├── .gitignore ├── README.md ├── app ├── .gitignore ├── build.gradle ├── proguard-rules.pro └── src │ ├── androidTest │ └── java │ │ └── com │ │ └── oyp │ │ └── battery │ │ └── ExampleInstrumentedTest.java │ ├── main │ ├── AndroidManifest.xml │ ├── java │ │ └── com │ │ │ └── oyp │ │ │ └── battery │ │ │ ├── BaseHandlerCallBack.java │ │ │ ├── MainActivity.java │ │ │ └── PowerConsumptionRankingsBatteryView.java │ └── res │ │ ├── drawable-v24 │ │ └── ic_launcher_foreground.xml │ │ ├── drawable │ │ └── ic_launcher_background.xml │ │ ├── layout │ │ └── activity_main.xml │ │ ├── mipmap-anydpi-v26 │ │ ├── ic_launcher.xml │ │ └── ic_launcher_round.xml │ │ ├── mipmap-hdpi │ │ ├── ic_launcher.png │ │ └── ic_launcher_round.png │ │ ├── mipmap-mdpi │ │ ├── ic_launcher.png │ │ └── ic_launcher_round.png │ │ ├── mipmap-xhdpi │ │ ├── ic_launcher.png │ │ └── ic_launcher_round.png │ │ ├── mipmap-xxhdpi │ │ ├── ic_launcher.png │ │ └── ic_launcher_round.png │ │ ├── mipmap-xxxhdpi │ │ ├── ic_launcher.png │ │ └── ic_launcher_round.png │ │ └── values │ │ ├── attrs.xml │ │ ├── colors.xml │ │ ├── dimens.xml │ │ ├── strings.xml │ │ └── styles.xml │ └── test │ └── java │ └── com │ └── oyp │ └── battery │ └── ExampleUnitTest.java ├── build.gradle ├── gradle.properties ├── gradle └── wrapper │ ├── gradle-wrapper.jar │ └── gradle-wrapper.properties ├── gradlew ├── gradlew.bat ├── screenshot ├── v1.png ├── v2.png ├── v3.png └── v4.mp4 └── settings.gradle /.gitignore: -------------------------------------------------------------------------------- 1 | *.iml 2 | .gradle 3 | /local.properties 4 | /.idea/libraries 5 | /.idea/modules.xml 6 | /.idea/workspace.xml 7 | .DS_Store 8 | /build 9 | /captures 10 | .externalNativeBuild 11 | -------------------------------------------------------------------------------- /README.md: -------------------------------------------------------------------------------- 1 | # PowerConsumptionRankingsBatteryView 2 | 自定义一个电池View 3 | 4 | # 一、背景 5 | 最近公司有个业务，需要自定义一个电池控件，因此自己按照UI图编写了一个自定义View。 6 | 7 | # 二、效果 8 | 9 | ![这里写图片描述](https://img-blog.csdn.net/20180615162931331?watermark/2/text/aHR0cHM6Ly9ibG9nLmNzZG4ubmV0L3FxNDQ2MjgyNDEy/font/5a6L5L2T/fontsize/400/fill/I0JBQkFCMA==/dissolve/70) 10 | 11 | ![这里写图片描述](https://img-blog.csdn.net/20180615160601248?watermark/2/text/aHR0cHM6Ly9ibG9nLmNzZG4ubmV0L3FxNDQ2MjgyNDEy/font/5a6L5L2T/fontsize/400/fill/I0JBQkFCMA==/dissolve/70) 12 | 13 | ![这里写图片描述](https://img-blog.csdn.net/20180615155731624?watermark/2/text/aHR0cHM6Ly9ibG9nLmNzZG4ubmV0L3FxNDQ2MjgyNDEy/font/5a6L5L2T/fontsize/400/fill/I0JBQkFCMA==/dissolve/70) 14 | 15 | ![这里写图片描述](https://img-blog.csdn.net/20180615155750874?watermark/2/text/aHR0cHM6Ly9ibG9nLmNzZG4ubmV0L3FxNDQ2MjgyNDEy/font/5a6L5L2T/fontsize/400/fill/I0JBQkFCMA==/dissolve/70) 16 | 17 | 18 | # 三、实现过程 19 | 20 | 首先看下视觉给出的UI效果图 21 | 22 | ![这里写图片描述](https://img-blog.csdn.net/20180615160810101?watermark/2/text/aHR0cHM6Ly9ibG9nLmNzZG4ubmV0L3FxNDQ2MjgyNDEy/font/5a6L5L2T/fontsize/400/fill/I0JBQkFCMA==/dissolve/70) 23 | 24 | 从这里我们可以看得出来，要自定义这个电池View的话，分为3部分来绘制。 25 | 26 | 1. 第一部分是电池头 27 | 2. 第二部分是电池边框 28 | 3. 第三部分是电池电量 29 | 30 | ## 3.1 自定义属性 31 | 因此按照上面的UI效果图来做的话，我们自定义几个属性。 32 | 33 | attrs.xml 34 | 35 | ``` 36 | 37 | 38 | 39 | 40 | 41 | 42 | 43 | 44 | 45 | 46 | 47 | 48 | 49 | 50 | 51 | 52 | 53 | 54 | 55 | 56 | 57 | 58 | 59 | 60 | 61 | 62 | 63 | 64 | ``` 65 | 执行自定义属性，包括电池颜色、电池最大高度、电池宽度、电池头部的相关信息和电池边框的相关信息。 66 | 67 | colors.xml 定义了一些UI标注的颜色值 68 | 69 | ``` 70 | 71 | 72 | #3F51B5 73 | #303F9F 74 | #FF4081 75 | 76 | 77 | #ff4d4d 78 | #00d68d 79 | #bfbfbf 80 | 81 | ``` 82 | dimens.xml 定义了一些UI标注的尺寸值 83 | 84 | ``` 85 | 86 | 87 | 88 | 48dp 89 | 90 | 31dp 91 | 92 | 93 | 2.5dp 94 | 95 | 96 | 28dp 97 | 98 | 42dp 99 | 100 | 3dp 101 | 102 | 103 | 14dp 104 | 105 | 3dp 106 | 107 | 2dp 108 | 109 | 110 | 2dp 111 | 112 | 113 | 22dp 114 | 115 | 35dp 116 | 117 | 118 | ``` 119 | 120 | ## 3.2 实现自定义View 121 | 122 | 创建PowerConsumptionRankingsBatteryView继承View， 123 | 在View的构造方法中，获取我们需要的自定义样式，重写onMesure，onDraw方法。 124 | 125 | ``` 126 | package com.oyp.battery; 127 | 128 | import android.content.Context; 129 | import android.content.res.TypedArray; 130 | import android.graphics.Canvas; 131 | import android.graphics.DrawFilter; 132 | import android.graphics.Paint; 133 | import android.graphics.PaintFlagsDrawFilter; 134 | import android.graphics.RectF; 135 | import android.support.annotation.Nullable; 136 | import android.util.AttributeSet; 137 | import android.view.View; 138 | 139 | 140 | /** 141 | * 自定义 耗电排行内的 电池图标 142 | *

143 | * created by OuyangPeng at 2018/6/10 下午 05:57 144 | * 145 | * @author OuyangPeng 146 | */ 147 | public class PowerConsumptionRankingsBatteryView extends View { 148 | /** 149 | * 电池最大电量 150 | */ 151 | public static final int MAX_LEVEL = 100; 152 | /** 153 | * 电池默认电量 154 | */ 155 | public static final int DEFAULT_LEVEL = 40; 156 | 157 | /** 158 | * 自定义View的宽 159 | */ 160 | private int width; 161 | /** 162 | * 自定义View的高 163 | */ 164 | private int height; 165 | /** 166 | * 抗锯齿标志 167 | */ 168 | private DrawFilter drawFilter; 169 | /** 170 | * 电池外壳 厚度 171 | */ 172 | private int shellStrokeWidth; 173 | /** 174 | * 电池外壳 圆角 175 | */ 176 | private int shellCornerRadius; 177 | /** 178 | * 电池外壳 宽度 179 | */ 180 | private int shellWidth; 181 | /** 182 | * 电池外壳 宽度 183 | */ 184 | private int shellHeight; 185 | /** 186 | * 电池头 圆角 187 | */ 188 | private int shellHeadCornerRadius; 189 | /** 190 | * 电池头 宽度 191 | */ 192 | private int shellHeadWidth; 193 | /** 194 | * 电池头 高度 195 | */ 196 | private int shellHeadHeight; 197 | 198 | /** 199 | * 电池宽度 200 | */ 201 | private int levelWidth; 202 | /** 203 | * 电池最大高度 204 | */ 205 | private int levelMaxHeight; 206 | /** 207 | * 电池高度 208 | */ 209 | private int levelHeight = 100; 210 | 211 | /** 212 | * 电池外壳和电池等级直接的间距 213 | */ 214 | private int gap; 215 | 216 | /** 217 | * 电池外壳 画笔 218 | */ 219 | private Paint shellPaint; 220 | /** 221 | * 电池外壳 222 | */ 223 | private RectF shellRectF; 224 | /** 225 | * 电池头 226 | */ 227 | private RectF shellHeadRect; 228 | 229 | /** 230 | * 电池电量 画笔 231 | */ 232 | private Paint levelPaint; 233 | /** 234 | * 电池电量 235 | */ 236 | private RectF levelRect; 237 | 238 | /** 239 | * 低电颜色 240 | */ 241 | private int lowerPowerColor; 242 | /** 243 | * 在线颜色 244 | */ 245 | private int onlineColor; 246 | /** 247 | * 离线颜色 248 | */ 249 | private int offlineColor; 250 | 251 | public PowerConsumptionRankingsBatteryView(Context context) { 252 | super(context); 253 | } 254 | 255 | public PowerConsumptionRankingsBatteryView(Context context, @Nullable AttributeSet attrs) { 256 | super(context, attrs); 257 | drawFilter = new PaintFlagsDrawFilter(0, Paint.ANTI_ALIAS_FLAG | Paint.FILTER_BITMAP_FLAG); 258 | 259 | initTypeArray(context, attrs); 260 | 261 | //设置 电池壳画笔的相关属性 262 | shellPaint = new Paint(); 263 | shellPaint.setAntiAlias(true); 264 | shellPaint.setColor(onlineColor); 265 | shellPaint.setStrokeWidth(shellStrokeWidth); 266 | shellPaint.setAntiAlias(true); 267 | 268 | //设置 电池画笔的相关属性 269 | levelPaint = new Paint(); 270 | levelPaint.setColor(onlineColor); 271 | levelPaint.setStyle(Paint.Style.FILL); 272 | levelPaint.setStrokeWidth(levelWidth); 273 | 274 | shellRectF = new RectF(); 275 | shellHeadRect = new RectF(); 276 | levelRect = new RectF(); 277 | } 278 | 279 | /** 280 | * 初始化自定义属性 281 | */ 282 | private void initTypeArray(Context context, @Nullable AttributeSet attrs) { 283 | TypedArray typedArray = context.obtainStyledAttributes(attrs, R.styleable.PowerConsumptionRankingsBatteryView); 284 | lowerPowerColor = typedArray.getColor(R.styleable.PowerConsumptionRankingsBatteryView_batteryLowerPowerColor, 285 | getResources().getColor(R.color.lowerPowerColor)); 286 | onlineColor = typedArray.getColor(R.styleable.PowerConsumptionRankingsBatteryView_batteryOnlineColor, 287 | getResources().getColor(R.color.onlineColor)); 288 | offlineColor = typedArray.getColor(R.styleable.PowerConsumptionRankingsBatteryView_batteryOfflineColor, 289 | getResources().getColor(R.color.offlineColor)); 290 | //外壳的相关信息 291 | shellCornerRadius = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellCornerRadius, 292 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_shell_corner)); 293 | shellWidth = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellWidth, 294 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_shell_width)); 295 | shellHeight = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellHeight, 296 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_shell_height)); 297 | shellStrokeWidth = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellStrokeWidth, 298 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_shell_stroke_width)); 299 | 300 | //电池头的相关信息 301 | shellHeadCornerRadius = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellHeadCornerRadius, 302 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_head_corner)); 303 | shellHeadWidth = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellHeadWidth, 304 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_head_width)); 305 | shellHeadHeight = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellHeadHeight, 306 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_head_height)); 307 | 308 | //电池最大高度 309 | levelMaxHeight = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryLevelMaxHeight, 310 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_level_max_height)); 311 | //电池宽度 312 | levelWidth = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryLevelWidth, 313 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_level_width)); 314 | 315 | //电池外壳和电池等级直接的间距 316 | gap = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryGap, 317 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_gap)); 318 | //回收typedArray 319 | typedArray.recycle(); 320 | } 321 | 322 | @Override 323 | protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) { 324 | super.onMeasure(widthMeasureSpec, heightMeasureSpec); 325 | //对View上的內容进行测量后得到的View內容占据的宽度 326 | width = getMeasuredWidth(); 327 | //对View上的內容进行测量后得到的View內容占据的高度 328 | height = getMeasuredHeight(); 329 | } 330 | 331 | @Override 332 | protected void onDraw(Canvas canvas) { 333 | super.onDraw(canvas); 334 | canvas.setDrawFilter(drawFilter); 335 | 336 | // 电池头 矩形的坐标 337 | 338 | //坐标 left：控件整体宽度的一半 减去 电池头宽度的一半 339 | shellHeadRect.left = width / 2 - shellHeadWidth / 2; 340 | //坐标 top： 0 341 | shellHeadRect.top = 0; 342 | //坐标 right：控件整体宽度的一半 加上 电池头宽度的一半 343 | shellHeadRect.right = width / 2 + shellHeadWidth / 2; 344 | //坐标 bottom：电池头的高度 345 | shellHeadRect.bottom = shellHeadHeight; 346 | 347 | // 电池壳 矩形的坐标 348 | 349 | //坐标 left：电池壳厚度的一半 350 | shellRectF.left = shellStrokeWidth / 2; 351 | //坐标 left：电池壳厚度的一半 加上 电池头的高度 352 | shellRectF.top = shellStrokeWidth / 2 + shellHeadHeight; 353 | //坐标 right：控件整体宽度 减去 电池壳厚度的一半 354 | shellRectF.right = width - shellStrokeWidth / 2; 355 | //坐标 bottom：控件整体高度 减去 电池壳厚度的一半 356 | shellRectF.bottom = height - shellStrokeWidth / 2; 357 | 358 | // 电池电量 矩形的坐标 359 | 360 | //坐标 left：电池壳厚度的一半 加上 电池外壳和电池等级直接的间距 361 | levelRect.left = shellStrokeWidth + gap; 362 | 363 | //电池满格时候的最大高度 ：（控件整体高度 减去电池壳厚度 减去电池头高度 减去 电池外壳和电池等级直接的间距的两倍） 364 | //topOffset: 电池满格时候的最大高度 * （电池满格100 - 当前的电量）/ 电池满格100 365 | float topOffset = (height - shellHeadHeight - gap * 2 - shellStrokeWidth) * (MAX_LEVEL - levelHeight) / MAX_LEVEL; 366 | //坐标 top：电池头的高度 + 电池壳的厚度 + 电池外壳和电池等级直接的间距 + topOffset 367 | levelRect.top = shellHeadHeight + shellStrokeWidth + gap + topOffset; 368 | 369 | //坐标 right：控件整体宽度 减去 电池壳厚度的一半 减去 电池外壳和电池等级直接的间距 370 | levelRect.right = width - shellStrokeWidth - gap; 371 | 372 | //坐标 bottom：控件整体宽度 减去 电池壳厚度的一半 减去 电池外壳和电池等级直接的间距 373 | levelRect.bottom = height - shellStrokeWidth - gap; 374 | 375 | //绘制电池头 376 | shellPaint.setStyle(Paint.Style.FILL); 377 | canvas.drawRoundRect(shellHeadRect, shellHeadCornerRadius, shellHeadCornerRadius, shellPaint); 378 | //由于电池头的左下角和右下角不是圆角的，因此我们需要画一个矩形 覆盖圆角 379 | //绘制左下角矩形 380 | canvas.drawRect(shellHeadRect.left, shellHeadRect.bottom - shellHeadCornerRadius, 381 | shellHeadRect.left + shellHeadCornerRadius, shellHeadRect.bottom, shellPaint); 382 | //绘制右下角矩形 383 | canvas.drawRect(shellHeadRect.right - shellHeadCornerRadius, shellHeadRect.bottom - shellHeadCornerRadius, 384 | shellHeadRect.right, shellHeadRect.bottom, shellPaint); 385 | 386 | //绘制电池壳 387 | shellPaint.setStyle(Paint.Style.STROKE); 388 | canvas.drawRoundRect(shellRectF, shellCornerRadius, shellCornerRadius, shellPaint); 389 | 390 | //绘制电池等级 391 | canvas.drawRect(levelRect, levelPaint); 392 | } 393 | 394 | /** 395 | * 设置电池电量 396 | * 397 | * @param level 398 | */ 399 | public void setLevelHeight(int level) { 400 | this.levelHeight = level; 401 | if (this.levelHeight < 0) { 402 | levelHeight = MAX_LEVEL; 403 | } else if (this.levelHeight > MAX_LEVEL) { 404 | levelHeight = MAX_LEVEL; 405 | } 406 | postInvalidate(); 407 | } 408 | 409 | /** 410 | * 设置在线 重绘 411 | */ 412 | public void setOnline() { 413 | shellPaint.setColor(onlineColor); 414 | levelPaint.setColor(onlineColor); 415 | postInvalidate(); 416 | } 417 | 418 | /** 419 | * 设置离线 重绘 420 | */ 421 | public void setOffline() { 422 | shellPaint.setColor(offlineColor); 423 | levelPaint.setColor(offlineColor); 424 | postInvalidate(); 425 | } 426 | 427 | /** 428 | * 设置低电 重绘 429 | */ 430 | public void setLowerPower() { 431 | shellPaint.setColor(lowerPowerColor); 432 | levelPaint.setColor(lowerPowerColor); 433 | postInvalidate(); 434 | } 435 | } 436 | 437 | ``` 438 | 439 | ## 3.3 使用我们的自定义View 440 | 441 | activity_main.xml 中使用我们的自定义View 442 | 443 | ``` 444 | 445 | 452 | 453 | 462 | 463 | 474 | 475 | 476 | ``` 477 | 478 | ## 3.4 动态展示不同状态下的电池View 479 | 480 | MainActivity.java 文件中 动态更新电池的状态 481 | 482 | ``` 483 | package com.oyp.battery; 484 | 485 | import android.os.Handler; 486 | import android.os.Message; 487 | import android.support.v7.app.AppCompatActivity; 488 | import android.os.Bundle; 489 | 490 | import java.lang.ref.WeakReference; 491 | import java.util.Timer; 492 | import java.util.TimerTask; 493 | /** 494 | * 自定义View 展示界面 495 | *

496 | * created by OuyangPeng at 2018/6/15 下午 03:33 497 | * @author OuyangPeng 498 | */ 499 | public class MainActivity extends AppCompatActivity implements BaseHandlerCallBack { 500 | 501 | private PowerConsumptionRankingsBatteryView mPowerConsumptionRankingsBatteryView; 502 | private int power; 503 | 504 | private NoLeakHandler mHandler; 505 | 506 | @Override 507 | protected void onCreate(Bundle savedInstanceState) { 508 | super.onCreate(savedInstanceState); 509 | setContentView(R.layout.activity_main); 510 | mHandler = new NoLeakHandler(this); 511 | mPowerConsumptionRankingsBatteryView = (PowerConsumptionRankingsBatteryView) findViewById(R.id.mPowerConsumptionRankingsBatteryView); 512 | 513 | new Timer().schedule(new TimerTask() { 514 | @Override 515 | public void run() { 516 | mHandler.sendEmptyMessage(0); 517 | } 518 | }, 0, 100); 519 | } 520 | 521 | @Override 522 | protected void onDestroy() { 523 | super.onDestroy(); 524 | mHandler.removeCallbacksAndMessages(null); 525 | } 526 | 527 | @Override 528 | public void callBack(Message msg) { 529 | switch (msg.what) { 530 | case 0: 531 | mPowerConsumptionRankingsBatteryView.setLevelHeight(power += 5); 532 | if (power == 100) { 533 | power = 0; 534 | } 535 | if (power < 30) { 536 | mPowerConsumptionRankingsBatteryView.setLowerPower(); 537 | } else if (power < 60) { 538 | mPowerConsumptionRankingsBatteryView.setOffline(); 539 | } else { 540 | mPowerConsumptionRankingsBatteryView.setOnline(); 541 | } 542 | break; 543 | default: 544 | break; 545 | } 546 | } 547 | 548 | private static class NoLeakHandler extends Handler { 549 | private WeakReference wr; 550 | 551 | public NoLeakHandler(T t) { 552 | wr = new WeakReference<>(t); 553 | } 554 | 555 | @Override 556 | public void handleMessage(Message msg) { 557 | super.handleMessage(msg); 558 | T t = wr.get(); 559 | if (t != null) { 560 | t.callBack(msg); 561 | } 562 | } 563 | } 564 | } 565 | 566 | 567 | ``` 568 | BaseHandlerCallBack 定义的接口 569 | ``` 570 | package com.oyp.battery; 571 | 572 | import android.os.Message; 573 | 574 | public interface BaseHandlerCallBack { 575 | public void callBack(Message msg); 576 | } 577 | ``` 578 | 579 | ## 3.5 效果 580 | ![这里写图片描述](https://img-blog.csdn.net/20180615162931331?watermark/2/text/aHR0cHM6Ly9ibG9nLmNzZG4ubmV0L3FxNDQ2MjgyNDEy/font/5a6L5L2T/fontsize/400/fill/I0JBQkFCMA==/dissolve/70) 581 | 582 | 583 | # 四、github源代码 584 | 585 | https://github.com/ouyangpeng/PowerConsumptionRankingsBatteryView 586 | 587 | ------ 588 | 589 | >作者：欧阳鹏 欢迎转载，与人分享是进步的源泉！ 590 | 转载请保留原文地址：https://blog.csdn.net/ouyang_peng/article/details/80372805 591 | > 592 | > 593 | 594 | ####如果本文对您有所帮助，欢迎您扫码下图所示的支付宝和微信支付二维码对本文进行打赏。 595 | ![这里写图片描述](https://img-blog.csdn.net/20170413233715262?watermark/2/text/aHR0cDovL2Jsb2cuY3Nkbi5uZXQvb3V5YW5nX3Blbmc=/font/5a6L5L2T/fontsize/400/fill/I0JBQkFCMA==/dissolve/70/gravity/SouthEast) 596 | -------------------------------------------------------------------------------- /app/.gitignore: -------------------------------------------------------------------------------- 1 | /build 2 | -------------------------------------------------------------------------------- /app/build.gradle: -------------------------------------------------------------------------------- 1 | apply plugin: 'com.android.application' 2 | 3 | android { 4 | compileSdkVersion 28 5 | defaultConfig { 6 | applicationId "com.oyp.battery" 7 | minSdkVersion 15 8 | targetSdkVersion 28 9 | versionCode 1 10 | versionName "1.0" 11 | testInstrumentationRunner "android.support.test.runner.AndroidJUnitRunner" 12 | } 13 | buildTypes { 14 | release { 15 | minifyEnabled false 16 | proguardFiles getDefaultProguardFile('proguard-android.txt'), 'proguard-rules.pro' 17 | } 18 | } 19 | } 20 | 21 | dependencies { 22 | implementation fileTree(dir: 'libs', include: ['*.jar']) 23 | implementation 'com.android.support:appcompat-v7:28.+' 24 | implementation 'com.android.support.constraint:constraint-layout:1.0.2' 25 | testImplementation 'junit:junit:4.12' 26 | androidTestImplementation 'com.android.support.test:runner:1.0.1' 27 | androidTestImplementation 'com.android.support.test.espresso:espresso-core:3.0.1' 28 | } 29 | -------------------------------------------------------------------------------- /app/proguard-rules.pro: -------------------------------------------------------------------------------- 1 | # Add project specific ProGuard rules here. 2 | # You can control the set of applied configuration files using the 3 | # proguardFiles setting in build.gradle. 4 | # 5 | # For more details, see 6 | # http://developer.android.com/guide/developing/tools/proguard.html 7 | 8 | # If your project uses WebView with JS, uncomment the following 9 | # and specify the fully qualified class name to the JavaScript interface 10 | # class: 11 | #-keepclassmembers class fqcn.of.javascript.interface.for.webview { 12 | # public *; 13 | #} 14 | 15 | # Uncomment this to preserve the line number information for 16 | # debugging stack traces. 17 | #-keepattributes SourceFile,LineNumberTable 18 | 19 | # If you keep the line number information, uncomment this to 20 | # hide the original source file name. 21 | #-renamesourcefileattribute SourceFile 22 | -------------------------------------------------------------------------------- /app/src/androidTest/java/com/oyp/battery/ExampleInstrumentedTest.java: -------------------------------------------------------------------------------- 1 | package com.oyp.battery; 2 | 3 | import android.content.Context; 4 | import android.support.test.InstrumentationRegistry; 5 | import android.support.test.runner.AndroidJUnit4; 6 | 7 | import org.junit.Test; 8 | import org.junit.runner.RunWith; 9 | 10 | import static org.junit.Assert.*; 11 | 12 | /** 13 | * Instrumented test, which will execute on an Android device. 14 | * 15 | * @see Testing documentation 16 | */ 17 | @RunWith(AndroidJUnit4.class) 18 | public class ExampleInstrumentedTest { 19 | @Test 20 | public void useAppContext() { 21 | // Context of the app under test. 22 | Context appContext = InstrumentationRegistry.getTargetContext(); 23 | 24 | assertEquals("com.oyp.battery", appContext.getPackageName()); 25 | } 26 | } 27 | -------------------------------------------------------------------------------- /app/src/main/AndroidManifest.xml: -------------------------------------------------------------------------------- 1 | 2 | 4 | 5 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 20 | 21 | -------------------------------------------------------------------------------- /app/src/main/java/com/oyp/battery/BaseHandlerCallBack.java: -------------------------------------------------------------------------------- 1 | package com.oyp.battery; 2 | 3 | import android.os.Message; 4 | 5 | public interface BaseHandlerCallBack { 6 | public void callBack(Message msg); 7 | } -------------------------------------------------------------------------------- /app/src/main/java/com/oyp/battery/MainActivity.java: -------------------------------------------------------------------------------- 1 | package com.oyp.battery; 2 | 3 | import android.os.Handler; 4 | import android.os.Message; 5 | import android.support.v7.app.AppCompatActivity; 6 | import android.os.Bundle; 7 | 8 | import java.lang.ref.WeakReference; 9 | import java.util.Timer; 10 | import java.util.TimerTask; 11 | /** 12 | * 自定义View 展示界面 13 | *

14 | * created by OuyangPeng at 2018/6/15 下午 03:33 15 | * @author OuyangPeng 16 | */ 17 | public class MainActivity extends AppCompatActivity implements BaseHandlerCallBack { 18 | 19 | private PowerConsumptionRankingsBatteryView mPowerConsumptionRankingsBatteryView; 20 | private int power; 21 | 22 | private NoLeakHandler mHandler; 23 | 24 | @Override 25 | protected void onCreate(Bundle savedInstanceState) { 26 | super.onCreate(savedInstanceState); 27 | setContentView(R.layout.activity_main); 28 | mHandler = new NoLeakHandler(this); 29 | mPowerConsumptionRankingsBatteryView = (PowerConsumptionRankingsBatteryView) findViewById(R.id.mPowerConsumptionRankingsBatteryView); 30 | 31 | new Timer().schedule(new TimerTask() { 32 | @Override 33 | public void run() { 34 | mHandler.sendEmptyMessage(0); 35 | } 36 | }, 0, 100); 37 | } 38 | 39 | @Override 40 | protected void onDestroy() { 41 | super.onDestroy(); 42 | mHandler.removeCallbacksAndMessages(null); 43 | } 44 | 45 | @Override 46 | public void callBack(Message msg) { 47 | switch (msg.what) { 48 | case 0: 49 | mPowerConsumptionRankingsBatteryView.setLevelHeight(power += 5); 50 | if (power == 100) { 51 | power = 0; 52 | } 53 | if (power < 30) { 54 | mPowerConsumptionRankingsBatteryView.setLowerPower(); 55 | } else if (power < 60) { 56 | mPowerConsumptionRankingsBatteryView.setOffline(); 57 | } else { 58 | mPowerConsumptionRankingsBatteryView.setOnline(); 59 | } 60 | break; 61 | default: 62 | break; 63 | } 64 | } 65 | 66 | private static class NoLeakHandler extends Handler { 67 | private WeakReference wr; 68 | 69 | public NoLeakHandler(T t) { 70 | wr = new WeakReference<>(t); 71 | } 72 | 73 | @Override 74 | public void handleMessage(Message msg) { 75 | super.handleMessage(msg); 76 | T t = wr.get(); 77 | if (t != null) { 78 | t.callBack(msg); 79 | } 80 | } 81 | } 82 | } 83 | -------------------------------------------------------------------------------- /app/src/main/java/com/oyp/battery/PowerConsumptionRankingsBatteryView.java: -------------------------------------------------------------------------------- 1 | package com.oyp.battery; 2 | 3 | import android.content.Context; 4 | import android.content.res.TypedArray; 5 | import android.graphics.Canvas; 6 | import android.graphics.DrawFilter; 7 | import android.graphics.Paint; 8 | import android.graphics.PaintFlagsDrawFilter; 9 | import android.graphics.RectF; 10 | import android.support.annotation.Nullable; 11 | import android.util.AttributeSet; 12 | import android.view.View; 13 | 14 | 15 | /** 16 | * 自定义 耗电排行内的 电池图标 17 | *

18 | * created by OuyangPeng at 2018/6/10 下午 05:57 19 | * 20 | * @author OuyangPeng 21 | */ 22 | public class PowerConsumptionRankingsBatteryView extends View { 23 | /** 24 | * 电池最大电量 25 | */ 26 | public static final int MAX_LEVEL = 100; 27 | /** 28 | * 电池默认电量 29 | */ 30 | public static final int DEFAULT_LEVEL = 40; 31 | 32 | /** 33 | * 自定义View的宽 34 | */ 35 | private int width; 36 | /** 37 | * 自定义View的高 38 | */ 39 | private int height; 40 | /** 41 | * 抗锯齿标志 42 | */ 43 | private DrawFilter drawFilter; 44 | /** 45 | * 电池外壳 厚度 46 | */ 47 | private int shellStrokeWidth; 48 | /** 49 | * 电池外壳 圆角 50 | */ 51 | private int shellCornerRadius; 52 | /** 53 | * 电池外壳 宽度 54 | */ 55 | private int shellWidth; 56 | /** 57 | * 电池外壳 宽度 58 | */ 59 | private int shellHeight; 60 | /** 61 | * 电池头 圆角 62 | */ 63 | private int shellHeadCornerRadius; 64 | /** 65 | * 电池头 宽度 66 | */ 67 | private int shellHeadWidth; 68 | /** 69 | * 电池头 高度 70 | */ 71 | private int shellHeadHeight; 72 | 73 | /** 74 | * 电池宽度 75 | */ 76 | private int levelWidth; 77 | /** 78 | * 电池最大高度 79 | */ 80 | private int levelMaxHeight; 81 | /** 82 | * 电池高度 83 | */ 84 | private int levelHeight = 100; 85 | 86 | /** 87 | * 电池外壳和电池等级直接的间距 88 | */ 89 | private int gap; 90 | 91 | /** 92 | * 电池外壳 画笔 93 | */ 94 | private Paint shellPaint; 95 | /** 96 | * 电池外壳 97 | */ 98 | private RectF shellRectF; 99 | /** 100 | * 电池头 101 | */ 102 | private RectF shellHeadRect; 103 | 104 | /** 105 | * 电池电量 画笔 106 | */ 107 | private Paint levelPaint; 108 | /** 109 | * 电池电量 110 | */ 111 | private RectF levelRect; 112 | 113 | /** 114 | * 低电颜色 115 | */ 116 | private int lowerPowerColor; 117 | /** 118 | * 在线颜色 119 | */ 120 | private int onlineColor; 121 | /** 122 | * 离线颜色 123 | */ 124 | private int offlineColor; 125 | 126 | public PowerConsumptionRankingsBatteryView(Context context) { 127 | super(context); 128 | } 129 | 130 | public PowerConsumptionRankingsBatteryView(Context context, @Nullable AttributeSet attrs) { 131 | super(context, attrs); 132 | drawFilter = new PaintFlagsDrawFilter(0, Paint.ANTI_ALIAS_FLAG | Paint.FILTER_BITMAP_FLAG); 133 | 134 | initTypeArray(context, attrs); 135 | 136 | //设置 电池壳画笔的相关属性 137 | shellPaint = new Paint(); 138 | shellPaint.setAntiAlias(true); 139 | shellPaint.setColor(onlineColor); 140 | shellPaint.setStrokeWidth(shellStrokeWidth); 141 | shellPaint.setAntiAlias(true); 142 | 143 | //设置 电池画笔的相关属性 144 | levelPaint = new Paint(); 145 | levelPaint.setColor(onlineColor); 146 | levelPaint.setStyle(Paint.Style.FILL); 147 | levelPaint.setStrokeWidth(levelWidth); 148 | 149 | shellRectF = new RectF(); 150 | shellHeadRect = new RectF(); 151 | levelRect = new RectF(); 152 | } 153 | 154 | /** 155 | * 初始化自定义属性 156 | */ 157 | private void initTypeArray(Context context, @Nullable AttributeSet attrs) { 158 | TypedArray typedArray = context.obtainStyledAttributes(attrs, R.styleable.PowerConsumptionRankingsBatteryView); 159 | lowerPowerColor = typedArray.getColor(R.styleable.PowerConsumptionRankingsBatteryView_batteryLowerPowerColor, 160 | getResources().getColor(R.color.lowerPowerColor)); 161 | onlineColor = typedArray.getColor(R.styleable.PowerConsumptionRankingsBatteryView_batteryOnlineColor, 162 | getResources().getColor(R.color.onlineColor)); 163 | offlineColor = typedArray.getColor(R.styleable.PowerConsumptionRankingsBatteryView_batteryOfflineColor, 164 | getResources().getColor(R.color.offlineColor)); 165 | //外壳的相关信息 166 | shellCornerRadius = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellCornerRadius, 167 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_shell_corner)); 168 | shellWidth = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellWidth, 169 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_shell_width)); 170 | shellHeight = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellHeight, 171 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_shell_height)); 172 | shellStrokeWidth = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellStrokeWidth, 173 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_shell_stroke_width)); 174 | 175 | //电池头的相关信息 176 | shellHeadCornerRadius = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellHeadCornerRadius, 177 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_head_corner)); 178 | shellHeadWidth = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellHeadWidth, 179 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_head_width)); 180 | shellHeadHeight = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryShellHeadHeight, 181 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_head_height)); 182 | 183 | //电池最大高度 184 | levelMaxHeight = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryLevelMaxHeight, 185 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_level_max_height)); 186 | //电池宽度 187 | levelWidth = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryLevelWidth, 188 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_level_width)); 189 | 190 | //电池外壳和电池等级直接的间距 191 | gap = typedArray.getDimensionPixelOffset(R.styleable.PowerConsumptionRankingsBatteryView_batteryGap, 192 | getResources().getDimensionPixelOffset(R.dimen.power_consumption_rankings_dimen_main_battery_view_gap)); 193 | //回收typedArray 194 | typedArray.recycle(); 195 | } 196 | 197 | @Override 198 | protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) { 199 | super.onMeasure(widthMeasureSpec, heightMeasureSpec); 200 | //对View上的內容进行测量后得到的View內容占据的宽度 201 | width = getMeasuredWidth(); 202 | //对View上的內容进行测量后得到的View內容占据的高度 203 | height = getMeasuredHeight(); 204 | } 205 | 206 | @Override 207 | protected void onDraw(Canvas canvas) { 208 | super.onDraw(canvas); 209 | canvas.setDrawFilter(drawFilter); 210 | 211 | // 电池头 矩形的坐标 212 | 213 | //坐标 left：控件整体宽度的一半 减去 电池头宽度的一半 214 | shellHeadRect.left = width / 2 - shellHeadWidth / 2; 215 | //坐标 top： 0 216 | shellHeadRect.top = 0; 217 | //坐标 right：控件整体宽度的一半 加上 电池头宽度的一半 218 | shellHeadRect.right = width / 2 + shellHeadWidth / 2; 219 | //坐标 bottom：电池头的高度 220 | shellHeadRect.bottom = shellHeadHeight; 221 | 222 | // 电池壳 矩形的坐标 223 | 224 | //坐标 left：电池壳厚度的一半 225 | shellRectF.left = shellStrokeWidth / 2; 226 | //坐标 left：电池壳厚度的一半 加上 电池头的高度 227 | shellRectF.top = shellStrokeWidth / 2 + shellHeadHeight; 228 | //坐标 right：控件整体宽度 减去 电池壳厚度的一半 229 | shellRectF.right = width - shellStrokeWidth / 2; 230 | //坐标 bottom：控件整体高度 减去 电池壳厚度的一半 231 | shellRectF.bottom = height - shellStrokeWidth / 2; 232 | 233 | // 电池电量 矩形的坐标 234 | 235 | //坐标 left：电池壳厚度的一半 加上 电池外壳和电池等级直接的间距 236 | levelRect.left = shellStrokeWidth + gap; 237 | 238 | //电池满格时候的最大高度 ：（控件整体高度 减去电池壳厚度 减去电池头高度 减去 电池外壳和电池等级直接的间距的两倍） 239 | //topOffset: 电池满格时候的最大高度 * （电池满格100 - 当前的电量）/ 电池满格100 240 | float topOffset = (height - shellHeadHeight - gap * 2 - shellStrokeWidth) * (MAX_LEVEL - levelHeight) / MAX_LEVEL; 241 | //坐标 top：电池头的高度 + 电池壳的厚度 + 电池外壳和电池等级直接的间距 + topOffset 242 | levelRect.top = shellHeadHeight + shellStrokeWidth + gap + topOffset; 243 | 244 | //坐标 right：控件整体宽度 减去 电池壳厚度的一半 减去 电池外壳和电池等级直接的间距 245 | levelRect.right = width - shellStrokeWidth - gap; 246 | 247 | //坐标 bottom：控件整体宽度 减去 电池壳厚度的一半 减去 电池外壳和电池等级直接的间距 248 | levelRect.bottom = height - shellStrokeWidth - gap; 249 | 250 | //绘制电池头 251 | shellPaint.setStyle(Paint.Style.FILL); 252 | canvas.drawRoundRect(shellHeadRect, shellHeadCornerRadius, shellHeadCornerRadius, shellPaint); 253 | //由于电池头的左下角和右下角不是圆角的，因此我们需要画一个矩形 覆盖圆角 254 | //绘制左下角矩形 255 | canvas.drawRect(shellHeadRect.left, shellHeadRect.bottom - shellHeadCornerRadius, 256 | shellHeadRect.left + shellHeadCornerRadius, shellHeadRect.bottom, shellPaint); 257 | //绘制右下角矩形 258 | canvas.drawRect(shellHeadRect.right - shellHeadCornerRadius, shellHeadRect.bottom - shellHeadCornerRadius, 259 | shellHeadRect.right, shellHeadRect.bottom, shellPaint); 260 | 261 | //绘制电池壳 262 | shellPaint.setStyle(Paint.Style.STROKE); 263 | canvas.drawRoundRect(shellRectF, shellCornerRadius, shellCornerRadius, shellPaint); 264 | 265 | //绘制电池等级 266 | canvas.drawRect(levelRect, levelPaint); 267 | } 268 | 269 | /** 270 | * 设置电池电量 271 | * 272 | * @param level 273 | */ 274 | public void setLevelHeight(int level) { 275 | this.levelHeight = level; 276 | if (this.levelHeight < 0) { 277 | levelHeight = MAX_LEVEL; 278 | } else if (this.levelHeight > MAX_LEVEL) { 279 | levelHeight = MAX_LEVEL; 280 | } 281 | postInvalidate(); 282 | } 283 | 284 | /** 285 | * 设置在线 重绘 286 | */ 287 | public void setOnline() { 288 | shellPaint.setColor(onlineColor); 289 | levelPaint.setColor(onlineColor); 290 | postInvalidate(); 291 | } 292 | 293 | /** 294 | * 设置离线 重绘 295 | */ 296 | public void setOffline() { 297 | shellPaint.setColor(offlineColor); 298 | levelPaint.setColor(offlineColor); 299 | postInvalidate(); 300 | } 301 | 302 | /** 303 | * 设置低电 重绘 304 | */ 305 | public void setLowerPower() { 306 | shellPaint.setColor(lowerPowerColor); 307 | levelPaint.setColor(lowerPowerColor); 308 | postInvalidate(); 309 | } 310 | } 311 | -------------------------------------------------------------------------------- /app/src/main/res/drawable-v24/ic_launcher_foreground.xml: -------------------------------------------------------------------------------- 1 | 7 | 12 | 13 | 19 | 22 | 25 | 26 | 27 | 28 | 34 | 35 | -------------------------------------------------------------------------------- /app/src/main/res/drawable/ic_launcher_background.xml: -------------------------------------------------------------------------------- 1 | 2 | 7 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 55 | 60 | 65 | 70 | 75 | 80 | 85 | 90 | 95 | 100 | 105 | 110 | 115 | 120 | 125 | 130 | 135 | 140 | 145 | 150 | 155 | 160 | 165 | 170 | 171 | -------------------------------------------------------------------------------- /app/src/main/res/layout/activity_main.xml: -------------------------------------------------------------------------------- 1 | 2 | 9 | 10 | 19 | 20 | 31 | 32 | -------------------------------------------------------------------------------- /app/src/main/res/mipmap-anydpi-v26/ic_launcher.xml: -------------------------------------------------------------------------------- 1 | 2 | 3 | 4 | 5 | -------------------------------------------------------------------------------- /app/src/main/res/mipmap-anydpi-v26/ic_launcher_round.xml: -------------------------------------------------------------------------------- 1 | 2 | 3 | 4 | 5 | -------------------------------------------------------------------------------- /app/src/main/res/mipmap-hdpi/ic_launcher.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-hdpi/ic_launcher.png -------------------------------------------------------------------------------- /app/src/main/res/mipmap-hdpi/ic_launcher_round.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-hdpi/ic_launcher_round.png -------------------------------------------------------------------------------- /app/src/main/res/mipmap-mdpi/ic_launcher.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-mdpi/ic_launcher.png -------------------------------------------------------------------------------- /app/src/main/res/mipmap-mdpi/ic_launcher_round.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-mdpi/ic_launcher_round.png -------------------------------------------------------------------------------- /app/src/main/res/mipmap-xhdpi/ic_launcher.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-xhdpi/ic_launcher.png -------------------------------------------------------------------------------- /app/src/main/res/mipmap-xhdpi/ic_launcher_round.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-xhdpi/ic_launcher_round.png -------------------------------------------------------------------------------- /app/src/main/res/mipmap-xxhdpi/ic_launcher.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-xxhdpi/ic_launcher.png -------------------------------------------------------------------------------- /app/src/main/res/mipmap-xxhdpi/ic_launcher_round.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-xxhdpi/ic_launcher_round.png -------------------------------------------------------------------------------- /app/src/main/res/mipmap-xxxhdpi/ic_launcher.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-xxxhdpi/ic_launcher.png -------------------------------------------------------------------------------- /app/src/main/res/mipmap-xxxhdpi/ic_launcher_round.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/app/src/main/res/mipmap-xxxhdpi/ic_launcher_round.png -------------------------------------------------------------------------------- /app/src/main/res/values/attrs.xml: -------------------------------------------------------------------------------- 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 20 | 21 | 22 | 23 | 24 | 25 | 26 | 27 | 28 | -------------------------------------------------------------------------------- /app/src/main/res/values/colors.xml: -------------------------------------------------------------------------------- 1 | 2 | 3 | #3F51B5 4 | #303F9F 5 | #FF4081 6 | 7 | 8 | #ff4d4d 9 | #00d68d 10 | #bfbfbf 11 | 12 | -------------------------------------------------------------------------------- /app/src/main/res/values/dimens.xml: -------------------------------------------------------------------------------- 1 | 2 | 3 | 4 | 48dp 5 | 6 | 31dp 7 | 8 | 9 | 2.5dp 10 | 11 | 12 | 28dp 13 | 14 | 42dp 15 | 16 | 3dp 17 | 18 | 19 | 14dp 20 | 21 | 3dp 22 | 23 | 2dp 24 | 25 | 26 | 2dp 27 | 28 | 29 | 22dp 30 | 31 | 35dp 32 | 33 | -------------------------------------------------------------------------------- /app/src/main/res/values/strings.xml: -------------------------------------------------------------------------------- 1 | 2 | 自定义电池View 【作者：欧阳鹏】 3 | 欧阳鹏 https://blog.csdn.net/ouyang_peng/ 4 | 5 | -------------------------------------------------------------------------------- /app/src/main/res/values/styles.xml: -------------------------------------------------------------------------------- 1 | 2 | 3 | 4 | 10 | 11 | 12 | -------------------------------------------------------------------------------- /app/src/test/java/com/oyp/battery/ExampleUnitTest.java: -------------------------------------------------------------------------------- 1 | package com.oyp.battery; 2 | 3 | import org.junit.Test; 4 | 5 | import static org.junit.Assert.*; 6 | 7 | /** 8 | * Example local unit test, which will execute on the development machine (host). 9 | * 10 | * @see Testing documentation 11 | */ 12 | public class ExampleUnitTest { 13 | @Test 14 | public void addition_isCorrect() { 15 | assertEquals(4, 2 + 2); 16 | } 17 | } -------------------------------------------------------------------------------- /build.gradle: -------------------------------------------------------------------------------- 1 | // Top-level build file where you can add configuration options common to all sub-projects/modules. 2 | 3 | buildscript { 4 | 5 | repositories { 6 | google() 7 | jcenter() 8 | } 9 | dependencies { 10 | classpath 'com.android.tools.build:gradle:3.1.3' 11 | 12 | 13 | // NOTE: Do not place your application dependencies here; they belong 14 | // in the individual module build.gradle files 15 | } 16 | } 17 | 18 | allprojects { 19 | repositories { 20 | google() 21 | jcenter() 22 | } 23 | } 24 | 25 | task clean(type: Delete) { 26 | delete rootProject.buildDir 27 | } 28 | -------------------------------------------------------------------------------- /gradle.properties: -------------------------------------------------------------------------------- 1 | # Project-wide Gradle settings. 2 | # IDE (e.g. Android Studio) users: 3 | # Gradle settings configured through the IDE *will override* 4 | # any settings specified in this file. 5 | # For more details on how to configure your build environment visit 6 | # http://www.gradle.org/docs/current/userguide/build_environment.html 7 | # Specifies the JVM arguments used for the daemon process. 8 | # The setting is particularly useful for tweaking memory settings. 9 | org.gradle.jvmargs=-Xmx1536m 10 | # When configured, Gradle will run in incubating parallel mode. 11 | # This option should only be used with decoupled projects. More details, visit 12 | # http://www.gradle.org/docs/current/userguide/multi_project_builds.html#sec:decoupled_projects 13 | # org.gradle.parallel=true 14 | -------------------------------------------------------------------------------- /gradle/wrapper/gradle-wrapper.jar: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/gradle/wrapper/gradle-wrapper.jar -------------------------------------------------------------------------------- /gradle/wrapper/gradle-wrapper.properties: -------------------------------------------------------------------------------- 1 | #Fri Jun 15 15:00:11 CST 2018 2 | distributionBase=GRADLE_USER_HOME 3 | distributionPath=wrapper/dists 4 | zipStoreBase=GRADLE_USER_HOME 5 | zipStorePath=wrapper/dists 6 | distributionUrl=https\://services.gradle.org/distributions/gradle-4.4-all.zip 7 | -------------------------------------------------------------------------------- /gradlew: -------------------------------------------------------------------------------- 1 | #!/usr/bin/env sh 2 | 3 | ############################################################################## 4 | ## 5 | ## Gradle start up script for UN*X 6 | ## 7 | ############################################################################## 8 | 9 | # Attempt to set APP_HOME 10 | # Resolve links: $0 may be a link 11 | PRG="$0" 12 | # Need this for relative symlinks. 13 | while [ -h "$PRG" ] ; do 14 | ls=`ls -ld "$PRG"` 15 | link=`expr "$ls" : '.*-> \(.*\)$'` 16 | if expr "$link" : '/.*' > /dev/null; then 17 | PRG="$link" 18 | else 19 | PRG=`dirname "$PRG"`"/$link" 20 | fi 21 | done 22 | SAVED="`pwd`" 23 | cd "`dirname \"$PRG\"`/" >/dev/null 24 | APP_HOME="`pwd -P`" 25 | cd "$SAVED" >/dev/null 26 | 27 | APP_NAME="Gradle" 28 | APP_BASE_NAME=`basename "$0"` 29 | 30 | # Add default JVM options here. You can also use JAVA_OPTS and GRADLE_OPTS to pass JVM options to this script. 31 | DEFAULT_JVM_OPTS="" 32 | 33 | # Use the maximum available, or set MAX_FD != -1 to use that value. 34 | MAX_FD="maximum" 35 | 36 | warn () { 37 | echo "$*" 38 | } 39 | 40 | die () { 41 | echo 42 | echo "$*" 43 | echo 44 | exit 1 45 | } 46 | 47 | # OS specific support (must be 'true' or 'false'). 48 | cygwin=false 49 | msys=false 50 | darwin=false 51 | nonstop=false 52 | case "`uname`" in 53 | CYGWIN* ) 54 | cygwin=true 55 | ;; 56 | Darwin* ) 57 | darwin=true 58 | ;; 59 | MINGW* ) 60 | msys=true 61 | ;; 62 | NONSTOP* ) 63 | nonstop=true 64 | ;; 65 | esac 66 | 67 | CLASSPATH=$APP_HOME/gradle/wrapper/gradle-wrapper.jar 68 | 69 | # Determine the Java command to use to start the JVM. 70 | if [ -n "$JAVA_HOME" ] ; then 71 | if [ -x "$JAVA_HOME/jre/sh/java" ] ; then 72 | # IBM's JDK on AIX uses strange locations for the executables 73 | JAVACMD="$JAVA_HOME/jre/sh/java" 74 | else 75 | JAVACMD="$JAVA_HOME/bin/java" 76 | fi 77 | if [ ! -x "$JAVACMD" ] ; then 78 | die "ERROR: JAVA_HOME is set to an invalid directory: $JAVA_HOME 79 | 80 | Please set the JAVA_HOME variable in your environment to match the 81 | location of your Java installation." 82 | fi 83 | else 84 | JAVACMD="java" 85 | which java >/dev/null 2>&1 || die "ERROR: JAVA_HOME is not set and no 'java' command could be found in your PATH. 86 | 87 | Please set the JAVA_HOME variable in your environment to match the 88 | location of your Java installation." 89 | fi 90 | 91 | # Increase the maximum file descriptors if we can. 92 | if [ "$cygwin" = "false" -a "$darwin" = "false" -a "$nonstop" = "false" ] ; then 93 | MAX_FD_LIMIT=`ulimit -H -n` 94 | if [ $? -eq 0 ] ; then 95 | if [ "$MAX_FD" = "maximum" -o "$MAX_FD" = "max" ] ; then 96 | MAX_FD="$MAX_FD_LIMIT" 97 | fi 98 | ulimit -n $MAX_FD 99 | if [ $? -ne 0 ] ; then 100 | warn "Could not set maximum file descriptor limit: $MAX_FD" 101 | fi 102 | else 103 | warn "Could not query maximum file descriptor limit: $MAX_FD_LIMIT" 104 | fi 105 | fi 106 | 107 | # For Darwin, add options to specify how the application appears in the dock 108 | if $darwin; then 109 | GRADLE_OPTS="$GRADLE_OPTS \"-Xdock:name=$APP_NAME\" \"-Xdock:icon=$APP_HOME/media/gradle.icns\"" 110 | fi 111 | 112 | # For Cygwin, switch paths to Windows format before running java 113 | if $cygwin ; then 114 | APP_HOME=`cygpath --path --mixed "$APP_HOME"` 115 | CLASSPATH=`cygpath --path --mixed "$CLASSPATH"` 116 | JAVACMD=`cygpath --unix "$JAVACMD"` 117 | 118 | # We build the pattern for arguments to be converted via cygpath 119 | ROOTDIRSRAW=`find -L / -maxdepth 1 -mindepth 1 -type d 2>/dev/null` 120 | SEP="" 121 | for dir in $ROOTDIRSRAW ; do 122 | ROOTDIRS="$ROOTDIRS$SEP$dir" 123 | SEP="|" 124 | done 125 | OURCYGPATTERN="(^($ROOTDIRS))" 126 | # Add a user-defined pattern to the cygpath arguments 127 | if [ "$GRADLE_CYGPATTERN" != "" ] ; then 128 | OURCYGPATTERN="$OURCYGPATTERN|($GRADLE_CYGPATTERN)" 129 | fi 130 | # Now convert the arguments - kludge to limit ourselves to /bin/sh 131 | i=0 132 | for arg in "$@" ; do 133 | CHECK=`echo "$arg"|egrep -c "$OURCYGPATTERN" -` 134 | CHECK2=`echo "$arg"|egrep -c "^-"` ### Determine if an option 135 | 136 | if [ $CHECK -ne 0 ] && [ $CHECK2 -eq 0 ] ; then ### Added a condition 137 | eval `echo args$i`=`cygpath --path --ignore --mixed "$arg"` 138 | else 139 | eval `echo args$i`="\"$arg\"" 140 | fi 141 | i=$((i+1)) 142 | done 143 | case $i in 144 | (0) set -- ;; 145 | (1) set -- "$args0" ;; 146 | (2) set -- "$args0" "$args1" ;; 147 | (3) set -- "$args0" "$args1" "$args2" ;; 148 | (4) set -- "$args0" "$args1" "$args2" "$args3" ;; 149 | (5) set -- "$args0" "$args1" "$args2" "$args3" "$args4" ;; 150 | (6) set -- "$args0" "$args1" "$args2" "$args3" "$args4" "$args5" ;; 151 | (7) set -- "$args0" "$args1" "$args2" "$args3" "$args4" "$args5" "$args6" ;; 152 | (8) set -- "$args0" "$args1" "$args2" "$args3" "$args4" "$args5" "$args6" "$args7" ;; 153 | (9) set -- "$args0" "$args1" "$args2" "$args3" "$args4" "$args5" "$args6" "$args7" "$args8" ;; 154 | esac 155 | fi 156 | 157 | # Escape application args 158 | save () { 159 | for i do printf %s\\n "$i" | sed "s/'/'\\\\''/g;1s/^/'/;\$s/\$/' \\\\/" ; done 160 | echo " " 161 | } 162 | APP_ARGS=$(save "$@") 163 | 164 | # Collect all arguments for the java command, following the shell quoting and substitution rules 165 | eval set -- $DEFAULT_JVM_OPTS $JAVA_OPTS $GRADLE_OPTS "\"-Dorg.gradle.appname=$APP_BASE_NAME\"" -classpath "\"$CLASSPATH\"" org.gradle.wrapper.GradleWrapperMain "$APP_ARGS" 166 | 167 | # by default we should be in the correct project dir, but when run from Finder on Mac, the cwd is wrong 168 | if [ "$(uname)" = "Darwin" ] && [ "$HOME" = "$PWD" ]; then 169 | cd "$(dirname "$0")" 170 | fi 171 | 172 | exec "$JAVACMD" "$@" 173 | -------------------------------------------------------------------------------- /gradlew.bat: -------------------------------------------------------------------------------- 1 | @if "%DEBUG%" == "" @echo off 2 | @rem ########################################################################## 3 | @rem 4 | @rem Gradle startup script for Windows 5 | @rem 6 | @rem ########################################################################## 7 | 8 | @rem Set local scope for the variables with windows NT shell 9 | if "%OS%"=="Windows_NT" setlocal 10 | 11 | set DIRNAME=%~dp0 12 | if "%DIRNAME%" == "" set DIRNAME=. 13 | set APP_BASE_NAME=%~n0 14 | set APP_HOME=%DIRNAME% 15 | 16 | @rem Add default JVM options here. You can also use JAVA_OPTS and GRADLE_OPTS to pass JVM options to this script. 17 | set DEFAULT_JVM_OPTS= 18 | 19 | @rem Find java.exe 20 | if defined JAVA_HOME goto findJavaFromJavaHome 21 | 22 | set JAVA_EXE=java.exe 23 | %JAVA_EXE% -version >NUL 2>&1 24 | if "%ERRORLEVEL%" == "0" goto init 25 | 26 | echo. 27 | echo ERROR: JAVA_HOME is not set and no 'java' command could be found in your PATH. 28 | echo. 29 | echo Please set the JAVA_HOME variable in your environment to match the 30 | echo location of your Java installation. 31 | 32 | goto fail 33 | 34 | :findJavaFromJavaHome 35 | set JAVA_HOME=%JAVA_HOME:"=% 36 | set JAVA_EXE=%JAVA_HOME%/bin/java.exe 37 | 38 | if exist "%JAVA_EXE%" goto init 39 | 40 | echo. 41 | echo ERROR: JAVA_HOME is set to an invalid directory: %JAVA_HOME% 42 | echo. 43 | echo Please set the JAVA_HOME variable in your environment to match the 44 | echo location of your Java installation. 45 | 46 | goto fail 47 | 48 | :init 49 | @rem Get command-line arguments, handling Windows variants 50 | 51 | if not "%OS%" == "Windows_NT" goto win9xME_args 52 | 53 | :win9xME_args 54 | @rem Slurp the command line arguments. 55 | set CMD_LINE_ARGS= 56 | set _SKIP=2 57 | 58 | :win9xME_args_slurp 59 | if "x%~1" == "x" goto execute 60 | 61 | set CMD_LINE_ARGS=%* 62 | 63 | :execute 64 | @rem Setup the command line 65 | 66 | set CLASSPATH=%APP_HOME%\gradle\wrapper\gradle-wrapper.jar 67 | 68 | @rem Execute Gradle 69 | "%JAVA_EXE%" %DEFAULT_JVM_OPTS% %JAVA_OPTS% %GRADLE_OPTS% "-Dorg.gradle.appname=%APP_BASE_NAME%" -classpath "%CLASSPATH%" org.gradle.wrapper.GradleWrapperMain %CMD_LINE_ARGS% 70 | 71 | :end 72 | @rem End local scope for the variables with windows NT shell 73 | if "%ERRORLEVEL%"=="0" goto mainEnd 74 | 75 | :fail 76 | rem Set variable GRADLE_EXIT_CONSOLE if you need the _script_ return code instead of 77 | rem the _cmd.exe /c_ return code! 78 | if not "" == "%GRADLE_EXIT_CONSOLE%" exit 1 79 | exit /b 1 80 | 81 | :mainEnd 82 | if "%OS%"=="Windows_NT" endlocal 83 | 84 | :omega 85 | -------------------------------------------------------------------------------- /screenshot/v1.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/screenshot/v1.png -------------------------------------------------------------------------------- /screenshot/v2.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/screenshot/v2.png -------------------------------------------------------------------------------- /screenshot/v3.png: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/screenshot/v3.png -------------------------------------------------------------------------------- /screenshot/v4.mp4: -------------------------------------------------------------------------------- https://raw.githubusercontent.com/ouyangpeng/PowerConsumptionRankingsBatteryView/5f233a6e0de93daeb866bd3638ff1108546e49ad/screenshot/v4.mp4 -------------------------------------------------------------------------------- /settings.gradle: -------------------------------------------------------------------------------- 1 | include ':app' 2 | --------------------------------------------------------------------------------
