 | text_add.extend(txt_res[0]) 227 | text_del.extend(txt_res[1]) 228 | 229 | # remove the old ones 230 | for item in text_del: 231 | item.remove() 232 | # append the new ones 233 | for item in text_add: 234 | ax.text(item["x"], item["y"], item["text"], **item["kw"]) 235 | 236 | # titles and legends 237 | ax.set_title("Confusion matrix") 238 | ax.set_xlabel(xlbl) 239 | ax.set_ylabel(ylbl) 240 | plt.tight_layout() # set layout slim 241 | plt.show() 242 | 243 | 244 | def pp_matrix_from_data( 245 | y_test, 246 | predictions, 247 | columns=None, 248 | annot=True, 249 | cmap="Oranges", 250 | fmt=".2f", 251 | fz=11, 252 | lw=0.5, 253 | cbar=False, 254 | figsize=[8, 8], 255 | show_null_values=0, 256 | pred_val_axis="lin", 257 | ): 258 | """ 259 | plot confusion matrix function with y_test (actual values) and predictions (predic), 260 | whitout a confusion matrix yet 261 | """ 262 | from pandas import DataFrame 263 | from sklearn.metrics import confusion_matrix 264 | 265 | # data 266 | if not columns: 267 | from string import ascii_uppercase 268 | 269 | columns = [ 270 | "class %s" % (i) 271 | for i in list(ascii_uppercase)[0 : len(np.unique(y_test))] 272 | ] 273 | 274 | confm = confusion_matrix(y_test, predictions) 275 | df_cm = DataFrame(confm, index=columns, columns=columns) 276 | pp_matrix( 277 | df_cm, 278 | fz=fz, 279 | cmap=cmap, 280 | figsize=figsize, 281 | show_null_values=show_null_values, 282 | pred_val_axis=pred_val_axis, 283 | ) -------------------------------------------------------------------------------- /NIFTI/bipolar.m: -------------------------------------------------------------------------------- 1 | %BIPOLAR returns an M-by-3 matrix containing a blue-red colormap, in 2 | % in which red stands for positive, blue stands for negative, 3 | % and white stands for 0. 4 | % 5 | % Usage: cmap = bipolar(M, lo, hi, contrast); or cmap = bipolar; 6 | % 7 | % cmap: output M-by-3 matrix for BIPOLAR colormap. 8 | % M: number of shades in the colormap. By default, it is the 9 | % same length as the current colormap. 10 | % lo: the lowest value to represent. 11 | % hi: the highest value to represent. 12 | % 13 | % Inspired from the LORETA PASCAL program: 14 | % http://www.unizh.ch/keyinst/NewLORETA 15 | % 16 | % jimmy@rotman-baycrest.on.ca 17 | % 18 | %---------------------------------------------------------------- 19 | function cmap = bipolar(M, lo, hi, contrast) 20 | 21 | if ~exist('contrast','var') 22 | contrast = 128; 23 | end 24 | 25 | if ~exist('lo','var') 26 | lo = -1; 27 | end 28 | 29 | if ~exist('hi','var') 30 | hi = 1; 31 | end 32 | 33 | if ~exist('M','var') 34 | cmap = colormap; 35 | M = size(cmap,1); 36 | end 37 | 38 | steepness = 10 ^ (1 - (contrast-1)/127); 39 | pos_infs = 1e-99; 40 | neg_infs = -1e-99; 41 | 42 | doubleredc = []; 43 | doublebluec = []; 44 | 45 | if lo >= 0 % all positive 46 | 47 | if lo == 0 48 | lo = pos_infs; 49 | end 50 | 51 | for i=linspace(hi/M, hi, M) 52 | t = exp(log(i/hi)*steepness); 53 | doubleredc = [doubleredc; [(1-t)+t,(1-t)+0,(1-t)+0]]; 54 | end 55 | 56 | cmap = doubleredc; 57 | 58 | elseif hi <= 0 % all negative 59 | 60 | if hi == 0 61 | hi = neg_infs; 62 | end 63 | 64 | for i=linspace(abs(lo)/M, abs(lo), M) 65 | t = exp(log(i/abs(lo))*steepness); 66 | doublebluec = [doublebluec; [(1-t)+0,(1-t)+0,(1-t)+t]]; 67 | end 68 | 69 | cmap = flipud(doublebluec); 70 | 71 | else 72 | 73 | if hi > abs(lo) 74 | maxc = hi; 75 | else 76 | maxc = abs(lo); 77 | end 78 | 79 | for i=linspace(maxc/M, hi, round(M*hi/(hi-lo))) 80 | t = exp(log(i/maxc)*steepness); 81 | doubleredc = [doubleredc; [(1-t)+t,(1-t)+0,(1-t)+0]]; 82 | end 83 | 84 | for i=linspace(maxc/M, abs(lo), round(M*abs(lo)/(hi-lo))) 85 | t = exp(log(i/maxc)*steepness); 86 | doublebluec = [doublebluec; [(1-t)+0,(1-t)+0,(1-t)+t]]; 87 | end 88 | 89 | cmap = [flipud(doublebluec); doubleredc]; 90 | 91 | end 92 | 93 | return; % bipolar 94 | 95 | -------------------------------------------------------------------------------- /NIFTI/bresenham_line3d.m: -------------------------------------------------------------------------------- 1 | % Generate X Y Z coordinates of a 3D Bresenham's line between 2 | % two given points. 3 | % 4 | % A very useful application of this algorithm can be found in the 5 | % implementation of Fischer's Bresenham interpolation method in my 6 | % another program that can rotate three dimensional image volume 7 | % with an affine matrix: 8 | % http://www.mathworks.com/matlabcentral/fileexchange/loadFile.do?objectId=21080 9 | % 10 | % Usage: [X Y Z] = bresenham_line3d(P1, P2, [precision]); 11 | % 12 | % P1 - vector for Point1, where P1 = [x1 y1 z1] 13 | % 14 | % P2 - vector for Point2, where P2 = [x2 y2 z2] 15 | % 16 | % precision (optional) - Although according to Bresenham's line 17 | % algorithm, point coordinates x1 y1 z1 and x2 y2 z2 should 18 | % be integer numbers, this program extends its limit to all 19 | % real numbers. If any of them are floating numbers, you 20 | % should specify how many digits of decimal that you would 21 | % like to preserve. Be aware that the length of output X Y 22 | % Z coordinates will increase in 10 times for each decimal 23 | % digit that you want to preserve. By default, the precision 24 | % is 0, which means that they will be rounded to the nearest 25 | % integer. 26 | % 27 | % X - a set of x coordinates on Bresenham's line 28 | % 29 | % Y - a set of y coordinates on Bresenham's line 30 | % 31 | % Z - a set of z coordinates on Bresenham's line 32 | % 33 | % Therefore, all points in XYZ set (i.e. P(i) = [X(i) Y(i) Z(i)]) 34 | % will constitute the Bresenham's line between P1 and P1. 35 | % 36 | % Example: 37 | % P1 = [12 37 6]; P2 = [46 3 35]; 38 | % [X Y Z] = bresenham_line3d(P1, P2); 39 | % figure; plot3(X,Y,Z,'s','markerface','b'); 40 | % 41 | % This program is ported to MATLAB from: 42 | % 43 | % B.Pendleton. line3d - 3D Bresenham's (a 3D line drawing algorithm) 44 | % ftp://ftp.isc.org/pub/usenet/comp.sources.unix/volume26/line3d, 1992 45 | % 46 | % Which is also referenced by: 47 | % 48 | % Fischer, J., A. del Rio (2004). A Fast Method for Applying Rigid 49 | % Transformations to Volume Data, WSCG2004 Conference. 50 | % http://wscg.zcu.cz/wscg2004/Papers_2004_Short/M19.pdf 51 | % 52 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 53 | % 54 | function [X,Y,Z] = bresenham_line3d(P1, P2, precision) 55 | 56 | if ~exist('precision','var') | isempty(precision) | round(precision) == 0 57 | precision = 0; 58 | P1 = round(P1); 59 | P2 = round(P2); 60 | else 61 | precision = round(precision); 62 | P1 = round(P1*(10^precision)); 63 | P2 = round(P2*(10^precision)); 64 | end 65 | 66 | d = max(abs(P2-P1)+1); 67 | X = zeros(1, d); 68 | Y = zeros(1, d); 69 | Z = zeros(1, d); 70 | 71 | x1 = P1(1); 72 | y1 = P1(2); 73 | z1 = P1(3); 74 | 75 | x2 = P2(1); 76 | y2 = P2(2); 77 | z2 = P2(3); 78 | 79 | dx = x2 - x1; 80 | dy = y2 - y1; 81 | dz = z2 - z1; 82 | 83 | ax = abs(dx)*2; 84 | ay = abs(dy)*2; 85 | az = abs(dz)*2; 86 | 87 | sx = sign(dx); 88 | sy = sign(dy); 89 | sz = sign(dz); 90 | 91 | x = x1; 92 | y = y1; 93 | z = z1; 94 | idx = 1; 95 | 96 | if(ax>=max(ay,az)) % x dominant 97 | yd = ay - ax/2; 98 | zd = az - ax/2; 99 | 100 | while(1) 101 | X(idx) = x; 102 | Y(idx) = y; 103 | Z(idx) = z; 104 | idx = idx + 1; 105 | 106 | if(x == x2) % end 107 | break; 108 | end 109 | 110 | if(yd >= 0) % move along y 111 | y = y + sy; 112 | yd = yd - ax; 113 | end 114 | 115 | if(zd >= 0) % move along z 116 | z = z + sz; 117 | zd = zd - ax; 118 | end 119 | 120 | x = x + sx; % move along x 121 | yd = yd + ay; 122 | zd = zd + az; 123 | end 124 | elseif(ay>=max(ax,az)) % y dominant 125 | xd = ax - ay/2; 126 | zd = az - ay/2; 127 | 128 | while(1) 129 | X(idx) = x; 130 | Y(idx) = y; 131 | Z(idx) = z; 132 | idx = idx + 1; 133 | 134 | if(y == y2) % end 135 | break; 136 | end 137 | 138 | if(xd >= 0) % move along x 139 | x = x + sx; 140 | xd = xd - ay; 141 | end 142 | 143 | if(zd >= 0) % move along z 144 | z = z + sz; 145 | zd = zd - ay; 146 | end 147 | 148 | y = y + sy; % move along y 149 | xd = xd + ax; 150 | zd = zd + az; 151 | end 152 | elseif(az>=max(ax,ay)) % z dominant 153 | xd = ax - az/2; 154 | yd = ay - az/2; 155 | 156 | while(1) 157 | X(idx) = x; 158 | Y(idx) = y; 159 | Z(idx) = z; 160 | idx = idx + 1; 161 | 162 | if(z == z2) % end 163 | break; 164 | end 165 | 166 | if(xd >= 0) % move along x 167 | x = x + sx; 168 | xd = xd - az; 169 | end 170 | 171 | if(yd >= 0) % move along y 172 | y = y + sy; 173 | yd = yd - az; 174 | end 175 | 176 | z = z + sz; % move along z 177 | xd = xd + ax; 178 | yd = yd + ay; 179 | end 180 | end 181 | 182 | if precision ~= 0 183 | X = X/(10^precision); 184 | Y = Y/(10^precision); 185 | Z = Z/(10^precision); 186 | end 187 | 188 | return; % bresenham_line3d 189 | 190 | -------------------------------------------------------------------------------- /NIFTI/clip_nii.m: -------------------------------------------------------------------------------- 1 | % CLIP_NII: Clip the NIfTI volume from any of the 6 sides 2 | % 3 | % Usage: nii = clip_nii(nii, [option]) 4 | % 5 | % Inputs: 6 | % 7 | % nii - NIfTI volume. 8 | % 9 | % option - struct instructing how many voxel to be cut from which side. 10 | % 11 | % option.cut_from_L = ( number of voxel ) 12 | % option.cut_from_R = ( number of voxel ) 13 | % option.cut_from_P = ( number of voxel ) 14 | % option.cut_from_A = ( number of voxel ) 15 | % option.cut_from_I = ( number of voxel ) 16 | % option.cut_from_S = ( number of voxel ) 17 | % 18 | % Options description in detail: 19 | % ============================== 20 | % 21 | % cut_from_L: Number of voxels from Left side will be clipped. 22 | % 23 | % cut_from_R: Number of voxels from Right side will be clipped. 24 | % 25 | % cut_from_P: Number of voxels from Posterior side will be clipped. 26 | % 27 | % cut_from_A: Number of voxels from Anterior side will be clipped. 28 | % 29 | % cut_from_I: Number of voxels from Inferior side will be clipped. 30 | % 31 | % cut_from_S: Number of voxels from Superior side will be clipped. 32 | % 33 | % NIfTI data format can be found on: http://nifti.nimh.nih.gov 34 | % 35 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 36 | % 37 | function nii = clip_nii(nii, opt) 38 | 39 | dims = abs(nii.hdr.dime.dim(2:4)); 40 | origin = abs(nii.hdr.hist.originator(1:3)); 41 | 42 | if isempty(origin) | all(origin == 0) % according to SPM 43 | origin = round((dims+1)/2); 44 | end 45 | 46 | cut_from_L = 0; 47 | cut_from_R = 0; 48 | cut_from_P = 0; 49 | cut_from_A = 0; 50 | cut_from_I = 0; 51 | cut_from_S = 0; 52 | 53 | if nargin > 1 & ~isempty(opt) 54 | if ~isstruct(opt) 55 | error('option argument should be a struct'); 56 | end 57 | 58 | if isfield(opt,'cut_from_L') 59 | cut_from_L = round(opt.cut_from_L); 60 | 61 | if cut_from_L >= origin(1) | cut_from_L < 0 62 | error('cut_from_L cannot be negative or cut beyond originator'); 63 | end 64 | end 65 | 66 | if isfield(opt,'cut_from_P') 67 | cut_from_P = round(opt.cut_from_P); 68 | 69 | if cut_from_P >= origin(2) | cut_from_P < 0 70 | error('cut_from_P cannot be negative or cut beyond originator'); 71 | end 72 | end 73 | 74 | if isfield(opt,'cut_from_I') 75 | cut_from_I = round(opt.cut_from_I); 76 | 77 | if cut_from_I >= origin(3) | cut_from_I < 0 78 | error('cut_from_I cannot be negative or cut beyond originator'); 79 | end 80 | end 81 | 82 | if isfield(opt,'cut_from_R') 83 | cut_from_R = round(opt.cut_from_R); 84 | 85 | if cut_from_R > dims(1)-origin(1) | cut_from_R < 0 86 | error('cut_from_R cannot be negative or cut beyond originator'); 87 | end 88 | end 89 | 90 | if isfield(opt,'cut_from_A') 91 | cut_from_A = round(opt.cut_from_A); 92 | 93 | if cut_from_A > dims(2)-origin(2) | cut_from_A < 0 94 | error('cut_from_A cannot be negative or cut beyond originator'); 95 | end 96 | end 97 | 98 | if isfield(opt,'cut_from_S') 99 | cut_from_S = round(opt.cut_from_S); 100 | 101 | if cut_from_S > dims(3)-origin(3) | cut_from_S < 0 102 | error('cut_from_S cannot be negative or cut beyond originator'); 103 | end 104 | end 105 | end 106 | 107 | nii = make_nii(nii.img( (cut_from_L+1) : (dims(1)-cut_from_R), ... 108 | (cut_from_P+1) : (dims(2)-cut_from_A), ... 109 | (cut_from_I+1) : (dims(3)-cut_from_S), ... 110 | :,:,:,:,:), nii.hdr.dime.pixdim(2:4), ... 111 | [origin(1)-cut_from_L origin(2)-cut_from_P origin(3)-cut_from_I], ... 112 | nii.hdr.dime.datatype, nii.hdr.hist.descrip); 113 | 114 | return; 115 | 116 | -------------------------------------------------------------------------------- /NIFTI/collapse_nii_scan.m: -------------------------------------------------------------------------------- 1 | % Collapse multiple single-scan NIFTI files into a multiple-scan NIFTI file 2 | % 3 | % Usage: collapse_nii_scan(scan_file_pattern, [collapsed_fileprefix], [scan_file_folder]) 4 | % 5 | % Here, scan_file_pattern should look like: 'myscan_0*.img' 6 | % If collapsed_fileprefix is omit, 'multi_scan' will be used 7 | % If scan_file_folder is omit, current file folder will be used 8 | % 9 | % The order of volumes in the collapsed file will be the order of 10 | % corresponding filenames for those selected scan files. 11 | % 12 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 13 | % 14 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 15 | % 16 | function collapse_nii_scan(scan_pattern, fileprefix, scan_path) 17 | 18 | if ~exist('fileprefix','var') 19 | fileprefix = 'multi_scan'; 20 | else 21 | [tmp fileprefix] = fileparts(fileprefix); 22 | end 23 | 24 | if ~exist('scan_path','var'), scan_path = pwd; end 25 | pnfn = fullfile(scan_path, scan_pattern); 26 | 27 | file_lst = dir(pnfn); 28 | flist = {file_lst.name}; 29 | flist = flist(:); 30 | filename = flist{1}; 31 | 32 | v = version; 33 | 34 | % Check file extension. If .gz, unpack it into temp folder 35 | % 36 | if length(filename) > 2 & strcmp(filename(end-2:end), '.gz') 37 | 38 | if ~strcmp(filename(end-6:end), '.img.gz') & ... 39 | ~strcmp(filename(end-6:end), '.hdr.gz') & ... 40 | ~strcmp(filename(end-6:end), '.nii.gz') 41 | 42 | error('Please check filename.'); 43 | end 44 | 45 | if str2num(v(1:3)) < 7.1 | ~usejava('jvm') 46 | error('Please use MATLAB 7.1 (with java) and above, or run gunzip outside MATLAB.'); 47 | else 48 | gzFile = 1; 49 | end 50 | else 51 | if ~strcmp(filename(end-3:end), '.img') & ... 52 | ~strcmp(filename(end-3:end), '.hdr') & ... 53 | ~strcmp(filename(end-3:end), '.nii') 54 | 55 | error('Please check filename.'); 56 | end 57 | end 58 | 59 | nii = load_untouch_nii(fullfile(scan_path,filename)); 60 | nii.hdr.dime.dim(5) = length(flist); 61 | 62 | if nii.hdr.dime.dim(1) < 4 63 | nii.hdr.dime.dim(1) = 4; 64 | end 65 | 66 | hdr = nii.hdr; 67 | filetype = nii.filetype; 68 | 69 | if isfield(nii,'ext') & ~isempty(nii.ext) 70 | ext = nii.ext; 71 | [ext, esize_total] = verify_nii_ext(ext); 72 | else 73 | ext = []; 74 | end 75 | 76 | switch double(hdr.dime.datatype), 77 | case 1, 78 | hdr.dime.bitpix = int16(1 ); precision = 'ubit1'; 79 | case 2, 80 | hdr.dime.bitpix = int16(8 ); precision = 'uint8'; 81 | case 4, 82 | hdr.dime.bitpix = int16(16); precision = 'int16'; 83 | case 8, 84 | hdr.dime.bitpix = int16(32); precision = 'int32'; 85 | case 16, 86 | hdr.dime.bitpix = int16(32); precision = 'float32'; 87 | case 32, 88 | hdr.dime.bitpix = int16(64); precision = 'float32'; 89 | case 64, 90 | hdr.dime.bitpix = int16(64); precision = 'float64'; 91 | case 128, 92 | hdr.dime.bitpix = int16(24); precision = 'uint8'; 93 | case 256 94 | hdr.dime.bitpix = int16(8 ); precision = 'int8'; 95 | case 512 96 | hdr.dime.bitpix = int16(16); precision = 'uint16'; 97 | case 768 98 | hdr.dime.bitpix = int16(32); precision = 'uint32'; 99 | case 1024 100 | hdr.dime.bitpix = int16(64); precision = 'int64'; 101 | case 1280 102 | hdr.dime.bitpix = int16(64); precision = 'uint64'; 103 | case 1792, 104 | hdr.dime.bitpix = int16(128); precision = 'float64'; 105 | otherwise 106 | error('This datatype is not supported'); 107 | end 108 | 109 | if filetype == 2 110 | fid = fopen(sprintf('%s.nii',fileprefix),'w'); 111 | 112 | if fid < 0, 113 | msg = sprintf('Cannot open file %s.nii.',fileprefix); 114 | error(msg); 115 | end 116 | 117 | hdr.dime.vox_offset = 352; 118 | 119 | if ~isempty(ext) 120 | hdr.dime.vox_offset = hdr.dime.vox_offset + esize_total; 121 | end 122 | 123 | hdr.hist.magic = 'n+1'; 124 | save_untouch_nii_hdr(hdr, fid); 125 | 126 | if ~isempty(ext) 127 | save_nii_ext(ext, fid); 128 | end 129 | elseif filetype == 1 130 | fid = fopen(sprintf('%s.hdr',fileprefix),'w'); 131 | 132 | if fid < 0, 133 | msg = sprintf('Cannot open file %s.hdr.',fileprefix); 134 | error(msg); 135 | end 136 | 137 | hdr.dime.vox_offset = 0; 138 | hdr.hist.magic = 'ni1'; 139 | save_untouch_nii_hdr(hdr, fid); 140 | 141 | if ~isempty(ext) 142 | save_nii_ext(ext, fid); 143 | end 144 | 145 | fclose(fid); 146 | fid = fopen(sprintf('%s.img',fileprefix),'w'); 147 | else 148 | fid = fopen(sprintf('%s.hdr',fileprefix),'w'); 149 | 150 | if fid < 0, 151 | msg = sprintf('Cannot open file %s.hdr.',fileprefix); 152 | error(msg); 153 | end 154 | 155 | save_untouch0_nii_hdr(hdr, fid); 156 | 157 | fclose(fid); 158 | fid = fopen(sprintf('%s.img',fileprefix),'w'); 159 | end 160 | 161 | if filetype == 2 & isempty(ext) 162 | skip_bytes = double(hdr.dime.vox_offset) - 348; 163 | else 164 | skip_bytes = 0; 165 | end 166 | 167 | if skip_bytes 168 | fwrite(fid, zeros(1,skip_bytes), 'uint8'); 169 | end 170 | 171 | glmax = -inf; 172 | glmin = inf; 173 | 174 | for i = 1:length(flist) 175 | nii = load_untouch_nii(fullfile(scan_path,flist{i})); 176 | 177 | if double(hdr.dime.datatype) == 128 178 | 179 | % RGB planes are expected to be in the 4th dimension of nii.img 180 | % 181 | if(size(nii.img,4)~=3) 182 | error(['The NII structure does not appear to have 3 RGB color planes in the 4th dimension']); 183 | end 184 | 185 | nii.img = permute(nii.img, [4 1 2 3 5 6 7 8]); 186 | end 187 | 188 | % For complex float32 or complex float64, voxel values 189 | % include [real, imag] 190 | % 191 | if hdr.dime.datatype == 32 | hdr.dime.datatype == 1792 192 | real_img = real(nii.img(:))'; 193 | nii.img = imag(nii.img(:))'; 194 | nii.img = [real_img; nii.img]; 195 | end 196 | 197 | if nii.hdr.dime.glmax > glmax 198 | glmax = nii.hdr.dime.glmax; 199 | end 200 | 201 | if nii.hdr.dime.glmin < glmin 202 | glmin = nii.hdr.dime.glmin; 203 | end 204 | 205 | fwrite(fid, nii.img, precision); 206 | end 207 | 208 | hdr.dime.glmax = round(glmax); 209 | hdr.dime.glmin = round(glmin); 210 | 211 | if filetype == 2 212 | fseek(fid, 140, 'bof'); 213 | fwrite(fid, hdr.dime.glmax, 'int32'); 214 | fwrite(fid, hdr.dime.glmin, 'int32'); 215 | elseif filetype == 1 216 | fid2 = fopen(sprintf('%s.hdr',fileprefix),'w'); 217 | 218 | if fid2 < 0, 219 | msg = sprintf('Cannot open file %s.hdr.',fileprefix); 220 | error(msg); 221 | end 222 | 223 | save_untouch_nii_hdr(hdr, fid2); 224 | 225 | if ~isempty(ext) 226 | save_nii_ext(ext, fid2); 227 | end 228 | 229 | fclose(fid2); 230 | else 231 | fid2 = fopen(sprintf('%s.hdr',fileprefix),'w'); 232 | 233 | if fid2 < 0, 234 | msg = sprintf('Cannot open file %s.hdr.',fileprefix); 235 | error(msg); 236 | end 237 | 238 | save_untouch0_nii_hdr(hdr, fid2); 239 | 240 | fclose(fid2); 241 | end 242 | 243 | fclose(fid); 244 | 245 | % gzip output file if requested 246 | % 247 | if exist('gzFile', 'var') 248 | if filetype == 1 249 | gzip([fileprefix, '.img']); 250 | delete([fileprefix, '.img']); 251 | gzip([fileprefix, '.hdr']); 252 | delete([fileprefix, '.hdr']); 253 | elseif filetype == 2 254 | gzip([fileprefix, '.nii']); 255 | delete([fileprefix, '.nii']); 256 | end; 257 | end; 258 | 259 | return; % collapse_nii_scan 260 | 261 | -------------------------------------------------------------------------------- /NIFTI/examples.txt: -------------------------------------------------------------------------------- 1 | 2 | - Examples to load, make and save a nii struct: 3 | 4 | To load Analyze data or NIFTI data to a structure: 5 | 6 | nii = load_nii(NIFTI_file_name, [img_idx], [old_RGB24]); 7 | 8 | img_idx is a numerical array of image indices along the temporal 9 | axis, which is only available in NIFTI data. After you specify 10 | img_idx, only those images indexed by img_idx will be loaded. If 11 | there is no img_idx or img_idx is empty, all available images 12 | will be loaded. 13 | 14 | For RGB image, most people use RGB triple sequentially for each 15 | voxel, like [R1 G1 B1 R2 G2 B2 ...]. However, some program like 16 | Analyze 6.0 developed by AnalyzeDirect uses old RGB24, in a way 17 | like [R1 R2 ... G1 G2 ... B1 B2 ...] for each slices. In this 18 | case, you can set old_RGB24 flag to 1 and load data correctly: 19 | 20 | nii = load_nii(NIFTI_file_name, [], 1); 21 | 22 | To get a total number of images along the temporal axis: 23 | 24 | num_scan = get_nii_frame(NIFTI_file_name); 25 | 26 | You can also load the header extension if it exists: 27 | 28 | nii.ext = load_nii_ext(NIFTI_file_name); 29 | 30 | You can just load the Analyze or NIFTI header: 31 | (header contains: hk, dime, and hist) 32 | 33 | hdr = load_nii_hdr(NIFTI_file_name); 34 | 35 | You can also save the structure to a new file: 36 | (header extension will be saved if there is nii.ext structure) 37 | 38 | save_nii(nii, NIFTI_file_name); 39 | 40 | To make the structure from any 3D (or 4D) data: 41 | 42 | img = rand(91,109,91); or 43 | img = rand(64,64,21,18); 44 | nii = make_nii(img [, voxel_size, origin, datatype] ); 45 | 46 | Use "help load_nii", "help save_nii", "help make_nii" etc. 47 | to get more detail information. 48 | 49 | 50 | - Examples to plot a nii struct: 51 | (More detail descriptions are available on top of "view_nii.m") 52 | 53 | Simple way to plot a nii struct: 54 | 55 | view_nii(nii); 56 | 57 | The default colormap will use the Gray if all data values are 58 | non-negative; otherwise, the default colormap will use BiPolar. 59 | You can choose other colormap, including customized colormap 60 | from panel. 61 | 62 | To imbed the plot into your existing figure: 63 | 64 | h = gcf; 65 | opt.command = 'init'; 66 | opt.setarea = [0.3 0.1 0.6 0.8]; 67 | view_nii(h, nii, opt); 68 | 69 | To add a colorbar: 70 | 71 | opt.usecolorbar = 1; 72 | view_nii(gcf, opt); 73 | 74 | Here, opt.command is implicitly set to 'update'. 75 | 76 | To display in real aspect ratio: 77 | 78 | opt.usestretch = 0; 79 | view_nii(gcf, opt); 80 | 81 | If you want the data value to be directly used as the index 82 | of colormap, instead of scale to the whole colormap: 83 | 84 | opt.useimagesc = 0; 85 | view_nii(gcf, opt); 86 | 87 | If you modified the data value without changing the dimension, 88 | voxel_size, and origin, you can update the display by: 89 | 90 | opt.command = 'updateimg'; 91 | view_nii(gcf, nii.img, opt); 92 | 93 | If the data is completely different, display can be updated by: 94 | 95 | opt.command = 'updatenii'; 96 | view_nii(gcf, nii, opt); 97 | 98 | This is an example to plot EEG source imaging on top of T1 background: 99 | 1. download overlay.zip and unzip it from: 100 | http://www.rotman-baycrest.on.ca/~jimmy/NIFTI/overlay.zip 101 | 2. T1 = load_nii('T1.nii'); 102 | 3. EEG = load_nii('EEG.nii'); 103 | 4. option.setvalue.idx = find(EEG.img); 104 | 5. option.setvalue.val = EEG.img(option.setvalue.idx); 105 | 6. option.useinterp = 1; 106 | 7. option.setviewpoint = [62 48 46]; 107 | 8. view_nii(T1, option); 108 | 109 | 110 | - Contrast and Brightness are available under Gray and Bipolar colormap: 111 | 112 | Increase contrast in Gray colormap will make high end values 113 | more distinguishable by sacrificing the low end values; The 114 | minimum contrast (default) will display the whole range. 115 | 116 | Increase or decrease contrast in BiPolar colormap will shift 117 | the distinguishable position for both positive and negative 118 | values. 119 | 120 | Increase or decrease brightness in Gray colormap will shift 121 | the distinguishable position. 122 | 123 | Increase or decrease brightness in BiPolar colormap will make 124 | both positive and negative values more distinguishable. 125 | 126 | 127 | - Required files: 128 | 129 | All files in this package. 130 | 131 | -------------------------------------------------------------------------------- /NIFTI/expand_nii_scan.m: -------------------------------------------------------------------------------- 1 | % Expand a multiple-scan NIFTI file into multiple single-scan NIFTI files 2 | % 3 | % Usage: expand_nii_scan(multi_scan_filename, [img_idx], [path_to_save]) 4 | % 5 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 6 | % 7 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 8 | % 9 | function expand_nii_scan(filename, img_idx, newpath) 10 | 11 | v = version; 12 | 13 | % Check file extension. If .gz, unpack it into temp folder 14 | % 15 | if length(filename) > 2 & strcmp(filename(end-2:end), '.gz') 16 | 17 | if ~strcmp(filename(end-6:end), '.img.gz') & ... 18 | ~strcmp(filename(end-6:end), '.hdr.gz') & ... 19 | ~strcmp(filename(end-6:end), '.nii.gz') 20 | 21 | error('Please check filename.'); 22 | end 23 | 24 | if str2num(v(1:3)) < 7.1 | ~usejava('jvm') 25 | error('Please use MATLAB 7.1 (with java) and above, or run gunzip outside MATLAB.'); 26 | else 27 | gzFile = 1; 28 | end 29 | end 30 | 31 | if ~exist('newpath','var') | isempty(newpath), newpath = pwd; end 32 | if ~exist('img_idx','var') | isempty(img_idx), img_idx = 1:get_nii_frame(filename); end 33 | 34 | for i=img_idx 35 | nii_i = load_untouch_nii(filename, i); 36 | 37 | fn = [nii_i.fileprefix '_' sprintf('%04d',i)]; 38 | pnfn = fullfile(newpath, fn); 39 | 40 | if exist('gzFile', 'var') 41 | pnfn = [pnfn '.nii.gz']; 42 | end 43 | 44 | save_untouch_nii(nii_i, pnfn); 45 | end 46 | 47 | return; % expand_nii_scan 48 | 49 | -------------------------------------------------------------------------------- /NIFTI/extra_nii_hdr.m: -------------------------------------------------------------------------------- 1 | % Decode extra NIFTI header information into hdr.extra 2 | % 3 | % Usage: hdr = extra_nii_hdr(hdr) 4 | % 5 | % hdr can be obtained from load_nii_hdr 6 | % 7 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 8 | % 9 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 10 | % 11 | function hdr = extra_nii_hdr(hdr) 12 | 13 | switch hdr.dime.datatype 14 | case 1 15 | extra.NIFTI_DATATYPES = 'DT_BINARY'; 16 | case 2 17 | extra.NIFTI_DATATYPES = 'DT_UINT8'; 18 | case 4 19 | extra.NIFTI_DATATYPES = 'DT_INT16'; 20 | case 8 21 | extra.NIFTI_DATATYPES = 'DT_INT32'; 22 | case 16 23 | extra.NIFTI_DATATYPES = 'DT_FLOAT32'; 24 | case 32 25 | extra.NIFTI_DATATYPES = 'DT_COMPLEX64'; 26 | case 64 27 | extra.NIFTI_DATATYPES = 'DT_FLOAT64'; 28 | case 128 29 | extra.NIFTI_DATATYPES = 'DT_RGB24'; 30 | case 256 31 | extra.NIFTI_DATATYPES = 'DT_INT8'; 32 | case 512 33 | extra.NIFTI_DATATYPES = 'DT_UINT16'; 34 | case 768 35 | extra.NIFTI_DATATYPES = 'DT_UINT32'; 36 | case 1024 37 | extra.NIFTI_DATATYPES = 'DT_INT64'; 38 | case 1280 39 | extra.NIFTI_DATATYPES = 'DT_UINT64'; 40 | case 1536 41 | extra.NIFTI_DATATYPES = 'DT_FLOAT128'; 42 | case 1792 43 | extra.NIFTI_DATATYPES = 'DT_COMPLEX128'; 44 | case 2048 45 | extra.NIFTI_DATATYPES = 'DT_COMPLEX256'; 46 | otherwise 47 | extra.NIFTI_DATATYPES = 'DT_UNKNOWN'; 48 | end 49 | 50 | switch hdr.dime.intent_code 51 | case 2 52 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_CORREL'; 53 | case 3 54 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_TTEST'; 55 | case 4 56 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_FTEST'; 57 | case 5 58 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_ZSCORE'; 59 | case 6 60 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_CHISQ'; 61 | case 7 62 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_BETA'; 63 | case 8 64 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_BINOM'; 65 | case 9 66 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_GAMMA'; 67 | case 10 68 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_POISSON'; 69 | case 11 70 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_NORMAL'; 71 | case 12 72 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_FTEST_NONC'; 73 | case 13 74 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_CHISQ_NONC'; 75 | case 14 76 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_LOGISTIC'; 77 | case 15 78 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_LAPLACE'; 79 | case 16 80 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_UNIFORM'; 81 | case 17 82 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_TTEST_NONC'; 83 | case 18 84 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_WEIBULL'; 85 | case 19 86 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_CHI'; 87 | case 20 88 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_INVGAUSS'; 89 | case 21 90 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_EXTVAL'; 91 | case 22 92 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_PVAL'; 93 | case 23 94 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_LOGPVAL'; 95 | case 24 96 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_LOG10PVAL'; 97 | case 1001 98 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_ESTIMATE'; 99 | case 1002 100 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_LABEL'; 101 | case 1003 102 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_NEURONAME'; 103 | case 1004 104 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_GENMATRIX'; 105 | case 1005 106 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_SYMMATRIX'; 107 | case 1006 108 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_DISPVECT'; 109 | case 1007 110 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_VECTOR'; 111 | case 1008 112 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_POINTSET'; 113 | case 1009 114 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_TRIANGLE'; 115 | case 1010 116 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_QUATERNION'; 117 | case 1011 118 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_DIMLESS'; 119 | otherwise 120 | extra.NIFTI_INTENT_CODES = 'NIFTI_INTENT_NONE'; 121 | end 122 | 123 | extra.NIFTI_INTENT_NAMES = hdr.hist.intent_name; 124 | 125 | if hdr.hist.sform_code > 0 126 | switch hdr.hist.sform_code 127 | case 1 128 | extra.NIFTI_SFORM_CODES = 'NIFTI_XFORM_SCANNER_ANAT'; 129 | case 2 130 | extra.NIFTI_SFORM_CODES = 'NIFTI_XFORM_ALIGNED_ANAT'; 131 | case 3 132 | extra.NIFTI_SFORM_CODES = 'NIFTI_XFORM_TALAIRACH'; 133 | case 4 134 | extra.NIFTI_SFORM_CODES = 'NIFTI_XFORM_MNI_152'; 135 | otherwise 136 | extra.NIFTI_SFORM_CODES = 'NIFTI_XFORM_UNKNOWN'; 137 | end 138 | 139 | extra.NIFTI_QFORM_CODES = 'NIFTI_XFORM_UNKNOWN'; 140 | elseif hdr.hist.qform_code > 0 141 | extra.NIFTI_SFORM_CODES = 'NIFTI_XFORM_UNKNOWN'; 142 | 143 | switch hdr.hist.qform_code 144 | case 1 145 | extra.NIFTI_QFORM_CODES = 'NIFTI_XFORM_SCANNER_ANAT'; 146 | case 2 147 | extra.NIFTI_QFORM_CODES = 'NIFTI_XFORM_ALIGNED_ANAT'; 148 | case 3 149 | extra.NIFTI_QFORM_CODES = 'NIFTI_XFORM_TALAIRACH'; 150 | case 4 151 | extra.NIFTI_QFORM_CODES = 'NIFTI_XFORM_MNI_152'; 152 | otherwise 153 | extra.NIFTI_QFORM_CODES = 'NIFTI_XFORM_UNKNOWN'; 154 | end 155 | else 156 | extra.NIFTI_SFORM_CODES = 'NIFTI_XFORM_UNKNOWN'; 157 | extra.NIFTI_QFORM_CODES = 'NIFTI_XFORM_UNKNOWN'; 158 | end 159 | 160 | switch bitand(hdr.dime.xyzt_units, 7) % mask with 0x07 161 | case 1 162 | extra.NIFTI_SPACE_UNIT = 'NIFTI_UNITS_METER'; 163 | case 2 164 | extra.NIFTI_SPACE_UNIT = 'NIFTI_UNITS_MM'; % millimeter 165 | case 3 166 | extra.NIFTI_SPACE_UNIT = 'NIFTI_UNITS_MICRO'; 167 | otherwise 168 | extra.NIFTI_SPACE_UNIT = 'NIFTI_UNITS_UNKNOWN'; 169 | end 170 | 171 | switch bitand(hdr.dime.xyzt_units, 56) % mask with 0x38 172 | case 8 173 | extra.NIFTI_TIME_UNIT = 'NIFTI_UNITS_SEC'; 174 | case 16 175 | extra.NIFTI_TIME_UNIT = 'NIFTI_UNITS_MSEC'; 176 | case 24 177 | extra.NIFTI_TIME_UNIT = 'NIFTI_UNITS_USEC'; % microsecond 178 | otherwise 179 | extra.NIFTI_TIME_UNIT = 'NIFTI_UNITS_UNKNOWN'; 180 | end 181 | 182 | switch hdr.dime.xyzt_units 183 | case 32 184 | extra.NIFTI_SPECTRAL_UNIT = 'NIFTI_UNITS_HZ'; 185 | case 40 186 | extra.NIFTI_SPECTRAL_UNIT = 'NIFTI_UNITS_PPM'; % part per million 187 | case 48 188 | extra.NIFTI_SPECTRAL_UNIT = 'NIFTI_UNITS_RADS'; % radians per second 189 | otherwise 190 | extra.NIFTI_SPECTRAL_UNIT = 'NIFTI_UNITS_UNKNOWN'; 191 | end 192 | 193 | % MRI-specific spatial and temporal information 194 | % 195 | dim_info = hdr.hk.dim_info; 196 | extra.NIFTI_FREQ_DIM = bitand(dim_info, 3); 197 | extra.NIFTI_PHASE_DIM = bitand(bitshift(dim_info, -2), 3); 198 | extra.NIFTI_SLICE_DIM = bitand(bitshift(dim_info, -4), 3); 199 | 200 | % Check slice code 201 | % 202 | switch hdr.dime.slice_code 203 | case 1 204 | extra.NIFTI_SLICE_ORDER = 'NIFTI_SLICE_SEQ_INC'; % sequential increasing 205 | case 2 206 | extra.NIFTI_SLICE_ORDER = 'NIFTI_SLICE_SEQ_DEC'; % sequential decreasing 207 | case 3 208 | extra.NIFTI_SLICE_ORDER = 'NIFTI_SLICE_ALT_INC'; % alternating increasing 209 | case 4 210 | extra.NIFTI_SLICE_ORDER = 'NIFTI_SLICE_ALT_DEC'; % alternating decreasing 211 | case 5 212 | extra.NIFTI_SLICE_ORDER = 'NIFTI_SLICE_ALT_INC2'; % ALT_INC # 2 213 | case 6 214 | extra.NIFTI_SLICE_ORDER = 'NIFTI_SLICE_ALT_DEC2'; % ALT_DEC # 2 215 | otherwise 216 | extra.NIFTI_SLICE_ORDER = 'NIFTI_SLICE_UNKNOWN'; 217 | end 218 | 219 | % Check NIFTI version 220 | % 221 | if ~isempty(hdr.hist.magic) & strcmp(hdr.hist.magic(1),'n') & ... 222 | ( strcmp(hdr.hist.magic(2),'i') | strcmp(hdr.hist.magic(2),'+') ) & ... 223 | str2num(hdr.hist.magic(3)) >= 1 & str2num(hdr.hist.magic(3)) <= 9 224 | 225 | extra.NIFTI_VERSION = str2num(hdr.hist.magic(3)); 226 | else 227 | extra.NIFTI_VERSION = 0; 228 | end 229 | 230 | % Check if data stored in the same file (*.nii) or separate 231 | % files (*.hdr/*.img) 232 | % 233 | if isempty(hdr.hist.magic) 234 | extra.NIFTI_ONEFILE = 0; 235 | else 236 | extra.NIFTI_ONEFILE = strcmp(hdr.hist.magic(2), '+'); 237 | end 238 | 239 | % Swap has been taken care of by checking whether sizeof_hdr is 240 | % 348 (machine is 'ieee-le' or 'ieee-be' etc) 241 | % 242 | % extra.NIFTI_NEEDS_SWAP = (hdr.dime.dim(1) < 0 | hdr.dime.dim(1) > 7); 243 | 244 | % Check NIFTI header struct contains a 5th (vector) dimension 245 | % 246 | if hdr.dime.dim(1) > 4 & hdr.dime.dim(6) > 1 247 | extra.NIFTI_5TH_DIM = hdr.dime.dim(6); 248 | else 249 | extra.NIFTI_5TH_DIM = 0; 250 | end 251 | 252 | hdr.extra = extra; 253 | 254 | return; % extra_nii_hdr 255 | 256 | -------------------------------------------------------------------------------- /NIFTI/flip_lr.m: -------------------------------------------------------------------------------- 1 | % When you load any ANALYZE or NIfTI file with 'load_nii.m', and view 2 | % it with 'view_nii.m', you may find that the image is L-R flipped. 3 | % This is because of the confusion of radiological and neurological 4 | % convention in the medical image before NIfTI format is adopted. You 5 | % can find more details from: 6 | % 7 | % http://www.rotman-baycrest.on.ca/~jimmy/UseANALYZE.htm 8 | % 9 | % Sometime, people even want to convert RAS (standard orientation) back 10 | % to LAS orientation to satisfy the legend programs or processes. This 11 | % program is only written for those purpose. So PLEASE BE VERY CAUTIOUS 12 | % WHEN USING THIS 'FLIP_LR.M' PROGRAM. 13 | % 14 | % With 'flip_lr.m', you can convert any ANALYZE or NIfTI (no matter 15 | % 3D or 4D) file to a flipped NIfTI file. This is implemented simply 16 | % by flipping the affine matrix in the NIfTI header. Since the L-R 17 | % orientation is determined there, so the image will be flipped. 18 | % 19 | % Usage: flip_lr(original_fn, flipped_fn, [old_RGB],[tolerance],[preferredForm]) 20 | % 21 | % original_fn - filename of the original ANALYZE or NIfTI (3D or 4D) file 22 | % 23 | % flipped_fn - filename of the L-R flipped NIfTI file 24 | % 25 | % old_RGB (optional) - a scale number to tell difference of new RGB24 26 | % from old RGB24. New RGB24 uses RGB triple sequentially for each 27 | % voxel, like [R1 G1 B1 R2 G2 B2 ...]. Analyze 6.0 from AnalyzeDirect 28 | % uses old RGB24, in a way like [R1 R2 ... G1 G2 ... B1 B2 ...] for 29 | % each slices. If the image that you view is garbled, try to set 30 | % old_RGB variable to 1 and try again, because it could be in 31 | % old RGB24. It will be set to 0, if it is default or empty. 32 | % 33 | % tolerance (optional) - distortion allowed for non-orthogonal rotation 34 | % or shearing in NIfTI affine matrix. It will be set to 0.1 (10%), 35 | % if it is default or empty. 36 | % 37 | % preferredForm (optional) - selects which transformation from voxels 38 | % to RAS coordinates; values are s,q,S,Q. Lower case s,q indicate 39 | % "prefer sform or qform, but use others if preferred not present". 40 | % Upper case indicate the program is forced to use the specificied 41 | % tranform or fail loading. 'preferredForm' will be 's', if it is 42 | % default or empty. - Jeff Gunter 43 | % 44 | % Example: flip_lr('avg152T1_LR_nifti.nii', 'flipped_lr.nii'); 45 | % flip_lr('avg152T1_RL_nifti.nii', 'flipped_rl.nii'); 46 | % 47 | % You will find that 'avg152T1_LR_nifti.nii' and 'avg152T1_RL_nifti.nii' 48 | % are the same, and 'flipped_lr.nii' and 'flipped_rl.nii' are also the 49 | % the same, but they are L-R flipped from 'avg152T1_*'. 50 | % 51 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 52 | % 53 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 54 | % 55 | function flip_lr(original_fn, flipped_fn, old_RGB, tolerance, preferredForm) 56 | 57 | if ~exist('original_fn','var') | ~exist('flipped_fn','var') 58 | error('Usage: flip_lr(original_fn, flipped_fn, [old_RGB],[tolerance])'); 59 | end 60 | 61 | if ~exist('old_RGB','var') | isempty(old_RGB) 62 | old_RGB = 0; 63 | end 64 | 65 | if ~exist('tolerance','var') | isempty(tolerance) 66 | tolerance = 0.1; 67 | end 68 | 69 | if ~exist('preferredForm','var') | isempty(preferredForm) 70 | preferredForm= 's'; % Jeff 71 | end 72 | 73 | nii = load_nii(original_fn, [], [], [], [], old_RGB, tolerance, preferredForm); 74 | M = diag(nii.hdr.dime.pixdim(2:5)); 75 | M(1:3,4) = -M(1:3,1:3)*(nii.hdr.hist.originator(1:3)-1)'; 76 | M(1,:) = -1*M(1,:); 77 | nii.hdr.hist.sform_code = 1; 78 | nii.hdr.hist.srow_x = M(1,:); 79 | nii.hdr.hist.srow_y = M(2,:); 80 | nii.hdr.hist.srow_z = M(3,:); 81 | save_nii(nii, flipped_fn); 82 | 83 | return; % flip_lr 84 | 85 | -------------------------------------------------------------------------------- /NIFTI/get_nii_frame.m: -------------------------------------------------------------------------------- 1 | % Return time frame of a NIFTI dataset. Support both *.nii and 2 | % *.hdr/*.img file extension. If file extension is not provided, 3 | % *.hdr/*.img will be used as default. 4 | % 5 | % It is a lightweighted "load_nii_hdr", and is equivalent to 6 | % hdr.dime.dim(5) 7 | % 8 | % Usage: [ total_scan ] = get_nii_frame(filename) 9 | % 10 | % filename - NIFTI file name. 11 | % 12 | % Returned values: 13 | % 14 | % total_scan - total number of image scans for the time frame 15 | % 16 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 17 | % 18 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 19 | % 20 | function [ total_scan ] = get_nii_frame(filename) 21 | 22 | if ~exist('filename','var'), 23 | error('Usage: [ total_scan ] = get_nii_frame(filename)'); 24 | end 25 | 26 | v = version; 27 | 28 | % Check file extension. If .gz, unpack it into temp folder 29 | % 30 | if length(filename) > 2 & strcmp(filename(end-2:end), '.gz') 31 | 32 | if ~strcmp(filename(end-6:end), '.img.gz') & ... 33 | ~strcmp(filename(end-6:end), '.hdr.gz') & ... 34 | ~strcmp(filename(end-6:end), '.nii.gz') 35 | 36 | error('Please check filename.'); 37 | end 38 | 39 | if str2num(v(1:3)) < 7.1 | ~usejava('jvm') 40 | error('Please use MATLAB 7.1 (with java) and above, or run gunzip outside MATLAB.'); 41 | elseif strcmp(filename(end-6:end), '.img.gz') 42 | filename1 = filename; 43 | filename2 = filename; 44 | filename2(end-6:end) = ''; 45 | filename2 = [filename2, '.hdr.gz']; 46 | 47 | tmpDir = tempname; 48 | mkdir(tmpDir); 49 | gzFileName = filename; 50 | 51 | filename1 = gunzip(filename1, tmpDir); 52 | filename2 = gunzip(filename2, tmpDir); 53 | filename = char(filename1); % convert from cell to string 54 | elseif strcmp(filename(end-6:end), '.hdr.gz') 55 | filename1 = filename; 56 | filename2 = filename; 57 | filename2(end-6:end) = ''; 58 | filename2 = [filename2, '.img.gz']; 59 | 60 | tmpDir = tempname; 61 | mkdir(tmpDir); 62 | gzFileName = filename; 63 | 64 | filename1 = gunzip(filename1, tmpDir); 65 | filename2 = gunzip(filename2, tmpDir); 66 | filename = char(filename1); % convert from cell to string 67 | elseif strcmp(filename(end-6:end), '.nii.gz') 68 | tmpDir = tempname; 69 | mkdir(tmpDir); 70 | gzFileName = filename; 71 | filename = gunzip(filename, tmpDir); 72 | filename = char(filename); % convert from cell to string 73 | end 74 | end 75 | 76 | fileprefix = filename; 77 | machine = 'ieee-le'; 78 | new_ext = 0; 79 | 80 | if findstr('.nii',fileprefix) & strcmp(fileprefix(end-3:end), '.nii') 81 | new_ext = 1; 82 | fileprefix(end-3:end)=''; 83 | end 84 | 85 | if findstr('.hdr',fileprefix) & strcmp(fileprefix(end-3:end), '.hdr') 86 | fileprefix(end-3:end)=''; 87 | end 88 | 89 | if findstr('.img',fileprefix) & strcmp(fileprefix(end-3:end), '.img') 90 | fileprefix(end-3:end)=''; 91 | end 92 | 93 | if new_ext 94 | fn = sprintf('%s.nii',fileprefix); 95 | 96 | if ~exist(fn) 97 | msg = sprintf('Cannot find file "%s.nii".', fileprefix); 98 | error(msg); 99 | end 100 | else 101 | fn = sprintf('%s.hdr',fileprefix); 102 | 103 | if ~exist(fn) 104 | msg = sprintf('Cannot find file "%s.hdr".', fileprefix); 105 | error(msg); 106 | end 107 | end 108 | 109 | fid = fopen(fn,'r',machine); 110 | 111 | if fid < 0, 112 | msg = sprintf('Cannot open file %s.',fn); 113 | error(msg); 114 | else 115 | hdr = read_header(fid); 116 | fclose(fid); 117 | end 118 | 119 | if hdr.sizeof_hdr ~= 348 120 | % first try reading the opposite endian to 'machine' 121 | switch machine, 122 | case 'ieee-le', machine = 'ieee-be'; 123 | case 'ieee-be', machine = 'ieee-le'; 124 | end 125 | 126 | fid = fopen(fn,'r',machine); 127 | 128 | if fid < 0, 129 | msg = sprintf('Cannot open file %s.',fn); 130 | error(msg); 131 | else 132 | hdr = read_header(fid); 133 | fclose(fid); 134 | end 135 | end 136 | 137 | if hdr.sizeof_hdr ~= 348 138 | % Now throw an error 139 | msg = sprintf('File "%s" is corrupted.',fn); 140 | error(msg); 141 | end 142 | 143 | total_scan = hdr.dim(5); 144 | 145 | % Clean up after gunzip 146 | % 147 | if exist('gzFileName', 'var') 148 | rmdir(tmpDir,'s'); 149 | end 150 | 151 | return; % get_nii_frame 152 | 153 | 154 | %--------------------------------------------------------------------- 155 | function [ dsr ] = read_header(fid) 156 | 157 | fseek(fid,0,'bof'); 158 | dsr.sizeof_hdr = fread(fid,1,'int32')'; % should be 348! 159 | 160 | fseek(fid,40,'bof'); 161 | dsr.dim = fread(fid,8,'int16')'; 162 | 163 | return; % read_header 164 | 165 | -------------------------------------------------------------------------------- /NIFTI/license.txt: -------------------------------------------------------------------------------- 1 | Copyright (c) 2009, Jimmy Shen 2 | All rights reserved. 3 | 4 | Redistribution and use in source and binary forms, with or without 5 | modification, are permitted provided that the following conditions are 6 | met: 7 | 8 | * Redistributions of source code must retain the above copyright 9 | notice, this list of conditions and the following disclaimer. 10 | * Redistributions in binary form must reproduce the above copyright 11 | notice, this list of conditions and the following disclaimer in 12 | the documentation and/or other materials provided with the distribution 13 | 14 | THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" 15 | AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE 16 | IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE 17 | ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE 18 | LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR 19 | CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF 20 | SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS 21 | INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN 22 | CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) 23 | ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE 24 | POSSIBILITY OF SUCH DAMAGE. 25 | -------------------------------------------------------------------------------- /NIFTI/load_nii.m: -------------------------------------------------------------------------------- 1 | % Load NIFTI or ANALYZE dataset. Support both *.nii and *.hdr/*.img 2 | % file extension. If file extension is not provided, *.hdr/*.img will 3 | % be used as default. 4 | % 5 | % A subset of NIFTI transform is included. For non-orthogonal rotation, 6 | % shearing etc., please use 'reslice_nii.m' to reslice the NIFTI file. 7 | % It will not cause negative effect, as long as you remember not to do 8 | % slice time correction after reslicing the NIFTI file. Output variable 9 | % nii will be in RAS orientation, i.e. X axis from Left to Right, 10 | % Y axis from Posterior to Anterior, and Z axis from Inferior to 11 | % Superior. 12 | % 13 | % Usage: nii = load_nii(filename, [img_idx], [dim5_idx], [dim6_idx], ... 14 | % [dim7_idx], [old_RGB], [tolerance], [preferredForm]) 15 | % 16 | % filename - NIFTI or ANALYZE file name. 17 | % 18 | % img_idx (optional) - a numerical array of 4th dimension indices, 19 | % which is the indices of image scan volume. The number of images 20 | % scan volumes can be obtained from get_nii_frame.m, or simply 21 | % hdr.dime.dim(5). Only the specified volumes will be loaded. 22 | % All available image volumes will be loaded, if it is default or 23 | % empty. 24 | % 25 | % dim5_idx (optional) - a numerical array of 5th dimension indices. 26 | % Only the specified range will be loaded. All available range 27 | % will be loaded, if it is default or empty. 28 | % 29 | % dim6_idx (optional) - a numerical array of 6th dimension indices. 30 | % Only the specified range will be loaded. All available range 31 | % will be loaded, if it is default or empty. 32 | % 33 | % dim7_idx (optional) - a numerical array of 7th dimension indices. 34 | % Only the specified range will be loaded. All available range 35 | % will be loaded, if it is default or empty. 36 | % 37 | % old_RGB (optional) - a scale number to tell difference of new RGB24 38 | % from old RGB24. New RGB24 uses RGB triple sequentially for each 39 | % voxel, like [R1 G1 B1 R2 G2 B2 ...]. Analyze 6.0 from AnalyzeDirect 40 | % uses old RGB24, in a way like [R1 R2 ... G1 G2 ... B1 B2 ...] for 41 | % each slices. If the image that you view is garbled, try to set 42 | % old_RGB variable to 1 and try again, because it could be in 43 | % old RGB24. It will be set to 0, if it is default or empty. 44 | % 45 | % tolerance (optional) - distortion allowed in the loaded image for any 46 | % non-orthogonal rotation or shearing of NIfTI affine matrix. If 47 | % you set 'tolerance' to 0, it means that you do not allow any 48 | % distortion. If you set 'tolerance' to 1, it means that you do 49 | % not care any distortion. The image will fail to be loaded if it 50 | % can not be tolerated. The tolerance will be set to 0.1 (10%), if 51 | % it is default or empty. 52 | % 53 | % preferredForm (optional) - selects which transformation from voxels 54 | % to RAS coordinates; values are s,q,S,Q. Lower case s,q indicate 55 | % "prefer sform or qform, but use others if preferred not present". 56 | % Upper case indicate the program is forced to use the specificied 57 | % tranform or fail loading. 'preferredForm' will be 's', if it is 58 | % default or empty. - Jeff Gunter 59 | % 60 | % Returned values: 61 | % 62 | % nii structure: 63 | % 64 | % hdr - struct with NIFTI header fields. 65 | % 66 | % filetype - Analyze format .hdr/.img (0); 67 | % NIFTI .hdr/.img (1); 68 | % NIFTI .nii (2) 69 | % 70 | % fileprefix - NIFTI filename without extension. 71 | % 72 | % machine - machine string variable. 73 | % 74 | % img - 3D (or 4D) matrix of NIFTI data. 75 | % 76 | % original - the original header before any affine transform. 77 | % 78 | % Part of this file is copied and modified from: 79 | % http://www.mathworks.com/matlabcentral/fileexchange/1878-mri-analyze-tools 80 | % 81 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 82 | % 83 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 84 | % 85 | function nii = load_nii(filename, img_idx, dim5_idx, dim6_idx, dim7_idx, ... 86 | old_RGB, tolerance, preferredForm) 87 | 88 | if ~exist('filename','var') 89 | error('Usage: nii = load_nii(filename, [img_idx], [dim5_idx], [dim6_idx], [dim7_idx], [old_RGB], [tolerance], [preferredForm])'); 90 | end 91 | 92 | if ~exist('img_idx','var') | isempty(img_idx) 93 | img_idx = []; 94 | end 95 | 96 | if ~exist('dim5_idx','var') | isempty(dim5_idx) 97 | dim5_idx = []; 98 | end 99 | 100 | if ~exist('dim6_idx','var') | isempty(dim6_idx) 101 | dim6_idx = []; 102 | end 103 | 104 | if ~exist('dim7_idx','var') | isempty(dim7_idx) 105 | dim7_idx = []; 106 | end 107 | 108 | if ~exist('old_RGB','var') | isempty(old_RGB) 109 | old_RGB = 0; 110 | end 111 | 112 | if ~exist('tolerance','var') | isempty(tolerance) 113 | tolerance = 0.1; % 10 percent 114 | end 115 | 116 | if ~exist('preferredForm','var') | isempty(preferredForm) 117 | preferredForm= 's'; % Jeff 118 | end 119 | 120 | v = version; 121 | 122 | % Check file extension. If .gz, unpack it into temp folder 123 | % 124 | if length(filename) > 2 & strcmp(filename(end-2:end), '.gz') 125 | 126 | if ~strcmp(filename(end-6:end), '.img.gz') & ... 127 | ~strcmp(filename(end-6:end), '.hdr.gz') & ... 128 | ~strcmp(filename(end-6:end), '.nii.gz') 129 | 130 | error('Please check filename.'); 131 | end 132 | 133 | if str2num(v(1:3)) < 7.1 | ~usejava('jvm') 134 | error('Please use MATLAB 7.1 (with java) and above, or run gunzip outside MATLAB.'); 135 | elseif strcmp(filename(end-6:end), '.img.gz') 136 | filename1 = filename; 137 | filename2 = filename; 138 | filename2(end-6:end) = ''; 139 | filename2 = [filename2, '.hdr.gz']; 140 | 141 | tmpDir = tempname; 142 | mkdir(tmpDir); 143 | gzFileName = filename; 144 | 145 | filename1 = gunzip(filename1, tmpDir); 146 | filename2 = gunzip(filename2, tmpDir); 147 | filename = char(filename1); % convert from cell to string 148 | elseif strcmp(filename(end-6:end), '.hdr.gz') 149 | filename1 = filename; 150 | filename2 = filename; 151 | filename2(end-6:end) = ''; 152 | filename2 = [filename2, '.img.gz']; 153 | 154 | tmpDir = tempname; 155 | mkdir(tmpDir); 156 | gzFileName = filename; 157 | 158 | filename1 = gunzip(filename1, tmpDir); 159 | filename2 = gunzip(filename2, tmpDir); 160 | filename = char(filename1); % convert from cell to string 161 | elseif strcmp(filename(end-6:end), '.nii.gz') 162 | tmpDir = tempname; 163 | mkdir(tmpDir); 164 | gzFileName = filename; 165 | filename = gunzip(filename, tmpDir); 166 | filename = char(filename); % convert from cell to string 167 | end 168 | end 169 | 170 | % Read the dataset header 171 | % 172 | [nii.hdr,nii.filetype,nii.fileprefix,nii.machine] = load_nii_hdr(filename); 173 | 174 | % Read the header extension 175 | % 176 | % nii.ext = load_nii_ext(filename); 177 | 178 | % Read the dataset body 179 | % 180 | [nii.img,nii.hdr] = load_nii_img(nii.hdr,nii.filetype,nii.fileprefix, ... 181 | nii.machine,img_idx,dim5_idx,dim6_idx,dim7_idx,old_RGB); 182 | 183 | % Perform some of sform/qform transform 184 | % 185 | nii = xform_nii(nii, tolerance, preferredForm); 186 | 187 | % Clean up after gunzip 188 | % 189 | if exist('gzFileName', 'var') 190 | 191 | % fix fileprefix so it doesn't point to temp location 192 | % 193 | nii.fileprefix = gzFileName(1:end-7); 194 | rmdir(tmpDir,'s'); 195 | end 196 | 197 | return % load_nii 198 | 199 | -------------------------------------------------------------------------------- /NIFTI/load_nii_ext.m: -------------------------------------------------------------------------------- 1 | % Load NIFTI header extension after its header is loaded using load_nii_hdr. 2 | % 3 | % Usage: ext = load_nii_ext(filename) 4 | % 5 | % filename - NIFTI file name. 6 | % 7 | % Returned values: 8 | % 9 | % ext - Structure of NIFTI header extension, which includes num_ext, 10 | % and all the extended header sections in the header extension. 11 | % Each extended header section will have its esize, ecode, and 12 | % edata, where edata can be plain text, xml, or any raw data 13 | % that was saved in the extended header section. 14 | % 15 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 16 | % 17 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 18 | % 19 | function ext = load_nii_ext(filename) 20 | 21 | if ~exist('filename','var'), 22 | error('Usage: ext = load_nii_ext(filename)'); 23 | end 24 | 25 | 26 | v = version; 27 | 28 | % Check file extension. If .gz, unpack it into temp folder 29 | % 30 | if length(filename) > 2 & strcmp(filename(end-2:end), '.gz') 31 | 32 | if ~strcmp(filename(end-6:end), '.img.gz') & ... 33 | ~strcmp(filename(end-6:end), '.hdr.gz') & ... 34 | ~strcmp(filename(end-6:end), '.nii.gz') 35 | 36 | error('Please check filename.'); 37 | end 38 | 39 | if str2num(v(1:3)) < 7.1 | ~usejava('jvm') 40 | error('Please use MATLAB 7.1 (with java) and above, or run gunzip outside MATLAB.'); 41 | elseif strcmp(filename(end-6:end), '.img.gz') 42 | filename1 = filename; 43 | filename2 = filename; 44 | filename2(end-6:end) = ''; 45 | filename2 = [filename2, '.hdr.gz']; 46 | 47 | tmpDir = tempname; 48 | mkdir(tmpDir); 49 | gzFileName = filename; 50 | 51 | filename1 = gunzip(filename1, tmpDir); 52 | filename2 = gunzip(filename2, tmpDir); 53 | filename = char(filename1); % convert from cell to string 54 | elseif strcmp(filename(end-6:end), '.hdr.gz') 55 | filename1 = filename; 56 | filename2 = filename; 57 | filename2(end-6:end) = ''; 58 | filename2 = [filename2, '.img.gz']; 59 | 60 | tmpDir = tempname; 61 | mkdir(tmpDir); 62 | gzFileName = filename; 63 | 64 | filename1 = gunzip(filename1, tmpDir); 65 | filename2 = gunzip(filename2, tmpDir); 66 | filename = char(filename1); % convert from cell to string 67 | elseif strcmp(filename(end-6:end), '.nii.gz') 68 | tmpDir = tempname; 69 | mkdir(tmpDir); 70 | gzFileName = filename; 71 | filename = gunzip(filename, tmpDir); 72 | filename = char(filename); % convert from cell to string 73 | end 74 | end 75 | 76 | machine = 'ieee-le'; 77 | new_ext = 0; 78 | 79 | if findstr('.nii',filename) & strcmp(filename(end-3:end), '.nii') 80 | new_ext = 1; 81 | filename(end-3:end)=''; 82 | end 83 | 84 | if findstr('.hdr',filename) & strcmp(filename(end-3:end), '.hdr') 85 | filename(end-3:end)=''; 86 | end 87 | 88 | if findstr('.img',filename) & strcmp(filename(end-3:end), '.img') 89 | filename(end-3:end)=''; 90 | end 91 | 92 | if new_ext 93 | fn = sprintf('%s.nii',filename); 94 | 95 | if ~exist(fn) 96 | msg = sprintf('Cannot find file "%s.nii".', filename); 97 | error(msg); 98 | end 99 | else 100 | fn = sprintf('%s.hdr',filename); 101 | 102 | if ~exist(fn) 103 | msg = sprintf('Cannot find file "%s.hdr".', filename); 104 | error(msg); 105 | end 106 | end 107 | 108 | fid = fopen(fn,'r',machine); 109 | vox_offset = 0; 110 | 111 | if fid < 0, 112 | msg = sprintf('Cannot open file %s.',fn); 113 | error(msg); 114 | else 115 | fseek(fid,0,'bof'); 116 | 117 | if fread(fid,1,'int32') == 348 118 | if new_ext 119 | fseek(fid,108,'bof'); 120 | vox_offset = fread(fid,1,'float32'); 121 | end 122 | 123 | ext = read_extension(fid, vox_offset); 124 | fclose(fid); 125 | else 126 | fclose(fid); 127 | 128 | % first try reading the opposite endian to 'machine' 129 | % 130 | switch machine, 131 | case 'ieee-le', machine = 'ieee-be'; 132 | case 'ieee-be', machine = 'ieee-le'; 133 | end 134 | 135 | fid = fopen(fn,'r',machine); 136 | 137 | if fid < 0, 138 | msg = sprintf('Cannot open file %s.',fn); 139 | error(msg); 140 | else 141 | fseek(fid,0,'bof'); 142 | 143 | if fread(fid,1,'int32') ~= 348 144 | 145 | % Now throw an error 146 | % 147 | msg = sprintf('File "%s" is corrupted.',fn); 148 | error(msg); 149 | end 150 | 151 | if new_ext 152 | fseek(fid,108,'bof'); 153 | vox_offset = fread(fid,1,'float32'); 154 | end 155 | 156 | ext = read_extension(fid, vox_offset); 157 | fclose(fid); 158 | end 159 | end 160 | end 161 | 162 | 163 | % Clean up after gunzip 164 | % 165 | if exist('gzFileName', 'var') 166 | rmdir(tmpDir,'s'); 167 | end 168 | 169 | 170 | return % load_nii_ext 171 | 172 | 173 | %--------------------------------------------------------------------- 174 | function ext = read_extension(fid, vox_offset) 175 | 176 | ext = []; 177 | 178 | if vox_offset 179 | end_of_ext = vox_offset; 180 | else 181 | fseek(fid, 0, 'eof'); 182 | end_of_ext = ftell(fid); 183 | end 184 | 185 | if end_of_ext > 352 186 | fseek(fid, 348, 'bof'); 187 | ext.extension = fread(fid,4)'; 188 | end 189 | 190 | if isempty(ext) | ext.extension(1) == 0 191 | ext = []; 192 | return; 193 | end 194 | 195 | i = 1; 196 | 197 | while(ftell(fid) < end_of_ext) 198 | ext.section(i).esize = fread(fid,1,'int32'); 199 | ext.section(i).ecode = fread(fid,1,'int32'); 200 | ext.section(i).edata = char(fread(fid,ext.section(i).esize-8)'); 201 | i = i + 1; 202 | end 203 | 204 | ext.num_ext = length(ext.section); 205 | 206 | return % read_extension 207 | 208 | -------------------------------------------------------------------------------- /NIFTI/load_untouch0_nii_hdr.m: -------------------------------------------------------------------------------- 1 | % internal function 2 | 3 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 4 | 5 | function hdr = load_nii_hdr(fileprefix, machine) 6 | 7 | fn = sprintf('%s.hdr',fileprefix); 8 | fid = fopen(fn,'r',machine); 9 | 10 | if fid < 0, 11 | msg = sprintf('Cannot open file %s.',fn); 12 | error(msg); 13 | else 14 | fseek(fid,0,'bof'); 15 | hdr = read_header(fid); 16 | fclose(fid); 17 | end 18 | 19 | return % load_nii_hdr 20 | 21 | 22 | %--------------------------------------------------------------------- 23 | function [ dsr ] = read_header(fid) 24 | 25 | % Original header structures 26 | % struct dsr 27 | % { 28 | % struct header_key hk; /* 0 + 40 */ 29 | % struct image_dimension dime; /* 40 + 108 */ 30 | % struct data_history hist; /* 148 + 200 */ 31 | % }; /* total= 348 bytes*/ 32 | 33 | dsr.hk = header_key(fid); 34 | dsr.dime = image_dimension(fid); 35 | dsr.hist = data_history(fid); 36 | 37 | return % read_header 38 | 39 | 40 | %--------------------------------------------------------------------- 41 | function [ hk ] = header_key(fid) 42 | 43 | fseek(fid,0,'bof'); 44 | 45 | % Original header structures 46 | % struct header_key /* header key */ 47 | % { /* off + size */ 48 | % int sizeof_hdr /* 0 + 4 */ 49 | % char data_type[10]; /* 4 + 10 */ 50 | % char db_name[18]; /* 14 + 18 */ 51 | % int extents; /* 32 + 4 */ 52 | % short int session_error; /* 36 + 2 */ 53 | % char regular; /* 38 + 1 */ 54 | % char hkey_un0; /* 39 + 1 */ 55 | % }; /* total=40 bytes */ 56 | % 57 | % int sizeof_header Should be 348. 58 | % char regular Must be 'r' to indicate that all images and 59 | % volumes are the same size. 60 | 61 | v6 = version; 62 | if str2num(v6(1))<6 63 | directchar = '*char'; 64 | else 65 | directchar = 'uchar=>char'; 66 | end 67 | 68 | hk.sizeof_hdr = fread(fid, 1,'int32')'; % should be 348! 69 | hk.data_type = deblank(fread(fid,10,directchar)'); 70 | hk.db_name = deblank(fread(fid,18,directchar)'); 71 | hk.extents = fread(fid, 1,'int32')'; 72 | hk.session_error = fread(fid, 1,'int16')'; 73 | hk.regular = fread(fid, 1,directchar)'; 74 | hk.hkey_un0 = fread(fid, 1,directchar)'; 75 | 76 | return % header_key 77 | 78 | 79 | %--------------------------------------------------------------------- 80 | function [ dime ] = image_dimension(fid) 81 | 82 | %struct image_dimension 83 | % { /* off + size */ 84 | % short int dim[8]; /* 0 + 16 */ 85 | % /* 86 | % dim[0] Number of dimensions in database; usually 4. 87 | % dim[1] Image X dimension; number of *pixels* in an image row. 88 | % dim[2] Image Y dimension; number of *pixel rows* in slice. 89 | % dim[3] Volume Z dimension; number of *slices* in a volume. 90 | % dim[4] Time points; number of volumes in database 91 | % */ 92 | % char vox_units[4]; /* 16 + 4 */ 93 | % char cal_units[8]; /* 20 + 8 */ 94 | % short int unused1; /* 28 + 2 */ 95 | % short int datatype; /* 30 + 2 */ 96 | % short int bitpix; /* 32 + 2 */ 97 | % short int dim_un0; /* 34 + 2 */ 98 | % float pixdim[8]; /* 36 + 32 */ 99 | % /* 100 | % pixdim[] specifies the voxel dimensions: 101 | % pixdim[1] - voxel width, mm 102 | % pixdim[2] - voxel height, mm 103 | % pixdim[3] - slice thickness, mm 104 | % pixdim[4] - volume timing, in msec 105 | % ..etc 106 | % */ 107 | % float vox_offset; /* 68 + 4 */ 108 | % float roi_scale; /* 72 + 4 */ 109 | % float funused1; /* 76 + 4 */ 110 | % float funused2; /* 80 + 4 */ 111 | % float cal_max; /* 84 + 4 */ 112 | % float cal_min; /* 88 + 4 */ 113 | % int compressed; /* 92 + 4 */ 114 | % int verified; /* 96 + 4 */ 115 | % int glmax; /* 100 + 4 */ 116 | % int glmin; /* 104 + 4 */ 117 | % }; /* total=108 bytes */ 118 | 119 | v6 = version; 120 | if str2num(v6(1))<6 121 | directchar = '*char'; 122 | else 123 | directchar = 'uchar=>char'; 124 | end 125 | 126 | dime.dim = fread(fid,8,'int16')'; 127 | dime.vox_units = deblank(fread(fid,4,directchar)'); 128 | dime.cal_units = deblank(fread(fid,8,directchar)'); 129 | dime.unused1 = fread(fid,1,'int16')'; 130 | dime.datatype = fread(fid,1,'int16')'; 131 | dime.bitpix = fread(fid,1,'int16')'; 132 | dime.dim_un0 = fread(fid,1,'int16')'; 133 | dime.pixdim = fread(fid,8,'float32')'; 134 | dime.vox_offset = fread(fid,1,'float32')'; 135 | dime.roi_scale = fread(fid,1,'float32')'; 136 | dime.funused1 = fread(fid,1,'float32')'; 137 | dime.funused2 = fread(fid,1,'float32')'; 138 | dime.cal_max = fread(fid,1,'float32')'; 139 | dime.cal_min = fread(fid,1,'float32')'; 140 | dime.compressed = fread(fid,1,'int32')'; 141 | dime.verified = fread(fid,1,'int32')'; 142 | dime.glmax = fread(fid,1,'int32')'; 143 | dime.glmin = fread(fid,1,'int32')'; 144 | 145 | return % image_dimension 146 | 147 | 148 | %--------------------------------------------------------------------- 149 | function [ hist ] = data_history(fid) 150 | 151 | %struct data_history 152 | % { /* off + size */ 153 | % char descrip[80]; /* 0 + 80 */ 154 | % char aux_file[24]; /* 80 + 24 */ 155 | % char orient; /* 104 + 1 */ 156 | % char originator[10]; /* 105 + 10 */ 157 | % char generated[10]; /* 115 + 10 */ 158 | % char scannum[10]; /* 125 + 10 */ 159 | % char patient_id[10]; /* 135 + 10 */ 160 | % char exp_date[10]; /* 145 + 10 */ 161 | % char exp_time[10]; /* 155 + 10 */ 162 | % char hist_un0[3]; /* 165 + 3 */ 163 | % int views /* 168 + 4 */ 164 | % int vols_added; /* 172 + 4 */ 165 | % int start_field; /* 176 + 4 */ 166 | % int field_skip; /* 180 + 4 */ 167 | % int omax; /* 184 + 4 */ 168 | % int omin; /* 188 + 4 */ 169 | % int smax; /* 192 + 4 */ 170 | % int smin; /* 196 + 4 */ 171 | % }; /* total=200 bytes */ 172 | 173 | v6 = version; 174 | if str2num(v6(1))<6 175 | directchar = '*char'; 176 | else 177 | directchar = 'uchar=>char'; 178 | end 179 | 180 | hist.descrip = deblank(fread(fid,80,directchar)'); 181 | hist.aux_file = deblank(fread(fid,24,directchar)'); 182 | hist.orient = fread(fid, 1,'char')'; 183 | hist.originator = fread(fid, 5,'int16')'; 184 | hist.generated = deblank(fread(fid,10,directchar)'); 185 | hist.scannum = deblank(fread(fid,10,directchar)'); 186 | hist.patient_id = deblank(fread(fid,10,directchar)'); 187 | hist.exp_date = deblank(fread(fid,10,directchar)'); 188 | hist.exp_time = deblank(fread(fid,10,directchar)'); 189 | hist.hist_un0 = deblank(fread(fid, 3,directchar)'); 190 | hist.views = fread(fid, 1,'int32')'; 191 | hist.vols_added = fread(fid, 1,'int32')'; 192 | hist.start_field = fread(fid, 1,'int32')'; 193 | hist.field_skip = fread(fid, 1,'int32')'; 194 | hist.omax = fread(fid, 1,'int32')'; 195 | hist.omin = fread(fid, 1,'int32')'; 196 | hist.smax = fread(fid, 1,'int32')'; 197 | hist.smin = fread(fid, 1,'int32')'; 198 | 199 | return % data_history 200 | 201 | -------------------------------------------------------------------------------- /NIFTI/load_untouch_header_only.m: -------------------------------------------------------------------------------- 1 | % Load NIfTI / Analyze header without applying any appropriate affine 2 | % geometric transform or voxel intensity scaling. It is equivalent to 3 | % hdr field when using load_untouch_nii to load dataset. Support both 4 | % *.nii and *.hdr file extension. If file extension is not provided, 5 | % *.hdr will be used as default. 6 | % 7 | % Usage: [header, ext, filetype, machine] = load_untouch_header_only(filename) 8 | % 9 | % filename - NIfTI / Analyze file name. 10 | % 11 | % Returned values: 12 | % 13 | % header - struct with NIfTI / Analyze header fields. 14 | % 15 | % ext - NIfTI extension if it is not empty. 16 | % 17 | % filetype - 0 for Analyze format (*.hdr/*.img); 18 | % 1 for NIFTI format in 2 files (*.hdr/*.img); 19 | % 2 for NIFTI format in 1 file (*.nii). 20 | % 21 | % machine - a string, see below for details. The default here is 'ieee-le'. 22 | % 23 | % 'native' or 'n' - local machine format - the default 24 | % 'ieee-le' or 'l' - IEEE floating point with little-endian 25 | % byte ordering 26 | % 'ieee-be' or 'b' - IEEE floating point with big-endian 27 | % byte ordering 28 | % 'vaxd' or 'd' - VAX D floating point and VAX ordering 29 | % 'vaxg' or 'g' - VAX G floating point and VAX ordering 30 | % 'cray' or 'c' - Cray floating point with big-endian 31 | % byte ordering 32 | % 'ieee-le.l64' or 'a' - IEEE floating point with little-endian 33 | % byte ordering and 64 bit long data type 34 | % 'ieee-be.l64' or 's' - IEEE floating point with big-endian byte 35 | % ordering and 64 bit long data type. 36 | % 37 | % Part of this file is copied and modified from: 38 | % http://www.mathworks.com/matlabcentral/fileexchange/1878-mri-analyze-tools 39 | % 40 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 41 | % 42 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 43 | % 44 | function [hdr, ext, filetype, machine] = load_untouch_header_only(filename) 45 | 46 | if ~exist('filename','var') 47 | error('Usage: [header, ext, filetype, machine] = load_untouch_header_only(filename)'); 48 | end 49 | 50 | 51 | v = version; 52 | 53 | % Check file extension. If .gz, unpack it into temp folder 54 | % 55 | if length(filename) > 2 & strcmp(filename(end-2:end), '.gz') 56 | 57 | if ~strcmp(filename(end-6:end), '.img.gz') & ... 58 | ~strcmp(filename(end-6:end), '.hdr.gz') & ... 59 | ~strcmp(filename(end-6:end), '.nii.gz') 60 | 61 | error('Please check filename.'); 62 | end 63 | 64 | if str2num(v(1:3)) < 7.1 | ~usejava('jvm') 65 | error('Please use MATLAB 7.1 (with java) and above, or run gunzip outside MATLAB.'); 66 | elseif strcmp(filename(end-6:end), '.img.gz') 67 | filename1 = filename; 68 | filename2 = filename; 69 | filename2(end-6:end) = ''; 70 | filename2 = [filename2, '.hdr.gz']; 71 | 72 | tmpDir = tempname; 73 | mkdir(tmpDir); 74 | gzFileName = filename; 75 | 76 | filename1 = gunzip(filename1, tmpDir); 77 | filename2 = gunzip(filename2, tmpDir); 78 | filename = char(filename1); % convert from cell to string 79 | elseif strcmp(filename(end-6:end), '.hdr.gz') 80 | filename1 = filename; 81 | filename2 = filename; 82 | filename2(end-6:end) = ''; 83 | filename2 = [filename2, '.img.gz']; 84 | 85 | tmpDir = tempname; 86 | mkdir(tmpDir); 87 | gzFileName = filename; 88 | 89 | filename1 = gunzip(filename1, tmpDir); 90 | filename2 = gunzip(filename2, tmpDir); 91 | filename = char(filename1); % convert from cell to string 92 | elseif strcmp(filename(end-6:end), '.nii.gz') 93 | tmpDir = tempname; 94 | mkdir(tmpDir); 95 | gzFileName = filename; 96 | filename = gunzip(filename, tmpDir); 97 | filename = char(filename); % convert from cell to string 98 | end 99 | end 100 | 101 | % Read the dataset header 102 | % 103 | [hdr, filetype, fileprefix, machine] = load_nii_hdr(filename); 104 | 105 | if filetype == 0 106 | hdr = load_untouch0_nii_hdr(fileprefix, machine); 107 | ext = []; 108 | else 109 | hdr = load_untouch_nii_hdr(fileprefix, machine, filetype); 110 | 111 | % Read the header extension 112 | % 113 | ext = load_nii_ext(filename); 114 | end 115 | 116 | % Set bitpix according to datatype 117 | % 118 | % /*Acceptable values for datatype are*/ 119 | % 120 | % 0 None (Unknown bit per voxel) % DT_NONE, DT_UNKNOWN 121 | % 1 Binary (ubit1, bitpix=1) % DT_BINARY 122 | % 2 Unsigned char (uchar or uint8, bitpix=8) % DT_UINT8, NIFTI_TYPE_UINT8 123 | % 4 Signed short (int16, bitpix=16) % DT_INT16, NIFTI_TYPE_INT16 124 | % 8 Signed integer (int32, bitpix=32) % DT_INT32, NIFTI_TYPE_INT32 125 | % 16 Floating point (single or float32, bitpix=32) % DT_FLOAT32, NIFTI_TYPE_FLOAT32 126 | % 32 Complex, 2 float32 (Use float32, bitpix=64) % DT_COMPLEX64, NIFTI_TYPE_COMPLEX64 127 | % 64 Double precision (double or float64, bitpix=64) % DT_FLOAT64, NIFTI_TYPE_FLOAT64 128 | % 128 uint8 RGB (Use uint8, bitpix=24) % DT_RGB24, NIFTI_TYPE_RGB24 129 | % 256 Signed char (schar or int8, bitpix=8) % DT_INT8, NIFTI_TYPE_INT8 130 | % 511 Single RGB (Use float32, bitpix=96) % DT_RGB96, NIFTI_TYPE_RGB96 131 | % 512 Unsigned short (uint16, bitpix=16) % DT_UNINT16, NIFTI_TYPE_UNINT16 132 | % 768 Unsigned integer (uint32, bitpix=32) % DT_UNINT32, NIFTI_TYPE_UNINT32 133 | % 1024 Signed long long (int64, bitpix=64) % DT_INT64, NIFTI_TYPE_INT64 134 | % 1280 Unsigned long long (uint64, bitpix=64) % DT_UINT64, NIFTI_TYPE_UINT64 135 | % 1536 Long double, float128 (Unsupported, bitpix=128) % DT_FLOAT128, NIFTI_TYPE_FLOAT128 136 | % 1792 Complex128, 2 float64 (Use float64, bitpix=128) % DT_COMPLEX128, NIFTI_TYPE_COMPLEX128 137 | % 2048 Complex256, 2 float128 (Unsupported, bitpix=256) % DT_COMPLEX128, NIFTI_TYPE_COMPLEX128 138 | % 139 | switch hdr.dime.datatype 140 | case 1, 141 | hdr.dime.bitpix = 1; precision = 'ubit1'; 142 | case 2, 143 | hdr.dime.bitpix = 8; precision = 'uint8'; 144 | case 4, 145 | hdr.dime.bitpix = 16; precision = 'int16'; 146 | case 8, 147 | hdr.dime.bitpix = 32; precision = 'int32'; 148 | case 16, 149 | hdr.dime.bitpix = 32; precision = 'float32'; 150 | case 32, 151 | hdr.dime.bitpix = 64; precision = 'float32'; 152 | case 64, 153 | hdr.dime.bitpix = 64; precision = 'float64'; 154 | case 128, 155 | hdr.dime.bitpix = 24; precision = 'uint8'; 156 | case 256 157 | hdr.dime.bitpix = 8; precision = 'int8'; 158 | case 511 159 | hdr.dime.bitpix = 96; precision = 'float32'; 160 | case 512 161 | hdr.dime.bitpix = 16; precision = 'uint16'; 162 | case 768 163 | hdr.dime.bitpix = 32; precision = 'uint32'; 164 | case 1024 165 | hdr.dime.bitpix = 64; precision = 'int64'; 166 | case 1280 167 | hdr.dime.bitpix = 64; precision = 'uint64'; 168 | case 1792, 169 | hdr.dime.bitpix = 128; precision = 'float64'; 170 | otherwise 171 | error('This datatype is not supported'); 172 | end 173 | 174 | tmp = hdr.dime.dim(2:end); 175 | tmp(find(tmp < 1)) = 1; 176 | hdr.dime.dim(2:end) = tmp; 177 | 178 | 179 | % Clean up after gunzip 180 | % 181 | if exist('gzFileName', 'var') 182 | rmdir(tmpDir,'s'); 183 | end 184 | 185 | 186 | return % load_untouch_header_only 187 | 188 | -------------------------------------------------------------------------------- /NIFTI/load_untouch_nii.m: -------------------------------------------------------------------------------- 1 | % Load NIFTI or ANALYZE dataset, but not applying any appropriate affine 2 | % geometric transform or voxel intensity scaling. 3 | % 4 | % Although according to NIFTI website, all those header information are 5 | % supposed to be applied to the loaded NIFTI image, there are some 6 | % situations that people do want to leave the original NIFTI header and 7 | % data untouched. They will probably just use MATLAB to do certain image 8 | % processing regardless of image orientation, and to save data back with 9 | % the same NIfTI header. 10 | % 11 | % Since this program is only served for those situations, please use it 12 | % together with "save_untouch_nii.m", and do not use "save_nii.m" or 13 | % "view_nii.m" for the data that is loaded by "load_untouch_nii.m". For 14 | % normal situation, you should use "load_nii.m" instead. 15 | % 16 | % Usage: nii = load_untouch_nii(filename, [img_idx], [dim5_idx], [dim6_idx], ... 17 | % [dim7_idx], [old_RGB], [slice_idx]) 18 | % 19 | % filename - NIFTI or ANALYZE file name. 20 | % 21 | % img_idx (optional) - a numerical array of image volume indices. 22 | % Only the specified volumes will be loaded. All available image 23 | % volumes will be loaded, if it is default or empty. 24 | % 25 | % The number of images scans can be obtained from get_nii_frame.m, 26 | % or simply: hdr.dime.dim(5). 27 | % 28 | % dim5_idx (optional) - a numerical array of 5th dimension indices. 29 | % Only the specified range will be loaded. All available range 30 | % will be loaded, if it is default or empty. 31 | % 32 | % dim6_idx (optional) - a numerical array of 6th dimension indices. 33 | % Only the specified range will be loaded. All available range 34 | % will be loaded, if it is default or empty. 35 | % 36 | % dim7_idx (optional) - a numerical array of 7th dimension indices. 37 | % Only the specified range will be loaded. All available range 38 | % will be loaded, if it is default or empty. 39 | % 40 | % old_RGB (optional) - a scale number to tell difference of new RGB24 41 | % from old RGB24. New RGB24 uses RGB triple sequentially for each 42 | % voxel, like [R1 G1 B1 R2 G2 B2 ...]. Analyze 6.0 from AnalyzeDirect 43 | % uses old RGB24, in a way like [R1 R2 ... G1 G2 ... B1 B2 ...] for 44 | % each slices. If the image that you view is garbled, try to set 45 | % old_RGB variable to 1 and try again, because it could be in 46 | % old RGB24. It will be set to 0, if it is default or empty. 47 | % 48 | % slice_idx (optional) - a numerical array of image slice indices. 49 | % Only the specified slices will be loaded. All available image 50 | % slices will be loaded, if it is default or empty. 51 | % 52 | % Returned values: 53 | % 54 | % nii structure: 55 | % 56 | % hdr - struct with NIFTI header fields. 57 | % 58 | % filetype - Analyze format .hdr/.img (0); 59 | % NIFTI .hdr/.img (1); 60 | % NIFTI .nii (2) 61 | % 62 | % fileprefix - NIFTI filename without extension. 63 | % 64 | % machine - machine string variable. 65 | % 66 | % img - 3D (or 4D) matrix of NIFTI data. 67 | % 68 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 69 | % 70 | function nii = load_untouch_nii(filename, img_idx, dim5_idx, dim6_idx, dim7_idx, ... 71 | old_RGB, slice_idx) 72 | 73 | if ~exist('filename','var') 74 | error('Usage: nii = load_untouch_nii(filename, [img_idx], [dim5_idx], [dim6_idx], [dim7_idx], [old_RGB], [slice_idx])'); 75 | end 76 | 77 | if ~exist('img_idx','var') | isempty(img_idx) 78 | img_idx = []; 79 | end 80 | 81 | if ~exist('dim5_idx','var') | isempty(dim5_idx) 82 | dim5_idx = []; 83 | end 84 | 85 | if ~exist('dim6_idx','var') | isempty(dim6_idx) 86 | dim6_idx = []; 87 | end 88 | 89 | if ~exist('dim7_idx','var') | isempty(dim7_idx) 90 | dim7_idx = []; 91 | end 92 | 93 | if ~exist('old_RGB','var') | isempty(old_RGB) 94 | old_RGB = 0; 95 | end 96 | 97 | if ~exist('slice_idx','var') | isempty(slice_idx) 98 | slice_idx = []; 99 | end 100 | 101 | 102 | v = version; 103 | 104 | % Check file extension. If .gz, unpack it into temp folder 105 | % 106 | if length(filename) > 2 & strcmp(filename(end-2:end), '.gz') 107 | 108 | if ~strcmp(filename(end-6:end), '.img.gz') & ... 109 | ~strcmp(filename(end-6:end), '.hdr.gz') & ... 110 | ~strcmp(filename(end-6:end), '.nii.gz') 111 | 112 | error('Please check filename.'); 113 | end 114 | 115 | if str2num(v(1:3)) < 7.1 | ~usejava('jvm') 116 | error('Please use MATLAB 7.1 (with java) and above, or run gunzip outside MATLAB.'); 117 | elseif strcmp(filename(end-6:end), '.img.gz') 118 | filename1 = filename; 119 | filename2 = filename; 120 | filename2(end-6:end) = ''; 121 | filename2 = [filename2, '.hdr.gz']; 122 | 123 | tmpDir = tempname; 124 | mkdir(tmpDir); 125 | gzFileName = filename; 126 | 127 | filename1 = gunzip(filename1, tmpDir); 128 | filename2 = gunzip(filename2, tmpDir); 129 | filename = char(filename1); % convert from cell to string 130 | elseif strcmp(filename(end-6:end), '.hdr.gz') 131 | filename1 = filename; 132 | filename2 = filename; 133 | filename2(end-6:end) = ''; 134 | filename2 = [filename2, '.img.gz']; 135 | 136 | tmpDir = tempname; 137 | mkdir(tmpDir); 138 | gzFileName = filename; 139 | 140 | filename1 = gunzip(filename1, tmpDir); 141 | filename2 = gunzip(filename2, tmpDir); 142 | filename = char(filename1); % convert from cell to string 143 | elseif strcmp(filename(end-6:end), '.nii.gz') 144 | tmpDir = tempname; 145 | mkdir(tmpDir); 146 | gzFileName = filename; 147 | filename = gunzip(filename, tmpDir); 148 | filename = char(filename); % convert from cell to string 149 | end 150 | end 151 | 152 | % Read the dataset header 153 | % 154 | [nii.hdr,nii.filetype,nii.fileprefix,nii.machine] = load_nii_hdr(filename); 155 | 156 | if nii.filetype == 0 157 | nii.hdr = load_untouch0_nii_hdr(nii.fileprefix,nii.machine); 158 | nii.ext = []; 159 | else 160 | nii.hdr = load_untouch_nii_hdr(nii.fileprefix,nii.machine,nii.filetype); 161 | 162 | % Read the header extension 163 | % 164 | nii.ext = load_nii_ext(filename); 165 | end 166 | 167 | % Read the dataset body 168 | % 169 | [nii.img,nii.hdr] = load_untouch_nii_img(nii.hdr,nii.filetype,nii.fileprefix, ... 170 | nii.machine,img_idx,dim5_idx,dim6_idx,dim7_idx,old_RGB,slice_idx); 171 | 172 | % Perform some of sform/qform transform 173 | % 174 | % nii = xform_nii(nii, tolerance, preferredForm); 175 | 176 | nii.untouch = 1; 177 | 178 | 179 | % Clean up after gunzip 180 | % 181 | if exist('gzFileName', 'var') 182 | 183 | % fix fileprefix so it doesn't point to temp location 184 | % 185 | nii.fileprefix = gzFileName(1:end-7); 186 | rmdir(tmpDir,'s'); 187 | end 188 | 189 | 190 | return % load_untouch_nii 191 | 192 | -------------------------------------------------------------------------------- /NIFTI/load_untouch_nii_hdr.m: -------------------------------------------------------------------------------- 1 | % internal function 2 | 3 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 4 | 5 | function hdr = load_nii_hdr(fileprefix, machine, filetype) 6 | 7 | if filetype == 2 8 | fn = sprintf('%s.nii',fileprefix); 9 | 10 | if ~exist(fn) 11 | msg = sprintf('Cannot find file "%s.nii".', fileprefix); 12 | error(msg); 13 | end 14 | else 15 | fn = sprintf('%s.hdr',fileprefix); 16 | 17 | if ~exist(fn) 18 | msg = sprintf('Cannot find file "%s.hdr".', fileprefix); 19 | error(msg); 20 | end 21 | end 22 | 23 | fid = fopen(fn,'r',machine); 24 | 25 | if fid < 0, 26 | msg = sprintf('Cannot open file %s.',fn); 27 | error(msg); 28 | else 29 | fseek(fid,0,'bof'); 30 | hdr = read_header(fid); 31 | fclose(fid); 32 | end 33 | 34 | return % load_nii_hdr 35 | 36 | 37 | %--------------------------------------------------------------------- 38 | function [ dsr ] = read_header(fid) 39 | 40 | % Original header structures 41 | % struct dsr 42 | % { 43 | % struct header_key hk; /* 0 + 40 */ 44 | % struct image_dimension dime; /* 40 + 108 */ 45 | % struct data_history hist; /* 148 + 200 */ 46 | % }; /* total= 348 bytes*/ 47 | 48 | dsr.hk = header_key(fid); 49 | dsr.dime = image_dimension(fid); 50 | dsr.hist = data_history(fid); 51 | 52 | % For Analyze data format 53 | % 54 | if ~strcmp(dsr.hist.magic, 'n+1') & ~strcmp(dsr.hist.magic, 'ni1') 55 | dsr.hist.qform_code = 0; 56 | dsr.hist.sform_code = 0; 57 | end 58 | 59 | return % read_header 60 | 61 | 62 | %--------------------------------------------------------------------- 63 | function [ hk ] = header_key(fid) 64 | 65 | fseek(fid,0,'bof'); 66 | 67 | % Original header structures 68 | % struct header_key /* header key */ 69 | % { /* off + size */ 70 | % int sizeof_hdr /* 0 + 4 */ 71 | % char data_type[10]; /* 4 + 10 */ 72 | % char db_name[18]; /* 14 + 18 */ 73 | % int extents; /* 32 + 4 */ 74 | % short int session_error; /* 36 + 2 */ 75 | % char regular; /* 38 + 1 */ 76 | % char dim_info; % char hkey_un0; /* 39 + 1 */ 77 | % }; /* total=40 bytes */ 78 | % 79 | % int sizeof_header Should be 348. 80 | % char regular Must be 'r' to indicate that all images and 81 | % volumes are the same size. 82 | 83 | v6 = version; 84 | if str2num(v6(1))<6 85 | directchar = '*char'; 86 | else 87 | directchar = 'uchar=>char'; 88 | end 89 | 90 | hk.sizeof_hdr = fread(fid, 1,'int32')'; % should be 348! 91 | hk.data_type = deblank(fread(fid,10,directchar)'); 92 | hk.db_name = deblank(fread(fid,18,directchar)'); 93 | hk.extents = fread(fid, 1,'int32')'; 94 | hk.session_error = fread(fid, 1,'int16')'; 95 | hk.regular = fread(fid, 1,directchar)'; 96 | hk.dim_info = fread(fid, 1,'uchar')'; 97 | 98 | return % header_key 99 | 100 | 101 | %--------------------------------------------------------------------- 102 | function [ dime ] = image_dimension(fid) 103 | 104 | % Original header structures 105 | % struct image_dimension 106 | % { /* off + size */ 107 | % short int dim[8]; /* 0 + 16 */ 108 | % /* 109 | % dim[0] Number of dimensions in database; usually 4. 110 | % dim[1] Image X dimension; number of *pixels* in an image row. 111 | % dim[2] Image Y dimension; number of *pixel rows* in slice. 112 | % dim[3] Volume Z dimension; number of *slices* in a volume. 113 | % dim[4] Time points; number of volumes in database 114 | % */ 115 | % float intent_p1; % char vox_units[4]; /* 16 + 4 */ 116 | % float intent_p2; % char cal_units[8]; /* 20 + 4 */ 117 | % float intent_p3; % char cal_units[8]; /* 24 + 4 */ 118 | % short int intent_code; % short int unused1; /* 28 + 2 */ 119 | % short int datatype; /* 30 + 2 */ 120 | % short int bitpix; /* 32 + 2 */ 121 | % short int slice_start; % short int dim_un0; /* 34 + 2 */ 122 | % float pixdim[8]; /* 36 + 32 */ 123 | % /* 124 | % pixdim[] specifies the voxel dimensions: 125 | % pixdim[1] - voxel width, mm 126 | % pixdim[2] - voxel height, mm 127 | % pixdim[3] - slice thickness, mm 128 | % pixdim[4] - volume timing, in msec 129 | % ..etc 130 | % */ 131 | % float vox_offset; /* 68 + 4 */ 132 | % float scl_slope; % float roi_scale; /* 72 + 4 */ 133 | % float scl_inter; % float funused1; /* 76 + 4 */ 134 | % short slice_end; % float funused2; /* 80 + 2 */ 135 | % char slice_code; % float funused2; /* 82 + 1 */ 136 | % char xyzt_units; % float funused2; /* 83 + 1 */ 137 | % float cal_max; /* 84 + 4 */ 138 | % float cal_min; /* 88 + 4 */ 139 | % float slice_duration; % int compressed; /* 92 + 4 */ 140 | % float toffset; % int verified; /* 96 + 4 */ 141 | % int glmax; /* 100 + 4 */ 142 | % int glmin; /* 104 + 4 */ 143 | % }; /* total=108 bytes */ 144 | 145 | dime.dim = fread(fid,8,'int16')'; 146 | dime.intent_p1 = fread(fid,1,'float32')'; 147 | dime.intent_p2 = fread(fid,1,'float32')'; 148 | dime.intent_p3 = fread(fid,1,'float32')'; 149 | dime.intent_code = fread(fid,1,'int16')'; 150 | dime.datatype = fread(fid,1,'int16')'; 151 | dime.bitpix = fread(fid,1,'int16')'; 152 | dime.slice_start = fread(fid,1,'int16')'; 153 | dime.pixdim = fread(fid,8,'float32')'; 154 | dime.vox_offset = fread(fid,1,'float32')'; 155 | dime.scl_slope = fread(fid,1,'float32')'; 156 | dime.scl_inter = fread(fid,1,'float32')'; 157 | dime.slice_end = fread(fid,1,'int16')'; 158 | dime.slice_code = fread(fid,1,'uchar')'; 159 | dime.xyzt_units = fread(fid,1,'uchar')'; 160 | dime.cal_max = fread(fid,1,'float32')'; 161 | dime.cal_min = fread(fid,1,'float32')'; 162 | dime.slice_duration = fread(fid,1,'float32')'; 163 | dime.toffset = fread(fid,1,'float32')'; 164 | dime.glmax = fread(fid,1,'int32')'; 165 | dime.glmin = fread(fid,1,'int32')'; 166 | 167 | return % image_dimension 168 | 169 | 170 | %--------------------------------------------------------------------- 171 | function [ hist ] = data_history(fid) 172 | 173 | % Original header structures 174 | % struct data_history 175 | % { /* off + size */ 176 | % char descrip[80]; /* 0 + 80 */ 177 | % char aux_file[24]; /* 80 + 24 */ 178 | % short int qform_code; /* 104 + 2 */ 179 | % short int sform_code; /* 106 + 2 */ 180 | % float quatern_b; /* 108 + 4 */ 181 | % float quatern_c; /* 112 + 4 */ 182 | % float quatern_d; /* 116 + 4 */ 183 | % float qoffset_x; /* 120 + 4 */ 184 | % float qoffset_y; /* 124 + 4 */ 185 | % float qoffset_z; /* 128 + 4 */ 186 | % float srow_x[4]; /* 132 + 16 */ 187 | % float srow_y[4]; /* 148 + 16 */ 188 | % float srow_z[4]; /* 164 + 16 */ 189 | % char intent_name[16]; /* 180 + 16 */ 190 | % char magic[4]; % int smin; /* 196 + 4 */ 191 | % }; /* total=200 bytes */ 192 | 193 | v6 = version; 194 | if str2num(v6(1))<6 195 | directchar = '*char'; 196 | else 197 | directchar = 'uchar=>char'; 198 | end 199 | 200 | hist.descrip = deblank(fread(fid,80,directchar)'); 201 | hist.aux_file = deblank(fread(fid,24,directchar)'); 202 | hist.qform_code = fread(fid,1,'int16')'; 203 | hist.sform_code = fread(fid,1,'int16')'; 204 | hist.quatern_b = fread(fid,1,'float32')'; 205 | hist.quatern_c = fread(fid,1,'float32')'; 206 | hist.quatern_d = fread(fid,1,'float32')'; 207 | hist.qoffset_x = fread(fid,1,'float32')'; 208 | hist.qoffset_y = fread(fid,1,'float32')'; 209 | hist.qoffset_z = fread(fid,1,'float32')'; 210 | hist.srow_x = fread(fid,4,'float32')'; 211 | hist.srow_y = fread(fid,4,'float32')'; 212 | hist.srow_z = fread(fid,4,'float32')'; 213 | hist.intent_name = deblank(fread(fid,16,directchar)'); 214 | hist.magic = deblank(fread(fid,4,directchar)'); 215 | 216 | return % data_history 217 | 218 | -------------------------------------------------------------------------------- /NIFTI/make_ana.m: -------------------------------------------------------------------------------- 1 | % Make ANALYZE 7.5 data structure specified by a 3D or 4D matrix. 2 | % Optional parameters can also be included, such as: voxel_size, 3 | % origin, datatype, and description. 4 | % 5 | % Once the ANALYZE structure is made, it can be saved into ANALYZE 7.5 6 | % format data file using "save_untouch_nii" command (for more detail, 7 | % type: help save_untouch_nii). 8 | % 9 | % Usage: ana = make_ana(img, [voxel_size], [origin], [datatype], [description]) 10 | % 11 | % Where: 12 | % 13 | % img: a 3D matrix [x y z], or a 4D matrix with time 14 | % series [x y z t]. When image is in RGB format, 15 | % make sure that the size of 4th dimension is 16 | % always 3 (i.e. [R G B]). In that case, make 17 | % sure that you must specify RGB datatype to 128. 18 | % 19 | % voxel_size (optional): Voxel size in millimeter for each 20 | % dimension. Default is [1 1 1]. 21 | % 22 | % origin (optional): The AC origin. Default is [0 0 0]. 23 | % 24 | % datatype (optional): Storage data type: 25 | % 2 - uint8, 4 - int16, 8 - int32, 16 - float32, 26 | % 64 - float64, 128 - RGB24 27 | % Default will use the data type of 'img' matrix 28 | % For RGB image, you must specify it to 128. 29 | % 30 | % description (optional): Description of data. Default is ''. 31 | % 32 | % e.g.: 33 | % origin = [33 44 13]; datatype = 64; 34 | % ana = make_ana(img, [], origin, datatype); % default voxel_size 35 | % 36 | % ANALYZE 7.5 format: http://www.rotman-baycrest.on.ca/~jimmy/ANALYZE75.pdf 37 | % 38 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 39 | % 40 | function ana = make_ana(varargin) 41 | 42 | ana.img = varargin{1}; 43 | dims = size(ana.img); 44 | dims = [4 dims ones(1,8)]; 45 | dims = dims(1:8); 46 | 47 | voxel_size = [0 ones(1,3) zeros(1,4)]; 48 | origin = zeros(1,5); 49 | descrip = ''; 50 | 51 | switch class(ana.img) 52 | case 'uint8' 53 | datatype = 2; 54 | case 'int16' 55 | datatype = 4; 56 | case 'int32' 57 | datatype = 8; 58 | case 'single' 59 | datatype = 16; 60 | case 'double' 61 | datatype = 64; 62 | otherwise 63 | error('Datatype is not supported by make_ana.'); 64 | end 65 | 66 | if nargin > 1 & ~isempty(varargin{2}) 67 | voxel_size(2:4) = double(varargin{2}); 68 | end 69 | 70 | if nargin > 2 & ~isempty(varargin{3}) 71 | origin(1:3) = double(varargin{3}); 72 | end 73 | 74 | if nargin > 3 & ~isempty(varargin{4}) 75 | datatype = double(varargin{4}); 76 | 77 | if datatype == 128 | datatype == 511 78 | dims(5) = []; 79 | dims = [dims 1]; 80 | end 81 | end 82 | 83 | if nargin > 4 & ~isempty(varargin{5}) 84 | descrip = varargin{5}; 85 | end 86 | 87 | if ndims(ana.img) > 4 88 | error('NIfTI only allows a maximum of 4 Dimension matrix.'); 89 | end 90 | 91 | maxval = round(double(max(ana.img(:)))); 92 | minval = round(double(min(ana.img(:)))); 93 | 94 | ana.hdr = make_header(dims, voxel_size, origin, datatype, ... 95 | descrip, maxval, minval); 96 | ana.filetype = 0; 97 | ana.ext = []; 98 | ana.untouch = 1; 99 | 100 | switch ana.hdr.dime.datatype 101 | case 2 102 | ana.img = uint8(ana.img); 103 | case 4 104 | ana.img = int16(ana.img); 105 | case 8 106 | ana.img = int32(ana.img); 107 | case 16 108 | ana.img = single(ana.img); 109 | case 64 110 | ana.img = double(ana.img); 111 | case 128 112 | ana.img = uint8(ana.img); 113 | otherwise 114 | error('Datatype is not supported by make_ana.'); 115 | end 116 | 117 | return; % make_ana 118 | 119 | 120 | %--------------------------------------------------------------------- 121 | function hdr = make_header(dims, voxel_size, origin, datatype, ... 122 | descrip, maxval, minval) 123 | 124 | hdr.hk = header_key; 125 | hdr.dime = image_dimension(dims, voxel_size, datatype, maxval, minval); 126 | hdr.hist = data_history(origin, descrip); 127 | 128 | return; % make_header 129 | 130 | 131 | %--------------------------------------------------------------------- 132 | function hk = header_key 133 | 134 | hk.sizeof_hdr = 348; % must be 348! 135 | hk.data_type = ''; 136 | hk.db_name = ''; 137 | hk.extents = 0; 138 | hk.session_error = 0; 139 | hk.regular = 'r'; 140 | hk.hkey_un0 = '0'; 141 | 142 | return; % header_key 143 | 144 | 145 | %--------------------------------------------------------------------- 146 | function dime = image_dimension(dims, voxel_size, datatype, maxval, minval) 147 | 148 | dime.dim = dims; 149 | dime.vox_units = 'mm'; 150 | dime.cal_units = ''; 151 | dime.unused1 = 0; 152 | dime.datatype = datatype; 153 | 154 | switch dime.datatype 155 | case 2, 156 | dime.bitpix = 8; precision = 'uint8'; 157 | case 4, 158 | dime.bitpix = 16; precision = 'int16'; 159 | case 8, 160 | dime.bitpix = 32; precision = 'int32'; 161 | case 16, 162 | dime.bitpix = 32; precision = 'float32'; 163 | case 64, 164 | dime.bitpix = 64; precision = 'float64'; 165 | case 128 166 | dime.bitpix = 24; precision = 'uint8'; 167 | otherwise 168 | error('Datatype is not supported by make_ana.'); 169 | end 170 | 171 | dime.dim_un0 = 0; 172 | dime.pixdim = voxel_size; 173 | dime.vox_offset = 0; 174 | dime.roi_scale = 1; 175 | dime.funused1 = 0; 176 | dime.funused2 = 0; 177 | dime.cal_max = 0; 178 | dime.cal_min = 0; 179 | dime.compressed = 0; 180 | dime.verified = 0; 181 | dime.glmax = maxval; 182 | dime.glmin = minval; 183 | 184 | return; % image_dimension 185 | 186 | 187 | %--------------------------------------------------------------------- 188 | function hist = data_history(origin, descrip) 189 | 190 | hist.descrip = descrip; 191 | hist.aux_file = 'none'; 192 | hist.orient = 0; 193 | hist.originator = origin; 194 | hist.generated = ''; 195 | hist.scannum = ''; 196 | hist.patient_id = ''; 197 | hist.exp_date = ''; 198 | hist.exp_time = ''; 199 | hist.hist_un0 = ''; 200 | hist.views = 0; 201 | hist.vols_added = 0; 202 | hist.start_field = 0; 203 | hist.field_skip = 0; 204 | hist.omax = 0; 205 | hist.omin = 0; 206 | hist.smax = 0; 207 | hist.smin = 0; 208 | 209 | return; % data_history 210 | 211 | -------------------------------------------------------------------------------- /NIFTI/make_nii.m: -------------------------------------------------------------------------------- 1 | % Make NIfTI structure specified by an N-D matrix. Usually, N is 3 for 2 | % 3D matrix [x y z], or 4 for 4D matrix with time series [x y z t]. 3 | % Optional parameters can also be included, such as: voxel_size, 4 | % origin, datatype, and description. 5 | % 6 | % Once the NIfTI structure is made, it can be saved into NIfTI file 7 | % using "save_nii" command (for more detail, type: help save_nii). 8 | % 9 | % Usage: nii = make_nii(img, [voxel_size], [origin], [datatype], [description]) 10 | % 11 | % Where: 12 | % 13 | % img: Usually, img is a 3D matrix [x y z], or a 4D 14 | % matrix with time series [x y z t]. However, 15 | % NIfTI allows a maximum of 7D matrix. When the 16 | % image is in RGB format, make sure that the size 17 | % of 4th dimension is always 3 (i.e. [R G B]). In 18 | % that case, make sure that you must specify RGB 19 | % datatype, which is either 128 or 511. 20 | % 21 | % voxel_size (optional): Voxel size in millimeter for each 22 | % dimension. Default is [1 1 1]. 23 | % 24 | % origin (optional): The AC origin. Default is [0 0 0]. 25 | % 26 | % datatype (optional): Storage data type: 27 | % 2 - uint8, 4 - int16, 8 - int32, 16 - float32, 28 | % 32 - complex64, 64 - float64, 128 - RGB24, 29 | % 256 - int8, 511 - RGB96, 512 - uint16, 30 | % 768 - uint32, 1792 - complex128 31 | % Default will use the data type of 'img' matrix 32 | % For RGB image, you must specify it to either 128 33 | % or 511. 34 | % 35 | % description (optional): Description of data. Default is ''. 36 | % 37 | % e.g.: 38 | % origin = [33 44 13]; datatype = 64; 39 | % nii = make_nii(img, [], origin, datatype); % default voxel_size 40 | % 41 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 42 | % 43 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 44 | % 45 | function nii = make_nii(varargin) 46 | 47 | nii.img = varargin{1}; 48 | dims = size(nii.img); 49 | dims = [length(dims) dims ones(1,8)]; 50 | dims = dims(1:8); 51 | 52 | voxel_size = [0 ones(1,7)]; 53 | origin = zeros(1,5); 54 | descrip = ''; 55 | 56 | switch class(nii.img) 57 | case 'uint8' 58 | datatype = 2; 59 | case 'int16' 60 | datatype = 4; 61 | case 'int32' 62 | datatype = 8; 63 | case 'single' 64 | if isreal(nii.img) 65 | datatype = 16; 66 | else 67 | datatype = 32; 68 | end 69 | case 'double' 70 | if isreal(nii.img) 71 | datatype = 64; 72 | else 73 | datatype = 1792; 74 | end 75 | case 'int8' 76 | datatype = 256; 77 | case 'uint16' 78 | datatype = 512; 79 | case 'uint32' 80 | datatype = 768; 81 | otherwise 82 | error('Datatype is not supported by make_nii.'); 83 | end 84 | 85 | if nargin > 1 & ~isempty(varargin{2}) 86 | voxel_size(2:4) = double(varargin{2}); 87 | end 88 | 89 | if nargin > 2 & ~isempty(varargin{3}) 90 | origin(1:3) = double(varargin{3}); 91 | end 92 | 93 | if nargin > 3 & ~isempty(varargin{4}) 94 | datatype = double(varargin{4}); 95 | 96 | if datatype == 128 | datatype == 511 97 | dims(5) = []; 98 | dims(1) = dims(1) - 1; 99 | dims = [dims 1]; 100 | end 101 | end 102 | 103 | if nargin > 4 & ~isempty(varargin{5}) 104 | descrip = varargin{5}; 105 | end 106 | 107 | if ndims(nii.img) > 7 108 | error('NIfTI only allows a maximum of 7 Dimension matrix.'); 109 | end 110 | 111 | maxval = round(double(max(nii.img(:)))); 112 | minval = round(double(min(nii.img(:)))); 113 | 114 | nii.hdr = make_header(dims, voxel_size, origin, datatype, ... 115 | descrip, maxval, minval); 116 | 117 | switch nii.hdr.dime.datatype 118 | case 2 119 | nii.img = uint8(nii.img); 120 | case 4 121 | nii.img = int16(nii.img); 122 | case 8 123 | nii.img = int32(nii.img); 124 | case 16 125 | nii.img = single(nii.img); 126 | case 32 127 | nii.img = single(nii.img); 128 | case 64 129 | nii.img = double(nii.img); 130 | case 128 131 | nii.img = uint8(nii.img); 132 | case 256 133 | nii.img = int8(nii.img); 134 | case 511 135 | img = double(nii.img(:)); 136 | img = single((img - min(img))/(max(img) - min(img))); 137 | nii.img = reshape(img, size(nii.img)); 138 | nii.hdr.dime.glmax = double(max(img)); 139 | nii.hdr.dime.glmin = double(min(img)); 140 | case 512 141 | nii.img = uint16(nii.img); 142 | case 768 143 | nii.img = uint32(nii.img); 144 | case 1792 145 | nii.img = double(nii.img); 146 | otherwise 147 | error('Datatype is not supported by make_nii.'); 148 | end 149 | 150 | return; % make_nii 151 | 152 | 153 | %--------------------------------------------------------------------- 154 | function hdr = make_header(dims, voxel_size, origin, datatype, ... 155 | descrip, maxval, minval) 156 | 157 | hdr.hk = header_key; 158 | hdr.dime = image_dimension(dims, voxel_size, datatype, maxval, minval); 159 | hdr.hist = data_history(origin, descrip); 160 | 161 | return; % make_header 162 | 163 | 164 | %--------------------------------------------------------------------- 165 | function hk = header_key 166 | 167 | hk.sizeof_hdr = 348; % must be 348! 168 | hk.data_type = ''; 169 | hk.db_name = ''; 170 | hk.extents = 0; 171 | hk.session_error = 0; 172 | hk.regular = 'r'; 173 | hk.dim_info = 0; 174 | 175 | return; % header_key 176 | 177 | 178 | %--------------------------------------------------------------------- 179 | function dime = image_dimension(dims, voxel_size, datatype, maxval, minval) 180 | 181 | dime.dim = dims; 182 | dime.intent_p1 = 0; 183 | dime.intent_p2 = 0; 184 | dime.intent_p3 = 0; 185 | dime.intent_code = 0; 186 | dime.datatype = datatype; 187 | 188 | switch dime.datatype 189 | case 2, 190 | dime.bitpix = 8; precision = 'uint8'; 191 | case 4, 192 | dime.bitpix = 16; precision = 'int16'; 193 | case 8, 194 | dime.bitpix = 32; precision = 'int32'; 195 | case 16, 196 | dime.bitpix = 32; precision = 'float32'; 197 | case 32, 198 | dime.bitpix = 64; precision = 'float32'; 199 | case 64, 200 | dime.bitpix = 64; precision = 'float64'; 201 | case 128 202 | dime.bitpix = 24; precision = 'uint8'; 203 | case 256 204 | dime.bitpix = 8; precision = 'int8'; 205 | case 511 206 | dime.bitpix = 96; precision = 'float32'; 207 | case 512 208 | dime.bitpix = 16; precision = 'uint16'; 209 | case 768 210 | dime.bitpix = 32; precision = 'uint32'; 211 | case 1792, 212 | dime.bitpix = 128; precision = 'float64'; 213 | otherwise 214 | error('Datatype is not supported by make_nii.'); 215 | end 216 | 217 | dime.slice_start = 0; 218 | dime.pixdim = voxel_size; 219 | dime.vox_offset = 0; 220 | dime.scl_slope = 0; 221 | dime.scl_inter = 0; 222 | dime.slice_end = 0; 223 | dime.slice_code = 0; 224 | dime.xyzt_units = 0; 225 | dime.cal_max = 0; 226 | dime.cal_min = 0; 227 | dime.slice_duration = 0; 228 | dime.toffset = 0; 229 | dime.glmax = maxval; 230 | dime.glmin = minval; 231 | 232 | return; % image_dimension 233 | 234 | 235 | %--------------------------------------------------------------------- 236 | function hist = data_history(origin, descrip) 237 | 238 | hist.descrip = descrip; 239 | hist.aux_file = 'none'; 240 | hist.qform_code = 0; 241 | hist.sform_code = 0; 242 | hist.quatern_b = 0; 243 | hist.quatern_c = 0; 244 | hist.quatern_d = 0; 245 | hist.qoffset_x = 0; 246 | hist.qoffset_y = 0; 247 | hist.qoffset_z = 0; 248 | hist.srow_x = zeros(1,4); 249 | hist.srow_y = zeros(1,4); 250 | hist.srow_z = zeros(1,4); 251 | hist.intent_name = ''; 252 | hist.magic = ''; 253 | hist.originator = origin; 254 | 255 | return; % data_history 256 | 257 | -------------------------------------------------------------------------------- /NIFTI/mat_into_hdr.m: -------------------------------------------------------------------------------- 1 | %MAT_INTO_HDR The old versions of SPM (any version before SPM5) store 2 | % an affine matrix of the SPM Reoriented image into a matlab file 3 | % (.mat extension). The file name of this SPM matlab file is the 4 | % same as the SPM Reoriented image file (.img/.hdr extension). 5 | % 6 | % This program will convert the ANALYZE 7.5 SPM Reoriented image 7 | % file into NIfTI format, and integrate the affine matrix in the 8 | % SPM matlab file into its header file (.hdr extension). 9 | % 10 | % WARNING: Before you run this program, please save the header 11 | % file (.hdr extension) into another file name or into another 12 | % folder location, because all header files (.hdr extension) 13 | % will be overwritten after they are converted into NIfTI 14 | % format. 15 | % 16 | % Usage: mat_into_hdr(filename); 17 | % 18 | % filename: file name(s) with .hdr or .mat file extension, like: 19 | % '*.hdr', or '*.mat', or a single .hdr or .mat file. 20 | % e.g. mat_into_hdr('T1.hdr') 21 | % mat_into_hdr('*.mat') 22 | % 23 | 24 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 25 | % 26 | %------------------------------------------------------------------------- 27 | function mat_into_hdr(files) 28 | 29 | pn = fileparts(files); 30 | file_lst = dir(files); 31 | file_lst = {file_lst.name}; 32 | file1 = file_lst{1}; 33 | [p n e]= fileparts(file1); 34 | 35 | for i=1:length(file_lst) 36 | [p n e]= fileparts(file_lst{i}); 37 | disp(['working on file ', num2str(i) ,' of ', num2str(length(file_lst)), ': ', n,e]); 38 | process=1; 39 | 40 | if isequal(e,'.hdr') 41 | mat=fullfile(pn, [n,'.mat']); 42 | hdr=fullfile(pn, file_lst{i}); 43 | 44 | if ~exist(mat,'file') 45 | warning(['Cannot find file "',mat , '". File "', n, e, '" will not be processed.']); 46 | process=0; 47 | end 48 | elseif isequal(e,'.mat') 49 | hdr=fullfile(pn, [n,'.hdr']); 50 | mat=fullfile(pn, file_lst{i}); 51 | 52 | if ~exist(hdr,'file') 53 | warning(['Can not find file "',hdr , '". File "', n, e, '" will not be processed.']); 54 | process=0; 55 | end 56 | else 57 | warning(['Input file must have .mat or .hdr extension. File "', n, e, '" will not be processed.']); 58 | process=0; 59 | end 60 | 61 | if process 62 | load(mat); 63 | R=M(1:3,1:3); 64 | T=M(1:3,4); 65 | T=R*ones(3,1)+T; 66 | M(1:3,4)=T; 67 | 68 | [h filetype fileprefix machine]=load_nii_hdr(hdr); 69 | h.hist.qform_code=0; 70 | h.hist.sform_code=1; 71 | h.hist.srow_x=M(1,:); 72 | h.hist.srow_y=M(2,:); 73 | h.hist.srow_z=M(3,:); 74 | h.hist.magic='ni1'; 75 | 76 | fid = fopen(hdr,'w',machine); 77 | save_nii_hdr(h,fid); 78 | fclose(fid); 79 | end 80 | end 81 | 82 | return; % mat_into_hdr 83 | 84 | -------------------------------------------------------------------------------- /NIFTI/rri_file_menu.m: -------------------------------------------------------------------------------- 1 | % Imbed a file menu to any figure. If file menu exist, it will append 2 | % to the existing file menu. This file menu includes: Copy to clipboard, 3 | % print, save, close etc. 4 | % 5 | % Usage: rri_file_menu(fig); 6 | % 7 | % rri_file_menu(fig,0) means no 'Close' menu. 8 | % 9 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 10 | % 11 | %-------------------------------------------------------------------- 12 | 13 | function rri_file_menu(action, varargin) 14 | 15 | if isnumeric(action) 16 | fig = action; 17 | action = 'init'; 18 | end 19 | 20 | % clear the message line, 21 | % 22 | h = findobj(gcf,'Tag','MessageLine'); 23 | set(h,'String',''); 24 | 25 | if ~strcmp(action, 'init') 26 | set(gcbf, 'InvertHardcopy','off'); 27 | % set(gcbf, 'PaperPositionMode','auto'); 28 | end 29 | 30 | switch action 31 | case {'init'} 32 | if nargin > 1 33 | init(fig, 1); % no 'close' menu 34 | else 35 | init(fig, 0); 36 | end 37 | case {'print_fig'} 38 | printdlg(gcbf); 39 | case {'copy_fig'} 40 | copy_fig; 41 | case {'export_fig'} 42 | export_fig; 43 | end 44 | 45 | return % rri_file_menu 46 | 47 | 48 | %------------------------------------------------ 49 | % 50 | % Create (or append) File menu 51 | % 52 | function init(fig, no_close) 53 | 54 | % search for file menu 55 | % 56 | h_file = []; 57 | menuitems = findobj(fig, 'type', 'uimenu'); 58 | 59 | for i=1:length(menuitems) 60 | filelabel = get(menuitems(i),'label'); 61 | 62 | if strcmpi(strrep(filelabel, '&', ''), 'file') 63 | h_file = menuitems(i); 64 | break; 65 | end 66 | end 67 | 68 | set(fig, 'menubar', 'none'); 69 | 70 | if isempty(h_file) 71 | if isempty(menuitems) 72 | h_file = uimenu('parent', fig, 'label', 'File'); 73 | else 74 | h_file = uimenu('parent', fig, 'label', 'Copy Figure'); 75 | end 76 | 77 | h1 = uimenu('parent', h_file, ... 78 | 'callback','rri_file_menu(''copy_fig'');', ... 79 | 'label','Copy to Clipboard'); 80 | else 81 | h1 = uimenu('parent', h_file, ... 82 | 'callback','rri_file_menu(''copy_fig'');', ... 83 | 'separator','on', ... 84 | 'label','Copy to Clipboard'); 85 | end 86 | 87 | h2 = uimenu(h_file, ... 88 | 'callback','pagesetupdlg(gcbf);', ... 89 | 'label','Page Setup...'); 90 | 91 | h2 = uimenu(h_file, ... 92 | 'callback','printpreview(gcbf);', ... 93 | 'label','Print Preview...'); 94 | 95 | h2 = uimenu('parent', h_file, ... 96 | 'callback','printdlg(gcbf);', ... 97 | 'label','Print Figure ...'); 98 | 99 | h2 = uimenu('parent', h_file, ... 100 | 'callback','rri_file_menu(''export_fig'');', ... 101 | 'label','Save Figure ...'); 102 | 103 | arch = computer; 104 | if ~strcmpi(arch(1:2),'PC') 105 | set(h1, 'enable', 'off'); 106 | end 107 | 108 | if ~no_close 109 | h1 = uimenu('parent', h_file, ... 110 | 'callback','close(gcbf);', ... 111 | 'separator','on', ... 112 | 'label','Close'); 113 | end 114 | 115 | return; % init 116 | 117 | 118 | %------------------------------------------------ 119 | % 120 | % Copy to clipboard 121 | % 122 | function copy_fig 123 | 124 | arch = computer; 125 | if(~strcmpi(arch(1:2),'PC')) 126 | error('copy to clipboard can only be used under MS Windows'); 127 | return; 128 | end 129 | 130 | print -noui -dbitmap; 131 | 132 | return % copy_fig 133 | 134 | 135 | %------------------------------------------------ 136 | % 137 | % Save as an image file 138 | % 139 | function export_fig 140 | 141 | curr = pwd; 142 | if isempty(curr) 143 | curr = filesep; 144 | end 145 | 146 | [selected_file, selected_path] = rri_select_file(curr,'Save As'); 147 | 148 | if isempty(selected_file) | isempty(selected_path) 149 | return; 150 | end 151 | 152 | filename = [selected_path selected_file]; 153 | 154 | if(exist(filename,'file')==2) % file exist 155 | 156 | dlg_title = 'Confirm File Overwrite'; 157 | msg = ['File ',filename,' exist. Are you sure you want to overwrite it?']; 158 | response = questdlg(msg,dlg_title,'Yes','No','Yes'); 159 | 160 | if(strcmp(response,'No')) 161 | return; 162 | end 163 | 164 | end 165 | 166 | old_pointer = get(gcbf,'pointer'); 167 | set(gcbf,'pointer','watch'); 168 | 169 | try 170 | saveas(gcbf,filename); 171 | catch 172 | msg = 'ERROR: Cannot save file'; 173 | set(findobj(gcf,'Tag','MessageLine'),'String',msg); 174 | end 175 | 176 | set(gcbf,'pointer',old_pointer); 177 | 178 | return; % export_fig 179 | 180 | -------------------------------------------------------------------------------- /NIFTI/rri_orient.m: -------------------------------------------------------------------------------- 1 | % Convert image of different orientations to standard Analyze orientation 2 | % 3 | % Usage: nii = rri_orient(nii); 4 | 5 | % Jimmy Shen (jimmy@rotman-baycrest.on.ca), 26-APR-04 6 | %___________________________________________________________________ 7 | 8 | function [nii, orient, pattern] = rri_orient(nii, varargin) 9 | 10 | if nargin > 1 11 | pattern = varargin{1}; 12 | else 13 | pattern = []; 14 | end 15 | 16 | orient = [1 2 3]; 17 | dim = double(nii.hdr.dime.dim([2:4])); 18 | 19 | if ~isempty(pattern) & ~isequal(length(pattern), prod(dim)) 20 | return; 21 | end 22 | 23 | % get orient of the current image 24 | % 25 | orient = rri_orient_ui; 26 | pause(.1); 27 | 28 | % no need for conversion 29 | % 30 | if isequal(orient, [1 2 3]) 31 | return; 32 | end 33 | 34 | if isempty(pattern) 35 | pattern = 1:prod(dim); 36 | end 37 | 38 | pattern = reshape(pattern, dim); 39 | img = nii.img; 40 | 41 | % calculate after flip orient 42 | % 43 | rot_orient = mod(orient + 2, 3) + 1; 44 | 45 | % do flip: 46 | % 47 | flip_orient = orient - rot_orient; 48 | 49 | for i = 1:3 50 | if flip_orient(i) 51 | pattern = flipdim(pattern, i); 52 | img = flipdim(img, i); 53 | end 54 | end 55 | 56 | % get index of orient (do inverse) 57 | % 58 | [tmp rot_orient] = sort(rot_orient); 59 | 60 | % do rotation: 61 | % 62 | pattern = permute(pattern, rot_orient); 63 | img = permute(img, [rot_orient 4 5 6]); 64 | 65 | % rotate resolution, or 'dim' 66 | % 67 | new_dim = nii.hdr.dime.dim([2:4]); 68 | new_dim = new_dim(rot_orient); 69 | nii.hdr.dime.dim([2:4]) = new_dim; 70 | 71 | % rotate voxel_size, or 'pixdim' 72 | % 73 | tmp = nii.hdr.dime.pixdim([2:4]); 74 | tmp = tmp(rot_orient); 75 | nii.hdr.dime.pixdim([2:4]) = tmp; 76 | 77 | % re-calculate originator 78 | % 79 | tmp = nii.hdr.hist.originator([1:3]); 80 | tmp = tmp(rot_orient); 81 | flip_orient = flip_orient(rot_orient); 82 | 83 | for i = 1:3 84 | if flip_orient(i) & ~isequal(double(tmp(i)), 0) 85 | tmp(i) = int16(double(new_dim(i)) - double(tmp(i)) + 1); 86 | end 87 | end 88 | 89 | nii.hdr.hist.originator([1:3]) = tmp; 90 | 91 | nii.img = img; 92 | pattern = pattern(:); 93 | 94 | return; % rri_orient 95 | 96 | -------------------------------------------------------------------------------- /NIFTI/rri_orient_ui.m: -------------------------------------------------------------------------------- 1 | % Return orientation of the current image: 2 | % orient is orientation 1x3 matrix, in that: 3 | % Three elements represent: [x y z] 4 | % Element value: 1 - Left to Right; 2 - Posterior to Anterior; 5 | % 3 - Inferior to Superior; 4 - Right to Left; 6 | % 5 - Anterior to Posterior; 6 - Superior to Inferior; 7 | % e.g.: 8 | % Standard RAS Orientation: [1 2 3] 9 | % Standard RHOS Orientation: [2 4 3] 10 | 11 | % Jimmy Shen (jimmy@rotman-baycrest.on.ca), 26-APR-04 12 | % 13 | function orient = rri_orient_ui(varargin) 14 | 15 | if nargin == 0 16 | init; 17 | orient_ui_fig = gcf; 18 | uiwait; % wait for user finish 19 | 20 | orient = getappdata(gcf, 'orient'); 21 | 22 | if isempty(orient) 23 | orient = [1 2 3]; 24 | end 25 | 26 | if ishandle(orient_ui_fig) 27 | close(gcf); 28 | end 29 | 30 | return; 31 | end 32 | 33 | action = varargin{1}; 34 | 35 | if strcmp(action, 'done') 36 | click_done; 37 | elseif strcmp(action, 'cancel') 38 | uiresume; 39 | end 40 | 41 | return; % rri_orient_ui 42 | 43 | 44 | %---------------------------------------------------------------------- 45 | function init 46 | 47 | save_setting_status = 'on'; 48 | rri_orient_pos = []; 49 | 50 | try 51 | load('pls_profile'); 52 | catch 53 | end 54 | 55 | try 56 | load('rri_pos_profile'); 57 | catch 58 | end 59 | 60 | if ~isempty(rri_orient_pos) & strcmp(save_setting_status,'on') 61 | 62 | pos = rri_orient_pos; 63 | 64 | else 65 | 66 | w = 0.35; 67 | h = 0.4; 68 | x = (1-w)/2; 69 | y = (1-h)/2; 70 | 71 | pos = [x y w h]; 72 | 73 | end 74 | 75 | handles.figure = figure('Color',[0.8 0.8 0.8], ... 76 | 'Units','normal', ... 77 | 'Name', 'Convert to standard RAS orientation', ... 78 | 'NumberTitle','off', ... 79 | 'MenuBar','none', ... 80 | 'Position',pos, ... 81 | 'WindowStyle', 'normal', ... 82 | 'ToolBar','none'); 83 | 84 | h0 = handles.figure; 85 | Font.FontUnits = 'point'; 86 | Font.FontSize = 12; 87 | 88 | margin = .1; 89 | line_num = 6; 90 | line_ht = (1 - margin*2) / line_num; 91 | 92 | x = margin; 93 | y = 1 - margin - line_ht; 94 | w = 1 - margin * 2; 95 | h = line_ht * .7; 96 | 97 | pos = [x y w h]; 98 | 99 | handles.Ttit = uicontrol('parent', h0, ... 100 | 'style','text', ... 101 | 'unit', 'normal', ... 102 | Font, ... 103 | 'Position',pos, ... 104 | 'HorizontalAlignment','left',... 105 | 'background', [0.8 0.8 0.8], ... 106 | 'string', 'Please input orientation of the current image:'); 107 | 108 | y = y - line_ht; 109 | w = .2; 110 | 111 | pos = [x y w h]; 112 | 113 | handles.Tx_orient = uicontrol('parent', h0, ... 114 | 'style','text', ... 115 | 'unit', 'normal', ... 116 | Font, ... 117 | 'Position',pos, ... 118 | 'HorizontalAlignment','left',... 119 | 'background', [0.8 0.8 0.8], ... 120 | 'string', 'X Axes:'); 121 | 122 | y = y - line_ht; 123 | 124 | pos = [x y w h]; 125 | 126 | handles.Ty_orient = uicontrol('parent', h0, ... 127 | 'style','text', ... 128 | 'unit', 'normal', ... 129 | Font, ... 130 | 'Position',pos, ... 131 | 'HorizontalAlignment','left',... 132 | 'background', [0.8 0.8 0.8], ... 133 | 'string', 'Y Axes:'); 134 | 135 | y = y - line_ht; 136 | 137 | pos = [x y w h]; 138 | 139 | handles.Tz_orient = uicontrol('parent', h0, ... 140 | 'style','text', ... 141 | 'unit', 'normal', ... 142 | Font, ... 143 | 'Position',pos, ... 144 | 'HorizontalAlignment','left',... 145 | 'background', [0.8 0.8 0.8], ... 146 | 'string', 'Z Axes:'); 147 | 148 | choice = { 'From Left to Right', 'From Posterior to Anterior', ... 149 | 'From Inferior to Superior', 'From Right to Left', ... 150 | 'From Anterior to Posterior', 'From Superior to Inferior' }; 151 | 152 | y = 1 - margin - line_ht; 153 | y = y - line_ht; 154 | w = 1 - margin - x - w; 155 | x = 1 - margin - w; 156 | 157 | pos = [x y w h]; 158 | 159 | handles.x_orient = uicontrol('parent', h0, ... 160 | 'style','popupmenu', ... 161 | 'unit', 'normal', ... 162 | Font, ... 163 | 'Position',pos, ... 164 | 'HorizontalAlignment','left',... 165 | 'string', choice, ... 166 | 'value', 1, ... 167 | 'background', [1 1 1]); 168 | 169 | y = y - line_ht; 170 | 171 | pos = [x y w h]; 172 | 173 | handles.y_orient = uicontrol('parent', h0, ... 174 | 'style','popupmenu', ... 175 | 'unit', 'normal', ... 176 | Font, ... 177 | 'Position',pos, ... 178 | 'HorizontalAlignment','left',... 179 | 'string', choice, ... 180 | 'value', 2, ... 181 | 'background', [1 1 1]); 182 | 183 | y = y - line_ht; 184 | 185 | pos = [x y w h]; 186 | 187 | handles.z_orient = uicontrol('parent', h0, ... 188 | 'style','popupmenu', ... 189 | 'unit', 'normal', ... 190 | Font, ... 191 | 'Position',pos, ... 192 | 'HorizontalAlignment','left',... 193 | 'string', choice, ... 194 | 'value', 3, ... 195 | 'background', [1 1 1]); 196 | 197 | x = margin; 198 | y = y - line_ht * 1.5; 199 | w = .3; 200 | 201 | pos = [x y w h]; 202 | 203 | handles.done = uicontrol('parent', h0, ... 204 | 'unit', 'normal', ... 205 | Font, ... 206 | 'Position',pos, ... 207 | 'HorizontalAlignment','center',... 208 | 'callback', 'rri_orient_ui(''done'');', ... 209 | 'string', 'Done'); 210 | 211 | x = 1 - margin - w; 212 | 213 | pos = [x y w h]; 214 | 215 | handles.cancel = uicontrol('parent', h0, ... 216 | 'unit', 'normal', ... 217 | Font, ... 218 | 'Position',pos, ... 219 | 'HorizontalAlignment','center',... 220 | 'callback', 'rri_orient_ui(''cancel'');', ... 221 | 'string', 'Cancel'); 222 | 223 | setappdata(h0, 'handles', handles); 224 | setappdata(h0, 'orient', [1 2 3]); 225 | 226 | return; % init 227 | 228 | 229 | %---------------------------------------------------------------------- 230 | function click_done 231 | 232 | handles = getappdata(gcf, 'handles'); 233 | 234 | x_orient = get(handles.x_orient, 'value'); 235 | y_orient = get(handles.y_orient, 'value'); 236 | z_orient = get(handles.z_orient, 'value'); 237 | 238 | orient = [x_orient y_orient z_orient]; 239 | test_orient = [orient, orient + 3]; 240 | test_orient = mod(test_orient, 3); 241 | 242 | if length(unique(test_orient)) ~= 3 243 | msgbox('Please don''t choose same or opposite direction','Error','modal'); 244 | return; 245 | end 246 | 247 | setappdata(gcf, 'orient', [x_orient y_orient z_orient]); 248 | uiresume; 249 | 250 | return; % click_done 251 | 252 | -------------------------------------------------------------------------------- /NIFTI/rri_xhair.m: -------------------------------------------------------------------------------- 1 | % rri_xhair: create a pair of full_cross_hair at point [x y] in 2 | % axes h_ax, and return xhair struct 3 | % 4 | % Usage: xhair = rri_xhair([x y], xhair, h_ax); 5 | % 6 | % If omit xhair, rri_xhair will create a pair of xhair; otherwise, 7 | % rri_xhair will update the xhair. If omit h_ax, current axes will 8 | % be used. 9 | % 10 | 11 | % 24-nov-2003 jimmy (jimmy@rotman-baycrest.on.ca) 12 | % 13 | %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% 14 | 15 | function xhair = rri_xhair(varargin) 16 | 17 | if nargin == 0 18 | error('Please enter a point position as first argument'); 19 | return; 20 | end 21 | 22 | if nargin > 0 23 | p = varargin{1}; 24 | 25 | if ~isnumeric(p) | length(p) ~= 2 26 | error('Invalid point position'); 27 | return; 28 | else 29 | xhair = []; 30 | end 31 | end 32 | 33 | if nargin > 1 34 | xhair = varargin{2}; 35 | 36 | if ~isempty(xhair) 37 | if ~isstruct(xhair) 38 | error('Invalid xhair struct'); 39 | return; 40 | elseif ~isfield(xhair,'lx') | ~isfield(xhair,'ly') 41 | error('Invalid xhair struct'); 42 | return; 43 | elseif ~ishandle(xhair.lx) | ~ishandle(xhair.ly) 44 | error('Invalid xhair struct'); 45 | return; 46 | end 47 | 48 | lx = xhair.lx; 49 | ly = xhair.ly; 50 | else 51 | lx = []; 52 | ly = []; 53 | end 54 | end 55 | 56 | if nargin > 2 57 | h_ax = varargin{3}; 58 | 59 | if ~ishandle(h_ax) 60 | error('Invalid axes handle'); 61 | return; 62 | elseif ~strcmp(lower(get(h_ax,'type')), 'axes') 63 | error('Invalid axes handle'); 64 | return; 65 | end 66 | else 67 | h_ax = gca; 68 | end 69 | 70 | x_range = get(h_ax,'xlim'); 71 | y_range = get(h_ax,'ylim'); 72 | 73 | if ~isempty(xhair) 74 | set(lx, 'ydata', [p(2) p(2)]); 75 | set(ly, 'xdata', [p(1) p(1)]); 76 | set(h_ax, 'selected', 'on'); 77 | set(h_ax, 'selected', 'off'); 78 | else 79 | figure(get(h_ax,'parent')); 80 | axes(h_ax); 81 | 82 | xhair.lx = line('xdata', x_range, 'ydata', [p(2) p(2)], ... 83 | 'zdata', [11 11], 'color', [1 0 0], 'hittest', 'off'); 84 | xhair.ly = line('xdata', [p(1) p(1)], 'ydata', y_range, ... 85 | 'zdata', [11 11], 'color', [1 0 0], 'hittest', 'off'); 86 | end 87 | 88 | set(h_ax,'xlim',x_range); 89 | set(h_ax,'ylim',y_range); 90 | 91 | return; 92 | 93 | -------------------------------------------------------------------------------- /NIFTI/rri_zoom_menu.m: -------------------------------------------------------------------------------- 1 | % Imbed a zoom menu to any figure. 2 | % 3 | % Usage: rri_zoom_menu(fig); 4 | % 5 | 6 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 7 | % 8 | %-------------------------------------------------------------------- 9 | function menu_hdl = rri_zoom_menu(fig) 10 | 11 | if isnumeric(fig) 12 | menu_hdl = uimenu('Parent',fig, ... 13 | 'Label','Zoom on', ... 14 | 'Userdata', 1, ... 15 | 'Callback','rri_zoom_menu(''zoom'');'); 16 | 17 | return; 18 | end 19 | 20 | zoom_on_state = get(gcbo,'Userdata'); 21 | 22 | if (zoom_on_state == 1) 23 | zoom on; 24 | set(gcbo,'Userdata',0,'Label','Zoom off'); 25 | set(gcbf,'pointer','crosshair'); 26 | else 27 | zoom off; 28 | set(gcbo,'Userdata',1,'Label','Zoom on'); 29 | set(gcbf,'pointer','arrow'); 30 | end 31 | 32 | return % rri_zoom_menu 33 | 34 | -------------------------------------------------------------------------------- /NIFTI/save_nii.m: -------------------------------------------------------------------------------- 1 | % Save NIFTI dataset. Support both *.nii and *.hdr/*.img file extension. 2 | % If file extension is not provided, *.hdr/*.img will be used as default. 3 | % 4 | % Usage: save_nii(nii, filename, [old_RGB]) 5 | % 6 | % nii.hdr - struct with NIFTI header fields (from load_nii.m or make_nii.m) 7 | % 8 | % nii.img - 3D (or 4D) matrix of NIFTI data. 9 | % 10 | % filename - NIFTI file name. 11 | % 12 | % old_RGB - an optional boolean variable to handle special RGB data 13 | % sequence [R1 R2 ... G1 G2 ... B1 B2 ...] that is used only by 14 | % AnalyzeDirect (Analyze Software). Since both NIfTI and Analyze 15 | % file format use RGB triple [R1 G1 B1 R2 G2 B2 ...] sequentially 16 | % for each voxel, this variable is set to FALSE by default. If you 17 | % would like the saved image only to be opened by AnalyzeDirect 18 | % Software, set old_RGB to TRUE (or 1). It will be set to 0, if it 19 | % is default or empty. 20 | % 21 | % Tip: to change the data type, set nii.hdr.dime.datatype, 22 | % and nii.hdr.dime.bitpix to: 23 | % 24 | % 0 None (Unknown bit per voxel) % DT_NONE, DT_UNKNOWN 25 | % 1 Binary (ubit1, bitpix=1) % DT_BINARY 26 | % 2 Unsigned char (uchar or uint8, bitpix=8) % DT_UINT8, NIFTI_TYPE_UINT8 27 | % 4 Signed short (int16, bitpix=16) % DT_INT16, NIFTI_TYPE_INT16 28 | % 8 Signed integer (int32, bitpix=32) % DT_INT32, NIFTI_TYPE_INT32 29 | % 16 Floating point (single or float32, bitpix=32) % DT_FLOAT32, NIFTI_TYPE_FLOAT32 30 | % 32 Complex, 2 float32 (Use float32, bitpix=64) % DT_COMPLEX64, NIFTI_TYPE_COMPLEX64 31 | % 64 Double precision (double or float64, bitpix=64) % DT_FLOAT64, NIFTI_TYPE_FLOAT64 32 | % 128 uint RGB (Use uint8, bitpix=24) % DT_RGB24, NIFTI_TYPE_RGB24 33 | % 256 Signed char (schar or int8, bitpix=8) % DT_INT8, NIFTI_TYPE_INT8 34 | % 511 Single RGB (Use float32, bitpix=96) % DT_RGB96, NIFTI_TYPE_RGB96 35 | % 512 Unsigned short (uint16, bitpix=16) % DT_UNINT16, NIFTI_TYPE_UNINT16 36 | % 768 Unsigned integer (uint32, bitpix=32) % DT_UNINT32, NIFTI_TYPE_UNINT32 37 | % 1024 Signed long long (int64, bitpix=64) % DT_INT64, NIFTI_TYPE_INT64 38 | % 1280 Unsigned long long (uint64, bitpix=64) % DT_UINT64, NIFTI_TYPE_UINT64 39 | % 1536 Long double, float128 (Unsupported, bitpix=128) % DT_FLOAT128, NIFTI_TYPE_FLOAT128 40 | % 1792 Complex128, 2 float64 (Use float64, bitpix=128) % DT_COMPLEX128, NIFTI_TYPE_COMPLEX128 41 | % 2048 Complex256, 2 float128 (Unsupported, bitpix=256) % DT_COMPLEX128, NIFTI_TYPE_COMPLEX128 42 | % 43 | % Part of this file is copied and modified from: 44 | % http://www.mathworks.com/matlabcentral/fileexchange/1878-mri-analyze-tools 45 | % 46 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 47 | % 48 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 49 | % - "old_RGB" related codes in "save_nii.m" are added by Mike Harms (2006.06.28) 50 | % 51 | function save_nii(nii, fileprefix, old_RGB) 52 | 53 | if ~exist('nii','var') | isempty(nii) | ~isfield(nii,'hdr') | ... 54 | ~isfield(nii,'img') | ~exist('fileprefix','var') | isempty(fileprefix) 55 | 56 | error('Usage: save_nii(nii, filename, [old_RGB])'); 57 | end 58 | 59 | if isfield(nii,'untouch') & nii.untouch == 1 60 | error('Usage: please use ''save_untouch_nii.m'' for the untouched structure.'); 61 | end 62 | 63 | if ~exist('old_RGB','var') | isempty(old_RGB) 64 | old_RGB = 0; 65 | end 66 | 67 | v = version; 68 | 69 | % Check file extension. If .gz, unpack it into temp folder 70 | % 71 | if length(fileprefix) > 2 & strcmp(fileprefix(end-2:end), '.gz') 72 | 73 | if ~strcmp(fileprefix(end-6:end), '.img.gz') & ... 74 | ~strcmp(fileprefix(end-6:end), '.hdr.gz') & ... 75 | ~strcmp(fileprefix(end-6:end), '.nii.gz') 76 | 77 | error('Please check filename.'); 78 | end 79 | 80 | if str2num(v(1:3)) < 7.1 | ~usejava('jvm') 81 | error('Please use MATLAB 7.1 (with java) and above, or run gunzip outside MATLAB.'); 82 | else 83 | gzFile = 1; 84 | fileprefix = fileprefix(1:end-3); 85 | end 86 | end 87 | 88 | filetype = 1; 89 | 90 | % Note: fileprefix is actually the filename you want to save 91 | % 92 | if findstr('.nii',fileprefix) & strcmp(fileprefix(end-3:end), '.nii') 93 | filetype = 2; 94 | fileprefix(end-3:end)=''; 95 | end 96 | 97 | if findstr('.hdr',fileprefix) & strcmp(fileprefix(end-3:end), '.hdr') 98 | fileprefix(end-3:end)=''; 99 | end 100 | 101 | if findstr('.img',fileprefix) & strcmp(fileprefix(end-3:end), '.img') 102 | fileprefix(end-3:end)=''; 103 | end 104 | 105 | write_nii(nii, filetype, fileprefix, old_RGB); 106 | 107 | % gzip output file if requested 108 | % 109 | if exist('gzFile', 'var') 110 | if filetype == 1 111 | gzip([fileprefix, '.img']); 112 | delete([fileprefix, '.img']); 113 | gzip([fileprefix, '.hdr']); 114 | delete([fileprefix, '.hdr']); 115 | elseif filetype == 2 116 | gzip([fileprefix, '.nii']); 117 | delete([fileprefix, '.nii']); 118 | end; 119 | end; 120 | 121 | if filetype == 1 122 | 123 | % So earlier versions of SPM can also open it with correct originator 124 | % 125 | M=[[diag(nii.hdr.dime.pixdim(2:4)) -[nii.hdr.hist.originator(1:3).*nii.hdr.dime.pixdim(2:4)]'];[0 0 0 1]]; 126 | save([fileprefix '.mat'], 'M'); 127 | end 128 | 129 | return % save_nii 130 | 131 | 132 | %----------------------------------------------------------------------------------- 133 | function write_nii(nii, filetype, fileprefix, old_RGB) 134 | 135 | hdr = nii.hdr; 136 | 137 | if isfield(nii,'ext') & ~isempty(nii.ext) 138 | ext = nii.ext; 139 | [ext, esize_total] = verify_nii_ext(ext); 140 | else 141 | ext = []; 142 | end 143 | 144 | switch double(hdr.dime.datatype), 145 | case 1, 146 | hdr.dime.bitpix = int16(1 ); precision = 'ubit1'; 147 | case 2, 148 | hdr.dime.bitpix = int16(8 ); precision = 'uint8'; 149 | case 4, 150 | hdr.dime.bitpix = int16(16); precision = 'int16'; 151 | case 8, 152 | hdr.dime.bitpix = int16(32); precision = 'int32'; 153 | case 16, 154 | hdr.dime.bitpix = int16(32); precision = 'float32'; 155 | case 32, 156 | hdr.dime.bitpix = int16(64); precision = 'float32'; 157 | case 64, 158 | hdr.dime.bitpix = int16(64); precision = 'float64'; 159 | case 128, 160 | hdr.dime.bitpix = int16(24); precision = 'uint8'; 161 | case 256 162 | hdr.dime.bitpix = int16(8 ); precision = 'int8'; 163 | case 511, 164 | hdr.dime.bitpix = int16(96); precision = 'float32'; 165 | case 512 166 | hdr.dime.bitpix = int16(16); precision = 'uint16'; 167 | case 768 168 | hdr.dime.bitpix = int16(32); precision = 'uint32'; 169 | case 1024 170 | hdr.dime.bitpix = int16(64); precision = 'int64'; 171 | case 1280 172 | hdr.dime.bitpix = int16(64); precision = 'uint64'; 173 | case 1792, 174 | hdr.dime.bitpix = int16(128); precision = 'float64'; 175 | otherwise 176 | error('This datatype is not supported'); 177 | end 178 | 179 | hdr.dime.glmax = round(double(max(nii.img(:)))); 180 | hdr.dime.glmin = round(double(min(nii.img(:)))); 181 | 182 | if filetype == 2 183 | fid = fopen(sprintf('%s.nii',fileprefix),'w'); 184 | 185 | if fid < 0, 186 | msg = sprintf('Cannot open file %s.nii.',fileprefix); 187 | error(msg); 188 | end 189 | 190 | hdr.dime.vox_offset = 352; 191 | 192 | if ~isempty(ext) 193 | hdr.dime.vox_offset = hdr.dime.vox_offset + esize_total; 194 | end 195 | 196 | hdr.hist.magic = 'n+1'; 197 | save_nii_hdr(hdr, fid); 198 | 199 | if ~isempty(ext) 200 | save_nii_ext(ext, fid); 201 | end 202 | else 203 | fid = fopen(sprintf('%s.hdr',fileprefix),'w'); 204 | 205 | if fid < 0, 206 | msg = sprintf('Cannot open file %s.hdr.',fileprefix); 207 | error(msg); 208 | end 209 | 210 | hdr.dime.vox_offset = 0; 211 | hdr.hist.magic = 'ni1'; 212 | save_nii_hdr(hdr, fid); 213 | 214 | if ~isempty(ext) 215 | save_nii_ext(ext, fid); 216 | end 217 | 218 | fclose(fid); 219 | fid = fopen(sprintf('%s.img',fileprefix),'w'); 220 | end 221 | 222 | ScanDim = double(hdr.dime.dim(5)); % t 223 | SliceDim = double(hdr.dime.dim(4)); % z 224 | RowDim = double(hdr.dime.dim(3)); % y 225 | PixelDim = double(hdr.dime.dim(2)); % x 226 | SliceSz = double(hdr.dime.pixdim(4)); 227 | RowSz = double(hdr.dime.pixdim(3)); 228 | PixelSz = double(hdr.dime.pixdim(2)); 229 | 230 | x = 1:PixelDim; 231 | 232 | if filetype == 2 & isempty(ext) 233 | skip_bytes = double(hdr.dime.vox_offset) - 348; 234 | else 235 | skip_bytes = 0; 236 | end 237 | 238 | if double(hdr.dime.datatype) == 128 239 | 240 | % RGB planes are expected to be in the 4th dimension of nii.img 241 | % 242 | if(size(nii.img,4)~=3) 243 | error(['The NII structure does not appear to have 3 RGB color planes in the 4th dimension']); 244 | end 245 | 246 | if old_RGB 247 | nii.img = permute(nii.img, [1 2 4 3 5 6 7 8]); 248 | else 249 | nii.img = permute(nii.img, [4 1 2 3 5 6 7 8]); 250 | end 251 | end 252 | 253 | if double(hdr.dime.datatype) == 511 254 | 255 | % RGB planes are expected to be in the 4th dimension of nii.img 256 | % 257 | if(size(nii.img,4)~=3) 258 | error(['The NII structure does not appear to have 3 RGB color planes in the 4th dimension']); 259 | end 260 | 261 | if old_RGB 262 | nii.img = permute(nii.img, [1 2 4 3 5 6 7 8]); 263 | else 264 | nii.img = permute(nii.img, [4 1 2 3 5 6 7 8]); 265 | end 266 | end 267 | 268 | % For complex float32 or complex float64, voxel values 269 | % include [real, imag] 270 | % 271 | if hdr.dime.datatype == 32 | hdr.dime.datatype == 1792 272 | real_img = real(nii.img(:))'; 273 | nii.img = imag(nii.img(:))'; 274 | nii.img = [real_img; nii.img]; 275 | end 276 | 277 | if skip_bytes 278 | fwrite(fid, zeros(1,skip_bytes), 'uint8'); 279 | end 280 | 281 | fwrite(fid, nii.img, precision); 282 | % fwrite(fid, nii.img, precision, skip_bytes); % error using skip 283 | fclose(fid); 284 | 285 | return; % write_nii 286 | 287 | -------------------------------------------------------------------------------- /NIFTI/save_nii_ext.m: -------------------------------------------------------------------------------- 1 | % Save NIFTI header extension. 2 | % 3 | % Usage: save_nii_ext(ext, fid) 4 | % 5 | % ext - struct with NIFTI header extension fields. 6 | % 7 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 8 | % 9 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 10 | % 11 | function save_nii_ext(ext, fid) 12 | 13 | if ~exist('ext','var') | ~exist('fid','var') 14 | error('Usage: save_nii_ext(ext, fid)'); 15 | end 16 | 17 | if ~isfield(ext,'extension') | ~isfield(ext,'section') | ~isfield(ext,'num_ext') 18 | error('Wrong header extension'); 19 | end 20 | 21 | write_ext(ext, fid); 22 | 23 | return; % save_nii_ext 24 | 25 | 26 | %--------------------------------------------------------------------- 27 | function write_ext(ext, fid) 28 | 29 | fwrite(fid, ext.extension, 'uchar'); 30 | 31 | for i=1:ext.num_ext 32 | fwrite(fid, ext.section(i).esize, 'int32'); 33 | fwrite(fid, ext.section(i).ecode, 'int32'); 34 | fwrite(fid, ext.section(i).edata, 'uchar'); 35 | end 36 | 37 | return; % write_ext 38 | 39 | -------------------------------------------------------------------------------- /NIFTI/save_nii_hdr.m: -------------------------------------------------------------------------------- 1 | % internal function 2 | 3 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 4 | 5 | function save_nii_hdr(hdr, fid) 6 | 7 | if ~exist('hdr','var') | ~exist('fid','var') 8 | error('Usage: save_nii_hdr(hdr, fid)'); 9 | end 10 | 11 | if ~isequal(hdr.hk.sizeof_hdr,348), 12 | error('hdr.hk.sizeof_hdr must be 348.'); 13 | end 14 | 15 | if hdr.hist.qform_code == 0 & hdr.hist.sform_code == 0 16 | hdr.hist.sform_code = 1; 17 | hdr.hist.srow_x(1) = hdr.dime.pixdim(2); 18 | hdr.hist.srow_x(2) = 0; 19 | hdr.hist.srow_x(3) = 0; 20 | hdr.hist.srow_y(1) = 0; 21 | hdr.hist.srow_y(2) = hdr.dime.pixdim(3); 22 | hdr.hist.srow_y(3) = 0; 23 | hdr.hist.srow_z(1) = 0; 24 | hdr.hist.srow_z(2) = 0; 25 | hdr.hist.srow_z(3) = hdr.dime.pixdim(4); 26 | hdr.hist.srow_x(4) = (1-hdr.hist.originator(1))*hdr.dime.pixdim(2); 27 | hdr.hist.srow_y(4) = (1-hdr.hist.originator(2))*hdr.dime.pixdim(3); 28 | hdr.hist.srow_z(4) = (1-hdr.hist.originator(3))*hdr.dime.pixdim(4); 29 | end 30 | 31 | write_header(hdr, fid); 32 | 33 | return; % save_nii_hdr 34 | 35 | 36 | %--------------------------------------------------------------------- 37 | function write_header(hdr, fid) 38 | 39 | % Original header structures 40 | % struct dsr /* dsr = hdr */ 41 | % { 42 | % struct header_key hk; /* 0 + 40 */ 43 | % struct image_dimension dime; /* 40 + 108 */ 44 | % struct data_history hist; /* 148 + 200 */ 45 | % }; /* total= 348 bytes*/ 46 | 47 | header_key(fid, hdr.hk); 48 | image_dimension(fid, hdr.dime); 49 | data_history(fid, hdr.hist); 50 | 51 | % check the file size is 348 bytes 52 | % 53 | fbytes = ftell(fid); 54 | 55 | if ~isequal(fbytes,348), 56 | msg = sprintf('Header size is not 348 bytes.'); 57 | warning(msg); 58 | end 59 | 60 | return; % write_header 61 | 62 | 63 | %--------------------------------------------------------------------- 64 | function header_key(fid, hk) 65 | 66 | fseek(fid,0,'bof'); 67 | 68 | % Original header structures 69 | % struct header_key /* header key */ 70 | % { /* off + size */ 71 | % int sizeof_hdr /* 0 + 4 */ 72 | % char data_type[10]; /* 4 + 10 */ 73 | % char db_name[18]; /* 14 + 18 */ 74 | % int extents; /* 32 + 4 */ 75 | % short int session_error; /* 36 + 2 */ 76 | % char regular; /* 38 + 1 */ 77 | % char dim_info; % char hkey_un0; /* 39 + 1 */ 78 | % }; /* total=40 bytes */ 79 | 80 | fwrite(fid, hk.sizeof_hdr(1), 'int32'); % must be 348. 81 | 82 | % data_type = sprintf('%-10s',hk.data_type); % ensure it is 10 chars from left 83 | % fwrite(fid, data_type(1:10), 'uchar'); 84 | pad = zeros(1, 10-length(hk.data_type)); 85 | hk.data_type = [hk.data_type char(pad)]; 86 | fwrite(fid, hk.data_type(1:10), 'uchar'); 87 | 88 | % db_name = sprintf('%-18s', hk.db_name); % ensure it is 18 chars from left 89 | % fwrite(fid, db_name(1:18), 'uchar'); 90 | pad = zeros(1, 18-length(hk.db_name)); 91 | hk.db_name = [hk.db_name char(pad)]; 92 | fwrite(fid, hk.db_name(1:18), 'uchar'); 93 | 94 | fwrite(fid, hk.extents(1), 'int32'); 95 | fwrite(fid, hk.session_error(1), 'int16'); 96 | fwrite(fid, hk.regular(1), 'uchar'); % might be uint8 97 | 98 | % fwrite(fid, hk.hkey_un0(1), 'uchar'); 99 | % fwrite(fid, hk.hkey_un0(1), 'uint8'); 100 | fwrite(fid, hk.dim_info(1), 'uchar'); 101 | 102 | return; % header_key 103 | 104 | 105 | %--------------------------------------------------------------------- 106 | function image_dimension(fid, dime) 107 | 108 | % Original header structures 109 | % struct image_dimension 110 | % { /* off + size */ 111 | % short int dim[8]; /* 0 + 16 */ 112 | % float intent_p1; % char vox_units[4]; /* 16 + 4 */ 113 | % float intent_p2; % char cal_units[8]; /* 20 + 4 */ 114 | % float intent_p3; % char cal_units[8]; /* 24 + 4 */ 115 | % short int intent_code; % short int unused1; /* 28 + 2 */ 116 | % short int datatype; /* 30 + 2 */ 117 | % short int bitpix; /* 32 + 2 */ 118 | % short int slice_start; % short int dim_un0; /* 34 + 2 */ 119 | % float pixdim[8]; /* 36 + 32 */ 120 | % /* 121 | % pixdim[] specifies the voxel dimensions: 122 | % pixdim[1] - voxel width 123 | % pixdim[2] - voxel height 124 | % pixdim[3] - interslice distance 125 | % pixdim[4] - volume timing, in msec 126 | % ..etc 127 | % */ 128 | % float vox_offset; /* 68 + 4 */ 129 | % float scl_slope; % float roi_scale; /* 72 + 4 */ 130 | % float scl_inter; % float funused1; /* 76 + 4 */ 131 | % short slice_end; % float funused2; /* 80 + 2 */ 132 | % char slice_code; % float funused2; /* 82 + 1 */ 133 | % char xyzt_units; % float funused2; /* 83 + 1 */ 134 | % float cal_max; /* 84 + 4 */ 135 | % float cal_min; /* 88 + 4 */ 136 | % float slice_duration; % int compressed; /* 92 + 4 */ 137 | % float toffset; % int verified; /* 96 + 4 */ 138 | % int glmax; /* 100 + 4 */ 139 | % int glmin; /* 104 + 4 */ 140 | % }; /* total=108 bytes */ 141 | 142 | fwrite(fid, dime.dim(1:8), 'int16'); 143 | fwrite(fid, dime.intent_p1(1), 'float32'); 144 | fwrite(fid, dime.intent_p2(1), 'float32'); 145 | fwrite(fid, dime.intent_p3(1), 'float32'); 146 | fwrite(fid, dime.intent_code(1), 'int16'); 147 | fwrite(fid, dime.datatype(1), 'int16'); 148 | fwrite(fid, dime.bitpix(1), 'int16'); 149 | fwrite(fid, dime.slice_start(1), 'int16'); 150 | fwrite(fid, dime.pixdim(1:8), 'float32'); 151 | fwrite(fid, dime.vox_offset(1), 'float32'); 152 | fwrite(fid, dime.scl_slope(1), 'float32'); 153 | fwrite(fid, dime.scl_inter(1), 'float32'); 154 | fwrite(fid, dime.slice_end(1), 'int16'); 155 | fwrite(fid, dime.slice_code(1), 'uchar'); 156 | fwrite(fid, dime.xyzt_units(1), 'uchar'); 157 | fwrite(fid, dime.cal_max(1), 'float32'); 158 | fwrite(fid, dime.cal_min(1), 'float32'); 159 | fwrite(fid, dime.slice_duration(1), 'float32'); 160 | fwrite(fid, dime.toffset(1), 'float32'); 161 | fwrite(fid, dime.glmax(1), 'int32'); 162 | fwrite(fid, dime.glmin(1), 'int32'); 163 | 164 | return; % image_dimension 165 | 166 | 167 | %--------------------------------------------------------------------- 168 | function data_history(fid, hist) 169 | 170 | % Original header structures 171 | %struct data_history 172 | % { /* off + size */ 173 | % char descrip[80]; /* 0 + 80 */ 174 | % char aux_file[24]; /* 80 + 24 */ 175 | % short int qform_code; /* 104 + 2 */ 176 | % short int sform_code; /* 106 + 2 */ 177 | % float quatern_b; /* 108 + 4 */ 178 | % float quatern_c; /* 112 + 4 */ 179 | % float quatern_d; /* 116 + 4 */ 180 | % float qoffset_x; /* 120 + 4 */ 181 | % float qoffset_y; /* 124 + 4 */ 182 | % float qoffset_z; /* 128 + 4 */ 183 | % float srow_x[4]; /* 132 + 16 */ 184 | % float srow_y[4]; /* 148 + 16 */ 185 | % float srow_z[4]; /* 164 + 16 */ 186 | % char intent_name[16]; /* 180 + 16 */ 187 | % char magic[4]; % int smin; /* 196 + 4 */ 188 | % }; /* total=200 bytes */ 189 | 190 | % descrip = sprintf('%-80s', hist.descrip); % 80 chars from left 191 | % fwrite(fid, descrip(1:80), 'uchar'); 192 | pad = zeros(1, 80-length(hist.descrip)); 193 | hist.descrip = [hist.descrip char(pad)]; 194 | fwrite(fid, hist.descrip(1:80), 'uchar'); 195 | 196 | % aux_file = sprintf('%-24s', hist.aux_file); % 24 chars from left 197 | % fwrite(fid, aux_file(1:24), 'uchar'); 198 | pad = zeros(1, 24-length(hist.aux_file)); 199 | hist.aux_file = [hist.aux_file char(pad)]; 200 | fwrite(fid, hist.aux_file(1:24), 'uchar'); 201 | 202 | fwrite(fid, hist.qform_code, 'int16'); 203 | fwrite(fid, hist.sform_code, 'int16'); 204 | fwrite(fid, hist.quatern_b, 'float32'); 205 | fwrite(fid, hist.quatern_c, 'float32'); 206 | fwrite(fid, hist.quatern_d, 'float32'); 207 | fwrite(fid, hist.qoffset_x, 'float32'); 208 | fwrite(fid, hist.qoffset_y, 'float32'); 209 | fwrite(fid, hist.qoffset_z, 'float32'); 210 | fwrite(fid, hist.srow_x(1:4), 'float32'); 211 | fwrite(fid, hist.srow_y(1:4), 'float32'); 212 | fwrite(fid, hist.srow_z(1:4), 'float32'); 213 | 214 | % intent_name = sprintf('%-16s', hist.intent_name); % 16 chars from left 215 | % fwrite(fid, intent_name(1:16), 'uchar'); 216 | pad = zeros(1, 16-length(hist.intent_name)); 217 | hist.intent_name = [hist.intent_name char(pad)]; 218 | fwrite(fid, hist.intent_name(1:16), 'uchar'); 219 | 220 | % magic = sprintf('%-4s', hist.magic); % 4 chars from left 221 | % fwrite(fid, magic(1:4), 'uchar'); 222 | pad = zeros(1, 4-length(hist.magic)); 223 | hist.magic = [hist.magic char(pad)]; 224 | fwrite(fid, hist.magic(1:4), 'uchar'); 225 | 226 | return; % data_history 227 | 228 | -------------------------------------------------------------------------------- /NIFTI/save_untouch0_nii_hdr.m: -------------------------------------------------------------------------------- 1 | % internal function 2 | 3 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 4 | 5 | function save_nii_hdr(hdr, fid) 6 | 7 | if ~isequal(hdr.hk.sizeof_hdr,348), 8 | error('hdr.hk.sizeof_hdr must be 348.'); 9 | end 10 | 11 | write_header(hdr, fid); 12 | 13 | return; % save_nii_hdr 14 | 15 | 16 | %--------------------------------------------------------------------- 17 | function write_header(hdr, fid) 18 | 19 | % Original header structures 20 | % struct dsr /* dsr = hdr */ 21 | % { 22 | % struct header_key hk; /* 0 + 40 */ 23 | % struct image_dimension dime; /* 40 + 108 */ 24 | % struct data_history hist; /* 148 + 200 */ 25 | % }; /* total= 348 bytes*/ 26 | 27 | header_key(fid, hdr.hk); 28 | image_dimension(fid, hdr.dime); 29 | data_history(fid, hdr.hist); 30 | 31 | % check the file size is 348 bytes 32 | % 33 | fbytes = ftell(fid); 34 | 35 | if ~isequal(fbytes,348), 36 | msg = sprintf('Header size is not 348 bytes.'); 37 | warning(msg); 38 | end 39 | 40 | return; % write_header 41 | 42 | 43 | %--------------------------------------------------------------------- 44 | function header_key(fid, hk) 45 | 46 | fseek(fid,0,'bof'); 47 | 48 | % Original header structures 49 | % struct header_key /* header key */ 50 | % { /* off + size */ 51 | % int sizeof_hdr /* 0 + 4 */ 52 | % char data_type[10]; /* 4 + 10 */ 53 | % char db_name[18]; /* 14 + 18 */ 54 | % int extents; /* 32 + 4 */ 55 | % short int session_error; /* 36 + 2 */ 56 | % char regular; /* 38 + 1 */ 57 | % char hkey_un0; /* 39 + 1 */ 58 | % }; /* total=40 bytes */ 59 | 60 | fwrite(fid, hk.sizeof_hdr(1), 'int32'); % must be 348. 61 | 62 | % data_type = sprintf('%-10s',hk.data_type); % ensure it is 10 chars from left 63 | % fwrite(fid, data_type(1:10), 'uchar'); 64 | pad = zeros(1, 10-length(hk.data_type)); 65 | hk.data_type = [hk.data_type char(pad)]; 66 | fwrite(fid, hk.data_type(1:10), 'uchar'); 67 | 68 | % db_name = sprintf('%-18s', hk.db_name); % ensure it is 18 chars from left 69 | % fwrite(fid, db_name(1:18), 'uchar'); 70 | pad = zeros(1, 18-length(hk.db_name)); 71 | hk.db_name = [hk.db_name char(pad)]; 72 | fwrite(fid, hk.db_name(1:18), 'uchar'); 73 | 74 | fwrite(fid, hk.extents(1), 'int32'); 75 | fwrite(fid, hk.session_error(1), 'int16'); 76 | fwrite(fid, hk.regular(1), 'uchar'); 77 | 78 | fwrite(fid, hk.hkey_un0(1), 'uchar'); 79 | 80 | return; % header_key 81 | 82 | 83 | %--------------------------------------------------------------------- 84 | function image_dimension(fid, dime) 85 | 86 | %struct image_dimension 87 | % { /* off + size */ 88 | % short int dim[8]; /* 0 + 16 */ 89 | % char vox_units[4]; /* 16 + 4 */ 90 | % char cal_units[8]; /* 20 + 8 */ 91 | % short int unused1; /* 28 + 2 */ 92 | % short int datatype; /* 30 + 2 */ 93 | % short int bitpix; /* 32 + 2 */ 94 | % short int dim_un0; /* 34 + 2 */ 95 | % float pixdim[8]; /* 36 + 32 */ 96 | % /* 97 | % pixdim[] specifies the voxel dimensions: 98 | % pixdim[1] - voxel width 99 | % pixdim[2] - voxel height 100 | % pixdim[3] - interslice distance 101 | % ..etc 102 | % */ 103 | % float vox_offset; /* 68 + 4 */ 104 | % float roi_scale; /* 72 + 4 */ 105 | % float funused1; /* 76 + 4 */ 106 | % float funused2; /* 80 + 4 */ 107 | % float cal_max; /* 84 + 4 */ 108 | % float cal_min; /* 88 + 4 */ 109 | % int compressed; /* 92 + 4 */ 110 | % int verified; /* 96 + 4 */ 111 | % int glmax; /* 100 + 4 */ 112 | % int glmin; /* 104 + 4 */ 113 | % }; /* total=108 bytes */ 114 | 115 | fwrite(fid, dime.dim(1:8), 'int16'); 116 | 117 | pad = zeros(1, 4-length(dime.vox_units)); 118 | dime.vox_units = [dime.vox_units char(pad)]; 119 | fwrite(fid, dime.vox_units(1:4), 'uchar'); 120 | 121 | pad = zeros(1, 8-length(dime.cal_units)); 122 | dime.cal_units = [dime.cal_units char(pad)]; 123 | fwrite(fid, dime.cal_units(1:8), 'uchar'); 124 | 125 | fwrite(fid, dime.unused1(1), 'int16'); 126 | fwrite(fid, dime.datatype(1), 'int16'); 127 | fwrite(fid, dime.bitpix(1), 'int16'); 128 | fwrite(fid, dime.dim_un0(1), 'int16'); 129 | fwrite(fid, dime.pixdim(1:8), 'float32'); 130 | fwrite(fid, dime.vox_offset(1), 'float32'); 131 | fwrite(fid, dime.roi_scale(1), 'float32'); 132 | fwrite(fid, dime.funused1(1), 'float32'); 133 | fwrite(fid, dime.funused2(1), 'float32'); 134 | fwrite(fid, dime.cal_max(1), 'float32'); 135 | fwrite(fid, dime.cal_min(1), 'float32'); 136 | fwrite(fid, dime.compressed(1), 'int32'); 137 | fwrite(fid, dime.verified(1), 'int32'); 138 | fwrite(fid, dime.glmax(1), 'int32'); 139 | fwrite(fid, dime.glmin(1), 'int32'); 140 | 141 | return; % image_dimension 142 | 143 | 144 | %--------------------------------------------------------------------- 145 | function data_history(fid, hist) 146 | 147 | % Original header structures - ANALYZE 7.5 148 | %struct data_history 149 | % { /* off + size */ 150 | % char descrip[80]; /* 0 + 80 */ 151 | % char aux_file[24]; /* 80 + 24 */ 152 | % char orient; /* 104 + 1 */ 153 | % char originator[10]; /* 105 + 10 */ 154 | % char generated[10]; /* 115 + 10 */ 155 | % char scannum[10]; /* 125 + 10 */ 156 | % char patient_id[10]; /* 135 + 10 */ 157 | % char exp_date[10]; /* 145 + 10 */ 158 | % char exp_time[10]; /* 155 + 10 */ 159 | % char hist_un0[3]; /* 165 + 3 */ 160 | % int views /* 168 + 4 */ 161 | % int vols_added; /* 172 + 4 */ 162 | % int start_field; /* 176 + 4 */ 163 | % int field_skip; /* 180 + 4 */ 164 | % int omax; /* 184 + 4 */ 165 | % int omin; /* 188 + 4 */ 166 | % int smax; /* 192 + 4 */ 167 | % int smin; /* 196 + 4 */ 168 | % }; /* total=200 bytes */ 169 | 170 | % descrip = sprintf('%-80s', hist.descrip); % 80 chars from left 171 | % fwrite(fid, descrip(1:80), 'uchar'); 172 | pad = zeros(1, 80-length(hist.descrip)); 173 | hist.descrip = [hist.descrip char(pad)]; 174 | fwrite(fid, hist.descrip(1:80), 'uchar'); 175 | 176 | % aux_file = sprintf('%-24s', hist.aux_file); % 24 chars from left 177 | % fwrite(fid, aux_file(1:24), 'uchar'); 178 | pad = zeros(1, 24-length(hist.aux_file)); 179 | hist.aux_file = [hist.aux_file char(pad)]; 180 | fwrite(fid, hist.aux_file(1:24), 'uchar'); 181 | 182 | fwrite(fid, hist.orient(1), 'uchar'); 183 | fwrite(fid, hist.originator(1:5), 'int16'); 184 | 185 | pad = zeros(1, 10-length(hist.generated)); 186 | hist.generated = [hist.generated char(pad)]; 187 | fwrite(fid, hist.generated(1:10), 'uchar'); 188 | 189 | pad = zeros(1, 10-length(hist.scannum)); 190 | hist.scannum = [hist.scannum char(pad)]; 191 | fwrite(fid, hist.scannum(1:10), 'uchar'); 192 | 193 | pad = zeros(1, 10-length(hist.patient_id)); 194 | hist.patient_id = [hist.patient_id char(pad)]; 195 | fwrite(fid, hist.patient_id(1:10), 'uchar'); 196 | 197 | pad = zeros(1, 10-length(hist.exp_date)); 198 | hist.exp_date = [hist.exp_date char(pad)]; 199 | fwrite(fid, hist.exp_date(1:10), 'uchar'); 200 | 201 | pad = zeros(1, 10-length(hist.exp_time)); 202 | hist.exp_time = [hist.exp_time char(pad)]; 203 | fwrite(fid, hist.exp_time(1:10), 'uchar'); 204 | 205 | pad = zeros(1, 3-length(hist.hist_un0)); 206 | hist.hist_un0 = [hist.hist_un0 char(pad)]; 207 | fwrite(fid, hist.hist_un0(1:3), 'uchar'); 208 | 209 | fwrite(fid, hist.views(1), 'int32'); 210 | fwrite(fid, hist.vols_added(1), 'int32'); 211 | fwrite(fid, hist.start_field(1),'int32'); 212 | fwrite(fid, hist.field_skip(1), 'int32'); 213 | fwrite(fid, hist.omax(1), 'int32'); 214 | fwrite(fid, hist.omin(1), 'int32'); 215 | fwrite(fid, hist.smax(1), 'int32'); 216 | fwrite(fid, hist.smin(1), 'int32'); 217 | 218 | return; % data_history 219 | 220 | -------------------------------------------------------------------------------- /NIFTI/save_untouch_nii.m: -------------------------------------------------------------------------------- 1 | % Save NIFTI or ANALYZE dataset that is loaded by "load_untouch_nii.m". 2 | % The output image format and file extension will be the same as the 3 | % input one (NIFTI.nii, NIFTI.img or ANALYZE.img). Therefore, any file 4 | % extension that you specified will be ignored. 5 | % 6 | % Usage: save_untouch_nii(nii, filename) 7 | % 8 | % nii - nii structure that is loaded by "load_untouch_nii.m" 9 | % 10 | % filename - NIFTI or ANALYZE file name. 11 | % 12 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 13 | % 14 | function save_untouch_nii(nii, filename) 15 | 16 | if ~exist('nii','var') | isempty(nii) | ~isfield(nii,'hdr') | ... 17 | ~isfield(nii,'img') | ~exist('filename','var') | isempty(filename) 18 | 19 | error('Usage: save_untouch_nii(nii, filename)'); 20 | end 21 | 22 | if ~isfield(nii,'untouch') | nii.untouch == 0 23 | error('Usage: please use ''save_nii.m'' for the modified structure.'); 24 | end 25 | 26 | if isfield(nii.hdr.hist,'magic') & strcmp(nii.hdr.hist.magic(1:3),'ni1') 27 | filetype = 1; 28 | elseif isfield(nii.hdr.hist,'magic') & strcmp(nii.hdr.hist.magic(1:3),'n+1') 29 | filetype = 2; 30 | else 31 | filetype = 0; 32 | end 33 | 34 | v = version; 35 | 36 | % Check file extension. If .gz, unpack it into temp folder 37 | % 38 | if length(filename) > 2 & strcmp(filename(end-2:end), '.gz') 39 | 40 | if ~strcmp(filename(end-6:end), '.img.gz') & ... 41 | ~strcmp(filename(end-6:end), '.hdr.gz') & ... 42 | ~strcmp(filename(end-6:end), '.nii.gz') 43 | 44 | error('Please check filename.'); 45 | end 46 | 47 | if str2num(v(1:3)) < 7.1 | ~usejava('jvm') 48 | error('Please use MATLAB 7.1 (with java) and above, or run gunzip outside MATLAB.'); 49 | else 50 | gzFile = 1; 51 | filename = filename(1:end-3); 52 | end 53 | end 54 | 55 | [p,f] = fileparts(filename); 56 | fileprefix = fullfile(p, f); 57 | 58 | write_nii(nii, filetype, fileprefix); 59 | 60 | % gzip output file if requested 61 | % 62 | if exist('gzFile', 'var') 63 | if filetype == 1 64 | gzip([fileprefix, '.img']); 65 | delete([fileprefix, '.img']); 66 | gzip([fileprefix, '.hdr']); 67 | delete([fileprefix, '.hdr']); 68 | elseif filetype == 2 69 | gzip([fileprefix, '.nii']); 70 | delete([fileprefix, '.nii']); 71 | end; 72 | end; 73 | 74 | % % So earlier versions of SPM can also open it with correct originator 75 | % % 76 | % if filetype == 0 77 | % M=[[diag(nii.hdr.dime.pixdim(2:4)) -[nii.hdr.hist.originator(1:3).*nii.hdr.dime.pixdim(2:4)]'];[0 0 0 1]]; 78 | % save(fileprefix, 'M'); 79 | % elseif filetype == 1 80 | % M=[]; 81 | % save(fileprefix, 'M'); 82 | %end 83 | 84 | return % save_untouch_nii 85 | 86 | 87 | %----------------------------------------------------------------------------------- 88 | function write_nii(nii, filetype, fileprefix) 89 | 90 | hdr = nii.hdr; 91 | 92 | if isfield(nii,'ext') & ~isempty(nii.ext) 93 | ext = nii.ext; 94 | [ext, esize_total] = verify_nii_ext(ext); 95 | else 96 | ext = []; 97 | end 98 | 99 | switch double(hdr.dime.datatype), 100 | case 1, 101 | hdr.dime.bitpix = int16(1 ); precision = 'ubit1'; 102 | case 2, 103 | hdr.dime.bitpix = int16(8 ); precision = 'uint8'; 104 | case 4, 105 | hdr.dime.bitpix = int16(16); precision = 'int16'; 106 | case 8, 107 | hdr.dime.bitpix = int16(32); precision = 'int32'; 108 | case 16, 109 | hdr.dime.bitpix = int16(32); precision = 'float32'; 110 | case 32, 111 | hdr.dime.bitpix = int16(64); precision = 'float32'; 112 | case 64, 113 | hdr.dime.bitpix = int16(64); precision = 'float64'; 114 | case 128, 115 | hdr.dime.bitpix = int16(24); precision = 'uint8'; 116 | case 256 117 | hdr.dime.bitpix = int16(8 ); precision = 'int8'; 118 | case 512 119 | hdr.dime.bitpix = int16(16); precision = 'uint16'; 120 | case 768 121 | hdr.dime.bitpix = int16(32); precision = 'uint32'; 122 | case 1024 123 | hdr.dime.bitpix = int16(64); precision = 'int64'; 124 | case 1280 125 | hdr.dime.bitpix = int16(64); precision = 'uint64'; 126 | case 1792, 127 | hdr.dime.bitpix = int16(128); precision = 'float64'; 128 | otherwise 129 | error('This datatype is not supported'); 130 | end 131 | 132 | % hdr.dime.glmax = round(double(max(nii.img(:)))); 133 | % hdr.dime.glmin = round(double(min(nii.img(:)))); 134 | 135 | if filetype == 2 136 | fid = fopen(sprintf('%s.nii',fileprefix),'w'); 137 | 138 | if fid < 0, 139 | msg = sprintf('Cannot open file %s.nii.',fileprefix); 140 | error(msg); 141 | end 142 | 143 | hdr.dime.vox_offset = 352; 144 | 145 | if ~isempty(ext) 146 | hdr.dime.vox_offset = hdr.dime.vox_offset + esize_total; 147 | end 148 | 149 | hdr.hist.magic = 'n+1'; 150 | save_untouch_nii_hdr(hdr, fid); 151 | 152 | if ~isempty(ext) 153 | save_nii_ext(ext, fid); 154 | end 155 | elseif filetype == 1 156 | fid = fopen(sprintf('%s.hdr',fileprefix),'w'); 157 | 158 | if fid < 0, 159 | msg = sprintf('Cannot open file %s.hdr.',fileprefix); 160 | error(msg); 161 | end 162 | 163 | hdr.dime.vox_offset = 0; 164 | hdr.hist.magic = 'ni1'; 165 | save_untouch_nii_hdr(hdr, fid); 166 | 167 | if ~isempty(ext) 168 | save_nii_ext(ext, fid); 169 | end 170 | 171 | fclose(fid); 172 | fid = fopen(sprintf('%s.img',fileprefix),'w'); 173 | else 174 | fid = fopen(sprintf('%s.hdr',fileprefix),'w'); 175 | 176 | if fid < 0, 177 | msg = sprintf('Cannot open file %s.hdr.',fileprefix); 178 | error(msg); 179 | end 180 | 181 | save_untouch0_nii_hdr(hdr, fid); 182 | 183 | fclose(fid); 184 | fid = fopen(sprintf('%s.img',fileprefix),'w'); 185 | end 186 | 187 | ScanDim = double(hdr.dime.dim(5)); % t 188 | SliceDim = double(hdr.dime.dim(4)); % z 189 | RowDim = double(hdr.dime.dim(3)); % y 190 | PixelDim = double(hdr.dime.dim(2)); % x 191 | SliceSz = double(hdr.dime.pixdim(4)); 192 | RowSz = double(hdr.dime.pixdim(3)); 193 | PixelSz = double(hdr.dime.pixdim(2)); 194 | 195 | x = 1:PixelDim; 196 | 197 | if filetype == 2 & isempty(ext) 198 | skip_bytes = double(hdr.dime.vox_offset) - 348; 199 | else 200 | skip_bytes = 0; 201 | end 202 | 203 | if double(hdr.dime.datatype) == 128 204 | 205 | % RGB planes are expected to be in the 4th dimension of nii.img 206 | % 207 | if(size(nii.img,4)~=3) 208 | error(['The NII structure does not appear to have 3 RGB color planes in the 4th dimension']); 209 | end 210 | 211 | nii.img = permute(nii.img, [4 1 2 3 5 6 7 8]); 212 | end 213 | 214 | % For complex float32 or complex float64, voxel values 215 | % include [real, imag] 216 | % 217 | if hdr.dime.datatype == 32 | hdr.dime.datatype == 1792 218 | real_img = real(nii.img(:))'; 219 | nii.img = imag(nii.img(:))'; 220 | nii.img = [real_img; nii.img]; 221 | end 222 | 223 | if skip_bytes 224 | fwrite(fid, zeros(1,skip_bytes), 'uint8'); 225 | end 226 | 227 | fwrite(fid, nii.img, precision); 228 | % fwrite(fid, nii.img, precision, skip_bytes); % error using skip 229 | fclose(fid); 230 | 231 | return; % write_nii 232 | 233 | -------------------------------------------------------------------------------- /NIFTI/save_untouch_nii_hdr.m: -------------------------------------------------------------------------------- 1 | % internal function 2 | 3 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 4 | 5 | function save_nii_hdr(hdr, fid) 6 | 7 | if ~isequal(hdr.hk.sizeof_hdr,348), 8 | error('hdr.hk.sizeof_hdr must be 348.'); 9 | end 10 | 11 | write_header(hdr, fid); 12 | 13 | return; % save_nii_hdr 14 | 15 | 16 | %--------------------------------------------------------------------- 17 | function write_header(hdr, fid) 18 | 19 | % Original header structures 20 | % struct dsr /* dsr = hdr */ 21 | % { 22 | % struct header_key hk; /* 0 + 40 */ 23 | % struct image_dimension dime; /* 40 + 108 */ 24 | % struct data_history hist; /* 148 + 200 */ 25 | % }; /* total= 348 bytes*/ 26 | 27 | header_key(fid, hdr.hk); 28 | image_dimension(fid, hdr.dime); 29 | data_history(fid, hdr.hist); 30 | 31 | % check the file size is 348 bytes 32 | % 33 | fbytes = ftell(fid); 34 | 35 | if ~isequal(fbytes,348), 36 | msg = sprintf('Header size is not 348 bytes.'); 37 | warning(msg); 38 | end 39 | 40 | return; % write_header 41 | 42 | 43 | %--------------------------------------------------------------------- 44 | function header_key(fid, hk) 45 | 46 | fseek(fid,0,'bof'); 47 | 48 | % Original header structures 49 | % struct header_key /* header key */ 50 | % { /* off + size */ 51 | % int sizeof_hdr /* 0 + 4 */ 52 | % char data_type[10]; /* 4 + 10 */ 53 | % char db_name[18]; /* 14 + 18 */ 54 | % int extents; /* 32 + 4 */ 55 | % short int session_error; /* 36 + 2 */ 56 | % char regular; /* 38 + 1 */ 57 | % char dim_info; % char hkey_un0; /* 39 + 1 */ 58 | % }; /* total=40 bytes */ 59 | 60 | fwrite(fid, hk.sizeof_hdr(1), 'int32'); % must be 348. 61 | 62 | % data_type = sprintf('%-10s',hk.data_type); % ensure it is 10 chars from left 63 | % fwrite(fid, data_type(1:10), 'uchar'); 64 | pad = zeros(1, 10-length(hk.data_type)); 65 | hk.data_type = [hk.data_type char(pad)]; 66 | fwrite(fid, hk.data_type(1:10), 'uchar'); 67 | 68 | % db_name = sprintf('%-18s', hk.db_name); % ensure it is 18 chars from left 69 | % fwrite(fid, db_name(1:18), 'uchar'); 70 | pad = zeros(1, 18-length(hk.db_name)); 71 | hk.db_name = [hk.db_name char(pad)]; 72 | fwrite(fid, hk.db_name(1:18), 'uchar'); 73 | 74 | fwrite(fid, hk.extents(1), 'int32'); 75 | fwrite(fid, hk.session_error(1), 'int16'); 76 | fwrite(fid, hk.regular(1), 'uchar'); % might be uint8 77 | 78 | % fwrite(fid, hk.hkey_un0(1), 'uchar'); 79 | % fwrite(fid, hk.hkey_un0(1), 'uint8'); 80 | fwrite(fid, hk.dim_info(1), 'uchar'); 81 | 82 | return; % header_key 83 | 84 | 85 | %--------------------------------------------------------------------- 86 | function image_dimension(fid, dime) 87 | 88 | % Original header structures 89 | % struct image_dimension 90 | % { /* off + size */ 91 | % short int dim[8]; /* 0 + 16 */ 92 | % float intent_p1; % char vox_units[4]; /* 16 + 4 */ 93 | % float intent_p2; % char cal_units[8]; /* 20 + 4 */ 94 | % float intent_p3; % char cal_units[8]; /* 24 + 4 */ 95 | % short int intent_code; % short int unused1; /* 28 + 2 */ 96 | % short int datatype; /* 30 + 2 */ 97 | % short int bitpix; /* 32 + 2 */ 98 | % short int slice_start; % short int dim_un0; /* 34 + 2 */ 99 | % float pixdim[8]; /* 36 + 32 */ 100 | % /* 101 | % pixdim[] specifies the voxel dimensions: 102 | % pixdim[1] - voxel width 103 | % pixdim[2] - voxel height 104 | % pixdim[3] - interslice distance 105 | % pixdim[4] - volume timing, in msec 106 | % ..etc 107 | % */ 108 | % float vox_offset; /* 68 + 4 */ 109 | % float scl_slope; % float roi_scale; /* 72 + 4 */ 110 | % float scl_inter; % float funused1; /* 76 + 4 */ 111 | % short slice_end; % float funused2; /* 80 + 2 */ 112 | % char slice_code; % float funused2; /* 82 + 1 */ 113 | % char xyzt_units; % float funused2; /* 83 + 1 */ 114 | % float cal_max; /* 84 + 4 */ 115 | % float cal_min; /* 88 + 4 */ 116 | % float slice_duration; % int compressed; /* 92 + 4 */ 117 | % float toffset; % int verified; /* 96 + 4 */ 118 | % int glmax; /* 100 + 4 */ 119 | % int glmin; /* 104 + 4 */ 120 | % }; /* total=108 bytes */ 121 | 122 | fwrite(fid, dime.dim(1:8), 'int16'); 123 | fwrite(fid, dime.intent_p1(1), 'float32'); 124 | fwrite(fid, dime.intent_p2(1), 'float32'); 125 | fwrite(fid, dime.intent_p3(1), 'float32'); 126 | fwrite(fid, dime.intent_code(1), 'int16'); 127 | fwrite(fid, dime.datatype(1), 'int16'); 128 | fwrite(fid, dime.bitpix(1), 'int16'); 129 | fwrite(fid, dime.slice_start(1), 'int16'); 130 | fwrite(fid, dime.pixdim(1:8), 'float32'); 131 | fwrite(fid, dime.vox_offset(1), 'float32'); 132 | fwrite(fid, dime.scl_slope(1), 'float32'); 133 | fwrite(fid, dime.scl_inter(1), 'float32'); 134 | fwrite(fid, dime.slice_end(1), 'int16'); 135 | fwrite(fid, dime.slice_code(1), 'uchar'); 136 | fwrite(fid, dime.xyzt_units(1), 'uchar'); 137 | fwrite(fid, dime.cal_max(1), 'float32'); 138 | fwrite(fid, dime.cal_min(1), 'float32'); 139 | fwrite(fid, dime.slice_duration(1), 'float32'); 140 | fwrite(fid, dime.toffset(1), 'float32'); 141 | fwrite(fid, dime.glmax(1), 'int32'); 142 | fwrite(fid, dime.glmin(1), 'int32'); 143 | 144 | return; % image_dimension 145 | 146 | 147 | %--------------------------------------------------------------------- 148 | function data_history(fid, hist) 149 | 150 | % Original header structures 151 | %struct data_history 152 | % { /* off + size */ 153 | % char descrip[80]; /* 0 + 80 */ 154 | % char aux_file[24]; /* 80 + 24 */ 155 | % short int qform_code; /* 104 + 2 */ 156 | % short int sform_code; /* 106 + 2 */ 157 | % float quatern_b; /* 108 + 4 */ 158 | % float quatern_c; /* 112 + 4 */ 159 | % float quatern_d; /* 116 + 4 */ 160 | % float qoffset_x; /* 120 + 4 */ 161 | % float qoffset_y; /* 124 + 4 */ 162 | % float qoffset_z; /* 128 + 4 */ 163 | % float srow_x[4]; /* 132 + 16 */ 164 | % float srow_y[4]; /* 148 + 16 */ 165 | % float srow_z[4]; /* 164 + 16 */ 166 | % char intent_name[16]; /* 180 + 16 */ 167 | % char magic[4]; % int smin; /* 196 + 4 */ 168 | % }; /* total=200 bytes */ 169 | 170 | % descrip = sprintf('%-80s', hist.descrip); % 80 chars from left 171 | % fwrite(fid, descrip(1:80), 'uchar'); 172 | pad = zeros(1, 80-length(hist.descrip)); 173 | hist.descrip = [hist.descrip char(pad)]; 174 | fwrite(fid, hist.descrip(1:80), 'uchar'); 175 | 176 | % aux_file = sprintf('%-24s', hist.aux_file); % 24 chars from left 177 | % fwrite(fid, aux_file(1:24), 'uchar'); 178 | pad = zeros(1, 24-length(hist.aux_file)); 179 | hist.aux_file = [hist.aux_file char(pad)]; 180 | fwrite(fid, hist.aux_file(1:24), 'uchar'); 181 | 182 | fwrite(fid, hist.qform_code, 'int16'); 183 | fwrite(fid, hist.sform_code, 'int16'); 184 | fwrite(fid, hist.quatern_b, 'float32'); 185 | fwrite(fid, hist.quatern_c, 'float32'); 186 | fwrite(fid, hist.quatern_d, 'float32'); 187 | fwrite(fid, hist.qoffset_x, 'float32'); 188 | fwrite(fid, hist.qoffset_y, 'float32'); 189 | fwrite(fid, hist.qoffset_z, 'float32'); 190 | fwrite(fid, hist.srow_x(1:4), 'float32'); 191 | fwrite(fid, hist.srow_y(1:4), 'float32'); 192 | fwrite(fid, hist.srow_z(1:4), 'float32'); 193 | 194 | % intent_name = sprintf('%-16s', hist.intent_name); % 16 chars from left 195 | % fwrite(fid, intent_name(1:16), 'uchar'); 196 | pad = zeros(1, 16-length(hist.intent_name)); 197 | hist.intent_name = [hist.intent_name char(pad)]; 198 | fwrite(fid, hist.intent_name(1:16), 'uchar'); 199 | 200 | % magic = sprintf('%-4s', hist.magic); % 4 chars from left 201 | % fwrite(fid, magic(1:4), 'uchar'); 202 | pad = zeros(1, 4-length(hist.magic)); 203 | hist.magic = [hist.magic char(pad)]; 204 | fwrite(fid, hist.magic(1:4), 'uchar'); 205 | 206 | return; % data_history 207 | 208 | -------------------------------------------------------------------------------- /NIFTI/unxform_nii.m: -------------------------------------------------------------------------------- 1 | % Undo the flipping and rotations performed by xform_nii; spit back only 2 | % the raw img data block. Initial cut will only deal with 3D volumes 3 | % strongly assume we have called xform_nii to write down the steps used 4 | % in xform_nii. 5 | % 6 | % Usage: a = load_nii('original_name'); 7 | % manipulate a.img to make array b; 8 | % 9 | % if you use unxform_nii to un-tranform the image (img) data 10 | % block, then nii.original.hdr is the corresponding header. 11 | % 12 | % nii.original.img = unxform_nii(a, b); 13 | % save_nii(nii.original,'newname'); 14 | % 15 | % Where, 'newname' is created with data in the same space as the 16 | % original_name data 17 | % 18 | % - Jeff Gunter, 26-JUN-06 19 | % 20 | function outblock = unxform_nii(nii, inblock) 21 | 22 | if isempty(nii.hdr.hist.rot_orient) 23 | outblock=inblock; 24 | else 25 | [dummy unrotate_orient] = sort(nii.hdr.hist.rot_orient); 26 | outblock = permute(inblock, unrotate_orient); 27 | end 28 | 29 | if ~isempty(nii.hdr.hist.flip_orient) 30 | flip_orient = nii.hdr.hist.flip_orient(unrotate_orient); 31 | 32 | for i = 1:3 33 | if flip_orient(i) 34 | outblock = flipdim(outblock, i); 35 | end 36 | end 37 | end; 38 | 39 | return; 40 | 41 | -------------------------------------------------------------------------------- /NIFTI/verify_nii_ext.m: -------------------------------------------------------------------------------- 1 | % Verify NIFTI header extension to make sure that each extension section 2 | % must be an integer multiple of 16 byte long that includes the first 8 3 | % bytes of esize and ecode. If the length of extension section is not the 4 | % above mentioned case, edata should be padded with all 0. 5 | % 6 | % Usage: [ext, esize_total] = verify_nii_ext(ext) 7 | % 8 | % ext - Structure of NIFTI header extension, which includes num_ext, 9 | % and all the extended header sections in the header extension. 10 | % Each extended header section will have its esize, ecode, and 11 | % edata, where edata can be plain text, xml, or any raw data 12 | % that was saved in the extended header section. 13 | % 14 | % esize_total - Sum of all esize variable in all header sections. 15 | % 16 | % NIFTI data format can be found on: http://nifti.nimh.nih.gov 17 | % 18 | % - Jimmy Shen (jimmy@rotman-baycrest.on.ca) 19 | % 20 | function [ext, esize_total] = verify_nii_ext(ext) 21 | 22 | if ~isfield(ext, 'section') 23 | error('Incorrect NIFTI header extension structure.'); 24 | elseif ~isfield(ext, 'num_ext') 25 | ext.num_ext = length(ext.section); 26 | elseif ~isfield(ext, 'extension') 27 | ext.extension = [1 0 0 0]; 28 | end 29 | 30 | esize_total = 0; 31 | 32 | for i=1:ext.num_ext 33 | if ~isfield(ext.section(i), 'ecode') | ~isfield(ext.section(i), 'edata') 34 | error('Incorrect NIFTI header extension structure.'); 35 | end 36 | 37 | ext.section(i).esize = ceil((length(ext.section(i).edata)+8)/16)*16; 38 | ext.section(i).edata = ... 39 | [ext.section(i).edata ... 40 | zeros(1,ext.section(i).esize-length(ext.section(i).edata)-8)]; 41 | esize_total = esize_total + ext.section(i).esize; 42 | end 43 | 44 | return % verify_nii_ext 45 | 46 | -------------------------------------------------------------------------------- /README.md: -------------------------------------------------------------------------------- 1 | # DOMINO: Domain-aware Model Calibration in Medical Image Segmentation 2 | We create and provide open-source code of a model called a **domain-aware model calibration method**, nicknamed **DOMINO** that leverages the semantic confusability and hierarchical similarity between class labels. Our experiments demonstrate that our DOMINO-calibrated deep neural networks outperform non-calibrated models and state-of-the-art morphometric methods in head image segmentation. Our results show that our method can consistently achieve better calibration, higher accuracy, and faster inference times than these methods, especially on rarer classes. This performance is attributed to our domain-aware regularization to inform semantic model calibration. These findings show the importance of semantic ties between class labels in building confidence in deep learning models. The framework has the potential to improve the trustworthiness and reliability of generic medical image segmentation models. 3 | 4 | ## Paper 5 | This repository provides the official implemantation of training DOMINO as well as the usage the model DOMINO in the following paper: 6 | 7 | **DOMINO: Domain-aware Model Calibration in Medical Image Segmentation** 8 | 9 | Skylar E. Stolte1, Kyle Volle2, Aprinda Indahlastari3,4, Alejandro Albizu3,5, Adam J. Woods3,4,5, Kevin Brink6, Matthew Hale2, and Ruogu Fang1,3,7* 10 | 11 | 1 J. Crayton Pruitt Family Department of Biomedical Engineering, HerbertWertheim College of Engineering, University of Florida (UF), USA
12 | 2 Department of Mechanical and Aerospace Engineering, Herbert Wertheim Collegeof Engineering, UF, USA
13 | 3 Center for Cognitive Aging and Memory, McKnight Brain Institute, UF, USA
14 | 4 Department of Clinical and Health Psychology, College of Public Health andHealth Professions, UF, USA
15 | 5 Department of Neuroscience, College of Medicine, UF, USA
16 | 6 United States Air Force Research Laboratory, Eglin Air Force Base, Florida, USA
17 | 7 Department of Electrical and Computer Engineering, Herbert Wertheim College ofEngineering, UF, USA
18 | 19 | International Conference on Medical Image Computing and Computer Assisted Intervention (MICCAI) 2022
20 | [paper](https://arxiv.org/abs/2209.06077) | [code](https://github.com/lab-smile/DOMINO) | [slides](https://github.com/lab-smile/DOMINO/blob/5378ad4ad099efe2700ad75c23ecbc5ce585d266/doc/DOMINO_MICCAI22_PPT.pdf) | [poster](https://github.com/lab-smile/DOMINO/blob/5378ad4ad099efe2700ad75c23ecbc5ce585d266/doc/poster1693.pdf) | [talk](https://www.youtube.com/watch?v=tzdPTrUWlHk) 21 | ![overview.png](https://s2.loli.net/2022/09/15/4XyMgzcNJVx5QlA.png) 22 | 23 | ## Major results from our work 24 | 25 | - Our DOMINO methods improve calibration and accuracy in head segmentation problems from T1 MRIs 26 | - DOMINO-CM achieves higher Top-1, Top-2, and Top-3 accuracy than DOMINO-HC or an uncalibrated model. This indicates superior regional performance and higher relevance to the non-selected classes (important in calibration). 27 | - DOMINO-HC achieves more precise boundary detection when compared to DOMINO-CM or an uncalibrated model. This is important to calibration problems because boundaries are the most uncertain areas in segmentation challenges. 28 | 29 |
30 | 31 |
32 | 33 |
34 | fig. 1: Top-N Accuracy on 6 classes
35 |
36 |
37 | 38 | 39 | ![image.png](https://s2.loli.net/2022/09/16/jaK2OZsr4Bfhwxm.png) 40 |
41 | fig. 2: (a) Dice scores and (b) Hausdorff distances in 11-class segmentation
42 |
43 |
44 | 45 | 46 | 47 | ![image.png](https://s2.loli.net/2022/09/16/xov4uAc5raP7tOH.png) 48 |
49 | fig. 3: Sample image slice for 11-tissue segmentation
50 |
51 |
52 | 53 | ![image.png](https://s2.loli.net/2022/09/16/WAyP9Dhs5RlHJSw.png) 54 |
55 | fig. 4: Sample image slice for 6-tissue segmentation
56 |
57 | 58 | 59 | ## Usage 60 | You can find there are two MATLAB codes, you can directly change the directory to your own data. You need to select the DOMINO working folder and add to path before you running these two MATLAB codes. 61 | 62 | To run the combineIn case of you are using different version of MATLAB, if you are using MATLAB 2020b, you need to change line 56 to : 63 | ``` 64 | image(index) = tissue_cond_updated.Labels(k) 65 | ``` 66 | Then you can run the combine_mask.m. The output should be a Data folder with the following structure: 67 | ``` 68 | Data ImagesTr sub-TrX_T1.nii sub-TrXX_T1.nii ... 69 | ImagesTs sub-TsX_T1.nii sub-TsXX_T1.nii ... 70 | LabelsTr sub-TrX_seg.nii sub-TrXX_seg.nii ... 71 | LabelsTs sub-TsX_seg.nii sub-TsX_seg.nii ... 72 | ``` 73 | Maneuver to the /your_data/Data/. Run make_datalist_json.m 74 | 75 | After this code is done, you may exit MATLAB and open the terminal to run the other codes. 76 | 77 | ### Build container 78 | The DOMINO code uses the MONAI, an open-source foundation. We provide a .sh script to help you to build your own container for running your code. 79 | 80 | Run the following code in the terminal, you need to change the line after --sandbox to your desired writable directory and change the line after --nv to your own directory. 81 | ``` 82 | sbatch building_container_v08.sh 83 | ``` 84 | 85 | The output should be a folder named monaicore08 under your desired directory. 86 | 87 | ### Training 88 | Once the data and the container are ready, you can train the model by using the following command: 89 | ``` 90 | sbatch train.sh 91 | ``` 92 | Before you training the model, you need to make sure change the following directory: 93 | - change the first singularity exec -nv to the directory includes monaicore08, for example: /user/DOMINO/monaicore08 94 | - change the line after --bind to the directory includes monaicore08 95 | - change the data_dir to your data directory 96 | - change the model name to your desired model name 97 | You can also specify the max iteration number for training. For the iterations = 100, the training progress might take about one hours, and for the iterations = 25,000, the training progress might take about 24 hours. 98 | 99 | ### Testing 100 | The test progress is very similar to the training progress. You need to change all paths and make sure the model_save_name matches your model name in runMONAI.sh. Then running the runMONAI_test.sh with the following command: 101 | ``` 102 | sbatch test.sh 103 | ``` 104 | The outputs for each test subject is saved as a mat file. 105 | 106 | ### Pre-trained models 107 | You can also use the pre-trained models we provide for testing, please fill out the following request form before accessing to DOMINO models. 108 | Download pre-trained models [here](https://forms.gle/3GPnXXvWgaM6RZvr5) 109 | 110 | ### Code Ocean 111 | You can alternatively find the link to our reproducible capsule for our code on Code Ocean. The link to this capsule is as follows: https://codeocean.com/capsule/6022409/tree/v2. 112 | 113 | ## Citation 114 | If you use this code, please cite our papers: 115 | ``` 116 | @InProceedings{stolte2022DOMINO, 117 | author="Stolte, Skylar E. and Volle, Kyle and Indahlastari, Aprinda and Albizu, Alejandro and Woods, Adam J. and Brink, Kevin and Hale, Matthew and Fang, Ruogu", 118 | title="DOMINO: Domain-aware Model Calibration in Medical Image Segmentation", 119 | booktitle="Medical Image Computing and Computer Assisted Intervention (MICCAI) 2022", 120 | year="2022", 121 | url="https://arxiv.org/abs/2209.06077" 122 | } 123 | ``` 124 | ## Acknowledgement 125 | 126 | This work was supported by the National Institutes ofHealth/National Institute on Aging (NIA RF1AG071469, NIA R01AG054077),the National Science Foundation (1908299), and the NSF-AFRL INTERN Sup-plement (2130885). 127 | 128 | We acknowledge NVIDIA AI Technology Center (NVAITC)for their suggestions. We also thank Jiaqing Zhang for formatting assistance. 129 | 130 | We employ UNETR as our base model from: 131 | https://github.com/Project-MONAI/research-contributions/tree/main/UNETR 132 | ## Contact 133 | Any discussion, suggestions and questions please contact: [Skylar Stolte](mailto:skylastolte4444@ufl.edu), [Dr. Ruogu Fang](mailto:ruogu.fang@bme.ufl.edu). 134 | 135 | *Smart Medical Informatics Learning & Evaluation Laboratory, Dept. of Biomedical Engineering, University of Florida* 136 | -------------------------------------------------------------------------------- /UNETR_matrixpenalty_v5_2d.csv: -------------------------------------------------------------------------------- 1 | 0,0.999999992,1,1,0.999999984,0.99999029,1,1,0.999998278,0.999623564,0.999999516,0.99998146 2 | 0.999990477,0,0.930067945,0.999950797,0.998069989,1,0.999956239,0.999999773,0.999571688,0.999948303,0.999738569,0.999414331 3 | 1,0.980327666,0,1,0.947401465,1,1,0.999991598,0.999437618,1,1,0.99999825 4 | 0.999885009,0.999012994,1,0,0.968214573,1,1,1,0.999597532,0.962321285,0.966432213,0.94579133 5 | 0.999947667,0.999447344,0.903345211,0.998282222,0,0.999998275,0.999411401,0.998227301,0.937511861,0.999994824,0.999995974,0.999762202 6 | 0.997312003,0.999998553,1,1,0.999998553,0,1,0.999817616,0.886309454,0.999675761,1,0.97068245 7 | 0.994282344,0.99907697,0.999794882,1,0.831700938,0.999615404,0,0.975514076,0.940438952,0.9982565,0.800292293,0.304445926 8 | 1,0.999977785,0.999861772,1,0.992594951,0.999997532,0.999039812,0,0.803091526,0.99961576,0.995874565,0.925463248 9 | 0.999753484,0.999956423,0.999329366,1,0.95887749,0.98052425,0.999110466,0.951492661,0,0.999548012,0.995745135,0.906914118 10 | 0.859514759,1,1,0.999682116,1,0.998863924,1,0.999996119,0.999639809,0,0.988288756,0.978038459 11 | 0.999994015,0.999967898,0.999999637,0.999758603,0.999971888,1,0.999892088,0.999546587,0.99878975,0.9799031,0,0.979812962 12 | 0.999525959,0.999920496,0.999977167,0.999553626,0.999880898,0.998755089,0.999362528,0.9985066,0.977906838,0.973810891,0.957159484,0 -------------------------------------------------------------------------------- /build_container_v08.sh: -------------------------------------------------------------------------------- 1 | #!/bin/bash 2 | #SBATCH --job-name=build_container 3 | #SBATCH --mail-type=END,FAIL 4 | #SBATCH --mail-user=skylastolte4444@ufl.edu 5 | #SBATCH --nodes=1 6 | #SBATCH --cpus-per-task=1 7 | #SBATCH --mem-per-cpu=30gb 8 | #SBATCH --time=08:00:00 9 | #SBATCH --output=%x.%j.out 10 | date;hostname;pwd 11 | 12 | module load singularity 13 | 14 | # build a Singularity sandbox container (container in a writable directory) from MONAI Core docker image 15 | singularity build --sandbox /red/nvidia-ai/SkylarStolte/monaicore08/ docker://projectmonai/monai:0.8.1 16 | # check nsys environment 17 | singularity exec --nv /red/nvidia-ai/SkylarStolte/monaicore08 nsys status -e -------------------------------------------------------------------------------- /combine_masks.m: -------------------------------------------------------------------------------- 1 | clc; clear; 2 | ACT_dir = dir('.'); 3 | for i = length(ACT_dir) : -1 : 1 4 | if ~isdir(ACT_dir(i).name) 5 | ACT_dir(i)=[]; 6 | elseif strcmp(ACT_dir(i).name,'.') || strcmp(ACT_dir(i).name,'..') 7 | ACT_dir(i)=[]; 8 | end 9 | end 10 | names = []; 11 | for i = 1 : length(ACT_dir) 12 | names(i) = str2num(ACT_dir(i).name(11:16)); 13 | end 14 | x = 256; y = 256; z = 256; 15 | ccnt=x*y*z; 16 | 17 | tissues_cond = readtable('tissue_cond_11.xlsx'); 18 | tissue_cond_updated = tissues_cond; 19 | tissue_cond_updated.TissueType(2) = {'wm'}; 20 | tissue_cond_updated.TissueType(3) = {'gm'}; 21 | tissue_cond_updated.TissueType(8) = {'cancellous'}; 22 | tissue_cond_updated.TissueType(9) = {'cortical'}; 23 | tissue_cond_updated(13:14,:)=[]; 24 | 25 | T = length(ACT_dir); Te = round(T*0.10); 26 | 27 | mkdir('data') 28 | imagesTr = fullfile('data', 'imagesTr'); mkdir(imagesTr); 29 | imagesTs = fullfile('data', 'imagesTs'); mkdir(imagesTs); 30 | labelsTr = fullfile('data', 'labelsTr'); mkdir(labelsTr); 31 | labelsTs = fullfile('data', 'labelsTs'); mkdir(labelsTs); 32 | 33 | for i = 1 : length(ACT_dir) 34 | path_raw = strcat('./',ACT_dir(i).name,'/idv_mask/'); 35 | path_save = strcat('./',ACT_dir(i).name,'/comb_mask/'); 36 | 37 | if ~exist(path_save, 'dir') 38 | mkdir(path_save) 39 | end 40 | 41 | path_dir = dir(fullfile(path_raw, '*.raw')); 42 | image = zeros(x*y*z,1); 43 | 44 | for k = height(tissue_cond_updated):-1:1 45 | 46 | for j = 1 : length(path_dir) 47 | fileID = fopen(strcat('/', path_dir(j).folder,'//',path_dir(j).name),'r'); 48 | A=fread(fileID,ccnt,'uint8=>uint8'); 49 | A=reshape(A,x,y,z); 50 | fclose(fileID); 51 | 52 | index = find(A==255); 53 | 54 | if contains(path_dir(j).name, string(tissue_cond_updated.TissueType(k)), 'IgnoreCase', true) 55 | %labels = tissue_cond_updated.Labels{k} * ones(length(index),1); 56 | image(index)=str2num(tissue_cond_updated.Labels{k}); 57 | 58 | end 59 | 60 | end 61 | end 62 | 63 | image = reshape(image,x,y,z); 64 | figure; imshow(image(:,:,floor(z/2)),[0 13]); 65 | save(strcat(path_save,ACT_dir(i).name(7:16),'_seg.mat'),'image'); 66 | 67 | seg_file = make_nii(image); 68 | seg_file.filetype = 2; 69 | seg_file.fileprefix = strcat(path_save,ACT_dir(i).name(7:16),'_seg'); 70 | seg_file.machine = 'ieee-le'; 71 | seg_file.original.hdr = seg_file.hdr; 72 | save_nii(seg_file, char(strcat(path_save,ACT_dir(i).name(7:16),'_seg.nii'))); 73 | 74 | copyfile(fullfile(ACT_dir(i).name, 'T1.nii'), fullfile(ACT_dir(i).name,strcat(ACT_dir(i).name(7:16), '_T1.nii'))); 75 | 76 | if (i>(T-Te-1)) && (i<=T) 77 | copyfile(fullfile(ACT_dir(i).name,'comb_mask', strcat(ACT_dir(i).name(7:16), '_seg.nii')), labelsTs); 78 | copyfile(fullfile(ACT_dir(i).name,strcat(ACT_dir(i).name(7:16), '_T1.nii')), imagesTs); 79 | else 80 | copyfile(fullfile(ACT_dir(i).name,'comb_mask', strcat(ACT_dir(i).name(7:16), '_seg.nii')), labelsTr); 81 | copyfile(fullfile(ACT_dir(i).name,strcat(ACT_dir(i).name(7:16), '_T1.nii')), imagesTr); 82 | end 83 | 84 | end -------------------------------------------------------------------------------- /doc/DOMINO_MICCAI22_PPT.pdf: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/lab-smile/DOMINO/3d261da4dec8ba338818babfa471c47c51d0866d/doc/DOMINO_MICCAI22_PPT.pdf -------------------------------------------------------------------------------- /doc/ReadMeDoc.md: -------------------------------------------------------------------------------- 1 | This is the ReadMe file for the MICCAI presentation documents. 2 | -------------------------------------------------------------------------------- /doc/poster1693.pdf: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/lab-smile/DOMINO/3d261da4dec8ba338818babfa471c47c51d0866d/doc/poster1693.pdf -------------------------------------------------------------------------------- /make_datalist_json.m: -------------------------------------------------------------------------------- 1 | % fname = 'dataset_2.json'; 2 | % fid = fopen(fname); 3 | % raw = fread(fid,inf); 4 | % str = char(raw'); 5 | % fclose(fid); 6 | % val = jsondecode(str); 7 | 8 | description = 'AISEG V5 - Code Validation'; 9 | labels = struct('xO', 'background', ... 10 | 'x1', 'wm', ... 11 | 'x2', 'gm', ... 12 | 'x3', 'eyes', ... 13 | 'x4', 'csf', ... 14 | 'x5', 'air', ... 15 | 'x6', 'blood', ... 16 | 'x7', 'cancellous', ... 17 | 'x8', 'cortical', ... 18 | 'x9', 'skin', ... 19 | 'x10', 'fat', ... 20 | 'x11', 'muscle'); 21 | license = 'UF'; 22 | modality = struct('x0', 'T1'); 23 | numTest = length(dir(fullfile('imagesTs', '*.nii'))); 24 | numTraining = length(dir(fullfile('imagesTr', '*.nii'))); 25 | 26 | testdir = dir(fullfile('imagesTs', '*.nii')); 27 | for i = 1 : length(testdir) 28 | test(i,1) = {fullfile('imagesTs',testdir(i).name)}; 29 | end 30 | 31 | traindir = dir(fullfile('imagesTr', '*.nii')); 32 | trainlabeldir = dir(fullfile('labelsTr', '*.nii')); 33 | 34 | T = length(traindir); Te = round(T*0.10); 35 | traindir_fin = traindir(1:T-Te-1); 36 | validdir_fin = traindir(T-Te:T); 37 | traindir_label_fin = trainlabeldir(1:T-Te-1); 38 | validdir_label_fin = trainlabeldir(T-Te:T); 39 | 40 | %training = struct('image', fullfile('imagesTr',traindir_fin(:).name), 'label', fullfile('labelsTr',traindir_label_fin(:).name)); 41 | % training = struct(); 42 | % training.image = {fullfile('imagesTr',traindir_fin(:).name)}; 43 | % training.label = {fullfile('labelsTr',traindir_label_fin(:).name)}; 44 | % training = struct('image', fullfile('imagesTr',traindir_fin(:).name), 'label', fullfile('labelsTr',traindir_label_fin(:).name)); 45 | % training = [image, label]; 46 | for i = 1 : length(traindir_fin) 47 | newtrain = struct('image', fullfile('imagesTr',traindir_fin(i).name), 'label', fullfile('labelsTr',traindir_label_fin(i).name)); 48 | if i == 1 49 | training = newtrain; 50 | else 51 | training = [training; newtrain]; 52 | end 53 | end 54 | for i = 1 : length(validdir_fin) 55 | newtrain = struct('image', fullfile('imagesTr',validdir_fin(i).name), 'label', fullfile('labelsTr',validdir_label_fin(i).name)); 56 | if i == 1 57 | validation = newtrain; 58 | else 59 | validation = [validation; newtrain]; 60 | end 61 | end 62 | 63 | % s = struct('description', description, ... 64 | % 'license', license, ... 65 | % 'labels', labels, ... 66 | % 'modality', modality, ... 67 | % 'name', 'ACT', ... 68 | % 'numTest', numTest, ... 69 | % 'numTraining', numTraining, ... 70 | % 'reference', 'NA', ... 71 | % 'release', 'NA', ... 72 | % 'tensorImageSize', '3D', ... 73 | % 'test', test, ... 74 | % 'training', training, ... 75 | % 'validation', validation); 76 | s = struct(); 77 | s.description = description; 78 | s.labels = labels; 79 | s.license = license; 80 | s.modality = modality; 81 | s.name = 'ACT'; 82 | s.numTest = numTest; 83 | s.numTraining = numTraining; 84 | s.reference = 'NA'; 85 | s.release = 'NA'; 86 | s.tensorImageSize = '3D'; 87 | s.test = test; 88 | s.training = training; 89 | s.validation = validation; 90 | 91 | s = jsonencode(s); 92 | fid = fopen('dataset_1.json','w'); 93 | fprintf(fid,s); 94 | fclose(fid); 95 | 96 | 97 | -------------------------------------------------------------------------------- /test.sh: -------------------------------------------------------------------------------- 1 | #!/bin/bash 2 | #SBATCH --job-name=monai_test 3 | #SBATCH --mail-type=END,FAIL 4 | #SBATCH --mail-user= 5 | #SBATCH --ntasks=1 6 | #SBATCH --cpus-per-task=4 7 | #SBATCH --distribution=block:block 8 | #SBATCH --partition=hpg-ai 9 | #SBATCH --gres=gpu:a100:2 10 | #SBATCH --mem=30gb 11 | #SBATCH --time=72:00:00 12 | #SBATCH --output=%x_%j.log 13 | 14 | #module load pytorch 15 | module load singularity 16 | #module load monai 17 | 18 | # Check if cuda enabled 19 | #python -c "import torch; print(torch.cuda.is_available())" 20 | singularity exec --nv /monaicore081 python3 -c "import torch; print(torch.cuda.is_available())" 21 | 22 | #run code 23 | #python test.py --num_gpu 2 --data_dir "" --N_classes 12 --model_load_name "unetr_v5_bfc.pth" --dataparallel "True" 24 | 25 | singularity exec --nv --bind :/mnt /monaicore081 python3 /mnt/test.py --num_gpu 2 --data_dir '/mnt//' --model_load_name "unetr_v5_06-19-22.pth" --N_classes 12 --dataparallel "True" --a_max_value 255 --spatial_size 64 -------------------------------------------------------------------------------- /test_domino.py: -------------------------------------------------------------------------------- 1 | # coding=utf-8 2 | 3 | #load packages: 4 | 5 | #standard packages - 6 | 7 | import os 8 | import shutil 9 | import tempfile 10 | import matplotlib.pyplot as plt 11 | import numpy as np 12 | from tqdm import tqdm 13 | import torch 14 | import torch.nn as nn 15 | import time 16 | import argparse 17 | from scipy.io import savemat 18 | 19 | #load monai functions - 20 | 21 | from monai.losses import DiceCELoss 22 | from monai.inferers import sliding_window_inference 23 | from monai.transforms import ( 24 | AsDiscrete, 25 | AddChanneld, 26 | Compose, 27 | CropForegroundd, 28 | LoadImaged, 29 | Orientationd, 30 | RandFlipd, 31 | RandCropByPosNegLabeld, 32 | RandShiftIntensityd, 33 | ScaleIntensityRanged, 34 | Spacingd, 35 | RandRotate90d, 36 | ToTensord, 37 | SpatialPadd, 38 | RandGaussianNoised, 39 | ToDeviced, 40 | ) 41 | 42 | from monai.config import print_config 43 | from monai.metrics import DiceMetric 44 | from monai.networks.nets import UNETR, BasicUNet 45 | #from monai.networks.nets import UNet 46 | 47 | from monai.data import ( 48 | DataLoader, 49 | load_decathlon_datalist, 50 | decollate_batch, 51 | Dataset, 52 | pad_list_data_collate, 53 | ) 54 | 55 | #----------------------------------- 56 | 57 | #set up starting conditions: 58 | 59 | #start_time = time.time() 60 | print_config() 61 | 62 | # our CLI parser 63 | parser = argparse.ArgumentParser() 64 | parser.add_argument("--data_dir", type=str, default="/red/nvidia-ai/SkylarStolte/training_pairs_v5_bfc/", help="directory the dataset is in") 65 | parser.add_argument("--batch_size_test", type=int, default=1, help="batch size testing data") 66 | parser.add_argument("--num_gpu", type=int, default=1, help="number of gpus") 67 | parser.add_argument("--N_classes", type=int, default=12, help="number of tissues classes") 68 | parser.add_argument("--spatial_size", type=int, default=256, help="one patch dimension") 69 | parser.add_argument("--model_load_name", type=str, default="unetr_v5_bfc.pth", help="model to load") 70 | parser.add_argument("--dataparallel", type=str, default="True", help="did your model use multi-gpu") 71 | parser.add_argument("--a_max_value", type=int, default=255, help="maximum image intensity") 72 | parser.add_argument("--a_min_value", type=int, default=0, help="minimum image intensity") 73 | args = parser.parse_args() 74 | 75 | split_JSON = "dataset_1.json" 76 | datasets = args.data_dir + split_JSON 77 | 78 | #os.environ["CUDA_DEVICE_ORDER"] = "PCI_BUS_ID" 79 | #device = torch.device("cuda" if torch.cuda.is_available() else "cpu") 80 | 81 | #----------------------------------- 82 | 83 | #data transformations: 84 | 85 | test_transforms = Compose( 86 | [ 87 | LoadImaged(keys=["image"]), 88 | AddChanneld(keys=["image"]), 89 | Spacingd( 90 | keys=["image"], 91 | pixdim=(1.0, 1.0, 1.0), 92 | mode=("bilinear"), 93 | ), 94 | Orientationd(keys=["image"], axcodes="RAS"), 95 | ScaleIntensityRanged(keys=["image"], a_min=args.a_min_value, a_max=args.a_max_value, b_min=0.0, b_max=1.0, clip=True), 96 | #CropForegroundd(keys=["image", "label"], source_key="image"), 97 | ToTensord(keys=["image"]), 98 | #ToDeviced(keys=["image", "label"], device=device), 99 | ] 100 | ) 101 | 102 | #----------------------------------- 103 | 104 | #set up data loaders 105 | 106 | test_files = load_decathlon_datalist(datasets, True, "test") 107 | 108 | test_ds = Dataset( 109 | data=test_files, transform=test_transforms, 110 | ) 111 | test_loader = DataLoader( 112 | test_ds, batch_size=args.batch_size_test, shuffle=False, num_workers=4, pin_memory=True, collate_fn=pad_list_data_collate, 113 | ) 114 | 115 | #----------------------------------- 116 | 117 | #set up gpu device and unetr model 118 | 119 | #os.environ["CUDA_DEVICE_ORDER"] = "PCI_BUS_ID" 120 | #device = torch.device("cuda" if torch.cuda.is_available() else "cpu") 121 | 122 | if args.dataparallel == "True": 123 | 124 | model = nn.DataParallel( 125 | UNETR( 126 | in_channels=1, 127 | out_channels=args.N_classes, #12 for all tissues 128 | img_size=(args.spatial_size, args.spatial_size, args.spatial_size), 129 | feature_size=16, 130 | hidden_size=768, 131 | mlp_dim=3072, 132 | num_heads=12, 133 | pos_embed="perceptron", 134 | norm_name="instance", 135 | res_block=True, 136 | dropout_rate=0.0, 137 | ), device_ids=[i for i in range(args.num_gpu)]).cuda() 138 | 139 | elif args.dataparallel == "False": 140 | 141 | #device = torch.device(f"cuda:{args.local_rank}") 142 | #torch.cuda.set_device(device) 143 | os.environ["CUDA_DEVICE_ORDER"] = "PCI_BUS_ID" 144 | device = torch.device("cuda" if torch.cuda.is_available() else "cpu") 145 | 146 | model = UNETR( 147 | in_channels=1, 148 | out_channels=args.N_classes, #12 for all tissues 149 | img_size=(args.spatial_size, args.spatial_size, args.spatial_size), 150 | feature_size=16, 151 | hidden_size=768, 152 | mlp_dim=3072, 153 | num_heads=12, 154 | pos_embed="perceptron", 155 | norm_name="instance", 156 | res_block=True, 157 | dropout_rate=0.0, 158 | ).to(device) 159 | 160 | loss_function = DiceCELoss(to_onehot_y=True, softmax=True) 161 | torch.backends.cudnn.benchmark = True 162 | optimizer = torch.optim.AdamW(model.parameters(), lr=1e-4, weight_decay=1e-5) 163 | 164 | #----------------------------------- 165 | 166 | model.load_state_dict(torch.load(os.path.join(args.data_dir, args.model_load_name))) 167 | model.eval() 168 | 169 | case_num = len(test_ds) 170 | for i in range(case_num): 171 | #start_time = time.time() 172 | with torch.no_grad(): 173 | img_name = os.path.split(test_ds[i]["image_meta_dict"]["filename_or_obj"])[1] 174 | img = test_ds[i]["image"] 175 | test_inputs = torch.unsqueeze(img, 1).cuda() 176 | #start_time = time.time() 177 | test_outputs = sliding_window_inference(test_inputs, (args.spatial_size, args.spatial_size, args.spatial_size), 4, model, overlap=0.8) 178 | #print("--- %s seconds ---" % (time.time() - start_time)) 179 | #logits = test_outputs.detach().cpu().numpy() 180 | testimage = torch.argmax(test_outputs, dim=1).detach().cpu().numpy() 181 | #savepath = 'testimage' + str(i) + '.mat' 182 | filename, file_extension = os.path.splitext(img_name) 183 | savepath = filename + '.mat' 184 | savemat(os.path.join(args.data_dir,savepath), {'testimage':testimage})#, 'logits':logits}) 185 | #print("--- %s seconds ---" % (time.time() - start_time)) 186 | 187 | #------------------------------------ 188 | 189 | #time since start 190 | 191 | #print("--- %s seconds ---" % (time.time() - start_time)) 192 | -------------------------------------------------------------------------------- /tissue_cond_11.xlsx: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/lab-smile/DOMINO/3d261da4dec8ba338818babfa471c47c51d0866d/tissue_cond_11.xlsx -------------------------------------------------------------------------------- /train.sh: -------------------------------------------------------------------------------- 1 | #!/bin/bash 2 | #SBATCH --job-name=train 3 | #SBATCH --mail-type=END,FAIL 4 | #SBATCH --mail-user= 5 | #SBATCH --ntasks=1 6 | #SBATCH --cpus-per-task=4 7 | #SBATCH --partition=hpg-ai 8 | #SBATCH --gres=gpu:a100:1 9 | #SBATCH --mem=90gb 10 | #SBATCH --time=72:00:00 11 | #SBATCH --output=%x_%j.log 12 | 13 | #module load pytorch 14 | module load singularity 15 | #module load monai 16 | 17 | # Check if cuda enabled 18 | singularity exec --nv /monaicore081 python3 -c "import torch; print(torch.cuda.is_available())" 19 | 20 | #run code 21 | #singularity exec --nv /monaicore08 python3 /train_domino.py --num_gpu 3 22 | #python3 /train_domino.py --num_gpu 3 --a_min_value 0 --a_max_value 255 23 | 24 | singularity exec --nv --bind :/mnt /monaicore081 python3 /mnt/train_domino.py --num_gpu 1 --data_dir '/mnt//' --model_save_name "unetr_v5_domino_06-20-22" --N_classes 12 --max_iteration 100 --------------------------------------------------------------------------------
