3 | # 0.6.6 Update Broke JSON
4 | Scrap Mechanic's Nov 0.6.6 update broke the JSON export to file method, for a workaround see the github issue with [workaround]. I have emailed the developers about the issue but with the holidays will probably be a while for a response.
5 |
6 | # Introduction
7 | This quickly outputs the world data of your scrap mechanic save game to a json file for display via leafletJS from pre-screenshotted tiles. Not quite as beautiful as my [older screenshot method], but SOOOOOoooooo much quicker. This method is somewhat future proof as well. New tiles will still be displayed just blank, but updates should only require a new download of the missing tiles images.
8 |
9 | # Example
10 | https://the1killer.github.io/scrapmechanictilemap/
11 |
12 | # INSTRUCTIONS
13 |
14 | !!!! BACKUP YOUR SAVE, not responsible for any issues !!!!
15 |
16 | 1. **Really backup your save!**
17 | 1. Download this repoistory, green "Code" button on the top right, or [Download Link]
18 | 1. Open `terrain_overworld.lua` from the downloaded files.
19 | 1. Copy lines 132-157, `local cells` *...to...* `cells = nil end`
20 | 1. Open `terrain_overworld.lua` in your game files, e.x. C:\Program Files (x86)\Steam\steamapps\common\Scrap Mechanic\Survival\Scripts\terrain\terrain_overworld.lua
21 | 1. Paste the lines into the game's terrain_overworld.lua, approx **line 130**, after `CreateCellTileStorageKeys()` within the `Load()` Function.
22 | 1. Replace `tile_database.lua` in your game files with the one from the downloaded files. E.x. C:\Program Files (x86)\Steam\steamapps\common\Scrap Mechanic\Survival\Scripts\terrain\overworld\tile_database.lua
23 | 1. Load your save game.
24 | 1. Copy **cells.json** from your game files C:\Program Files (x86)\Steam\steamapps\common\Scrap Mechanic\Survival\ to the **html\assets\json directory** in the downloads.
25 | 1. **If hosting on a webserver**
26 | 1. Copy all the files under **html/** to your webserver and open index.html and good to go.
27 | 1. **If viewing locally**
28 | 1. Open **cells.json**, select all text (ctrl-a), copy all text
29 | 1. Paste text into https://codebeautify.org/jsonminifier and click "minify/compress" then copy the resulting text on the right
30 | 1. Open **html/index.html**, on line 26 `SMOverviewMap.init();` add two back ticks( ` ) inside the parentheses
31 | 1. Paste the text from Part 2 inbetween the backticks. becomes `SMOverviewMap.init(`\``[[{......`\``);`
32 | 1. Open **html/index.html** to view your map
33 | 1. If you wish, remove or comment (--) the added lines in terrain_overworld.lua to improve game loading times
34 |
35 |
36 | ## Some things to note
37 | - Terrain height not really shown.
38 | - Game updates will remove the lua changes, requiring you to re-add them
39 | - How to setup your own free [GitHub website]
40 | - I think there could be some missing road/cliff tiles as there are many possibilties on how they mesh with eachother. Create an issue with your map seed and I can try to capture them.
41 |
42 |
43 | # Changelog
44 | - v1.0.0
45 | - Initial Release
46 |
47 | # Donation
48 | If you love this project and want to see more features give the developer a cup of coffee!
49 |
50 | [](https://www.paypal.com/cgi-bin/webscr?cmd=_donations&business=7JF52HNLJNHFE&item_name=SM+Overview+Donations¤cy_code=USD)
51 |
52 |
53 | # Tutorial Video
54 | Thanks to LionHeartBlue Gaming to making a tutorial video. Most people will need **Option 2** listed above and in the video.
