├── README.md ├── __pycache__ ├── sort.cpython-36.pyc └── yolo.cpython-36.pyc ├── font ├── FiraMono-Medium.otf └── SIL Open Font License.txt ├── kmeansfix.py ├── main.py ├── model_data ├── classes.txt.txt ├── tiny_yolo_anchors.txt ├── voc_classes.txt └── yolo_anchor.txt ├── sort.py ├── train.py ├── yolo.py └── yolo3 ├── model.py └── utils.py /README.md: -------------------------------------------------------------------------------- 1 | # Python Traffic Counter 2 | 3 | The purpose of this project is to detect and track vehicles on a webcam or video stream and count those going through a defined line. 4 | 5 | It uses: 6 | 7 | * [YOLO](https://www.pyimagesearch.com/2018/11/12/yolo-object-detection-with-opencv) to detect objects on each of the video frames. 8 | 9 | * [SORT](https://github.com/abewley/sort) to track those objects over different frames. 10 | 11 | Once the objects are detected and tracked over different frames a simple mathematical calculation is applied to count the intersections between the vehicles previous and current frame positions with a defined line. 12 | 13 | The code on this prototype uses the code structure developed by Adrian Rosebrock for his article [YOLO object detection with OpenCV](https://www.pyimagesearch.com/2018/11/12/yolo-object-detection-with-opencv). 14 | 15 | ## Quick Start 16 | - You can use weight from YOLO website (http://pjreddie.com/darknet/yolo/) or use your own trained weight 17 | - Change lines coordinate with your own video in main.py 18 | - Set path file with your own path 19 | - run main.py 20 | 21 | [![](http://img.youtube.com/vi/FDZiLg3_S64/0.jpg)](http://www.youtube.com/watch?v=FDZiLg3_S64 "") 22 | -------------------------------------------------------------------------------- /__pycache__/sort.cpython-36.pyc: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/mizarzulfa/Traffic-Counting-using-YOLO-Tensorflow-SORT/1c81c6deaf678e94d04d2513a3ea27ce3d46d018/__pycache__/sort.cpython-36.pyc -------------------------------------------------------------------------------- /__pycache__/yolo.cpython-36.pyc: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/mizarzulfa/Traffic-Counting-using-YOLO-Tensorflow-SORT/1c81c6deaf678e94d04d2513a3ea27ce3d46d018/__pycache__/yolo.cpython-36.pyc -------------------------------------------------------------------------------- /font/FiraMono-Medium.otf: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/mizarzulfa/Traffic-Counting-using-YOLO-Tensorflow-SORT/1c81c6deaf678e94d04d2513a3ea27ce3d46d018/font/FiraMono-Medium.otf -------------------------------------------------------------------------------- /font/SIL Open Font License.txt: -------------------------------------------------------------------------------- 1 | Copyright (c) 2014, Mozilla Foundation https://mozilla.org/ with Reserved Font Name Fira Mono. 2 | 3 | Copyright (c) 2014, Telefonica S.A. 4 | 5 | This Font Software is licensed under the SIL Open Font License, Version 1.1. 6 | This license is copied below, and is also available with a FAQ at: http://scripts.sil.org/OFL 7 | 8 | ----------------------------------------------------------- 9 | SIL OPEN FONT LICENSE Version 1.1 - 26 February 2007 10 | ----------------------------------------------------------- 11 | 12 | PREAMBLE 13 | The goals of the Open Font License (OFL) are to stimulate worldwide development of collaborative font projects, to support the font creation efforts of academic and linguistic communities, and to provide a free and open framework in which fonts may be shared and improved in partnership with others. 14 | 15 | The OFL allows the licensed fonts to be used, studied, modified and redistributed freely as long as they are not sold by themselves. The fonts, including any derivative works, can be bundled, embedded, redistributed and/or sold with any software provided that any reserved names are not used by derivative works. The fonts and derivatives, however, cannot be released under any other type of license. The requirement for fonts to remain under this license does not apply to any document created using the fonts or their derivatives. 16 | 17 | DEFINITIONS 18 | "Font Software" refers to the set of files released by the Copyright Holder(s) under this license and clearly marked as such. This may include source files, build scripts and documentation. 19 | 20 | "Reserved Font Name" refers to any names specified as such after the copyright statement(s). 21 | 22 | "Original Version" refers to the collection of Font Software components as distributed by the Copyright Holder(s). 23 | 24 | "Modified Version" refers to any derivative made by adding to, deleting, or substituting -- in part or in whole -- any of the components of the Original Version, by changing formats or by porting the Font Software to a new environment. 25 | 26 | "Author" refers to any designer, engineer, programmer, technical writer or other person who contributed to the Font Software. 27 | 28 | PERMISSION & CONDITIONS 29 | Permission is hereby granted, free of charge, to any person obtaining a copy of the Font Software, to use, study, copy, merge, embed, modify, redistribute, and sell modified and unmodified copies of the Font Software, subject to the following conditions: 30 | 31 | 1) Neither the Font Software nor any of its individual components, in Original or Modified Versions, may be sold by itself. 32 | 33 | 2) Original or Modified Versions of the Font Software may be bundled, redistributed and/or sold with any software, provided that each copy contains the above copyright notice and this license. These can be included either as stand-alone text files, human-readable headers or in the appropriate machine-readable metadata fields within text or binary files as long as those fields can be easily viewed by the user. 34 | 35 | 3) No Modified Version of the Font Software may use the Reserved Font Name(s) unless explicit written permission is granted by the corresponding Copyright Holder. This restriction only applies to the primary font name as presented to the users. 36 | 37 | 4) The name(s) of the Copyright Holder(s) or the Author(s) of the Font Software shall not be used to promote, endorse or advertise any Modified Version, except to acknowledge the contribution(s) of the Copyright Holder(s) and the Author(s) or with their explicit written permission. 38 | 39 | 5) The Font Software, modified or unmodified, in part or in whole, must be distributed entirely under this license, and must not be distributed under any other license. The requirement for fonts to remain under this license does not apply to any document created using the Font Software. 40 | 41 | TERMINATION 42 | This license becomes null and void if any of the above conditions are not met. 43 | 44 | DISCLAIMER 45 | THE FONT SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF COPYRIGHT, PATENT, TRADEMARK, OR OTHER RIGHT. IN NO EVENT SHALL THE COPYRIGHT HOLDER BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, INCLUDING ANY GENERAL, SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF THE USE OR INABILITY TO USE THE FONT SOFTWARE OR FROM OTHER DEALINGS IN THE FONT SOFTWARE. -------------------------------------------------------------------------------- /kmeansfix.py: -------------------------------------------------------------------------------- 1 | import numpy as np 2 | 3 | 4 | class YOLO_Kmeans: 5 | 6 | def __init__(self, cluster_number, filename): 7 | self.cluster_number = cluster_number 8 | self.filename = "F:/annotation.txt" 9 | 10 | def iou(self, boxes, clusters): # 1 box -> k clusters 11 | n = boxes.shape[0] 12 | k = self.cluster_number 13 | 14 | box_area = boxes[:, 0] * boxes[:, 1] 15 | box_area = box_area.repeat(k) 16 | box_area = np.reshape(box_area, (n, k)) 17 | 18 | cluster_area = clusters[:, 0] * clusters[:, 1] 19 | cluster_area = np.tile(cluster_area, [1, n]) 20 | cluster_area = np.reshape(cluster_area, (n, k)) 21 | 22 | box_w_matrix = np.reshape(boxes[:, 0].repeat(k), (n, k)) 23 | cluster_w_matrix = np.reshape(np.tile(clusters[:, 0], (1, n)), (n, k)) 24 | min_w_matrix = np.minimum(cluster_w_matrix, box_w_matrix) 25 | 26 | box_h_matrix = np.reshape(boxes[:, 1].repeat(k), (n, k)) 27 | cluster_h_matrix = np.reshape(np.tile(clusters[:, 1], (1, n)), (n, k)) 28 | min_h_matrix = np.minimum(cluster_h_matrix, box_h_matrix) 29 | inter_area = np.multiply(min_w_matrix, min_h_matrix) 30 | 31 | result = inter_area / (box_area + cluster_area - inter_area) 32 | return result 33 | 34 | def avg_iou(self, boxes, clusters): 35 | accuracy = np.mean([np.max(self.iou(boxes, clusters), axis=1)]) 36 | return accuracy 37 | 38 | def kmeans(self, boxes, k, dist=np.median): 39 | box_number = boxes.shape[0] 40 | distances = np.empty((box_number, k)) 41 | last_nearest = np.zeros((box_number,)) 42 | np.random.seed() 43 | clusters = boxes[np.random.choice( 44 | box_number, k, replace=False)] # init k clusters 45 | while True: 46 | 47 | distances = 1 - self.iou(boxes, clusters) 48 | 49 | current_nearest = np.argmin(distances, axis=1) 50 | if (last_nearest == current_nearest).all(): 51 | break # clusters won't change 52 | for cluster in range(k): 53 | clusters[cluster] = dist( # update clusters 54 | boxes[current_nearest == cluster], axis=0) 55 | 56 | last_nearest = current_nearest 57 | 58 | return clusters 59 | 60 | def result2txt(self, data): 61 | f = open("F:/model_data/yolo_anchor.txt", 'w') 62 | row = np.shape(data)[0] 63 | for i in range(row): 64 | if i == 0: 65 | x_y = "%d,%d" % (data[i][0], data[i][1]) 66 | else: 67 | x_y = ", %d,%d" % (data[i][0], data[i][1]) 68 | f.write(x_y) 69 | f.close() 70 | 71 | def txt2boxes(self): 72 | f = open(self.filename, 'r') 73 | lines = f.readlines() 74 | dataSet = [] 75 | for i in range(len(lines)-1): 76 | infos = lines[i].split() 77 | for j in range(2,len(infos)): 78 | width = int(infos[j].split(",")[2]) - int(infos[j].split(",")[0]) 79 | height = int(infos[j].split(",")[3]) - int(infos[j].split(",")[1]) 80 | dataSet.append([width, height]) 81 | result = np.array(dataSet) 82 | f.close() 83 | return result 84 | 85 | def txt2clusters(self): 86 | all_boxes = self.txt2boxes() 87 | result = self.kmeans(all_boxes, k=self.cluster_number) 88 | result = result[np.lexsort(result.T[0, None])] 89 | self.result2txt(result) 90 | print("K anchors:\n {}".format(result)) 91 | print("Accuracy: {:.2f}%".format( 92 | self.avg_iou(all_boxes, result) * 100)) 93 | 94 | 95 | if __name__ == "__main__": 96 | cluster_number = 9 97 | filename = "F:/annotation.txt" 98 | kmeans = YOLO_Kmeans(cluster_number, filename) 99 | kmeans.txt2clusters() 100 | -------------------------------------------------------------------------------- /main.py: -------------------------------------------------------------------------------- 1 | # import the necessary packages 2 | import numpy as np 3 | import argparse 4 | import imutils 5 | import time 6 | import cv2 7 | import datetime 8 | import os 9 | from yolo import YOLO 10 | from PIL import Image, ImageDraw, ImageFont 11 | from sort import * 12 | 13 | 14 | def main(yolo): 15 | tracker = Sort() 16 | memory = {} 17 | line1 = [(50, 600), (800, 800)] 18 | line2 = [(900,900), (2000,747)] 19 | 20 | # construct the argument parse and parse the arguments 21 | ap = argparse.ArgumentParser() 22 | ap.add_argument("-c", "--confidence", type=float, default=0.5, 23 | help="minimum probability to filter weak detections") 24 | ap.add_argument("-t", "--threshold", type=float, default=0.4, 25 | help="threshold when applyong non-maxima suppression") 26 | args = vars(ap.parse_args()) 27 | 28 | # Return true if line segments AB and CD intersect 29 | def intersect(A,B,C,D): 30 | return ccw(A,C,D) != ccw(B,C,D) and ccw(A,B,C) != ccw(A,B,D) 31 | 32 | def ccw(A,B,C): 33 | return (C[1]-A[1]) * (B[0]-A[0]) > (B[1]-A[1]) * (C[0]-A[0]) 34 | 35 | # load the COCO class labels our YOLO model was trained on 36 | #labelsPath = os.path.sep.join([args["yolo"], "classes.names"]) 37 | #LABELS = open(labelsPath).read().strip().split("\n") 38 | 39 | # initialize a list of colors to represent each possible class label 40 | np.random.seed(42) 41 | COLORS = np.random.randint(0, 255, size=(200, 3),dtype="uint8") 42 | 43 | # initialize the video stream, pointer to output video file, and 44 | # frame dimensions 45 | vs = cv2.VideoCapture('traffic.mp4') 46 | writer = None 47 | (W, H) = (None, None) 48 | 49 | font = ImageFont.truetype(font='font/FiraMono-Medium.otf', size=40) 50 | 51 | frameIndex = 0 52 | car = 0 53 | motor = 0 54 | bus = 0 55 | truck = 0 56 | car2 = 0 57 | motor2 = 0 58 | bus2 = 0 59 | truck2 = 0 60 | # loop over frames from the video file stream 61 | while True: 62 | # read the next frame from the file 63 | (grabbed, frame) = vs.read() 64 | 65 | # if the frame was not grabbed, then we have reached the end 66 | # of the stream 67 | if not grabbed: 68 | break 69 | 70 | image = Image.fromarray(frame[...,::-1]) 71 | boxes, out_class, confidences, midPoint = yolo.detect_image(image) 72 | image = np.asarray(image) 73 | 74 | # and class IDs, respectively 75 | classIDs = [] 76 | #classIDs.append(classID) 77 | 78 | # apply non-maxima suppression to suppress weak, overlapping 79 | # bounding boxes 80 | 81 | idxs = cv2.dnn.NMSBoxes(boxes, confidences, 0.4, 0.4) 82 | 83 | dets = [] 84 | if len(idxs) > 0: 85 | # loop over the indexes we are keeping 86 | for i in idxs.flatten(): 87 | (x, y) = (boxes[i][0], boxes[i][1]) 88 | (w, h) = (boxes[i][2], boxes[i][3]) 89 | dets.append([x, y, x+w, y+h, confidences[i]]) 90 | 91 | np.set_printoptions(formatter={'float': lambda x: "{0:0.3f}".format(x)}) 92 | dets = np.asarray(dets) 93 | tracks = tracker.update(dets) 94 | 95 | boxes = [] 96 | indexIDs = [] 97 | c = [] 98 | previous = memory.copy() 99 | memory = {} 100 | 101 | for track in tracks: 102 | boxes.append([track[0], track[1], track[2], track[3]]) 103 | indexIDs.append(int(track[4])) 104 | memory[indexIDs[-1]] = boxes[-1] 105 | 106 | if len(boxes) > 0: 107 | i = int(0) 108 | for box in boxes: 109 | # extract the bounding box coordinates 110 | (x, y) = (int(box[0]), int(box[1])) 111 | (w, h) = (int(box[2]), int(box[3])) 112 | 113 | # draw a bounding box rectangle and label on the image 114 | # color = [int(c) for c in COLORS[classIDs[i]]] 115 | # cv2.rectangle(frame, (x, y), (x + w, y + h), color, 2) 116 | 117 | color = [int(c) for c in COLORS[indexIDs[i] % len(COLORS)]] 118 | cv2.rectangle(frame, (x, y), (w, h), color, 2) 119 | 120 | if indexIDs[i] in previous: 121 | previous_box = previous[indexIDs[i]] 122 | (x2, y2) = (int(previous_box[0]), int(previous_box[1])) 123 | (w2, h2) = (int(previous_box[2]), int(previous_box[3])) 124 | p0 = (int(x + (w-x)/2), int(y + (h-y)/2)) 125 | p1 = (int(x2 + (w2-x2)/2), int(y2 + (h2-y2)/2)) 126 | cv2.line(frame, p0, p1, color, 3) 127 | 128 | if intersect(p0, p1, line1[0], line1[1]): 129 | detected_class = yolo.counter(p0,out_class, midPoint) 130 | if detected_class == 'car': 131 | car = car + 1 132 | elif detected_class == 'motorbike': 133 | motor = motor+1 134 | elif detected_class == 'bus': 135 | bus = bus+1 136 | else: 137 | truck = truck + 1 138 | 139 | if intersect(p0, p1, line2[0], line2[1]): 140 | detected_class = yolo.counter(p0,out_class, midPoint) 141 | if detected_class == 'car': 142 | car2 = car2 + 1 143 | elif detected_class == 'motorbike': 144 | motor2 = motor2+1 145 | elif detected_class == 'bus': 146 | bus2 = bus2+1 147 | else: 148 | truck2 = truck2 + 1 149 | 150 | 151 | # text = "{}: {:.4f}".format(LABELS[classIDs[i]], confidences[i]) 152 | text = "{}".format(indexIDs[i]) 153 | cv2.putText(frame, text, (x, y - 5), cv2.FONT_HERSHEY_SIMPLEX, 0.5, color, 2) 154 | i += 1 155 | 156 | frame = Image.fromarray(frame) 157 | draw = ImageDraw.Draw(frame) 158 | draw.text((83,152), 'mobil %d \nmotor %d \nbus %d \ntruck %d' %(car,motor,bus,truck), fill=(255, 255, 255),font=font) 159 | draw.text((1328,112), 'mobil %d \nmotor %d \nbus %d \ntruck %d' %(car2,motor2,bus2,truck2), fill=(255, 255, 255),font=font) 160 | 161 | frame = np.asarray(frame) 162 | # draw line 163 | cv2.line(frame, line1[0], line1[1], (0, 255, 255), 5) 164 | cv2.line(frame, line2[0], line2[1], (0, 255, 255), 5) 165 | 166 | # draw counter 167 | # counter += 1 168 | 169 | # check if the video writer is None 170 | if writer is None: 171 | # initialize our video writer 172 | fourcc = cv2.VideoWriter_fourcc(*"XVID") 173 | video_fps = vs.get(cv2.CAP_PROP_FPS) 174 | cv2.putText(frame, 'fps: %d' %(video_fps), (9,20), cv2.FONT_HERSHEY_SIMPLEX, 0.5, (0,0,255), 5) 175 | writer = cv2.VideoWriter('output.avi', fourcc, video_fps, (frame.shape[1], frame.shape[0]), True) 176 | 177 | # write the output frame to disk 178 | writer.write(frame) 179 | 180 | # increase frame index 181 | frameIndex += 1 182 | 183 | # release the file pointers 184 | print("[INFO] cleaning up...") 185 | writer.release() 186 | vs.release() 187 | 188 | if __name__ == '__main__': 189 | main(YOLO()) 190 | -------------------------------------------------------------------------------- /model_data/classes.txt.txt: -------------------------------------------------------------------------------- 1 | car 2 | motorbike 3 | bus 4 | truck -------------------------------------------------------------------------------- /model_data/tiny_yolo_anchors.txt: -------------------------------------------------------------------------------- 1 | 10,14, 23,27, 37,58, 81,82, 135,169, 344,319 2 | -------------------------------------------------------------------------------- /model_data/voc_classes.txt: -------------------------------------------------------------------------------- 1 | aeroplane 2 | bicycle 3 | bird 4 | boat 5 | bottle 6 | bus 7 | car 8 | cat 9 | chair 10 | cow 11 | diningtable 12 | dog 13 | horse 14 | motorbike 15 | person 16 | pottedplant 17 | sheep 18 | sofa 19 | train 20 | tvmonitor 21 | -------------------------------------------------------------------------------- /model_data/yolo_anchor.txt: -------------------------------------------------------------------------------- 1 | 12,14, 14,26, 23,40, 24,21, 37,32, 41,61, 60,43, 81,74, 162,136 -------------------------------------------------------------------------------- /sort.py: -------------------------------------------------------------------------------- 1 | """ 2 | SORT: A Simple, Online and Realtime Tracker 3 | Copyright (C) 2016 Alex Bewley alex@dynamicdetection.com 4 | 5 | This program is free software: you can redistribute it and/or modify 6 | it under the terms of the GNU General Public License as published by 7 | the Free Software Foundation, either version 3 of the License, or 8 | (at your option) any later version. 9 | 10 | This program is distributed in the hope that it will be useful, 11 | but WITHOUT ANY WARRANTY; without even the implied warranty of 12 | MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the 13 | GNU General Public License for more details. 14 | 15 | You should have received a copy of the GNU General Public License 16 | along with this program. If not, see . 17 | """ 18 | from __future__ import print_function 19 | 20 | from numba import jit 21 | import numpy as np 22 | from sklearn.utils.linear_assignment_ import linear_assignment 23 | from filterpy.kalman import KalmanFilter 24 | 25 | @jit 26 | def iou(bb_test,bb_gt): 27 | """ 28 | Computes IUO between two bboxes in the form [x1,y1,x2,y2] 29 | """ 30 | xx1 = np.maximum(bb_test[0], bb_gt[0]) 31 | yy1 = np.maximum(bb_test[1], bb_gt[1]) 32 | xx2 = np.minimum(bb_test[2], bb_gt[2]) 33 | yy2 = np.minimum(bb_test[3], bb_gt[3]) 34 | w = np.maximum(0., xx2 - xx1) 35 | h = np.maximum(0., yy2 - yy1) 36 | wh = w * h 37 | o = wh / ((bb_test[2]-bb_test[0])*(bb_test[3]-bb_test[1]) 38 | + (bb_gt[2]-bb_gt[0])*(bb_gt[3]-bb_gt[1]) - wh) 39 | return(o) 40 | 41 | def convert_bbox_to_z(bbox): 42 | """ 43 | Takes a bounding box in the form [x1,y1,x2,y2] and returns z in the form 44 | [x,y,s,r] where x,y is the centre of the box and s is the scale/area and r is 45 | the aspect ratio 46 | """ 47 | w = bbox[2]-bbox[0] 48 | h = bbox[3]-bbox[1] 49 | x = bbox[0]+w/2. 50 | y = bbox[1]+h/2. 51 | s = w*h #scale is just area 52 | r = w/float(h) 53 | return np.array([x,y,s,r]).reshape((4,1)) 54 | 55 | def convert_x_to_bbox(x,score=None): 56 | """ 57 | Takes a bounding box in the centre form [x,y,s,r] and returns it in the form 58 | [x1,y1,x2,y2] where x1,y1 is the top left and x2,y2 is the bottom right 59 | """ 60 | w = np.sqrt(x[2]*x[3]) 61 | h = x[2]/w 62 | if(score==None): 63 | return np.array([x[0]-w/2.,x[1]-h/2.,x[0]+w/2.,x[1]+h/2.]).reshape((1,4)) 64 | else: 65 | return np.array([x[0]-w/2.,x[1]-h/2.,x[0]+w/2.,x[1]+h/2.,score]).reshape((1,5)) 66 | 67 | class KalmanBoxTracker(object): 68 | """ 69 | This class represents the internel state of individual tracked objects observed as bbox. 70 | """ 71 | count = 0 72 | def __init__(self,bbox): 73 | """ 74 | Initialises a tracker using initial bounding box. 75 | """ 76 | #define constant velocity model 77 | self.kf = KalmanFilter(dim_x=7, dim_z=4) 78 | self.kf.F = np.array([[1,0,0,0,1,0,0],[0,1,0,0,0,1,0],[0,0,1,0,0,0,1],[0,0,0,1,0,0,0], [0,0,0,0,1,0,0],[0,0,0,0,0,1,0],[0,0,0,0,0,0,1]]) 79 | self.kf.H = np.array([[1,0,0,0,0,0,0],[0,1,0,0,0,0,0],[0,0,1,0,0,0,0],[0,0,0,1,0,0,0]]) 80 | 81 | self.kf.R[2:,2:] *= 10. 82 | self.kf.P[4:,4:] *= 1000. #give high uncertainty to the unobservable initial velocities 83 | self.kf.P *= 10. 84 | self.kf.Q[-1,-1] *= 0.01 85 | self.kf.Q[4:,4:] *= 0.01 86 | 87 | self.kf.x[:4] = convert_bbox_to_z(bbox) 88 | self.time_since_update = 0 89 | self.id = KalmanBoxTracker.count 90 | KalmanBoxTracker.count += 1 91 | self.history = [] 92 | self.hits = 0 93 | self.hit_streak = 0 94 | self.age = 0 95 | 96 | def update(self,bbox): 97 | """ 98 | Updates the state vector with observed bbox. 99 | """ 100 | self.time_since_update = 0 101 | self.history = [] 102 | self.hits += 1 103 | self.hit_streak += 1 104 | self.kf.update(convert_bbox_to_z(bbox)) 105 | 106 | def predict(self): 107 | """ 108 | Advances the state vector and returns the predicted bounding box estimate. 109 | """ 110 | if((self.kf.x[6]+self.kf.x[2])<=0): 111 | self.kf.x[6] *= 0.0 112 | self.kf.predict() 113 | self.age += 1 114 | if(self.time_since_update>0): 115 | self.hit_streak = 0 116 | self.time_since_update += 1 117 | self.history.append(convert_x_to_bbox(self.kf.x)) 118 | return self.history[-1] 119 | 120 | def get_state(self): 121 | """ 122 | Returns the current bounding box estimate. 123 | """ 124 | return convert_x_to_bbox(self.kf.x) 125 | 126 | def associate_detections_to_trackers(detections,trackers,iou_threshold = 0.3): 127 | """ 128 | Assigns detections to tracked object (both represented as bounding boxes) 129 | 130 | Returns 3 lists of matches, unmatched_detections and unmatched_trackers 131 | """ 132 | if(len(trackers)==0) or (len(detections)==0): 133 | return np.empty((0,2),dtype=int), np.arange(len(detections)), np.empty((0,5),dtype=int) 134 | iou_matrix = np.zeros((len(detections),len(trackers)),dtype=np.float32) 135 | 136 | for d,det in enumerate(detections): 137 | for t,trk in enumerate(trackers): 138 | iou_matrix[d,t] = iou(det,trk) 139 | matched_indices = linear_assignment(-iou_matrix) 140 | 141 | unmatched_detections = [] 142 | for d,det in enumerate(detections): 143 | if(d not in matched_indices[:,0]): 144 | unmatched_detections.append(d) 145 | unmatched_trackers = [] 146 | for t,trk in enumerate(trackers): 147 | if(t not in matched_indices[:,1]): 148 | unmatched_trackers.append(t) 149 | 150 | #filter out matched with low IOU 151 | matches = [] 152 | for m in matched_indices: 153 | if(iou_matrix[m[0],m[1]]= self.min_hits or self.frame_count <= self.min_hits)): 218 | ret.append(np.concatenate((d,[trk.id+1])).reshape(1,-1)) # +1 as MOT benchmark requires positive 219 | i -= 1 220 | #remove dead tracklet 221 | if(trk.time_since_update > self.max_age): 222 | self.trackers.pop(i) 223 | if(len(ret)>0): 224 | return np.concatenate(ret) 225 | return np.empty((0,5)) 226 | -------------------------------------------------------------------------------- /train.py: -------------------------------------------------------------------------------- 1 | """ 2 | Retrain the YOLO model for your own dataset. 3 | """ 4 | 5 | import numpy as np 6 | import keras.backend as K 7 | from keras.layers import Input, Lambda 8 | from keras.models import Model 9 | from keras.optimizers import Adam 10 | from keras.callbacks import TensorBoard, ModelCheckpoint, ReduceLROnPlateau, EarlyStopping 11 | from keras.utils import plot_model 12 | import matplotlib.pyplot as plt 13 | from yolo3.model import preprocess_true_boxes, yolo_body, tiny_yolo_body, yolo_loss 14 | from yolo3.utils import get_random_data 15 | 16 | 17 | def _main(): 18 | annotation_path = 'F:/annotation.txt' 19 | log_dir = 'F:/logs/000/' 20 | classes_path = 'F:/model_data/coco_classes.txt' 21 | anchors_path = 'F:/model_data/yolo_anchor.txt' 22 | class_names = get_classes(classes_path) 23 | num_classes = len(class_names) 24 | anchors = get_anchors(anchors_path) 25 | 26 | input_shape = (608,608) # multiple of 32, hw 27 | 28 | is_tiny_version = len(anchors)==6 # default setting 29 | if is_tiny_version: 30 | model = create_tiny_model(input_shape, anchors, num_classes, 31 | freeze_body=2, weights_path='tiny_yolo_weights.h5') 32 | else: 33 | model = create_model(input_shape, anchors, num_classes, 34 | freeze_body=2, weights_path='F:/model_data/trained_weights_final_1214_608_3.h5') # make sure you know what you freeze 35 | 36 | logging = TensorBoard(log_dir=log_dir) 37 | checkpoint = ModelCheckpoint(log_dir + 'ep{epoch:03d}-loss{loss:.3f}-val_loss{val_loss:.3f}.h5', 38 | monitor='val_loss', save_weights_only=True, save_best_only=True, period=3) 39 | reduce_lr = ReduceLROnPlateau(monitor='val_loss', factor=0.1, patience=3, verbose=1) 40 | early_stopping = EarlyStopping(monitor='val_loss', min_delta=0, patience=10, verbose=1) 41 | 42 | val_split = 0.12 43 | with open(annotation_path) as f: 44 | lines = f.readlines() 45 | np.random.seed(10101) 46 | np.random.shuffle(lines) 47 | np.random.seed(None) 48 | num_val = int(len(lines)*val_split) 49 | num_train = len(lines) - num_val 50 | 51 | # Train with frozen layers first, to get a stable loss. 52 | # Adjust num epochs to your dataset. This step is enough to obtain a not bad model. 53 | if True: 54 | model.compile(optimizer=Adam(lr=1e-3), loss={ 55 | # use custom yolo_loss Lambda layer. 56 | 'yolo_loss': lambda y_true, y_pred: y_pred}) 57 | 58 | batch_size = 16 59 | print('Train on {} samples, val on {} samples, with batch size {}.'.format(num_train, num_val, batch_size)) 60 | model.fit_generator(data_generator_wrapper(lines[:num_train], batch_size, input_shape, anchors, num_classes), 61 | steps_per_epoch=max(1, num_train//batch_size), 62 | validation_data=data_generator_wrapper(lines[num_train:], batch_size, input_shape, anchors, num_classes), 63 | validation_steps=max(1, num_val//batch_size), 64 | epochs=100, 65 | initial_epoch=0, 66 | callbacks=[logging, checkpoint]) 67 | model.save_weights(log_dir + 'trained_weights_stage_1.h5') 68 | 69 | # Unfreeze and continue training, to fine-tune. 70 | # Train longer if the result is not good. 71 | if True: 72 | for i in range(len(model.layers)): 73 | model.layers[i].trainable = True 74 | model.compile(optimizer=Adam(lr=1e-4), loss={'yolo_loss': lambda y_true, y_pred: y_pred}) # recompile to apply the change 75 | print('Unfreeze all of the layers.') 76 | 77 | batch_size = 4 # note that more GPU memory is required after unfreezing the body 78 | print('Train on {} samples, val on {} samples, with batch size {}.'.format(num_train, num_val, batch_size)) 79 | model.fit_generator(data_generator_wrapper(lines[:num_train], batch_size, input_shape, anchors, num_classes), 80 | steps_per_epoch=max(1, num_train//batch_size), 81 | validation_data=data_generator_wrapper(lines[num_train:], batch_size, input_shape, anchors, num_classes), 82 | validation_steps=max(1, num_val//batch_size), 83 | epochs=50, 84 | initial_epoch=100, 85 | callbacks=[logging, checkpoint, reduce_lr,early_stopping]) 86 | model.save_weights(log_dir + 'trained_weights_final.h5') 87 | #plot_model(model, to_file='/content/drive/My Drive/App/model_data/model.png') 88 | # Further training if needed. 89 | 90 | 91 | def get_classes(classes_path): 92 | '''loads the classes''' 93 | with open(classes_path) as f: 94 | class_names = f.readlines() 95 | class_names = [c.strip() for c in class_names] 96 | return class_names 97 | 98 | def get_anchors(anchors_path): 99 | '''loads the anchors from a file''' 100 | with open(anchors_path) as f: 101 | anchors = f.readline() 102 | anchors = [float(x) for x in anchors.split(',')] 103 | return np.array(anchors).reshape(-1, 2) 104 | 105 | 106 | def create_model(input_shape, anchors, num_classes, load_pretrained=True, freeze_body=2, 107 | weights_path='F:/model_data/trained_weights_final_1214_608_3.h5'): 108 | '''create the training model''' 109 | K.clear_session() # get a new session 110 | image_input = Input(shape=(None, None, 3)) 111 | h, w = input_shape 112 | num_anchors = len(anchors) 113 | 114 | y_true = [Input(shape=(h//{0:32, 1:16, 2:8}[l], w//{0:32, 1:16, 2:8}[l], \ 115 | num_anchors//3, num_classes+5)) for l in range(3)] 116 | 117 | model_body = yolo_body(image_input, num_anchors//3, num_classes) 118 | print('Create YOLOv3 model with {} anchors and {} classes.'.format(num_anchors, num_classes)) 119 | 120 | if load_pretrained: 121 | model_body.load_weights(weights_path, by_name=True, skip_mismatch=True) 122 | print('Load weights {}.'.format(weights_path)) 123 | if freeze_body in [1, 2]: 124 | # Freeze darknet53 body or freeze all but 3 output layers. 125 | num = (185, len(model_body.layers)-3)[freeze_body-1] 126 | for i in range(num): model_body.layers[i].trainable = False 127 | print('Freeze the first {} layers of total {} layers.'.format(num, len(model_body.layers))) 128 | 129 | model_loss = Lambda(yolo_loss, output_shape=(1,), name='yolo_loss', 130 | arguments={'anchors': anchors, 'num_classes': num_classes, 'ignore_thresh': 0.5})( 131 | [*model_body.output, *y_true]) 132 | model = Model([model_body.input, *y_true], model_loss) 133 | 134 | return model 135 | 136 | def create_tiny_model(input_shape, anchors, num_classes, load_pretrained=True, freeze_body=2, 137 | weights_path='model_data/tiny_yolo_weights.h5'): 138 | '''create the training model, for Tiny YOLOv3''' 139 | K.clear_session() # get a new session 140 | image_input = Input(shape=(None, None, 3)) 141 | h, w = input_shape 142 | num_anchors = len(anchors) 143 | 144 | y_true = [Input(shape=(h//{0:32, 1:16}[l], w//{0:32, 1:16}[l], \ 145 | num_anchors//2, num_classes+5)) for l in range(2)] 146 | 147 | model_body = tiny_yolo_body(image_input, num_anchors//2, num_classes) 148 | print('Create Tiny YOLOv3 model with {} anchors and {} classes.'.format(num_anchors, num_classes)) 149 | 150 | if load_pretrained: 151 | model_body.load_weights(weights_path, by_name=True, skip_mismatch=True) 152 | print('Load weights {}.'.format(weights_path)) 153 | if freeze_body in [1, 2]: 154 | # Freeze the darknet body or freeze all but 2 output layers. 155 | num = (20, len(model_body.layers)-2)[freeze_body-1] 156 | for i in range(num): model_body.layers[i].trainable = False 157 | print('Freeze the first {} layers of total {} layers.'.format(num, len(model_body.layers))) 158 | 159 | model_loss = Lambda(yolo_loss, output_shape=(1,), name='yolo_loss', 160 | arguments={'anchors': anchors, 'num_classes': num_classes, 'ignore_thresh': 0.7})( 161 | [*model_body.output, *y_true]) 162 | model = Model([model_body.input, *y_true], model_loss) 163 | 164 | return model 165 | 166 | def data_generator(annotation_lines, batch_size, input_shape, anchors, num_classes): 167 | '''data generator for fit_generator''' 168 | n = len(annotation_lines) 169 | i = 0 170 | while True: 171 | image_data = [] 172 | box_data = [] 173 | for b in range(batch_size): 174 | if i==0: 175 | np.random.shuffle(annotation_lines) 176 | image, box = get_random_data(annotation_lines[i], input_shape, random=True) 177 | image_data.append(image) 178 | box_data.append(box) 179 | i = (i+1) % n 180 | image_data = np.array(image_data) 181 | box_data = np.array(box_data) 182 | y_true = preprocess_true_boxes(box_data, input_shape, anchors, num_classes) 183 | yield [image_data, *y_true], np.zeros(batch_size) 184 | 185 | def data_generator_wrapper(annotation_lines, batch_size, input_shape, anchors, num_classes): 186 | n = len(annotation_lines) 187 | if n==0 or batch_size<=0: return None 188 | return data_generator(annotation_lines, batch_size, input_shape, anchors, num_classes) 189 | 190 | if __name__ == '__main__': 191 | _main() 192 | -------------------------------------------------------------------------------- /yolo.py: -------------------------------------------------------------------------------- 1 | # -*- coding: utf-8 -*- 2 | """ 3 | Class definition of YOLO_v3 style detection model on image and video 4 | """ 5 | 6 | import colorsys 7 | import os 8 | from timeit import default_timer as timer 9 | 10 | import numpy as np 11 | from keras import backend as K 12 | from keras.models import load_model 13 | from keras.layers import Input 14 | from PIL import Image, ImageFont, ImageDraw 15 | 16 | from yolo3.model import yolo_eval, yolo_body 17 | from yolo3.utils import letterbox_image 18 | import os 19 | from keras.utils import multi_gpu_model 20 | 21 | class YOLO(object): 22 | _defaults = { 23 | "model_path": '/model_data/yourweight.h5', #Put your weight name here 24 | "anchors_path": '/model_data/yolo_anchor.txt', 25 | "classes_path": '/model_data/coco_classes.txt', 26 | "score" : 0.4, 27 | "iou" : 0.5, 28 | "model_image_size" : (608, 608), 29 | "gpu_num" : 1, 30 | "class_used": ['car', 'motorbike', 'bus', 'truck'] 31 | } 32 | 33 | @classmethod 34 | def get_defaults(cls, n): 35 | if n in cls._defaults: 36 | return cls._defaults[n] 37 | else: 38 | return "Unrecognized attribute name '" + n + "'" 39 | 40 | def __init__(self, **kwargs): 41 | self.__dict__.update(self._defaults) # set up default values 42 | self.__dict__.update(kwargs) # and update with user overrides 43 | self.class_names = self._get_class() 44 | self.anchors = self._get_anchors() 45 | self.sess = K.get_session() 46 | self.boxes, self.scores, self.classes = self.generate() 47 | 48 | def _get_class(self): 49 | classes_path = os.path.expanduser(self.classes_path) 50 | with open(classes_path) as f: 51 | class_names = f.readlines() 52 | class_names = [c.strip() for c in class_names] 53 | return class_names 54 | 55 | def _get_anchors(self): 56 | anchors_path = os.path.expanduser(self.anchors_path) 57 | with open(anchors_path) as f: 58 | anchors = f.readline() 59 | anchors = [float(x) for x in anchors.split(',')] 60 | return np.array(anchors).reshape(-1, 2) 61 | 62 | def generate(self): 63 | model_path = os.path.expanduser(self.model_path) 64 | assert model_path.endswith('.h5'), 'Keras model or weights must be a .h5 file.' 65 | 66 | # Load model, or construct model and load weights. 67 | num_anchors = len(self.anchors) 68 | num_classes = len(self.class_names) 69 | is_tiny_version = num_anchors==6 # default setting 70 | try: 71 | self.yolo_model = load_model(model_path, compile=False) 72 | except: 73 | self.yolo_model = tiny_yolo_body(Input(shape=(None,None,3)), num_anchors//2, num_classes) \ 74 | if is_tiny_version else yolo_body(Input(shape=(None,None,3)), num_anchors//3, num_classes) 75 | self.yolo_model.load_weights(self.model_path) # make sure model, anchors and classes match 76 | else: 77 | assert self.yolo_model.layers[-1].output_shape[-1] == \ 78 | num_anchors/len(self.yolo_model.output) * (num_classes + 5), \ 79 | 'Mismatch between model and given anchor and class sizes' 80 | 81 | print('{} model, anchors, and classes loaded.'.format(model_path)) 82 | 83 | # Generate colors for drawing bounding boxes. 84 | hsv_tuples = [(x / len(self.class_names), 1., 1.) 85 | for x in range(len(self.class_names))] 86 | self.colors = list(map(lambda x: colorsys.hsv_to_rgb(*x), hsv_tuples)) 87 | self.colors = list( 88 | map(lambda x: (int(x[0] * 255), int(x[1] * 255), int(x[2] * 255)), 89 | self.colors)) 90 | np.random.seed(10101) # Fixed seed for consistent colors across runs. 91 | np.random.shuffle(self.colors) # Shuffle colors to decorrelate adjacent classes. 92 | np.random.seed(None) # Reset seed to default. 93 | 94 | # Generate output tensor targets for filtered bounding boxes. 95 | self.input_image_shape = K.placeholder(shape=(2, )) 96 | if self.gpu_num>=2: 97 | self.yolo_model = multi_gpu_model(self.yolo_model, gpus=self.gpu_num) 98 | boxes, scores, classes = yolo_eval(self.yolo_model.output, self.anchors, 99 | len(self.class_names), self.input_image_shape, 100 | score_threshold=self.score, iou_threshold=self.iou) 101 | return boxes, scores, classes 102 | 103 | def detect_image(self, image): 104 | start = timer() 105 | 106 | #image2 = image.crop((0,0,image.width/2,image.height)) 107 | if self.model_image_size != (None, None): 108 | assert self.model_image_size[0]%32 == 0, 'Multiples of 32 required' 109 | assert self.model_image_size[1]%32 == 0, 'Multiples of 32 required' 110 | boxed_image = letterbox_image(image, tuple(reversed(self.model_image_size))) 111 | else: 112 | new_image_size = (image.width - (image.width % 32), 113 | image.height - (image.height % 32)) 114 | boxed_image = letterbox_image(image, new_image_size) 115 | image_data = np.array(boxed_image, dtype='float32') 116 | 117 | print(image_data.shape) 118 | image_data /= 255. 119 | image_data = np.expand_dims(image_data, 0) # Add batch dimension. 120 | 121 | out_boxes, out_scores, out_classes = self.sess.run( 122 | [self.boxes, self.scores, self.classes], 123 | feed_dict={ 124 | self.yolo_model.input: image_data, 125 | self.input_image_shape: [image.size[1], image.size[0]], 126 | K.learning_phase(): 0 127 | }) 128 | 129 | print('Found {} boxes for {}'.format(len(out_boxes), 'img')) 130 | 131 | font = ImageFont.truetype(font='/font/FiraMono-Medium.otf', 132 | size=np.floor(3e-2 * image.size[1] + 0.5).astype('int32')) 133 | 134 | confidences = [] 135 | return_boxs = [] 136 | midPoint = [] 137 | detected_class = [] 138 | 139 | for i, c in reversed(list(enumerate(out_classes))): 140 | predicted_class = self.class_names[c] 141 | box = out_boxes[i] 142 | score = out_scores[i] 143 | 144 | label = '{} {:.2f}'.format(predicted_class, score) 145 | draw = ImageDraw.Draw(image) 146 | label_size = draw.textsize(label, font) 147 | 148 | top, left, bottom, right = box 149 | top = max(0, np.floor(top + 0.5).astype('int32')) 150 | left = max(0, np.floor(left + 0.5).astype('int32')) 151 | bottom = min(image.size[1], np.floor(bottom + 0.5).astype('int32')) 152 | right = min(image.size[0], np.floor(right + 0.5).astype('int32')) 153 | midBoxYOLO = [int((right+left)/2),int((top+bottom)/2)] 154 | print(label, (left, top), (right, bottom), midBoxYOLO) 155 | confidences.append(float(score)) 156 | midPoint.append(midBoxYOLO) 157 | detected_class.append(predicted_class) 158 | 159 | if top - label_size[1] >= 0: 160 | text_origin = np.array([left, top - label_size[1]]) 161 | else: 162 | text_origin = np.array([left, top + 1]) 163 | 164 | box = out_boxes[i] 165 | x = int(box[1]) 166 | y = int(box[0]) 167 | w = int(box[3]-box[1]) 168 | h = int(box[2]-box[0]) 169 | if x < 0 : 170 | w = w + x 171 | x = 0 172 | if y < 0 : 173 | h = h + y 174 | y = 0 175 | return_boxs.append([x,y,w,h]) 176 | 177 | return return_boxs, detected_class, confidences, midPoint 178 | 179 | def counter(self,p0, out_class, midPoint): 180 | for mid in midPoint: 181 | if abs(p0[0] - mid[0]) < 7 and abs(p0[1] - mid[1]) < 7: 182 | i = midPoint.index(mid) 183 | print(mid,midPoint,p0,out_class[i]) 184 | return out_class[i] 185 | 186 | def close_session(self): 187 | self.sess.close() 188 | -------------------------------------------------------------------------------- /yolo3/model.py: -------------------------------------------------------------------------------- 1 | "YOLO_v3 Model Defined in Keras.""" 2 | 3 | from functools import wraps 4 | 5 | import numpy as np 6 | import tensorflow as tf 7 | from keras import backend as K 8 | from keras.layers import Conv2D, Add, ZeroPadding2D, UpSampling2D, Concatenate, MaxPooling2D 9 | from keras.layers.advanced_activations import LeakyReLU 10 | from keras.layers.normalization import BatchNormalization 11 | from keras.models import Model 12 | from keras.regularizers import l2 13 | 14 | from yolo3.utils import compose 15 | 16 | 17 | @wraps(Conv2D) 18 | def DarknetConv2D(*args, **kwargs): 19 | """Wrapper to set Darknet parameters for Convolution2D.""" 20 | darknet_conv_kwargs = {'kernel_regularizer': l2(5e-4)} 21 | darknet_conv_kwargs['padding'] = 'valid' if kwargs.get('strides')==(2,2) else 'same' 22 | darknet_conv_kwargs.update(kwargs) 23 | return Conv2D(*args, **darknet_conv_kwargs) 24 | 25 | def DarknetConv2D_BN_Leaky(*args, **kwargs): 26 | """Darknet Convolution2D followed by BatchNormalization and LeakyReLU.""" 27 | no_bias_kwargs = {'use_bias': False} 28 | no_bias_kwargs.update(kwargs) 29 | return compose( 30 | DarknetConv2D(*args, **no_bias_kwargs), 31 | BatchNormalization(), 32 | LeakyReLU(alpha=0.1)) 33 | 34 | def resblock_body(x, num_filters, num_blocks): 35 | '''A series of resblocks starting with a downsampling Convolution2D''' 36 | # Darknet uses left and top padding instead of 'same' mode 37 | x = ZeroPadding2D(((1,0),(1,0)))(x) 38 | x = DarknetConv2D_BN_Leaky(num_filters, (3,3), strides=(2,2))(x) 39 | for i in range(num_blocks): 40 | y = compose( 41 | DarknetConv2D_BN_Leaky(num_filters//2, (1,1)), 42 | DarknetConv2D_BN_Leaky(num_filters, (3,3)))(x) 43 | x = Add()([x,y]) 44 | return x 45 | 46 | def darknet_body(x): 47 | '''Darknent body having 52 Convolution2D layers''' 48 | x = DarknetConv2D_BN_Leaky(32, (3,3))(x) 49 | x = resblock_body(x, 64, 1) 50 | x = resblock_body(x, 128, 2) 51 | x = resblock_body(x, 256, 8) 52 | x = resblock_body(x, 512, 8) 53 | x = resblock_body(x, 1024, 4) 54 | return x 55 | 56 | def make_last_layers(x, num_filters, out_filters): 57 | '''6 Conv2D_BN_Leaky layers followed by a Conv2D_linear layer''' 58 | x = compose( 59 | DarknetConv2D_BN_Leaky(num_filters, (1,1)), 60 | DarknetConv2D_BN_Leaky(num_filters*2, (3,3)), 61 | DarknetConv2D_BN_Leaky(num_filters, (1,1)), 62 | DarknetConv2D_BN_Leaky(num_filters*2, (3,3)), 63 | DarknetConv2D_BN_Leaky(num_filters, (1,1)))(x) 64 | y = compose( 65 | DarknetConv2D_BN_Leaky(num_filters*2, (3,3)), 66 | DarknetConv2D(out_filters, (1,1)))(x) 67 | return x, y 68 | 69 | 70 | def yolo_body(inputs, num_anchors, num_classes): 71 | """Create YOLO_V3 model CNN body in Keras.""" 72 | darknet = Model(inputs, darknet_body(inputs)) 73 | x, y1 = make_last_layers(darknet.output, 512, num_anchors*(num_classes+5)) 74 | 75 | x = compose( 76 | DarknetConv2D_BN_Leaky(256, (1,1)), 77 | UpSampling2D(2))(x) 78 | x = Concatenate()([x,darknet.layers[152].output]) 79 | x, y2 = make_last_layers(x, 256, num_anchors*(num_classes+5)) 80 | 81 | x = compose( 82 | DarknetConv2D_BN_Leaky(128, (1,1)), 83 | UpSampling2D(2))(x) 84 | x = Concatenate()([x,darknet.layers[92].output]) 85 | x, y3 = make_last_layers(x, 128, num_anchors*(num_classes+5)) 86 | 87 | return Model(inputs, [y1,y2,y3]) 88 | 89 | def tiny_yolo_body(inputs, num_anchors, num_classes): 90 | '''Create Tiny YOLO_v3 model CNN body in keras.''' 91 | x1 = compose( 92 | DarknetConv2D_BN_Leaky(16, (3,3)), 93 | MaxPooling2D(pool_size=(2,2), strides=(2,2), padding='same'), 94 | DarknetConv2D_BN_Leaky(32, (3,3)), 95 | MaxPooling2D(pool_size=(2,2), strides=(2,2), padding='same'), 96 | DarknetConv2D_BN_Leaky(64, (3,3)), 97 | MaxPooling2D(pool_size=(2,2), strides=(2,2), padding='same'), 98 | DarknetConv2D_BN_Leaky(128, (3,3)), 99 | MaxPooling2D(pool_size=(2,2), strides=(2,2), padding='same'), 100 | DarknetConv2D_BN_Leaky(256, (3,3)))(inputs) 101 | x2 = compose( 102 | MaxPooling2D(pool_size=(2,2), strides=(2,2), padding='same'), 103 | DarknetConv2D_BN_Leaky(512, (3,3)), 104 | MaxPooling2D(pool_size=(2,2), strides=(1,1), padding='same'), 105 | DarknetConv2D_BN_Leaky(1024, (3,3)), 106 | DarknetConv2D_BN_Leaky(256, (1,1)))(x1) 107 | y1 = compose( 108 | DarknetConv2D_BN_Leaky(512, (3,3)), 109 | DarknetConv2D(num_anchors*(num_classes+5), (1,1)))(x2) 110 | 111 | x2 = compose( 112 | DarknetConv2D_BN_Leaky(128, (1,1)), 113 | UpSampling2D(2))(x2) 114 | y2 = compose( 115 | Concatenate(), 116 | DarknetConv2D_BN_Leaky(256, (3,3)), 117 | DarknetConv2D(num_anchors*(num_classes+5), (1,1)))([x2,x1]) 118 | 119 | return Model(inputs, [y1,y2]) 120 | 121 | 122 | def yolo_head(feats, anchors, num_classes, input_shape, calc_loss=False): 123 | """Convert final layer features to bounding box parameters.""" 124 | num_anchors = len(anchors) 125 | # Reshape to batch, height, width, num_anchors, box_params. 126 | anchors_tensor = K.reshape(K.constant(anchors), [1, 1, 1, num_anchors, 2]) 127 | 128 | grid_shape = K.shape(feats)[1:3] # height, width 129 | grid_y = K.tile(K.reshape(K.arange(0, stop=grid_shape[0]), [-1, 1, 1, 1]), 130 | [1, grid_shape[1], 1, 1]) 131 | grid_x = K.tile(K.reshape(K.arange(0, stop=grid_shape[1]), [1, -1, 1, 1]), 132 | [grid_shape[0], 1, 1, 1]) 133 | grid = K.concatenate([grid_x, grid_y]) 134 | grid = K.cast(grid, K.dtype(feats)) 135 | 136 | feats = K.reshape( 137 | feats, [-1, grid_shape[0], grid_shape[1], num_anchors, num_classes + 5]) 138 | 139 | # Adjust preditions to each spatial grid point and anchor size. 140 | box_xy = (K.sigmoid(feats[..., :2]) + grid) / K.cast(grid_shape[::-1], K.dtype(feats)) 141 | box_wh = K.exp(feats[..., 2:4]) * anchors_tensor / K.cast(input_shape[::-1], K.dtype(feats)) 142 | box_confidence = K.sigmoid(feats[..., 4:5]) 143 | box_class_probs = K.sigmoid(feats[..., 5:]) 144 | 145 | if calc_loss == True: 146 | return grid, feats, box_xy, box_wh 147 | return box_xy, box_wh, box_confidence, box_class_probs 148 | 149 | 150 | def yolo_correct_boxes(box_xy, box_wh, input_shape, image_shape): 151 | '''Get corrected boxes''' 152 | box_yx = box_xy[..., ::-1] 153 | box_hw = box_wh[..., ::-1] 154 | input_shape = K.cast(input_shape, K.dtype(box_yx)) 155 | image_shape = K.cast(image_shape, K.dtype(box_yx)) 156 | new_shape = K.round(image_shape * K.min(input_shape/image_shape)) 157 | offset = (input_shape-new_shape)/2./input_shape 158 | scale = input_shape/new_shape 159 | box_yx = (box_yx - offset) * scale 160 | box_hw *= scale 161 | 162 | box_mins = box_yx - (box_hw / 2.) 163 | box_maxes = box_yx + (box_hw / 2.) 164 | boxes = K.concatenate([ 165 | box_mins[..., 0:1], # y_min 166 | box_mins[..., 1:2], # x_min 167 | box_maxes[..., 0:1], # y_max 168 | box_maxes[..., 1:2] # x_max 169 | ]) 170 | 171 | # Scale boxes back to original image shape. 172 | boxes *= K.concatenate([image_shape, image_shape]) 173 | return boxes 174 | 175 | 176 | def yolo_boxes_and_scores(feats, anchors, num_classes, input_shape, image_shape): 177 | '''Process Conv layer output''' 178 | box_xy, box_wh, box_confidence, box_class_probs = yolo_head(feats, 179 | anchors, num_classes, input_shape) 180 | boxes = yolo_correct_boxes(box_xy, box_wh, input_shape, image_shape) 181 | boxes = K.reshape(boxes, [-1, 4]) 182 | box_scores = box_confidence * box_class_probs 183 | box_scores = K.reshape(box_scores, [-1, num_classes]) 184 | return boxes, box_scores 185 | 186 | 187 | def yolo_eval(yolo_outputs, 188 | anchors, 189 | num_classes, 190 | image_shape, 191 | max_boxes=40, 192 | score_threshold=.5, 193 | iou_threshold=.5): 194 | """Evaluate YOLO model on given input and return filtered boxes.""" 195 | num_layers = len(yolo_outputs) 196 | anchor_mask = [[6,7,8], [3,4,5], [0,1,2]] if num_layers==3 else [[3,4,5], [1,2,3]] # default setting 197 | input_shape = K.shape(yolo_outputs[0])[1:3] * 32 198 | boxes = [] 199 | box_scores = [] 200 | for l in range(num_layers): 201 | _boxes, _box_scores = yolo_boxes_and_scores(yolo_outputs[l], 202 | anchors[anchor_mask[l]], num_classes, input_shape, image_shape) 203 | boxes.append(_boxes) 204 | box_scores.append(_box_scores) 205 | boxes = K.concatenate(boxes, axis=0) 206 | box_scores = K.concatenate(box_scores, axis=0) 207 | 208 | mask = box_scores >= score_threshold 209 | max_boxes_tensor = K.constant(max_boxes, dtype='int32') 210 | boxes_ = [] 211 | scores_ = [] 212 | classes_ = [] 213 | for c in range(num_classes): 214 | # TODO: use keras backend instead of tf. 215 | class_boxes = tf.boolean_mask(boxes, mask[:, c]) 216 | class_box_scores = tf.boolean_mask(box_scores[:, c], mask[:, c]) 217 | nms_index = tf.image.non_max_suppression( 218 | class_boxes, class_box_scores, max_boxes_tensor, iou_threshold=iou_threshold) 219 | class_boxes = K.gather(class_boxes, nms_index) 220 | class_box_scores = K.gather(class_box_scores, nms_index) 221 | classes = K.ones_like(class_box_scores, 'int32') * c 222 | boxes_.append(class_boxes) 223 | scores_.append(class_box_scores) 224 | classes_.append(classes) 225 | boxes_ = K.concatenate(boxes_, axis=0) 226 | scores_ = K.concatenate(scores_, axis=0) 227 | classes_ = K.concatenate(classes_, axis=0) 228 | 229 | return boxes_, scores_, classes_ 230 | 231 | 232 | def preprocess_true_boxes(true_boxes, input_shape, anchors, num_classes): 233 | '''Preprocess true boxes to training input format 234 | 235 | Parameters 236 | ---------- 237 | true_boxes: array, shape=(m, T, 5) 238 | Absolute x_min, y_min, x_max, y_max, class_id relative to input_shape. 239 | input_shape: array-like, hw, multiples of 32 240 | anchors: array, shape=(N, 2), wh 241 | num_classes: integer 242 | 243 | Returns 244 | ------- 245 | y_true: list of array, shape like yolo_outputs, xywh are reletive value 246 | 247 | ''' 248 | assert (true_boxes[..., 4]0 269 | 270 | for b in range(m): 271 | # Discard zero rows. 272 | wh = boxes_wh[b, valid_mask[b]] 273 | if len(wh)==0: continue 274 | # Expand dim to apply broadcasting. 275 | wh = np.expand_dims(wh, -2) 276 | box_maxes = wh / 2. 277 | box_mins = -box_maxes 278 | 279 | intersect_mins = np.maximum(box_mins, anchor_mins) 280 | intersect_maxes = np.minimum(box_maxes, anchor_maxes) 281 | intersect_wh = np.maximum(intersect_maxes - intersect_mins, 0.) 282 | intersect_area = intersect_wh[..., 0] * intersect_wh[..., 1] 283 | box_area = wh[..., 0] * wh[..., 1] 284 | anchor_area = anchors[..., 0] * anchors[..., 1] 285 | iou = intersect_area / (box_area + anchor_area - intersect_area) 286 | 287 | # Find best anchor for each true box 288 | best_anchor = np.argmax(iou, axis=-1) 289 | 290 | for t, n in enumerate(best_anchor): 291 | for l in range(num_layers): 292 | if n in anchor_mask[l]: 293 | i = np.floor(true_boxes[b,t,0]*grid_shapes[l][1]).astype('int32') 294 | j = np.floor(true_boxes[b,t,1]*grid_shapes[l][0]).astype('int32') 295 | k = anchor_mask[l].index(n) 296 | c = true_boxes[b,t, 4].astype('int32') 297 | y_true[l][b, j, i, k, 0:4] = true_boxes[b,t, 0:4] 298 | y_true[l][b, j, i, k, 4] = 1 299 | y_true[l][b, j, i, k, 5+c] = 1 300 | 301 | return y_true 302 | 303 | 304 | def box_iou(b1, b2): 305 | '''Return iou tensor 306 | 307 | Parameters 308 | ---------- 309 | b1: tensor, shape=(i1,...,iN, 4), xywh 310 | b2: tensor, shape=(j, 4), xywh 311 | 312 | Returns 313 | ------- 314 | iou: tensor, shape=(i1,...,iN, j) 315 | 316 | ''' 317 | 318 | # Expand dim to apply broadcasting. 319 | b1 = K.expand_dims(b1, -2) 320 | b1_xy = b1[..., :2] 321 | b1_wh = b1[..., 2:4] 322 | b1_wh_half = b1_wh/2. 323 | b1_mins = b1_xy - b1_wh_half 324 | b1_maxes = b1_xy + b1_wh_half 325 | 326 | # Expand dim to apply broadcasting. 327 | b2 = K.expand_dims(b2, 0) 328 | b2_xy = b2[..., :2] 329 | b2_wh = b2[..., 2:4] 330 | b2_wh_half = b2_wh/2. 331 | b2_mins = b2_xy - b2_wh_half 332 | b2_maxes = b2_xy + b2_wh_half 333 | 334 | intersect_mins = K.maximum(b1_mins, b2_mins) 335 | intersect_maxes = K.minimum(b1_maxes, b2_maxes) 336 | intersect_wh = K.maximum(intersect_maxes - intersect_mins, 0.) 337 | intersect_area = intersect_wh[..., 0] * intersect_wh[..., 1] 338 | b1_area = b1_wh[..., 0] * b1_wh[..., 1] 339 | b2_area = b2_wh[..., 0] * b2_wh[..., 1] 340 | iou = intersect_area / (b1_area + b2_area - intersect_area) 341 | 342 | return iou 343 | 344 | 345 | def yolo_loss(args, anchors, num_classes, ignore_thresh=.5, print_loss=False): 346 | '''Return yolo_loss tensor 347 | 348 | Parameters 349 | ---------- 350 | yolo_outputs: list of tensor, the output of yolo_body or tiny_yolo_body 351 | y_true: list of array, the output of preprocess_true_boxes 352 | anchors: array, shape=(N, 2), wh 353 | num_classes: integer 354 | ignore_thresh: float, the iou threshold whether to ignore object confidence loss 355 | 356 | Returns 357 | ------- 358 | loss: tensor, shape=(1,) 359 | 360 | ''' 361 | num_layers = len(anchors)//3 # default setting 362 | yolo_outputs = args[:num_layers] 363 | y_true = args[num_layers:] 364 | anchor_mask = [[6,7,8], [3,4,5], [0,1,2]] if num_layers==3 else [[3,4,5], [1,2,3]] 365 | input_shape = K.cast(K.shape(yolo_outputs[0])[1:3] * 32, K.dtype(y_true[0])) 366 | grid_shapes = [K.cast(K.shape(yolo_outputs[l])[1:3], K.dtype(y_true[0])) for l in range(num_layers)] 367 | loss = 0 368 | m = K.shape(yolo_outputs[0])[0] # batch size, tensor 369 | mf = K.cast(m, K.dtype(yolo_outputs[0])) 370 | 371 | for l in range(num_layers): 372 | object_mask = y_true[l][..., 4:5] 373 | true_class_probs = y_true[l][..., 5:] 374 | 375 | grid, raw_pred, pred_xy, pred_wh = yolo_head(yolo_outputs[l], 376 | anchors[anchor_mask[l]], num_classes, input_shape, calc_loss=True) 377 | pred_box = K.concatenate([pred_xy, pred_wh]) 378 | 379 | # Darknet raw box to calculate loss. 380 | raw_true_xy = y_true[l][..., :2]*grid_shapes[l][::-1] - grid 381 | raw_true_wh = K.log(y_true[l][..., 2:4] / anchors[anchor_mask[l]] * input_shape[::-1]) 382 | raw_true_wh = K.switch(object_mask, raw_true_wh, K.zeros_like(raw_true_wh)) # avoid log(0)=-inf 383 | box_loss_scale = 2 - y_true[l][...,2:3]*y_true[l][...,3:4] 384 | 385 | # Find ignore mask, iterate over each of batch. 386 | ignore_mask = tf.TensorArray(K.dtype(y_true[0]), size=1, dynamic_size=True) 387 | object_mask_bool = K.cast(object_mask, 'bool') 388 | def loop_body(b, ignore_mask): 389 | true_box = tf.boolean_mask(y_true[l][b,...,0:4], object_mask_bool[b,...,0]) 390 | iou = box_iou(pred_box[b], true_box) 391 | best_iou = K.max(iou, axis=-1) 392 | ignore_mask = ignore_mask.write(b, K.cast(best_iou0: 60 | np.random.shuffle(box) 61 | if len(box)>max_boxes: box = box[:max_boxes] 62 | box[:, [0,2]] = box[:, [0,2]]*scale + dx 63 | box[:, [1,3]] = box[:, [1,3]]*scale + dy 64 | box_data[:len(box)] = box 65 | 66 | return image_data, box_data 67 | 68 | # resize image 69 | new_ar = w/h * rand(1-jitter,1+jitter)/rand(1-jitter,1+jitter) 70 | scale = rand(.25, 2) 71 | if new_ar < 1: 72 | nh = int(scale*h) 73 | nw = int(nh*new_ar) 74 | else: 75 | nw = int(scale*w) 76 | nh = int(nw/new_ar) 77 | image = image.resize((nw,nh), Image.BICUBIC) 78 | 79 | # place image 80 | dx = int(rand(0, w-nw)) 81 | dy = int(rand(0, h-nh)) 82 | new_image = Image.new('RGB', (w,h), (128,128,128)) 83 | new_image.paste(image, (dx, dy)) 84 | image = new_image 85 | 86 | # flip image or not 87 | flip = rand()<.5 88 | if flip: image = image.transpose(Image.FLIP_LEFT_RIGHT) 89 | 90 | # distort image 91 | hue = rand(-hue, hue) 92 | sat = rand(1, sat) if rand()<.5 else 1/rand(1, sat) 93 | val = rand(1, val) if rand()<.5 else 1/rand(1, val) 94 | x = rgb_to_hsv(np.array(image)/255.) 95 | x[..., 0] += hue 96 | x[..., 0][x[..., 0]>1] -= 1 97 | x[..., 0][x[..., 0]<0] += 1 98 | x[..., 1] *= sat 99 | x[..., 2] *= val 100 | x[x>1] = 1 101 | x[x<0] = 0 102 | image_data = hsv_to_rgb(x) # numpy array, 0 to 1 103 | 104 | # correct boxes 105 | box_data = np.zeros((max_boxes,5)) 106 | if len(box)>0: 107 | np.random.shuffle(box) 108 | box[:, [0,2]] = box[:, [0,2]]*nw/iw + dx 109 | box[:, [1,3]] = box[:, [1,3]]*nh/ih + dy 110 | if flip: box[:, [0,2]] = w - box[:, [2,0]] 111 | box[:, 0:2][box[:, 0:2]<0] = 0 112 | box[:, 2][box[:, 2]>w] = w 113 | box[:, 3][box[:, 3]>h] = h 114 | box_w = box[:, 2] - box[:, 0] 115 | box_h = box[:, 3] - box[:, 1] 116 | box = box[np.logical_and(box_w>1, box_h>1)] # discard invalid box 117 | if len(box)>max_boxes: box = box[:max_boxes] 118 | box_data[:len(box)] = box 119 | 120 | return image_data, box_data 121 | --------------------------------------------------------------------------------
