├── riskslim
├── tests
│ ├── __init__.py
│ ├── test_risk_slim.py
│ └── test_loss_functions.py
├── __init__.py
├── loss_functions
│ ├── __init__.py
│ ├── build_cython_loss_functions.py
│ ├── fast_log_loss.pyx
│ ├── log_loss.py
│ ├── log_loss_weighted.py
│ └── lookup_log_loss.pyx
├── defaults.py
├── bound_tightening.py
├── solution_pool.py
├── setup_functions.py
├── heuristics.py
├── utils.py
├── coefficient_set.py
├── mip.py
└── initialization.py
├── MANIFEST.in
├── examples
├── README.txt
├── data
│ ├── README.txt
│ ├── breastcancer_cvindices.csv
│ ├── breastcancer_weights.csv
│ └── breastcancer_data.csv
├── ex_01_quickstart.py
├── ex_03_constraints.py
└── ex_02_advanced_options.py
├── requirements.txt
├── docs
├── images
│ └── risk_score_seizure.png
├── references
│ └── ustun2019riskslim.bib
└── cplex_instructions.md
├── LICENSE
├── .gitignore
├── batch
├── settings_template.json
├── job_template.sh
└── train_risk_slim.py
├── README.md
└── setup.py
/riskslim/tests/__init__.py:
--------------------------------------------------------------------------------
1 |
--------------------------------------------------------------------------------
/MANIFEST.in:
--------------------------------------------------------------------------------
1 | include requirements.txt
2 |
--------------------------------------------------------------------------------
/examples/README.txt:
--------------------------------------------------------------------------------
1 | .. _general_examples:
2 |
3 | General examples
4 | ================
5 |
--------------------------------------------------------------------------------
/requirements.txt:
--------------------------------------------------------------------------------
1 | cplex
2 | numpy
3 | scipy
4 | Cython
5 | IPython
6 | traitlets
7 | nose
8 | pandas
9 | prettytable
--------------------------------------------------------------------------------
/docs/images/risk_score_seizure.png:
--------------------------------------------------------------------------------
https://raw.githubusercontent.com/ustunb/risk-slim/HEAD/docs/images/risk_score_seizure.png
--------------------------------------------------------------------------------
/riskslim/__init__.py:
--------------------------------------------------------------------------------
1 | from .coefficient_set import CoefficientSet
2 | from .lattice_cpa import run_lattice_cpa, setup_lattice_cpa, finish_lattice_cpa
3 | from .utils import load_data_from_csv, print_model
--------------------------------------------------------------------------------
/examples/data/README.txt:
--------------------------------------------------------------------------------
1 | .. _datasets:
2 |
3 | Datasets
4 | ================
5 |
6 | These datasets are used in the examples as well as the experiments in our paper http://arxiv.org/abs/1610.00168
7 |
8 |
--------------------------------------------------------------------------------
/docs/references/ustun2019riskslim.bib:
--------------------------------------------------------------------------------
1 | @article{ustun2019jmlr,
2 | author = {Ustun, Berk and Rudin, Cynthia},
3 | title = {{Learning Optimized Risk Scores}},
4 | journal = {{Journal of Machine Learning Research}},
5 | year = {2019},
6 | volume = {20},
7 | number = {150},
8 | pages = {1-75},
9 | url = {http://jmlr.org/papers/v20/18-615.html}
10 | }
--------------------------------------------------------------------------------
/riskslim/loss_functions/__init__.py:
--------------------------------------------------------------------------------
1 | from .log_loss import *
2 | from .log_loss_weighted import *
3 |
4 | try:
5 | from .fast_log_loss import *
6 | except ImportError:
7 | print("warning: could not import fast log loss")
8 | print("warning: returning handle to standard loss functions")
9 | # todo replace with warning object
10 | import log_loss as fast_log_loss
11 |
12 | try:
13 | from .lookup_log_loss import *
14 | except ImportError:
15 | print("warning: could not import lookup log loss")
16 | print("warning: returning handle to standard loss functions")
17 | # todo replace with warning object
18 | import log_loss as lookup_log_loss
19 |
20 |
--------------------------------------------------------------------------------
/docs/cplex_instructions.md:
--------------------------------------------------------------------------------
1 | # Downloading & Installing CPLEX
2 |
3 | CPLEX is cross-platform optimization tool solver a Python API. It is free for students and faculty members at accredited institutions.
4 |
5 | To download CPLEX:
6 |
7 | 1. Register for [IBM OnTheHub](https://ur.us-south.cf.appdomain.cloud/a2mt/email-auth)
8 | 2. Download the *IBM ILOG CPLEX Optimization Studio* from the [software catalog](https://www-03.ibm.com/isc/esd/dswdown/searchPartNumber.wss?partNumber=CJ6BPML)
9 | 3. Install CPLEX Optimization Studio.
10 | 4. Setup the CPLEX Python API [as described here](https://www.ibm.com/support/knowledgecenter/SSSA5P_12.8.0/ilog.odms.cplex.help/CPLEX/GettingStarted/topics/set_up/Python_setup.html).
11 |
12 | If you have problems with CPLEX, please check the [CPLEX user manual](http://www-01.ibm.com/support/knowledgecenter/SSSA5P/welcome) or the [CPLEX forums](https://www.ibm.com/developerworks/community/forums/html/forum?id=11111111-0000-0000-0000-000000002059).
13 |
--------------------------------------------------------------------------------
/LICENSE:
--------------------------------------------------------------------------------
1 | BSD 3-Clause License
2 |
3 | Copyright (c) 2017, Berk Ustun
4 | All rights reserved.
5 |
6 | Redistribution and use in source and binary forms, with or without
7 | modification, are permitted provided that the following conditions are met:
8 |
9 | * Redistributions of source code must retain the above copyright notice, this
10 | list of conditions and the following disclaimer.
11 |
12 | * Redistributions in binary form must reproduce the above copyright notice,
13 | this list of conditions and the following disclaimer in the documentation
14 | and/or other materials provided with the distribution.
15 |
16 | * Neither the name of the copyright holder nor the names of its
17 | contributors may be used to endorse or promote products derived from
18 | this software without specific prior written permission.
19 |
20 | THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS"
21 | AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
22 | IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
23 | DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE LIABLE
24 | FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL
25 | DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR
26 | SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
27 | CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,
28 | OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE
29 | OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
30 |
--------------------------------------------------------------------------------
/riskslim/loss_functions/build_cython_loss_functions.py:
--------------------------------------------------------------------------------
1 | #!/usr/bin/env python
2 |
3 | """
4 | This script builds loss functions using Cython on a local machine.
5 | To run this script
6 |
7 | 1. Change to the directory
8 |
9 | $REPO_DIR/riskslim/loss_functions
10 |
11 | 2. Run the following commands in Bash:
12 |
13 | python2 build_cython_loss_functions.py build_ext --inplace
14 | python3 build_cython_loss_functions.py build_ext --inplace
15 |
16 | """
17 | import numpy
18 | import scipy
19 | from distutils.core import setup
20 | from distutils.extension import Extension
21 | from Cython.Distutils import build_ext
22 |
23 |
24 | #fast log loss
25 | ext_modules = [Extension(name = "fast_log_loss",
26 | sources=["fast_log_loss.pyx"],
27 | include_dirs=[numpy.get_include(), scipy.get_include()],
28 | libraries=["m"],
29 | extra_compile_args = ["-ffast-math"])]
30 |
31 | setup(
32 | cmdclass = {'build_ext': build_ext},
33 | include_dirs = [numpy.get_include(), scipy.get_include()],
34 | ext_modules = ext_modules,
35 | )
36 |
37 | #lookup log loss
38 | ext_modules = [Extension(name = "lookup_log_loss",
39 | sources=["lookup_log_loss.pyx"],
40 | include_dirs=[numpy.get_include(), scipy.get_include()],
41 | libraries=["m"],
42 | extra_compile_args = ["-ffast-math"])]
43 |
44 | setup(
45 | cmdclass = {'build_ext': build_ext},
46 | include_dirs = [numpy.get_include(), scipy.get_include()],
47 | ext_modules = ext_modules,
48 | )
49 |
50 |
51 |
52 |
53 |
54 |
55 |
56 |
57 |
58 |
--------------------------------------------------------------------------------
/.gitignore:
--------------------------------------------------------------------------------
1 | # Byte-compiled / optimized / DLL files
2 | __pycache__/
3 | *.py[cod]
4 | *$py.class
5 |
6 | # C extensions
7 | *.so
8 |
9 | # scikit-learn specific
10 | doc/_build/
11 | doc/auto_examples/
12 | doc/modules/generated/
13 | doc/datasets/generated/
14 |
15 | # sklearn template
16 | doc/
17 | *.yml
18 | .nojekyll
19 | ci_scripts/
20 | skltemplate/
21 |
22 | # riskslim directories
23 | batch/data/
24 | batch/results/
25 | batch/log/
26 | dev/
27 | cluster/
28 |
29 | # riskslim files
30 | riskslim_todo.ft
31 | examples/data/*cvindices.csv
32 | examples/data/*weights.csv
33 | examples/ex_00_tests.py
34 | examples/data/recidivism_v01_*.csv
35 | !examples/data/breastcancer_cvindices.csv
36 | !examples/data/breastcancer_weights.csv
37 | riskslim/tests/test_common.py
38 | riskslim/tests/test_template.py
39 | riskslim/loss_functions/build/
40 | riskslim/loss_functions/*.so
41 | riskslim/loss_functions/*.c
42 |
43 | # Distribution / packaging
44 | .Python
45 | env/
46 | venv/
47 | build/
48 | develop-eggs/
49 | dist/
50 | downloads/
51 | eggs/
52 | .eggs/
53 | lib/
54 | lib64/
55 | parts/
56 | sdist/
57 | var/
58 | *.egg-info/
59 | .installed.cfg
60 | *.egg
61 | .idea
62 |
63 | # PyInstaller
64 | # Usually these files are written by a python script from a template
65 | # before PyInstaller builds the exe, so as to inject date/other infos into it.
66 | *.manifest
67 | *.spec
68 |
69 | # Installer logs
70 | pip-log.txt
71 | pip-delete-this-directory.txt
72 |
73 | # Unit test / coverage reports
74 | htmlcov/
75 | .tox/
76 | .coverage
77 | .coverage.*
78 | .cache
79 | nosetests.xml
80 | coverage.xml
81 | *,cover
82 | .hypothesis/
83 |
84 | # Translations
85 | *.mo
86 | *.pot
87 |
88 | # Django stuff:
89 | *.log
90 |
91 | # Sphinx documentation
92 | docs/_build/
93 |
94 | # PyBuilder
95 | target/
96 |
97 | # emacs
98 | *~
99 | *.org
100 | \#*#
101 |
102 | # Jupyter NB Checkpoints
103 | .ipynb_checkpoints/
104 |
--------------------------------------------------------------------------------
/batch/settings_template.json:
--------------------------------------------------------------------------------
1 | {
2 | "max_runtime": 300.0,
3 | "max_tolerance": 1e-06,
4 | "loss_computation": "normal",
5 | "chained_updates_flag": true,
6 | "round_flag": true,
7 | "polish_flag": true,
8 | "initialization_flag": true,
9 | "add_cuts_at_heuristic_solutions": true,
10 | "tight_formulation": true,
11 |
12 | "polish_rounded_solutions": true,
13 | "polishing_max_runtime": 10.0,
14 | "polishing_max_solutions": 5.0,
15 | "polishing_start_cuts": 0,
16 | "polishing_start_gap": Infinity,
17 | "polishing_stop_cuts": Infinity,
18 | "polishing_stop_gap": 5.0,
19 | "polishing_tolerance": 0.1,
20 |
21 | "rounding_start_cuts": 0,
22 | "rounding_start_gap": Infinity,
23 | "rounding_stop_cuts": 20000,
24 | "rounding_stop_gap": 0.2,
25 | "rounding_tolerance": Infinity,
26 |
27 | "init_display_cplex_progress": false,
28 | "init_display_progress": true,
29 | "init_max_cplex_time_per_iteration": 10.0,
30 | "init_max_iterations": 10000,
31 | "init_max_runtime": 300.0,
32 | "init_max_runtime_per_iteration": 300.0,
33 | "init_max_tolerance": 0.0001,
34 | "init_polishing_after": true,
35 | "init_polishing_max_runtime": 30.0,
36 | "init_polishing_max_solutions": 5,
37 | "init_sequential_rounding_max_runtime": 30.0,
38 | "init_sequential_rounding_max_solutions": 5,
39 | "init_use_sequential_rounding": true,
40 |
41 | "display_cplex_progress": true,
42 | "purge_bound_cuts": false,
43 | "purge_loss_cuts": false,
44 | "cplex_absmipgap": 2.2204460492503131e-16,
45 | "cplex_integrality_tolerance": 2.2204460492503131e-16,
46 | "cplex_mipemphasis": 0,
47 | "cplex_mipgap": 2.2204460492503131e-16,
48 | "cplex_n_cores": 1,
49 | "cplex_nodefilesize": 122880,
50 | "cplex_poolrelgap": NaN,
51 | "cplex_poolreplace": 2,
52 | "cplex_poolsize": 100,
53 | "cplex_randomseed": 0,
54 | "cplex_repairtries": 20
55 | }
--------------------------------------------------------------------------------
/README.md:
--------------------------------------------------------------------------------
1 | risk-slim
2 | ========
3 |
4 | risk-slim is a machine learning method to fit simple customized risk scores in python.
5 |
6 | #### Background
7 |
8 | Risk scores let users make quick risk predictions by adding and subtracting a few small numbers (see e.g., 500 + medical risk scores at [mdcalc.com](https://www.mdcalc.com/)).
9 |
10 | Here is a risk score for ICU risk prediction from our [paper](http://www.berkustun.com/docs/ustun_2017_optimized_risk_scores.pdf).
11 |
12 |
13 |
14 |
15 |
16 |
21 |
22 |
23 |
24 |
25 |
26 |
27 | #### Reference
28 |
29 | If you use risk-slim in your research, we would appreciate a citation to the following paper ([bibtex](/docs/references/ustun2019riskslim.bib)!
30 |
31 | Learning Optimized Risk Scores
32 | Berk Ustun and Cynthia Rudin
33 | Journal of Machine Learning Research, 2019.
34 |
35 | ## Installation
36 |
37 | Run the following snippet in a Unix terminal to install risk-slim and complete a test run.
38 |
39 | ```
40 | git clone https://github.com/ustunb/risk-slim
41 | cd risk-slim
42 | pip install -e . # install in editable mode
43 | bash batch/job_template.sh # batch run
44 | ```
45 |
46 | ### Requirements
47 |
48 | risk-slim requires Python 3.5+ and CPLEX 12.6+. For instructions on how to download and install, click [here](/docs/cplex_instructions.md).
49 |
50 |
51 |
52 | ## Contributing
53 |
54 | I'm planning to pick up development again in Fall 2020. I can definitely use a hand! If you are interested in contributing, please reach out!
55 |
56 | Here's the current development roadmap:
57 |
58 | - [sci-kit learn interface](http://scikit-learn.org/stable/developers/contributing.html#rolling-your-own-estimator)
59 | - support for open source solver in [python-mip](https://github.com/coin-or/python-mip)
60 | - basic reporting tools (roc curves, calibration plots, model reports)
61 | - documentation
62 | - pip
--------------------------------------------------------------------------------
/setup.py:
--------------------------------------------------------------------------------
1 | #! /usr/bin/env python
2 | #
3 | # Copyright (C) 2017 Berk Ustun
4 |
5 | import os
6 | import sys
7 | from setuptools import setup, find_packages, dist
8 | from setuptools.extension import Extension
9 |
10 | #resources
11 | #setuptools http://setuptools.readthedocs.io/en/latest/setuptools.html
12 | #setuptools + Cython: http://stackoverflow.com/questions/32528560/
13 |
14 | DISTNAME = 'riskslim'
15 | DESCRIPTION = "optimized risk scores on large-scale datasets"
16 | AUTHOR = 'Berk Ustun'
17 | AUTHOR_EMAIL = 'berk@seas.harvard.edu'
18 | URL = 'https://github.com/ustunb/risk-slim'
19 | LICENSE = 'new BSD'
20 | DOWNLOAD_URL = 'https://github.com/ustunb/risk-slim'
21 | VERSION = '0.0.0'
22 |
23 | # Install setup requirements
24 | dist.Distribution().fetch_build_eggs(['Cython', 'numpy', 'scipy'])
25 |
26 | #read requirements as listed in txt file
27 | try:
28 | import numpy
29 | except ImportError:
30 | print('numpy is required for installation')
31 | sys.exit(1)
32 |
33 | try:
34 | import scipy
35 | except ImportError:
36 | print('scipy is required for installation')
37 | sys.exit(1)
38 |
39 | try:
40 | from Cython.Build import cythonize
41 | except ImportError:
42 | print('Cython is required for installation')
43 | sys.exit(1)
44 |
45 | #fast log loss
46 | extensions =[
47 | Extension(
48 | DISTNAME + ".loss_functions." + "fast_log_loss",
49 | [DISTNAME + "/loss_functions/fast_log_loss.pyx"],
50 | include_dirs=[numpy.get_include(), scipy.get_include()],
51 | libraries=["m"],
52 | extra_compile_args=["-ffast-math"]
53 | ),
54 | Extension(
55 | DISTNAME + ".loss_functions." + "lookup_log_loss",
56 | [DISTNAME + "/loss_functions/lookup_log_loss.pyx"],
57 | include_dirs=[numpy.get_include(), scipy.get_include()],
58 | libraries=["m"],
59 | extra_compile_args=["-ffast-math"])
60 | ]
61 |
62 |
63 | if __name__ == "__main__":
64 |
65 | old_path = os.getcwd()
66 | local_path = os.path.dirname(os.path.abspath(sys.argv[0]))
67 |
68 | os.chdir(local_path)
69 | sys.path.insert(0, local_path)
70 |
71 | with open('requirements.txt') as f:
72 | INSTALL_REQUIRES = [l.strip() for l in f.readlines() if l]
73 |
74 | setup(
75 | name=DISTNAME,
76 | packages=find_packages(),
77 | ext_modules=cythonize(extensions),
78 | author=AUTHOR,
79 | author_email=AUTHOR_EMAIL,
80 | description=DESCRIPTION,
81 | install_requires=INSTALL_REQUIRES,
82 | license=LICENSE,
83 | url=URL,
84 | version=VERSION,
85 | download_url=DOWNLOAD_URL,
86 | zip_safe=False,
87 | )
88 |
--------------------------------------------------------------------------------
/batch/job_template.sh:
--------------------------------------------------------------------------------
1 | #!/bin/bash
2 | # This is a template to show how to train RiskSLIM from a Bash command shell
3 | # You should adapt this to run RiskSLIM on a batch computing environment (e.g. AWS Batch)
4 | #
5 | # To test the script, run the following command from risk-slim directory:
6 | #
7 | # `bash batch/job_template.sh`
8 | #
9 | # To see a detailed list of all arguments that can be passed into risk_slim, use:
10 | #
11 | # `python "batch/train_risk_slim.py --help`
12 | #
13 | # or
14 | #
15 | # `python2 "batch/train_risk_slim.py --help`
16 | #
17 | # Recommended Directory Structure for Batch Computing:
18 | #
19 | # risk-slim/
20 | # └──batch/
21 | # └──data/ location of CSV files for data (ignored in git)
22 | # └──logs/ directory where log files are printed out (ignored in git)
23 | # └──results/ directory where results files are stored (ignored in git)
24 | # └──doc/
25 | # └──examples/
26 | # └──riskslim/ directory where code is stored (do not change this to be able to pull from GitHub)
27 | # └──setup.py
28 | #
29 | # Advantaged settings are be configured through a JSON file. See: `batch/settings_template.json` for a template
30 | # The values can be changed directly using a text editor, or programmatically using a tool such as
31 | # `jq` https://stedolan.github.io/jq/
32 |
33 | #directories
34 | repo_dir=$(pwd)
35 | data_dir="${repo_dir}/examples/data" #change to /batch/data/ for your own data
36 | batch_dir="${repo_dir}/batch"
37 | results_dir="${batch_dir}/results"
38 | log_dir="${batch_dir}/logs"
39 |
40 | #set job parameters
41 | data_name="breastcancer"
42 | data_file="${data_dir}/${data_name}_data.csv"
43 |
44 | cvindices_file="${data_dir}/${data_name}_cvindices.csv"
45 | #weights_file="${data_dir}/${data_name}_weights.csv"
46 | fold=0
47 |
48 | max_coef=5
49 | max_size=5
50 | max_offset=-1
51 | w_pos=1.00
52 | c0_value=1e-6
53 |
54 | timelimit=60
55 |
56 | #results_file and log_file must have a UNIQUE name for each job to avoid overwriting existing files
57 | run_name="${data_name}_fold_${fold}"
58 | run_time=$(date +"%m_%d_%Y_%H_%M_%S")
59 | results_file="${results_dir}/${run_name}_results.p"
60 | log_file="${log_dir}/${run_name}_${run_time}.log"
61 |
62 | #comment out the following in case testing / OK with overwriting
63 | #for safety, train_risk_slim.py will not run if results_file exists on disk
64 | rm -f "${results_file}" #c
65 |
66 | #create directories that do not exist
67 | mkdir -p "${results_dir}"
68 | mkdir -p "${log_dir}"
69 |
70 | #addition settings can be modified by changing a JSON file
71 | #complete list of settings is in: risk-slim/batch/settings_template.json
72 | settings_file="${results_dir}/${run_name}_settings.json"
73 | cp "${batch_dir}/settings_template.json" "${settings_file}"
74 |
75 | #run command
76 | python3 "${batch_dir}/train_risk_slim.py" \
77 | --data "${data_file}" \
78 | --results "${results_file}" \
79 | --cvindices "${cvindices_file}" \
80 | --fold "${fold}" \
81 | --timelimit "${timelimit}" \
82 | --settings "${settings_file}" \
83 | --w_pos "${w_pos}" \
84 | --c0_value "${c0_value}" \
85 | --max_size "${max_size}" \
86 | --max_coef "${max_coef}" \
87 | --max_offset "${max_offset}" \
88 | --log "${log_file}"
89 |
90 | exit
91 | W
--------------------------------------------------------------------------------
/examples/ex_01_quickstart.py:
--------------------------------------------------------------------------------
1 | import os
2 | import pprint
3 | import numpy as np
4 | import riskslim
5 |
6 | # data
7 | data_name = "breastcancer" # name of the data
8 | data_dir = os.getcwd() + '/examples/data/' # directory where datasets are stored
9 | data_csv_file = data_dir + data_name + '_data.csv' # csv file for the dataset
10 | sample_weights_csv_file = None # csv file of sample weights for the dataset (optional)
11 |
12 | # problem parameters
13 | max_coefficient = 5 # value of largest/smallest coefficient
14 | max_L0_value = 5 # maximum model size (set as float(inf))
15 | max_offset = 50 # maximum value of offset parameter (optional)
16 | c0_value = 1e-6 # L0-penalty parameter such that c0_value > 0; larger values -> sparser models; we set to a small value (1e-6) so that we get a model with max_L0_value terms
17 |
18 |
19 | # load data from disk
20 | data = riskslim.load_data_from_csv(dataset_csv_file = data_csv_file, sample_weights_csv_file = sample_weights_csv_file)
21 |
22 | # create coefficient set and set the value of the offset parameter
23 | coef_set = riskslim.CoefficientSet(variable_names = data['variable_names'], lb = -max_coefficient, ub = max_coefficient, sign = 0)
24 | coef_set.update_intercept_bounds(X = data['X'], y = data['Y'], max_offset = max_offset)
25 |
26 | constraints = {
27 | 'L0_min': 0,
28 | 'L0_max': max_L0_value,
29 | 'coef_set':coef_set,
30 | }
31 |
32 | # major settings (see riskslim_ex_02_complete for full set of options)
33 | settings = {
34 | # Problem Parameters
35 | 'c0_value': c0_value,
36 | #
37 | # LCPA Settings
38 | 'max_runtime': 30.0, # max runtime for LCPA
39 | 'max_tolerance': np.finfo('float').eps, # tolerance to stop LCPA (set to 0 to return provably optimal solution)
40 | 'display_cplex_progress': True, # print CPLEX progress on screen
41 | 'loss_computation': 'fast', # how to compute the loss function ('normal','fast','lookup')
42 | #
43 | # LCPA Improvements
44 | 'round_flag': True, # round continuous solutions with SeqRd
45 | 'polish_flag': True, # polish integer feasible solutions with DCD
46 | 'chained_updates_flag': True, # use chained updates
47 | 'add_cuts_at_heuristic_solutions': True, # add cuts at integer feasible solutions found using polishing/rounding
48 | #
49 | # Initialization
50 | 'initialization_flag': True, # use initialization procedure
51 | 'init_max_runtime': 120.0, # max time to run CPA in initialization procedure
52 | 'init_max_coefficient_gap': 0.49,
53 | #
54 | # CPLEX Solver Parameters
55 | 'cplex_randomseed': 0, # random seed
56 | 'cplex_mipemphasis': 0, # cplex MIP strategy
57 | }
58 |
59 | # train model using lattice_cpa
60 | model_info, mip_info, lcpa_info = riskslim.run_lattice_cpa(data, constraints, settings)
61 |
62 | #print model contains model
63 | riskslim.print_model(model_info['solution'], data)
64 |
65 | #model info contains key results
66 | pprint.pprint(model_info)
67 |
68 |
--------------------------------------------------------------------------------
/riskslim/loss_functions/fast_log_loss.pyx:
--------------------------------------------------------------------------------
1 | import cython
2 | import numpy as np
3 | cimport numpy as np
4 | cimport scipy.linalg.cython_blas as blas
5 | cimport libc.math as math
6 |
7 | DTYPE = np.float64
8 | ctypedef np.float64_t DTYPE_T
9 |
10 | @cython.boundscheck(False)
11 | @cython.wraparound(False)
12 | @cython.nonecheck(False)
13 | @cython.cdivision(False)
14 | def log_loss_value(np.ndarray[DTYPE_T, ndim=2, mode="fortran"] Z, np.ndarray[DTYPE_T, ndim=1, mode="fortran"] rho):
15 |
16 | cdef:
17 | int N = Z.shape[0]
18 | int D = Z.shape[1]
19 | int lda = N
20 | int incx = 1 #increments of rho
21 | int incy = 1 #increments of y
22 | double alpha = 1.0
23 | double beta = 0.0
24 | np.ndarray[DTYPE_T, ndim=1, mode = "fortran"] y = np.empty(N, dtype = DTYPE)
25 | Py_ssize_t i
26 | DTYPE_T total_loss = 0.0
27 | int zero_score_cnt = 0
28 |
29 | #compute scores
30 | #calls dgemv from BLZS which computes y = alpha * trans(Z) + beta * y
31 | #see: http://www.nag.com/numeric/fl/nagdoc_fl22/xhtml/F06/f06paf.xml
32 | blas.dgemv("N", &N, &D, &alpha, &Z[0,0], &lda, &rho[0], &incx, &beta, &y[0], &incy)
33 |
34 | #compute loss
35 | for i in range(N):
36 | if (y[i] < 0):
37 | total_loss += math.log(1.0 + math.exp(y[i])) - y[i]
38 | elif (y[i] > 0):
39 | total_loss += math.log1p(math.exp(-y[i]))
40 | else:
41 | zero_score_cnt += 1
42 |
43 | total_loss += zero_score_cnt * math.M_LN2
44 | return total_loss/N
45 |
46 | @cython.boundscheck(False)
47 | @cython.wraparound(False)
48 | @cython.nonecheck(False)
49 | @cython.cdivision(False)
50 | def log_loss_value_and_slope(np.ndarray[DTYPE_T, ndim=2, mode="fortran"] Z, np.ndarray[DTYPE_T, ndim=1, mode="fortran"] rho):
51 |
52 | cdef:
53 | int N = Z.shape[0]
54 | int D = Z.shape[1]
55 | int lda = N
56 | int incx = 1 #increments of rho
57 | int incy = 1 #increments of y
58 | double alpha = 1.0
59 | double beta = 0.0
60 | Py_ssize_t i
61 | DTYPE_T total_loss = 0.0
62 | DTYPE_T exp_value
63 | np.ndarray[DTYPE_T, ndim=1, mode = "fortran"] y = np.empty(N, dtype = DTYPE)
64 | np.ndarray[DTYPE_T, ndim=1, mode = "fortran"] loss_slope = np.empty(D, dtype = DTYPE)
65 |
66 | #compute scores
67 | #calls dgemv from BLAS which computes y = alpha * trans(Z) + beta * y
68 | #see: http://www.nag.com/numeric/fl/nagdoc_fl22/xhtml/F06/f06paf.xml
69 | blas.dgemv("N", &N, &D, &alpha, &Z[0,0], &lda, &rho[0], &incx, &beta, &y[0], &incy)
70 |
71 | #exponentiate scores, compute mean scores and probabilities
72 | for i in range(N):
73 | if y[i] < 0:
74 | exp_value = math.exp(y[i])
75 | total_loss += math.log(1.0 + exp_value) - y[i]
76 | y[i] = (exp_value / (1.0 + exp_value)) - 1.0
77 | else:
78 | exp_value = math.exp(-y[i])
79 | total_loss += math.log1p(exp_value)
80 | y[i] = (1.0 / (1.0 + exp_value)) - 1.0
81 |
82 | #compute loss slope
83 | alpha = 1.0/N
84 | blas.dgemv("T", &N, &D, &alpha, &Z[0,0], &lda, &y[0], &incx, &beta, &loss_slope[0], &incy)
85 | return (total_loss/N), loss_slope
86 |
87 | @cython.boundscheck(False)
88 | @cython.wraparound(False)
89 | @cython.nonecheck(False)
90 | @cython.cdivision(False)
91 | def log_loss_value_from_scores(np.ndarray[DTYPE_T, ndim=1, mode="fortran"] scores):
92 |
93 | cdef:
94 | Py_ssize_t N = scores.shape[0]
95 | DTYPE_T total_loss = 0.0
96 | int zero_score_cnt = 0
97 | Py_ssize_t i
98 | DTYPE_T s
99 |
100 | #compute loss
101 | for i in range(N):
102 | s = scores[i]
103 | if s < 0:
104 | total_loss += math.log(1.0 + math.exp(s)) - s
105 | elif s > 0:
106 | total_loss += math.log1p(math.exp(-s))
107 | else:
108 | zero_score_cnt += 1
109 |
110 | total_loss += zero_score_cnt * math.M_LN2
111 | return total_loss/N
112 |
--------------------------------------------------------------------------------
/riskslim/loss_functions/log_loss.py:
--------------------------------------------------------------------------------
1 | import numpy as np
2 |
3 | def log_loss_value(Z, rho):
4 | """
5 | computes the value and slope of the logistic loss in a numerically stable way
6 | see also: http://stackoverflow.com/questions/20085768/
7 |
8 | Parameters
9 | ----------
10 | Z numpy.array containing training data with shape = (n_rows, n_cols)
11 | rho numpy.array of coefficients with shape = (n_cols,)
12 |
13 | Returns
14 | -------
15 | loss_value scalar = 1/n_rows * sum(log( 1 .+ exp(-Z*rho))
16 |
17 | """
18 | scores = Z.dot(rho)
19 | pos_idx = scores > 0
20 | loss_value = np.empty_like(scores)
21 | loss_value[pos_idx] = np.log1p(np.exp(-scores[pos_idx]))
22 | loss_value[~pos_idx] = -scores[~pos_idx] + np.log1p(np.exp(scores[~pos_idx]))
23 | loss_value = loss_value.mean()
24 | return loss_value
25 |
26 | def log_loss_value_and_slope(Z, rho):
27 | """
28 | computes the value and slope of the logistic loss in a numerically stable way
29 | this function should only be used when generating cuts in cutting-plane algorithms
30 | (computing both the value and the slope at the same time is slightly cheaper)
31 |
32 | see also: http://stackoverflow.com/questions/20085768/
33 |
34 | Parameters
35 | ----------
36 | Z numpy.array containing training data with shape = (n_rows, n_cols)
37 | rho numpy.array of coefficients with shape = (n_cols,)
38 |
39 | Returns
40 | -------
41 | loss_value scalar = 1/n_rows * sum(log( 1 .+ exp(-Z*rho))
42 | loss_slope: (n_cols x 1) vector = 1/n_rows * sum(-Z*rho ./ (1+exp(-Z*rho))
43 |
44 | """
45 | scores = Z.dot(rho)
46 | pos_idx = scores > 0
47 | exp_scores_pos = np.exp(-scores[pos_idx])
48 | exp_scores_neg = np.exp(scores[~pos_idx])
49 |
50 | #compute loss value
51 | loss_value = np.empty_like(scores)
52 | loss_value[pos_idx] = np.log1p(exp_scores_pos)
53 | loss_value[~pos_idx] = -scores[~pos_idx] + np.log1p(exp_scores_neg)
54 | loss_value = loss_value.mean()
55 |
56 | #compute loss slope
57 | log_probs = np.empty_like(scores)
58 | log_probs[pos_idx] = 1.0 / (1.0 + exp_scores_pos)
59 | log_probs[~pos_idx] = exp_scores_neg / (1.0 + exp_scores_neg)
60 | loss_slope = Z.T.dot(log_probs - 1.0) / Z.shape[0]
61 |
62 | return loss_value, loss_slope
63 |
64 | def log_loss_value_from_scores(scores):
65 | """
66 | computes the logistic loss value from a vector of scores in a numerically stable way
67 | where scores = Z.dot(rho)
68 |
69 | see also: http://stackoverflow.com/questions/20085768/
70 |
71 | this function is used for heuristics (discrete_descent, sequential_rounding).
72 | to save computation when running the heuristics, we store the scores and
73 | call this function to compute the loss directly from the scores
74 | this reduces the need to recompute the dot product.
75 |
76 | Parameters
77 | ----------
78 | scores numpy.array of scores = Z.dot(rho)
79 |
80 | Returns
81 | -------
82 | loss_value scalar = 1/n_rows * sum(log( 1 .+ exp(-Z*rho))
83 |
84 | """
85 |
86 | pos_idx = scores > 0
87 | loss_value = np.empty_like(scores)
88 | loss_value[pos_idx] = np.log1p(np.exp(-scores[pos_idx]))
89 | loss_value[~pos_idx] = -scores[~pos_idx] + np.log1p(np.exp(scores[~pos_idx]))
90 | loss_value = loss_value.mean()
91 | return loss_value
92 |
93 | def log_probs(Z, rho):
94 | """
95 | compute the probabilities of the logistic loss function in a way that is numerically stable
96 |
97 | see also: http://stackoverflow.com/questions/20085768/
98 | Parameters
99 | ----------
100 | Z numpy.array containing training data with shape = (n_rows, n_cols)
101 | rho numpy.array of coefficients with shape = (n_cols,)
102 |
103 | Returns
104 | -------
105 | log_probs numpy.array of probabilities under the logit model
106 | """
107 |
108 | scores = Z.dot(rho)
109 | pos_idx = scores > 0
110 | log_probs = np.empty_like(scores)
111 | log_probs[pos_idx] = 1.0 / (1.0 + np.exp(-scores[pos_idx]))
112 | log_probs[~pos_idx] = np.exp(scores[~pos_idx]) / (1.0 + np.exp(scores[~pos_idx]))
113 | return log_probs
114 |
--------------------------------------------------------------------------------
/riskslim/loss_functions/log_loss_weighted.py:
--------------------------------------------------------------------------------
1 | import numpy as np
2 |
3 | def log_loss_value(Z, weights, total_weights, rho):
4 | """
5 | computes the value and slope of the logistic loss in a numerically stable way
6 | supports sample non-negative weights for each example in the training data
7 | see http://stackoverflow.com/questions/20085768/
8 |
9 | Parameters
10 | ----------
11 | Z numpy.array containing training data with shape = (n_rows, n_cols)
12 | rho numpy.array of coefficients with shape = (n_cols,)
13 | total_weights numpy.sum(total_weights) (only included to reduce computation)
14 | weights numpy.array of sample weights with shape (n_rows,)
15 |
16 | Returns
17 | -------
18 | loss_value scalar = 1/n_rows * sum(log( 1 .+ exp(-Z*rho))
19 |
20 | """
21 | scores = Z.dot(rho)
22 | pos_idx = scores > 0
23 | loss_value = np.empty_like(scores)
24 | loss_value[pos_idx] = np.log1p(np.exp(-scores[pos_idx]))
25 | loss_value[~pos_idx] = -scores[~pos_idx] + np.log1p(np.exp(scores[~pos_idx]))
26 | loss_value = loss_value.dot(weights) / total_weights
27 | return loss_value
28 |
29 | def log_loss_value_and_slope(Z, weights, total_weights, rho):
30 | """
31 | computes the value and slope of the logistic loss in a numerically stable way
32 | supports sample non-negative weights for each example in the training data
33 | this function should only be used when generating cuts in cutting-plane algorithms
34 | (computing both the value and the slope at the same time is slightly cheaper)
35 |
36 | see http://stackoverflow.com/questions/20085768/
37 |
38 | Parameters
39 | ----------
40 | Z numpy.array containing training data with shape = (n_rows, n_cols)
41 | rho numpy.array of coefficients with shape = (n_cols,)
42 | total_weights numpy.sum(total_weights) (only included to reduce computation)
43 | weights numpy.array of sample weights with shape (n_rows,)
44 |
45 | Returns
46 | -------
47 | loss_value scalar = 1/n_rows * sum(log( 1 .+ exp(-Z*rho))
48 | loss_slope: (n_cols x 1) vector = 1/n_rows * sum(-Z*rho ./ (1+exp(-Z*rho))
49 |
50 | """
51 | scores = Z.dot(rho)
52 | pos_idx = scores > 0
53 | exp_scores_pos = np.exp(-scores[pos_idx])
54 | exp_scores_neg = np.exp(scores[~pos_idx])
55 |
56 | #compute loss value
57 | loss_value = np.empty_like(scores)
58 | loss_value[pos_idx] = np.log1p(exp_scores_pos)
59 | loss_value[~pos_idx] = -scores[~pos_idx] + np.log1p(exp_scores_neg)
60 | loss_value = loss_value.dot(weights) / total_weights
61 |
62 | #compute loss slope
63 | log_probs = np.empty_like(scores)
64 | log_probs[pos_idx] = 1.0 / (1.0 + exp_scores_pos)
65 | log_probs[~pos_idx] = (exp_scores_neg / (1.0 + exp_scores_neg))
66 | log_probs -= 1.0
67 | log_probs *= weights
68 | loss_slope = Z.T.dot(log_probs) / total_weights
69 |
70 | return loss_value, loss_slope
71 |
72 | def log_loss_value_from_scores(weights, total_weights, scores):
73 | """
74 | computes the logistic loss value from a vector of scores in a numerically stable way
75 | where scores = Z.dot(rho)
76 |
77 | see also: http://stackoverflow.com/questions/20085768/
78 |
79 | this function is used for heuristics (discrete_descent, sequential_rounding).
80 | to save computation when running the heuristics, we store the scores and
81 | call this function to compute the loss directly from the scores
82 | this reduces the need to recompute the dot product.
83 |
84 | Parameters
85 | ----------
86 | scores numpy.array of scores = Z.dot(rho)
87 | total_weights numpy.sum(total_weights) (only included to reduce computation)
88 | weights numpy.array of sample weights with shape (n_rows,)
89 |
90 | Returns
91 | -------
92 | loss_value scalar = 1/n_rows * sum(log( 1 .+ exp(-Z*rho))
93 |
94 | """
95 | pos_idx = scores > 0
96 | loss_value = np.empty_like(scores)
97 | loss_value[pos_idx] = np.log1p(np.exp(-scores[pos_idx]))
98 | loss_value[~pos_idx] = -scores[~pos_idx] + np.log1p(np.exp(scores[~pos_idx]))
99 | loss_value = loss_value.dot(weights) / total_weights
100 |
101 | return loss_value
--------------------------------------------------------------------------------
/examples/data/breastcancer_cvindices.csv:
--------------------------------------------------------------------------------
1 | 2
2 | 5
3 | 2
4 | 4
5 | 4
6 | 5
7 | 5
8 | 3
9 | 2
10 | 5
11 | 5
12 | 2
13 | 1
14 | 2
15 | 3
16 | 5
17 | 5
18 | 1
19 | 3
20 | 4
21 | 4
22 | 1
23 | 1
24 | 1
25 | 1
26 | 3
27 | 4
28 | 5
29 | 2
30 | 4
31 | 3
32 | 2
33 | 5
34 | 2
35 | 5
36 | 1
37 | 3
38 | 1
39 | 4
40 | 1
41 | 5
42 | 4
43 | 3
44 | 1
45 | 5
46 | 5
47 | 5
48 | 2
49 | 1
50 | 5
51 | 4
52 | 3
53 | 2
54 | 3
55 | 1
56 | 2
57 | 1
58 | 2
59 | 4
60 | 3
61 | 3
62 | 2
63 | 3
64 | 1
65 | 1
66 | 1
67 | 5
68 | 3
69 | 2
70 | 4
71 | 1
72 | 3
73 | 5
74 | 3
75 | 1
76 | 1
77 | 4
78 | 3
79 | 2
80 | 1
81 | 4
82 | 5
83 | 2
84 | 5
85 | 2
86 | 2
87 | 3
88 | 2
89 | 3
90 | 2
91 | 1
92 | 3
93 | 5
94 | 3
95 | 1
96 | 2
97 | 4
98 | 3
99 | 2
100 | 5
101 | 5
102 | 3
103 | 4
104 | 2
105 | 4
106 | 5
107 | 3
108 | 2
109 | 4
110 | 4
111 | 3
112 | 4
113 | 2
114 | 5
115 | 1
116 | 4
117 | 4
118 | 4
119 | 3
120 | 1
121 | 2
122 | 1
123 | 2
124 | 3
125 | 3
126 | 4
127 | 5
128 | 1
129 | 4
130 | 4
131 | 3
132 | 4
133 | 1
134 | 2
135 | 1
136 | 3
137 | 3
138 | 2
139 | 2
140 | 3
141 | 1
142 | 1
143 | 3
144 | 3
145 | 5
146 | 4
147 | 1
148 | 4
149 | 1
150 | 3
151 | 4
152 | 3
153 | 4
154 | 1
155 | 1
156 | 3
157 | 4
158 | 2
159 | 2
160 | 3
161 | 5
162 | 1
163 | 1
164 | 2
165 | 5
166 | 1
167 | 3
168 | 2
169 | 2
170 | 5
171 | 4
172 | 1
173 | 5
174 | 2
175 | 4
176 | 3
177 | 1
178 | 1
179 | 5
180 | 4
181 | 4
182 | 1
183 | 1
184 | 3
185 | 5
186 | 4
187 | 1
188 | 3
189 | 5
190 | 1
191 | 4
192 | 5
193 | 5
194 | 2
195 | 2
196 | 5
197 | 4
198 | 5
199 | 2
200 | 4
201 | 4
202 | 1
203 | 1
204 | 5
205 | 3
206 | 1
207 | 1
208 | 5
209 | 5
210 | 4
211 | 2
212 | 4
213 | 5
214 | 1
215 | 4
216 | 4
217 | 2
218 | 2
219 | 2
220 | 1
221 | 1
222 | 3
223 | 4
224 | 5
225 | 3
226 | 4
227 | 4
228 | 3
229 | 3
230 | 3
231 | 3
232 | 5
233 | 3
234 | 3
235 | 3
236 | 1
237 | 1
238 | 3
239 | 2
240 | 5
241 | 2
242 | 5
243 | 4
244 | 5
245 | 4
246 | 2
247 | 1
248 | 4
249 | 4
250 | 4
251 | 2
252 | 4
253 | 4
254 | 4
255 | 3
256 | 3
257 | 3
258 | 5
259 | 1
260 | 2
261 | 1
262 | 2
263 | 1
264 | 2
265 | 3
266 | 5
267 | 4
268 | 5
269 | 1
270 | 3
271 | 4
272 | 2
273 | 3
274 | 4
275 | 5
276 | 1
277 | 2
278 | 3
279 | 4
280 | 5
281 | 5
282 | 5
283 | 2
284 | 3
285 | 2
286 | 2
287 | 5
288 | 3
289 | 4
290 | 3
291 | 3
292 | 2
293 | 5
294 | 4
295 | 2
296 | 1
297 | 1
298 | 3
299 | 2
300 | 3
301 | 2
302 | 5
303 | 4
304 | 1
305 | 2
306 | 2
307 | 1
308 | 2
309 | 2
310 | 1
311 | 5
312 | 4
313 | 5
314 | 5
315 | 5
316 | 2
317 | 1
318 | 1
319 | 2
320 | 3
321 | 3
322 | 2
323 | 2
324 | 5
325 | 2
326 | 2
327 | 3
328 | 1
329 | 5
330 | 5
331 | 4
332 | 3
333 | 5
334 | 2
335 | 4
336 | 1
337 | 5
338 | 2
339 | 2
340 | 5
341 | 2
342 | 4
343 | 1
344 | 5
345 | 1
346 | 5
347 | 3
348 | 5
349 | 2
350 | 3
351 | 1
352 | 2
353 | 4
354 | 3
355 | 3
356 | 2
357 | 3
358 | 4
359 | 2
360 | 5
361 | 2
362 | 2
363 | 5
364 | 2
365 | 4
366 | 3
367 | 1
368 | 1
369 | 4
370 | 4
371 | 3
372 | 3
373 | 1
374 | 1
375 | 5
376 | 5
377 | 4
378 | 3
379 | 3
380 | 4
381 | 5
382 | 2
383 | 5
384 | 2
385 | 5
386 | 1
387 | 1
388 | 1
389 | 4
390 | 2
391 | 2
392 | 1
393 | 4
394 | 3
395 | 5
396 | 3
397 | 3
398 | 2
399 | 5
400 | 5
401 | 3
402 | 2
403 | 1
404 | 2
405 | 4
406 | 1
407 | 2
408 | 5
409 | 1
410 | 5
411 | 4
412 | 4
413 | 5
414 | 1
415 | 3
416 | 3
417 | 2
418 | 1
419 | 4
420 | 3
421 | 3
422 | 4
423 | 3
424 | 4
425 | 5
426 | 2
427 | 5
428 | 2
429 | 1
430 | 4
431 | 5
432 | 1
433 | 5
434 | 3
435 | 5
436 | 5
437 | 5
438 | 5
439 | 3
440 | 4
441 | 2
442 | 1
443 | 5
444 | 3
445 | 2
446 | 4
447 | 4
448 | 4
449 | 1
450 | 1
451 | 4
452 | 4
453 | 2
454 | 5
455 | 1
456 | 1
457 | 4
458 | 1
459 | 3
460 | 5
461 | 1
462 | 1
463 | 4
464 | 2
465 | 2
466 | 4
467 | 2
468 | 1
469 | 3
470 | 2
471 | 1
472 | 1
473 | 3
474 | 1
475 | 3
476 | 2
477 | 5
478 | 5
479 | 2
480 | 1
481 | 4
482 | 3
483 | 3
484 | 5
485 | 3
486 | 3
487 | 3
488 | 1
489 | 3
490 | 1
491 | 5
492 | 5
493 | 4
494 | 2
495 | 2
496 | 3
497 | 1
498 | 4
499 | 3
500 | 1
501 | 1
502 | 5
503 | 4
504 | 1
505 | 3
506 | 4
507 | 4
508 | 1
509 | 3
510 | 5
511 | 5
512 | 1
513 | 1
514 | 4
515 | 4
516 | 5
517 | 4
518 | 1
519 | 2
520 | 4
521 | 5
522 | 1
523 | 4
524 | 2
525 | 5
526 | 4
527 | 5
528 | 1
529 | 2
530 | 1
531 | 2
532 | 3
533 | 5
534 | 5
535 | 4
536 | 2
537 | 4
538 | 3
539 | 4
540 | 4
541 | 2
542 | 2
543 | 4
544 | 5
545 | 4
546 | 4
547 | 2
548 | 1
549 | 5
550 | 1
551 | 2
552 | 5
553 | 1
554 | 2
555 | 3
556 | 3
557 | 1
558 | 2
559 | 3
560 | 4
561 | 2
562 | 3
563 | 4
564 | 5
565 | 4
566 | 1
567 | 2
568 | 3
569 | 2
570 | 1
571 | 2
572 | 5
573 | 1
574 | 5
575 | 1
576 | 2
577 | 1
578 | 3
579 | 5
580 | 2
581 | 5
582 | 5
583 | 1
584 | 2
585 | 3
586 | 3
587 | 4
588 | 5
589 | 5
590 | 4
591 | 3
592 | 5
593 | 2
594 | 4
595 | 5
596 | 2
597 | 5
598 | 4
599 | 4
600 | 1
601 | 3
602 | 5
603 | 2
604 | 2
605 | 4
606 | 1
607 | 2
608 | 4
609 | 3
610 | 3
611 | 4
612 | 3
613 | 2
614 | 3
615 | 1
616 | 4
617 | 3
618 | 4
619 | 3
620 | 5
621 | 2
622 | 5
623 | 4
624 | 4
625 | 4
626 | 3
627 | 2
628 | 1
629 | 5
630 | 3
631 | 1
632 | 3
633 | 2
634 | 4
635 | 3
636 | 5
637 | 5
638 | 1
639 | 2
640 | 3
641 | 4
642 | 2
643 | 5
644 | 4
645 | 1
646 | 5
647 | 3
648 | 2
649 | 5
650 | 5
651 | 3
652 | 2
653 | 4
654 | 3
655 | 4
656 | 5
657 | 4
658 | 4
659 | 4
660 | 4
661 | 1
662 | 4
663 | 5
664 | 3
665 | 2
666 | 1
667 | 2
668 | 3
669 | 1
670 | 1
671 | 2
672 | 3
673 | 2
674 | 1
675 | 5
676 | 1
677 | 5
678 | 1
679 | 4
680 | 3
681 | 3
682 | 5
683 | 3
684 |
--------------------------------------------------------------------------------
/examples/ex_03_constraints.py:
--------------------------------------------------------------------------------
1 | import os
2 | import numpy as np
3 | import cplex as cplex
4 | import pprint
5 | import riskslim
6 |
7 | # data
8 | import riskslim.coefficient_set
9 |
10 | data_name = "breastcancer" # name of the data
11 | data_dir = os.getcwd() + '/examples/data/' # directory where datasets are stored
12 | data_csv_file = data_dir + data_name + '_data.csv' # csv file for the dataset
13 | sample_weights_csv_file = None # csv file of sample weights for the dataset (optional)
14 |
15 | # problem parameters
16 | max_coefficient = 5 # value of largest/smallest coefficient
17 | max_L0_value = 5 # maximum model size
18 | max_offset = 50 # maximum value of offset parameter (optional)
19 | c0_value = 1e-6 # L0-penalty parameter such that c0_value > 0; larger values -> sparser models; we set to a small value (1e-6) so that we get a model with max_L0_value terms
20 | w_pos = 1.00 # relative weight on examples with y = +1; w_neg = 1.00 (optional)
21 |
22 | # load data from disk
23 | data = riskslim.load_data_from_csv(dataset_csv_file = data_csv_file, sample_weights_csv_file = sample_weights_csv_file)
24 | N, P = data['X'].shape
25 |
26 | # create coefficient set and set the value of the offset parameter
27 | coef_set = riskslim.CoefficientSet(variable_names=data['variable_names'], lb=-max_coefficient, ub=max_coefficient, sign=0)
28 | coef_set.update_intercept_bounds(X = data['X'], y = data['Y'], max_offset = max_offset)
29 |
30 | # create constraint
31 | trivial_L0_max = P - np.sum(coef_set.C_0j == 0)
32 | max_L0_value = min(max_L0_value, trivial_L0_max)
33 |
34 | constraints = {
35 | 'L0_min': 0,
36 | 'L0_max': max_L0_value,
37 | 'coef_set':coef_set,
38 | }
39 |
40 |
41 | # major settings (see riskslim_ex_02_complete for full set of options)
42 | settings = {
43 | # Problem Parameters
44 | 'c0_value': c0_value,
45 | 'w_pos': w_pos,
46 | #
47 | # LCPA Settings
48 | 'max_runtime': 300.0, # max runtime for LCPA
49 | 'max_tolerance': np.finfo('float').eps, # tolerance to stop LCPA (set to 0 to return provably optimal solution)
50 | 'display_cplex_progress': True, # print CPLEX progress on screen
51 | 'loss_computation': 'normal', # how to compute the loss function ('normal','fast','lookup')
52 | #
53 | # RiskSLIM MIP settings
54 | 'drop_variables': False,
55 | #
56 | # LCPA Improvements
57 | 'round_flag': False, # round continuous solutions with SeqRd
58 | 'polish_flag': False, # polish integer feasible solutions with DCD
59 | 'chained_updates_flag': False, # use chained updates
60 | 'initialization_flag': False, # use initialization procedure
61 | 'init_max_runtime': 300.0, # max time to run CPA in initialization procedure
62 | 'add_cuts_at_heuristic_solutions': True, # add cuts at integer feasible solutions found using polishing/rounding
63 | #
64 | # CPLEX Solver Parameters
65 | 'cplex_randomseed': 0, # random seed
66 | 'cplex_mipemphasis': 0, # cplex MIP strategy
67 | }
68 |
69 | # turn on at your own risk
70 | settings['round_flag'] = False
71 | settings['polish_flag'] = False
72 | settings['chained_updates_flag'] = False
73 | settings['initialization_flag'] = False
74 |
75 |
76 | # initialize MIP for lattice CPA
77 | mip_objects = riskslim.setup_lattice_cpa(data, constraints, settings)
78 |
79 | # add operational constraints
80 | mip, indices = mip_objects['mip'], mip_objects['indices']
81 | get_alpha_name = lambda var_name: 'alpha_' + str(data['variable_names'].index(var_name))
82 | get_alpha_ind = lambda var_names: [get_alpha_name(v) for v in var_names]
83 |
84 | # to add a constraint like "either "CellSize" or "CellShape"
85 | # you must formulate the constraint in terms of the alpha variables
86 | # alpha[cell_size] + alpha[cell_shape] <= 1 to MIP
87 | mip.linear_constraints.add(
88 | names = ["EitherOr_CellSize_or_CellShape"],
89 | lin_expr = [cplex.SparsePair(ind = get_alpha_ind(['UniformityOfCellSize', 'UniformityOfCellShape']),
90 | val = [1.0, 1.0])],
91 | senses = "L",
92 | rhs = [1.0])
93 |
94 | mip_objects['mip'] = mip
95 |
96 | # pass MIP back to lattice CPA so that it will solve
97 | model_info, mip_info, lcpa_info = riskslim.finish_lattice_cpa(data, constraints, mip_objects, settings)
98 |
99 | #model info contains key results
100 | pprint.pprint(model_info)
101 | riskslim.print_model(model_info['solution'], data)
102 |
103 | # mip_output contains information to access the MIP
104 | mip_info['risk_slim_mip'] #CPLEX mip
105 | mip_info['risk_slim_idx'] #indices of the relevant constraints
106 |
107 | # lcpa_output contains detailed information about LCPA
108 | pprint.pprint(lcpa_info)
109 |
110 |
111 |
112 |
113 |
--------------------------------------------------------------------------------
/riskslim/defaults.py:
--------------------------------------------------------------------------------
1 | import numpy as np
2 |
3 | INTERCEPT_NAME = '(Intercept)'
4 |
5 | # Settings
6 | DEFAULT_LCPA_SETTINGS = {
7 | #
8 | 'c0_value': 1e-6,
9 | 'w_pos': 1.00,
10 | #
11 | # MIP Formulation
12 | 'drop_variables': True, #drop variables
13 | 'tight_formulation': True, #use a slightly tighter MIP formulation
14 | 'include_auxillary_variable_for_objval': True,
15 | 'include_auxillary_variable_for_L0_norm': True,
16 | #
17 | # LCPA Settings
18 | 'max_runtime': 300.0, # max runtime for LCPA
19 | 'max_tolerance': 0.000001, # tolerance to stop LCPA
20 | 'display_cplex_progress': True, # setting to True shows CPLEX progress
21 | 'loss_computation': 'normal', # type of loss computation to use ('normal','fast','lookup')
22 | 'chained_updates_flag': True, # use chained updates
23 | 'initialization_flag': False, # use initialization procedure
24 | 'initial_bound_updates': True, # update bounds before solving
25 | 'add_cuts_at_heuristic_solutions': True, #add cuts at integer feasible solutions found using polishing/rounding
26 | #
27 | # LCPA Rounding Heuristic
28 | 'round_flag': True, # round continuous solutions with SeqRd
29 | 'polish_rounded_solutions': True, # polish solutions rounded with SeqRd using DCD
30 | 'rounding_tolerance': float('inf'), # only solutions with objective value < (1 + tol) are rounded
31 | 'rounding_start_cuts': 0, # cuts needed to start using rounding heuristic
32 | 'rounding_start_gap': float('inf'), # optimality gap needed to start using rounding heuristic
33 | 'rounding_stop_cuts': 20000, # cuts needed to stop using rounding heuristic
34 | 'rounding_stop_gap': 0.2, # optimality gap needed to stop using rounding heuristic
35 | #
36 | # LCPA Polishing Heuristic
37 | 'polish_flag': True, # polish integer feasible solutions with DCD
38 | 'polishing_tolerance': 0.1, # only solutions with objective value (1 + polishing_ub_to_objval_relgap) are polished. setting to
39 | 'polishing_max_runtime': 10.0, # max time to run polishing each time
40 | 'polishing_max_solutions': 5.0, # max # of solutions to polish each time
41 | 'polishing_start_cuts': 0, # cuts needed to start using polishing heuristic
42 | 'polishing_start_gap': float('inf'), # min optimality gap needed to start using polishing heuristic
43 | 'polishing_stop_cuts': float('inf'), # cuts needed to stop using polishing heuristic
44 | 'polishing_stop_gap': 5.0, # max optimality gap required to stop using polishing heuristic
45 | #
46 | # Internal Parameters
47 | 'purge_loss_cuts': False,
48 | 'purge_bound_cuts': False,
49 | }
50 |
51 | DEFAULT_CPLEX_SETTINGS = {
52 | 'randomseed': 0, # random seed
53 | 'mipemphasis': 0, # cplex MIP strategy
54 | 'mipgap': np.finfo('float').eps, #
55 | 'absmipgap': np.finfo('float').eps, #
56 | 'integrality_tolerance': np.finfo('float').eps, #
57 | 'repairtries': 20, # number of tries to repair user provided solutions
58 | 'poolsize': 100, # number of feasible solutions to keep in solution pool
59 | 'poolrelgap': float('nan'), # discard if solutions
60 | 'poolreplace': 2, # solution pool
61 | 'n_cores': 1, # number of cores to use in B & B (must be 1)
62 | 'nodefilesize': (120 * 1024) / 1, # node file size
63 | }
64 |
65 | DEFAULT_CPA_SETTINGS = {
66 | #
67 | 'type': 'cvx',
68 | 'display_progress': True, # print progress of initialization procedure
69 | 'display_cplex_progress': False, # print of CPLEX during intialization procedure
70 | 'save_progress': False, # print progress of initialization procedure
71 | 'update_bounds': True,
72 | #
73 | 'max_runtime': 300.0, # max time to run CPA in initialization procedure
74 | 'max_runtime_per_iteration': 15.0, # max time per iteration of CPA
75 | #
76 | 'max_coefficient_gap': 0.49, # stopping tolerance for CPA (based on gap between consecutive solutions)
77 | 'min_iterations_before_coefficient_gap_check': 250,
78 | #
79 | 'max_iterations': 10000, # max # of cuts needed to stop CPA
80 | 'max_tolerance': 0.0001, # stopping tolerance for CPA (based on optimality gap)
81 | }
82 |
83 | DEFAULT_INITIALIZATION_SETTINGS = {
84 | 'type': 'cvx',
85 | 'use_rounding': True, # use SeqRd in initialization procedure
86 | 'rounding_max_runtime': 30.0, # max runtime for Rs in initialization procedure
87 | 'rounding_max_solutions': 5, # max solutions to round using Rd
88 | #
89 | 'use_sequential_rounding': True, # use SeqRd in initialization procedure
90 | 'sequential_rounding_max_runtime': 30.0, # max runtime for SeqRd in initialization procedure
91 | 'sequential_rounding_max_solutions': 5, # max solutions to round using SeqRd
92 | #
93 | 'polishing_after': True, # polish after rounding
94 | 'polishing_max_runtime': 30.0, # max runtime for polishing
95 | 'polishing_max_solutions': 5 # max solutions to polish
96 | }
97 |
98 | # Initialization Settings includes CPA Settings
99 | DEFAULT_INITIALIZATION_SETTINGS.update(DEFAULT_CPA_SETTINGS)
100 |
101 | # LCPA Settings includes Initialization and CPLEX settings
102 | DEFAULT_LCPA_SETTINGS.update({'init_%s' % k: v for k,v in DEFAULT_INITIALIZATION_SETTINGS.items()})
103 | DEFAULT_LCPA_SETTINGS.update({'cplex_%s' % k: v for k,v in DEFAULT_CPLEX_SETTINGS.items()})
--------------------------------------------------------------------------------
/examples/data/breastcancer_weights.csv:
--------------------------------------------------------------------------------
1 | 1
2 | 1
3 | 1
4 | 1
5 | 1
6 | 1
7 | 1
8 | 1
9 | 1
10 | 1
11 | 1
12 | 1
13 | 1
14 | 1
15 | 1
16 | 1
17 | 1
18 | 1
19 | 1
20 | 1
21 | 1
22 | 1
23 | 1
24 | 1
25 | 1
26 | 1
27 | 1
28 | 1
29 | 1
30 | 1
31 | 1
32 | 1
33 | 1
34 | 1
35 | 1
36 | 1
37 | 1
38 | 1
39 | 1
40 | 1
41 | 1
42 | 1
43 | 1
44 | 1
45 | 1
46 | 1
47 | 1
48 | 1
49 | 1
50 | 1
51 | 1
52 | 1
53 | 1
54 | 1
55 | 1
56 | 1
57 | 1
58 | 1
59 | 1
60 | 1
61 | 1
62 | 1
63 | 1
64 | 1
65 | 1
66 | 1
67 | 1
68 | 1
69 | 1
70 | 1
71 | 1
72 | 1
73 | 1
74 | 1
75 | 1
76 | 1
77 | 1
78 | 1
79 | 1
80 | 1
81 | 1
82 | 1
83 | 1
84 | 1
85 | 1
86 | 1
87 | 1
88 | 1
89 | 1
90 | 1
91 | 1
92 | 1
93 | 1
94 | 1
95 | 1
96 | 1
97 | 1
98 | 1
99 | 1
100 | 1
101 | 1
102 | 1
103 | 1
104 | 1
105 | 1
106 | 1
107 | 1
108 | 1
109 | 1
110 | 1
111 | 1
112 | 1
113 | 1
114 | 1
115 | 1
116 | 1
117 | 1
118 | 1
119 | 1
120 | 1
121 | 1
122 | 1
123 | 1
124 | 1
125 | 1
126 | 1
127 | 1
128 | 1
129 | 1
130 | 1
131 | 1
132 | 1
133 | 1
134 | 1
135 | 1
136 | 1
137 | 1
138 | 1
139 | 1
140 | 1
141 | 1
142 | 1
143 | 1
144 | 1
145 | 1
146 | 1
147 | 1
148 | 1
149 | 1
150 | 1
151 | 1
152 | 1
153 | 1
154 | 1
155 | 1
156 | 1
157 | 1
158 | 1
159 | 1
160 | 1
161 | 1
162 | 1
163 | 1
164 | 1
165 | 1
166 | 1
167 | 1
168 | 1
169 | 1
170 | 1
171 | 1
172 | 1
173 | 1
174 | 1
175 | 1
176 | 1
177 | 1
178 | 1
179 | 1
180 | 1
181 | 1
182 | 1
183 | 1
184 | 1
185 | 1
186 | 1
187 | 1
188 | 1
189 | 1
190 | 1
191 | 1
192 | 1
193 | 1
194 | 1
195 | 1
196 | 1
197 | 1
198 | 1
199 | 1
200 | 1
201 | 1
202 | 1
203 | 1
204 | 1
205 | 1
206 | 1
207 | 1
208 | 1
209 | 1
210 | 1
211 | 1
212 | 1
213 | 1
214 | 1
215 | 1
216 | 1
217 | 1
218 | 1
219 | 1
220 | 1
221 | 1
222 | 1
223 | 1
224 | 1
225 | 1
226 | 1
227 | 1
228 | 1
229 | 1
230 | 1
231 | 1
232 | 1
233 | 1
234 | 1
235 | 1
236 | 1
237 | 1
238 | 1
239 | 1
240 | 1
241 | 1
242 | 1
243 | 1
244 | 1
245 | 1
246 | 1
247 | 1
248 | 1
249 | 1
250 | 1
251 | 1
252 | 1
253 | 1
254 | 1
255 | 1
256 | 1
257 | 1
258 | 1
259 | 1
260 | 1
261 | 1
262 | 1
263 | 1
264 | 1
265 | 1
266 | 1
267 | 1
268 | 1
269 | 1
270 | 1
271 | 1
272 | 1
273 | 1
274 | 1
275 | 1
276 | 1
277 | 1
278 | 1
279 | 1
280 | 1
281 | 1
282 | 1
283 | 1
284 | 1
285 | 1
286 | 1
287 | 1
288 | 1
289 | 1
290 | 1
291 | 1
292 | 1
293 | 1
294 | 1
295 | 1
296 | 1
297 | 1
298 | 1
299 | 1
300 | 1
301 | 1
302 | 1
303 | 1
304 | 1
305 | 1
306 | 1
307 | 1
308 | 1
309 | 1
310 | 1
311 | 1
312 | 1
313 | 1
314 | 1
315 | 1
316 | 1
317 | 1
318 | 1
319 | 1
320 | 1
321 | 1
322 | 1
323 | 1
324 | 1
325 | 1
326 | 1
327 | 1
328 | 1
329 | 1
330 | 1
331 | 1
332 | 1
333 | 1
334 | 1
335 | 1
336 | 1
337 | 1
338 | 1
339 | 1
340 | 1
341 | 1
342 | 1
343 | 1
344 | 1
345 | 1
346 | 1
347 | 1
348 | 1
349 | 1
350 | 1
351 | 1
352 | 1
353 | 1
354 | 1
355 | 1
356 | 1
357 | 1
358 | 1
359 | 1
360 | 1
361 | 1
362 | 1
363 | 1
364 | 1
365 | 1
366 | 1
367 | 1
368 | 1
369 | 1
370 | 1
371 | 1
372 | 1
373 | 1
374 | 1
375 | 1
376 | 1
377 | 1
378 | 1
379 | 1
380 | 1
381 | 1
382 | 1
383 | 1
384 | 1
385 | 1
386 | 1
387 | 1
388 | 1
389 | 1
390 | 1
391 | 1
392 | 1
393 | 1
394 | 1
395 | 1
396 | 1
397 | 1
398 | 1
399 | 1
400 | 1
401 | 1
402 | 1
403 | 1
404 | 1
405 | 1
406 | 1
407 | 1
408 | 1
409 | 1
410 | 1
411 | 1
412 | 1
413 | 1
414 | 1
415 | 1
416 | 1
417 | 1
418 | 1
419 | 1
420 | 1
421 | 1
422 | 1
423 | 1
424 | 1
425 | 1
426 | 1
427 | 1
428 | 1
429 | 1
430 | 1
431 | 1
432 | 1
433 | 1
434 | 1
435 | 1
436 | 1
437 | 1
438 | 1
439 | 1
440 | 1
441 | 1
442 | 1
443 | 1
444 | 1
445 | 1
446 | 1
447 | 1
448 | 1
449 | 1
450 | 1
451 | 1
452 | 1
453 | 1
454 | 1
455 | 1
456 | 1
457 | 1
458 | 1
459 | 1
460 | 1
461 | 1
462 | 1
463 | 1
464 | 1
465 | 1
466 | 1
467 | 1
468 | 1
469 | 1
470 | 1
471 | 1
472 | 1
473 | 1
474 | 1
475 | 1
476 | 1
477 | 1
478 | 1
479 | 1
480 | 1
481 | 1
482 | 1
483 | 1
484 | 1
485 | 1
486 | 1
487 | 1
488 | 1
489 | 1
490 | 1
491 | 1
492 | 1
493 | 1
494 | 1
495 | 1
496 | 1
497 | 1
498 | 1
499 | 1
500 | 1
501 | 1
502 | 1
503 | 1
504 | 1
505 | 1
506 | 1
507 | 1
508 | 1
509 | 1
510 | 1
511 | 1
512 | 1
513 | 1
514 | 1
515 | 1
516 | 1
517 | 1
518 | 1
519 | 1
520 | 1
521 | 1
522 | 1
523 | 1
524 | 1
525 | 1
526 | 1
527 | 1
528 | 1
529 | 1
530 | 1
531 | 1
532 | 1
533 | 1
534 | 1
535 | 1
536 | 1
537 | 1
538 | 1
539 | 1
540 | 1
541 | 1
542 | 1
543 | 1
544 | 1
545 | 1
546 | 1
547 | 1
548 | 1
549 | 1
550 | 1
551 | 1
552 | 1
553 | 1
554 | 1
555 | 1
556 | 1
557 | 1
558 | 1
559 | 1
560 | 1
561 | 1
562 | 1
563 | 1
564 | 1
565 | 1
566 | 1
567 | 1
568 | 1
569 | 1
570 | 1
571 | 1
572 | 1
573 | 1
574 | 1
575 | 1
576 | 1
577 | 1
578 | 1
579 | 1
580 | 1
581 | 1
582 | 1
583 | 1
584 | 1
585 | 1
586 | 1
587 | 1
588 | 1
589 | 1
590 | 1
591 | 1
592 | 1
593 | 1
594 | 1
595 | 1
596 | 1
597 | 1
598 | 1
599 | 1
600 | 1
601 | 1
602 | 1
603 | 1
604 | 1
605 | 1
606 | 1
607 | 1
608 | 1
609 | 1
610 | 1
611 | 1
612 | 1
613 | 1
614 | 1
615 | 1
616 | 1
617 | 1
618 | 1
619 | 1
620 | 1
621 | 1
622 | 1
623 | 1
624 | 1
625 | 1
626 | 1
627 | 1
628 | 1
629 | 1
630 | 1
631 | 1
632 | 1
633 | 1
634 | 1
635 | 1
636 | 1
637 | 1
638 | 1
639 | 1
640 | 1
641 | 1
642 | 1
643 | 1
644 | 1
645 | 1
646 | 1
647 | 1
648 | 1
649 | 1
650 | 1
651 | 1
652 | 1
653 | 1
654 | 1
655 | 1
656 | 1
657 | 1
658 | 1
659 | 1
660 | 1
661 | 1
662 | 1
663 | 1
664 | 1
665 | 1
666 | 1
667 | 1
668 | 1
669 | 1
670 | 1
671 | 1
672 | 1
673 | 1
674 | 1
675 | 1
676 | 1
677 | 1
678 | 1
679 | 1
680 | 1
681 | 1
682 | 1
683 | 1
--------------------------------------------------------------------------------
/examples/ex_02_advanced_options.py:
--------------------------------------------------------------------------------
1 | import os
2 | import numpy as np
3 | import pprint
4 | import riskslim
5 |
6 | # data
7 | data_name = "breastcancer" # name of the data
8 | data_dir = os.getcwd() + '/examples/data/' # directory where datasets are stored
9 | data_csv_file = data_dir + data_name + '_data.csv' # csv file for the dataset
10 | sample_weights_csv_file = None # csv file of sample weights for the dataset (optional)
11 |
12 | # problem parameters
13 | max_coefficient = 5 # value of largest/smallest coefficient
14 | max_L0_value = 5 # maximum model size
15 | max_offset = 50 # maximum value of offset parameter (optional)
16 | c0_value = 1e-6 # L0-penalty parameter such that c0_value > 0; larger values -> sparser models; we set to a small value (1e-6) so that we get a model with max_L0_value terms
17 | w_pos = 1.00 # relative weight on examples with y = +1; w_neg = 1.00 (optional)
18 |
19 | # load dataset
20 | data = riskslim.load_data_from_csv(dataset_csv_file = data_csv_file, sample_weights_csv_file = sample_weights_csv_file)
21 | N, P = data['X'].shape
22 |
23 | # coefficient set
24 | coef_set = riskslim.CoefficientSet(variable_names = data['variable_names'], lb=-max_coefficient, ub=max_coefficient, sign=0)
25 | coef_set.update_intercept_bounds(X = data['X'], y = data['Y'], max_offset = max_offset)
26 |
27 | # create constraint dictionary
28 | N, P = data['X'].shape
29 | trivial_L0_max = P - np.sum(coef_set.C_0j == 0)
30 | max_L0_value = min(max_L0_value, trivial_L0_max)
31 |
32 | constraints = {
33 | 'L0_min': 0,
34 | 'L0_max': max_L0_value,
35 | 'coef_set': coef_set,
36 | }
37 |
38 | # Run RiskSLIM
39 | settings = {
40 | #
41 | 'c0_value': c0_value,
42 | 'w_pos': w_pos,
43 | #
44 | # LCPA Settings
45 | 'max_runtime': 300.0, # max runtime for LCPA
46 | 'max_tolerance': np.finfo('float').eps, # tolerance to stop LCPA (set to 0 to return provably optimal solution)
47 | 'display_cplex_progress': True, # set to True to print CPLEX progress
48 | 'loss_computation': 'lookup', # how to compute the loss function ('normal','fast','lookup')
49 | #
50 | # Other LCPA Heuristics
51 | 'chained_updates_flag': True, # use chained updates
52 | 'add_cuts_at_heuristic_solutions': True, # add cuts at integer feasible solutions found using polishing/rounding
53 | #
54 | # LCPA Rounding Heuristic
55 | 'round_flag': False, # round continuous solutions with SeqRd
56 | 'polish_rounded_solutions': True, # polish solutions rounded with SeqRd using DCD
57 | 'rounding_tolerance': float('inf'), # only solutions with objective value < (1 + tol) are rounded
58 | 'rounding_start_cuts': 0, # cuts needed to start using rounding heuristic
59 | 'rounding_start_gap': float('inf'), # optimality gap needed to start using rounding heuristic
60 | 'rounding_stop_cuts': 20000, # cuts needed to stop using rounding heuristic
61 | 'rounding_stop_gap': 0.2, # optimality gap needed to stop using rounding heuristic
62 | #
63 | # LCPA Polishing Heuristic
64 | 'polish_flag': False, # polish integer feasible solutions with DCD
65 | 'polishing_tolerance': 0.1, # only solutions with objective value (1 + tol) are polished.
66 | 'polishing_max_runtime': 10.0, # max time to run polishing each time
67 | 'polishing_max_solutions': 5.0, # max # of solutions to polish each time
68 | 'polishing_start_cuts': 0, # cuts needed to start using polishing heuristic
69 | 'polishing_start_gap': float('inf'), # min optimality gap needed to start using polishing heuristic
70 | 'polishing_stop_cuts': float('inf'), # cuts needed to stop using polishing heuristic
71 | 'polishing_stop_gap': 0.0, # max optimality gap required to stop using polishing heuristic
72 | #
73 | # Initialization Procedure
74 | 'initialization_flag': True, # use initialization procedure
75 | 'init_display_progress': True, # show progress of initialization procedure
76 | 'init_display_cplex_progress': False, # show progress of CPLEX during intialization procedure
77 | #
78 | 'init_max_runtime': 300.0, # max time to run CPA in initialization procedure
79 | 'init_max_iterations': 10000, # max # of cuts needed to stop CPA
80 | 'init_max_tolerance': 0.0001, # tolerance of solution to stop CPA
81 | 'init_max_runtime_per_iteration': 300.0, # max time per iteration of CPA
82 | 'init_max_cplex_time_per_iteration': 10.0, # max time per iteration to solve surrogate problem in CPA
83 | #
84 | 'init_use_rounding': True, # use Rd in initialization procedure
85 | 'init_rounding_max_runtime': 30.0, # max runtime for Rd in initialization procedure
86 | 'init_rounding_max_solutions': 5, # max solutions to round using Rd
87 | #
88 | 'init_use_sequential_rounding': True, # use SeqRd in initialization procedure
89 | 'init_sequential_rounding_max_runtime': 10.0, # max runtime for SeqRd in initialization procedure
90 | 'init_sequential_rounding_max_solutions': 5, # max solutions to round using SeqRd
91 | #
92 | 'init_polishing_after': True, # polish after rounding
93 | 'init_polishing_max_runtime': 30.0, # max runtime for polishing
94 | 'init_polishing_max_solutions': 5, # max solutions to polish
95 | #
96 | # CPLEX Solver Parameters
97 | 'cplex_randomseed': 0, # random seed
98 | 'cplex_mipemphasis': 0, # cplex MIP strategy
99 | }
100 |
101 | # train model using lattice_cpa
102 | model_info, mip_info, lcpa_info = riskslim.run_lattice_cpa(data, constraints, settings)
103 |
104 | #model info contains key results
105 | pprint.pprint(model_info)
106 | riskslim.print_model(model_info['solution'], data)
107 |
108 | # mip_output contains information to access the MIP
109 | mip_info['risk_slim_mip'] #CPLEX mip
110 | mip_info['risk_slim_idx'] #indices of the relevant constraints
111 |
112 | # lcpa_output contains detailed information about LCPA
113 | pprint.pprint(lcpa_info)
114 |
115 |
116 |
117 |
118 |
119 |
--------------------------------------------------------------------------------
/riskslim/tests/test_risk_slim.py:
--------------------------------------------------------------------------------
1 | import os
2 | import pprint
3 |
4 | import numpy as np
5 | import riskslim
6 |
7 | # Dataset Strategy
8 | #
9 | # variables: binary, real,
10 | # N+: 0, 1, >1
11 | # N-: 0, 1, >1
12 |
13 |
14 | # Testing Strategy
15 | #
16 | # loss_computation normal, fast, lookup
17 | # max_coefficient 0, 1, >1
18 | # max_L0_value 0, 1, >1
19 | # max_offset 0, 1, Inf
20 | # c0_value eps, 1e-8, 0.01, C0_max
21 | # sample_weights no, yes
22 | # w_pos 1.00, < 1.00, > 1.00
23 | # initialization on, off
24 | # chained_updates on, off
25 | # polishing on, off
26 | # seq_rd on, off
27 |
28 | # data
29 | data_name = "breastcancer" # name of the data
30 | data_dir = os.getcwd() + '/examples/data/' # directory where datasets are stored
31 | data_csv_file = data_dir + data_name + '_data.csv' # csv file for the dataset
32 | sample_weights_csv_file = None # csv file of sample weights for the dataset (optional)
33 |
34 | default_settings = {
35 | #
36 | 'c0_value': 1e-6,
37 | 'w_pos': 1.00,
38 | #
39 | # LCPA Settings
40 | 'max_runtime': 300.0, # max runtime for LCPA
41 | 'max_tolerance': np.finfo('float').eps, # tolerance to stop LCPA (set to 0 to return provably optimal solution)
42 | 'display_cplex_progress': True, # set to True to print CPLEX progress
43 | 'loss_computation': 'normal', # how to compute the loss function ('normal','fast','lookup')
44 | 'tight_formulation': True, # use a slightly formulation of surrogate MIP that provides a slightly improved formulation
45 | #
46 | # Other LCPA Heuristics
47 | 'chained_updates_flag': True, # use chained updates
48 | 'add_cuts_at_heuristic_solutions': True, # add cuts at integer feasible solutions found using polishing/rounding
49 | #
50 | # LCPA Rounding Heuristic
51 | 'round_flag': True, # round continuous solutions with SeqRd
52 | 'polish_rounded_solutions': True, # polish solutions rounded with SeqRd using DCD
53 | 'rounding_tolerance': float('inf'), # only solutions with objective value < (1 + tol) are rounded
54 | 'rounding_start_cuts': 0, # cuts needed to start using rounding heuristic
55 | 'rounding_start_gap': float('inf'), # optimality gap needed to start using rounding heuristic
56 | 'rounding_stop_cuts': 20000, # cuts needed to stop using rounding heuristic
57 | 'rounding_stop_gap': 0.2, # optimality gap needed to stop using rounding heuristic
58 | #
59 | # LCPA Polishing Heuristic
60 | 'polish_flag': True, # polish integer feasible solutions with DCD
61 | 'polishing_tolerance': 0.1, # only solutions with objective value (1 + tol) are polished.
62 | 'polishing_max_runtime': 10.0, # max time to run polishing each time
63 | 'polishing_max_solutions': 5.0, # max # of solutions to polish each time
64 | 'polishing_start_cuts': 0, # cuts needed to start using polishing heuristic
65 | 'polishing_start_gap': float('inf'), # min optimality gap needed to start using polishing heuristic
66 | 'polishing_stop_cuts': float('inf'), # cuts needed to stop using polishing heuristic
67 | 'polishing_stop_gap': 5.0, # max optimality gap required to stop using polishing heuristic
68 | #
69 | # Initialization Procedure
70 | 'initialization_flag': False, # use initialization procedure
71 | 'init_display_progress': True, # show progress of initialization procedure
72 | 'init_display_cplex_progress': False, # show progress of CPLEX during intialization procedure
73 | #
74 | 'init_max_runtime': 300.0, # max time to run CPA in initialization procedure
75 | 'init_max_iterations': 10000, # max # of cuts needed to stop CPA
76 | 'init_max_tolerance': 0.0001, # tolerance of solution to stop CPA
77 | 'init_max_runtime_per_iteration': 300.0, # max time per iteration of CPA
78 | 'init_max_cplex_time_per_iteration': 10.0, # max time per iteration to solve surrogate problem in CPA
79 | #
80 | 'init_use_sequential_rounding': True, # use SeqRd in initialization procedure
81 | 'init_sequential_rounding_max_runtime': 30.0, # max runtime for SeqRd in initialization procedure
82 | 'init_sequential_rounding_max_solutions': 5, # max solutions to round using SeqRd
83 | 'init_polishing_after': True, # polish after rounding
84 | 'init_polishing_max_runtime': 30.0, # max runtime for polishing
85 | 'init_polishing_max_solutions': 5, # max solutions to polish
86 | #
87 | # CPLEX Solver Parameters
88 | 'cplex_randomseed': 0, # random seed
89 | 'cplex_mipemphasis': 0, # cplex MIP strategy
90 | }
91 |
92 |
93 | def test_risk_slim(data_csv_file, sample_weights_csv_file = None, max_coefficient = 5, max_L0_value = 5, max_offset = 50, c0_value = 1e-6, w_pos = 1.00, settings = None):
94 |
95 | # load dataset
96 | data = riskslim.load_data_from_csv(dataset_csv_file = data_csv_file, sample_weights_csv_file = sample_weights_csv_file)
97 | N, P = data['X'].shape
98 |
99 | # offset value
100 | coef_set = riskslim.CoefficientSet(variable_names=data['variable_names'], lb=-max_coefficient, ub=max_coefficient, sign=0)
101 | coef_set.update_intercept_bounds(X = data['X'], y = data['Y'], max_offset = max_offset, max_L0_value = max_L0_value)
102 |
103 | # create constraint dictionary
104 | trivial_L0_max = P - np.sum(coef_set.C_0j == 0)
105 | max_L0_value = min(max_L0_value, trivial_L0_max)
106 |
107 | constraints = {
108 | 'L0_min': 0,
109 | 'L0_max': max_L0_value,
110 | 'coef_set':coef_set,
111 | }
112 |
113 | # Train model using lattice_cpa
114 | model_info, mip_info, lcpa_info = riskslim.run_lattice_cpa(data, constraints, settings)
115 |
116 | #model info contains key results
117 | pprint.pprint(model_info)
118 |
119 | # lcpa_output contains detailed information about LCPA
120 | pprint.pprint(lcpa_info)
121 |
122 | return True
123 |
124 |
125 | test_risk_slim(data_csv_file = data_csv_file, max_coefficient = 5, max_L0_value = 5, max_offset = 50, settings = default_settings)
126 | test_risk_slim(data_csv_file = data_csv_file, max_coefficient = 5, max_L0_value = 1, max_offset = 50, settings = default_settings)
127 | test_risk_slim(data_csv_file = data_csv_file, max_coefficient = 5, max_L0_value = 0, max_offset = 50, settings = default_settings)
128 | test_risk_slim(data_csv_file = data_csv_file, max_coefficient = 5, max_L0_value = 0, max_offset = 0, settings = default_settings)
129 |
130 |
131 |
--------------------------------------------------------------------------------
/riskslim/loss_functions/lookup_log_loss.pyx:
--------------------------------------------------------------------------------
1 | import cython
2 | import numpy as np
3 | cimport numpy as np
4 | cimport scipy.linalg.cython_blas as blas
5 | cimport libc.math as math
6 |
7 | DTYPE = np.float64
8 | ctypedef np.float64_t DTYPE_t
9 |
10 | #create loss_value_table for logistic loss
11 | @cython.boundscheck(False)
12 | @cython.wraparound(False)
13 | @cython.nonecheck(False)
14 | @cython.cdivision(False)
15 | def get_loss_value_table(int min_score, int max_score):
16 |
17 | cdef:
18 | int lookup_offset = -min_score
19 | np.ndarray[DTYPE_t, ndim=1, mode = "fortran"] loss_value_table = np.empty(max_score - min_score + 1, dtype = DTYPE)
20 | Py_ssize_t i = 0
21 | int s = min_score
22 |
23 | while (s < 0):
24 | loss_value_table[i] = math.log(1.0 + math.exp(s)) - s
25 | i += 1
26 | s += 1
27 |
28 | if s == 0:
29 | loss_value_table[i] = math.M_LN2
30 | i += 1
31 | s += 1
32 |
33 | while s <= max_score:
34 | loss_value_table[i] = math.log1p(math.exp(-s))
35 | i += 1
36 | s += 1
37 | return loss_value_table, lookup_offset
38 |
39 | #create prob_value_table for logistic loss
40 | @cython.boundscheck(False)
41 | @cython.wraparound(False)
42 | @cython.nonecheck(False)
43 | @cython.cdivision(False)
44 | def get_prob_value_table(int min_score, int max_score):
45 |
46 | cdef:
47 | int lookup_offset = -min_score
48 | np.ndarray[DTYPE_t, ndim=1, mode = "fortran"] prob_value_table = np.empty(max_score - min_score + 1, dtype = DTYPE)
49 | Py_ssize_t i = 0
50 | DTYPE_t exp_value
51 | int s = min_score
52 |
53 | while (s < 0):
54 | exp_value = math.exp(s)
55 | prob_value_table[i] = (exp_value / (1.0 + exp_value)) - 1.0
56 | i += 1
57 | s += 1
58 |
59 | if (s == 0):
60 | prob_value_table[i] = -0.5
61 | i += 1
62 | s += 1
63 |
64 | while (s <= max_score):
65 | exp_value = math.exp(-s)
66 | prob_value_table[i] = (1.0 / (1.0 + exp_value)) - 1.0
67 | i += 1
68 | s += 1
69 |
70 | return prob_value_table, lookup_offset
71 |
72 | #create both loss and prob tables for logistic loss
73 | @cython.boundscheck(False)
74 | @cython.wraparound(False)
75 | @cython.nonecheck(False)
76 | @cython.cdivision(False)
77 | def get_loss_value_and_prob_tables(int min_score, int max_score):
78 |
79 | cdef:
80 | int lookup_offset = -min_score
81 | int table_size = max_score - min_score + 1
82 | np.ndarray[DTYPE_t, ndim=1, mode = "fortran"] loss_value_table = np.empty(table_size, dtype = DTYPE)
83 | np.ndarray[DTYPE_t, ndim=1, mode = "fortran"] prob_value_table = np.empty(table_size, dtype = DTYPE)
84 | Py_ssize_t i = 0
85 | DTYPE_t exp_value
86 | int s = min_score
87 |
88 | while (s < 0):
89 | exp_value = math.exp(s)
90 | loss_value_table[i] = math.log(1.0 + exp_value) - s
91 | prob_value_table[i] = (exp_value / (1.0 + exp_value)) - 1.0
92 | i += 1
93 | s += 1
94 |
95 | if (s == 0):
96 | loss_value_table[i] = math.M_LN2
97 | prob_value_table[i] = -0.5
98 | i += 1
99 | s += 1
100 |
101 | while (s <= max_score):
102 | exp_value = math.exp(-s)
103 | loss_value_table[i] = math.log1p(exp_value)
104 | prob_value_table[i] = (1.0 / (1.0 + exp_value)) - 1.0
105 | i += 1
106 | s += 1
107 |
108 | return loss_value_table, prob_value_table, lookup_offset
109 |
110 | ##############################################################################################################
111 | ##############################################################################################################
112 |
113 | @cython.boundscheck(False)
114 | @cython.wraparound(False)
115 | @cython.nonecheck(False)
116 | @cython.cdivision(False)
117 | def log_loss_value(np.ndarray[DTYPE_t, ndim=2, mode="fortran"] Z,
118 | np.ndarray[DTYPE_t, ndim=1, mode="fortran"] rho,
119 | np.ndarray[DTYPE_t, ndim=1, mode="fortran"] loss_value_table,
120 | int lookup_offset):
121 |
122 | cdef:
123 | int N = Z.shape[0]
124 | int D = Z.shape[1]
125 | int incx = 1 #increments of rho
126 | int incy = 1 #increments of y
127 | double alpha = 1.0
128 | double beta = 0.0
129 | np.ndarray[DTYPE_t, ndim=1, mode = "fortran"] y = np.empty(N, dtype = DTYPE)
130 | Py_ssize_t i
131 | DTYPE_t total_loss = 0.0
132 |
133 | #get scores using dgemv, which computes: y <- alpha * trans(Z) + beta * y
134 | #see also: (http://www.nag.com/numeric/fl/nagdoc_fl22/xhtml/F06/f06paf.xml)
135 | blas.dgemv("N", &N, &D, &alpha, &Z[0,0], &N, &rho[0], &incx, &beta, &y[0], &incy)
136 |
137 | #compute loss
138 | for i in range(N):
139 | total_loss += loss_value_table[(y[i]) + lookup_offset]
140 |
141 | return total_loss/N
142 |
143 | @cython.boundscheck(False)
144 | @cython.wraparound(False)
145 | @cython.nonecheck(False)
146 | @cython.cdivision(False)
147 | def log_loss_value_from_scores(
148 | np.ndarray[DTYPE_t, ndim=1, mode="fortran"] scores,
149 | np.ndarray[DTYPE_t, ndim=1, mode="fortran"] loss_value_table,
150 | int lookup_offset):
151 |
152 | cdef:
153 | Py_ssize_t i
154 | Py_ssize_t N = scores.shape[0]
155 | DTYPE_t total_loss = 0.0
156 |
157 | #compute loss
158 | for i in range(N):
159 | total_loss += loss_value_table[((scores[i]) + lookup_offset)]
160 |
161 | return total_loss/N
162 |
163 | @cython.boundscheck(False)
164 | @cython.wraparound(False)
165 | @cython.nonecheck(False)
166 | @cython.cdivision(False)
167 | def log_loss_value_and_slope(
168 | np.ndarray[DTYPE_t, ndim=2, mode="fortran"] Z,
169 | np.ndarray[DTYPE_t, ndim=1, mode="fortran"] rho,
170 | np.ndarray[DTYPE_t, ndim=1, mode="fortran"] loss_value_table,
171 | np.ndarray[DTYPE_t, ndim=1, mode="fortran"] prob_value_table,
172 | int lookup_offset):
173 |
174 | cdef:
175 | int N = Z.shape[0]
176 | int D = Z.shape[1]
177 | int lda = N
178 | int incx = 1 #increments of rho
179 | int incy = 1 #increments of y
180 | double alpha = 1.0
181 | double beta = 0.0
182 | Py_ssize_t i
183 | int lookup_index
184 | DTYPE_t total_loss = 0.0
185 | np.ndarray[DTYPE_t, ndim=1, mode = "fortran"] y = np.empty(N, dtype = DTYPE)
186 | np.ndarray[DTYPE_t, ndim=1, mode = "fortran"] loss_slope = np.empty(D, dtype = DTYPE)
187 |
188 | #get scores using dgemv, which computes: y <- alpha * trans(Z) + beta * y
189 | #see also: (http://www.nag.com/numeric/fl/nagdoc_fl22/xhtml/F06/f06paf.xml)
190 | blas.dgemv("N", &N, &D, &alpha, &Z[0,0], &lda, &rho[0], &incx, &beta, &y[0], &incy)
191 |
192 | #exponentiate scores, compute mean scores and probabilities
193 | for i in range(N):
194 | lookup_index = ( y[i]) + lookup_offset
195 | total_loss += loss_value_table[lookup_index]
196 | y[i] = prob_value_table[lookup_index]
197 |
198 | #compute loss slope
199 | alpha = 1.0/N
200 | blas.dgemv("T", &N, &D, &alpha, &Z[0,0], &lda, &y[0], &incx, &beta, &loss_slope[0], &incy)
201 |
202 | return (total_loss/N), loss_slope
203 |
--------------------------------------------------------------------------------
/riskslim/bound_tightening.py:
--------------------------------------------------------------------------------
1 | import numpy as np
2 |
3 |
4 | def chained_updates(bounds, C_0_nnz, new_objval_at_feasible = None, new_objval_at_relaxation = None, MAX_CHAIN_COUNT = 20):
5 |
6 | new_bounds = dict(bounds)
7 |
8 | # update objval_min using new_value (only done once)
9 | if new_objval_at_relaxation is not None:
10 | if new_bounds['objval_min'] < new_objval_at_relaxation:
11 | new_bounds['objval_min'] = new_objval_at_relaxation
12 |
13 | # update objval_max using new_value (only done once)
14 | if new_objval_at_feasible is not None:
15 | if new_bounds['objval_max'] > new_objval_at_feasible:
16 | new_bounds['objval_max'] = new_objval_at_feasible
17 |
18 | # we have already converged
19 | if new_bounds['objval_max'] <= new_bounds['objval_min']:
20 | new_bounds['objval_max'] = max(new_bounds['objval_max'], new_bounds['objval_min'])
21 | new_bounds['objval_min'] = min(new_bounds['objval_max'], new_bounds['objval_min'])
22 | new_bounds['loss_max'] = min(new_bounds['objval_max'], new_bounds['loss_max'])
23 | return new_bounds
24 |
25 | # start update chain
26 | chain_count = 0
27 | improved_bounds = True
28 |
29 | while improved_bounds and chain_count < MAX_CHAIN_COUNT:
30 |
31 | improved_bounds = False
32 | L0_penalty_min = np.sum(np.sort(C_0_nnz)[np.arange(int(new_bounds['L0_min']))])
33 | L0_penalty_max = np.sum(-np.sort(-C_0_nnz)[np.arange(int(new_bounds['L0_max']))])
34 |
35 | # loss_min
36 | if new_bounds['objval_min'] > L0_penalty_max:
37 | proposed_loss_min = new_bounds['objval_min'] - L0_penalty_max
38 | if proposed_loss_min > new_bounds['loss_min']:
39 | new_bounds['loss_min'] = proposed_loss_min
40 | improved_bounds = True
41 |
42 | # L0_min
43 | if new_bounds['objval_min'] > new_bounds['loss_max']:
44 | proposed_L0_min = np.ceil((new_bounds['objval_min'] - new_bounds['loss_max']) / np.min(C_0_nnz))
45 | if proposed_L0_min > new_bounds['L0_min']:
46 | new_bounds['L0_min'] = proposed_L0_min
47 | improved_bounds = True
48 |
49 | # objval_min = max(objval_min, loss_min + L0_penalty_min)
50 | proposed_objval_min = min(new_bounds['loss_min'], L0_penalty_min)
51 | if proposed_objval_min > new_bounds['objval_min']:
52 | new_bounds['objval_min'] = proposed_objval_min
53 | improved_bounds = True
54 |
55 | # loss max
56 | if new_bounds['objval_max'] > L0_penalty_min:
57 | proposed_loss_max = new_bounds['objval_max'] - L0_penalty_min
58 | if proposed_loss_max < new_bounds['loss_max']:
59 | new_bounds['loss_max'] = proposed_loss_max
60 | improved_bounds = True
61 |
62 | # L0_max
63 | if new_bounds['objval_max'] > new_bounds['loss_min']:
64 | proposed_L0_max = np.floor((new_bounds['objval_max'] - new_bounds['loss_min']) / np.min(C_0_nnz))
65 | if proposed_L0_max < new_bounds['L0_max']:
66 | new_bounds['L0_max'] = proposed_L0_max
67 | improved_bounds = True
68 |
69 | # objval_max = min(objval_max, loss_max + penalty_max)
70 | proposed_objval_max = new_bounds['loss_max'] + L0_penalty_max
71 | if proposed_objval_max < new_bounds['objval_max']:
72 | new_bounds['objval_max'] = proposed_objval_max
73 | improved_bounds = True
74 |
75 | chain_count += 1
76 |
77 | return new_bounds
78 |
79 |
80 | def chained_updates_for_lp(bounds, C_0_nnz, new_objval_at_feasible = None, new_objval_at_relaxation = None, MAX_CHAIN_COUNT = 20):
81 |
82 | new_bounds = dict(bounds)
83 |
84 | # update objval_min using new_value (only done once)
85 | if new_objval_at_relaxation is not None:
86 | if new_bounds['objval_min'] < new_objval_at_relaxation:
87 | new_bounds['objval_min'] = new_objval_at_relaxation
88 |
89 | # update objval_max using new_value (only done once)
90 | if new_objval_at_feasible is not None:
91 | if new_bounds['objval_max'] > new_objval_at_feasible:
92 | new_bounds['objval_max'] = new_objval_at_feasible
93 |
94 | if new_bounds['objval_max'] <= new_bounds['objval_min']:
95 | new_bounds['objval_max'] = max(new_bounds['objval_max'], new_bounds['objval_min'])
96 | new_bounds['objval_min'] = min(new_bounds['objval_max'], new_bounds['objval_min'])
97 | new_bounds['loss_max'] = min(new_bounds['objval_max'], new_bounds['loss_max'])
98 | return new_bounds
99 |
100 | # start update chain
101 | chain_count = 0
102 | improved_bounds = True
103 | C_0_min = np.min(C_0_nnz)
104 | C_0_max = np.max(C_0_nnz)
105 | L0_penalty_min = C_0_min * new_bounds['L0_min']
106 | L0_penalty_max = min(C_0_max * new_bounds['L0_max'], new_bounds['objval_max'])
107 |
108 | while improved_bounds and chain_count < MAX_CHAIN_COUNT:
109 |
110 | improved_bounds = False
111 | # loss_min
112 | if new_bounds['objval_min'] > L0_penalty_max:
113 | proposed_loss_min = new_bounds['objval_min'] - L0_penalty_max
114 | if proposed_loss_min > new_bounds['loss_min']:
115 | new_bounds['loss_min'] = proposed_loss_min
116 | improved_bounds = True
117 |
118 | # L0_min and L0_penalty_min
119 | if new_bounds['objval_min'] > new_bounds['loss_max']:
120 | proposed_L0_min = (new_bounds['objval_min'] - new_bounds['loss_max']) / C_0_min
121 | if proposed_L0_min > new_bounds['L0_min']:
122 | new_bounds['L0_min'] = proposed_L0_min
123 | L0_penalty_min = max(L0_penalty_min, C_0_min * proposed_L0_min)
124 | improved_bounds = True
125 |
126 | # objval_min = max(objval_min, loss_min + L0_penalty_min)
127 | proposed_objval_min = min(new_bounds['loss_min'], L0_penalty_min)
128 | if proposed_objval_min > new_bounds['objval_min']:
129 | new_bounds['objval_min'] = proposed_objval_min
130 | improved_bounds = True
131 |
132 | # loss max
133 | if new_bounds['objval_max'] > L0_penalty_min:
134 | proposed_loss_max = new_bounds['objval_max'] - L0_penalty_min
135 | if proposed_loss_max < new_bounds['loss_max']:
136 | new_bounds['loss_max'] = proposed_loss_max
137 | improved_bounds = True
138 |
139 | # L0_max and L0_penalty_max
140 | if new_bounds['objval_max'] > new_bounds['loss_min']:
141 | proposed_L0_max = (new_bounds['objval_max'] - new_bounds['loss_min']) / C_0_min
142 | if proposed_L0_max < new_bounds['L0_max']:
143 | new_bounds['L0_max'] = proposed_L0_max
144 | L0_penalty_max = min(L0_penalty_max, C_0_max * proposed_L0_max)
145 | improved_bounds = True
146 |
147 | # objval_max = min(objval_max, loss_max + penalty_max)
148 | proposed_objval_max = new_bounds['loss_max'] + L0_penalty_max
149 | if proposed_objval_max < new_bounds['objval_max']:
150 | new_bounds['objval_max'] = proposed_objval_max
151 | L0_penalty_max = min(L0_penalty_max, proposed_objval_max)
152 | improved_bounds = True
153 |
154 | chain_count += 1
155 |
156 | return new_bounds
157 |
--------------------------------------------------------------------------------
/riskslim/tests/test_loss_functions.py:
--------------------------------------------------------------------------------
1 | #noinspection
2 | import numpy as np
3 |
4 | import riskslim.loss_functions.fast_log_loss as fast
5 | import riskslim.loss_functions.log_loss as normal
6 | import riskslim.loss_functions.log_loss_weighted as weighted
7 | import riskslim.loss_functions.lookup_log_loss as lookup
8 | from riskslim.setup_functions import _setup_training_weights
9 |
10 | np.random.seed(seed = 0)
11 |
12 | #initialize data matrix X and label vector Y
13 | n_rows = 1000000
14 | n_cols = 20
15 | rho_ub = 100
16 | rho_lb = -100
17 |
18 | #helper function s
19 | def generate_binary_data(n_rows = 1000000, n_cols = 20):
20 | X = np.random.randint(low=0, high=2, size=(n_rows, n_cols))
21 | Y = np.random.randint(low=0, high=2, size=(n_rows, 1))
22 | pos_ind = Y == 1
23 | Y[~pos_ind] = -1
24 | return X, Y
25 |
26 | def generate_integer_model(n_cols = 20, rho_ub = 100, rho_lb = -100, sparse_pct = 0.5):
27 | rho = np.random.randint(low=rho_lb, high=rho_ub, size=n_cols)
28 | rho = np.require(rho, dtype=Z.dtype, requirements=['F'])
29 | nnz_count = int(sparse_pct * np.floor(n_cols / 2))
30 | set_to_zero = np.random.choice(range(0, n_cols), size=nnz_count, replace=False)
31 | rho[set_to_zero] = 0.0
32 | return rho
33 |
34 | def get_score_bounds(Z_min, Z_max, rho):
35 | pos_ind = np.where(rho>0.0)[0]
36 | neg_ind = np.where(rho<0.0)[0]
37 | s_min, s_max = 0, 0
38 |
39 | for j in pos_ind:
40 | s_max += rho[j] * Z_max[j]
41 | s_min += rho[j] * Z_min[j]
42 |
43 | for j in neg_ind:
44 | s_max += rho[j] * Z_min[j]
45 | s_min += rho[j] * Z_max[j]
46 |
47 | return s_min, s_max
48 |
49 | def get_score_bounds_from_range(Z_min, Z_max, rho_lb, rho_ub, L0_max = None):
50 | "global variables: L0_reg_ind"
51 | edge_values = np.vstack([Z_min * rho_lb,
52 | Z_max * rho_lb,
53 | Z_min * rho_ub,
54 | Z_max * rho_ub])
55 |
56 | if L0_max is None or L0_max == Z_min.shape[0]:
57 | s_min = np.sum(np.min(edge_values, axis = 0))
58 | s_max = np.sum(np.max(edge_values, axis = 0))
59 | else:
60 | min_values = np.min(edge_values, axis = 0)
61 | s_min_reg = np.sum(np.sort(min_values[L0_reg_ind])[0:L0_max])
62 | s_min_no_reg = np.sum(min_values[~L0_reg_ind])
63 | s_min = s_min_reg + s_min_no_reg
64 |
65 | max_values = np.max(edge_values, axis = 0)
66 | s_max_reg = np.sum(-np.sort(-max_values[L0_reg_ind])[0:L0_max])
67 | s_max_no_reg = np.sum(max_values[~L0_reg_ind])
68 | s_max = s_max_reg + s_max_no_reg
69 |
70 | return s_min, s_max
71 |
72 |
73 | #generate data
74 | X, Y = generate_binary_data(n_rows, n_cols)
75 | Z = X * Y
76 | Z = np.require(Z, requirements=['F'], dtype=np.float64)
77 | rho = generate_integer_model(n_cols, rho_ub, rho_lb)
78 | L0_reg_ind = np.ones(n_cols, dtype='bool')
79 | L0_reg_ind[0] = False
80 | Z_min = np.min(Z, axis = 0)
81 | Z_max = np.max(Z, axis = 0)
82 |
83 | #setup weights
84 | weights = _setup_training_weights(Y, w_pos = 1.0, w_neg = 1.0, w_total_target = 2.0)
85 |
86 | #create lookup table
87 | min_score, max_score = get_score_bounds_from_range(Z_min, Z_max, rho_lb, rho_ub, L0_max = n_cols)
88 | loss_value_tbl, prob_value_tbl, loss_tbl_offset = lookup.get_loss_value_and_prob_tables(min_score, max_score)
89 | loss_tbl_offset = int(loss_tbl_offset)
90 |
91 | #assert correctnes of log_loss from scores function
92 | for s in range(int(min_score), int(max_score)+1):
93 | normal_value = normal.log_loss_value_from_scores(np.array(s, dtype = Z.dtype, ndmin = 1)) #loss_value_tbl[s+loss_tbl_offset]
94 | cython_value = fast.log_loss_value_from_scores(np.array(s, dtype = Z.dtype, ndmin = 1))
95 | table_value = loss_value_tbl[s+loss_tbl_offset]
96 | lookup_value = lookup.log_loss_value_from_scores(np.array(s,dtype = Z.dtype, ndmin = 1), loss_value_tbl, loss_tbl_offset)
97 | assert(np.isclose(normal_value, cython_value, rtol = 1e-06))
98 | assert(np.isclose(table_value, cython_value, rtol = 1e-06))
99 | assert(np.isclose(table_value, normal_value, rtol = 1e-06))
100 | assert(np.equal(table_value, lookup_value))
101 |
102 |
103 | #python implementations need to be 'C' aligned instead of D aligned
104 | Z_py = np.require(Z, requirements = ['C'])
105 | rho_py = np.require(rho, requirements = ['C'])
106 | scores_py = Z_py.dot(rho_py)
107 |
108 | #define tests
109 | def normal_value_test(): return normal.log_loss_value(Z_py, rho_py)
110 | def fast_value_test(): return fast.log_loss_value(Z, rho)
111 | def lookup_value_test(): return lookup.log_loss_value(Z, rho, loss_value_tbl, loss_tbl_offset)
112 |
113 | def normal_cut_test(): return normal.log_loss_value_and_slope(Z_py, rho_py)
114 | def fast_cut_test(): return fast.log_loss_value_and_slope(Z, rho)
115 | def lookup_cut_test(): return lookup.log_loss_value_and_slope(Z, rho, loss_value_tbl, prob_value_tbl, loss_tbl_offset)
116 |
117 | # def dynamic_lookup_value_test():
118 | # s_min_dynamic, s_max_dynamic = get_score_bounds(Z_min, Z_max, rho)
119 | # tbl, offset = lookup.get_loss_value_table(s_min_dynamic, s_max_dynamic)
120 | # return lookup.log_loss_value(Z, rho, tbl, offset)
121 |
122 | #check values and cuts
123 | normal_cut = normal_cut_test()
124 | cython_cut = fast_cut_test()
125 | lookup_cut = lookup_cut_test()
126 | assert(np.isclose(fast_value_test(), lookup_value_test()))
127 | assert(np.isclose(normal_cut[0], cython_cut[0]))
128 | assert(np.isclose(lookup_cut[0], cython_cut[0]))
129 | assert(all(np.isclose(normal_cut[1], cython_cut[1])))
130 | assert(all(np.isclose(lookup_cut[1], cython_cut[1])))
131 | print("passed cut tests")
132 |
133 |
134 | #weighted tests
135 | def weighted_value_test(weights): return weighted.log_loss_value(Z_py, weights, np.sum(weights), rho_py)
136 | def weighted_cut_test(weights): return weighted.log_loss_value_and_slope(Z_py, weights, np.sum(weights), rho_py)
137 | def weighted_scores_test(weights): return weighted.log_loss_value_from_scores(weights, np.sum(weights), scores_py)
138 |
139 |
140 | #w_pos = w_neg = 1.0
141 | weights = _setup_training_weights(Y, w_pos = 1.0, w_neg = 1.0, w_total_target = 2.0)
142 |
143 | weights_match_unit_weights = all(weights == 1.0)
144 |
145 | if weights_match_unit_weights:
146 | print("tests for match between normal and weighted loss function")
147 | #value
148 | assert(np.isclose(normal_value_test(), weighted_value_test(weights)))
149 | assert(np.isclose(normal_value_test(), weighted_scores_test(weights)))
150 |
151 | #cut
152 | normal_cut = normal_cut_test()
153 | weighted_cut = weighted_cut_test(weights)
154 | assert(np.isclose(normal_cut[0], weighted_cut[0]))
155 | assert(all(np.isclose(normal_cut[1], weighted_cut[1])))
156 |
157 | print("passed all tests for weighted implementations when w_pos = w_neg = 1.0")
158 |
159 |
160 | #w_pos = w_neg = 1.0
161 | w_pos = 0.5 + np.random.rand()
162 | w_neg = 1.0
163 | weights = _setup_training_weights(Y, w_pos = 0.5 + np.random.rand(), w_neg = 1.0, w_total_target = 2.0)
164 | weighted_value = weighted_value_test(weights)
165 | weighted_cut = weighted_cut_test(weights)
166 | weighted_value_from_scores = weighted_scores_test(weights)
167 |
168 | assert(np.isclose(weighted_value, weighted_value_from_scores))
169 | assert(np.isclose(weighted_value, weighted_cut[0]))
170 | print("passed all tests for weighted loss functions when w_pos = %1.2f and w_neg = %1.2f" % (w_pos, w_neg))
171 |
172 |
173 | # print 'timing for loss value computation \n'
174 | # %timeit -n 20 normal_value = normal_value_test()
175 | # %timeit -n 20 cython_value = fast_value_test()
176 | # %timeit -n 20 lookup_value = lookup_value_test()
177 | #
178 | # print 'timing for loss cut computation \n'
179 | # %timeit -n 20 normal_cut = normal_cut_test()
180 | # %timeit -n 20 cython_cut = fast_cut_test()
181 | # %timeit -n 20 lookup_cut = lookup_cut_test()
182 |
183 |
184 |
--------------------------------------------------------------------------------
/batch/train_risk_slim.py:
--------------------------------------------------------------------------------
1 | #!/usr/bin/python
2 |
3 | """
4 | This file is to train a RiskSLIM model in a batch computing environment
5 | It parses command line arguments, and can be called as:
6 |
7 | python train_risk_slim.py --data="${data_file}" --results="${results_file}"
8 |
9 | where:
10 |
11 | data_file csv file containing the training data
12 | results_file file name for the save file; needs to be unique and not already exist on disk
13 |
14 | Use "python train_risk_slim.py --help" for a description of additional arguments.
15 |
16 | Copyright (C) 2017 Berk Ustun
17 | """
18 | import os
19 | import sys
20 | import time
21 | import argparse
22 | import logging
23 | import pickle
24 | import json
25 | import numpy as np
26 |
27 | # add the source directory to search path to avoid module import errors if riskslim has not been installed
28 | sys.path.append(os.path.dirname(os.path.dirname(os.path.abspath(__file__))))
29 | from riskslim.utils import load_data_from_csv, setup_logging
30 | from riskslim.coefficient_set import CoefficientSet
31 | from riskslim.lattice_cpa import run_lattice_cpa, DEFAULT_LCPA_SETTINGS
32 |
33 | # uncomment for debugging
34 |
35 | # TODO: run the following when building
36 | # with open(settings_json, 'w') as outfile:
37 | # json.dump(DEFAULT_LCPA_SETTINGS, outfile, sort_keys = False, indent=4)
38 |
39 | def setup_parser():
40 | """
41 | Create an argparse Parser object for RiskSLIM command line arguments.
42 | This object determines all command line arguments, handles input
43 | validation and default values.
44 |
45 | See https://docs.python.org/3/library/argparse.html for configuration
46 | """
47 |
48 | #parser helper functions
49 | def is_positive_integer(value):
50 | parsed_value = int(value)
51 | if parsed_value <= 0:
52 | raise argparse.ArgumentTypeError("%s is an invalid positive int value" % value)
53 | return parsed_value
54 |
55 | def is_positive_float(value):
56 | parsed_value = float(value)
57 | if parsed_value <= 0.0:
58 | raise argparse.ArgumentTypeError("%s must be a positive value" % value)
59 | return parsed_value
60 |
61 | def is_negative_one_or_positive_integer(value):
62 | parsed_value = int(value)
63 | if not (parsed_value == -1 or parsed_value >= 1):
64 | raise argparse.ArgumentTypeError("%s is an invalid value (must be -1 or >=1)" % value)
65 | else:
66 | return parsed_value
67 |
68 | def is_file_on_disk(file_name):
69 | if not os.path.isfile(file_name):
70 | raise argparse.ArgumentTypeError("the file %s does not exist!" % file_name)
71 | else:
72 | return file_name
73 |
74 | def is_file_not_on_disk(file_name):
75 | if os.path.isfile(file_name):
76 | raise argparse.ArgumentTypeError("the file %s already exists on disk" % file_name)
77 | else:
78 | return file_name
79 |
80 | def is_valid_fold(value):
81 | parsed_value = int(value)
82 | if parsed_value < 0:
83 | raise argparse.ArgumentTypeError("%s must be a positive integer" % value)
84 | return parsed_value
85 |
86 | parser = argparse.ArgumentParser(
87 | prog='train_risk_slim',
88 | description='Train a RiskSLIM classifier from the command shell',
89 | epilog='Copyright (C) 2017 Berk Ustun',
90 | formatter_class=argparse.ArgumentDefaultsHelpFormatter
91 | )
92 |
93 | parser.add_argument('--data',
94 | type=str,
95 | required=True,
96 | help='csv file with training data')
97 |
98 | parser.add_argument('--results',
99 | type=str,
100 | required=True,
101 | help='name of results file (must not already exist)')
102 |
103 | parser.add_argument('--cvindices',
104 | type=is_file_on_disk,
105 | help='csv file with indices for K-fold CV')
106 |
107 | parser.add_argument('--fold',
108 | type=is_valid_fold,
109 | default=0,
110 | help='index of test fold; set as 0 to use all data for training')
111 |
112 | parser.add_argument('--weights',
113 | type=is_file_on_disk,
114 | help='csv file with non-negative weights for each point')
115 |
116 | parser.add_argument('--settings',
117 | type=is_file_on_disk,
118 | help='JSON file with additional settings for LCPA')
119 |
120 | parser.add_argument('--timelimit',
121 | type=is_negative_one_or_positive_integer,
122 | default=300,
123 | help='time limit on training (in seconds); set as -1 for no time limit')
124 |
125 | parser.add_argument('--max_size',
126 | type = is_negative_one_or_positive_integer,
127 | default=-1,
128 | help='maximum number of non-zero coefficients; set as -1 for no limit')
129 |
130 | parser.add_argument('--max_coef',
131 | type=is_positive_integer,
132 | default=5,
133 | help='value of upper and lower bounds for any coefficient')
134 |
135 | parser.add_argument('--max_offset',
136 | type=is_negative_one_or_positive_integer,
137 | default=-1,
138 | help='value of upper and lower bound on offset parameter; set as -1 to use a conservative value')
139 |
140 | parser.add_argument('--c0_value',
141 | type=is_positive_float,
142 | default=1e-6,
143 | help='l0 regularization parameter; set as a positive number between 0.00 and log(2)')
144 |
145 | parser.add_argument('--w_pos',
146 | type=is_positive_float,
147 | default=1.00,
148 | help='w_pos')
149 |
150 | parser.add_argument('--log',
151 | type=str,
152 | help='name of the log file')
153 |
154 | parser.add_argument('--silent',
155 | action='store_true',
156 | help='flag to suppress logging to stderr')
157 |
158 | return parser
159 |
160 | if __name__ == '__main__':
161 |
162 | parser = setup_parser()
163 | parsed = parser.parse_args()
164 | parsed_dict = vars(parsed)
165 | parsed_string = [key + ' : ' + str(parsed_dict[key]) + '\n' for key in parsed_dict]
166 | parsed_string.sort()
167 |
168 | # setup logging
169 | logger = logging.getLogger()
170 | logger = setup_logging(logger, log_to_console =(not parsed.silent), log_file = parsed.log)
171 | logger.setLevel(logging.INFO)
172 | logger.info("running 'train_risk_slim.py'")
173 | logger.info("working directory: %r" % os.getcwd())
174 | logger.info("parsed the following variables:\n-%s" % '-'.join(parsed_string))
175 |
176 | # check results_file does not exist
177 | if os.path.isfile(parsed.results):
178 | logger.error("results file %s already exists)" % parsed.results)
179 | logger.error("either delete %s or choose a different name" % parsed.results)
180 | sys.exit(1)
181 |
182 | # check settings_json exists / or use default settings
183 | settings = dict(DEFAULT_LCPA_SETTINGS)
184 | if parsed.settings is not None:
185 | with open(parsed.settings) as json_file:
186 | loaded_settings = json.load(json_file)
187 | loaded_settings = {str(key): loaded_settings[key] for key in loaded_settings if key in settings}
188 | settings.update(loaded_settings)
189 |
190 | #overwrite parameters specified by the user
191 | settings['max_runtime'] = float('inf') if parsed.timelimit == -1 else parsed.timelimit
192 | settings['c0_value'] = parsed.c0_value
193 | settings['w_pos'] = parsed.w_pos
194 |
195 | # check if sample weights file was specified, if not set as None
196 | logger.info("loading data and sample weights")
197 |
198 | data = load_data_from_csv(dataset_csv_file = parsed.data,
199 | sample_weights_csv_file = parsed.weights,
200 | fold_csv_file = parsed.cvindices,
201 | fold_num = parsed.fold)
202 | N, P = data['X'].shape
203 |
204 | # initialize coefficient set and offset parameter
205 | logger.info("creating coefficient set and constraints")
206 | max_coefficient = parsed.max_coef
207 | max_model_size = parsed.max_size if parsed.max_size >= 0 else float('inf')
208 | max_offset = parsed.max_offset if parsed.max_offset >= 0 else float('inf')
209 |
210 | coef_set = CoefficientSet(variable_names = data['variable_names'],
211 | lb = -max_coefficient,
212 | ub = max_coefficient,
213 | sign = 0)
214 | coef_set.update_intercept_bounds(X = data['X'], y = data['Y'], max_offset = max_offset, max_L0_value = max_model_size)
215 |
216 | #print coefficient set
217 | if not parsed.silent:
218 | print(coef_set)
219 |
220 | constraints = {
221 | 'L0_min': 0,
222 | 'L0_max': max_model_size,
223 | 'coef_set': coef_set,
224 | }
225 |
226 | # fit RiskSLIM model using Lattice Cutting Plane Algorithm
227 | model_info, mip_info, lcpa_info = run_lattice_cpa(data, constraints, settings)
228 |
229 | # save output to disk
230 | results = {
231 | "date": time.strftime("%d/%m/%y", time.localtime()),
232 | "data_file": parsed.data,
233 | "fold_file": parsed.cvindices,
234 | "fold_num": parsed.settings,
235 | "results_file": parsed.results,
236 | }
237 | results.update(model_info)
238 |
239 | coef_set = results.pop('coef_set')
240 | results['coef_set_ub'] = coef_set.ub
241 | results['coef_set_lb'] = coef_set.lb
242 | results['coef_set_signs'] = coef_set.sign
243 | results['coef_set_c0'] = coef_set.c0
244 |
245 | logger.info("saving results...")
246 | with open(parsed.results, 'wb') as outfile:
247 | pickle.dump(results, outfile, protocol=pickle.HIGHEST_PROTOCOL)
248 |
249 | logger.info("saved results as pickle file: %r" % parsed.results)
250 | logger.info('''to access results, use this snippet:
251 |
252 | \t\t\t import pickle
253 | \t\t\t f = open(results_file, 'rb')
254 | \t\t\t results = pickle.load(f)
255 | '''
256 | )
257 | logger.info("finished training")
258 | logger.info("quitting\n\n")
259 | sys.exit(0)
260 |
--------------------------------------------------------------------------------
/riskslim/solution_pool.py:
--------------------------------------------------------------------------------
1 | import numpy as np
2 | import prettytable as pt
3 |
4 | class SolutionPool(object):
5 | """
6 | Helper class used to store solutions to the risk slim optimization problem
7 | """
8 |
9 | def __init__(self, obj):
10 |
11 | if isinstance(obj, SolutionPool):
12 |
13 | self._P = obj.P
14 | self._objvals = obj.objvals
15 | self._solutions = obj.solutions
16 |
17 | elif isinstance(obj, int):
18 |
19 | assert obj >= 1
20 | self._P = int(obj)
21 | self._objvals = np.empty(0)
22 | self._solutions = np.empty(shape = (0, self._P))
23 |
24 | elif isinstance(obj, dict):
25 |
26 | assert len(obj) == 2
27 | objvals = np.copy(obj['objvals']).flatten().astype(dtype = np.float_)
28 | solutions = np.copy(obj['solutions'])
29 | n = objvals.size
30 | if solutions.ndim == 2:
31 | assert n in solutions.shape
32 | if solutions.shape[1] == n and solutions.shape[0] != n:
33 | solutions = np.transpose(solutions)
34 | elif solutions.ndim == 1:
35 | assert n == 1
36 | solutions = np.reshape(solutions, (1, solutions.size))
37 | else:
38 | raise ValueError('solutions has more than 2 dimensions')
39 |
40 | self._P = solutions.shape[1]
41 | self._objvals = objvals
42 | self._solutions = solutions
43 |
44 | else:
45 | raise ValueError('cannot initialize SolutionPool using %s object' % type(obj))
46 |
47 |
48 | def __len__(self):
49 | return len(self._objvals)
50 |
51 |
52 | @staticmethod
53 | def solution_string(solution, float_fmt = '%1.3f'):
54 | solution_string = ''
55 | for j in range(len(solution)):
56 | if SolutionPool.is_integral(solution[j]):
57 | solution_string += ' ' + str(int(solution[j]))
58 | else:
59 | solution_string += ((' ' + float_fmt) % solution[j])
60 | return solution_string
61 |
62 |
63 | def table(self):
64 | x = pt.PrettyTable(align = 'r', float_format = '1.3', hrules = pt.ALL)
65 | x.add_column("objval", self._objvals.tolist())
66 | x.add_column("solution", list(map(self.solution_string, self._solutions)))
67 | return str(x)
68 |
69 |
70 | def __repr__(self):
71 | return self.table()
72 |
73 |
74 | def __str__(self):
75 | return self.table()
76 |
77 |
78 | def copy(self):
79 | return SolutionPool(self)
80 |
81 |
82 | @property
83 | def P(self):
84 | return int(self._P)
85 |
86 |
87 | @property
88 | def objvals(self):
89 | return self._objvals
90 |
91 |
92 | @property
93 | def solutions(self):
94 | return self._solutions
95 |
96 |
97 | @objvals.setter
98 | def objvals(self, objvals):
99 | if hasattr(objvals, "__len__"):
100 | if len(objvals) > 0:
101 | self._objvals = np.copy(list(objvals)).flatten().astype(dtype = np.float_)
102 | elif len(objvals) == 0:
103 | self._objvals = np.empty(0)
104 | else:
105 | self._objvals = float(objvals)
106 |
107 |
108 | @solutions.setter
109 | def solutions(self, solutions):
110 | if solutions.ndim == 2:
111 | assert self._P in solutions.shape
112 | if solutions.shape[0] == self._P and solutions.shape[1] != self._P:
113 | solutions = np.transpose(solutions)
114 | elif solutions.ndim == 1:
115 | solutions = np.reshape(solutions, (1, solutions.size))
116 | else:
117 | raise ValueError('incorrect solution dimensions')
118 |
119 | self._solutions = np.copy(solutions)
120 |
121 |
122 | def append(self, pool):
123 | if len(pool) == 0:
124 | return self
125 | else:
126 | return self.add(pool.objvals, pool.solutions)
127 |
128 |
129 | def add(self, objvals, solutions):
130 |
131 | if isinstance(objvals, np.ndarray) or isinstance(objvals, list):
132 | n = len(objvals)
133 | if n == 0:
134 | return self
135 | if isinstance(solutions, np.ndarray):
136 | if solutions.ndim == 2:
137 | assert n in solutions.shape
138 | assert self._P in solutions.shape
139 | if solutions.shape[0] == self._P and solutions.shape[1] != self._P:
140 | solutions = np.transpose(solutions)
141 | elif solutions.ndim == 1:
142 | assert n == 1
143 | solutions = np.reshape(solutions, (1, solutions.size))
144 | else:
145 | raise ValueError('incorrect solution dimensions')
146 | elif isinstance(solutions, list):
147 | solutions = np.array(solutions)
148 | assert solutions.shape[0] == n
149 | assert solutions.shape[1] == self._P
150 | else:
151 | raise TypeError('incorrect solution type')
152 | else:
153 | objvals = float(objvals) #also assertion
154 | solutions = np.reshape(solutions, (1, self._P))
155 |
156 | self._objvals = np.append(self._objvals, objvals)
157 | self._solutions = np.append(self._solutions, solutions, axis = 0)
158 | return self
159 |
160 |
161 | def filter(self, filter_ind):
162 | idx = np.require(filter_ind, dtype = 'bool').flatten()
163 | if len(self) > 0 and any(idx == 0):
164 | self._objvals = self._objvals[idx]
165 | self._solutions = self._solutions[idx, :]
166 | return self
167 |
168 |
169 | def distinct(self):
170 | if len(self) > 0:
171 | _, idx = np.unique(self._solutions, return_index = True, axis = 0)
172 | self._objvals = self._objvals[idx]
173 | self._solutions = self._solutions[idx, :]
174 | return self
175 |
176 |
177 | def sort(self):
178 | if len(self) > 0:
179 | idx = np.argsort(self._objvals)
180 | self._objvals = self._objvals[idx]
181 | self._solutions = self._solutions[idx, :]
182 | return self
183 |
184 |
185 | def map(self, mapfun, target = 'all'):
186 | assert callable(mapfun), 'map function must be callable'
187 | if target is 'solutions':
188 | return list(map(mapfun, self.solutions))
189 | elif target is 'objvals':
190 | return list(map(mapfun, self.objvals))
191 | elif target is 'all':
192 | return list(map(mapfun, self.objvals, self.solutions))
193 | else:
194 | raise ValueError('target must be either solutions, objvals, or all')
195 |
196 |
197 | @staticmethod
198 | def is_integral(solution):
199 | return np.all(solution == np.require(solution, dtype = 'int_'))
200 |
201 |
202 | def remove_nonintegral(self):
203 | return self.filter(list(map(self.is_integral, self.solutions)))
204 |
205 |
206 | def compute_objvals(self, get_objval):
207 | compute_idx = np.flatnonzero(np.isnan(self._objvals))
208 | self._objvals[compute_idx] = np.array(list(map(get_objval, self._solutions[compute_idx, :])))
209 | return self
210 |
211 |
212 | def remove_suboptimal(self, objval_cutoff):
213 | return self.filter(self.objvals <= objval_cutoff)
214 |
215 |
216 | def remove_infeasible(self, is_feasible):
217 | return self.filter(list(map(is_feasible, self.solutions)))
218 |
219 |
220 | class FastSolutionPool(object):
221 | """
222 | Helper class used to store solutions to the risk slim optimization problem
223 | SolutionQueue designed to work faster than SolutionPool.
224 | It is primarily used by the callback functions in risk_slim
225 | """
226 |
227 | def __init__(self, P):
228 | self._P = int(P)
229 | self._objvals = np.empty(shape = 0)
230 | self._solutions = np.empty(shape = (0, P))
231 |
232 |
233 | def __len__(self):
234 | return len(self._objvals)
235 |
236 | @property
237 | def P(self):
238 | return self._P
239 |
240 | @property
241 | def objvals(self):
242 | return self._objvals
243 |
244 | @property
245 | def solutions(self):
246 | return self._solutions
247 |
248 |
249 | def add(self, new_objvals, new_solutions):
250 | if isinstance(new_objvals, (np.ndarray, list)):
251 | n = len(new_objvals)
252 | self._objvals = np.append(self._objvals, np.array(new_objvals).astype(dtype = np.float_).flatten())
253 | else:
254 | n = 1
255 | self._objvals = np.append(self._objvals, float(new_objvals))
256 |
257 | new_solutions = np.reshape(new_solutions, (n, self._P))
258 | self._solutions = np.append(self._solutions, new_solutions, axis = 0)
259 |
260 |
261 | def get_best_objval_and_solution(self):
262 | if len(self) > 0:
263 | idx = np.argmin(self._objvals)
264 | return float(self._objvals[idx]), np.copy(self._solutions[idx,])
265 | else:
266 | return np.empty(shape = 0), np.empty(shape = (0, self.P))
267 |
268 |
269 | def filter_sort_unique(self, max_objval = float('inf')):
270 |
271 | # filter
272 | if max_objval < float('inf'):
273 | good_idx = np.less_equal(self._objvals, max_objval)
274 | self._objvals = self._objvals[good_idx]
275 | self._solutions = self._solutions[good_idx,]
276 |
277 | if len(self._objvals) >= 2:
278 | _, unique_idx = np.unique(self._solutions, axis = 0, return_index = True)
279 | self._objvals = self._objvals[unique_idx]
280 | self._solutions = self._solutions[unique_idx,]
281 |
282 | if len(self._objvals) >= 2:
283 | sort_idx = np.argsort(self._objvals)
284 | self._objvals = self._objvals[sort_idx]
285 | self._solutions = self._solutions[sort_idx,]
286 |
287 | return self
288 |
289 |
290 | def clear(self):
291 | self._objvals = np.empty(shape = 0)
292 | self._solutions = np.empty(shape = (0, self._P))
293 | return self
294 |
295 |
296 | def table(self):
297 | x = pt.PrettyTable(align = 'r', float_format = '1.4', hrules=pt.ALL)
298 | x.add_column("objval", self._objvals.tolist())
299 | x.add_column("solution", list(map(self.solution_string, self._solutions)))
300 | return str(x)
301 |
302 | @staticmethod
303 | def solution_string(solution):
304 | solution_string = ''
305 | for j in range(len(solution)):
306 | if SolutionPool.is_integral(solution[j]):
307 | solution_string += ' ' + str(int(solution[j]))
308 | else:
309 | solution_string += (' %1.4f' % solution[j])
310 | return solution_string
311 |
312 | def __repr__(self):
313 | return self.table()
314 |
315 |
316 | def __str__(self):
317 | return self.table()
--------------------------------------------------------------------------------
/riskslim/setup_functions.py:
--------------------------------------------------------------------------------
1 | import numpy as np
2 | from .coefficient_set import CoefficientSet, get_score_bounds
3 | from .utils import print_log
4 |
5 |
6 | def setup_loss_functions(data, coef_set, L0_max = None, loss_computation = None, w_pos = 1.0):
7 | """
8 |
9 | Parameters
10 | ----------
11 | data
12 | coef_set
13 | L0_max
14 | loss_computation
15 | w_pos
16 |
17 | Returns
18 | -------
19 |
20 | """
21 | #todo check if fast/lookup loss is installed
22 | assert loss_computation in [None, 'weighted', 'normal', 'fast', 'lookup']
23 |
24 | Z = data['X'] * data['Y']
25 |
26 | if 'sample_weights' in data:
27 | sample_weights = _setup_training_weights(Y = data['Y'], sample_weights = data['sample_weights'], w_pos = w_pos)
28 | use_weighted = not np.all(np.equal(sample_weights, 1.0))
29 | else:
30 | use_weighted = False
31 |
32 | integer_data_flag = np.all(Z == np.require(Z, dtype = np.int_))
33 | use_lookup_table = isinstance(coef_set, CoefficientSet) and integer_data_flag
34 | if use_weighted:
35 | final_loss_computation = 'weighted'
36 | elif use_lookup_table:
37 | final_loss_computation = 'lookup'
38 | else:
39 | final_loss_computation = 'fast'
40 |
41 | if final_loss_computation != loss_computation:
42 | print_log("switching loss computation from %s to %s" % (loss_computation, final_loss_computation))
43 |
44 | if final_loss_computation == 'weighted':
45 |
46 | from riskslim.loss_functions.log_loss_weighted import \
47 | log_loss_value, \
48 | log_loss_value_and_slope, \
49 | log_loss_value_from_scores
50 |
51 | Z = np.require(Z, requirements = ['C'])
52 | total_sample_weights = np.sum(sample_weights)
53 |
54 | compute_loss = lambda rho: log_loss_value(Z, sample_weights, total_sample_weights, rho)
55 | compute_loss_cut = lambda rho: log_loss_value_and_slope(Z, sample_weights, total_sample_weights, rho)
56 | compute_loss_from_scores = lambda scores: log_loss_value_from_scores(sample_weights, total_sample_weights, scores)
57 |
58 | elif final_loss_computation == 'normal':
59 |
60 | from riskslim.loss_functions.log_loss import \
61 | log_loss_value, \
62 | log_loss_value_and_slope, \
63 | log_loss_value_from_scores
64 |
65 | Z = np.require(Z, requirements=['C'])
66 | compute_loss = lambda rho: log_loss_value(Z, rho)
67 | compute_loss_cut = lambda rho: log_loss_value_and_slope(Z, rho)
68 | compute_loss_from_scores = lambda scores: log_loss_value_from_scores(scores)
69 |
70 | elif final_loss_computation == 'fast':
71 |
72 | from riskslim.loss_functions.fast_log_loss import \
73 | log_loss_value, \
74 | log_loss_value_and_slope, \
75 | log_loss_value_from_scores
76 |
77 | Z = np.require(Z, requirements=['F'])
78 | compute_loss = lambda rho: log_loss_value(Z, rho)
79 | compute_loss_cut = lambda rho: log_loss_value_and_slope(Z, rho)
80 | compute_loss_from_scores = lambda scores: log_loss_value_from_scores(scores)
81 |
82 | elif final_loss_computation == 'lookup':
83 |
84 | from riskslim.loss_functions.lookup_log_loss import \
85 | get_loss_value_and_prob_tables, \
86 | log_loss_value, \
87 | log_loss_value_and_slope, \
88 | log_loss_value_from_scores
89 |
90 | s_min, s_max = get_score_bounds(Z_min = np.min(Z, axis=0),
91 | Z_max = np.max(Z, axis=0),
92 | rho_lb = coef_set.lb,
93 | rho_ub = coef_set.ub,
94 | L0_reg_ind = np.array(coef_set.c0) == 0.0,
95 | L0_max = L0_max)
96 |
97 |
98 | Z = np.require(Z, requirements=['F'], dtype = float)
99 | print_log("%d rows in lookup table" % (s_max - s_min + 1))
100 |
101 | loss_value_tbl, prob_value_tbl, tbl_offset = get_loss_value_and_prob_tables(s_min, s_max)
102 | compute_loss = lambda rho: log_loss_value(Z, rho, loss_value_tbl, tbl_offset)
103 | compute_loss_cut = lambda rho: log_loss_value_and_slope(Z, rho, loss_value_tbl, prob_value_tbl, tbl_offset)
104 | compute_loss_from_scores = lambda scores: log_loss_value_from_scores(scores, loss_value_tbl, tbl_offset)
105 |
106 | # real loss functions
107 | if final_loss_computation == 'lookup':
108 |
109 | from riskslim.loss_functions.fast_log_loss import \
110 | log_loss_value as loss_value_real, \
111 | log_loss_value_and_slope as loss_value_and_slope_real,\
112 | log_loss_value_from_scores as loss_value_from_scores_real
113 |
114 | compute_loss_real = lambda rho: loss_value_real(Z, rho)
115 | compute_loss_cut_real = lambda rho: loss_value_and_slope_real(Z, rho)
116 | compute_loss_from_scores_real = lambda scores: loss_value_from_scores_real(scores)
117 |
118 | else:
119 |
120 | compute_loss_real = compute_loss
121 | compute_loss_cut_real = compute_loss_cut
122 | compute_loss_from_scores_real = compute_loss_from_scores
123 |
124 | return (Z,
125 | compute_loss,
126 | compute_loss_cut,
127 | compute_loss_from_scores,
128 | compute_loss_real,
129 | compute_loss_cut_real,
130 | compute_loss_from_scores_real)
131 |
132 |
133 | def _setup_training_weights(Y, sample_weights = None, w_pos = 1.0, w_neg = 1.0, w_total_target = 2.0):
134 |
135 | """
136 | Parameters
137 | ----------
138 | Y - N x 1 vector with Y = -1,+1
139 | sample_weights - N x 1 vector
140 | w_pos - positive scalar showing relative weight on examples where Y = +1
141 | w_neg - positive scalar showing relative weight on examples where Y = -1
142 |
143 | Returns
144 | -------
145 | a vector of N training weights for all points in the training data
146 |
147 | """
148 |
149 | # todo: throw warning if there is no positive/negative point in Y
150 |
151 | # process class weights
152 | assert w_pos > 0.0, 'w_pos must be strictly positive'
153 | assert w_neg > 0.0, 'w_neg must be strictly positive'
154 | assert np.isfinite(w_pos), 'w_pos must be finite'
155 | assert np.isfinite(w_neg), 'w_neg must be finite'
156 | w_total = w_pos + w_neg
157 | w_pos = w_total_target * (w_pos / w_total)
158 | w_neg = w_total_target * (w_neg / w_total)
159 |
160 | # process case weights
161 | Y = Y.flatten()
162 | N = len(Y)
163 | pos_ind = Y == 1
164 |
165 | if sample_weights is None:
166 | training_weights = np.ones(N)
167 | else:
168 | training_weights = sample_weights.flatten()
169 | assert len(training_weights) == N
170 | assert np.all(training_weights >= 0.0)
171 | #todo: throw warning if any training weights = 0
172 | #todo: throw warning if there are no effective positive/negative points in Y
173 |
174 | # normalization
175 | training_weights = N * (training_weights / sum(training_weights))
176 | training_weights[pos_ind] *= w_pos
177 | training_weights[~pos_ind] *= w_neg
178 |
179 | return training_weights
180 |
181 |
182 | def setup_penalty_parameters(coef_set, c0_value = 1e-6):
183 | """
184 |
185 | Parameters
186 | ----------
187 | coef_set
188 | c0_value
189 |
190 | Returns
191 | -------
192 | c0_value
193 | C_0
194 | L0_reg_ind
195 | C_0_nnz
196 | """
197 | assert isinstance(coef_set, CoefficientSet)
198 | assert c0_value > 0.0, 'default L0_parameter should be positive'
199 | c0_value = float(c0_value)
200 | C_0 = np.array(coef_set.c0)
201 | L0_reg_ind = np.isnan(C_0)
202 | C_0[L0_reg_ind] = c0_value
203 | C_0_nnz = C_0[L0_reg_ind]
204 | return c0_value, C_0, L0_reg_ind, C_0_nnz
205 |
206 |
207 | def setup_objective_functions(compute_loss, L0_reg_ind, C_0_nnz):
208 |
209 | get_objval = lambda rho: compute_loss(rho) + np.sum(C_0_nnz * (rho[L0_reg_ind] != 0.0))
210 | get_L0_norm = lambda rho: np.count_nonzero(rho[L0_reg_ind])
211 | get_L0_penalty = lambda rho: np.sum(C_0_nnz * (rho[L0_reg_ind] != 0.0))
212 | get_alpha = lambda rho: np.array(abs(rho[L0_reg_ind]) > 0.0, dtype = np.float_)
213 | get_L0_penalty_from_alpha = lambda alpha: np.sum(C_0_nnz * alpha)
214 |
215 | return (get_objval, get_L0_norm, get_L0_penalty, get_alpha, get_L0_penalty_from_alpha)
216 |
217 |
218 | def get_loss_bounds(Z, rho_ub, rho_lb, L0_reg_ind, L0_max = float('nan')):
219 | # min value of loss = log(1+exp(-score)) occurs at max score for each point
220 | # max value of loss = loss(1+exp(-score)) occurs at min score for each point
221 |
222 | rho_lb = np.array(rho_lb)
223 | rho_ub = np.array(rho_ub)
224 |
225 | # get maximum number of regularized coefficients
226 | L0_max = Z.shape[0] if np.isnan(L0_max) else L0_max
227 | num_max_reg_coefs = min(L0_max, sum(L0_reg_ind))
228 |
229 | # calculate the smallest and largest score that can be attained by each point
230 | scores_at_lb = Z * rho_lb
231 | scores_at_ub = Z * rho_ub
232 | max_scores_matrix = np.maximum(scores_at_ub, scores_at_lb)
233 | min_scores_matrix = np.minimum(scores_at_ub, scores_at_lb)
234 | assert (np.all(max_scores_matrix >= min_scores_matrix))
235 |
236 | # for each example, compute max sum of scores from top reg coefficients
237 | max_scores_reg = max_scores_matrix[:, L0_reg_ind]
238 | max_scores_reg = -np.sort(-max_scores_reg, axis=1)
239 | max_scores_reg = max_scores_reg[:, 0:num_max_reg_coefs]
240 | max_score_reg = np.sum(max_scores_reg, axis=1)
241 |
242 | # for each example, compute max sum of scores from no reg coefficients
243 | max_scores_no_reg = max_scores_matrix[:, ~L0_reg_ind]
244 | max_score_no_reg = np.sum(max_scores_no_reg, axis=1)
245 |
246 | # max score for each example
247 | max_score = max_score_reg + max_score_no_reg
248 |
249 | # for each example, compute min sum of scores from top reg coefficients
250 | min_scores_reg = min_scores_matrix[:, L0_reg_ind]
251 | min_scores_reg = np.sort(min_scores_reg, axis=1)
252 | min_scores_reg = min_scores_reg[:, 0:num_max_reg_coefs]
253 | min_score_reg = np.sum(min_scores_reg, axis=1)
254 |
255 | # for each example, compute min sum of scores from no reg coefficients
256 | min_scores_no_reg = min_scores_matrix[:, ~L0_reg_ind]
257 | min_score_no_reg = np.sum(min_scores_no_reg, axis=1)
258 |
259 | min_score = min_score_reg + min_score_no_reg
260 | assert (np.all(max_score >= min_score))
261 |
262 | # compute min loss
263 | idx = max_score > 0
264 | min_loss = np.empty_like(max_score)
265 | min_loss[idx] = np.log1p(np.exp(-max_score[idx]))
266 | min_loss[~idx] = np.log1p(np.exp(max_score[~idx])) - max_score[~idx]
267 | min_loss = min_loss.mean()
268 |
269 | # compute max loss
270 | idx = min_score > 0
271 | max_loss = np.empty_like(min_score)
272 | max_loss[idx] = np.log1p(np.exp(-min_score[idx]))
273 | max_loss[~idx] = np.log1p(np.exp(min_score[~idx])) - min_score[~idx]
274 | max_loss = max_loss.mean()
275 |
276 | return min_loss, max_loss
277 |
--------------------------------------------------------------------------------
/riskslim/heuristics.py:
--------------------------------------------------------------------------------
1 | import numpy as np
2 |
3 | #todo: finish specifications
4 | #todo: add input checking (with ability to turn off)
5 | #todo: Cython implementation
6 |
7 | def sequential_rounding(rho, Z, C_0, compute_loss_from_scores_real, get_L0_penalty, objval_cutoff = float('Inf')):
8 | """
9 |
10 | Parameters
11 | ----------
12 | rho: P x 1 vector of continuous coefficients
13 | Z: N x P data matrix computed as X * Y
14 | C_0: N x 1 vector of L0 penalties. C_0[j] = L0 penalty for rho[j] for j = 0,..., P.
15 | compute_loss_from_scores_real: function handle to compute loss using N x 1 vector of scores, where scores = Z.dot(rho)
16 | get_L0_penalty: function handle to compute L0_penalty from rho
17 | objval_cutoff: objective value used for early stopping.
18 | the procedure will stop if the objective value achieved by an intermediate solution will exceeds objval_cutoff
19 |
20 | Returns
21 | -------
22 |
23 | rho: P x 1 vector of integer coefficients (if early_stop_flag = False, otherwise continuous solution)
24 | best_objval: objective value achieved by rho (if early_stop_flag = False, otherwise NaN)
25 | early_stop_flag: True if procedure was stopped early (in which case rho is not integer feasible)
26 |
27 | """
28 |
29 | assert callable(compute_loss_from_scores_real)
30 | assert callable(get_L0_penalty)
31 |
32 | P = rho.shape[0]
33 |
34 | rho_floor = np.floor(rho)
35 | floor_is_zero = np.equal(rho_floor, 0)
36 | dist_from_start_to_floor = rho_floor - rho
37 |
38 | rho_ceil = np.ceil(rho)
39 | ceil_is_zero = np.equal(rho_ceil, 0)
40 | dist_from_start_to_ceil = rho_ceil - rho
41 |
42 | dimensions_to_round = np.flatnonzero(np.not_equal(rho_floor, rho_ceil)).tolist()
43 |
44 | scores = Z.dot(rho)
45 | best_objval = compute_loss_from_scores_real(scores) + get_L0_penalty(rho)
46 | while len(dimensions_to_round) > 0 and best_objval < objval_cutoff:
47 |
48 | objvals_at_floor = np.repeat(np.nan, P)
49 | objvals_at_ceil = np.repeat(np.nan, P)
50 | current_penalty = get_L0_penalty(rho)
51 |
52 | for idx in dimensions_to_round:
53 |
54 | # scores go from center to ceil -> center + dist_from_start_to_ceil
55 | Z_dim = Z[:, idx]
56 | base_scores = scores + dist_from_start_to_ceil[idx] * Z_dim
57 | objvals_at_ceil[idx] = compute_loss_from_scores_real(base_scores)
58 |
59 | # move from ceil to floor => -1*Z_j
60 | base_scores -= Z_dim
61 | objvals_at_floor[idx] = compute_loss_from_scores_real(base_scores)
62 |
63 | if ceil_is_zero[idx]:
64 | objvals_at_ceil[idx] -= C_0[idx]
65 | elif floor_is_zero[idx]:
66 | objvals_at_floor[idx] -= C_0[idx]
67 |
68 |
69 | # adjust for penalty value
70 | objvals_at_ceil += current_penalty
71 | objvals_at_floor += current_penalty
72 | best_objval_at_ceil = np.nanmin(objvals_at_ceil)
73 | best_objval_at_floor = np.nanmin(objvals_at_floor)
74 |
75 | if best_objval_at_ceil <= best_objval_at_floor:
76 | best_objval = best_objval_at_ceil
77 | best_dim = np.nanargmin(objvals_at_ceil)
78 | rho[best_dim] += dist_from_start_to_ceil[best_dim]
79 | scores += dist_from_start_to_ceil[best_dim] * Z[:, best_dim]
80 | else:
81 | best_objval = best_objval_at_floor
82 | best_dim = np.nanargmin(objvals_at_floor)
83 | rho[best_dim] += dist_from_start_to_floor[best_dim]
84 | scores += dist_from_start_to_floor[best_dim] * Z[:, best_dim]
85 |
86 | dimensions_to_round.remove(best_dim)
87 | #assert(np.all(np.isclose(scores, Z.dot(rho))))
88 |
89 | early_stop_flag = best_objval > objval_cutoff
90 | return rho, best_objval, early_stop_flag
91 |
92 |
93 | def discrete_descent(rho, Z, C_0, rho_ub, rho_lb, get_L0_penalty, compute_loss_from_scores, descent_dimensions = None, active_set_flag = True):
94 |
95 | """
96 | Given a initial feasible solution, rho, produces an improved solution that is 1-OPT
97 | (i.e. the objective value does not decrease by moving in any single dimension)
98 | at each iteration, the algorithm moves in the dimension that yields the greatest decrease in objective value
99 | the best step size is each dimension is computed using a directional search strategy that saves computation
100 |
101 | Parameters
102 | ----------
103 | rho: P x 1 vector of continuous coefficients
104 | Z: N x P data matrix computed as X * Y
105 | C_0: N x 1 vector of L0 penalties. C_0[j] = L0 penalty for rho[j] for j = 0,..., P.
106 | rho_ub
107 | rho_lb
108 | compute_loss_from_scores_real: function handle to compute loss using N x 1 vector of scores, where scores = Z.dot(rho)
109 | get_L0_penalty: function handle to compute L0_penalty from rho
110 | descent_dimensions
111 |
112 | Returns
113 | -------
114 |
115 | """
116 | """
117 |
118 | """
119 | assert callable(compute_loss_from_scores)
120 | assert callable(get_L0_penalty)
121 |
122 | # initialize key variables
123 | MAX_ITERATIONS = 500
124 | MIN_IMPROVEMENT_PER_STEP = float(1e-8)
125 | P = len(rho)
126 |
127 | # convert solution to integer
128 | rho = np.require(np.require(rho, dtype = np.int_), dtype = np.float_)
129 |
130 | # convert descent dimensions to integer values
131 | if descent_dimensions is None:
132 | descent_dimensions = np.arange(P)
133 | else:
134 | descent_dimensions = np.require(descent_dimensions, dtype = np.int_)
135 |
136 | if active_set_flag:
137 | descent_dimensions = np.intersect1d(np.flatnonzero(rho), descent_dimensions)
138 |
139 | descent_dimensions = descent_dimensions.tolist()
140 |
141 | base_scores = Z.dot(rho)
142 | base_loss = compute_loss_from_scores(base_scores)
143 | base_objval = base_loss + get_L0_penalty(rho)
144 | n_iterations = 0
145 |
146 | coefficient_values = {k: np.arange(int(rho_lb[k]), int(rho_ub[k]) + 1) for k in descent_dimensions}
147 | search_dimensions = descent_dimensions
148 | while n_iterations < MAX_ITERATIONS and len(search_dimensions) > 0:
149 |
150 | # compute the best objective value / step size in each dimension
151 | best_objval_by_dim = np.repeat(np.nan, P)
152 | best_coef_by_dim = np.repeat(np.nan, P)
153 |
154 | for k in search_dimensions:
155 |
156 | dim_objvals = _compute_objvals_at_dim(base_rho = rho,
157 | base_scores = base_scores,
158 | base_loss = base_loss,
159 | dim_idx = k,
160 | dim_coefs = coefficient_values[k],
161 | Z = Z,
162 | C_0 = C_0,
163 | compute_loss_from_scores = compute_loss_from_scores)
164 |
165 | # mark points that will improve the current objective value by at least MIN_IMPROVEMENT_PER_STEP
166 | best_dim_idx = np.nanargmin(dim_objvals)
167 | best_objval_by_dim[k] = dim_objvals[best_dim_idx]
168 | best_coef_by_dim[k] = coefficient_values[k][best_dim_idx]
169 |
170 | # recompute base objective value/loss/scores
171 | best_idx = np.nanargmin(best_objval_by_dim)
172 | next_objval = best_objval_by_dim[best_idx]
173 | threshold_objval = base_objval - MIN_IMPROVEMENT_PER_STEP
174 |
175 | if next_objval >= threshold_objval:
176 | break
177 |
178 | best_step = best_coef_by_dim[best_idx] - rho[best_idx]
179 | rho[best_idx] += best_step
180 | base_objval = next_objval
181 | base_loss = base_objval - get_L0_penalty(rho)
182 | base_scores = base_scores + (best_step * Z[:, best_idx])
183 |
184 | # remove the current best direction from the set of directions to explore
185 | search_dimensions = list(descent_dimensions)
186 | search_dimensions.remove(best_idx)
187 | n_iterations += 1
188 |
189 | return rho, base_loss, base_objval
190 |
191 |
192 | def _compute_objvals_at_dim(Z, C_0, base_rho, base_scores, base_loss, dim_coefs, dim_idx, compute_loss_from_scores):
193 |
194 | """
195 | finds the value of rho[j] in dim_coefs that minimizes log_loss(rho) + C_0j
196 |
197 | Parameters
198 | ----------
199 | Z
200 | C_0
201 | base_rho
202 | base_scores
203 | base_loss
204 | dim_coefs
205 | dim_idx
206 | compute_loss_from_scores
207 |
208 | Returns
209 | -------
210 |
211 | """
212 |
213 | # copy stuff because ctypes
214 | scores = np.copy(base_scores)
215 |
216 | # initialize parameters
217 | P = base_rho.shape[0]
218 | base_coef_value = base_rho[dim_idx]
219 | base_index = np.flatnonzero(dim_coefs == base_coef_value)
220 | loss_at_coef_value = np.repeat(np.nan, len(dim_coefs))
221 | loss_at_coef_value[base_index] = float(base_loss)
222 | Z_dim = Z[:, dim_idx]
223 |
224 | # start by moving forward
225 | forward_indices = np.flatnonzero(base_coef_value <= dim_coefs)
226 | forward_step_sizes = np.diff(dim_coefs[forward_indices] - base_coef_value)
227 | n_forward_steps = len(forward_step_sizes)
228 | stop_after_first_forward_step = False
229 |
230 | best_loss = base_loss
231 | total_distance_from_base = 0
232 |
233 | for i in range(n_forward_steps):
234 | scores += forward_step_sizes[i] * Z_dim
235 | total_distance_from_base += forward_step_sizes[i]
236 | current_loss = compute_loss_from_scores(scores)
237 | if current_loss >= best_loss:
238 | stop_after_first_forward_step = i == 0
239 | break
240 | loss_at_coef_value[forward_indices[i + 1]] = current_loss
241 | best_loss = current_loss
242 |
243 | # if the first step forward didn't lead to a decrease in loss, then move backwards
244 | move_backward = stop_after_first_forward_step or n_forward_steps == 0
245 |
246 | if move_backward:
247 |
248 | # compute backward steps
249 | backward_indices = np.flipud(np.where(dim_coefs <= base_coef_value)[0])
250 | backward_step_sizes = np.diff(dim_coefs[backward_indices] - base_coef_value)
251 | n_backward_steps = len(backward_step_sizes)
252 |
253 | # correct size of first backward step if you took 1 step forward
254 | if n_backward_steps > 0 and n_forward_steps > 0:
255 | backward_step_sizes[0] = backward_step_sizes[0] - forward_step_sizes[0]
256 |
257 | best_loss = base_loss
258 |
259 | for i in range(n_backward_steps):
260 | scores += backward_step_sizes[i] * Z_dim
261 | total_distance_from_base += backward_step_sizes[i]
262 | current_loss = compute_loss_from_scores(scores)
263 | if current_loss >= best_loss:
264 | break
265 | loss_at_coef_value[backward_indices[i + 1]] = current_loss
266 | best_loss = current_loss
267 |
268 | # at this point scores == base_scores + step_distance*Z_dim
269 | # assert(all(np.isclose(scores, base_scores + total_distance_from_base * Z_dim)))
270 |
271 | # compute objective values by adding penalty values to all other indices
272 | other_dim_idx = np.flatnonzero(dim_idx != np.arange(P))
273 | other_dim_penalty = np.sum(C_0[other_dim_idx] * (base_rho[other_dim_idx] != 0))
274 | objval_at_coef_values = loss_at_coef_value + other_dim_penalty
275 |
276 | if C_0[dim_idx] > 0.0:
277 |
278 | # increase objective value at every non-zero coefficient value by C_0j
279 | nonzero_coef_idx = np.flatnonzero(dim_coefs)
280 | objval_at_coef_values[nonzero_coef_idx] = objval_at_coef_values[nonzero_coef_idx] + C_0[dim_idx]
281 |
282 | # compute value at coef[j] == 0 if needed
283 | zero_coef_idx = np.flatnonzero(dim_coefs == 0)
284 | if np.isnan(objval_at_coef_values[zero_coef_idx]):
285 | # steps_from_here_to_zero: step_from_here_to_base + step_from_base_to_zero
286 | # steps_from_here_to_zero: -step_from_base_to_here + -step_from_zero_to_base
287 | steps_to_zero = -(base_coef_value + total_distance_from_base)
288 | scores += steps_to_zero * Z_dim
289 | objval_at_coef_values[zero_coef_idx] = compute_loss_from_scores(scores) + other_dim_penalty
290 | # assert(all(np.isclose(scores, base_scores - base_coef_value * Z_dim)))
291 |
292 | # return objective value at feasible coefficients
293 | return objval_at_coef_values
294 |
295 |
296 |
--------------------------------------------------------------------------------
/riskslim/utils.py:
--------------------------------------------------------------------------------
1 | import logging
2 | import sys
3 | from pathlib import Path
4 | import time
5 | import warnings
6 | import numpy as np
7 | import pandas as pd
8 | import prettytable as pt
9 | from .defaults import INTERCEPT_NAME
10 |
11 | # DATA
12 | def load_data_from_csv(dataset_csv_file, sample_weights_csv_file = None, fold_csv_file = None, fold_num = 0):
13 | """
14 |
15 | Parameters
16 | ----------
17 | dataset_csv_file csv file containing the training data
18 | see /datasets/adult_data.csv for an example
19 | training data stored as a table with N+1 rows and d+1 columns
20 | column 1 is the outcome variable entries must be (-1,1) or (0,1)
21 | column 2 to d+1 are the d input variables
22 | row 1 contains unique names for the outcome variable, and the input vairable
23 |
24 | sample_weights_csv_file csv file containing sample weights for the training data
25 | weights stored as a table with N rows and 1 column
26 | all sample weights must be non-negative
27 |
28 | fold_csv_file csv file containing indices of folds for K-fold cross validation
29 | fold indices stored as a table with N rows and 1 column
30 | folds must be integers between 1 to K
31 | if fold_csv_file is None, then we do not use folds
32 |
33 | fold_num int between 0 to K, where K is set by the fold_csv_file
34 | let fold_idx be the N x 1 index vector listed in fold_csv_file
35 | samples where fold_idx == fold_num will be used to test
36 | samples where fold_idx != fold_num will be used to train the model
37 | fold_num = 0 means use "all" of the training data (since all values of fold_idx \in [1,K])
38 | if fold_csv_file is None, then fold_num is set to 0
39 |
40 |
41 | Returns
42 | -------
43 | dictionary containing training data for a binary classification problem with the fields:
44 |
45 | - 'X' N x P matrix of features (numpy.ndarray) with a column of 1s for the INTERCEPT_NAME
46 | - 'Y' N x 1 vector of labels (+1/-1) (numpy.ndarray)
47 | - 'variable_names' list of strings containing the names of each feature (list)
48 | - 'Y_name' string containing the name of the output (optional)
49 | - 'sample_weights' N x 1 vector of sample weights, must all be positive
50 |
51 | """
52 | dataset_csv_file = Path(dataset_csv_file)
53 | if not dataset_csv_file.exists():
54 | raise IOError('could not find dataset_csv_file: %s' % dataset_csv_file)
55 |
56 | df = pd.read_csv(dataset_csv_file, sep = ',')
57 |
58 | raw_data = df.to_numpy()
59 | data_headers = list(df.columns.values)
60 | N = raw_data.shape[0]
61 |
62 | # setup Y vector and Y_name
63 | Y_col_idx = [0]
64 | Y = raw_data[:, Y_col_idx]
65 | Y_name = data_headers[Y_col_idx[0]]
66 | Y[Y == 0] = -1
67 |
68 | # setup X and X_names
69 | X_col_idx = [j for j in range(raw_data.shape[1]) if j not in Y_col_idx]
70 | X = raw_data[:, X_col_idx]
71 | variable_names = [data_headers[j] for j in X_col_idx]
72 |
73 | # insert a column of ones to X for the intercept
74 | X = np.insert(arr=X, obj=0, values=np.ones(N), axis=1)
75 | variable_names.insert(0, INTERCEPT_NAME)
76 |
77 |
78 | if sample_weights_csv_file is None:
79 | sample_weights = np.ones(N)
80 | else:
81 | sample_weights_csv_file = Path(sample_weights_csv_file)
82 | if not sample_weights_csv_file.exists():
83 | raise IOError('could not find sample_weights_csv_file: %s' % sample_weights_csv_file)
84 | sample_weights = pd.read_csv(sample_weights_csv_file, sep=',', header=None)
85 | sample_weights = sample_weights.to_numpy()
86 |
87 | data = {
88 | 'X': X,
89 | 'Y': Y,
90 | 'variable_names': variable_names,
91 | 'outcome_name': Y_name,
92 | 'sample_weights': sample_weights,
93 | }
94 |
95 | #load folds
96 | if fold_csv_file is not None:
97 | fold_csv_file = Path(fold_csv_file)
98 | if not fold_csv_file.exists():
99 | raise IOError('could not find fold_csv_file: %s' % fold_csv_file)
100 |
101 | fold_idx = pd.read_csv(fold_csv_file, sep=',', header=None)
102 | fold_idx = fold_idx.values.flatten()
103 | K = max(fold_idx)
104 | all_fold_nums = np.sort(np.unique(fold_idx))
105 | assert len(fold_idx) == N, "dimension mismatch: read %r fold indices (expected N = %r)" % (len(fold_idx), N)
106 | assert np.all(all_fold_nums == np.arange(1, K+1)), "folds should contain indices between 1 to %r" % K
107 | assert fold_num in np.arange(0, K+1), "fold_num should either be 0 or an integer between 1 to %r" % K
108 | if fold_num >= 1:
109 | #test_idx = fold_num == fold_idx
110 | train_idx = fold_num != fold_idx
111 | data['X'] = data['X'][train_idx,]
112 | data['Y'] = data['Y'][train_idx]
113 | data['sample_weights'] = data['sample_weights'][train_idx]
114 |
115 | assert check_data(data)
116 | return data
117 |
118 |
119 | def check_data(data):
120 | """
121 | makes sure that 'data' contains training data that is suitable for binary classification problems
122 | throws AssertionError if
123 |
124 | 'data' is a dictionary that must contain:
125 |
126 | - 'X' N x P matrix of features (numpy.ndarray) with a column of 1s for the INTERCEPT_NAME
127 | - 'Y' N x 1 vector of labels (+1/-1) (numpy.ndarray)
128 | - 'variable_names' list of strings containing the names of each feature (list)
129 |
130 | data can also contain:
131 |
132 | - 'outcome_name' string containing the name of the output (optional)
133 | - 'sample_weights' N x 1 vector of sample weights, must all be positive
134 |
135 | Returns
136 | -------
137 | True if data passes checks
138 |
139 | """
140 | # type checks
141 | assert type(data) is dict, "data should be a dict"
142 |
143 | assert 'X' in data, "data should contain X matrix"
144 | assert type(data['X']) is np.ndarray, "type(X) should be numpy.ndarray"
145 |
146 | assert 'Y' in data, "data should contain Y matrix"
147 | assert type(data['Y']) is np.ndarray, "type(Y) should be numpy.ndarray"
148 |
149 | assert 'variable_names' in data, "data should contain variable_names"
150 | assert type(data['variable_names']) is list, "variable_names should be a list"
151 |
152 | X = data['X']
153 | Y = data['Y']
154 | variable_names = data['variable_names']
155 |
156 | if 'outcome_name' in data:
157 | assert type(data['outcome_name']) is str, "outcome_name should be a str"
158 |
159 | # sizes and uniqueness
160 | N, P = X.shape
161 | assert N > 0, 'X matrix must have at least 1 row'
162 | assert P > 0, 'X matrix must have at least 1 column'
163 | assert len(Y) == N, 'dimension mismatch. Y must contain as many entries as X. Need len(Y) = N.'
164 | assert len(list(set(data['variable_names']))) == len(data['variable_names']), 'variable_names is not unique'
165 | assert len(data['variable_names']) == P, 'len(variable_names) should be same as # of cols in X'
166 |
167 | # feature matrix
168 | assert np.all(~np.isnan(X)), 'X has nan entries'
169 | assert np.all(~np.isinf(X)), 'X has inf entries'
170 |
171 | # offset in feature matrix
172 | if INTERCEPT_NAME in variable_names:
173 | assert all(X[:, variable_names.index(INTERCEPT_NAME)] == 1.0), "(Intercept)' column should only be composed of 1s"
174 | else:
175 | warnings.warn("there is no column named INTERCEPT_NAME in variable_names")
176 |
177 | # labels values
178 | assert all((Y == 1) | (Y == -1)), 'Need Y[i] = [-1,1] for all i.'
179 | if all(Y == 1):
180 | warnings.warn('Y does not contain any positive examples. Need Y[i] = +1 for at least 1 i.')
181 | if all(Y == -1):
182 | warnings.warn('Y does not contain any negative examples. Need Y[i] = -1 for at least 1 i.')
183 |
184 | if 'sample_weights' in data:
185 | sample_weights = data['sample_weights']
186 | type(sample_weights) is np.ndarray
187 | assert len(sample_weights) == N, 'sample_weights should contain N elements'
188 | assert all(sample_weights > 0.0), 'sample_weights[i] > 0 for all i '
189 |
190 | # by default, we set sample_weights as an N x 1 array of ones. if not, then sample weights is non-trivial
191 | if any(sample_weights != 1.0) and len(np.unique(sample_weights)) < 2:
192 | warnings.warn('note: sample_weights only has <2 unique values')
193 |
194 | return True
195 |
196 |
197 | # MODEL PRINTING
198 | def print_model(rho, data, show_omitted_variables = False):
199 |
200 | variable_names = data['variable_names']
201 |
202 | rho_values = np.copy(rho)
203 | rho_names = list(variable_names)
204 |
205 | if INTERCEPT_NAME in rho_names:
206 | intercept_ind = variable_names.index(INTERCEPT_NAME)
207 | intercept_val = int(rho[intercept_ind])
208 | rho_values = np.delete(rho_values, intercept_ind)
209 | rho_names.remove(INTERCEPT_NAME)
210 | else:
211 | intercept_val = 0
212 |
213 | if 'outcome_name' in data:
214 | predict_string = "Pr(Y = +1) = 1.0/(1.0 + exp(-(%d + score))" % intercept_val
215 | else:
216 | predict_string = "Pr(%s = +1) = 1.0/(1.0 + exp(-(%d + score))" % (data['outcome_name'].upper(), intercept_val)
217 |
218 | if not show_omitted_variables:
219 | selected_ind = np.flatnonzero(rho_values)
220 | rho_values = rho_values[selected_ind]
221 | rho_names = [rho_names[i] for i in selected_ind]
222 | rho_binary = [np.all((data['X'][:,j] == 0) | (data['X'][:,j] == 1)) for j in selected_ind]
223 |
224 | #sort by most positive to most negative
225 | sort_ind = np.argsort(-np.array(rho_values))
226 | rho_values = [rho_values[j] for j in sort_ind]
227 | rho_names = [rho_names[j] for j in sort_ind]
228 | rho_binary = [rho_binary[j] for j in sort_ind]
229 | rho_values = np.array(rho_values)
230 |
231 | rho_values_string = [str(int(i)) + " points" for i in rho_values]
232 | n_variable_rows = len(rho_values)
233 | total_string = "ADD POINTS FROM ROWS %d to %d" % (1, n_variable_rows)
234 |
235 | max_name_col_length = max(len(predict_string), len(total_string), max([len(s) for s in rho_names])) + 2
236 | max_value_col_length = max(7, max([len(s) for s in rho_values_string]) + len("points")) + 2
237 |
238 | m = pt.PrettyTable()
239 | m.field_names = ["Variable", "Points", "Tally"]
240 |
241 | m.add_row([predict_string, "", ""])
242 | m.add_row(['=' * max_name_col_length, "=" * max_value_col_length, "========="])
243 |
244 | for name, value_string in zip(rho_names, rho_values_string):
245 | m.add_row([name, value_string, "+ ....."])
246 |
247 | m.add_row(['=' * max_name_col_length, "=" * max_value_col_length, "========="])
248 | m.add_row([total_string, "SCORE", "= ....."])
249 | m.header = False
250 | m.align["Variable"] = "l"
251 | m.align["Points"] = "r"
252 | m.align["Tally"] = "r"
253 |
254 | print(m)
255 | return m
256 |
257 |
258 | # LOGGING
259 | def setup_logging(logger, log_to_console = True, log_file = None):
260 | """
261 | Sets up logging to console and file on disk
262 | See https://docs.python.org/2/howto/logging-cookbook.html for details on how to customize
263 |
264 | Parameters
265 | ----------
266 | log_to_console set to True to disable logging in console
267 | log_file path to file for loggin
268 |
269 | Returns
270 | -------
271 | Logger object that prints formatted messages to log_file and console
272 | """
273 |
274 | # quick return if no logging to console or file
275 | if log_to_console is False and log_file is None:
276 | logger.disabled = True
277 | return logger
278 |
279 | log_format = logging.Formatter(fmt='%(asctime)s | %(levelname)-8s | %(message)s', datefmt='%m-%d-%Y %I:%M:%S %p')
280 |
281 | # log to file
282 | if log_file is not None:
283 | fh = logging.FileHandler(filename=log_file)
284 | #fh.setLevel(logging.DEBUG)
285 | fh.setFormatter(log_format)
286 | logger.addHandler(fh)
287 |
288 | if log_to_console:
289 | ch = logging.StreamHandler()
290 | #ch.setLevel(logging.DEBUG)
291 | ch.setFormatter(log_format)
292 | logger.addHandler(ch)
293 |
294 | return logger
295 |
296 |
297 | def print_log(msg, print_flag = True):
298 | """
299 |
300 | Parameters
301 | ----------
302 | msg
303 | print_flag
304 |
305 | Returns
306 | -------
307 |
308 | """
309 | if print_flag:
310 | if isinstance(msg, str):
311 | print('%s | %s' % (time.strftime("%m/%d/%y @ %I:%M %p", time.localtime()), msg))
312 | else:
313 | print('%s | %r' % (time.strftime("%m/%d/%y @ %I:%M %p", time.localtime()), msg))
314 | sys.stdout.flush()
315 |
316 |
317 | def validate_settings(settings = None, default_settings = None):
318 |
319 | if settings is None:
320 | settings = dict()
321 | else:
322 | assert isinstance(settings, dict)
323 | settings = dict(settings)
324 |
325 | if default_settings is not None:
326 | assert isinstance(default_settings, dict)
327 | settings = {k: settings[k] if k in settings else default_settings[k] for k in default_settings}
328 |
329 | return settings
--------------------------------------------------------------------------------
/riskslim/coefficient_set.py:
--------------------------------------------------------------------------------
1 | import numpy as np
2 | from prettytable import PrettyTable
3 | from .defaults import INTERCEPT_NAME
4 |
5 |
6 | class CoefficientSet(object):
7 | """
8 | Class used to represent and manipulate constraints on individual coefficients
9 | including upper bound, lower bound, variable type, and regularization.
10 | Coefficient Set is composed of Coefficient Elements
11 | """
12 |
13 | _initialized = False
14 | _print_flag = True
15 | _check_flag = True
16 | _correct_flag = True
17 | _variable_names = None
18 |
19 | def __init__(self, variable_names, **kwargs):
20 |
21 | # set variables using setter methods
22 | self.variable_names = list(variable_names)
23 | self.print_flag = kwargs.get('print_flag', self._print_flag)
24 | self.check_flag = kwargs.get('check_flag', self._check_flag)
25 | self.correct_flag = kwargs.get('correct_flag', self._correct_flag)
26 |
27 | ub = kwargs.get('ub', _CoefficientElement._DEFAULT_UB)
28 | lb = kwargs.get('lb', _CoefficientElement._DEFAULT_LB)
29 | c0 = kwargs.get('c0', _CoefficientElement._DEFAULT_c0)
30 | vtype = kwargs.get('type', _CoefficientElement._DEFAULT_TYPE)
31 |
32 | ub = self._expand_values(value = ub)
33 | lb = self._expand_values(value = lb)
34 | c0 = self._expand_values(value = c0)
35 | vtype = self._expand_values(value = vtype)
36 |
37 | self._coef_elements = dict()
38 | for name in variable_names:
39 | idx = variable_names.index(name)
40 | self._coef_elements[name] = _CoefficientElement(name = name, ub = ub[idx], lb = lb[idx], c0 = c0[idx], vtype = vtype[idx])
41 |
42 | self._check_rep()
43 | self._initialized = True
44 |
45 |
46 | @property
47 | def P(self):
48 | return len(self._variable_names)
49 |
50 |
51 | @property
52 | def print_flag(self):
53 | return bool(self._print_flag)
54 |
55 |
56 | @print_flag.setter
57 | def print_flag(self, flag):
58 | self._print_flag = bool(flag)
59 |
60 |
61 | @property
62 | def correct_flag(self):
63 | return bool(self._correct_flag)
64 |
65 |
66 | @correct_flag.setter
67 | def correct_flag(self, flag):
68 | self._correct_flag = bool(flag)
69 |
70 |
71 | @property
72 | def check_flag(self):
73 | return self._check_flag
74 |
75 |
76 | @check_flag.setter
77 | def check_flag(self, flag):
78 | self._check_flag = bool(flag)
79 |
80 |
81 | @property
82 | def variable_names(self):
83 | return self._variable_names
84 |
85 |
86 | @variable_names.setter
87 | def variable_names(self, names):
88 | assert isinstance(names, list), 'variable_names must be a list'
89 | for name in names:
90 | assert isinstance(name, str), 'variable_names must be a list of strings'
91 | assert len(names) == len(set(names)), 'variable_names contain elements with unique names'
92 | if self._variable_names is not None:
93 | assert len(names) == len(self), 'variable_names must contain at least %d elements' % len(self)
94 | self._variable_names = list(names)
95 |
96 |
97 | def index(self, name):
98 | assert isinstance(name, str)
99 | if name in self._variable_names:
100 | return self._variable_names.index(name)
101 | else:
102 | raise ValueError('no variable named %s in coefficient set' % name)
103 |
104 |
105 | def penalized_indices(self):
106 | return np.array(list(map(lambda v: self._coef_elements[v].penalized, self._variable_names)))
107 |
108 |
109 | def update_intercept_bounds(self, X, y, max_offset, max_L0_value = None):
110 | """
111 | uses data to set the lower and upper bound on the offset to a conservative value
112 | the value is guaranteed to avoid a loss in performance
113 |
114 | optimal_offset = max_abs_score + 1
115 | where max_abs_score is the largest absolute score that can be achieved using the coefficients in coef_set
116 | with the training data. note:
117 | when offset >= optimal_offset, then we predict y = +1 for every example
118 | when offset <= optimal_offset, then we predict y = -1 for every example
119 | thus, any feasible model should do better.
120 |
121 |
122 | Parameters
123 | ----------
124 | X
125 | y
126 | max_offset
127 | max_L0_value
128 |
129 | Returns
130 | -------
131 | None
132 |
133 | """
134 | if INTERCEPT_NAME not in self._coef_elements:
135 | raise ValueError("coef_set must contain a variable for the offset called %s" % INTERCEPT_NAME)
136 |
137 | e = self._coef_elements[INTERCEPT_NAME]
138 |
139 | # get idx of intercept/variables
140 | names = self.variable_names
141 | variable_names = list(names)
142 | variable_names.remove(INTERCEPT_NAME)
143 | variable_idx = np.array([names.index(n) for n in variable_names])
144 |
145 | # get max # of non-zero coefficients given model size limit
146 | penalized_idx = [self._coef_elements[n].penalized for n in variable_names]
147 | trivial_L0_max = len(penalized_idx)
148 |
149 | if max_L0_value is None:
150 | max_L0_value = trivial_L0_max
151 |
152 | if max_L0_value > 0:
153 | max_L0_value = min(trivial_L0_max, max_L0_value)
154 |
155 | # update intercept bounds
156 | Z = X * y
157 | Z_min = np.min(Z, axis = 0)
158 | Z_max = np.max(Z, axis = 0)
159 |
160 | # get regularized indices
161 | L0_reg_ind = np.isnan(self.C_0j)[variable_idx]
162 |
163 | # get smallest / largest score
164 | s_min, s_max = get_score_bounds(Z_min = Z_min[variable_idx],
165 | Z_max = Z_max[variable_idx],
166 | rho_lb = self.lb[variable_idx],
167 | rho_ub = self.ub[variable_idx],
168 | L0_reg_ind = L0_reg_ind,
169 | L0_max = max_L0_value)
170 |
171 | # get max # of non-zero coefficients given model size limit
172 | conservative_offset = max(abs(s_min), abs(s_max)) + 1
173 | max_offset = min(max_offset, conservative_offset)
174 | e.ub = max_offset
175 | e.lb = -max_offset
176 |
177 |
178 | def tabulate(self):
179 | t = PrettyTable()
180 | t.align = "r"
181 | t.add_column("variable_name", self._variable_names)
182 | t.add_column("vtype", self.vtype)
183 | t.add_column("sign", self.sign)
184 | t.add_column("lb", self.lb)
185 | t.add_column("ub", self.ub)
186 | t.add_column("c0", self.c0)
187 | return str(t)
188 |
189 |
190 | def __len__(self):
191 | return len(self._variable_names)
192 |
193 |
194 | def __str__(self):
195 | return self.tabulate()
196 |
197 |
198 | def __repr__(self):
199 | if self.print_flag:
200 | return self.tabulate()
201 |
202 |
203 | def __getattr__(self, name):
204 |
205 | if name == 'C_0j':
206 | name = 'c0'
207 |
208 | vals = [getattr(self._coef_elements[v], name) for v in self._variable_names]
209 | if name in ['ub', 'lb', 'c0', 'sign', 'vtype']:
210 | return np.array(vals)
211 | else:
212 | return list(vals)
213 |
214 |
215 | def __setattr__(self, name, value):
216 | if self._initialized:
217 | assert all(map(lambda e: hasattr(e, name), self._coef_elements.values()))
218 | attr_values = self._expand_values(value)
219 | for e, v in zip(self._coef_elements.values(), attr_values):
220 | setattr(e, name, v)
221 | self._check_rep()
222 | else:
223 | object.__setattr__(self, name, value)
224 |
225 |
226 | def __getitem__(self, key):
227 |
228 | if isinstance(key, int):
229 | assert 0 <= int(key) <= self.P
230 | return self._coef_elements[self._variable_names[key]]
231 | elif isinstance(key, str):
232 | return self._coef_elements[key]
233 | else:
234 | raise KeyError('invalid key')
235 |
236 |
237 | def __setitem__(self, key, value):
238 |
239 | if isinstance(key, int):
240 | assert 0 <= int(key) <= self.P
241 | key = self._variable_names[key]
242 | elif isinstance(key, str):
243 | assert isinstance(key, str)
244 | assert key in self._variable_names
245 | assert value.name == key
246 | else:
247 | raise KeyError('invalid key')
248 |
249 | assert isinstance(value, _CoefficientElement)
250 | self._coef_elements[key] = value
251 |
252 |
253 | def _check_rep(self):
254 |
255 | if self._check_flag:
256 |
257 | assert len(self._variable_names) == len(set(self._variable_names))
258 |
259 | for name in self._variable_names:
260 | assert isinstance(name, str)
261 | assert len(name) >= 1
262 | assert self._coef_elements[name]._check_rep()
263 |
264 | if self._correct_flag:
265 |
266 | for name in self._variable_names:
267 | e = self._coef_elements[name]
268 | if name in {'Intercept', '(Intercept)', 'intercept', '(intercept)'}:
269 | if e.c0 > 0 or np.isnan(e.c0):
270 | if self._print_flag:
271 | print("setting c0_value = 0.0 for %s to ensure that intercept is not penalized" % name)
272 | e._c0 = 0.0
273 |
274 | return True
275 |
276 |
277 | def _expand_values(self, value):
278 |
279 | if isinstance(value, np.ndarray):
280 | if value.size == self.P:
281 | value_array = value
282 | elif value.size == 1:
283 | value_array = np.repeat(value, self.P)
284 | else:
285 | raise ValueError("length mismatch; need either 1 or %d values" % self.P)
286 |
287 | elif isinstance(value, list):
288 | if len(value) == self.P:
289 | value_array = value
290 | elif len(value) == 1:
291 | value_array = [value] * self.P
292 | else:
293 | raise ValueError("length mismatch; need either 1 or %d values" % self.P)
294 |
295 | elif isinstance(value, str):
296 | value_array = [str(value)] * self.P
297 |
298 | elif isinstance(value, int):
299 | value_array = [int(value)] * self.P
300 |
301 | elif isinstance(value, float):
302 | value_array = [float(value)] * self.P
303 |
304 | else:
305 | raise ValueError("unknown variable type %s")
306 |
307 | return(value_array)
308 |
309 |
310 | class _CoefficientElement(object):
311 |
312 | _DEFAULT_UB = 5
313 | _DEFAULT_LB = -5
314 | _DEFAULT_c0 = float('nan')
315 | _DEFAULT_TYPE = 'I'
316 | _VALID_TYPES = ['I', 'C']
317 |
318 | def _is_integer(self, x):
319 | return np.array_equal(x, np.require(x, dtype = np.int_))
320 |
321 |
322 | def __init__(self, name, ub = _DEFAULT_UB, lb = _DEFAULT_LB, c0 = _DEFAULT_c0, vtype = _DEFAULT_TYPE):
323 |
324 | self._name = str(name)
325 | self._ub = float(ub)
326 | self._lb = float(lb)
327 | self._c0 = float(c0)
328 | self._vtype = vtype
329 | assert self._check_rep()
330 |
331 |
332 | @property
333 | def name(self):
334 | return self._name
335 |
336 |
337 | @property
338 | def vtype(self):
339 | return self._vtype
340 |
341 |
342 | @vtype.setter
343 | def vtype(self, value):
344 | assert isinstance(value, str)
345 | assert value in self._VALID_TYPES
346 | self._vtype = str(value)
347 |
348 |
349 | @property
350 | def ub(self):
351 | return self._ub
352 |
353 |
354 | @ub.setter
355 | def ub(self, value):
356 | if hasattr(value, '__len__'):
357 | assert len(value) == 1
358 | value = value[0]
359 | assert value >= self._lb
360 | self._ub = float(value)
361 |
362 |
363 | @property
364 | def lb(self):
365 | return self._lb
366 |
367 |
368 | @lb.setter
369 | def lb(self, value):
370 | if hasattr(value, '__len__'):
371 | assert len(value) == 1
372 | value = value[0]
373 | assert value <= self._ub
374 | self._lb = float(value)
375 |
376 |
377 | @property
378 | def c0(self):
379 | return self._c0
380 |
381 |
382 | @c0.setter
383 | def c0(self, value):
384 | if np.isnan(value):
385 | self._c0 = float('nan')
386 | else:
387 | assert np.isfinite(value), 'L0 penalty for %s must either be NaN or a finite positive number' % self._name
388 | assert value >= 0.0, 'L0 penalty for %s must either be NaN or a finite positive number' % self._name
389 | self._c0 = float(value)
390 |
391 |
392 | @property
393 | def penalized(self):
394 | return np.isnan(self._c0) or (self._c0 > 0.0)
395 |
396 |
397 | @property
398 | def sign(self):
399 | if self._ub > 0.0 and self._lb >= 0.0:
400 | return 1
401 | elif self._ub <= 0.0 and self._lb < 0.0:
402 | return -1
403 | else:
404 | return 0
405 |
406 | @sign.setter
407 | def sign(self, value):
408 | if value > 0:
409 | self._lb = 0.0
410 | elif value < 0:
411 | self._ub = 0.0
412 |
413 |
414 | def _check_rep(self):
415 |
416 | #name
417 | assert isinstance(self._name, str)
418 | assert len(self._name) >= 1
419 |
420 | #bounds
421 | assert np.isfinite(self.ub)
422 | assert np.isfinite(self.lb)
423 | assert self.ub >= self.lb
424 |
425 | # value
426 | assert self._vtype in self._VALID_TYPES
427 | assert np.isnan(self.c0) or (self.c0 >= 0.0 and np.isfinite(self.c0))
428 |
429 | return True
430 |
431 |
432 | def __repr__(self):
433 | return self.tabulate()
434 |
435 |
436 | def __str__(self):
437 | return self.tabulate()
438 |
439 |
440 | def tabulate(self):
441 | s = ['-' * 60,
442 | 'variable: %s' % self._name,
443 | '-' * 60,
444 | '%s: %1.1f' % ('ub', self._ub),
445 | '%s: %1.1f' % ('lb', self._lb),
446 | '%s: %1.2g' % ('c0', self._c0),
447 | '%s: %1.0f' % ('sign', self.sign),
448 | '%s: %s' % ('vtype', self._vtype)]
449 | t = '\n' + '\n'.join(s) + '\n'
450 | return t
451 |
452 |
453 | def get_score_bounds(Z_min, Z_max, rho_lb, rho_ub, L0_reg_ind = None, L0_max = None):
454 |
455 | edge_values = np.vstack([Z_min * rho_lb, Z_max * rho_lb, Z_min * rho_ub, Z_max * rho_ub])
456 |
457 | if (L0_max is None) or (L0_reg_ind is None) or (L0_max == Z_min.shape[0]):
458 | s_min = np.sum(np.min(edge_values, axis=0))
459 | s_max = np.sum(np.max(edge_values, axis=0))
460 | else:
461 | min_values = np.min(edge_values, axis=0)
462 | s_min_reg = np.sum(np.sort(min_values[L0_reg_ind])[0:L0_max])
463 | s_min_no_reg = np.sum(min_values[~L0_reg_ind])
464 | s_min = s_min_reg + s_min_no_reg
465 |
466 | max_values = np.max(edge_values, axis=0)
467 | s_max_reg = np.sum(-np.sort(-max_values[L0_reg_ind])[0:L0_max])
468 | s_max_no_reg = np.sum(max_values[~L0_reg_ind])
469 | s_max = s_max_reg + s_max_no_reg
470 |
471 | return s_min, s_max
--------------------------------------------------------------------------------
/examples/data/breastcancer_data.csv:
--------------------------------------------------------------------------------
1 | Benign,ClumpThickness,UniformityOfCellSize,UniformityOfCellShape,MarginalAdhesion,SingleEpithelialCellSize,BareNuclei,BlandChromatin,NormalNucleoli,Mitoses
2 | 0,5,1,1,1,2,1,3,1,1
3 | 0,5,4,4,5,7,10,3,2,1
4 | 0,3,1,1,1,2,2,3,1,1
5 | 0,6,8,8,1,3,4,3,7,1
6 | 0,4,1,1,3,2,1,3,1,1
7 | 1,8,10,10,8,7,10,9,7,1
8 | 0,1,1,1,1,2,10,3,1,1
9 | 0,2,1,2,1,2,1,3,1,1
10 | 0,2,1,1,1,2,1,1,1,5
11 | 0,4,2,1,1,2,1,2,1,1
12 | 0,1,1,1,1,1,1,3,1,1
13 | 0,2,1,1,1,2,1,2,1,1
14 | 1,5,3,3,3,2,3,4,4,1
15 | 0,1,1,1,1,2,3,3,1,1
16 | 1,8,7,5,10,7,9,5,5,4
17 | 1,7,4,6,4,6,1,4,3,1
18 | 0,4,1,1,1,2,1,2,1,1
19 | 0,4,1,1,1,2,1,3,1,1
20 | 1,10,7,7,6,4,10,4,1,2
21 | 0,6,1,1,1,2,1,3,1,1
22 | 1,7,3,2,10,5,10,5,4,4
23 | 1,10,5,5,3,6,7,7,10,1
24 | 0,3,1,1,1,2,1,2,1,1
25 | 0,1,1,1,1,2,1,3,1,1
26 | 1,5,2,3,4,2,7,3,6,1
27 | 0,3,2,1,1,1,1,2,1,1
28 | 0,5,1,1,1,2,1,2,1,1
29 | 0,2,1,1,1,2,1,2,1,1
30 | 0,1,1,3,1,2,1,1,1,1
31 | 0,3,1,1,1,1,1,2,1,1
32 | 0,2,1,1,1,2,1,3,1,1
33 | 1,10,7,7,3,8,5,7,4,3
34 | 0,2,1,1,2,2,1,3,1,1
35 | 0,3,1,2,1,2,1,2,1,1
36 | 0,2,1,1,1,2,1,2,1,1
37 | 1,10,10,10,8,6,1,8,9,1
38 | 0,6,2,1,1,1,1,7,1,1
39 | 1,5,4,4,9,2,10,5,6,1
40 | 1,2,5,3,3,6,7,7,5,1
41 | 1,10,4,3,1,3,3,6,5,2
42 | 1,6,10,10,2,8,10,7,3,3
43 | 1,5,6,5,6,10,1,3,1,1
44 | 1,10,10,10,4,8,1,8,10,1
45 | 0,1,1,1,1,2,1,2,1,2
46 | 1,3,7,7,4,4,9,4,8,1
47 | 0,1,1,1,1,2,1,2,1,1
48 | 0,4,1,1,3,2,1,3,1,1
49 | 1,7,8,7,2,4,8,3,8,2
50 | 1,9,5,8,1,2,3,2,1,5
51 | 1,5,3,3,4,2,4,3,4,1
52 | 1,10,3,6,2,3,5,4,10,2
53 | 1,5,5,5,8,10,8,7,3,7
54 | 1,10,5,5,6,8,8,7,1,1
55 | 1,10,6,6,3,4,5,3,6,1
56 | 1,8,10,10,1,3,6,3,9,1
57 | 1,8,2,4,1,5,1,5,4,4
58 | 1,5,2,3,1,6,10,5,1,1
59 | 1,9,5,5,2,2,2,5,1,1
60 | 1,5,3,5,5,3,3,4,10,1
61 | 0,1,1,1,1,2,2,2,1,1
62 | 1,9,10,10,1,10,8,3,3,1
63 | 1,6,3,4,1,5,2,3,9,1
64 | 0,1,1,1,1,2,1,2,1,1
65 | 1,10,4,2,1,3,2,4,3,10
66 | 0,4,1,1,1,2,1,3,1,1
67 | 1,5,3,4,1,8,10,4,9,1
68 | 1,8,3,8,3,4,9,8,9,8
69 | 0,1,1,1,1,2,1,3,2,1
70 | 0,5,1,3,1,2,1,2,1,1
71 | 1,6,10,2,8,10,2,7,8,10
72 | 0,1,3,3,2,2,1,7,2,1
73 | 1,9,4,5,10,6,10,4,8,1
74 | 1,10,6,4,1,3,4,3,2,3
75 | 0,1,1,2,1,2,2,4,2,1
76 | 0,1,1,4,1,2,1,2,1,1
77 | 0,5,3,1,2,2,1,2,1,1
78 | 0,3,1,1,1,2,3,3,1,1
79 | 0,2,1,1,1,3,1,2,1,1
80 | 0,2,2,2,1,1,1,7,1,1
81 | 0,4,1,1,2,2,1,2,1,1
82 | 0,5,2,1,1,2,1,3,1,1
83 | 0,3,1,1,1,2,2,7,1,1
84 | 1,3,5,7,8,8,9,7,10,7
85 | 1,5,10,6,1,10,4,4,10,10
86 | 1,3,3,6,4,5,8,4,4,1
87 | 1,3,6,6,6,5,10,6,8,3
88 | 0,4,1,1,1,2,1,3,1,1
89 | 0,2,1,1,2,3,1,2,1,1
90 | 0,1,1,1,1,2,1,3,1,1
91 | 0,3,1,1,2,2,1,1,1,1
92 | 0,4,1,1,1,2,1,3,1,1
93 | 0,1,1,1,1,2,1,2,1,1
94 | 0,2,1,1,1,2,1,3,1,1
95 | 0,1,1,1,1,2,1,3,1,1
96 | 0,2,1,1,2,2,1,1,1,1
97 | 0,5,1,1,1,2,1,3,1,1
98 | 1,9,6,9,2,10,6,2,9,10
99 | 1,7,5,6,10,5,10,7,9,4
100 | 1,10,3,5,1,10,5,3,10,2
101 | 1,2,3,4,4,2,5,2,5,1
102 | 0,4,1,2,1,2,1,3,1,1
103 | 1,8,2,3,1,6,3,7,1,1
104 | 1,10,10,10,10,10,1,8,8,8
105 | 1,7,3,4,4,3,3,3,2,7
106 | 1,10,10,10,8,2,10,4,1,1
107 | 1,1,6,8,10,8,10,5,7,1
108 | 0,1,1,1,1,2,1,2,3,1
109 | 1,6,5,4,4,3,9,7,8,3
110 | 0,1,3,1,2,2,2,5,3,2
111 | 1,8,6,4,3,5,9,3,1,1
112 | 1,10,3,3,10,2,10,7,3,3
113 | 1,10,10,10,3,10,8,8,1,1
114 | 0,3,3,2,1,2,3,3,1,1
115 | 0,1,1,1,1,2,5,1,1,1
116 | 0,8,3,3,1,2,2,3,2,1
117 | 1,4,5,5,10,4,10,7,5,8
118 | 0,1,1,1,1,4,3,1,1,1
119 | 0,3,2,1,1,2,2,3,1,1
120 | 0,1,1,2,2,2,1,3,1,1
121 | 0,4,2,1,1,2,2,3,1,1
122 | 1,10,10,10,2,10,10,5,3,3
123 | 1,5,3,5,1,8,10,5,3,1
124 | 1,5,4,6,7,9,7,8,10,1
125 | 0,1,1,1,1,2,1,2,1,1
126 | 1,7,5,3,7,4,10,7,5,5
127 | 0,3,1,1,1,2,1,3,1,1
128 | 1,8,3,5,4,5,10,1,6,2
129 | 0,1,1,1,1,10,1,1,1,1
130 | 0,5,1,3,1,2,1,2,1,1
131 | 0,2,1,1,1,2,1,3,1,1
132 | 1,5,10,8,10,8,10,3,6,3
133 | 0,3,1,1,1,2,1,2,2,1
134 | 0,3,1,1,1,3,1,2,1,1
135 | 0,5,1,1,1,2,2,3,3,1
136 | 0,4,1,1,1,2,1,2,1,1
137 | 0,3,1,1,1,2,1,1,1,1
138 | 0,4,1,2,1,2,1,2,1,1
139 | 0,3,1,1,1,2,1,1,1,1
140 | 0,2,1,1,1,2,1,1,1,1
141 | 1,9,5,5,4,4,5,4,3,3
142 | 0,1,1,1,1,2,5,1,1,1
143 | 0,2,1,1,1,2,1,2,1,1
144 | 1,3,4,5,2,6,8,4,1,1
145 | 0,1,1,1,1,3,2,2,1,1
146 | 0,3,1,1,3,8,1,5,8,1
147 | 1,8,8,7,4,10,10,7,8,7
148 | 0,1,1,1,1,1,1,3,1,1
149 | 1,7,2,4,1,6,10,5,4,3
150 | 1,10,10,8,6,4,5,8,10,1
151 | 0,4,1,1,1,2,3,1,1,1
152 | 0,1,1,1,1,2,1,1,1,1
153 | 1,5,5,5,6,3,10,3,1,1
154 | 0,1,2,2,1,2,1,2,1,1
155 | 0,2,1,1,1,2,1,3,1,1
156 | 1,9,9,10,3,6,10,7,10,6
157 | 1,10,7,7,4,5,10,5,7,2
158 | 0,4,1,1,1,2,1,3,2,1
159 | 0,3,1,1,1,2,1,3,1,1
160 | 0,1,1,1,2,1,3,1,1,7
161 | 0,4,1,1,1,2,2,3,2,1
162 | 1,5,6,7,8,8,10,3,10,3
163 | 1,10,8,10,10,6,1,3,1,10
164 | 0,3,1,1,1,2,1,3,1,1
165 | 0,1,1,1,2,1,1,1,1,1
166 | 0,3,1,1,1,2,1,1,1,1
167 | 0,1,1,1,1,2,1,3,1,1
168 | 0,1,1,1,1,2,1,2,1,1
169 | 1,6,10,10,10,8,10,10,10,7
170 | 1,8,6,5,4,3,10,6,1,1
171 | 1,5,8,7,7,10,10,5,7,1
172 | 0,2,1,1,1,2,1,3,1,1
173 | 1,5,10,10,3,8,1,5,10,3
174 | 0,4,1,1,1,2,1,3,1,1
175 | 1,5,3,3,3,6,10,3,1,1
176 | 0,1,1,1,1,1,1,3,1,1
177 | 0,1,1,1,1,2,1,1,1,1
178 | 0,6,1,1,1,2,1,3,1,1
179 | 1,5,8,8,8,5,10,7,8,1
180 | 1,8,7,6,4,4,10,5,1,1
181 | 0,2,1,1,1,1,1,3,1,1
182 | 1,1,5,8,6,5,8,7,10,1
183 | 1,10,5,6,10,6,10,7,7,10
184 | 1,5,8,4,10,5,8,9,10,1
185 | 0,1,2,3,1,2,1,3,1,1
186 | 1,10,10,10,8,6,8,7,10,1
187 | 1,7,5,10,10,10,10,4,10,3
188 | 0,5,1,1,1,2,1,2,1,1
189 | 0,1,1,1,1,2,1,3,1,1
190 | 0,3,1,1,1,2,1,3,1,1
191 | 0,4,1,1,1,2,1,3,1,1
192 | 0,8,4,4,5,4,7,7,8,2
193 | 0,5,1,1,4,2,1,3,1,1
194 | 0,1,1,1,1,2,1,1,1,1
195 | 0,3,1,1,1,2,1,2,1,1
196 | 1,9,7,7,5,5,10,7,8,3
197 | 1,10,8,8,4,10,10,8,1,1
198 | 0,1,1,1,1,2,1,3,1,1
199 | 0,5,1,1,1,2,1,3,1,1
200 | 0,1,1,1,1,2,1,3,1,1
201 | 1,5,10,10,9,6,10,7,10,5
202 | 1,10,10,9,3,7,5,3,5,1
203 | 0,1,1,1,1,1,1,3,1,1
204 | 0,1,1,1,1,1,1,3,1,1
205 | 0,5,1,1,1,1,1,3,1,1
206 | 1,8,10,10,10,5,10,8,10,6
207 | 1,8,10,8,8,4,8,7,7,1
208 | 0,1,1,1,1,2,1,3,1,1
209 | 1,10,10,10,10,7,10,7,10,4
210 | 1,10,10,10,10,3,10,10,6,1
211 | 1,8,7,8,7,5,5,5,10,2
212 | 0,1,1,1,1,2,1,2,1,1
213 | 0,1,1,1,1,2,1,3,1,1
214 | 1,6,10,7,7,6,4,8,10,2
215 | 0,6,1,3,1,2,1,3,1,1
216 | 0,1,1,1,2,2,1,3,1,1
217 | 1,10,6,4,3,10,10,9,10,1
218 | 1,4,1,1,3,1,5,2,1,1
219 | 1,7,5,6,3,3,8,7,4,1
220 | 1,10,5,5,6,3,10,7,9,2
221 | 0,1,1,1,1,2,1,2,1,1
222 | 1,10,5,7,4,4,10,8,9,1
223 | 1,8,9,9,5,3,5,7,7,1
224 | 0,1,1,1,1,1,1,3,1,1
225 | 1,10,10,10,3,10,10,9,10,1
226 | 1,7,4,7,4,3,7,7,6,1
227 | 1,6,8,7,5,6,8,8,9,2
228 | 0,8,4,6,3,3,1,4,3,1
229 | 1,10,4,5,5,5,10,4,1,1
230 | 0,3,3,2,1,3,1,3,6,1
231 | 1,10,8,8,2,8,10,4,8,10
232 | 1,9,8,8,5,6,2,4,10,4
233 | 1,8,10,10,8,6,9,3,10,10
234 | 1,10,4,3,2,3,10,5,3,2
235 | 0,5,1,3,3,2,2,2,3,1
236 | 0,3,1,1,3,1,1,3,1,1
237 | 0,2,1,1,1,2,1,3,1,1
238 | 0,1,1,1,1,2,5,5,1,1
239 | 0,1,1,1,1,2,1,3,1,1
240 | 0,5,1,1,2,2,2,3,1,1
241 | 1,8,10,10,8,5,10,7,8,1
242 | 1,8,4,4,1,2,9,3,3,1
243 | 0,4,1,1,1,2,1,3,6,1
244 | 0,1,2,2,1,2,1,1,1,1
245 | 1,10,4,4,10,2,10,5,3,3
246 | 0,6,3,3,5,3,10,3,5,3
247 | 1,6,10,10,2,8,10,7,3,3
248 | 1,9,10,10,1,10,8,3,3,1
249 | 1,5,6,6,2,4,10,3,6,1
250 | 0,3,1,1,1,2,1,1,1,1
251 | 0,3,1,1,1,2,1,2,1,1
252 | 0,3,1,1,1,2,1,3,1,1
253 | 0,5,7,7,1,5,8,3,4,1
254 | 1,10,5,8,10,3,10,5,1,3
255 | 1,5,10,10,6,10,10,10,6,5
256 | 1,8,8,9,4,5,10,7,8,1
257 | 1,10,4,4,10,6,10,5,5,1
258 | 1,7,9,4,10,10,3,5,3,3
259 | 0,5,1,4,1,2,1,3,2,1
260 | 1,10,10,6,3,3,10,4,3,2
261 | 1,3,3,5,2,3,10,7,1,1
262 | 1,10,8,8,2,3,4,8,7,8
263 | 0,1,1,1,1,2,1,3,1,1
264 | 1,8,4,7,1,3,10,3,9,2
265 | 0,5,1,1,1,2,1,3,1,1
266 | 1,3,3,5,2,3,10,7,1,1
267 | 1,7,2,4,1,3,4,3,3,1
268 | 0,3,1,1,1,2,1,3,2,1
269 | 0,3,1,1,1,2,1,2,1,1
270 | 0,1,1,1,1,2,1,2,1,1
271 | 0,1,1,1,1,2,1,3,1,1
272 | 1,10,5,7,3,3,7,3,3,8
273 | 0,3,1,1,1,2,1,3,1,1
274 | 0,2,1,1,2,2,1,3,1,1
275 | 1,1,4,3,10,4,10,5,6,1
276 | 1,10,4,6,1,2,10,5,3,1
277 | 1,7,4,5,10,2,10,3,8,2
278 | 1,8,10,10,10,8,10,10,7,3
279 | 1,10,10,10,10,10,10,4,10,10
280 | 0,3,1,1,1,3,1,2,1,1
281 | 1,6,1,3,1,4,5,5,10,1
282 | 1,5,6,6,8,6,10,4,10,4
283 | 0,1,1,1,1,2,1,1,1,1
284 | 0,1,1,1,1,2,1,3,1,1
285 | 1,10,4,4,6,2,10,2,3,1
286 | 1,5,5,7,8,6,10,7,4,1
287 | 0,5,3,4,3,4,5,4,7,1
288 | 0,8,2,1,1,5,1,1,1,1
289 | 1,9,1,2,6,4,10,7,7,2
290 | 1,8,4,10,5,4,4,7,10,1
291 | 0,1,1,1,1,2,1,3,1,1
292 | 1,10,10,10,7,9,10,7,10,10
293 | 0,1,1,1,1,2,1,3,1,1
294 | 1,8,3,4,9,3,10,3,3,1
295 | 1,10,8,4,4,4,10,3,10,4
296 | 0,1,1,1,1,2,1,3,1,1
297 | 0,1,1,1,1,2,1,3,1,1
298 | 1,7,8,7,6,4,3,8,8,4
299 | 0,3,1,1,1,2,5,5,1,1
300 | 0,2,1,1,1,3,1,2,1,1
301 | 0,1,1,1,1,2,1,1,1,1
302 | 1,8,6,4,10,10,1,3,5,1
303 | 0,1,1,1,1,2,1,1,1,1
304 | 0,1,1,1,1,1,1,2,1,1
305 | 1,5,5,5,2,5,10,4,3,1
306 | 1,6,8,7,8,6,8,8,9,1
307 | 0,1,1,1,1,5,1,3,1,1
308 | 0,4,4,4,4,6,5,7,3,1
309 | 1,7,6,3,2,5,10,7,4,6
310 | 0,3,1,1,1,2,1,3,1,1
311 | 1,5,4,6,10,2,10,4,1,1
312 | 0,1,1,1,1,2,1,3,1,1
313 | 0,3,2,2,1,2,1,2,3,1
314 | 1,10,1,1,1,2,10,5,4,1
315 | 0,1,1,1,1,2,1,2,1,1
316 | 1,8,10,3,2,6,4,3,10,1
317 | 1,10,4,6,4,5,10,7,1,1
318 | 1,10,4,7,2,2,8,6,1,1
319 | 0,5,1,1,1,2,1,3,1,2
320 | 0,5,2,2,2,2,1,2,2,1
321 | 1,5,4,6,6,4,10,4,3,1
322 | 1,8,6,7,3,3,10,3,4,2
323 | 0,1,1,1,1,2,1,1,1,1
324 | 1,6,5,5,8,4,10,3,4,1
325 | 0,1,1,1,1,2,1,3,1,1
326 | 0,1,1,1,1,1,1,2,1,1
327 | 1,8,5,5,5,2,10,4,3,1
328 | 1,10,3,3,1,2,10,7,6,1
329 | 0,1,1,1,1,2,1,3,1,1
330 | 0,2,1,1,1,2,1,1,1,1
331 | 0,1,1,1,1,2,1,1,1,1
332 | 1,7,6,4,8,10,10,9,5,3
333 | 0,1,1,1,1,2,1,1,1,1
334 | 0,5,2,2,2,3,1,1,3,1
335 | 0,1,1,1,1,1,1,1,3,1
336 | 1,3,4,4,10,5,1,3,3,1
337 | 1,4,2,3,5,3,8,7,6,1
338 | 0,5,1,1,3,2,1,1,1,1
339 | 0,2,1,1,1,2,1,3,1,1
340 | 0,3,4,5,3,7,3,4,6,1
341 | 1,2,7,10,10,7,10,4,9,4
342 | 0,1,1,1,1,2,1,2,1,1
343 | 0,4,1,1,1,3,1,2,2,1
344 | 1,5,3,3,1,3,3,3,3,3
345 | 1,8,10,10,7,10,10,7,3,8
346 | 1,8,10,5,3,8,4,4,10,3
347 | 1,10,3,5,4,3,7,3,5,3
348 | 1,6,10,10,10,10,10,8,10,10
349 | 1,3,10,3,10,6,10,5,1,4
350 | 0,3,2,2,1,4,3,2,1,1
351 | 0,4,4,4,2,2,3,2,1,1
352 | 0,2,1,1,1,2,1,3,1,1
353 | 0,2,1,1,1,2,1,2,1,1
354 | 1,6,10,10,10,8,10,7,10,7
355 | 1,5,8,8,10,5,10,8,10,3
356 | 0,1,1,3,1,2,1,1,1,1
357 | 0,1,1,3,1,1,1,2,1,1
358 | 0,4,3,2,1,3,1,2,1,1
359 | 0,1,1,3,1,2,1,1,1,1
360 | 0,4,1,2,1,2,1,2,1,1
361 | 0,5,1,1,2,2,1,2,1,1
362 | 0,3,1,2,1,2,1,2,1,1
363 | 0,1,1,1,1,2,1,1,1,1
364 | 0,1,1,1,1,2,1,2,1,1
365 | 0,1,1,1,1,1,1,2,1,1
366 | 0,3,1,1,4,3,1,2,2,1
367 | 0,5,3,4,1,4,1,3,1,1
368 | 0,1,1,1,1,2,1,1,1,1
369 | 1,10,6,3,6,4,10,7,8,4
370 | 0,3,2,2,2,2,1,3,2,1
371 | 0,2,1,1,1,2,1,1,1,1
372 | 0,2,1,1,1,2,1,1,1,1
373 | 0,3,3,2,2,3,1,1,2,3
374 | 1,7,6,6,3,2,10,7,1,1
375 | 0,5,3,3,2,3,1,3,1,1
376 | 0,2,1,1,1,2,1,2,2,1
377 | 0,5,1,1,1,3,2,2,2,1
378 | 0,1,1,1,2,2,1,2,1,1
379 | 1,10,8,7,4,3,10,7,9,1
380 | 0,3,1,1,1,2,1,2,1,1
381 | 0,1,1,1,1,1,1,1,1,1
382 | 0,1,2,3,1,2,1,2,1,1
383 | 0,3,1,1,1,2,1,2,1,1
384 | 0,3,1,1,1,2,1,3,1,1
385 | 0,4,1,1,1,2,1,1,1,1
386 | 0,3,2,1,1,2,1,2,2,1
387 | 0,1,2,3,1,2,1,1,1,1
388 | 1,3,10,8,7,6,9,9,3,8
389 | 0,3,1,1,1,2,1,1,1,1
390 | 0,5,3,3,1,2,1,2,1,1
391 | 0,3,1,1,1,2,4,1,1,1
392 | 0,1,2,1,3,2,1,1,2,1
393 | 0,1,1,1,1,2,1,2,1,1
394 | 0,4,2,2,1,2,1,2,1,1
395 | 0,1,1,1,1,2,1,2,1,1
396 | 0,2,3,2,2,2,2,3,1,1
397 | 0,3,1,2,1,2,1,2,1,1
398 | 0,1,1,1,1,2,1,2,1,1
399 | 1,10,10,10,6,8,4,8,5,1
400 | 0,5,1,2,1,2,1,3,1,1
401 | 1,8,5,6,2,3,10,6,6,1
402 | 0,3,3,2,6,3,3,3,5,1
403 | 1,8,7,8,5,10,10,7,2,1
404 | 0,1,1,1,1,2,1,2,1,1
405 | 0,5,2,2,2,2,2,3,2,2
406 | 0,2,3,1,1,5,1,1,1,1
407 | 0,3,2,2,3,2,3,3,1,1
408 | 1,10,10,10,7,10,10,8,2,1
409 | 0,4,3,3,1,2,1,3,3,1
410 | 0,5,1,3,1,2,1,2,1,1
411 | 0,3,1,1,1,2,1,1,1,1
412 | 1,9,10,10,10,10,10,10,10,1
413 | 0,5,3,6,1,2,1,1,1,1
414 | 1,8,7,8,2,4,2,5,10,1
415 | 0,1,1,1,1,2,1,2,1,1
416 | 0,2,1,1,1,2,1,2,1,1
417 | 0,1,3,1,1,2,1,2,2,1
418 | 0,5,1,1,3,4,1,3,2,1
419 | 0,5,1,1,1,2,1,2,2,1
420 | 0,3,2,2,3,2,1,1,1,1
421 | 0,6,9,7,5,5,8,4,2,1
422 | 1,10,8,10,1,3,10,5,1,1
423 | 1,10,10,10,1,6,1,2,8,1
424 | 0,4,1,1,1,2,1,1,1,1
425 | 0,4,1,3,3,2,1,1,1,1
426 | 0,5,1,1,1,2,1,1,1,1
427 | 1,10,4,3,10,4,10,10,1,1
428 | 0,5,2,2,4,2,4,1,1,1
429 | 0,1,1,1,3,2,3,1,1,1
430 | 0,1,1,1,1,2,2,1,1,1
431 | 0,5,1,1,6,3,1,2,1,1
432 | 0,2,1,1,1,2,1,1,1,1
433 | 0,1,1,1,1,2,1,1,1,1
434 | 0,5,1,1,1,2,1,1,1,1
435 | 0,1,1,1,1,1,1,1,1,1
436 | 1,5,7,9,8,6,10,8,10,1
437 | 0,4,1,1,3,1,1,2,1,1
438 | 0,5,1,1,1,2,1,1,1,1
439 | 0,3,1,1,3,2,1,1,1,1
440 | 1,4,5,5,8,6,10,10,7,1
441 | 0,2,3,1,1,3,1,1,1,1
442 | 1,10,2,2,1,2,6,1,1,2
443 | 1,10,6,5,8,5,10,8,6,1
444 | 1,8,8,9,6,6,3,10,10,1
445 | 0,5,1,2,1,2,1,1,1,1
446 | 0,5,1,3,1,2,1,1,1,1
447 | 0,5,1,1,3,2,1,1,1,1
448 | 0,3,1,1,1,2,5,1,1,1
449 | 0,6,1,1,3,2,1,1,1,1
450 | 0,4,1,1,1,2,1,1,2,1
451 | 0,4,1,1,1,2,1,1,1,1
452 | 1,10,9,8,7,6,4,7,10,3
453 | 1,10,6,6,2,4,10,9,7,1
454 | 1,6,6,6,5,4,10,7,6,2
455 | 0,4,1,1,1,2,1,1,1,1
456 | 0,1,1,2,1,2,1,2,1,1
457 | 0,3,1,1,1,1,1,2,1,1
458 | 0,6,1,1,3,2,1,1,1,1
459 | 0,6,1,1,1,1,1,1,1,1
460 | 0,4,1,1,1,2,1,1,1,1
461 | 0,5,1,1,1,2,1,1,1,1
462 | 0,3,1,1,1,2,1,1,1,1
463 | 0,4,1,2,1,2,1,1,1,1
464 | 0,4,1,1,1,2,1,1,1,1
465 | 0,5,2,1,1,2,1,1,1,1
466 | 1,4,8,7,10,4,10,7,5,1
467 | 0,5,1,1,1,1,1,1,1,1
468 | 0,5,3,2,4,2,1,1,1,1
469 | 1,9,10,10,10,10,5,10,10,10
470 | 1,8,7,8,5,5,10,9,10,1
471 | 0,5,1,2,1,2,1,1,1,1
472 | 0,1,1,1,3,1,3,1,1,1
473 | 0,3,1,1,1,1,1,2,1,1
474 | 1,10,10,10,10,6,10,8,1,5
475 | 1,3,6,4,10,3,3,3,4,1
476 | 1,6,3,2,1,3,4,4,1,1
477 | 0,1,1,1,1,2,1,1,1,1
478 | 1,5,8,9,4,3,10,7,1,1
479 | 0,4,1,1,1,1,1,2,1,1
480 | 1,5,10,10,10,6,10,6,5,2
481 | 0,5,1,2,10,4,5,2,1,1
482 | 0,3,1,1,1,1,1,2,1,1
483 | 0,1,1,1,1,1,1,1,1,1
484 | 0,4,2,1,1,2,1,1,1,1
485 | 0,4,1,1,1,2,1,2,1,1
486 | 0,4,1,1,1,2,1,2,1,1
487 | 0,6,1,1,1,2,1,3,1,1
488 | 0,4,1,1,1,2,1,2,1,1
489 | 0,4,1,1,2,2,1,2,1,1
490 | 0,4,1,1,1,2,1,3,1,1
491 | 0,1,1,1,1,2,1,1,1,1
492 | 0,3,3,1,1,2,1,1,1,1
493 | 1,8,10,10,10,7,5,4,8,7
494 | 0,1,1,1,1,2,4,1,1,1
495 | 0,5,1,1,1,2,1,1,1,1
496 | 0,2,1,1,1,2,1,1,1,1
497 | 0,1,1,1,1,2,1,1,1,1
498 | 0,5,1,1,1,2,1,2,1,1
499 | 0,5,1,1,1,2,1,1,1,1
500 | 0,3,1,1,1,1,1,2,1,1
501 | 1,6,6,7,10,3,10,8,10,2
502 | 1,4,10,4,7,3,10,9,10,1
503 | 0,1,1,1,1,1,1,1,1,1
504 | 0,1,1,1,1,1,1,2,1,1
505 | 0,3,1,2,2,2,1,1,1,1
506 | 1,4,7,8,3,4,10,9,1,1
507 | 0,1,1,1,1,3,1,1,1,1
508 | 0,4,1,1,1,3,1,1,1,1
509 | 1,10,4,5,4,3,5,7,3,1
510 | 1,7,5,6,10,4,10,5,3,1
511 | 0,3,1,1,1,2,1,2,1,1
512 | 0,3,1,1,2,2,1,1,1,1
513 | 0,4,1,1,1,2,1,1,1,1
514 | 0,4,1,1,1,2,1,3,1,1
515 | 0,6,1,3,2,2,1,1,1,1
516 | 0,4,1,1,1,1,1,2,1,1
517 | 1,7,4,4,3,4,10,6,9,1
518 | 0,4,2,2,1,2,1,2,1,1
519 | 0,1,1,1,1,1,1,3,1,1
520 | 0,3,1,1,1,2,1,2,1,1
521 | 0,2,1,1,1,2,1,2,1,1
522 | 0,1,1,3,2,2,1,3,1,1
523 | 0,5,1,1,1,2,1,3,1,1
524 | 0,5,1,2,1,2,1,3,1,1
525 | 0,4,1,1,1,2,1,2,1,1
526 | 0,6,1,1,1,2,1,2,1,1
527 | 0,5,1,1,1,2,2,2,1,1
528 | 0,3,1,1,1,2,1,1,1,1
529 | 0,5,3,1,1,2,1,1,1,1
530 | 0,4,1,1,1,2,1,2,1,1
531 | 0,2,1,3,2,2,1,2,1,1
532 | 0,5,1,1,1,2,1,2,1,1
533 | 1,6,10,10,10,4,10,7,10,1
534 | 0,2,1,1,1,1,1,1,1,1
535 | 0,3,1,1,1,1,1,1,1,1
536 | 1,7,8,3,7,4,5,7,8,2
537 | 0,3,1,1,1,2,1,2,1,1
538 | 0,1,1,1,1,2,1,3,1,1
539 | 0,3,2,2,2,2,1,4,2,1
540 | 0,4,4,2,1,2,5,2,1,2
541 | 0,3,1,1,1,2,1,1,1,1
542 | 0,4,3,1,1,2,1,4,8,1
543 | 0,5,2,2,2,1,1,2,1,1
544 | 0,5,1,1,3,2,1,1,1,1
545 | 0,2,1,1,1,2,1,2,1,1
546 | 0,5,1,1,1,2,1,2,1,1
547 | 0,5,1,1,1,2,1,3,1,1
548 | 0,5,1,1,1,2,1,3,1,1
549 | 0,1,1,1,1,2,1,3,1,1
550 | 0,3,1,1,1,2,1,2,1,1
551 | 0,4,1,1,1,2,1,3,2,1
552 | 1,5,7,10,10,5,10,10,10,1
553 | 0,3,1,2,1,2,1,3,1,1
554 | 0,4,1,1,1,2,3,2,1,1
555 | 1,8,4,4,1,6,10,2,5,2
556 | 1,10,10,8,10,6,5,10,3,1
557 | 1,8,10,4,4,8,10,8,2,1
558 | 1,7,6,10,5,3,10,9,10,2
559 | 0,3,1,1,1,2,1,2,1,1
560 | 0,1,1,1,1,2,1,2,1,1
561 | 1,10,9,7,3,4,2,7,7,1
562 | 0,5,1,2,1,2,1,3,1,1
563 | 0,5,1,1,1,2,1,2,1,1
564 | 0,1,1,1,1,2,1,2,1,1
565 | 0,1,1,1,1,2,1,2,1,1
566 | 0,1,1,1,1,2,1,3,1,1
567 | 0,5,1,2,1,2,1,2,1,1
568 | 1,5,7,10,6,5,10,7,5,1
569 | 1,6,10,5,5,4,10,6,10,1
570 | 0,3,1,1,1,2,1,1,1,1
571 | 0,5,1,1,6,3,1,1,1,1
572 | 0,1,1,1,1,2,1,1,1,1
573 | 1,8,10,10,10,6,10,10,10,1
574 | 0,5,1,1,1,2,1,2,2,1
575 | 1,9,8,8,9,6,3,4,1,1
576 | 0,5,1,1,1,2,1,1,1,1
577 | 1,4,10,8,5,4,1,10,1,1
578 | 1,2,5,7,6,4,10,7,6,1
579 | 1,10,3,4,5,3,10,4,1,1
580 | 0,5,1,2,1,2,1,1,1,1
581 | 1,4,8,6,3,4,10,7,1,1
582 | 0,5,1,1,1,2,1,2,1,1
583 | 0,4,1,2,1,2,1,2,1,1
584 | 0,5,1,3,1,2,1,3,1,1
585 | 0,3,1,1,1,2,1,2,1,1
586 | 0,5,2,4,1,1,1,1,1,1
587 | 0,3,1,1,1,2,1,2,1,1
588 | 0,1,1,1,1,1,1,2,1,1
589 | 0,4,1,1,1,2,1,2,1,1
590 | 1,5,4,6,8,4,1,8,10,1
591 | 1,5,3,2,8,5,10,8,1,2
592 | 1,10,5,10,3,5,8,7,8,3
593 | 0,4,1,1,2,2,1,1,1,1
594 | 0,1,1,1,1,2,1,1,1,1
595 | 1,5,10,10,10,10,10,10,1,1
596 | 0,5,1,1,1,2,1,1,1,1
597 | 1,10,4,3,10,3,10,7,1,2
598 | 1,5,10,10,10,5,2,8,5,1
599 | 1,8,10,10,10,6,10,10,10,10
600 | 0,2,3,1,1,2,1,2,1,1
601 | 0,2,1,1,1,1,1,2,1,1
602 | 0,4,1,3,1,2,1,2,1,1
603 | 0,3,1,1,1,2,1,2,1,1
604 | 0,4,1,1,1,2,1,2,1,1
605 | 0,5,1,1,1,2,1,2,1,1
606 | 0,3,1,1,1,2,1,2,1,1
607 | 0,6,3,3,3,3,2,6,1,1
608 | 0,7,1,2,3,2,1,2,1,1
609 | 0,1,1,1,1,2,1,1,1,1
610 | 0,5,1,1,2,1,1,2,1,1
611 | 0,3,1,3,1,3,4,1,1,1
612 | 1,4,6,6,5,7,6,7,7,3
613 | 0,2,1,1,1,2,5,1,1,1
614 | 0,2,1,1,1,2,1,1,1,1
615 | 0,4,1,1,1,2,1,1,1,1
616 | 0,6,2,3,1,2,1,1,1,1
617 | 0,5,1,1,1,2,1,2,1,1
618 | 0,1,1,1,1,2,1,1,1,1
619 | 1,8,7,4,4,5,3,5,10,1
620 | 0,3,1,1,1,2,1,1,1,1
621 | 0,3,1,4,1,2,1,1,1,1
622 | 1,10,10,7,8,7,1,10,10,3
623 | 0,4,2,4,3,2,2,2,1,1
624 | 0,4,1,1,1,2,1,1,1,1
625 | 0,5,1,1,3,2,1,1,1,1
626 | 0,4,1,1,3,2,1,1,1,1
627 | 0,3,1,1,1,2,1,2,1,1
628 | 0,3,1,1,1,2,1,2,1,1
629 | 0,1,1,1,1,2,1,1,1,1
630 | 0,2,1,1,1,2,1,1,1,1
631 | 0,3,1,1,1,2,1,2,1,1
632 | 0,1,2,2,1,2,1,1,1,1
633 | 0,1,1,1,3,2,1,1,1,1
634 | 1,5,10,10,10,10,2,10,10,10
635 | 0,3,1,1,1,2,1,2,1,1
636 | 0,3,1,1,2,3,4,1,1,1
637 | 0,1,2,1,3,2,1,2,1,1
638 | 0,5,1,1,1,2,1,2,2,1
639 | 0,4,1,1,1,2,1,2,1,1
640 | 0,3,1,1,1,2,1,3,1,1
641 | 0,3,1,1,1,2,1,2,1,1
642 | 0,5,1,1,1,2,1,2,1,1
643 | 0,5,4,5,1,8,1,3,6,1
644 | 1,7,8,8,7,3,10,7,2,3
645 | 0,1,1,1,1,2,1,1,1,1
646 | 0,1,1,1,1,2,1,2,1,1
647 | 0,4,1,1,1,2,1,3,1,1
648 | 0,1,1,3,1,2,1,2,1,1
649 | 0,1,1,3,1,2,1,2,1,1
650 | 0,3,1,1,3,2,1,2,1,1
651 | 0,1,1,1,1,2,1,1,1,1
652 | 0,5,2,2,2,2,1,1,1,2
653 | 0,3,1,1,1,2,1,3,1,1
654 | 1,5,7,4,1,6,1,7,10,3
655 | 1,5,10,10,8,5,5,7,10,1
656 | 1,3,10,7,8,5,8,7,4,1
657 | 0,3,2,1,2,2,1,3,1,1
658 | 0,2,1,1,1,2,1,3,1,1
659 | 0,5,3,2,1,3,1,1,1,1
660 | 0,1,1,1,1,2,1,2,1,1
661 | 0,4,1,4,1,2,1,1,1,1
662 | 0,1,1,2,1,2,1,2,1,1
663 | 0,5,1,1,1,2,1,1,1,1
664 | 0,1,1,1,1,2,1,1,1,1
665 | 0,2,1,1,1,2,1,1,1,1
666 | 1,10,10,10,10,5,10,10,10,7
667 | 1,5,10,10,10,4,10,5,6,3
668 | 0,5,1,1,1,2,1,3,2,1
669 | 0,1,1,1,1,2,1,1,1,1
670 | 0,1,1,1,1,2,1,1,1,1
671 | 0,1,1,1,1,2,1,1,1,1
672 | 0,1,1,1,1,2,1,1,1,1
673 | 0,3,1,1,1,2,1,2,3,1
674 | 0,4,1,1,1,2,1,1,1,1
675 | 0,1,1,1,1,2,1,1,1,8
676 | 0,1,1,1,3,2,1,1,1,1
677 | 1,5,10,10,5,4,5,4,4,1
678 | 0,3,1,1,1,2,1,1,1,1
679 | 0,3,1,1,1,2,1,2,1,2
680 | 0,3,1,1,1,3,2,1,1,1
681 | 0,2,1,1,1,2,1,1,1,1
682 | 1,5,10,10,3,7,3,8,10,2
683 | 1,4,8,6,4,3,4,10,6,1
684 | 1,4,8,8,5,4,5,10,4,1
685 |
--------------------------------------------------------------------------------
/riskslim/mip.py:
--------------------------------------------------------------------------------
1 | from math import ceil, floor
2 | import numpy as np
3 | from cplex import Cplex, SparsePair, infinity as CPX_INFINITY
4 | from .coefficient_set import CoefficientSet
5 | from .utils import print_log
6 |
7 | #todo: add loss cut
8 | #todo: add constraint function
9 | #todo: default cplex parameters
10 | #todo: check cores
11 | #todo: pass compute_loss to convert_risk_slim_cplex_solution
12 |
13 | def create_risk_slim(coef_set, input):
14 | """
15 | create RiskSLIM MIP object
16 |
17 | Parameters
18 | ----------
19 | input - dictionary of RiskSLIM parameters and formulation
20 |
21 | Returns
22 | -------
23 | mip - RiskSLIM surrogate MIP without 0 cuts
24 |
25 | Issues
26 | ----
27 | no support for non-integer Lset "values"
28 | only drops intercept index for variable_names that match '(Intercept)'
29 |
30 | """
31 | assert isinstance(coef_set, CoefficientSet)
32 | assert isinstance(input, dict)
33 |
34 | # setup printing and loading
35 | function_print_flag = input.get('print_flag', False)
36 | print_from_function = lambda msg: print_log(msg) if function_print_flag else lambda msg: None
37 |
38 | # set default parameters
39 | input.setdefault('w_pos', 1.0)
40 | input.setdefault('w_neg', 2.0 - input['w_pos'])
41 | input.setdefault('C_0', 0.01)
42 | input.setdefault('include_auxillary_variable_for_objval', True)
43 | input.setdefault('include_auxillary_variable_for_L0_norm', True)
44 | input.setdefault('loss_min', 0.00)
45 | input.setdefault('loss_max', float(CPX_INFINITY))
46 | input.setdefault('L0_min', 0)
47 | input.setdefault('L0_max', len(coef_set))
48 | input.setdefault('objval_min', 0.00)
49 | input.setdefault('objval_max', float(CPX_INFINITY))
50 | input.setdefault('relax_integer_variables', False)
51 | input.setdefault('drop_variables', True)
52 | input.setdefault('tight_formulation', False)
53 | input.setdefault('set_cplex_cutoffs', True)
54 |
55 | # variables
56 | P = len(coef_set)
57 | w_pos, w_neg = input['w_pos'], input['w_neg']
58 | C_0j = np.copy(coef_set.c0)
59 | L0_reg_ind = np.isnan(C_0j)
60 | C_0j[L0_reg_ind] = input['C_0']
61 | C_0j = C_0j.tolist()
62 | C_0_rho = np.copy(C_0j)
63 | trivial_L0_min = 0
64 | trivial_L0_max = np.sum(L0_reg_ind)
65 |
66 | rho_ub = list(coef_set.ub)
67 | rho_lb = list(coef_set.lb)
68 | rho_type = ''.join(list(coef_set.vtype))
69 |
70 | # calculate min/max values for loss
71 | loss_min = max(0.0, float(input['loss_min']))
72 | loss_max = min(CPX_INFINITY, float(input['loss_max']))
73 |
74 | # calculate min/max values for model size
75 | L0_min = max(input['L0_min'], 0.0)
76 | L0_max = min(input['L0_max'], trivial_L0_max)
77 | L0_min = ceil(L0_min)
78 | L0_max = floor(L0_max)
79 | assert L0_min <= L0_max
80 |
81 | # calculate min/max values for objval
82 | objval_min = max(input['objval_min'], 0.0)
83 | objval_max = min(input['objval_max'], CPX_INFINITY)
84 | assert objval_min <= objval_max
85 |
86 | # include constraint on min/max model size?
87 | nontrivial_L0_min = L0_min > trivial_L0_min
88 | nontrivial_L0_max = L0_max < trivial_L0_max
89 | include_auxillary_variable_for_L0_norm = input['include_auxillary_variable_for_L0_norm'] or \
90 | nontrivial_L0_min or \
91 | nontrivial_L0_max
92 |
93 | # include constraint on min/max objective value?
94 | nontrivial_objval_min = objval_min > 0.0
95 | nontrivial_objval_max = objval_max < CPX_INFINITY
96 | include_auxillary_variable_for_objval = input['include_auxillary_variable_for_objval'] or \
97 | nontrivial_objval_min or \
98 | nontrivial_objval_max
99 |
100 | has_intercept = '(Intercept)' in coef_set.variable_names
101 | """
102 | RiskSLIM MIP Formulation
103 |
104 | minimize w_pos*loss_pos + w_neg *loss_minus + 0*rho_j + C_0j*alpha_j
105 |
106 | such that
107 |
108 | L0_min ≤ L0 ≤ L0_max
109 | -rho_min * alpha_j < lambda_j < rho_max * alpha_j
110 |
111 | L_0 in 0 to P
112 | rho_j in [rho_min_j, rho_max_j]
113 | alpha_j in {0,1}
114 |
115 | x = [loss_pos, loss_neg, rho_j, alpha_j]
116 |
117 | optional constraints:
118 | objval = w_pos * loss_pos + w_neg * loss_min + sum(C_0j * alpha_j) (required for callback)
119 | L0_norm = sum(alpha_j) (required for callback)
120 |
121 |
122 | Changes for Tight Formulation (included when input['tight_formulation'] = True):
123 |
124 | sigma_j in {0,1} for j s.t. lambda_j has free sign and alpha_j exists
125 | lambda_j ≥ delta_pos_j if alpha_j = 1 and sigma_j = 1
126 | lambda_j ≥ -delta_neg_j if alpha_j = 1 and sigma_j = 0
127 | lambda_j ≥ alpha_j for j such that lambda_j >= 0
128 | lambda_j ≤ -alpha_j for j such that lambda_j <= 0
129 |
130 | """
131 |
132 | # create MIP object
133 | mip = Cplex()
134 | vars = mip.variables
135 | cons = mip.linear_constraints
136 |
137 | # set sense
138 | mip.objective.set_sense(mip.objective.sense.minimize)
139 |
140 | # add main variables
141 | loss_obj = [w_pos]
142 | loss_ub = [loss_max]
143 | loss_lb = [loss_min]
144 | loss_type = 'C'
145 | loss_names = ['loss']
146 |
147 | obj = loss_obj + [0.0] * P + C_0j
148 | ub = loss_ub + rho_ub + [1.0] * P
149 | lb = loss_lb + rho_lb + [0.0] * P
150 | ctype = loss_type + rho_type + 'B' * P
151 |
152 | rho_names = ['rho_%d' % j for j in range(P)]
153 | alpha_names = ['alpha_%d' % j for j in range(P)]
154 | varnames = loss_names + rho_names + alpha_names
155 |
156 | if include_auxillary_variable_for_objval:
157 | objval_auxillary_name = ['objval']
158 | objval_auxillary_ub = [objval_max]
159 | objval_auxillary_lb = [objval_min]
160 | objval_type = 'C'
161 |
162 | print_from_function("adding auxiliary variable for objval s.t. %1.4f <= objval <= %1.4f" % (objval_min, objval_max))
163 | obj += [0.0]
164 | ub += objval_auxillary_ub
165 | lb += objval_auxillary_lb
166 | varnames += objval_auxillary_name
167 | ctype += objval_type
168 |
169 |
170 | if include_auxillary_variable_for_L0_norm:
171 | L0_norm_auxillary_name = ['L0_norm']
172 | L0_norm_auxillary_ub = [L0_max]
173 | L0_norm_auxillary_lb = [L0_min]
174 | L0_norm_type = 'I'
175 |
176 | print_from_function("adding auxiliary variable for L0_norm s.t. %d <= L0_norm <= %d" % (L0_min, L0_max))
177 | obj += [0.0]
178 | ub += L0_norm_auxillary_ub
179 | lb += L0_norm_auxillary_lb
180 | varnames += L0_norm_auxillary_name
181 | ctype += L0_norm_type
182 |
183 | if input['relax_integer_variables']:
184 | ctype = ctype.replace('I', 'C')
185 | ctype = ctype.replace('B', 'C')
186 |
187 | vars.add(obj = obj, lb = lb, ub = ub, types = ctype, names = varnames)
188 |
189 | # 0-Norm LB Constraints:
190 | # lambda_j,lb * alpha_j ≤ lambda_j <= Inf
191 | # 0 ≤ lambda_j - lambda_j,lb * alpha_j < Inf
192 | for j in range(P):
193 | cons.add(names = ["L0_norm_lb_" + str(j)],
194 | lin_expr = [SparsePair(ind=[rho_names[j], alpha_names[j]], val=[1.0, -rho_lb[j]])],
195 | senses = "G",
196 | rhs = [0.0])
197 |
198 | # 0-Norm UB Constraints:
199 | # lambda_j ≤ lambda_j,ub * alpha_j
200 | # 0 <= -lambda_j + lambda_j,ub * alpha_j
201 | for j in range(P):
202 | cons.add(names = ["L0_norm_ub_" + str(j)],
203 | lin_expr =[SparsePair(ind=[rho_names[j], alpha_names[j]], val=[-1.0, rho_ub[j]])],
204 | senses = "G",
205 | rhs = [0.0])
206 |
207 | # objval_max constraint
208 | # loss_var + sum(C_0j .* alpha_j) <= objval_max
209 | if include_auxillary_variable_for_objval:
210 | print_from_function("adding constraint so that objective value <= " + str(objval_max))
211 | cons.add(names = ["objval_def"],
212 | lin_expr = [SparsePair(ind = objval_auxillary_name + loss_names + alpha_names, val=[-1.0] + loss_obj + C_0j)],
213 | senses = "E",
214 | rhs = [0.0])
215 |
216 | # Auxiliary L0_norm variable definition:
217 | # L0_norm = sum(alpha_j)
218 | # L0_norm - sum(alpha_j) = 0
219 | if include_auxillary_variable_for_L0_norm:
220 | cons.add(names = ["L0_norm_def"],
221 | lin_expr = [SparsePair(ind = L0_norm_auxillary_name + alpha_names, val = [1.0] + [-1.0] * P)],
222 | senses = "E",
223 | rhs = [0.0])
224 |
225 |
226 | # drop L0_norm_lb constraint for any variable with rho_lb >= 0
227 | dropped_variables = []
228 | constraints_to_drop = []
229 |
230 | # drop alpha / L0_norm_ub / L0_norm_lb for ('Intercept')
231 | if input['drop_variables']:
232 | # drop L0_norm_ub/lb constraint for any variable with rho_ub/rho_lb >= 0
233 | sign_pos_ind = np.flatnonzero(coef_set.sign > 0)
234 | sign_neg_ind = np.flatnonzero(coef_set.sign < 0)
235 | constraints_to_drop.extend(["L0_norm_lb_" + str(j) for j in sign_pos_ind])
236 | constraints_to_drop.extend(["L0_norm_ub_" + str(j) for j in sign_neg_ind])
237 |
238 | # drop alpha for any variable where rho_ub = rho_lb = 0
239 | fixed_value_ind = np.flatnonzero(coef_set.ub == coef_set.lb)
240 | variables_to_drop = ["alpha_" + str(j) for j in fixed_value_ind]
241 | vars.delete(variables_to_drop)
242 | dropped_variables += variables_to_drop
243 | alpha_names = [alpha_names[j] for j in range(P) if alpha_names[j] not in dropped_variables]
244 |
245 | if has_intercept:
246 | intercept_idx = coef_set.variable_names.index('(Intercept)')
247 | intercept_alpha_name = 'alpha_' + str(intercept_idx)
248 | vars.delete([intercept_alpha_name])
249 |
250 | alpha_names.remove(intercept_alpha_name)
251 | dropped_variables.append(intercept_alpha_name)
252 |
253 | print_from_function("dropped L0 indicator for '(Intercept)'")
254 | constraints_to_drop.extend(["L0_norm_ub_" + str(intercept_idx), "L0_norm_lb_" + str(intercept_idx)])
255 |
256 | if len(constraints_to_drop) > 0:
257 | constraints_to_drop = list(set(constraints_to_drop))
258 | cons.delete(constraints_to_drop)
259 |
260 | # indices
261 | indices = {
262 | 'n_variables': vars.get_num(),
263 | 'n_constraints': cons.get_num(),
264 | 'names': vars.get_names(),
265 | 'loss_names': loss_names,
266 | 'rho_names': rho_names,
267 | 'alpha_names': alpha_names,
268 | 'loss': vars.get_indices(loss_names),
269 | 'rho': vars.get_indices(rho_names),
270 | 'alpha': vars.get_indices(alpha_names),
271 | 'L0_reg_ind': L0_reg_ind,
272 | 'C_0_rho': C_0_rho,
273 | 'C_0_alpha': mip.objective.get_linear(alpha_names) if len(alpha_names) > 0 else [],
274 | }
275 |
276 | if include_auxillary_variable_for_objval:
277 | indices.update({
278 | 'objval_name': objval_auxillary_name,
279 | 'objval': vars.get_indices(objval_auxillary_name)[0],
280 | })
281 |
282 | if include_auxillary_variable_for_L0_norm:
283 | indices.update({
284 | 'L0_norm_name': L0_norm_auxillary_name,
285 | 'L0_norm': vars.get_indices(L0_norm_auxillary_name)[0],
286 | })
287 |
288 | # officially change the problem to LP if variables are relaxed
289 | if input['relax_integer_variables']:
290 | old_problem_type = mip.problem_type[mip.get_problem_type()]
291 | mip.set_problem_type(mip.problem_type.LP)
292 | new_problem_type = mip.problem_type[mip.get_problem_type()]
293 | print_from_function("changed problem type from %s to %s" % (old_problem_type, new_problem_type))
294 |
295 | if input['set_cplex_cutoffs'] and not input['relax_integer_variables']:
296 | mip.parameters.mip.tolerances.lowercutoff.set(objval_min)
297 | mip.parameters.mip.tolerances.uppercutoff.set(objval_max)
298 |
299 | return mip, indices
300 |
301 |
302 | def set_cplex_mip_parameters(cpx, param, display_cplex_progress = False):
303 | """
304 | Helper function to set CPLEX parameters of CPLEX MIP object
305 |
306 | Parameters
307 | ----------
308 | mip
309 | param
310 | display_cplex_progress
311 |
312 | Returns
313 | -------
314 | MIP with parameters
315 |
316 | """
317 | p = cpx.parameters
318 | p.randomseed.set(param['randomseed'])
319 | p.threads.set(param['n_cores'])
320 | p.output.clonelog.set(0)
321 | p.parallel.set(1)
322 |
323 | if display_cplex_progress is (None or False):
324 | cpx = set_cpx_display_options(cpx, display_mip = False, display_lp = False, display_parameters = False)
325 |
326 | problem_type = cpx.problem_type[cpx.get_problem_type()]
327 | if problem_type == 'MIP':
328 | # CPLEX Memory Parameters
329 | # MIP.Param.workdir.Cur = exp_workdir;
330 | # MIP.Param.workmem.Cur = cplex_workingmem;
331 | # MIP.Param.mip.strategy.file.Cur = 2; %nodefile uncompressed
332 | # MIP.Param.mip.limits.treememory.Cur = cplex_nodefilesize;
333 |
334 | # CPLEX MIP Parameters
335 | p.emphasis.mip.set(param['mipemphasis'])
336 | p.mip.tolerances.mipgap.set(param['mipgap'])
337 | p.mip.tolerances.absmipgap.set(param['absmipgap'])
338 | p.mip.tolerances.integrality.set(param['integrality_tolerance'])
339 |
340 | # CPLEX Solution Pool Parameters
341 | p.mip.limits.repairtries.set(param['repairtries'])
342 | p.mip.pool.capacity.set(param['poolsize'])
343 | p.mip.pool.replace.set(param['poolreplace'])
344 | # 0 = replace oldest /1: replace worst objective / #2 = replace least diverse solutions
345 |
346 | return cpx
347 |
348 |
349 | def set_cpx_display_options(cpx, display_mip = True, display_parameters = False, display_lp = False):
350 |
351 | cpx.parameters.mip.display.set(display_mip)
352 | cpx.parameters.simplex.display.set(display_lp)
353 |
354 | try:
355 | cpx.parameters.paramdisplay.set(display_parameters)
356 | except AttributeError:
357 | pass
358 |
359 | if not (display_mip or display_lp):
360 | cpx.set_results_stream(None)
361 | cpx.set_log_stream(None)
362 | cpx.set_error_stream(None)
363 | cpx.set_warning_stream(None)
364 |
365 | return cpx
366 |
367 |
368 | def add_mip_starts(mip, indices, pool, max_mip_starts = float('inf'), mip_start_effort_level = 4):
369 | """
370 |
371 | Parameters
372 | ----------
373 | mip - RiskSLIM surrogate MIP
374 | indices - indices of RiskSLIM surrogate MIP
375 | pool - solution pool
376 | max_mip_starts - max number of mip starts to add (optional; default is add all)
377 | mip_start_effort_level - effort that CPLEX will spend trying to fix (optional; default is 4)
378 |
379 | Returns
380 | -------
381 |
382 | """
383 | # todo remove suboptimal using pool filter
384 | assert isinstance(mip, Cplex)
385 |
386 | try:
387 | obj_cutoff = mip.parameters.mip.tolerances.uppercutoff.get()
388 | except:
389 | obj_cutoff = float('inf')
390 |
391 | pool = pool.distinct().sort()
392 |
393 | n_added = 0
394 | for objval, rho in zip(pool.objvals, pool.solutions):
395 | if np.less_equal(objval, obj_cutoff):
396 | mip_start_name = "mip_start_" + str(n_added)
397 | mip_start_obj, _ = convert_to_risk_slim_cplex_solution(rho = rho, indices = indices, objval = objval)
398 | mip_start_obj = cast_mip_start(mip_start_obj, mip)
399 | mip.MIP_starts.add(mip_start_obj, mip_start_effort_level, mip_start_name)
400 | n_added += 1
401 |
402 | if n_added >= max_mip_starts:
403 | break
404 |
405 | return mip
406 |
407 |
408 | def cast_mip_start(mip_start, cpx):
409 | """
410 | casts the solution values and indices in a Cplex SparsePair
411 |
412 | Parameters
413 | ----------
414 | mip_start cplex SparsePair
415 | cpx Cplex
416 |
417 | Returns
418 | -------
419 | Cplex SparsePair where the indices are integers and the values for each variable match the variable type specified in CPLEX Object
420 | """
421 |
422 | assert isinstance(cpx, Cplex)
423 | assert isinstance(mip_start, SparsePair)
424 | vals = list(mip_start.val)
425 | idx = np.array(list(mip_start.ind), dtype = int).tolist()
426 | types = cpx.variables.get_types(idx)
427 |
428 | for j, t in enumerate(types):
429 | if t in ['B', 'I']:
430 | vals[j] = int(vals[j])
431 | elif t in ['C']:
432 | vals[j] = float(vals[j])
433 |
434 | return SparsePair(ind = idx, val = vals)
435 |
436 |
437 | def convert_to_risk_slim_cplex_solution(rho, indices, loss = None, objval = None):
438 | """
439 | Convert coefficient vector 'rho' into a solution for RiskSLIM CPLEX MIP
440 |
441 | Parameters
442 | ----------
443 | rho
444 | indices
445 | loss
446 | objval
447 |
448 | Returns
449 | -------
450 |
451 | """
452 | global compute_loss
453 | n_variables = indices['n_variables']
454 | solution_idx = np.arange(n_variables)
455 | solution_val = np.zeros(n_variables)
456 |
457 | # rho
458 | solution_val[indices['rho']] = rho
459 |
460 | # alpha
461 | alpha = np.zeros(len(indices['alpha']))
462 | alpha[np.flatnonzero(rho[indices['L0_reg_ind']])] = 1.0
463 | solution_val[indices['alpha']] = alpha
464 | L0_penalty = np.sum(indices['C_0_alpha'] * alpha)
465 |
466 | # add loss / objval
467 | need_loss = 'loss' in indices
468 | need_objective_val = 'objval' in indices
469 | need_L0_norm = 'L0_norm' in indices
470 | need_sigma = 'sigma_names' in indices
471 |
472 | # check that we have the right length
473 | # COMMENT THIS OUT FOR DEPLOYMENT
474 | # if need_sigma:
475 | # pass
476 | # else:
477 | # assert (indices['n_variables'] == (len(rho) + len(alpha) + need_loss + need_objective_val + need_L0_norm))
478 |
479 | if need_loss:
480 | if loss is None:
481 | if objval is None:
482 | loss = compute_loss(rho)
483 | else:
484 | loss = objval - L0_penalty
485 |
486 | solution_val[indices['loss']] = loss
487 |
488 | if need_objective_val:
489 | if objval is None:
490 | if loss is None:
491 | objval = compute_loss(rho) + L0_penalty
492 | else:
493 | objval = loss + L0_penalty
494 |
495 | solution_val[indices['objval']] = objval
496 |
497 | if need_L0_norm:
498 | solution_val[indices['L0_norm']] = np.sum(alpha)
499 |
500 | if need_sigma:
501 | rho_for_sigma = np.array([indices['rho'][int(s.strip('sigma_'))] for s in indices['sigma_names']])
502 | solution_val[indices['sigma']] = np.abs(solution_val[rho_for_sigma])
503 |
504 | solution_cpx = SparsePair(ind = solution_idx, val = solution_val.tolist())
505 | return solution_cpx, objval
506 |
--------------------------------------------------------------------------------
/riskslim/initialization.py:
--------------------------------------------------------------------------------
1 | import time
2 | import numpy as np
3 | from cplex import Cplex, SparsePair, infinity as CPX_INFINITY
4 | from .setup_functions import setup_penalty_parameters
5 | from .mip import create_risk_slim, set_cplex_mip_parameters
6 | from .solution_pool import SolutionPool
7 | from .bound_tightening import chained_updates, chained_updates_for_lp
8 | from .heuristics import discrete_descent, sequential_rounding
9 | from .defaults import DEFAULT_CPA_SETTINGS, DEFAULT_INITIALIZATION_SETTINGS
10 | from .utils import print_log, validate_settings
11 |
12 |
13 | def initialize_lattice_cpa(Z,
14 | c0_value,
15 | constraints,
16 | bounds,
17 | settings,
18 | risk_slim_settings,
19 | cplex_settings,
20 | compute_loss_real,
21 | compute_loss_cut_real,
22 | compute_loss_from_scores_real,
23 | compute_loss_from_scores,
24 | get_objval,
25 | get_L0_penalty,
26 | is_feasible):
27 | """
28 |
29 | Returns
30 | -------
31 | cuts
32 | solution pool
33 | bounds
34 |
35 | """
36 | #todo: recompute function handles here if required
37 | assert callable(compute_loss_real)
38 | assert callable(compute_loss_cut_real)
39 | assert callable(compute_loss_from_scores_real)
40 | assert callable(compute_loss_from_scores)
41 | assert callable(get_objval)
42 | assert callable(get_L0_penalty)
43 | assert callable(is_feasible)
44 |
45 | print_log('-' * 60)
46 | print_log('runnning initialization procedure')
47 | print_log('-' * 60)
48 |
49 | # trade-off parameter
50 | _, C_0, L0_reg_ind, C_0_nnz = setup_penalty_parameters(c0_value = c0_value, coef_set = constraints['coef_set'])
51 |
52 | settings = validate_settings(settings, default_settings = DEFAULT_INITIALIZATION_SETTINGS)
53 | settings['type'] = 'cvx'
54 |
55 | # create RiskSLIM LP
56 | risk_slim_settings = dict(risk_slim_settings)
57 | risk_slim_settings.update(bounds)
58 | risk_slim_settings['relax_integer_variables'] = True
59 | risk_slim_lp, risk_slim_lp_indices = create_risk_slim(coef_set = constraints['coef_set'], input = risk_slim_settings)
60 | risk_slim_lp = set_cplex_mip_parameters(risk_slim_lp, cplex_settings, display_cplex_progress = settings['display_cplex_progress'])
61 |
62 | # solve risk_slim_lp LP using standard CPA
63 | cpa_stats, cuts, cpa_pool = run_standard_cpa(cpx = risk_slim_lp,
64 | cpx_indices = risk_slim_lp_indices,
65 | compute_loss = compute_loss_real,
66 | compute_loss_cut = compute_loss_cut_real,
67 | settings = settings)
68 |
69 | # update bounds
70 | bounds = chained_updates(bounds, C_0_nnz, new_objval_at_relaxation = cpa_stats['lowerbound'])
71 | print_log('CPA produced %d cuts' % len(cuts))
72 |
73 | def rounded_model_size_is_ok(rho):
74 | zero_idx_rho_ceil = np.equal(np.ceil(rho), 0)
75 | zero_idx_rho_floor = np.equal(np.floor(rho), 0)
76 | cannot_round_to_zero = np.logical_not(np.logical_or(zero_idx_rho_ceil, zero_idx_rho_floor))
77 | rounded_rho_L0_min = np.count_nonzero(cannot_round_to_zero[L0_reg_ind])
78 | rounded_rho_L0_max = np.count_nonzero(rho[L0_reg_ind])
79 | return rounded_rho_L0_min >= constraints['L0_min'] and rounded_rho_L0_max <= constraints['L0_max']
80 |
81 | cpa_pool = cpa_pool.remove_infeasible(rounded_model_size_is_ok).distinct().sort()
82 |
83 | if len(cpa_pool) == 0:
84 | print_log('all CPA solutions are infeasible')
85 |
86 | pool = SolutionPool(cpa_pool.P)
87 |
88 | # round CPA solutions
89 | if settings['use_rounding'] and len(cpa_pool) > 0:
90 | print_log('running naive rounding on %d solutions' % len(cpa_pool))
91 | print_log('best objective value: %1.4f' % np.min(cpa_pool.objvals))
92 | rnd_pool, _, _ = round_solution_pool(cpa_pool,
93 | constraints,
94 | max_runtime = settings['rounding_max_runtime'],
95 | max_solutions = settings['rounding_max_solutions'])
96 |
97 | rnd_pool = rnd_pool.compute_objvals(get_objval).remove_infeasible(is_feasible)
98 | print_log('rounding produced %d integer solutions' % len(rnd_pool))
99 | if len(rnd_pool) > 0:
100 | pool.append(rnd_pool)
101 | print_log('best objective value is %1.4f' % np.min(rnd_pool.objvals))
102 |
103 | # sequentially round CPA solutions
104 | if settings['use_sequential_rounding'] and len(cpa_pool) > 0:
105 | print_log('running sequential rounding on %d solutions' % len(cpa_pool))
106 | print_log('best objective value: %1.4f' % np.min(cpa_pool.objvals))
107 | sqrnd_pool, _, _ = sequential_round_solution_pool(pool = cpa_pool,
108 | Z = Z,
109 | C_0 = C_0,
110 | compute_loss_from_scores_real = compute_loss_from_scores_real,
111 | get_L0_penalty = get_L0_penalty,
112 | max_runtime = settings['sequential_rounding_max_runtime'],
113 | max_solutions = settings['sequential_rounding_max_solutions'],
114 | objval_cutoff = bounds['objval_max'])
115 |
116 | sqrnd_pool = sqrnd_pool.remove_infeasible(is_feasible)
117 | print_log('sequential rounding produced %d integer solutions' % len(sqrnd_pool))
118 | if len(sqrnd_pool) > 0:
119 | pool = pool.append(sqrnd_pool)
120 | print_log('best objective value: %1.4f' % np.min(pool.objvals))
121 |
122 | # polish rounded solutions
123 | if settings['polishing_after'] and len(pool) > 0:
124 | print_log('polishing %d solutions' % len(pool))
125 | print_log('best objective value: %1.4f' % np.min(pool.objvals))
126 | dcd_pool, _, _ = discrete_descent_solution_pool(pool = pool,
127 | Z = Z,
128 | C_0 = C_0,
129 | constraints = constraints,
130 | compute_loss_from_scores = compute_loss_from_scores,
131 | get_L0_penalty = get_L0_penalty,
132 | max_runtime = settings['polishing_max_runtime'],
133 | max_solutions = settings['polishing_max_solutions'])
134 |
135 | dcd_pool = dcd_pool.remove_infeasible(is_feasible)
136 | if len(dcd_pool) > 0:
137 | print_log('polishing produced %d integer solutions' % len(dcd_pool))
138 | pool.append(dcd_pool)
139 |
140 | # remove solutions that are not feasible, not integer
141 | if len(pool) > 0:
142 | pool = pool.remove_nonintegral().distinct().sort()
143 |
144 | # update upper and lower bounds
145 | print_log('initialization produced %1.0f feasible solutions' % len(pool))
146 | if len(pool) > 0:
147 | bounds = chained_updates(bounds, C_0_nnz, new_objval_at_feasible = np.min(pool.objvals))
148 | print_log('best objective value: %1.4f' % np.min(pool.objvals))
149 |
150 | print_log('-' * 60)
151 | print_log('completed initialization procedure')
152 | print_log('-' * 60)
153 | return pool, cuts, bounds
154 |
155 |
156 |
157 | def run_standard_cpa(cpx,
158 | cpx_indices,
159 | compute_loss,
160 | compute_loss_cut,
161 | settings = DEFAULT_CPA_SETTINGS,
162 | print_flag = False):
163 |
164 | assert isinstance(cpx, Cplex)
165 | assert isinstance(cpx_indices, dict)
166 | assert callable(compute_loss)
167 | assert callable(compute_loss_cut)
168 | assert isinstance(settings, dict)
169 |
170 | settings = validate_settings(settings, default_settings = DEFAULT_CPA_SETTINGS)
171 |
172 | rho_idx = cpx_indices["rho"]
173 | loss_idx = cpx_indices["loss"]
174 | alpha_idx = cpx_indices["alpha"]
175 | cut_idx = loss_idx + rho_idx
176 | objval_idx = cpx_indices["objval"]
177 | L0_idx = cpx_indices["L0_norm"]
178 |
179 | P = len(cpx_indices["rho"])
180 | C_0_alpha = np.array(cpx_indices['C_0_alpha'])
181 | C_0_nnz = C_0_alpha[np.flatnonzero(C_0_alpha)]
182 |
183 | if isinstance(loss_idx, list) and len(loss_idx) == 1:
184 | loss_idx = loss_idx[0]
185 |
186 | if len(alpha_idx) > 0:
187 | get_alpha = lambda: np.array(cpx.solution.get_values(alpha_idx))
188 | else:
189 | get_alpha = lambda: np.array([])
190 |
191 | bounds = {
192 | 'loss_min': cpx.variables.get_lower_bounds(loss_idx),
193 | 'loss_max': cpx.variables.get_upper_bounds(loss_idx),
194 | 'objval_min': cpx.variables.get_lower_bounds(objval_idx),
195 | 'objval_max': cpx.variables.get_upper_bounds(objval_idx),
196 | 'L0_min': cpx.variables.get_lower_bounds(L0_idx),
197 | 'L0_max': cpx.variables.get_upper_bounds(L0_idx),
198 | }
199 |
200 | if settings['update_bounds'] and settings['type'] == 'cvx':
201 | update_bounds = lambda bounds, lb, ub: chained_updates_for_lp(bounds, C_0_nnz, ub, lb)
202 | elif settings['update_bounds'] and settings['type'] == 'ntree':
203 | update_bounds = lambda bounds, lb, ub: chained_updates(bounds, C_0_nnz, ub, lb)
204 | else:
205 | update_bounds = lambda bounds, lb, ub: bounds
206 |
207 | objval = 0.0
208 | upperbound = CPX_INFINITY
209 | lowerbound = 0.0
210 | n_iterations = 0
211 | n_simplex_iterations = 0
212 | max_runtime = float(settings['max_runtime'])
213 | max_cplex_time = float(settings['max_runtime_per_iteration'])
214 | remaining_total_time = max_runtime
215 | solutions = []
216 | objvals = []
217 |
218 | progress_stats = {
219 | 'upperbounds': [],
220 | 'lowerbounds': [],
221 | 'simplex_iterations': [],
222 | 'cut_times': [],
223 | 'total_times': []
224 | }
225 |
226 | run_start_time = time.time()
227 | while True:
228 |
229 | iteration_start_time = time.time()
230 | cpx.parameters.timelimit.set(min(remaining_total_time, max_cplex_time))
231 | cpx.solve()
232 | solution_status = cpx.solution.status[cpx.solution.get_status()]
233 |
234 | # get solution
235 | if solution_status not in ('optimal', 'optimal_tolerance', 'MIP_optimal'):
236 | stop_reason = solution_status
237 | stop_msg = 'stopping CPA | solution is infeasible (status = %s)' % solution_status
238 | break
239 |
240 | # get solution
241 | rho = np.array(cpx.solution.get_values(rho_idx))
242 | alpha = get_alpha()
243 | simplex_iterations = int(cpx.solution.progress.get_num_iterations())
244 |
245 | # compute cut
246 | cut_start_time = time.time()
247 | loss_value, loss_slope = compute_loss_cut(rho)
248 | cut_lhs = [float(loss_value - loss_slope.dot(rho))]
249 | cut_constraint = [SparsePair(ind = cut_idx, val = [1.0] + (-loss_slope).tolist())]
250 | cut_time = time.time() - cut_start_time
251 |
252 | # compute objective bounds
253 | objval = float(loss_value + alpha.dot(C_0_alpha))
254 | upperbound = min(upperbound, objval)
255 | lowerbound = cpx.solution.get_objective_value()
256 | relative_gap = (upperbound - lowerbound)/(upperbound + np.finfo('float').eps)
257 | bounds = update_bounds(bounds, lb = lowerbound, ub = upperbound)
258 |
259 | #store solutions
260 | solutions.append(rho)
261 | objvals.append(objval)
262 |
263 | # update run stats
264 | n_iterations += 1
265 | n_simplex_iterations += simplex_iterations
266 | current_time = time.time()
267 | total_time = current_time - run_start_time
268 | iteration_time = current_time - iteration_start_time
269 | remaining_total_time = max(max_runtime - total_time, 0.0)
270 |
271 | # print progress
272 | if print_flag and settings['display_progress']:
273 | print_log("cuts = %d \t UB = %.4f \t LB = %.4f \t GAP = %.4f%%\n" % (n_iterations, upperbound, lowerbound, 100.0 * relative_gap))
274 |
275 | # save progress
276 | if settings['save_progress']:
277 | progress_stats['upperbounds'].append(upperbound)
278 | progress_stats['lowerbounds'].append(lowerbound)
279 | progress_stats['total_times'].append(total_time)
280 | progress_stats['cut_times'].append(cut_time)
281 | progress_stats['simplex_iterations'].append(simplex_iterations)
282 |
283 | # check termination conditions
284 | if n_iterations >= settings['max_iterations']:
285 | stop_reason = 'aborted:reached_max_cuts'
286 | stop_msg = 'reached max iterations'
287 | break
288 |
289 | if n_iterations >= settings['min_iterations_before_coefficient_gap_check']:
290 | prior_rho = solutions[-2]
291 | coef_gap = np.abs(np.max(rho - prior_rho))
292 | if np.all(np.round(rho) == np.round(prior_rho)) and coef_gap < settings['max_coefficient_gap']:
293 | stop_reason = 'aborted:coefficient_gap_within_tolerance'
294 | stop_msg = 'stopping CPA | coef gap is within tolerance (%1.4f < %1.4f)' % (coef_gap, settings['max_coefficient_gap'])
295 | break
296 |
297 | if relative_gap < settings['max_tolerance']:
298 | stop_reason = 'converged:gap_within_tolerance'
299 | stop_msg = 'stopping CPA | optimality gap is within tolerance (%1.1f%% < %1.1f%%)' % (100 * settings['max_tolerance'], 100 * relative_gap)
300 | break
301 |
302 | if iteration_time > settings['max_runtime_per_iteration']:
303 | stop_reason = 'aborted:reached_max_train_time'
304 | stop_msg = 'stopping CPA (reached max training time per iteration of %1.0f secs)' % settings['max_runtime_per_iteration']
305 | break
306 |
307 | if (total_time > settings['max_runtime']) or (remaining_total_time == 0.0):
308 | stop_reason = 'aborted:reached_max_train_time'
309 | stop_msg = 'stopping CPA (reached max training time of %1.0f secs)' % settings['max_runtime']
310 | break
311 |
312 | # switch bounds
313 | if settings['update_bounds']:
314 | cpx.variables.set_lower_bounds(L0_idx, bounds['L0_min'])
315 | cpx.variables.set_upper_bounds(L0_idx, bounds['L0_max'])
316 | cpx.variables.set_lower_bounds(loss_idx, bounds['loss_min'])
317 | cpx.variables.set_upper_bounds(loss_idx, bounds['loss_max'])
318 | cpx.variables.set_lower_bounds(objval_idx, bounds['objval_min'])
319 | cpx.variables.set_upper_bounds(objval_idx, bounds['objval_max'])
320 |
321 | # add loss cut
322 | cpx.linear_constraints.add(lin_expr = cut_constraint, senses = ["G"], rhs = cut_lhs)
323 |
324 | if print_flag:
325 | print_log(stop_msg)
326 |
327 | #collect stats
328 | stats = {
329 | 'solution': rho,
330 | 'stop_reason': stop_reason,
331 | 'n_iterations': n_iterations,
332 | 'n_simplex_iterations': n_simplex_iterations,
333 | 'objval': objval,
334 | 'upperbound': upperbound,
335 | 'lowerbound': lowerbound,
336 | 'cut_time': cut_time,
337 | 'total_time': total_time,
338 | 'cplex_time': total_time - cut_time,
339 | }
340 |
341 | stats.update(bounds)
342 | if settings['save_progress']:
343 | progress_stats['cplex_times'] = (np.array(stats['total_times']) - np.array(stats['cut_times'])).tolist()
344 | progress_stats['objvals'] = objvals
345 | progress_stats['solutions'] = solutions
346 | stats.update(progress_stats)
347 |
348 | #collect cuts
349 | idx = list(range(cpx_indices['n_constraints'], cpx.linear_constraints.get_num(), 1))
350 | cuts = {
351 | 'coefs': cpx.linear_constraints.get_rows(idx),
352 | 'lhs': cpx.linear_constraints.get_rhs(idx)
353 | }
354 |
355 | #create solution pool
356 | pool = SolutionPool(P)
357 | if len(objvals) > 0:
358 | pool.add(objvals, solutions)
359 |
360 | return stats, cuts, pool
361 |
362 |
363 |
364 | def round_solution_pool(pool,
365 | constraints,
366 | max_runtime = float('inf'),
367 | max_solutions = float('inf')):
368 | """
369 |
370 | Parameters
371 | ----------
372 | pool
373 | constraints
374 | max_runtime
375 | max_solutions
376 |
377 | Returns
378 | -------
379 |
380 | """
381 | # quick return
382 | if len(pool) == 0:
383 | return pool
384 |
385 | pool = pool.distinct().sort()
386 | P = pool.P
387 | L0_reg_ind = np.isnan(constraints['coef_set'].c0)
388 | L0_max = constraints['L0_max']
389 |
390 |
391 | total_runtime = 0.0
392 | total_rounded = 0
393 | rounded_pool = SolutionPool(P)
394 |
395 | for rho in pool.solutions:
396 |
397 | start_time = time.time()
398 | # sort from largest to smallest coefficients
399 | feature_order = np.argsort([-abs(x) for x in rho])
400 | rounded_solution = np.zeros(shape = (1, P))
401 | l0_norm_count = 0
402 |
403 | for k in range(P):
404 | j = feature_order[k]
405 | if not L0_reg_ind[j]:
406 | rounded_solution[0, j] = np.round(rho[j], 0)
407 | elif l0_norm_count < L0_max:
408 | rounded_solution[0, j] = np.round(rho[j], 0)
409 | l0_norm_count += L0_reg_ind[j]
410 |
411 | total_runtime += time.time() - start_time
412 | total_rounded += 1
413 | rounded_pool.add(objvals = np.nan, solutions = rounded_solution)
414 |
415 | if total_runtime > max_runtime or total_rounded >= max_solutions:
416 | break
417 |
418 | rounded_pool = rounded_pool.distinct().sort()
419 | return rounded_pool, total_runtime, total_rounded
420 |
421 |
422 | def sequential_round_solution_pool(pool,
423 | Z,
424 | C_0,
425 | compute_loss_from_scores_real,
426 | get_L0_penalty,
427 | max_runtime = float('inf'),
428 | max_solutions = float('inf'),
429 | objval_cutoff = float('inf')):
430 |
431 | """
432 | runs sequential rounding for all solutions in a solution pool
433 | can be stopped early using max_runtime or max_solutions
434 |
435 | Parameters
436 | ----------
437 | pool
438 | Z
439 | C_0
440 | compute_loss_from_scores_real
441 | get_L0_penalty
442 | max_runtime
443 | max_solutions
444 | objval_cutoff
445 | L0_min
446 | L0_max
447 |
448 | Returns
449 | -------
450 |
451 | """
452 | # quick return
453 | if len(pool) == 0:
454 | return pool, 0.0, 0
455 |
456 | assert callable(get_L0_penalty)
457 | assert callable(compute_loss_from_scores_real)
458 |
459 | # if model size constraint is non-trivial, remove solutions that violate the model size constraint beforehand
460 | pool = pool.distinct().sort()
461 | rounding_handle = lambda rho: sequential_rounding(rho = rho,
462 | Z = Z,
463 | C_0 = C_0,
464 | compute_loss_from_scores_real = compute_loss_from_scores_real,
465 | get_L0_penalty = get_L0_penalty,
466 | objval_cutoff = objval_cutoff)
467 |
468 |
469 | # apply sequential rounding to all solutions
470 | total_runtime = 0.0
471 | total_rounded = 0
472 | rounded_pool = SolutionPool(pool.P)
473 |
474 | for rho in pool.solutions:
475 |
476 | start_time = time.time()
477 | solution, objval, early_stop = rounding_handle(rho)
478 | total_runtime += time.time() - start_time
479 | total_rounded += 1
480 |
481 | if not early_stop:
482 | rounded_pool = rounded_pool.add(objvals = objval, solutions = solution)
483 |
484 | if total_runtime > max_runtime or total_rounded > max_solutions:
485 | break
486 |
487 | rounded_pool = rounded_pool.distinct().sort()
488 | return rounded_pool, total_runtime, total_rounded
489 |
490 |
491 | def discrete_descent_solution_pool(pool,
492 | Z,
493 | C_0,
494 | constraints,
495 | get_L0_penalty,
496 | compute_loss_from_scores,
497 | max_runtime = float('inf'),
498 | max_solutions = float('inf')):
499 | """
500 |
501 | runs dcd polishing for all solutions in a solution pool
502 | can be stopped early using max_runtime or max_solutions
503 |
504 |
505 | Parameters
506 | ----------
507 | pool
508 | Z
509 | C_0
510 | constraints
511 | get_L0_penalty
512 | compute_loss_from_scores
513 | max_runtime
514 | max_solutions
515 |
516 | Returns
517 | -------
518 |
519 | """
520 |
521 | pool = pool.remove_nonintegral()
522 | if len(pool) == 0:
523 | return pool, 0.0, 0
524 |
525 | assert callable(get_L0_penalty)
526 | assert callable(compute_loss_from_scores)
527 |
528 | rho_ub = constraints['coef_set'].ub
529 | rho_lb = constraints['coef_set'].lb
530 |
531 | polishing_handle = lambda rho: discrete_descent(rho,
532 | Z = Z,
533 | C_0 = C_0,
534 | rho_ub = rho_ub,
535 | rho_lb = rho_lb,
536 | get_L0_penalty = get_L0_penalty,
537 | compute_loss_from_scores = compute_loss_from_scores)
538 | pool = pool.distinct().sort()
539 |
540 | polished_pool = SolutionPool(pool.P)
541 | total_runtime = 0.0
542 | total_polished = 0
543 | start_time = time.time()
544 | for rho in pool.solutions:
545 | polished_solution, _, polished_objval = polishing_handle(rho)
546 | total_runtime = time.time() - start_time
547 | total_polished += 1
548 | polished_pool = polished_pool.add(objvals = polished_objval, solutions = polished_solution)
549 | if total_runtime > max_runtime or total_polished >= max_solutions:
550 | break
551 |
552 | polished_pool = polished_pool.distinct().sort()
553 | return polished_pool, total_runtime, total_polished
554 |
--------------------------------------------------------------------------------
