├── directTDoA_static_server_list.db
├── icon.gif
├── maps
    ├── directTDoA_map.jpg
    ├── directTDoA_map_grayscale_with_sea.jpg
    └── How to find the other maps.txt
├── .gitignore
├── .idea
    ├── vcs.xml
    ├── modules.xml
    ├── misc.xml
    ├── directTDoA.iml
    └── directTDoA4.iml
├── .gitmodules
├── kiwiwavreader_patch.diff
├── json_save_patch.diff
├── Copying.wtfpl
├── read_data_patch.diff
├── kiwiclient_patch.diff
├── modsocket_patch.diff
├── nognss.py
├── setup.sh
├── kiwiworker_patch.diff
├── plot_map_patch.diff
├── plot_iq.py
├── directTDoA.cfg
├── getmap.py
├── kiwirecorder_patch.diff
├── trim_iq.py
├── microkiwi_patch.diff
├── README.md
├── directTDoA_server_list.db
└── compute_ultimate.py


/directTDoA_static_server_list.db:
--------------------------------------------------------------------------------
1 | []


--------------------------------------------------------------------------------
/icon.gif:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/llinkz/directTDoA/HEAD/icon.gif


--------------------------------------------------------------------------------
/maps/directTDoA_map.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/llinkz/directTDoA/HEAD/maps/directTDoA_map.jpg


--------------------------------------------------------------------------------
/maps/directTDoA_map_grayscale_with_sea.jpg:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/llinkz/directTDoA/HEAD/maps/directTDoA_map_grayscale_with_sea.jpg


--------------------------------------------------------------------------------
/.gitignore:
--------------------------------------------------------------------------------
1 | # Python 2.7
2 | __pycache__/
3 | *.py[cod]
4 | *$py.class
5 |
6 | # directTDoA
7 | directTDoA_server_list.db.bak*
8 | directTDoA.cfg.bak*
9 |


--------------------------------------------------------------------------------
/maps/How to find the other maps.txt:
--------------------------------------------------------------------------------
1 | Additional World maps are stored here:
2 | http://linkz.ddns.net/dmaps/
3 |
4 | download them to /maps directory and they will be available in the "Browse map folder"


--------------------------------------------------------------------------------
/.idea/vcs.xml:
--------------------------------------------------------------------------------
1 | <?xml version="1.0" encoding="UTF-8"?>
2 | <project version="4">
3 |   <component name="VcsDirectoryMappings">
4 |     <mapping directory="$PROJECT_DIR$" vcs="Git" />
5 |   </component>
6 | </project>


--------------------------------------------------------------------------------
/.gitmodules:
--------------------------------------------------------------------------------
1 | [submodule "TDoA"]
2 | 	path = TDoA
3 | 	url = https://github.com/hcab14/TDoA
4 | 	ignore = dirty
5 | [submodule "kiwiclient"]
6 | 	path = kiwiclient
7 | 	url = https://github.com/jks-prv/kiwiclient
8 | 	ignore = dirty
9 |


--------------------------------------------------------------------------------
/.idea/modules.xml:
--------------------------------------------------------------------------------
1 | <?xml version="1.0" encoding="UTF-8"?>
2 | <project version="4">
3 |   <component name="ProjectModuleManager">
4 |     <modules>
5 |       <module fileurl="file://$PROJECT_DIR$/.idea/directTDoA4.iml" filepath="$PROJECT_DIR$/.idea/directTDoA4.iml" />
6 |     </modules>
7 |   </component>
8 | </project>


--------------------------------------------------------------------------------
/.idea/misc.xml:
--------------------------------------------------------------------------------
1 | <?xml version="1.0" encoding="UTF-8"?>
2 | <project version="4">
3 |   <component name="ProjectRootManager" version="2" project-jdk-name="Python 2.7" project-jdk-type="Python SDK" />
4 |   <component name="PythonCompatibilityInspectionAdvertiser">
5 |     <option name="version" value="3" />
6 |   </component>
7 | </project>


--------------------------------------------------------------------------------
/kiwiwavreader_patch.diff:
--------------------------------------------------------------------------------
 1 | --- wavreader.py	2023-05-03 23:23:46.634226575 +0200
 2 | +++ wavreader.py	2023-05-03 23:24:46.541523946 +0200
 3 | @@ -8,7 +8,7 @@
 4 |  class KiwiIQWavError(Exception):
 5 |      pass
 6 |
 7 | -class KiwiIQWavReader(collections.Iterator):
 8 | +class KiwiIQWavReader(collections.abc.Iterator):
 9 |      def __init__(self, f):
10 |          super(KiwiIQWavReader, self).__init__()
11 |          self._frame_counter = 0
12 |


--------------------------------------------------------------------------------
/.idea/directTDoA.iml:
--------------------------------------------------------------------------------
 1 | <?xml version="1.0" encoding="UTF-8"?>
 2 | <module type="PYTHON_MODULE" version="4">
 3 |   <component name="NewModuleRootManager">
 4 |     <content url="file://$MODULE_DIR$" />
 5 |     <orderEntry type="inheritedJdk" />
 6 |     <orderEntry type="sourceFolder" forTests="false" />
 7 |   </component>
 8 |   <component name="TestRunnerService">
 9 |     <option name="PROJECT_TEST_RUNNER" value="Unittests" />
10 |   </component>
11 | </module>


--------------------------------------------------------------------------------
/.idea/directTDoA4.iml:
--------------------------------------------------------------------------------
 1 | <?xml version="1.0" encoding="UTF-8"?>
 2 | <module type="PYTHON_MODULE" version="4">
 3 |   <component name="NewModuleRootManager">
 4 |     <content url="file://$MODULE_DIR$" />
 5 |     <orderEntry type="inheritedJdk" />
 6 |     <orderEntry type="sourceFolder" forTests="false" />
 7 |   </component>
 8 |   <component name="TestRunnerService">
 9 |     <option name="PROJECT_TEST_RUNNER" value="Unittests" />
10 |   </component>
11 | </module>


--------------------------------------------------------------------------------
/json_save_patch.diff:
--------------------------------------------------------------------------------
 1 | --- json_save_cc.cc	2020-02-23 13:20:55.283898093 +0000
 2 | +++ json_save_cc.cc	2020-02-23 13:20:30.051086971 +0000
 3 | @@ -1,6 +1,6 @@
 4 |  #include <octave/oct.h>
 5 |
 6 | -#if OCTAVE_MAJOR_VERSION >= 4 and OCTAVE_MINOR_VERSION >= 4
 7 | +#if OCTAVE_MAJOR_VERSION >= 5 or (OCTAVE_MAJOR_VERSION >= 4 and OCTAVE_MINOR_VERSION >= 4)
 8 |  #  include <octave/interpreter.h>
 9 |  #  define OCT_STREAM_TYPE    octave::stream
10 |  #  define OCT_REGEXP_REPLACE octave::regexp::replace
11 |


--------------------------------------------------------------------------------
/Copying.wtfpl:
--------------------------------------------------------------------------------
 1 | DO WHAT THE FUCK YOU WANT TO PUBLIC LICENSE
 2 |                     Version 2, December 2004
 3 |
 4 |  Copyright (C) 2004 Sam Hocevar <sam@hocevar.net>
 5 |
 6 |  Everyone is permitted to copy and distribute verbatim or modified
 7 |  copies of this license document, and changing it is allowed as long
 8 |  as the name is changed.
 9 |
10 |             DO WHAT THE FUCK YOU WANT TO PUBLIC LICENSE
11 |    TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION
12 |
13 |   0. You just DO WHAT THE FUCK YOU WANT TO.


--------------------------------------------------------------------------------
/read_data_patch.diff:
--------------------------------------------------------------------------------
 1 | --- tdoa_read_data.m	2020-02-03 21:07:32.745370216 +0000
 2 | +++ tdoa_read_data2.m	2020-01-24 21:22:43.892867681 +0000
 3 | @@ -83,11 +83,11 @@
 4 |      b = input(i).t<t0 | input(i).t>t1;
 5 |      input(i).t(b) = [];
 6 |      input(i).z(b) = [];
 7 | -    input(i).use  = numel(input(i).z)/input(i).fs > 10;
 8 | +    input(i).use  = numel(input(i).z)/input(i).fs > 3;
 9 |      if ~input(i).use
10 |        printf('tdoa_read_data: %-40s excluded (%.2f sec < %g sec overlap)\n', ...
11 | -             input(i).fn, numel(input(i).z)/input(i).fs, 10);
12 | -      status.per_file(i).message = sprintf('excluded (%.2f sec < %g sec overlap)', numel(input(i).z)/12000, 10);
13 | +             input(i).fn, numel(input(i).z)/input(i).fs, 3);
14 | +      status.per_file(i).message = sprintf('excluded (%.2f sec < %g sec overlap)', numel(input(i).z)/12000, 3);
15 |      end
16 |    end
17 |
18 |


--------------------------------------------------------------------------------
/kiwiclient_patch.diff:
--------------------------------------------------------------------------------
 1 | --- client.py	2020-01-24 21:05:52.530626977 +0000
 2 | +++ client.py	2020-02-03 20:51:42.290914515 +0000
 3 | @@ -292,12 +292,12 @@
 4 |          else:
 5 |              logging.debug("recv MSG (%s) %s: %s", self._stream_name, name, value)
 6 |          # Handle error conditions
 7 | -        if name == 'too_busy':
 8 | -            raise KiwiTooBusyError('%s: all %s client slots taken' % (self._options.server_host, value))
 9 | -        if name == 'badp' and value == '1':
10 | -            raise KiwiBadPasswordError('%s: bad password' % self._options.server_host)
11 | -        if name == 'down':
12 | -            raise KiwiDownError('%s: server is down atm' % self._options.server_host)
13 | +        # if name == 'too_busy':
14 | +        #     raise KiwiTooBusyError('%s: all %s client slots taken' % (self._options.server_host, value))
15 | +        # if name == 'badp' and value == '1':
16 | +        #     raise KiwiBadPasswordError('%s: bad password' % self._options.server_host)
17 | +        # if name == 'down':
18 | +        #     raise KiwiDownError('%s: server is down atm' % self._options.server_host)
19 |          # Handle data items
20 |          if name == 'audio_rate':
21 |              self._set_ar_ok(int(value), 44100)
22 |


--------------------------------------------------------------------------------
/modsocket_patch.diff:
--------------------------------------------------------------------------------
 1 | --- util.py	2021-02-21 15:10:41.318806871 +0100
 2 | +++ util.py	2021-02-21 15:10:39.728806882 +0100
 3 | @@ -33,6 +33,7 @@
 4 |
 5 |  import array
 6 |  import errno
 7 | +import sys
 8 |
 9 |  # Import hash classes from a module available and recommended for each Python
10 |  # version and re-export those symbol. Use sha and md5 module in Python 2.4, and
11 | @@ -198,7 +199,10 @@
12 |      def _mask_using_array(self, s):
13 |          """Perform the mask via python."""
14 |          result = array.array('B')
15 | -        result.fromstring(bytes(s))
16 | +        if sys.version_info[0] == 3 and sys.version_info[1] >= 9:
17 | +            result.frombytes(bytes(s))
18 | +        else:
19 | +            result.fromstring(bytes(s))
20 |
21 |          # Use temporary local variables to eliminate the cost to access
22 |          # attributes
23 | @@ -214,8 +218,10 @@
24 |              masking_key_index = (masking_key_index + 1) % masking_key_size
25 |
26 |          self._masking_key_index = masking_key_index
27 | -
28 | -        return result.tostring()
29 | +        if sys.version_info[0] == 3 and sys.version_info[1] >= 9:
30 | +            return result.tobytes()
31 | +        else:
32 | +            return result.tostring()
33 |
34 |      if 'fast_masking' in globals():
35 |          mask = _mask_using_swig
36 |


--------------------------------------------------------------------------------
/nognss.py:
--------------------------------------------------------------------------------
 1 | #!/usr/bin/python
 2 | # -*- coding: utf-8 -*-
 3 | """ This python script removes GNSS data from KiwiSDR IQ files
 4 | credits: Daniel Ekmann & linkz
 5 | usage ./plot_iq.py """
 6 |
 7 | # python 2/3 compatibility
 8 | from __future__ import print_function
 9 | from __future__ import division
10 | from __future__ import absolute_import
11 |
12 | import struct
13 | import os
14 | import glob
15 |
16 | os.makedirs('NOGPS')
17 |
18 |
19 | def removegnss(source):
20 |     """ Removes GNSS from the KiwiSDR original IQ file and save it as standard wav. """
21 |     old_f = open(source, 'rb')
22 |     new_f = open(os.path.join('NOGPS') + os.sep + source[:-4] + '.nogps.wav', 'wb')
23 |     old_size = os.path.getsize(source)
24 |     data_size = 2048 * ((old_size - 36) // 2074)
25 |     new_f.write(old_f.read(36))
26 |     new_f.write(b'data')
27 |     new_f.write(struct.pack('<i', data_size))
28 |     for i in range(62, old_size, 2074):
29 |         old_f.seek(i)
30 |         new_f.write(old_f.read(2048))
31 |     new_f.close()
32 |     old_f.close()
33 |
34 |
35 | if __name__ == '__main__':
36 |
37 |     COUNT = 1
38 |     TOTALCOUNT = len(glob.glob("*.wav"))
39 |     for wavfiles in glob.glob("*.wav"):
40 |         print(str(COUNT) + "/" + str(TOTALCOUNT) + " ... [" + wavfiles.rsplit("_", 3)[2] + "]")
41 |         removegnss(wavfiles)
42 |         COUNT += 1
43 |


--------------------------------------------------------------------------------
/setup.sh:
--------------------------------------------------------------------------------
 1 | #!/bin/sh
 2 | echo "1/3 Upgrading python pip and installing python modules"
 3 | sudo python -m pip install --upgrade pip
 4 | python -m pip install pillow requests matplotlib numpy future sounddevice samplerate
 5 | echo "2/3 Compilating TDoA binaries and installing packages for GNU Octave (ignore warnings)"
 6 | cd TDoA/src
 7 | patch -i ../../json_save_patch.diff json_save_cc.cc
 8 | rm -f ../../json_save_patch.diff
 9 | mkoctfile json_save_cc.cc
10 | mkoctfile read_kiwi_iq_wav.cc
11 | mv json_save_cc.oct read_kiwi_iq_wav.oct ../oct
12 | octave --silent --eval "pkg install -forge control signal"
13 | octave --silent --eval "pkg load signal"
14 | octave --silent --eval "pkg list"
15 | cd ../..
16 | echo "3/3 Patching some python and GNU Octave files"
17 | patch -i kiwiworker_patch.diff ./kiwiclient/kiwi/worker.py
18 | patch -i kiwiclient_patch.diff ./kiwiclient/kiwi/client.py
19 | patch -i kiwiwavreader_patch.diff ./kiwiclient/kiwi/wavreader.py
20 | patch -i kiwirecorder_patch.diff ./kiwiclient/kiwirecorder.py
21 | patch -i microkiwi_patch.diff ./kiwiclient/microkiwi_waterfall.py
22 | patch -i modsocket_patch.diff ./kiwiclient/mod_pywebsocket/util.py
23 | patch -i plot_map_patch.diff ./TDoA/m/tdoa_plot_map.m
24 | patch -i read_data_patch.diff ./TDoA/m/tdoa_read_data.m
25 | rm -f *.diff
26 | echo "The setup is now finished.\nTo start the software from console, type ./directTDoA.py"
27 | sleep 5


--------------------------------------------------------------------------------
/kiwiworker_patch.diff:
--------------------------------------------------------------------------------
 1 | --- worker.py	2020-01-24 21:05:52.530626977 +0000
 2 | +++ worker.py	2020-02-03 20:50:50.601945384 +0000
 3 | @@ -42,21 +42,21 @@
 4 |                  if self._options.no_api:
 5 |                      msg = ''
 6 |                  else:
 7 | -                    msg = ' Reconnecting after 5 seconds'
 8 | +                    msg = ' Reconnecting after 2 seconds'
 9 |                  logging.info("%s:%s %s.%s" % (self._options.server_host, self._options.server_port, e, msg))
10 |                  self._recorder.close()
11 |                  if self._options.no_api:    ## don't retry
12 |                      break
13 |                  self._recorder._start_ts = None ## this makes the recorder open a new file on restart
14 | -                self._event.wait(timeout=5)
15 | +                self._event.wait(timeout=2)
16 |                  continue
17 |              except KiwiTooBusyError:
18 | -                logging.info("%s:%d too busy now. Reconnecting after 15 seconds"
19 | +                logging.info("%s:%d too busy now. Reconnecting after 2 seconds"
20 |                        % (self._options.server_host, self._options.server_port))
21 |                  if self._options.is_kiwi_tdoa:
22 |                      self._options.status = 2
23 |                      break
24 | -                self._event.wait(timeout=15)
25 | +                self._event.wait(timeout=2)
26 |                  continue
27 |              except KiwiTimeLimitError:
28 |                  break
29 |


--------------------------------------------------------------------------------
/plot_map_patch.diff:
--------------------------------------------------------------------------------
 1 | --- tdoa_plot_map.m	2023-06-15 07:39:12.531485461 +0200
 2 | +++ tdoa_plot_map.m	2021-12-29 02:38:55.195793080 +0100
 3 | @@ -38,8 +38,8 @@
 4 |    if ~plot_kiwi
 5 |      set(0,'defaultaxesposition', [0.05, 0.05, 0.90, 0.9])
 6 |      figure(1, 'position', [100,100, 900,600])
 7 | -    plot_info.titlefontsize = 10;
 8 | -    plot_info.labelfontsize =  7.5;
 9 | +    plot_info.titlefontsize = 10; # 10
10 | +    plot_info.labelfontsize =  5; # 7.5
11 |    end
12 |
13 |    n_stn      = length(input_data);
14 | @@ -140,6 +140,7 @@
15 |      end
16 |      set(colorbar(),'XLabel', 'sqrt(\chi^2)/ndf')
17 |      printf('tdoa_plot_map_combined: [%.3f sec]\n', toc());
18 | +    global mlp
19 |      ha = axes('Position', [0 0 1 1], ...
20 |                'Xlim',     [0 1], ...
21 |                'Ylim',     [0 1], ...
22 | @@ -147,12 +148,13 @@
23 |                'Visible',  'off', ...
24 |                'Units',    'normalized', ...
25 |                'clipping', 'off');
26 | -    text(0.5, 0.98,  plot_info.title, ...
27 | +    text(0.5, 0.98,  strcat(plot_info.title, mlp), ...
28 |           'fontweight', 'bold', ...
29 |           'horizontalalignment', 'center', ...
30 | -         'fontsize', 15);
31 | -    print('-dpng','-S900,600', fullfile('png', sprintf('%s.png', plot_info.plotname)));
32 | -    print('-dpdf','-S900,600', fullfile('pdf', sprintf('%s.pdf', plot_info.plotname)));
33 | +         'fontsize', 12); # 15
34 | +    ## print('-dpng','-S3600,2400', fullfile('png', sprintf('%s.png', plot_info.plotname)));
35 | +    set(gcf, "paperunits", "points", "papersize", [900, 600], 'PaperPosition', [0 0 900 600]);
36 | +    print('-dpdf', fullfile('pdf', sprintf('%s.pdf', plot_info.plotname)));
37 |    end
38 |    if plot_info.plot_kiwi_json
39 |      [h,h_max] = adjust_scale(plot_info, h);
40 | @@ -184,6 +186,7 @@
41 |    _i = _i(_j);
42 |    pos = [plot_info.lat(_i) plot_info.lon(_j)];
43 |    printf('most likely position: lat = %.2f deg  lon = %.2f deg\n', pos);
44 | +  global mlp=cstrcat(sprintf(' - [lat %.2f lon %.2f]', plot_info.lat(_i), plot_info.lon(_j)));
45 |  endfunction
46 |
47 |  function [bb_lon, bb_lat, idx_lon, idx_lat] = find_bounding_box(plot_info, h)
48 |


--------------------------------------------------------------------------------
/plot_iq.py:
--------------------------------------------------------------------------------
  1 | #!/usr/bin/python
  2 | # -*- coding: utf-8 -*-
  3 | """ Removes GNSS datas from KiwiSDR IQ files, do a SNR check and plot all into a single .pdf file.
  4 | credits: Daniel Ekmann & linkz - usage ./plot_iq.py """
  5 |
  6 | # python 2/3 compatibility
  7 | from __future__ import print_function
  8 | from __future__ import division
  9 | from __future__ import absolute_import
 10 |
 11 | import glob
 12 | import math
 13 | import os
 14 | import re
 15 | from io import BytesIO
 16 | import numpy as np
 17 | import matplotlib.pyplot as plt
 18 | import matplotlib.colors as clr
 19 | # import matplotlib.ticker as tkr
 20 |
 21 | GRADIENT = {
 22 |     'red': ((0.0, 0.0, 0.0),
 23 |             (0.077, 0.0, 0.0),
 24 |             (0.16, 0.0, 0.0),
 25 |             (0.265, 1.0, 1.0),
 26 |             (0.403, 1.0, 1.0),
 27 |             (0.604, 1.0, 1.0),
 28 |             (1.0, 1.0, 1.0)),
 29 |
 30 |     'green': ((0.0, 0.0, 0.0),
 31 |               (0.077, 0.0, 0.0),
 32 |               (0.16, 1.0, 1.0),
 33 |               (0.265, 1.0, 1.0),
 34 |               (0.403, 0.0, 0.0),
 35 |               (0.604, 0.0, 0.0),
 36 |               (1.0, 0.764, 0.764)),
 37 |
 38 |     'blue': ((0.0, 0.117, 0.117),
 39 |              (0.077, 1.0, 1.0),
 40 |              (0.16, 1.0, 1.0),
 41 |              (0.265, 0.0, 0.0),
 42 |              (0.403, 0.0, 0.0),
 43 |              (0.604, 1.0, 1.0),
 44 |              (1.0, 1.0, 1.0)),
 45 | }
 46 | COLORMAP = clr.LinearSegmentedColormap('SAColorMap', GRADIENT, 1024)
 47 |
 48 |
 49 | def load(path):
 50 |     """ IQ loading. """
 51 |     buf = BytesIO()
 52 |     with open(path, 'rb') as iq_file:
 53 |         size = os.path.getsize(path)
 54 |         for i in range(62, size, 2074):
 55 |             iq_file.seek(i)
 56 |             buf.write(iq_file.read(2048))
 57 |     data = np.frombuffer(buf.getvalue(), dtype='int16')
 58 |     data = data[0::2] + 1j * data[1::2]
 59 |     return data
 60 |
 61 |
 62 | def score(data):
 63 |     """ SNR scoring. """
 64 |     max_snr = 0.0
 65 |     for offset in range(12000, len(data), 512):
 66 |         snr = np.std(np.fft.fft(data[offset:], n=1024))
 67 |         if snr > max_snr:
 68 |             max_snr = snr
 69 |     return max_snr
 70 |
 71 |
 72 | def plot(files, order, cols):
 73 |     """ Plotting. """
 74 |     rows = int(math.ceil(len(files) / cols))
 75 |     fig, axs = plt.subplots(ncols=cols, nrows=rows)
 76 |     fig.set_figwidth(cols * 6.4)
 77 |     fig.set_figheight(rows * 4.8)
 78 |     for i, (path, _) in enumerate(order):
 79 |         a_x = axs.flat[i]
 80 |         a_x.specgram(files[path], NFFT=1024, Fs=12000, window=lambda data: data * np.hanning(len(data)), noverlap=512,
 81 |                      vmin=10, vmax=200, cmap=COLORMAP)
 82 |         a_x.set_title(path.rsplit('_', 3)[2])
 83 |         a_x.axes.get_yaxis().set_visible(False)
 84 |         # a_x.get_yaxis().set_major_formatter(tkr.FuncFormatter(lambda x, pos: '{0:g}'.format(x // 1e3)))
 85 |         # a_x.set_ybound(-6000.0, 6000.0)
 86 |     for i in range(len(scores), len(axs.flat)):
 87 |         fig.delaxes(axs.flat[i])
 88 |     fig.tight_layout(rect=[0, 0.03, 1, 0.95])
 89 |     for mfile in glob.glob('*.*m*'):
 90 |         oct_file = open(mfile, 'r')
 91 |         file_d = oct_file.read()
 92 |         oct_file.close()
 93 |         fig.suptitle(re.search(r".+title.+\'(.+)\'", file_d).group(1), fontsize=20)
 94 |     fig.savefig('TDoA_' + path.rsplit('_', 3)[1] + '_spectrogram.pdf', bbox_inches='tight', dpi=50)
 95 |
 96 |
 97 | if __name__ == '__main__':
 98 |     files = {path: load(path) for path in glob.glob('*.wav*')}
 99 |     scores = sorted([(path, score(data)) for path, data in files.items()], key=lambda item: item[1], reverse=True)
100 |     plot(files, scores, cols=3)
101 |


--------------------------------------------------------------------------------
/directTDoA.cfg:
--------------------------------------------------------------------------------
  1 | {
  2 |   "guicolors": {
  3 |     "main_b": "#d9d9d9",
  4 |     "stat_b": "#000000",
  5 |     "main_f": "#000000",
  6 |     "stat_f": "#ff0000",
  7 |     "cons_b": "#000000",
  8 |     "grad": 7,
  9 |     "cons_f": "#00ff00",
 10 |     "thres": 150
 11 |   },
 12 |   "iq": {
 13 |     "pkj": "false",
 14 |     "uc": "false",
 15 |     "mode": "true"
 16 |   },
 17 |   "tcp": {
 18 |     "host": "127.0.0.1",
 19 |     "port": 55554,
 20 |     "duration": 20,
 21 |     "word": "[NORMAL MODE]"
 22 |   },
 23 |   "map": {
 24 |     "std": "#00ff00",
 25 |     "icontype": 1,
 26 |     "blk": "#ff0000",
 27 |     "iconsize": 2,
 28 |     "mapfl": 1,
 29 |     "hlt": "#ffffff",
 30 |     "fav": "#ffff00",
 31 |     "file": "maps/directTDoA_map.jpg",
 32 |     "poi": "#ff7400",
 33 |     "y1": "944.0",
 34 |     "y0": "169.0",
 35 |     "x0": "1495.0",
 36 |     "x1": "2924.0",
 37 |     "mapbox": "streets-v11",
 38 |     "gui": "1429x775+0+27"
 39 |   },
 40 |   "nodes": {
 41 |     "blacklist": [],
 42 |     "whitelist": [
 43 |       "b0d5ccfc816b",
 44 |       "985dad81139c",
 45 |       "689e198fa238",
 46 |       "985dad35082b",
 47 |       "985dad7f54e1",
 48 |       "884aeaf53205",
 49 |       "985dad7f1af5",
 50 |       "884aeadf9485",
 51 |       "985dad488ca5",
 52 |       "88c2556b3d70",
 53 |       "9059af4c1331",
 54 |       "985dad32f160",
 55 |       "985dad818d3e",
 56 |       "985dad7f4a82",
 57 |       "38d2693e706f",
 58 |       "985dad382ec3",
 59 |       "884aeaf5408e",
 60 |       "c4f312a68ad5",
 61 |       "985dad7f5e06",
 62 |       "38d2697cd2cd",
 63 |       "c4f312724e8b",
 64 |       "884aeaf55c98",
 65 |       "40bd322ecc6d",
 66 |       "9884e393ae55",
 67 |       "40bd32e4ffc8",
 68 |       "38d2697cd29d",
 69 |       "b0d5ccfdb8da",
 70 |       "40bd322eb47c",
 71 |       "c4f312755668",
 72 |       "985dad87b076",
 73 |       "b0d5cc571028",
 74 |       "40bd32c8d066",
 75 |       "40bd32e4c880",
 76 |       "40bd32e4d538",
 77 |       "c4f312a678db",
 78 |       "40bd32e93a3e",
 79 |       "9884e38cd8b8",
 80 |       "985dad48e79f",
 81 |       "907065cc0731",
 82 |       "c4f312b9fa95",
 83 |       "38d2697ce5ac",
 84 |       "40bd32e5123d",
 85 |       "c4f312724129",
 86 |       "985dad7f150b",
 87 |       "0479b71beb8a",
 88 |       "38d2697cc238",
 89 |       "985dad7f7ad6",
 90 |       "883f4a9a75ef",
 91 |       "883f4a8c7e84",
 92 |       "883f4aab6d9f",
 93 |       "38d2697cbb2b",
 94 |       "780473832efb",
 95 |       "780473505c0d",
 96 |       "4c3fd33a816e",
 97 |       "9059af54c6d8",
 98 |       "40bd32e94221",
 99 |       "40bd32e54d17",
100 |       "b0d5cc571067",
101 |       "985dad7efeca",
102 |       "38d2697cae44",
103 |       "84eb18e6e373",
104 |       "38d2697cc202",
105 |       "c4f312a68af3",
106 |       "884aeaf593d0",
107 |       "40bd32e4da2a",
108 |       "883f4aabaff6",
109 |       "9059af5e0500",
110 |       "884aeaf52a6a",
111 |       "40bd32e5554b",
112 |       "38d2697ccb6d",
113 |       "883f4aab980e",
114 |       "884aeaf53712",
115 |       "38d269837eca",
116 |       "b0d5cc5711f4",
117 |       "40bd32e53ceb",
118 |       "40bd32c8d2a3",
119 |       "38d2697cbb79",
120 |       "e415f6f6fd1a",
121 |       "e415f6f6d4d0",
122 |       "0cb2b7d6cd80",
123 |       "0035ff8f7152",
124 |       "883f4a9a8729",
125 |       "74e1827b88ed",
126 |       "780473a94c5f",
127 |       "28ec9aeff774",
128 |       "40bd32e93def",
129 |       "38d2697cc6e3",
130 |       "985dad7f54fc",
131 |       "c4f312ba0a2e",
132 |       "0035ff9baf06",
133 |       "3403de631d0d",
134 |       "9884e3930faf",
135 |       "606405357b64",
136 |       "884aeaf59cc6",
137 |       "0035ff8fa43d",
138 |       "ffffffffffff",
139 |       "985dad7f0eb7",
140 |       "04a316eda0a3",
141 |       "40bd322ec32b",
142 |       "c4f312727699",
143 |       "28ec9af0cb86",
144 |       "38d2693e89d5",
145 |       "1442fc102a45",
146 |       "e062346fdb39",
147 |       "38d269837796",
148 |       "b0d5cc571db4",
149 |       "28ec9ae91aec",
150 |       "40bd32e51c9f",
151 |       "40bd32e4d511",
152 |       "e45f01029752",
153 |       "04a316df1bca",
154 |       "c4f312b9ff12",
155 |       "883f4aa8cf37",
156 |       "f045da7def63",
157 |       "88c2556bd4a5",
158 |       "1cba8c980f54",
159 |       "6433db48e8b4",
160 |       "38d2697ccb40",
161 |       "985dad7f2a14",
162 |       "884aeaf58c0f",
163 |       "74e1825d65ae",
164 |       "544a16bbe1cb",
165 |       "6433db5a6a4c",
166 |       "6433db1ba09c",
167 |       "0035ff994d4c",
168 |       "883f4a982497",
169 |       "780473831fb6",
170 |       "c4f312726fdf",
171 |       "78047338b8a5",
172 |       "9059af5c2844",
173 |       "38d269837ec7",
174 |       "6433db20ab39",
175 |       "884aeaf5558a",
176 |       "e062346fe688",
177 |       "3403de9a653c",
178 |       "884aeaf5858e",
179 |       "6433db49bc88",
180 |       "40bd32e9420f",
181 |       "6433db174cbe",
182 |       "3403de81254c",
183 |       "40bd32c8d9ea",
184 |       "b8804f25b074",
185 |       "985dad4279a3",
186 |       "e8eb11d2fb52",
187 |       "1442fc0f98c1",
188 |       "1862e4d0c3f3",
189 |       "40bd322ebe12",
190 |       "78047383479a",
191 |       "883f4aa8d915",
192 |       "c4f312818918",
193 |       "985dad810cef",
194 |       "780473834f23",
195 |       "38d2697cc27d",
196 |       "6433db38a069",
197 |       "40bd32e50db4",
198 |       "544a16e70e44",
199 |       "985dad48d15a",
200 |       "20d7787c8c5e",
201 |       "1442fc0f74f7",
202 |       "985dad7f80cb",
203 |       "e062346fd635",
204 |       "e062346fcf7b",
205 |       "3484e40060d8",
206 |       "40bd32c8d280",
207 |       "985dad7f80a4",
208 |       "0035ff9a436a",
209 |       "1442fc0f664e",
210 |       "985dad4533a3",
211 |       "e415f6f74598",
212 |       "28ec9af1610a"
213 |     ]
214 |   },
215 |   "presets(x0/y1/x1/y0)": {
216 |     "ME": [
217 |       25,
218 |       45,
219 |       65,
220 |       10
221 |     ],
222 |     "US": [
223 |       -125,
224 |       50,
225 |       -66,
226 |       23
227 |     ],
228 |     "W": [
229 |       -179,
230 |       89,
231 |       179,
232 |       -59
233 |     ],
234 |     "SAM": [
235 |       -85,
236 |       15,
237 |       -30,
238 |       -60
239 |     ],
240 |     "AF": [
241 |       -20,
242 |       40,
243 |       55,
244 |       -35
245 |     ],
246 |     "SEAS": [
247 |       85,
248 |       30,
249 |       155,
250 |       -12
251 |     ],
252 |     "O": [
253 |       110,
254 |       -10,
255 |       180,
256 |       -50
257 |     ],
258 |     "NAM": [
259 |       -170,
260 |       82,
261 |       -50,
262 |       13
263 |     ],
264 |     "SAS": [
265 |       60,
266 |       39,
267 |       100,
268 |       4
269 |     ],
270 |     "WR": [
271 |       27,
272 |       72,
273 |       90,
274 |       40
275 |     ],
276 |     "CAM": [
277 |       -120,
278 |       33,
279 |       -50,
280 |       5
281 |     ],
282 |     "EU": [
283 |       -30,
284 |       72,
285 |       55,
286 |       25
287 |     ],
288 |     "EAS": [
289 |       73,
290 |       55,
291 |       147,
292 |       10
293 |     ],
294 |     "ER": [
295 |       90,
296 |       82,
297 |       180,
298 |       40
299 |     ]
300 |   }
301 | }


--------------------------------------------------------------------------------
/getmap.py:
--------------------------------------------------------------------------------
  1 | #!/usr/bin/python
  2 | # -*- coding: utf-8 -*-
  3 | """ get mapbox files, draw POIs and merge to pdf. (linkz 2019)
  4 | usage: ./getmap.py <TDoA-LAT> <TDoA-LON> <known-LAT> <known-LON> <map-style> <filename>
  5 | known bug: maximum 24 mapmarkers are allowed at this time : fixed for IQ recordings < 22 """
  6 |
  7 | import sys
  8 | import os
  9 | import json
 10 | import glob
 11 | import re
 12 | import threading
 13 | import shutil
 14 | import platform
 15 | from io import BytesIO
 16 | import requests
 17 | import numpy as np
 18 | from PIL import Image, ImageDraw, ImageFont
 19 | if sys.version_info[0] == 2:
 20 |     import urllib
 21 | else:
 22 |     import urllib.parse
 23 |
 24 | # <map-style> :
 25 | # streets-v11 / outdoors-v11 / light-v10 / dark-v10
 26 | # satellite-v9 / satellite-streets-v11
 27 | # navigation-preview-day-v4 / navigation-preview-night-v4
 28 | # navigation-guidance-day-v4 / navigation-guidance-night-v4
 29 |
 30 | MAP_TOK = "Your_Mapbox_token_here"
 31 | DATA_L = []
 32 | MAPBOX_ZOOM = {'2': [0, 0], '4': [900, 0], '6': [0, 600], '8': [900, 600]}
 33 | NB_OF_NODES = len(glob.glob1(sys.argv[6].rsplit(os.sep, 1)[0], "*.wav"))
 34 | NB_OF_FILES = 0
 35 | if platform.system() == "Windows":
 36 |     FONT = ImageFont.truetype(r'C:\Windows\Fonts\arial.ttf', 18)
 37 | else:
 38 |     FONT = ImageFont.truetype('Pillow/Tests/fonts/DejaVuSans.ttf', 18)
 39 | NEW_IMAGE = Image.new("RGB", (1800, 1200))
 40 |
 41 | for wavfiles in glob.glob(sys.argv[6].rsplit(os.sep, 1)[0] + os.sep + "*.wav"):
 42 |     for gnssfiles in glob.glob("gnss_pos/*.txt"):
 43 |         if wavfiles.rsplit("_", 2)[1] + ".txt" == gnssfiles.rsplit(os.sep, 2)[1]:
 44 |             DATA_LATLON = {}
 45 |             filent2 = open("gnss_pos/" + gnssfiles.rsplit(os.sep, 2)[1], 'r')
 46 |             data2 = filent2.readlines()
 47 |             DATA_LATLON['lon'] = data2[0].rsplit("[", 1)[1].rsplit("]", 1)[0].rsplit(",", 1)[1]
 48 |             DATA_LATLON['lat'] = data2[0].rsplit("[", 1)[1].rsplit("]", 1)[0].rsplit(",", 1)[0]
 49 |             DATA_LATLON['size'] = "small"
 50 |             DATA_LATLON['symbol'] = "triangle"
 51 |             filent = open(os.getcwd() + os.sep + sys.argv[7], 'r')
 52 |             if wavfiles.rsplit("_", 2)[1] in filent.read():
 53 |                 DATA_LATLON['color'] = "#ff0"
 54 |                 DATA_L.append(DATA_LATLON)
 55 |             elif NB_OF_NODES <= 22:
 56 |                 DATA_LATLON['color'] = "#999"
 57 |                 DATA_L.append(DATA_LATLON)
 58 |
 59 | # TDoA coordinates and style
 60 | DATA_LATLON = dict()
 61 | DATA_LATLON['lon'] = sys.argv[2]
 62 | DATA_LATLON['lat'] = sys.argv[1]
 63 | DATA_LATLON['size'] = "medium"
 64 | DATA_LATLON['color'] = "#d00"
 65 | DATA_LATLON['symbol'] = ""
 66 | DATA_L.append(DATA_LATLON)
 67 |
 68 | # Known point coordinates and style (if filled)
 69 | if sys.argv[3] != "0" and sys.argv[4] != "0":
 70 |     DATA_LATLON = dict()
 71 |     DATA_LATLON['lon'] = sys.argv[4]
 72 |     DATA_LATLON['lat'] = sys.argv[3]
 73 |     DATA_LATLON['size'] = "small"
 74 |     DATA_LATLON['color'] = "#f70"
 75 |     DATA_LATLON['symbol'] = "star"
 76 |     DATA_L.append(DATA_LATLON)
 77 |
 78 | # Mapbox's geojson maker
 79 | GEOJSON = {
 80 |     "type": "FeatureCollection",
 81 |     "features": [
 82 |         {
 83 |             "type": "Feature",
 84 |             "geometry": {
 85 |                 "type": "Point",
 86 |                 "coordinates": [d["lon"], d["lat"]],
 87 |             },
 88 |             "properties": {
 89 |                 "marker-size": d["size"],
 90 |                 "marker-color": d["color"],
 91 |                 "marker-symbol": d["symbol"]
 92 |             },
 93 |         } for d in DATA_L]
 94 | }
 95 |
 96 | # Remove double-quotes on coordinates and convert json to url-style
 97 | GEOJSON = re.sub(r'\"(-?\d+(\.\d+)?)\"', r'\1', json.dumps(GEOJSON))
 98 | if sys.version_info[0] == 2:
 99 |     GEOJSON = urllib.quote(GEOJSON)
100 | else:
101 |     GEOJSON = urllib.parse.quote(GEOJSON)
102 |
103 |
104 | def haversine_distance(lat1, lon1, lat2, lon2):
105 |     """ code source from Dario Radečić https://medium.com/@radecicdario
106 |     https://towardsdatascience.com/heres-how-to-calculate-distance-between-2-geolocations-in-python-93ecab5bbba4 """
107 |     r = 6371
108 |     phi1 = np.radians(lat1)
109 |     phi2 = np.radians(lat2)
110 |     delta_phi = np.radians(lat2 - lat1)
111 |     delta_lambda = np.radians(lon2 - lon1)
112 |     a = np.sin(delta_phi / 2)**2 + np.cos(phi1) * np.cos(phi2) * np.sin(delta_lambda / 2)**2
113 |     res = r * (2 * np.arctan2(np.sqrt(a), np.sqrt(1 - a)))
114 |     return np.round(res, 2)
115 |
116 |
117 | class GetMaps(threading.Thread):
118 |     """ Curl processing routine """
119 |
120 |     def __init__(self, zooming=None, x=None, y=None):
121 |         super(GetMaps, self).__init__()
122 |         self.zoom2 = zooming
123 |         self.x_pos = x
124 |         self.y_pos = y
125 |
126 |     def run(self):
127 |         global NB_OF_FILES
128 |         req = requests.get(
129 |             "https://api.mapbox.com/styles/v1/mapbox/" + sys.argv[5] + "/static/geojson(" + GEOJSON + ')/' + sys.argv[
130 |                 2] + ',' + sys.argv[1] + "," + self.zoom2 + "/900x600?access_token=" + MAP_TOK, timeout=2,
131 |             stream=True)
132 |         if req.status_code == 200:
133 |             new_pic = BytesIO()
134 |             req.raw.decode_content = True
135 |             shutil.copyfileobj(req.raw, new_pic)
136 |             img = Image.open(new_pic)
137 |             NEW_IMAGE.paste(img, (self.x_pos, self.y_pos))
138 |             NB_OF_FILES += 1
139 |             if NB_OF_FILES == 4:
140 |                 draw = ImageDraw.Draw(NEW_IMAGE)
141 |                 text_length = 10.5 * len(sys.argv[1] + " " + sys.argv[2])
142 |                 draw.polygon([(395, 255), (395, 235), (395 + text_length, 235), (395 + text_length, 255)], fill="#222")
143 |                 draw.polygon([(1295, 255), (1295, 235), (1295 + text_length, 235), (1295 + text_length, 255)],
144 |                              fill="#222")
145 |                 draw.polygon([(395, 855), (395, 835), (395 + text_length, 835), (395 + text_length, 855)], fill="#222")
146 |                 draw.polygon([(1295, 855), (1295, 835), (1295 + text_length, 835), (1295 + text_length, 855)],
147 |                              fill="#222")
148 |                 [(draw.text((x, y), sys.argv[1] + " " + sys.argv[2], fill="#fff", font=FONT)) for x in [400, 1300] for y
149 |                  in [235, 835]]
150 |                 # distance between most likely & known point red rectangle label
151 |                 if sys.argv[3] != "-90" and sys.argv[4] != "180":
152 |                     distance = "Distance between TDoA most likely location and map marker = " + str(
153 |                         haversine_distance(float(sys.argv[1]), float(sys.argv[2]), float(sys.argv[3]),
154 |                                            float(sys.argv[4]))) + " km"
155 |                     draw.polygon([(0, 0), (900, 0), (900, 20), (0, 20)], fill="#FFF")
156 |                     draw.text((0, 0), distance, fill="#000", font=FONT)
157 |                 draw.line((900, 0, 900, 1200), fill="#000")
158 |                 draw.line((0, 600, 1800, 600), fill="#000")
159 |                 NEW_IMAGE.save(sys.argv[6].replace("_[[]", "_[").replace("[]]_", "]_").replace(".png", ".pdf"), "PDF",
160 |                                resolution=144, append_images=[NEW_IMAGE])
161 |         else:
162 |             img = Image.new('RGB', (900, 600), (255, 255, 255))
163 |             NEW_IMAGE.paste(img, (self.x_pos, self.y_pos))
164 |             NB_OF_FILES += 1
165 |             if NB_OF_FILES == 4:
166 |                 draw = ImageDraw.Draw(NEW_IMAGE)
167 |                 draw.text((15, 15), "Error: unable to get maps, check Mapbox token", (0, 0, 0), font=FONT)
168 |                 NEW_IMAGE.save(sys.argv[6].replace("_[[]", "_[").replace("[]]_", "]_").replace(".png", ".pdf"), "PDF",
169 |                                resolution=144, append_images=[NEW_IMAGE])
170 |
171 |
172 | if sys.version_info[0] == 2:
173 |     for zoom, placement in MAPBOX_ZOOM.iteritems():
174 |         GetMaps(zoom, placement[0], placement[1]).start()
175 | else:
176 |     for zoom, placement in MAPBOX_ZOOM.items():
177 |         GetMaps(zoom, placement[0], placement[1]).start()
178 |


--------------------------------------------------------------------------------
/kiwirecorder_patch.diff:
--------------------------------------------------------------------------------
  1 | --- kiwirecorder.py	2024-01-14 09:48:45.338711534 +0100
  2 | +++ kiwirecorder.py	2024-01-14 09:36:05.647684241 +0100
  3 | @@ -10,6 +10,10 @@
  4 |  from kiwi import KiwiSDRStream, KiwiWorker
  5 |  from optparse import OptionParser
  6 |  from optparse import OptionGroup
  7 | +import sounddevice
  8 | +
  9 | +stream = sounddevice.OutputStream(48000, 2048, channels=1, dtype='int16')
 10 | +stream.start()
 11 |
 12 |  HAS_RESAMPLER = True
 13 |  try:
 14 | @@ -21,11 +25,12 @@
 15 |
 16 |
 17 |  def _write_wav_header(fp, filesize, samplerate, num_channels, is_kiwi_wav):
 18 | +    samplerate = int(samplerate+0.5);
 19 |      fp.write(struct.pack('<4sI4s', b'RIFF', filesize - 8, b'WAVE'))
 20 |      bits_per_sample = 16
 21 |      byte_rate       = samplerate * num_channels * bits_per_sample // 8
 22 |      block_align     = num_channels * bits_per_sample // 8
 23 | -    fp.write(struct.pack('<4sIHHIIHH', b'fmt ', 16, 1, num_channels, int(samplerate+0.5), byte_rate, block_align, bits_per_sample))
 24 | +    fp.write(struct.pack('<4sIHHIIHH', b'fmt ', 16, 1, num_channels, samplerate, byte_rate, block_align, bits_per_sample))
 25 |      if not is_kiwi_wav:
 26 |          fp.write(struct.pack('<4sI', b'data', filesize - 12 - 8 - 16 - 8))
 27 |
 28 | @@ -151,8 +156,10 @@
 29 |              # For AM, ignore the low pass filter cutoff
 30 |              lp_cut = -hp_cut if hp_cut is not None else hp_cut
 31 |          self.set_mod(mod, lp_cut, hp_cut, self._freq)
 32 | -        if self._options.agc_gain != None:
 33 | -            self.set_agc(on=False, gain=self._options.agc_gain)
 34 | +        if self._options.agc_gain is not None:
 35 | +            self.set_agc(on=False, gain=self._options.agc_gain[0], hang=self._options.agc_gain[1],
 36 | +                         thresh=self._options.agc_gain[2], slope=self._options.agc_gain[3],
 37 | +                         decay=self._options.agc_gain[4])
 38 |          else:
 39 |              self.set_agc(on=True)
 40 |          if self._options.compression is False:
 41 | @@ -267,34 +274,37 @@
 42 |
 43 |              # fp.tell() sometimes returns zero. _write_wav_header writes filesize - 8
 44 |              if filesize >= 8:
 45 | -                _write_wav_header(fp, filesize, int(self._output_sample_rate), self._num_channels, self._options.is_kiwi_wav)
 46 | +                _write_wav_header(fp, filesize, self._output_sample_rate, self._num_channels, self._options.is_kiwi_wav)
 47 |
 48 |      def _write_samples(self, samples, *args):
 49 | -        """Output to a file on the disk."""
 50 | -        now = time.gmtime()
 51 | -        sec_of_day = lambda x: 3600*x.tm_hour + 60*x.tm_min + x.tm_sec
 52 | -        dt_reached = self._options.dt != 0 and self._start_ts is not None and sec_of_day(now)//self._options.dt != sec_of_day(self._start_ts)//self._options.dt
 53 | -        if self._start_ts is None or (self._options.filename == '' and dt_reached):
 54 | -            self._start_ts = now
 55 | -            self._start_time = time.time()
 56 | -            # Write a static WAV header
 57 | -            with open(self._get_output_filename(), 'wb') as fp:
 58 | -                _write_wav_header(fp, 100, int(self._output_sample_rate), self._num_channels, self._options.is_kiwi_wav)
 59 | -            if self._options.is_kiwi_tdoa:
 60 | -                # NB: MUST be a print (i.e. not a logging.info)
 61 | -                print("file=%d %s" % (self._options.idx, self._get_output_filename()))
 62 | -            else:
 63 | -                logging.info("Started a new file: %s" % self._get_output_filename())
 64 | -        with open(self._get_output_filename(), 'ab') as fp:
 65 | -            if self._options.is_kiwi_wav:
 66 | -                gps = args[0]
 67 | -                self._gnss_performance.analyze(self._get_output_filename(), gps)
 68 | -                fp.write(struct.pack('<4sIBBII', b'kiwi', 10, gps['last_gps_solution'], 0, gps['gpssec'], gps['gpsnsec']))
 69 | -                sample_size = samples.itemsize * len(samples)
 70 | -                fp.write(struct.pack('<4sI', b'data', sample_size))
 71 | -            # TODO: something better than that
 72 | -            samples.tofile(fp)
 73 | -        self._update_wav_header()
 74 | +        """Output to a file on the disk OR give me sound ! """
 75 | +        if self._options.audio:
 76 | +            stream.write(np.array(samples, dtype=np.int16))
 77 | +        else:
 78 | +            now = time.gmtime()
 79 | +            sec_of_day = lambda x: 3600*x.tm_hour + 60*x.tm_min + x.tm_sec
 80 | +            dt_reached = self._options.dt != 0 and self._start_ts is not None and sec_of_day(now)//self._options.dt != sec_of_day(self._start_ts)//self._options.dt
 81 | +            if self._start_ts is None or (self._options.filename == '' and dt_reached):
 82 | +                self._start_ts = now
 83 | +                self._start_time = time.time()
 84 | +                # Write a static WAV header
 85 | +                with open(self._get_output_filename(), 'wb') as fp:
 86 | +                    _write_wav_header(fp, 100, self._output_sample_rate, self._num_channels, self._options.is_kiwi_wav)
 87 | +                if self._options.is_kiwi_tdoa:
 88 | +                    # NB: MUST be a print (i.e. not a logging.info)
 89 | +                    print("file=%d %s" % (self._options.idx, self._get_output_filename()))
 90 | +                else:
 91 | +                    logging.info("Started a new file: %s" % self._get_output_filename())
 92 | +            with open(self._get_output_filename(), 'ab') as fp:
 93 | +                if self._options.is_kiwi_wav:
 94 | +                    gps = args[0]
 95 | +                    self._gnss_performance.analyze(self._get_output_filename(), gps)
 96 | +                    fp.write(struct.pack('<4sIBBII', b'kiwi', 10, gps['last_gps_solution'], 0, gps['gpssec'], gps['gpsnsec']))
 97 | +                    sample_size = samples.itemsize * len(samples)
 98 | +                    fp.write(struct.pack('<4sI', b'data', sample_size))
 99 | +                # TODO: something better than that
100 | +                samples.tofile(fp)
101 | +            self._update_wav_header()
102 |
103 |      def _on_gnss_position(self, pos):
104 |          pos_record = False
105 | @@ -371,9 +381,9 @@
106 |          opt_single.server_host = s
107 |          opt_single.status = 0
108 |
109 | -        # time() returns seconds, so add pid and host index to make tstamp unique per connection
110 | +        # time() returns seconds, so add pid and host index to make timestamp unique per connection
111 |          opt_single.timestamp = int(time.time() + os.getpid() + i) & 0xffffffff
112 | -        for x in ['server_port', 'password', 'tlimit_password', 'frequency', 'agc_gain', 'filename', 'station', 'user']:
113 | +        for x in ['server_port', 'password', 'tlimit_password', 'frequency', 'filename', 'station', 'user']:
114 |              opt_single.__dict__[x] = _sel_entry(i, opt_single.__dict__[x])
115 |          l.append(opt_single)
116 |          multiple_connections = i
117 | @@ -567,6 +577,11 @@
118 |                        default=False,
119 |                        action='store_true',
120 |                        help='Also process sound data when in waterfall or S-meter mode (sound connection options above apply)')
121 | +    group.add_option('-a', '--audio',
122 | +                      dest='audio',
123 | +                      default=False,
124 | +                      action='store_true',
125 | +                      help='Get audio output instead of writing to disk (mod by linkz)')
126 |      parser.add_option_group(group)
127 |
128 |      group = OptionGroup(parser, "S-meter mode options", "")
129 | @@ -635,7 +650,7 @@
130 |              if opt.launch_delay != 0 and i != 0 and options[i-1].server_host == options[i].server_host:
131 |                  time.sleep(opt.launch_delay)
132 |              r.start()
133 | -            #logging.info("started sound recorder %d, tstamp=%d" % (i, options[i].timestamp))
134 | +            #logging.info("started sound recorder %d, timestamp=%d" % (i, options[i].timestamp))
135 |              logging.info("started sound recorder %d" % i)
136 |
137 |          for i,r in enumerate(wf_recorders):
138 | @@ -664,6 +679,7 @@
139 |
140 |      logging.debug('gc %s' % gc.garbage)
141 |
142 | +
143 |  if __name__ == '__main__':
144 |      #import faulthandler
145 |      #faulthandler.enable()
146 |


--------------------------------------------------------------------------------
/trim_iq.py:
--------------------------------------------------------------------------------
  1 | #!/usr/bin/python
  2 | # -*- coding: utf-8 -*-
  3 | """ credits: Daniel Ekmann for core code & linkz for GUI code
  4 | usage ./trim_iq.py """
  5 |
  6 | # python 2/3 compatibility
  7 | from __future__ import print_function
  8 | from __future__ import division
  9 | from __future__ import absolute_import
 10 |
 11 | import subprocess
 12 | import struct
 13 | import os
 14 | import glob
 15 | import shutil
 16 | import platform
 17 | import sys
 18 | import argparse
 19 | import io
 20 | from io import BytesIO
 21 | import numpy as np
 22 | import matplotlib.pyplot as plt
 23 | from matplotlib.colors import LinearSegmentedColormap
 24 | from matplotlib.widgets import SpanSelector
 25 | from matplotlib.ticker import FuncFormatter
 26 |
 27 | TRIM_PROC = 1
 28 | FILE_NUMBER = 0
 29 | TOTAL_FILES = len(glob.glob("*.wav"))
 30 | START = 0
 31 | FREQUENCY = float(os.getcwd().rsplit("F", 1)[1])
 32 | GRADIENT = {
 33 |     'red': ((0.0, 0.0, 0.0),
 34 |             (0.077, 0.0, 0.0),
 35 |             (0.16, 0.0, 0.0),
 36 |             (0.265, 1.0, 1.0),
 37 |             (0.403, 1.0, 1.0),
 38 |             (0.604, 1.0, 1.0),
 39 |             (1.0, 1.0, 1.0)),
 40 |
 41 |     'green': ((0.0, 0.0, 0.0),
 42 |               (0.077, 0.0, 0.0),
 43 |               (0.16, 1.0, 1.0),
 44 |               (0.265, 1.0, 1.0),
 45 |               (0.403, 0.0, 0.0),
 46 |               (0.604, 0.0, 0.0),
 47 |               (1.0, 0.764, 0.764)),
 48 |
 49 |     'blue': ((0.0, 0.117, 0.117),
 50 |              (0.077, 1.0, 1.0),
 51 |              (0.16, 1.0, 1.0),
 52 |              (0.265, 0.0, 0.0),
 53 |              (0.403, 0.0, 0.0),
 54 |              (0.604, 1.0, 1.0),
 55 |              (1.0, 1.0, 1.0)),
 56 | }
 57 | COLORMAP = LinearSegmentedColormap('SAColorMap', GRADIENT, 1024)
 58 |
 59 |
 60 | def on_press(event):
 61 |     """ Close IQ preview plot with mouse click. """
 62 |
 63 |     plt.close()
 64 |
 65 |
 66 | def on_mouse_move(event):
 67 |     """ Range selection length measurement. """
 68 |
 69 |     if None not in (event.xdata, event.ydata) and START != 0:
 70 |         if -2 <= round(event.xdata - START, 2) <= 2:
 71 |             span.set_visible(True)
 72 |             span2.set_visible(False)
 73 |         else:
 74 |             span.set_visible(False)
 75 |             span2.set_visible(True)
 76 |
 77 |
 78 | def on_mouse_click(event):
 79 |     """ First click on the spectrogram. """
 80 |
 81 |     global START
 82 |     START = event.xdata
 83 |
 84 |
 85 | def onselect(event1, event2):
 86 |     """ Drag-select procedure on temp IQ stored in memory. """
 87 |
 88 |     global START
 89 |     if float(event2 - event1) <= 2:
 90 |         print ("Period range is too small (less than 2 sec) - deleting " + IQfile)
 91 |         plt.close()
 92 |         os.remove(IQfile)
 93 |     START = 0
 94 |
 95 |
 96 | def onselect2(event10, event20):
 97 |     """ Drag-select procedure on temp IQ stored in memory. """
 98 |
 99 |     global START
100 |     if float(event20 - event10) > 2:
101 |         trim_iq(round(event10, 2), round(event20, 2))
102 |     START = 0
103 |
104 |
105 | def trim_iq(from_block, to_block):
106 |     """ Trim the original IQ file and save it. """
107 |
108 |     global TRIM_PROC
109 |     plt.close()
110 |     block_duration = 512 / 12000.0
111 |     from_idx = int(float(from_block) // block_duration)
112 |     to_idx = int(float(to_block) // block_duration)
113 |     old_f = open(IQfile, 'rb')
114 |     new_f = io.BytesIO()
115 |     new_f.write(b'RIFF')
116 |     new_f.write(struct.pack('<i', (to_idx - from_idx + 1) * 2074 + 28))
117 |     old_f.seek(8)
118 |     new_f.write(old_f.read(28))
119 |     for i in range(from_idx, to_idx + 1):
120 |         old_f.seek(i * 2074 + 36)
121 |         new_f.write(old_f.read(2074))
122 |     old_f.close()
123 |     new_f.seek(0)
124 |     with open(IQfile, 'wb') as f_data:
125 |         shutil.copyfileobj(new_f, f_data)
126 |     # file result preview if requested by user
127 |     if ARGS.get_preview == "y":
128 |         TRIM_PROC = 0
129 |         convert_iq_and_plot_from_mem(IQfile, FILE_NUMBER)
130 |     else:
131 |         TRIM_PROC = 1
132 |
133 |
134 | def convert_iq_and_plot_from_mem(in_file, number):
135 |     """ remove GNSS data from the IQ file and plot it from memory. """
136 |
137 |     global TRIM_PROC, fig, a_x, span, span2
138 |     # Remove GNSS data from the IQ file
139 |     old_f = open(in_file, 'rb')
140 |     old_size = os.path.getsize(in_file)
141 |     data_size = 2048 * ((old_size - 36) // 2074)
142 |     new_f = BytesIO()
143 |     new_f.write(old_f.read(36))
144 |     new_f.write(b'data')
145 |     new_f.write(struct.pack('<i', data_size))
146 |     for i in range(62, old_size, 2074):
147 |         old_f.seek(i)
148 |         new_f.write(old_f.read(2048))
149 |     old_f.close()
150 |     new_f.seek(0, 0)
151 |     data = np.frombuffer(new_f.getvalue(), dtype='int16')
152 |     data = data[0::2] + 1j * data[1::2]
153 |     # Plot the IQ w/o GNSS data
154 |     plt.rcParams['toolbar'] = 'None'
155 |     fig, a_x = plt.subplots()
156 |     plt.specgram(data, NFFT=1024, Fs=12000, window=lambda data: data * np.hanning(len(data)), noverlap=512, vmin=10,
157 |                  vmax=200, cmap=COLORMAP)
158 |     plt.xlabel("Time (s)")
159 |     ticks = FuncFormatter(lambda x, pos: FREQUENCY + (x // 1e3))
160 |     a_x.yaxis.set_major_formatter(ticks)
161 |     a_x.set_ybound(-6000.0, 6000.0)
162 |     if TRIM_PROC == 1:
163 |         plt.title(in_file.rsplit("_", 2)[1] + " - [" + str(number) + "/" + str(TOTAL_FILES) + "]", fontsize=10)
164 |         span = SpanSelector(a_x, onselect, 'horizontal', useblit=True, rectprops=dict(alpha=0.4, facecolor='red'))
165 |         span2 = SpanSelector(a_x, onselect2, 'horizontal', useblit=True, rectprops=dict(alpha=0.4, facecolor='green'))
166 |         fig.canvas.mpl_connect('motion_notify_event', on_mouse_move)
167 |         fig.canvas.mpl_connect('button_press_event', on_mouse_click)
168 |     else:
169 |         plt.gcf().set_facecolor("yellow")
170 |         fig.canvas.mpl_connect('button_press_event', on_press)
171 |         plt.title(in_file.rsplit("_", 2)[1] + " - [" + str(number) + "/" + str(
172 |             TOTAL_FILES) + "]" + " - [trimmed IQ preview]", fontsize=10)
173 |         TRIM_PROC = 1
174 |     plt.show()
175 |
176 |
177 | if __name__ == '__main__':
178 |     PARSER = argparse.ArgumentParser(description='Trim KiwiSDR IQ files.')
179 |     PARSER.add_argument('-o', dest='get_original', action='store', choices=['y', 'n'], default='n',
180 |                         help='Use original IQ files (default=no)')
181 |     PARSER.add_argument('-v', dest='get_preview', action='store', choices=['y', 'n'], default='n',
182 |                         help='Show preview window (default=no)')
183 |     PARSER.add_argument('-p', dest='plot_iq', action='store', choices=['y', 'n'], default='n',
184 |                         help='Run plot_iq script (default=yes)')
185 |     PARSER.add_argument('-r', dest='show_result', action='store', choices=['y', 'n'], default='n',
186 |                         help='Show plot_iq PDF result (default=yes)')
187 |     ARGS = PARSER.parse_args()
188 |
189 |     # Always do the backup of IQ files + spectrogram pdf (if present)
190 |     if not os.path.isdir('./IQ'):
191 |         os.makedirs("IQ")
192 |         for OriginalIQfile in glob.glob("*.wav"):
193 |             shutil.copyfile(OriginalIQfile, "IQ" + os.sep + OriginalIQfile)
194 |         for SPECfile in glob.glob("*spec.pdf"):
195 |             shutil.copyfile(SPECfile, "IQ" + os.sep + SPECfile)
196 |
197 |     # Restore the IQ files if requested by user
198 |     if ARGS.get_original == "y":
199 |         for IQfile in glob.glob("IQ" + os.sep + "*.wav"):
200 |             shutil.copyfile(IQfile, IQfile.rsplit(os.sep, 1)[1])
201 |
202 |     # Compute all IQ files in the current directory
203 |     for IQfile in glob.glob("*.wav"):
204 |         FILE_NUMBER += 1
205 |         convert_iq_and_plot_from_mem(IQfile, FILE_NUMBER)
206 |
207 |     # Run plot_iq.py to get the spectrogram pdf file using the new trimmed files if requested by user
208 |     if ARGS.plot_iq == "y":
209 |         with open(os.devnull, 'w') as fp:
210 |             subprocess.call([sys.executable, 'plot_iq.py'], shell=False, stdout=fp)
211 |
212 |     # Show the spectrogram pdf file if requested by user
213 |     if ARGS.show_result == "y":
214 |         if platform.system() == "Windows":
215 |             os.system('start' + ' TDoA_' + str(IQfile.rsplit("_", 3)[1]) + '_spec.pdf')
216 |         elif platform.system() == "Darwin":
217 |             subprocess.Popen(["open", 'TDoA_' + str(IQfile.rsplit("_", 3)[1]) + '_spec.pdf'])
218 |         else:
219 |             subprocess.Popen(["xdg-open", 'TDoA_' + str(IQfile.rsplit("_", 3)[1]) + '_spec.pdf'])
220 |


--------------------------------------------------------------------------------
/microkiwi_patch.diff:
--------------------------------------------------------------------------------
  1 | --- microkiwi_waterfall.py	2021-06-26 07:48:51.769275069 +0200
  2 | +++ microkiwi_waterfall.py	2021-06-26 07:48:51.769275069 +0200
  3 | @@ -1,30 +1,61 @@
  4 | -import numpy as np
  5 | -import struct
  6 | +#!/usr/bin/python
  7 | +# -*- coding: utf-8 -*-
  8 | +""" Here is the IS0KYB microkiwi_waterfall script, modified to use python instead of jupyther notebook """
  9 | +
 10 | +# python 2/3 compatibility
 11 | +from __future__ import print_function
 12 | +from __future__ import division
 13 | +from __future__ import absolute_import
 14 |
 15 | -import array
 16 | -import logging
 17 | +import numpy as np
 18 |  import socket
 19 |  import struct
 20 |  import time
 21 | +import matplotlib.pyplot as plt
 22 | +from matplotlib.colors import LinearSegmentedColormap
 23 | +import io
 24 |  from datetime import datetime
 25 | -
 26 |  from kiwi import wsclient
 27 | -
 28 |  import mod_pywebsocket.common
 29 |  from mod_pywebsocket.stream import Stream
 30 |  from mod_pywebsocket.stream import StreamOptions
 31 | -
 32 |  from optparse import OptionParser
 33 | +from mpl_toolkits.axes_grid1 import make_axes_locatable
 34 | +
 35 | +processfailed = False
 36 | +
 37 | +cdict1 = {
 38 | +    'red': ((0.0, 0.0, 0.0),
 39 | +            (0.2, 0.0, 0.0),
 40 | +            (0.4, 1.0, 1.0),
 41 | +            (0.6, 1.0, 1.0),
 42 | +            (0.8, 1.0, 1.0),
 43 | +            (1.0, 1.0, 1.0)),
 44 | +
 45 | +    'green': ((0.0, 0.0, 0.0),
 46 | +              (0.2, 0.0, 0.0),
 47 | +              (0.4, 1.0, 1.0),
 48 | +              (0.6, 0.0, 0.0),
 49 | +              (0.8, 0.0, 0.0),
 50 | +              (1.0, 0.764, 0.764)),
 51 | +
 52 | +    'blue': ((0.0, 0.0, 0.0),
 53 | +             (0.2, 1.0, 1.0),
 54 | +             (0.4, 0.0, 0.0),
 55 | +             (0.6, 0.0, 0.0),
 56 | +             (0.8, 1.0, 1.0),
 57 | +             (1.0, 1.0, 1.0)),
 58 | +}
 59 | +
 60 | +cmap = LinearSegmentedColormap('SAColorMap', cdict1, 1024)
 61 |
 62 |  parser = OptionParser()
 63 | -parser.add_option("-f", "--file", dest="filename", type=str,
 64 | -                  help="write waterfall data to binary FILE", metavar="FILE")
 65 |  parser.add_option("-s", "--server", type=str,
 66 |                    help="server name", dest="server", default='192.168.1.82')
 67 |  parser.add_option("-p", "--port", type=int,
 68 |                    help="port number", dest="port", default=8073)
 69 |  parser.add_option("-l", "--length", type=int,
 70 | -                  help="how many samples to draw from the server", dest="length", default=100)
 71 | +                  help="how many samples to draw from the server", dest="length", default=200)
 72 |  parser.add_option("-z", "--zoom", type=int,
 73 |                    help="zoom factor", dest="zoom", default=0)
 74 |  parser.add_option("-o", "--offset", type=int,
 75 | @@ -32,126 +63,124 @@
 76 |  parser.add_option("-v", "--verbose", type=int,
 77 |                    help="whether to print progress and debug info", dest="verbosity", default=0)
 78 |
 79 | -
 80 |  options = vars(parser.parse_args()[0])
 81 | -
 82 | -if 'filename' in options:
 83 | -    filename = options['filename']
 84 | -else:
 85 | -    filename = None
 86 | -
 87 |  host = options['server']
 88 |  port = options['port']
 89 | -print "KiwiSDR Server: %s:%d" % (host,port)
 90 | +
 91 |  # the default number of bins is 1024
 92 |  bins = 1024
 93 | -print "Number of waterfall bins: %d" % bins
 94 | -
 95 |  zoom = options['zoom']
 96 | -print "Zoom factor:", zoom
 97 | -
 98 | -offset_khz = options['start'] # this is offset in kHz
 99 | -
100 | -full_span = 30000.0 # for a 30MHz kiwiSDR
101 | -if zoom>0:
102 | -    span = full_span / 2.**zoom
103 | +offset_khz = options['start']  # this is offset in kHz
104 | +full_span = 30000  # for a 30MHz kiwiSDR
105 | +if zoom > 0:
106 | +    span = full_span // 2.**zoom
107 |  else:
108 | -	span = full_span
109 | -
110 | -rbw = span/bins
111 | -if offset_khz>0:
112 | -#	offset = (offset_khz-span/2)/(full_span/bins)*2**(zoom)*1000.
113 | -	offset = (offset_khz+100)/(full_span/bins)*2**(4)*1000.
114 | -	offset = max(0, offset)
115 | +    span = full_span
116 | +rbw = span//bins
117 | +if offset_khz > 0:
118 | +    offset = (offset_khz+100)//(full_span//bins)*2**4*1000.
119 | +    offset = max(0, offset)
120 |  else:
121 | -	offset = 0
122 | -
123 | -print span, offset
124 | -
125 | -center_freq = span/2+offset_khz
126 | -print "Center frequency: %.3f MHz" % (center_freq/1000)
127 | -
128 | -now = str(datetime.now())
129 | +    offset = 0
130 | +center_freq = span//2+offset_khz
131 | +now = b'(datetime.now()'
132 |  header = [center_freq, span, now]
133 |  header_bin = struct.pack("II26s", *header)
134 |
135 | -print "Trying to contact server..."
136 |  try:
137 |      mysocket = socket.socket()
138 |      mysocket.connect((host, port))
139 |  except:
140 | -    print "Failed to connect"
141 | -    exit()
142 | -print "Socket open..."
143 | +    print("Failed to connect")
144 | +    exit()
145 |
146 |  uri = '/%d/%s' % (int(time.time()), 'W/F')
147 |  handshake = wsclient.ClientHandshakeProcessor(mysocket, host, port)
148 |  handshake.handshake(uri)
149 | -
150 |  request = wsclient.ClientRequest(mysocket)
151 |  request.ws_version = mod_pywebsocket.common.VERSION_HYBI13
152 | -
153 |  stream_option = StreamOptions()
154 |  stream_option.mask_send = True
155 |  stream_option.unmask_receive = False
156 | -
157 |  mystream = Stream(request, stream_option)
158 | -print "Data stream active..."
159 | -
160 |
161 |  # send a sequence of messages to the server, hardcoded for now
162 |  # max wf speed, no compression
163 | -msg_list = ['SET auth t=kiwi p=', 'SET zoom=%d start=%d'%(zoom,offset),\
164 | -'SET maxdb=0 mindb=-100', 'SET wf_speed=4', 'SET wf_comp=0']
165 | +msg_list = ['SET auth t=kiwi p=', 'SET zoom=%d start=%d' % (zoom, offset),
166 | +            'SET maxdb=0 mindb=-100', 'SET wf_speed=4', 'SET wf_comp=0']
167 |  for msg in msg_list:
168 |      mystream.send_message(msg)
169 | -print "Starting to retrieve waterfall data..."
170 |  # number of samples to draw from server
171 |  length = options['length']
172 |  # create a numpy array to contain the waterfall data
173 |  wf_data = np.zeros((length, bins))
174 |  binary_wf_list = []
175 |  time = 0
176 | -while time<length:
177 | +
178 | +while time < length:
179 |      # receive one msg from server
180 | -    tmp = mystream.receive_message()
181 | -    if "W/F" in tmp: # this is one waterfall line
182 | -        tmp = tmp[16:] # remove some header from each msg
183 | +    try:
184 | +        tmp = mystream.receive_message()
185 | +    except:
186 | +        processfailed = True
187 | +        break
188 | +    if b'W/F' in tmp:  # this is one waterfall line
189 | +        tmp = tmp[16:]  # remove some header from each msg
190 | +        print("received sample")
191 |          if options['verbosity']:
192 | -            print time,
193 | -        #spectrum = np.array(struct.unpack('%dB'%len(tmp), tmp) ) # convert from binary data to uint8
194 | -        spectrum = np.ndarray(len(tmp), dtype='B', buffer=tmp) # convert from binary data to uint8
195 | -        if filename:
196 | -            binary_wf_list.append(tmp) # append binary data to be saved to file
197 | -        #wf_data[time, :] = spectrum-255 # mirror dBs
198 | +            print(time),
199 | +        spectrum = np.array(struct.unpack('%dB' % len(tmp), tmp))  # convert from binary data to uint8
200 | +        # spectrum = np.ndarray(len(tmp), dtype='B', buffer=tmp)  # convert from binary data to uint8
201 | +        binary_wf_list.append(tmp)  # append binary data to be saved to file
202 | +        # wf_data[time, :] = spectrum-255 # mirror dBs
203 |          wf_data[time, :] = spectrum
204 |          wf_data[time, :] = -(255 - wf_data[time, :])  # dBm
205 |          wf_data[time, :] = wf_data[time, :] - 13  # typical Kiwi wf cal
206 |          time += 1
207 | -    else: # this is chatter between client and server
208 | -        #print tmp
209 | +    else:  # this is chatter between client and server
210 |          pass
211 |
212 |  try:
213 |      mystream.close_connection(mod_pywebsocket.common.STATUS_GOING_AWAY)
214 |      mysocket.close()
215 |  except Exception as e:
216 | -    print "exception: %s" % e
217 | -
218 | -
219 | -avg_wf = np.mean(wf_data, axis=0) # average over time
220 | +    print("exception: %s" % e)
221 |
222 | +avg_wf = np.mean(wf_data, axis=0)  # average over time
223 |  p95 = np.percentile(avg_wf, 95)
224 |  median = np.percentile(avg_wf, 50)
225 | +maxsig = np.max(wf_data)
226 | +minsig = np.min(wf_data)
227 |
228 | -print "Average SNR computation..."
229 | -print "Waterfall with %d bins: median= %f dB, p95= %f dB - SNR= %f rbw= %f kHz" % (bins, median, p95,p95-median, rbw)
230 | -
231 | +# print "Waterfall with %d bins: median= %f dB, p95= %f dB - SNR= %f rbw= %f kHz" % (bins, median, p95,p95-median, rbw)
232 | +print("SNR: %i dB [median: %i dB, p95: %i dB, high: %i dBm, low: %i dBm]" % (p95 - median, median, p95, maxsig, minsig))
233 |
234 | -if filename:
235 | -    print "Saving binary data to file..."
236 | -    with open(filename, "wb") as fd:
237 | -    	fd.write(header_bin) # write the header info at the top
238 | -        for line in binary_wf_list:
239 | -            fd.write(line)
240 | -print "All done!"
241 | +fd = io.BytesIO()  # no more file to write on disk
242 | +fd.write(header_bin)  # write the header info at the top
243 | +for line in binary_wf_list:
244 | +    fd.write(line)
245 | +
246 | +fd.seek(0)
247 | +buff = fd.read()
248 | +header_len = 8 + 26  # 2 unsigned int for center_freq and span: 8 bytes PLUS 26 bytes for datetime
249 | +length = len(buff[header_len:])
250 | +n_t = length // bins
251 | +header = struct.unpack('2I26s', buff[:header_len])
252 | +data = struct.unpack('%dB' % length, buff[header_len:])
253 | +waterfall_array = np.reshape(np.array(data[:]), (n_t, bins))
254 | +waterfall_array -= 255
255 | +plt.figure(figsize=(14, 5))
256 | +plt.yticks(np.arange(0, 0, step=1))
257 | +plt.xlabel('MHz')
258 | +plt.xticks(np.linspace(0, bins, 31), np.linspace(0, 30, num=31, endpoint=True, dtype=int))
259 | +plt.pcolormesh(waterfall_array[:, 1:], cmap=cmap, vmin=minsig+30, vmax=maxsig+30)
260 | +if processfailed:
261 | +    plt.title("Sorry, measurement failed on this Kiwi, no slot available, try later")
262 | +else:
263 | +    plt.title("HF waterfall @ " + str(host) + " - [SNR: %i dB" % (p95 - median) + "]")
264 | +divider = make_axes_locatable(plt.gca())
265 | +cax = divider.append_axes("right", "2%", pad="1%")
266 | +clb = plt.colorbar(cax=cax)
267 | +clb.ax.set_title('dBm')
268 | +plt.tight_layout()
269 | +plt.show()
270 |


--------------------------------------------------------------------------------
/README.md:
--------------------------------------------------------------------------------
  1 | # directTDoA v7.20
  2 |
  3 | >### 03 Jan 2024 - KiwiSDR software version > v1.647 broke directTDoA (no GNSS/GPS detected because of IQ wav incompatibility)
  4 | >### 12 Jan 2024 - Good news! Christoph, our TDoA master fixed the issue (was a bug in kiwirecorder.py)
  5 | >#### FIX : https://github.com/jks-prv/kiwiclient/commit/bc189087cf503820d56ddcc0f8781d7eed1b6337
  6 | >#### The fix is simple and can be done by hand, just edit your kiwiclient/kiwirecorder.py file if you want a quick one !
  7 | ---
  8 | ![directTDoA picture](http://linkz.ddns.net/directTDoA.png)
  9 |
 10 | This software is JUST a python 2/3 GUI designed to compute TDoA runs on shortwave radio transmissions using remote (GPS enabled) KiwiSDR receivers around the World.
 11 |
 12 | > TDoA = Time Difference of Arrival .. (in this case: the Arrival of shortwave radio transmissions)
 13 |
 14 | >## Linux users : GNU Octave version < 8 only !
 15 | > else, read_kiwi_iq_wav.cc will not compile - fix in progress...
 16 |
 17 | ## KNOWN ISSUES:
 18 |
 19 | #### 1/ If you plan to use the software on a machine without a sound card then you must comment out lines 15 & 16 in `/directTDoA/kiwiclient/kiwirecorder.py`
 20 | `#stream = sounddevice.OutputStream(48000, 2048, channels=1, dtype='int16')`
 21 |
 22 | `#stream.start()`
 23 |
 24 | #### 2/ On recent versions of Octave the handling of the font size has been changed (pixels Vs points) and you may find that they are too large in the final file, you can reduce the fontsize values on lines 41, 42 & 154 in `/directTDoA/TDoA/m/tdoa_plot_map.m`
 25 |
 26 | ---
 27 | ## WINDOWS
 28 |
 29 | ##### The decision was made not to support installation from the repository.
 30 |
 31 | 1/ Download the latest [directTDoA-windows.zip](https://github.com/llinkz/directTDoA/releases), unzip and extract it
 32 |
 33 | 2/ Create your own [Mapbox.com](https://account.mapbox.com/auth/signup/) account, go to account and get/create a default public token then edit [getmap.py](https://github.com/llinkz/directTDoA/blob/master/getmap.py#L30) and modify `MAP_TOK` variable with your default public token
 34 | > NOTE: directTDoA use [Static Images API](https://docs.mapbox.com/api/maps/static-images/) and you'll get 50000 free monthly requests
 35 |
 36 | 3/ double-click on `directTDoA.bat`
 37 |
 38 | >#### IMPORTANT: You must use only this method to launch the program to avoid file path issues.
 39 | #### This .zip archive contains all the necessary files already patched and compiled and also includes light versions of GNU Octave and python, so no need to install the full versions of the last two on your machine. The unzipped archive is 272 MB, compared to ~2 GB in the other installer way.
 40 |
 41 | ---
 42 | ## LINUX
 43 |
 44 | 1/ Install python 3 and python3-pip using your package manager
 45 |
 46 | 2/ Install GNU octave (important: only versions < 8)
 47 |
 48 | 3/ Install git, patch, gcc, base-devel, ttf-dejavu, gcc-fortran, tk, portaudio, xdg-utils, epdfview, fltk, liboctave-dev
 49 |
 50 | 4/ `git clone --recursive https://github.com/llinkz/directTDoA && cd directTDoA`
 51 |
 52 | 5/ `./setup.sh`
 53 | > ####This setup script will install python modules, compile the necessary .oct file and apply some files patchs
 54 | > ####IMPORTANT: The octave files compilation process takes a lot of time, be patient, ignore warnings and don't stop the script
 55 |
 56 | 6/ Create your own [Mapbox.com](https://account.mapbox.com/auth/signup/) account, go to account and get/create a default public token then edit file named [getmap.py](https://github.com/llinkz/directTDoA/blob/master/getmap.py#L30) and modify `MAP_TOK` variable with your default public token  (directTDoA use [Static Images API](https://docs.mapbox.com/api/maps/static-images/) and you'll get 50000 free monthly requests)
 57 |
 58 | 7/ `./directTDoA.py`
 59 |
 60 | ---
 61 | ## MAC OS X
 62 |
 63 | * REQUIREMENT 	Xcode + Homebrew (https://brew.sh/index_fr)
 64 |
 65 | 1/ Install Homebrew, in terminal : `/usr/bin/ruby -e "$(curl -fsSL https://raw.githubusercontent.com/Homebrew/install/master/install)"`
 66 |
 67 | 2/ Install Python, in terminal : `brew install python@2` or `brew install python@3`
 68 |
 69 | 3/ Install GNU Octave in Terminal : `brew install octave`
 70 |
 71 | 4/ `git clone --recursive https://github.com/llinkz/directTDoA && cd directTDoA`
 72 |
 73 | 5/ `./setup.sh`
 74 | > ####This setup script will install python modules, compile the necessary .oct file and apply some files patchs
 75 | > ####IMPORTANT: The octave files compilation process takes a lot of time, be patient, ignore warnings and don't stop the script
 76 |
 77 | 6/ Create your own [Mapbox.com](https://account.mapbox.com/auth/signup/) account, go to account and get/create a default public token then edit file named [getmap.py](https://github.com/llinkz/directTDoA/blob/master/getmap.py#L30) and modify `MAP_TOK` variable with your default public token  (directTDoA use [Static Images API](https://docs.mapbox.com/api/maps/static-images/) and you'll get 50000 free monthly requests)
 78 |
 79 | 7/ `./directTDoA.py`
 80 |
 81 | ---
 82 | ## LICENSE
 83 | * This python GUI code has been written and released under the "do what the f$ck you want with it" license
 84 | ---
 85 | ## CHANGE LOG
 86 | * v1.00-1.50 : first working version, basic, static map, manual host adding, hardcoded coordinates, manual octave code run etc...
 87 | * v2.00 : current work, update & dynamic maps full of GPS enabled nodes, auto octave code run, easier to use
 88 | * v2.10beta : adding differents maps that can be choosed by the user, early work on SNR and tiny waterfall for nodes
 89 | * v2.20: adding favorite/blacklist node management, popup menu when clicking a node gives: add for TDoA proc + Open KiwiSDR in browser
 90 | * v2.21: reducing the map boundaries red rectangle 'sensivity' when mouse is near main window borders
 91 | * v2.30: adding node color change possible + code clean-up + adding a popup window telling you forgot to choose your map boundaries before starting the IQ recording + Popup menus are now disabled (Add/Open) if the node has no slot available + Added a gray scale map more brighter
 92 | * v2.31: bugfix on checkfilesize process
 93 | * v2.32: adding a restart GUI button
 94 | * v2.33: adding MacOS X compatibility, thx Nicolas M.
 95 | * v2.40: known points (world capitals) listing is now a file, format is 'name,lat,lon' - easier for you to add yours :-)
 96 | * v2.41: update process modified due to missing tags for some nodes in kiwisdr.com/public page
 97 | * v2.42: forgot some conditions for MacOS compatibility  oops  thanks Nicolas M. again  :-)
 98 | * v2.43: auto create the directTDoA_server_list.db file at 1st start, file does not need to be in the repo anymore
 99 | * v2.44: MacOS tested OK, code cleanup + warning about missing GPS timestamps in IQ recordings  -uglymaps +kickass NASA maps
100 | * v2.50: some TODO list items coded or fixed
101 | * v2.60: map update now based on John's json listing + GPS fix/min map filter + nodes are identified by IDs, no hosts anymore + no .png file creation (patch) + no more gnss_pos.txt backup and no more TDoA/gnss_pos/ purge
102 | * v2.70: Octave subprocess management modified (no more octave defunct remaining in "ps aux" now) + stdout & stderr saved in the same "TDoA/iq/<backup>/TDoA_<freq>.txt" file
103 | * v2.71: each node color brightness is now based on its latest GPS fix/min value, it will become darker when fix/min will go towards "0" + my own kiwiSDR coordinates more accurate
104 | * v2.72: Adding the SNR values of each node from linkfanel's (JSON) database + Color points (nodes) change in brightness according to the SNR, minimum=0 <darker - brighter> maximum=35? (version not released)
105 | * v2.80: Listing update is now made from both linkfanel's (JSON) databases only (GPS enabled nodes list + SNR values) + adding regexp to create TDoA_id (parsing callsigns), IPs and node various coordinates format (version not released)
106 | * v2.90: Code clean-up + SNR values are now only from IS0KYB (JSON) database + count TDoA runs at start + adding a ./recompute.sh script to backup dir + directTDoA node db now in JSON format + add map legend + popup menu font color managed for more readibility + new maps
107 | * v3.00: More code clean-up and as the GUI has changed a lot recently, it's now entering the v.3xx version range
108 | * v3.10: Removed "20 kHz wide audio bandwidth mode" set KiwiSDRs from the node list, incompatible with TDoA at this time (2jan19) + reachability & GPS_good, fixes_min, user, users_max values are now dynamic when node is clicked on map (timeout/host not found/obsolete proxy data)
109 | * v3.20: Better management of clicked nodes (checking offline=yes/no + TDoA_ch>=1 + fixes_min>0) + default IQ rec BW in config file added + possibility to restart the IQ rec process + Marco/Pierre websites checked before update process start + current release version check menu added
110 | * v3.21: the popup when map boundaries are set has been removed - adding mode informations in the TDoA map result title - minor bug fixes with the bandwidth default/current setting
111 | * v3.22: map boundaries informations back, as label..
112 | * v3.23: bug fixes with add/remove fav/black process..
113 | * v3.24: allowing the possibility to "Open" a node in browser even if 0 GPS fixes were reported at instant T + minor date modification on TDoA output file title + minor text corrections
114 | * v4.00: no more GUI restart after TDoA runs (node list is kept intact) + Listen/Demod mode added, **requires python modules _pygame_ (for all) + _scipy_ (for MacOS X), new file _KiwiSDRclient.py_ also required** + possibility to remove a single node from the list + purge button added + check version runned on software start + minor fixes on many routines
115 | * v4.10: "Restart Rec" is now "Stop Rec" instead (it saves IQ files and generate .m file only) + added "Abort TDoA" routine so you can stop a previewed bad result octave process w/o having to restart full GUI + minor mods on checkversion(), float(frequency) and restart/close GUI + 200Hz high pass filter block commented out and empty known point block added in proc.m files
116 | * v4.18: early ultimateTDoA mode dev, adding a necessary patch for TDoA/kiwiclient/kiwiworker.py to bypass returned errors causing full IQ recording process freezes (KiwiBadPasswordError & KiwiDownError) **to apply run: _patch -i kiwiworker_patch.diff ./TDoA/kiwiclient/kiwiworker.py_**
117 | * v4.19: adding another patch for TDoA/m/tdoa_plot_map.m to display the 'most likely position' string in the final pdf title + exchanging lon and lat values position for better reading - **Note: that patch already contains the nopng patch previously released**
118 | * v4.20: introducing new **ultimateTDoA** mode (massive IQ recordings without octave run from the GUI), nodes selection using the same way as defining TDoA map boundaries, all IQ files saved and compute_ultimate.sh dynamic bash script created in same ./TDoA/iq/subdirectory + recomputed pdf files now containing a timestamp so you'll keep all of them (instead of overwriting the only ./TDoA/pdf one)
119 | * v5.00: big code optimization + adding waterfall/SNR measurement + removing Marco website source + keyboard shortcuts + filter/color/icon/add rem fav/blk changes w/o restart - better precision on map (coordinates with decimals) + highlight on selected nodes + plot_iq.py script (plotting IQ spectrograms w/o GPS ticks) + GUI colors management
120 |          + mapbox.com world maps in final results + trim_iq.py script to modify the recorded IQ files + Sorcerer TCP client for ALE auto-detect & auto-compute TDoAs
121 | * v5.10: removed KiwiSDR nodes "names" from .db files + compute_ultimate script has been transformed into GUI with plot_iq now only displaying the selected nodes + adding command arguments to trim_iq.py script (./trim_iq.py -h ,for help)
122 | * v5.20: "directTDoA_v5.xx" now displayed on the KiwiSDR target's userlist when connected + simplification of the node rec-list management + adding a checkbox to automatically start (or not) _compute_ultimate.py_ script when "Stop Rec" button is clicked + extra command on KiwiSDR first line popup to add the node even if it has _fixes_min=0_
123 |          + new _has_gps_ routine in both _plot_iq.py_ & _compute_ultimate.py_ + bug fix: regexp wrongly detecting LON + bug fix: if Sorcerer TCP client checkbox is unchecked while recording, no more endless record session.
124 | * v6.00: Listen mode (AM/LSB/USB) is back, to get it working you must apply a patch: `patch -i kiwirecorder_patch.diff ./kiwiclient/kiwirecorder.py` from directTDoA dir and install sounddevice + samplerate python modules with `python -m pip install sounddevice samplerate` + some python 2 Vs. python 3 bug fixes + bug fixed on map update process + .desktop files creation removed
125 | * v6.10: Restart GUI routine modified + less CMD windows for Windows OS users (using pythonw instead of python) + bug fix that caused the map to move suddenly far away when selecting a node (problem only noticed on Windows OS) + no more auto-PlotIQ() start on ultimateTDoA runs + modifications of the .bat files for Windows OS users (CPU affinity of the python processes now set towards a single one, the allocation on several generated a delay in the starting of the IQ records)
126 | * v6.20: User demand and personal use: added functionality to manage the overlapping of icons on the map. Now when you click near a cluster of multiple nodes, a menu will appear and allow you to choose the one you really want + some GUI design changes + bug fix on map locations search (avoid multiple displayed)
127 | * v7.00: Adding USB/LSB/CW/AM/2kHz/4kHz/6kHz/8kHz IQ BW presets + display bug fix for known places on map + adding recorded nodes Vs selected nodes counter + recording time in file size window + IQ rec length max limit set to 120 seconds (just in case) + TCP client modified, possibility to change the trigger word (regexp supported) + PDF title mods + remember GUI size & position on close + MAP & SNR update only via KiwiSDR.com/public now + nognss.py script added, to remove GNSS ticks from the IQs so files can get opened and demodulated fine
128 | * v7.01: Bug fix on map update because of a single KiwiSDR node using https (ofc it just happened after the v7.00 release - haha)
129 | * v7.02: Small but important fix
130 | * v7.10: Bug fix on Start/Stop Listen function + TKinter exception at start fixed + modified patches for wavreader.py & tdoa_plot_map.m + more map POIs + more recording mode choices + legend showing current TDoA algo + files directories shortcut menu + some ultimateTDoA interface improvements
131 | * v7.20: TDoA broken because of early 2024 software mods, a bug was fixed in kiwirecorder.py (credit: Christoph Mayer, Thanks !) - only kiwirecorder_patch.diff has been modified (we will still use an old kiwiclient version) - apparently Listen mode is not working anymore - this version is only for bug correction.
132 | ---
133 | ## Thanks
134 | * Christoph Mayer @ https://github.com/hcab14/TDoA for the main TDoA code, excellent work and thanks for the public release !
135 | * John Seamons, KiwiSDR developper @ https://github.com/jks-prv
136 | * Dmitry Janushkevich @ https://github.com/dev-zzo/kiwiclient for the code that I've modified to work with the GUI
137 | * Marco Cogoni (IS0KYB) for the microkiwi_waterfall.py code that I've modified to work directly via python
138 | * Nicolas M. for the MAC OS X directTDoA installing procedure
139 |
140 | ## Special Thanks
141 | * Daniel Ekmann, naturally designated as a beta tester, for the help on coding, feedbacks and suggestions since the beginning.
142 |


--------------------------------------------------------------------------------
/directTDoA_server_list.db:
--------------------------------------------------------------------------------
  1 | [
  2 | {"mac": "9059af5c2844", "url": "kiwisdr.r7d.xyz:8073", "id": "ZS6ETA", "snr": "14", "lat": "-25.850000", "lon": "28.210000"},
  3 | {"mac": "6433db1f85a7", "url": "93.41.148.192:8073", "id": "JN70iq", "snr": "11", "lat": "40.670139", "lon": "14.719914"},
  4 | {"mac": "40bd32e94227", "url": "apx.twrmon.net:8073", "id": "FM05os", "snr": "17", "lat": "35.760000", "lon": "-78.790000"},
  5 | {"mac": "e415f6f74898", "url": "119.18.20.124:8073", "id": "VK3OQ", "snr": "15", "lat": "-35.808583", "lon": "144.222015"},
  6 | {"mac": "9059af5e0500", "url": "lounix.net:8073", "id": "KD4HSO", "snr": "14", "lat": "38.934530", "lon": "-94.656210"},
  7 | {"mac": "883f4aa8f046", "url": "kiwisdr.itfais.com:8073", "id": "KT4RS", "snr": "21", "lat": "36.500000", "lon": "-81.300000"},
  8 | {"mac": "74e1827b88ed", "url": "arcticsdr.proxy.kiwisdr.com:8073", "id": "KQ40qr", "snr": "16", "lat": "70.730000", "lon": "29.350000"},
  9 | {"mac": "38d2697cae0e", "url": "kphsdr.com:8072", "id": "CM88mc", "snr": "6", "lat": "38.100000", "lon": "-122.950000"},
 10 | {"mac": "78047383804f", "url": "173.48.154.170:8073", "id": "KA1GXR", "snr": "21", "lat": "42.260000", "lon": "-71.500000"},
 11 | {"mac": "1442fc0fd7c7", "url": "sdr.hfunderground.com:8078", "id": "W3HFU/6", "snr": "23", "lat": "39.704000", "lon": "-76.974000"},
 12 | {"mac": "4c3fd33a816e", "url": "kiwibsb.ddns.net:8073", "id": "PT2FHC", "snr": "22", "lat": "-15.710000", "lon": "-47.820000"},
 13 | {"mac": "38d2697cc250", "url": "ciw321.cfars.ca:8174", "id": "VE6JY2", "snr": "16", "lat": "53.740000", "lon": "-112.820000"},
 14 | {"mac": "6433db38a07b", "url": "81.166.137.148:8073", "id": "JO28tu", "snr": "13", "lat": "58.843300", "lon": "5.597590"},
 15 | {"mac": "985dad48b1b1", "url": "kiwisdr.yensaw.net:8073", "id": "IO77VQ", "snr": "10", "lat": "57.695916", "lon": "-4.246218"},
 16 | {"mac": "985dad2b5d9d", "url": "rio.f5.si:8073", "id": "JA1GJD", "snr": "12", "lat": "35.175205", "lon": "137.040611"},
 17 | {"mac": "985dad810cef", "url": "la3rk.dyndns.org:8073", "id": "LA3RK", "snr": "34", "lat": "59.938200", "lon": "10.636200"},
 18 | {"mac": "e0623466fa5c", "url": "kiwisdr2541.ddns.net:8073", "id": "G7JHU", "snr": "11", "lat": "53.230000", "lon": "0.330000"},
 19 | {"mac": "6433db5a795e", "url": "hjf2021.ddns.net:8073", "id": "IN50tf", "snr": "25", "lat": "40.235000", "lon": "-8.415000"},
 20 | {"mac": "1442fc0f7d58", "url": "86.209.103.192:8073", "id": "LZ1AQ", "snr": "23", "lat": "46.426400", "lon": "0.871400"},
 21 | {"mac": "b0d5cc571478", "url": "no1dsdr.ddns.net:8073", "id": "NO1D", "snr": "9", "lat": "34.569542", "lon": "-112.338320"},
 22 | {"mac": "40bd32e51c9f", "url": "sdr.hfunderground.com:8077", "id": "W3HFU/5", "snr": "24", "lat": "39.704000", "lon": "-76.974000"},
 23 | {"mac": "6433db5a6a3a", "url": "kiwi.wlansupport.no:8073", "id": "LA6LLA", "snr": "26", "lat": "58.646000", "lon": "8.375000"},
 24 | {"mac": "c4f312b9ff6f", "url": "fraso.ddns.net:8073", "id": "JN37MC", "snr": "11", "lat": "47.090000", "lon": "7.070000"},
 25 | {"mac": "40bd32e94614", "url": "kiwisdr-iz0ina.ns0.it:8073", "id": "IZ0INA", "snr": "32", "lat": "41.910000", "lon": "12.580000"},
 26 | {"mac": "40bd32c8d04e", "url": "dj9kaikiwi.ddns.net:8073", "id": "DJ9KAI", "snr": "21", "lat": "48.784060", "lon": "9.151472"},
 27 | {"mac": "40bd32e54864", "url": "80.88.23.229:8073", "id": "JO50kq", "snr": "13", "lat": "50.690000", "lon": "10.910000"},
 28 | {"mac": "883f4a94b3f0", "url": "kiwisdr.inf.dhbw-ravensburg.de:8073", "id": "DK0TE/JN47rp", "snr": "25", "lat": "47.665021", "lon": "9.448193"},
 29 | {"mac": "40bd32c8d4cb", "url": "136.35.211.245:8073", "id": "EM29QE", "snr": "11", "lat": "39.200000", "lon": "-94.640000"},
 30 | {"mac": "883f4aabafa2", "url": "kiwisdrtrebor.ddns.net:8073", "id": "JO32mk", "snr": "20", "lat": "52.440000", "lon": "7.050000"},
 31 | {"mac": "3403de5f5808", "url": "railgun.proxy.kiwisdr.com:8073", "id": "PL05sa", "snr": "18", "lat": "25.040854", "lon": "121.518549"},
 32 | {"mac": "884aeaf59cc6", "url": "kiwisdr.areg.org.au:8074", "id": "VK5ARG", "snr": "32", "lat": "-34.273700", "lon": "138.771000"},
 33 | {"mac": "38d2697cc24a", "url": "81.207.169.26:8073", "id": "PA1KE", "snr": "20", "lat": "51.730000", "lon": "5.300000"},
 34 | {"mac": "884aeaf55ae5", "url": "47.188.174.170:8073", "id": "N5HYH", "snr": "11", "lat": "32.960000", "lon": "-97.090000"},
 35 | {"mac": "20d7787dc6ef", "url": "barossa.servebeer.com:8073", "id": "PF95ml", "snr": "18", "lat": "-34.510000", "lon": "139.050000"},
 36 | {"mac": "0035ff9c9e94", "url": "lb1pj-kiwisdr.hopto.org:8073", "id": "JO49ue", "snr": "22", "lat": "59.190928", "lon": "9.715149"},
 37 | {"mac": "883f4aa8cf13", "url": "kiwisdrknoxville.ddns.net:8073", "id": "AI4FU", "snr": "15", "lat": "36.000016", "lon": "-83.827475"},
 38 | {"mac": "883f4aa8e0aa", "url": "meinsdr.ddns.net:8073", "id": "DL7APJ", "snr": "24", "lat": "52.396902", "lon": "13.276442"},
 39 | {"mac": "38d2697cd2d3", "url": "nordheide.proxy.kiwisdr.com:8073", "id": "JO43UG", "snr": "20", "lat": "53.280939", "lon": "9.712275"},
 40 | {"mac": "985dad4533a3", "url": "fsdr.duckdns.org:80", "id": "SZFVAR", "snr": "21", "lat": "47.150000", "lon": "18.390000"},
 41 | {"mac": "e415f6f6fd1a", "url": "jk1lot.ham-radio-op.net:8073", "id": "JK1LOT", "snr": "27", "lat": "35.540000", "lon": "139.460000"},
 42 | {"mac": "985dad49294b", "url": "data3.caprockweather.com:8073", "id": "N5PYK", "snr": "13", "lat": "33.600000", "lon": "-101.900000"},
 43 | {"mac": "883f4aa8c5c8", "url": "bikedork.myddns.me:8073", "id": "BIKEDORK", "snr": "8", "lat": "44.910000", "lon": "-93.280000"},
 44 | {"mac": "883f4aa8e0a7", "url": "kb0fxkiwisdr.hopto.org:8073", "id": "KB0FX", "snr": "15", "lat": "38.850000", "lon": "-91.200000"},
 45 | {"mac": "e415f6f74598", "url": "pallas-kiwi.ddns.net:8073", "id": "KP28be", "snr": "16", "lat": "68.170694", "lon": "24.157444"},
 46 | {"mac": "3403de8b3421", "url": "kiwisdr.serveftp.com:8073", "id": "JO31rl", "snr": "33", "lat": "51.497878", "lon": "7.426248"},
 47 | {"mac": "b0d5cc5711f4", "url": "foxgulch.proxy.kiwisdr.com:8073", "id": "W0AY", "snr": "2", "lat": "46.523234", "lon": "-114.114358"},
 48 | {"mac": "74e182a80d93", "url": "jq1zyv.ddns.net:80", "id": "QM06gi", "snr": "16", "lat": "36.367547", "lon": "140.562087"},
 49 | {"mac": "985dad7f7aeb", "url": "kiwib.la2zoa.net:8073", "id": "LA2ZOA/B", "snr": "25", "lat": "59.890000", "lon": "10.520000"},
 50 | {"mac": "84eb189bc646", "url": "kiwisdr.vk3tlw.net:8073", "id": "VK3TLW", "snr": "9", "lat": "-37.853689", "lon": "145.132825"},
 51 | {"mac": "74e18276045c", "url": "jp1odj.proxy.kiwisdr.com:8073", "id": "JP1ODJ", "snr": "19", "lat": "36.008373", "lon": "139.544020"},
 52 | {"mac": "689e1985cec0", "url": "sm2byc.ddns.net:8073", "id": "SM2BYC/1", "snr": "24", "lat": "65.965298", "lon": "24.030000"},
 53 | {"mac": "985dad48ecc1", "url": "80.75.112.98:8073", "id": "HB9NF", "snr": "10", "lat": "47.328590", "lon": "8.961670"},
 54 | {"mac": "883f4a9a75f2", "url": "oe1xtu.proxy.kiwisdr.com:8073", "id": "OE1XTU", "snr": "34", "lat": "48.196600", "lon": "16.371100"},
 55 | {"mac": "6433db49bc88", "url": "45.84.170.14:8073", "id": "JN60wr", "snr": "29", "lat": "40.730510", "lon": "13.906815"},
 56 | {"mac": "883f4aa8c5e6", "url": "taudel.ddns.net:8073", "id": "HB9CJJ", "snr": "15", "lat": "47.361472", "lon": "8.112919"},
 57 | {"mac": "40bd32e94608", "url": "f6bir.ddns.net:8073", "id": "f6bir", "snr": "14", "lat": "49.220000", "lon": "2.210000"},
 58 | {"mac": "883f4aa8be0f", "url": "sdr-amradioantennas.com:8075", "id": "VK3KHZ/5", "snr": "9", "lat": "-37.820000", "lon": "145.280000"},
 59 | {"mac": "c4f312a0a6ef", "url": "websdr.uk:8076", "id": "G4SZM", "snr": "37", "lat": "51.317266", "lon": "-2.950479"},
 60 | {"mac": "0035ff9cf603", "url": "9k2ra-3.proxy.kiwisdr.com:8073", "id": "LL39xi", "snr": "21", "lat": "29.364500", "lon": "47.988899"},
 61 | {"mac": "1442fc0f664e", "url": "77.223.174.203:8073", "id": "LB3J", "snr": "22", "lat": "63.426353", "lon": "8.146556"},
 62 | {"mac": "985dad7f14d9", "url": "witikiwi.ddns.net:8073", "id": "OE5EAN", "snr": "20", "lat": "48.151842", "lon": "13.998109"},
 63 | {"mac": "0035ff989f2e", "url": "w9adkiwi.hopto.org:8073", "id": "W9AD", "snr": "12", "lat": "42.140000", "lon": "-88.200000"},
 64 | {"mac": "0035ff9b915d", "url": "pallas-kiwi-2.ddns.net:8074", "id": "KP28be/4", "snr": "1", "lat": "68.170694", "lon": "24.157444"},
 65 | {"mac": "3403de939828", "url": "vk3cmz.ddns.net:8073", "id": "VK3KKP", "snr": "10", "lat": "-37.065100", "lon": "144.220400"},
 66 | {"mac": "38d2697ccb5b", "url": "ams.dedyn.io:8073", "id": "JN49em", "snr": "20", "lat": "49.530000", "lon": "8.390000"},
 67 | {"mac": "9884e38cd47c", "url": ":8073", "id": "LA5F", "snr": "35", "lat": "59.090000", "lon": "10.930000"},
 68 | {"mac": "40bd32c8d9f3", "url": "94.214.128.124:8073", "id": "PE1OPQ", "snr": "27", "lat": "53.080000", "lon": "6.800000"},
 69 | {"mac": "b8804f25ac6c", "url": "68.14.214.57:8073", "id": "W7DJS", "snr": "8", "lat": "33.626471", "lon": "-112.433728"},
 70 | {"mac": "0035ff98d084", "url": "kiwieriz.dyndns.org:8073", "id": "JN36us", "snr": "18", "lat": "46.791090", "lon": "7.741990"},
 71 | {"mac": "884aeaf5ad46", "url": "kernow.hopto.org:8073", "id": "Kernow", "snr": "28", "lat": "50.048000", "lon": "-5.182000"},
 72 | {"mac": "985dad7f2a38", "url": "iw2nke.ddns.net:8073", "id": "MarkerIT06", "snr": "54", "lat": "43.662612", "lon": "13.136668"},
 73 | {"mac": "c4f312a05b41", "url": "204.235.44.74:8073", "id": "WS5W", "snr": "10", "lat": "33.360000", "lon": "-96.620000"},
 74 | {"mac": "0035ff9cf990", "url": "kiwi5167.ddns.net:8073", "id": "DN06je", "snr": "17", "lat": "46.170000", "lon": "-119.170000"},
 75 | {"mac": "40bd322eb47c", "url": "vr2bg.proxy.kiwisdr.com:8073", "id": "VR2BG", "snr": "12", "lat": "22.350000", "lon": "114.130000"},
 76 | {"mac": "b8804f25ac18", "url": "boomerthedog.com:8073", "id": "EN90xk", "snr": "12", "lat": "40.420000", "lon": "-80.040000"},
 77 | {"mac": "780473392d93", "url": "lodsdr.proxy.kiwisdr.com:8073", "id": "SM5VXO", "snr": "15", "lat": "58.380000", "lon": "15.640000"},
 78 | {"mac": "985dad7f5e4b", "url": "z2abpyweepil7rhq.myfritz.net:8074", "id": "DC9FD", "snr": "34", "lat": "50.540000", "lon": "9.460000"},
 79 | {"mac": "38d2697ccb6d", "url": "raleigh.twrmon.net:8073", "id": "FM05qx", "snr": "22", "lat": "35.970000", "lon": "-78.650000"},
 80 | {"mac": "883f4a9a96dd", "url": "hasenberg700m.ddns.net:8076", "id": "JN47ej", "snr": "16", "lat": "47.378185", "lon": "8.365395"},
 81 | {"mac": "b8804f25b071", "url": "79.2.157.173:8073", "id": "I5HGM", "snr": "38", "lat": "43.522711", "lon": "11.477597"},
 82 | {"mac": "0035ff622cbf", "url": "mvradio.org:8073", "id": "Methow", "snr": "9", "lat": "48.478441", "lon": "-120.190905"},
 83 | {"mac": "883f4aabbd88", "url": "kc9ffvkiwisdr.gotdns.com:8073", "id": "KC9FFV", "snr": "19", "lat": "32.765568", "lon": "-96.457835"},
 84 | {"mac": "b827ebda93f7", "url": "tredxk.no-ip.org:8074", "id": "KP11wm", "snr": "25", "lat": "61.528000", "lon": "23.848000"},
 85 | {"mac": "88c2556b3d70", "url": "pardinho.kiwisdr.com.br:8073", "id": "GG56tv", "snr": "12", "lat": "-23.110000", "lon": "-48.380000"},
 86 | {"mac": "e06234437fef", "url": "dl4eeckiwi.proxy.kiwisdr.com:8073", "id": "DL4EECKiwi", "snr": "32", "lat": "53.628994", "lon": "7.906808"},
 87 | {"mac": "9884e3938d35", "url": "91.149.49.175:8073", "id": "LA3SP", "snr": "17", "lat": "60.628128", "lon": "8.175728"},
 88 | {"mac": "6433db1ba09c", "url": "th-thamai.feste-ip.net:8073", "id": "OK12ao", "snr": "18", "lat": "12.620000", "lon": "102.010000"},
 89 | {"mac": "780473388770", "url": "sdr-amradioantennas.com:8076", "id": "VK3KHZ/6", "snr": "10", "lat": "-37.817000", "lon": "145.288000"},
 90 | {"mac": "0035ff9baf06", "url": "vk2ggc2.ddns.net:8074", "id": "VK2GGC", "snr": "34", "lat": "-32.525000", "lon": "151.754400"},
 91 | {"mac": "402e71ec70f8", "url": "g3sdh.com:8054", "id": "IO81qh", "snr": "29", "lat": "51.310000", "lon": "-2.650000"},
 92 | {"mac": "e415f6f748da", "url": "de1lon.dd-dns.de:8073", "id": "DE1LON", "snr": "24", "lat": "51.140000", "lon": "6.700000"},
 93 | {"mac": "b0d5cc5723d1", "url": "kiwicam.sk3w.se:8073", "id": "SA0CAM", "snr": "28", "lat": "59.460112", "lon": "17.884806"},
 94 | {"mac": "c4f312b9ff12", "url": "argyllsdr.ddns.net:8073", "id": "GM8XBZ", "snr": "23", "lat": "55.910000", "lon": "-5.240000"},
 95 | {"mac": "e415f6f761d3", "url": "45.73.0.50:8073", "id": "FN35dn", "snr": "21", "lat": "45.554785", "lon": "-73.670049"},
 96 | {"mac": "40bd322e9bbf", "url": "kiwiik2wbg.ddns.net:8073", "id": "IK2WBG", "snr": "18", "lat": "45.800000", "lon": "9.130000"},
 97 | {"mac": "78047338d12c", "url": "websdr.uk:8077", "id": "G4SZM/7", "snr": "39", "lat": "51.317266", "lon": "-2.950479"},
 98 | {"mac": "0035ff98d9d2", "url": "5.102.161.100:8073", "id": "JO50gx", "snr": "16", "lat": "50.999256", "lon": "10.581883"},
 99 | {"mac": "985dad4921e2", "url": "31.187.212.94:8073", "id": "PA1W", "snr": "10", "lat": "51.787787", "lon": "5.936868"},
100 | {"mac": "80f5b52d1ac6", "url": "sdr.w5tsu.net:8073", "id": "W5TSU", "snr": "13", "lat": "35.533180", "lon": "-97.621357"},
101 | {"mac": "80f5b5f563a3", "url": "iceharbor5815.ddns.net:8073", "id": "DN06nf", "snr": "16", "lat": "46.242692", "lon": "-118.875750"},
102 | {"mac": "40bd32c8d2ac", "url": "do1dbs.dd-dns.de:8073", "id": "DO1DBS", "snr": "25", "lat": "51.555956", "lon": "7.381721"},
103 | {"mac": "c4f312a08754", "url": "74.82.153.108:8073", "id": "ND7M", "snr": "15", "lat": "36.240000", "lon": "-116.060000"},
104 | {"mac": "985dad4279a3", "url": "tranp.sytes.net:8073", "id": "Hanoi", "snr": "11", "lat": "21.037490", "lon": "105.812904"},
105 | {"mac": "38d2697ce597", "url": "sdr-amradioantennas.com:8073", "id": "VK3KHZ/3", "snr": "11", "lat": "-37.817000", "lon": "145.288000"},
106 | {"mac": "e415f6f745fb", "url": "77.162.242.103:8073", "id": "JO21gv", "snr": "21", "lat": "51.881980", "lon": "4.542561"},
107 | {"mac": "985dad7f1b21", "url": "fieldstation.no-ip.biz:8073", "id": "DL7APJ/3", "snr": "30", "lat": "52.396902", "lon": "13.276442"},
108 | {"mac": "0035ff994d4c", "url": "109.164.114.15:8073", "id": "CSDX", "snr": "31", "lat": "49.940000", "lon": "12.560000"},
109 | {"mac": "985dad7f0de1", "url": "g4bkhkiwi.ddns.net:8073", "id": "G4BKH", "snr": "14", "lat": "53.540000", "lon": "-2.140000"},
110 | {"mac": "985dad7f366a", "url": "99.3.11.63:8073", "id": "WB8CXO", "snr": "20", "lat": "41.150000", "lon": "-81.430000"},
111 | {"mac": "883f4a9a109a", "url": "212.225.223.202:8073", "id": "IM77ow", "snr": "20", "lat": "37.950000", "lon": "-4.810000"},
112 | {"mac": "c4f31281ccbf", "url": "kiwisdr.areg.org.au:8073", "id": "VK5ARG/3", "snr": "28", "lat": "-34.273700", "lon": "138.771000"},
113 | {"mac": "985dad7f7443", "url": "f1jeksdr1.ddns.net:8073", "id": "F1JEK", "snr": "31", "lat": "45.790000", "lon": "0.650000"},
114 | {"mac": "40bd32e30ee2", "url": "picamiolos.dynns.com:8073", "id": "hb9tpc", "snr": "0", "lat": "40.710000", "lon": "-8.050000"},
115 | {"mac": "0035ff9dbe2b", "url": "sdrwales.hopto.org:8073", "id": "IO72wn", "snr": "19", "lat": "52.580000", "lon": "-4.090000"},
116 | {"mac": "0cb2b7d6cdb0", "url": "westernmd.proxy.kiwisdr.com:8073", "id": "KB3CS", "snr": "13", "lat": "39.600000", "lon": "-78.900000"},
117 | {"mac": "c4f312a0873f", "url": "planet3.dyndns.org:8073", "id": "G8AOE1", "snr": "23", "lat": "54.510000", "lon": "-1.330000"},
118 | {"mac": "6433db465dc9", "url": "f5nkp.freeboxos.fr:8073", "id": "F5NKP", "snr": "26", "lat": "48.822431", "lon": "2.252981"},
119 | {"mac": "e415f6fd892d", "url": "gw0kig.ddns.net:8073", "id": "IO81hr", "snr": "16", "lat": "51.747940", "lon": "-3.377790"},
120 | {"mac": "38d2697cc695", "url": "sbs1suisse.internet-box.ch:8074", "id": "JN47ej/4", "snr": "25", "lat": "47.378175", "lon": "8.365381"},
121 | {"mac": "b0d5ccfc816b", "url": "sielsdr.ddns.net:8073", "id": "DF0KL", "snr": "30", "lat": "53.665337", "lon": "7.282766"},
122 | {"mac": "9884e38ccfad", "url": "0kqvydic4s76vnto.myfritz.net:8073", "id": "DO2STK", "snr": "23", "lat": "54.507518", "lon": "8.993393"},
123 | {"mac": "0035ff9cb4a2", "url": "g3sdh.com:8053", "id": "IO81qh/3", "snr": "31", "lat": "51.310000", "lon": "-2.650000"},
124 | {"mac": "985dadd0af03", "url": "pdbh2d76wb7bt5z2.myfritz.net:8073", "id": "DL3ZID", "snr": "32", "lat": "53.599300", "lon": "11.328700"},
125 | {"mac": "40bd32e4deb3", "url": "hb9flq.ham-radio-op.net:8073", "id": "JN47jk", "snr": "12", "lat": "47.424539", "lon": "8.812500"},
126 | {"mac": "780473a94c5f", "url": "zl1mga.zapto.org:8073", "id": "ZL1ROT", "snr": "20", "lat": "-38.030000", "lon": "176.200000"},
127 | {"mac": "884aeaf5b7b0", "url": "kiwisdr.hameleers.net:8073", "id": "JO21JN", "snr": "15", "lat": "51.570000", "lon": "4.780000"},
128 | {"mac": "40bd32e4da12", "url": "on5pvd.dyndns.info:8073", "id": "ON5PVD", "snr": "20", "lat": "50.910000", "lon": "4.290000"},
129 | {"mac": "985dad7f809e", "url": "kiwisdr.lollisoft.de:8073", "id": "JO40gd", "snr": "7", "lat": "50.162217", "lon": "8.553844"},
130 | {"mac": "985dad48e1b0", "url": "ha6smfkiwi.proxy.kiwisdr.com:8073", "id": "HA6SMF", "snr": "29", "lat": "47.740000", "lon": "20.420000"},
131 | {"mac": "b0d5cc571400", "url": "dentonhill-sdr.moses.bz:80", "id": "W8FSM", "snr": "13", "lat": "42.776054", "lon": "-83.706163"},
132 | {"mac": "e06234439ace", "url": "176.155.231.43:8073", "id": "JN39ak", "snr": "23", "lat": "49.440000", "lon": "6.080000"},
133 | {"mac": "40bd32e4f962", "url": "65.60.166.216:8073", "id": "EN80md", "snr": "18", "lat": "40.125100", "lon": "-82.931500"},
134 | {"mac": "38d269837eaf", "url": "sdr-amradioantennas.com:8072", "id": "VK3KHZ/2", "snr": "10", "lat": "-37.817000", "lon": "145.288000"},
135 | {"mac": "544a16bbe1cb", "url": "kiwi8073.ddns.net:8074", "id": "IV3HZR", "snr": "24", "lat": "45.606785", "lon": "13.744692"},
136 | {"mac": "780473505c0d", "url": "149.28.25.218:8073", "id": "DU6/PE1NSQ", "snr": "25", "lat": "10.723531", "lon": "122.973989"},
137 | {"mac": "985dad7f2a14", "url": "84.228.126.167:8073", "id": "Z7GUL", "snr": "10", "lat": "32.178200", "lon": "34.907600"},
138 | {"mac": "e062346fdfef", "url": "km4rt.ddns.net:8073", "id": "KM4RT", "snr": "9", "lat": "35.448000", "lon": "-89.653000"},
139 | {"mac": "40bd32c8d6ab", "url": "zubi.proxy.kiwisdr.com:8073", "id": "JN49ji", "snr": "14", "lat": "49.342221", "lon": "8.752874"},
140 | {"mac": "9059af7e9491", "url": "rixon.get-o.net:80", "id": "K0DEZ", "snr": "19", "lat": "39.220000", "lon": "-94.600000"},
141 | {"mac": "780473834f0e", "url": "kiwisdr.lamont.me.uk:8073", "id": "G4DYA/1", "snr": "29", "lat": "52.900000", "lon": "-2.100000"},
142 | {"mac": "c8a030ab6fad", "url": "kiwisdr.briata.org:8073", "id": "I1CRA", "snr": "28", "lat": "44.782900", "lon": "8.529038"},
143 | {"mac": "b827ebe743eb", "url": "swiss.ham-radio-op.net:8075", "id": "HE9JAP", "snr": "13", "lat": "46.552000", "lon": "6.642000"},
144 | {"mac": "e415f6f74af0", "url": "kd7nfr.freeddns.org:8073", "id": "KD7NFR", "snr": "5", "lat": "31.040000", "lon": "-83.190000"},
145 | {"mac": "40bd322ebe12", "url": "kiwisdr.oh6ai.fi:8073", "id": "OH6LSL", "snr": "29", "lat": "63.835500", "lon": "22.957000"},
146 | {"mac": "38d269837ea9", "url": "ahorn.proxy.kiwisdr.com:8073", "id": "HB9DSE", "snr": "39", "lat": "47.050000", "lon": "7.870000"},
147 | {"mac": "78047338fe86", "url": "hasenberg700m.ddns.net:8073", "id": "JN47ej/3", "snr": "15", "lat": "47.378185", "lon": "8.365395"},
148 | {"mac": "985dad7f50ce", "url": "os.f5.si:8073", "id": "PM74tu", "snr": "13", "lat": "34.850000", "lon": "135.590000"},
149 | {"mac": "883f4aa8cf37", "url": "websdr.uk:8060", "id": "IO81mh", "snr": "41", "lat": "51.317266", "lon": "-2.950479"},
150 | {"mac": "780473388725", "url": "kiwisdr.tgcfabian.nl:80", "id": "TGCFabian", "snr": "14", "lat": "52.516775", "lon": "6.083022"},
151 | {"mac": "883f4a99ff09", "url": "websdr.uk:80", "id": "G4SZM/0", "snr": "41", "lat": "51.317266", "lon": "-2.950479"},
152 | {"mac": "1442fc0f6d4a", "url": "hnswerkstatt.dyndns.org:8073", "id": "h13RF029", "snr": "35", "lat": "51.890000", "lon": "12.760000"},
153 | {"mac": "1442fc0f6984", "url": "kiwisdr2.hoka.co.uk:8073", "id": "STNB", "snr": "17", "lat": "51.292581", "lon": "0.979165"},
154 | {"mac": "1862e4d0c3f3", "url": "190.123.83.42:8073", "id": "LU1HCW", "snr": "25", "lat": "-32.660000", "lon": "-64.760000"},
155 | {"mac": "c4f312753dae", "url": "kiwi-vih.aprs.fi:8073", "id": "KP20/aprsfi", "snr": "19", "lat": "63.075000", "lon": "27.275000"},
156 | {"mac": "b8804f327a29", "url": "dl0dtm.ddns.net:8073", "id": "DL0DTM", "snr": "20", "lat": "50.723782", "lon": "7.145407"},
157 | {"mac": "0035ff9b68bf", "url": "azzg6sujivyua29f.myfritz.net:8073", "id": "JO53cl", "snr": "31", "lat": "53.480000", "lon": "10.190000"},
158 | {"mac": "40bd32e2d990", "url": "plonsk.proxy.kiwisdr.com:8073", "id": "SDRPlonsk", "snr": "39", "lat": "52.620000", "lon": "20.368000"},
159 | {"mac": "28ec9af27714", "url": "air.swl.su:80", "id": "KO85rw", "snr": "0", "lat": "55.917158", "lon": "37.418104"},
160 | {"mac": "6433db11f7dc", "url": "pe1rdp.no-ip.org:8073", "id": "PE1RDP", "snr": "19", "lat": "51.441661", "lon": "5.374092"},
161 | {"mac": "b0d5cc571b4e", "url": "kiwisdr.aprsinfo.com:8073", "id": "M0XDK", "snr": "20", "lat": "52.186065", "lon": "-0.895373"},
162 | {"mac": "1442fc0c8dc9", "url": "177.ham-radio-op.net:8073", "id": "JO01mi", "snr": "15", "lat": "51.355177", "lon": "1.017452"},
163 | {"mac": "38d2697cc211", "url": "s4wmv4hovyls5ebz.myfritz.net:8075", "id": "SWLJO43/3", "snr": "37", "lat": "53.307000", "lon": "9.987400"},
164 | {"mac": "883f4aa8cf0a", "url": "kr6la.proxy.kiwisdr.com:8073", "id": "CN90ao", "snr": "12", "lat": "40.620000", "lon": "-121.920000"},
165 | {"mac": "04a316af0eed", "url": "thomas0177.dnshome.de:8073", "id": "DL0073SWL", "snr": "24", "lat": "52.418663", "lon": "13.306890"},
166 | {"mac": "b8804f25c4de", "url": "99.102.143.126:8073", "id": "KU4SD", "snr": "16", "lat": "34.010000", "lon": "-83.490000"},
167 | {"mac": "c4f312a678db", "url": "ve3hoa.ddns.net:8073", "id": "VE3HOA", "snr": "22", "lat": "45.270000", "lon": "-76.050000"},
168 | {"mac": "f045da7def63", "url": "sm2byc.ddns.net:8074", "id": "SM2BYC/2", "snr": "25", "lat": "65.965298", "lon": "24.03"},
169 | {"mac": "38d2697cae38", "url": "nutronix.dd-dns.de:8073", "id": "OE9NGH", "snr": "2", "lat": "47.464298", "lon": "9.907030"},
170 | {"mac": "c4f312b9faaa", "url": "websdr.uk:8074", "id": "G4SZM/4", "snr": "41", "lat": "51.317266", "lon": "-2.950479"},
171 | {"mac": "7804733915f3", "url": "plonsk2.proxy.kiwisdr.com:8073", "id": "SDRPlonsk/3", "snr": "41", "lat": "52.620000", "lon": "20.368000"},
172 | {"mac": "e06234438865", "url": "sm4fge.ddns.net:8073", "id": "SM4FGE", "snr": "31", "lat": "60.070000", "lon": "15.140000"},
173 | {"mac": "6433db48e8b4", "url": "bv3un.ddns.net:8073", "id": "BV3UN", "snr": "9", "lat": "25.052481", "lon": "121.297046"},
174 | {"mac": "04a316b0a8d8", "url": "jp1odj-air.proxy.kiwisdr.com:8073", "id": "JP1ODJ/3", "snr": "0", "lat": "36.038350", "lon": "139.314034"},
175 | {"mac": "0035ff89db87", "url": "oe3wyc.ddns.net:8073", "id": "OE1WYC", "snr": "29", "lat": "48.218000", "lon": "16.466290"},
176 | {"mac": "985dad491114", "url": "k2zn.ddns.net:8073", "id": "K2ZN", "snr": "12", "lat": "43.120000", "lon": "-77.620000"},
177 | {"mac": "b8804f25d25b", "url": "81.92.181.198:8073", "id": "JO33bg", "snr": "25", "lat": "53.280789", "lon": "6.088008"},
178 | {"mac": "b0d5cc571679", "url": "ik2biy.proxy.kiwisdr.com:8073", "id": "IK2BIY", "snr": "27", "lat": "45.709315", "lon": "10.212806"},
179 | {"mac": "6433db391ce6", "url": "kiwi-kuo.aprs.fi:8073", "id": "KP33pb", "snr": "23", "lat": "63.075000", "lon": "27.275000"},
180 | {"mac": "884aeaf5858e", "url": "kiwisdr.surriel.com:80", "id": "AB1KW", "snr": "28", "lat": "43.170715", "lon": "-71.566939"},
181 | {"mac": "3403de631d0d", "url": "sdr.ironstonerange.com:8073", "id": "VK5PH", "snr": "29", "lat": "-34.964437", "lon": "138.762380"},
182 | {"mac": "985dad812e70", "url": "sdrtoyb.ddns.net:8073", "id": "JP40nn", "snr": "9", "lat": "60.568060", "lon": "9.102760"},
183 | {"mac": "78047338da92", "url": "plonsk3.proxy.kiwisdr.com:8073", "id": "SDRPlonsk/3", "snr": "38", "lat": "52.620000", "lon": "20.368000"},
184 | {"mac": "884aeae013ab", "url": "sdr.n3ka.com:8073", "id": "N3LGA", "snr": "12", "lat": "37.370000", "lon": "-122.026000"},
185 | {"mac": "04a316df1bca", "url": "linkz.ddns.net:8073", "id": "linkz", "snr": "31", "lat": "45.402767", "lon": "5.277375"},
186 | {"mac": "3403de8df4b8", "url": "w9xa.us:8073", "id": "W9XA", "snr": "16", "lat": "41.852336", "lon": "-88.327603"},
187 | {"mac": "38d2693e89d5", "url": "irk.swl.su:80", "id": "OO22eg", "snr": "19", "lat": "52.277911", "lon": "104.359891"},
188 | {"mac": "40bd32e55512", "url": "sigmasdr.ddns.net:8073", "id": "N1NTE/1", "snr": "25", "lat": "42.033943", "lon": "-72.140461"},
189 | {"mac": "e062346753e1", "url": "sbs1suisse.internet-box.ch:8073", "id": "JN47di", "snr": "0", "lat": "47.351333", "lon": "8.271333"},
190 | {"mac": "b0d5ccff4b38", "url": "rgv2.twrmon.net:8074", "id": "EL15gw", "snr": "13", "lat": "25.934624", "lon": "-97.462922"},
191 | {"mac": "40bd32e54d17", "url": "rgv.twrmon.net:8075", "id": "EL15gw/5", "snr": "13", "lat": "25.930000", "lon": "-97.462921"},
192 | {"mac": "985dad7f31da", "url": "72.235.217.245:8073", "id": "NH6XO", "snr": "8", "lat": "21.403000", "lon": "-157.807000"},
193 | {"mac": "1442fc0f98c1", "url": "bv7au.ddns.net:8073", "id": "BV7AU", "snr": "0", "lat": "22.790000", "lon": "120.580000"},
194 | {"mac": "883f4a998b86", "url": "sdrbcn.duckdns.org:8073", "id": "EA3HRU", "snr": "15", "lat": "41.411360", "lon": "1.999500"},
195 | {"mac": "40bd322ec32b", "url": "linkz.ddns.net:8074", "id": "lnkz", "snr": "39", "lat": "45.402778", "lon": "5.277473"},
196 | {"mac": "780473832a84", "url": "warszawa.proxy.kiwisdr.com:8073", "id": "KO02lg", "snr": "18", "lat": "52.259885", "lon": "20.957187"},
197 | {"mac": "883f4aab90d6", "url": "kf2da.ddns.net:8073", "id": "KF2DA", "snr": "16", "lat": "42.080000", "lon": "-76.820000"},
198 | {"mac": "b8804f25b077", "url": "db0bbb.dnshome.de:8073", "id": "JO62sq", "snr": "20", "lat": "52.672911", "lon": "13.547363"},
199 | {"mac": "e062346fcf69", "url": "kiwi-neuwied.ddns.net:8073", "id": "JO30QK", "snr": "21", "lat": "50.457916", "lon": "7.428928"},
200 | {"mac": "b8804f25c0d9", "url": "kiwisdr-schwarzenburg.try.yaler.io:80", "id": "JN36qt", "snr": "16", "lat": "46.810606", "lon": "7.355672"},
201 | {"mac": "e415f6f66b0d", "url": "scaeschi.ddns.net:8073", "id": "JN36UP", "snr": "18", "lat": "46.640000", "lon": "7.730000"},
202 | {"mac": "e415f6f748f2", "url": "vk2ggc.ddns.net:8073", "id": "VK2GGC/3", "snr": "12", "lat": "-32.550000", "lon": "151.735000"},
203 | {"mac": "84eb18e5377f", "url": "kiwi-sdr2-leiden.impactam.nl:8073", "id": "ImpactAM", "snr": "22", "lat": "52.150000", "lon": "4.450000"},
204 | {"mac": "985dad49051b", "url": "14.8.66.227:5025", "id": "PM96ok", "snr": "21", "lat": "36.450000", "lon": "139.200000"},
205 | {"mac": "c4f312a678c9", "url": "rx2.wa2zkd.net:8073", "id": "ZKD/Maine", "snr": "23", "lat": "44.170000", "lon": "-69.080000"},
206 | {"mac": "e415f6f4ee16", "url": "ze30.internetdsl.tpnet.pl:8888", "id": "KO00sl", "snr": "19", "lat": "50.477006", "lon": "21.554581"},
207 | {"mac": "c4f312724129", "url": "72.172.110.98:8175", "id": "VE6JY", "snr": "18", "lat": "53.740000", "lon": "-112.820000"},
208 | {"mac": "38d2697ce5e5", "url": "javaradiofrance.ddns.net:8073", "id": "CX0006SWL", "snr": "7", "lat": "47.250153", "lon": "6.039819"},
209 | {"mac": "e062346fe688", "url": "217.113.51.121:8073", "id": "HA6PX", "snr": "35", "lat": "48.128700", "lon": "19.883700"},
210 | {"mac": "e415f6fd942e", "url": "47.54.214.91:8073", "id": "VY2HF", "snr": "11", "lat": "46.235520", "lon": "-63.082160"},
211 | {"mac": "883f4aa8b614", "url": "kiwisdrik4cie.ddns.net:8073", "id": "IK4CIE", "snr": "28", "lat": "44.680000", "lon": "10.270000"},
212 | {"mac": "b827ebb18685", "url": "iw3hbx.ddns.net:5555", "id": "IW3HBX", "snr": "13", "lat": "45.548833", "lon": "12.062231"},
213 | {"mac": "c4f3127553a4", "url": "emeraldsdr.proxy.kiwisdr.com:8073", "id": "IO62nu", "snr": "5", "lat": "52.870000", "lon": "-6.850000"},
214 | {"mac": "e062346fcf7b", "url": "graz.sytes.net:8073", "id": "OE6ADD", "snr": "35", "lat": "46.990000", "lon": "15.300000"},
215 | {"mac": "b0d5ccf0df17", "url": "kiwisdr.k7biz.com:8073", "id": "K7BIZ", "snr": "7", "lat": "47.700000", "lon": "-116.770000"},
216 | {"mac": "b0d5cc571db4", "url": "sv8rv.dyndns.org:8073", "id": "SV8RV", "snr": "18", "lat": "37.783103", "lon": "20.896453"},
217 | {"mac": "40bd322ea078", "url": "kb1uif-kiwisdr.ddns.net:8073", "id": "KB1UIF", "snr": "14", "lat": "42.060000", "lon": "-73.310000"},
218 | {"mac": "6433db1fa731", "url": "hanshomepa0ehg.ddns.net:8073", "id": "PA0EHG", "snr": "34", "lat": "52.684094", "lon": "7.519360"},
219 | {"mac": "40bd32c8d4e0", "url": "la6lukiwisdr.ddns.net:8073", "id": "LA6LU", "snr": "26", "lat": "59.690000", "lon": "10.340000"},
220 | {"mac": "c4f312b9fad7", "url": "websdr.uk:8073", "id": "G4SZM/3", "snr": "41", "lat": "51.317266", "lon": "-2.950479"},
221 | {"mac": "b0d5cc570aac", "url": "take4radio.asuscomm.com:8073", "id": "PM84lw", "snr": "12", "lat": "34.920000", "lon": "136.990000"},
222 | {"mac": "883f4a9a3c80", "url": "kiwionline.ddns.net:8073", "id": "JO31dh", "snr": "27", "lat": "51.296443", "lon": "6.273451"},
223 | {"mac": "6433db175429", "url": "dl2kcl.selfhost.eu:8073", "id": "LZ1AQ/3", "snr": "28", "lat": "50.621803", "lon": "6.936500"},
224 | {"mac": "40bd32e9462c", "url": "80.75.112.98:8075", "id": "HB9NF/5", "snr": "11", "lat": "47.328590", "lon": "8.961670"},
225 | {"mac": "b827ebc60dc2", "url": "pso2.p.sdrotg.com:80", "id": "KotkaFinland", "snr": "28", "lat": "60.507676", "lon": "26.981506"},
226 | {"mac": "985dad7efeca", "url": "mauisdr.wsprdaemon.org:8073", "id": "AI6VN", "snr": "18", "lat": "20.970000", "lon": "-156.540000"},
227 | {"mac": "883f4aa8d939", "url": "hasenberg700m.ddns.net:8074", "id": "JN47ej/4", "snr": "15", "lat": "47.378185", "lon": "8.365395"},
228 | {"mac": "38d2697cae44", "url": "209.115.233.71:8073", "id": "ve6ars1", "snr": "16", "lat": "50.080000", "lon": "-113.680000"},
229 | {"mac": "b0d5cc5711dc", "url": "db0hal.dyndns.org:8073", "id": "DM2NT", "snr": "14", "lat": "51.466044", "lon": "11.977189"},
230 | {"mac": "1442fc0f69b4", "url": "g7jur.ddns.net:8073", "id": "G7JUR", "snr": "24", "lat": "51.240304", "lon": "-0.786030"},
231 | {"mac": "0035ff98e25a", "url": "jsgkiwi.ddns.net:8073", "id": "KP24sm", "snr": "17", "lat": "64.510000", "lon": "25.550000"},
232 | {"mac": "0035ff98e248", "url": "217.26.107.148:8073", "id": "PA3GJX", "snr": "37", "lat": "52.603096", "lon": "5.950619"},
233 | {"mac": "e415f6f745b3", "url": "sdr.k1vl.com:8073", "id": "K1VL", "snr": "28", "lat": "43.507697", "lon": "-72.816799"},
234 | {"mac": "883f4aab7be8", "url": "62.170.14.132:8073", "id": "JN61vq", "snr": "16", "lat": "41.690000", "lon": "13.750000"},
235 | {"mac": "c4f312b9ff51", "url": "f6abj-kiwihf.ddns.net:8073", "id": "F6ABJ", "snr": "22", "lat": "45.384028", "lon": "5.093461"},
236 | {"mac": "40bd32e93def", "url": "WV5L-sdr.dynu.net:8073", "id": "EM74sc", "snr": "12", "lat": "34.107823", "lon": "-84.462645"},
237 | {"mac": "3403de81254c", "url": "sdr1hgn.ddns.net:80", "id": "DL0HGN", "snr": "38", "lat": "53.402192", "lon": "11.218731"},
238 | {"mac": "985dad7f4aee", "url": "kiwi.minish.org:8073", "id": "IO53hu", "snr": "31", "lat": "53.840000", "lon": "-9.370000"},
239 | {"mac": "38d2697cbb3d", "url": "kiwisdr4.sdrutah.org:8076", "id": "KK7DV4", "snr": "19", "lat": "41.589151", "lon": "-112.274395"},
240 | {"mac": "38d269837796", "url": "kiwi.oe9.at:8074", "id": "OE9HLH", "snr": "40", "lat": "47.442516", "lon": "9.843918"},
241 | {"mac": "e415f6f7741e", "url": "213.109.126.8:8074", "id": "PD0OHW", "snr": "39", "lat": "53.110000", "lon": "6.970000"},
242 | {"mac": "b0d5cc571610", "url": "sdr.vy.fi:80", "id": "KP13un", "snr": "20", "lat": "63.550000", "lon": "23.710000"},
243 | {"mac": "e45f01235128", "url": "pso.p.sdrotg.com:80", "id": "KotkaFIN", "snr": "41", "lat": "60.496041", "lon": "26.991192"},
244 | {"mac": "985dad7f456a", "url": "dl2sba.ddns.net:8073", "id": "DL2SBA", "snr": "21", "lat": "48.670000", "lon": "9.240000"},
245 | {"mac": "780473833ace", "url": "g4gnk.proxy.kiwisdr.com:8073", "id": "G4GNK", "snr": "26", "lat": "51.818823", "lon": "-0.035258"},
246 | {"mac": "74e1825d65ae", "url": "73.68.202.112:8073", "id": "WA3ETD", "snr": "25", "lat": "43.680000", "lon": "-73.020000"},
247 | {"mac": "985dad7f4a82", "url": "gnss.0am.jp:80", "id": "JE1AHJ", "snr": "25", "lat": "35.710307", "lon": "139.495750"},
248 | {"mac": "38d2698370f8", "url": "ntkiwi.uni-paderborn.de:8073", "id": "DB1UJ", "snr": "12", "lat": "51.709104", "lon": "8.768726"},
249 | {"mac": "40bd322ecc6d", "url": "88.220.45.111:8073", "id": "SQ5BPD", "snr": "26", "lat": "52.350000", "lon": "20.600000"},
250 | {"mac": "0035ff8e0580", "url": "kiwisdr.spookhollow.net:8073", "id": "E0UCD", "snr": "20", "lat": "51.211208", "lon": "-0.329840"},
251 | {"mac": "40bd32e55008", "url": "sdr.hfunderground.com:8079", "id": "W3HFU/1", "snr": "13", "lat": "39.704000", "lon": "-76.974000"},
252 | {"mac": "04a316dd6657", "url": "kiwisdr.njctech.com:8073", "id": "W1NJC", "snr": "20", "lat": "42.110000", "lon": "-71.710000"},
253 | {"mac": "b8804f260f54", "url": "n0ls.homedns.org:8073", "id": "N0LS", "snr": "11", "lat": "39.987567", "lon": "-105.033435"},
254 | {"mac": "28ec9aea49ce", "url": "gibsons.dyndns.org:8073", "id": "G8PFR", "snr": "2", "lat": "51.910000", "lon": "-2.510000"},
255 | {"mac": "e062346708cf", "url": "m14.fernschreibstelle.de:8073", "id": "DO5EU/JO62qm", "snr": "15", "lat": "52.521490", "lon": "13.383490"},
256 | {"mac": "40bd32c8d280", "url": "87.251.229.127:8073", "id": "SP1EXB", "snr": "26", "lat": "53.850000", "lon": "16.680000"},
257 | {"mac": "40bd32e4d57d", "url": "ka7u.no-ip.org:8075", "id": "KA7U", "snr": "0", "lat": "44.245234", "lon": "-117.005488"},
258 | {"mac": "6433db466280", "url": "kiwisdr-dk9ip.ddns.net:8073", "id": "JN48fx", "snr": "33", "lat": "48.974000", "lon": "8.461950"},
259 | {"mac": "985dad7f7a85", "url": "83.162.220.82:8073", "id": "PA0RDT", "snr": "15", "lat": "51.500500", "lon": "3.600690"},
260 | {"mac": "38d2697cd2cd", "url": "kiwisdr1.sdrutah.org:8073", "id": "KA7OEI1", "snr": "25", "lat": "41.590000", "lon": "-112.270000"},
261 | {"mac": "883f4a9834a8", "url": "kiwisdr.cathalferris.com:8074", "id": "HB9HJF/2", "snr": "8", "lat": "47.400000", "lon": "8.400000"},
262 | {"mac": "40bd32e5550c", "url": "kiwisdr.cathalferris.com:8073", "id": "HB9HJF/1", "snr": "6", "lat": "47.400000", "lon": "8.400000"},
263 | {"mac": "780473838586", "url": "kareliamwdx.ddns.net:8073", "id": "KP52cn", "snr": "0", "lat": "62.560000", "lon": "30.180000"},
264 | {"mac": "1442fc0f8e00", "url": "websdr.uk:8079", "id": "G4SZM/9", "snr": "43", "lat": "51.317266", "lon": "-2.950479"},
265 | {"mac": "985dad7f0dd5", "url": "emeraldsdr1.proxy.kiwisdr.com:8073", "id": "IO62nu/3", "snr": "6", "lat": "52.870000", "lon": "-6.850000"},
266 | {"mac": "04a316fcb3ea", "url": "z2abpyweepil7rhq.myfritz.net:8073", "id": "DC9FD/3", "snr": "33", "lat": "50.540000", "lon": "9.470000"},
267 | {"mac": "38d269837e91", "url": "sdr1.on1aff.be:80", "id": "ON1AFF", "snr": "20", "lat": "51.094345", "lon": "4.514251"},
268 | {"mac": "b0d5cc571b7b", "url": "62.2.184.6:8073", "id": "HB9AZT", "snr": "32", "lat": "47.410000", "lon": "9.580000"},
269 | {"mac": "e415f6f96ff0", "url": "59.129.216.68:8073", "id": "JJ1LIB", "snr": "17", "lat": "35.450000", "lon": "139.630000"},
270 | {"mac": "40bd32e4cfd7", "url": "gti.proxy.kiwisdr.com:8073", "id": "PE0RL", "snr": "31", "lat": "51.670000", "lon": "5.580000"},
271 | {"mac": "6433db5a6a4c", "url": "122.117.30.20:8073", "id": "BV5AC", "snr": "0", "lat": "23.900000", "lon": "120.520000"},
272 | {"mac": "e415f6f23445", "url": "websdr.uk:8078", "id": "G4SZM/8", "snr": "41", "lat": "51.317266", "lon": "-2.950479"},
273 | {"mac": "e415f6f75390", "url": "82.74.101.138:8073", "id": "JO32hu", "snr": "25", "lat": "52.859104", "lon": "6.604887"},
274 | {"mac": "b0d5ccfc7404", "url": "kiwisdr.ddnss.de:8073", "id": "DL6ECS", "snr": "16", "lat": "50.936075", "lon": "11.586538"},
275 | {"mac": "e415f6f74da2", "url": "kiwi.web-sdr.at:8073", "id": "OE3KDC", "snr": "22", "lat": "47.801795", "lon": "14.933132"},
276 | {"mac": "b0d5ccfe3042", "url": "eemedia.mynetgear.com:8073", "id": "FN31do", "snr": "25", "lat": "41.612703", "lon": "-73.691838"},
277 | {"mac": "e415f6f745cb", "url": "sv1xv.ddns.net:8073", "id": "SV1XV", "snr": "17", "lat": "38.010000", "lon": "23.700000"},
278 | {"mac": "40bd322ea054", "url": "midtn.dynu.net:8073", "id": "PC4ALP", "snr": "10", "lat": "36.240000", "lon": "-86.640000"},
279 | {"mac": "74e1828e070c", "url": "kiwi8073.ddns.net:8073", "id": "IV3HZR/3", "snr": "15", "lat": "45.606785", "lon": "13.744692"},
280 | {"mac": "38d269837eca", "url": "ve6hfd.ddns.net:8074", "id": "VE6HFD", "snr": "17", "lat": "51.630000", "lon": "-111.990000"},
281 | {"mac": "38d2697cbb0a", "url": "oz1bfm.proxy.kiwisdr.com:8073", "id": "OZ1BFM", "snr": "21", "lat": "56.080000", "lon": "12.160000"},
282 | {"mac": "6433db38a009", "url": "nndatentechnik.dynv6.net:8073", "id": "DO6NIK", "snr": "39", "lat": "51.734884", "lon": "8.738878"},
283 | {"mac": "985dad7f0de4", "url": ":8073", "id": "G0EZY/1", "snr": "20", "lat": "53.569677", "lon": "-1.061190"},
284 | {"mac": "b827ebd2868f", "url": "swiss.ham-radio-op.net:8073", "id": "JN36hn", "snr": "14", "lat": "46.552000", "lon": "6.642000"},
285 | {"mac": "64cfd9cffb2b", "url": "pa4hjh.ddns.net:8073", "id": "PA4HJH", "snr": "34", "lat": "52.845351", "lon": "5.699363"},
286 | {"mac": "0c1c57090756", "url": "sk5sm.dyndns.info:8073", "id": "SK5SM", "snr": "36", "lat": "58.537633", "lon": "14.443303"},
287 | {"mac": "e45f010ec061", "url": "hb9ttu.dyndns.org:8075", "id": "HB9TTU", "snr": "11", "lat": "47.385085", "lon": "8.781054"},
288 | {"mac": "6433db174cbe", "url": "oh5ae.dyndns.org:8073", "id": "OH5AE", "snr": "35", "lat": "60.720000", "lon": "26.410000"},
289 | {"mac": "dca6327d7c73", "url": "sergiocorda.synology.me:58075", "id": "JM49nf", "snr": "17", "lat": "39.220000", "lon": "9.130000"},
290 | {"mac": "c4f3127256da", "url": "norfolk.george-smart.co.uk:8073", "id": "M1GEO", "snr": "25", "lat": "52.441319", "lon": "1.214225"},
291 | {"mac": "c4f312a6844e", "url": "shack.oe9.at:8073", "id": "JN47um", "snr": "28", "lat": "47.500000", "lon": "9.720000"},
292 | {"mac": "dca6326d3b71", "url": "admtan.p.sdrotg.com:80", "id": "PM94nw", "snr": "17", "lat": "34.956000", "lon": "139.092000"},
293 | {"mac": "84eb18e54e3a", "url": "119.47.17.25:8073", "id": "JA5FP", "snr": "16", "lat": "35.667916", "lon": "140.171996"},
294 | {"mac": "985dad7f4aa9", "url": "ce3pbr.proxy.kiwisdr.com:8073", "id": "CA3PBR", "snr": "12", "lat": "-33.521667", "lon": "-70.568694"},
295 | {"mac": "c4f312a093ed", "url": "81.168.1.206:8073", "id": "G3XOU", "snr": "32", "lat": "50.530000", "lon": "-4.130000"},
296 | {"mac": "883f4aa8d915", "url": "kiwibsb.ddns.net:8074", "id": "PT2FHC/4", "snr": "24", "lat": "-15.710000", "lon": "-47.820000"},
297 | {"mac": "c4f312a678f3", "url": "swiss.ham-radio-op.net:8074", "id": "HE9JAP/4", "snr": "15", "lat": "46.545000", "lon": "6.627000"},
298 | {"mac": "40bd32e2d9ab", "url": "86.135.190.85:8073", "id": "MX0NCA", "snr": "18", "lat": "52.933400", "lon": "1.272500"},
299 | {"mac": "985dad876650", "url": "izh.swl.su:80", "id": "LO66ou", "snr": "11", "lat": "56.836560", "lon": "53.227097"},
300 | {"mac": "28ec9af32af4", "url": "erserver.ddns.net:8073", "id": "JO50uw", "snr": "21", "lat": "50.930000", "lon": "11.680000"},
301 | {"mac": "884aeaf59046", "url": "kiwisdr-dm7rm.goip.de:8073", "id": "DM7RM", "snr": "29", "lat": "49.523685", "lon": "9.313056"},
302 | {"mac": "883f4aa8cf34", "url": "sdr.k9mq.com:8073", "id": "K9MQ", "snr": "10", "lat": "41.450000", "lon": "-87.440000"},
303 | {"mac": "38d2697cd800", "url": "82.70.254.222:8073", "id": "IO82qv", "snr": "0", "lat": "52.890000", "lon": "-2.640000"},
304 | {"mac": "28ec9aeff774", "url": "jimlill.com:8075", "id": "WA2ZKD", "snr": "22", "lat": "43.126741", "lon": "-77.584850"},
305 | {"mac": "e415f6f502a4", "url": "sdr.hfunderground.com:8075", "id": "W3HFU/3", "snr": "19", "lat": "39.704000", "lon": "-76.974000"},
306 | {"mac": "6433db38da8f", "url": "ve6lrn.narc.net:8073", "id": "VE6LRN", "snr": "18", "lat": "53.450000", "lon": "-114.540000"},
307 | {"mac": "0c1c57099f75", "url": "hik.iptime.org:8075", "id": "HL3AMO", "snr": "9", "lat": "36.387000", "lon": "127.321000"},
308 | {"mac": "9884e3aeda64", "url": "nsk.swl.su:80", "id": "NO14th", "snr": "27", "lat": "54.300000", "lon": "83.630000"},
309 | {"mac": "38d2697ce5ac", "url": "186.193.231.135:8073", "id": "GG66rf", "snr": "12", "lat": "-23.770058", "lon": "-46.535755"},
310 | {"mac": "40bd32e4cc5f", "url": "88.163.155.169:18073", "id": "Sakamurro", "snr": "19", "lat": "46.290000", "lon": "6.090000"},
311 | {"mac": "985dad48a547", "url": "julussdalen.proxy.kiwisdr.com:8073", "id": "JP51ua", "snr": "27", "lat": "61.037636", "lon": "11.689167"},
312 | {"mac": "fc69474a3914", "url": "sdr.vebik.cz:8073", "id": "OK1KKI", "snr": "41", "lat": "49.142938", "lon": "15.006931"},
313 | {"mac": "1442fc0f60ab", "url": "ik7fmo.ddns.net:8073", "id": "IK7FMO", "snr": "27", "lat": "40.970000", "lon": "17.120000"},
314 | {"mac": "6433db48f061", "url": "kiwisdr.servepics.com:8073", "id": "JO52ue", "snr": "23", "lat": "52.180200", "lon": "11.732500"},
315 | {"mac": "c4f312b9ff30", "url": "kb6c.proxy.kiwisdr.com:8073", "id": "KB6C", "snr": "22", "lat": "34.750000", "lon": "-119.080000"},
316 | {"mac": "6433db1c02dc", "url": "178.63.122.223:8073", "id": "JO41tb", "snr": "13", "lat": "51.075500", "lon": "9.615500"},
317 | {"mac": "c4f312756f70", "url": "kiwi.dd9lh.de:8073", "id": "DD9LH", "snr": "16", "lat": "54.200000", "lon": "9.090000"},
318 | {"mac": "985dad38006d", "url": "la2g.ddns.net:8072", "id": "LA2G", "snr": "37", "lat": "60.147410", "lon": "11.146040"},
319 | {"mac": "883f4aa8c5e3", "url": "24.78.155.2:8073", "id": "W6LPV", "snr": "14", "lat": "49.860000", "lon": "-97.420000"},
320 | {"mac": "40bd32e54015", "url": "Hallmann.selfhost.eu:80", "id": "JN49av", "snr": "24", "lat": "49.890000", "lon": "8.070000"},
321 | {"mac": "40bd32c8d492", "url": "kiwisdr.k3fef.com:8073", "id": "K3FEF", "snr": "26", "lat": "41.325953", "lon": "-74.922089"},
322 | {"mac": "04a316edf709", "url": "kiwisdr.ve6slp.ca:8173", "id": "VE6JY1", "snr": "18", "lat": "53.742089", "lon": "-112.830264"},
323 | {"mac": "5051a9a7944e", "url": "jimlill.com:8076", "id": "WA2ZKD/6", "snr": "0", "lat": "43.126741", "lon": "-77.584850"},
324 | {"mac": "c4f312726fdf", "url": "oe3akb.ddns.net:8073", "id": "OE3AKB", "snr": "35", "lat": "48.320000", "lon": "15.580000"},
325 | {"mac": "0cb2b7d6cd86", "url": "83.247.88.41:8073", "id": "JO21nn", "snr": "16", "lat": "51.560000", "lon": "5.100000"},
326 | {"mac": "884aeaf5408e", "url": "kiwisdr.owdjim.gen.nz:8073", "id": "Marahau", "snr": "8", "lat": "-41.006161", "lon": "173.013660"},
327 | {"mac": "80f5b5f56892", "url": "sdr.zapto.org:8073", "id": "ZL2QF/RF70fk", "snr": "15", "lat": "-39.574552", "lon": "174.434932"},
328 | {"mac": "40bd32c8d810", "url": "kiwi.ziegler.bz:8073", "id": "HB9GVC", "snr": "14", "lat": "47.365368", "lon": "8.897944"},
329 | {"mac": "985dad48e186", "url": "kiwisdr.tecsunradios.com.au:8073", "id": "Tecsun", "snr": "13", "lat": "-35.632626", "lon": "149.807140"},
330 | {"mac": "38d2697cc27d", "url": "vk2aak.ddns.net:8073", "id": "VK2AAK", "snr": "13", "lat": "-32.080000", "lon": "152.480000"},
331 | {"mac": "884aeaf5907c", "url": "kiwisdr.k1ra.us:8073", "id": "K1RA", "snr": "20", "lat": "38.742405", "lon": "-77.797874"},
332 | {"mac": "e0623467033b", "url": "hb9efk.proxy.kiwisdr.com:8073", "id": "HB9EFK", "snr": "11", "lat": "47.267764", "lon": "8.314324"},
333 | {"mac": "78047338fe98", "url": "sdr-bayern.spdns.de:8073", "id": "JN69fg", "snr": "39", "lat": "49.290000", "lon": "12.440000"},
334 | {"mac": "544a16e70e44", "url": "balou.spdns.de:8074", "id": "JO64pb", "snr": "21", "lat": "54.080000", "lon": "13.280000"},
335 | {"mac": "7c386655e729", "url": "msk.swl.su:8073", "id": "KO85qw", "snr": "17", "lat": "55.920000", "lon": "37.400000"},
336 | {"mac": "40bd32e4da2a", "url": "irelandnorthwest.proxy.kiwisdr.com:8073", "id": "NorthWest", "snr": "44", "lat": "54.229144", "lon": "-9.312494"},
337 | {"mac": "883f4aabca66", "url": "sdr.hfunderground.com:8076", "id": "W3HFU/2", "snr": "25", "lat": "39.704000", "lon": "-76.974000"},
338 | {"mac": "e062346fdfb3", "url": "jpvm54.ddns.net:8073", "id": "KA0GBG", "snr": "8", "lat": "39.680000", "lon": "-105.120000"},
339 | {"mac": "c4f312727699", "url": "78.40.253.65:80", "id": "TF3GZ", "snr": "5", "lat": "66.450000", "lon": "-15.950000"},
340 | {"mac": "6433db175099", "url": "nikola.animats.net:8073", "id": "VK2KTJ", "snr": "2", "lat": "-33.640000", "lon": "150.280000"},
341 | {"mac": "0cb2b7d6efd6", "url": "sigmasdr.ddns.net:8074", "id": "N1NTE/2", "snr": "25", "lat": "42.033943", "lon": "-72.140461"},
342 | {"mac": "883f4aa8acf6", "url": "69.27.184.58:8075", "id": "KFSSW", "snr": "10", "lat": "37.382406", "lon": "-122.413786"},
343 | {"mac": "04a316eda0a3", "url": "la1d.proxy.kiwisdr.com:8073", "id": "LA1D", "snr": "40", "lat": "60.950870", "lon": "11.295140"},
344 | {"mac": "1442fc0f98c4", "url": "vilradio.dynv6.net:8073", "id": "DL1NDG", "snr": "21", "lat": "49.455160", "lon": "11.079390"},
345 | {"mac": "78047338fece", "url": "67.233.122.90:8073", "id": "w4kel", "snr": "23", "lat": "38.150000", "lon": "-78.560000"},
346 | {"mac": "3403de656ece", "url": "kiwisdr.on3rvh.be:8073", "id": "ON3RVH", "snr": "24", "lat": "51.249976", "lon": "2.998107"},
347 | {"mac": "3403de637ca1", "url": "81.174.134.21:8073", "id": "G3PWJ", "snr": "20", "lat": "52.445614", "lon": "-2.129931"},
348 | {"mac": "e415f6f6d4d0", "url": "202.127.177.27:8074", "id": "PM96vn", "snr": "24", "lat": "36.550000", "lon": "139.800000"},
349 | {"mac": "883f4aabaff6", "url": "69.27.184.58:8074", "id": "KFSNW", "snr": "15", "lat": "37.384275", "lon": "-122.413133"},
350 | {"mac": "2476257e1bc4", "url": "109.194.11.214:8073", "id": "R3YBN", "snr": "15", "lat": "53.300000", "lon": "34.250000"},
351 | {"mac": "38d2697ccb40", "url": "jp7fso.proxy.kiwisdr.com:8073", "id": "JP7FSO", "snr": "24", "lat": "37.669419", "lon": "140.491418"},
352 | {"mac": "e415f6f80bc2", "url": "192.168.1.148:8073", "id": "E0MAH", "snr": "2", "lat": "53.610000", "lon": "-1.360000"},
353 | {"mac": "c4f312753037", "url": "sdr-amradioantennas.com:8074", "id": "VK3KHZ/4", "snr": "12", "lat": "-37.817000", "lon": "145.288000"},
354 | {"mac": "e062346fd635", "url": "rvrgm.asuscomm.com:8073", "id": "OF77vq", "snr": "8", "lat": "-32.330000", "lon": "115.820000"},
355 | {"mac": "78047347a2bc", "url": "n4dkd.asuscomm.com:8901", "id": "N4DKD", "snr": "11", "lat": "33.380000", "lon": "-86.720000"},
356 | {"mac": "40bd32e4d538", "url": "n0emp.ddns.net:8073", "id": "N0EMP", "snr": "21", "lat": "40.480000", "lon": "-105.070000"},
357 | {"mac": "40bd32e93a4d", "url": "85.183.11.108:8073", "id": "DF3LZ", "snr": "32", "lat": "53.450757", "lon": "10.220651"},
358 | {"mac": "1442fc0f74f4", "url": "9k2ra-4.proxy.kiwisdr.com:8073", "id": "LL39xi/3", "snr": "26", "lat": "29.364500", "lon": "47.988899"},
359 | {"mac": "5051a9987dbc", "url": "sdr.hfunderground.com:8074", "id": "W3HFU", "snr": "23", "lat": "39.704000", "lon": "-76.974000"},
360 | {"mac": "0035ff9cf993", "url": "g4fui.ddns.net:8073", "id": "G4FUI/IO84pp", "snr": "17", "lat": "54.670000", "lon": "-2.730000"},
361 | {"mac": "985dad493529", "url": "sdr.tambov.gq:8901", "id": "LO02ss", "snr": "0", "lat": "52.763229", "lon": "41.502566"},
362 | {"mac": "0cb2b7d6da9a", "url": "kb1.psokiwi.net:8073", "id": "SDXLKB1", "snr": "0", "lat": "60.587472", "lon": "26.448102"},
363 | {"mac": "689e198fab29", "url": "sergiocorda.synology.me:58073", "id": "JM49nf/3", "snr": "20", "lat": "39.220000", "lon": "9.130000"},
364 | {"mac": "0035ff8df93e", "url": "kiwisdr.dynpc.net:8073", "id": "DO1TI", "snr": "27", "lat": "53.430000", "lon": "9.770000"},
365 | {"mac": "985dad7f14e8", "url": "n1bpd.net:8073", "id": "N1BPD", "snr": "18", "lat": "41.703720", "lon": "-70.155635"},
366 | {"mac": "883f4a8c7e84", "url": "hl3amo.ddns.net:8074", "id": "HL3AMO/4", "snr": "16", "lat": "36.387000", "lon": "127.321000"},
367 | {"mac": "6433db1fbc61", "url": "tustinfarm.ddns.net:2311", "id": "KX4AZ", "snr": "11", "lat": "44.114150", "lon": "-85.459500"},
368 | {"mac": "e415f6f487e9", "url": "sk6ag1.ddns.net:8071", "id": "JO67nl", "snr": "29", "lat": "57.493215", "lon": "13.097758"},
369 | {"mac": "9884e3938a46", "url": "winsenallerkiwi.ddns.net:8076", "id": "WinsenAller", "snr": "3", "lat": "52.673055", "lon": "9.871644"},
370 | {"mac": "78047338ad5c", "url": "69.27.184.58:8073", "id": "KFSOmni", "snr": "15", "lat": "37.390000", "lon": "-122.410000"},
371 | {"mac": "985dad382ef0", "url": "141.135.55.42:8073", "id": "ON7AVC", "snr": "22", "lat": "50.8549541", "lon": "4.3053505"},
372 | {"mac": "985dad7f80cb", "url": "sdrbris.proxy.kiwisdr.com:8073", "id": "QG62ms", "snr": "12", "lat": "-27.220000", "lon": "153.010000"},
373 | {"mac": "883f4aab0c13", "url": "69.27.184.58:8076", "id": "KFSSE", "snr": "12", "lat": "37.383136", "lon": "-122.413261"},
374 | {"mac": "74e182a7b32a", "url": "alfaromeo170.myqnapcloud.com:8073", "id": "JO61al", "snr": "8", "lat": "51.480518", "lon": "12.033653"},
375 | {"mac": "0cb2b7d6efbe", "url": "km6cq.hopto.org:8073", "id": "KM6CQ", "snr": "13", "lat": "39.310000", "lon": "-119.790000"},
376 | {"mac": "04a316bd7f88", "url": "kiwisdr.ku4by.com:8073", "id": "KU4BY", "snr": "23", "lat": "36.250000", "lon": "-76.220000"},
377 | {"mac": "883f4a9cc9a5", "url": "nw8s-kiwi.ddns.net:8073", "id": "NW8S", "snr": "26", "lat": "41.404660", "lon": "-82.116985"},
378 | {"mac": "e415f6f74439", "url": "213.109.126.8:8073", "id": "PD0OHW/3", "snr": "40", "lat": "53.110000", "lon": "6.970000"},
379 | {"mac": "6433db4655cb", "url": "80.56.195.123:8073", "id": "JO22jl", "snr": "2", "lat": "52.474033", "lon": "4.809525"},
380 | {"mac": "fc6947b8273d", "url": "sk6ag2.ddns.net:8072", "id": "SK6AG", "snr": "28", "lat": "57.720000", "lon": "13.070000"},
381 | {"mac": "40bd32c8d063", "url": "s57bit.proxy.kiwisdr.com:8073", "id": "S57BIT", "snr": "19", "lat": "46.170000", "lon": "14.300000"},
382 | {"mac": "40bd32e55056", "url": "67.170.2.228:8086", "id": "WA7HL", "snr": "12", "lat": "48.760000", "lon": "-122.510000"},
383 | {"mac": "e415f6f74ae1", "url": "birdsnest.zapto.org:8073", "id": "JO32qk", "snr": "22", "lat": "52.430000", "lon": "7.340000"},
384 | {"mac": "40bd32e518e2", "url": "sdr.hfunderground.com:8073", "id": "W3HFU/1/3", "snr": "27", "lat": "39.704000", "lon": "-76.974000"},
385 | {"mac": "884aeaf58c0f", "url": "s4wmv4hovyls5ebz.myfritz.net:8073", "id": "SWLJO43/1", "snr": "37", "lat": "53.310000", "lon": "9.990000"},
386 | {"mac": "780473836210", "url": "w7pua-2.ddns.net:8073", "id": "W7PUA", "snr": "17", "lat": "44.676700", "lon": "-123.227333"},
387 | {"mac": "b8804f25cd5a", "url": "kiwisdr-bern.try.yaler.io:80", "id": "JN36qw", "snr": "37", "lat": "46.955462", "lon": "7.367836"},
388 | {"mac": "883f4aa8cf2b", "url": "home.jeffreyrandow.org:8075", "id": "N5SNT", "snr": "12", "lat": "29.672000", "lon": "-98.116000"},
389 | {"mac": "40bd32c8d498", "url": "kiwistbg.ddns.net:8074", "id": "HB9TTU/4", "snr": "15", "lat": "47.385100", "lon": "8.915500"},
390 | {"mac": "5051a998d422", "url": "jimlill.com:8073", "id": "WA2ZKD/3", "snr": "11", "lat": "43.126741", "lon": "-77.584850"},
391 | {"mac": "b0d5cc552cf3", "url": "202.127.177.27:8073", "id": "PM96vn/3", "snr": "22", "lat": "36.550000", "lon": "139.800000"},
392 | {"mac": "1442fc0f6654", "url": "83.128.85.68:8073", "id": "PI4AMF/JO22q", "snr": "34", "lat": "52.240202", "lon": "5.429781"},
393 | {"mac": "b827eb5ebc99", "url": "tredxk.no-ip.org:8073", "id": "KP11wm/3", "snr": "27", "lat": "61.528000", "lon": "23.902000"},
394 | {"mac": "38d269837ec7", "url": "boavista.twrmon.net:8073", "id": "TWR/BoaVista", "snr": "18", "lat": "2.820000", "lon": "-60.670000"},
395 | {"mac": "40bd32e4c8b1", "url": "dl4qb.proxy.kiwisdr.com:8073", "id": "DL4QB", "snr": "30", "lat": "51.760000", "lon": "7.390000"},
396 | {"mac": "0035ff98e239", "url": "59.167.177.246:8073", "id": "VK3JTM", "snr": "15", "lat": "-37.290743", "lon": "142.939774"},
397 | {"mac": "985dad51600d", "url": "sdr.m0taz.co.uk:8073", "id": "M0TAZ", "snr": "21", "lat": "51.583729", "lon": "0.199700"},
398 | {"mac": "40bd32c8d6b4", "url": "beefy.fun:8073", "id": "FN42nl", "snr": "22", "lat": "42.489110", "lon": "-70.904797"},
399 | {"mac": "1442fc0f60c9", "url": "kiwisdr1.hoka.co.uk:8072", "id": "STNB/2", "snr": "20", "lat": "51.292581", "lon": "0.979165"},
400 | {"mac": "b827ebed9a7e", "url": "kb1vwc.ddns.net:8073", "id": "KB1VWC", "snr": "23", "lat": "41.570000", "lon": "-70.550000"},
401 | {"mac": "38d2697cbb58", "url": "78.71.162.126:8073", "id": "JO57uq", "snr": "30", "lat": "57.691322", "lon": "11.684921"},
402 | {"mac": "9884e38cd8b8", "url": "vk6qs.proxy.kiwisdr.com:8073", "id": "VK6QS", "snr": "32", "lat": "-32.360000", "lon": "116.620000"},
403 | {"mac": "c4f312b9fac5", "url": "12.29.214.134:8073", "id": "WO7I", "snr": "24", "lat": "40.920000", "lon": "-117.760000"},
404 | {"mac": "6433db4655b3", "url": "kiwisdr.ve7av.ca:8073", "id": "VE7AV", "snr": "16", "lat": "53.810000", "lon": "-122.830000"},
405 | {"mac": "780473832538", "url": "k1fb.proxy.kiwisdr.com:8073", "id": "EM66mf", "snr": "10", "lat": "36.240000", "lon": "-86.920000"},
406 | {"mac": "40bd32e53ceb", "url": "kk6pr.ddns.net:8075", "id": "KK6PR", "snr": "16", "lat": "44.426300", "lon": "-121.262300"},
407 | {"mac": "60640538d7b9", "url": "kphsdr.com:8073", "id": "CM88mc/3", "snr": "14", "lat": "38.100000", "lon": "-122.950000"},
408 | {"mac": "6433db465592", "url": "kiwi.dol.la:8073", "id": "ScratchMoney", "snr": "14", "lat": "30.109691", "lon": "-92.124861"},
409 | {"mac": "38d2697cbb55", "url": "sdr-amradioantennas.com:8071", "id": "VK3KHZ/1", "snr": "12", "lat": "-37.817000", "lon": "145.288000"},
410 | {"mac": "883f4aa8b65c", "url": "2gbl9qiptwfhej62.myfritz.net:8073", "id": "JO62rb", "snr": "23", "lat": "52.050000", "lon": "13.430000"},
411 | {"mac": "1442fc0f74ee", "url": "84.3.151.98:8073", "id": "HA2NA", "snr": "30", "lat": "47.810110", "lon": "18.747200"},
412 | {"mac": "780473393a41", "url": "kiwi.ve7gl.ca:8073", "id": "VE7GL", "snr": "16", "lat": "49.090000", "lon": "-122.010000"},
413 | {"mac": "883f4aa8cf1c", "url": "lu4eec.ddns.net:8073", "id": "LU4EEC", "snr": "11", "lat": "-34.656060", "lon": "-58.541084"},
414 | {"mac": "40bd322ea01e", "url": "209.115.233.71:8074", "id": "ve6ars2", "snr": "15", "lat": "50.080000", "lon": "-113.680000"},
415 | {"mac": "40bd32c8d2d0", "url": "kiwiradio.proxy.kiwisdr.com:8073", "id": "JN97tf", "snr": "31", "lat": "47.240000", "lon": "19.610000"},
416 | {"mac": "b8804f25c900", "url": "boezberg600m.ddns.net:8073", "id": "JN47bl", "snr": "11", "lat": "47.499476", "lon": "8.154871"},
417 | {"mac": "04a316ee0fa3", "url": "hg5acz.ddns.net:8073", "id": "HG5ACZ", "snr": "22", "lat": "47.691040", "lon": "17.253259"},
418 | {"mac": "247d4d1b6834", "url": "jimlill.com:8074", "id": "WA2ZKD/4", "snr": "0", "lat": "43.126741", "lon": "-77.584850"},
419 | {"mac": "d0ff50091fd3", "url": "hfrx.ddns.net:8073", "id": "XE2MCC", "snr": "6", "lat": "24.029643", "lon": "-104.660274"},
420 | {"mac": "6433db1bde10", "url": "kiwi.dl7vdx.com:8073", "id": "DL7VDX", "snr": "39", "lat": "52.658220", "lon": "13.781170"},
421 | {"mac": "b8804f25c910", "url": "shtsf.ddns.net:8073", "id": "F6KOH", "snr": "18", "lat": "49.508367", "lon": "0.162412"},
422 | {"mac": "40bd32c8d48f", "url": "80.75.112.98:8074", "id": "HB9NF/4", "snr": "11", "lat": "47.328590", "lon": "8.961670"},
423 | {"mac": "985dad7f5e27", "url": "lu4aa.proxy.kiwisdr.com:8073", "id": "LU5AGQ", "snr": "22", "lat": "-34.866789", "lon": "-58.139648"},
424 | {"mac": "e415f6f785fd", "url": "sdxlkiwi7.proxy.kiwisdr.com:8073", "id": "KP22ag", "snr": "18", "lat": "62.265653", "lon": "24.032185"},
425 | {"mac": "40bd32e9420f", "url": "kiwi.narodnaya.keenetic.link:80", "id": "KO37xu", "snr": "29", "lat": "57.855869", "lon": "27.950980"},
426 | {"mac": "04a316fd98d4", "url": "hb9exc.iotvs.ch:8073", "id": "HB9EXC", "snr": "25", "lat": "46.135100", "lon": "7.116000"}
427 | ]


--------------------------------------------------------------------------------
/compute_ultimate.py:
--------------------------------------------------------------------------------
   1 | #!/usr/bin/python
   2 | # -*- coding: utf-8 -*-
   3 | """ compute_ultimate python code. """
   4 |
   5 | # python 2/3 compatibility
   6 | from __future__ import print_function
   7 | from __future__ import division
   8 | from __future__ import absolute_import
   9 |
  10 | import glob
  11 | import sys
  12 | import json
  13 | import os
  14 | from os.path import dirname as up
  15 | import re
  16 | import signal
  17 | import subprocess
  18 | import threading
  19 | import time
  20 | import math
  21 | import platform
  22 | import webbrowser
  23 | from io import BytesIO
  24 | from collections import OrderedDict
  25 | import numpy as np
  26 | import matplotlib.pyplot as plt
  27 | from matplotlib.colors import LinearSegmentedColormap
  28 | from PIL import Image, ImageTk
  29 |
  30 | # python 2/3 compatibility
  31 | if sys.version_info[0] == 2:
  32 |     import tkMessageBox
  33 |     from Tkinter import Checkbutton, CURRENT, IntVar, Listbox
  34 |     from Tkinter import Entry, Text, Menu, Label, Button, Frame, Tk, PhotoImage, Canvas
  35 |     from tkFont import Font
  36 |
  37 | else:
  38 |     import tkinter.messagebox as tkMessageBox
  39 |     from tkinter import Checkbutton, CURRENT, IntVar, Listbox
  40 |     from tkinter import Entry, Text, Menu, Label, Button, Frame, Tk, PhotoImage, Canvas
  41 |     from tkinter.font import Font
  42 |
  43 | VERSION = "ultimateTDoA interface v2.10 "
  44 | for mfi_le in glob.glob('*.*m*'):
  45 |     ff = open(mfi_le, 'r')
  46 |     fi_le_d = ff.read()
  47 |     ff.close()
  48 |     FREQUENCY = re.search(r".+title.+\'(.+)\s-\sR.+\'", fi_le_d).group(1)
  49 | ALEID = ""
  50 | CLICKEDNODE = ""
  51 | if str(os.getcwd().rsplit("_", 2)[1]) == "UA":
  52 |     for ale_file in glob.glob(os.getcwd() + os.sep + "ALE*.txt"):
  53 |         a = open(ale_file, 'r')
  54 |         aledata = a.read()
  55 |         a.close()
  56 |         try:
  57 |             ALEID = " [ALE ID: " + str(re.search(r".+\[(TWS|TIS)\]\[(.*)\]\[", aledata).group(2)) + "]"
  58 |         except AttributeError:
  59 |             ALEID = " [ALE]"
  60 |
  61 | cdict1 = {
  62 |     'red': ((0.0, 0.0, 0.0),
  63 |             (0.077, 0.0, 0.0),
  64 |             (0.16, 0.0, 0.0),
  65 |             (0.265, 1.0, 1.0),
  66 |             (0.403, 1.0, 1.0),
  67 |             (0.604, 1.0, 1.0),
  68 |             (1.0, 1.0, 1.0)),
  69 |
  70 |     'green': ((0.0, 0.0, 0.0),
  71 |               (0.077, 0.0, 0.0),
  72 |               (0.16, 1.0, 1.0),
  73 |               (0.265, 1.0, 1.0),
  74 |               (0.403, 0.0, 0.0),
  75 |               (0.604, 0.0, 0.0),
  76 |               (1.0, 0.764, 0.764)),
  77 |
  78 |     'blue': ((0.0, 0.117, 0.117),
  79 |              (0.077, 1.0, 1.0),
  80 |              (0.16, 1.0, 1.0),
  81 |              (0.265, 0.0, 0.0),
  82 |              (0.403, 0.0, 0.0),
  83 |              (0.604, 1.0, 1.0),
  84 |              (1.0, 1.0, 1.0)),
  85 | }
  86 |
  87 | COLORMAP = LinearSegmentedColormap('SAColorMap', cdict1, 1024)
  88 |
  89 |
  90 | class Restart(object):
  91 |     """ GUI Restart routine. """
  92 |
  93 |     def __init__(self):
  94 |         pass
  95 |
  96 |     def __str__(self):
  97 |         return self.__class__.__name__
  98 |
  99 |     @staticmethod
 100 |     def run():
 101 |         """ GUI Restart routine. """
 102 |         try:  # to kill octave-cli process if exists
 103 |             os.kill(PROC_PID, signal.SIGTERM)
 104 |         except (NameError, OSError):
 105 |             pass
 106 |         if platform.system() == "Windows":
 107 |             os.execlp("pythonw.exe", "pythonw.exe", "compute_ultimate.py")
 108 |         else:
 109 |             os.execv(sys.executable, [sys.executable] + sys.argv)
 110 |
 111 |
 112 | class ReadKnownPointFile(threading.Thread):
 113 |     """ Read known location list routine (see directTDoA_knownpoints.db file). """
 114 |
 115 |     def __init__(self):
 116 |         super(ReadKnownPointFile, self).__init__()
 117 |
 118 |     def run(self):
 119 |         """ Read known location list routine (see directTDoA_knownpoints.db file). """
 120 |         with open(up(up(up(os.getcwd()))) + os.sep + "directTDoA_knownpoints.db") as h:
 121 |             global my_info1, my_info2, my_info3
 122 |             i = 3  # skip the 3x comment lines at start of the text file database
 123 |             lines = h.readlines()
 124 |             my_info1 = []
 125 |             my_info2 = []
 126 |             my_info3 = []
 127 |             while i < sum(1 for _ in open(up(up(up(os.getcwd()))) + os.sep + "directTDoA_knownpoints.db")):
 128 |                 inforegexp = re.search(r"(.*),(.*),(.*)", lines[i])
 129 |                 my_info1.append(inforegexp.group(1))
 130 |                 my_info2.append(inforegexp.group(2))
 131 |                 my_info3.append(inforegexp.group(3))
 132 |                 i += 1
 133 |         h.close()
 134 |
 135 |
 136 | class ReadCfg(object):
 137 |     """ DirectKiwi configuration file read process. """
 138 |
 139 |     def __init__(self):
 140 |         pass
 141 |
 142 |     @staticmethod
 143 |     def read_cfg():
 144 |         """ compute_ultimate.py configuration file read process. """
 145 |         global CFG, DX0, DY0, DX1, DY1, DMAP
 146 |         global POICOLOR, ICONSIZE, ICONTYPE, HIGHLIGHT
 147 |         global BGC, FGC, CONS_B, CONS_F, MAP_BOX, GUI
 148 |         try:
 149 |             # Read the config file v5.0 format and declare variables
 150 |             with open(up(up(up(os.getcwd()))) + os.sep + 'directTDoA.cfg', 'r') as config_file:
 151 |                 CFG = json.load(config_file, object_pairs_hook=OrderedDict)
 152 |             DX0, DX1 = CFG["map"]["x0"], CFG["map"]["x1"]
 153 |             DY0, DY1 = CFG["map"]["y0"], CFG["map"]["y1"]
 154 |             DMAP, ICONSIZE = CFG["map"]["file"], CFG["map"]["iconsize"]
 155 |             POICOLOR, ICONTYPE = CFG["map"]["poi"], CFG["map"]["icontype"]
 156 |             HIGHLIGHT = CFG["map"]["hlt"]
 157 |             BGC, FGC = CFG["guicolors"]["main_b"], CFG["guicolors"]["main_f"]
 158 |             CONS_B, CONS_F = CFG["guicolors"]["cons_b"], CFG["guicolors"]["cons_f"]
 159 |             MAP_BOX, GUI = CFG["map"]["mapbox"], CFG["map"]["gui"]
 160 |         except (ImportError, ValueError):
 161 |             sys.exit("config file not found")
 162 |
 163 |
 164 | class TrimIQ(threading.Thread):
 165 |     """ trim_iq.py processing routine """
 166 |
 167 |     def __init__(self, tdoa_rootdir):
 168 |         super(TrimIQ, self).__init__()
 169 |         self.tdoa_rootdir = tdoa_rootdir
 170 |
 171 |     def run(self):
 172 |         APP.gui.writelog("trim_iq.py script started.")
 173 |         APP.gui.writelog("Click & drag : Select the time portion of the IQ record that you want to keep.")
 174 |         APP.gui.writelog("Close window : No change made to the IQ.")
 175 |         APP.gui.writelog("Single click : Deletes IQ.")
 176 |         APP.gui.writelog("< 2 seconds  : Deletes IQ.")
 177 |         subprocess.call([sys.executable, 'trim_iq.py'], cwd=self.tdoa_rootdir, shell=False)
 178 |         Restart().run()
 179 |
 180 |
 181 | class PlotIQ(threading.Thread):
 182 |     """ Plot_iq, enhanced version with SNR ranking. """
 183 |
 184 |     def __init__(self, iqfile, mode, filelist):
 185 |         super(PlotIQ, self).__init__()
 186 |         self.iqfile = iqfile
 187 |         self.plot_mode = mode
 188 |         self.filelist = filelist
 189 |
 190 |     def run(self):
 191 |         global scores
 192 |         plt.rcParams.update({'figure.max_open_warning': 0})
 193 |         # mode 0 = GUI display preview
 194 |         # mode 1 = temp.pdf (for a run with 3 < nodes < 6)
 195 |         if self.plot_mode == 1:
 196 |             files = {path: self.load(path) for path in self.filelist}
 197 |             scores = sorted([(path, self.score(data)) for path, data in files.items()], key=lambda item: item[1],
 198 |                             reverse=True)
 199 |             self.plot(files, scores, cols=3, iqfile=files)
 200 |         else:
 201 |             self.plot(self.load(self.iqfile), order=None, cols=1, iqfile=self.iqfile)
 202 |
 203 |     @staticmethod
 204 |     def load(path):
 205 |         """ Remove GNSS from IQ recordings. """
 206 |         buf = BytesIO()
 207 |         with open(path, 'rb') as f:
 208 |             size = os.path.getsize(path)
 209 |             for i in range(62, size, 2074):
 210 |                 f.seek(i)
 211 |                 buf.write(f.read(2048))
 212 |         data = np.frombuffer(buf.getvalue(), dtype='int16')
 213 |         data = data[0::2] + 1j * data[1::2]
 214 |         return data
 215 |
 216 |     @staticmethod
 217 |     def score(data):
 218 |         """ IQ SNR calculation. """
 219 |         max_snr = 0.0
 220 |         for offset in range(12000, len(data), 512):
 221 |             snr = np.std(np.fft.fft(data[offset:], n=1024))
 222 |             if snr > max_snr:
 223 |                 max_snr = snr
 224 |         return max_snr
 225 |
 226 |     @staticmethod
 227 |     def has_gps(path):
 228 |         """ Detect if IQ file has GPS GNSS data (in test). """
 229 |         gpslast = 0
 230 |         f_wav = open(path, 'rb')
 231 |         for i in range(2118, os.path.getsize(path), 2074):
 232 |             f_wav.seek(i)
 233 |             if sys.version_info[0] < 3:
 234 |                 gpslast = max(gpslast, ord(f_wav.read(1)[0]))
 235 |             else:
 236 |                 gpslast = max(gpslast, f_wav.read(1)[0])
 237 |         return 0 < gpslast < 254
 238 |
 239 |     @staticmethod
 240 |     def plot(files, order, cols, iqfile):
 241 |         if not order:
 242 |             # mode 0
 243 |             global CLICKEDNODE
 244 |             CLICKEDNODE = iqfile.rsplit('_', 3)[2]
 245 |             buf = BytesIO()
 246 |             fig, a_x = plt.subplots()
 247 |             a_x.specgram(files, NFFT=1024, Fs=12000, window=lambda data: data * np.hanning(len(data)), noverlap=512,
 248 |                          vmin=10, vmax=200, cmap=COLORMAP)
 249 |             a_x.set_title(iqfile.rsplit('_', 3)[2])
 250 |             a_x.axes.get_yaxis().set_visible(False)
 251 |             plt.savefig(buf, bbox_inches='tight')
 252 |             img = ImageTk.PhotoImage(Image.open(buf).resize((320, 240), Image.ANTIALIAS))
 253 |             APP.gui.plot_iq_button.configure(image=img)
 254 |             APP.gui.plot_iq_button.image = img
 255 |         else:
 256 |             # mode 1
 257 |             rows = int(math.ceil(len(files) / cols))
 258 |             fig, axs = plt.subplots(ncols=cols, nrows=rows)
 259 |             fig.set_figwidth(cols * 5.27)
 260 |             fig.set_figheight(rows * 3)
 261 |             for i, (path, _) in enumerate(order):
 262 |                 a_x = axs.flat[i]
 263 |                 a_x.specgram(files[path], NFFT=1024, Fs=12000, window=lambda data: data * np.hanning(len(data)),
 264 |                              noverlap=512, vmin=10, vmax=200, cmap=COLORMAP)
 265 |                 a_x.set_title(path.rsplit('_', 3)[2])
 266 |                 a_x.axes.get_yaxis().set_visible(False)
 267 |             for i in range(len(scores), len(axs.flat)):
 268 |                 fig.delaxes(axs.flat[i])
 269 |             fig.savefig('TDoA_' + str(path.rsplit("_", 3)[1]) + '_temp.pdf', bbox_inches='tight')
 270 |
 271 |
 272 | class OctaveProcessing(threading.Thread):
 273 |     """ Octave processing routine """
 274 |
 275 |     def __init__(self, input_file, tdoa_rootdir, log_file):
 276 |         super(OctaveProcessing, self).__init__()
 277 |         self.m_file_to_process = input_file
 278 |         self.tdoa_rootdir = tdoa_rootdir
 279 |         self.log_file = log_file
 280 |
 281 |     def run(self):
 282 |         global PROC_PID  # stdout
 283 |         APP.gui.console_window.configure(bg=CONS_B, fg=CONS_F)
 284 |         octave_errors = [b'index-out-of-bounds', b'< 2 good stations found', b'Octave:nonconformant - args',
 285 |                          b'n_stn=2 is not supported', b'resample.m: p and q must be positive integers',
 286 |                          b'Octave:invalid-index', b'incomplete \'data\' chunk',
 287 |                          b'reshape: can\'t reshape 0x0 array to 242x258 array', b'malformed filename:',
 288 |                          b'element number 1 undefined in return list']
 289 |         proc = subprocess.Popen(['octave-cli', self.m_file_to_process], cwd=self.tdoa_rootdir, stderr=subprocess.STDOUT,
 290 |                                 stdout=subprocess.PIPE, shell=False)
 291 |         PROC_PID = proc.pid
 292 |         if PROC_PID:
 293 |             APP.gui.writelog("ultimateTDoA process started.")
 294 |         logfile = open(self.log_file, 'w')
 295 |         if sys.version_info[0] == 2:
 296 |             for octave_output in proc.stdout:
 297 |                 logfile.write(octave_output)
 298 |                 if any(x in octave_output for x in octave_errors):
 299 |                     APP.gui.console_window.configure(bg='#800000', fg='white')
 300 |                     ProcessFailed(octave_output).start()
 301 |                     proc.terminate()
 302 |                 if b"finished" in octave_output:
 303 |                     logfile.close()
 304 |                     ProcessFinished(self.log_file).start()
 305 |                     proc.terminate()
 306 |         else:
 307 |             octave_output = proc.communicate()[0]
 308 |             logfile.write(str(octave_output, 'utf-8'))
 309 |             if any(x in octave_output for x in octave_errors):
 310 |                 APP.gui.console_window.configure(bg='#800000', fg='white')
 311 |                 ProcessFailed(octave_output).start()
 312 |                 proc.terminate()
 313 |             if b"finished" in octave_output:
 314 |                 logfile.close()
 315 |                 ProcessFinished(self.log_file).start()
 316 |                 proc.terminate()
 317 |         proc.wait()
 318 |
 319 |
 320 | class ProcessFailed(threading.Thread):
 321 |     """ The actions to perform when a TDoA run has failed. """
 322 |
 323 |     def __init__(self, returned_error):
 324 |         super(ProcessFailed, self).__init__()
 325 |         self.Returned_error = returned_error
 326 |
 327 |     def run(self):
 328 |         global tdoa_in_progress  # TDoA process status
 329 |         APP.gui.writelog(
 330 |             "TDoA process error.\n" + bytes.decode(self.Returned_error).rsplit(",\n\t\"stack", 1)[0].replace(
 331 |                 "{\n\t\"identifier\": \"\",\n\t", ""))
 332 |         APP.gui.compute_button.configure(text="Compute")
 333 |         tdoa_in_progress = 0
 334 |
 335 |
 336 | class ProcessFinished(threading.Thread):
 337 |     """ The actions to perform when a TDoA run has finished. """
 338 |
 339 |     def __init__(self, log_file):
 340 |         super(ProcessFinished, self).__init__()
 341 |         self.log_file = log_file
 342 |
 343 |     def run(self):
 344 |         global tdoa_in_progress  # TDoA process status
 345 |         APP.gui.compute_button.configure(text="Compute")
 346 |         tdoa_in_progress = 0
 347 |         with open(os.getcwd() + os.sep + self.log_file, 'r') as read_file:
 348 |             content = read_file.readlines()
 349 |             for line in content:
 350 |                 if "last_gnss_fix" in line:
 351 |                     APP.gui.writelog("  " + " ".join(line.rstrip().rsplit(" ", 5)[2:]))
 352 |                 if "position" in line:
 353 |                     APP.gui.writelog("  " + line.rstrip())
 354 |                 if "tdoa_plot_map_combined" in line:
 355 |                     APP.gui.writelog("  " + line.rstrip())
 356 |         APP.gui.writelog("TDoA process finished successfully.")
 357 |         if open_pdf.get() == 1:
 358 |             if platform.system() == "Windows":
 359 |                 os.system('start ' + sorted(glob.iglob('*.pdf'), key=os.path.getctime)[-1])
 360 |             elif platform.system() == "Darwin":
 361 |                 subprocess.Popen(["open", os.getcwd() + os.sep + sorted(glob.iglob('*.pdf'), key=os.path.getctime)[-1]])
 362 |             else:
 363 |                 subprocess.Popen(
 364 |                     ["xdg-open", os.getcwd() + os.sep + sorted(glob.iglob('*.pdf'), key=os.path.getctime)[-1]])
 365 |         for spec_file in glob.glob(os.getcwd() + os.sep + "*temp.pdf"):
 366 |             os.remove(spec_file)
 367 |
 368 |
 369 | class FillMapWithNodes(threading.Thread):
 370 |     """ process to display the nodes on the World Map. """
 371 |
 372 |     def __init__(self, parent):
 373 |         super(FillMapWithNodes, self).__init__()
 374 |         self.parent = parent
 375 |
 376 |     def run(self):
 377 |         """ ultimate interface process to display the nodes on the World Map. """
 378 |         global tag_list, node_file, node_list, deleted_file, ranking_scale
 379 |         tag_list = []
 380 |         node_list = []
 381 |         node_file = []
 382 |         deleted_file = 0
 383 |         ranking_scale = []
 384 |         point_list = []
 385 |         for wavfiles in glob.glob('*.wav'):
 386 |             if PlotIQ.has_gps(wavfiles):
 387 |                 node_snr_rank = PlotIQ.score(PlotIQ.load(wavfiles))
 388 |                 ranking_scale.append(node_snr_rank)
 389 |                 tdoa_id = re.search(r'(.*)_(.*)_iq.wav', wavfiles)
 390 |                 node_list.append(tdoa_id.group(2))
 391 |                 node_file.append(wavfiles)
 392 |                 with open(up(up(os.getcwd())) + os.sep + "gnss_pos" + os.sep + tdoa_id.group(2) + ".txt", "rt") as gnss:
 393 |                     contents = gnss.read()
 394 |                     info = re.search(r'd\.(.+?)\s.+\W.\[(.*),(.*)\], \'host\', \'(.+?)\', \'port\', (.+?)\);', contents)
 395 |                 nodeinfo = dict(
 396 |                     url=(info.group(4) + ":" + info.group(5)),
 397 |                     lat=info.group(2),
 398 |                     lon=info.group(3),
 399 |                     id=info.group(1),
 400 |                     snr=str(node_snr_rank)
 401 |                 )
 402 |                 point_list.append([nodeinfo, node_snr_rank])
 403 |             else:
 404 |                 os.rename(wavfiles, wavfiles + ".nogps")
 405 |                 deleted_file += 1
 406 |         if 'APP' in globals():
 407 |             APP.gui.writelog(str(len(node_file)) + " nodes are available for this run.")
 408 |         if deleted_file > 0:
 409 |             APP.gui.writelog(str(deleted_file) + " node(s) excluded because of missing GPS data.")
 410 |         for it in point_list:
 411 |             self.add_point(it[0], (it[1] - min(ranking_scale)) * (1/(max(ranking_scale) - min(ranking_scale)) * 255))
 412 |
 413 |     @staticmethod
 414 |     def convert_lat(lat):
 415 |         """ Convert the real node latitude coordinates to adapt to GUI window map geometry. """
 416 |         # nodes are between LATITUDE 0 and 90N
 417 |         if float(lat) > 0:
 418 |             return 990 - (float(lat) * 11)
 419 |         # nodes are between LATITUDE 0 and 60S
 420 |         return 990 + (float(0 - float(lat)) * 11)
 421 |
 422 |     @staticmethod
 423 |     def convert_lon(lon):
 424 |         """ Convert the real node longitude coordinates to adapt to GUI window map geometry. """
 425 |         return 1910 + ((float(lon) * 1910) / 180)
 426 |
 427 |     def add_point(self, node_db_data, snr_rank):
 428 |         """ Process that add node icons over the World map. """
 429 |         global tag_list
 430 |         mykeys = ['url', 'id', 'lat', 'lon', 'snr']
 431 |         node_lat = self.convert_lat(node_db_data["lat"])
 432 |         node_lon = self.convert_lon(node_db_data["lon"])
 433 |         node_tag = str('$'.join([node_db_data[x] for x in mykeys]))
 434 |         node_tag = node_tag.rsplit('$', 1)[0] + "$%g" % round(snr_rank, 0)
 435 |         ic_size = int(ICONSIZE)
 436 |         try:
 437 |             if ICONTYPE == 0:
 438 |                 self.parent.canvas.create_oval(node_lon - ic_size, node_lat - ic_size, node_lon + ic_size,
 439 |                                                node_lat + ic_size, fill=self.color_variant(snr=snr_rank), tag=node_tag)
 440 |             else:
 441 |                 self.parent.canvas.create_rectangle(node_lon - ic_size, node_lat - ic_size, node_lon + ic_size,
 442 |                                                     node_lat + ic_size, fill=self.color_variant(snr=snr_rank),
 443 |                                                     tag=node_tag)
 444 |             self.parent.canvas.tag_bind(node_tag, "<Button-1>", self.parent.onclickleft)
 445 |             tag_list.append(node_tag)
 446 |         except NameError:
 447 |             print("OOPS - Error in adding the point to the map")
 448 |
 449 |     def delete_point(self, map_definition):
 450 |         """ Map presets deletion process. """
 451 |         self.parent.canvas.delete(map_definition)
 452 |
 453 |     @staticmethod
 454 |     def color_variant(snr):
 455 |         green_val = min([255, max([0, int(snr)])])
 456 |         return "#00" + "".join("0" + hex(green_val)[2:] if len(hex(green_val)[2:]) < 2 else hex(green_val)[2:]) + "00"
 457 |
 458 |     @staticmethod
 459 |     def get_font_color(font_color):
 460 |         """ Adapting the foreground font color regarding background luminosity.
 461 |         stackoverflow questions/946544/good-text-foreground-color-for-a-given-background-color """
 462 |         rgb_hex = [font_color[x:x + 2] for x in [1, 3, 5]]
 463 |         threshold = 120  # default = 120
 464 |         if int(rgb_hex[0], 16) * 0.299 + int(rgb_hex[1], 16) * 0.587 + int(rgb_hex[2], 16) * 0.114 > threshold:
 465 |             return "#000000"
 466 |         # else:
 467 |         return "#ffffff"
 468 |         # if (red*0.299 + green*0.587 + blue*0.114) > 186 use #000000 else use #ffffff
 469 |
 470 |     def node_sel_active(self, node_mac):
 471 |         """ Adding additionnal highlight on node icon. """
 472 |         for node_tag_item in tag_list:
 473 |             if node_mac in node_tag_item:
 474 |                 tmp_latlon = node_tag_item.rsplit("$", 4)
 475 |                 tmp_lat = self.convert_lat(tmp_latlon[2])
 476 |                 tmp_lon = self.convert_lon(tmp_latlon[3])
 477 |                 is_delta = int(ICONSIZE) + 1
 478 |                 if ICONTYPE == 0:
 479 |                     self.parent.canvas.create_oval(tmp_lon - is_delta, tmp_lat - is_delta, tmp_lon + is_delta,
 480 |                                                    tmp_lat + is_delta, fill='', outline=HIGHLIGHT,
 481 |                                                    tag=node_tag_item + "$#")
 482 |                 else:
 483 |                     self.parent.canvas.create_rectangle(tmp_lon - is_delta, tmp_lat - is_delta, tmp_lon + is_delta,
 484 |                                                         tmp_lat + is_delta, fill='', outline=HIGHLIGHT,
 485 |                                                         tag=node_tag_item + "$#")
 486 |                 self.parent.canvas.tag_bind(node_tag_item + "$#", "<Button-1>", self.parent.onclickleft)
 487 |
 488 |     def node_selection_inactive(self, node_mac):
 489 |         """ Removing additionnal highlight on selected node icon. """
 490 |         for node_tag_item in tag_list:
 491 |             if node_mac in node_tag_item:
 492 |                 self.parent.canvas.tag_unbind(node_tag_item + "$#", "<Button-1>")
 493 |                 self.parent.canvas.delete(node_tag_item + "$#")
 494 |
 495 |     def node_selection_inactiveall(self):
 496 |         """ Removing ALL additionnal highlights on selected nodes icons. """
 497 |         for node_tag_item in tag_list:
 498 |             self.parent.canvas.tag_unbind(node_tag_item + "$#", "<Button-1>")
 499 |             self.parent.canvas.delete(node_tag_item + "$#")
 500 |
 501 |
 502 | class GuiCanvas(Frame):
 503 |     """ Process that creates the GUI map canvas, enabling move & zoom on a picture.
 504 |     source: stackoverflow.com/questions/41656176/tkinter-canvas-zoom-move-pan?noredirect=1&lq=1 """
 505 |
 506 |     def __init__(self, parent):
 507 |         Frame.__init__(self, parent=None)
 508 |         # tip: GuiCanvas is member1
 509 |         parent.call('wm', 'iconphoto', parent, PhotoImage(file='../../../icon.gif'))
 510 |         global fulllist, mapboundaries_set, map_preset, selectedcity
 511 |         global lat_min_map, lat_max_map, lon_min_map, lon_max_map, selectedlat, selectedlon
 512 |         fulllist = []
 513 |         mapboundaries_set = None
 514 |         map_preset = 1
 515 |         ReadCfg().read_cfg()
 516 |         parent.geometry(GUI)
 517 |         parent.geometry('+0+60')
 518 |         self.x = self.y = 0
 519 |         # Create canvas and put image on it
 520 |         self.canvas = Canvas(self.master, highlightthickness=0)
 521 |         self.canvas.grid(row=0, column=0, sticky='nswe')
 522 |         self.canvas.update()  # wait till canvas is created
 523 |         # Make the canvas expandable
 524 |         self.master.rowconfigure(0, weight=1)
 525 |         self.master.columnconfigure(0, weight=1)
 526 |         # Bind events to the Canvas
 527 |         self.canvas.bind('<Configure>', self.show_image)  # canvas is resized
 528 |         self.canvas.bind('<ButtonPress-1>', self.move_from)  # map move
 529 |         self.canvas.bind('<B1-Motion>', self.move_to)  # map move
 530 |         # self.canvas.bind_all('<MouseWheel>', self.wheel)  # Windows Zoom
 531 |         # self.canvas.bind('<Button-5>', self.wheel)  # Linux Zoom
 532 |         # self.canvas.bind('<Button-4>', self.wheel)  # Linux Zoom
 533 |         self.canvas.bind("<ButtonPress-3>", self.on_button_press)  # red rectangle selection
 534 |         self.canvas.bind("<B3-Motion>", self.on_move_press)  # red rectangle selection
 535 |         self.canvas.bind("<ButtonRelease-3>", self.on_button_release)  # red rectangle selection
 536 |         self.image = Image.open(up(up(up(os.getcwd()))) + os.sep + DMAP)
 537 |         self.width, self.height = self.image.size
 538 |         self.imscale = 1.0  # scale for the image
 539 |         self.delta = 2.0  # zoom magnitude
 540 |         # Put image into container rectangle and use it to set proper coordinates to the image
 541 |         self.container = self.canvas.create_rectangle(0, 0, self.width, self.height, width=0)
 542 |         self.canvas.config(scrollregion=(0, 0, self.width, self.height))
 543 |         self.rect = None
 544 |         self.start_x = None
 545 |         self.start_y = None
 546 |         for mfil_e in glob.glob(os.getcwd() + os.sep + "proc*.empty"):
 547 |             m = open(mfil_e, 'r')
 548 |             filedata = m.read()
 549 |             m.close()
 550 |             try:
 551 |                 mapposx = re.search(r"##\s(.*),(.*)", filedata)
 552 |                 tdoa_x0 = mapposx.group(1)
 553 |                 tdoa_y0 = mapposx.group(2)
 554 |             except AttributeError:
 555 |                 tdoa_x0 = DX0
 556 |                 tdoa_y0 = DY0
 557 |             lat = re.search(r"lat_range', \[([-]?[0-9]{1,2}(\.[0-9]*)?) ?([-]?[0-9]{1,2}(\.[0-9]*|))?\]", filedata)
 558 |             lon = re.search(r"lon_range', \[([-]?[0-9]{1,3}(\.[0-9]*)?) ?([-]?[0-9]{1,3}(\.[0-9]*|))?\]", filedata)
 559 |             lat_min_map = lat.group(1)
 560 |             lat_max_map = lat.group(3)
 561 |             lon_min_map = lon.group(1)
 562 |             lon_max_map = lon.group(3)
 563 |             place_regexp_coords = re.search(r"('known_location', struct\('coord', \[([-]?[0-9]{1,2}(\.[0-9]*)?|0) ?([-]?[0-9]{1,3}(\.[0-9]*)?|0)\],)", filedata)
 564 |             selectedlat = place_regexp_coords.group(2)
 565 |             selectedlon = place_regexp_coords.group(4)
 566 |             selectedcity = re.search(r"('name',\s '(.+)'\),)", filedata).group(2)
 567 |             self.canvas.create_rectangle(self.convert_lon(lon_min_map), self.convert_lat(lat_max_map),
 568 |                                          self.convert_lon(lon_max_map), self.convert_lat(lat_min_map), outline='red',
 569 |                                          tag="mappreset")
 570 |             self.create_known_point(selectedlat, selectedlon, selectedcity)
 571 |         self.canvas.scan_dragto(-int(tdoa_x0.split('.')[0]), -int(tdoa_y0.split('.')[0]), gain=1)
 572 |         FillMapWithNodes(self).start()
 573 |
 574 |     @staticmethod
 575 |     def convert_lat(lat):
 576 |         """ Convert the real node latitude coordinates to adapt to GUI window map geometry. """
 577 |         # nodes are between LATITUDE 0 and 90N
 578 |         if float(lat) > 0:
 579 |             return 990 - (float(lat) * 11)
 580 |         # nodes are between LATITUDE 0 and 60S
 581 |         return 990 + (float(0 - float(lat)) * 11)
 582 |
 583 |     @staticmethod
 584 |     def convert_lon(lon):
 585 |         """ Convert the real node longitude coordinates to adapt to GUI window map geometry. """
 586 |         return 1910 + ((float(lon) * 1910) / 180)
 587 |
 588 |     def on_button_press(self, event):
 589 |         """ Red rectangle selection drawing on the World map. """
 590 |         global map_preset
 591 |         self.delete_point("mappreset")
 592 |         if map_preset == 1:
 593 |             self.rect = None
 594 |             map_preset = 0
 595 |         self.start_x = self.canvas.canvasx(event.x)
 596 |         self.start_y = self.canvas.canvasy(event.y)
 597 |         # create rectangle if not yet exist
 598 |         if not self.rect:
 599 |             self.rect = self.canvas.create_rectangle(self.x, self.y, 1, 1, outline='red', tag="mapmanual")
 600 |
 601 |     def on_move_press(self, event):
 602 |         """ Get the Map boundaries red rectangle selection coordinates. """
 603 |         global lat_min_map, lat_max_map, lon_min_map, lon_max_map
 604 |         if image_scale == 1:
 605 |             if map_preset == 1:
 606 |                 pass
 607 |             else:
 608 |                 cur_x = self.canvas.canvasx(event.x)
 609 |                 cur_y = self.canvas.canvasy(event.y)
 610 |                 lonmin = round(((self.start_x - 1910) * 180) / 1910, 1)
 611 |                 lonmax = round(((cur_x - 1910) * 180) / 1910, 1)
 612 |                 latmax = round(0 - ((cur_y - 990) / 11), 1)
 613 |                 latmin = round((self.start_y - 990) / 11, 1)
 614 |
 615 |                 if cur_x > self.start_x and cur_y > self.start_y:
 616 |                     lat_max_map = 0 - latmin
 617 |                     lat_min_map = latmax
 618 |                     lon_max_map = lonmax
 619 |                     lon_min_map = lonmin
 620 |
 621 |                 if cur_x < self.start_x and cur_y > self.start_y:
 622 |                     lat_max_map = 0 - latmin
 623 |                     lat_min_map = latmax
 624 |                     lon_max_map = lonmin
 625 |                     lon_min_map = lonmax
 626 |
 627 |                 if cur_x > self.start_x and cur_y < self.start_y:
 628 |                     lat_max_map = latmax
 629 |                     lat_min_map = 0 - latmin
 630 |                     lon_max_map = lonmax
 631 |                     lon_min_map = lonmin
 632 |
 633 |                 if cur_x < self.start_x and cur_y < self.start_y:
 634 |                     lat_max_map = latmax
 635 |                     lat_min_map = 0 - latmin
 636 |                     lon_max_map = lonmin
 637 |                     lon_min_map = lonmax
 638 |
 639 |                 w_canva, h_canva = self.canvas.winfo_width(), self.canvas.winfo_height()
 640 |                 if event.x > 0.98 * w_canva:
 641 |                     self.canvas.xview_scroll(1, 'units')
 642 |                 elif event.x < 0.02 * w_canva:
 643 |                     self.canvas.xview_scroll(-1, 'units')
 644 |                 if event.y > 0.98 * h_canva:
 645 |                     self.canvas.yview_scroll(1, 'units')
 646 |                 elif event.y < 0.02 * h_canva:
 647 |                     self.canvas.yview_scroll(-1, 'units')
 648 |                 # expand rectangle as you drag the mouse
 649 |                 self.canvas.coords(self.rect, self.start_x, self.start_y, cur_x, cur_y)
 650 |                 self.show_image()
 651 |         else:
 652 |             pass
 653 |
 654 |     @staticmethod
 655 |     def on_button_release(event):
 656 |         """ When Mouse right button is released (map boundaries set or ultimateTDoA set). """
 657 |
 658 |         global mapboundaries_set, map_preset  # lon_min_map, lon_max_map, lat_min_map, lat_max_map
 659 |         global map_manual
 660 |         if map_preset == 1 and map_manual == 0:
 661 |             pass
 662 |         else:
 663 |             try:
 664 |                 mapboundaries_set = 1
 665 |                 map_manual = 1
 666 |             except NameError:
 667 |                 pass
 668 |
 669 |     def create_known_point(self, y_kwn, x_kwn, n):
 670 |         """ Map known place creation process, works only when self.imscale = 1.0 """
 671 |         #  city coordinates y & x (degrees) converted to pixels
 672 |         ic_size = int(ICONSIZE)
 673 |         xx0 = (1910 + ((float(x_kwn) * 1910) / 180)) - ic_size
 674 |         xx1 = (1910 + ((float(x_kwn) * 1910) / 180)) + ic_size
 675 |         if float(y_kwn) > 0:  # point is located in North Hemisphere
 676 |             yy0 = (990 - (float(y_kwn) * 11)) - ic_size
 677 |             yy1 = (990 - (float(y_kwn) * 11)) + ic_size
 678 |         else:  # point is located in South Hemisphere
 679 |             yy0 = (990 + (float(0 - float(y_kwn)) * 11)) - ic_size
 680 |             yy1 = (990 + (float(0 - float(y_kwn)) * 11)) + ic_size
 681 |         self.canvas.create_rectangle(xx0, yy0, xx1, yy1, fill=POICOLOR, outline="black", activefill=POICOLOR,
 682 |                                      tag="#POI")
 683 |         self.canvas.create_text(xx0, yy0 - 10, text=selectedcity.rsplit(' (')[0].replace("_", " "), justify='center',
 684 |                                 fill=POICOLOR, tag="#POI")
 685 |
 686 |     def unselect_allpoint(self):
 687 |         """ Calling process that remove additionnal highlight on all selected nodes. """
 688 |         FillMapWithNodes(self).node_selection_inactiveall()
 689 |
 690 |     def delete_point(self, n):
 691 |         """ KnownPoint deletion process. """
 692 |         FillMapWithNodes(self).delete_point(n.rsplit(' (')[0])
 693 |
 694 |     def onclickleft(self, event):
 695 |         """ Left Mouse Click bind on the World map. """
 696 |         global HOST, node_file, node_list
 697 |         menu0 = Menu(self, tearoff=0, fg="black", bg=BGC, font='TkFixedFont 7')  # node overlap list menu
 698 |         menu1 = Menu(self, tearoff=0, fg="black", bg=BGC, font='TkFixedFont 7')
 699 |         # search for overlapping nodes
 700 |         overlap_range = ICONSIZE * 4
 701 |         overlap_rect = (self.canvas.canvasx(event.x) - overlap_range), (self.canvas.canvasy(event.y) - overlap_range), (
 702 |                 self.canvas.canvasx(event.x) + overlap_range), (self.canvas.canvasy(event.y) + overlap_range)
 703 |         node_overlap_match = self.canvas.find_enclosed(*overlap_rect)
 704 |         overlap_list = []
 705 |         for item_o in list(node_overlap_match):
 706 |             if "$#" not in self.canvas.gettags(self.canvas.find_withtag(item_o))[0]:
 707 |                 overlap_list.append(item_o)
 708 |         if len(node_overlap_match) > 1 and len(overlap_list) != 1:  # node icon overlap found, displays menu0
 709 |             for el1, el2 in enumerate(node_overlap_match):
 710 |                 if "$#" not in str(self.canvas.gettags(el2)):  # dont display node highlight tags
 711 |                     HOST = self.canvas.gettags(self.canvas.find_withtag(el2))[0]
 712 |                     # mykeys = ['url', 'id', 'lat', 'lon', 'snr']
 713 |                     # n_field    0      1      2     3     4
 714 |                     n_field = HOST.rsplit("$", 4)
 715 |                     cbg = FillMapWithNodes.color_variant(snr=n_field[4])
 716 |                     dfg = FillMapWithNodes.get_font_color(cbg)
 717 |                     # check if node is already in the TDoA node listing
 718 |                     if len([el for el in fulllist if n_field[1] == el.rsplit("$", 3)[2]]) != 1:
 719 |                         name = n_field[1]
 720 |                     else:
 721 |                         name = "✔ " + n_field[1]
 722 |                     menu0.add_command(label=name, background=cbg, foreground=dfg,
 723 |                                       command=lambda x=HOST: self.create_node_menu(x, event.x_root, event.y_root,
 724 |                                                                                    menu1))
 725 |                 else:
 726 |                     pass
 727 |             menu0.tk_popup(event.x_root, event.y_root)
 728 |         else:
 729 |             HOST = self.canvas.gettags(self.canvas.find_withtag(CURRENT))[0]
 730 |             self.create_node_menu(HOST, event.x_root, event.y_root, menu1)
 731 |
 732 |     def create_node_menu(self, kiwinodetag, popx, popy, menu):
 733 |         n_field = kiwinodetag.rsplit("$", 5)
 734 |         matches = [el for el in fulllist if n_field[1] == el.rsplit("$", 3)[2]]
 735 |         cbg = FillMapWithNodes.color_variant(snr=n_field[4])
 736 |         dfg = FillMapWithNodes.get_font_color(cbg)
 737 |         # show IQ spectrogram in GUI (PlotIQ mode 0)
 738 |         PlotIQ(node_file[node_list.index(n_field[1].replace("/", ""))], 0, 0).run()
 739 |         if len(matches) != 1:
 740 |             menu.add_command(label="Add " + n_field[1] + " for TDoA process", background=cbg, foreground=dfg,
 741 |                              font="TkFixedFont 7 bold", command=lambda *args: self.populate("add", n_field))
 742 |         elif len(matches) == 1:
 743 |             menu.add_command(label="Remove " + n_field[1] + " from TDoA process]", background=cbg, foreground=dfg,
 744 |                              font="TkFixedFont 7 bold", command=lambda: self.populate("del", n_field))
 745 |         menu.tk_popup(int(popx), int(popy))  # popup placement // node icon
 746 |
 747 |     def populate(self, action, sel_node_tag):
 748 |         """ TDoA listing node populate/depopulate process. """
 749 |         if action == "add":
 750 |             if len(fulllist) < 6:
 751 |                 fulllist.append(
 752 |                     sel_node_tag[0].rsplit(':')[0] + "$" + sel_node_tag[0].rsplit(':')[1] + "$" + sel_node_tag[
 753 |                         1].replace("/", ""))
 754 |                 FillMapWithNodes(self).node_sel_active(sel_node_tag[0])
 755 |             else:
 756 |                 tkMessageBox.showinfo(title="  ¯\\_(ツ)_/¯", message="6 nodes Maximum !")
 757 |         elif action == "del":
 758 |             fulllist.remove(
 759 |                 sel_node_tag[0].rsplit(':')[0] + "$" + sel_node_tag[0].rsplit(':')[1] + "$" + sel_node_tag[1].replace(
 760 |                     "/", ""))
 761 |             FillMapWithNodes(self).node_selection_inactive(sel_node_tag[0])
 762 |         if fulllist:
 763 |             APP.title(VERSION + "| " + FREQUENCY + ALEID + " - Selected nodes [" + str(
 764 |                 len(fulllist)) + "] : " + '/'.join(str(p).rsplit('$')[2] for p in fulllist))
 765 |         else:
 766 |             APP.title(VERSION + "| " + FREQUENCY + ALEID)
 767 |
 768 |     def move_from(self, event):
 769 |         """ Move from. """
 770 |         self.canvas.scan_mark(event.x, event.y)
 771 |
 772 |     def move_to(self, event):
 773 |         """ Move to. """
 774 |         if 'HOST' in globals() and "current" not in self.canvas.gettags(self.canvas.find_withtag(CURRENT))[0]:
 775 |             pass
 776 |         elif "current" in self.canvas.gettags(self.canvas.find_withtag(CURRENT))[0]:
 777 |             self.canvas.scan_dragto(event.x, event.y, gain=1)
 778 |             self.show_image()  # redraw the image
 779 |
 780 |     def wheel(self, event):
 781 |         """ Routine for mouse wheel actions. """
 782 |         x_eve = self.canvas.canvasx(event.x)
 783 |         y_eve = self.canvas.canvasy(event.y)
 784 |         global image_scale
 785 |         bbox = self.canvas.bbox(self.container)  # get image area
 786 |         if bbox[0] < x_eve < bbox[2] and bbox[1] < y_eve < bbox[3]:
 787 |             pass  # Ok! Inside the image
 788 |         else:
 789 |             return  # zoom only inside image area
 790 |         scale = 1.0
 791 |         # Respond to Linux (event.num) or Windows (event.delta) wheel event
 792 |         if event.num == 5 or event.delta == -120:  # scroll down
 793 |             i = min(self.width, self.height)
 794 |             if int(i * self.imscale) < 2000:
 795 |                 return  # block zoom if image is less than 2000 pixels
 796 |             self.imscale /= self.delta
 797 |             scale /= self.delta
 798 |         if event.num == 4 or event.delta == 120:  # scroll up
 799 |             i = min(self.canvas.winfo_width(), self.canvas.winfo_height())
 800 |             if i < self.imscale:
 801 |                 return  # 1 pixel is bigger than the visible area
 802 |             self.imscale *= self.delta
 803 |             scale *= self.delta
 804 |         # rescale all canvas objects
 805 |         # scale = 2.0 or 0.5
 806 |         image_scale = self.imscale
 807 |         # APP.gui.label04.configure(text="Map Zoom : " + str(int(image_scale)))
 808 |         self.canvas.scale('all', x_eve, y_eve, scale, scale)
 809 |         # self.canvas.scale('')
 810 |         self.show_image()
 811 |
 812 |     def show_image(self, event=None):
 813 |         """ Creating the canvas with the picture. """
 814 |         global b_box2
 815 |         b_box1 = self.canvas.bbox(self.container)  # get image area
 816 |         # Remove 1 pixel shift at the sides of the bbox1
 817 |         b_box1 = (b_box1[0] + 1, b_box1[1] + 1, b_box1[2] - 1, b_box1[3] - 1)
 818 |         b_box2 = (self.canvas.canvasx(0),  # get visible area of the canvas
 819 |                   self.canvas.canvasy(0),
 820 |                   self.canvas.canvasx(self.canvas.winfo_width()),
 821 |                   self.canvas.canvasy(self.canvas.winfo_height()))
 822 |         bbox = [min(b_box1[0], b_box2[0]), min(b_box1[1], b_box2[1]),  # get scroll region box
 823 |                 max(b_box1[2], b_box2[2]), max(b_box1[3], b_box2[3])]
 824 |         if bbox[0] == b_box2[0] and bbox[2] == b_box2[2]:  # whole image in the visible area
 825 |             bbox[0] = b_box1[0]
 826 |             bbox[2] = b_box1[2]
 827 |         if bbox[1] == b_box2[1] and bbox[3] == b_box2[3]:  # whole image in the visible area
 828 |             bbox[1] = b_box1[1]
 829 |             bbox[3] = b_box1[3]
 830 |         self.canvas.configure(scrollregion=bbox)  # set scroll region
 831 |         x_1 = max(b_box2[0] - b_box1[0], 0)  # get coordinates (x1,y1,x2,y2) of the image tile
 832 |         y_1 = max(b_box2[1] - b_box1[1], 0)
 833 |         x_2 = min(b_box2[2], b_box1[2]) - b_box1[0]
 834 |         y_2 = min(b_box2[3], b_box1[3]) - b_box1[1]
 835 |         if int(x_2 - x_1) > 0 and int(y_2 - y_1) > 0:  # show image if it in the visible area
 836 |             x = min(int(x_2 / self.imscale), self.width)  # sometimes it is larger on 1 pixel...
 837 |             y = min(int(y_2 / self.imscale), self.height)  # ...and sometimes not
 838 |             image = self.image.crop((int(x_1 / self.imscale), int(y_1 / self.imscale), x, y))
 839 |             imagetk = ImageTk.PhotoImage(image.resize((int(x_2 - x_1), int(y_2 - y_1))))
 840 |             imageid = self.canvas.create_image(max(b_box2[0], b_box1[0]), max(b_box2[1], b_box1[1]),
 841 |                                                anchor='nw', image=imagetk)
 842 |             self.canvas.lower(imageid)  # set image into background
 843 |             self.canvas.imagetk = imagetk  # keep an extra reference to prevent garbage-collection
 844 |
 845 |
 846 | class MainWindow(Frame):
 847 |     """ GUI design definitions. """
 848 |
 849 |     def __init__(self, parent):
 850 |         Frame.__init__(self, parent)
 851 |         self.member1 = GuiCanvas(parent)
 852 |         ReadKnownPointFile().start()
 853 |         global image_scale, node_file
 854 |         global map_preset, tdoa_in_progress, open_pdf
 855 |         global lat_min_map, lat_max_map, lon_min_map, lon_max_map
 856 |         dfgc = '#a3a3a3'  # GUI (disabled) foreground color
 857 |         image_scale = 1
 858 |         la_f = Font(family="TkFixedFont", size=7, weight="bold")
 859 |         map_preset = 0
 860 |         tdoa_in_progress = 0
 861 |         open_pdf = IntVar(self, value=1)
 862 |         # Control panel background
 863 |         self.label0 = Label(parent)
 864 |         self.label0.place(relx=0, rely=0.64, relheight=0.4, relwidth=1)
 865 |         self.label0.configure(bg=BGC, fg=FGC, width=214)
 866 |         # get values from the original .empty proc file
 867 |         for mfile in glob.glob(os.getcwd() + os.sep + "proc*.empty"):
 868 |             f = open(mfile, 'r')
 869 |             file_d = f.read()
 870 |             f.close()
 871 |         use_constraints_origin = re.search(r"(\s{16}'use_constraints', (.+),)", file_d).group(2)
 872 |         algo_origin = re.search(r"(\s{16}'new', (.+))", file_d).group(2)
 873 |         mapbox_style = re.search(r"(?:\S+ ){15}(\S+)", file_d).group(1)
 874 |         self.label01 = Label(parent)
 875 |         self.label01.place(x=14, y=14, height=14, width=105)
 876 |         self.label01.configure(bg="black", font=la_f, anchor="w", fg="deepskyblue2",
 877 |                                text="Algorithm: 2020" if algo_origin == "true" else "Algorithm: 2018")
 878 |         self.label02 = Label(parent)
 879 |         self.label02.place(x=14, y=28, height=14, width=105)
 880 |         self.label02.configure(bg="black", font=la_f, anchor="w", fg="deepskyblue2",
 881 |                                text="Constraints: yes" if use_constraints_origin == "true" else "Constraints: no")
 882 |         self.label03 = Label(parent)
 883 |         self.label03.place(x=14, y=42, height=14, width=105)
 884 |         self.label03.configure(bg="black", font=la_f, anchor="w", fg="deepskyblue2", text="Map: " + mapbox_style)
 885 |
 886 |         # Compute button
 887 |         self.compute_button = Button(parent)
 888 |         self.compute_button.place(relx=0.61, rely=0.65, height=64, relwidth=0.115)
 889 |         self.compute_button.configure(activebackground="#d9d9d9", activeforeground="#000000", bg='#d9d9d9',
 890 |                                       disabledforeground=dfgc, fg="#000000", highlightbackground="#d9d9d9",
 891 |                                       highlightcolor="#000000", pady="0", text="Compute",
 892 |                                       command=self.start_stop_tdoa)
 893 |
 894 |         # Trim_iq button
 895 |         self.trim_iq_button = Button(parent)
 896 |         self.trim_iq_button.place(relx=0.61, rely=0.75, height=24, relwidth=0.115)
 897 |         self.trim_iq_button.configure(activebackground="lightblue3", activeforeground="#000000", bg="lightblue",
 898 |                                       disabledforeground=dfgc, fg="#000000", highlightbackground="#d9d9d9",
 899 |                                       highlightcolor="#000000", pady="0", text="run trim_iq.py",
 900 |                                       command=lambda: APP.gui.trimbutton(), state="normal")
 901 |
 902 |         # Purge node listing button
 903 |         self.purge_button = Button(parent)
 904 |         self.purge_button.place(relx=0.61, rely=0.8, height=24, relwidth=0.115)
 905 |         self.purge_button.configure(activebackground="red", activeforeground="#000000", bg="red3",
 906 |                                     disabledforeground=dfgc, fg="#000000", highlightbackground="#d9d9d9",
 907 |                                     highlightcolor="#000000", pady="0", text="purge node list", command=self.purgenode,
 908 |                                     state="normal")
 909 |
 910 |         # Auto open TDoA PDF result file
 911 |         self.open_pdf_checkbox = Checkbutton(parent)
 912 |         self.open_pdf_checkbox.place(relx=0.61, rely=0.85, height=21, relwidth=0.11)
 913 |         self.open_pdf_checkbox.configure(bg=BGC, fg=FGC, activebackground=BGC, activeforeground=FGC,
 914 |                                          font="TkFixedFont 8", width=214, selectcolor=BGC,
 915 |                                          text="open pdf automatically?",
 916 |                                          anchor="w", variable=open_pdf, command=None)
 917 |
 918 |         # Known places search textbox
 919 |         self.choice = Entry(parent)
 920 |         self.choice.place(relx=0.01, rely=0.95, height=21, relwidth=0.18)
 921 |         self.choice.insert(0, "TDoA map city/site search here")
 922 |         self.listbox = Listbox(parent)
 923 |         self.listbox.place(relx=0.2, rely=0.95, height=21, relwidth=0.3)
 924 |
 925 |         # Console window
 926 |         self.console_window = Text(parent)
 927 |         self.console_window.place(relx=0.005, rely=0.65, relheight=0.285, relwidth=0.6)
 928 |         self.console_window.configure(bg=CONS_B, font="TkTextFont", fg=CONS_F, highlightbackground=BGC,
 929 |                                       highlightcolor=FGC, insertbackground=FGC, selectbackground="#c4c4c4",
 930 |                                       selectforeground=FGC, undo="1", width=970, wrap="word")
 931 |
 932 |         # plot IQ preview window
 933 |         self.plot_iq_button = Button(parent, command=lambda: APP.gui.openinbrowser(
 934 |             [tag_list[tag_list.index(x)].rsplit("$", 4)[0] for x in tag_list if CLICKEDNODE in x],
 935 |             ''.join(re.match(r"(\d+.\d+)", FREQUENCY).group(1))))
 936 |         self.plot_iq_button.place(relx=0.73, rely=0.65, height=240, width=320)
 937 |
 938 |         # Adding some texts to console window at program start
 939 |         self.writelog("This is " + VERSION + ", a GUI written for python 2/3 with Tk")
 940 |
 941 |         # GUI topbar menus
 942 |         menubar = Menu(self)
 943 |         parent.config(menu=menubar)
 944 |         menu_1 = Menu(menubar, tearoff=0)
 945 |         menubar.add_cascade(label="Mapbox style", menu=menu_1)
 946 |         menu_1.add_command(label="streets", command=lambda *args: self.mapbox_style("streets-v11"))
 947 |         menu_1.add_command(label="outdoors", command=lambda *args: self.mapbox_style("outdoors-v11"))
 948 |         menu_1.add_command(label="light", command=lambda *args: self.mapbox_style("light-v10"))
 949 |         menu_1.add_command(label="dark", command=lambda *args: self.mapbox_style("dark-v10"))
 950 |         menu_1.add_command(label="satellite", command=lambda *args: self.mapbox_style("satellite-v9"))
 951 |         menu_1.add_command(label="satellite-streets", command=lambda *args: self.mapbox_style("satellite-streets-v11"))
 952 |         menu_2 = Menu(menubar, tearoff=0)
 953 |         menubar.add_cascade(label="Map Presets", menu=menu_2)
 954 |         menu_2.add_command(label="Europe", command=lambda *args: self.map_preset("EU"))
 955 |         menu_2.add_command(label="Africa", command=lambda *args: self.map_preset("AF"))
 956 |         menu_2.add_command(label="Middle-East", command=lambda *args: self.map_preset("ME"))
 957 |         menu_2.add_command(label="South Asia", command=lambda *args: self.map_preset("SAS"))
 958 |         menu_2.add_command(label="South-East Asia", command=lambda *args: self.map_preset("SEAS"))
 959 |         menu_2.add_command(label="East Asia", command=lambda *args: self.map_preset("EAS"))
 960 |         menu_2.add_command(label="North America", command=lambda *args: self.map_preset("NAM"))
 961 |         menu_2.add_command(label="Central America", command=lambda *args: self.map_preset("CAM"))
 962 |         menu_2.add_command(label="South America", command=lambda *args: self.map_preset("SAM"))
 963 |         menu_2.add_command(label="Oceania", command=lambda *args: self.map_preset("O"))
 964 |         menu_2.add_command(label="West Russia", command=lambda *args: self.map_preset("WR"))
 965 |         menu_2.add_command(label="East Russia", command=lambda *args: self.map_preset("ER"))
 966 |         menu_2.add_command(label="USA", command=lambda *args: self.map_preset("US"))
 967 |         menu_2.add_command(label="World (use with caution)", command=lambda *args: self.map_preset("W"))
 968 |
 969 |         # TDoA settings menu
 970 |         menu_3 = Menu(menubar, tearoff=0)
 971 |         menubar.add_cascade(label="TDoA settings", menu=menu_3)
 972 |         sm8 = Menu(menu_3, tearoff=0)
 973 |         sm9 = Menu(menu_3, tearoff=0)
 974 |         sm10 = Menu(menu_3, tearoff=0)
 975 |         menu_3.add_cascade(label='plot_kiwi_json', menu=sm8, underline=0)
 976 |         menu_3.add_cascade(label='algorithm', menu=sm10, underline=0)
 977 |         sm8.add_command(label="yes", command=lambda *args: self.tdoa_settings(0))
 978 |         sm8.add_command(label="no", command=lambda *args: self.tdoa_settings(1))
 979 |         sm9.add_command(label="option: use_constraints = 1", command=lambda *args: self.tdoa_settings(2))
 980 |         sm9.add_command(label="option: use_constraints = 0", command=lambda *args: self.tdoa_settings(3))
 981 |         sm10.add_cascade(label='former (2018)', menu=sm9, underline=0)
 982 |         sm10.add_command(label="new (2020)", command=lambda *args: self.tdoa_settings(4))
 983 |
 984 |         # Various GUI binds
 985 |         self.listbox_update(my_info1)
 986 |         self.listbox.bind('<<ListboxSelect>>', self.on_select)
 987 |         self.choice.bind('<FocusIn>', self.resetcity)
 988 |         self.choice.bind('<KeyRelease>', self.on_keyrelease)
 989 |
 990 |     @staticmethod
 991 |     def trimbutton():
 992 |         if tkMessageBox.askokcancel("Modify IQ files ?", "Do you want to run the trim_iq script ?", icon="warning"):
 993 |             TrimIQ(os.getcwd()).start()
 994 |
 995 |     @staticmethod
 996 |     def openinbrowser(host_port, freq_and_mode):
 997 |         """ Web browser call to connect on the node (default = IQ mode & fixed zoom level at 8). """
 998 |         if len(host_port) == 1:
 999 |             webbrowser.open_new("http://" + str("".join(host_port)) + "/?f=" + freq_and_mode)
1000 |
1001 |     def mapbox_style(self, value):
1002 |         global MAP_BOX
1003 |         self.label03.configure(text="Map: " + value)
1004 |         MAP_BOX = value
1005 |
1006 |     def tdoa_settings(self, value):
1007 |         global plot_kiwi_json_new, use_constraints_new, algo_new
1008 |         if value == 0:
1009 |             self.writelog("OPTION: plot_kiwi_json set to YES.")
1010 |             plot_kiwi_json_new = "true"
1011 |         if value == 1:
1012 |             self.writelog("OPTION: plot_kiwi_json set to NO.")
1013 |             plot_kiwi_json_new = "false"
1014 |         if value == 2:
1015 |             self.writelog("OPTION: former TDoA algorithm selected w/ option \'use_constraints\' set to YES.")
1016 |             algo_new = "false"
1017 |             use_constraints_new = "true"
1018 |             self.label01.configure(text="Algorithm: 2018")
1019 |             self.label02.configure(text="Constraints: yes")
1020 |         if value == 3:
1021 |             self.writelog("OPTION: former TDoA algorithm selected w/ option \'use_constraints\' set to NO.")
1022 |             algo_new = "false"
1023 |             use_constraints_new = "false"
1024 |             self.label01.configure(text="Algorithm: 2018")
1025 |             self.label02.configure(text="Constraints: no")
1026 |         if value == 4:
1027 |             self.writelog("OPTION: new TDoA algorithm selected.")
1028 |             algo_new = "true"
1029 |             use_constraints_new = "false"
1030 |             self.label01.configure(text="Algorithm: 2020")
1031 |             self.label02.configure(text="Constraints: no")
1032 |
1033 |     def map_preset(self, pmap):
1034 |         """ Map boundaries static presets. """
1035 |         global mapboundaries_set, lon_min_map, lon_max_map, lat_min_map, lat_max_map
1036 |         global sx0, sy0
1037 |         global map_preset, map_manual
1038 |         if image_scale == 1:
1039 |             p_map = []
1040 |             self.member1.delete_point("mappreset")
1041 |             for i in range(0, 4):
1042 |                 p_map.append(CFG["presets(x0/y1/x1/y0)"][pmap][i])
1043 |             sx0 = (1911 + ((float(p_map[0]) * 1911) / 180))
1044 |             sx1 = (1911 + ((float(p_map[2]) * 1911) / 180))
1045 |             if float(p_map[1]) > 0:  # point is located in North Hemisphere
1046 |                 sy0 = (990 - (float(p_map[1]) * 11))
1047 |                 sy1 = (990 - (float(p_map[3]) * 11))
1048 |             else:                     # point is located in South Hemisphere
1049 |                 sy0 = (990 + (float(0 - (float(p_map[1]) * 11))))
1050 |                 sy1 = (990 + (float(0 - float(p_map[3])) * 11))
1051 |             self.member1.canvas.create_rectangle(sx0, sy0, sx1, sy1, tag="mappreset", outline='yellow')
1052 |             self.member1.delete_point("mapmanual")
1053 |             lon_min_map = p_map[0]
1054 |             lat_max_map = p_map[1]
1055 |             lon_max_map = p_map[2]
1056 |             lat_min_map = p_map[3]
1057 |             mapboundaries_set = 1
1058 |             map_preset = 1
1059 |             map_manual = 0
1060 |         else:
1061 |             self.writelog("ERROR : The boundaries selection is forbidden unless map un-zoomed.")
1062 |
1063 |     def on_keyrelease(self, event):
1064 |         """ Known place location listing search management. """
1065 |         value = event.widget.get()
1066 |         value = value.strip().lower()
1067 |         if value == '':
1068 |             data = my_info1
1069 |         else:
1070 |             data = []
1071 |             for item in my_info1:
1072 |                 if value in item.lower():
1073 |                     data.append(item)
1074 |         self.listbox_update(data)
1075 |
1076 |     def listbox_update(self, data):
1077 |         """ Known place location listing search management. """
1078 |         self.listbox.delete(0, 'end')
1079 |         data = sorted(data, key=str.lower)
1080 |         for item in data:
1081 |             self.listbox.insert('end', item)
1082 |
1083 |     def on_select(self, event):
1084 |         """ Known place location selection process. """
1085 |         global selectedlat, selectedlon, selectedcity
1086 |         try:
1087 |             if event.widget.get(event.widget.curselection()) == " ":
1088 |                 tkMessageBox.showinfo(title="  ¯\\_(ツ)_/¯", message="Type something in the POI Search box first !")
1089 |             else:
1090 |                 selectedcity = event.widget.get(event.widget.curselection()).rsplit(" |", 1)[0]
1091 |                 selectedlat = str(my_info2[my_info1.index(selectedcity)])
1092 |                 selectedlon = str(my_info3[my_info1.index(selectedcity)])
1093 |                 self.member1.delete_point(n="#POI")
1094 |                 self.member1.create_known_point(selectedlat, selectedlon, selectedcity)
1095 |         except:
1096 |             pass
1097 |
1098 |     def resetcity(self, event):
1099 |         """ Erase previous known location choice from both textbox input and World map icon and name. """
1100 |         global selectedcity, selectedlat, selectedlon
1101 |         self.choice.delete(0, 'end')
1102 |         if selectedcity:
1103 |             self.member1.delete_point(n="#POI")
1104 |             selectedcity = " "
1105 |             selectedlat = "-90"
1106 |             selectedlon = "180"
1107 |
1108 |     def writelog(self, msg):
1109 |         """ The main console log text feed. """
1110 |         self.console_window.insert('end -1 lines',
1111 |                                    "[" + str(time.strftime('%H:%M.%S', time.gmtime())) + "] - " + msg + "\n")
1112 |         time.sleep(0.01)
1113 |         self.console_window.see('end')
1114 |
1115 |     def purgenode(self):
1116 |         """ Purge ultimateTDoA list process. """
1117 |         if tkMessageBox.askokcancel("Purge node listing ?", "Do you want to purge the listing ?", icon="warning"):
1118 |             global fulllist
1119 |             fulllist = []
1120 |             APP.title(VERSION + "| " + FREQUENCY + ALEID)
1121 |             self.member1.unselect_allpoint()
1122 |
1123 |     def start_stop_tdoa(self):
1124 |         """ Actions to perform when Compute button is clicked. """
1125 |         global tdoa_in_progress, PROC_PID
1126 |         global plot_kiwi_json_new, use_constraints_new, algo_new
1127 |         global lon_min_map, lon_max_map, lat_min_map, lat_max_map
1128 |         global plot_kiwi_json_origin, use_constraints_origin, algo_origin
1129 |         global selectedlat, selectedlon, selectedcity
1130 |         if tdoa_in_progress == 1:  # Abort TDoA process
1131 |             self.purge_button.configure(state="normal")
1132 |             try:  # kills the octave process
1133 |                 os.kill(PROC_PID, signal.SIGTERM)
1134 |             except (NameError, OSError):
1135 |                 pass
1136 |             try:  # and ghostscript
1137 |                 if platform.system() == "Windows":
1138 |                     if "gs.exe" in os.popen("tasklist").read():
1139 |                         os.system("taskkill /F /IM gs.exe")
1140 |                 else:
1141 |                     os.system("killall -9 gs")
1142 |             except (NameError, OSError):
1143 |                 pass
1144 |             self.writelog("Octave process has been aborted...")
1145 |             tdoa_in_progress = 0
1146 |             self.compute_button.configure(text="Compute")
1147 |         else:
1148 |             if len(fulllist) < 3:  # debug
1149 |                 self.writelog("ERROR : Select at least 3 nodes for TDoA processing !")
1150 |             else:
1151 |                 new_nodes = []
1152 |                 file_list = []
1153 |                 # Open the proc.empty file and read the lines
1154 |                 for mfile in glob.glob(os.getcwd() + os.sep + "proc*.empty"):
1155 |                     f = open(mfile, 'r')
1156 |                     file_d = f.read()
1157 |                     f.close()
1158 |                     # get values from the original .empty proc file
1159 |                     plot_kiwi_json_origin = re.search(r"(\s{16}'plot_kiwi_json', (.+),)", file_d).group(2)
1160 |                     use_constraints_origin = re.search(r"(\s{16}'use_constraints', (.+),)", file_d).group(2)
1161 |                     algo_origin = re.search(r"(\s{16}'new', (.+))", file_d).group(2)
1162 |                     dir_origin = re.search(r".+/(.+)/", file_d).group(1)
1163 |                     # Fill the .m file with selected node listing
1164 |                     i = 1
1165 |                     for node in fulllist:
1166 |                         new_nodes.append("    input(" + str(i) + ").fn    = fullfile('iq', '" + os.path.basename(
1167 |                             os.path.dirname(mfile)) + "', '" + node_file[
1168 |                                              node_list.index(node.rsplit("$", 4)[2])] + "\');")
1169 |                         file_list.append(node_file[node_list.index(node.rsplit("$", 4)[2])])
1170 |                         i += 1
1171 |                     file_d = file_d.replace("  # nodes", "\n".join(new_nodes))
1172 |                     # Create new config block
1173 |                     pkjn = plot_kiwi_json_new if 'plot_kiwi_json_new' in globals() and plot_kiwi_json_origin != plot_kiwi_json_new else plot_kiwi_json_origin
1174 |                     uc = use_constraints_new if 'use_constraints_new' in globals() and use_constraints_origin != use_constraints_new else use_constraints_origin
1175 |                     al = algo_new if 'algo_new' in globals() and algo_origin != algo_new else algo_origin
1176 |                     new_config = """
1177 |     config = struct('lat_range', [""" + str(lat_min_map) + " " + str(lat_max_map) + """],
1178 |                     'lon_range', [""" + str(lon_min_map) + " " + str(lon_max_map) + """],
1179 |                     'known_location', struct('coord', [""" + selectedlat + " " + selectedlon + """],
1180 |                                              'name',  '""" + selectedcity.rsplit(' (')[0].replace('_', ' ') + """'),
1181 |                     'dir', 'png',
1182 |                     'plot_kiwi', false,
1183 |                     'plot_kiwi_json', """ + pkjn + """,
1184 |                     'use_constraints', """ + uc + """,
1185 |                     'new', """ + al + """
1186 |                    );"""
1187 |                     new_mapbox = "lon, \" " + selectedlat + "\", \" " + selectedlon + "\", \" " + MAP_BOX + " \", \"iq"
1188 |                     dir_new = os.path.basename(os.path.dirname(mfile)) if os.path.basename(
1189 |                         os.path.dirname(mfile)) != dir_origin else dir_origin
1190 |                     # replace old config block by the new one
1191 |                     file_d = re.sub('(\n    config = struct(.*)(\n(.*)){9})', new_config, file_d, flags=re.M)
1192 |                     file_d = re.sub(r'lon(.*)iq', new_mapbox, file_d)
1193 |                     file_d = file_d.replace("spectrogram.pdf", "temp.pdf")
1194 |                     file_d = file_d.replace(os.sep + dir_origin, os.sep + dir_new)
1195 |                     # get some file names and directory
1196 |                     logfile = os.path.basename(mfile).replace("empty", "txt")
1197 |                     tdoa_rootdir = up(up(up(mfile)))
1198 |                     newfile = tdoa_rootdir + os.sep + os.path.basename(mfile).replace("empty", "m")
1199 |                     # create the new proc_tdoa file
1200 |                     f = open(newfile, 'w')
1201 |                     f.write(file_d)
1202 |                     f.close()
1203 |                     # get only selected nodes for a TDoA run (PlotIQ mode 1)
1204 |                     PlotIQ(None, 1, file_list).run()
1205 |                     OctaveProcessing(os.path.basename(mfile).replace("empty", "m"), tdoa_rootdir, logfile).start()
1206 |                     self.compute_button.configure(text="Abort TDoA")
1207 |                     tdoa_in_progress = 1
1208 |
1209 |
1210 | class MainW(Tk, object):
1211 |     """ Creating the Tk GUI design. """
1212 |
1213 |     def __init__(self):
1214 |         Tk.__init__(self)
1215 |         Tk.option_add(self, '*Dialog.msg.font', 'TkFixedFont 7')
1216 |         self.gui = MainWindow(self)
1217 |
1218 |
1219 | def on_closing():
1220 |     """ Actions to perform when software is closed using the top-right check button. """
1221 |     try:  # to kill octave
1222 |         os.kill(PROC_PID, signal.SIGTERM)
1223 |     except (NameError, OSError):
1224 |         pass
1225 |     os.kill(os.getpid(), signal.SIGTERM)
1226 |     APP.destroy()
1227 |
1228 |
1229 | if __name__ == '__main__':
1230 |     APP = MainW()
1231 |     APP.title(VERSION + "| " + FREQUENCY + ALEID)
1232 |     APP.protocol("WM_DELETE_WINDOW", on_closing)
1233 |     APP.mainloop()
1234 |


--------------------------------------------------------------------------------
