├── .gitignore
├── README.md
├── README_zh.md
├── config.h
├── examples
    ├── DataPointType
    │   ├── DataPointType.ino
    │   ├── README.md
    │   └── README_zh.md
    ├── GetGreenTime
    │   ├── GetGreenTime.ino
    │   ├── README.md
    │   └── README_zh.md
    ├── ModuleControlSelf
    │   ├── ModuleControlSelf.ino
    │   ├── README.md
    │   └── README_zh.md
    ├── SHT30
    │   ├── README.md
    │   ├── README_zh.md
    │   └── SHT30.ino
    └── start
    │   ├── README.md
    │   ├── README_zh.md
    │   └── start.ino
├── keywords.txt
├── library.properties
└── src
    ├── TuyaDataPoint.cpp
    ├── TuyaDataPoint.h
    ├── TuyaDefs.h
    ├── TuyaExtras.cpp
    ├── TuyaExtras.h
    ├── TuyaTools.cpp
    ├── TuyaTools.h
    ├── TuyaUart.cpp
    ├── TuyaUart.h
    ├── TuyaWifi.cpp
    └── TuyaWifi.h


/.gitignore:
--------------------------------------------------------------------------------
1 | *.o
2 | *.d


--------------------------------------------------------------------------------
/README.md:
--------------------------------------------------------------------------------
  1 | # Tuya MCU SDK Arduino Library
  2 |
  3 | [English](./README.md) | [中文](./README_zh.md)
  4 |
  5 | Tuya MCU SDK Arduino Library is developed based on the Tuya Wi-Fi general integration solution. The device's MCU is connected to a Wi-Fi module through a serial port to implement a network connection. **The development is based on general firmware, which supports the adaptative 9600 and115200 baud rate. Please read this document carefully before development.**
  6 |
  7 | <div align='center'>
  8 | <img src="https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/mcu_wifi_connect.png"/>
  9 | </div>
 10 |
 11 | ## [Tuya Beta Test Program](https://pages.tuya.com/develop/ArduinoBetaTest_discord?_source=f21d8ebfe2cde74110e27b26366a81f3)
 12 | Now welcome to join the [Tuya Beta Test Program](https://pages.tuya.com/develop/ArduinoBetaTest_discord?_source=f21d8ebfe2cde74110e27b26366a81f3) to get your development gifts and make your own arduino projects with Tuya Support. Your feedback is helpful and valuable to the whole community.
 13 | ![image](https://user-images.githubusercontent.com/85163056/126034859-0b9b8856-0556-4d3f-a201-a6951172c080.png)
 14 |
 15 |
 16 |
 17 | ## Document introduction
 18 |
 19 | ```bash
 20 | ├── config.h // Configuration file. Add and define features in the MCU SDK with macros.
 21 | ├── examples // The folder to save routines.
 22 | ├── keywords.txt
 23 | ├── library.properties
 24 | ├── README.md
 25 | └── src // The folder to save Tuya MCU SDK Arduino Library.
 26 |     ├── TuyaWifi.cpp // The APIs for users.
 27 |     ├── TuyaDataPoint.cpp // The class of DP operations.
 28 |     ├── TuyaDataPoint.h
 29 |     ├── TuyaDefs.h // Some constants.
 30 |     ├── TuyaWifi.h
 31 |     ├── TuyaTools.cpp // Tools used by the MCU SDK.
 32 |     ├── TuyaTools.h
 33 |     ├── TuyaUart.cpp // Functions for serial communications and data buffer.
 34 |     └── TuyaUart.h
 35 | ```
 36 |
 37 |
 38 |
 39 | ## Important functions
 40 |
 41 | When you use this library for development with Arduino, you must add the header file `TuyaWifi.h` in your Arduino project.
 42 |
 43 | ### 1. Initialization
 44 |
 45 | Every product that is created on the Tuya IoT Platform will have a unique product ID (PID). The PID is associated with all information related to this product, including specific DP, app control panel, and delivery information.
 46 |
 47 | In `unsigned char TuyaWifi::init(unsigned char *pid, unsigned char *mcu_ver)`, the PID is obtained after you create a product on the [Tuya IoT Platform](http://iot.tuya.com/?_source=bcd157afd1c16c931b7b44381c9fe884). The PID of a Wi-Fi product is typically 16 bytes. The `mcu_ver` parameter is the version number of the software. Pay attention to this parameter if you want to support OTA updates of the MCU.
 48 | > **Note**: The current version of the library does not support the OTA feature.
 49 |
 50 | ```c
 51 | #include <TuyaWifi.h>
 52 |
 53 | TuyaWifi my_device;
 54 | ...
 55 | void setup()
 56 | {
 57 |   Serial.begin(9600);
 58 |   ...
 59 |   my_device.init("xxxxxxxxxxxxxxxx", "1.0.0");// "xxxxxxxxxxxxxxxx": the PID on the Tuya IoT Platform. "1.0.0" is the default value. You can change "1.0.0" to the actual version number of the current software.
 60 |
 61 |   ...
 62 | }
 63 |
 64 | void loop()
 65 | {
 66 |   ...
 67 |   my_device.uart_service();
 68 |   ...
 69 | }
 70 | ...
 71 | ```
 72 |
 73 |
 74 |
 75 | ### 2. Pass in the DP information to the MCU SDK
 76 |
 77 | Create products on the [Tuya IoT Platform](http://iot.tuya.com/?_source=bcd157afd1c16c931b7b44381c9fe884) and get information on product DP points.
 78 |
 79 | A data point (DP) represents a smart device function.
 80 |
 81 | + Tuya abstracts each function into a data point. DPs are defined in different data types, such as Boolean, enumeration, and integer.
 82 | + DPs have read and write attributes. For example, a 2-gang switch has two Boolean DPs, and each DP has either a `True` or `False` value, which is readable and writable.
 83 | + To read means to get the current value of the switch, and to write means to change the current value of the switch.
 84 |
 85 | DPID: specifies the ID of a DP event under a communication protocol.
 86 |
 87 |
 88 | The MCU SDK needs to know which DPs you have created and what type they are. Pass them to the MCU SDK through the `void TuyaWifi::set_dp_cmd_total(unsigned char dp_cmd_array[][2], unsigned char dp_cmd_num)` function.
 89 | The Tuya IoT Platform has six types of DPs:
 90 |
 91 | ```c
 92 | #define DP_TYPE_RAW     0x00    // Raw type
 93 | #define DP_TYPE_BOOL    0x01    // Boolean type
 94 | #define DP_TYPE_VALUE   0x02    // Numeric type
 95 | #define DP_TYPE_STRING  0x03    // String type
 96 | #define DP_TYPE_ENUM    0x04    // Enum type
 97 | #define DP_TYPE_BITMAP  0x05    // Fault type
 98 | ```
 99 |
100 | In the `void TuyaWifi::set_dp_cmd_total(unsigned char dp_cmd_array[][2], unsigned char dp_cmd_num)` function, `dp_cmd_array[][2]` is the array that stores DP information, and `dp_cmd_num` is the total number of DPs.
101 |
102 |
103 |
104 | Assume that a light has three functions, corresponding to three DPs as below:
105 | * Switch (DP ID: 20, DP type: Boolean type).
106 | * Brightness (DP ID: 21, DP type: numeric type).
107 | * Light mode (DP ID: 22, DP type: enum type).
108 |
109 | ```c
110 | #include <TuyaWifi.h>
111 |
112 | TuyaWifi my_device;
113 | ...
114 | #define DPID_SWITCH 20 // The switch DP of the light.
115 | #define DPID_LIGHT 21 // The brightness DP of the light.
116 | #define DPID_MODE 22 // The working mode DP of the light.
117 |
118 | // Note: array[][0] is DP ID, and array[][1] is DP type.
119 | unsigned char dp_id_array[][2] = {
120 |     /*  DPID     |  DP type  */
121 |     {DPID_SWITCH, DP_TYPE_BOOL},
122 |     {DPID_LIGHT, DP_TYPE_VALUE},
123 |     {DPID_MODE, DP_TYPE_ENUM},
124 | };
125 | ...
126 | void setup()
127 | {
128 |     ...
129 |     my_device.set_dp_cmd_total(dp_id_array, 3);
130 |     ...
131 | }
132 | ```
133 |
134 |
135 |
136 | ### 3. Pairing mode setting
137 |
138 | Call `void TuyaWifi::mcu_set_wifi_mode(unsigned char mode)` to enter the pairing mode.
139 |
140 | ```c
141 | /**
142 |  * @description: The MCU sets Wi-Fi working mode
143 |  * @param {unsigned char} mode: Enter the specified mode
144 |  *                              0(SMART_CONFIG): Enter SmartConfig (Wi-Fi Easy Connect) mode
145 |  *                              1(AP_CONFIG): Enter AP mode
146 |  * @return {*}
147 |  */
148 | void TuyaWifi::mcu_set_wifi_mode(unsigned char mode);
149 | ```
150 |
151 |
152 |
153 |
154 |
155 | ### 4. Send and process DP data
156 |
157 | After the cloud sends data, the sent data must be parsed through the `unsigned char TuyaWifi::mcu_get_dp_download_data(unsigned char dpid, const unsigned char value[], unsigned short len)` function.
158 | Currently, this function only supports three types: `DP_TYPE_BOOL`, `DP_TYPE_VALUE`, and `DP_TYPE_ENUM`. `DP_TYPE_BITMAP` refers to the data of fault type, in which the data is only reported to the cloud. You do not need to handle this type. `DP_TYPE_RAW` and `DP_TYPE_STRING` must be implemented yourself.
159 |
160 | ```c
161 | /**
162 |  * @description: The MCU gets Boolean, numeric, and enum types to send DP value. (The data of the raw and string types shall be handled at the user's discretion. The data of the fault type can only be reported.)
163 |  * @param {unsigned char} dpid: Data point (DP) ID
164 |  * @param {const unsigned char} value: DP data buffer address
165 |  * @param {unsigned short} len: Data length
166 |  * @return {unsigned char} Parsed data
167 |  */
168 | unsigned char TuyaWifi::mcu_get_dp_download_data(unsigned char dpid, const unsigned char value[], unsigned short len);
169 | ```
170 |
171 |
172 |
173 | ### 5. Register a function to process DP sending
174 |
175 | The app sends DP control commands to the device through the cloud. After data parsing, the device executes the specified actions accordingly.
176 |
177 | A callback function is required to process the sent commands, so a processing function must be registered. We can call `void TuyaWifi::dp_process_func_register(tuya_callback_dp_download _func)` to register the callback function.
178 |
179 | ```c
180 | #include <TuyaWifi.h>
181 |
182 | TuyaWifi my_device;
183 | ...
184 |
185 | void setup()
186 | {
187 |     ...
188 |   // Register DP download processing callback function
189 |   my_device.dp_process_func_register(dp_process);
190 |     ...
191 | }
192 |
193 | /**
194 |  * @description: DP download callback function.
195 |  * @param {unsigned char} dpid
196 |  * @param {const unsigned char} value
197 |  * @param {unsigned short} length
198 |  * @return {unsigned char}
199 |  */
200 | unsigned char dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
201 | {
202 |   switch(dpid) {
203 |     case DPID_SWITCH:
204 |       switch_value = my_device.mcu_get_dp_download_data(dpid, value, length);
205 |       if (switch_value) {
206 |         // Turn on
207 |
208 |       } else {
209 |         // Turn off
210 |
211 |       }
212 |       // Status changes must be reported.
213 |       my_device.mcu_dp_update(dpid, value, length);
214 |     break;
215 |
216 |     default:break;
217 |   }
218 |   return SUCCESS;
219 | }
220 | ```
221 |
222 |
223 |
224 | ### 6. Report device status
225 |
226 | Reporting the device status is to report the values of all DPs. It is also implemented through function registration.
227 |
228 | Six data types of DPs are defined as follows:
229 |
230 | DP reporting function:
231 |
232 | ```c
233 | /**
234 |  * @description: DP data upload
235 |  * @param {unsigned char} dpid
236 |  * @param {const unsigned char} value
237 |  * @param {unsigned short} length
238 |  * @return {*}
239 |  */
240 | unsigned char mcu_dp_update(unsigned char dpid, const unsigned char value[], unsigned short len);//update raw, string type
241 | unsigned char mcu_dp_update(unsigned char dpid, unsigned long value, unsigned short len);
242 | unsigned char mcu_dp_update(unsigned char dpid, unsigned int value, unsigned short len);
243 | ```
244 |
245 |
246 | Example of registering a device status reporting function
247 |
248 | ```c
249 | #include <TuyaWifi.h>
250 |
251 | TuyaWifi my_device;
252 |
253 | #define DPID_SWITCH 20
254 | // Record the current status of the LED
255 | unsigned char switch_value = 0;
256 | ...
257 | void setup()
258 | {
259 |     ...
260 |   // Register DP download processing callback function
261 |   my_device.dp_update_all_func_register(dp_update_all);
262 |     ...
263 | }
264 |
265 | /**
266 |  * @description: Upload all DP status of the current device.
267 |  * @param {*}
268 |  * @return {*}
269 |  */
270 | void dp_update_all(void)
271 | {
272 |   my_device.mcu_dp_update(DPID_SWITCH, switch_value, 1);
273 | }
274 | ```
275 |
276 | ## Technical Support
277 |
278 | You can get support for Tuya by using the following methods:
279 |
280 | - Developer Centre: https://developer.tuya.com?_source=d3b1d41903c59173453028c00b26eda6
281 | - Help Centre: https://support.tuya.com/en/help?_source=9e55ab864ce95b016070141319a5206f
282 | - Technical Support Work Order Centre: https://service.console.tuya.com?_source=5817a709f62789fbeb91c94062bf8993
283 |
284 |


--------------------------------------------------------------------------------
/README_zh.md:
--------------------------------------------------------------------------------
  1 | # Tuya MCU SDK Arduino Library
  2 |
  3 | [English](./README.md) | [中文](./README_zh.md)
  4 |
  5 | Tuya MCU SDK Arduino Library 基于涂鸦Wi-Fi 通用对接方案进行开发的，设备 MCU 通过串口与 Wi-Fi 模组连接实现设备联网。**涂鸦模组中的固件应为通用固件，通用固件支持9600，115200两种波特率自适应。开发前请仔细阅读该文档。**
  6 |
  7 | <div align='center'>
  8 | <img src="https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/mcu_wifi_connect.png"/>
  9 | </div>
 10 |
 11 |
 12 |
 13 | ## 文件介绍
 14 |
 15 | ```bash
 16 | ├── config.h	//配置文件，通过一些宏对mcu sdk内的功能进行添加和裁剪
 17 | ├── examples	//例程存放文件夹(DataPointType例程对于涂鸦的数据类型进行了示例，具有较强的参考价值)
 18 | ├── keywords.txt
 19 | ├── library.properties
 20 | ├── README.md
 21 | └── src	//Tuya mcu sdk Arduino Library 存放文件夹
 22 |     ├── TuyaWifi.cpp	//用户会使用到的API接口
 23 |     ├── TuyaDataPoint.cpp //对DP点相关操作的类
 24 |     ├── TuyaDataPoint.h
 25 |     ├── TuyaDefs.h	//会用到的，用户不需改动的一些常量
 26 |     ├── TuyaWifi.h
 27 |     ├── TuyaTools.cpp	//MCU SDK会使用到的一些工具
 28 |     ├── TuyaTools.h
 29 |     ├── TuyaUart.cpp	//对串口和数据缓存区处理的一些函数
 30 |     └── TuyaUart.h
 31 | ```
 32 |
 33 |
 34 |
 35 | ## 重要函数
 36 |
 37 | 在Arduino中使用该库进行编程开发时，必须在你的Arduino工程文件中包含 `TuyaWifi.h` 头文件。
 38 |
 39 |
 40 |
 41 | ### 1、相关信息初始化
 42 |
 43 | 在使用Tuya IoT 云平台的时候，Product ID（简称：PID） 关联了产品具体的功能点、App 控制面板、出货信息等所有跟这个产品相关的信息。
 44 |
 45 | `unsigned char TuyaWifi::init(unsigned char *pid, unsigned char *mcu_ver)` ，PID通过在 [Tuya IoT平台](https://iot.tuya.com/?_source=97c44038fafc20e9c8dd5fdb508cc9c2) 上创建产品获取，wifi类的长度一般为16，`mcu_ver` 这个参数是软件的版本号，如果你的mcu想要支持OTA的话，该信息也是非常重要的。
 46 |
 47 | > **提示**：当前版本的library暂不支持OTA功能。
 48 |
 49 | ```c
 50 | #include <TuyaWifi.h>
 51 |
 52 | TuyaWifi my_device;
 53 | ...
 54 | void setup()
 55 | {
 56 |   Serial.begin(9600);
 57 |   ...
 58 |   my_device.init("xxxxxxxxxxxxxxxx", "1.0.0");//"xxxxxxxxxxxxxxxx":应为你在Tuya IoT 平台上获取的的PID，"1.0.0"应是当前软件的实际版本号
 59 |
 60 |   ...
 61 | }
 62 |
 63 | void loop()
 64 | {
 65 |   ...
 66 |   my_device.uart_service();
 67 |   ...
 68 | }
 69 |
 70 | ...
 71 | ```
 72 |
 73 |
 74 |
 75 | ### 2、DP信息传入MCU SDK
 76 |
 77 | 在[Tuya IoT平台](https://iot.tuya.com/?_source=97c44038fafc20e9c8dd5fdb508cc9c2)创建产品，获取产品DP点信息。
 78 |
 79 | DP为 Data Point 的缩写，即数据点，偶尔被称为 DP 点，表示智能设备所具备的功能点。
 80 |
 81 | + 涂鸦智能将每个功能点抽象成数据点，数据点定义成不同的类型，例如布尔、枚举、数值等。
 82 | + 数据点具备读写属性。例如，一个两路的开关，可以抽象成两个数据点，每个数据点类型为布尔型，可取值为 `True` 或 `False`。
 83 | + 数据点可读写，读表示获取开关目前的值，写表示改变开关目前的值。
 84 |
 85 | DPID:指定通信协议下 DP 事件的 ID。
 86 |
 87 |
 88 |
 89 | MCU SDK需要知道你创建了哪些DP点，他们是什么类型的，通过 `void TuyaWifi::set_dp_cmd_total(unsigned char dp_cmd_array[][2], unsigned char dp_cmd_num)` 函数传入MCU SDK。Tuya IoT 对于DP的类型分为6类：
 90 |
 91 | ```c
 92 | #define DP_TYPE_RAW     0x00    //RAW type
 93 | #define DP_TYPE_BOOL    0x01    //bool type
 94 | #define DP_TYPE_VALUE   0x02    //value type
 95 | #define DP_TYPE_STRING  0x03    //string type
 96 | #define DP_TYPE_ENUM    0x04    //enum type
 97 | #define DP_TYPE_BITMAP  0x05    //fault type
 98 | ```
 99 |
100 | 关于`void TuyaWifi::set_dp_cmd_total(unsigned char dp_cmd_array[][2], unsigned char dp_cmd_num)` 函数，`dp_cmd_array[][2]` 为存储的信息的数组，`dp_cmd_num` 为DP总数。
101 |
102 |
103 |
104 | 这里我们假设有一个灯，它主要有3个功能也就是3个DP点，分别是:
105 |
106 | + 开关（DP ID : 20, DP 类型：布尔类型）
107 | + 灯的亮度（DP ID : 21, DP 类型：数值类型）
108 | + 灯光模式（DP ID : 22, DP 类型：枚举类型）
109 |
110 | ```c
111 | #include <TuyaWifi.h>
112 |
113 | TuyaWifi my_device;
114 | ...
115 | #define DPID_SWITCH	20	//灯的开关DP
116 | #define DPID_LIGHT	21	//灯的亮度DP
117 | #define DPID_MODE	22	//灯的工作模式DP
118 |
119 | //注意：array[][0]为DPID, array[][1]为DP type
120 | unsigned char dp_id_array[][2] = {
121 |     /*  DPID     |  DP type  */
122 |     {DPID_SWITCH, DP_TYPE_BOOL},
123 |     {DPID_LIGHT, DP_TYPE_VALUE},
124 |     {DPID_MODE, DP_TYPE_ENUM},
125 | };
126 | ...
127 | void setup()
128 | {
129 |     ...
130 |     my_device.set_dp_cmd_total(dp_id_array, 3);
131 |     ...
132 | }
133 | ```
134 |
135 |
136 |
137 | ### 3、配网模式设置
138 |
139 | 调用 `void TuyaWifi::mcu_set_wifi_mode(unsigned char mode)` 进入配网模式。
140 |
141 | ```c
142 | /**
143 |  * @description: MCU set wifi working mode
144 |  * @param {unsigned char} mode : enter mode
145 |  *                               0(SMART_CONFIG):enter smartconfig mode
146 |  *                               1(AP_CONFIG):enter AP mode
147 |  * @return {*}
148 |  */
149 | void TuyaWifi::mcu_set_wifi_mode(unsigned char mode);
150 | ```
151 |
152 |
153 |
154 | ### 4、下发DP数据处理
155 |
156 | 当云端下发数据后，需要对下发的数据进行解析，通过`unsigned char TuyaWifi::mcu_get_dp_download_data(unsigned char dpid, const unsigned char value[], unsigned short len)` 这个函数进行解析。该函数目前只支持`DP_TYPE_BOOL`，`DP_TYPE_VALUE`，`DP_TYPE_ENUM` 这3种类型；`DP_TYPE_BITMAP` 为故障型一般只上报处理，不会下发，对该类型不用处理；`DP_TYPE_RAW` ,`DP_TYPE_STRING` 这两种类型需要用户自己进行处理。
157 |
158 |
159 |
160 | ```c
161 | /**
162 |  * @description: mcu gets bool,value,enum type to send dp value. (raw, string type needs to be handled at the user's discretion. fault only report)
163 |  * @param {unsigned char} dpid : data point ID
164 |  * @param {const unsigned char} value : dp data buffer address
165 |  * @param {unsigned short} len : data length
166 |  * @return {unsigned char} Parsed data
167 |  */
168 | unsigned char TuyaWifi::mcu_get_dp_download_data(unsigned char dpid, const unsigned char value[], unsigned short len);
169 | ```
170 |
171 |
172 |
173 | ### 5、DP下发处理函数注册
174 |
175 | 当APP控制设备的时候，会从云端下发对应的DP命令到设备，设备对数据进行解析后，对下发的命令执行相对于的动作。
176 |
177 | 对下发命令的处理，通过回调函数来调用，所以我们需要把你的处理函数注册一下。调用这个`void TuyaWifi::dp_process_func_register(tuya_callback_dp_download _func)` 对回调函数进行注册。
178 |
179 | ```c
180 | #include <TuyaWifi.h>
181 |
182 | TuyaWifi my_device;
183 | ...
184 |
185 | void setup()
186 | {
187 |     ...
188 |   //register DP download processing callback function
189 |   my_device.dp_process_func_register(dp_process);
190 |     ...
191 | }
192 |
193 | /**
194 |  * @description: DP download callback function.
195 |  * @param {unsigned char} dpid
196 |  * @param {const unsigned char} value
197 |  * @param {unsigned short} length
198 |  * @return {unsigned char}
199 |  */
200 | unsigned char dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
201 | {
202 |   switch(dpid) {
203 |     case DPID_SWITCH:
204 |       switch_value = my_device.mcu_get_dp_download_data(dpid, value, length);
205 |       if (switch_value) {
206 |         //Turn on
207 |
208 |       } else {
209 |         //Turn off
210 |
211 |       }
212 |       //Status changes should be reported.
213 |       my_device.mcu_dp_update(dpid, value, length);
214 |     break;
215 |
216 |     default:break;
217 |   }
218 |   return SUCCESS;
219 | }
220 | ```
221 |
222 |
223 |
224 | ### 6、上报设备状态
225 |
226 | 上报设备状态也就是上报所有DP点值，也是通过注册函数的方式进行的。
227 |
228 |
229 |
230 | 接收 DataPoint 的 6 种不同DP类型的数据类型定义：
231 |
232 | DP上报函数：
233 |
234 | ```c
235 | /**
236 |  * @description: dp data upload
237 |  * @param {unsigned char} dpid
238 |  * @param {const unsigned char} value
239 |  * @param {unsigned short} len
240 |  * @return {*}
241 |  */
242 | unsigned char mcu_dp_update(unsigned char dpid, const unsigned char value[], unsigned short len);//update raw, string type
243 | unsigned char mcu_dp_update(unsigned char dpid, unsigned long value, unsigned short len);
244 | unsigned char mcu_dp_update(unsigned char dpid, unsigned int value, unsigned short len);
245 | ```
246 |
247 |
248 |
249 | 上报设备状态函数注册示例：
250 |
251 | ```c
252 | #include <TuyaWifi.h>
253 |
254 | TuyaWifi my_device;
255 |
256 | #define DPID_SWITCH 20
257 | //Record the current status of the led
258 | unsigned char switch_value = 0;
259 | ...
260 | void setup()
261 | {
262 |     ...
263 |   //register DP download processing callback function
264 |   my_device.dp_update_all_func_register(dp_update_all);
265 |     ...
266 | }
267 |
268 | /**
269 |  * @description: Upload all DP status of the current device.
270 |  * @param {*}
271 |  * @return {*}
272 |  */
273 | void dp_update_all(void)
274 | {
275 |   my_device.mcu_dp_update(DPID_SWITCH, switch_value, 1);
276 | }
277 | ```
278 |
279 |
280 |
281 | ## 技术支持
282 |
283 | 您可以通过以下方法获得涂鸦的支持:
284 |
285 | - 开发者中心：https://developer.tuya.com
286 | - 帮助中心: https://support.tuya.com/help
287 | - 技术支持工单中心: https://service.console.tuya.com


--------------------------------------------------------------------------------
/config.h:
--------------------------------------------------------------------------------
 1 | /*
 2 |  * @FileName: config.h
 3 |  * @Author: Tuya
 4 |  * @Email:
 5 |  * @LastEditors: shiliu
 6 |  * @Date: 2021-04-10 11:24:27
 7 |  * @LastEditTime: 2021-11-04 14:00:42
 8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
 9 |  * @Company: http://www.tuya.com
10 |  * @Description: Tuya mcu sdk Arduino library config file.
11 |  */
12 | #ifndef __CONFIG_H__
13 | #define __CONFIG_H__
14 |
15 | #include "TuyaDefs.h"
16 |
17 | /*  Distribution mode selection, only three choices, Anti-touch mode is recommende */
18 | #define CONFIG_MODE     CONFIG_MODE_DEFAULT     //Default working mode
19 | // #define CONFIG_MODE     CONFIG_MODE_LOWPOWER    //Safe mode (low power working mode)
20 | // #define CONFIG_MODE     CONFIG_MODE_SPECIAL     // Anti-touch mode (special working mode)
21 |
22 | /* some extra features defined begin */
23 | #define WIFI_CONTROL_SELF_MODE  0
24 | #define SUPPORT_GREEN_TIME      1
25 | #define SUPPORT_RTC_TIME        1
26 | /* some extra features defined end */
27 |
28 | #ifndef SUPPORT_MCU_FIRM_UPDATE
29 | #define WIFI_UART_RECV_BUF_LMT  32      //UART data receiving buffer size, can be reduced if the MCU has insufficient RAM
30 | #define WIFI_DATA_PROCESS_LMT   64      //UART data processing buffer size, according to the user DP data size, must be greater than 24
31 | #else
32 | #define WIFI_UART_RECV_BUF_LMT  128     //UART data receiving buffer size, can be reduced if the MCU has insufficient RAM
33 | /*  Select the appropriate UART data processing buffer size here
34 |     (select the buffer size based on the size selected by the above MCU firmware upgrade package and whether to turn on the weather service)  */
35 | #define WIFI_DATA_PROCESS_LMT   1000    //UART data processing buffer size. If the MCU firmware upgrade is required, the single-packet size is 256, the buffer must be greater than 260, or larger if the weather service is enabled
36 | // #define WIFI_DATA_PROCESS_LMT   600     //UART data processing buffer size. If the MCU firmware upgrade is required, the single-packet size is 512, the buffer must be greater than 520, or larger if the weather service is enabled
37 | // #define WIFI_DATA_PROCESS_LMT   1200    //UART data processing buffer size. If the MCU firmware upgrade is required, the single-packet size is 1024, the buffer must be greater than 1030, or larger if the weather service is enabled
38 | #endif
39 |
40 | #define WIFIR_UART_SEND_BUF_LMT 64      //According to the user's DP data size, it must be greater than 48
41 |
42 |
43 | #endif /* __CONFIG_H__ */
44 |


--------------------------------------------------------------------------------
/examples/DataPointType/DataPointType.ino:
--------------------------------------------------------------------------------
  1 | /*
  2 |  * @FileName: DataPointType.ino
  3 |  * @Author: Tuya
  4 |  * @Email:
  5 |  * @LastEditors: shiliu
  6 |  * @Date: 2021-04-19 14:31:52
  7 |  * @LastEditTime: 2021-11-01 10:02:07
  8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
  9 |  * @Company: http://www.tuya.com
 10 |  * @Description:
 11 |  * @Github:https://github.com/tuya/tuya-wifi-mcu-sdk-arduino-library
 12 |  */
 13 |
 14 | #include <TuyaWifi.h>
 15 |
 16 | // STM32
 17 | // HardwareSerial Serial2(PA_3, PA_2);
 18 |
 19 | TuyaWifi my_device;
 20 |
 21 | /* Current LED status */
 22 | unsigned char led_state = 0;
 23 | /* Connect network button pin */
 24 | int wifi_key_pin = 7;
 25 |
 26 | /* Data point define */
 27 | #define DPID_BOOL   101
 28 | #define DPID_VALUE  102
 29 | #define DPID_ENUM   103
 30 | #define DPID_STRING 104
 31 | #define DPID_RAW    105
 32 | #define DPID_FAULT  106
 33 |
 34 | /* Current device DP values */
 35 | unsigned char dp_bool_value = 0;
 36 | long dp_value_value = 0;
 37 | unsigned char dp_enum_value = 0;
 38 | unsigned char dp_string_value[8] = {"Hi,Tuya"};
 39 | unsigned char dp_raw_value[8] = {0x01, 0x23, 0x45, 0x67, 0x89, 0xab, 0xcd, 0xef};
 40 | int dp_fault_value = 0x01;
 41 |
 42 | /* Stores all DPs and their types. PS: array[][0]:dpid, array[][1]:dp type.
 43 |  *                                     dp type(TuyaDefs.h) : DP_TYPE_RAW, DP_TYPE_BOOL, DP_TYPE_VALUE, DP_TYPE_STRING, DP_TYPE_ENUM, DP_TYPE_BITMAP
 44 | */
 45 | unsigned char dp_array[][2] = {
 46 |     {DPID_BOOL, DP_TYPE_BOOL},
 47 |     {DPID_VALUE, DP_TYPE_VALUE},
 48 |     {DPID_ENUM, DP_TYPE_ENUM},
 49 |     {DPID_STRING, DP_TYPE_STRING},
 50 |     {DPID_RAW, DP_TYPE_RAW},
 51 |     {DPID_FAULT, DP_TYPE_BITMAP},
 52 | };
 53 |
 54 | unsigned char pid[] = {"yw3fhhvcbsfnl3eg"};
 55 | unsigned char mcu_ver[] = {"1.0.0"};
 56 |
 57 | /* last time */
 58 | unsigned long last_time = 0;
 59 |
 60 | void setup()
 61 | {
 62 |     Serial.begin(9600);
 63 |     Serial2.begin(9600);
 64 |
 65 |     //Initialize led port, turn off led.
 66 |     pinMode(LED_BUILTIN, OUTPUT);
 67 |     digitalWrite(LED_BUILTIN, LOW);
 68 |
 69 |     //Initialize networking keys.
 70 |     pinMode(wifi_key_pin, INPUT_PULLUP);
 71 |
 72 |     //Enter the PID and MCU software version
 73 |     my_device.init(pid, mcu_ver);
 74 |     //incoming all DPs and their types array, DP numbers
 75 |     my_device.set_dp_cmd_total(dp_array, 6);
 76 |     //register DP download processing callback function
 77 |     my_device.dp_process_func_register(dp_process);
 78 |     //register upload all DP callback function
 79 |     my_device.dp_update_all_func_register(dp_update_all);
 80 |
 81 |     last_time = millis();
 82 | }
 83 |
 84 | void loop()
 85 | {
 86 |     my_device.uart_service();
 87 |
 88 |     //Enter the connection network mode when Pin7 is pressed.
 89 |     if (digitalRead(wifi_key_pin) == LOW) {
 90 |         delay(80);
 91 |         if (digitalRead(wifi_key_pin) == LOW) {
 92 |             my_device.mcu_set_wifi_mode(SMART_CONFIG);
 93 |         }
 94 |     }
 95 |
 96 |     /* LED blinks when network is being connected */
 97 |     if ((my_device.mcu_get_wifi_work_state() != WIFI_LOW_POWER) && (my_device.mcu_get_wifi_work_state() != WIFI_CONN_CLOUD) && (my_device.mcu_get_wifi_work_state() != WIFI_SATE_UNKNOW)) {
 98 |         if (millis() - last_time >= 500) {
 99 |             last_time = millis();
100 |             /* Toggle current LED status */
101 |             if (led_state == LOW) {
102 |                 led_state = HIGH;
103 |             } else {
104 |                 led_state = LOW;
105 |             }
106 |
107 |             digitalWrite(LED_BUILTIN, led_state);
108 |         }
109 |     }
110 |
111 |     delay(10);
112 | }
113 |
114 | /**
115 |  * @description: DP download callback function.
116 |  * @param {unsigned char} dpid
117 |  * @param {const unsigned char} value
118 |  * @param {unsigned short} length
119 |  * @return {unsigned char}
120 |  */
121 | unsigned char dp_process(unsigned char dpid, const unsigned char value[], unsigned short length)
122 | {
123 |     switch (dpid) {
124 |         case DPID_BOOL:
125 |             Serial2.println("Bool type:");
126 |             dp_bool_value = my_device.mcu_get_dp_download_data(dpid, value, length);
127 |             Serial2.println(dp_bool_value);
128 |             /* After processing the download DP command, the current status should be reported. */
129 |             my_device.mcu_dp_update(DPID_BOOL, dp_bool_value, 1);
130 |         break;
131 |
132 |         case DPID_VALUE:
133 |             Serial2.println("Value type:");
134 |             dp_value_value = my_device.mcu_get_dp_download_data(DPID_VALUE, value, length);
135 |             Serial2.println(dp_value_value);
136 |             /* After processing the download DP command, the current status should be reported. */
137 |             my_device.mcu_dp_update(DPID_VALUE, dp_value_value, 1);
138 |         break;
139 |
140 |         case DPID_ENUM:
141 |             Serial2.println("Enum type:");
142 |             dp_enum_value = my_device.mcu_get_dp_download_data(dpid, value, length);
143 |             Serial2.println(dp_enum_value);
144 |             /* After processing the download DP command, the current status should be reported. */
145 |             my_device.mcu_dp_update(DPID_ENUM, dp_enum_value, 1);
146 |         break;
147 |
148 |         case DPID_STRING:
149 |             Serial2.println("String type:");
150 |             /*  */
151 |             for (unsigned int i=0; i<length; i++) {
152 |                 dp_string_value[i] = value[i];
153 |                 Serial2.write(dp_string_value[i]);
154 |             }
155 |             Serial2.println("");
156 |             /* After processing the download DP command, the current status should be reported. */
157 |             my_device.mcu_dp_update(DPID_STRING, dp_string_value, length);
158 |         break;
159 |
160 |         case DPID_RAW:
161 |             Serial2.println("Raw type:");
162 |             /*  */
163 |             for (unsigned int i=0; i<length; i++) {
164 |                 dp_raw_value[i] = value[i];
165 |                 Serial2.write(dp_raw_value[i]);
166 |             }
167 |             Serial2.println("");
168 |             /* After processing the download DP command, the current status should be reported. */
169 |             my_device.mcu_dp_update(DPID_RAW, dp_raw_value, length);
170 |         break;
171 |
172 |         default:
173 |             break;
174 |     }
175 |
176 |     return TY_SUCCESS;
177 | }
178 |
179 | /**
180 |  * @description: Upload all DP status of the current device.
181 |  * @param {*}
182 |  * @return {*}
183 |  */
184 | void dp_update_all(void)
185 | {
186 |     my_device.mcu_dp_update(DPID_BOOL, dp_bool_value, 1);
187 |     my_device.mcu_dp_update(DPID_VALUE, dp_value_value, 1);
188 |     my_device.mcu_dp_update(DPID_ENUM, dp_enum_value, 1);
189 |     my_device.mcu_dp_update(DPID_STRING, dp_string_value, (sizeof(dp_string_value) / sizeof(dp_string_value[0])));
190 |     my_device.mcu_dp_update(DPID_RAW, dp_raw_value, (sizeof(dp_raw_value) / sizeof(dp_raw_value[0])));
191 |     my_device.mcu_dp_update(DPID_FAULT, dp_fault_value, 1); /* Fault type Only report */
192 | }
193 |


--------------------------------------------------------------------------------
/examples/DataPointType/README.md:
--------------------------------------------------------------------------------
 1 | # DataPointType
 2 |
 3 | [English](./README.md) | [中文](./README_zh.md)
 4 |
 5 |   This library only supports Tuya WiFi+BLE, WiFi modules with generic firmware burned in and verified on Arduino UNO boards.
 6 |
 7 | **Note: The default Serial serial port in Arduino has been taken over by the Tuya mcu sdk, please do not do anything with the default Serial (pins 0 , 1).**
 8 |
 9 |   ## I. Introduction to the demo
10 |
11 | The connection between the Tuya module and the Arduino board will interfere with the burning of the Arduino board. The Arduino board should be disconnected from the Tuya communication board or the Tuya communication board when burning. After the routine is successfully burned, connect the serial port (Serial) on the Arduino board to the `RXD` and `TXD` on the Tuya module, then pull down the `Pin7` pin on the UNO board for about 1s (simulating a key press), the device will enter the connection network mode, the LED on the Arduino board will flash during the connection network state and connection network process After successful connection, the LED on the Arduino board will stop flashing and the device can be controlled by the APP.
12 |
13 | This demo introduces and demonstrates the 6 data types of the Tuya IoT platform.
14 |
15 |   ## II.
16 |
17 | The data types of the Tuya IoT platform are divided into 6 types, namely `Bool` , `value` , `enum` , `string` , `raw` , `fault(BITMAP)` . Each type has the option of `uploadable and downlinkable`, `upload only` and ` downlink only`, except for `fault(BITMAP)` which can only be uploaded.
18 |
19 |   ### `Bool` and `ENUM`
20 |
21 | The `Bool` and `enum` types are used in the same way as in C and are relatively simple to use. But it is worth mentioning `enum` , the enum values in the `enum` type are sorted according to the order you create them in the [Tuya IoT platform](https://iot.tuya.com/?_source=97c44038fafc20e9c8dd5fdb508cc9c2), starting from 0 and going from left to right + 1. The following diagram.
22 |
23 | ![DP_type_enum](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/DataPointType/DP_type_enum.png)
24 |
25 |   ### value
26 |
27 |   The `value` type is one of our more common types, storing 4 bytes, i.e. data in the range `0 ~ 4,294,967,295` or `-2,147,483,648 ~ 2,147,483,647`.
28 |
29 |   The `value` type requires attention to spacing and multiplicity.
30 |
31 |   Spacing: assuming the data range is 0-100, with a spacing of 1: the data values should be 0, 1, 2, 3...; with a spacing of 2: the data values should be 0, 2, 4, 6...; with a spacing of 3: the data values should be 0, 3, 6, 9...
32 |
33 | Multiplier: default is 0, the value is an integer, when a decimal is required changing the multiplier value the data will be transmitted as an exponent of 10. For example: when you enter 10000, the multiplier is configured to 0, then the value displayed is 10000; the multiplier is configured to 1, then the value displayed is 1000.0; the multiplier is configured to 2, then the value displayed is 100.00; the multiplier is configured to 3, then the value displayed is 10.000, and so on.
34 |
35 | ![DP_type_value](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/DataPointType/DP_type_value.png)
36 |
37 |   ### string
38 |
39 | The `string` type is also known as a string type, with a maximum length of 255 bytes.
40 |
41 |   ### fault
42 |
43 | `fault(BITMAP)` also known as fault type, this type is only reported, and is identified by the corresponding byte bits, in order of bit0-bitx, multiple byte bits means multiple faults can occur at the same time, up to 30 bits are supported.
44 |
45 |   ### raw
46 |
47 | The `raw` type is used when none of the above types will meet your needs. The `raw` type of data transfer is also known as transparent transfer.
48 |
49 |
50 |
51 |   ## III. Technical support
52 |
53 | You can get support for Tuya by using the following methods:
54 |
55 | - Developer Centre: https://developer.tuya.com
56 | - Help Centre: https://support.tuya.com/help
57 | - Technical Support Work Order Centre: https://service.console.tuya.com


--------------------------------------------------------------------------------
/examples/DataPointType/README_zh.md:
--------------------------------------------------------------------------------
 1 | # DataPointType
 2 |
 3 | [English](./README.md) | [中文](./README_zh.md)
 4 |
 5 | 该库仅支持烧录了通用固件的涂鸦 WiFi+BLE 、WiFi模组，在Arduino UNO板子上验证通过。
 6 |
 7 | **注意：Arduino 中的 默认Serial 串口已被Tuya mcu sdk 接管，请不要对默认Serial（引脚 0 ，1）做任何操作。**
 8 |
 9 | ## 一、demo 介绍
10 |
11 | 涂鸦模组和Arduino板连接时会干扰到对Arduino板的烧录，烧录时应断开Arduino板与涂鸦通信板或涂鸦通信板的连接。例程烧录成功后将Arduino板上串口(Serial) 与 涂鸦模组上的 `RXD` 和 `TXD` 连接起来，然后将UNO板子上的 `Pin7` 脚拉低1s左右（模拟按键按下），设备将会进入配网模式，在进入配网状态和配网过程中Arduino板上LED将会闪烁，打开涂鸦智能APP对设备（Arduino_DataPointType）进行配网操作，连接成功后Arduino板上LED将会停止闪烁，配网成功后即可通过APP对设备进行控制。
12 |
13 | 本demo对涂鸦 IoT 平台的6种数据类型进项了介绍和演示。
14 |
15 | ## 二、功能介绍
16 |
17 | 涂鸦IoT平台的数据类型主要分为6种，分别是`Bool` , `value` , `enum` , `string` , `raw` , `fault(BITMAP)` 。除 `fault(BITMAP)` 仅能上传外，其他每个类型都可选择`可上报可下发` ，`仅上报` ， `仅下发` 三种数据传输方式。
18 |
19 | ### `Bool`和`ENUM`
20 |
21 | `Bool` 和 `enum` 这两种类型和C语言中的使用方式一致，比较简单。但是值得一提的是`enum` ，`enum` 型中的枚举值是根据你在[涂鸦IoT平台](https://iot.tuya.com/?_source=97c44038fafc20e9c8dd5fdb508cc9c2)中创建的顺序进行排序的，从0开始，从左到右+1。如下图：
22 |
23 | ![DP_type_enum](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/DataPointType/DP_type_enum.png)
24 |
25 | ### value
26 |
27 | `value` 型是我们比较常用的类型之一，存储大小为4字节，即数据范围为`0 ~ 4,294,967,295` 或 `-2,147,483,648 ~ 2,147,483,647`。
28 |
29 | `value` 类型中需要注意的是间距与倍数：
30 |
31 | 间距：假设数据范围是0-100，间距为1时：数据值为0，1，2，3…；间距为2：数据值应0，2，4，6…；间距为3时：数据值为0，3，6，9…
32 |
33 | 倍数：默认为0，数值为整数，当需要小数时改变倍数值数据将以10的指数形式进行传输。如：当你输入10000时，倍数配置为0，那么显示数值为10000；倍数配置为1，那么显示数值为1000.0；倍数配置为2，那么显示数值为100.00；倍数配置为3，那么显示数值为10.000，以此类推。
34 |
35 | ![DP_type_value](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/DataPointType/DP_type_value.png)
36 |
37 | ### string
38 |
39 | `string` 类型也就是字符串类型，最大长度不超过255个字节。
40 |
41 | ### fault
42 | `fault(BITMAP)`  也就是故障型，该类型只上报，按照对应的字节位来标识的，依次为bit0-bitx，多个字节位代表多个故障可同时发生，最多支持30位。
43 | ### raw
44 | `raw` 类型是当上述几种类型都没有办法满足你的需求时，使用该类型。`raw` 型的数据传输也就是透明传输。
45 |
46 |
47 |
48 | ## 三、技术支持
49 |
50 | 您可以通过以下方法获得涂鸦的支持:
51 |
52 | - 开发者中心：https://developer.tuya.com
53 | - 帮助中心: https://support.tuya.com/cn/help
54 | - 技术支持工单中心: https://service.console.tuya.com


--------------------------------------------------------------------------------
/examples/GetGreenTime/GetGreenTime.ino:
--------------------------------------------------------------------------------
  1 | /*
  2 |  * @FileName: GetGreenTime.ino
  3 |  * @Author: Tuya
  4 |  * @Email:
  5 |  * @LastEditors: shiliu
  6 |  * @Date: 2021-11-04 14:44:25
  7 |  * @LastEditTime: 2021-11-04 14:50:21
  8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
  9 |  * @Company: http://www.tuya.com
 10 |  * @Description: get Greenwich Mean Time
 11 |  * @Github:https://github.com/tuya/tuya-wifi-mcu-sdk-arduino-library
 12 |  */
 13 | #include <TuyaWifi.h>
 14 |
 15 | // STM32
 16 | // HardwareSerial Serial2(PA_3, PA_2);
 17 |
 18 | TuyaWifi my_device;
 19 |
 20 | /* Current LED status */
 21 | unsigned char led_state = 0;
 22 | /* Connect network button pin */
 23 | int key_pin = 7;
 24 |
 25 | /* Data point define */
 26 | #define DPID_SWITCH 20
 27 |
 28 | TUYA_WIFI_TIME green_time;
 29 | unsigned long last_get_green_time;
 30 |
 31 | /* Stores all DPs and their types. PS: array[][0]:dpid, array[][1]:dp type.
 32 |  *                                     dp type(TuyaDefs.h) : DP_TYPE_RAW, DP_TYPE_BOOL, DP_TYPE_VALUE, DP_TYPE_STRING, DP_TYPE_ENUM, DP_TYPE_BITMAP
 33 | */
 34 | unsigned char dp_array[][2] =
 35 | {
 36 |   {DPID_SWITCH, DP_TYPE_BOOL},
 37 | };
 38 |
 39 | unsigned char pid[] = {"ma67l9sgmdyg3d2k"};
 40 | unsigned char mcu_ver[] = {"1.0.0"};
 41 |
 42 | /* last time */
 43 | unsigned long last_time = 0;
 44 |
 45 | void setup()
 46 | {
 47 |   Serial.begin(9600);
 48 |   Serial2.begin(9600);
 49 |
 50 |   //Initialize led port, turn off led.
 51 |   pinMode(LED_BUILTIN, OUTPUT);
 52 |   digitalWrite(LED_BUILTIN, LOW);
 53 |
 54 |   //Initialize networking keys.
 55 |   pinMode(key_pin, INPUT_PULLUP);
 56 |
 57 |   //Enter the PID and MCU software version
 58 |   my_device.init(pid, mcu_ver);
 59 |   //incoming all DPs and their types array, DP numbers
 60 |   my_device.set_dp_cmd_total(dp_array, 1);
 61 |   //register DP download processing callback function
 62 |   my_device.dp_process_func_register(dp_process);
 63 |   //register upload all DP callback function
 64 |   my_device.dp_update_all_func_register(dp_update_all);
 65 |
 66 |   last_time = millis();
 67 | }
 68 |
 69 | void loop()
 70 | {
 71 |   my_device.uart_service();
 72 |
 73 |   //Enter the connection network mode when Pin7 is pressed.
 74 |   if (digitalRead(key_pin) == LOW) {
 75 |     delay(80);
 76 |     if (digitalRead(key_pin) == LOW) {
 77 |       my_device.mcu_set_wifi_mode(SMART_CONFIG);
 78 |     }
 79 |   }
 80 |   /* LED blinks when network is being connected */
 81 |   if ((my_device.mcu_get_wifi_work_state() != WIFI_LOW_POWER) && (my_device.mcu_get_wifi_work_state() != WIFI_CONN_CLOUD) && (my_device.mcu_get_wifi_work_state() != WIFI_SATE_UNKNOW)) {
 82 |     if (millis()- last_time >= 500) {
 83 |       last_time = millis();
 84 |
 85 |       if (led_state == LOW) {
 86 |         led_state = HIGH;
 87 |       } else {
 88 |         led_state = LOW;
 89 |       }
 90 |       digitalWrite(LED_BUILTIN, led_state);
 91 |     }
 92 |   }
 93 |
 94 |   /* 5s get Greenwich Mean Time */
 95 |   if (millis() - last_get_green_time >= 3000) {
 96 |     last_get_green_time = millis();
 97 |     if (TY_SUCCESS == my_device.get_green_time(&green_time, 100)) { /* if network lag, you can increase the timeout */
 98 |       Serial2.print(green_time.year);
 99 |       Serial2.print("-");
100 |       Serial2.print(green_time.month);
101 |       Serial2.print("-");
102 |       Serial2.println(green_time.day);
103 |
104 |       Serial2.print(green_time.hour);
105 |       Serial2.print(":");
106 |       Serial2.print(green_time.minute);
107 |       Serial2.print(":");
108 |       Serial2.println(green_time.second);
109 |     } else {
110 |       Serial2.println("get green time failed");
111 |     }
112 |   }
113 |
114 |   delay(10);
115 | }
116 |
117 | /**
118 |  * @description: DP download callback function.
119 |  * @param {unsigned char} dpid
120 |  * @param {const unsigned char} value
121 |  * @param {unsigned short} length
122 |  * @return {unsigned char}
123 |  */
124 | unsigned char dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
125 | {
126 |   switch(dpid) {
127 |     case DPID_SWITCH:
128 |       led_state = my_device.mcu_get_dp_download_data(dpid, value, length); /* Get the value of the down DP command */
129 |       if (led_state) {
130 |         //Turn on
131 |         digitalWrite(LED_BUILTIN, HIGH);
132 |       } else {
133 |         //Turn off
134 |         digitalWrite(LED_BUILTIN, LOW);
135 |       }
136 |       //Status changes should be reported.
137 |       my_device.mcu_dp_update(dpid, value, length);
138 |     break;
139 |
140 |     default:break;
141 |   }
142 |   return TY_SUCCESS;
143 | }
144 |
145 | /**
146 |  * @description: Upload all DP status of the current device.
147 |  * @param {*}
148 |  * @return {*}
149 |  */
150 | void dp_update_all(void)
151 | {
152 |   my_device.mcu_dp_update(DPID_SWITCH, led_state, 1);
153 | }
154 |
155 |


--------------------------------------------------------------------------------
/examples/GetGreenTime/README.md:
--------------------------------------------------------------------------------
 1 | # get green time
 2 | [English](./README.md) | [中文](./README_zh.md)
 3 |
 4 | This library only supports the Tuya WiFi+BLE, WiFi module with the generic firmware burned in and verified on the Arduino UNO board.
 5 |
 6 | **Note: The default Serial serial port in Arduino has been taken over by the Tuya mcu sdk, please do not do anything with the default Serial (pins 0 , 1).**
 7 |
 8 |
 9 |
10 | ## I. Introduction to the demo
11 |
12 | The connection between the Tuya module and the Arduino board will interfere with the burning of the Arduino board. The Arduino board should be disconnected from the Tuya communication board or the Tuya communication board when burning.
13 |
14 | This example uses Arduino board + Tuya wifi communication board. This demo is mainly used to show how to get the network time, using Arduino pin 8 of as RX and pin 9 as TX to print the time information.
15 |
16 | The function of getting time can only be used after the module is successfully networked.
17 |
18 |
19 | ### 1. Get Green time
20 |
21 | **Function**
22 | ```c
23 | char TuyaWifi::get_green_time(TUYA_WIFI_TIME *time, const unsigned int timeout);
24 | ```
25 | **Parameters:**
26 |  + <font color="#dd0000">`time`: </font> Store the data of the time from the module.
27 |     ```c
28 |     typedef struct
29 |     {
30 |         unsigned short year;
31 |         unsigned char month;
32 |         unsigned char day;
33 |         unsigned char hour;
34 |         unsigned char minute;
35 |         unsigned char second;
36 |         unsigned char weekday;
37 |
38 |         char update_flag;
39 |     }TUYA_WIFI_TIME;
40 |     ```
41 |  + <font color="#dd0000">`timeout`: </font> Timeout time, unit ms. The timeout time can be extended if the network condition is bad.
42 |
43 | **Return:**
44 | + <font color="#dd0000">`1`: </font> Get success.
45 | + <font color="#dd0000">`-1`: </font> The input parameter is `NULL`, the input parameter is wrong.
46 | + <font color="#dd0000">`-2`: </font> Timeout.
47 |
48 | </br>
49 |
50 | ### 1. Get RTC time
51 |
52 | **Function**
53 | ```c
54 | char TuyaWifi::get_rtc_time(TUYA_WIFI_TIME *time, const unsigned int timeout);
55 | ```
56 | **Parameters:**
57 |  + <font color="#dd0000">`time`: </font> Store the data of the time from the module.
58 |     ```c
59 |     typedef struct
60 |     {
61 |         unsigned short year;
62 |         unsigned char month;
63 |         unsigned char day;
64 |         unsigned char hour;
65 |         unsigned char minute;
66 |         unsigned char second;
67 |         unsigned char weekday;
68 |
69 |         char update_flag;
70 |     }TUYA_WIFI_TIME;
71 |     ```
72 |  + <font color="#dd0000">`timeout`: </font> Timeout time, unit ms. The timeout time can be extended if the network condition is bad.
73 |
74 | **Return:**
75 | + <font color="#dd0000">`1`: </font> Get success.
76 | + <font color="#dd0000">`-1`: </font> The input parameter is `NULL`, the input parameter is wrong.
77 | + <font color="#dd0000">`-2`: </font> Timeout.
78 |
79 | </br>
80 |
81 |
82 | ## III. Technical Support
83 |
84 | You can get support for Tuya by using the following methods:
85 |
86 | - Developer Centre: https://developer.tuya.com
87 | - Help Centre: https://support.tuya.com/help
88 | - Technical Support Work Order Centre: https://service.console.tuya.com


--------------------------------------------------------------------------------
/examples/GetGreenTime/README_zh.md:
--------------------------------------------------------------------------------
 1 | # get green time
 2 | [English](./README.md) | [中文](./README_zh.md)
 3 |
 4 | 该库仅支持烧录了通用固件的涂鸦 WiFi+BLE 、WiFi模组，在Arduino UNO板子上验证通过。
 5 | </br>
 6 | **注意：Arduino 中的 默认Serial 串口已被Tuya mcu sdk 接管，请不要对默认Serial（引脚 0 ，1）做任何操作。**
 7 | </br>
 8 |
 9 | ## 一、demo 介绍
10 |
11 | 涂鸦模组和Arduino板连接时会干扰到对Arduino板的烧录，烧录时应断开Arduino板与涂鸦通信板或涂鸦通信板的连接。例程烧录成功后将Arduino板上串口(Serial) 与 涂鸦模组上的 `RXD` 和 `TXD` 连接起来，然后将UNO板子上的 `Pin7` 脚拉低1s左右（模拟按键按下），设备将会进入配网模式，在进入配网状态和配网过程中Arduino板上LED将会闪烁，打开涂鸦智能APP对设备（Arduino_led）进行配网操作，连接成功后Arduino板上LED将会停止闪烁，配网成功后即可通过APP对设备进行控制。
12 |
13 | 本例程硬件使用了Arduino板+涂鸦wifi通信板，在 start demo 的基础上进行了修改。本 demo 主要用于演示如何获取网络时间，将 Arduino 的 pin 8 作为 RX, pin 9 作为 TX，打印时间信息。
14 |
15 | 获取时间的功能需要在模组成功联网后才可使用。
16 |
17 | ### 1. 获取格林时间
18 |
19 | **函数原型**
20 | ```c
21 | char TuyaWifi::get_green_time(TUYA_WIFI_TIME *time, const unsigned int timeout);
22 | ```
23 | **Parameters:**
24 |  + <font color="#dd0000">`time`: </font> 存储从模组上获取的时间的数据。
25 |     ```c
26 |     typedef struct
27 |     {
28 |         unsigned short year;
29 |         unsigned char month;
30 |         unsigned char day;
31 |         unsigned char hour;
32 |         unsigned char minute;
33 |         unsigned char second;
34 |         unsigned char weekday;
35 |
36 |         char update_flag;
37 |     }TUYA_WIFI_TIME;
38 |     ```
39 |  + <font color="#dd0000">`timeout`: </font> 超时时间，单位 ms。如果网络状况不好可将超时时间适当延长。
40 |
41 | **Return:**
42 | + <font color="#dd0000">`1`: </font> 获取成功。
43 | + <font color="#dd0000">`-1`: </font> 入参为 `NULL`，入参错误。
44 | + <font color="#dd0000">`-2`: </font> 获取时间超时。
45 |
46 | </br>
47 |
48 | ### 2.获取模组RTC时间
49 | 函数原型：
50 | ```c
51 | char TuyaWifi::get_rtc_time(TUYA_WIFI_TIME *time, const unsigned int timeout);
52 | ```
53 | **Parameters:**
54 |  + <font color="#dd0000">`time`: </font> 存储从模组上获取的时间的数据。
55 |     ```c
56 |     typedef struct
57 |     {
58 |         unsigned short year;
59 |         unsigned char month;
60 |         unsigned char day;
61 |         unsigned char hour;
62 |         unsigned char minute;
63 |         unsigned char second;
64 |         unsigned char weekday;
65 |
66 |         char update_flag;
67 |     }TUYA_WIFI_TIME;
68 |     ```
69 |  + <font color="#dd0000">`timeout`: </font> 超时时间，单位 ms。如果网络状况不好可将超时时间适当延长。
70 |
71 | **Return:**
72 | + <font color="#dd0000">`1`: </font> 获取成功。
73 | + <font color="#dd0000">`-1`: </font> 入参为 `NULL`，入参错误。
74 | + <font color="#dd0000">`-2`: </font> 获取时间超时。
75 |
76 | </br>
77 |
78 | ## 二、技术支持
79 |
80 | 您可以通过以下方法获得涂鸦的支持:
81 |
82 | - 开发者中心：https://developer.tuya.com
83 | - 帮助中心: https://support.tuya.com/help
84 | - 技术支持工单中心: https://service.console.tuya.com
85 |


--------------------------------------------------------------------------------
/examples/ModuleControlSelf/ModuleControlSelf.ino:
--------------------------------------------------------------------------------
 1 | /*
 2 |  * @FileName: start.ino
 3 |  * @Author: Tuya
 4 |  * @Email:
 5 |  * @LastEditors: shiliu
 6 |  * @Date: 2021-11-04 11:06:13
 7 |  * @LastEditTime: 2021-11-04 14:29:10
 8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
 9 |  * @Company: http://www.tuya.com
10 |  * @Description: Note: Please read the readme!!!
11 |  *               Note: Please read the readme!!!
12 |  *               Note: Please read the readme!!!
13 |  * @Github:https://github.com/tuya/tuya-wifi-mcu-sdk-arduino-library
14 |  */
15 |
16 | #include <TuyaWifi.h>
17 |
18 | TuyaWifi my_device;
19 |
20 | /* Data point define */
21 | #define DPID_SWITCH 20
22 |
23 | /* Stores all DPs and their types. PS: array[][0]:dpid, array[][1]:dp type.
24 |  *                                     dp type(TuyaDefs.h) : DP_TYPE_RAW, DP_TYPE_BOOL, DP_TYPE_VALUE, DP_TYPE_STRING, DP_TYPE_ENUM, DP_TYPE_BITMAP
25 | */
26 | unsigned char dp_array[][2] =
27 | {
28 |   {DPID_SWITCH, DP_TYPE_BOOL},
29 | };
30 |
31 | unsigned char pid[] = {"ma67l9sgmdyg3d2k"};
32 | unsigned char mcu_ver[] = {"1.0.0"};
33 |
34 | void setup()
35 | {
36 |   // Serial.begin(9600);
37 |   Serial.begin(9600);
38 |
39 |   //Enter the PID and MCU software version
40 |   my_device.init(pid, mcu_ver);
41 |   //incoming all DPs and their types array, DP numbers
42 |   my_device.set_dp_cmd_total(dp_array, 1);
43 |   //register DP download processing callback function
44 |   my_device.dp_process_func_register(dp_process);
45 |   //register upload all DP callback function
46 |   my_device.dp_update_all_func_register(dp_update_all);
47 |
48 |   /* set tuya module pin 16 as led, set tuya module pin 28 as connect wifi key.
49 |    * Long press 5s to enter networking mode.
50 |   */
51 |   my_device.set_state_pin(16, 28);
52 | }
53 |
54 | void loop()
55 | {
56 |   my_device.uart_service();
57 |
58 |   delay(10);
59 | }
60 |
61 | /**
62 |  * @description: DP download callback function.
63 |  * @param {unsigned char} dpid
64 |  * @param {const unsigned char} value
65 |  * @param {unsigned short} length
66 |  * @return {unsigned char}
67 |  */
68 | unsigned char dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
69 | {
70 |   switch(dpid) {
71 |     case DPID_SWITCH:
72 |       led_state = my_device.mcu_get_dp_download_data(dpid, value, length); /* Get the value of the down DP command */
73 |       if (led_state) {
74 |         //Turn on
75 |         digitalWrite(LED_BUILTIN, HIGH);
76 |       } else {
77 |         //Turn off
78 |         digitalWrite(LED_BUILTIN, LOW);
79 |       }
80 |       //Status changes should be reported.
81 |       my_device.mcu_dp_update(dpid, value, length);
82 |     break;
83 |
84 |     default:break;
85 |   }
86 |   return TY_SUCCESS;
87 | }
88 |
89 | /**
90 |  * @description: Upload all DP status of the current device.
91 |  * @param {*}
92 |  * @return {*}
93 |  */
94 | void dp_update_all(void)
95 | {
96 |   my_device.mcu_dp_update(DPID_SWITCH, led_state, 1);
97 | }
98 |


--------------------------------------------------------------------------------
/examples/ModuleControlSelf/README.md:
--------------------------------------------------------------------------------
 1 | # Module control self
 2 | [English](./README.md) | [中文](./README_zh.md)
 3 |
 4 | This library only supports the Tuya WiFi+BLE, WiFi module with the generic firmware burned in and verified on the Arduino UNO board.
 5 |
 6 | **Note: The default Serial serial port in Arduino has been taken over by the Tuya mcu sdk, please do not do anything with the default Serial (pins 0 , 1).**
 7 |
 8 |
 9 |
10 | ## I. Introduction to the demo
11 |
12 | The connection between the Tuya module and the Arduino board will interfere with the burning of the Arduino board. The Arduino board should be disconnected from the Tuya communication board or the Tuya communication board when burning.
13 |
14 | This example uses Arduino board + Tuya wifi communication board and is modified from the start demo. This demo is mainly used to show how to use the module self-processing function.
15 | </br>
16 |
17 | ### 1. How to open the module self-processing function?
18 | In `.. /.. /config.h`, change `#define WIFI_CONTROL_SELF_MODE 0` to
19 |
20 | ```c
21 | #define WIFI_CONTROL_SELF_MODE 1
22 | ```
23 | It turns on the module self-processing function.
24 | **This function is turned off by default. After turning it on, other demos will have compilation errors except this demo. Because some functions can not be used under module self-processing, such as getting the current network connection status, mcu sending re-entering network mode and other functions can not be used.**
25 | </br>
26 |
27 | ### 2. What does the module self-processing function do?
28 | The main function of the module self-processing function is to leave the function of the wiring indicator and wiring button to the module, so the pin pin on the module is used. Developers do not need to implement the function of the wiring button and wiring indicator on the MCU. Press and hold the wiring button for 5s to start the module into the wiring state.
29 | </br>
30 |
31 | ### 3. How to use the module self-processing function?
32 | First, you need to enable the module self-processing function. Then you need to call the function in `setup()` to configure the pins of the module as the led pin and button pin.
33 | If you do not call the function, the default parameters will be used. The default `pin 16` is the pin for the wiring indicator and `pin 28` is the pin for the wiring button.
34 |
35 | ```c
36 | void set_state_pin(unsigned char led_pin, unsigned char key_pin);
37 | ```
38 | </br>
39 |
40 | ## III. Technical Support
41 |
42 | You can get support for Tuya by using the following methods:
43 |
44 | - Developer Centre: https://developer.tuya.com
45 | - Help Centre: https://support.tuya.com/help
46 | - Technical Support Work Order Centre: https://service.console.tuya.com


--------------------------------------------------------------------------------
/examples/ModuleControlSelf/README_zh.md:
--------------------------------------------------------------------------------
 1 | # Module control self
 2 | [English](./README.md) | [中文](./README_zh.md)
 3 |
 4 | 该库仅支持烧录了通用固件的涂鸦 WiFi+BLE 、WiFi模组，在Arduino UNO板子上验证通过。
 5 | </br>
 6 | **注意：Arduino 中的 默认Serial 串口已被Tuya mcu sdk 接管，请不要对默认Serial（引脚 0 ，1）做任何操作。**
 7 | </br>
 8 | ## 一、demo 介绍
 9 |
10 | 涂鸦模组和Arduino板连接时会干扰到对Arduino板的烧录，烧录时应断开Arduino板与涂鸦通信板或涂鸦通信板的连接。
11 |
12 | 本例程硬件使用了Arduino板+涂鸦wifi通信板，在 start demo 的基础上进行了修改。本 demo 主要用于演示模组自处理功能如何使用。
13 | ### 1.如何开启模组自处理功能
14 | 在 `../../config.h` 中将 `#define WIFI_CONTROL_SELF_MODE  0` 更改为：
15 | ```c
16 | #define WIFI_CONTROL_SELF_MODE  1
17 | ```
18 | 就开启了模组自处理功能。
19 | **该功能默认关闭，打开后除本 demo 外，其他 demo 会出现编译错误的情况。因为在模组自处理下部分功能无法使用，如获取当前网络连接状态，mcu 发送重新进入配网模式等功能无法使用。**
20 | </br>
21 |
22 | ### 2.模组自处理功能有什么作用
23 | 模组自处理功能，主要作用是将配网指示灯和配网按键的功能交给了模组去处理，所以使用的也就是模组上的 pin 脚。开发者不用在 MCU 上实现配网按键和配网指示灯的功能了。长按配网按键 5s 开始进入模组进入配网状态。
24 | </br>
25 |
26 | ### 3.如何使用模组自处理功能
27 | 首先要开启模组自处理功能。然后需要在 `setup()` 内调用下面的函数配置对应模组的引脚作为配网指示灯和配网按键的引脚。
28 | 不调用函数修改，将会使用默认参数进行设置。默认 `pin 16` 为配网指示灯的引脚， `pin 28` 为配网按键的引脚。
29 | ```c
30 | void set_state_pin(unsigned char led_pin, unsigned char key_pin);
31 | ```
32 | </br>
33 |
34 | ## 二、技术支持
35 |
36 | 您可以通过以下方法获得涂鸦的支持:
37 |
38 | - 开发者中心：https://developer.tuya.com
39 | - 帮助中心: https://support.tuya.com/help
40 | - 技术支持工单中心: https://service.console.tuya.com


--------------------------------------------------------------------------------
/examples/SHT30/README.md:
--------------------------------------------------------------------------------
  1 | # SHT30
  2 |
  3 | [English](./README.md) | [中文](./README_zh.md)
  4 |
  5 | This library only supports the Tuya WiFi+BLE, WiFi module with the generic firmware burned in and verified on the Arduino UNO board.
  6 |
  7 | **Note: The default Serial serial port in Arduino has been taken over by the Tuya mcu sdk, please do not do anything with the default Serial (pins 0 , 1).**
  8 |
  9 | ## I. Introduction to the demo
 10 |
 11 | The connection between the Tuya module and the Arduino board will interfere with the burning of the Arduino board. The Arduino board should be disconnected from the Tuya communication board or the Tuya communication board when burning. After the routine is successfully burned, connect the serial port (Serial) on the Arduino board to the `RXD` and `TXD` on the Tuya module, then pull down the `Pin7` pin on the UNO board for about 1s (simulating a key press), the device will enter the connection network mode, the LED on the Arduino board will flash during the connection network state and connection network process After successful connection, the LED on the Arduino board will stop flashing and the device can be controlled by the APP.
 12 |
 13 | This example uses an Arduino board, a Tuya wifi communication board and a SHT30 temperature and humidity sensor. The device uploads the temperature and humidity values of the current environment every 1 second, which can be viewed through the Tuya Smart App.
 14 |
 15 | ## II. Functional realisation
 16 |
 17 | In the [Tuya IoT platform](https://iot.tuya.com/?_source=97c44038fafc20e9c8dd5fdb508cc9c2) after creating the product, the implementation of the code part can be mainly divided into three major parts: network distribution, device information initialization, and obtaining SHT30 sensing information.
 18 |
 19 | The distribution network section.
 20 |
 21 | ```c
 22 | /* Current LED status */
 23 | unsigned char led_state = 0;
 24 | /* Connect network button pin */
 25 | int wifi_key_pin = 7;
 26 | /* last time */
 27 | unsigned long last_time = 0;
 28 |
 29 | void setup()
 30 | {
 31 |     ...
 32 |    /* Related peripheral initialization */
 33 |   //Initialize led port, turn off led.
 34 |   pinMode(LED_BUILTIN, OUTPUT);
 35 |   digitalWrite(LED_BUILTIN, LOW);
 36 |   //Initialize networking keys.
 37 |   pinMode(wifi_key_pin, INPUT_PULLUP);
 38 |     ...
 39 |   last_time = millis();
 40 | }
 41 |
 42 | void loop()
 43 | {
 44 |     ...
 45 |   //Enter the connection network mode when Pin7 is pressed.
 46 |   if (digitalRead(wifi_key_pin) == LOW) {
 47 |     delay(80);
 48 |     if (digitalRead(wifi_key_pin) == LOW) {
 49 |       my_device.mcu_set_wifi_mode(SMART_CONFIG);
 50 |     }
 51 |   }
 52 |   /* LED blinks when network is being connected */
 53 |   if ((my_device.mcu_get_wifi_work_state() != WIFI_LOW_POWER) && (my_device.mcu_get_wifi_work_state() != WIFI_CONN_CLOUD) && (my_device.mcu_get_wifi_work_state() != WIFI_SATE_UNKNOW)) {
 54 |     if (millis()- last_time >= 500) {
 55 |       last_time = millis();
 56 |
 57 |       if (led_state == LOW) {
 58 |         led_state = HIGH;
 59 |       } else {
 60 |         led_state = LOW;
 61 |       }
 62 |
 63 |       digitalWrite(LED_BUILTIN, led_state);
 64 |     }
 65 |       ...
 66 | }
 67 | ```
 68 |
 69 |
 70 |
 71 | Device information initialization.
 72 |
 73 | ```c
 74 | #include <TuyaWifi.h>
 75 |
 76 | TuyaWifi my_device;
 77 |
 78 | /* Data point define */
 79 | #define DPID_TEMP_CURRENT     1
 80 | #define DPID_HUMIDITY_CURRENT 2
 81 |
 82 | /* Current device DP values */
 83 | int temperature = 0;
 84 | int humidity = 0;
 85 |
 86 | /* Stores all DPs and their types. PS: array[][0]:dpid, array[][1]:dp type.
 87 |  *                                     dp type(TuyaDefs.h) : DP_TYPE_RAW, DP_TYPE_BOOL, DP_TYPE_VALUE, DP_TYPE_STRING, DP_TYPE_ENUM, DP_TYPE_BITMAP
 88 | */
 89 | unsigned char dp_array[][2] =
 90 | {
 91 |   {DPID_TEMP_CURRENT, DP_TYPE_VALUE},
 92 |   {DPID_HUMIDITY_CURRENT, DP_TYPE_VALUE},
 93 | };
 94 |
 95 | unsigned char pid[] = {"xxxxxxxxxxxxxxxx"};//xxxxxxxxxxxxxxxx is your PID
 96 | unsigned char mcu_ver[] = {"1.0.0"};
 97 |
 98 | void setup()
 99 | {
100 |   Serial.begin(9600);
101 |     ...
102 |   my_device.init(pid, mcu_ver);
103 |   //incoming all DPs and their types array, DP numbers
104 |   my_device.set_dp_cmd_total(dp_array, 2);
105 |   //register DP download processing callback function
106 |   my_device.dp_process_func_register(dp_process);
107 |   //register upload all DP callback function
108 |   my_device.dp_update_all_func_register(dp_update_all);
109 |     ...
110 | }
111 |
112 | void loop()
113 | {
114 |   my_device.uart_service();
115 |     ...
116 |   delay(1000);
117 | }
118 |
119 | /**
120 |  * @description: DP download callback function.
121 |  * @param {unsigned char} dpid
122 |  * @param {const unsigned char} value
123 |  * @param {unsigned short} length
124 |  * @return {unsigned char}
125 |  */
126 | unsigned char dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
127 | {
128 |   /* all DP only report */
129 |   return SUCCESS;
130 | }
131 |
132 | /**
133 |  * @description: Upload all DP status of the current device.
134 |  * @param {*}
135 |  * @return {*}
136 |  */
137 | void dp_update_all(void)
138 | {
139 |   my_device.mcu_dp_update(DPID_TEMP_CURRENT, temperature, 1);
140 |   my_device.mcu_dp_update(DPID_HUMIDITY_CURRENT, humidity, 1);
141 | }
142 | ```
143 |
144 |
145 |
146 |  Get SHT30 sensor data.
147 |
148 | ```c
149 | #include <Wire.h>
150 |
151 | /* SHT30 */
152 | #define SHT30_I2C_ADDR 0x44
153 |
154 | /* Current device DP values */
155 | int temperature = 0;
156 | int humidity = 0;
157 |
158 | void setup()
159 | {
160 |     ...
161 |   // Initialise I2C communication as MASTER
162 |   Wire.begin();
163 |     ...
164 | }
165 |
166 | void loop()
167 | {
168 |     ...
169 |   /* get the temperature and humidity */
170 |   get_sht30_value(&temperature, &humidity);
171 |
172 |   if ((my_device.mcu_get_wifi_work_state() == WIFI_CONNECTED) || (my_device.mcu_get_wifi_work_state() == WIFI_CONN_CLOUD)) {
173 |     my_device.mcu_dp_update(DPID_TEMP_CURRENT, temperature, 1);
174 |     my_device.mcu_dp_update(DPID_HUMIDITY_CURRENT, humidity, 1);
175 |   }
176 |
177 |   delay(1000);
178 | }
179 |
180 | void get_sht30_value(int *temp_value, int *humi_value)
181 | {
182 |   unsigned char i2c_data[6];
183 |
184 |   // Start I2C Transmission
185 |   Wire.beginTransmission(SHT30_I2C_ADDR);
186 |   // Send measurement command
187 |   Wire.write(0x2C);
188 |   Wire.write(0x06);
189 |   // Stop I2C transmission
190 |   Wire.endTransmission();
191 |   delay(500);
192 |
193 |   // Request 6 bytes of data
194 |   Wire.requestFrom(SHT30_I2C_ADDR, 6);
195 |
196 |   // Read 6 bytes of i2c_data
197 |   // temperature msb, temperature lsb, temperature crc, humidity msb, humidity lsb, humidity crc
198 |   if (Wire.available() == 6) {
199 |     for (int i = 0; i < 6 ; i++) {
200 |       i2c_data[i] = Wire.read();
201 |     }
202 |
203 |     if ((sht30_crc(i2c_data, 2) == i2c_data[2]) && (sht30_crc(i2c_data+3, 2) == i2c_data[5])) {/* crc success */
204 |       *temp_value = (((((i2c_data[0] * 256.0) + i2c_data[1]) * 175) / 65535.0) - 45) * 100;
205 |       *humi_value = ((((i2c_data[3] * 256.0) + i2c_data[4]) * 100) / 65535.0) * 100;
206 |     } else {
207 |       *temp_value = 0;
208 |       *humi_value = 0;
209 |     }
210 |   }
211 | }
212 |
213 | /**
214 |  * @description: check sht30 temperature and humidity data
215 |  * @param {unsigned char} *data
216 |  * @param {unsigned int} count
217 |  * @return {*}
218 |  */
219 | unsigned char sht30_crc(unsigned char *data, unsigned int count)
220 | {
221 |     unsigned char crc = 0xff;
222 |     unsigned char current_byte;
223 |     unsigned char crc_bit;
224 |
225 |     /* calculates 8-Bit checksum with given polynomial */
226 |     for (current_byte = 0; current_byte < count; ++current_byte)
227 |     {
228 |         crc ^= (data[current_byte]);
229 |         for (crc_bit = 8; crc_bit > 0; --crc_bit)
230 |         {
231 |             if (crc & 0x80)
232 |                 crc = (crc << 1) ^ 0x31;
233 |             else
234 |                 crc = (crc << 1);
235 |         }
236 |     }
237 |     return crc;
238 | }
239 | ```
240 |
241 |
242 |
243 | ## III. Technical support
244 |
245 | You can get support for Tuya by using the following methods:
246 |
247 | - Developer Centre: https://developer.tuya.com
248 | - Help Centre: https://support.tuya.com/help
249 | - Technical Support Work Order Centre: https://service.console.tuya.com


--------------------------------------------------------------------------------
/examples/SHT30/README_zh.md:
--------------------------------------------------------------------------------
  1 | # SHT30
  2 |
  3 | [English](./README.md) | [中文](./README_zh.md)
  4 |
  5 | 该库仅支持烧录了通用固件的涂鸦 WiFi+BLE 、WiFi模组，在Arduino UNO板子上验证通过。
  6 |
  7 | **注意：Arduino 中的 默认Serial 串口已被Tuya mcu sdk 接管，请不要对默认Serial（引脚 0 ，1）做任何操作。**
  8 |
  9 | ## 一、demo 介绍
 10 |
 11 | 涂鸦模组和Arduino板连接时会干扰到对Arduino板的烧录，烧录时应断开Arduino板与涂鸦通信板或涂鸦通信板的连接。例程烧录成功后将Arduino板上串口(Serial) 与 涂鸦模组上的 `RXD` 和 `TXD` 连接起来，然后将UNO板子上的 `Pin7` 脚拉低1s左右（模拟按键按下），设备将会进入配网模式，在进入配网状态和配网过程中Arduino板上LED将会闪烁，打开涂鸦智能APP对设备（Arduino_SHT30）进行配网操作，连接成功后Arduino板上LED将会停止闪烁，配网成功后即可通过APP对设备进行控制。
 12 |
 13 | 本例程硬件使用了Arduino板+涂鸦wifi通信板+SHT30温湿度传感器，设备每隔1秒上传一次当前环境下温湿度值，可通过涂鸦智能APP配网后查看。
 14 |
 15 | ## 二、功能实现
 16 |
 17 | 在[涂鸦IoT平台](https://iot.tuya.com/?_source=97c44038fafc20e9c8dd5fdb508cc9c2) 创建完产品后，代码部分的实现主要可以分为配网、设备信息初始化、获取SHT30传感信息三大部分。
 18 |
 19 | 配网部分：
 20 |
 21 | ```c
 22 | /* Current LED status */
 23 | unsigned char led_state = 0;
 24 | /* Connect network button pin */
 25 | int wifi_key_pin = 7;
 26 | /* last time */
 27 | unsigned long last_time = 0;
 28 |
 29 | void setup()
 30 | {
 31 |     ...
 32 |    /* 相关外设初始化 */
 33 |   //Initialize led port, turn off led.
 34 |   pinMode(LED_BUILTIN, OUTPUT);
 35 |   digitalWrite(LED_BUILTIN, LOW);
 36 |   //Initialize networking keys.
 37 |   pinMode(wifi_key_pin, INPUT_PULLUP);
 38 |     ...
 39 |   last_time = millis();
 40 | }
 41 |
 42 | void loop()
 43 | {
 44 |     ...
 45 |   //Enter the connection network mode when Pin7 is pressed.
 46 |   if (digitalRead(wifi_key_pin) == LOW) {
 47 |     delay(80);
 48 |     if (digitalRead(wifi_key_pin) == LOW) {
 49 |       my_device.mcu_set_wifi_mode(SMART_CONFIG);
 50 |     }
 51 |   }
 52 |   /* LED blinks when network is being connected */
 53 |   if ((my_device.mcu_get_wifi_work_state() != WIFI_LOW_POWER) && (my_device.mcu_get_wifi_work_state() != WIFI_CONN_CLOUD) && (my_device.mcu_get_wifi_work_state() != WIFI_SATE_UNKNOW)) {
 54 |     if (millis()- last_time >= 500) {
 55 |       last_time = millis();
 56 |
 57 |       if (led_state == LOW) {
 58 |         led_state = HIGH;
 59 |       } else {
 60 |         led_state = LOW;
 61 |       }
 62 |
 63 |       digitalWrite(LED_BUILTIN, led_state);
 64 |     }
 65 |       ...
 66 | }
 67 | ```
 68 |
 69 |
 70 |
 71 | 设备信息初始化：
 72 |
 73 | ```c
 74 | #include <TuyaWifi.h>
 75 |
 76 | TuyaWifi my_device;
 77 |
 78 | /* Data point define */
 79 | #define DPID_TEMP_CURRENT     1
 80 | #define DPID_HUMIDITY_CURRENT 2
 81 |
 82 | /* Current device DP values */
 83 | int temperature = 0;
 84 | int humidity = 0;
 85 |
 86 | /* Stores all DPs and their types. PS: array[][0]:dpid, array[][1]:dp type.
 87 |  *                                     dp type(TuyaDefs.h) : DP_TYPE_RAW, DP_TYPE_BOOL, DP_TYPE_VALUE, DP_TYPE_STRING, DP_TYPE_ENUM, DP_TYPE_BITMAP
 88 | */
 89 | unsigned char dp_array[][2] =
 90 | {
 91 |   {DPID_TEMP_CURRENT, DP_TYPE_VALUE},
 92 |   {DPID_HUMIDITY_CURRENT, DP_TYPE_VALUE},
 93 | };
 94 |
 95 | unsigned char pid[] = {"xxxxxxxxxxxxxxxx"};//xxxxxxxxxxxxxxxx 应为你的PID
 96 | unsigned char mcu_ver[] = {"1.0.0"};
 97 |
 98 | void setup()
 99 | {
100 |   Serial.begin(9600);
101 |     ...
102 |   my_device.init(pid, mcu_ver);
103 |   //incoming all DPs and their types array, DP numbers
104 |   my_device.set_dp_cmd_total(dp_array, 2);
105 |   //register DP download processing callback function
106 |   my_device.dp_process_func_register(dp_process);
107 |   //register upload all DP callback function
108 |   my_device.dp_update_all_func_register(dp_update_all);
109 |     ...
110 | }
111 |
112 | void loop()
113 | {
114 |   my_device.uart_service();
115 |     ...
116 |   delay(1000);
117 | }
118 |
119 | /**
120 |  * @description: DP download callback function.
121 |  * @param {unsigned char} dpid
122 |  * @param {const unsigned char} value
123 |  * @param {unsigned short} length
124 |  * @return {unsigned char}
125 |  */
126 | unsigned char dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
127 | {
128 |   /* all DP only report */
129 |   return SUCCESS;
130 | }
131 |
132 | /**
133 |  * @description: Upload all DP status of the current device.
134 |  * @param {*}
135 |  * @return {*}
136 |  */
137 | void dp_update_all(void)
138 | {
139 |   my_device.mcu_dp_update(DPID_TEMP_CURRENT, temperature, 1);
140 |   my_device.mcu_dp_update(DPID_HUMIDITY_CURRENT, humidity, 1);
141 | }
142 | ```
143 |
144 |
145 |
146 | 获取SHT30传感器信息：
147 |
148 | ```c
149 | #include <Wire.h>
150 |
151 | /* SHT30 */
152 | #define SHT30_I2C_ADDR 0x44
153 |
154 | /* Current device DP values */
155 | int temperature = 0;
156 | int humidity = 0;
157 |
158 | void setup()
159 | {
160 |     ...
161 |   // Initialise I2C communication as MASTER
162 |   Wire.begin();
163 |     ...
164 | }
165 |
166 | void loop()
167 | {
168 |     ...
169 |   /* get the temperature and humidity */
170 |   get_sht30_value(&temperature, &humidity);
171 |
172 |   if ((my_device.mcu_get_wifi_work_state() == WIFI_CONNECTED) || (my_device.mcu_get_wifi_work_state() == WIFI_CONN_CLOUD)) {
173 |     my_device.mcu_dp_update(DPID_TEMP_CURRENT, temperature, 1);
174 |     my_device.mcu_dp_update(DPID_HUMIDITY_CURRENT, humidity, 1);
175 |   }
176 |
177 |   delay(1000);
178 | }
179 |
180 | void get_sht30_value(int *temp_value, int *humi_value)
181 | {
182 |   unsigned char i2c_data[6];
183 |
184 |   // Start I2C Transmission
185 |   Wire.beginTransmission(SHT30_I2C_ADDR);
186 |   // Send measurement command
187 |   Wire.write(0x2C);
188 |   Wire.write(0x06);
189 |   // Stop I2C transmission
190 |   Wire.endTransmission();
191 |   delay(500);
192 |
193 |   // Request 6 bytes of data
194 |   Wire.requestFrom(SHT30_I2C_ADDR, 6);
195 |
196 |   // Read 6 bytes of i2c_data
197 |   // temperature msb, temperature lsb, temperature crc, humidity msb, humidity lsb, humidity crc
198 |   if (Wire.available() == 6) {
199 |     for (int i = 0; i < 6 ; i++) {
200 |       i2c_data[i] = Wire.read();
201 |     }
202 |
203 |     if ((sht30_crc(i2c_data, 2) == i2c_data[2]) && (sht30_crc(i2c_data+3, 2) == i2c_data[5])) {/* crc success */
204 |       *temp_value = (((((i2c_data[0] * 256.0) + i2c_data[1]) * 175) / 65535.0) - 45) * 100;
205 |       *humi_value = ((((i2c_data[3] * 256.0) + i2c_data[4]) * 100) / 65535.0) * 100;
206 |     } else {
207 |       *temp_value = 0;
208 |       *humi_value = 0;
209 |     }
210 |   }
211 | }
212 |
213 | /**
214 |  * @description: check sht30 temperature and humidity data
215 |  * @param {unsigned char} *data
216 |  * @param {unsigned int} count
217 |  * @return {*}
218 |  */
219 | unsigned char sht30_crc(unsigned char *data, unsigned int count)
220 | {
221 |     unsigned char crc = 0xff;
222 |     unsigned char current_byte;
223 |     unsigned char crc_bit;
224 |
225 |     /* calculates 8-Bit checksum with given polynomial */
226 |     for (current_byte = 0; current_byte < count; ++current_byte)
227 |     {
228 |         crc ^= (data[current_byte]);
229 |         for (crc_bit = 8; crc_bit > 0; --crc_bit)
230 |         {
231 |             if (crc & 0x80)
232 |                 crc = (crc << 1) ^ 0x31;
233 |             else
234 |                 crc = (crc << 1);
235 |         }
236 |     }
237 |     return crc;
238 | }
239 | ```
240 |
241 |
242 |
243 | ## 三、技术支持
244 |
245 | 您可以通过以下方法获得涂鸦的支持:
246 |
247 | - 开发者中心：https://developer.tuya.com
248 | - 帮助中心: https://support.tuya.com/cn/help
249 | - 技术支持工单中心: https://service.console.tuya.com


--------------------------------------------------------------------------------
/examples/SHT30/SHT30.ino:
--------------------------------------------------------------------------------
  1 | /*
  2 |  * @FileName: SHT30_DIS.ino
  3 |  * @Author: Tuya
  4 |  * @Email:
  5 |  * @LastEditors: shiliu
  6 |  * @Date: 2021-04-21 15:23:49
  7 |  * @LastEditTime: 2021-11-01 10:01:57
  8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
  9 |  * @Company: http://www.tuya.com
 10 |  * @Description:
 11 |  * @Github:https://github.com/tuya/tuya-wifi-mcu-sdk-arduino-library
 12 |  */
 13 | #include <Wire.h>
 14 | #include <TuyaWifi.h>
 15 |
 16 | TuyaWifi my_device;
 17 |
 18 | /* Current LED status */
 19 | unsigned char led_state = 0;
 20 | /* Connect network button pin */
 21 | int wifi_key_pin = 7;
 22 |
 23 | /* SHT30 */
 24 | #define SHT30_I2C_ADDR 0x44
 25 |
 26 | /* Data point define */
 27 | #define DPID_TEMP_CURRENT     1
 28 | #define DPID_HUMIDITY_CURRENT 2
 29 |
 30 | /* Current device DP values */
 31 | int temperature = 0;
 32 | int humidity = 0;
 33 |
 34 | /* Stores all DPs and their types. PS: array[][0]:dpid, array[][1]:dp type.
 35 |  *                                     dp type(TuyaDefs.h) : DP_TYPE_RAW, DP_TYPE_BOOL, DP_TYPE_VALUE, DP_TYPE_STRING, DP_TYPE_ENUM, DP_TYPE_BITMAP
 36 | */
 37 | unsigned char dp_array[][2] =
 38 | {
 39 |   {DPID_TEMP_CURRENT, DP_TYPE_VALUE},
 40 |   {DPID_HUMIDITY_CURRENT, DP_TYPE_VALUE},
 41 | };
 42 |
 43 | unsigned char pid[] = {"so33adeiympep2v6"};
 44 | unsigned char mcu_ver[] = {"1.0.0"};
 45 |
 46 | /* last time */
 47 | unsigned long last_time = 0;
 48 |
 49 | void setup()
 50 | {
 51 |   Serial.begin(9600);
 52 |
 53 |   // Initialise I2C communication as MASTER
 54 |   Wire.begin();
 55 |
 56 |   //Initialize led port, turn off led.
 57 |   pinMode(LED_BUILTIN, OUTPUT);
 58 |   digitalWrite(LED_BUILTIN, LOW);
 59 |   //Initialize networking keys.
 60 |   pinMode(wifi_key_pin, INPUT_PULLUP);
 61 |
 62 |   my_device.init(pid, mcu_ver);
 63 |   //incoming all DPs and their types array, DP numbers
 64 |   my_device.set_dp_cmd_total(dp_array, 2);
 65 |   //register DP download processing callback function
 66 |   my_device.dp_process_func_register(dp_process);
 67 |   //register upload all DP callback function
 68 |   my_device.dp_update_all_func_register(dp_update_all);
 69 |
 70 |   delay(300);
 71 |   last_time = millis();
 72 | }
 73 |
 74 | void loop()
 75 | {
 76 |   my_device.uart_service();
 77 |
 78 |   //Enter the connection network mode when Pin7 is pressed.
 79 |   if (digitalRead(wifi_key_pin) == LOW) {
 80 |     delay(80);
 81 |     if (digitalRead(wifi_key_pin) == LOW) {
 82 |       my_device.mcu_set_wifi_mode(SMART_CONFIG);
 83 |     }
 84 |   }
 85 |   /* LED blinks when network is being connected */
 86 |   if ((my_device.mcu_get_wifi_work_state() != WIFI_LOW_POWER) && (my_device.mcu_get_wifi_work_state() != WIFI_CONN_CLOUD) && (my_device.mcu_get_wifi_work_state() != WIFI_SATE_UNKNOW)) {
 87 |     if (millis()- last_time >= 500) {
 88 |       last_time = millis();
 89 |
 90 |       if (led_state == LOW) {
 91 |         led_state = HIGH;
 92 |       } else {
 93 |         led_state = LOW;
 94 |       }
 95 |
 96 |       digitalWrite(LED_BUILTIN, led_state);
 97 |     }
 98 |   }
 99 |
100 |   /* get the temperature and humidity */
101 |   get_sht30_value(&temperature, &humidity);
102 |
103 |   /* report the temperature and humidity */
104 |   if ((my_device.mcu_get_wifi_work_state() == WIFI_CONNECTED) || (my_device.mcu_get_wifi_work_state() == WIFI_CONN_CLOUD)) {
105 |     my_device.mcu_dp_update(DPID_TEMP_CURRENT, temperature, 1);
106 |     my_device.mcu_dp_update(DPID_HUMIDITY_CURRENT, humidity, 1);
107 |   }
108 |
109 |   delay(1000);
110 | }
111 |
112 | void get_sht30_value(int *temp_value, int *humi_value)
113 | {
114 |   unsigned char i2c_data[6];
115 |
116 |   // Start I2C Transmission
117 |   Wire.beginTransmission(SHT30_I2C_ADDR);
118 |   // Send measurement command
119 |   Wire.write(0x2C);
120 |   Wire.write(0x06);
121 |   // Stop I2C transmission
122 |   Wire.endTransmission();
123 |   delay(500);
124 |
125 |   // Request 6 bytes of data
126 |   Wire.requestFrom(SHT30_I2C_ADDR, 6);
127 |
128 |   // Read 6 bytes of i2c_data
129 |   // temperature msb, temperature lsb, temperature crc, humidity msb, humidity lsb, humidity crc
130 |   if (Wire.available() == 6) {
131 |     for (int i = 0; i < 6 ; i++) {
132 |       i2c_data[i] = Wire.read();
133 |     }
134 |
135 |     if ((sht30_crc(i2c_data, 2) == i2c_data[2]) && (sht30_crc(i2c_data+3, 2) == i2c_data[5])) {/* crc success */
136 |       *temp_value = (((((i2c_data[0] * 256.0) + i2c_data[1]) * 175) / 65535.0) - 45) * 100;
137 |       *humi_value = ((((i2c_data[3] * 256.0) + i2c_data[4]) * 100) / 65535.0) * 100;
138 |     } else {
139 |       *temp_value = 0;
140 |       *humi_value = 0;
141 |     }
142 |   }
143 | }
144 |
145 | /**
146 |  * @description: check sht30 temperature and humidity data
147 |  * @param {unsigned char} *data
148 |  * @param {unsigned int} count
149 |  * @return {*}
150 |  */
151 | unsigned char sht30_crc(unsigned char *data, unsigned int count)
152 | {
153 |     unsigned char crc = 0xff;
154 |     unsigned char current_byte;
155 |     unsigned char crc_bit;
156 |
157 |     /* calculates 8-Bit checksum with given polynomial */
158 |     for (current_byte = 0; current_byte < count; ++current_byte)
159 |     {
160 |         crc ^= (data[current_byte]);
161 |         for (crc_bit = 8; crc_bit > 0; --crc_bit)
162 |         {
163 |             if (crc & 0x80)
164 |                 crc = (crc << 1) ^ 0x31;
165 |             else
166 |                 crc = (crc << 1);
167 |         }
168 |     }
169 |     return crc;
170 | }
171 |
172 | /**
173 |  * @description: DP download callback function.
174 |  * @param {unsigned char} dpid
175 |  * @param {const unsigned char} value
176 |  * @param {unsigned short} length
177 |  * @return {unsigned char}
178 |  */
179 | unsigned char dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
180 | {
181 |   /* all DP only report */
182 |   return TY_SUCCESS;
183 | }
184 |
185 | /**
186 |  * @description: Upload all DP status of the current device.
187 |  * @param {*}
188 |  * @return {*}
189 |  */
190 | void dp_update_all(void)
191 | {
192 |   my_device.mcu_dp_update(DPID_TEMP_CURRENT, temperature, 1);
193 |   my_device.mcu_dp_update(DPID_HUMIDITY_CURRENT, humidity, 1);
194 | }
195 |
196 |
197 |


--------------------------------------------------------------------------------
/examples/start/README.md:
--------------------------------------------------------------------------------
  1 | # start
  2 | [English](./README.md) | [中文](./README_zh.md)
  3 |
  4 | This library only supports the Tuya WiFi+BLE, WiFi module with the generic firmware burned in and verified on the Arduino UNO board.
  5 |
  6 | **Note: The default Serial serial port in Arduino has been taken over by the Tuya mcu sdk, please do not do anything with the default Serial (pins 0 , 1).**
  7 |
  8 |
  9 |
 10 | ## I. Introduction to the demo
 11 |
 12 | The connection between the Tuya module and the Arduino board will interfere with the burning of the Arduino board. The Arduino board should be disconnected from the Tuya communication board or the Tuya communication board when burning. After the routine is successfully burned, connect the serial port (Serial) on the Arduino board to the `RXD` and `TXD` on the Tuya module, then pull down the `Pin7` pin on the UNO board for about 1s (simulating a key press), the device will enter the connection network mode, the LED on the Arduino board will flash during the connection network state and connection network process After successful connection, the LED on the Arduino board will stop flashing and the device can be controlled by the APP.
 13 |
 14 | This example uses Arduino board + Tuya wifi communication board, which can be controlled by the Arduino board after connection network through the Tuya Smart App.
 15 |
 16 |
 17 |
 18 | ## II. Function Implementation
 19 |
 20 | ### 1. Create product
 21 |
 22 | Go to [Tuya IoT Platform](https://iot.tuya.com/?_source=97c44038fafc20e9c8dd5fdb508cc9c2) to create a product.
 23 |
 24 | ![creat_produce1](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce1.png)
 25 |
 26 | Select category, programme.
 27 |
 28 | ![creat_produce2](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce2.png)
 29 |
 30 | Complete the product information and click on create product: !
 31 |
 32 | ![creat_produce3](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce3.png)
 33 |
 34 | Select the relevant functions according to your needs and click on Confirm: !
 35 |
 36 | ![create_produce4](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce4.png)
 37 |
 38 | After selecting the device panel, go to Hardware Development, select the Tuya Standard Module MCU SDK development method and select the corresponding module:
 39 |
 40 | ![create_produce6](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce6.png)
 41 |
 42 | Select the firmware.
 43 |
 44 | ![create_produce7](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce7.png)
 45 |
 46 | ### 2. Important function descriptions
 47 |
 48 | Initialise the serial port, the generic firmware of the Tuya WIFi module supports 115200, 9600 baud rate adaptive, so the serial port should be initialised to 115200 or 9600 when initialising the serial port. in `setup()`.
 49 |
 50 | ```c++
 51 | Serial.begin(9600);
 52 | ```
 53 |
 54 | mcu needs to send the created PID and the mcu's software version number to the Tuya Cloud module. In `setup()`.
 55 |
 56 | ```c++
 57 |   //Enter the PID and MCU software version
 58 |   my_device.init("ma67l9sgmdyg3d2k", "1.0.0");
 59 | ```
 60 |
 61 | We need to pass the ID and type of the DP selected when creating the product into the MCU SDK to use.
 62 |
 63 | ```c++
 64 | TuyaWifi my_device;
 65 |
 66 | #define DPID_SWITCH 20 //DP ID
 67 |
 68 | unsigned char dp_array[][2] =
 69 | {
 70 |   //This product was created with only one DP point selected, so there is only one piece of information in this array
 71 |   {DPID_SWITCH, DP_TYPE_BOOL}, // the first one is filled with the DP point ID, the second one is the data type of the DP point
 72 | };
 73 |
 74 | void setup()
 75 | {
 76 |     ...
 77 |     my_device.set_dp_cmd_total(dp_array, 1); //dp_array: is an array of DP point IDs and data types, 1: is the number of DPs defined in the array
 78 |     ...
 79 | }
 80 |
 81 | ```
 82 |
 83 | The initialization also requires registration of the DP point down processing function and the upload all DP points function.
 84 |
 85 | ```c++
 86 | unsigned char led_state = 0;
 87 |
 88 | void setup()
 89 | {
 90 | ...
 91 |   //register DP download processing callback function
 92 |   my_device.dp_process_func_register(led_dp_process); //register DP download processing callback function
 93 |   //register upload all DP callback function
 94 |   my_device.dp_update_all_func_register(dp_update_all); //register device status function, upload all DP points
 95 | ...
 96 | }
 97 |
 98 | void loop()
 99 | {
100 |     ...
101 |     my_device.uart_service();
102 |     ...
103 | }
104 |
105 | /**
106 |  * @description: DP download callback function.
107 |  * @param {unsigned char} dpid
108 |  * @param {const unsigned char} value
109 |  * @param {unsigned short} length
110 |  * @return {unsigned char}
111 |  */
112 | unsigned char led_dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
113 | {
114 |   switch(dpid) {
115 |     case DPID_SWITCH:
116 |       led_state = my_device.mcu_get_dp_download_data(dpid, value, length);//get the data of this DP in the downstream data frame
117 |       if (led_state) {
118 |         digitalWrite(LED_BUILTIN, HIGH);
119 |       } else {
120 |         digitalWrite(LED_BUILTIN, LOW);
121 |       }
122 |       my_device.mcu_dp_update(dpid, value, length);
123 |     break;
124 |
125 |     default:break;
126 |   }
127 |   return 1;
128 | }
129 |
130 | /**
131 |  * @description: Upload all DP status of the current device.
132 |  * @param {*}
133 |  * @return {*}
134 |  */
135 | void dp_update_all(void)
136 | {
137 |   my_device.mcu_dp_update(DPID_SWITCH, &led_state, 1);
138 | }
139 | ```
140 |
141 |
142 |
143 | ## III. Technical Support
144 |
145 | You can get support for Tuya by using the following methods:
146 |
147 | - Developer Centre: https://developer.tuya.com
148 | - Help Centre: https://support.tuya.com/help
149 | - Technical Support Work Order Centre: https://service.console.tuya.com


--------------------------------------------------------------------------------
/examples/start/README_zh.md:
--------------------------------------------------------------------------------
  1 | # start
  2 | [English](./README.md) | [中文](./README_zh.md)
  3 |
  4 | 该库仅支持烧录了通用固件的涂鸦 WiFi+BLE 、WiFi模组，在Arduino UNO板子上验证通过。
  5 |
  6 | **注意：Arduino 中的 默认Serial 串口已被Tuya mcu sdk 接管，请不要对默认Serial（引脚 0 ，1）做任何操作。**
  7 |
  8 |
  9 |
 10 | ## 一、demo 介绍
 11 |
 12 | 涂鸦模组和Arduino板连接时会干扰到对Arduino板的烧录，烧录时应断开Arduino板与涂鸦通信板或涂鸦通信板的连接。例程烧录成功后将Arduino板上串口(Serial) 与 涂鸦模组上的 `RXD` 和 `TXD` 连接起来，然后将UNO板子上的 `Pin7` 脚拉低1s左右（模拟按键按下），设备将会进入配网模式，在进入配网状态和配网过程中Arduino板上LED将会闪烁，打开涂鸦智能APP对设备（Arduino_led）进行配网操作，连接成功后Arduino板上LED将会停止闪烁，配网成功后即可通过APP对设备进行控制。
 13 |
 14 | 本例程硬件使用了Arduino板+涂鸦wifi通信板，可通过涂鸦智能APP配网后对Arduino板上LED进行控制。
 15 |
 16 |
 17 |
 18 | ## 二、功能实现
 19 |
 20 | ### 1、创建产品
 21 |
 22 | 进入 [Tuya IoT平台](https://iot.tuya.com/?_source=97c44038fafc20e9c8dd5fdb508cc9c2) 创建产品：
 23 |
 24 | ![creat_produce1](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce1.png)
 25 |
 26 | 选择品类，方案：
 27 |
 28 | ![creat_produce2](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce2.png)
 29 |
 30 | 完善产品信息，点击创建产品：
 31 |
 32 | ![creat_produce3](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce3.png)
 33 |
 34 | 根据自身需求选择相关功能，点击确认：
 35 |
 36 | ![creat_produce4](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce4.png)
 37 |
 38 | 选择设备面板后，进入硬件开发，选择 涂鸦标准模组 MCU SDK 开发方式，选择对应的模组：
 39 |
 40 | ![creat_produce6](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce6.png)
 41 |
 42 | 选择固件：
 43 |
 44 | ![creat_produce7](https://images.tuyacn.com/smart/shiliu_zone/Tuya_Arduino_library/creat_produce7.png)
 45 |
 46 | ### 2、重要函数说明
 47 |
 48 | 初始化串口，涂鸦WIFi模组的通用固件支持115200、9600波特率自适应，所以初始化串口时应将串口波特率初始化为115200或9600。在 `setup()` 中：
 49 |
 50 | ```c++
 51 | Serial.begin(9600);
 52 | ```
 53 |
 54 | mcu需要将创建的PID和mcu的软件版本号发送给涂鸦云模组。在 `setup()` 中：
 55 |
 56 | ```c++
 57 |   //Enter the PID and MCU software version
 58 |   my_device.init("ma67l9sgmdyg3d2k", "1.0.0");
 59 | ```
 60 |
 61 | 我们需要将创建产品时选择的所DP 的 ID 和类型传入MCU SDK内使用：
 62 |
 63 | ```c++
 64 | TuyaWifi my_device;
 65 |
 66 | #define DPID_SWITCH 20 //DP ID
 67 |
 68 | unsigned char dp_array[][2] =
 69 | {
 70 |   //该产品创建时只选择了一个DP点，所以该数组只有一条信息
 71 |   {DPID_SWITCH, DP_TYPE_BOOL}, //前一个填入DP点ID，后一个为DP点的数据类型
 72 | };
 73 |
 74 | void setup()
 75 | {
 76 |     ...
 77 |     my_device.set_dp_cmd_total(dp_array, 1); //dp_array:为存储DP点ID和数据类型的数组， 1：为数组内定义的DP个数
 78 |     ...
 79 | }
 80 |
 81 | ```
 82 |
 83 | 初始化时还需注册DP点下发处理函数和上传所有DP点函数：
 84 |
 85 | ```c++
 86 | unsigned char led_state = 0;
 87 |
 88 | void setup()
 89 | {
 90 | ...
 91 |   //register DP download processing callback function
 92 |   my_device.dp_process_func_register(led_dp_process); //注册DP下发处理函数
 93 |   //register upload all DP callback function
 94 |   my_device.dp_update_all_func_register(dp_update_all);//注册设备状态函数，上传所有DP点
 95 | ...
 96 | }
 97 |
 98 | void loop()
 99 | {
100 |     ...
101 |     my_device.uart_service();
102 |     ...
103 | }
104 |
105 | /**
106 |  * @description: DP download callback function.
107 |  * @param {unsigned char} dpid
108 |  * @param {const unsigned char} value
109 |  * @param {unsigned short} length
110 |  * @return {unsigned char}
111 |  */
112 | unsigned char led_dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
113 | {
114 |   switch(dpid) {
115 |     case DPID_SWITCH:
116 |       led_state = my_device.mcu_get_dp_download_data(dpid, value, length);//得到下发数据帧中该DP的数据
117 |       if (led_state) {
118 |         digitalWrite(LED_BUILTIN, HIGH);
119 |       } else {
120 |         digitalWrite(LED_BUILTIN, LOW);
121 |       }
122 |       my_device.mcu_dp_update(dpid, value, length);
123 |     break;
124 |
125 |     default:break;
126 |   }
127 |   return 1;
128 | }
129 |
130 | /**
131 |  * @description: Upload all DP status of the current device.
132 |  * @param {*}
133 |  * @return {*}
134 |  */
135 | void dp_update_all(void)
136 | {
137 |   my_device.mcu_dp_update(DPID_SWITCH, &led_state, 1);
138 | }
139 | ```
140 |
141 |
142 |
143 | ## 三、技术支持
144 |
145 | 您可以通过以下方法获得涂鸦的支持:
146 |
147 | - 开发者中心：https://developer.tuya.com
148 | - 帮助中心: https://support.tuya.com/help
149 | - 技术支持工单中心: https://service.console.tuya.com


--------------------------------------------------------------------------------
/examples/start/start.ino:
--------------------------------------------------------------------------------
  1 | /*
  2 |  * @FileName: start.ino
  3 |  * @Author: Tuya
  4 |  * @Email:
  5 |  * @LastEditors: shiliu
  6 |  * @Date: 2021-04-10 11:24:27
  7 |  * @LastEditTime: 2021-11-04 11:06:13
  8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
  9 |  * @Company: http://www.tuya.com
 10 |  * @Description: This demo is based on the Arduino UNO, and the LEDs on the UNO board are controlled by the Tuya Smart App.
 11 |  *               Enter network connection mode when Pin7 to GND.
 12 |  * @Github:https://github.com/tuya/tuya-wifi-mcu-sdk-arduino-library
 13 |  */
 14 |
 15 | #include <Arduino.h>
 16 |
 17 | #include <TuyaWifi.h>
 18 |
 19 | TuyaWifi my_device;
 20 |
 21 | /* Current LED status */
 22 | unsigned char led_state = 0;
 23 | /* Connect network button pin */
 24 | int key_pin = 7;
 25 |
 26 | /* Data point define */
 27 | #define DPID_SWITCH 20
 28 |
 29 | /* Stores all DPs and their types. PS: array[][0]:dpid, array[][1]:dp type.
 30 |  *                                     dp type(TuyaDefs.h) : DP_TYPE_RAW, DP_TYPE_BOOL, DP_TYPE_VALUE, DP_TYPE_STRING, DP_TYPE_ENUM, DP_TYPE_BITMAP
 31 | */
 32 | unsigned char dp_array[][2] =
 33 | {
 34 |   {DPID_SWITCH, DP_TYPE_BOOL},
 35 | };
 36 |
 37 | unsigned char pid[] = {"ma67l9sgmdyg3d2k"};
 38 | unsigned char mcu_ver[] = {"1.0.0"};
 39 |
 40 | /* last time */
 41 | unsigned long last_time = 0;
 42 |
 43 | void setup()
 44 | {
 45 |   Serial.begin(9600);
 46 |
 47 |   //Initialize led port, turn off led.
 48 |   pinMode(LED_BUILTIN, OUTPUT);
 49 |   digitalWrite(LED_BUILTIN, LOW);
 50 |
 51 |   //Initialize networking keys.
 52 |   pinMode(key_pin, INPUT_PULLUP);
 53 |
 54 |   //Enter the PID and MCU software version
 55 |   my_device.init(pid, mcu_ver);
 56 |   //incoming all DPs and their types array, DP numbers
 57 |   my_device.set_dp_cmd_total(dp_array, 1);
 58 |   //register DP download processing callback function
 59 |   my_device.dp_process_func_register(dp_process);
 60 |   //register upload all DP callback function
 61 |   my_device.dp_update_all_func_register(dp_update_all);
 62 |
 63 |   last_time = millis();
 64 | }
 65 |
 66 | void loop()
 67 | {
 68 |   my_device.uart_service();
 69 |
 70 |   //Enter the connection network mode when Pin7 is pressed.
 71 |   if (digitalRead(key_pin) == LOW) {
 72 |     delay(80);
 73 |     if (digitalRead(key_pin) == LOW) {
 74 |       my_device.mcu_set_wifi_mode(SMART_CONFIG);
 75 |     }
 76 |   }
 77 |   /* LED blinks when network is being connected */
 78 |   if ((my_device.mcu_get_wifi_work_state() != WIFI_LOW_POWER) && (my_device.mcu_get_wifi_work_state() != WIFI_CONN_CLOUD) && (my_device.mcu_get_wifi_work_state() != WIFI_SATE_UNKNOW)) {
 79 |     if (millis()- last_time >= 500) {
 80 |       last_time = millis();
 81 |
 82 |       if (led_state == LOW) {
 83 |         led_state = HIGH;
 84 |       } else {
 85 |         led_state = LOW;
 86 |       }
 87 |       digitalWrite(LED_BUILTIN, led_state);
 88 |     }
 89 |   }
 90 |
 91 |   delay(10);
 92 | }
 93 |
 94 | /**
 95 |  * @description: DP download callback function.
 96 |  * @param {unsigned char} dpid
 97 |  * @param {const unsigned char} value
 98 |  * @param {unsigned short} length
 99 |  * @return {unsigned char}
100 |  */
101 | unsigned char dp_process(unsigned char dpid,const unsigned char value[], unsigned short length)
102 | {
103 |   switch(dpid) {
104 |     case DPID_SWITCH:
105 |       led_state = my_device.mcu_get_dp_download_data(dpid, value, length); /* Get the value of the down DP command */
106 |       if (led_state) {
107 |         //Turn on
108 |         digitalWrite(LED_BUILTIN, HIGH);
109 |       } else {
110 |         //Turn off
111 |         digitalWrite(LED_BUILTIN, LOW);
112 |       }
113 |       //Status changes should be reported.
114 |       my_device.mcu_dp_update(dpid, value, length);
115 |     break;
116 |
117 |     default:break;
118 |   }
119 |   return TY_SUCCESS;
120 | }
121 |
122 | /**
123 |  * @description: Upload all DP status of the current device.
124 |  * @param {*}
125 |  * @return {*}
126 |  */
127 | void dp_update_all(void)
128 | {
129 |   my_device.mcu_dp_update(DPID_SWITCH, led_state, 1);
130 | }
131 |


--------------------------------------------------------------------------------
/keywords.txt:
--------------------------------------------------------------------------------
 1 | #######################################
 2 | # Data types (KEYWORD1)
 3 | #######################################
 4 |
 5 | TuyaWifi	KEYWORD1
 6 | TuyaUart	KEYWORD1
 7 | TuyaTools	KEYWORD1
 8 | TuyaDataPoint	KEYWORD1
 9 |
10 | #######################################
11 | # Methods and Functions (KEYWORD2)
12 | #######################################
13 |
14 | my_device KEYWORD2
15 | init	KEYWORD2
16 | uart_service	KEYWORD2
17 | dp_process_func_register	KEYWORD2
18 | dp_update_all_func_register	KEYWORD2
19 | data_point_handle	KEYWORD2
20 | set_download_cmd_total	KEYWORD2
21 | get_dowmload_dpid_index	KEYWORD2
22 | mcu_get_dp_download_data	KEYWORD2
23 | mcu_dp_update	KEYWORD2
24 | mcu_set_wifi_mode	KEYWORD2
25 | mcu_get_wifi_work_state	KEYWORD2
26 | set_dp_cmd_total	KEYWORD2
27 |
28 | #######################################
29 | # Constants (LITERAL1)
30 | #######################################
31 |
32 | SMART_CONFIG_STATE	LITERAL1
33 | AP_STATE	LITERAL1
34 | WIFI_NOT_CONNECTED	LITERAL1
35 | WIFI_CONNECTED	LITERAL1
36 | WIFI_CONN_CLOUD	LITERAL1
37 | WIFI_LOW_POWER	LITERAL1
38 | SMART_AND_AP_STATE	LITERAL1
39 | WIFI_SATE_UNKNOW	LITERAL1
40 |
41 | DP_TYPE_RAW	LITERAL1
42 | DP_TYPE_BOOL	LITERAL1
43 | DP_TYPE_VALUE	LITERAL1
44 | DP_TYPE_STRING	LITERAL1
45 | DP_TYPE_ENUM	LITERAL1
46 | DP_TYPE_BITMAP	LITERAL1
47 |
48 | SMART_CONFIG	LITERAL1
49 | AP_CONFIG	LITERAL1
50 |
51 | CONFIG_MODE_DEFAULT	LITERAL1
52 | CONFIG_MODE_LOWPOWER	LITERAL1
53 | CONFIG_MODE_SPECIAL	LITERAL1
54 |


--------------------------------------------------------------------------------
/library.properties:
--------------------------------------------------------------------------------
 1 | name=Tuya_WiFi_MCU_SDK
 2 | version=0.0.3
 3 | author=Tuya
 4 | maintainer=Tuya
 5 | sentence=Communicate with Tuya modules that have flashed the Tuya common Wi-Fi firmware.
 6 | paragraph=
 7 | category=Communication
 8 | url=https://github.com/tuya/tuya-wifi-mcu-sdk-arduino-library
 9 | architectures=*
10 | includes=TuyaWifi.h
11 |


--------------------------------------------------------------------------------
/src/TuyaDataPoint.cpp:
--------------------------------------------------------------------------------
  1 | /*
  2 |  * @FileName: TuyaDataPoint.cpp
  3 |  * @Author: Tuya
  4 |  * @Email:
  5 |  * @LastEditors: Tuya
  6 |  * @Date: 2021-04-10 15:34:17
  7 |  * @LastEditTime: 2021-04-28 19:48:05
  8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
  9 |  * @Company: http://www.tuya.com
 10 |  * @Description: tuya mcu sdk Arduino library about data point process.
 11 |  */
 12 | #include "TuyaDataPoint.h"
 13 | #include "TuyaDefs.h"
 14 | #include "TuyaTools.h"
 15 | #include "TuyaUart.h"
 16 | #include <TuyaWifi.h>
 17 |
 18 | extern TuyaTools tuya_tools;
 19 | extern TuyaUart tuya_uart;
 20 |
 21 | unsigned char TuyaDataPoint::mcu_get_dp_download_bool(const unsigned char value[], unsigned short len)
 22 | {
 23 |     return (value[0]);
 24 | }
 25 |
 26 | unsigned char TuyaDataPoint::mcu_get_dp_download_enum(const unsigned char value[], unsigned short len)
 27 | {
 28 |     return (value[0]);
 29 | }
 30 |
 31 | unsigned long TuyaDataPoint::mcu_get_dp_download_value(const unsigned char value[], unsigned short len)
 32 | {
 33 |     return (tuya_tools.byte_to_int(value));
 34 | }
 35 |
 36 | unsigned char TuyaDataPoint::mcu_dp_raw_update(unsigned char dpid, const unsigned char value[], unsigned short len)
 37 | {
 38 |     unsigned short send_len = 0;
 39 |
 40 |     if (stop_update_flag == TY_ENABLE)
 41 |         return TY_SUCCESS;
 42 |     //
 43 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, dpid);
 44 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, DP_TYPE_RAW);
 45 |     //
 46 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, len / 0x100);
 47 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, len % 0x100);
 48 |     //
 49 |     send_len = tuya_uart.set_wifi_uart_buffer(send_len, (unsigned char *)value, len);
 50 |
 51 |     tuya_uart.wifi_uart_write_frame(STATE_UPLOAD_CMD, MCU_TX_VER, send_len);
 52 |
 53 |     return TY_SUCCESS;
 54 | }
 55 |
 56 | unsigned char TuyaDataPoint::mcu_dp_bool_update(unsigned char dpid, unsigned char value)
 57 | {
 58 |     unsigned short send_len = 0;
 59 |
 60 |     if (stop_update_flag == TY_ENABLE)
 61 |         return TY_SUCCESS;
 62 |
 63 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, dpid);
 64 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, DP_TYPE_BOOL);
 65 |     //
 66 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, 0);
 67 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, 1);
 68 |     //
 69 |     if (value == TY_FALSE)
 70 |     {
 71 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, TY_FALSE);
 72 |     }
 73 |     else
 74 |     {
 75 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, 1);
 76 |     }
 77 |
 78 |     tuya_uart.wifi_uart_write_frame(STATE_UPLOAD_CMD, MCU_TX_VER, send_len);
 79 |
 80 |     return TY_SUCCESS;
 81 | }
 82 |
 83 | unsigned char TuyaDataPoint::mcu_dp_value_update(unsigned char dpid, unsigned long value)
 84 | {
 85 |     unsigned short send_len = 0;
 86 |
 87 |     if (stop_update_flag == TY_ENABLE)
 88 |         return TY_SUCCESS;
 89 |
 90 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, dpid);
 91 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, DP_TYPE_VALUE);
 92 |     //
 93 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, 0);
 94 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, 4);
 95 |     //
 96 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, value >> 24);
 97 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, value >> 16);
 98 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, value >> 8);
 99 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, value & 0xff);
100 |
101 |     tuya_uart.wifi_uart_write_frame(STATE_UPLOAD_CMD, MCU_TX_VER, send_len);
102 |
103 |     return TY_SUCCESS;
104 | }
105 |
106 | unsigned char TuyaDataPoint::mcu_dp_string_update(unsigned char dpid, const unsigned char value[], unsigned short len)
107 | {
108 |     unsigned short send_len = 0;
109 |
110 |     if (stop_update_flag == TY_ENABLE)
111 |         return TY_SUCCESS;
112 |     //
113 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, dpid);
114 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, DP_TYPE_STRING);
115 |     //
116 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, len / 0x100);
117 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, len % 0x100);
118 |     //
119 |     send_len = tuya_uart.set_wifi_uart_buffer(send_len, (unsigned char *)value, len);
120 |
121 |     tuya_uart.wifi_uart_write_frame(STATE_UPLOAD_CMD, MCU_TX_VER, send_len);
122 |
123 |     return TY_SUCCESS;
124 | }
125 |
126 | unsigned char TuyaDataPoint::mcu_dp_enum_update(unsigned char dpid, unsigned char value)
127 | {
128 |     unsigned short send_len = 0;
129 |
130 |     if (stop_update_flag == TY_ENABLE)
131 |         return TY_SUCCESS;
132 |
133 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, dpid);
134 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, DP_TYPE_ENUM);
135 |     //
136 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, 0);
137 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, 1);
138 |     //
139 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, value);
140 |
141 |     tuya_uart.wifi_uart_write_frame(STATE_UPLOAD_CMD, MCU_TX_VER, send_len);
142 |
143 |     return TY_SUCCESS;
144 | }
145 |
146 | unsigned char TuyaDataPoint::mcu_dp_fault_update(unsigned char dpid, unsigned long value)
147 | {
148 |     unsigned short send_len = 0;
149 |
150 |     if (stop_update_flag == TY_ENABLE)
151 |         return TY_SUCCESS;
152 |
153 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, dpid);
154 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, DP_TYPE_BITMAP);
155 |     //
156 |     send_len = tuya_uart.set_wifi_uart_byte(send_len, 0);
157 |
158 |     if ((value | 0xff) == 0xff)
159 |     {
160 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, 1);
161 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, value);
162 |     }
163 |     else if ((value | 0xffff) == 0xffff)
164 |     {
165 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, 2);
166 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, value >> 8);
167 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, value & 0xff);
168 |     }
169 |     else
170 |     {
171 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, 4);
172 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, value >> 24);
173 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, value >> 16);
174 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, value >> 8);
175 |         send_len = tuya_uart.set_wifi_uart_byte(send_len, value & 0xff);
176 |     }
177 |
178 |     tuya_uart.wifi_uart_write_frame(STATE_UPLOAD_CMD, MCU_TX_VER, send_len);
179 |
180 |     return TY_SUCCESS;
181 | }
182 |


--------------------------------------------------------------------------------
/src/TuyaDataPoint.h:
--------------------------------------------------------------------------------
 1 | /*
 2 |  * @FileName: TuyaDataPoint.h
 3 |  * @Author: Tuya
 4 |  * @Email:
 5 |  * @LastEditors: Tuya
 6 |  * @Date: 2021-04-10 15:34:17
 7 |  * @LastEditTime: 2021-04-28 19:48:45
 8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
 9 |  * @Company: http://www.tuya.com
10 |  * @Description:
11 |  */
12 | #ifndef __TUYA_DATA_POINT_H__
13 | #define __TUYA_DATA_POINT_H__
14 |
15 | class TuyaDataPoint
16 | {
17 | public:
18 |     // TuyaDataPoint(void);
19 |     // ~TuyaDataPoint(void);
20 |
21 |     unsigned char mcu_get_dp_download_bool(const unsigned char value[], unsigned short len);
22 |     unsigned char mcu_get_dp_download_enum(const unsigned char value[], unsigned short len);
23 |     unsigned long mcu_get_dp_download_value(const unsigned char value[], unsigned short len);
24 |
25 |     unsigned char mcu_dp_raw_update(unsigned char dpid, const unsigned char value[], unsigned short len);
26 |     unsigned char mcu_dp_bool_update(unsigned char dpid, unsigned char value);
27 |     unsigned char mcu_dp_value_update(unsigned char dpid, unsigned long value);
28 |     unsigned char mcu_dp_string_update(unsigned char dpid, const unsigned char value[], unsigned short len);
29 |     unsigned char mcu_dp_enum_update(unsigned char dpid, unsigned char value);
30 |     unsigned char mcu_dp_fault_update(unsigned char dpid, unsigned long value);
31 |
32 | private:
33 | };
34 |
35 | #endif /* __TUYA_DATA_POINT_H__ */
36 |


--------------------------------------------------------------------------------
/src/TuyaDefs.h:
--------------------------------------------------------------------------------
  1 | /*
  2 |  * @FileName: TuyaDefs.h
  3 |  * @Author: Tuya
  4 |  * @Email:
  5 |  * @LastEditors: Tuya
  6 |  * @Date: 2021-04-10 11:28:40
  7 |  * @LastEditTime: 2021-04-28 19:48:57
  8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
  9 |  * @Company: http://www.tuya.com
 10 |  * @Description: Some necessary constant definitions.
 11 |  */
 12 | #ifndef __TUYA_DEFS_H__
 13 | #define __TUYA_DEFS_H__
 14 |
 15 | /* Define constant */
 16 | #ifndef TY_TRUE
 17 | #define TY_TRUE 1
 18 | #endif
 19 |
 20 | #ifndef TY_FALSE
 21 | #define TY_FALSE 0
 22 | #endif
 23 |
 24 | #ifndef TY_NULL
 25 | #ifdef __cplusplus
 26 | #define TY_NULL    0
 27 | #else
 28 | #define TY_NULL   ((void *)0)
 29 | #endif
 30 | #endif
 31 |
 32 | #ifndef TY_SUCCESS
 33 | #define TY_SUCCESS 1
 34 | #endif
 35 |
 36 | #ifndef TY_ERROR
 37 | #define TY_ERROR 0
 38 | #endif
 39 |
 40 | #ifndef TY_INVALID
 41 | #define TY_INVALID 0xFF
 42 | #endif
 43 |
 44 | #ifndef TY_ENABLE
 45 | #define TY_ENABLE 1
 46 | #endif
 47 |
 48 | #ifndef TY_DISABLE
 49 | #define TY_DISABLE 0
 50 | #endif
 51 |
 52 | #define MCU_RX_VER      0x00    //Module send frame protocol version number
 53 | #define MCU_TX_VER      0x03    //MCU send frame protocol version number(default)
 54 | #define PROTOCOL_HEAD   0x07    //Fixed protocol header length
 55 | #define FRAME_FIRST     0x55    //Frame header first byte
 56 | #define FRAME_SECOND    0xaa    //Frame header second byte
 57 |
 58 | //=============================================================================
 59 | //Byte order of the frame
 60 | //=============================================================================
 61 | #define HEAD_FIRST          0
 62 | #define HEAD_SECOND         1
 63 | #define PROTOCOL_VERSION    2
 64 | #define FRAME_TYPE          3
 65 | #define LENGTH_HIGH         4
 66 | #define LENGTH_LOW          5
 67 | #define DATA_START          6
 68 |
 69 | //=============================================================================
 70 | //Data frame type
 71 | //=============================================================================
 72 | #define         HEAT_BEAT_CMD                   0                               //Heartbeat package
 73 | #define         PRODUCT_INFO_CMD                1                               //Product information
 74 | #define         WORK_MODE_CMD                   2                               //Query the module working mode set by the MCU
 75 | #define         WIFI_STATE_CMD                  3                               //Wifi working status
 76 | #define         WIFI_RESET_CMD                  4                               //Reset wifi
 77 | #define         WIFI_MODE_CMD                   5                               //Select smartconfig/AP mode
 78 | #define         DATA_QUERT_CMD                  6                               //Order send
 79 | #define         STATE_UPLOAD_CMD                7                               //Status upload
 80 | #define         STATE_QUERY_CMD                 8                               //Status query
 81 | #define         UPDATE_START_CMD                0x0a                            //Upgrade start
 82 | #define         UPDATE_TRANS_CMD                0x0b                            //Upgrade transfer
 83 | #define         GET_ONLINE_TIME_CMD             0x0c                            //Get system time (Greenwich Mean Time)
 84 | #define         FACTORY_MODE_CMD                0x0d                            //Enter production test mode
 85 | #define         WIFI_TEST_CMD                   0x0e                            //Wifi function test
 86 | #define         GET_LOCAL_TIME_CMD              0x1c                            //Get local time
 87 | #define         WEATHER_OPEN_CMD                0x20                            //Turn on the weather
 88 | #define         WEATHER_DATA_CMD                0x21                            //Weather data
 89 | #define         STATE_UPLOAD_SYN_CMD            0x22                            //Status upload (synchronization)
 90 | #define         STATE_UPLOAD_SYN_RECV_CMD       0x23                            //Status upload results(synchronization)
 91 | #define         HEAT_BEAT_STOP                  0x25                            //Turn off the WIFI module heartbeat
 92 | #define         STREAM_TRANS_CMD                0x28                            //Stream data transmission
 93 | #define         GET_WIFI_STATUS_CMD             0x2b                            //Gets the wifi networking status
 94 | #define         WIFI_CONNECT_TEST_CMD           0x2c                            //Wifi function test(connection designated route)
 95 | #define         GET_MAC_CMD                     0x2d                            //Get module mac
 96 | #define         GET_IR_STATUS_CMD               0x2e                            //IR status notification
 97 | #define         IR_TX_RX_TEST_CMD               0x2f                            //IR into send-receive test
 98 | #define         MAPS_STREAM_TRANS_CMD           0x30                            //streams trans(Support for multiple maps)
 99 | #define         FILE_DOWNLOAD_START_CMD         0x31                            //File download startup
100 | #define         FILE_DOWNLOAD_TRANS_CMD         0x32                            //File download data transfer
101 | #define         MODULE_EXTEND_FUN_CMD           0x34                            //Open the module time service notification
102 | #define         BLE_TEST_CMD                    0x35                            //Bluetooth functional test（Scan designated bluetooth beacon）
103 | #define         GET_VOICE_STATE_CMD             0x60                            //Gets the voice status code
104 | #define         MIC_SILENCE_CMD                 0x61                            //MIC mute Settings
105 | #define         SET_SPEAKER_VOLUME_CMD          0x62                            //speaker volume set
106 | #define         VOICE_TEST_CMD                  0x63                            //Audio production test
107 | #define         VOICE_AWAKEN_TEST_CMD           0x64                            //Wake up production test
108 | #define         VOICE_EXTEND_FUN_CMD            0x65                            //Voice module extension function
109 |
110 | //=============================================================================
111 | //WIFI work status
112 | //=============================================================================
113 | #define         SMART_CONFIG_STATE              0x00
114 | #define         AP_STATE                        0x01
115 | #define         WIFI_NOT_CONNECTED              0x02
116 | #define         WIFI_CONNECTED                  0x03
117 | #define         WIFI_CONN_CLOUD                 0x04
118 | #define         WIFI_LOW_POWER                  0x05
119 | #define         SMART_AND_AP_STATE              0x06
120 | #define         WIFI_SATE_UNKNOW                0xff
121 | //=============================================================================
122 | //wifi reset status
123 | //=============================================================================
124 | #define         RESET_WIFI_ERROR                0
125 | #define         RESET_WIFI_SUCCESS              1
126 |
127 | //=============================================================================
128 | //wifi reset result
129 | //=============================================================================
130 | #define         SET_WIFICONFIG_ERROR            0
131 | #define         SET_WIFICONFIG_SUCCESS          1
132 |
133 | //=============================================================================
134 | //dp data point type
135 | //=============================================================================
136 | #define         DP_TYPE_RAW                     0x00        //RAW type
137 | #define         DP_TYPE_BOOL                    0x01        //bool type
138 | #define         DP_TYPE_VALUE                   0x02        //value type
139 | #define         DP_TYPE_STRING                  0x03        //string type
140 | #define         DP_TYPE_ENUM                    0x04        //enum type
141 | #define         DP_TYPE_BITMAP                  0x05        //fault type
142 |
143 | //=============================================================================
144 | //wifi distribution network
145 | //=============================================================================
146 | #define         SMART_CONFIG                    0x0
147 | #define         AP_CONFIG                       0x1
148 |
149 | //=============================================================================
150 | //Choose network access mode
151 | //=============================================================================
152 | #define         CONFIG_MODE_DEFAULT             "0"                             //Default mode
153 | #define         CONFIG_MODE_LOWPOWER            "1"                             //low power mode
154 | #define         CONFIG_MODE_SPECIAL             "2"                             //special mode
155 |
156 | #endif /* __TUYA_DEFS_H__ */


--------------------------------------------------------------------------------
/src/TuyaExtras.cpp:
--------------------------------------------------------------------------------
 1 | /*
 2 |  * @FileName: TuyaExtras.h
 3 |  * @Author: Tuya
 4 |  * @Email:
 5 |  * @LastEditors: shiliu
 6 |  * @Date: 2021-10-30 15:50:27
 7 |  * @LastEditTime: 2021-11-04 11:47:47
 8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
 9 |  * @Company: http://www.tuya.com
10 |  * @Description:
11 |  */
12 | #include "TuyaExtras.h"
13 | #include "TuyaDefs.h"
14 | #include "TuyaUart.h"
15 |
16 | extern TuyaUart tuya_uart;
17 |
18 | #if SUPPORT_GREEN_TIME
19 | void TuyaExtras::mcu_request_green_time(void)
20 | {
21 |     tuya_uart.wifi_uart_write_frame(GET_ONLINE_TIME_CMD, MCU_TX_VER, 0);
22 | }
23 |
24 | void TuyaExtras::mcu_get_green_time(unsigned char time[], TUYA_WIFI_TIME *tuya_time)
25 | {
26 |     if (time == TY_NULL || tuya_time == TY_NULL) {
27 |         return;
28 |     }
29 |
30 |     if(time[0] == 1) {
31 |         tuya_time->update_flag = 1;
32 |         tuya_time->year = 2000+time[1];
33 |         tuya_time->month = time[2];
34 |         tuya_time->day = time[3];
35 |         tuya_time->hour = time[4];
36 |         tuya_time->minute = time[5];
37 |         tuya_time->second = time[6];
38 |         tuya_time->weekday = 0;
39 |     }else {
40 |         tuya_time->update_flag = -1;
41 |     }
42 | }
43 | #endif /* SUPPORT_GREEN_TIME */
44 |
45 | #if SUPPORT_RTC_TIME
46 | void TuyaExtras::mcu_request_rtc_time(void)
47 | {
48 |     tuya_uart.wifi_uart_write_frame(GET_LOCAL_TIME_CMD, MCU_TX_VER, 0);
49 | }
50 |
51 | void TuyaExtras::mcu_get_rtc_time(unsigned char time[], TUYA_WIFI_TIME *tuya_time)
52 | {
53 |     if (time == TY_NULL || tuya_time == TY_NULL) {
54 |         return;
55 |     }
56 |
57 |     if(time[0] == 1) {
58 |         tuya_time->update_flag = 1;
59 |         tuya_time->year = time[1];
60 |         tuya_time->month = time[2];
61 |         tuya_time->day = time[3];
62 |         tuya_time->hour = time[4];
63 |         tuya_time->minute = time[5];
64 |         tuya_time->second = time[6];
65 |         tuya_time->weekday = time[7];
66 |     }else {
67 |         tuya_time->update_flag = -1;
68 |     }
69 | }
70 | #endif /* SUPPORT_RTC_TIME */
71 |


--------------------------------------------------------------------------------
/src/TuyaExtras.h:
--------------------------------------------------------------------------------
 1 | /*
 2 |  * @FileName: TuyaExtras.h
 3 |  * @Author: Tuya
 4 |  * @Email:
 5 |  * @LastEditors: shiliu
 6 |  * @Date: 2021-10-30 15:49:00
 7 |  * @LastEditTime: 2021-11-01 19:31:15
 8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
 9 |  * @Company: http://www.tuya.com
10 |  * @Description:
11 |  */
12 | #ifndef __TUYA_EXTRAS_H__
13 | #define __TUYA_EXTRAS_H__
14 |
15 | #include "../config.h"
16 |
17 | extern "C"
18 | {
19 | #if SUPPORT_GREEN_TIME
20 |     typedef struct
21 |     {
22 |         unsigned short year;
23 |         unsigned char month;
24 |         unsigned char day;
25 |         unsigned char hour;
26 |         unsigned char minute;
27 |         unsigned char second;
28 |         unsigned char weekday;
29 |
30 |         char update_flag;
31 |     }TUYA_WIFI_TIME;
32 | #endif /* SUPPORT_GREEN_TIME */
33 | }
34 |
35 | class TuyaExtras
36 | {
37 | public:
38 | #if SUPPORT_GREEN_TIME
39 |     void mcu_request_green_time(void);
40 |     void mcu_get_green_time(unsigned char time[], TUYA_WIFI_TIME *tuya_time);
41 | #endif /* SUPPORT_GREEN_TIME */
42 |
43 | #if SUPPORT_RTC_TIME
44 |     void mcu_request_rtc_time(void);
45 |     void mcu_get_rtc_time(unsigned char time[], TUYA_WIFI_TIME *tuya_time);
46 | #endif /* SUPPORT_RTC_TIME */
47 |
48 | private:
49 | };
50 |
51 | #endif /* __TUYA_EXTRA_H__ */
52 |


--------------------------------------------------------------------------------
/src/TuyaTools.cpp:
--------------------------------------------------------------------------------
  1 | /*
  2 |  * @FileName: TuyaTools.cpp
  3 |  * @Author: Tuya
  4 |  * @Email:
  5 |  * @LastEditors: Tuya
  6 |  * @Date: 2021-04-10 14:04:23
  7 |  * @LastEditTime: 2021-04-28 19:49:08
  8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
  9 |  * @Company: http://www.tuya.com
 10 |  * @Description: Some necessary tools.
 11 |  */
 12 | #include "TuyaTools.h"
 13 | #include "TuyaDefs.h"
 14 |
 15 | TuyaTools::TuyaTools(void)
 16 | {
 17 | }
 18 |
 19 | TuyaTools::~TuyaTools(void)
 20 | {
 21 | }
 22 |
 23 | unsigned char TuyaTools::hex_to_bcd(unsigned char Value_H, unsigned char Value_L)
 24 | {
 25 |     unsigned char bcd_value;
 26 |
 27 |     if ((Value_H >= '0') && (Value_H <= '9'))
 28 |         Value_H -= '0';
 29 |     else if ((Value_H >= 'A') && (Value_H <= 'F'))
 30 |         Value_H = Value_H - 'A' + 10;
 31 |     else if ((Value_H >= 'a') && (Value_H <= 'f'))
 32 |         Value_H = Value_H - 'a' + 10;
 33 |
 34 |     bcd_value = Value_H & 0x0f;
 35 |
 36 |     bcd_value <<= 4;
 37 |     if ((Value_L >= '0') && (Value_L <= '9'))
 38 |         Value_L -= '0';
 39 |     else if ((Value_L >= 'A') && (Value_L <= 'F'))
 40 |         Value_L = Value_L - 'a' + 10;
 41 |     else if ((Value_L >= 'a') && (Value_L <= 'f'))
 42 |         Value_L = Value_L - 'a' + 10;
 43 |
 44 |     bcd_value |= Value_L & 0x0f;
 45 |
 46 |     return bcd_value;
 47 | }
 48 |
 49 | unsigned long TuyaTools::my_strlen(unsigned char *str)
 50 | {
 51 |     unsigned long len = 0;
 52 |     if (str == TY_NULL)
 53 |     {
 54 |         return 0;
 55 |     }
 56 |
 57 |     for (len = 0; *str++ != '\0';)
 58 |     {
 59 |         len++;
 60 |     }
 61 |
 62 |     return len;
 63 | }
 64 |
 65 | void *TuyaTools::my_memset(void *src, unsigned char ch, unsigned short count)
 66 | {
 67 |     unsigned char *tmp = (unsigned char *)src;
 68 |
 69 |     if (src == TY_NULL)
 70 |     {
 71 |         return TY_NULL;
 72 |     }
 73 |
 74 |     while (count--)
 75 |     {
 76 |         *tmp++ = ch;
 77 |     }
 78 |
 79 |     return src;
 80 | }
 81 |
 82 | void *TuyaTools::my_memcpy(void *dest, const void *src, unsigned short count)
 83 | {
 84 |     unsigned char *pdest = (unsigned char *)dest;
 85 |     const unsigned char *psrc = (const unsigned char *)src;
 86 |     unsigned short i;
 87 |
 88 |     if (dest == TY_NULL || src == TY_NULL)
 89 |     {
 90 |         return TY_NULL;
 91 |     }
 92 |
 93 |     if ((pdest <= psrc) || (pdest > psrc + count))
 94 |     {
 95 |         for (i = 0; i < count; i++)
 96 |         {
 97 |             pdest[i] = psrc[i];
 98 |         }
 99 |     }
100 |     else
101 |     {
102 |         for (i = count; i > 0; i--)
103 |         {
104 |             pdest[i - 1] = psrc[i - 1];
105 |         }
106 |     }
107 |
108 |     return dest;
109 | }
110 |
111 | char *TuyaTools::my_strcpy(char *dest, const char *src)
112 | {
113 |     if ((TY_NULL == dest) || (TY_NULL == src))
114 |     {
115 |         return TY_NULL;
116 |     }
117 |
118 |     char *p = dest;
119 |     while (*src != '\0')
120 |     {
121 |         *dest++ = *src++;
122 |     }
123 |     *dest = '\0';
124 |     return p;
125 | }
126 |
127 | int TuyaTools::my_strcmp(char *s1, char *s2)
128 | {
129 |     while (*s1 && *s2 && *s1 == *s2)
130 |     {
131 |         s1++;
132 |         s2++;
133 |     }
134 |     return *s1 - *s2;
135 | }
136 |
137 | void TuyaTools::int_to_byte(unsigned long number, unsigned char value[4])
138 | {
139 |     value[0] = number >> 24;
140 |     value[1] = number >> 16;
141 |     value[2] = number >> 8;
142 |     value[3] = number & 0xff;
143 | }
144 |
145 | unsigned long TuyaTools::byte_to_int(const unsigned char value[4])
146 | {
147 |     unsigned long nubmer = 0;
148 |
149 |     nubmer = (unsigned long)value[0];
150 |     nubmer <<= 8;
151 |     nubmer |= (unsigned long)value[1];
152 |     nubmer <<= 8;
153 |     nubmer |= (unsigned long)value[2];
154 |     nubmer <<= 8;
155 |     nubmer |= (unsigned long)value[3];
156 |
157 |     return nubmer;
158 | }
159 |
160 | unsigned char TuyaTools::get_check_sum(unsigned char *pack, unsigned short pack_len)
161 | {
162 |     unsigned short i;
163 |     unsigned char check_sum = 0;
164 |
165 |     for (i = 0; i < pack_len; i++)
166 |     {
167 |         check_sum += *pack++;
168 |     }
169 |
170 |     return check_sum;
171 | }
172 |


--------------------------------------------------------------------------------
/src/TuyaTools.h:
--------------------------------------------------------------------------------
 1 | /*
 2 |  * @FileName: TuyaTools.h
 3 |  * @Author: Tuya
 4 |  * @Email:
 5 |  * @LastEditors: Tuya
 6 |  * @Date: 2021-04-25 17:44:25
 7 |  * @LastEditTime: 2021-04-28 19:49:36
 8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
 9 |  * @Company: http://www.tuya.com
10 |  * @Description:
11 |  */
12 | #ifndef __TUYA_TOOLS_H__
13 | #define __TUYA_TOOLS_H__
14 |
15 | class TuyaTools
16 | {
17 | public:
18 |     TuyaTools(void);
19 |     ~TuyaTools(void);
20 |
21 |     unsigned char hex_to_bcd(unsigned char Value_H, unsigned char Value_L);
22 |     unsigned long my_strlen(unsigned char *str);
23 |     void *my_memset(void *src, unsigned char ch, unsigned short count);
24 |     void *my_memcpy(void *dest, const void *src, unsigned short count);
25 |     char *my_strcpy(char *dest, const char *src);
26 |     int my_strcmp(char *s1, char *s2);
27 |     void int_to_byte(unsigned long number, unsigned char value[4]);
28 |     unsigned long byte_to_int(const unsigned char value[4]);
29 |     unsigned char get_check_sum(unsigned char *pack, unsigned short pack_len);
30 |
31 | private:
32 | };
33 |
34 | #endif /* __TUYA_TOOLS_H__ */
35 |


--------------------------------------------------------------------------------
/src/TuyaUart.cpp:
--------------------------------------------------------------------------------
  1 | /*
  2 |  * @FileName: TuyaUart.cpp
  3 |  * @Author: Tuya
  4 |  * @Email:
  5 |  * @LastEditors: shiliu
  6 |  * @Date: 2021-04-10 15:34:37
  7 |  * @LastEditTime: 2021-11-04 11:03:14
  8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
  9 |  * @Company: http://www.tuya.com
 10 |  * @Description: Tuya mcu sdk Arduino library about uart buffer, data receiving and sending.
 11 |  */
 12 | #include "TuyaWifi.h"
 13 | #include "TuyaUart.h"
 14 | #include "TuyaTools.h"
 15 |
 16 | extern TuyaTools tuya_tools;
 17 |
 18 | TuyaUart::TuyaUart(void)
 19 | {
 20 |     wifi_protocol_init();
 21 | }
 22 |
 23 | TuyaUart::~TuyaUart(void)
 24 | {
 25 | }
 26 |
 27 | void TuyaUart::wifi_protocol_init(void)
 28 | {
 29 |     rx_buf_in = (unsigned char *)wifi_uart_rx_buf;
 30 |     rx_buf_out = (unsigned char *)wifi_uart_rx_buf;
 31 |
 32 |     stop_update_flag = TY_DISABLE;
 33 | }
 34 |
 35 | void TuyaUart::uart_transmit_output(unsigned char value)
 36 | {
 37 |     write(value);
 38 | }
 39 |
 40 | unsigned char TuyaUart::uart_receive_input(unsigned char data)
 41 | {
 42 |     if (1 == rx_buf_out - rx_buf_in)
 43 |     {
 44 |         //UART receive buffer is full
 45 |         return TY_ERROR;
 46 |     }
 47 |     else if ((rx_buf_in > rx_buf_out) && ((unsigned long)(rx_buf_in - rx_buf_out) >= sizeof(wifi_uart_rx_buf)))
 48 |     {
 49 |         //UART receive buffer is full
 50 |         return TY_ERROR;
 51 |     }
 52 |     else
 53 |     {
 54 |         //UART receive buffer is not full
 55 |         if (rx_buf_in >= (unsigned char *)(wifi_uart_rx_buf + sizeof(wifi_uart_rx_buf)))
 56 |         {
 57 |             rx_buf_in = (unsigned char *)(wifi_uart_rx_buf);
 58 |         }
 59 |
 60 |         *rx_buf_in++ = data;
 61 |     }
 62 |     return TY_SUCCESS;
 63 | }
 64 |
 65 | void TuyaUart::uart_receive_buff_input(unsigned char value[], unsigned short data_len)
 66 | {
 67 |     unsigned short i = 0;
 68 |     for (i = 0; i < data_len; i++)
 69 |     {
 70 |         uart_receive_input(value[i]);
 71 |     }
 72 | }
 73 |
 74 | unsigned char TuyaUart::take_byte_rxbuff(void)
 75 | {
 76 |     unsigned char date = 0;
 77 |
 78 |     if (rx_buf_out != rx_buf_in)
 79 |     {
 80 |         //With data
 81 |         if (rx_buf_out >= (unsigned char *)(wifi_uart_rx_buf + sizeof(wifi_uart_rx_buf)))
 82 |         {
 83 |             //The data has reached the end
 84 |             rx_buf_out = (unsigned char *)(wifi_uart_rx_buf);
 85 |         }
 86 |
 87 |         date = *rx_buf_out++;
 88 |     }
 89 |
 90 |     return date;
 91 | }
 92 |
 93 | unsigned char TuyaUart::with_data_rxbuff(void)
 94 | {
 95 |     if (rx_buf_in != rx_buf_out)
 96 |         return 1;
 97 |     else
 98 |         return 0;
 99 | }
100 |
101 | void TuyaUart::wifi_uart_write_data(unsigned char *in, unsigned short len)
102 | {
103 |     if ((TY_NULL == in) || (0 == len))
104 |     {
105 |         return;
106 |     }
107 |
108 |     while (len--)
109 |     {
110 |         uart_transmit_output(*in);
111 |         in++;
112 |     }
113 | }
114 |
115 | void TuyaUart::wifi_uart_write_frame(unsigned char fr_type, unsigned char fr_ver, unsigned short len)
116 | {
117 |     unsigned char check_sum = 0;
118 |
119 |     wifi_uart_tx_buf[HEAD_FIRST] = 0x55;
120 |     wifi_uart_tx_buf[HEAD_SECOND] = 0xaa;
121 |     wifi_uart_tx_buf[PROTOCOL_VERSION] = fr_ver;
122 |     wifi_uart_tx_buf[FRAME_TYPE] = fr_type;
123 |     wifi_uart_tx_buf[LENGTH_HIGH] = len >> 8;
124 |     wifi_uart_tx_buf[LENGTH_LOW] = len & 0xff;
125 |
126 |     len += PROTOCOL_HEAD;
127 |     check_sum = tuya_tools.get_check_sum((unsigned char *)wifi_uart_tx_buf, len - 1);
128 |     wifi_uart_tx_buf[len - 1] = check_sum;
129 |
130 |     wifi_uart_write_data((unsigned char *)wifi_uart_tx_buf, len);
131 | }
132 |
133 | unsigned short TuyaUart::set_wifi_uart_byte(unsigned short dest, unsigned char byte)
134 | {
135 |     unsigned char *obj = (unsigned char *)wifi_uart_tx_buf + DATA_START + dest;
136 |
137 |     *obj = byte;
138 |     dest += 1;
139 |
140 |     return dest;
141 | }
142 |
143 | unsigned short TuyaUart::set_wifi_uart_buffer(unsigned short dest, const unsigned char *src, unsigned short len)
144 | {
145 |     unsigned char *obj = (unsigned char *)wifi_uart_tx_buf + DATA_START + dest;
146 |
147 |     tuya_tools.my_memcpy(obj, src, len);
148 |
149 |     dest += len;
150 |     return dest;
151 | }
152 |
153 | void TuyaUart::set_serial(TY_UART *serial)
154 | {
155 |     _serial_port = serial;
156 | }
157 |
158 | void TuyaUart::begin(unsigned long baud_rate)
159 | {
160 |     _serial_port->begin(baud_rate);
161 | }
162 |
163 | int TuyaUart::read(void)
164 | {
165 |     return _serial_port->read();
166 | }
167 |
168 | size_t TuyaUart::write(uint8_t c)
169 | {
170 |     return _serial_port->write(c);
171 | }
172 |
173 | int TuyaUart::available(void)
174 | {
175 |     return _serial_port->available();
176 | }
177 |


--------------------------------------------------------------------------------
/src/TuyaUart.h:
--------------------------------------------------------------------------------
 1 | /*
 2 |  * @FileName: TuyaUart.h
 3 |  * @Author: Tuya
 4 |  * @Email:
 5 |  * @LastEditors: Tuya
 6 |  * @Date: 2021-04-15 17:56:56
 7 |  * @LastEditTime: 2021-04-28 19:50:07
 8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
 9 |  * @Company: http://www.tuya.com
10 |  * @Description:
11 |  */
12 | #ifndef __TUYA_UART_H__
13 | #define __TUYA_UART_H__
14 |
15 | #include <Arduino.h>
16 |
17 | #include "../config.h"
18 | #include "TuyaDefs.h"
19 |
20 | #include <HardwareSerial.h>
21 | #undef TY_UART
22 | #define TY_UART HardwareSerial
23 |
24 | class TuyaUart
25 | {
26 | public:
27 |     unsigned char wifi_uart_rx_buf[PROTOCOL_HEAD + WIFI_UART_RECV_BUF_LMT];     //Serial data processing buffer
28 |     unsigned char wifi_uart_tx_buf[PROTOCOL_HEAD + WIFIR_UART_SEND_BUF_LMT];    //Serial receive buffer
29 |     unsigned char wifi_data_process_buf[PROTOCOL_HEAD + WIFI_DATA_PROCESS_LMT]; //Serial port send buffer
30 |
31 |     TuyaUart(void);
32 |     ~TuyaUart(void);
33 |     void wifi_protocol_init(void);
34 |
35 |     unsigned char uart_receive_input(unsigned char data);
36 |     void uart_receive_buff_input(unsigned char value[], unsigned short data_len);
37 |     unsigned char take_byte_rxbuff(void);
38 |     unsigned char with_data_rxbuff(void);
39 |
40 |     void uart_transmit_output(unsigned char value);
41 |     void wifi_uart_write_data(unsigned char *in, unsigned short len);
42 |     void wifi_uart_write_frame(unsigned char fr_type, unsigned char fr_ver, unsigned short len);
43 |     unsigned short set_wifi_uart_byte(unsigned short dest, unsigned char byte);
44 |     unsigned short set_wifi_uart_buffer(unsigned short dest, const unsigned char *src, unsigned short len);
45 |
46 |     void set_serial(TY_UART *serial);
47 |     void begin(unsigned long baud_rate);
48 |     int read(void);
49 |     size_t write(uint8_t c);
50 |     int available(void);
51 |
52 | private:
53 |     volatile unsigned char *rx_buf_in;
54 |     volatile unsigned char *rx_buf_out;
55 |     TY_UART *_serial_port;
56 | };
57 |
58 | #endif /* __TUYA_UART_H__ */
59 |


--------------------------------------------------------------------------------
/src/TuyaWifi.cpp:
--------------------------------------------------------------------------------
   1 | /*
   2 |  * @FileName: Tuya.cpp
   3 |  * @Author: Tuya
   4 |  * @Email:
   5 |  * @LastEditors: shiliu
   6 |  * @Date: 2021-04-10 11:25:17
   7 |  * @LastEditTime: 2021-11-04 13:58:06
   8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
   9 |  * @Company: http://www.tuya.com
  10 |  * @Description: The functions that the user needs to actively call are in this file.
  11 |  */
  12 |
  13 | #define TUYA_GLOBAL
  14 |
  15 | #include <TuyaWifi.h>
  16 | #include "TuyaTools.h"
  17 | #include "TuyaDataPoint.h"
  18 |
  19 | TuyaTools tuya_tools;
  20 | TuyaUart tuya_uart;
  21 | TuyaDataPoint tuya_dp;
  22 | TuyaExtras tuya_extras;
  23 |
  24 | /* Constants required to report product information */
  25 | /* Here "key" means key-value */
  26 | static unsigned char pid_key[] = {"{\"p\":\""};
  27 | static unsigned char mcu_ver_key[] = {"\",\"v\":\""};
  28 | static unsigned char mode_key[] = {"\",\"m\":"};
  29 | static unsigned char product_info_end[] = {"}"};
  30 |
  31 | /* Protocol serial port initialization */
  32 | TuyaWifi::TuyaWifi(void)
  33 | {
  34 |     tuya_uart.set_serial(&Serial);
  35 |
  36 | #if WIFI_CONTROL_SELF_MODE
  37 |     /* nothing to do here */
  38 | #else
  39 |     wifi_work_state = WIFI_SATE_UNKNOW;
  40 | #endif
  41 | }
  42 |
  43 | TuyaWifi::TuyaWifi(TY_UART *serial)
  44 | {
  45 |     tuya_uart.set_serial(serial);
  46 | }
  47 |
  48 | /**
  49 |  * @description: Initialize product information
  50 |  * @param {unsigned char} *pid : Product ID(Create products on the Tuya IoT platform to get)
  51 |  * @param {unsigned char} *mcu_ver : MCU Software Version Number
  52 |  * @return {*}
  53 |  */
  54 | unsigned char TuyaWifi::init(unsigned char *pid, unsigned char *mcu_ver)
  55 | {
  56 |     if (pid == TY_NULL || mcu_ver == TY_NULL)
  57 |     {
  58 |         return TY_ERROR;
  59 |     }
  60 |
  61 |     if (tuya_tools.my_strlen(pid) <= PID_LEN)
  62 |     {
  63 |         tuya_tools.my_memcpy(product_id, pid, tuya_tools.my_strlen(pid));
  64 |     }
  65 |     else
  66 |     {
  67 |         tuya_tools.my_memcpy(product_id, pid, PID_LEN);
  68 |         return TY_ERROR;
  69 |     }
  70 |
  71 |     if (tuya_tools.my_strlen(mcu_ver) <= VER_LEN)
  72 |     {
  73 |         tuya_tools.my_memcpy(mcu_ver_value, mcu_ver, tuya_tools.my_strlen(mcu_ver));
  74 |     }
  75 |     else
  76 |     {
  77 |         tuya_tools.my_memcpy(mcu_ver_value, mcu_ver, VER_LEN);
  78 |         return TY_ERROR;
  79 |     }
  80 |
  81 |     return TY_SUCCESS;
  82 | }
  83 |
  84 | /**
  85 |  * @description: Wifi serial port processing service
  86 |  * @param {*}
  87 |  * @return {*}
  88 |  */
  89 | void TuyaWifi::uart_service(void)
  90 | {
  91 |     unsigned char ret;
  92 |     static unsigned short rx_in = 0;
  93 |     unsigned short offset = 0;
  94 |     unsigned short rx_value_len = 0;
  95 |
  96 |     /* extract serial data */
  97 |     while(tuya_uart.available()) {
  98 |         ret = tuya_uart.uart_receive_input(tuya_uart.read());
  99 |         if (ret != TY_SUCCESS) {
 100 |             break;
 101 |         }
 102 |     }
 103 |
 104 |     while ((rx_in < sizeof(tuya_uart.wifi_data_process_buf)) && tuya_uart.with_data_rxbuff() > 0)
 105 |     {
 106 |         tuya_uart.wifi_data_process_buf[rx_in++] = tuya_uart.take_byte_rxbuff();
 107 |     }
 108 |
 109 |     if (rx_in < PROTOCOL_HEAD)
 110 |         return;
 111 |
 112 |     while ((rx_in - offset) >= PROTOCOL_HEAD)
 113 |     {
 114 |         if (tuya_uart.wifi_data_process_buf[offset + HEAD_FIRST] != FRAME_FIRST)
 115 |         {
 116 |             offset++;
 117 |             continue;
 118 |         }
 119 |
 120 |         if (tuya_uart.wifi_data_process_buf[offset + HEAD_SECOND] != FRAME_SECOND)
 121 |         {
 122 |             offset++;
 123 |             continue;
 124 |         }
 125 |
 126 |         if (tuya_uart.wifi_data_process_buf[offset + PROTOCOL_VERSION] != MCU_RX_VER)
 127 |         {
 128 |             offset += 2;
 129 |             continue;
 130 |         }
 131 |
 132 |         rx_value_len = tuya_uart.wifi_data_process_buf[offset + LENGTH_HIGH] * 0x100;
 133 |         rx_value_len += (tuya_uart.wifi_data_process_buf[offset + LENGTH_LOW] + PROTOCOL_HEAD);
 134 |         if (rx_value_len > sizeof(tuya_uart.wifi_data_process_buf) + PROTOCOL_HEAD)
 135 |         {
 136 |             offset += 3;
 137 |             continue;
 138 |         }
 139 |
 140 |         if ((rx_in - offset) < rx_value_len)
 141 |         {
 142 |             break;
 143 |         }
 144 |
 145 |         //data receive finish
 146 |         if (tuya_tools.get_check_sum((unsigned char *)tuya_uart.wifi_data_process_buf + offset, rx_value_len - 1) != tuya_uart.wifi_data_process_buf[offset + rx_value_len - 1])
 147 |         {
 148 |             //check error
 149 |             offset += 3;
 150 |             continue;
 151 |         }
 152 |
 153 |         data_handle(offset);
 154 |         offset += rx_value_len;
 155 |     } //end while
 156 |
 157 |     rx_in -= offset;
 158 |     if (rx_in > 0)
 159 |     {
 160 |         tuya_tools.my_memcpy((char *)tuya_uart.wifi_data_process_buf, (const char *)tuya_uart.wifi_data_process_buf + offset, rx_in);
 161 |     }
 162 |
 163 | }
 164 |
 165 | /**
 166 |  * @description: Data frame processing
 167 |  * @param {unsigned short} offset : Data start position
 168 |  * @return {*}
 169 |  */
 170 | void TuyaWifi::data_handle(unsigned short offset)
 171 | {
 172 | #ifdef SUPPORT_MCU_FIRM_UPDATE
 173 |     unsigned char *firmware_addr = TY_NULL;
 174 |     static unsigned short firm_size;           //Upgrade package size
 175 |     static unsigned long firm_length;          //MCU upgrade file length
 176 |     static unsigned char firm_update_flag = 0; //MCU upgrade flag
 177 |     unsigned long dp_len;
 178 |     unsigned char firm_flag; //Upgrade package size flag
 179 | #else
 180 |     unsigned short dp_len;
 181 | #endif
 182 |
 183 |     unsigned char ret;
 184 |     unsigned short i, total_len;
 185 |     unsigned char cmd_type = tuya_uart.wifi_data_process_buf[offset + FRAME_TYPE];
 186 |
 187 | #if ((defined VOICE_MODULE_PROTOCOL_ENABLE) || (defined BLE_RELATED_FUNCTION_ENABLE) || (defined MODULE_EXPANDING_SERVICE_ENABLE) || \
 188 |     (defined IR_TX_RX_TEST_ENABLE) || (defined GET_IR_STATUS_ENABLE) || (defined MCU_DP_UPLOAD_SYN) || (defined GET_WIFI_STATUS_ENABLE) || \
 189 |     (defined WIFI_CONNECT_TEST_ENABLE) || (defined WIFI_STREAM_ENABLE) || (defined WIFI_TEST_ENABLE))
 190 |     unsigned char result;
 191 | #endif
 192 |
 193 | #ifdef WEATHER_ENABLE
 194 |     static unsigned char isWoSend = 0; //Whether the weather data has been opened, 0:no  1:yes
 195 | #endif
 196 |
 197 | #ifdef WIFI_TEST_ENABLE
 198 |     unsigned char rssi;
 199 | #endif
 200 |
 201 | #ifdef FILE_DOWNLOAD_ENABLE
 202 |     unsigned char *file_data_addr = TY_NULL;
 203 |     static unsigned short file_package_size = 0; //File packet size
 204 |     static unsigned char file_download_flag = 0; //File download flag
 205 |     unsigned int file_download_size = 0;
 206 | #endif
 207 |
 208 |     switch (cmd_type)
 209 |     {
 210 |     case HEAT_BEAT_CMD: //Heartbeat package
 211 |         heat_beat_check();
 212 |         break;
 213 |
 214 |     case PRODUCT_INFO_CMD: //Product information
 215 |         product_info_update();
 216 |         break;
 217 |
 218 |     case WORK_MODE_CMD: //Query the module working mode set by the MCU
 219 |         get_mcu_wifi_mode();
 220 |         break;
 221 |
 222 | #if WIFI_CONTROL_SELF_MODE
 223 |     /* nothing to do here */
 224 | #else
 225 |     case WIFI_STATE_CMD: //Wifi working status
 226 |         wifi_work_state = tuya_uart.wifi_data_process_buf[offset + DATA_START];
 227 |         tuya_uart.wifi_uart_write_frame(WIFI_STATE_CMD, MCU_TX_VER, 0);
 228 | #ifdef WEATHER_ENABLE
 229 |         if (wifi_work_state == WIFI_CONNECTED && isWoSend == 0) //When the WIFI connection is successful, open the weather data only once
 230 |         {
 231 |             mcu_open_weather();
 232 |             isWoSend = 1;
 233 |         }
 234 | #endif
 235 |         break;
 236 |
 237 |     case WIFI_RESET_CMD: //Reset wifi
 238 |         reset_wifi_flag = RESET_WIFI_SUCCESS;
 239 |         break;
 240 |
 241 |     case WIFI_MODE_CMD: //Select smartconfig/AP mode
 242 |         set_wifimode_flag = SET_WIFICONFIG_SUCCESS;
 243 |         break;
 244 | #endif
 245 |
 246 |     case DATA_QUERT_CMD: //Order send
 247 |         total_len = (tuya_uart.wifi_data_process_buf[offset + LENGTH_HIGH] << 8) | tuya_uart.wifi_data_process_buf[offset + LENGTH_LOW];
 248 |
 249 |         for (i = 0; i < total_len;)
 250 |         {
 251 |             dp_len = tuya_uart.wifi_data_process_buf[offset + DATA_START + i + 2] * 0x100;
 252 |             dp_len += tuya_uart.wifi_data_process_buf[offset + DATA_START + i + 3];
 253 |             //
 254 |             ret = data_point_handle((unsigned char *)tuya_uart.wifi_data_process_buf + offset + DATA_START + i);
 255 |
 256 |             if (TY_SUCCESS == ret)
 257 |             {
 258 |                 //Send success
 259 |             }
 260 |             else
 261 |             {
 262 |                 //Send fault
 263 |             }
 264 |
 265 |             i += (dp_len + 4);
 266 |         }
 267 |         break;
 268 |
 269 |     case STATE_QUERY_CMD: //Status query
 270 |         all_data_update();
 271 |         break;
 272 |
 273 | #ifdef SUPPORT_MCU_FIRM_UPDATE
 274 |     case UPDATE_START_CMD: //Upgrade start
 275 |         //Get global variable of upgrade package size
 276 |         firm_flag = PACKAGE_SIZE;
 277 |         if (firm_flag == 0)
 278 |         {
 279 |             firm_size = 256;
 280 |         }
 281 |         else if (firm_flag == 1)
 282 |         {
 283 |             firm_size = 512;
 284 |         }
 285 |         else if (firm_flag == 2)
 286 |         {
 287 |             firm_size = 1024;
 288 |         }
 289 |
 290 |         firm_length = wifi_data_process_buf[offset + DATA_START];
 291 |         firm_length <<= 8;
 292 |         firm_length |= wifi_data_process_buf[offset + DATA_START + 1];
 293 |         firm_length <<= 8;
 294 |         firm_length |= wifi_data_process_buf[offset + DATA_START + 2];
 295 |         firm_length <<= 8;
 296 |         firm_length |= wifi_data_process_buf[offset + DATA_START + 3];
 297 |
 298 |         upgrade_package_choose(PACKAGE_SIZE);
 299 |         firm_update_flag = UPDATE_START_CMD;
 300 |         break;
 301 |
 302 |     case UPDATE_TRANS_CMD: //Upgrade transfer
 303 |         if (firm_update_flag == UPDATE_START_CMD)
 304 |         {
 305 |             //Stop all data reporting
 306 |             stop_update_flag = TY_ENABLE;
 307 |
 308 |             total_len = (wifi_data_process_buf[offset + LENGTH_HIGH] << 8) | wifi_data_process_buf[offset + LENGTH_LOW];
 309 |
 310 |             dp_len = wifi_data_process_buf[offset + DATA_START];
 311 |             dp_len <<= 8;
 312 |             dp_len |= wifi_data_process_buf[offset + DATA_START + 1];
 313 |             dp_len <<= 8;
 314 |             dp_len |= wifi_data_process_buf[offset + DATA_START + 2];
 315 |             dp_len <<= 8;
 316 |             dp_len |= wifi_data_process_buf[offset + DATA_START + 3];
 317 |
 318 |             firmware_addr = (unsigned char *)wifi_data_process_buf;
 319 |             firmware_addr += (offset + DATA_START + 4);
 320 |
 321 |             if ((total_len == 4) && (dp_len == firm_length))
 322 |             {
 323 |                 //Last pack
 324 |                 ret = mcu_firm_update_handle(firmware_addr, dp_len, 0);
 325 |                 firm_update_flag = 0;
 326 |             }
 327 |             else if ((total_len - 4) <= firm_size)
 328 |             {
 329 |                 ret = mcu_firm_update_handle(firmware_addr, dp_len, total_len - 4);
 330 |             }
 331 |             else
 332 |             {
 333 |                 firm_update_flag = 0;
 334 |                 ret = TY_ERROR;
 335 |             }
 336 |
 337 |             if (ret == TY_SUCCESS)
 338 |             {
 339 |                 wifi_uart_write_frame(UPDATE_TRANS_CMD, MCU_TX_VER, 0);
 340 |             }
 341 |             //Restore all data reported
 342 |             stop_update_flag = TY_DISABLE;
 343 |         }
 344 |         break;
 345 | #endif
 346 |
 347 | #if SUPPORT_GREEN_TIME
 348 |     case GET_ONLINE_TIME_CMD: //Get system time (Greenwich Mean Time)
 349 |         tuya_extras.mcu_get_green_time((unsigned char *)(tuya_uart.wifi_data_process_buf + offset + DATA_START), &_green_time);
 350 |         break;
 351 | #endif
 352 |
 353 | #if SUPPORT_RTC_TIME
 354 |     case GET_LOCAL_TIME_CMD: //Get local time
 355 |         tuya_extras.mcu_get_rtc_time((unsigned char *)(tuya_uart.wifi_data_process_buf + offset + DATA_START), &_rtc_time);
 356 |         break;
 357 | #endif
 358 |
 359 | #ifdef WIFI_TEST_ENABLE
 360 |     case WIFI_TEST_CMD: //Wifi function test
 361 |         result = wifi_data_process_buf[offset + DATA_START];
 362 |         rssi = wifi_data_process_buf[offset + DATA_START + 1];
 363 |         wifi_test_result(result, rssi);
 364 |         break;
 365 | #endif
 366 |
 367 | #ifdef WEATHER_ENABLE
 368 |     case WEATHER_OPEN_CMD: //Turn on the weather
 369 |         weather_open_return_handle(wifi_data_process_buf[offset + DATA_START], wifi_data_process_buf[offset + DATA_START + 1]);
 370 |         break;
 371 |
 372 |     case WEATHER_DATA_CMD: //Weather data
 373 |         total_len = (wifi_data_process_buf[offset + LENGTH_HIGH] << 8) | wifi_data_process_buf[offset + LENGTH_LOW];
 374 |         weather_data_raw_handle((unsigned char *)wifi_data_process_buf + offset + DATA_START, total_len);
 375 |         break;
 376 | #endif
 377 |
 378 | #ifdef WIFI_STREAM_ENABLE
 379 |     case STREAM_TRANS_CMD:                                          //Stream data transmission
 380 |         stream_status = wifi_data_process_buf[offset + DATA_START]; //Service transmission back to reception
 381 |         stream_trans_send_result(stream_status);
 382 |         break;
 383 |
 384 |     case MAPS_STREAM_TRANS_CMD:                                          //streams trans(Support for multiple maps)
 385 |         maps_stream_status = wifi_data_process_buf[offset + DATA_START]; //Service transmission back to reception
 386 |         maps_stream_trans_send_result(maps_stream_status);
 387 |         break;
 388 | #endif
 389 |
 390 | #ifdef WIFI_CONNECT_TEST_ENABLE
 391 |     case WIFI_CONNECT_TEST_CMD: //Wifi function test(connection designated route)
 392 |         result = wifi_data_process_buf[offset + DATA_START];
 393 |         wifi_connect_test_result(result);
 394 |         break;
 395 | #endif
 396 |
 397 | #ifdef GET_MODULE_MAC_ENABLE
 398 |     case GET_MAC_CMD: //Get module mac
 399 |         mcu_get_mac((unsigned char *)(wifi_data_process_buf + offset + DATA_START));
 400 |         break;
 401 | #endif
 402 |
 403 | #ifdef GET_WIFI_STATUS_ENABLE
 404 |     case GET_WIFI_STATUS_CMD: //Gets the wifi networking status
 405 |         result = wifi_data_process_buf[offset + DATA_START];
 406 |         get_wifi_status(result);
 407 |         break;
 408 | #endif
 409 |
 410 | #ifdef MCU_DP_UPLOAD_SYN
 411 |     case STATE_UPLOAD_SYN_RECV_CMD: //Status upload results(synchronization)
 412 |         result = wifi_data_process_buf[offset + DATA_START];
 413 |         get_upload_syn_result(result);
 414 |         break;
 415 | #endif
 416 |
 417 | #ifdef GET_IR_STATUS_ENABLE
 418 |     case GET_IR_STATUS_CMD: //IR status notification
 419 |         result = wifi_data_process_buf[offset + DATA_START];
 420 |         get_ir_status(result);
 421 |         break;
 422 | #endif
 423 |
 424 | #ifdef IR_TX_RX_TEST_ENABLE
 425 |     case IR_TX_RX_TEST_CMD: //IR into send-receive test
 426 |         result = wifi_data_process_buf[offset + DATA_START];
 427 |         ir_tx_rx_test_result(result);
 428 |         break;
 429 | #endif
 430 |
 431 | #ifdef FILE_DOWNLOAD_ENABLE
 432 |     case FILE_DOWNLOAD_START_CMD: //File download startup
 433 |         //Get file package size selection
 434 |         if (FILE_DOWNLOAD_PACKAGE_SIZE == 0)
 435 |         {
 436 |             file_package_size = 256;
 437 |         }
 438 |         else if (FILE_DOWNLOAD_PACKAGE_SIZE == 1)
 439 |         {
 440 |             file_package_size = 512;
 441 |         }
 442 |         else if (FILE_DOWNLOAD_PACKAGE_SIZE == 2)
 443 |         {
 444 |             file_package_size = 1024;
 445 |         }
 446 |
 447 |         file_download_size = wifi_data_process_buf[offset + DATA_START];
 448 |         file_download_size = (file_download_size << 8) | wifi_data_process_buf[offset + DATA_START + 1];
 449 |         file_download_size = (file_download_size << 8) | wifi_data_process_buf[offset + DATA_START + 2];
 450 |         file_download_size = (file_download_size << 8) | wifi_data_process_buf[offset + DATA_START + 3];
 451 |
 452 |         file_download_package_choose(FILE_DOWNLOAD_PACKAGE_SIZE);
 453 |         file_download_flag = FILE_DOWNLOAD_START_CMD;
 454 |         break;
 455 |
 456 |     case FILE_DOWNLOAD_TRANS_CMD: //File download data transfer
 457 |         if (file_download_flag == FILE_DOWNLOAD_START_CMD)
 458 |         {
 459 |             total_len = (wifi_data_process_buf[offset + LENGTH_HIGH] << 8) | wifi_data_process_buf[offset + LENGTH_LOW];
 460 |
 461 |             dp_len = wifi_data_process_buf[offset + DATA_START];
 462 |             dp_len <<= 8;
 463 |             dp_len |= wifi_data_process_buf[offset + DATA_START + 1];
 464 |             dp_len <<= 8;
 465 |             dp_len |= wifi_data_process_buf[offset + DATA_START + 2];
 466 |             dp_len <<= 8;
 467 |             dp_len |= wifi_data_process_buf[offset + DATA_START + 3];
 468 |
 469 |             file_data_addr = (unsigned char *)wifi_data_process_buf;
 470 |             file_data_addr += (offset + DATA_START + 4);
 471 |
 472 |             if ((total_len == 4) && (dp_len == file_download_size))
 473 |             {
 474 |                 //Last pack
 475 |                 ret = file_download_handle(file_data_addr, dp_len, 0);
 476 |                 file_download_flag = 0;
 477 |             }
 478 |             else if ((total_len - 4) <= file_package_size)
 479 |             {
 480 |                 ret = file_download_handle(file_data_addr, dp_len, total_len - 4);
 481 |             }
 482 |             else
 483 |             {
 484 |                 file_download_flag = 0;
 485 |                 ret = TY_ERROR;
 486 |             }
 487 |
 488 |             if (ret == TY_SUCCESS)
 489 |             {
 490 |                 wifi_uart_write_frame(FILE_DOWNLOAD_TRANS_CMD, MCU_TX_VER, 0);
 491 |             }
 492 |         }
 493 |         break;
 494 | #endif
 495 |
 496 | #ifdef MODULE_EXPANDING_SERVICE_ENABLE
 497 |     case MODULE_EXTEND_FUN_CMD: //Module expansion service
 498 |         total_len = (wifi_data_process_buf[offset + LENGTH_HIGH] << 8) | wifi_data_process_buf[offset + LENGTH_LOW];
 499 |         open_module_time_serve_result((unsigned char *)(wifi_data_process_buf + offset + DATA_START), total_len);
 500 |         break;
 501 | #endif
 502 |
 503 | #ifdef BLE_RELATED_FUNCTION_ENABLE
 504 |     case BLE_TEST_CMD: //Bluetooth functional test（Scan designated bluetooth beacon）
 505 |         total_len = (wifi_data_process_buf[offset + LENGTH_HIGH] << 8) | wifi_data_process_buf[offset + LENGTH_LOW];
 506 |         BLE_test_result((unsigned char *)(wifi_data_process_buf + offset + DATA_START), total_len);
 507 |         break;
 508 | #endif
 509 |
 510 | #ifdef VOICE_MODULE_PROTOCOL_ENABLE
 511 |     case GET_VOICE_STATE_CMD: //Gets the voice status code
 512 |         result = wifi_data_process_buf[offset + DATA_START];
 513 |         get_voice_state_result(result);
 514 |         break;
 515 |     case MIC_SILENCE_CMD: //MIC mute Settings
 516 |         result = wifi_data_process_buf[offset + DATA_START];
 517 |         set_voice_MIC_silence_result(result);
 518 |         break;
 519 |     case SET_SPEAKER_VOLUME_CMD: //speaker volume set
 520 |         result = wifi_data_process_buf[offset + DATA_START];
 521 |         set_speaker_voice_result(result);
 522 |         break;
 523 |     case VOICE_TEST_CMD: //Audio production test
 524 |         result = wifi_data_process_buf[offset + DATA_START];
 525 |         voice_test_result(result);
 526 |         break;
 527 |     case VOICE_AWAKEN_TEST_CMD: //Wake up production test
 528 |         result = wifi_data_process_buf[offset + DATA_START];
 529 |         voice_awaken_test_result(result);
 530 |         break;
 531 |     case VOICE_EXTEND_FUN_CMD: //Voice module extension function
 532 |         total_len = (wifi_data_process_buf[offset + LENGTH_HIGH] << 8) | wifi_data_process_buf[offset + LENGTH_LOW];
 533 |         voice_module_extend_fun((unsigned char *)(wifi_data_process_buf + offset + DATA_START), total_len);
 534 |         break;
 535 | #endif
 536 |
 537 |     default:
 538 |         break;
 539 |     }
 540 | }
 541 |
 542 |
 543 | /**
 544 |  * @description: Input product All DP ID, Type, total number of DPs
 545 |  * @param {unsigned char} dp_cmd_array : DP array. array[][0] : DP ID,
 546 |  *                                                 array[][1] : DP Type(DP_TYPE_RAW, DP_TYPE_BOOL, DP_TYPE_VALUE, DP_TYPE_STRING, DP_TYPE_ENUM, DP_TYPE_BITMAP)
 547 |  * @param {unsigned char} dp_cmd_num : total number of DPs
 548 |  * @return {*}
 549 |  */
 550 | void TuyaWifi::set_dp_cmd_total(unsigned char dp_cmd_array[][2], unsigned char dp_cmd_num)
 551 | {
 552 |     download_dp_number = dp_cmd_num;
 553 |     download_cmd = dp_cmd_array;
 554 | }
 555 |
 556 | /**
 557 |  * @description: Get the serial number of the DPID in the array.
 558 |  * @param {unsigned char} dpid
 559 |  * @return {unsigned char} index : The index of the input dpid in the array
 560 |  */
 561 | unsigned char TuyaWifi::get_dowmload_dpid_index(unsigned char dpid)
 562 | {
 563 |     unsigned char index;
 564 |
 565 |     for (index = 0; index < download_dp_number; index++)
 566 |     {
 567 |         if (download_cmd[index][0] == dpid)
 568 |         {
 569 |             break;
 570 |         }
 571 |     }
 572 |     return index;
 573 | }
 574 |
 575 | /**
 576 |  * @description: Delivery data processing
 577 |  * @param {const unsigned char} value : Send data source pointer
 578 |  * @return Return data processing result
 579 |  */
 580 | unsigned char TuyaWifi::data_point_handle(const unsigned char value[])
 581 | {
 582 |     unsigned char dp_id, index;
 583 |     unsigned char dp_type;
 584 |     unsigned char ret;
 585 |     unsigned short dp_len;
 586 |
 587 |     dp_id = value[0];
 588 |     dp_type = value[1];
 589 |     dp_len = value[2] * 0x100;
 590 |     dp_len += value[3];
 591 |
 592 |     index = get_dowmload_dpid_index(dp_id);
 593 |
 594 |     if (dp_type != download_cmd[index][1])
 595 |     {
 596 |         //Error message
 597 |         return TY_FALSE;
 598 |     }
 599 |     else
 600 |     {
 601 |         ret = dp_download_handle(dp_id, value + 4, dp_len);
 602 |     }
 603 |
 604 |     return ret;
 605 | }
 606 |
 607 | /**
 608 |  * @description: DP command processing callback function
 609 |  * @param {tuya_callback_dp_download} _func
 610 |  * @return {*}
 611 |  */
 612 | void TuyaWifi::dp_process_func_register(tuya_callback_dp_download _func)
 613 | {
 614 |     dp_download_handle = _func;
 615 | }
 616 |
 617 | /**
 618 |  * @description: Reply to the current device status callback function
 619 |  * @param {tuya_callback_dp_update_all} _func
 620 |  * @return {*}
 621 |  */
 622 | void TuyaWifi::dp_update_all_func_register(tuya_callback_dp_update_all _func)
 623 | {
 624 |     all_data_update = _func;
 625 | }
 626 |
 627 | /**
 628 |  * @description: Heartbeat packet detection
 629 |  * @param {*}
 630 |  * @return {*}
 631 |  */
 632 | void TuyaWifi::heat_beat_check(void)
 633 | {
 634 |     unsigned char length = 0;
 635 |     static unsigned char mcu_reset_state = TY_FALSE;
 636 |
 637 |     if (TY_FALSE == mcu_reset_state)
 638 |     {
 639 |         length = tuya_uart.set_wifi_uart_byte(length, TY_FALSE);
 640 |         mcu_reset_state = TY_TRUE;
 641 |     }
 642 |     else
 643 |     {
 644 |         length = tuya_uart.set_wifi_uart_byte(length, TY_TRUE);
 645 |     }
 646 |
 647 |     tuya_uart.wifi_uart_write_frame(HEAT_BEAT_CMD, MCU_TX_VER, length);
 648 | }
 649 |
 650 | /**
 651 |  * @description: Product information upload
 652 |  * @param {*}
 653 |  * @return {*}
 654 |  */
 655 | void TuyaWifi::product_info_update(void)
 656 | {
 657 |     unsigned char length = 0;
 658 |
 659 | #if ((defined CONFIG_MODE_DELAY_TIME) || (defined CONFIG_MODE_CHOOSE) || (defined ENABLE_MODULE_IR_FUN) || (defined LONG_CONN_LOWPOWER))
 660 |     unsigned char str[10] = {0};
 661 | #endif
 662 |
 663 |     length = tuya_uart.set_wifi_uart_buffer(length, pid_key, (unsigned short)(tuya_tools.my_strlen(pid_key)));
 664 |     length = tuya_uart.set_wifi_uart_buffer(length, product_id, PID_LEN);
 665 |     length = tuya_uart.set_wifi_uart_buffer(length, mcu_ver_key, (unsigned short)(tuya_tools.my_strlen(mcu_ver_key)));
 666 |     length = tuya_uart.set_wifi_uart_buffer(length, mcu_ver_value, VER_LEN);
 667 |     length = tuya_uart.set_wifi_uart_buffer(length, mode_key, (unsigned short)(tuya_tools.my_strlen(mode_key)));
 668 |     length = tuya_uart.set_wifi_uart_buffer(length, (const unsigned char *)CONFIG_MODE, (unsigned short)(tuya_tools.my_strlen((unsigned char *)CONFIG_MODE)));
 669 |
 670 | #ifdef CONFIG_MODE_DELAY_TIME
 671 |     sprintf((char *)str, ",\"mt\":%d", CONFIG_MODE_DELAY_TIME);
 672 |     length = tuya_uart.set_wifi_uart_buffer(length, str, tuya_tools.my_strlen(str));
 673 | #endif
 674 | #ifdef CONFIG_MODE_CHOOSE
 675 |     sprintf((char *)str, ",\"n\":%d", CONFIG_MODE_CHOOSE);
 676 |     length = tuya_uart.set_wifi_uart_buffer(length, str, tuya_tools.my_strlen(str));
 677 | #endif
 678 | #ifdef ENABLE_MODULE_IR_FUN
 679 |     sprintf((char *)str, ",\"ir\":\"%d.%d\"", MODULE_IR_PIN_TX, MODULE_IR_PIN_RX);
 680 |     length = tuya_uart.set_wifi_uart_buffer(length, str, tuya_tools.my_strlen(str));
 681 | #endif
 682 | #ifdef LONG_CONN_LOWPOWER
 683 |     sprintf((char *)str, ",\"low\":%d", LONG_CONN_LOWPOWER);
 684 |     length = tuya_uart.set_wifi_uart_buffer(length, str, tuya_tools.my_strlen(str));
 685 | #endif
 686 |
 687 |     length = tuya_uart.set_wifi_uart_buffer(length, product_info_end, tuya_tools.my_strlen(product_info_end));
 688 |
 689 |     tuya_uart.wifi_uart_write_frame(PRODUCT_INFO_CMD, MCU_TX_VER, length);
 690 | }
 691 |
 692 | /**
 693 |  * @description: Query the working mode of mcu and wifi
 694 |  * @param {*}
 695 |  * @return {*}
 696 |  */
 697 | void TuyaWifi::get_mcu_wifi_mode(void)
 698 | {
 699 |     unsigned char length = 0;
 700 |
 701 | #if WIFI_CONTROL_SELF_MODE //Module self-processing
 702 |     length = tuya_uart.set_wifi_uart_byte(length, wifi_state_led);
 703 |     length = tuya_uart.set_wifi_uart_byte(length, wifi_reset_key);
 704 | #else
 705 |     //No need to process data
 706 | #endif
 707 |
 708 |     tuya_uart.wifi_uart_write_frame(WORK_MODE_CMD, MCU_TX_VER, length);
 709 | }
 710 |
 711 | /**
 712 |  * @description: mcu gets bool,value,enum type to send dp value. (raw, string type needs to be handled at the user's discretion. fault only report)
 713 |  * @param {unsigned char} dpid : data point ID
 714 |  * @param {const unsigned char} value : dp data buffer address
 715 |  * @param {unsigned short} len : data length
 716 |  * @return {unsigned char} Parsed data
 717 |  */
 718 | unsigned long TuyaWifi::mcu_get_dp_download_data(unsigned char dpid, const unsigned char value[], unsigned short len)
 719 | {
 720 |     unsigned long ret = 0;
 721 |     switch (download_cmd[get_dowmload_dpid_index(dpid)][1])
 722 |     {
 723 |     case DP_TYPE_BOOL:
 724 |         ret = tuya_dp.mcu_get_dp_download_bool(value, len);
 725 |         break;
 726 |
 727 |     case DP_TYPE_VALUE:
 728 |         ret = tuya_dp.mcu_get_dp_download_value(value, len);
 729 |         break;
 730 |
 731 |     case DP_TYPE_ENUM:
 732 |         ret = tuya_dp.mcu_get_dp_download_enum(value, len);
 733 |         break;
 734 |
 735 |     default:
 736 |         break;
 737 |     }
 738 |     return ret;
 739 | }
 740 |
 741 | /**
 742 |  * @description: dp data upload
 743 |  * @param {unsigned char} dpid
 744 |  * @param {const unsigned char} value
 745 |  * @param {unsigned short} len
 746 |  * @return {*}
 747 |  */
 748 | unsigned char TuyaWifi::mcu_dp_update(unsigned char dpid, const unsigned char value[], unsigned short len)
 749 | {
 750 |     unsigned char ret = 0;
 751 |     switch (download_cmd[get_dowmload_dpid_index(dpid)][1])
 752 |     {
 753 |         case DP_TYPE_RAW:
 754 |             ret = tuya_dp.mcu_dp_raw_update(dpid, value, len);
 755 |         break;
 756 |
 757 |         case DP_TYPE_BOOL:
 758 |             ret = tuya_dp.mcu_dp_bool_update(dpid, *value);
 759 |         break;
 760 |
 761 |         case DP_TYPE_VALUE:
 762 |             ret = tuya_dp.mcu_dp_value_update(dpid, *value);
 763 |         break;
 764 |
 765 |         case DP_TYPE_STRING:
 766 |             ret = tuya_dp.mcu_dp_string_update(dpid, value, len);
 767 |         break;
 768 |
 769 |         case DP_TYPE_ENUM:
 770 |             ret = tuya_dp.mcu_dp_enum_update(dpid, *value);
 771 |         break;
 772 |
 773 |         case DP_TYPE_BITMAP:
 774 |             ret = tuya_dp.mcu_dp_fault_update(dpid, *value);
 775 |         break;
 776 |
 777 |
 778 |         default:
 779 |             break;
 780 |     }
 781 |     return ret;
 782 | }
 783 |
 784 | unsigned char TuyaWifi::mcu_dp_update(unsigned char dpid, unsigned char value, unsigned short len)
 785 | {
 786 |     unsigned char ret = 0;
 787 |     switch (download_cmd[get_dowmload_dpid_index(dpid)][1])
 788 |     {
 789 |         case DP_TYPE_BOOL:
 790 |             ret = tuya_dp.mcu_dp_bool_update(dpid, value);
 791 |         break;
 792 |
 793 |         case DP_TYPE_ENUM:
 794 |             ret = tuya_dp.mcu_dp_enum_update(dpid, value);
 795 |         break;
 796 |
 797 |         case DP_TYPE_VALUE:
 798 |             ret = tuya_dp.mcu_dp_value_update(dpid, value);
 799 |         break;
 800 |
 801 |         case DP_TYPE_BITMAP:
 802 |             ret = tuya_dp.mcu_dp_fault_update(dpid, value);
 803 |         break;
 804 |
 805 |         default:
 806 |             break;
 807 |     }
 808 |     return ret;
 809 | }
 810 |
 811 | unsigned char TuyaWifi::mcu_dp_update(unsigned char dpid, char value, unsigned short len)
 812 | {
 813 |     unsigned char ret = 0;
 814 |     switch (download_cmd[get_dowmload_dpid_index(dpid)][1])
 815 |     {
 816 |         case DP_TYPE_BOOL:
 817 |             ret = tuya_dp.mcu_dp_bool_update(dpid, value);
 818 |         break;
 819 |
 820 |         case DP_TYPE_ENUM:
 821 |             ret = tuya_dp.mcu_dp_enum_update(dpid, value);
 822 |         break;
 823 |
 824 |         case DP_TYPE_VALUE:
 825 |             ret = tuya_dp.mcu_dp_value_update(dpid, value);
 826 |         break;
 827 |
 828 |         case DP_TYPE_BITMAP:
 829 |             ret = tuya_dp.mcu_dp_fault_update(dpid, value);
 830 |         break;
 831 |
 832 |         default:
 833 |             break;
 834 |     }
 835 |     return ret;
 836 | }
 837 |
 838 | unsigned char TuyaWifi::mcu_dp_update(unsigned char dpid, unsigned long value, unsigned short len)
 839 | {
 840 |     unsigned char ret = 0;
 841 |     switch (download_cmd[get_dowmload_dpid_index(dpid)][1])
 842 |     {
 843 |         case DP_TYPE_BOOL:
 844 |             ret = tuya_dp.mcu_dp_bool_update(dpid, value);
 845 |         break;
 846 |
 847 |         case DP_TYPE_ENUM:
 848 |             ret = tuya_dp.mcu_dp_enum_update(dpid, value);
 849 |         break;
 850 |
 851 |         case DP_TYPE_VALUE:
 852 |             ret = tuya_dp.mcu_dp_value_update(dpid, value);
 853 |         break;
 854 |
 855 |         case DP_TYPE_BITMAP:
 856 |             ret = tuya_dp.mcu_dp_fault_update(dpid, value);
 857 |         break;
 858 |
 859 |         default:
 860 |             break;
 861 |     }
 862 |     return ret;
 863 | }
 864 |
 865 | unsigned char TuyaWifi::mcu_dp_update(unsigned char dpid, long value, unsigned short len)
 866 | {
 867 |     unsigned char ret = 0;
 868 |     switch (download_cmd[get_dowmload_dpid_index(dpid)][1])
 869 |     {
 870 |         case DP_TYPE_BOOL:
 871 |             ret = tuya_dp.mcu_dp_bool_update(dpid, value);
 872 |         break;
 873 |
 874 |         case DP_TYPE_ENUM:
 875 |             ret = tuya_dp.mcu_dp_enum_update(dpid, value);
 876 |         break;
 877 |
 878 |         case DP_TYPE_VALUE:
 879 |             ret = tuya_dp.mcu_dp_value_update(dpid, value);
 880 |         break;
 881 |
 882 |         case DP_TYPE_BITMAP:
 883 |             ret = tuya_dp.mcu_dp_fault_update(dpid, value);
 884 |         break;
 885 |
 886 |         default:
 887 |             break;
 888 |     }
 889 |     return ret;
 890 | }
 891 |
 892 | unsigned char TuyaWifi::mcu_dp_update(unsigned char dpid, unsigned int value, unsigned short len)
 893 | {
 894 |     unsigned char ret = 0;
 895 |     switch (download_cmd[get_dowmload_dpid_index(dpid)][1])
 896 |     {
 897 |         case DP_TYPE_BOOL:
 898 |             ret = tuya_dp.mcu_dp_bool_update(dpid, value);
 899 |         break;
 900 |
 901 |         case DP_TYPE_ENUM:
 902 |             ret = tuya_dp.mcu_dp_enum_update(dpid, value);
 903 |         break;
 904 |
 905 |         case DP_TYPE_VALUE:
 906 |             ret = tuya_dp.mcu_dp_value_update(dpid, value);
 907 |         break;
 908 |
 909 |         case DP_TYPE_BITMAP:
 910 |             ret = tuya_dp.mcu_dp_fault_update(dpid, value);
 911 |         break;
 912 |
 913 |         default:
 914 |             break;
 915 |     }
 916 |     return ret;
 917 | }
 918 |
 919 | unsigned char TuyaWifi::mcu_dp_update(unsigned char dpid, int value, unsigned short len)
 920 | {
 921 |     unsigned char ret = 0;
 922 |     switch (download_cmd[get_dowmload_dpid_index(dpid)][1])
 923 |     {
 924 |         case DP_TYPE_BOOL:
 925 |             ret = tuya_dp.mcu_dp_bool_update(dpid, value);
 926 |         break;
 927 |
 928 |         case DP_TYPE_ENUM:
 929 |             ret = tuya_dp.mcu_dp_enum_update(dpid, value);
 930 |         break;
 931 |
 932 |         case DP_TYPE_VALUE:
 933 |             ret = tuya_dp.mcu_dp_value_update(dpid, value);
 934 |         break;
 935 |
 936 |         case DP_TYPE_BITMAP:
 937 |             ret = tuya_dp.mcu_dp_fault_update(dpid, value);
 938 |         break;
 939 |
 940 |         default:
 941 |             break;
 942 |     }
 943 |     return ret;
 944 | }
 945 |
 946 | #if WIFI_CONTROL_SELF_MODE
 947 |
 948 | void TuyaWifi::set_state_pin(unsigned char led_pin, unsigned char key_pin)
 949 | {
 950 |     wifi_state_led = led_pin;
 951 |     wifi_reset_key = key_pin;
 952 | }
 953 | #else
 954 | /**
 955 |  * @brief  Get set wifi status success flag
 956 |  * @param  Null
 957 |  * @return wifimode flag
 958 |  * -           0(SET_WIFICONFIG_ERROR):failure
 959 |  * -           1(SET_WIFICONFIG_SUCCESS):success
 960 |  * @note   1:The MCU actively calls to obtain whether the reset wifi is successful through the mcu_get_reset_wifi_flag() function.
 961 |  *         2:If the module is in self-processing mode, the MCU does not need to call this function.
 962 |  */
 963 | unsigned char TuyaWifi::mcu_get_wifimode_flag(void)
 964 | {
 965 |     return set_wifimode_flag;
 966 | }
 967 |
 968 | /**
 969 |  * @description: MCU set wifi working mode
 970 |  * @param {unsigned char} mode : enter mode
 971 |  *                               0(SMART_CONFIG):enter smartconfig mode
 972 |  *                               1(AP_CONFIG):enter AP mode
 973 |  * @return {*}
 974 |  */
 975 | void TuyaWifi::mcu_set_wifi_mode(unsigned char mode)
 976 | {
 977 |     unsigned char length = 0;
 978 |
 979 |     set_wifimode_flag = SET_WIFICONFIG_ERROR;
 980 |
 981 |     length = tuya_uart.set_wifi_uart_byte(length, mode);
 982 |
 983 |     tuya_uart.wifi_uart_write_frame(WIFI_MODE_CMD, MCU_TX_VER, length);
 984 | }
 985 |
 986 | /**
 987 |  * @brief  MCU gets reset wifi success flag
 988 |  * @param  Null
 989 |  * @return Reset flag
 990 |  * -           0(RESET_WIFI_ERROR):failure
 991 |  * -           1(RESET_WIFI_SUCCESS):success
 992 |  * @note   1:The MCU actively calls mcu_reset_wifi() and calls this function to get the reset state.
 993 |  *         2:If the module is in self-processing mode, the MCU does not need to call this function.
 994 |  */
 995 | unsigned char TuyaWifi::mcu_get_reset_wifi_flag(void)
 996 | {
 997 |     return reset_wifi_flag;
 998 | }
 999 |
1000 | /**
1001 |  * @description: MCU actively resets wifi working mode
1002 |  * @param {*}
1003 |  * @return {*}
1004 |  * @note   1:The MCU actively calls to obtain whether the reset wifi is successful through the mcu_get_reset_wifi_flag() function.
1005 |  *         2:If the module is in self-processing mode, the MCU does not need to call this function.
1006 |  */
1007 | void TuyaWifi::mcu_reset_wifi(void)
1008 | {
1009 |     reset_wifi_flag = RESET_WIFI_ERROR;
1010 |
1011 |     tuya_uart.wifi_uart_write_frame(WIFI_RESET_CMD, MCU_TX_VER, 0);
1012 | }
1013 |
1014 | /**
1015 |  * @description: The MCU actively obtains the current wifi working status.
1016 |  * @param {*}
1017 |  * @return {unsigned char} wifi work state
1018 |  *                          SMART_CONFIG_STATE:smartconfig config status
1019 |  *                          AP_STATE:AP config status
1020 |  *                          WIFI_NOT_CONNECTED:WIFI configuration succeeded but not connected to the router
1021 |  *                          WIFI_CONNECTED:WIFI configuration is successful and connected to the router
1022 |  *                          WIFI_CONN_CLOUD:WIFI is connected to the cloud server
1023 |  *                          WIFI_LOW_POWER:WIFI is in low power mode
1024 |  *                          SMART_AND_AP_STATE: WIFI smartconfig&AP mode
1025 |  * @note   1:If the module is in self-processing mode, the MCU does not need to call this function.
1026 |  */
1027 | unsigned char TuyaWifi::mcu_get_wifi_work_state(void)
1028 | {
1029 |     return wifi_work_state;
1030 | }
1031 | #endif /* WIFI_CONTROL_SELF_MODE */
1032 |
1033 | #if SUPPORT_GREEN_TIME
1034 | char TuyaWifi::get_green_time(TUYA_WIFI_TIME *time, const unsigned int timeout)
1035 | {
1036 |     if (TY_NULL == time) {
1037 |         return -1;
1038 |     }
1039 |
1040 | #if WIFI_CONTROL_SELF_MODE
1041 |     /* nothing to do here*/
1042 | #else
1043 |     if (WIFI_CONN_CLOUD != mcu_get_wifi_work_state()) {
1044 |         return -1;
1045 |     }
1046 | #endif
1047 |
1048 |     unsigned long get_green_time_begin = 0;
1049 |     unsigned int delay_time = 100;
1050 |
1051 |     if (timeout > 10) {
1052 |         delay_time = timeout;
1053 |     }
1054 |
1055 |     /* 1.request green time */
1056 |     tuya_extras.mcu_request_green_time();
1057 |     /* 2.wait for green time */
1058 |     get_green_time_begin = millis();
1059 |     while (millis()<(get_green_time_begin + timeout)) {
1060 |         uart_service();
1061 |         if (1 == _green_time.update_flag) { /* request green time success */
1062 |             tuya_tools.my_memcpy(time, &_green_time, sizeof(_green_time));
1063 |             _green_time.update_flag = 0;
1064 |             return TY_SUCCESS;
1065 |         }
1066 |     }
1067 |     _green_time.update_flag = 0;
1068 |     return -2; /* request green time timeout */
1069 | }
1070 | #endif /* SUPPORT_GREEN_TIME */
1071 |
1072 | #if SUPPORT_RTC_TIME
1073 | char TuyaWifi::get_rtc_time(TUYA_WIFI_TIME *time, const unsigned int timeout)
1074 | {
1075 |     unsigned long get_rtc_time_begin = 0;
1076 |     unsigned int delay_time = 100;
1077 |
1078 |     if (TY_NULL == time) {
1079 |         return -1;
1080 |     }
1081 |
1082 |     if (timeout > 10) {
1083 |         delay_time = timeout;
1084 |     }
1085 |
1086 |     /* 1.request rtc time */
1087 |     tuya_extras.mcu_request_rtc_time();
1088 |     /* 2.wait for rtc time */
1089 |     get_rtc_time_begin = millis();
1090 |     while (millis()<(get_rtc_time_begin + delay_time)) {
1091 |         uart_service();
1092 |         if (1 == _rtc_time.update_flag) { /* request rtc time success */
1093 |             tuya_tools.my_memcpy(time, &_rtc_time, sizeof(_rtc_time));
1094 |             _rtc_time.update_flag = 0;
1095 |             return TY_SUCCESS;
1096 |         }
1097 |     }
1098 |     _rtc_time.update_flag = 0;
1099 |     return -2; /* request rtc time timeout */
1100 | }
1101 | #endif /* SUPPORT_RTC_TIME */
1102 |


--------------------------------------------------------------------------------
/src/TuyaWifi.h:
--------------------------------------------------------------------------------
  1 | /*
  2 |  * @FileName: Tuya.h
  3 |  * @Author: Tuya
  4 |  * @Email:
  5 |  * @LastEditors: shiliu
  6 |  * @Date: 2021-04-10 11:25:26
  7 |  * @LastEditTime: 2021-11-04 12:01:38
  8 |  * @Copyright: HANGZHOU TUYA INFORMATION TECHNOLOGY CO.,LTD
  9 |  * @Company: http://www.tuya.com
 10 |  * @Description:
 11 |  */
 12 | #ifndef __TUYA_WIFI_H__
 13 | #define __TUYA_WIFI_H__
 14 |
 15 | #include <Arduino.h>
 16 |
 17 | #include "../config.h"
 18 | #include "TuyaDefs.h"
 19 | #include "TuyaUart.h"
 20 | #include "TuyaExtras.h"
 21 |
 22 | #ifdef TUYA_GLOBAL
 23 | #define TUYA_GLOBAL_EXTERN
 24 | #else
 25 | #define TUYA_GLOBAL_EXTERN extern
 26 | #endif
 27 |
 28 | #ifndef TUYA_GLOBAL
 29 | extern TuyaUart tuya_uart;
 30 | #endif
 31 |
 32 | #define PID_LEN 16
 33 | #define VER_LEN 5
 34 |
 35 | TUYA_GLOBAL_EXTERN volatile unsigned char stop_update_flag; //ENABLE:Stop all data uploads   DISABLE:Restore all data uploads
 36 |
 37 | extern "C"
 38 | {
 39 |     typedef void (*tuya_callback_dp_update_all)(void);
 40 |     typedef unsigned char (*tuya_callback_dp_download)(unsigned char dpid, const unsigned char value[], unsigned short length);
 41 | }
 42 |
 43 | class TuyaWifi
 44 | {
 45 | public:
 46 |     TuyaWifi(void);
 47 |     TuyaWifi(TY_UART *serial);
 48 |
 49 |     unsigned char init(unsigned char *pid, unsigned char *mcu_ver);
 50 |     void uart_service(void);
 51 |
 52 |     void dp_process_func_register(tuya_callback_dp_download _func);
 53 |     void dp_update_all_func_register(tuya_callback_dp_update_all _func);
 54 |
 55 |     void set_dp_cmd_total(unsigned char download_cmd_array[][2], unsigned char download_cmd_num);
 56 |
 57 |     unsigned long mcu_get_dp_download_data(unsigned char dpid, const unsigned char value[], unsigned short len);
 58 |
 59 |     /* char * */
 60 |     unsigned char mcu_dp_update(unsigned char dpid, const unsigned char value[], unsigned short len); /* char raw */
 61 |     /* unsigned long / long */
 62 |     unsigned char mcu_dp_update(unsigned char dpid, unsigned long value, unsigned short len);
 63 |     unsigned char mcu_dp_update(unsigned char dpid, long value, unsigned short len);
 64 |     /* unsigned char / char */
 65 |     unsigned char mcu_dp_update(unsigned char dpid, unsigned char value, unsigned short len);
 66 |     unsigned char mcu_dp_update(unsigned char dpid, char value, unsigned short len);
 67 |     /* unsigned int / int */
 68 |     unsigned char mcu_dp_update(unsigned char dpid, unsigned int value, unsigned short len);
 69 |     unsigned char mcu_dp_update(unsigned char dpid, int value, unsigned short len);
 70 |
 71 | #if WIFI_CONTROL_SELF_MODE
 72 |     void set_state_pin(unsigned char led_pin, unsigned char key_pin);
 73 | #else
 74 |     unsigned char mcu_get_wifimode_flag(void);
 75 |     void mcu_set_wifi_mode(unsigned char mode);
 76 |     unsigned char mcu_get_reset_wifi_flag(void);
 77 |     void mcu_reset_wifi(void);
 78 |     unsigned char mcu_get_wifi_work_state(void);
 79 | #endif /* WIFI_CONTROL_SELF_MODE */
 80 |
 81 | #if SUPPORT_GREEN_TIME
 82 |     char get_green_time(TUYA_WIFI_TIME *time, const unsigned int timeout);
 83 | #endif /* SUPPORT_GREEN_TIME */
 84 |
 85 | #if SUPPORT_RTC_TIME
 86 |     char get_rtc_time(TUYA_WIFI_TIME *time, const unsigned int timeout);
 87 | #endif /* SUPPORT_GREEN_TIME */
 88 |
 89 |
 90 | private:
 91 |
 92 | #if WIFI_CONTROL_SELF_MODE
 93 |     unsigned char wifi_state_led = 16;
 94 |     unsigned char wifi_reset_key = 28;
 95 | #else
 96 |     unsigned char reset_wifi_flag;   //Reset wifi flag (TRUE: successful / FALSE: failed)
 97 |     unsigned char set_wifimode_flag; //Set the WIFI working mode flag (TRUE: Success / FALSE: Failed)
 98 |     unsigned char wifi_work_state;   //Wifi module current working status
 99 | #endif /* WIFI_CONTROL_SELF_MODE */
100 |
101 | #if SUPPORT_GREEN_TIME
102 |     TUYA_WIFI_TIME _green_time;
103 | #endif /* SUPPORT_GREEN_TIME */
104 |
105 | #if SUPPORT_RTC_TIME
106 |     TUYA_WIFI_TIME _rtc_time;
107 | #endif /* SUPPORT_RTC_TIME */
108 |
109 |     unsigned char product_id[PID_LEN];
110 |     unsigned char mcu_ver_value[VER_LEN];
111 |
112 |     unsigned char download_dp_number;
113 |     unsigned char (*download_cmd)[2];
114 |
115 |     tuya_callback_dp_download dp_download_handle;
116 |     tuya_callback_dp_update_all all_data_update;
117 |     void data_handle(unsigned short offset);
118 |     void heat_beat_check(void);
119 |     void product_info_update(void);
120 |     void get_mcu_wifi_mode(void);
121 |     unsigned char data_point_handle(const unsigned char value[]);
122 |     unsigned char get_dowmload_dpid_index(unsigned char dpid);
123 | };
124 |
125 | #endif /* __TUYA_WIFI_H__ */
126 |


--------------------------------------------------------------------------------
